Rosslare Mifare CP-R25, Mifare AS-B01 Hardware And Software Manual

2012 March

CP-R25 & AS-B01

Mifare® Card Programmer/Fingerprint Swipe Enrollment Station and Software

Hardware and Software Manual

This manual and the information contained herein are proprietary to REL, RSP Inc. and/or their related companies and/or subsidiaries’ (hereafter:”ROSSLARE”). Only ROSSLARE and its customers have the right to use the information.

No part of this manual may be re-produced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of ROSSLARE.

ROSSLARE owns patents and patent applications, trademarks, copyrights, or other intellectual property rights covering the subject matter in this manual.

TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL PROCEEDINGS.

The furnishing of this manual to any party does not give that party or any third party any license to these patents, trademarks, copyrights or other intellectual property rights, except as expressly provided in any written agreement of ROSSLARE.

ROSSLARE reserves the right to revise and change this document at any time, without being obliged to announce such revisions or changes beforehand or after the fact.

Table of Contents

1. Introduction ....................................................................... 8

1.1 The CP-R25 System ............................................................................. 8

1.2 Desktop Convenience ......................................................................... 8

1.3 Intuitive Software System .................................................................... 8

1.4 Compatibility ...................................................................................... 9

1.5 Main Features ..................................................................................... 9

1.6 CP-R25 Desktop Programmer .............................................................. 9

1.7 AS-B01 Software ................................................................................ 9

2. Specifications and Requirements .................................. 10

2.1 CP-R25 Hardware Specifications ....................................................... 10

2.2 AS-B01 Software Requirements ........................................................ 11

3. Installation ...................................................................... 12

3.1 Unpacking the Equipment................................................................. 12

3.2 CP-R25 Description ........................................................................... 12

3.3 AS-B01 Software Installation ............................................................. 12

3.4 Connecting the CP-R25 .................................................................... 15

4. AS-B01 Software Overview and LEDs ........................... 18

4.1 Software Overview ........................................................................... 18

4.2 Indication LEDs ................................................................................. 19

5. Programming Cards and Tags ........................................ 21

5.1 Programming a Master Card ............................................................. 23

5.2 Programming a Configuration Card .................................................. 23

5.2.1 Sector Reader Configuration Cards ............................................................ 24

5.2.2 Fingerprint Swipe Reader Configuration Cards ............................................ 25

5.3 Programming User Cards or Tags ...................................................... 26

5.3.1 Programming a Sector Reader User Card .................................................... 26

5.3.2 Programming and Enrolling Fingerprint User Card ....................................... 27

CP-R25 Hardware and AS-B01 Software Manual iii

Table of Contents

6. Additional Programmer Utilities ................................... 30

6.1 Card Utilities ..................................................................................... 30

6.1.1 Reading a Configuration Card .................................................................... 30

6.1.2 Reading an ID from a User Card ................................................................. 31

6.1.3 Programming a User Card ID ...................................................................... 31

6.1.4 Changing the User Card KeyA in a Specific Sector ...................................... 32

6.1.5 Changing the User Card KeyA in All Sectors ............................................... 33

6.1.6 Erasing Specific User Card Data .................................................................. 34

6.1.7 Read Serial Number and Card Type ............................................................ 35

6.1.8 Changing KeyA and Erasing All Data .......................................................... 35

6.2 Fingerprint Utilities ............................................................................ 36

6.2.1 Enrolling Fingerprints on a Pre-configured User Card .................................. 36

6.2.2 Verifying Fingerprint Enrollment on a User Card.......................................... 37

7. Global Options ................................................................ 39

7.1 Change Password ............................................................................. 39

7.2 Card Overwrite ................................................................................. 39

7.3 Updating Firmware ........................................................................... 40

A. Maintenance .................................................................... 42

B. Field Descriptions ........................................................... 43

C. Additional Mifare® Card Memory Map Information ... 45

C.1 Manufacture Block ........................................................................... 45

C.2 Data Blocks ....................................................................................... 45

D. Sample Worksheets ........................................................ 47

E. Limited Warranty ............................................................ 48

iv CP-R25 Hardware and AS-B01 Software Manual

List of Figures

Figure 1: The CP-R25...................................................................................... 8

Figure 2: CP-R25 Components ..................................................................... 12

Figure 3: AS-B01 Setup – Welcome Screen ................................................... 13

Figure 4: AS-B01 Setup – Select Installation Folder ........................................ 14

Figure 5: ASB01 Setup – Disk Space Availability ............................................ 14

Figure 6: AS-B01 Login Dialog ...................................................................... 15

Figure 7: AS-B01 – Main Window ................................................................. 16

Figure 8: AS-B01 Connectivity – Connected .................................................. 17

Figure 9: AS-B01 – Main Window Layout...................................................... 18

Figure 10: AS-B01 Sector Reader Configuration Tab Areas ............................ 22

Figure 11: CP-R25 Antenna Areas ................................................................ 22

Figure 12: Read Configuration Card ............................................................. 30

Figure 13: Read ID from User Card ............................................................... 31

Figure 14: Program ID into User Card ........................................................... 32

Figure 15: Change User Card KeyA on Selected Sector ................................. 32

Figure 16: Change User Card KeyA on All Sectors ......................................... 33

Figure 17: Erase User Card Selected Block ..................................................... 34

Figure 18: Read Serial Number and Card Type .............................................. 35

Figure 19: Change User Card KeyA and Erase Data – All Sectors ................... 36

Figure 20: Enroll Fingerprints to Card............................................................ 37

Figure 21: Verify Live Fingerprints ................................................................. 38

Figure 22: AS-B01 Change Password ............................................................ 39

Figure 23: Enable Card Overwrite Popup Window ........................................ 40

Figure 24: AS-B01 Desktop Reader Firmware Programming .......................... 40

Figure 25: Disconnect USB Cable .................................................................. 41

Figure 26: Connect USB Cable ...................................................................... 41

Figure 27: Mifare® 1K Memory Diagram ....................................................... 46

CP-R25 Hardware and AS-B01 Software Manual v

List of Tables

Table 1: Indication LEDs................................................................................ 19

Table 2: Field Descriptions ............................................................................ 43

vi CP-R25 Hardware and AS-B01 Software Manual

Notice and Disclaimer

This manual’s sole purpose is to assist installers and/or users in the safe and efficient installation and usage of the system and/or product, and/or software described herein.

EFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM, THE INSTALLER AND

THE USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY

REQUIREMENTS AND OPERATING PROCEDURES

 The system must not be used for purposes other than those for which it

was designed.

 The use of the software associated with the system and/or product, if

applicable, is subject to the terms of the license provided as part of the purchase documents.

 ROSSLARE ENTERPRISES LIMITED and/or its related companies and/or

subsidiaries’ (hereafter:"ROSSLARE") exclusive warranty and liability is limited to the warranty and liability statement provided in an appendix at the end of this document.

 This manual describes the maximum configuration of the system with the

maximum number of functions, including future options. Therefore, not all functions described in this manual may be available in the specific system and/or product configuration you purchased.

 Incorrect operation or installation, or failure of the user to effectively

maintain the system, relieves the manufacturer (and seller) from all or any responsibility for consequent noncompliance, damage, or injury.

 The text, images and graphics contained in the manual are for the

purpose of illustration and reference only.

 In no event shall manufacturer be liable for any special, direct, indirect,

incidental, consequential, exemplary or punitive damages (including, without limitation, any and all damages from business interruption, loss of profits or revenue, cost of capital or loss of use of any property or capital or injury).

 All graphics in this manual are for reference only, some deviation between

the image(s) and the actual product may occur.

 All wiring diagrams are intended for reference only, the photograph or

graphic of the PCB(s) are intended for clearer illustration and understanding of the product and may differ from the actual PCB(s).

CP-R25 Hardware and AS-B01 Software Manual vii

Introduction

1. Introduction

Rosslare's CP-R25 is a desktop Mifare® and fingerprint card programmer for Mifare® 1K and 4K RFID proximity cards and tags.

The CP-R25 makes managing fingerprint and Mifare facilitate the effective deployment and control of any facility code application, including access control, intrusion, and time and attendance applications.

1.1 The CP-R25 System

The CP-R25 is built for high-security, portability and ease of use, enabling high quality Mifare

and fingerprint enrollment at a low cost.

The CP-R25 programmer is controlled by computer using Rosslare's powerful AS-B01 Programmer software package.

1.2 Desktop Convenience

The CP-R25 is small and lightweight, with a slim and attractive design. It is built for convenience and portability, with a USB 2.0 computer interface, which makes it quick to install and allows it to run without any additional power source.

Figure 1: The CP-R25

cards easier and can help

Designed to sit safely on any desktop, the CP-R25 is sturdily built, with large card and fingerprint trays and surface-gripping rubber feet.

1.3 Intuitive Software System

The AS-B01 is a software application intended for programming Mifare

cards,

tags and fingerprints using Rosslare's CP-R25 Desktop Programmer. The system includes a security authentication system and a real-time

operations log. Using this tool requires basic understanding of Mifare

cards memory

architecture and access condition mechanisms.

8 CP-R25 Hardware and AS-B01 Software Manual

Introduction

The software does not support all Mifare® cards features required by the systems using the CP-R25 programmed Mifare® cards.

1.4 Compatibility

The CP-R25 Desktop Programmer and AS-B01 software are compatible with other products, including but not limited to:

 AY-W6260 and AY-W6360 Read-Sector, Smartcard, Read-Write Access

Control reader family

 AY-Q6260 and AY-Q6360 Anti-vandal, read-sector, Smartcard, Read-

Write Access Control reader family

 AY-Bx663 (X=1,3,4) Mifare

1.5 Main Features

The CP-R25 Desktop Programmer is a feature-rich Mifare and fingerprint enroller.

1.6 CP-R25 Desktop Programmer

 Enables the user to read, verify, and program Mifare  Uses a swipe type fingerprint sensor  Supports USB 2.0 computer connections  Utilizes LED and buzzer sub-systems to indicate programming, card, and

power supply status

 Runs a thorough internal diagnostic self-test every time it is powered up

1.7 AS-B01 Software

 Programs fingerprints on User cards  Programs ID data on User cards  Produces configuration cards for Rosslare Mifare  Performs firmware updates on supported desktop programmers  Maintains a user log to provide feedback to the software user  Provides password protection  Indicates valid connections with Desktop Programmer

Smartcard Fingerprint Swipe Sensor family

card programmer

proximity cards

readers

CP-R25 Hardware and AS-B01 Software Manual 9

Specifications and Requirements

2. Specifications and Requirements

2.1 CP-R25 Hardware Specifications

Data Specifications

Mifare

Cards

RF Frequency

Bit rate

Classic 1K and 4K

13.56 MHz

106 kHz

Fingerprint Reader Specifications

Sensor type

Sensor ESD Rating

Electrostatic Discharge:

FAR – False Accept Rate

FRR – False Reject Rate

Swipe type UPEK TCS4C-TCD50A

Sensor technology – Capacitive sensor

Up to +/- 15 kV air discharge on the sensor surface

Actual values depend on specific user's finger, usage condition and quality of enrollment.

Specification – 0.0010% (1/100000) Actual values depend on specific user's finger, usage

condition and quality of enrollment. Specification – 2% (1/50)

Electrical Specifications

Operating Voltage

Input Current

5 VDC Via USB

75 mA (standby) 160 mA (maximum)

CP-R25 Physical Specifications

Dimensions (L x W x H)

Weight

17.3 x 5.8 x 3.3 cm

6.18 x 2.28 x 1.30 inch

309 g (10.89 oz.)

Environmental Data

Operating Temperature

Operating Humidity

10ºC to 50ºC (50ºF to 122ºF) 5% to 93% (non-condensing)

10 CP-R25 Hardware and AS-B01 Software Manual

Specifications and Requirements

2.2 AS-B01 Software Requirements

Minimum Software Requirements

Operating System

Framework

Processor

RAM Memory

Free HD space:

Connection Port

Windows XP SP2

Microsoft .NET 2

400 MHz Pentium or equivalent

512 Mbytes

1 Gigabyte

USB

CP-R25 Hardware and AS-B01 Software Manual 11

Installation

3. Installation

3.1 Unpacking the Equipment

The CP-R25 programmer is ready to use immediately "out of the box" and includes a USB cable and documentation.

Please confirm all the items listed below are received before beginning. If any items are missing, contact your dealer immediately.

 One CP-R25 Programmer  One Male A to Male B USB Cable  One Software CD  Instruction Manual

3.2 CP-R25 Description

The following figure illustrates the CP-R25 components:

Figure 2: CP-R25 Components

3.3 AS-B01 Software Installation

The AS-B01 software is included on the installation CD-ROM, which is packaged with the CP-R25 hardware.

12 CP-R25 Hardware and AS-B01 Software Manual

Installation

To install the AS-B01 software for the first time:

1. Insert the CD into the computer's CD drive.

2. If the Autoloader does not initiate the installation, open My Computer, double-click on the CD drive icon and then double-click the AS-B01 setup file.

If Microsoft .NET 2 Framework is not installed on the computer, it is installed automatically before beginning the AS-B01 installation.

The installation package extracts the installation files. After the files are extracted, the

Welcome to the CP-R25 Setup Wizard

Figure 3: AS-B01 Setup – Welcome Screen

screen opens.

3. Click Next. The

Select Installation Folder

screen opens.

CP-R25 Hardware and AS-B01 Software Manual 13

Installation

Figure 4: AS-B01 Setup – Select Installation Folder

4. [Optional]Click Disk Cost…. to ensure the computer has sufficient space.

AS-B01 Setup Disk Space

The

Figure 5: ASB01 Setup – Disk Space Availability

window opens.

5. Select the users allowed to use the program, Everyone or Just me. For security purposes it is suggested that Just me is selected.

6. [Optional] You can change the destination folder of the installation: a. Click Browse.

The standard Windows Explorer window opens.

b. Navigate to and select the required folder.

7. Click Next to continue the installation process.

Confirm Installation

The

14 CP-R25 Hardware and AS-B01 Software Manual

screen opens.

Installation

8. Click Next. The installation process is initiated. When the process finishes, the

Installation Complete

screen opens.

9. Click Close to complete the installation process.

3.4 Connecting the CP-R25

The CP-R25 unit does not require special installation. Follow the following steps to prepare the unit for enrollment.

Before connecting the CP-R25 hardware, ensure that the ASB01 software is installed and running.

To connect the CP-R25:

1. Click the AS-B01 icon on the desktop or select the program from the Rosslare folder in the Start menu. The login dialog opens.

Figure 6: AS-B01 Login Dialog

2. Enter a password. When using the application for the first time, use the default password of

"admin".

After initial use, make sure to change the default password to your company’s approved password (see Section 7.1).

The AS-B01 software Main Window opens.

CP-R25 Hardware and AS-B01 Software Manual 15

Installation

Figure 7: AS-B01 – Main Window

At the bottom left of the main window, the connection indication is red with the description “Disconnected”.

3. Connect the Desktop Programmer to a PC using the USB cable – one cable end connects to the PC USB host port output and the other end connects to the USB connector on the Desktop Programmer.

Windows Programmer receives its power through the USB; no external power supply is required.

On the AS-B01 main window, the connection indicator at the bottom of the window changes from red to green with the description “Connected” to indicate that the CP-R25 Desktop Programmer is connected. In addition, the CPR-26 tab that was previously visible closes, leaving only the CPR-25 tab visible.

automatically installs the required drivers. The Desktop

16 CP-R25 Hardware and AS-B01 Software Manual

Installation

Figure 8: AS-B01 Connectivity – Connected

The event log displays a connected message. If the indicator does not turn green, and the description still indicates

Disconnected after the USB cable is connected, try disconnecting the USB cable from the Desktop Programmer and reconnecting it.

When the hardware and software are disconnected, the software can only function in demonstration mode.

Once the indicator is green and the description is Connected, the CP-R25 Desktop Programmer is ready for use.

CP-R25 Hardware and AS-B01 Software Manual 17

AS-B01 Software Overview and LEDs

4. AS-B01 Software Overview and

LEDs

This section describes the AS-B01 and CP-R25 LEDs.

4.1 Software Overview

Once the login is completed with the correct password, the main software window opens.

Figure 9: AS-B01 – Main Window Layout

The AS-B01 main window consists of the following functional areas:

 File menu area – Used for general operations such as setting global

options on the Desktop Programmer, getting version information, and closing the software.

 Configuration Tab area – The main working area, which is used for

entering and displaying all card and swipe configuration parameters.

18 CP-R25 Hardware and AS-B01 Software Manual

AS-B01 Software Overview and LEDs

Descriptions for fields requiring parameters under all the tabs are described in Appendix A.

There are two programming tabs:

 Sector reader – Used to configure and read sector reader cards. This

tab allows configuring both User ID/Card Serial number user cards as well as Reader Configuration cards.

 Swipe reader – Used to write and read cards containing fingerprint

templates. This tab also allows creating configuration cards for fingerprint readers.

 Message log area – The event log records all activities and provides the

user with real time system monitoring. The information messages may either be operation success or failure messages, or instruction messages such as during fingerprint enrollment.

 Status information area – Indicates connection status with the CP-R25

Desktop Programmer hardware.

4.2 Indication LEDs

The following table describes LED behavior on the CP-R25 Programmer (see Figure 2).

Table 1: Indication LEDs

Event Swipe Card Reader

General

Power on One red LED lights for several seconds followed by all the LEDs flashing and

Card Programming

Card not loaded

Card loaded

Write card success

Write card fail

CP-R25 Hardware and AS-B01 Software Manual 19

LED

the buzzer beeps 3 times for the duration of 3 seconds.

Green flashing

On card detection, green turns on for 1 second, then off

Green on for 3 sec All off

Red on for 3 seconds All off

Fingerprint Reader LED

All off

Buzzer Fingerprint

Off

On card detection short beep, then off

3 High tone beeps

Long buzz

Directional Indication LED

All on

AS-B01 Software Overview and LEDs

Event Swipe Card Reader

Fingerprint Scanning

Waiting for fingerprint

Read fingerprint success

Read fingerprint fail

Read finger timeout – When no finger is passed over the scanner for 30 seconds, the CP-R25 Desktop Programmer goes back to Standby mode of swipe LEDs.

LED

Off

Fingerprint Reader LED

Green flashes Off

Green on for 3 sec

Red on for 3 sec

Buzzer Fingerprint

3 high-tone beeps

Long buzz

Directional Indication LED

Rolling LEDs in circular mode to indicate finger swipe

Turning all LEDs on, and then according to status, leaving all on or going back to circular mode

20 CP-R25 Hardware and AS-B01 Software Manual

Programming Cards and Tags

5. Programming Cards and Tags

To configure the Mifare® cards and tags, the Configuration Tab area of the Main Window is used.

Within the Configuration Tab Area, there are three sub-areas whose display changes depending on what options are selected.

Refer to Appendix B for a description of the various fields that appear in the Configuration Tab area.

Two of the sub-areas always appear:

 General Reader Configuration area – This area is the same for all

configuration functions

 Operations area – This area varies according to the configuration function

being performed. The configuration function is selected in the Operation Type dropdown menu.

The following 2 sub-areas appear depending on what options are selected in

Operation Mode



Reader Specific Configurations

Reader tab is active and Program Configuration Card is selected in

Operation Type



Finger options Operation Type

The following figure illustrates one of the possible appearances of the Configuration Tab area.

and

Operation Type

– This area is visible when the CPR-25 tab is active and

is Program User Card KeyA + template.

area – This area is visible when the Sector

CP-R25 Hardware and AS-B01 Software Manual 21

Programming Cards and Tags

Figure 10: AS-B01 Sector Reader Configuration Tab Areas

When programming a Mifare

card or tag, the card or tag is placed on the CPR25 Desktop Programmer antenna area. The following figure illustrates where these areas are located on the CP-R25 Desktop Programmer.

Figure 11: CP-R25 Antenna Areas

22 CP-R25 Hardware and AS-B01 Software Manual

Programming Cards and Tags

The CP-R25 Programmer configures three card or tags types:

 Configuration Card – This card is used to configure a reader. The

Configuration card is simply held up against a reader to automatically program the reader with the relevant security information thus allowing the reader to identify the user cards or tags.

 Master Card – This card is used to put the reader into Configuration mode

so that a Configuration card can then be used to program the reader.

 User Card – This card is used to enable access by presenting the card or

tag to the reader. With readers requiring fingerprint identification the same card or tag is used in conjunction with swiping of the fingertip.

5.1 Programming a Master Card

The Master card is used to put the reader into Configuration mode in which a Configuration card is then used to program the reader.

To prepare a Master card:

1. Select either the Sector Reader or CP-R25 tab.

2. In the Operations area, in

The Operation Mode field is not relevant for configuring Master card. The default value of Sector can be used.

3. In

Card Type

4. From the

, select either Mifare® 1 K or Mifare® 4 K.

Transmit Format

Operation Type

, select Create Master Card.

dropdown menu, select the applicable

transmission format.

5. Place either a blank Mifare

card or a Mifare® card that has been previously used as a Master card on the CP-R25 Desktop Programmer antenna area.

6. Click Start to begin programming the Mifare

card.

On completion, a message is displayed in the Message Log area to verify that the programming succeeded.

If the programming is a failure there is a short buzz and the Swipe Card Reader LEDs light red for three seconds.

5.2 Programming a Configuration Card

A Configuration card is used for configuring specific Rosslare Mifare

and Fingerprint reader's operation modes. Holding the Configuration card in front of the reader after presenting the Master card configures that reader. The organization's Configuration card should be kept in a safe place to avoid being copied by unauthorized persons as it stores the organization/site KeyA. It is advisable to create a backup Configuration card and store it in a safe place.

Preparing a sector reader Configuration card requires a KeyA value. Do not expose the KeyA value to any unauthorized personnel while preparing the Configuration card.

CP-R25 Hardware and AS-B01 Software Manual 23

Programming Cards and Tags

Refer to the specific reader’s installation manual for a detailed explanation of the various options.

5.2.1 Sector Reader Configuration Cards

A Sector Reader Configuration card allows you to create a configuration card, which is used to configure the various sector readers such as the AY-W6260, AY-W6360, AY-Q6260, and AY-Q6360 units.

To prepare a Sector Reader Configuration card:

1. Select the Sector Reader tab.

2. Select the applicable

Number (CSN).

3. From the

Configuration Card.

4. In

5. From the

transmission format.

6. For

Number, and Byte Number fields in

7. Ensure that

8. Define the

Enable Led and Enable Buzzer checkboxes.

9. For readers with a keypad:

a. Select the Keypad checkbox.

b. In the

c. From the

10. For

KeyA for the organization or site in both the Reader KeyA and the Confirm Reader KeyA fields.

11. Place a blank Mifare® card or a card previously configured as a

Configuration card on the CP-R25 Desktop Programmer antenna area.

12. Click Start to begin programming the Mifare® card.

On completion, a message appears in the Message Log area to verify that the programming succeeded.

Operation Type

Card Type

, select either Mifare® 1 K or Mifare® 4 K.

Transmit Format

Sector

operation mode, select values for the Sector Number, Block

Operations

Led and Buzzer Control

Additional keypad options appear.

Backlight options

behavior.

transmission format.

Sector

mode, enter the KeyA to be used by the reader as the unique

The KeyA number is hidden by "*" characters, so write down the new key and keep it in a safe place to avoid exposing this secret key to unauthorized personnel. The KeyA value is entered as a 12 hexadecimal digit. The default KeyA is FFFFFFFFFFFF.

Operation Mode

dropdown menu, select Program

dropdown menu, select the applicable

is set to Program Card.

Transmit Format

, either Sector or Card Serial

ID Location.

behavior by selecting or clearing the

dropdown menu, select the backlight

dropdown menu, set the keypads’

24 CP-R25 Hardware and AS-B01 Software Manual

Programming Cards and Tags

If the programming fails, there is a short buzz and the Swipe Card Reader LEDs light red for three seconds.

5.2.2 Fingerprint Swipe Reader Configuration Cards

The Fingerprint Swipe Reader Configuration card allows you to create a Configuration card to configure the various Fingerprint Swipe readers such as the AY-B1663, AY-B3663, and AY-B4663.

To prepare a Biometric Swipe Configuration Card:

1. Select the CPR-25 tab.

2. In

Operation Mode

3. In

Card Type

4. From the

Transmit Format

, select either Sector or Card Serial Number (CSN).

, select either Mifare® 1 K or Mifare® 4 K.

dropdown menu, select the applicable

transmission format.

5. For Sector operation mode, define the

ID Location

using the Sector

Number, Block Number, and Byte Number fields.

6. From the

Operation Type

dropdown menu, select Program

Configuration Card.

7. Ensure that the

8. Define the

Operations

is set to Program Card.

Led and Buzzer Control

behavior by selecting or clearing the

Enable Led and Enable Buzzer checkboxes.

9. To enable the

Lockout

feature:

a. Select the Enable checkbox. b. Define the lockout behavior using the Attempts and Duration

fields.

10. For reports on operational failures, select the Enable checkbox under

Failed operation reporting

11. In

KeyA

, enter the KeyA to be used by the reader as the unique KeyA for

the organization or site in both the Reader KeyA and the Confirm Reader KeyA fields.

12. Place a blank Mifare® card or a card previously configured as a

Configuration Card on the CP-R25 Desktop Programmer antenna area.

13. Click Start to begin programming the Mifare

card.

On completion, a message appears in the Message Log area to verify that the programming succeeded.

If the programming fails, there is a short buzz and the swipe Card Reader LEDs light red for three seconds.

CP-R25 Hardware and AS-B01 Software Manual 25

Programming Cards and Tags

5.3 Programming User Cards or Tags

In this section, both cards and tags are referred to as cards. The card configuration type depends on what level of system security is implemented. The cards configuration depends on the reader type used. There are two reader types that determine what tab to use when configuring the cards:

 Sector reader – Used to configure and read sector reader cards. This tab

allows configuring both User ID/card serial number user cards as well as reader configuration cards.

 Swipe reader – Used to write and read cards containing fingerprint

templates. The

CP-R25

tab also allows creating configuration cards for

fingerprint readers.

The AS-B01 application offers various configuration options including the following:

 For a new Mifare

User Card, configuring the Card ID, card key and

fingerprint enrollment separately.

 For a previously configured Mifare

User Card, configuring the Card ID

and card key at the same time.

 For a previously configured Mifare

User Card, configuring the Card ID,

card key, and fingerprint enrollment at the same time.

Once a card is configured, the Card ID and the KeyA value can be modified, or if required, completely wiped from the card.

5.3.1 Programming a Sector Reader User Card

The first stage of preparing a Mifare

sector read User Card is configuring a card ID and card KeyA value. These two configuration values are done simultaneously.

To program a Mifare® Sector Read User Card:

1. Select the Sector Reader tab.

2. In

Operation Mode Card Type

3. In

4. From the

Transmit Format

, select the Sector.

, select either Mifare® 1 K or Mifare® 4 K.

dropdown menu, select the applicable

transmission format.

5. In

ID Location

, select values for the Sector Number, Block Number, and

Byte Number fields.

If the Card Serial Number operation mode is being used by the organization, no programming is available for the user card.

6. Ensure that the

7. From the

Operations

Operation Type

is set to Program Card.

dropdown menu, select Program User Card ID

+ KeyA.

26 CP-R25 Hardware and AS-B01 Software Manual

Programming Cards and Tags

8. Enter the User Card ID number or scroll to a value using the Up and

Down arrows. The range of possible values is shown just above the

9. In

KeyA

User Card ID

a. Enter the KeyA to be used by the reader as the unique KeyA for the

organization or site in both the Reader KeyA and the Confirm Reader KeyA fields.

b. Enter the current KeyA of the card being programmed.

• The KeyA number is hidden by "*" characters, so write down the new key and keep it in a safe place to avoid exposing this secret key to unauthorized personnel. The KeyA value is entered as a 12 hexadecimal digit. The default KeyA is FFFFFFFFFFFF.

• The current KeyA during a new installation is the default KeyA FFFFFFFFFFFF. For existing sites, the current KeyA is the KeyA entered the original site installation. The current KeyA remains active until it is changed after configuring the reader.

10. Place a Mifare® card on the CP-R25 Desktop Programmer antenna area.

11. Click Start to begin programming the Mifare

card.

On completion, a message appears in the Message Log area to verify that the programming succeeded.

If the programming fails, there is a short buzz and the swipe Card Reader LEDs lights red for three seconds.

12. To program additional Mifare

User Cards, repeat Step 8 and then Steps

10 and 11.

5.3.2 Programming and Enrolling Fingerprint User Card

Before enrolling a card user’s fingerprint, the card must have a configured card ID and KeyA value.

There are two options for enrolling fingerprints on a Mifare

User Card. Either one or two fingerprints can be programmed on the card. This number of fingerprints is defined by the company security specifications and the card type used.

To enroll fingerprints on a Mifare® User Card:

1. Select the CP-R25 tab.

2. Select the applicable

Operation Mode

, either Sector or Card Serial

Number (CSN).

Card Type

3. In

4. From the

, select either Mifare® 1 K or Mifare® 4 K.

Transmit Format

dropdown menu, select the applicable

transmission format.

5. For Sector operation mode, select values for the Sector Number, Block

Number, and Byte Number fields in

6. Ensure that the

Operations

ID Location

is set to Program Card.

CP-R25 Hardware and AS-B01 Software Manual 27

field.

Programming Cards and Tags

7. From the

a. If

Operation Type

Operation type

dropdown menu:

is Sector, select Program User Card ID + KeyA +

template.

b. If

Operation type

is Card Serial Number (CSN), select Program

User Card KeyA + template.

8. For Sector

Operation Mode

, enter the User Card ID number or scroll to a

value using the Up and Down arrows. The range of possible values is shown just above the

9. In

KeyA

User Card ID

a. Enter the KeyA to be used by the reader as the unique KeyA for the

organization or site in both the Reader KeyA and the Confirm Reader KeyA fields.

b. Enter the current KeyA of the card being programmed.

10. In

Fingers options

, select the number of fingers per card to enroll onto the

Mifare® User Card.

11. [Optional] Select the Verify after enrollment checkbox to verify the enrolled fingerprints if required. This is usually not required as the CP-R25 Desktop Programmer has an automatic internal verification during enrollment.

12. If needed, select the Ignore Template checkbox for a cardholder who is unable to present a finger for verification.

Note that when this option is selected, the parameters in

Finger options

Step 10 are grayed out.

13. Place a Mifare

14. Click Start to begin programming the Mifare

card on the CP-R25 Desktop Programmer antenna area.

card.

15. Instruct the person whose fingerprints are being enrolled to swipe his/her finger on the finger sensor, located on the CP-R25 Desktop Programmer, in the direction indicated by the Fingerprint Directional Indication LEDs.

16. Follow the instructions messages in the Message Log area to repeat the fingerprint swipe process three (3) times.

If enabled in the system settings (see Section 7.2), the system alerts if the card being programmed is not empty. The “The card is not empty. Do you want to overwrite it?" prompt message is displayed. Choose Continue or Cancel.

28 CP-R25 Hardware and AS-B01 Software Manual

field.

Programming Cards and Tags

On a successful completion of all three reads and card programming, 3 short beeps are generated and a success message "Writing template to card succeeded" appears in the Message Log area.

If the programming fails, there is a short buzz and the swipe Card Reader LEDs light red for three seconds.

17. To program and enroll additional user cards, repeat Step 8 and then Steps 13 to 16.

CP-R25 Hardware and AS-B01 Software Manual 29

Additional Programmer Utilities

6. Additional Programmer Utilities

The AS-B01 software includes additional utilities that allow you to use the programmer in the best and easiest possible way.

The card utilities are identical for both the Sector Read and CP-R25 tabs. The CP-R25 tab has additional utilities designed specifically for the fingerprint swipe application.

6.1 Card Utilities

The card utilities vary depending on the selection of either Sector or Card Serial Number (CSN) in

When Card Serial Number (CSN) is selected, there are two card utility options available.

When Sector is selected, the same two card utilities are available, plus six additional utilities specific to the Sector type card.

6.1.1 Reading a Configuration Card

This function is used to confirm the card configuration when performing other functions in order to save time and enhance accuracy.

To read the Configuration cards:

1. Select either the Sector Reader or CP-R25 tab.

2. Select the applicable Number (CSN).

Operations

3. In

4. In the

Operation Type

dropdown menu.

Operation Mode

, select Card utilities.

field, select Read Configuration Card from the

Figure 12: Read Configuration Card

, either Sector or Card Serial

5. Place the Mifare® Configuration Card on the CP-R25 Desktop Programmer antenna area.

6. Click Start to begin reading the Configuration Card. The configuration options are displayed on the screen.

30 CP-R25 Hardware and AS-B01 Software Manual

Additional Programmer Utilities

6.1.2 Reading an ID from a User Card

This utility is used to ensure that the Mifare This option is only available for the Sector

User Card is configured properly.

Operation Mode

To read an ID from a Mifare® User Card:

1. Select either the Sector Reader or CP-R25 tab.

In Operation Mode

3. Select the

4. From the transmission format.

Operations

5. In

6. From the User Card.

The KeyA and User Card ID fields appear.

7. Enter the KeyA of the card being read.

8. Place the Mifare® User Card on the CP-R25 Desktop Programmer antenna area.

9. Click Start to display the card ID in the Mifare® User Card ID field.

6.1.3 Programming a User Card ID

This utility is used to program the User Card ID into a specific location on the User card without configuring the card template or KeyA.

This option is only available for the Sector

Card Type

Transmit Format

Operation Type

, select Sector.

, either Mifare® 1 K or Mifare® 4 K.

dropdown menu, select the applicable

, select Card utilities.

field dropdown menu, select Read ID from

Figure 13: Read ID from User Card

Operation Mode

To program an ID into a Mifare® User Card:

1. Select either the Sector Reader or CP-R25 tab.

In Operation Mode

3. Select the

4. From the transmission format.

Operations

5. In

6. From the User Card.

Card Type

Transmit Format

Operation Type

, select Sector.

, either Mifare® 1 K or Mifare® 4 K.

dropdown menu, select the applicable

, select Card utilities.

field dropdown menu, select Program ID into

CP-R25 Hardware and AS-B01 Software Manual 31

Additional Programmer Utilities

Figure 14: Program ID into User Card

The KeyA and Mifare

User Card ID fields appear.

7. Enter the KeyA of the card being programmed.

8. Enter the User Card ID or scroll to the value using the Up and Down arrows. The value can be between 0 and 16777215.

9. Select values for the Sector Number, Block Number, and Byte Number fields in

10. Place the Mifare

ID Location

User Card on the CP-R25 Desktop Programmer antenna

area.

11. Click Start to begin programming procedure.

6.1.4 Changing the User Card KeyA in a Specific Sector

Use this utility to change the KeyA value in a specific sector of the User Card without changing the card template or User Card ID.

This option is only available for the Sector

Operation Mode.

To change the KeyA in a specific sector:

1. Select either the Sector Reader or CP-R25 tab.

2. Select the Sector

3. Select the

4. Define the

5. In

Operations

6. From the

Operation Type

Operation Mode

Card Type

ID Location

, either Mifare® 1 K or Mifare® 4 K.

using the Sector Number field.

, select Card utilities.

field dropdown menu, select Change User

Card KeyA on selected sector.

Figure 15: Change User Card KeyA on Selected Sector

The KeyA fields are displayed.

32 CP-R25 Hardware and AS-B01 Software Manual

Additional Programmer Utilities

7. In

KeyA

a. Enter the KeyA to be used by the reader as the unique KeyA for the

organization or site in both the Reader KeyA and the Confirm Reader KeyA fields.

b. Enter the current KeyA of the card being programmed.

8. Place the Mifare® User Card on the CP-R25 Desktop Programmer antenna area.

9. Click Start to program the card with the new KeyA.

6.1.5 Changing the User Card KeyA in All Sectors

Use this utility to change the KeyA value in all sectors of the User Card without changing the card template or User Card ID.

This option is only available for the Sector

Operation Mode.

To change the KeyA in a specific sector:

1. Select either the Sector Reader or CP-R25 tab.

2. Select the Sector

3. Select the

4. In

Operations

5. From the

Card Type

, select Card utilities.

Operation Type

Operation Mode

, either Mifare® 1 K or Mifare® 4 K.

field dropdown menu, select Change User

Card KeyA on all sectors.

Figure 16: Change User Card KeyA on All Sectors

The KeyA fields are displayed.

CP-R25 Hardware and AS-B01 Software Manual 33

Additional Programmer Utilities

6. In

KeyA

a. Enter the KeyA to be used by the reader as the unique KeyA for the

organization or site in both the Reader KeyA and the Confirm Reader KeyA fields.

b. Enter the current KeyA of the card being programmed.

7. Place the Mifare® User Card on the CP-R25 Desktop Programmer antenna area.

8. Click Start to program the card with the new KeyA.

6.1.6 Erasing Specific User Card Data

This utility is used to erase specific information from a defined sector within the card.

This option is only available for the Sector

Operation Mode

To erase specific user card data:

1. Select either the Sector Reader or CP-R25 tab.

2. Select the Sector

3. Select the

4. In the

5. From the

Card Type

Operations

Operation Type

Operation Mode

, either Mifare® 1 K or Mifare® 4 K.

area, select Card utilities.

field dropdown menu select Erase User Card

selected block.

Figure 17: Erase User Card Selected Block

The KeyA field is displayed.

6. Enter the KeyA for the card being read.

7. Place the Mifare® User Card on the CP-R25 Desktop Programmer antenna area.

8. Click Start to erase the data from the specific sector within the card.

34 CP-R25 Hardware and AS-B01 Software Manual

Additional Programmer Utilities

6.1.7 Read Serial Number and Card Type

Each Mifare

card has a Unique Serial Number (UID). Use this utility to see a

card’s UID and card type.

To read a Mifare® User Card Serial Number and Type:

1. Select either the Sector Reader tab or the CP-R25 tab.

2. From the

Transmit Format

dropdown menu, select the applicable

transmission format.

3. In the

Operations

4. From the

area, select Card utilities.

Operation Type

field dropdown menu, select Read serial

number and card type.

Figure 18: Read Serial Number and Card Type

The Serial Number field appears.

5. Place the Mifare

User Card on the CP-R25 Desktop Programmer antenna

area.

6. Click Start to display the serial number and card type.

6.1.8 Changing KeyA and Erasing All Data

Use this utility to format a card to define a new KeyA, which is written on all sectors.

This option is only available for the Sector

Operation Mode.

To format the User Card:

1. Select either the Sector Reader or CP-R25 tab.

2. Select the Sector

3. Select the

4. In the

5. From the

Operations

Operation Type

Operation Mode

Card Type

, either Mifare® 1 K or Mifare® 4 K.

area, select Card utilities.

field dropdown menu, select Change User

Card KeyA and erase data – all sectors.

CP-R25 Hardware and AS-B01 Software Manual 35

Additional Programmer Utilities

Figure 19: Change User Card KeyA and Erase Data – All Sectors

The KeyA fields are displayed.

6. In

KeyA

a. Enter the KeyA to be used by the reader as the unique KeyA for the

organization or site in both the Reader KeyA and the Confirm Reader KeyA fields.

b. Enter the current KeyA of the card being programmed.

7. Place the Mifare® User Card on the CP-R25 Desktop Programmer antenna area.

8. Click Start to start the formatting procedure.

This operation may take up to 30 seconds for a 1K card and several minutes for a 4K card. Do not close the application or remove the card until you receive a confirmation message.

6.2 Fingerprint Utilities

The fingerprint utility allows you to enroll fingerprints to a pre-configured User card without changing the various information written on the card or to verify the fingerprint written on to a card.

6.2.1 Enrolling Fingerprints on a Pre-configured User Card

The AS-B01 software allows you to enroll fingerprints onto a card already configured with the User card ID.

To enroll fingerprints to a pre-configured user card:

1. Select the CP-R25 tab.

2. In the

Operations

area, select Finger utilities.

36 CP-R25 Hardware and AS-B01 Software Manual

Additional Programmer Utilities

3. From the

Operation Type

dropdown menu, select Enroll fingerprints to

card.

Figure 20: Enroll Fingerprints to Card

4. Select the number of fingers per card to enroll.

5. [Optional] In

Finger options

, select the Verify after enrollment checkbox to verify the enrolled fingerprints if required. This usually not required as the CP-R25 Desktop Programmer has an automatic internal verification on enrollment.

6. For security reasons, enter the KeyA value.

7. Define the

ID Location

using the Start Sector field.

8. Place the card on the CP-R25 Desktop Programmer antenna area.

9. Click Start to begin programming the Mifare

card.

10. Instruct the person whose fingerprints are being enrolled to swipe his/her finger on the finger sensor, located on the CP-R25 Desktop Programmer, in the direction indicated by the Fingerprint Directional Indication LEDs.

11. Follow the instructions messages in the Message Log area to repeat the fingerprint swipe process three (3) times.

To write the finger template onto a specific card sector, define the sector number by typing or selecting the number in the Sector Number field located in the finger options section of the screen.

6.2.2 Verifying Fingerprint Enrollment on a User Card

Verifying fingerprint enrollment on a Mifare

User Card can be done as a

separate function or at the same time an enrollment is preformed. As an added security measure the CP-R25 Desktop Programmer automatically

does an internal verification to ensure accuracy. That is why during the enrollment process, more than one swipe is required.

To verify fingerprint enrollment on a Mifare® User Card:

1. Select the CP-R25 tab.

2. In the

3. From the

Operations

Operation Type

area, select Finger utilities.

dropdown menu, select Verify live fingerprint.

CP-R25 Hardware and AS-B01 Software Manual 37

Additional Programmer Utilities

Figure 21: Verify Live Fingerprints

4. Select the number of fingers that were enrolled for verification.

5. For security reasons, enter the KeyA value.

6. Select the sector number that starts the fingerprint template location.

7. Place the card on the CP-R25 Desktop Programmer antenna area.

8. Click Start to begin programming the Mifare

9. Instruct the person whose fingerprints are being verified to swipe his/her finger on the finger sensor, located on the CP-R25 Desktop Programmer, in the direction indicated by the Fingerprint Directional Indication LEDs.

10. Follow the instructions messages in the Message Log area to repeat the fingerprint swipe process once for each template.

card.

38 CP-R25 Hardware and AS-B01 Software Manual

Global Options

7. Global Options

This section provides instruction on how to define the software behavior and change the password used to enter the application.

7.1 Change Password

For security reasons, it is highly advisable to change the login password to the AS-B01 software from the default password.

To change the AS-B01 application entry password:

1. In the File menu, click Options > Change Password. The

Change Password

window opens.

Figure 22: AS-B01 Change Password

2. Complete the fields as required. Passwords are case sensitive. For higher security, make sure that the password you choose is more than

4 letters long. Mixing letters and numbers also substantially strengthens the password.

All passwords are hidden by '*' characters to avoid exposing it to an unauthorized user.

3. Click OK. The password is changed.

7.2 Card Overwrite

Enabling the Card Overwrite option causes the system to issue a warning when attempting to write information onto a card with data already stored on it.

If disabled, the system overwrites information automatically without warning the user.

CP-R25 Hardware and AS-B01 Software Manual 39

Global Options

To enable the Card Overwrite warning:

1. In the File menu click Options > Card Overwrite.

Overwrite

The

2. Verify that the checkbox is selected.

3. Click OK.

7.3 Updating Firmware

You may need to periodically update your firmware.

window opens.

Figure 23: Enable Card Overwrite Popup Window

To update the CP-R25 Desktop Programmer firmware:

1. In the File menu click Options > Firmware Programming. The

Desktop Reader Firmware Programming

Figure 24: AS-B01 Desktop Reader Firmware Programming

window opens.

2. [Optional] You can change the default firmware location that is displayed

.bin file location

in the a. Click Browse.

The standard Windows Explorer window opens.

b. Navigate to the folder containing the binary firmware file to

download.

c. Select the binary firmware file.

3. Make sure the USB cable is disconnected from the CP-R25 Desktop Programmer. If the cable is still connected, a window opens telling you to disconnect the cable.

40 CP-R25 Hardware and AS-B01 Software Manual

field:

Global Options

Figure 25: Disconnect USB Cable

The indicator at the left bottom side of the screen displays Disconnected.

4. Click OK. You return to the

Desktop Reader Firmware Programming

5. Click OK. The Connect Cable window opens.

Figure 26: Connect USB Cable

6. Connect the USB Cable.

7. Wait until the indicator at the left bottom side of the screen displays Connected.

The installation automatically begins. On completion, a confirmation screen opens.

8. Click OK. The Desktop firmware is now updated. Two more messages should immediately follow in the Message window:

"Mifare

Programming Reader Disconnected" and "Mifare® Programming

Reader Connected". The Desktop Programmer is now ready for use.

Be careful not to select a wrong firmware file, as it may cause permanent Desktop reader hardware failure.

window.

CP-R25 Hardware and AS-B01 Software Manual 41

Maintenance

A. Maintenance

To maximize the lifetime of the product, we recommend following these guidelines as closely as possible.

 Do not expose the unit to water or rain or to humidity over the specified

safety level.

 Do not expose the unit to direct sunlight for extended periods. This can

cause overheating and system failure.

 Avoid dropping the unit onto the ground. This may cause

electromechanical failure.

42 CP-R25 Hardware and AS-B01 Software Manual

Field Descriptions

B. Field Descriptions

The following table describes the various fields that appear in the AS-B01 software application when configuring the CP-R25 Desktop Programmer, Mifare® cards and/or tags:

Table 2: Field Descriptions

Field Name Description

Card Serial Number (CSN) In the

Card Type

Confirm Password Used to confirm a new password entered in the

Current Password Password used to enter the AS-B01 software application,

Enable Buzzer Activates or deactivates the reader’s buzzer control. Enable LED Activates or deactivates the reader’s LED control. Failed operation Enables the reader to transmit to the panel any failed

ID Location All sectors in the Mifare® card contain 3 blocks of 16 bytes

KeyA Password Unique key used as a security access code. This code used

Keypad Defines the keypad type used to enter codes on an access

Operation Mode

reader has to transmit only the card serial number. Each

Mifare

card has a Unique Serial Number (UID) to uniquely

identify the card.

• The Mifare memory location on the card. There are two options:

• Mifare

1K memory – The 1024 x 8 bit EEPROM memory is organized in 16 sectors with 4 blocks of 16 bytes each. In the erased state the EEPROM cells are read as a logical “0”, in the written state as a logical “1”.

4K memory – The 4096 x 8 bit EEPROM memory is organized in 32 sectors with 4 blocks and 8 sectors with 16 blocks. Each block contains 16 bytes. In the erased state the EEPROM cells are read as a logical “0”, in the written state as a logical “1”.

area this option is selected if the

card type determines the size and

New

Password

and when changing the password.

operations. These are then displayed in the Message Log Area of the GUI.

for storing data. This parameter defines where the data is stored in these data blocks. The location is defined by the company security specifications.

is specified by the company security policies. The key is entered as a 12 digit hexadecimal value with digit values of 0-9, A-F.

reader.

field.

CP-R25 Hardware and AS-B01 Software Manual 43

Field Descriptions

Field Name Description

Lockout Attempts Defines the number times a user can present a wrong card

Lockout Duration Defines how long a card is locked out of the system after

New Password Field used to enter a new password. Passwords are case

Reader KeyA The Mifare® card storage is divided into sectors with each

Sector In the

Transmit Format Wiegand protocol is a secure transmission format where

Mifare® User Card ID Unique ID assigned to the card. This ID number is obtained

or swipe an unverified fingerprint before the reader locks the door for a predefined period of time.

too many invalid attempts at swiping the card through the reader or fingerprint scanned due to some inconsistencies with the configured card being used.

sensitive. For higher security, make sure that the passwords you choose are more than 4 letters. Mixing letters and numbers also substantially strengthens the password.

sector being protected by two different keys, KeyA and KeyB. These keys are programmable according to company security specifications. KeyB is not supported.

Operation Mode

reader has to transmit encrypted data from the card secured memory. More screen options are added when selecting Sector mode including the

ID Location

access control is required. The different bit configuration is used to define different security options specified by the company security officer.

from the company security officer. The ID number is a numeric with a range of 0 – 16777215.

fields.

area this option is selected if the

Reader KeyA

and the

44 CP-R25 Hardware and AS-B01 Software Manual

Additional Mifare® Card Memory Map Information

C. Additional Mifare® Card Memory

Map Information

C.1 Manufacture Block

This is the first data block (block 0) of the first sector (sector 0). It contains the IC manufacturer data. Because of security and system requirements, this block is write-protected after having been programmed by the IC manufacturer at production.

When the Rosslare Mifare number", the Unique ID of the card is read from manufacture block.

C.2 Data Blocks

All sectors contain 3 blocks of 16 bytes for storing data (Sector 0 contains only two data blocks and the read-only manufacturer block).

The data blocks can be configured by the access bits as:

 Read/write blocks (for example, contactless access control)  Value blocks (for example, electronic purse applications – not supported

by AS-B01).

An authentication command must be carried out before any memory operation to allow further commands. Authentication commands are based on KeyA, KeyB, and on Access Condition bits. AS-B01 supports programming only KeyA, thus both Access Bits and KeyB modifications are not supported; their location in the following diagram is indicated in black.

reader operation mode is configured to "card serial

CP-R25 Hardware and AS-B01 Software Manual 45

Additional Mifare® Card Memory Map Information

Figure 27: Mifare® 1K Memory Diagram

For further details about Mifare® cards, refer to the NXP Semiconductor

Mifare

datasheet.

46 CP-R25 Hardware and AS-B01 Software Manual

Sample Worksheets

D. Sample Worksheets

When entering information, the information must be obtained from the company security officer. To assist in preparing the information to be entered, the following sample form can be used.

Employee Security Card Configuration

Field Configuration

Employee Name Employee ID # Employee Company ID Employee Dept. Card Serial Number (if applicable) Reader KeyA Transmit Format Card Type (1K or 4K) ID Location – Sector Number ID Location – Block Number

ID Location – Byte Number Mifare® User Card ID Number of Fingerprints (1 or 2) LED Control Buzzer Control Lockout Attempts Lockout Duration Batch Order Code

CP-R25 Hardware and AS-B01 Software Manual 47

Limited Warranty

E. Limited Warranty

ROSSLARE’S TWO-YEAR LIMITED WARRANTY is applicable worldwide. This warranty supersedes any other warranty. ROSSLARE'S TWO-YEAR LIMITED WARRANTY is subject to the following conditions:

ARRANTY

Warranty of ROSSLARE'S products extends to the original purchaser (Customer) of the ROSSLARE product and is not transferable.

PRODUCTS COVERED BY THIS WARRANTY AND DURATION

ROSSLARE warrants that the CP-R25 Mifare® Card & Tag Programmer and Fingerprint Enroller to be free from defects in materials and assembly in the course of normal use and service. The warranty period commences with the date of shipment to the original purchaser and extends for a period of 2 years (24 months).

ARRANTY REMEDY COVERAGE

In the event of a breach of warranty, ROSSLARE will credit Customer with the price of the Product paid by Customer, provided that the warranty claim is delivered to ROSSLARE by the Customer during the warranty period in accordance with the terms of this warranty. Unless otherwise requested by a ROSSLARE representative, return of the failed product(s) is not immediately required.

If ROSSLARE has not contacted the Customer within a sixty (60) day holding period following the delivery of the warranty claim, Customer will not be required to return the failed product(s). All returned Product(s), as may be requested at ROSSLARE’S sole discretion, shall become the property of ROSSLARE.

To exercise the warranty, the user must contact ROSSLARE Enterprises Ltd. to obtain an RMA number after which, the product must be returned to the Manufacturer freight prepaid and insured.

In the event ROSSLARE chooses to perform a product evaluation within the sixty (60) day holding period and no defect is found, a minimum US$ 50.00 or equivalent charge will be applied to each Product for labor required in the evaluation.

ROSSLARE will repair or replace, at its discretion, any product that under normal conditions of use and service proves to be defective in material or workmanship. No charge will be applied for labor or parts with respect to defects covered by this warranty, provided that the work is done by ROSSLARE or a ROSSLARE authorized service center.

48 CP-R25 Hardware and AS-B01 Software Manual

Limited Warranty

EXCLUSIONS AND LIMITATIONS

ROSSLARE shall not be responsible or liable for any damage or loss resulting from the operation or performance of any Product or any systems in which a Product is incorporated. This warranty shall not extend to any ancillary equipment not furnished by ROSSLARE, which is attached to or used in conjunction with a Product, nor to any Product that is used with any ancillary equipment, which is not furnished by ROSSLARE.

This warranty does not cover expenses incurred in the transportation, freight cost to the repair center, removal or reinstallation of the product, whether or not proven defective.

Specifically excluded from this warranty are any failures resulting from Customer's improper testing, operation, installation, or damage resulting from use of the Product in other than its normal and customary manner, or any maintenance, modification, alteration, or adjustment or any type of abuse, neglect, accident, misuse, improper operation, normal wear, defects or damage due to lightning or other electrical discharge. This warranty does not cover repair or replacement where normal use has exhausted the life of a part or instrument, or any modification or abuse of, or tampering with, the Product if Product disassembled or repaired in such a manner as to adversely affect performance or prevent adequate inspection and testing to verify any warranty claim.

ROSSLARE does not warrant the installation, maintenance, or service of the Product. Service life of the product is dependent upon the care it receives and the conditions under which it has to operate.

In no event shall ROSSLARE be liable for incidental or consequential damages.

IMITED WARRANTY TERMS

HIS WARRANTY SETS FORTH THE FULL EXTENT OF ROSSLARE’S WARRANTY.

HE TERMS OF THIS WARRANTY MAY NOT BE VARIED BY ANY PERSON, WHETHER OR NOT

PURPORTING TO REPRESENT OR ACT ON BEHALF OF

HIS LIMITED WARRANTY IS PROVIDED IN LIEU OF ALL OTHER WARRANTIES. ALL OTHER WARRANTIES EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE SPECIFICALLY EXCLUDED.

N NO EVENT SHALL ROSSLARE BE LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, OR FOR ANY OTHER INCIDENTAL, CONSEQUENTIAL OR SPECIAL DAMAGES, INCLUDING BUT NOT LIMITED TO LOSS OF USE, LOSS OF TIME, COMMERCIAL LOSS, INCONVENIENCE, AND LOSS OF PROFITS, ARISING OUT OF THE INSTALLATION, USE, OR INABILITY TO USE SUCH PRODUCT, TO THE FULLEST EXTENT THAT ANY SUCH LOSS OR DAMAGE MAY BE DISCLAIMED BY LAW.

HIS WARRANTY SHALL BECOME NULL AND VOID IN THE EVENT OF A VIOLATION OF THE

PROVISIONS OF THIS LIMITED WARRANTY.

ROSSLARE.

CP-R25 Hardware and AS-B01 Software Manual 49

Asia Pacific, Middle East, Africa

Rosslare Enterprises Ltd. Kowloon Bay, Hong Kong Tel: +852 2795-5630 Fax: +852 2795-1508 support.apac@rosslaresecurity.com

United States and Canada

Rosslare Security Products, Inc. Southlake, TX, USA Toll Free: +1-866-632-1101 Local: +1-817-305-0006 Fax: +1-817-305-0069 support.na@rosslaresecurity.com

Europe

Rosslare Israel Ltd. Rosh HaAyin, Israel Tel: +972 3 938-6838 Fax: +972 3 938-6830 support.eu@rosslaresecurity.com

CP-R25 & AS-B01

Latin America

Rosslare Latin America Buenos Aires, Argentina support.la@rosslaresecurity.com

China

Rosslare Electronics (Shenzhen) Ltd. Shenzhen, China Tel: +86 755 8610 6842 Fax: +86 755 8610 6101 support.cn@rosslaresecurity.com

0706-0960349+01

Rosslare Mifare CP-R25, Mifare AS-B01 Hardware And Software Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Introduction

1.1 The CP-R25 System

1.2 Desktop Convenience

1.3 Intuitive Software System

1.4 Compatibility

1.5 Main Features

1.6 CP-R25 Desktop Programmer

1.7 AS-B01 Software

2. Specifications and Requirements

2.1 CP-R25 Hardware Specifications

2.2 AS-B01 Software Requirements

3. Installation

3.1 Unpacking the Equipment

3.2 CP-R25 Description

3.3 AS-B01 Software Installation

3.4 Connecting the CP-R25

AS-B01 Software Overview and LEDs

4.1 Software Overview

4.2 Indication LEDs

5. Programming Cards and Tags

5.1 Programming a Master Card

5.2 Programming a Configuration Card

5.2.1 Sector Reader Configuration Cards

5.2.2 Fingerprint Swipe Reader Configuration Cards

5.3 Programming User Cards or Tags

5.3.1 Programming a Sector Reader User Card

5.3.2 Programming and Enrolling Fingerprint User Card

6. Additional Programmer Utilities

6.1 Card Utilities

6.1.1 Reading a Configuration Card

6.1.2 Reading an ID from a User Card

6.1.3 Programming a User Card ID

6.1.4 Changing the User Card KeyA in a Specific Sector

6.1.5 Changing the User Card KeyA in All Sectors

6.1.6 Erasing Specific User Card Data

6.1.7 Read Serial Number and Card Type

6.1.8 Changing KeyA and Erasing All Data

6.2 Fingerprint Utilities

6.2.1 Enrolling Fingerprints on a Pre-configured User Card

6.2.2 Verifying Fingerprint Enrollment on a User Card

7. Global Options

7.1 Change Password

7.2 Card Overwrite

7.3 Updating Firmware
