BANTAM Modular Coalescing Filters
FLOW CHART
Ports: 1/8 & 1/4
Flow to 11 scfm
FEATURES:
• Modular assembly and mounting
• Threaded ports or quick-connect ttings for tubing up to 10 mm in diameter
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated lter element
• Automatic drain; optional manual drain
• High-strength polycarbonate plastic lter bowl; optional aluminum bowl
APPLICATION NOTE:
A general purpose filter must be installed ahead of a coalescing filter to ensure good
performance and to extend the life of the coalescing element.
A
C
Size A B † C Depth lb (kg)
No Port 1.7 (43) 3.6 (92) 0.5 (13) 1.8 (45) 0.27 (0.12)
Port
1/8, 1/4 3.0 (76) 3.6 (92) 0.5 (13) 1.8 (45) 0.49 (0.22)
B
Models below have quick-connect fittings for tubing.
1/4 3.4 (86) 3.6 (92) 0.5 (13) 1.8 (45) 0.47 (0.21)
3/8 3.9 (99) 3.6 (92) 0.5 (13) 1.8 (45) 0.47 (0.21)
4 mm 3.4 (86) 3.6 (92) 0.5 (13) 1.8 (45) 0.47 (0.21)
6 mm 3.4 (86) 3.6 (92) 0.5 (13) 1.8 (45) 0.47 (0.21)
8 mm 3.1 (79) 3.6 (92) 0.5 (13) 1.8 (45) 0.47 (0.21)
10 mm 3.9 (99) 3.6 (92) 0.5 (13) 1.8 (45) 0.47 (0.21)
† Dimension for polycarbonate plastic bowl; metal bowl is 3.8 (97).
Port Air Flow Automatic Drain Models Manual Drain Models
Size scfm (l/s) Plastic Bowl Metal Bowl Plastic Bowl Metal Bowl
Automatic Drain
ISO Symbols
Filter
Manual Drain
1/8 8 (3.8) 5B01B0700 5B01B0800 5B01B0500 5B01B0600
1/4 9 (4.2) 5B02B0700 5B02B0800 5B02B0500 5B02B0600
0.3-µm ELEMENT
1/4
bar
0.35
0.28
0.21
0.14
0.07
FLOW
STANDARD SPECIFICATIONS (for products on this page):
psi
5
4
3
2
1
PRESSURE DROP
0
0
scfm
0 24681012
l/s
0 3 5421
1/8
Inlet Pressure psig (bar)
36
(2.5)
91
(6.3)
150
(10.3)
14
6
WITH TUBE FITTINGS
1/4 8 (3.8) 5B03B0700 5B03B0800 5B03B0500 5B03B0600
3/8 8 (3.8) 5B04B0700 5B04B0800 5B04B0500 5B04B0600
4mm 8 (3.8) 5B05B0700 5B05B0800 5B05B0500 5B05B0600
6mm 8 (3.8) 5B06B0700 5B06B0800 5B06B0500 5B06B0600
8mm 8 (3.8) 5B07B0700 5B07B0800 5B07B0500 5B07B0600
10mm 8 (3.8) 5B08B0700 5B08B0800 5B08B0500 5B08B0600
Element Rating/Type Kit Number
3-µm - Standard 945K77
Plastic 921K77
Ambient/Media Temperature:
Polycarbonate plastic bowl: 40° to 125°F (4° to 52°C).
Metal bowl: 40° to 150°F (4° to 66°C).
Body: Acetal.
Bowl: 2-ounce (60-ml) capacity polycarbonate plastic; optional
aluminum bowl.
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated element. F or 0.01-m icron r ated
filter element, consult ROSS.
Fluid Media: Compressed air.
DIMENSIONS inches (mm)
Weight
REPLACEMENT FILTER ELEMENT KITS & BOWLS
0.01-µm - Optional R-A-10F-16E8
Bowl T ype Kit Number
Inlet Pressure:
For automatic drain model:
With polycarbonate plastic bowl: 15 to 150 psig (1.0 to 10.3 bar).
With metal bowl: 15 to 200 psig (1.0 to 13.8 bar).
For manual drain model:
With polycarbonate plastic bowl: 0 to 150 psig (0 to 10.3 bar).
With metal bowl: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP. For BSPP threads, add a “C”
prefix to the model number, e.g., C5B01B0700.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
www.rosscontrols.com 15
Ports: 1/8 & 1/4
A
Flow to 10 scfm
MINIATURE Coalescing Filters
FEATURES:
• Inline mounting
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated filter
element
• High-strength polycarbonate plastic lter bowl; optional metal bowl
• Automatic drain; optional manual drain
APPLICATION NOTE:
A general purpose filter must be installed ahead of a coalescing filter to ensure
good performance and to extend the life of the coalescing element.
C
bar
0.35
0.28
0.21
0.14
0.07
0
FLOW
FLOW CHART
0.3-µm ELEMENT
1/4
Inlet Pressure psig (bar)
psi
5
4
3
2
1
PRESSURE DROP
0
scfm
0 24681012
l/s
0 3 5421
36
(2.5)
1/8
91
(6.3)
B
150
(10.3)
ISO Symbols
Filter
Bowl Port
Automatic Drain
DIMENSIONS inches (mm)
Manual Drain
Weight
Type Size A B C Depth lb (kg)
Plastic 1/8, 1/4 1.6 (41) 3.6 (92) 0.4 (9.5) 1.6 (41) 0.33 (0.15)
Metal 1/8, 1/4 1.6 (41) 4.3 (97) 0.4 (9.5) 1.6 (41) 0.35 (0.16)
Port Air Flow Automatic Drain Models Manual Drain Models
Size scfm (l/s) Plastic Bowl Metal Bowl Plastic Bowl Metal Bowl
1/8 7 (3.3) 5031B1128 5032B1118 5031B1028 5032B1028
1/4 8 (3.8) 5031B2128 5032B2128 5031B2028 5032B2028
REPLACEMENT FILTER ELEMENT KIT
Element Rating/Type Kit Number
14
6
0.3-µm - Standard 945K77
0.01-µm - Optional R-A10F-16E8
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature:
Polycarbonate plastic bowl: 40° to 125°F (4° to 52°C).
Metal bowl: 40° to 150°F (4° to 66°C).
Body: Aluminum.
Bowl: 2-ounce (60-ml) capacity polycarbonate plastic; optional
aluminum bowl.
Bowl Drain: Manual drain; optional automatic drain. For optional
automatic drain, consult ROSS.
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated element. For 0.01-micron rated
filter element, consult ROSS.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
16 © 2012, ROSS CONTROLS.
Fluid Media: Compressed air.
Inlet Pressure:
For automatic drain model:
With polycarbonate plastic bowl: 15 to 150 psig (1.0 to 10.3 bar).
With metal bowl: 15 to 200 psig (1.0 to 13.8 bar).
For manual drain model:
With polycarbonate plastic bowl: 0 to 150 psig (0 to 10.3 bar).
With metal bowl: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP. For BSPP threads, add a “C”
prefix to the model number, e.g., C5031B1128.
All Rights Reserved.
MID-SIZE Coalescing Filters
B
Ports: 1/4, 3/8, 1/2
Flow to 100 scfm
A
C
B
FEATURES:
• Modular or inline mounting
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated filter element
• Differential pressure gauge
• Aluminum bowl with clear nylon sight glass
• Optional extended bowl with higher ow lter element
• Internal automatic drain; optional manual drain
C
APPLICATION NOTE:
A general purpose filter must be installed ahead of a coalescing filter to ensure good
performance and to extend the life of the coalescing element.
B
ISO Symbols
Filter
Bowl
Standard Bowl
Extended Bowl
DIMENSIONS inches (mm)
Automatic Drain
Weight
Manual Drain
Type A B C Depth lb (kg)
Standard 2.7 (67) 5.9 (151) 1.8 (45) 2.4 (60) 1.75 (0.80)
Extended 2.7 (67) 8.9 (227) 1.8 (45) 2.4 (60) 2.00 (0.91)
Port Air Flow Automatic Drain Models Manual Drain Models
Size scfm (l/s) Standard Bowl Extended Bowl Standard Bowl Extended Bowl
1/4 70 (33.0) 5032B2138 5032B2148 5032B2038 5032B2048
3/8 70 (33.0) 5032B3138 5032B3148 5032B3038 5032B3048
1/2 80 (37.7) 5032B4138 5032B4148 5032B4038 5032B4048
REPLACEMENT FILTER ELEMENT KITS
Bowl Type Element Rating/Type Kit Number
Standard 0.3-µm - Standard
Extended 0.3-µm - Standard
Standard 0.01-µm - Optional
Extended 0.01-µm - Optional
DIFFERENTIAL PRESSURE GAUGE
Standard Small
Slide Gauge R-A60F-28
R-A60F-29
R-A60F-32
R-A60F-29E8
R-A60F-32E8
bar
0.35
0.28
0.21
0.14
0.07
PRESSURE DROP
0.35
0.28
0.21
0.14
0.07
PRESSURE DROP
0
0
0.35
0.28
0.21
0.14
0.07
PRESSURE DROP
0
scfm
FLOW
FLOW CHARTS
STANDARD 0.3-µm ELEMENT
Inlet Pressure 100 psig (6.9 bar)
psi
0.3-µm element
5
4
3
2
1
00
psi
5
5
4
4
3
3
2
2
1
1
0
0
psi
5
5
4
4
3
3
2
2
1
1
0
0
10
0
l/s
l/s
0 5
0
H designates models with extended bowls.
H
20 30 40 50 60 70 80 90 100
10 15 20 25 30 35 40 45
µm element
0.01-
1/4 Ports
H
H
3/8 Ports
H H
1/2 Ports
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature: 40° to 175°F (4° to 79°C).
Body: Zinc.
Bowl: 6-ounce (180-ml) capacity aluminum with clear nylon sight
glass. Bowl can be rotaded for easy readability. Optional 10-ounce
(300-ml) extended aluminum bowl has higher flow filter element.
Bowl Drain: Internal automatic drain; optional manual drain.
Bowl Ring: Nylon.
Differential Pressure Gauge: R-A60F-28 standard.
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated element. For 0.01-micron filter
element replace the seventh digit from the model number with a
“2”, e.g., 5032B2238.
Fluid Media: Compressed air.
Inlet Pressure:
For automatic drain model: 15 to 150 psig (1.0 to 10.3 bar).
For manual drain model: 0 to 150 psig (0 to 10.3 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP . For BSPP threads, add a “C” prefix
to the model number, e.g., C5032B2138.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
www.rosscontrols.com 17
FULL-SIZE Coalescing Filters
A
Ports: 1/4, 3/8, 1/2
Flow to 100 scfm
C
FEATURES:
• Modular or inline mounting
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated filter element
A
C
• Differential pressure gauge
• High-strength polycarbonate plastic lter bowl with steel shatterguard;
optional metal bowl with clear nylon sight glass
• Optional extended bowl with higher ow lter element
• Manual drain; optional internal automatic drain
B
APPLICATION NOTE:
A general purpose filter must be installed ahead of a coalescing filter to ensure good
performance and to extend the life of the coalescing element.
Standard
Bowl
Bowl
DIMENSIONS inches (mm)
B
Extended
Bowl
Automatic Drain
ISO Symbols
Filter
Weight
Manual Drain
Type A B C Depth lb (kg)
Standard 3.5 (89) 5.8 (146) 1.8 (45) 3.5 (89) 2.13 (0.95)
Extended 3.5 (89) 10.3 (260) 1.8 (45) 3.5 (89) 3.25 (1.54)
Port Air Flow Automatic Drain Models Manual Drain Models
Size scfm (l/s) Plastic Bowl Metal Bowl Plastic Bowl Metal Bowl
1/4 70 (33.0) 5031B2108 5032B2118 5031B2008 5032B2018
3/8 70 (33.0) 5031B3108 5032B3118 5031B3008 5032B3018
1/2 80 (37.7) 5031B4108 5032B4118 5031B4008 5032B4018
1/2 77 (36.3) 5031B4128* 5032B4128* 5031B4028* 5032B4028*
*Models with extended bowl.
REPLACEMENT FILTER ELEMENT KITS
Bowl Type Element Rating/Type Kit Number
Standard 0.3-µm - Standard
Extended 0.3-µm - Standard
Standard 0.01-µm - Optional
Extended 0.01-µm - Optional
947K77
R-A103-133L
948K77
R-A103-133LE8
bar
0.35
0.28
0.21
0.14
0.07
0
bar
0.35
0.28
0.21
0.14
0.07
0
bar
0.35
0.28
0.21
0.14
0.07
FLOW
FLOW CHARTS
STANDARD 0.3-µm ELEMENT
psi
5
4
3
2
1
PRESSURE DROP
0
psi
5
4
3
2
1
PRESSURE DROP
0
psi
5
4
3
2
1
PRESSURE DROP
00
scfm
015
0
l/s
0
H designates models with extended bowls.
Inlet Pressure psig (bar)
H
H
H
H
H
30
15 30 45 60 75
H
H
H
H
45 60 75 90 105120135150 165
150(10.3)92(6.3)36(2.5)
1/4 Ports
3/8 Ports
1/2 Ports
DIFFERENTIAL PRESSURE GAUGES
Small
Slide Gauge
R-K103-151
Large Dual
Face Gauge
R-106-35
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature:
Polycarbonate plastic bowl: 40° to 125°F (4° to 52°C).
Metal bowl: 40° to 175°F (4° to 79°C).
Body: Zinc.
Bowl: 8-ounce (240-ml) capacity polycarbonate plastic with steel
shatterguard; optional zinc bowl with clear n ylon sight glass. Optional
20-ounce (600-ml) extended polycarbonate or zinc bowl has higher
flow filter element.
Bowl Drain: Manual; optional internal automatic drain only on
extended aluminum bowl. For optional internal flow drain (on
polycarbonate plastic bowl only), consult ROSS.
Bowl Ring: Aluminum.
Differential Pressure Gauge: Small Slide Gauge R-K103-151
standard; optional Large Dual Face Gauges, consult ROSS.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
18 © 2012, ROSS CONTROLS.
Large Dual Face Gauge
with Reed Switch
R-106-35E (Normally Open)
R-106-35EC (Normally Closed)
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated element. F or 0.01-micron filter
element replace the seventh digit from the model number with a “2”,
e.g., 5031B2208.
Fluid Media: Compressed air.
Inlet Pressure:
For automatic drain model:
With polycarbonate plastic bowl: 15 to 150 psig (1.0 to 10.3 bar).
With metal bowl: 15 to 200 psig (1.0 to 13.8 bar).
For manual drain model:
With polycarbonate plastic bowl: 0 to 150 psig (0 to 10.3 bar).
With metal bowl: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP . For BSPP threads, add a “C” prefix
to the model number, e.g., C5031B2108.
All Rights Reserved.
MD4
A
A
TM
Coalescing Filters
Ports: 3/8, 1/2, 3/4
Flow to 158 scfm
FEATURES:
• Modular or inline mounting
• 0.3-micron rated coalescing lter element; ; optional 0.01-micron rated element
• Polycarbonate plastic bowl with steel shatterguard; optional metal bowl with sight glass
• Gold cap color; optional gray, yellow, red, and blue
• Optional extended metal bowl with higher ow lter element
• Differential pressure gauge indicates when lter element needs changing
• Internal automatic bowl drain; optional manual drain or electronic drain
APPLICATION NOTE:
A general purpose filter must be installed ahead of a coalescing filter to ensure good
performance and to extend the life of the coalescing element.
ISO Symbols
Filter
C
Automatic Drain
C
B
Bowl T ype A B † C Depth lb (kg)
B
Standard Plastic Bowl
Extended Metal Bowl
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature:
Polycarbonate plastic bowl: 40° to 125°F (4° to 52°C).
Metal bowl: 40° to 175°F (4° to 79°C).
Body: Die-cast zinc.
Bowl: 9-ounce (270-ml) capacity polycarbonate plastic with steel
shatterguard; optional aluminum bowl with clear nylon sight glass.
Optional 15-ounce (450-ml) extended aluminum bowl with a clear
nylon sight glass and higher flow filter element.
Bowl Drain: Internal automatic drain; optional manual drain or
electronic drain. For optional internal float drain (on polycarbonate
plastic bowl only), consult ROSS.
Bowl Ring: Nylon.
Plastic 3.5 (88) 7.7 (195) 2.2 (55) 2.9 (73) 2.13 (0.97)
9-ounce Metal 3.5 (88) 7.6 (193) 2.2 (55) 3.1 (79) 2.13 (0.97)
Extended Metal 3.5 (88) 11.2 (284) 2.2 (55) 3.1 (79) 2.31 (1.05)
† Bowl removal clearance: add 3.1 (79) for 9-ounce bowl; 6.1 (155) for
extended bowl.
Differential Pressure Gauge (options): Small Slide Gauge, Large
Dual Face Gauge and Large Dual Face Gauges with Reed Switch.
Filter Element: 0.3-micron rated borosilicate-glass-fiber; optional
0.01-micron rated element (reduces flow by 20%).
Fluid Media: Compressed air.
Inlet Pressure:
For automatic drain model:
With polycarbonate plastic bowl: 15 to 150 psig (1.0 to 10.3 bar).
With metal bowl: 15 to 200 psig (1.0 to 13.8 bar).
For manual drain model:
With polycarbonate plastic bowl: 0 to 150 psig (0 to 10.3 bar).
With metal bowl: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP, SAE.
DIMENSIONS inches (mm)
Manual Drain
Weight
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
www.rosscontrols.com 19
MD4TM Coalescing Filters
FLOW CHARTS
HOW T O ORDER
MD4 50P C A B 5 2 L
BOWL SIZE
50P - 9 oz Polycarbonate Bowl
50E - 15 oz Metal Bowl
50M - 9 oz Metal Bowl
ELEMENT TYPE
C - 0.3 µm - Standard
D - 0.01 µm - Optional
BOWL DRAIN
A - Auto Drain
M - Manual Drain
E - Electronic Drain - available in manual bowl version only
H - Automatic External Drain - availab le in man ual drain v ersion only
L - Less Drain Fitting - 1/4 NPT female instead
F - Intenal float drain
DIFFERENTIAL PRESSURE GAUGES
Small
Slide Gauge
R-K103-151
PIPE SIZE
3 - 3/8 NPTF
4 - 1/2 NPTF
5 - 3/4 NPTF
C - 3/8 BSPP
D - 1/2 BSPP
E - 3/4 BSPP
F - 3/4-16 SAE
G - 7/8-14 SAE
bar
0.35
0.28
0.21
psi
DIFFERENTIAL
PRESSURE GAUGE
A - No Gauge
L - Large Gauge
S - Small Gauge
E - Large Gauge with Normally
Open Reed Switch
C - Large Gauge with Normally
COLOR
G - Gray
Y - Yellow
R - Red
B - Blue
2 - Gold - Standard
STANDARD 0.3-µm ELEMENT
5
4
3
Closed Reed Switch
Inlet Pressure psig (bar)
H
3/8 Ports
H
150(10.3)92(6.3)36(2.5)
Large Dual
Face Gauge
R-106-35
Large Dual Face Gauge
with Reed Switch
R-106-35E (Normally Open)
R-106-35EC (Normally Closed)
REPLACEMENT FILTER ELEMENT KITS
Bowl Type Element Rating/Type Kit Number
Standard 0.3-µm - Standard R-A115-117
Extended 0.3-µm - Standard R-A115-118
Standard 0.01-µm - Optional R-A115-117E8
Extended 0.01-µm - Optional R-A115-118E8
0.14
0.07
bar
bar
0.35
0.35
0.28
0.28
0.21
0.21
0.14
0.14
0.07
0.07
0
0
bar
bar
0.35
0.35
0.28
0.28
0.21
0.21
0.14
0.14
0.07
0.07
0
0
FLOW
FLOW
2
1
PRESSURE DROP
00
psi
psi
5
5
4
4
3
3
2
2
1
1
PRESSURE DROP
PRESSURE DROP
0
0
psi
psi
5
5
4
4
3
3
2
2
1
1
PRESSURE DROP
PRESSURE DROP
0
0
scfm
scfm
015
30
0
l/s
l/s
0
15 30 45 60 75
H designates models with extended bowls.
H
1/2 Ports
H H
H
H H
3/4 Ports
45 60 75 90 105120135150165H180195
90
20 © 2012, ROSS CONTROLS.
All Rights Reserved.
HIGH-CAPACITY Coalescing Filters
A
Ports: 3/4 & 1
Flow to 220 scfm
FEATURES:
• Inline mounting
• 0.3 micron rated coalescing lter element; optional 0.01-micron rated element
• Differential pressure gauge
• High-strength polycarbonate plastic lter bowl with steel shatterguard; optional
aluminum bowl with clear nylon sight glass
• Internal automatic drain; optional manual drain
APPLICATION NOTE:
C
A general purpose filter must be installed ahead of a coalescing filter to ensure
good performance and to extend the life of the coalescing element.
B
Automatic Drain
Bowl T ype A B C Depth lb (kg)
Polycarbonate
Metal
DIMENSIONS inches (mm)
4.5 (114) 8.0 (203) 3.1 (78) 4.5 (114) 2.38 (1.09)
4.5 (114) 8.3 (210) 3.1 (78) 4.5 (114) 3.20 (1.46)
Automatic Drain Models Manual Drain Models
ISO Symbols
Filter
Manual Drain
Weight
Port Air Flow Plastic Metal Plastic Metal
Size scfm (l/s) Bowl Bowl Bowl Bowl
3/4 140 (68) 5X00B5099 5X00B5076 5031B5008 5032B5018
1 160 (76) 5X00B6027 5X00B6054 5031C6008 5032B6117
REPLACEMENT FILTER ELEMENT KIT
Element Rating/Type Kit Number
0.3-µm - Standard 949K77
0.01-µm - Optional R-A109-106E8
DIFFERENTIAL PRESSURE GAUGES
Small
Slide Gauge
R-K103-151
Large Dual
Face Gauge
R-106-35
FLOW CHARTS
STANDARD 0.3-µm ELEMENT
Inlet Pressure psig (bar)
bar
0.35
0.28
0.14
0.07
bar
0.35
0.28
0.21
0.14
0.07
FLOW
psi
5
4
3
2
1
PRESSURE DROP
00
psi
5
4
3
2
1
PRESSURE DROP
00
scfm
020
40
0
l/s
0
20 40 60 80 100
60 80 100
Large Dual Face Gauge
with Reed Switch
R-106-35E (Normally Open)
R-106-35EC (Normally Closed)
150(10.3)92(6.3)36(2.5)
3/4 Ports
1 Ports
120140160 180 200 220
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature:
Polycarbonate plastic bowl: 40° to 125°F (4° to 52°C).
Metal Bowl: 40° to 175°F (4° to 79°C).
Body: Aluminum.
Bowl: 16-ounce (480-ml) capacity polycarbonate plastic with steel
shatterguard; optional aluminum bo wl with clear n ylon sight glass.
Bowl Drain: Bowl Drain: Internal automatic drain; optional manual
drain. For optional internal flow drain (on polycarbonate plastic bowl
only), consult ROSS.
Bowl Ring: Aluminum.
Differential Pressure Gauge: Large Dual Face Gauge R-106-35
standard; optional Small Slide Gauge and Large Dual Face Gauges
with Reed Switch, consult ROSS.
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated filter element. For 0.01-micron
rated filter element, consult ROSS.
Fluid Media: Compressed air.
Inlet Pressure:
For automatic drain model:
With polycarbonate plastic bowl: 15 to 150 psig (1.0 to 10.3 bar).
With metal bowl: 15 to 200 psig (1.0 to 13.8 bar).
For manual drain model:
With polycarbonate plastic bowl: 0 to 150 psig (0 to 10.3 bar).
With metal bowl: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP . For BSPP threads, add a “C” prefix
to the model number, e.g., C5X00B5099.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
www.rosscontrols.com 21
HIGH-CAPACITY Coalescing Filters
Ports: 3/4, 1
Flow to 295 scfm
A
C
B
FEATURES:
• Inline mounting
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated filter element
• Differential pressure gauge
• Aluminum bowl; optional extended aluminum bowl with higher ow lter element
A
• Internal automatic drain; optional manual drain
APPLICATION NOTE:
C
A general purpose filter must be installed ahead of a coalescing filter to ensure good
performance and to extend the life of the coalescing element.
ISO Symbols
Filter
B
Automatic Drain
Manual Drain
Standard Bowl
Extended Bowl
FLOW CHART
STANDARD 0.3-µm ELEMENT
Inlet Pressure 100 psig (6.9 bar)
psi
bar
bar
0.28
0.28
0.21
0.21
0.14
0.14
0.07
0.07
0
0
FLOW
FLOW
Standard Bowl
5
5
4
4
3
3
2
2
1
1
PRESSURE DROP
0
0
050
0
scfm
scfm
l/s
l/s
0 25
0
100 150 200 250
50 75 100 125
DIFFERENTIAL PRESSURE GAUGES
Small
Slide Gauge
R-K103-151
Extended Bowl
3/4
1
3/4
1
300
Large Dual
Face Gauge
R-106-35
Bowl
DIMENSIONS inches (mm)
Weight
Type A B C Depth lb (kg)
Standard 4.5 (114) 10.1 (257) 3.3 (83) 4.2 (106) 3.50 (1.59)
Extended 4.5 (114) 15.7 (399) 3.3 (83) 4.2 (106) 4.25 (1.91)
Automatic Drain Models Manual Drain Models
Port Air Flow* Standard Extended Standard Extended
Size scfm (l/s) Bowl Bowl Bowl Bowl
3/4 225 (106.2) 5X00B5086 5X00B5087 5032B5019 5032B5029
1 295 (139.2) 5X00B6064 5X00B6065 5032B6019 5032C6028
*Flow ratings are for standard bowl.
REPLACEMENT FILTER ELEMENT KITS
Bowl Type Element Rating/Type Kit Number
Standard 0.3-µm - Standard R-A114-112
Extended 0.3-µm - Standard R-A114-113
Standard 0.01-µm - Optional R-A114-112E8
Extended 0.01-µm - Optional R-A114-113E8
Large Dual Face Gauge
with Reed Switch
R-106-35E (Normally Open)
R-106-35EC (Normally Closed)
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature: 40° to 175°F (4° to 79°C).
Body: Aluminum.
Bowl: 35-ounce (1050-ml) capacity aluminum bowl. Optional
62-ounce (1860-ml) extended aluminum bowl has higher capacity
filter element for increased air flow.
Bowl Drain: Internal automatic drain or manual drain available.
For optional internal float drain, consult ROSS.
Bowl Ring: Aluminum.
Differential Pressure Gauge: Large Dual Face Gauge R-106-35
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated filter element. For 0.01-micron
rated filter element, consult ROSS.
Fluid Media: Compressed air.
Inlet Pressure:
For automatic drain model: 15 to 200 psig (1.0 to 13.8 bar).
For manual drain model: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP. For BSPP threads, add a “C”
prefix to the model number, e.g., C5X00B5086.
standard; optional Small Slide Gauge and Large Dual Face Gauges
with Reed Switch, consult ROSS.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
22 © 2012, ROSS CONTROLS.
All Rights Reserved.
HIGH-CAPACITY Coalescing Filters
A
A
FLOW CHART
Ports: 1¼ & 1½
Flow to 450 scfm
C
B
Standard Bowl
C
B
Extended Bowl
FEATURES:
• Inline mounting
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated filter element
• Differential pressure gauge
• Aluminum bowl; optional extended bowl with higher flow filter element
• Internal automatic drain; optional manual drain
APPLICATION NOTE:
A general purpose filter must be installed ahead of a coalescing filter to ensure
good performance and to extend the life of the coalescing element.
ISO Symbols
Filter
Automatic Drain
Bowl DIMENSIONS inches (mm) Weight
Manual Drain
Type A B C Depth lb (kg)
Standard 5.5 (140) 10.6 (270) 3.7 (94) 4.2 (106) 4.31 (1.94)
Extended 5.5 (140) 16.2 (412) 3.7 (94) 4.2 (106) 5.00 (2.27)
bar
bar
0.35
0.35
0.28
0.28
0.21
0.21
psi
psi
Standard Bowl
5
5
4
4
3
3
STANDARD 0.3-µm ELEMENT
Inlet Pressure 100 psig (7 bar)
Extended Bowl
1-1/2
1-1/4
1-1/4
1-1/2
Port Air Flow Standard Extended Standard Extended
Size scfm (l/s) Bowl Bowl Bowl Bowl
1¼ 230 (108.5) 5X00B7034 5X00B7036 5032B7019 5032B7029
1½ 270 (127.4) 5X00B8035 5X00B8036 5032B8019 5032B8029
Automatic Drain Models Manual Drain Models
REPLACEMENT FILTER ELEMENT KITS
0.14
0.14
0.07
0.07
FLOW
2
2
1
1
PRESSURE DROP
0
0
0
0
scfm
scfm
075
0
l/s
l/s
0
0
150 225 300 375
75 150112.5 187.537.5
450
Bowl Type Element Rating/Type Kit Number
Standard 0.3-µm - Standard R-A114-112
Extended 0.3-µm - Standard R-A114-113
Standard 0.01-µm - Optional R-A114-112E8
Extended 0.01-µm - Optional R-A114-113E8
DIFFERENTIAL PRESSURE GAUGES
Large Dual Face Gauge
Small
Slide Gauge
R-K103-151
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature: 40° to 175°F (4° to 79°C).
Body: Aluminum.
Bowl: 35-ounce (1050-ml) capacity aluminum bowl. Optional
62-ounce (1860-ml) extended aluminum bowl has higher capacity
filter element for increased air flow.
Bowl Drain: Internal automatic drain or manual drain available.
For optional internal float drain (on polycarbonate plastic bowl only),
consult ROSS.
Bowl Ring: Aluminum.
Large Dual
Face Gauge
R-106-35
with Reed Switch
R-106-35E (Normally Open)
R-106-35EC (Normally Closed)
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated filter element. For 0.01-micron
rated filter element, consult ROSS.
Fluid Media: Compressed air.
Inlet Pressure:
For automatic drain model: 15 to 200 psig (1.0 to 13.8 bar).
For manual drain model: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
Threads: NPT standard, BSPP . For BSPP threads, add a “C” prefix
to the model number, e.g., C5X00B7034.
Differential Pressure Gauge: Large Dual Face Gauge R-106-35
standard; optional Small Slide Gauge and Large Dual Face Gauges
with Reed Switch, consult ROSS.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
www.rosscontrols.com 23
HIGH-CAPACITY Coalescing Filters
A
FLOW CHARTS
Ports: 1¼ & 1½
Flow to 465 scfm
Standard Bowl Extended Bowl
FEATURES:
• Inline mounting
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated
A
C
filter element
• Differential pressure gauge
• Metal bowl; optional extended bowl with higher flow filter element
• Internal oat drain; optional manual drain
C
B
APPLICATION NOTE:
A general purpose filter must be installed ahead of a coalescing filter to ensure
performance and to extend the life of the coalescing element.
good
B
ISO Symbols
Filter
STANDARD 0.3-µm ELEMENT
psi
bar
bar
0
0
scfm
scfm
5
4
3
2
1
PRESSURE DROP
00
psi
5
4
4
3
3
2
2
1
1
PRESSURE DROP
PRESSURE DROP
0
0
050
0
l/s
l/s
025
0
0.35
0.28
0.21
0.14
0.07
0.35
0.28
0.28
0.21
0.21
0.14
0.14
0.07
0.07
FLOW
FLOW
DIFFERENTIAL PRESSURE GAUGES
Inlet Pressure psig (bar)
100 150 200 250 300 350 400 450 500
50 750 100 125 150 175 200 225
Small
Slide Gauge
R-K103-151
145(10.0)91(6.3)36(2.5)
1-1/4 Ports
1-1/2 Ports
Large Dual
Face Gauge
R-106-35
Internal Float Drain
Bowl DIMENSIONS inches (mm) Weight
Manual Drain
Type A B C Depth lb (kg)
Standard 7.8 (197) 15 (381) 3.9 (99) 7.8 (197) 14.6 (6.6)
Extended 7.8 (197) 22 (559) 3.9 (99) 7.8 (197) 19.7 (8.9)
Internal Float Drain Models Manual Drain Models
Port Air Flow Standard Extended Standard Extended
Size scfm (l/s) Bowl Bowl Bowl Bowl
1¼ 320 (151.0) 5X00B7019 –– 5032B7018 5032B7028
1½ 345 (162.8) 5X00B8008 –– 5032B8018 5032B8028
REPLACEMENT FILTER ELEMENT KITS
Bowl Type Element Rating/Type Kit Number
Standard 0.3-µm - Standard 952K77
Extended 0.3-µm - Extended 953K77
Standard 0.01-µm - Optional R-A106-24E8
Extended 0.4-µm - Optional R-A106-24LE8
Large Dual Face Gauge
with Reed Switch
R-106-35E (Normally Open)
R-106-35EC (Normally Closed)
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature: 40° to 175°F (4° to 79°C).
Body: Aluminum.
Bowl: 123-ounce (3.7-liter) capacity aluminum bowl. Optional
233-ounce (7-liter) extended aluminum bowl has higher flow filter
element.
Bowl Drain: Internal float drain; optional manual drain.
Differential Pressure Gauge: Large Dual Face Gauge R-106-35
standard; optional Small Slide Gauge and Large Dual Face Gauges
with Reed Switch, consult ROSS.
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated filter element. For 0.01-micron
rated filter element, consult ROSS.
Fluid Media: Compressed air.
Inlet Pressure:
For internal float drain model: 30 to 200 psig (2.1 to 13.8 bar).
For manual drain model: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
V-Band: Stainless steel.
Threads: NPT standard, BSPP. For BSPP threads, add a “C”
prefix to the model number, e.g., C5X00B7019.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
24 © 2012, ROSS CONTROLS.
All Rights Reserved.
FLOW CHART
HIGH-CAPACITY Coalescing Filters
Port: 2
Flow to 840 scfm
FEATURES:
• Inline mounting
• 0.3-micron rated coalescing lter element; optional 0.01-micron rated
filter element
A
C
• Differential pressure gauge
• Metal bowl
• Internal oat drain; optional manual drain
APPLICATION NOTE:
B
A general purpose filter must be installed ahead of a coalescing filter to
ensure good performance and to extend the life of the coalescing element.
ISO Symbols
Filter
STAMDARD 0.3-µm ELEMENT
bar
bar
0.35
0.35
0.28
0.28
0.21
0.21
0.14
0.14
0.07
0.07
0
0
FLOW
psi
psi
5
5
4
4
3
3
2
2
1
1
PRESSURE DROP
0
0
scfm
scfm
0 100
0
l/s
l/s
0 50
0
Inlet Pressure psig (bar)
150(10.3)92(6.3)36(2.5)
200 300 400 500 600 700 800 900 1000
100 150 200 250 300 350 400 450
DIFFERENTIAL PRESSURE GAUGES
Small
Slide Gauge
R-K103-151
Large Dual
Face Gauge
R-106-35
STANDARD SPECIFICATIONS (for products on this page):
Ambient/Media Temperature: 40° to 175°F (4° to 79°C).
Body: Aluminum.
Bowl: 233-ounce (7-liter) capacity aluminum bowl.
Bowl Drain: Internal float drain or manual drain available.
Differential Pressure Gauge: Large Dual Face Gauge R-106-35
standard; optional Small Slide Gauge and Large Dual Face Gauges
with Reed Switch, consult ROSS.
Filter Element: 0.3-micron rated borosilicate-glass-fiber coalescing
element; optional 0.01-micron rated element. For 0.01-micron rated
filter element, consult ROSS.
Internal Float Drain
DIMENSIONS inches (mm)
Manual Drain
Weight
A B C Depth lb (kg)
7.8 (197) 22 (559) 3.9 (99) 7.8 (197) 19.7 (8.9)
Port Air Flow Models
Size scfm (l/s) Internal Float Drain Manual Drain
2 600 (283.2) 5X00B9009 5032B9018
REPLACEMENT FILTER ELEMENT KIT
Element Rating/Type Kit Number
0.3 µm - Standard 953K77
0.01-µm - Optional R-A-106-24LE8
Large Dual Face Gauge
with Reed Switch
R-106-35E (Normally Open)
R-106-35EC (Normally Closed)
Fluid Media: Compressed air.
Inlet Pressure:
For internal float drain model: 30 to 200 psig (2.1 to 13.8 bar).
For manual drain model: 0 to 200 psig (0 to 13.8 bar).
Seals: Nitrile.
V-Band: Stainless steel.
Threads: NPT standard, BSPP . For BSPP threads, add a “C” prefix
to the model number, e.g., C5X00B9009.
IMPORTANT NOTE: Please read carefully and thoroughly all of the CAUTIONS on the inside back cover.
www.rosscontrols.com 25
Loading...
