Rosslare ACQ4XXB Users Manual

AC-Q4x Series
Anti-Vandal Standalone Controllers
Installation and Programming Manual
Models:
AC-Q41HB AC-Q41HP AC-Q41SB AC-Q42HB AC-Q42HP AC-Q42SB
Copyright © 2017 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to ROSSLARE ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’ (hereafter: "ROSSLARE"). Only ROSSLARE and its customers have the right to use the information.
No part of this manual may be re-produced or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the express written permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights, or other intellectual property rights covering the subject matter in this manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND TRANSMITTAL TO THIRD PARTIES WITHOUT EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any third party any license to these patents, trademarks, copyrights or other intellectual property rights, except as expressly provided in any written agreement of ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any time, without being obliged to announce such revisions or changes beforehand or after the fact.
Table of Contents
Table of Contents
1. Introduction ................................................................ 9
1.1 Controller Types ...................................................................... 9
1.2 Box Content ......................................................................... 10
1.3 Ancillary Equipment .............................................................. 10
1.4 Front Panel Description .......................................................... 11
2. Technical Specifications ............................................ 12
3. Installation ................................................................ 14
3.1 Mounting ............................................................................. 14
3.2 Wiring .................................................................................. 15
3.2.1
3.2.2
4. Operation .................................................................. 24
4.1 Modes of Operation .............................................................. 24
4.1.1
4.1.2
4.1.3
4.2 User Levels ............................................................................ 25
4.3 Switching Operational Modes ................................................ 26
4.3.1
4.3.2
4.3.3
4.3.4
4.4 Auxiliary Input and Output..................................................... 27
4.5 REX Button ........................................................................... 27
Pre-wired Models .......................................................................... 16
Terminal Block Models .................................................................. 20
Normal Mode ............................................................................... 24
Secure Mode ................................................................................ 24
Bypass Mode ................................................................................ 24
From Normal to Secure Mode ....................................................... 26
From Secure to Normal Mode ....................................................... 26
From Normal to Bypass Mode ....................................................... 27
From Bypass to Normal Mode ....................................................... 27
AC-Q4x Series Installation and Programming Manual iii
Table of Contents
4.6 Tamper Feature ..................................................................... 28
4.7 Lockout Feature (Keypad/Card Tamper) .................................. 28
4.8 BL-D40 External Sounder ....................................................... 29
5. Programming ............................................................ 30
5.1 Entering the Programming Mode ........................................... 31
5.2 Exiting the Programming Mode .............................................. 32
5.3 Changing the Open Code ...................................................... 32
5.4 Changing the Auxiliary Code ................................................. 33
5.5 Changing the Programming Code .......................................... 34
5.6 Changing the Normal/Secure Code ........................................ 34
5.7 Changing the Normal/Bypass Code ........................................ 35
5.8 Setting Fail Safe/Secure Operation, Tamper Siren and Lock Strike
Release Time ......................................................................... 36
5.9 Setting Auxiliary Modes ......................................................... 37
5.9.1
5.9.2
5.9.3
5.9.4
5.9.5
5.9.6
5.9.7
5.9.8
5.9.9
5.9.10 Auxiliary Mode 9 .......................................................................... 42
5.10 Keypad Heater Operation ...................................................... 43
5.11 Setting the Lockout Feature ................................................... 43
5.12 Setting the Backlight Behavior ............................................... 45
5.13 Enrolling Primary and Secondary Codes .................................. 45
Auxiliary Mode 0 .......................................................................... 39
Auxiliary Mode 1 .......................................................................... 39
Auxiliary Mode 2 .......................................................................... 39
Auxiliary Mode 3 .......................................................................... 40
Auxiliary Mode 4 .......................................................................... 40
Auxiliary Mode 5 .......................................................................... 40
Auxiliary Mode 6 .......................................................................... 41
Auxiliary Mode 7 .......................................................................... 41
Auxiliary Mode 8 .......................................................................... 42
iv AC-Q4x Series Installation and Programming Manual
Table of Contents
5.13.1 Primary Codes Definition .............................................................. 45
5.13.2 Secondary Codes Definition .......................................................... 46
5.13.3 Enrolling Methods ........................................................................ 46
5.14 Deleting Primary and Secondary Codes ................................... 49
5.14.1 Deleting Primary and Secondary Codes using the Standard Method
..................................................................................................... 49
5.14.2 Deleting Primary and Secondary Codes using the Code Search
Method ........................................................................................ 50
5.15 Relay Codes Assignment ........................................................ 51
5.15.1 Relay Code Assignment using Standard Method .......................... 51
5.15.2 Relay Code Assignment using Search Method .............................. 52
5.16 Changing PIN Code Length/Factory Default Settings ............... 54
5.17 Replacing a Programming Code ............................................. 55
5.18 Replacing a Normal/Secure Code ........................................... 55
A. Limited Warranty ...................................................... 56
AC-Q4x Series Installation and Programming Manual v
List of Figures
List of Figures
Figure 1: Front Panel........................................................................................ 11
Figure 2: Drilling Holes Identification ............................................................... 14
Figure 3: Pre-Wired Connection for Lock Strike Relay & REX............................ 17
Figure 4: Pre-Wired Connection for Auxiliary Input & Output .......................... 18
Figure 5: Pre-Wired Connection for the BL-D40 External Sounder ................... 19
Figure 6: Connections to Terminal Blocks ........................................................ 20
Figure 7: Terminal Block Wiring of the Lock Strike Relay & REX ....................... 21
Figure 8: Terminal Block Wiring of the Auxiliary Input and Output .................. 22
Figure 9: Terminal Block Wiring of the BL-D40 External Sounder ..................... 23
vi AC-Q4x Series Installation and Programming Manual
List of Tables
List of Tables
Table 1: Wire Color Guide ............................................................................... 16
Table 2: Programming Menus.......................................................................... 30
Table 3: Quick Reference Guide for Auxiliary Mode Setting ............................. 38
AC-Q4x Series Installation and Programming Manual vii
Introduction
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe and efficient installation and usage of the system and/or product, and/or software described herein.
B
EFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM, THE INSTALLER AND THE USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY REQUIREMENTS AND OPERATING PROCEDURES
The system must not be used for purposes other than those for which it
was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of the purchase documents.
ROSSLARE exclusive warranty and liability is limited to the warranty and
liability statement provided in an appendix at the end of this document.
This manual describes the maximum configuration of the system with the
maximum number of functions, including future options. Therefore, not all functions described in this manual may be available in the specific system and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or any responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the purpose
of illustration and reference only.
All data contained herein subject to change without prior notice.
In no event shall manufacturer be liable for any special, direct, indirect,
incidental, consequential, exemplary or punitive damages (including, without limitation, any and all damages from business interruption, loss of profits or revenue, cost of capital or loss of use of any property or capital or injury).
All graphics in this manual are for reference only, some deviation between
the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph or
graphic of the PCB(s) are intended for clearer illustration and understanding of the product and may differ from the actual PCB(s).
.
8 AC-Q4x Series Installation and Programming Manual
Introduction

1. Introduction

The AC-Q4x series are vandal resistant standalone controllers. All the units are water resistant and suitable for indoor or outdoor mounting. The unit(s) accepts up to 500 users and allows entry via a personal identification number (PIN) and/or by presenting a proximity card.

1.1 Controller Types

The different types of control units described in this manual are:
Type 41 – PIN only Type 42 – PIN and proximity card
Type 44 – PIN and proximity card, with piezoelectric contacts
Heater Relay
Current
AC-Q41HB
AC-Q41HP
AC-Q41SB
AC-Q42HB
AC-Q42HP
AC-Q42SB
AC-Q44
2 A Standard
2 A Standard
2 A Standard
2 A Standard
2 A Standard
2 A Standard
2 A Piezoelectric
Backlight Keypad
Type
Proximity
AC-Q4x Series Installation and Programming Manual 9
Introduction

1.2 Box Content

Before beginning, verify that all of the following is in the box. If anything is missing please report the discrepancy to your nearest Rosslare Office.
One controller unit Installation kit
1 drilling template (label/sticker)
1 security spline key 1 security hex screw
4 mounting screws and wall plugs

1.3 Ancillary Equipment

The following ancillary equipment may be required to complete your installation:
Electric Lock Strike Mechanism – Fail safe (power to lock) or fail
secure (power to open)
Power supply with backup battery – 12 to 24 VDC (from a
regulated power supply) or 16 to 24 VAC (from a transformer)
Request-to-Exit (REX) button (optional) – Normally open type;
switch is closed when pressed
BL-D40 external sounder (optional) – Provides siren, bell, and
chime
Magnetic contact (optional) – Installed for door monitor
capabilities
10 AC-Q4x Series Installation and Programming Manual
Introduction

1.4 Front Panel Description

Controls and indicators of all controller versions are identical (excluding the antenna, which is unique to Q42 and Q44) (Figure 1).
Figure 1: Front Panel
AC-Q4x Series Installation and Programming Manual 11
Technical Specifications

2. Technical Specifications

Input Voltage
Maximum Input Current (12 VDC)
Standby Input Current (12 VDC)
Maximum Relay Current
REX Input
Aux. Input
Max. Proximity Read Range*
VDC
VAC
Heater Off
Heater On
Heater Off
Heater On
AC-Q41HB AC-Q42HB
12–24 VAC 16–24 VAC 12–24 VAC 16–24 VAC
130 mA 125 mA 145 mA 130 mA 145 mA 125 mA
610 mA 605 mA 625 mA 610 mA 625 mA N/A
70 mA 65 mA 85 mA 70 mA 85 mA 65 mA
550 mA 545 mA 565 mA 550 mA 565 mA N/A
N/A 65 mm (2.5
in.)
AC­Q41SB
AC­Q41HP
12–24 VDC
2 A
Normally Open (dry contact)
Normally Open (dry contact)
N/A 65 mm (2.5 in.)
AC­Q42SB
AC­Q42HP
AC-Q44
12 AC-Q4x Series Installation and Programming Manual
Technical Specifications
Proximity Modulation
Proximity Card Compatibility
LED Indicators
Operating Temp. Range
Outdoor Usage
Size (H x W x T)
Weight
* Measured using a Rosslare proximity card or equivalent. Range also depends on electrical environment and proximity
to metal.
AC-Q41HB AC-Q42HB
N/A ASK at 125
kHz
N/A 26-Bit EM
cards
Water resistant, meets IP54 Weather resistant, epoxy-potted, meets IP65
120 x 76 x 27 mm
(4.7 x 3.0 x 1.1 in.)
440 g (1.0 lb) 521 g (1.2 lb)
AC­Q41SB
Two tri-colored LED (Mode and Door)
AC­Q41HP
N/A ASK at 125 kHz
N/A 26-Bit EM cards
-20ºC to 60ºC (-4ºF to 140ºF)
120 x 76 x 22 mm (4.7 x 3.0 x 0.9 in.)
AC­Q42SB
AC­Q42HP
AC-Q44
AC-Q4x Series Installation and Programming Manual 13
Installation

3. Installation

Installation of an RFID reader adjacent to metallic surfaces might alter the reader’s specifications. To diminish this interference, use a plastic spacer when mounting the reader.

3.1 Mounting

Prior to starting, select the location where the controller unit is to be mounted.
To mount the controller:
1. Peel off the back of the self-adhesive mounting label template
and place it on the required mounting location.
2. At the bottom of the unit’s case, remove the screw.
3. Carefully remove the snap-off front cover of the unit to reveal the
screw holes.
4. Depending on the type of installation, gang box or panel mount,
drill the respective holes in the rear cover (see Figure 2 for details). For gang box mounting, drill two holes marked “A”. For flat panel mount, drill four holes marked “B”.
Figure 2: Drilling Holes Identification
14 AC-Q4x Series Installation and Programming Manual
Installation
The central hole, marked “C” is for routing the wiring to the controller.
5. Drill an additional 10-mm (7/16”) hole for the cable. When
installing the reader on a metallic surface, cover the inside of the hole with a grommet or electrical tape.
6. Insert the unit’s cable wire into the cable hole and wire the unit
as described in Section 3.2.
7. Screw the back plate into the surface. Ensure the screws are the
size specified on the installation template.
The unit can also be mounted using strong epoxy glue. After application, firmly hold the unit in place until the glue dries.
8. Carefully re-attach the front cover of the unit.
9. Secure the front cover by using the supplied security Torx screw.
A Torx security screw tool is provided to tighten the security Torx screw.

3.2 Wiring

The controllers are provided either with a pre-wired cable or with a screw-type terminal block:
Pre-wired Cabling Models Terminal Block Models
AC-Q41SB AC-Q41HB/HP
AC-Q42SB AC-Q42HB
AC-Q44
AC-Q4x Series Installation and Programming Manual 15
Installation

3.2.1 Pre-wired Models

These units are supplied with a 10-conductor 60-cm (24-in.) pigtail (24-AWG cable) with exposed wires coated with solder.
To wire the controller:
1. Select the appropriate connections according to Table 1.
Table 1: Wire Color Guide
Color Description
Red V input
Black Ground
Green REX/BL
White In/Monitor
Purple Lock: Com
Gray Lock: N.O.
Brown Lock: N.C.
Blue Aux: Com
Yellow Aux: N.O.
Orange Aux: N.C.
2. Prepare the secured power supply’s cable by cutting the cable
jacket back 3.2 cm (1¼”) and strip the wire 1.3 cm (½”).
3. Splice the controller pigtail wires to the corresponding ancillary
devices and insulate each connection, including unused wires. Refer to the wiring diagrams, depending on the desired application:
Wiring the Lock Strike Relay & REX (Figure 3) Wiring for Auxiliary Input & Output (Figure 4)
Wiring for the BL-D40 External Sounder (Figure 5)
16 AC-Q4x Series Installation and Programming Manual
Installation
Figure 3: Pre-Wired Connection for Lock Strike Relay & REX
AC-Q4x Series Installation and Programming Manual 17
Installation
Figure 4: Pre-Wired Connection for Auxiliary Input & Output
18 AC-Q4x Series Installation and Programming Manual
Loading...
+ 39 hidden pages
