AC-F/G4x Series
Outdoor Backlit
Standalone Controllers
Models:
Installation and Programming
Manual
AC-F43
AC-F44
AC-G43
AC-G44
Copyright © 2018 by Rosslare. All rights reserved.
This manual and the information contained herein are proprietary to
ROSSLARE ENTERPRISES LIMITED and/or its related companies and/or
subsidiaries’ (hereafter: "ROSSLARE"). Only ROSSLARE and its customers
have the right to use the information.
No part of this manual may be re-produced or transmitted in any form or
by any means, electronic or mechanical, for any purpose, without the
express written permission of ROSSLARE.
ROSSLARE owns patents and patent applications, trademarks, copyrights,
or other intellectual property rights covering the subject matter in this
manual.
TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT
IN THIS DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT
LAWS AND OTHER LEGAL RIGHTS WORLDWIDE. THEIR USE,
REPRODUCTION, AND TRANSMITTAL TO THIRD PARTIES WITHOUT
EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL PROCEEDINGS.
The furnishing of this manual to any party does not give that party or any
third party any license to these patents, trademarks, copyrights or other
intellectual property rights, except as expressly provided in any written
agreement of ROSSLARE.
ROSSLARE reserves the right to revise and change this document at any
time, without being obliged to announce such revisions or changes
beforehand or after the fact.
Table of Contents
1. Introduction ............................................................. 11
2. Technical Specifications ............................................ 14
3. Installation .............................................................. 16
4. Operation ................................................................ 23
Table of Contents
1.1 Controller Types ...................................................................................... 11
1.2 Box Content .............................................................................................. 12
1.3 Ancillary Equipment ............................................................................... 12
3.1 Mounting ................................................................................................... 16
3.2 Wiring .......................................................................................................... 18
4.1 Modes of Operation .............................................................................. 23
4.1.1 Normal Mode ............................................................................................... 23
4.1.2 Secure Mode ................................................................................................. 23
4.1.3 Bypass Mode ................................................................................................. 24
4.2 User Levels................................................................................................. 24
4.3 Switching Operational Modes ........................................................... 26
4.3.1 From Normal to Secure Mode .............................................................. 26
4.3.2 From Secure to Normal Mode .............................................................. 26
4.3.3 From Normal to Bypass Mode .............................................................. 27
AC-F/G4x Series Installation and Programming Manual iii
Table of Contents
5. Programming ........................................................... 31
4.3.4 From Bypass to Normal Mode .............................................................. 27
4.4 Auxiliary Input and Output ................................................................. 28
4.5 REX Function ............................................................................................. 28
4.6 Tamper Feature ....................................................................................... 29
4.7 Lockout Feature (Keypad/Card Tamper) ....................................... 29
4.8 BL-D40 External Sounder ..................................................................... 30
5.1 Entering the Programming Mode .................................................... 33
5.2 Exiting the Programming Mode ....................................................... 33
5.3 Changing the Open Code ................................................................... 34
5.4 Changing the Auxiliary Code ............................................................. 36
5.5 Changing the Programming Code .................................................. 37
5.6 Changing the Normal/Secure Code ................................................ 38
5.7 Changing the Normal/Bypass Code ................................................ 38
5.8 Setting Fail Safe/Secure Operation ................................................. 40
5.9 Setting Auxiliary Modes ....................................................................... 41
5.9.1 Auxiliary Mode 0 ......................................................................................... 45
5.9.2 Auxiliary Mode 1 ......................................................................................... 45
5.9.3 Auxiliary Mode 2 ......................................................................................... 46
5.9.4 Auxiliary Mode 3 ......................................................................................... 46
5.9.5 Auxiliary Mode 4 ......................................................................................... 47
iv AC-F/G4x Series Installation and Programming Manual
Table of Contents
5.9.6 Auxiliary Mode 5 ......................................................................................... 47
5.9.7 Auxiliary Mode 6 ......................................................................................... 48
5.9.8 Auxiliary Mode 7 ......................................................................................... 48
5.9.9 Auxiliary Mode 8 ......................................................................................... 49
5.9.10 Auxiliary Mode 9 ......................................................................................... 50
5.10 Setting the Lockout Feature ............................................................... 50
5.11 Setting the Backlight Behavior .......................................................... 52
5.12 Enrolling Primary and Secondary Codes ....................................... 53
5.12.1 Primary Codes Definition ......................................................................... 53
5.12.2 Secondary Codes Definition ................................................................... 53
5.12.3 Enrolling Methods ....................................................................................... 54
5.13 Deleting Primary and Secondary Codes ........................................ 58
5.13.1 Deleting Primary and Secondary Codes using the Standard
Method ............................................................................................................ 58
5.13.2 Deleting Primary and Secondary Codes using the Code Search
Method ............................................................................................................ 59
5.14 Relay Codes Assignment ..................................................................... 60
5.14.1 Relay Code Assignment using Standard Method .......................... 61
5.14.2 Relay Code Assignment using Search Method .............................. 62
5.15 Changing PIN Code Length/Factory Default Settings ............. 64
5.16 Replacing a Programming Code ...................................................... 65
AC-F/G4x Series Installation and Programming Manual v
Table of Contents
A. Declaration of Conformity ......................................... 67
B. Limited Warranty ...................................................... 68
5.17 Replacing a Normal/Secure Code .................................................... 66
vi AC-F/G4x Series Installation and Programming Manual
List of Figures
List of Figures
Figure 1: Drilling Holes Identification ........................................................................ 17
Figure 2: Wiring Diagram for Lock Strike Relay and REX .................................. 20
Figure 3: Wiring Diagram for Auxiliary Input & Output .................................... 21
Figure 4: Wiring Diagram for the BL-D40 External Sounder ............................ 22
AC-F/G4x Series Installation and Programming Manual vii
List of Tables
List of Tables
Table 1: Wiring Color Guide .......................................................................................... 18
Table 2: Programming Menus....................................................................................... 31
Table 3: Quick Reference Guide for Auxiliary Mode Setting ........................... 43
viii AC-F/G4x Series Installation and Programming Manual
Introduction
BEFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM, THE INSTA LLER AND THE
USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY
REQUIREMENTS AND OPERATING PROCEDURES.
Notice and Disclaimer
This manual’s sole purpose is to assist installers and/or users in the safe
and efficient installation and usage of the system and/or product, and/or
software described herein.
The system must not be used for purposes other than those for
which it was designed.
The use of the software associated with the system and/or product, if
applicable, is subject to the terms of the license provided as part of
the purchase documents.
ROSSLARE exclusive warranty and liability is limited to the warranty
and liability statement provided in an appendix at the end of this
document.
This manual describes the maximum configuration of the system with
the maximum number of functions, including future options.
Therefore, not all functions described in this manual may be available
in the specific system and/or product configuration you purchased.
Incorrect operation or installation, or failure of the user to effectively
maintain the system, relieves the manufacturer (and seller) from all or
any responsibility for consequent noncompliance, damage, or injury.
The text, images and graphics contained in the manual are for the
purpose of illustration and reference only.
AC-F/G4x Series Installation and Programming Manual 9
Introduction
All data contained herein subject to change without prior notice.
In no event shall manufacturer be liable for any special, direct,
indirect, incidental, consequential, exemplary or punitive damages
(including, without limitation, any and all damages from business
interruption, loss of profits or revenue, cost of capital or loss of use
of any property or capital or injury).
All graphics in this manual are for reference only, some deviation
between the image(s) and the actual product may occur.
All wiring diagrams are intended for reference only, the photograph
or graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).
10 AC-F/G4x Series Installation and Programming Manual
Introduction
1.1
Controller Types
Relay
Current
Backlight
Keypad
Type
Proximity
1. Introduction
The AC-F4x series and AC-G4x series access control units are
waterproof standalone controllers. All the units are suitable for
both indoor and outdoor mounting. The unit(s) accepts up to
500 users and allows entry via a personal identification number
(PIN) and/or by presenting a proximity card.
The different types of control units described in this manual are:
AC-F43 – PIN only
AC-F44 – PIN and proximity card
AC-G43 – Mullion-Box PIN only
AC-G44 – Mullion-Box PIN and proximity card
AC-F43 2 A
AC-F44 2 A
AC-G43 2 A
AC-G44 2 A
AC-F/G4x Series Installation and Programming Manual 11
3x4 Standard
3x4 Standard
2x6 Mullion
2x6 Mullion
Introduction
1.2
Box Content
1.3
Ancillary Equipment
Before beginning, verify that all of the following is in the box. If
anything is missing please report the discrepancy to your nearest
Rosslare Office.
One unit
Installation kit
1 drilling template (label/sticker)
1 security spline key
1 security hex screw
4 mounting screws and wall plugs
The following ancillary equipment may be required to complete
your installation:
Electric Lock Strike Mechanism – fail safe (power to lock) or
fail secure (power to open).
Power supply with backup battery – 12 to 24 VDC (from a
regulated power supply) or 16 to 24 VAC (from a
transformer).
Request to Exit (REX) Button (optional) – normally open type;
switch is closed when pressed.
12 AC-F/G4x Series Installation and Programming Manual
Introduction
BL-D40 external sounder (optional) – provides siren, bell, and
chime.
Magnetic contact (optional) – installed for door monitor
capabilities.
Other Rosslare accessories can be found at Rosslare's website:
www.rosslaresecurity.com
AC-F/G4x Series Installation and Programming Manual 13
Technical Specifications
AC-F43
AC-F44
AC-G43
AC-G44
ASK at 125
ASK at 125
26 Bits EM
26 Bits EM
2. Technical Specifications
Input
Voltage
Maximum Input Current
(12 VDC)
Standby Input Current
(12 VDC)
Maximum Relay Current 2 A
REX Input Normally Open (dry contact)
Aux. Input Normally Open (dry contact)
Max. Proximity Read
Range*
Proximity Modulation N/A
Proximity Card
Compatibility
LED Indicators Two 3-colored LED (Mode and Door)
Operating Temp. Range -30°C to 65°C (-22°F to 150°F)
Operating Humidity
Range
Outdoor Usage Weather resistant, meets IP65, epoxy-potted
VDC 12 to 24 VDC
VAC 16 to 24 VAC
125 mA 160 mA 125 mA 160 mA
75 mA 95 mA 75 mA 95 mA
N/A 75 mm
(3.0 in.)
kHz
N/A
cards
0 to 95% (non-condensing)
N/A 80 mm
N/A
N/A
(3.2 in.)
kHz
cards
14 AC-F/G4x Series Installation and Programming Manual
Technical Specifications
AC-F43
AC-F44
AC-G43
AC-G44
Size (H x W x D) 120.9 x 71.1 x 29.7
mm (4.7 x 2.8 x 1.2 in.)
Weight 244 g (8.6 oz) 178 g (6.3 oz)
* Measured using a Rosslare proximity card or equivalent. Range also
depends on electrical environment and proximity to metal.
135.4 x 44.2 x 28.5
mm (5.3 x 1.7 x 1.1 in.)
AC-F/G4x Series Installation and Programming Manual 15
Installation
Installation of an RFID reader adjacent to metallic surfaces
might alter the reader’s
interference, use a plastic spacer when mounting the reader.
3.1
Mounting
To install the controller:
3. Installation
specifications. To diminish this
Prior to starting, select the location where the controller unit is
to be mounted.
1. Peel off the back of the self-adhesive mounting label
template and place it on the required mounting location.
2. At the bottom of the unit’s case, remove the screw.
3. Carefully remove the snap-off front cover of the unit to
reveal the screw holes.
4. Depending on the type of installation, gang box or panel
mount, drill the respective holes in the rear cover (Figure 1).
16 AC-F/G4x Series Installation and Programming Manual
Installation
The unit can also be mounted using strong epoxy glue.
After application, firmly hold the unit in place until the glue
dries
Figure 1: Drilling Holes Identification
7
5. Drill an additional 10-mm (
/16”) hole for the cable. When
installing the reader on a metallic surface, cover the inside of
the hole with a grommet or electrical tape.
6. Insert the unit’s cable wire into the cable hole and wire the
unit as described in Section 3.2.
7. Screw the back plate into the surface. Ensure the screws are
the size specified on the installation template.
.
8. Carefully re-attach the front cover of the unit.
9. Secure the front cover by using the supplied security Torx
screw. A Torx security screw tool is provided to tighten the
security Torx screw.
AC-F/G4x Series Installation and Programming Manual 17
Installation
3.2
Wiring
To wire the controller:
Color
Description
The unit is supplied with a 10-conductor 100-cm (40-in.) pigtail
(18-AWG cable) with exposed wires coated with solder.
1. Select the appropriate connections according to Table 1.
Table 1: Wiring Color Guide
Red V input
Black Ground
Green REX/BL
White In / Monitor
Purple Lock: Com
Gray Lock: N.O.
Brown Lock: N.C.
Blue Aux: Com
Yellow Aux: N.O.
Orange Aux: N.C.
2. Prepare the secured power supply’s cable by cutting the
cable jacket back 3.2 cm (1¼”) and strip the wire 1.3 cm
(½”).
18 AC-F/G4x Series Installation and Programming Manual
Installation
3. Splice the controller pigtail wires to the corresponding
ancillary devices and insulate each connection, including
unused wires. Refer to the wiring diagrams, depending on
the desired application:
Wiring the lock strike relay and REX (Figure 2)
Wiring for auxiliary input and output (Figure 3)
Wiring for the BL-D40 external sounder (Figure 4)
AC-F/G4x Series Installation and Programming Manual 19
Installation
Figure 2: Wiring Diagram for Lock Strike Relay and REX
20 AC-F/G4x Series Installation and Programming Manual
Installation
Figure 3: Wiring Diagram for Auxiliary Input & Output
AC-F/G4x Series Installation and Programming Manual 21
Installation
Figure 4: Wiring Diagram for the BL-D40 External Sounder
22 AC-F/G4x Series Installation and Programming Manual
Operation
•
•
ng on
4.1
Modes of Operation
In case of power failure, once the power is restored, the
controller returns to Normal mode for security reasons
The
The
Red
Green
4. Operation
In the Operation chapter, “code” refers to a PIN code or
proximity card depending on the unit you have.
Memory slots can be a proximity card or PIN code dependi
the unit you have.
There are three modes of operation.
4.1.1 Normal Mode
.
left LED is green.
Normal mode is the default mode. In Normal mode, the door is
locked until a valid primary code is presented to the controller.
The controller can only be programmed in Normal mode.
4.1.2 Secure Mode
left LED is red.
Only Secure and Master users can access the premises in
Secured mode.
A Secure user must enter the Primary and Secondary codes to
gain entry. After entering the Primary code, the right LED flashes
AC-F/G4x Series Installation and Programming Manual 23
Operation
The
4.2
User Levels
Orange
green for 10 seconds, during which the Secondary code must be
entered. A Master user only needs to present the code once to
gain entry.
4.1.3 Bypass Mode
left LED is orange.
In Bypass mode, access to the premises is dependent on whether
the controller's Lock Strike Relay is programmed for Fail Safe
Operation or Fail Secure Operation. When the Lock Strike is
programmed for Fail Secure Operation, the door is locked until *
is pressed. When the Lock Strike is programmed for Fail Safe
Operation, the door is constantly unlocked.
The AC-F4x and AC-G4x series access control units accept up to
500 users and provide entry via the use of codes. Each user is
allocated two memory slots: Memory Slot 1 (Primary code) and
Memory Slot 2 (Secondary code).
The way in which the two memory slots are programmed,
determines a user’s access level and also establishes access is
granted for each of the three modes of operation. There are
three user levels:
Normal
24 AC-F/G4x Series Installation and Programming Manual
Operation
A normal user only has a primary code and is granted access
only when the controller is in its Normal or Bypass mode.
Secure
A Secure user must have a Primary and Secondary code
assigned, and the two codes must not be the same. The
Secure user can gain access in any mode of operation. In
Normal mode, the Secure user must use the Primary code to
gain entry. In Secure mode, the Secure user must first enter
the Primary and then the Secondary code to gain entry.
Master
A Master user must have identical Primary and Secondary
codes assigned. The codes are entered with the same
proximity card or the same PIN. The Master user can gain
access during any mode of operation by entering the code
only once.
AC-F/G4x Series Installation and Programming Manual 25
Operation
4.3
Switching Operational Modes
To change from Normal to Secure mode:
1.
2.
To change from Secure to Normal mode:
1.
Green
Red
Red
The three modes of operation defined above can be changed
through a few steps.
4.3.1 From Normal to Secure Mode
The default factory setting for the normal/secure code is 3838.
Enter the 4-digit Normal/Secure code.
The left LED flashes red.
Press # to confirm the mode change.
The left LED stops flashing.
The auxiliary input of the controller can also be used to switch
the mode of operation from Secure to Normal and vice versa. If
the auxiliary input is selected it de-activates the Norma/Secure
mode code (see Section 5.9).
4.3.2 From Secure to Normal Mode
The default factory setting for the normal/secure code is 3838.
Enter the 4-digit Normal/Secure code.
The left LED flashes green.
26 AC-F/G4x Series Installation and Programming Manual
Operation
2.
To change from Normal to Bypass mode:
1.
2.
To change from Bypass to Normal mode:
1.
Green
Orange
Orange
Green
Press # to confirm the mode change.
The left LED stops flashing.
The auxiliary input of the controller can also be used to switch
the mode of operation from secure to normal and vice versa, if
the auxiliary input is selected it de-activates the Norma/Secure
mode code (see Section 5.9).
4.3.3 From Normal to Bypass Mode
By default, there is no Normal/Bypass code. The Normal/Bypass
code must first be programmed to use this function (see Section
5.7 to create/modify the Normal/Bypass code).
Enter the 4-digit Normal/Bypass code.
The left LED flashes orange.
Press # to confirm the mode change.
The left LED stops flashing.
4.3.4 From Bypass to Normal Mode
Enter the 4-digit Normal/Bypass code.
The left LED flashes green.
AC-F/G4x Series Installation and Programming Manual 27
Operation
2.
4.4
Auxiliary Input and Output
4.5
REX Function
Green
Press # to confirm the mode change.
The left LED stops flashing.
For optimum usability in different applications, the controller’s
auxiliary input and output can be configured in 10 different
modes of operation (see Section 5.9).
The REX button is located within the premises and is used to
open the door from the inside. It is usually located in a
convenient location, such as next to the door or at a
receptionist’s desk. The door chime in the BL-D40 (if enabled)
does not sound when the REX button is used to open the door.
The function of the REX button depends on the Lock Strike relay,
whether it is programmed for failsafe or for fail secure operation.
Fail Secure Operation
From the moment the REX button is pressed, the door is
unlocked until the Lock Strike Release time has elapsed. After
this time, the door is locked, even if the REX button has not
been released.
Fail Safe Operation
28 AC-F/G4x Series Installation and Programming Manual
Operation
4.6
Tamper Feature
4.7
Lockout Feature (Keypad/Card Tamper)
From the moment the REX button is pressed, the door is
unlocked until the REX button is released. In this case, the
Lock Strike relay only begins its countdown once the REX
button is released. This feature is designed to keep the door
open, when used in conjunction with fire systems.
If the controller is forcibly opened or the controller is removed
from the wall, a tamper event is triggered. A tamper signal is
sent to the BL-D40 external sounder.
If the BL-D40 receives a tamper event signal, it activates a
tamper output and a strobe light. The Siren Time can be easily
programmed in the controller from 0 to 9 minutes.
The tamper event can activate the auxiliary output if the
controller is in Auxiliary Mode 3 (see Table 3).
If the controller is presented with wrong codes (PIN or card)
consecutively several times, the unit goes into Lockout mode.
When a lockout occurs, the controller keypad and reader are de-
activated so no codes can be entered until the set lockout
period expires.
During Lockout mode, the left LED is Off, the right LED flashes
red, and the controller beeps every two seconds.
AC-F/G4x Series Installation and Programming Manual 29
Operation
4.8
BL-D40 External Sounder
The BL-D40 external sounder is designed for indoor use only and
installed within the secured premises. The sounder can be
powered by a 12 to 24 VDC power supply or by a 16 VAC
transformer. The BL-D40 is capable of emitting four different
types of audible and visual alerts: bell, chime, siren and strobe
light.
The bell sounds when the controller’s bell button is pressed.
The door chime can be programmed to sound whenever a
valid code is entered as well as for a door held open alert.
The siren can be programmed to sound when the controller
is tampered with (opened or removed from the wall). The
length of the siren can also be programmed in the controller.
The controller communicates with the BL-D40 via a Rosslare
proprietary protocol. If the BL-D40 receives an unrecognized
code over its communication line or communications between
the controller and the BL-D40 are severed, the strobe flashes
repeatedly, until the communication problem has been resolved.
30 AC-F/G4x Series Installation and Programming Manual
Programming
•
•
5. Programming
In the Programming chapter, “code” refers to a PIN code or
proximity card depending on the unit you have.
When entering a PIN or presenting a proximity card is
mentioned, the meaning may vary between units.
Programming is done solely via the unit’s keypad driven
Programming Menu System. To reach the Programming Menu
System, the controller must first be placed into Programming
mode (see Section 5.1).
During the manufacturing process, certain codes and settings are
pre-programmed. These settings are the called default factory
settings.
Table 2 shows all the programming menus, with default factory
codes and settings.
Table 2: Programming Menus
Menu
Description Default Section
No.
1 Change Open code 2580 25802 258025 25802580 5.3
2 Change Auxiliary code 0852 08520 085208 08520852 5.4
3 Change Program code 1234 12341 123412 12341234 5.5
4 Change Normal/Secure 3838 38383 383838 38383838 5.6
AC-F/G4x Series Installation and Programming Manual 31
4
Digits
5
Digits
6
Digits
4-8
Digits
Programming
Menu
Description Default Section
No.
code
5 Change Normal/Bypass
code
6 Change Door Release
time
6 Define auxiliary
inputs/outputs
6 Set Lockout Feature 4000 5.10
6 Backlight and LED
Behavior
7 Enroll proximity cards,
PIN or both
8 Delete proximity cards or
PIN
9 Code assignment with
strike/auxiliary
0 Return to factory
defaults/Change PIN
code Length
4
Digits
5
6
4-8
Digits
Digits
Digits
N/A 5.7
0004 5.8
2004 5.9
5100 5.11
N/A 5.12
N/A 5.13
N/A 5.14
N/A 5.15
32 AC-F/G4x Series Installation and Programming Manual
Programming
5.1
Entering the Programming Mode
•
•
•
To enter Programming mode:
1.
2.
5.2
Exiting the Programming Mode
•
•
To exit Programming mode:
1.
Red
The controller must be in Normal mode to enter the
programming mode.
The factory default 4-digit programming code is 1234.
If a Programming code is not entered within 5 seconds, the
controller returns to Normal mode.
Press # twice.
The left LED turns off and the right LED
turns red.
Enter your 4-digit Programming code.
The right LED turns green.
Wrong entries may reset the controller back to Normal mode.
If no key is pressed for 1 minute, while in Programming mode,
the controller exits Programming mode and returns to Normal
mode.
Press # twice to exit Programming mode at any time.
AC-F/G4x Series Installation and Programming Manual 33
Programming
5.3
Changing the Open Code
•
•
•
•
Green
You hear 3 beeps.
The left LED turns green and the right LED
turns off.
Wrong entries reset the controller back to Normal mode.
While in Programming mode, if no key is pressed for one
minute, the unit exits Programming mode and returns to
Normal mode.
The Open code is mainly used as a method to quickly test the
Lock Strike relay during installation.
For security reasons, when the first user is added to the
controller or the Auxiliary code is changed, the default Open
code is automatically deleted; non-default codes are not be
erased automatically.
Open code does not function in Secure mode.
For wrong entries, you hear a long beep and the controller
returns to Normal mode.
Code 0000 erases and deactivate the open code.
The factory 4-digit default setting for the open code is 2580.
34 AC-F/G4x Series Installation and Programming Manual
Programming
To change the Open code:
1.
2.
3.
Green
Red
Green
Green
Enter Programming mode.
Press 1 to enter Menu 1.
The left LED turns red.
Enter the new 4-digit Open code.
You hear three beeps.
The system returns to Normal mode.
AC-F/G4x Series Installation and Programming Manual 35
Programming
5.4
Changing the Auxiliary Code
•
•
•
•
•
To change the Auxiliary code:
1.
2.
3.
Green
Orange
Green
Green
The Auxiliary code is mainly used as a method to quickly test the
Auxiliary relay during installation.
For security reasons, when the first user is added to the
controller or the open code is changed, the default auxiliary
code is automatically deleted; non-default codes are not be
erased automatically.
Auxiliary code does not function in Secure mode.
Auxiliary code only works when the Auxiliary mode is 0, 1, 8 or 9.
Wrong entries return the controller to Normal mode.
Code 0000 erases and deactivates the auxiliary code.
The default 4-digit factory setting for the auxiliary code is 0852.
Enter Programming mode.
Press 2 to enter Menu 2.
The left LED turns orange.
Enter the new 4-digit Auxiliary code.
You hear three beeps.
The system returns to Normal mode.
36 AC-F/G4x Series Installation and Programming Manual
Programming
5.5
Changing the Programming Code
•
•
To change the Programming code:
1.
2.
3.
Green
Green
Green
Green
The Programming code cannot be erased; the code 0000 is
invalid and does not erase the Programming code.
The factory default 4-digit Programming code is 1234.
Enter Programming mode.
Press 3 to enter Menu 3.
The left LED turns green.
Enter the new 4-digit Programming code.
You hear three beeps.
The system returns to Normal mode.
AC-F/G4x Series Installation and Programming Manual 37
Programming
5.6
Changing the Normal/Secure Code
•
•
To change the Normal/Secure code:
1.
2.
3.
5.7
Changing the Normal/Bypass Code
•
•
To change the Normal/Bypass code:
1.
Green
Green
Red
Green
Green
When the Auxiliary mode is 1, 2, 3 or 4, the auxiliary input takes
priority over the Normal/Secure code.
Code 0000 erases and deactivates the Normal/Secure code.
Enter Programming mode.
Press 4 to enter Menu 4.
The left LED flashes red.
Enter the new 4-digit Normal/Secure code.
You hear three beeps.
The system returns to Normal mode.
The Normal/Bypass code is also used to turn the door chime off
and on. Chime only functions with the BL-D40 external sounder.
The chime is only heard when the Lock Strike relay is activated
by a valid code entry.
Code 0000 erases and deactivates the Normal/Bypass code.
Enter Programming mode.
38 AC-F/G4x Series Installation and Programming Manual
Programming
2.
3. There are four different ways to program the Normal/Bypass
Green
Orange
Green
Press 5 to enter Menu 5.
The left LED flashes orange.
code and door chime:
Disable both Bypass code and the door
chime. Enter the code 0000.
Disable Bypass code and enable the door
chime. Enter the code 0001.
Enable Bypass code and disable the door
chime. Enter any code ending with 0.
Enable Bypass code and enable the door
chime. Enter a code not ending with 0.
You hear three beeps.
The system returns to Normal mode.
AC-F/G4x Series Installation and Programming Manual 39
Programming
5.8
Setting Fail Safe/Secure Operation
To set the Fail Safe/Secure Operation, Tamper Siren and Lock
Strike Release Time:
1.
2.
3.
Green
Green
Green
In this paragraph, the failsafe/fail secure operation of the door
lock and the Door Lock Strike Release time are set. Setting the
sounding period for the siren feature requires a BL-D40 external
sounder.
Enter Programming mode.
Press 6 to enter Menu 6.
The left LED flashes green.
Construct a code using the following
instructions:
First digit
For Fail Secure Operation, the first digit should be 0.
For Fail Safe Operation the first digit should be 1.
Second digit
Siren Time in minutes (1–9, 0 – disabled)
Third and fourth digits
Enter the number of seconds (from 1 to 99) that you
want the Lock Strike to be released.
40 AC-F/G4x Series Installation and Programming Manual
Programming
second Lock Strike release time.
5.9
Setting Auxiliary Modes
Auxiliary Relay activation is subject to
code assignment (excluding Shunt, which is activated by
all users). For more
To set Aux iliary modes:
1.
2.
Green
Green
Green
Green
For example, 0312 means a Fail Secure Operation consisting
of a 3-minute siren and a 12-
You hear three beeps.
The system returns to Normal mode.
The default auxiliary setting is 2004.
the user’s Auxiliary
details, see Section 5.14.
Enter Programming mode.
Press 6 to enter Menu 6.
The left LED flashes green.
AC-F/G4x Series Installation and Programming Manual 41
Programming
3.
Green
Construct a code using the following
instructions:
Second digit (Auxiliary Mode)
In addition to the Lock Strike Relay and Lock Strike REX,
the unit features an Auxiliary Input. The Auxiliary mode
defines the function of the Auxiliary Input.
Third and fourth digits (Auxiliary Setting)
Each of the Auxiliary modes has a 2-digit setting that
affects how the Auxiliary mode functions (Table 3).
You hear three beeps.
The system returns to Normal mode.
42 AC-F/G4x Series Installation and Programming Manual
Programming
Auxiliary
Mode
Auxiliary
Input
Function
Auxiliary
Output
Activated
by
Auxiliary
Relay
Auxiliary
Settings
(in seconds)
Valid code or
01 to 99 Aux. Relay
Normal/Secure
Aux. Relay
Normal/Secure
01 to 99 Aux. Relay
Normal/Secure
Aux. Relay
Release Time
tamper activated
Normal/Secure
Table 3: Quick Reference Guide for Auxiliary Mode Setting
0 AUX REX
AUX REX
1
switch
2
switch
3
switch
4
switch
5 Door Monitor Shunt N.C. 01 to 99 maximum
AC-F/G4x Series Installation and Programming Manual 43
Valid code N.O. 01 to 99
Star button
(*)
Tamper event N.C.
Direct shunt N.O. 01 to 99 Shunt
N.O.
N.O.
Release Time
00 Aux. relay
toggle
Release Time
00 Aux. relay
toggle
Release Time
00 Aux. relay
toggle
01 to 99
00 Aux. relay
time
Shunt time
Programming
Aux. Relay
01 to 99 Aux. Relay
6 Door Monitor Forced door N.C. 01 to 99 Forced
delay
7 Door Monitor Door ajar N.C. 01 to 99 Ajar delay
8 LED control –
Green
9 LED control –
Red
Valid code N.O. 01 to 99
Release time
00 Aux. relay
toggle
Valid code N.O.
Release time
00 Aux. relay
toggle
44 AC-F/G4x Series Installation and Programming Manual
Programming
The following subsections describe each Auxiliary mode.
5.9.1 Auxiliary Mode 0
Auxiliary input function: Activates the auxiliary output
Auxiliary output activated by: Valid user code, Auxiliary code,
Auxiliary input
For example, in Auxiliary Mode 0, the controller can function as a
two-door controller. The auxiliary relay is to be attached to the
lock on the second door. The auxiliary setting defines the Door
Open time for the second door. The auxiliary input is to be
attached to the REX button for the second door. Door Monitor
input feature for the second door is not enabled when using this
mode.
5.9.2 Auxiliary Mode 1
Auxiliary input function: Toggles Normal/Secure modes
Auxiliary output activated by: Valid user code, Auxiliary code
For example, in Auxiliary Mode 1, the controller can function as a
two-door controller. The auxiliary relay is to be attached to the
lock on the second door. REX feature for the second door is not
enabled when using this mode.
The auxiliary setting defines the Door Open time for the second
door. The auxiliary input can switch the mode of operation of
the controller between Normal and Secure mode. By connecting
a switch timer or alarm system output to the auxiliary input, the
AC-F/G4x Series Installation and Programming Manual 45
Programming
controller can be automatically switched from Normal mode
(during office hours) to Secure mode (after office hours).
5.9.3 Auxiliary Mode 2
Auxiliary input function: Toggles Normal/Secure modes
Auxiliary output activated by: Star Button (*)
For example, in Auxiliary Mode 2, the auxiliary relay can function
as a general purpose time switch that can be activated when * is
pressed. The auxiliary setting establishes for how long the
auxiliary relay is to be activated. The auxiliary input can switch
the mode of operation of the controller between Normal and
Secure mode. By connecting a switch timer or alarm system
output to the auxiliary input, the controller can be automatically
switched from Normal mode (during office hours) to Secure
mode (after office hours).
5.9.4 Auxiliary Mode 3
Auxiliary input function: Toggles Normal/Secure modes
Auxiliary output activated by: Alarms
For example, in Auxiliary Mode 3, the auxiliary output is activated
if the controller is tampered; that is, if the case is forcibly opened
or removed from the wall. The auxiliary input can switch the
mode of operation of the controller between Normal and Secure
mode. By connecting a switch timer or alarm system output to
the auxiliary input, the controller can be automatically switched
46 AC-F/G4x Series Installation and Programming Manual
Programming
from Normal mode (during office hours) to Secure mode (after
office hours).
5.9.5 Auxiliary Mode 4
Auxiliary input function: Toggles Normal/Secure modes
Auxiliary output activated by: direct shunt (explanation below)
For example, in Auxiliary Mode 4, the controller is capable of
bypassing an alarm zone by shunting an alarm system’s door
sensor. The auxiliary output is to be wired in parallel to the door
sensor output. When in use, the auxiliary output is normally
open and the door sensor functions normally. When a valid code
is entered, the auxiliary relay shunts the door sensor for the
duration of the Shunt time, as defined by the auxiliary setting. If
the door is left open longer than the Shunt time, an alarm is
triggered.
5.9.6 Auxiliary Mode 5
Auxiliary input function: Door Monitor
Auxiliary output activated by: Shunt (explanation below)
For example, in Auxiliary Mode 5, the controller is capable of
shunting an alarm system. In this mode, the auxiliary input is to
be wired to the magnetic contact switch on the door. The
auxiliary relay is wired to the alarm system. Without a valid code
entered, the auxiliary relay matches the condition of the
magnetic contact switch; if the door opens, the auxiliary relay
AC-F/G4x Series Installation and Programming Manual 47
Programming
opens; if the door closes, the auxiliary relay closes. When a valid
code is entered, a countdown for maximum Shunt time, as
defined by the auxiliary setting, begins; if the door is not closed
before the maximum Shunt time, the alarm is triggered.
5.9.7 Auxiliary Mode 6
Auxiliary input function: Door Monitor
Auxiliary output activated by: Forced entry
For example, in auxiliary mode 6, the controller can trigger the
auxiliary relay if the door has been forced. If the Siren Settings is
enabled, the siren is activated.
In this mode, the auxiliary input functions as a door monitor
switch and is wired to the magnetic contact switch on the door.
The auxiliary relay is to be wired to the alarm system. If the door
is forced open, the controller waits for the period of the Forced
Door Delay time to elapse and then it activates the auxiliary
relay. The auxiliary setting sets the forced door delay period.
5.9.8 Auxiliary Mode 7
Auxiliary input function: Door Monitor
Auxiliary output activated by: Door Ajar (door held open)
For example, in Auxiliary Mode 7, the controller can trigger the
auxiliary relay, if it detects that the door has been held open
(ajar) too long. In this mode the auxiliary input functions as a
door monitor switch and is wired to the magnetic contact switch
48 AC-F/G4x Series Installation and Programming Manual
Programming
This mode control
The
•
•
on the door. The auxiliary relay is to be wired to the alarm
system. If the door is opened, the controller waits for the Door
Ajar Delay time to elapse and if the door does not close prior to
the end of this period, the controller activates the auxiliary relay.
The auxiliary setting defines the Door Ajar time.
If the BL-D40 external sounder is connected in the system and a
door-ajar event occurs, the BL-D40 chimes every few seconds for
1 minute or until the door is closed.
5.9.9 Auxiliary Mode 8
s the door indicator (right LED).
right LED is not lit when:
A valid code is entered
While in Secure mode when waiting for Secondary code.
Auxiliary input function: Green LED control
Auxiliary output activated by: Valid user code, Auxiliary code
For example, in Auxiliary Mode 8, the controller can function as a
2-door controller and also provide LED indicator functionality
control. The auxiliary relay is connected to the lock on the
second door. The auxiliary setting defines the Door Open time
for the second door. The auxiliary input is used to control the
door indicator (right LED). If the auxiliary input is open, the right
LED flashes green; if the auxiliary input is closed, the right LED
flashes red.
AC-F/G4x Series Installation and Programming Manual 49
Programming
This mode control
The
•
•
5.10 Setting the Lockout Feature
5.9.10 Auxiliary Mode 9
s the door indicator (right LED).
right LED is not lit when:
A valid code is entered
While in Secure mode when waiting for Secondary code.
Auxiliary input function: Red LED control
Auxiliary output activated by: Valid user code, Auxiliary code
For example, in Auxiliary Mode 9, the controller can function as a
2-door controller and also provide LED indicator functionality
control. The auxiliary relay is connected to the lock on the
second door. The auxiliary setting defines the Door Open time
for the second door. The auxiliary input is used to control the
door indicator (right LED). If the auxiliary input is open, the right
LED flashes red; if the auxiliary input is closed the right LED
flashes green.
If the controller is presented with wrong codes (PIN or card)
consecutively several times, the unit goes into Lockout mode.
When a lockout occurs, the controller keypad and reader are
locked so no codes can be entered until the set lockout period
expires. During Lockout, the left LED is Off, the right LED flashes
50 AC-F/G4x Series Installation and Programming Manual
Programming
Using the lockout feature is highly recommended, especially
when selecting to use short PIN code l
To define the Lockout feature:
1.
2.
3.
n 00 and 99; the
Green
Green
Green
red, and the controller beeps every two seconds. The default
setting for the Lockout Feature is 4000 (Lockout Disabled).
ength (4 or 5 digits).
Enter Programming mode.
Press 6 to enter Menu 6.
The left LED flashes green.
Construct a code using the following
instructions:
Second digit
Set the number of wrong code attempts, which causes a
Lockout between 0 and 9 attempts.
Third and fourth digits
Sets the Duration of the lockout, betwee
value is multiplied by ten, resulting in 0 to 990 seconds.
AC-F/G4x Series Installation and Programming Manual 51
Programming
5.11 Setting the Backlight Behavior
To set the backlight behavior:
1.
2.
3.
, after which it returns to a dimmed
Green
Green
Green
The controller allows you to define the way the unit’s backlight
works.
Enter Programming mode.
Press 6 to enter Menu 6.
The left LED flashes green.
Enter one of the following codes:
5000 – Backlight off
5100 – Backlight on (default)
5200 – Backlight is off, activates for 10 seconds when a
key is pressed, after which it dims until off
5300 – Backlight is dimmed, activates for 10 seconds
when a key is pressed
level
52 AC-F/G4x Series Installation and Programming Manual
Programming
5.12 Enrolling Primary and Secondary Codes
5.12.1 Primary Codes Definition
Primary codes can only be enrolled to an empty user slot, a
slot with no existing Primary code in the controller’s
memory.
A Primary code must be unique; for instance, one user’s
primary code may not be the same as that of another user.
Primary codes cannot be the same as system codes, such as:
the Normal/Secure code or the Open code.
Users possessing a Primary code can gain entry during
Normal and Bypass modes.
5.12.2 Secondary Codes Definition
Secondary codes can only be enrolled to a user slot that
already includes a primary code.
A Secondary code need not be unique; for instance, one
user’s Secondary code may be the same as that of another
user.
Secondary codes cannot be the same as any system codes,
such as: the normal/secure code or the open code.
Users possessing secondary codes can gain entry in any
mode of operation.
AC-F/G4x Series Installation and Programming Manual 53
Programming
To enroll Primary and Secondary codes using the Standard
method:
1.
2.
3.
number between
Orange
Green
A Secondary code can be the same as the primary code of
any user.
5.12.3 Enrolling Methods
There are two methods used to enroll primary and secondary
codes: the standard method and the code search method.
The Standard Method is used when the user slot number, for
the user you wish to program, is known. You can program
both primary and secondary codes using this method.
The Code Search Method is mainly used when enrolling a
secondary code and the user’s slot code is unknown. The
code search method functions only if a user’s primary code
is already enrolled and the secondary code is not.
5.12.3.1 Enrolling Primary and Secondary Codes using the Standard Method
Enter Programming mode.
Press 7 to enter Menu 7.
The right LED turns orange.
Enter the 3-digit user slot
001and 500 for the slot to which you wish
to enroll a Primary or Secondary code.
54 AC-F/G4x Series Installation and Programming Manual
Programming
, you hear a long beep
4.
Green
Red
Orange
Gree
Orange
For example, User Slot 003 represents User #3.
If the selected slot has no Primary code,
the left LED flashes green, indicating that
the controller is ready to accept a Primary
code.
If the selected slot already has a Primary
code but no Secondary code, the left LED
flashes red, indicating that the controller is
ready to accept a Secondary code.
If the selected slot already has a Primary
and Secondary code
and the controller returns to Normal mode.
Perform one of the following:
Enter the PIN code that you want to
assign as the Primary or Secondary
code for this slot number.
Present your user card that you want to assign as the
Primary or Secondary code for this slot number.
AC-F/G4x Series Installation and Programming Manual 55
Programming
you
5.
To enroll secondary codes using the Code Search method:
1.
2.
3.
Orange
Orange
Green
If the PIN or user card presented is valid, the left LED stops
flashing and the controller is ready for you to enter the next
3-digit slot number (refer to Step 3
) for the slot to which
want to assign a code.
Do one of the following:
Press # to move to the next available user slot number.
Enter another 3-digit user slot number.
If you do not wish to continue enrolling codes, press #
twice and the controller returns to Normal mode.
5.12.3.2 Enrolling Secondary Codes using the Code Search Method
The code search method enables to quickly enroll a secondary
code for a user whose primary code is known and whose slot
number is unknown.
Enter Programming mode.
Press 7 to enter Menu 7.
The right LED turns orange.
Enter 000 as the 3-digit user slot number.
The right LED flashes orange.
56 AC-F/G4x Series Installation and Programming Manual
Programming
4.
5.
If the Secondary code is invalid, the controller sounds a long
Red
Orange
The controller is now waiting for the Primary code of the
user to whom you want to add a Secondary code.
Perform one of the following:
Enter the PIN code belonging to the user
for whom you wish to add a Secondary
code.
Present the user card belonging to the user for whom you
wish to add a Secondary code.
The left LED flashes red.
If the Primary code entered is not valid, you hear a long
beep and the unit continues to wait for a valid Primary code.
Perform one of the following:
Enter the PIN code to be used as the
Secondary code.
Present the user card to be used as the Secondary code.
If the Secondary code is valid, the controller beeps three
times and returns to Normal mode.
beep, and the unit continues to wait for a valid Secondary
code to be entered.
AC-F/G4x Series Installation and Programming Manual 57
Programming
5.13 Deleting Primary and Secondary Codes
It
deleted users
slots
To delete the Primary and Secondary codes using the
Standard Method:
1.
2.
3.
Red
Orange
Red
Orange
Green
There are two methods to delete Primary and Secondary codes:
a standard method and a search method. When deleting a user
slot, both the primary code and the secondary code are erased.
is recommended that a record be kept of added and
. This makes it easier to keep track of user
’ status (empty or not).
5.13.1 Deleting Primary and Secondary Codes using the Standard Method
Enter Programming mode.
Press 8 to enter Menu 8.
The left LED turns red and the right LED
turns orange.
Enter the 3-digit User Slot code you wish
to delete.
The left LED flashes red indicating the
controller is waiting for the Programming
code to confirm the deletion.
58 AC-F/G4x Series Installation and Programming Manual
Programming
4.
If the Programming code is invalid, a long beep is heard and
To delete the Primary and Secondary codes using the Code
Search Method:
5.
6.
7.
Red
Orange
Red
Orange
Green
If the user slot is empty, you hear a long beep and the unit
returns to Normal mode.
Enter your 4-digit Programming code to
confirm the deletion.
If the Programming code is valid, three beeps are heard and
the controller returns to Normal mode.
the controller returns to Normal mode.
5.13.2 Deleting Primary and Secondary Codes using the Code Search Method
Enter Programming mode.
Press 8 to enter Menu 8.
The left LED turns red and the right LED
turns orange.
Enter 000 as the 3-digit user slot number.
The right LED flashes orange.
The controller is now waiting for the Primary code of the
user you want to delete.
AC-F/G4x Series Installation and Programming Manual 59
Programming
8.
Enter the PIN code of the Primary code
9.
5.14 Relay Codes Assignment
Red
Orange
Perform one of the following:
belonging to the user you want to
delete.
Present the user card of the Primary code belonging to
the user you want to delete.
The left LED flashes red.
Enter your 4-digit Programming code to confirm the
deletion.
If the Programming code is valid, you hear three beeps and
the unit returns to Normal mode.
If the Programming code is invalid, you hear a long beep
and the unit returns to Normal mode.
When a Primary code is enrolled for any user, the user is
authorized to activate the Lock Strike relay. However, different
user codes may be set to operate the auxiliary relay instead or
operate both the Lock strike and auxiliary relay. Assignment of
such codes is achievable for any valid user code entered in the
controller.
60 AC-F/G4x Series Installation and Programming Manual
Programming
To assign the relay code using Standard method:
1.
2.
3.
4.
Green
Orange
Green
Orange
Green
There are two methods to assign relay codes to users: a
standard method and a search method.
5.14.1 Relay Code Assignment using Standard Method
Enter Programming mode.
Press 9 to enter Menu 9.
The left LED turns green and the right LED
turns orange.
Enter the 3-digit user slot for code
assignment.
The left LED flashes green.
Enter the assignment digit for the current user slot:
1 activates the Lock Strike relay only default
2 activates the Auxiliary relay only
3 activates the Lock Strike and Auxiliary relays
If the assignment code is valid, the left LED stops flashing.
The controller is now waiting for another slot number.
AC-F/G4x Series Installation and Programming Manual 61
Programming
5.
twice
To assign the relay code using Search method:
1.
2.
3.
Green
Orange
Green
Orange
Green
Do one of the following:
Press # to move to the next available user slot number.
Enter another 3-digit user slot number.
If you do not wish to continue enrolling codes, press #
and the controller returns to Normal mode.
5.14.2 Relay Code Assignment using Search Method
Enter Programming mode.
Press 9 to enter Menu 9.
The left LED turns green and the right LED
turns orange.
Enter 000 for user slot access.
The right LED flashes orange.
62 AC-F/G4x Series Installation and Programming Manual
Programming
4.
Enter the PIN code of the Primary code
5.
, a long beep sounds and the
Green
Orange
Do one of the following:
belonging to the user you want to
delete.
Present the user card of the Primary code belonging to
the user you want to delete.
The left LED flashes green.
Enter the assignment digit for the current user slot:
1 activates the Lock Strike relay only default
2 activates the Auxiliary relay only
3 activates the Lock Strike and Auxiliary relays
valid
If the assignment digit is
, three beeps are heard and
the controller returns to Normal mode.
If the assignment digit is
invalid
controller waits for another assignment digit to be entered.
AC-F/G4x Series Installation and Programming Manual 63
Programming
5.15 Changing PIN Code Length/Factory Default Settings
You must be
Changing the PIN code length also
memory contents, including all user and special codes, and
return
To change the PIN code length:
1.
2.
8 digit code
When choosing the 4–8 option, please note that you should
either enter zeros before the code, or press
(for example if your code is 12345, enter either
or
3.
Red
Red
Green
very careful before using this command!
erases the entire
s all codes to their factory default settings.
Enter Programming mode.
Select the desired PIN code length as follows:
00 – Returns to factory defaults and sets a 4-digit code
05 – Returns to factory defaults and sets a 5-digit code
06 – Returns to factory defaults and sets a 6-digit code
08 – Returns to factory defaults and sets a 4-
# at the end
00012345
12345#).
Both LEDs flash red.
Enter your 4-digit Programming code.
If the Programming code is valid, all memory is erased. You
hear three beeps and the controller returns to Normal mode.
64 AC-F/G4x Series Installation and Programming Manual
Programming
5.16 Replacing a Programming Code
The
work. Make sure that the
proceeding
To replace a Programming code:
If the Programming code is invalid, you hear a long beep
and the controller returns to Normal mode without erasing
the memory contents.
unit must be in Normal mode; otherwise, this does not
left LED is green before
.
1. Remove power from the controller.
2. Press and hold the REX button.
3. Apply power to the unit with the REX button pressed.
4. Release the REX button.
5. You now have 15 seconds to program a new programming
code into the unit using the initial default code before the
controller reverts to the existing code.
The deafult code depends on the PIN length selected (see
Table 2).
AC-F/G4x Series Installation and Programming Manual 65
Programming
5.17 Replacing a Normal/Secure Code
The
work. Make sure that the
To replace a Normal/Secure code:
unit must be in Secure mode; otherwise, this does not
left LED is red before proceeding.
1. Remove power from the controller.
2. Press and hold the REX button.
3. Apply power to the unit with the REX button pressed.
4. Release the REX button.
You now have 15 seconds to use the Normal/Secure code to
return to the Normal mode.
5. Once in Normal mode, enter the Programming mode to
program a new Normal/Secure code.
The deafult code depends on the PIN length selected (see Table
2).
66 AC-F/G4x Series Installation and Programming Manual
Declaration of Conformity
A. Declaration of Conformity
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference.
This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to operate
the equipment.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more
of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
AC-F/G4x Series Installation and Programming Manual 67
Limited Warranty
B. Limited Warranty
The full ROSSLARE Limited Warranty Statement is available in the Quick
Links section on the ROSSLARE website at www.rosslaresecurity.com.
Rosslare considers any use of this product as agreement to the Warranty
Terms even if you do not review them.
68 AC-F/G4x Series Installation and Programming Manual
AC-F/G4x Series
Asia Pacific, Middle
East, Africa
Rosslare Enterprises Ltd.
Kowloon Bay, Hong Kong
Tel: +852 2795-5630
Fax: +852 2795-1508
support.apac@rosslaresecurity.com
United States and
Canada
Rosslare Security Products, Inc.
Southlake, TX, USA
Toll Free: +1-866-632-1101
Local: +1-817-305-0006
Fax: +1-817-305-0069
support.na@rosslaresecurity.com
Europe
Rosslare Israel Ltd.
Rosh HaAyin, Israel
Tel: +972 3 938-6838
Fax: +972 3 938-6830
support.eu@rosslaresecurity.com
Latin America
Rosslare Latin America
Buenos Aires, Argentina
Tel: +54-11-4001-3104
support.la@rosslaresecurity.com
China
Rosslare Electronics (Shenzhen) Ltd.
Shenzhen, China
Tel: +86 755 8610 6842
Fax: +86 755 8610 6101
support.cn@rosslaresecurity.com
India
Rosslare Electronics India Pvt Ltd.
Tel/Fax: +91 20 40147830
Mobile: +91 9975768824
sales.in@rosslaresecurity.com
CERT
ISO 9001
ISO 14001
0706-0960101+04
Loading...
