Rosslare HLX24G User Manual

Download

HLX-24

Advanced Wireless Security Panel

Hardware Installation and Programming Manual

Models:

HLX-24 HLX-24IP

This manual and the information contained herein are proprietary to ROSSLARE ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’ (hereafter: "ROSSLARE"). Only ROSSLARE and its customers have the right to use the information.

No part of this manual may be re-produced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of ROSSLARE.

ROSSLARE owns patents and patent applications, trademarks, copyrights, or other intellectual property rights covering the subject matter in this manual.

TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL PROCEEDINGS.

The furnishing of this manual to any party does not give that party or any third party any license to these patents, trademarks, copyrights or other intellectual property rights, except as expressly provided in any written agreement of ROSSLARE.

ROSSLARE reserves the right to revise and change this document at any time, without being obliged to announce such revisions or changes beforehand or after the fact.

Table of Contents

1. Introduction ..................................................................... 10

1.1 General ............................................................................................ 10

1.2 Special Features ................................................................................ 10

2. HLX-24 Quick Reference .................................................. 11

2.1 The Panel .......................................................................................... 11

2.2 The Keypad ...................................................................................... 12

2.2.1 Keypad Operated Functions ....................................................................... 13

2.3 Sound Indicators ............................................................................... 14

2.4 LED Indicators ................................................................................... 14

3. Specifications .................................................................. 16

3.1 RF Data............................................................................................. 16

3.2 Environmental Data .......................................................................... 16

3.3 Electrical Data ................................................................................... 16

3.4 Communication ................................................................................ 17

4. Installation ...................................................................... 18

4.1 Unpacking the Equipment................................................................. 18

4.1.1 HLX-24 Package Content ........................................................................... 18

4.2 Supply Power to the Unit .................................................................. 18

4.3 Planning and Programming ............................................................... 18

4.4 Wiring the System ............................................................................ 19

4.5 Connecting the AC Transformer ....................................................... 20

4.6 Connecting to a PC .......................................................................... 20

4.7 Mounting the Back Plate ................................................................... 20

4.7.1 General ..................................................................................................... 20

4.7.2 Required Space ......................................................................................... 21

4.8 Dismounting the Control Panel ......................................................... 22

4.9 Replacing the Backup Batteries ......................................................... 22

HLX-24 Hardware Installation and Programming Manual iii

Table of Contents

5. Programming the HLX-24 ............................................... 23

6. Installer Menu ................................................................. 24

6.1 Change Code ................................................................................... 25

6.2 Zones ............................................................................................... 25

6.3 Enrolling ........................................................................................... 27

6.3.1 Detectors .................................................................................................. 28

6.3.2 Remote Controls (KE-30 RFID Function) ...................................................... 28

6.3.3 RF Siren ..................................................................................................... 29

6.3.4 Keypads .................................................................................................... 29

6.3.5 Repeaters .................................................................................................. 30

6.4 Security ............................................................................................ 30

6.4.1 Exit Delay .................................................................................................. 31

6.4.2 Exit Restart ................................................................................................ 32

6.4.3 Entry Delay ................................................................................................ 32

6.4.4 Auto Arming ............................................................................................. 32

6.4.5 Siren Time ................................................................................................. 33

6.4.6 Siren Mode ............................................................................................... 33

6.4.7 Local Siren ................................................................................................ 33

6.4.8 External Siren ............................................................................................ 33

6.4.9 Supervision Time ....................................................................................... 33

6.4.10 Jamming ................................................................................................... 34

6.4.11 No Activity Time ........................................................................................ 34

6.4.12 Trouble Beeps ........................................................................................... 34

6.4.13 Bypass Option ........................................................................................... 35

6.4.14 Quick Arm ................................................................................................ 35

6.4.15 Arm Instant ............................................................................................... 35

6.4.16 Panic Button .............................................................................................. 36

6.4.17 Duress Code .............................................................................................. 36

6.4.18 Alarm Cancel ............................................................................................ 36

6.4.19 Alarm Abort Time ...................................................................................... 37

6.4.20 Backlight Time ........................................................................................... 37

6.4.21 Hide Display .............................................................................................. 37

6.4.22 Key Beeps ................................................................................................. 38

6.4.23 Select Language ........................................................................................ 38

6.4.24 EN-CENELEC ............................................................................................. 38

iv HLX-24 Hardware Installation and Programming Manual

Table of Contents

6.4.25 CP-01 ....................................................................................................... 39

6.5 Communications .............................................................................. 41

6.5.1 System Telephone ..................................................................................... 42

6.5.2 Private Report ............................................................................................ 42

6.5.3 CS Report Setup ........................................................................................ 43

6.5.4 Line Test ................................................................................................... 45

6.5.5 AC Fail Report ........................................................................................... 45

6.5.6 Fax Defeat ................................................................................................. 45

6.5.7 Number of Rings ....................................................................................... 45

6.5.8 Select Region/Country ............................................................................... 46

6.6 Automation ...................................................................................... 46

6.6.1 Keypad Manual ......................................................................................... 46

6.6.2 Set Triggers ............................................................................................... 47

6.7 Messages .......................................................................................... 47

6.7.1 Keypad Mute ............................................................................................ 48

6.7.2 House Name ............................................................................................. 48

6.7.3 Custom Zones ........................................................................................... 48

6.8 Maintenance .................................................................................... 49

6.8.1 Factory Defaults......................................................................................... 49

6.8.2 RF Test ...................................................................................................... 49

6.8.3 Test Indicators ........................................................................................... 50

6.8.4 Sirens Test ................................................................................................. 50

6.8.5 Test Devices .............................................................................................. 50

7. User Menu Structure ....................................................... 51

8. Reading the Event Log ................................................... 53

A. Quick Reference to Installer Menu ................................ 54

B. Quick Reference to User Menu ...................................... 56

C. Sensor Placement and Helpful Reference Tables ........ 57

C.1 Default Zone Descriptions ................................................................. 57

C.2 Custom Zone Descriptions ................................................................ 58

C.3 Detector Deployment Plan ................................................................ 58

C.4 Remote Control ................................................................................ 59

HLX-24 Hardware Installation and Programming Manual v

Table of Contents

D. Reporting Codes .............................................................. 60

E. GSM Stick Errors .............................................................. 62

F. Settings Requirements for CENELEC ............................. 63

G. Default Parameter Values .............................................. 64

H. Labeling Instructions ...................................................... 69

I. Declaration of Conformity ............................................. 70

J. Limited Warranty ............................................................ 71

vi HLX-24 Hardware Installation and Programming Manual

List of Figures

Figure 1: HLX-24 Panel ................................................................................. 11

Figure 2: HLX-24 Keypad .............................................................................. 12

Figure 3: Panel Wiring .................................................................................. 19

Figure 4: Back Plate Wiring ........................................................................... 20

Figure 5: Back Plate Mounting Holes ............................................................ 21

Figure 6: Backup Batteries ............................................................................ 22

HLX-24 Hardware Installation and Programming Manual vii

List of Tables

Table 1: Control Panel Functions .................................................................. 11

Table 2: Keypad Functions ............................................................................ 12

Table 3: Keypad Operated Functions............................................................. 13

Table 4: Sound Indicators ............................................................................. 14

Table 5: Power LED Indicator ........................................................................ 14

Table 6: Status LED Indicator ........................................................................ 14

Table 7: Keypad Function Indicators ............................................................. 15

Table 8: HLX-24 Connections ....................................................................... 19

Table 9: CP01 Menu..................................................................................... 39

Table 10: Trigger Type and Parameters ......................................................... 47

Table 11: User Menu Structure ..................................................................... 51

Table 12: Installer Menu ............................................................................... 54

Table 13: User Menu .................................................................................... 56

Table 14: List of CID Codes .......................................................................... 60

Table 15: GSM Stick Errors ........................................................................... 62

viii HLX-24 Hardware Installation and Programming Manual

Notice and Disclaimer

This manual’s sole purpose is to assist installers and/or users in the safe and efficient installation and usage of the system and/or product, and/or software described herein.

EFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM, THE INSTALLER AND

THE USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY

REQUIREMENTS AND OPERATING PROCEDURES

 The system must not be used for purposes other than those for which it

was designed.

 The use of the software associated with the system and/or product, if

applicable, is subject to the terms of the license provided as part of the purchase documents.

 ROSSLARE exclusive warranty and liability is limited to the warranty and

liability statement provided in an appendix at the end of this document.

 This manual describes the maximum configuration of the system with the

maximum number of functions, including future options. Therefore, not all functions described in this manual may be available in the specific system and/or product configuration you purchased.

 Incorrect operation or installation, or failure of the user to effectively

maintain the system, relieves the manufacturer (and seller) from all or any responsibility for consequent noncompliance, damage, or injury.

 The text, images and graphics contained in the manual are for the

purpose of illustration and reference only.

 All data contained herein is subject to change without prior notice.  In no event shall manufacturer be liable for any special, direct, indirect,

incidental, consequential, exemplary or punitive damages (including, without limitation, any and all damages from business interruption, loss of profits or revenue, cost of capital or loss of use of any property or capital or injury).

 All graphics in this manual are for reference only, some deviation between

the image(s) and the actual product may occur.

 All wiring diagrams are intended for reference only, the photograph or

graphic of the PCB(s) are intended for clearer illustration and understanding of the product and may differ from the actual PCB(s).

HLX-24 Hardware Installation and Programming Manual ix

Introduction

1. Introduction

1.1 General

The HLX-24 panel by Rosslare is the perfect wireless security system for intrusion protection of the home, or small office providing security monitoring and VIP Voice messaging.

Users receive the latest RF technology in a wide selection of advanced wireless sensors and remotes, and benefit from smooth and easy operation of a large number of security and communication options.

The HLX-24 panel is easy to install and set up via local programming and via direct or modem connection to a PC running the HLX-24 PC Software.

The panel has two full split reporting features for communicating to central station for Contact ID and voice enabled event reporting and vocal communications.

VIP features include option to provide status to the user via telephone and an option to activate arming options by using DTMF phone communication for up to three destinations by calling the user when there is an issue.

In addition to the regular version of the HLX-24 control panel, the HLX-24IP version allows users to control and monitor the status of the panel by using the HLX-24 mobile application, HomeLogiX™APP from a smartphone. For more information see the

1.2 Special Features

 24 wireless zones  Supports 8 remote controls, 4 wireless sirens, 4 wireless keypads, and 4

repeaters

 Programmable remote control buttons  Interactive telephone voice menu  PGM automation features  Five custom textual zone descriptions  Advanced testing and diagnostics options  Lockout feature upon wrong code entry  Programmable No Activity timer

HLX-24 Mobile Application User Manual

10 HLX-24 Hardware Installation and Programming Manual

HLX-24 Quick Reference

Power Indicator

2. HLX-24 Quick Reference

This chapter describes the control panel and the keypad, as well as the chimes emitted when the buttons on the keypad are pressed.

2.1 The Panel

Figure 1 presents the components of the wireless panel.

Figure 1: HLX-24 Panel

Display

Status Indicator

Keypad Door

Table 1: Control Panel Functions

Display

Power Indicator

Status Indicator

Keypad Door

LCD display

Power LED: green FLASHING when there is an AC power failure and during

Walk Test

Status LED: green On: system armed Off: system disarmed Flash: entry and exit delay (according to beep rate) FLASHING without beeps during Walk Test

Open to access the keypad buttons

HLX-24 Hardware Installation and Programming Manual 11

HLX-24 Quick Reference

2.2 The Keypad

Figure 2 shows the HLX-24 keypad.

Figure 2: HLX-24 Keypad

Table 2 describes the keypad functions:

Table 2: Keypad Functions

Key Icon Function

Panic

Keys 0 – 9

Arm Away

Arm Home

Disarm

When pressed for 3 seconds a standard panic alarm sounds

Enters alphanumeric entries Press 0 to enter a space

Arms all sensors and detectors for use when there is no one at home/office

Arms all perimeter sensors and detectors as defined by the installer (for use when home/office is occupied)

Disarms all armed sensors and detectors

ESC/Back

Enter

Up/Down Arrows

Ignores an entry or moves one level up in a menu

Accepts an entry or selection

Use to navigate between menus

12 HLX-24 Hardware Installation and Programming Manual

HLX-24 Quick Reference

2.2.1 Keypad Operated Functions

When the system is idle, the alphanumeric keys initiate the commands shown in Table 3.

Table 3: Keypad Operated Functions

Press Icon To

7 Record User Message

Memory Display

Press once to display the alarms caused during the last arming period per zone. The first line of the displays shows the alarm memory, and the second line shows the zone description, event and time. The display toggles between zone description and the date by pressing Enter.

Press Menu to display the next alarmed zone. Press Esc to exit.

Note: When EN-CENELEC standard is enabled, only the master

user can access the memory display.

PGM ON

Press once to turn on the PGM.

PGM OFF

Press once to turn off the PGM.

Chime ON/OFF

Manually toggle the chime on and off

Volume

Manually toggle the beep volume level

Mute ON/OFF

Manually toggle keypad tone and other sounds on and off

Bypass

Enter the User menu Bypass option

Record a voice message of up to 15 seconds. Press and hold key 7 for 3 seconds to erase a message.

Event Log Display

Press once to display the event log. The first line of the display shows the event log and the second line shows the zone description (or system, if a system event is displayed), event date and time. The display toggles between zone description and the date by pressing Enter.

Press again or press Menu to display the next event. Press Esc to exit the menu. Note that a Master code is required to access this function.

HLX-24 Hardware Installation and Programming Manual 13

HLX-24 Quick Reference

2.3 Sound Indicators

Table 4 presents the sounds emitted by the system and push buttons if enabled during programming.

Table 4: Sound Indicators

Sound Sounded when

Single beep

Long Beep

Three short beeps

Four short beeps a minute

Short beep every second

Chime

This table does not include actual alarm sounds.

Note that the audible indication of a fire zone differs from that of a normal intrusion zone.

2.4 LED Indicators

Table 5, Table 6, and Table 7 describe the LED indicators of the various panel indicators.

A key is pressed

There is an illegal key entry

An entry is successfully accepted

If enabled, on trouble condition

An exit/entry delay is activated (beep sounded every 0.5 seconds during last 10 seconds of delay)

When feature is activated (1 chime sounds)

Table 5: Power LED Indicator

Power LED

Status

(Red/Green)

Green ON Normal AC mode

FLASHES red every 0.5 seconds AC Failure

Table 6: Status LED Indicator

Status LED

Status

(Red/Green)

Green ON Panel ready Red ON Panel not ready

Green FLASHES every 1 second Walk Test mode

14 HLX-24 Hardware Installation and Programming Manual

HLX-24 Quick Reference

Table 7: Keypad Function Indicators

Panel

Panic

Arm Away

Arm Home Disarm

Status

Disarm OFF OFF OFF ON

Arm Home OFF OFF ON OFF Arm Away OFF ON OFF OFF

Arming Home OFF OFF FLASHES every 1

Arming Away OFF FLASHES

every 1 second (until last 10 seconds flashes every

0.5 seconds)

Panic ON Previous LED

status continues

second (until last 10 seconds flashes every 0.5 seconds)

OFF OFF

Previous LED status continues

OFF

Previous LED status continues

HLX-24 Hardware Installation and Programming Manual 15

Specifications

3. Specifications

This chapter provides the various specifications for the HLX-24 control panel.

3.1 RF Data

RF Unit Type

Antenna Type

Operating Frequencies

Receiver Sensitivity

Transmitter Power

Range (open field)

RF Device ID Coding

Integrated RF transceiver shielded super heterodyne, fixed frequency

Printed PCB type antenna

G series – 433.92 MHz H series – 868.35 MHz Up to -100 dBm

Up to +10 dBm, less based on country requirements

Up to 170 m (558 ft) in open space for detectors, and 110 m (361 ft) for hand-held remote controls

Three-bytes non-replicated per sensor type, or multiples of 16 million possible codes, make it almost impossible to have two like coded transmitters

The HLX-24 system has optimum range if installed according to the manufacturer’s recommendations, though this range may be affected by radio noise from high-power nearby sources, or interference with the signal (blocking) by large metal surfaces, or multiple concrete walls.

3.2 Environmental Data

Operation Temperature Range 0ºC to 40ºC (32ºF to 104ºF)

Storage Temperature Range -25ºC to 70ºC (-13ºF to 158ºF)

Relative Humidity 85% at 30ºC (non-condensing)

Dimensions (L x W x D)

Weight 330 g (11.6 oz)

174 x 152 x 48 mm

(8.5 x 5.7 x 1.9 in.)

3.3 Electrical Data

 Two lines of 16 characters, backlit LCD display  One PGM open collector outputs, 100 mA, PTC protected  Local, 85 dBA siren  220 VAC/50 Hz, 110 VAC/60 Hz (15 VDC, 800 mA) external power supply  Complies with the following standards:

 CE, FCC

16 HLX-24 Hardware Installation and Programming Manual

Specifications

 Current consumption:

 150 mA (standby), 300 mA (max)

 Auxiliary power output: 13.8 VDC, 500 mA max

 Output voltage range max. 13.8 VDC, minimum 9 VDC  Maximum output pick-to-pick ripple 0.6 Vptp  Maximum auxiliary current output 200 mA – EN50131-6 standard

 Battery

 Four rechargeable AA type batteries (1800 mAh) are included

3.4 Communication

 Frequencies: 433.92 MHz (G) and 868.35 MHz (H)  RF jamming detection (UL/EN selectable)  Proprietary anti-collision RF protocol  Programmable no-activity timer 1–30 minutes, per zone  Two central station numbers and accounts, backup and secondary modes  Reporting protocols: Contact ID  Three private telephone numbers for voice reporting  Local connection (with MD-62) port for local upload/download, and

remote programming by PC software

 Built-in telephone dialer and 2400 Baud rate modem

HLX-24 Hardware Installation and Programming Manual 17

Installation

4. Installation

4.1 Unpacking the Equipment

The contents of your package are listed below. First, make sure that all the items in the kit have been included. If you find that any item is missing, contact your dealer immediately.

4.1.1 HLX-24 Package Content

 HLX-24 unit  Four 1800 mAh AA batteries  Wall adaptor  Installation screw set

4.2 Supply Power to the Unit

It is easier to enroll the ID codes of the transmitting devices to the system before installation. Power the HLX-24 system using the external power transformer or from the backup batteries.

To initiate battery power, connect the batteries, connect external power (transformer), and then disconnect the power to initiate battery power operation.

4.3 Planning and Programming

Register the location of each detector in the tables provided in Appendix C and D. Mark the transmitters and detectors accordingly.

To program the system, refer to Chapter 5. To mount the HLX-24 unit, refer to Section 4.7.

18 HLX-24 Hardware Installation and Programming Manual

Installation

4.4 Wiring the System

Figure 3 shows the various HLX-24 connections, which are described in Table

Figure 3: Panel Wiring

Table 8: HLX-24 Connections

Input Description

PGM

VIN

LINE (RJ-11)

PHONE (RJ-11)

MD-62 Connection Socket

Battery Compartment

Wall Tamper Switch

Ethernet (RJ-45)*

* HLX-24IP models only

Terminal blocks for PGM activation

Input voltage from AC/DC adaptor VIN = 13.8–15

Telephone line in (from the wall to the system)

Telephone line out (from system to telephone device)

Connection socket for 10-pin plug connecting panel to PC with MD-62

4 AA rechargeable batteries

Tamper switch is pressed when the panel is mounted on the wall

Connection to the HomeLogiX™APP server

HLX-24 Hardware Installation and Programming Manual 19

Installation

To connect the AC transformer:

the wiring

4.5 Connecting the AC Transformer

Complete all the wiring before plugging the transformer in to the AC outlet.

1. Attach the transformer and power up the system. The display shows the HLX-24 logo and the current version.

2. Plug in the transformer. The power LED on the control panel should light up.

4.6 Connecting to a PC

The control panel can be equipped with an optional MD-62 adaptor for serial data interchange with a computer.

4.7 Mounting the Back Plate

4.7.1 General

It is important to mount the back plate first before connecting any of to the unit.

To complete the installation without exposed wires, all the wiring should be done through the wall. The wiring to the back plate can be done without having exposed wires by installing the panel on a standard electrical box or making a hole in the wall for the wiring (Figure 4).

Figure 4: Back Plate Wiring

20 HLX-24 Hardware Installation and Programming Manual

Installation

When drilling the hole for the wires, it is recommended to drill the hole in the marked out areas (Figure 5).

Figure 5: Back Plate Mounting Holes

4.7.2 Required Space

The required space on the wall for the panel is (L) x (H). The hole size for the wires is 2 x 5 cm (0.8 x 2 in.). This is to be drilled according to the openings on the back plate.

The optimum viewing angle of the LCD is achieved when the panel is mounted above the eye level of the user.

HLX-24 Hardware Installation and Programming Manual 21

Installation

To dismount the control panel:

To replace the backup batteries:

4.8 Dismounting the Control Panel

1. Release HLX-24 from the mounted back plate by unscrewing the bottom screws and unlocking the locking hooks on the top of the back plate by lifting them up and out of the recesses on top of the panel.

2. Pull the top of the panel away from the wall to disconnect the connector to the back plate and then remove the panel from the lower posts of the back plate.

4.9 Replacing the Backup Batteries

1. Dismount the panel.

2. Remove the cover of the battery compartment (Figure 6).

Figure 6: Backup Batteries

3. Replace the batteries.

4. Replace the cover.

Do not mix between different rechargeable batteries type and different charging levels.

22 HLX-24 Hardware Installation and Programming Manual

Programming the HLX-24

5. Programming the HLX-24

We recommend that you program the HLX-24 before installing it. The system must be connected to the AC power supply for programming; you may also connect the backup battery at this time.

HLX-24 is provided with two default codes:

 Default Installer code: 8888 – Enables you to program HLX-24  Default Master code: 1234 – Enables you to change the Master code and

modify the User and Master options

We recommend that you change the Master and Installer codes after first time use.

HLX-24 Hardware Installation and Programming Manual 23

Installer Menu

To access the Installer menu:

6. Installer Menu

The Installer menu enables access to the following group of options:

 Change Code  Zones  Enrolling  Security  Communications  Automation  Messages  Maintenance

Appendix A presents some the features available in the Installer menu and how to access them.

1. Press Menu twice to reach the

The default Installer code is 8888.

If a wrong code is entered, the system indicates that an illegal code was entered and waits once again for the correct code to be entered. After 30 seconds of no entry, the system returns to Normal mode automatically.

The system locks out for 90 seconds after entering 5 wrong codes.

INSTALLER MENU

option and press Enter.

No activity within the menu for 4 minutes causes the system to return to Normal mode. To return to Normal mode before 4 minutes pass, press ESC.

2. Once in the

3. Press Enter to access the desired submenu as detailed below.

Some menus can be accessed directly by typing the option number instead of scrolling the various options.

24 HLX-24 Hardware Installation and Programming Manual

INSTALLER MENU

, use Menu to browse the submenus.

Installer Menu

Enrolling Security

Communications

Automation Messages

To change the Installer code:

Security

Messages

To specify zones:

6.1 Change Code

Maintenance

Zones

CHANGE CODE

This option enables you to change the code with which you enter the system. The default code is 8888.

1. Press Enter to access the submenu. The first submenu is

CHANGE CODE

2. Enter a new 4-digit Installer code.

3. Press Enter to save your new code.

6.2 Zones

Communications

Change Code

Automation

Enrolling

Maintenance

ZONES

Zone #01–24 Zone Type Description Chime No Activity Swinger Zone Cross Cross Time Abort Window

This menu allows you to define each of the 24 available zones. You can define the zone type, description, activity type and its audible chime indication.

1. Press Enter to access the submenu. The second submenu is

ZONES

2. Select the required zone by either browsing all 24 using Menu or by entering the zone number using the numeric keypad.

3. Once in the desired zone, use Menu to browse the options.

HLX-24 Hardware Installation and Programming Manual 25

Installer Menu

4. Press Enter to access the desired submenu to define several characteristics as follows:

 Zone Type: Select one of the following:

 Delay – An opening in this zone is alarmed only after the exit or

entry time has passed

 Fire – An opening in this zone causes a fire alarm and is armed

24 hours a day

 24H Silent – An opening in this zone causes a silent alarm (no

audible local siren) and is armed 24 hours a day

 24H Audible – An opening in this zone causes an audible alarm

and is armed 24 hours a day

 No Secure – non-alarm zone – zone can be used for any non-

secured propose

 Interior – Zone is bypassed when system is in Arm Home (Stay)

mode

 Interior Follow – A non-entry/exit zone, typically an interior zone

located on an entry/exit path, which is treated as an entry/exit zone during an Entry Delay or Exit Time. An opening in this zone is alarmed only after the exit or entry time has passed.

 Perimeter – Zone is armed both in Arm Home and Arm Away

modes

 Description: Select one of 38 fixed descriptions or one of five

editable custom descriptions. HLX-24 enables you to specify five custom zones (see Section 6.7.3).

For your convenience and better control of the installation, use the tables provided in Appendix C.

 No Activity: Select to enable or disable the no activity time for each

zone. When there is no activity in the specified zone and the system is disarmed, a silent alarm is sent to the monitoring station. When the system is armed and there is no activity in the specified zone, an audible alarm and a report are sent to the monitoring station. By default the option is disabled.

 Swinger: Select the number of repeated opening events from the

zone after which the system ignores the zone. The default setting is 2 zone openings. The zone is restored after a manual system reset or automatically after a defined number of hours. The default value is 8 hours.

 Zone cross: The zone cross option requires an opening of two zones

within a given time period to initiate an Alarm event sequence. This setting links between the two zones.

26 HLX-24 Hardware Installation and Programming Manual

Installer Menu

Change Code

Security

Communications

Automation

Messages

• Crossing zones can be of zones with the same type.

• One cross zone gets the mutual zone automatically. Ex zone 1 cross zone 2

then zone 2 automatically cross zone is 1.

 Cross Time: Select the time period between two zones defined in

cross mode for alarm event. If one linked zone is opened and the other linked zone is not opened, a zone cross error is sent to the monitoring station. The default is 30 seconds.

 Abort Window: A period of time after a sensor initiates an alarm

condition that allows the user additional time to disarm the system before an alarm is transmitted. Select Enabled to allow the zone to abort an alarm event during the Alarm Abort Window defined in the system. The default setting is Enabled.

6.3 Enrolling

Maintenance

Zones

ENROLLING

Detectors Remote Controls

Sirens Keypads

Repeaters

The third submenu is Browse the desired devices listed below to be enrolled using Menu and access

it by pressing Enter:

 Detectors  Remote controls  Sirens  Keypads  Repeaters

ENROLLING.

HLX-24 Hardware Installation and Programming Manual 27

Installer Menu

To enroll/delete a detector:

To enroll a remote control or a proximity card to be used with the KE30 key pad and to specify a function:

6.3.1 Detectors

You can enroll up to 24 detectors, one detector per zone, numbered 01 through 24.

1. Select the desired zone by either browsing all 24 zones using Menu or by entering the zone number using the numeric keypad.

2. Select enrollment method, either Normal or Tamper.

 If no detector is associated to the selected zone, the screen shows a

message saying “waiting for detector signal” for 30 seconds.

 When browsing the zones, each zone already enrolled indicates "RF

ID code".

3. Press Enter to delete the detector (or ESC to go back).

4. Initiate a transmission from the detector.

 In Normal enrollment any transmission is accepted (Alarm, Tamper,

or any other transmission available, see the detector’s manual for reference).

 In Tamper enrollment, only Tamper activation is accepted all other

signals are ignored.

Tamper enrollment is suitable for areas with multiple sensors thus preventing false enrollment.

5. When the transmission is detected, you are asked to press Enter to store the detector into the zone.

When enrolling smoke and heat detectors, make sure to select the zone type “fire”.

If no signal is received with the allocated 30 seconds, the unit returns to Normal mode.

6.3.2 Remote Controls (KE-30 RFID Function)

You can enroll up to eight remote controls and specify functions for each button on the remote control. You can also delete enrolled remote controls. Each proximity card used with the KE-30 keypad is considered a remote control during enrollment.

1. Select the desired remote control number 01 to 08 by either browsing the remotes using Menu or by entering the remote number using the numeric keypad.

2. Enroll the remote control when the

WAITING FOR SIGNAL

message is displayed, by pressing a button on the remote you wish to enroll or by passing the proximity card through the KE-30 keypad.

28 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To delete a remote control or proximity card:

To enroll/remove an RF siren:

To enroll/remove a keypad:

3. When the signal is detected you are asked to press Enter to store and save your selection.

4. Once the selection is stored, you can then choose to configure each of the remote control buttons (except the * button that serves as a status announcement) to behave in one of the following options:

 Restore Default (sets the button to its original functionality)  Operate PGM 1  Status Request

5. At any time press ESC to exit the menu.

Once you exit the menu (after saving the enrollment) you cannot change the button’s behavior, unless you delete the remote and re-enroll it.

1. Select the pre-enrolled remote control number 01 to 08 by either browsing the list of remotes using Menu or by entering the remote number using the numeric keypad.

You are asked to confirm deletion.

2. Press Enter to delete or ESC to go back.

6.3.3 RF Siren

You can enroll up to four RF sirens. You can choose to remove enrolled sirens.

1. Select the required Siren location, #01–04 by either browsing the keys using Menu or by entering the siren’s number using the numeric keypad.

2. Enroll the RF Siren when the activating the siren’s tamper.

3. When the signal is detected, you are asked to press Enter to store and save your selection

If the selected location has a siren enrolled, you are asked whether you wish to delete it.

4. Press Enter to delete or ESC to go back.

6.3.4 Keypads

You can enroll up to four keypads. You can choose to remove enrolled keypads.

WAITING FOR SIGNAL

option is displayed by

1. Select the required keypad location, #01–04 by either browsing the keys using Menu or by entering the keypad’s number using the numeric keypad.

2. Enroll the keypad when the

3. When a signal is detected, you are asked to press Enter to store and save your selection

WAITING FOR SIGNAL

option is displayed.

HLX-24 Hardware Installation and Programming Manual 29

Installer Menu

To enroll/remove a repeater:

Communications

Messages

If the selected location has a keypad enrolled, you are asked whether you wish to delete it.

4. Press Enter to delete or ESC to go back

6.3.5 Repeaters

You can enroll up to four repeaters. You can choose to remove enrolled repeaters.

1. Select the required repeater location, #01–04 by either browsing the keys using Menu or by entering the repeater’s number using the numeric keypad.

2. Enroll the repeater when the

WAIT FOR SIGNAL

option is displayed, by

activating the tamper.

3. When the signal is detected, you are asked to press Enter to store and save your selection

If the selected location has a repeater enrolled, you are asked whether you wish to delete it.

4. Press Enter to delete or ESC to go back

6.4 Security

The following is a list of the system’s security features.

Change Code

Enrolling

Zones

SECURITY

Exit Delay

Exit Restart Entry Delay Auto Arming

Siren Time Siren Mode

Local Siren External Siren Supervision Time

Jamming No Activity Time

Trouble Beeps Bypass Option Quick Arm

30 HLX-24 Hardware Installation and Programming Manual

Automation

Maintenance

Installer Menu

Messages

Communications

Change Code

Enrolling

Zones

SECURITY

Arm Instant Panic Button

Duress Code Alarm Cancel Alarm Abort Time

Backlight Time Hide Display

Key Beeps Select Language EN-CENELEC*

CP01

* The panel is not yet EN-CENELEC standard certified.

The fourth submenu is

SECURITY.

Browse the desired security related settings

Automation

as described in the following subsections using Menu. Press Enter to access the desired submenu.

6.4.1 Exit Delay

An exit delay enables the user to arm the system and exit the site through a specified door (determined as a delay zone) using a predetermined path after arming the system, without setting off an alarm.

A progress annunciation of slow-rate warning beeps sound when the system is armed. The system counts down the last 10 seconds of the delay if the voice capability is configured; otherwise, the warning beeps are faster. The exit delay is set at 60 seconds by default.

An Exit Error sequence is initiated if an entry/exit zone is in an opened state at the instant of exit time expiration or if no delay zone is opened during the exit time.

An Exit Error process for a delay zone is as follows:

 The local alarm immediately sounds.  The annunciator sounds an Entry Delay or an alarm condition.  An Entry Delay is initiated.  If the alarm system is not Disarmed at the end of the Entry Delay, the

Alarm Transmission Sequence is initiated.

 The Alarm Transmission includes the alarm and an Exit Error message to

the central station.

Maintenance

HLX-24 Hardware Installation and Programming Manual 31

Installer Menu

To specify the exit delay:

To modify the entry delay:

To activate auto arm:

The user can use the Silent Exit feature to silence the audible progress annunciation of the exit delay.

If Silent Exit is active, the Exit Time is doubled for that exit period only but does not exceed 255 seconds.

1. Using the numeric keypad, specify the length of time for the exit delay between 45 and 255 seconds.

2. Press Enter to save your selection.

6.4.2 Exit Restart

When this feature is enabled, an Exit Restart delay occurs on the second zone opening within the same zone and the Exit Delay time is doubled. If it is disabled, the same zone may be opened several times while in the Exit Delay countdown. The default setting is Enabled.

6.4.3 Entry Delay

An entry delay enables the user to enter the site through a specified door (determined as a delay zone) using a predetermined path, without setting off an alarm. The entry delay is set at 30 seconds by default.

After entry, the user must disarm the system before the entry delay expires. A progress annunciation of slow-rate warning beeps sound upon detection of the specified zone. The system counts down the last 10 seconds of the delay indication if enabled or the warning beeps become faster.

1. Using the numeric keypad, specify the length of the entry delay between 30 and 240 seconds.

2. Press Enter to save your selection.

6.4.4 Auto Arming

Auto Arming allows scheduled arming and disarming of the system for all weekdays at different hours.

1. Using Menu, select the day of the week.

2. Press Enter to confirm.

3. Using Menu, select one of the following options:

 Disabled  Arm Home  Arm Away

4. Press Enter to confirm.

5. Using the numeric keys, enter the system arming time (24 hours).

6. Press Enter to confirm the time.

32 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To specify the siren time:

To specify the siren mode:

To set up a local siren:

To set up external wireless sirens:

7. Set the Alarm Duration between 1 to 9999 minutes, or enter 0 (zero), to disable Auto Arm Duration. The panel remains armed until disarmed by an authorized user.

6.4.5 Siren Time

This specifies the amount of time the siren sounds when an alarm has been set off. The siren time is set to three minutes by default. This relates to all siren types, wired, wireless and local.

1. Using the numeric keypad, specify the length of the siren time between 01 and 15 minutes

2. Press Enter to save your selection.

6.4.6 Siren Mode

You can specify whether you want the siren to be activated when armed in Away mode only or when armed both in away and home arming modes. The siren mode is set to Away + Home by default. This relates to all siren types, wired, wireless and local.

1. Using Menu, select one of the following options: Away or Away + Home.

2. Press Enter to confirm.

6.4.7 Local Siren

Specifies whether an activated alarm causes an internal siren (emitted from the system’s speaker) to sound or remain silent. The local siren is enabled by default.

1. Using Menu, select either Enable or Disable.

2. Press Enter to confirm.

6.4.8 External Siren

Enables or disables the wireless sirens. Wireless sirens are enabled by default.

1. Using Menu, select either Enable or Disable.

2. Press Enter to confirm.

6.4.9 Supervision Time

The supervision time submenu specifies the time limit during which the system receives supervision reports from specified wireless devices. If a device does not report in at least once within the specified time limit, the system initiates an inactivity alert. The default supervision time is set to one hour.

HLX-24 Hardware Installation and Programming Manual 33

Installer Menu

To specify the supervision time:

To specify jamming detection:

To set the no activity time:

ption should be set to ‘Enabled’ for this security

1. Using Menu, select one of the time limit options, 20 minutes, 1, 2, 4, 6, 8, 16, 24 or 48 hours.

2. Press Enter to confirm.

6.4.10 Jamming

Specifies whether the system detects and reports jamming – interferences of the radio channel used by the system.

The jamming detection is disabled by default.

1. Using Menu, select one of the following options:

 Disabled: to disable jamming detection  EN enabled: to enable European standard jamming detection  UL enabled: to enable US standard jamming detection

2. Press Enter to confirm.

6.4.11 No Activity Time

Specifies the time limit in which the system should receive a signal from a sensor used to monitor the activity of sick, elderly or disabled people. If no device detects and reports movement at least once within the specified time limit, a “not active alert” sounds and a report is sent to the CMS (if reporting is enabled). This option is disabled by default.

The behavior of the no activity zone feature varies when in Arm or Disarm modes:

• When Disarmed – Alert is sent to CMS

• When Armed – An alarm is heard and an alert is sent to CMS

1. Using Menu, select one of the following options:

 1, 2, 5, 10, 15, or 30 minutes  Disable the timer

2. Press Enter to confirm.

Required zones’ “No Activity” o feature to work.

6.4.12 Trouble Beeps

This parameter determines whether the system emits a “trouble beep” indicated by a series of four short beeps once a minute for the following “Trouble” events:

 Low battery (detectors and system)  Supervision loss (detectors)  Power (AC) failure (system)

34 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To specify trouble beeps:

To set bypass:

To enable/disable quick arm without a code:

To utilize quick arm:

To enable/disable the Arm Instant option:

 Communication failure (system)  Tamper (system and zones)  RF jamming

The default is set to Disabled. The HLX-24 allows you to enable the beeps for daytime only 8:00 AM to 8:00

PM.

1. Using Menu, choose Disable, Day & Night (enable), or Day Only for the trouble beeps.

2. Press Enter to confirm.

6.4.13 Bypass Option

Specifies either manual bypassing of individual zones, or enables the system to forcedly arm open zones when armed. Bypass is turned off by default.

1. Using Menu, select one of the following options:

 Off to set the bypass off  Off/Force allows forced arming (automatic bypass) only  Manual allows manual bypass only  Manual/Force allows both forced arming (automatic bypass) and

manual bypass

2. Press Enter to confirm.

6.4.14 Quick Arm

Enables the user to arm the system without entering a code; Quick Arm is set to disable by default.

1. Using Menu, select either Enable or Disable.

2. Press Enter to confirm.

1. Press continuously on the AWAY or HOME keys to arm AWAY or HOME.

6.4.15 Arm Instant

Enables the user to instantly arm the system by bypassing the Exit Delay; Arm Instant is set to disable by default.

1. Using Menu, select either Enable or Disable.

2. Press Enter to confirm.

HLX-24 Hardware Installation and Programming Manual 35

Installer Menu

To utilize Arm Instant:

To set a panic button:

To change the duress code:

1. Arm the system using one of the arming options.

2. Once the exit delay countdown initiates, press either the AWAY or HOME keys once again.

6.4.16 Panic Button

The user can generate an alarm (audible or silent) by pressing continuously on the emergency button on the control panel. The remote control panic button must be pressed twice to activate the panic alarm when the CP-01 standard is enabled (see Section 6.4.25). When CP-01 is disabled, the panic button must be pressed once. The local emergency button is disabled by default.

1. Using Menu, select one of the following options:

 Audible: to set an audible panic alarm that transmits a message to

the CMS or private telephone set.

 Silent: to set a silent panic alarm that transmits a message to the

CMS or private telephone set, but without a siren

 Disabled: to disable the panic alarm button all together

2. Press Enter to confirm.

6.4.17 Duress Code

The system allows you to define a unique duress code, which a user can enter when forced to disarm the system under duress. The duress code is disabled when there is no duress code defined in the system. By default, the duress code option is disabled.

The duress code should NOT be identical to any other existing code.

1. Type a new four-digit duress code using the numeric keypad.

2. Press Enter to save your new code.

6.4.18 Alarm Cancel

An Alarm Cancel window is a period of time starting at the end of the alarm abort window (Section 6.4.19), during which a user can cancel the alarm. The minimum duration of the window is 5 minutes and the maximum duration is 10 minutes. Setting “0” disables the alarm cancel transmission to the central station. The Alarm Cancel window applies to all alarms that have been subjected to the Abort window.

If an alarm had previously been transmitted, an Alarm Cancel event signal is transmitted if the control panel is disarmed during the Alarm Cancel window. By default, the Alarm Cancel time is 5 minutes.

36 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To set the Alarm Cancel:

To set the alarm abort time:

To set the backlight:

To display the system status:

For a signal to be sent to the CMS, the Alerts reporting group must be enabled in Report Options (Section 6.5.3).

1. Using the numeric keypad, set the alarm cancel time between 01 to 10 minutes or 00 to disable the option.

2. Press Enter to confirm.

6.4.19 Alarm Abort Time

The system sounds a warning, but the central station does not receive notification of the alarm if the user disarms the system within the specified alarm abort time. This function applies to interior, perimeter, and 24-hour zones. The default

Alarm Abort Time

is 30 seconds.

1. Using the numeric keypad, set the alarm abort time between 01 to 45 seconds or 00 to disable the option.

2. Press Enter to confirm.

6.4.20 Backlight Time

Specifies the backlight options; by default, the backlight time is set to 15 seconds.

1. Using Menu, select one of the following options:

 Always: to specify that the keypad and buttons are backlit at all

times.

 15 secs: to specify that the keypad and buttons are backlit for up to

15 seconds after last key press.

2. Press Enter to confirm.

6.4.21 Hide Display

Enables you to specify that when armed, the system does not display the system statuses or other system prompts; by default,

Hide Display

is off.

1. Using Menu, select one of the following options:

 Off to display status and prompts.  On to hide status and prompts.

2. Press Enter to confirm.

HLX-24 Hardware Installation and Programming Manual 37

Installer Menu

To set the key beeps:

To set the standard status:

To set the ready option:

6.4.22 Key Beeps

Choose to turn key beeps on to hear a beep on each key press; key beeps is on by default.

1. Using Menu, select one of the following options:

 On to turn the key beeps on  Off to turn the key beeps off

2. Press Enter to confirm.

6.4.23 Select Language

The HLX-24 currently supports English only.

6.4.24 EN-CENELEC

The panel is not yet EN-CENELEC standard certified

The HLX-24 supports CENELEC standard settings. By default, all CENELEC standard settings are enabled. During the installation process, the installer may enable or disable each setting according to the local requirements.

The menu includes the following:

 Status  Ready Options  Access Level  Event Filter

1. Using Menu, select either Enable or Disable.

2. Press Enter to confirm.

Enabling the standard sets all the standard features to default.

Enable state and the event filter is set to 10. Disabling the standard sets all the standard features to disable state and the

event filter is set to 0.

1. Using Menu, select Tamper, Low Battery, AC Fail, Comm Fail, Line Fail, Panic, or Supervision.

2. Press Enter to choose the submenu.

3. Using Menu, select either Enable or Disable.

4. Press Enter to confirm. The ready option restricts the relevant parameters so that the system

cannot be armed during the violation of that parameter.

38 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To set the access level:

To set the event filter:

Example: Setting the AC Fail parameter to enable restricts the system from being armed until the power supply returns.

1. Using Menu, select Memory Alarm, System Status, or Arm Instant.

2. Press Enter to choose the submenu.

3. Using Menu, select either Enable or Disable.

4. Press Enter to confirm. The access level options, restricts the information actions to be accessible

to the user by pressing PIN number. Usually system’s status information is valid to the user by pressing the

Enter key. Setting each parameter to enable, the enter key should be followed by a PIN code.

1. Using the numeric keypad, specify the value for the event filter between 0 and 10 cycles.

2. Press Enter to save your selection. An event filter enables the user to specify the maximum repetition of a

specific event in a session. A session is a period between each of the arming and disarming operations.

Setting the event filter to 0 enables specific events to be recorded with no filtering to the event log.

Setting 0, 1, 2 value in the event filter is not compatible with CENELEC standard.

6.4.25 CP-01

The panel is not yet CP-01 standard certified

The HLX-24 supports CP-01 standard settings. During the installation process, the installer may change each setting according to the local requirements.

The menu includes the following:

Table 9: CP01 Menu

Menu Item Description Default Setting

Abort Announce

Cancel Announce

When at least 1 zone is aborted, “ABT” (abort) is displayed on the LCD once the system enters Disarm mode.

When Alarm Cancel is transmitted to the central station, “CNL” (cancel) is displayed on the LCD once the system enters Disarm mode.

Enabled

HLX-24 Hardware Installation and Programming Manual 39

Installer Menu

which every additional fire alarm signal is

automatically if the system was armed in

To set the Abort Annunciation:

To set the Cancel Annunciation:

To set the Fire Verification:

Menu Item Description Default Setting

Fire Verify

Recent Close Time

Swinger Time

Unvacated Premises

Squawk Buzzer

Siren

1. Using Menu, select either Enabled or Disabled.

2. Press Enter to confirm.

1. Using Menu, select either Enabled or Disabled.

2. Press Enter to confirm.

1. Using Menu, select either Enabled or Disabled.

2. Press Enter to confirm.

Double checks the state of the fire detectors.

When there is a fire sensor alarm signal, a siren is heard immediately. A 60second retard-reset period starts during

ignored. After this period, an additional timeout of 60 seconds starts, which is the confirmation period, during which a fire sensor alarm signal causes an event transmission to the monitoring station.

When the confirmation period expires, the fire zone is automatically restored and ready for a new fire alarm session.

A Recent Closing transmission is sent if an alarm occurs within the programmable time after the Exit Time passes.

Duration for automatic resetting of detectors after being ignored by swinger trips

Triggers Arm Home (Stay) mode

Arm Away mode but there was no exiting from the premises during exit delay

Determines whether the buzzer sounds when arming or disarming the panel for remote operation.

Determines whether the siren sounds when arming or disarming the panel for remote operation.

Disabled

2 minutes

8 hours

Enabled

40 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To set the Recent Clos e Time:

To set the Swinger Time:

To set the Unvacated Premises mode:

To set the Squawk mode:

Security

Messages

1. Using the numeric keypad, specify the value between 0 and 9.

2. Press Enter to save your selection.

1. Using the numeric keypad, specify the value between 0 and 9.

2. Press Enter to save your selection.

1. Using Menu, select either Enabled or Disabled.

2. Press Enter to confirm.

1. Using Menu, select either Buzzer or Siren.

2. Select either Enabled or Disabled.

3. Press Enter to confirm.

6.5 Communications

Change Code

Enrolling

Zones

COMMUNICATIONS

System Telephone

Private Report CS Report Setup

Line Test AC Fail Report Fax Defeat

Number of Rings Select Region

The fifth submenu is

Communication,

which involves the setup of system

Automation

communications parameters and settings with the outside world. Browse the desired communication related setting, as described in detail below, using

Menu. Press Enter to access it.

Maintenance

HLX-24 Hardware Installation and Programming Manual 41

Installer Menu

To set up the system telephone:

To set up private report:

6.5.1 System Telephone

This menu allows you to specify the telephone number used for the ring back option when calling the system telephone.

1. Press Enter to access the

2. Using the numeric keypad, enter the system telephone number. Use * to enter a comma. Use # to delete the last digit.

3. Press Enter to confirm.

When setting up the system telephone, use a comma (,) to indicate a delay when dialing a number.

6.5.2 Private Report

This menu enables you to set the private telephone report options as detailed below.

Telephone Number

submenu.

1. Using Menu, select each of the following submenus and press Enter to confirm:

a. Set Numbers – Specify the telephone numbers of the subscribers to

which the system reports. You can enter up to three numbers. i. Using Menu, choose between number 1, 2 or 3 and press

Enter.

ii. Using the numeric keypad, enter the telephone number and

press Enter to confirm. Use * to enter a comma. Use # to delete the last digit.

b. Report Options – Specify the event groups that are included in a

report.

2. Using Menu, choose the reporting options for each group as desired. The options are Disable and Enable.

3. Press Enter to confirm. The available reporting groups are:

 Alarms (Voice by default)  Troubles (Voice by default)  Alerts  Bypass  Arm/disarm  Restore

4. Press ESC to exit the submenu.

42 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To set up CS report:

5. Dialing Attempts – Specify the number of cycles the panel goes through while attempting to connect to a remote private phone, where a cycle consists of up to 3 different remote private phones. The default is 3 attempts.

a. Using the numeric keypad, enter the dialing attempts value between

1 and 15.

b. Press Enter to save.

6.5.3 CS Report Setup

This menu allows you to set the Central Station (CS) report options.

1. Using Menu, select each of the following submenus and press Enter to confirm:

a. CS Report Method – Specify the reporting method.

i. Using Menu, select one of the following:

o Disable (default) o Primary Only o Alternate o Secondary Only o Both

ii. Press Enter to confirm.

b. CS Primary – Specify the first telephone number of the first central

station to which the system reports in case of an event as well as the primary account code and report options. Under this menu, you must set the following parameters:

 Phone Number – The primary CS telephone number

i. Using the numeric keypad, enter the primary CS telephone

number.

ii. Press Enter to confirm. Use * to enter a comma. Use # to

delete the last digit.

For PABX, use the digit followed by * and then the full number.

 Account Code – The number that identifies your system to the

central station. The account code range is 0–9, B, C, D, E, and F. i. Using the alphanumeric keypad, enter a code of four

digits/letters.

ii. Press Enter to confirm.

 Report Options – Specify the event groups that are included in

a report.

HLX-24 Hardware Installation and Programming Manual 43

Installer Menu

i. Using Menu, choose the reporting options for each group

as desired. The options are Disable and Enable. The available reporting groups are:

 Alarms  Troubles  Alerts  Bypass  Arm/disarm  Restore

ii. Press Enter to confirm. iii. Press ESC to exit the submenu.

 Ack Timeout – Specify the time that the system has to send a

report event before the report alert is discontinued. i. Using the alphanumeric keypad, set the value of the Ack

timeout to a value of 10 to 60.

ii. Press Enter to confirm.

 Signal Gain – Specify the strength of the DTMF.

i. Using the alphanumeric keypad, set the value of the signal

gain to a value of between 300 and 1200.

ii. Press Enter to confirm.

 Call Wait Cancel – Specify whether call waiting interferes in the

event transmission to the central station by dialing *70 and entering the central station phone number. The default setting is Disabled.

c. CS Secondary – Specify the secondary Central Station (see CS

Primary above for detailed options and instructions).

d. CS Protocol – Specify the reporting protocol used by the system to

report events to the central stations. Currently only Contact ID is available.

e. Dialing Attempts – Specify the number of times the system

attempts to dial the primary stations number before attempting to dial the secondary number. The default is 3 attempts.

i. Using the numeric keypad, enter the dialing attempts value

between 1 and 15.

ii. Press Enter to save.

44 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To set up line test:

To set up AC fail report:

To set up Fax Defeat:

6.5.4 Line Test

Enables you to specify the time when the phone line and CS reporting are tested and reported to the central station, as well as the time interval between each test (periodic reporting).

1. Using Menu, select one of the two options to define, and press Enter to confirm:

 Repeats – Specify the number of days between tests. The default is

7. i. Using the numeric keypad, choose 1 to 30 days. ii. Press Enter to save.

 Test_Time – Specify the hour of the day to perform the line test. The

test time is set at 12:00 by default i. Using the numeric keypad, type the four digits of the desired

hour (24H convention).

ii. Press Enter to save.

6.5.5 AC Fail Report

This option allows you to specify a delay time, before reporting the power failure to the CS, in which time power may be restored. The time is set to 0 (disabled) by default.

Power (AC) failure is indicated by the Power LED, which flashes green.

1. Using the numeric keypad, set the time between 1 and 240 minutes, or set it to 0 to disable the option.

2. Press Enter to confirm and save your selection.

6.5.6 Fax Defeat

When calling the system, fax and answering machines may need to be overridden. This menu specifies whether to enable or disable this override. By default, this option is disabled.

1. Using Menu, Enable or Disable the option.

2. Press Enter to confirm.

6.5.7 Number of Rings

Specify the number of rings before the system answers the line. By default, this option is set to 4 rings.

HLX-24 Hardware Installation and Programming Manual 45

Installer Menu

To specify the number of rings:

To select the region:

Security

Messages

To set up the keypad:

1. Using the numeric keypad, set the number of rings to between 1 and 15.

2. Press Enter to confirm.

6.5.8 Select Region/Country

Select the region/country for the telephone line DAA, matching the time set for the system. By default, this option is set to Other.

1. Use Menu to select one of the available regions.

2. Press Enter to confirm.

6.6 Automation

Communications

Change Code

Enrolling

Zones

AUTOMATION

Keypad Manual

Set Triggers

Maintenance

The sixth submenu is

Automation,

which deals with the setup of various home automation options. Browse the desired automation related setting, as described in detail below, using Menu. Press Enter to access it.

6.6.1 Keypad Manual

Enable or disable this option to determine whether the PGM output can be controlled by numeric keys 1 and 2 of the keypad as described in Section

2.2.1. This option is Enabled by default.

1. Using Menu, Enable or Disable the option.

2. Press Enter to confirm your selection.

46 HLX-24 Hardware Installation and Programming Manual

Installer Menu

To set up triggers:

Security

Communications

6.6.2 Set Triggers

This option enables you to activate the PGM using various events in an automated fashion. By default, no triggers are set.

1. Using Menu, select PGM Trigger and press Enter to confirm.

2. You can select the pulse time and triggers as described below:

a. Pulse time – Set the length of time for the device to stay on when a

pulse type activation is selected. Using the numeric keypad, set the time from 1 to 99 seconds and press Enter to save.

b. Select the trigger type and parameters according to Table 10. Use

only one trigger for each PGM simultaneously.

Table 10: Trigger Type and Parameters

Trigger PGM Activation

Remarks

Options

Arm Away

Arm Home

Disarm

Alarm

Panic

Trouble

AC Loss

Exit/Entry

Remote Control

Zone

On, Off, Pulse, Ignore

Enabled, Disabled Go OFF when alarm stops

Pulse, Ignore

Enabled, Disabled ON when AC fails, OFF when AC

returns

Enabled, Disabled Annunciation of exit/entry beeps

of remote sounder On, Off, Pulse, Trouble, Ignore Relates to remote’s panic button

On, Off, Pulse, Trouble, Ignore Relates to zone open or detection

6.7 Messages

Change Code

Enrolling

Zones

Keypad Mute

House Name

Automation

MESSAGES

Maintenance

Custom Zones

HLX-24 Hardware Installation and Programming Manual 47

Installer Menu

To set up keypad mute:

To set up and rev iew the house name:

The seventh submenu is descriptions. Browse the desired setting, as described in detail below, using Menu. Press Enter to access it.

6.7.1 Keypad Mute

This option allows you to enable or disable the option to mute all the voice messages and beeps (except for trouble beeps, forced arming, enrollment and RF test of wireless devices) by numeric key 5 of the keypad as described in

Section

2.2.1. By default, this option is Disabled.

Messages,

which deals with custom text zone

1. Using Menu, Enable or Disable the option.

2. Press Enter to confirm your selection.

6.7.2 House Name

This option enables you to type the House Name as defined in the system.

1. In the

6.7.3 Custom Zones

Enables you to record and listen to five voice and text custom zones descriptions and to toggle between them. On each zone, the user can simply edit the text by typing the keypad buttons. The text is limited to 16 characters.

1. Using Menu, locate the ENTER ZONE NAME submenu.

2. Repeat steps 1 through 3 for each of the 5 (five) custom zones.

HOUSE NAME

submenu. a. Press Enter to access the submenu.

Use the alphanumeric keypad to type the desired house name. Use # to delete the last entered value.

b. Press Enter to confirm.

 Press Enter to access the submenu.

Use the alphanumeric keypad to type the desired house name. Use # to delete the last entered value.

 Press Enter to confirm.

Reset to factory settings does not delete these recordings.

menu, use Menu to locate the ENTER HOUSE NAME

48 HLX-24 Hardware Installation and Programming Manual

Installer Menu

Security

Messages

To restore factory default:

6.8 Maintenance

Communications

Change Code

Enrolling

Zones

Factory Default

RF Test Test Indicators

Test Sirens Test Devices

The eighth submenu is maintenance options.

Maintenance,

Browse the desired security related setting, as described

which describes the various system

Automation

MAINTENANCE

in detail below, using Menu. Press Enter to access it.

6.8.1 Factory Defaults

This option allows you to restore the default factory settings for the system.

1. Press Enter to enter the submenu. Factory Defaults is the first submenu.

2. Press Enter and choose from the following four options using Menu to browse:

 Regular – CENELEC status disabled: Returns the factory default

settings without CENELEC settings

 Cenelec – CENELEC status enabled: Returns the factory default

settings with CENELEC settings

 Regular and Delete RF devices – Returns the factory default settings

without CENELEC settings and erases all RF devices previous identified by the unit

 CENELEC and Delete RF devices – Returns the factory default settings

with CENELEC settings and erases all RF devices previous identified by the unit

3. Press Enter to confirm.

6.8.2 RF Test

RF testing checks the signal strength of all the wireless devices enrolled to the system. If a weak signal is detected, a repeater may be used to improve the link quality.

The system saves the most recent set of RF test results for uploading. The system clears the tests when running another RF test.

HLX-24 Hardware Installation and Programming Manual 49

Installer Menu

To perform the test:

To view the results:

To test the indicators:

To test the sirens:

To test the PGM devices:

1. Using Menu select the test you wish to perform, and press Enter to access the test.

2. Activate the RF unit to send a signal to the unit. The results can be

Normal

Low

. The available tests are:

 Test Detectors (Walk Test) (refer to Table 11)  Test R. Controls  Test R. Siren  Test Keypads  Test Repeaters

Strong

1. For each of the tests, you can review the results by pressing Enter and then either Menu or the alphanumeric keys review all the units.

2. To exit the RF test mode you must press ESC.

6.8.3 Test Indicators

The indicators test checks the two indicator LEDs, power and status, located on the Panel.

After entering this menu, press Enter. The LEDs blink three times.

6.8.4 Sirens Test

This test checks the different available sirens by activating them.

1. Select the siren you wish to test:

 Local Siren  Wireless siren

 Siren 1  Siren 2  Siren 3  Siren 4

2. Press Enter to activate the sounder.

3. Press ESC to stop the siren.

6.8.5 Test Devices

This test checks the PGM connected to the system.

1. Select the PGM test

2. Press Enter to activate the PGM for three seconds.

50 HLX-24 Hardware Installation and Programming Manual

User Menu Structure

7. User Menu Structure

The user menu enables basic user settings such as Time & Date update and user codes edit (Table 11).

Table 11: User Menu Structure

Select To

Edit Master Code

User Codes

Authorize Code

Silent Exit/Entr

Set Date & Time Set the time and date, as specified in Date & Time Format.

Date & Time Format

Zone Bypass

Remote controls Enroll remote controls (see Section 6.3.2)

Private Numbers

PC Mode

Change the Master code

Specify user codes 1 through 20. If the user code exists, you can edit the code or delete the code.

Specify the code used to configure the system’s settings with the remote programming software HR-P02.

The default code is 1234.

Choose between disabling and enabling the progress annunciation during entry or exit delay.

The default is Disabled.

Specify the format in which the date is specified: 24 hour format or AM/PM.

Specify the format in which the date is specified: DD-MM-YY or MM-DD-YY

Enable if manual bypass has not been set to Off by the installer. It enables you to bypass and un-bypass selected zones.

Specify up to three private telephone numbers.

Enable or disable PC connection and activity when GSM expansion is installed; otherwise PC mode is enabled automatically.

HLX-24 Hardware Installation and Programming Manual 51

User Menu Structure

To enter the user menu:

Select To

Walk Test

When entering the detector’s Test mode, the red and green LEDs on the panel flash every second simultaneously, and the display shows “receiving…”.

If the alert monitoring station reporting options is enabled, an E607 event is transmitted.

The Walk Test sequence timeout is for 15 minutes. In the last 5 minutes, a squawk is heard every two seconds in addition the green and red LEDs flash simultaneously to indicate that the testing period will be terminated in another five minutes.

If the system walk detector test is terminated, an R607 restore event is transmitted (if enabled).

During the Walk Test, each successful detector violation causes a squawk and the signal strength is displayed.

In the conclusion of the Walk Test, the installer may browse through the recorded results by using Menu. Each browsing of a record is followed by the E613 event transmission with the relevant zone indication.

For 24-H and fire zones, reporting trouble event E380 is sent to the monitoring station.

Although the system supports up to twenty users, only one master user has access to all the settings.

1. Press Menu until the screen displays User.

2. Press Enter.

3. Enter the Master code; the default code is 1234.

The system lockouts for 90 seconds after entering 5 wrong codes.

52 HLX-24 Hardware Installation and Programming Manual

Reading the Event Log

To access the Event Log:

8. Reading the Event Log

The HLX-24 event log stores up to 250 events. When the log is full, the new incoming event replaces the oldest event.

Events are displayed in a chronological order, and include the date and time of their occurrence.

1. Access the event log by pressing 8 on the keypad when the system is in normal mode.

2. To read an event, enter the Master code and press Enter.

3. Browse the even log using Menu or go directly to an event by entering the event number using the numeric keypad.

4. Press Enter to view the date and time of the occurrence.

In EN-CENELEC standard menu, the event filter may be changed (default=10) so if an event reoccurs, the system only shows the event the defined number of times in the event log.

The event registration into log reoccurs after system disarming by the user.

HLX-24 Hardware Installation and Programming Manual 53

Quick Reference to Installer Menu

A. Quick Reference to Installer Menu

To enter the Installer menu, press Menu twice and press Enter. The default Installer code is 8888.

The available menus are as follows:

Menu Name Menu Number

Change Code 1 Zones 2

Enrolling 3 Security 4

Communications 5 Automation 6 Messages 7

Maintenance 8

Table 12 presents some the features available in the Installer menu and how to access them.

Table 12: Installer Menu

Feature Menu Programming Location

Exit Time

Exit Restart

Unvacat Premises

Recent Close Time

Entry Delay

Remote Arming

Remote Disarming

Abort Window

Alarm Abort Time

Cancel Window

Use of Duress Feature

Duress Code

Security

Security/CP01

Security

Enrolling

Zones

Security

Press 4 and Enter. Then press Enter.

Press 4 and Enter. Then press 2 and Enter.

Press 4 and Enter. Press 26 and Enter. Press Menu until reaching “Unvacat premises” and press Enter.

Press 4 and Enter. Press Menu until reaching “Recent Close Time”. Enter the desired value (0–15 minutes).

Press 4 and Enter. Then press 3 and Enter.

Press 3 and Enter. Press on Menu until reaching to “Remote controls” and Enter.

Press 2 and Enter. Select Zone by scrolling with Menu and Enter. Press Menu until reaching “Abort Window” and press Enter.

Press 4 and Enter. Then press 20 and Enter.

Press 4 and Enter. Then press 19 and Enter.

Press 4 and Enter. Press 18 and Enter. Enter 4 digits that will be used for the user’s under duress situation.

Press 4 and Enter. Then press 18 and Enter.

54 HLX-24 Hardware Installation and Programming Manual

Quick Reference to Installer Menu

Time”

Feature Menu Programming Location

Cross Zoning

Swinger

Fire Verify

Call Waiting

System Test

Communications

Recent Close Time

Zones

Security/CP01

Communications

Maintenance

Communications

Security

Press 2 and Enter. Select a zone by scrolling with Menu and Enter. Press Menu until reaching “Zone Cross” and press Enter.

Press 2 and Enter. Select zone by scrolling with Menu and Enter. Press Menu until reaching “Swinger” and press Enter.

Press 4 and Enter. Press Menu until reaching “Fire Verify”. Press Menu to toggle between Enabled and Disabled. Press Enter to select.

Press 5 and Enter. Press 4 and Enter. Press Menu until reaching “CS primary” or “CS secondary” and press Enter. Press on Menu until reaching “Call Wait Cancel” and press Enter.

Press 8 and Enter.

Press 5 and Enter.

Press 4 and Enter. Then press 26 and Enter. Press Menu until reaching “Recent Close and press Enter.

HLX-24 Hardware Installation and Programming Manual 55

Quick Reference to User Menu

B. Quick Reference to User Menu

To enter the User menu, press Menu once and press Enter. The default user menu code is 1234.

The available menus are as follows:

Menu Name Menu Number

Edit Master Code 1 User Codes 2

Authorize Code 3 Silent Exit/Entr 4

Set Date & Time 5 Date&Time Format 6 Zone Bypass 7

Remote Controls 8 Private Numbers 9

PC Serial Mode 10 Walk Test 11

Table 13 presents some the features available in the User menu and how to access them.

Table 13: User Menu

Feature Menu Programming Location

Exit Progress Annunciation

Entry Progress Annunciation

Silent Exit/Entr

Press 4 and Enter. Press Menu to toggle between Enabled and Disabled. Press Enter to select.

56 HLX-24 Hardware Installation and Programming Manual

Sensor Placement and Helpful Reference Tables

C. Sensor Placement and Helpful Reference Tables

C.1 Default Zone Descriptions

Attic

Back Door

Back Yard

Basement

Bathroom

Bedroom

Child’s Room

Closet

Den

Dining Room

Downstairs

Elevator

Emergency

Fire

Front Yard

Garage

Garage Door

Gate

Guest Bathroom

Guest Room

Hall

Kitchen

Laundry Room

Library

Living Room

Lower Bathroom

Main Entrance

Master Bathroom

Master Bedroom

Office

Storage Room

Store

Upper Bathroom

Upstairs

Vehicle Door

Walkway

Warehouse

Yard Door

HLX-24 Hardware Installation and Programming Manual 57

Sensor Placement and Helpful Reference Tables

C.2 Custom Zone Descriptions

Custom Zone Description

Custom #1 Custom #2

Custom #3 Custom #4

Custom #5

C.3 Detector Deployment Plan

Zone No.

10.

11.

12.

13.

14.

Zone Type Description Chime

No Activity Zone PGM 1 Remarks

Yes/No

58 HLX-24 Hardware Installation and Programming Manual

Sensor Placement and Helpful Reference Tables

Zone No.

15.

16.

17.

18.

19.

20.

21.

22.

23.

24.

Zone Type Description Chime

No Activity Zone PGM 1 Remarks

Yes/No

C.4 Remote Control

No. Holder Name Normal Operation PGM 1 Status Request

HLX-24 Hardware Installation and Programming Manual 59

Reporting Codes

D. Reporting Codes

Table 14 provides a listing of the codes used to communicate with the CMS.

Table 14: List of CID Codes

Programmable Feature Description CID Code

Burglary Event (Alarm for a zone) E130 Burglary Restore (for a zone) R130

Fire Event (Fire Alarm for a zone) E110 Fire Restore (Fire Alarm for a zone) R110

24 Hour zone Audible Alarm Event E133 24 Hour zone Audible Alarm Restore R133 Wire Sensor Tamper Event (Zone Tamper Alarm) E144

Wire Sensor Tamper Restore (Zone Tamper Alarm) R144 RF Low Battery Event (for RF zone) E384

RF Low Battery Restore (for RF zone) R384 Loss of supervision – RF Alarm Event (for a zone) E381 Loss of supervision – RF Restore (for a zone) R381

Wireless Panic Alarm Event From Remote Control E120 Wireless Panic Alarm Restore From Remote Control R120

Sensor Trouble Event E380 Sensor Trouble Restore R380 Duress Report Event E121

Open Report Event (Disarm) E401 Close Report Event (Arm Away) R401

Partial Close Report Event (Arm Home) R441 Cancel Event (Alarm Cancel Report) E406 Silent Panic From Panel E120

Audible Panic From Panel E120 Illegal Code Alarm E461

Quick Arm R408 Forced Arm R423 Auto Arm R403

Auto Disarm E403 Remote arm/disarm (Disarm) R407

Remote arm/disarm (Arm) E407 RF receiver Jam Detect Event E344 RF receiver Jam Detect Restore R344

Low system battery Event (Panel Low Battery) E302

60 HLX-24 Hardware Installation and Programming Manual

Reporting Codes

Programmable Feature Description CID Code

Low system battery Restore (Panel Low Battery) R302 AC Loss Event (Panel AC Failure) E301

AC Loss Restore (Panel AC Failure) R301 Line Failure E351 Line Restore R351

Zone swinger shutdown E575 Zone swinger restore R575

Inaccurate Time Restore R626 Battery Missing E311 Tamper Event (Panel Tamper) E137

Tamper Restore (Panel Tamper) R137 Fire Zone Trouble Event E373

Fire Zone Trouble Restore R373 Fire Zone Bypass Event E571 Fire Zone Bypass Restore R571

24 H Zone Bypass Event E572 24 H Zone Bypass Restore R572

Burglar Zone Bypass Event E573 Burglar Zone Bypass Restore R573 Grouped Zone Bypass Event E574

Enter Test Mode E607 Exit Test Mode R607

Walk Zone Tested Report Event E613 Periodic Test Report Event E602 Listen in Follow E606

Programming Mode Enter E627 Programming Mode Exit R628

Delete User or Device E306 Panel No Activity Alarm E382 Zone Exit Error E374

Zone Cross Trouble E378 Recent To Close E459

Auto Test E613

*This event is not sent by the panel to the dialer. Listen in Follow code is produced by the dialer according to current configuration:

 2-way voice enable/disable  2-way voice period – therefore there is no index

HLX-24 Hardware Installation and Programming Manual 61

GSM Stick Errors

E. GSM Stick Errors

Table 15 shows a list of possible errors that may appear on the HomeLogiX™ alarm panel related to the GSM stick.

Table 15: GSM Stick Errors

LCD Error Display

Communicator Error No SIM

SIM request Fail SIM Not Ready

No Signal (99) RSSI Length Err

GSM Type Error SIM Not Register

62 HLX-24 Hardware Installation and Programming Manual

Settings Requirements for CENELEC

F. Settings Requirements for

CENELEC

Quick Arm

Jamming

Tamper

Low Battery

AC Fail

Comm Fail

Line Fail

Panic

Supervision

Memory Alarm

System Status

Arm Instant

Event Filter

Enabled

3..10

HLX-24 Hardware Installation and Programming Manual 63

Default Parameter Values

G. Default Parameter Values

Description Default Value Range

Zones

Zone 1 Settings

Zone Type Delay Zone description ATTIC

Chime type No chime No activity check Disabled

Swinger trips 2 0..6 Cross zone 0 0..24 Cross time (seconds) 30 0..90

Abort time Enabled

Zone 2 Settings

Zone Type Delay

Zone description ATTIC Chime type No chime No activity check Disabled

Swinger trips 2 0..6 Cross zone None 0..24

Cross time (seconds) 30 0..90 Abort time Enabled

Zone 3 Settings

Zone Type Perimeter

Zone description ATTIC Chime type No chime

No activity check Disabled Swinger trips 2 0..6 Cross zone None 0..24

Cross time (seconds) 30 0..90 Abort time Enabled

Zones 4–40 Settings

Zone type Interior Zone description ATTIC Chime type No chime

No activity check Disabled Swinger trips 2 0..6

Cross zone None 0..24

64 HLX-24 Hardware Installation and Programming Manual

Default Parameter Values

Description Default Value Range

Cross time (seconds) 30 0..90 Abort time Enabled

Security

Exit delay (seconds) 60 45..255 Entry delay (seconds) 30 30..240 Silent exit and entry Disabled

Restart exit Enabled

Auto Arming Sunday–Saturday

Arm mode Disabled

Arm time 00:00 Arming duration (minutes) 0 0..9999

Sirens

Siren time (minutes) 3 01..15

Siren mode Away + Home Wired siren relay polarity N.O

Internal siren Enabled Wired siren Enabled

General Security Settings

Supervision time (hours) 24 1..48

Jamming detection Disabled No activity timer Disabled

Trouble beeps Disabled Bypass option Off Quick arm Disabled

Panic button Audible Duress code

Alarm cancel time (minutes) 5 0 (disable), 5..10 Alarm abort time (seconds) 30 0..45 Backlight time 15 15, Always

Hide display Off Key beeps On

Instant arm On Language English

CP-01 Settings

Recent to close time (minutes) 2 0..15

Swinger shutdown time (hours) 8 0..8 Abort annunciation Enabled

Cancel annunciation Enabled

HLX-24 Hardware Installation and Programming Manual 65

Default Parameter Values

Description Default Value Range

Fire verification Disabled Unvacated premises Enabled

Squawk buzzer Enabled Squawk siren Enabled

EN CENELEC Setting

Status Disabled

Event filter counter 0 0..10 Access memory Disabled

Access system status Disabled Access arm instant Disabled Low battery Disabled

Power fail Disabled Tamper Disabled

Supervision Disabled Dialer fail Disabled Panic Disabled

Communication

Panel phone

GPRS Settings

APN Uinternet

User name Password Server IO address 192.168.10.10

Server port number 1545 00000..65535 Listen port number 200 00000..65535

Private Reporting

Private phone 1 number Private phone 2 number Private phone 3 number

Alarm reporting Voice alerts Trouble reporting Voice alerts

Alerts reporting Disabled Arm/disarm reporting Disabled Restore reporting Disabled

Bypass reporting Disabled Dialing attempts 3 1..15

Link type – private phone Call via PSTN

66 HLX-24 Hardware Installation and Programming Manual

Default Parameter Values

Description Default Value Range

Central Station (CS) Settings

Primary CS connection method Primary Phone number

Primary Account code FFFF Primary Reporting option Alarms, troubles Primary Link type PSTN

Primary Acknowledge timeout (seconds)

Primary Signal gain 1000 300..1200 Primary Call wait cancel Disable Secondary Account code FFFF

Secondary Reporting option Alarms, troubles Secondary Link type PSTN

Secondary Acknowledge timeout (seconds)

Secondary Signal gain 1000 300..1200

Secondary Call wait cancel Disable Reporting protocol CID

Dialing attempts 3 1..16 Days between tests (days) 7 1..8 Line test time 12:00

AC fail reporting delay (minutes) 0 0..240

Two Way Voice

CS 2WV Disabled

CS 2WV timeout 30 seconds 30 sec,1,2,3,4 min

Miscellaneous

CS/Private 2WV mode Full duplex Fax defeat Mode Disabled

Number of rings 6 1..9 Country region setting Other

Automation

Panel keypad PGM function Disabled

PGM1

Pulse time (seconds) 5 1..99 Arm away Ignore

Arm home Ignore Disarm Ignore

Alarm Disabled Panic Ignore

30 10..60

HLX-24 Hardware Installation and Programming Manual 67

Default Parameter Values

Description Default Value Range

Trouble Ignore AC loss Disabled

Exit / Enter Enabled RC 1–8 panic Ignore Zone 1–24 opened or detected Ignore

PGM2

Pulse time (seconds) 5 1..99 Arm away Ignore

Arm home Ignore Disarm Ignore Alarm Disabled

Panic Ignore Trouble Ignore

AC loss Disabled Exit/Enter Enabled RC 1–8 panic Ignore

Zone 1–24 opened or detected Ignore

Options

Panel keypad Mute function Disabled

Custom Zone Description

House name HOMELOGIX Custom Description 1 CUSTOM #1 Custom Description 2 CUSTOM #2

Custom Description 3 CUSTOM #3 Custom Description 4 CUSTOM #4

Custom Description 5 CUSTOM #5

68 HLX-24 Hardware Installation and Programming Manual

Labeling Instructions

H. Labeling Instructions

 See the installation diagram in Section 4.4.  Do not connect to a receptacle controlled by a switch.  This equipment should be installed in accordance with Chapter 2 of the

National Fire Alarm Code, ANSI/NFPA 72, (National Fire Protection Association, Batterymarch Park, Quincy, MA, 02269). Printed information describing proper installation, operation, testing, maintenance, evacuation planning, and repair service is to be provided with this equipment. Warning: Owner’s instruction notice: ’Not to be removed by anyone except occupant’.

 See Section 3.3 for wired zone inputs specifications.

HLX-24 Hardware Installation and Programming Manual 69

Declaration of Conformity

I. Declaration of Conformity

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

 Reorient or relocate the receiving antenna.  Increase the separation between the equipment and receiver.  Connect the equipment into an outlet on a circuit different from that to

which the receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

70 HLX-24 Hardware Installation and Programming Manual

Limited Warranty

J. Limited Warranty

The full ROSSLARE Limited Warranty Statement is available in the Quick Links section on the ROSSLARE website at www.rosslaresecurity.com.

Rosslare considers any use of this product as agreement to the Warranty Terms even if you do not review them.

HLX-24 Hardware Installation and Programming Manual 71

Asia Pacific, Middle East, Africa

Rosslare Enterprises Ltd. Kowloon Bay, Hong Kong Tel: +852 2795-5630 Fax: +852 2795-1508 support.apac@rosslaresecurity.com

United States and Canada

Rosslare Security Products, Inc. Southlake, TX, USA Toll Free: +1-866-632-1101 Local: +1-817-305-0006 Fax: +1-817-305-0069 support.na@rosslaresecurity.com

Europe
