Rosslare AC-215-Bx, AC-215-DIN, AC-215IP-DIN, AC-215IP-Bx Installation Manual And User's Manual

AC-215x-B Series

2-Reader Networked
Access Control Panel

Hardware Installation Manual and User Guide

Models:

AC-215-Bx
AC-215-DIN
AC-215IP-Bx
AC-215IP-DIN

Copyright © 2018 by Rosslare. All rights reserved.

This manual and the information contained herein are proprietary to ROSSLARE
ENTERPRISES LIMITED and/or its related companies and/or subsidiaries’ (hereafter:
"ROSSLARE"). Only ROSSLARE and its customers have the right to use the information.

No part of this manual may be re-produced or transmitted in any form or by any means,
electronic or mechanical, for any purpose, without the express written permission of
ROSSLARE.

ROSSLARE owns patents and patent applications, trademarks, copyrights, or other
intellectual property rights covering the subject matter in this manual.

TEXTS, IMAGES, AND ILLUSTRATIONS INCLUDING THEIR ARRANGEMENT IN THIS
DOCUMENT ARE SUBJECT TO THE PROTECTION OF COPYRIGHT LAWS AND OTHER
LEGAL RIGHTS WORLDWIDE. THEIR USE, REPRODUCTION, AND TRANSMITTAL TO THIRD
PARTIES WITHOUT EXPRESS WRITTEN PERMISSION MAY RESULT IN LEGAL
PROCEEDINGS.

The furnishing of this manual to any party does not give that party or any third party any
license to these patents, trademarks, copyrights or other intellectual property rights,
except as expressly provided in any written agreement of ROSSLARE.

ROSSLARE reserves the right to revise and change this document at any time, without
being obliged to announce such revisions or changes beforehand or after the fact.

Table of Contents

AC-215x-B Series Hardware Installation Manual iii

Table of Contents

1. Introduction ................................................................................ 8

1.1 AxTraxNG ........................................................................................... 9

1.1.1 Client-Server Structure ............................................................................... 10

1.1.2 Configurable Links ..................................................................................... 10

2. Technical Specifications ........................................................... 11

2.1 AC-215x-DIN .................................................................................... 11

2.2 AC-215x Installed in ME-1015 .......................................................... 12

3. AC-215x Panel Setup ................................................................ 13

3.1 Inputs Wiring – Non-Supervised Inputs .............................................. 14

3.2 Inputs Wiring – Supervised Inputs ..................................................... 14

3.3 Outputs Wiring ................................................................................. 15

3.4 Power Supply .................................................................................... 17

3.5 AC-215x-B Wiring Communications .................................................. 18

3.6 Reader .............................................................................................. 19

4. Input and Output Connections ................................................ 20

4.1 Input Types ....................................................................................... 20

4.1.1 Normally Open Input Connection ............................................................... 20

4.1.2 Normally Closed Input Connection ............................................................. 21

4.1.3 Normally Open Supervised Single Resistor Input Connection........................ 22

4.1.4 Normally Open Supervised Double Resistor Input Connection ...................... 22

4.1.5 Normally Closed Supervised Single Resistor Input Connection ...................... 23

4.1.6 Normally Closed Supervised Double Resistor Input Connection .................... 24

4.2 Inputs Description ............................................................................. 24

4.2.1 Request-to-Exit Button (REX) Input ............................................................. 24

4.2.2 Door Monitor Input ................................................................................... 25

4.2.3 General Purpose Inputs .............................................................................. 25

4.3 Outputs ............................................................................................ 25

4.4 Card Readers and Keypads ................................................................ 26

5. AC-215x Hardware Settings ..................................................... 27

Table of Contents

iv AC-215x-B Series Hardware Installation Manual

5.1 DIP Switch Configuration .................................................................. 27

5.2 Access Control Panel Baud Rate ........................................................ 27

5.3 Access Control Panel Type ................................................................ 28

5.4 Access Control Panel Addressing ....................................................... 29

6. Communications ....................................................................... 31

6.1 Serial Network Connection ............................................................... 31

6.1.1 RS-232 Connection to the Computer ......................................................... 31

6.1.2 RS-485 Connection to the Computer ......................................................... 32

6.1.3 Daisy Chaining .......................................................................................... 33

6.2 TCP/IP Network Connection .............................................................. 34

6.2.1 LAN and WAN Requirements ..................................................................... 34

A. Declaration of Conformity....................................................... 36

B. Radio Equipment Directive (RED) ............................................ 37

C. RoHS Directive .......................................................................... 38

D. Limited Warranty...................................................................... 39

List of Figures

AC-215x-B Series Hardware Installation Manual v

List of Figures

Figure 1: AC-215x Panel ................................................................................. 9

Figure 2: Sample AC-215x Configuration...................................................... 13

Figure 3: Inputs Wiring – Non-supervised Inputs ........................................... 14

Figure 4: Door Lock – Failed Close ................................................................ 15

Figure 5: Door Lock – Failed Open ................................................................ 16

Figure 6: Wiring Between PM-10 and AC-215x-B ......................................... 17

Figure 7: AC-215x-B Wiring Communications ............................................... 18

Figure 8: Reader Wiring ................................................................................ 19

Figure 10: Normally Open Input Connection ................................................. 21

Figure 11: Normally Closed Input Connection ............................................... 21

Figure 12: Normally Open Supervised Input (Single Resistor) Connection ....... 22

Figure 13: Normally Open Supervised Input (Double Resistor) Connection ..... 23

Figure 14: Normally Closed Supervised Input (Single Resistor) Connection ..... 23

Figure 15: Normally Closed Supervised Input (Double Resistor) Connection ... 24

Figure 16: DIP Switches ................................................................................ 27

Figure 17: RS-232 Panel Connection to PC ................................................... 31

Figure 18: RS-485 Panel Connection to PC ................................................... 32

Figure 19: Daisy Chaining ............................................................................. 33

Figure 20: Connecting Multiple Access Control Panels to AC-215IP .............. 34

Figure 21: Connecting a Single Control Panel with MD-N32 ......................... 34

Figure 22: Connecting Multiple Access Control Panels with MD-N32 ............ 35

List of Tables

vi AC-215x-B Series Hardware Installation Manual

List of Tables

Table 1: Description of AC-215x-B Panels ....................................................... 8

Table 2: AxTraxNG Capabilities ....................................................................... 9

Table 3: DIP Switches and Their Functions ..................................................... 27

Table 4: Switch Baud Rates ........................................................................... 28

Table 5: Possible Hardware Settings .............................................................. 28

Table 6: Available Panel Addresses ............................................................... 29

Table 7: RS-232 Connection ......................................................................... 32

Notice and Disclaimer

AC-215x-B Series Hardware Installation Manual vii

Notice and Disclaimer

This manual’s sole purpose is to assist installers and/or users in the safe and
efficient installation and usage of the system and/or product, and/or software
described herein.

B

EFORE ATTEMPTING TO INSTALL AND/OR USE THE SYSTEM, THE INSTALLER AND

THE USER MUST READ THIS MANUAL AND BECOME FAMILIAR WITH ALL SAFETY

REQUIREMENTS AND OPERATING PROCEDURES

.

 The system must not be used for purposes other than those for which it

was designed.

 The use of the software associated with the system and/or product, if

applicable, is subject to the terms of the license provided as part of the
purchase documents.

 ROSSLARE exclusive warranty and liability is limited to the warranty and

liability statement provided in an appendix at the end of this document.

 This manual describes the maximum configuration of the system with the

maximum number of functions, including future options. Therefore, not
all functions described in this manual may be available in the specific
system and/or product configuration you purchased.

 Incorrect operation or installation, or failure of the user to effectively

maintain the system, relieves the manufacturer (and seller) from all or any
responsibility for consequent noncompliance, damage, or injury.

 The text, images and graphics contained in the manual are for the

purpose of illustration and reference only.

 All data contained herein subject to change without prior notice.
 In no event shall manufacturer be liable for any special, direct, indirect,

incidental, consequential, exemplary or punitive damages (including,
without limitation, any and all damages from business interruption, loss of
profits or revenue, cost of capital or loss of use of any property or capital
or injury).

 All wiring diagrams are intended for reference only, the photograph or

graphic of the PCB(s) are intended for clearer illustration and
understanding of the product and may differ from the actual PCB(s).

Introduction

8 AC-215x-B Series Hardware Installation Manual

1. Introduction

In this manual, unless otherwise stated, “AC-215x-B” refers to both the regular
AC-215-B and the AC-215IP-B moels

The AC-215x-B series of access control panels are networked access
controllers, employing the latest technology to meet the requirements of the
market.

Table 1 summarizes the AC-215x-B models and their respective descriptions.

Table 1: Description of AC-215x-B Panels

Model Name Description

AC-215-BA Installed in ME-1015 with Type I plug power cable, RS-485

connection

AC-215-BB Installed in ME-1015 with Type G plug power cable, RS-485

connection

AC-215-BE Installed in ME-1015 with Type F plug power cable, RS-485

connection

AC-215-BU Installed in ME-1015 with Type B plug power cable, RS-485

connection

AC-215-DIN PCBA only with wall /DIN rail mounting base, RS-485 connection

AC-215IP-BA Installed in ME-1015 with Type I plug power cable, TCP/IP

connection

AC-215IP-BB Installed in ME-1015 with Type G plug power cable, TCP/IP

connection

AC-215IP-BE Installed in ME-1015 with Type F plug power cable, TCP/IP

connection

AC-215IP-BU Installed in ME-1015 with Type B plug power cable, TCP/IP

connection

AC-215IP-DIN PCBA only with wall /DIN rail mounting base, TCP/IP connection

The IP models also includes onboard support for communications across a
TCP/IP network.

When used in combination with Rosslare's AxTraxNG™ software system, the
AC-215x gives you full control over access to your premises. The system can
control both single and double door entrances and up to two doors. AC-215x
supports up to 30,000 users and uses flash memory to enable easy firmware
upgrades. For more information on the AxTraxNG system, refer to the

AxTraxNG™ Software Installation and User Manual

.

The AC-215x comes either as a PCBA “DIN” module that can be wall or DIN
rail mountable, or pre-assembled within the ME-1015 power management
enclosure. The ME-1015 contains a universal switch mode power supply that

Introduction

AC-215x-B Series Hardware Installation Manual 9

accepts inputs from 90 ~ 265 VAC (50 ~ 60 Hz) and outputs 60 watts, a
power management board that provides two independently fused 12 VDC, 2
Amp power outputs – one for the controller and readers, and one for locks.
The ME-1015 power management enclosure also includes an alert sounder, a
lead acid battery charger for a lead acid battery of up 12 V and 7 Ah, and an
intelligent light bar that provides enclosure lighting, an enclosure tamper
sensor, and a power status LED indicator.

Figure 1 shows the general layout of the AC-215x panel.

Figure 1: AC-215x Panel

1.1 AxTraxNG

The AxTraxNG software system is designed to set up, manage, and supervise
all aspects of an access control panel network.

Table 2 presents the AxTraxNG software capabilities:

Table 2: AxTraxNG Capabilities

Users capacity

30,000
Unauthorized Users 30,000
Access groups 30,000

Number of panels in system 1,023
Number of doors in system 4,092

Introduction

10 AC-215x-B Series Hardware Installation Manual

These options are software and firmware dependent, and may change in later
releases or revisions.

1.1.1 Client-Server Structure

AxTraxNG operates through a dedicated AxTrax server computer, which
communicates with the access control panels and can serve an unlimited
number of network clients.

The server also runs the system's SQL database, which contains settings and
definitions for access control across the entire facility. Clients can define new
employees and control access permissions. The system includes tools for
database backup, input and export of previous configurations and automatic
backing-up on a periodic basis.

1.1.2 Configurable Links

The system's configurable links model makes it possible to trigger any chosen
output automatically or report a configurable alarm, based on a selected input.
This allows easy integration with related access systems such as intruder
alarms, CCTV systems and elevator controls.

AxTraxNG can also define a selected set of operations (defined in configurable
links) when a panel registers a specified user or group of users. This can be
useful, for example, in elevator control systems. The system can assign users
with counters, allowing a limited number of entries to each panel.

Technical Specifications

AC-215x-B Series Hardware Installation Manual 11

2. Technical Specifications

2.1 AC-215x-DIN

Electrical Characteristics

Operating Voltage

12 VDC, 1.5 A from a regulated power supply

Maximum Input Current

AC-215 Standby: 80 mA

Maximum: 325 mA

AC-215IP Standby: 120 mA

Maximum: 370 mA

General Inputs

• 4 supervised high impedance inputs

• Maximum voltage: 5 VDC

Relay Outputs

4 Form C 5 Amp relay outputs

Reader Ports

• 2 reader ports

• Communication: Wiegand (D0, D1) or Clock &

Data (C, D)

• Output voltage to reader: 12 VDC

• Max. current to reader: 245 mA

• LED control output and Tamper Input

Visual Indicators

11 LEDs for outputs and communication status

Audio

Sounder output for use with compatible speakers
provide chime, bell and siren signals

Battery Standby Time

3 hours with a 12 V, 7 Ah lead acid battery

Communication Characteristics

RS-485 / RS-232

• RS-485 or optional RS-232

• RS-485 connection by terminal block or MD-14U

connector

• RS-232 connection by terminal block

RS-232

Terminal Block

RS-485

Molex and Terminal Block

TCP/IP

On-board RJ-45 connector
(functional on AC-215IP models only)

Selectable Communication
Speed

9600, 19200, 57600, 115200 bps

Environmental Characteristics

Operating Temperature Range

0°C to 49°C (32°F to 120°F)

Operating Humidity Range

0 to 85% (non-condensing)

Dimensions

Height x Width x Depth

193 x 136.5 x 39 mm (7.6 x 5.4 x 1.5 in.)

Technical Specifications

12 AC-215x-B Series Hardware Installation Manual

Weight

0.36 kg (12.7 oz)

2.2 AC-215x Installed in ME-1015

Electrical Characteristics – Switch Mode Power Supply

Operating Voltage

90 ~ 265 VAC, 50 ~ 60 Hz from mains power

Maximum Input Current

1.5 A

Output Power

15 VDC, 4 A (60 Watts) to the power
management board

Electrical Characteristics – Power Management Board (PM-10)

Input Power

15 VDC, 4 A to the power management board

Output Power

Two PTC fused outputs, each provides 13.8
VDC, 2 A

One output for controller and readers
One output for locks

Battery Charger

13.8 VDC, 300 mA for 12VDC, 7Ah Lead Acid
Battery

Speaker

0.5 Watt, 8 Ohm

Light Bar

0.3 Watt for LED light

Environmental Characteristics

Operating Temperature Range

0°C to 49°C (32°F to 120°F)

Operating Humidity Range

0 to 85% (non-condensing)

Dimensions

Height x Width x Depth

365 x 264 x 97 mm (14.4 x 10.4 x 3.8 in.)

Weight

3.4 kg (7.5 lb)
