Rosslare AYC T65 User Manual

2013

January

AYC-Ex5 Family AYC-T65

Convertible 2x6 Ultra-Slim Backlit PIN & Prox Reader/Controller

Installation and Programming Manual

Ex5 Models:

AYC-E55 AYC-E65BB AYC-E65BG AYC-E65BW

T65 Models:

AYC-T65B AYC-T65N

Ex5 T65

This manual and the information contained herein are proprietary to REL, RSP Inc. and/or their related companies and/or subsidiaries’ (hereafter:”ROSSLARE”). Only ROSSLARE and its customers have the right to use the information.

No part of this manual may be re-produced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of ROSSLARE.

ROSSLARE owns patents and patent applications, trademarks, copyrights, or other intellectual property rights covering the subject matter in this manual.

TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL PROCEEDINGS.

The furnishing of this manual to any party does not give that party or any third party any license to these patents, trademarks, copyrights or other intellectual property rights, except as expressly provided in any written agreement of ROSSLARE.

ROSSLARE reserves the right to revise and change this document at any time, without being obliged to announce such revisions or changes beforehand or after the fact.

Table of Contents

1. General Information ................................................... 9

1.1 Introduction ............................................................................ 9

1.2 Reader/Controller Types......................................................... 10

1.3 Box Content ......................................................................... 10

1.4 Ancillary Equipment .............................................................. 11

1.4.1 Reader .......................................................................................... 11

1.4.2 Controller ..................................................................................... 11

2. Technical Specifications ............................................ 12

2.1 Key Features ......................................................................... 13

2.1.1 Reader .......................................................................................... 14

2.1.2 Controller ..................................................................................... 14

3. Installation ................................................................ 15

3.1 Mounting the AYC-Ex5 and AYC-T65 .................................... 15

4. Wiring Instructions ................................................... 16

5. Reader Functionality ................................................. 20

5.1 Transmit Mode ..................................................................... 20

5.2 Programming the AYC-Ex5 and AYC-T65 ............................... 20

5.2.1 Entering Programming Mode ........................................................ 21

5.2.2 Exiting Programming Mode .......................................................... 22

5.2.3 Selecting Keypad Transmission Format ......................................... 22

5.2.4 Selecting Proximity Card Transmission Format .............................. 29

5.2.5 Changing the Programming Code ................................................ 31

5.2.6 Changing the Facility Code ........................................................... 31

5.3 Setting the Backlight ............................................................. 32

AYC-Ex5 and AYC-T65 Installation and Programming Manual iii

Table of Contents

5.3.1 Return to Factory Default Settings ................................................ 33

5.3.2 Replacing a Lost Programming Code ............................................ 33

6. Controller Functionality............................................ 34

6.1 Normal, Secure, and Master Users .......................................... 34

6.2 Modes of Operation .............................................................. 35

6.2.1 Normal Mode ............................................................................... 35

6.2.2 Bypass Mode ................................................................................ 35

6.2.3 Secure Mode ................................................................................ 36

6.2.4 Changing the Modes of Operation ............................................... 36

6.3 Auxiliary Input & Output ........................................................ 37

6.4 Door Alarms ......................................................................... 38

6.5 Internal Case and Back Tamper .............................................. 38

6.6 Lockout Feature (Keypad Tamper) .......................................... 38

6.7 Request to Exit (REX) Function ............................................... 38

6.8 Secure Application Appurtenances ......................................... 39

6.9 Programming the AYC-Ex5 and AYC-T65 ............................... 39

6.9.1 Entering Programming Mode ........................................................ 40

6.9.2 Exiting Programming Mode .......................................................... 41

6.9.3 Changing Lock Strike Code .......................................................... 41

6.9.4 Changing Auxiliary Code .............................................................. 42

6.9.5 Changing the Programming Code ................................................ 43

6.9.6 Changing the Normal/Secure Code .............................................. 43

6.9.7 Changing the Normal/Bypass Code and Door Chime Settings ...... 44

6.9.8 Setting Fail Safe/Secure Operation, Tamper Siren and Lock Strike

Release Time ................................................................................. 45

6.9.9 Defining the Auxiliary Input and Output ....................................... 46

6.9.10 Detailed Reference Guide ............................................................. 49

6.9.11 Setting the Lockout Feature .......................................................... 53

iv AYC-Ex5 and AYC-T65 Installation and Programming Manual

Table of Contents

6.9.12 Setting the Backlight Behavior ...................................................... 54

6.9.13 Enrolling Primary and Secondary Codes ........................................ 54

6.9.14 Deleting Primary and Secondary Codes ......................................... 58

6.9.15 Relay Codes Assignment ............................................................... 60

6.9.16 Relay Code Assignment using Standard Method .......................... 60

6.9.17 Relay Code Assignment using Search Method .............................. 61

6.9.18 PIN Code Length/Factory Default Settings ..................................... 62

6.9.19 Replacing a Lost Programming Code ............................................ 63

6.9.20 Exiting Secure Mode if Normal/Secure Code was Lost................... 63

A. Declaration of Conformity........................................ 64

B. Limited Warranty ...................................................... 65

AYC-Ex5 and AYC-T65 Installation and Programming Manual v

List of Figures

Figure 1: Drilling & Mounting Template for AYC-Ex5....................................... 15

Figure 2: Drilling & Mounting Template for AYC-T65 ...................................... 15

Figure 3: Controller Application Wiring Diagram #1 ........................................ 17

Figure 4: Controller Application Wiring Diagram #2 ........................................ 18

Figure 5: Controller Application Wiring Diagram #3 ........................................ 18

Figure 6: Reader Application Wiring Diagram #4 ............................................. 19

vi AYC-Ex5 and AYC-T65 Installation and Programming Manual

List of Tables

Table 1: Wiring Colors ..................................................................................... 16

Table 2: Reader Programming Menus .............................................................. 21

Table 3: Keypad Transmission Format Option Number .................................... 23

Table 4: Controller Programming Menu .......................................................... 40

Table 5: Quick Reference Guide for Auxiliary Mode Setting ............................. 48

AYC-Ex5 and AYC-T65 Installation and Programming Manual vii

Notice and Disclaimer

This manual’s sole purpose is to assist installers and/or users in the safe and efficient installation and usage of the system and/or product, and/or software described herein.

EFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM, THE INSTALLER AND THE

USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY REQUIREMENTS AND OPERATING PROCEDURES

 The system must not be used for purposes other than those for which it

was designed.

 The use of the software associated with the system and/or product, if

applicable, is subject to the terms of the license provided as part of the purchase documents.

 ROSSLARE ENTERPRISES LIMITED and/or its related companies and/or

subsidiaries’ (hereafter:"ROSSLARE") exclusive warranty and liability is limited to the warranty and liability statement provided in an appendix at the end of this document.

 This manual describes the maximum configuration of the system with the

maximum number of functions, including future options. Therefore, not all functions described in this manual may be available in the specific system and/or product configuration you purchased.

 Incorrect operation or installation, or failure of the user to effectively

maintain the system, relieves the manufacturer (and seller) from all or any responsibility for consequent noncompliance, damage, or injury.

 The text, images and graphics contained in the manual are for the purpose

of illustration and reference only.

 In no event shall manufacturer be liable for any special, direct, indirect,

incidental, consequential, exemplary or punitive damages (including, without limitation, any and all damages from business interruption, loss of profits or revenue, cost of capital or loss of use of any property or capital or injury).

 All graphics in this manual are for reference only, some deviation between

the image(s) and the actual product may occur.

 All wiring diagrams are intended for reference only, the photograph or

graphic of the PCB(s) are intended for clearer illustration and understanding of the product and may differ from the actual PCB(s).

viii AYC-Ex5 and AYC-T65 Installation and Programming Manual

General Information

1. General Information

1.1 Introduction

The AYC-T65 and the AYC-Ex5 family are ultra-slim, vandal-resistant, integrated convertible readers and controllers with a Piezo Mullion keypad.

These units automatically determine whether to function as a reader or as a controller. If the unit is connected to a standard access control unit, then it functions as a reader. If the unit is connected to Rosslare's secure application appurtenances such as the PS-A25T, PSC25T or PS-C25TU, it functions as a secured controller.

For information on how the unit functions as a reader, see Chapter 5. For information on how the unit functions as a controller, see Chapter

6. The unit is vandal resistant and water resistant, suitable for indoor or

outdoor mounting. As a controller, the unit accepts up to 500 users and allows entry via a

personal identification number (PIN). The PIN code length for the controller has several options. The PIN

code length can be a set number of 4, 5, or 6 digits or it can be a 4to 8-digit option.

This manual contains the following information:

 Installation  Wiring instructions  Operation Instructions

AYC-Ex5 and AYC-T65 Installation and Programming Manual 9

General Information

Proximity



1.2 Reader/Controller Types

The different types of units described in this manual are:

 Type E55 has PIN only  Type E65 and T65 have PIN and Proximity card

Backlight Keypad

Type

AYC-E55

AYC-E65B

AYC-E65BB

AYC-T65

 Piezoelectric 

 Piezoelectric

 Piezoelectric 



Upon power-on reset, the AYC-Ex5 and AYC-T65 units search for the presence of Rosslare's secure application appurtenances. If a secure application appurtenance is detected, then the unit is automatically configured as a secure access control unit. This is indicated by two short beeps. If the secured controller is not detected, it is automatically configured as a reader, indicated by one short beep.

1.3 Box Content

Before beginning verify that all of the following is in the box. If anything is missing, please report the discrepancy to your nearest Rosslare office.

 One AYC-E55, AYC-E65B, AYC-E65BB, or AYC-T65 unit  Installation kit  Installation and operating instructions  secure application appurtenance (optional for controller

applications)

10 AYC-Ex5 and AYC-T65 Installation and Programming Manual

General Information

1.4 Ancillary Equipment

The following equipment is required to complete your installation:

1.4.1 Reader

 Compatible host controller (not supplied) – UL listed access

control unit, such as model AC-215U

1.4.2 Controller

 Secure application appurtenances (such as the PS-A25T, PS-C25T

or PS-C25TU secure controllers) The controller connects to the following:

 Electric lock strike mechanism or a magnetic lock device,

which implements fail safe (power to lock) or fail secure (power to open) functions.

 Request to Exit (REX) button – normally open type

Switch is closed when pressed.

 Door monitor switch

Rosslare accessories can be found on

www.rosslaresecurity.com.

AYC-Ex5 and AYC-T65 Installation and Programming Manual 11

Technical Specifications

2. Technical Specifications

Specification AYC-E55 AYC-E65B,

AYC-E65BB

Electrical Characteristics

Power Supply Type

Operating Voltage Range

Input Current Standby

Max Input Current

LED Control Input

Tamper Output

Cable Distance to Host Controller

Max Proximity Card Read Range*

Proximity Card Modulation

Proximity Card Compatibility

Card Transmit Format (Reader)

Keypad Transmit Format (Reader)

LED Indicators

Communication

5–16 VDC (when used as a controller, provided by the

15 m A@12 VDC 92 mA @12 VDC

40 mA @16 VDC 105 mA @16 VDC

Open collector, active low, 30 mA max sink current

Up to 500 ft. (150 meters) using an 18 AWG cable

Data1/C1, Data0/C2—open collector, 5 V termination

Linear type – recommended

secure application appurtenance)

Dry contact N.O.

N/A 1.58 inch (40 mm )

N/A ASK at 125 KHz

N/A EM cards

N/A Wiegand 26-Bit, or Clock & Data

Programmable PIN code formats

Two tri-colored LEDs

AYC-T65

12 AYC-Ex5 and AYC-T65 Installation and Programming Manual

Technical Specifications

Specification AYC-E55 AYC-E65B,

AYC-T65

AYC-E65BB

Environmental Characteristics

Operating Temp. Range

Operating Humidity

Outdoor Usage

Weather-resistant, meets IP-68, epoxy potted, suitable

-22°F to 150°F (-30°C to 65°C)

0 to 95% (non-condensing)

for outdoor use

Physical Characteristics

Size (Height x Width x

Depth)

Weight

* Measured using Rosslare proximity card (AT-14) or equivalent. Range also

depends on electrical environment and proximity to metal.

155 x 44 x 6.5

(6.1 x 1.73 x

0.256 in.)

120 g (0.265 lb) 143 g (0.315 lb) 121 g (0.27 lb)

155 x 44 x 9 mm

(6.1 x 1.73 x

0.354 in.)

121 x 70 x 8 mm

(4.77 x 2.76 x

0.31 in.)

2.1 Key Features

The key features for the AYC-Ex5 and AYC-T65 series are:

 Ultra-slim flush-mount design on flat surface  Built-in piezoelectric keypad for PIN code entry  Built-in 125 KHz ASK EM proximity card reader (AYC-E65B, AYC-

E65BB, AYC-T65)

 Programmable patented blue backlit keypad (AYC-E65B, AYC-

E65BB, AYC-T65)

 Optical back tamper sensor and open collector tamper output  Lockout feature on wrong entries (keypad tamper)  Internal buzzer provides audible interface feedback  Two status/programming interface LEDs (tri-colored)  Fully potted construction for outdoor use

AYC-Ex5 and AYC-T65 Installation and Programming Manual 13

Technical Specifications

 Comes with mounting template for easier installation  Comes with an installation kit that includes a security screw and a

security screw tool

2.1.1 Reader

 Programmable keypad transmission format  Programmable card transmission formats: Clock & Data and

Wiegand 26-Bit (AYC-E65B, AYC-E65BB, AYC-T65)

 LED control input  Programmable Facility code

2.1.2 Controller

 Bi-directional secure communication with Rosslare’s secure

application appurtenance

 Three User Levels:

 Normal User  Secure User  Master User

 "Code Search" feature that helps make maintaining user codes

easier

 Three modes of operation:

 Normal mode  Bypass mode

 Secure mode

 REX signal from Rosslare’s secure application appurtenance  Chime bell and siren features are available with secure application

appurtenance

 Programmable Lock Strike Release, Siren, and Alarm Delay timers  Programmable Auxiliary input with versatile functions  Programmable Auxiliary output functions  Programmable PIN code length

14 AYC-Ex5 and AYC-T65 Installation and Programming Manual

Installation

3. Installation

3.1 Mounting the AYC-Ex5 and AYC-T65

Before starting, select the location to mount the AYC-Ex5 or AYCT65. This location should be at shoulder height.

For wall mounting, use the included mounting template as a guide for drilling holes for mounting screws and wiring. For US Gang Box mounting, no drilling is necessary.

Figure 1: Drilling & Mounting

Template for AYC-Ex5

Figure 2: Drilling & Mounting

Template for AYC-T65

When the unit is used as a reader, route the interface cable from the unit to the controller. When the unit is used as a secured controller, route the interface cable from the unit to Rosslare’s secure application appurtenance. A linear type power supply is recommended, when using the unit as a controller.

Screw the unit to its mounting location or US gang box.

AYC-Ex5 and AYC-T65 Installation and Programming Manual 15

Wiring Instructions

4. Wiring Instructions

The unit is supplied with a 60-inch (1.5 meter) pigtail, having a 6conductor cable. To connect the unit to the controller, perform the following:

Prepare the unit's cable by cutting the cable jacket back 1¼ inches and strip the wire ½ inch. Prepare the controller cable by cutting the cable jacket back 1¼ inches and strip the wire ½ inch.

Splice the unit’s pigtail wires to the corresponding controller wires and cover each connection.

Refer to Table 1 and to the wiring diagrams provided on the following pages.

Table 1: Wiring Colors

Reader Controller Color Functionality

5~16 VDC 5~16 VDC Red +DC Input

Shield/Ground Shield/Ground Black Ground

Data 1/Clock C 1 White Communication

Data 0/Data C 2 Green Communication

LEDCTL AUX. IN Brown LED Control/Auxiliary Input

Tamper Tamper Purple Tamper

If the tamper output is used, connect the purple wire to the correct input on the controller when used as a reader, or to a zone input of an intruder alarm system when used as a controller.

Trim and cover all unused conductors.

16 AYC-Ex5 and AYC-T65 Installation and Programming Manual

Wiring Instructions

earth ground, or a signal ground connection at the panel, or power

• The individual wires from the unit are color-coded according the Wiegand standard.

• When using a separate power supply for the reader, this power supply and that of the controller must have a common ground.

• The reader’s cable shield wire should preferably be attached to an

supply end of the cable. This configuration is best for shielding the reader cable from external interference

Figure 3 shows the wiring for the controller application using a dual relay secure application appurtenance.

Figure 3: Controller Application Wiring Diagram #1

AYC-

Ex5/T65

Transorb: 1.5KE77c – Connect to load terminals

(optional transor b for inductive loads, not supplied)

AYC-Ex5 and AYC-T65 Installation and Programming Manual 17

Wiring Instructions

Figure 4 shows the auxiliary output connection using the internal power.

Figure 4: Controller Application Wiring Diagram #2

Figure 5 shows the auxiliary output connection using external power.

Figure 5: Controller Application Wiring Diagram #3

18 AYC-Ex5 and AYC-T65 Installation and Programming Manual

Wiring Instructions

Figure 6 shows how to wire a reader to the access control panel.

Figure 6: Reader Application Wiring Diagram #4

Standard access control

system with Wiegand

reader/keypad interface

AYC-Ex5

AYC-Ex5 and AYC-T65 Installation and Programming Manual 19

Reader Functionality

Mode/Transmit

Door/ Progra m

Red

5. Reader Functionality

The AYC-Ex5 series and the AYC-T65 can function both as a reader and as a controller. If the unit is connected to standard access controller, it functions as a reader, indicated by one beep immediately after power-on reset.

The following explains how the AYC-Ex5 and AYC-T65 function as a reader.

5.1 Transmit Mode

When the unit is in Transmit mode, it is ready to receive data from a presented proximity card or an entered PIN code.

When the reader is in Transmit mode, the Transmit LED is red and the Program LED is off.

When a proximity card or PIN entry is being transmitted, the Transmit LED flashes green.

PIN data can be sent via one of eight different Keypad Transmission Formats (see Section 5.2.3).

Proximity cards presented to the reader are always sent in either Wiegand 26-Bit, Clock & Data or, Wiegand Card + PIN format (see Section 5.2.4).

5.2 Programming the AYC-Ex5 and AYC-T65

Programming the AYC-Ex5 and AYC-T65 is done solely via the unit's keypad driven Programming Menu System. To reach the Programming Menu System, the unit must first be placed into Programming mode. During the unit’s manufacturing process, certain codes and settings are pre-programmed. These settings are called the default factory settings.

Table 2 shows the names of all the AYC-Ex5 and AYC-T65 reader menus.

20 AYC-Ex5 and AYC-T65 Installation and Programming Manual

Reader Functionality

Mode/Transmit

Door/ Progra m Red

Default factory settings are marked by a "*" sign.

Table 2: Reader Programming Menus

Menu Description Default

1 Selecting Keypad Transmission Format

Single Key, 6-Bit Wiegand (Rosslare Format) Single Key, 6-Bit Wiegand with Nibble + Parity Bits Single Key, 8-Bit Wiegand, Nibbles Complemented 4 Keys Binary + Facility Code, Wiegand 26-Bit 1 to 5 Keys + Facility Code, Wiegand 26-Bit 6 Keys BCD and Parity Bits, Wiegand 26-Bit Single Key, 3x4 Matrix Keypad 1 to 8 Keys BCD, Clock & Data

2 Selecting Card Transmission Format

Wiegand 26-Bit Clock & Data Wiegand Card + PIN

3 Changing the Programming Code

4 Changing the Facility Code

6 Backlight Options

Off On (Default) Off until key press when on for 10 seconds Dimmed until key press when on for 10 seconds

0 Return to Factory Default Settings

1234

5.2.1 Entering Programming Mode

1. Press # 4 times.

The Transmit LED turns off and the Program LED turns red.

AYC-Ex5 and AYC-T65 Installation and Programming Manual 21

+ 47 hidden pages
