1 INTRODUCTION
1.1 General
The SP-03V2 Elderly Care Telephone by Rosslare Enterprises, Ltd. is the
ideal wireless security system for home or small office providing
intrusion protection. The SP-03V2 Elderly Care Telephone is also the
wireless panel used to control, program and operate the security
monitoring and IVR (Interactive Voice Response) messaging, with all
of the regular features of a home telephone.
The SP-03V2 Elderly Care Telephone uses the latest RF technology
and enables the smooth and easy operation of a large number of
security and communication options.
The SP-03V2 panel is easy to install and set up via local programming
and via a direct or modem connection to a PC, running the SP-03V2
PC Software.
The Panel has two full split reporting features for communicating to
central station for Contact ID + 2-Way Voice Enabled event
reporting and vocal communications.
1.2 Special F eatures
• Five Custom textual and recordable zone descriptions
• Advanced testing and diagnostics options
• Programmable remote-control buttons
• 16 wireless zones
• Programmable No Activity timer
• Interactive Voice menus for private phones
• Full Duplex 2-way voice with private phone reporting
• USB port for local PC connection*
• TCP/IP port for internet based reporting and programming with
automatic detection and configuration of TCP/IP connection.
• 8 programmable Pill reminders
*available in next release
SP-03V2 OVERVIEW
SP-03V2 Installation Manu al
Page 7
2 SP-03V2 OVERVIEW
This section provides a description of the control panel and the
keypad. In addition, it also describes the chimes emitted when the
buttons on the keypad are pressed.
2.1 The Panel
Figure 1: SP-03V2 Front View
SP-03V2 OVERVIEW
SP-03V2 Installation Manu al
Page 8
Key
Icon
Action
number to
2.2 The Keypad
This chapter describes the keypad buttons and functions.
2.2.1 General
Emergency
Disarm /
Cancel
Arm (Away) /
Redial
Arm (Home) /
Flash
Alphanumeric
keys 1-9
Initiates an emergency
call
Disarms the system
when armed (requires
code)
Cancels emergency
calls and actions
Arms the system in
Away mode (requires
Code)
Redials last called
phone number in
telephone mode
Arms the system in
home mode (requires
code)
Numeric Entry (keys 1-9)
Initiate/edit a
dial or quick dial
Add an alphanumeric
character (keys 2-9)
0 Key
Numeric entry
initiating/editing a
number to dial or quick
dial.
Trouble Display
SP-03V2 OVERVIEW
SP-03V2 Installation Manu al
Page 9
Key
Icon
Action
# Key
Þ Key
Menu / Up
Quick Dial /
Speaker
Volume
Clears Access Code
Clears last entered digit
in Phone Number /
Numeric Value during
editing
Dials '#' during Manual
Call
Enters a comma ',' as a
Dialing Delay in Phone
Number (during editing)
Dials '*' during Manual
Call
Access the various
Menus.
Up – In the menus
Down
2.2.2 Q uick Dial Number s
The SP-03V2 unit allows storage of 10 memorized telephone numbers
with an alphanumeric name of up to 16 characters.
Entering, modifying or deleting quick-dial numbers is allowed under
Master code access.
The Quick Dial button must be pressed to activate this option.
Enter Quick Dial mode
Down – In the menus
Activates / Deactivates
speaker, Line On / Off
Increase/decrease
call/system volume
Yes/No (same as
Enter/Cancel)
SP-03V2 OVERVIEW
SP-03V2 Installation Manu al
Page 10
Quick Dial
Number
Behavior
UP or DOWN
Sound
Sounded when
Four short
minute
LED
Behavior
on when the system is armed and blinking
0 to 9
Indicates the quick-dial number to call.
Initiates a menu for displaying and selecting the
required number.
2.3 Sound Indicators
Following are the sounds emitted by the system and push buttons:
Single beep
Long beep
beeps a
Short beep
every second
Chime
A key is pressed
An attempt is made to enter an invalid or
unacceptable entry
If enabled, on trouble condition.
An exit/entry delay is activated.
Beep sounded every 0.5 seconds during last 10
seconds of delay.
Activated (if enabled). Three programmable
chime types available
2.4 LED Indicators
This section describes the status and communication LED indicators.
Status LED
Communication
LED
Red
while the system is arming.
Green ON when the phone line, Modem or
TCP/IP Channel are active.
SPECIFICATIONS
SP-03V2 Installation Manu al
Page 11
RF Data
Receiver
Sensitivity
Environme ntal Data
Operating Temperature
Storage Temperature
Relative Humidity
Dimensions
3 SPECIFICATIONS
RF Unit Type
Antenna Type
Operating
Frequencies
Transmitter
Power
Range
(open field)
RF Device ID
Coding
The SP-03V2 system has optimum range if installed according to the
manufacturer’s recommendations, however it may be affected by
radio noise from nearby high-power sources, or signal interference
(blocking) by large metal surfaces or multiple concrete walls.
Integrated RF transceiver (two-way) shielded
super heterodyne, fixed frequency
Printed PCB type antenna
433.92 MHz G series
868.35 MHz H series
Up to -68 dBm
Up to +10 dBm, less based on country
requirements
Up to 250 m in open space for detectors, and 110
m for hand-held remote controls
Three-bytes non-replicated per sensor type, or
multiples of 16 million possible codes, make it
almost impossible to have two like coded
transmitters
L x W x D
Weight
0º – 60º C (32º F - 140º F)
-25 º – 70º C (-13º F - 158º F)
85% at 30º C Non condensing
220 x 140 x 48 mm
8.7 x 5.5 x 1.9 inch
595 gr. (1.3 lbs.)
SP-03V2 Installation Manu al
Page 12
Electrica l Data
Display
Local siren
External Power Supply
Current Consumption
Internal Backup
Battery
Communication
RF Jamming Detection
Programmable NoActivity Timer
Two CRM Numbers
Reporting Protocols
Three Private
USB V2.0
Ethernet RJ-45 Por t
Telephone Line-In and
and Accounts
SPECIFICATIONS
2 Lines of 16 characters, backlit LCD
87 dbA
13.8 V DC; 800mA
Standby - 120 mA
Maximum - 500 mA
800 mAh for 6 hours standby,
2 hours full alarm
UL / EN selectable
1-30 minutes, per zone
Primary only, Secondary only, Alternate,
Both or Disable Modes
Contact ID + Contact ID over IP
Telephone Numbers
Line-Out
*available in next release
Voice reporting and two-way voice
communications
Local PC programming connection *
Remote PC programming and
monitoring on LAN or WAN connections
featuring line seizure in case of phone
use during alarm
INSTALLATION
SP-03V2 Installation Manu al
Page 13
Need new
4 INSTALLATION
4.1 Unpacking the Equipment
The contents of your package are listed below.
First, make sure that all the items in the kit have been included.
If you find that any item is missing, contact your dealer immediately.
SP-03V2 Elderly Phone package content
• One SP-03V2 Elderly Care Telephone - Wireless Emergency System
• One Handset
• One Handset cord
• O n e AC-DC power adapter
• One Telephone cord.
• One Rechargeable lead-acid battery
4.2 Getting to Know the SP-03V2
The SP-03V2 resembles an intelligent telephone set with a
speakerphone and a handset; however, it has several additional
keys, which are used for programming the system as detailed in the
SP-03V2 OVERVIEW, on page 7.
4.3 Planning the Installation
The tables located in Appendix A. through Appendix D. on page
51, to 54 can assist you to plan and register the location of each
detector. Mark the transmitters and detectors in the supplied tables
accordingly.
4.4 Installing the Backup Battery
The battery is installed by opening the battery door located on the
bottom of the SP-03V2. Turn the SP-03V2 over to see the battery door.
To install the Backup Battery:
1. Remove the screw that secures the battery door; use a small
Phillips head screwdriver and turn the screw counterclockwise.
INSTALLATION
SP-03V2 Installation Manu al
Page 14
Figure 2: Rear of SP-03V2 Showing Battery Door
2. Carefully insert a flat screwdriver in the slot under the screw-hole
tab, and twist to lift the tab off the main housing. Alternatively,
you may use your finger to pull off the battery lid.
Note:
Be particularly careful not to lose the screw, or damage the
battery door unit.
Do not try to remove the battery door from the catches without
removing the screw, and do not over tighten the screw
3. Inside the battery compartment, you will see a battery
connector on the PSB.
Figure 3: Battery Compartment Interior
INSTALLATION
SP-03V2 Installation Manu al
Page 15
4. Connect the rechargeable battery by connecting the wire block
as shown in Figure 3, on page 14. Once connected, slide the
battery into the compartment and replace the lid, and the
screw.
4.5 Connecting the Power, Telepho ne Li ne and Ethernet
The SP-03V2 utilizes a standard AC/DC adapter and uses the
standard RJ-11 phone wire.
To Connect the Phone Line and Ethernet:
1. Plug one end of the RJ-11 telephone cable to the Line-In phone
jack of the SP-03V2.
2. Plug the other end to the wall phone jack.
3. Connect the SP-03V2’s Line-Out phone jack to the rest of the
house.
4. Plug the RJ-45 Ethernet cable to the Ethernet jack of the SP-03V2.
5. Plug the other end to the Ethernet socket in the wall or to the
local Ethernet connection.
To Connect the Power:
1. Connect AC adapter jack into the socket (marked “13.8V DC”)
ensure that the (rounded) rectangular protrusion is horizontal.
2. Twist the jack clockwise by 90 degrees to lock in place.
3. Verify that the input marked on the AC to DC converter
corresponds to your mains voltage.
4. Plug the converter into an electric outlet.
5. Verify that the SP-03V2’s display is on.
6. The system will automatically detect and configure the Ethernet
connection. If the connection is established an arrow will appear
in the top right corner, if the Ethernet cable is disconnected, no
indication will appear. If the Ethernet cable is connected but the
system could not initialize the TCP/IP configuration, an X will
appear.
7. Lift the handset and verify the presence of a dial tone.
PROGRAMMING
SP-03V2 Installation Manu al
Page 16
5 PROGRAMMING
5.1 Overview
SP-03V2 must be programmed after installation. You can use the
backup battery or the AC power supply as operating power while
programming.
SP-03V2 is provided with two default codes:
• Default installer code: 8888 – Enables you to program SP-03V2
• Default Master code: 1234 – Enables you to change the master
code and modify the User and Master options
We recommend that you change the master and installer codes
after using them for the first time.
5.2 Installer M enu
The Installer’s menu enables access to the following group of
options:
• Change (installer) code
• Zones
• Enrolling
• Security
• Communications
• Messages
• Maintenance
• Select Language
To Enter the Installer Menu:
1. Press Menu until the screen displays Installer Menu.
2. Press Enter.
3. Enter the installer code; the default code is 8888.
4. Once in the INSTALLER
scroll the sub menus. Press Enter to access the desired sub menu
as detailed below.
MENU use the Up and Down buttons to
PROGRAMMING
SP-03V2 Installation Manu al
Page 17
5.2.1 Change Code
This option enables you to change the installer code with which you
enter the system. The default code is 8888.
To change the Installer Code:
1. Access the Installer menu as explained on page 16.
2. Use the Up and Down buttons to locate the CHANGE
CODE
submenu. Press the Enter button to access the submenu
3. Type a new four-digit installer code and press Enter to save your
new code.
5.2.2 Zone Options
This menu allows you to define each of the 16 available zones. You
can define the zone type, description, activity type and it’s audible
chime indication.
To specify Zone Behavior and Options:
1. Access the Installer menu as explained on page 16.
2. Use the Up and Down button to locate the Z
Press the Enter button to access the submenu.
3. Select the required zone by either browsing all 16 using the Up
and Down buttons and confirm with Enter or by entering the zone
number, using the numeric keypad.
4. Once in the desired zone, use the Up and Down buttons to
browse the options, press Enter to access the desired sub menu in
order to define several characteristics as follows:
• Zone Type; select one of the following:
o Interior
o Perimeter
o Delay
o Fire
o 24 Hour
Silent
• Description; select one of the fixed descriptions or one of the
five (5) editable custom descriptions.
• Chime; select one of three chimes, or chime off. By default,
zone is
• No Activity; select E
D
CHIME OFF.
NABLE or DISABLE, By default the option is
ISABLE
ONES submenu.
o 24 Hour
Audible
o Chime
PROGRAMMING
SP-03V2 Installation Manu al
Page 18
5.2.3 Enrolling Wireless Devices and Remote Controls
You can enroll up to sixteen (16) detectors, eight (8) remote controls,
four (4) remote sirens, four (4) keypads, and four (4) repeaters. The
enrollment process can also be done via the software, refer to the
software manual for further details.
Before enrolling wireless devices, the installer should determine
whether the working frequency of the wireless devices is H (868 MHz)
or G (433 MHz). The installer should also be sure that all of these
wireless devices contain the appropriate batteries.
To Enroll a Wireless Device or Remote Control:
1. Access the Installer menu as explained on page 16.
2. Use the Up and Down buttons to locate the E
Press the Enter button to access the submenu.
3. Select a group of wireless devices:
SIRENS
, KEYPADS, or REPEATERS.
DETECTORS, REMOTE CONTROLS, R.
4. Choose the device number to enroll within the selected device
group.
5. If a device exists, the system will display the following message:
Enter to Delete. To replace the device with a new device, press
Enter to delete, and continue with Step 4, above.
6. If a device does not exist, the system will display the following
message: Waiting for Signal. The system will wait for an event to
be sent from a wireless device (e.g., Tamper, Alarm).
7. If the system receives an event from any wireless device, the
system will provide an audible acknowledgement of receipt, and
will display the following message: Enter to Store.
8. After you press Enter, the system will be ready to enroll the next
wireless device.
NROLLING submenu.
Loading...
