Page 1
M35 Series
Safety Exhaust (Dump)
Control Reliable Double Valves
with or without EEZ-ON® (Soft-Start) Module
Operating Instructions
RC-M35-OI 01.2019 EN
HSM 18017
Sicherheit geprüft
tested safety
√
Declaration of CE Conformity and Certifications available for download at www.rosscontrols.com
Page 2
M35 Series Operating Instructions
-
M35 Series Dump Valve
Lockout Valve
Dual PO
Controlled Valve
ORDER KEY (Example)
M35 S 40 G A E X AA G A
Series
Soft-Start Function
With Soft-Start S
No Soft-Start X
Port Size
Inlet Outlet Exhaust
1/2 1/2 – Built-in Silencer
3/4 3/4 – Built-in Silencer
1/2 1/2 1 Threaded Exhaust Flange*
3/4 3/4 1 Threaded Exhaust Flange*
* Silencer not included but recommended.
Thread
BSPP G
NPT
Voltage
24 volts DC A
Exhaust Type
N
Monitoring
External E
Communication
None X
Pin Conguration Combinations*
Solenoid Sensor Solenoid Sensor
40
50
46
56
A A
A B
A C
*See Valve
AA
AB
AC
Pinout below.
Revision Level
Pressure Gauge
With Gauge G
No Gauge
X
C C
D B
D C
CC
DB
DC
With EEZ-ON
Solenoid
B
®
(soft-start) module
3
SCHEMATICS
21
Solenoid
A
Without EEZ-ON® (soft-start) module
3
2
Solenoid
B
1
3
Solenoid
A
Pinouts - Solenoid
A
1
4
5
2
+
+
Sol B Sol A
3
Pinouts - Pressure Sensor
A
1
4
5
2
Sensor A Sensor B
Valve with Built-In Exhaust
D
IN
A
SSA
Valve Type
Valve with
Built-In
Exhaust
Valve with
Threaded
Exhaust
Flange
3
PRODUCT LABEL
IDENTIFICATION
Sensor A Sensor B
Model No: M35X40NAEXDBGA
Pressure: 30 to 150 PSIG (2 to 10 bar)
Voltage: 24 VDC
DIMENSIONAL DRAWINGS
With EEZ-ON® module Without EEZ-ON® module
Valve with
Exhaust Flange
C
EXH
G
FL
H
SI (4 LED'S)
EXH
OUT
F
E
B
Flow Rates
C
Port
Size
1/2
3/4
1/2
3/4
Soft-Start
With 4.1
Without 4.3
With 4.1
Without 4.3
With
Without
With
Without
V
1-2 2-3
7.5
4.1
4.3
7.90
4.1
4.3
C
1
Sol B
Sol A
4
5
2
+
3
-
B
+
+
1
+
4
5
2
-
-
3
-
D
1
Sol B
4
5
2
+
3
-
+
2
-
Sensor A Sensor B
www.rosscontrols.com
Valve with Built-In Exhaust
SI (4 LED'S)
D
IN
A
Index
EXH
OUT
with EEZ-ON®
module
C
E
B
Dimensions - Inches (mm)
A
10.31 (261.9) 7.03 (178.5)
B
4.30 (109.3) 4.30 (109.3)
C
3.73 (94.7) 3.73 (94.7)
D
0.64 (16.3) 0.64 (16.3)
1.44 (36.5) 1.44 (36.5)
E
6.39 (162.3) 3.11 (79.0)
F
3.84 (97.6) 3.84 (97.6)
G
6.76 (171.6) 3.28 (83.3)
H
IN
Inlet
OUT
Outlet
EXH Exhaust
SI Status Indicator
SSA Soft-Start Adjustment
EXH FL Threaded Exhaust Flange Exhaust
Sol A
C
+
+
1
4
5
-
3
-
Valve with
Exhaust Flange
G
EXH
FL
H
F
without EEZ-ON®
module
1
Pressure
Sensors
+
-
Sensor ASensor B
2
+
-
Sensor B
1
Pressure
Sensors
+
-
Application Examples
without Soft Start
Pressure
Gauge
L-O-X®
Lockout Valve
L-O-X®
Filter
Pressure
Gauge
Pressure
Regulator
Filter
M35 Series Dump Valve
Pressure
Regulator
with Soft Start
3
3
1
2
21
5/3 Directional
5
1 3
5/2 Solenoid
Pilot Valve
M35 Series Soft Start Adjustment -Flow vs Number of Turns and Inlet Pressure
6000
5000
4000
3000
N Liters/min
2000
1000
0
30 psig (2 bar) 60 psig (4 bar) 90 psig (6 bar) 115 psig (8 bar) 145 psig (10 bar)
Turns (counterclockwise)
Exhaust Time – Normal and Faulted Conditions (s)
Valve with Built-in Silencer Valve with Threaded Exhaust Flange
Volume
3
(L)
ft
0.071
(2)
0.35
(10)
0.71
(20)
1.41
(40)
5.30
(150)
Operating Pressure psig (bar) Operating Pressure psig (bar)
30 (2) 90 (6) 145 (10) 30 (2) 90 (6) 145 (10)
to
to
to
to
to
to
Normal or Faulted
15 (1)
7 (0.5)
15 (1)
7 (0.5)
15 (1)
7 (0.5)
to
15 (1)
N 0.055 0.071 0.094 0.112 0.120 0.135 0.052 0.070 0.093 0.113 0.123 0.142
F 0.072 0.098 0.147 0.183 0.200 0.247 0.065 0.091 0.137 0.175 0.203 0.272
N 0.131 0.208 0.317 0.393 0.424 0.507 0.120 0.191 0.308 0.409 0.437 0.520
F 0.185 0.301 0.533 0.710 0.789 1.024 0.163 0.300 0.503 0.697 0.805 1.048
N 0.226 0.379 0.597 0.746 0.804 0.971 0.204 0.342 0.577 0.779 0.829 0.992
F 0.326 0.555 1.016 1.368 1.526 1.997 0.285 0.562 0.961 1.349 1.558 2.017
N 0.416 0.721 1.155 1.451 1.564 1.899 0.373 0.645 1.115 1.519 1.615 1.937
F 0.608 1.063 1.983 2.685 3.000 3.941 0.530 1.086 1.878 2.655 3.064 3.957
N 1.462 2.604 4.227 5.326 5.743 7.006 1.301 2.310 4.071 5.588 5.934 7.130
F 2.160 3.855 7.298 9.929 11.107 14.635 1.874 3.968 6.919 9.834 11.345 14.622
24
Check Valve
to
7 (0.5)
Flow Control
Flow Control
to
15 (1)
Flow Control
Flow Control
to
7 (0.5)
Sensor A
+
-
220
180
140
100
80
40
0
0186420
to
15 (1)
SCFM
7 (0.5)
2 www.rosscontrols.com
3
2
to
Page 3
M35 Series Operating Instructions
Dietrich Warmbier
Global Safety Product Manager
(Originalfassung)
CE-Konformitätserklärung
ROSS EUROPA GmbH • Robert-Bosch-Strasse 2 • D-63225 Langen
Telefon: (06103) 7597- 0 • Fax: (06103) 74694 • e-mail: info@rosseuropa.com • www.rosseuropa.com
Sitz: Langen • AG: Langen, B412 • Geschäftsführer: Ralf W. Dinkel
Unterschrift
-Zwillingsventile der Baureihe M35
®
an Pneumatikanlagen und deren Bauteile
Bevollmächtigter für die Zusammenstellung der technischen Unterlagen:
Klaus Goebel
Fa. ROSS EUROPA
Robert-Bosch-Straße 2
63225 Langen
Zertizierungsstelle der Baumusterprüfung:
DGUV Test
Prüf- und Zertifizierungsstelle Hebezeuge, Sicherheitskomponenten und Maschinen
Fachbereich Holz und Metall
Kreuzstraße 45
40210 Düsseldorf
Tel.: 0211 8224-16910
Fax: 0211 8224 26910
pz-hsm.fbhm@bghm.de
http://www.dguv.de/fb-holzundmetall/pruefstellen/hebezeuge
Kurzzeichen: HSM
Benannte Stelle der EU, Kennnummer: 0393
Hiermit erklären wir,
dass alle ROSS
den einschlägigen Bestimmungen folgender Richtlinien entsprechen:
Maschinenrichtlinie 2006/42/EG
Angewendete harmonisierte Normen:
EN ISO 13849-1:2015: Sicherheit von Maschinen
-Sicherheitsbezogene Teile von Steuerungen Teil 1
EN ISO 13849-2:2012: Sicherheit von Maschinen
-Sicherheitsbezogene Teile von Steuerungen Teil 2
EN60204-1:2006-06: Sicherheit von Maschinen
-Elektrische Ausrüstung von Maschinen Teil 1
EN ISO 4414:2010-11: Fluidtechnik
-Allgemeine Regeln und sicherheitstechnische Anforderungen
(Zertizierung eingeleitet)
Langen, 28. Juli 2017
Dietrich Warmbier
Global Safety Product Manager
Signature
(Translation from German-language Original)
Declaration of CE Conformity
double valve M35
®
Systems and their Components
Authorized person for the compilation of technical documentation:
Klaus Goebel
ROSS EUROPA GmbH
Robert-Bosch-Strasse 2
63225 Langen / Germany
Certication Body for Type Testing:
DGUV Test
Prüf- und Zertifizierungsstelle Hebezeuge, Sicherheitskomponenten und Maschinen
Fachbereich Holz und Metall
Kreuzstraße 45
40210 Düsseldorf
Tel.: 0211 8224-16910
Fax: 0211 8224 26910
pz-hsm.fbhm@bghm.de
http://www.dguv.de/fb-holzundmetall/pruefstellen/hebezeuge
Reference: HSM
Notied Body within the European Union, ID-No.: 0393
ROSS EUROPA GmbH • Robert-Bosch-Strasse 2 • D-63225 Langen
Telefon: (06103) 7597- 0 • Fax: (06103) 74694 • e-mail: info@rosseuropa.com • www.rosseuropa.com
Sitz: Langen • AG: Langen, B412 • Geschäftsführer: Ralf W. Dinkel
Herewith we declare
that all ROSS
are in full accordance with the following Directive:
Machinery Directive 2006/42/EC
Applied harmonized standards:
EN ISO 13849-1:2015: Safety of Machinery
- Safety related parts of a control system - Part 1
EN ISO 13849-2:2012: Safety of Machinery
- Safety related parts of a control system - Part 2
EN60204-1:2006-06: Safety of Machinery
-Electrical equipment of machines - Part 1
EN ISO 4414:2010-11: Pneumatic Fluid Power
- General Rules and Safety Requirements for Pneumatic
(Certication pending)
Langen, July 28, 2017
www.rosscontrols.com 3
Page 4
M35 Series Operating Instructions
1. About this Documentation
These instructions contain important information for the safe and appropriate
assembly and commissioning of the product.
f Read these instructions all the way through, particularly section 6.4 “Safety
instructions,” before working with the product.
Additional documentation:
• SISTEMA libraries
• DGUV (formerly BG) certicate: German professional association
• Technical documents
For more information see last page for contact information, or visit www.rosscontrols.com.
f In addition, observe all applicable local and national regulations on accident
prevention and on environmental protection.
1.1. Warning Notices in these Operating Instructions
In these operating instructions, warning notices precede sections with handling
requirements which incur risks of personal injury or material damage.
Warnings are structured as follows:
SIGNAL WORD
Type or source of hazard!
Consequences
f Measures to avert danger
• Warning triangle: Indicates a risk of fatal or severe injuries.
• Signal word: Indicates the severity of the danger.
• Type or source of hazard: States the type of danger or the source of the hazard.
• Consequences: Describes possible consequences of ignoring the warning.
• Measures to avert danger:Indicates how to avoid the danger. It is essential that
the measures to avert danger are complied with.
DANGER
WARNING
CAUTION
ATTENTION
Indicates an imminent and serious danger that will result in severe
or even fatal injury if you fail to avoid it.
Indicates a possible danger that could result in severe or even fatal
injury if you fail to avoid it.
Indicates a danger that may result in minor to moderate injuries if
you fail to avoid it.
Indicates potential property damage that may be incurred by the
product or its surroundings if you fail to avoid it.
2. Product Identication
Date of manufacture and site of manufacture are permanently stamped:
Manufacturing site Site abbreviation
ROSS CONTROLS USA (L) (5 16 L)
ROSS EUROPA (G) (
ROSS UK (RB) (
ROSS ASIA (J) (
ROSS SOUTH AMERICA (B) (
ROSS CONTROLS CHINA (C) (
ROSS CONTROLS INDIA (RCI) (
Valve printing
(example May 2016)
5 16
G)
5 16
RB)
5 16
J)
5 16
B)
5 16
C)
5 16
RCI)
See back page for ROSS addresses.
Product label identification & product key identification example, see page 2.
3. Prerequisites for Use of the Product
f Make these operating instructions available to the engineer and assembly
technician of the machine/system in which the product will be used.
f Keep these operating instructions for the entire product life cycle.
3.1. Qualied Personnel
Assembly, installation, commissioning, maintenance, and decommissioning should
only be carried out by qualied personnel that have the required knowledge of and
experience in dealing with electrical and pneumatic control technology.
4. Package Contents
Items included:
• M35 Series valve
• Operating instructions
5. Service, Repair, and Maintenance
f In case of technical problems or a required repair, please contact your local
ROSS representative. If used properly, the M35 Series valves will not require
maintenance. Unless otherwise required, ROSS recommends performing a
functional test at least annually (see 8.1 Test Procedure).
6. Notes on Safety
The product has been manufactured according to the accepted rules of current technology.
There is risk of injury or damage if the following safety instructions and warnings given
in this instruction manual are not observed.
6.1. Intended Use
The M35 Series of double valves are safety components designed and manufactured
in accordance with Machinery Directive 2006/42/EC and bear the CE mark. The
M35 Series double valves are redundant 3/2 valves that are designed to meet the
needs and requirements of safe air supply/exhaust applications for machinery with
pneumatic controls. Typically, these valves are implemented to meet the Category 4
and/or Performance Level e requirements of a machine’s (or system’s) safety circuit as
determined by a risk assessment of the hazards and tasks required of employees that
interact with the machine/system.
f See section 10 “Technical Data” for the standards and test values complied with and
adhered to by the product. See the declaration of conformity for product-relevant EC
directives.
The M35 Series valve is designed to supply air to a zone or entire machine/system
until signaled to shut off and exhaust residual downstream pneumatic energy from the
machine. Thus, reducing the hazards associated with the presence of residual energy
during employee access and/or minor servicing. The safety function of the M35 Series
valve is to shut off supply of pneumatic energy and to exhaust any pneumatic energy
from downstream of the valve.
Note: The M35 Series valve cannot exhaust pneumatic energy from downstream of
obstructions such as check valves and closed center function valves.
The M35 Series valves are designed for external monitoring for safe, redundant
operation. The M35 Series valves are constructed of redundant, 3/2 poppet type
valves, and have an overall function of a single solenoid pilot-operated, spring return
valve. Each valve element in the M35 Series is equipped with a solid state pressure
sensor. Monitoring both of these sensors on each actuation and de-actuation of the
M35 Series valve provides a diagnostic coverage up to 99%. Monitoring of these
sensors is to be done by an external monitoring system.
The M35 Series valves can also be purchased with an EEZ-ON® (soft-start) module.
The function of the EEZ-ON® (soft-start) module is to, on energization, allow outlet
pressure to increase at a slower than normal rate until it reaches approximately
50% of inlet pressure, at which point the valve will then open fully to finish filling the
system at full flow rate. This feature can be used to lessen the shock of sudden,
rapid pressurization of cylinders. This feature is especially useful where inline ow
controls are placed into the cylinder control lines in the “meter out” mode. Flow controls
mounted in this fashion do not operate sufciently when the system is initially being
relled with compressed air after the system has been de-pressurized. This causes
uncontrolled cylinder speed on the rst actuation of the cylinder. The EEZ-ON® (softstart) feature can remedy this situation by gradually relling the system. Thus, allowing
cylinders to ease into place instead of slamming. When using the EEZ-ON® (soft-start)
feature, the time it takes for the outlet pressure to reach approximately 50% of inlet
pressure can be changed by adjusting the ow control in the EEZ-ON® (soft-start)
module. Turning the ow control clockwise will increase the time it takes the outlet
pressure to reach 50% of inlet pressure. Turning the ow control counter-clockwise
will reduce this time. This time interval is directly affected by the volume of the system
being lled. In larger volume systems the time to reach 50% will be longer than in
systems with smaller volumes. It is important to note that the EEZ-ON® (soft-start)
feature only works when switching the M35 Series valve on. The EEZ-ON® (soft-start)
feature does not affect the exhaust (safety) function of the valve.
6.1.1. Safety Function According to ISO 13849 and EN 692
M35 Series valves are designed in accordance with the requirements listed in ISO
13849-1 and -2. Their “fail-to-safe” safety function is ensured even in case of a fault
within the valve (e.g., caused by wear, contamination, or similar situations).
The safety function of the 3/2 M35 Series valve is to only supply compressed air
(pneumatic energy) to the machine/system when the two valve elements are actuated
simultaneously, but to shut-off the supply and to exhaust any downstream compressed
air when both valves are shut off or if only one of the two valves is actuated. A fault in
the system where only one valve actuates when switching on or only one de-actuates
when switching off prevents air from being supplied downstream and simultaneously
exhausts any air that is already downstream. Monitoring of the two pressure sensors
by the user’s external safety monitoring system makes it possible to detect these fault
situations and to shut off and prevent further electrical energization of the solenoids.
The control outputs of the safety system must be designed and constructed to meet the
Category and/or Performance Level requirements of the safety system, as determined
by the risk assessment of the machine. Normally, the outputs to the solenoids is a
dual-channel output from a safety relay or safety PLC.
These products are designed and manufactured in accordance with the safety
principles of ISO 13849-1 and EN 692.
6.1.2. Common Cause Failure – CCF
Common Cause Failures (CCF) are failures of different components, resulting from a
single event. CCF are not to be confused with cascading faults or common mode faults.
4 www.rosscontrols.com
Page 5
M35 Series Operating Instructions
Common cause failures can cause loss of the safety function, especially in dual channel
circuits where both channels could fail simultaneously due to a single event.
• Maintain compressed air quality, e.g., ltration, pressure regulation, lubrication.
• Avoid compressor oils that can cause valve seals to swell, soften, or otherwise
deteriorate.
• Operate within prescribed temperature limits.
• Install the valve such that the normal stroke travel of the valve elements are
perpendicular to the main direction of machine vibration and/or mechanical shock.
• Do not use a test pulse longer than allowed by the Technical Specications.
• Avoid external magnetic elds.
• Do not plug the valve exhaust port.
• Use only high-ow, non-clogging silencers, available from ROSS®.
6.1.3. Diagnostic Coverage
A diagnostic coverage of 99% is achievable through appropriate integration of the M35
Series valve into the safety control system. The monitoring system must check for the
proper change of state of each valve pressure sensor (S1 & S2) with each change
of state of the safety control system outputs to the valve solenoids (Sol 1 & Sol 2).
Detection of a fault by the safety control system must trigger a shut-off of the safety
controller’s outputs to the valve solenoids (Sol 1 & Sol 2), see section 8.
6.1.4. Fault Modes
Note that normal operation requires that Sol 1 & Sol 2 be energized simultaneously
for switching the M35 Series valve on, and de-energizing both Sol 1 and Sol 2
simultaneously for switching the M35 Series valve off. Faults that could occur during
normal operation:
Sol 1 & Sol 2 energized simultaneously
S1 ON, S2 OFF
S1 OFF, S2 ON
S1 OFF, S2 OFF
Sol 1 & Sol 2 de-energized simultaneously
S1 ON, S2 OFF
S1 OFF, S2 ON
S1 ON, S2 ON
6.1.5. Foreseeable Misuse
WARNING
Risk of Injury!
Misuse may result in injury or damage.
f The product must be used exclusively as intended.
Foreseeable misuse includes:
• Use outdoors
• Bypassing the safety function or diagnostics
• Failing to utilize the onboard pressure sensors to verify valve operation on every
cycle – energizing and de-energizing
• Allowing continued operation of the valve when one or both valve shifted signals
(from pressure sensors) are not conrmed.
• Use in reverse operation (reversal of supply and exhaust air)
• Operation in low-demand mode per IEC 61508
• Operating at pressures below minimum operating pressure or above maximum
operating pressure.
6.2. Responsibilities of the System Owner
• Observe the information on assembly and operating conditions listed in the
operating instructions or the data sheet.
• Comply with the further requirements of ISO 13849 (e. g., CCF, DC, PLr, software)
if you intend to use the product in higher categories (2 to 4).
• Make sure that the maximum number of switching cycles (B
life TM is not exceeded. If the expected number of switching cycles for a component
exceeds the B
have to be specied.
• Switch the valve at least once a month to ensure its proper operation.
• Make sure that the fundamental and proven safety principles in accordance with
ISO 13849 for implementation and operation of the component are complied with.
• Make sure that the permissible switch-on and switch-off pulses for feedback-free
operation of the pneumatic devices are observed.
• If you operate the M35 Series valve together with an electric two-hand control, it
must comply with the EN 574 standard. Selection and installation of this two-hand
control must take place in accordance with the manufacturer’s specications.
value during its period of use, suitable replacement intervals
10D
6.3. Safety Instructions
• When implementing surge suppression measures, be sure to check whether or
not this extends the valve shut off response time which could extend the machine
stopping time.
• In case of high levels of machine vibration, use appropriate vibration-reducing
elements when installing the valve.
) within the service
10D
• Supply the proper voltage as overvoltage situations can result in solenoid burnout.
• Make sure that the silencer’s ow capacity is not restricted as this could affect
system performance.
• If required, replace the silencer with high-ow, non-clogging silencers, available
from ROSS
®
7. Assembly and Installation
CAUTIONS
Risk of injury due to installation while pressurized or with live parts!
Installation while pressurized or with electrical power switched on can result in
injuries due to sudden pressure build-up or electric shock.
f De-energize and de-pressurize the relevant system parts before installing the valves.
f Secure the system to prevent it being switched back on again.
ATTENTION
Destruction of components!
Chemical substances can damage the surface, the markings and the seals of the device.
f Install the valve such that it is protected against the ef fects of chemicals.
Damage to the device through storage at incorrect temperatures!
The storage temperature represents the permissible ambient temperature and depends on the type of valve in question.
f Observe the temperature information in chapter 10 “Technical Specifications.”
7.1. Mechanical Installation
If attaching to an installed ROSS MD3
connection clamps. If installing as a stand-alone unit, use either (2) ROSS connection
clamp and bracket sets or install ttings directly into the inlet and outlet ports.
Visit www.rosscontrols.com for more information.
7.2. Pneumatic Installation
Connect the compressed air supply to port 1. Connect port 2 to the downstream
portion of the circuit.
7.3. Pneumatic and Electrical Connections
Electrical connections to the solenoids and sensors are made with male 5-pin M12
receptacles on the valve. See Pinouts on page 2. Female connectors and cables are
sold separately. The cables and cable connections as well as the electrical control for
the double valves must comply with the applicable safety regulations.
TM
or MD4TM Air Preparation Unit, use (2) ROSS
8. Commissioning and Operation
CAUTIONS
Damage to health due to loud noise!
Levels above 70 dB(A) may lead to damage to health!
f Always wear ear protectors when working on the product.
Before commissioning, the installation has to be carefully inspected by a qualied,
trained professional.
Make sure that the technical specications matches the operating criteria of the
machine and/or the pneumatic system.
Always set the compressed air supply to a level that ensures that the minimum
operating pressure is adhered to (see section 10 Technical Specications).
8.1. Test Procedure
1. Only Solenoid A energized – Valve is faulted, supply is shut off, downstream air
exhausts through port 3. Sensor A is off, sensor B is on.
2. Reset valve by de-energizing both solenoids – Valve is off, supply is shut off, and
downstream air is exhausted through port 3. Sensors A & B are on.
3. Only Solenoid B energized – Valve is faulted, supply is shut off, downstream air
exhausts through port 3. Sensor A is on, sensor B is off.
4. Reset valve by de-energizing both solenoids – Valve is off, supply is shut off, and
downstream air is exhausted through port 3. Sensors A & B are on.
5. Solenoids A & B energized
Valve is on, air pressure is supplied downstream through port 2 and port 3 is shut
off. Sensors A & B are off.
6. Solenoids A & B de-energized – Valve is off, supply is shut off, and downstream
air is exhausted through port 3. Sensors A & B are on.
NOTE: Test 1 & 3 can only be conducted for solenoid conguration “A” (M35***AEXA**A).
Results from the test procedure other than those listed above could indicate a valve
malfunction. See section 5, Service, Repair, and Maintenance.
www.rosscontrols.com 5
Page 6
M35 Series Operating Instructions
Failure of the valve to shift synchronously leads to a fault in the M35 Series valve.
This could happen for a variety of reasons, such as:
• Defective piston seals,
• Main valve elements experiencing a switching delay due to dirt or resinous oil,
• Insufcient electrical signals to valve solenoids; suitable voltage not available,
• Receipt of signals at solenoids not synchronous,
• Pilot valves experiencing a switching delay due to damaged components, dirt, or
resinous oil,
• Excessive water build-up in the valve.
9. Disconnecting and Removal
CAUTIONS
Risk of injury due to installation while pressurized or with live parts!
Installation while pressurized or with electrical power switched on can result in
injuries due to sudden pressure build-up or electric shock.
f De-energize and de-pressurize the relevant system parts before installing the valves.
f Secure the system to prevent it being switched back on again.
Risk of injury due to disconnecting pressurized or live parts.
• Disconnecting a pneumatic component while the system is pressurized or while
electrical power is supplied can result in injury or death due to sudden pressure
release, unexpected movement, or electric shock.
• Isolate and lock out the electrical and pneumatic systems before disconnecting the valves.
10. Technical Specications
Design: Redundant, 3/2 Normally Closed, Dual Poppet.
Actuation: Solenoid pilot operated with air assisted spring return. One solenoid per
valve element (2 total) – both to be operated synchronously.
Shock test (based on DIN EN 60068-2-27):
• Acceleration: 30G.
• Shock duration: 16ms.
• Shock waveform: 1/2-sine.
• Vibration test: (based on DIN EN 60068-2-6): Acceleration: 10.g.
• Frequency Acceleration: 55Hz - 82,2Hz
• Amplitude: 0,75mm peak to peak.
Mounting Type: In-line mounted - modular/threaded.
Mounting Orientation: Any, preferably vertical.
Flow Media: Compressed air according to ISO 8573-1 Class 7:4:4.
Inlet Pressure: 30 to 150 psig (2 to 10 bar).
Ambient Temperature: 40° to 122°F (4° to 50°C).
Media Temperature: 40° to 175°F (4° to 80°C).
Standard Voltages: 24 volts DC.
Pilot Solenoids: According to VDE 0580. Rated for continuous duty.
Electrical connection type 5-pin M12. Enclosure rating according to DIN 400 50 IP 65.
Pilot Solenoids Power Consumption (each solenoid): 1.2 watts.
Enclosure Rating: According to DIN 400 50 IP 65.
Electrical Connections: Two 5-pin M12 connectors. Enclosure rating according to
DIN 400 50 IP 65.
Pressure Sensors (2 per valve): PNP solid state.
Pressure Sensors Current Consumption (each sensor): <23mA (each without
contacts).
Pressure Sensors: B
B
Value according to ISO 13849-1 and -2: Service life parameter measured
10D
according to ROSS Engineering Standard, Laboratory Test Procedures Section 8:
= 20 million cycles.
B
10D
Maximum Cycle Rate: 5 Hz, measured without volume. The switching frequency
decreases depending on the volume to be controlled.
Monitoring: Dynamic, cyclical, external with customer supplied equipment. Monitoring
should check state of both valve pressure sensors with any and all changes in state
of valve control signals.
Sound Pressure Level [dB(A)]: Consult ROSS for value, maximum pulse sound
pressure level at the loudest measuring point when exhausting the valve with a
ROSS Controls silencer. The sound pressure level is inuenced by the individual
systems used for reduction of noise emissions. Do not restrict the valve exhaust. Use
of the product without the silencer is not recommended.
Minimum Operation Frequency: Once per month, to ensure proper function.
Maximum Recommended Allowable Discordance Time: 150 msec.
= 200x106.
10D
11. Disposal
Dispose of the valve in accordance with the applicable statutory regulations in your
country.
6 www.rosscontrols.com
Page 7
M35 Series Operating Instructions
www.rosscontrols.com 7
Page 8
ROSS CONTROLS
Tel: +1-248-764-1800
Customer Svs. 1-800-GET-ROSS
(438-7677)
Technical Svs. 1-888-TEK-ROSS
(835-7677)
sales@rosscontrols.com
www.rosscontrols.com
U.S.A.
ROSS EUROPA GmbH
Tel: +49-6103-7597-100
Germany
sales@rosseuropa.com
www.rosseuropa.com
ROSS ASIA K.K.
Tel: +81-42-778-7251
Japan
www.rossasia.co.jp
ROSS UK Ltd.
United Kingdom
Tel: +44-1543-671495
sales.uk@rosscontrols.com
www.rossuk.co.uk
ROSS CONTROLS INDIA Pvt. Ltd.
