Rosslare MD-CC101 Installation Instructions Manual

MD-CC101

Installation Instructions GSM Communication Stick

1

0706-0960371+00

1. Introduction

Th e M D -CC101, " GSM Stick" is a dedicated GSM module
designed to fit snugly in the Hom eLog iX

TM

Th e M D -CC101 uses GSM communications to back up the
telephone line (PSTN) in case of telephone line failure, or else
it acts as the primary reporting mean.

alarm panel series.

Whe n using the MD-CC101 GSM module the system also
allows private phone to receive both voice and SM S
messages (alerts, troubles, bypass, arm/disarm), the user c a n
also se n d commands to the system via SM S m e ss a g e s,
allowing arming (home/away), disarming , PG M activatio n /
deactivation.

• Fu l l e v e n t r e p o r t i n g

• Contact ID reporting protocol

• 2-way voice communication

• GSM communication - via GSM Qua d Ba nd 900 / 1800

MHz or 850 / 1900 MHz modem

• Th r e e o p e r a t i n g m o d e s - backup for the control dialer,

primary alarm communicator and parallel reporting
channel

• Priva t e v o ic e / SM S re p o rti ng

• Compatible with Rosslare’s HomeLogiX

TM

• Pa ne l re m ot e u p lo a d ing / d o w nlo a d ing su p po rt via GSM

wireless

control panels

• Quad freq uencies band s for worldwide coverage

• Re m o t e l y u p g ra d e f i rm w a re

2. Technical Specifications

2.1 ELECTRICAL SPECIFICATIONS

Input Voltage 3.4V – 4.5V (from c o n tro l p a nel)
Current consumption

Tr a n s m i t : 2 m A

St a n d b y : 1 . 2 A

Ex t e r n a l A n t e n n a 50 O h m a n tenn a
Modem type GSM Quad band
Fre quency range GSM 850, EGSM 900, DSC 1800,

PC S 19 00 (M Hz)

GSM Class Sm a l l M S
SI M c a r d su p p o r t 1.8V , 3V
Se r ia l p o r t 115200 b p s

2.2 ENVIRONMENTAL SPECIFICATIONS

Operating environment Ind o or u se
Operating temperature -30°C to 80°C ( -22°F t o 176°F)
St o r a ge Te m p e r a t u r e -45°C to 90°C ( -49°F t o 194°F)
Operating humidity

0% t o 85% (Non-Condensing)

2.3 PHYSICAL SPECIFICATIONS

Dime nsions 16.2 x 7 c m (6.38 x 2.75 inc h )
We ig ht 68 g (2.4 oz.)

3. Installation

3.1 General

Th e M D -CC101 is intended for use with the HLX-40 fa m ily t hu s
enhancing the system’s performance by allowing GSM
communication used as a backup line communication,
when a problem occur with the PSTN line.

Th e MD-CC101 GSM St i c k module also allows private phone
to receive both voice and SM S m e ss a g e s (alerts, tro ub les,
bypass, arm/disarm) from the HLX-40 syst e m , the user c a n
also se n d commands to the system via SM S m e ss a g e s,
allowing arming (home/away), disarming , PG M activatio n /
deactivation.

3.2 Installing the MD-CC101 GSM Stick

1. Insert the GSM stick into the conne ctor slots loca ted on
the ba c k of the HLX-40 see the insta lla tio n fig ure.

2. Ti g h t e n t h e p l a c e m e n t sc re w s o n b o t h s i d e s o f t h e G SM
St i c k t o s e c u r e o n t o t h e p a n e l .

Note:. Whe n using th e HL-X40 w it h t he M D-CC101 unit

attached, make sure to place the unit in a location
with strong GSM reception.

3. Open the SIM holder by sliding it sideways. Insert the SIM
card into the holder and close the holder.

Note: En su r e t h a t t h e s y st e m i s p o w e r e d o f f b e f o r e
attempting to install the MD-CC101 and inserting the
SI M c a r d .

2

0706-0960371+00

3.3 Activating the DC-101 GSM Stick

Th e H L X -40 system a uto m a tic a lly d ete c ts t he a va ila b ility o f
the MD-CC101 GSM stick upon initial power up of the system,
the HLX-40 will a lso te st the re c ep tion levels and d isplay them
on the screen, the recep tion must be above 21.00 for b e
re a dy use.

After installation of the MD-CC101 GSM Stick, relevant menus
and options will be available in the HLX-40 m e n u syste m .

Th e G SM St i c k e n h a n c e m e n t o n l y w o r k s i n c onjunction with a
battery pack.

4. Limited Warranty

ROSSLARE ENTERPRISES LIMITED S (Rosslare) ONE YEAR LIMITED
WARRANTY is applicable worldwide. This warranty supersedes any other
warranty. Rosslare's ONE YEAR LIMITED WARRANTY is subject to the
following conditions:

Warranty of Rosslare's products extends to the original purchaser (Customer)
of the Rosslare product and is not transferable.

Warranty

ROSSLARE ENTERPRISES LTD. AND / ORSUBSIDIARIES (ROSSLARE)
warrants that the MD-CC101 GSM Stick, to be free from defects in materials
and assembly in the course of normal use and service. The warranty period
commences with the date of shipment to the original purchaser and extends
for a period of 1 year (12 Months).

Products Covered By This Warranty and Duration

In the event of a breach of warranty, ROSSLARE will credit Customer with the
price of the Product paid by Customer, provided that the warranty claim is
delivered to ROSSLARE by the Customer during the warranty period in
accordance with the terms of this warranty. Unless otherwise requested by
ROSSLARE ENTERPRISES LTD. AND / OR SUBSIDIARIES representative,
return of the failed product(s) is not immediately required.

Warranty Remedy Coverage

If ROSSLARE has not contacted the Customer within a sixty (60) day holding
period following the delivery of the warranty claim, Customer will not be
required to return the failed product(s). All returned Product(s), as may be
requested at ROSSLARE ENTERPRISES LTD. AND /OR SUBSIDIARY’S sole
discretion, shall become the property of ROSSLARE ENTERPRISES LTD.
AND /OR SUBSIDIARIES.
To exercise the warranty, the user must contact Rosslare Enterprises Ltd. to
obtain an RMA number after which, the product must be returned to the
Manufacturer freight prepaid and insured
In the event ROSSLARE chooses to perform a product evaluation within the
sixty (60) day holding period and no defect is found, a minimum US$ 50.00 or
equivalent charge will be applied to each Product for labor required in the
evaluation.
Rosslare will repair or replace, at its discretion, any product that under normal
conditions of use and service proves to be defective in material or
workmanship. No charge will be applied for labor or parts with respect to
defects covered by this warranty, provided that the work is done by Rosslare
or a Rosslare authorized service center.

ROSSLARE shall not be responsible or liable for any damage or loss resulting
from the operation or performance of any Product or any systems in which a
Product is incorporated. This warranty shall not extend to any ancillary

equipment not furnished by ROSSLARE, which is attached to or used in
conjunction with a Product, nor to any Product that is used with any ancillary
equipment, which is not furnished by ROSSLARE.

Exclusions and Limitations

This warranty does not cover expenses incurred in the transportation, freight
cost to the repair center, removal or reinstallation of the product, whether or
not proven defective.
Specifically excluded from this warranty are any failures resulting from
Customer's improper testing, operation, installation, or damage resulting from
use of the Product in other than its normal and customary manner, or any
maintenance, modification, alteration, or adjustment or any type of abuse,
neglect, accident, misuse, improper operation, normal wear, defects or
damage due to lightning or other electrical discharge. This warranty does not
cover repair or replacement where normal use has exhausted the life of a part
or instrument, or any modification or abuse of, or tampering with, the Product if
Product disassembled or repaired in such a manner as to adversely affect
performance or prevent adequate inspection and testing to verify any warranty
claim.
ROSSLARE does not warrant the installation, maintenance, or service of the
Product. Service life of the product is dependent upon the care it receives and
the conditions under which it has to operate.
In no event shall Rosslare be liable for incidental or consequential damages.

THIS WARRANTY SETS FORTH THE FULL EXTENT OF ROSSLARE
ENTERPRISES LTD

. AND IT’S SUBSIDIARIES’S WARRANTY

Limited Warranty Terms

70BTHE TERMS OF THIS WARRANTY MAY NOT BE VARIED BY ANY PERSON,

WHETHER OR NOT PURPORTING TO REPRESENT OR ACT ON BEHALF OF
ROSSLARE

.

71BTHIS LIMITED WARRANTY IS PROVIDED IN LIEU OF ALL OTHER

WARRANTIES

. ALL OTHER WARRANTIES EXPRESSED OR IMPLIED,

INCLUDING WITHOUT LIMITATION

, IMPLIED WARRANTIES OF

MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE

, ARE

SPECIFICALLY EXCLUDED

.

72BIN NO EVENT SHALL ROSSLARE BE LIABLE FOR DAMAGES IN EXCESS OF

THE PURCHASE PRICE OF THE PRODUCT

, OR FOR ANY OTHER INCIDENTAL,

CONSEQUENTIAL OR SPECIAL DAMAGES

, INCLUDING BUT NOT LIMITED TO

LOSS OF USE

, LOSS OF TIME, COMMERCIAL LOSS, INCONVENIENCE, AND

LOSS OF PROFITS

, ARISING OUT OF THE INSTALLATION, USE, OR INABILITY

TO USE SUCH PRODUCT

, TO THE FULLEST EXTENT THAT ANY SUCH LOSS

OR DAMAGE MAY BE DISCLAIMED BY LAW

.

73BTHIS WARRANTY SHALL BECOME NULL AND VOID IN THE EVENT OF A

VIOLATION OF THE PROVISIONS OF THIS LIMITED WARRANTY

.
