Rosieres BRBF 174 TFT User Manual
EN Built-in Freezer - Fridge / User Manual
FR Congélateur - Réfrigérateur Encastrable / Guide D’utilisation
BRBF 174 TFT/N
Thank you for choosing this product.
This user manual contains important information on safety and instructions intended to assist you in the operation and maintenance of your appliance.
Please take the time to read this user manual before using your appliance and keep this book for future reference.
Icon |
Type |
Meaning |
|
|
|
|
WARNING |
Serious injury or death risk |
|
|
|
|
RISK OF ELECTRIC SHOCK |
Dangerous voltage risk |
|
|
|
|
FIRE |
Warning; Risk of fire / flammable materials |
|
|
|
|
CAUTION |
Injury or property damage risk |
|
|
|
|
IMPORTANT |
Operating the system correctly |
|
|
|
EN - 2
CONTENTS |
|
|
1 SAFETY INSTRUCTIONS.................................................................................. |
4 |
|
1.1 |
General Safety Warnings................................................................................................ |
4 |
1.2 |
Installation warnings........................................................................................................ |
8 |
1.3 |
During Usage.................................................................................................................. |
8 |
2 DESCRIPTION OF THE APPLIANCE.............................................................. |
10 |
|
2.1 |
Dimensions................................................................................................................... |
11 |
3 USING THE APPLIANCE................................................................................. |
12 |
|
3.1 |
Information on the Frost Free Technology.................................................................... |
12 |
3.2 |
Display and Control Panel............................................................................................. |
12 |
3.3 |
Operating your Fridge Freezer...................................................................................... |
12 |
3.3.1 Temperature Set Button............................................................................................. |
12 |
|
3.3.2 Temperature Settings................................................................................................. |
12 |
|
3.3.3 Super Cooling Mode.................................................................................................. |
13 |
|
3.3.4 Alarm light.................................................................................................................. |
13 |
|
3.4 Temperature Adjustment Warnings............................................................................... |
13 |
|
3.5 Accessories................................................................................................................... |
14 |
|
3.5.1 Ice Tray...................................................................................................................... |
14 |
|
3.5.2 The Freezer Box........................................................................................................ |
14 |
|
3.5.3 The Fresh Dial............................................................................................................ |
14 |
|
4 FOOD STORAGE............................................................................................. |
15 |
|
4.1 |
Refrigerator Compartment............................................................................................ |
15 |
4.2 |
Freezer Compartment................................................................................................... |
16 |
5 CLEANING AND MAINTENANCE................................................................... |
17 |
|
5.1 |
Defrosting...................................................................................................................... |
17 |
6 SHIPMENT AND REPOSITIONING................................................................. |
18 |
|
6.1 |
Transportation and Changing Positioning..................................................................... |
18 |
7 BEFORE CALLING AFTER-SALES SERVICE............................................... |
19 |
|
8 TIPS FOR SAVING ENERGY........................................................................... |
20 |
|
9 TECHNICAL DATA........................................................................................... |
21 |
|
10 INFORMATION FOR TEST INSTITUTES...................................................... |
21 |
|
11 CUSTOMER CARE AND SERVICE............................................................... |
22 |
|
EN - 3
1 SAFETY INSTRUCTIONS
1.1 General Safety Warnings
Read this user manual carefully.
WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: When positioning the appliance, ensure the supply cord is not trapped or damaged.
WARNING: Do not locate multiple portable socketoutlets or portable power supplies at the rear of the appliance.
WARNING: In order to avoid any hazards resulting from the instability of the appliance, it must be fixed in accordance with the instructions.
If your appliance uses R600a as a refrigerant (this information will be provided on the label of the cooler) you should take care during transportation and installation to prevent the cooler elements from being damaged. R600a is an environmentally friendly and
EN - 4
natural gas, but it is explosive. In the event of a leak due to damage of the cooler elements, move your fridge away from open flames or heat sources and ventilate the room where the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the cooler gas circuit.
• Do not store explosive substances such as aerosol cans with a flammable propellant in this appliance.
• This appliance is intended to be used in household and domestic applications such as:
–– staff kitchen areas in shops, offices and other working environments.
–– farm houses and by clients in hotels, motels and other residential type environments.
–– bed and breakfast type environments;
–– catering and similar non-retail applications.
• If the socket does not match the refrigerator plug, it must be replaced by the manufacturer, a service
agent or similarly qualified persons in order to avoid a hazard.
• A specially grounded plug has been connected to the power cable of your refrigerator. This plug should be used with a specially grounded socket of 16 amperes. If there is no such socket in your
house, please have one installed by an authorised electrician.
EN - 5
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.
• Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances. Children are not expected to perform cleaning or user maintenance of the appliance, very young children (0-3 years old) are not expected to use appliances, young children (3-8 years old) are not expected to use appliances safely unless continuous supervision is given, older children (8-14 years old) and vulnerable people can use appliances safely after they have been given appropriate supervision or instruction concerning use of the appliance. Very vulnerable people are not expected to use appliances safely unless continuous supervision is given.
• If the supply cord is damaged, it must be replaced by the manufacturer, an authorised service agent or similar qualified persons, in order to avoid a hazard.
• This appliance is not intended for use at altitudes exceeding 2000 m.
EN - 6
To avoid contamination of food, please respect the following instructions:
• Opening the door for long periods can cause a significant increase of the temperature in the compartments of the appliance.
• Clean regularly surfaces that can come in contact with food and accessible drainage systems
• Store raw meat and fish in suitable containers in the refrigerator, so that it is not in contact with or drip onto other food.
• Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or making ice cream and making ice cubes.
• One-, twoand three-star compartments are not suitable for the freezing of fresh food.
• If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry, and leave the door open to prevent mould developing within the appliance.
EN - 7
1.2 Installation warnings
Before using your fridge freezer for the first time, please pay attention to the following points:
• The operating voltage for your fridge freezer is 220-240 V at 50Hz.
• The plug must be accessible after installation.
• Your fridge freezer may have an odour when it is operated for the first time. This is normal and the odour will fade when your fridge freezer starts to cool.
• Before connecting your fridge freezer, ensure that the information on the data plate (voltage and connected load) matches that of the mains electricity supply. If in doubt, consult a qualified electrician.
• Insert the plug into a socket with an efficient ground connection. If the socket has no ground contact or the plug does not match, we recommend you consult a qualified electrician for assistance.
• The appliance must be connected with a properly installed fused socket. The power supply (AC) and voltage at the operating point must match with the details on the name plate of the
appliance (the name plate is located on the inside left of the appliance).
• We do not accept responsibility for any damages that occur due to ungrounded usage.
• Place your fridge freezer where it will not be exposed to direct sunlight.
• Your fridge freezer must never be used outdoors or exposed to rain.
• Your appliance must be at least 50 cm away from stoves, gas ovens and heater cores, and at least 5 cm away from electrical ovens.
• If your fridge freezer is placed next to a deep freezer, there must be at least 2 cm between them to prevent humidity forming on the outer surface.
• Do not cover the body or top of fridge freezer with lace. This will affect the performance of your fridge freezer.
• Clearance of at least 150 mm is required at the top of your appliance. Do not place anything on top of your appliance.
• Do not place heavy items on the appliance.
• Clean the appliance thoroughly before use (see Cleaning and Maintenance).
• Before using your fridge freezer, wipe all parts with a solution of warm water and a teaspoon of sodium bicarbonate. Then, rinse with clean water and dry. Return all parts to the fridge freezer after cleaning.
• The installation procedure into a kitchen unit is given in the installation manual. This product is intended to be used in proper kitchen units only.
1.3 During Usage
• Do not connect your fridge freezer to the mains electricity supply using an extension lead.
• Do not use damaged, torn or old plugs. • Do not pull, bend or damage the cord. • Do not use plug adapter.
• This appliance is designed for use by adults. Do not allow children to play with the appliance or hang off the door.
• Never touch the power cord/plug with wet hands. This may cause a short circuit or electric shock.
• Do not place glass bottles or cans in the ice-making compartment as they will burst when the contents freeze.
• Do not place explosive or flammable material in your fridge. Place drinks with high alcohol content vertically in the fridge compartment and make sure their tops are tightly closed.
• When removing ice from the ice-making compartment, do not touch it. Ice may cause frost burns and/or cuts.
• Do not touch frozen goods with wet hands. Do not eat ice-cream or ice cubes immediately after they are removed from the ice-making compartment.
• Do not re-freeze thawed frozen food. This may cause health issues such as food poisoning.
EN - 8
Old and Out-of-order Fridges
• If your old fridge or freezer has a lock, break or remove the lock before discarding it, because children may
get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with CFC. Therefore, take care not to harm environment when you are discarding your old fridges.
CE Declaration of conformity
We declare that our products meet the applicable European Directives, Decisions and Regulations and the requirements listed in the standards referenced.
Guarantee
Minimum guarantee is: 2 years for EU Countries, 3 years for Turkey, 1 year for UK, 1 year for Russia, 3 years for Sweden, 2 years for Serbia, 5 years for Norway, 1 year for Morocco, 6 months
for Algeria, Tunisia no legal warranty required.
Disposal of your old appliance
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable
collection point for the recycling of electrical and electronic equipment. By ensuring
this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. For more detailed
information about recycling of this product, please contact your local city office, your household waste disposal service or the shop where you purchased the product.
Packaging and the Environment
Packaging materials protect your machine from damage that may occur during transportation. The packaging materials are
environmentally friendly as they are recyclable. The use of recycled material
reduces raw material consumption and therefore decreases waste production.
Notes:
• Please read the instruction manual carefully before installing and using your appliance. We are not responsible for the damage occurred due to misuse.
• Follow all instructions on your appliance and instruction manual, and keep this manual in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic environments and for the specified purposes. It is not suitable for commercial or common use. Such use
will cause the guarantee of the appliance to be cancelled and our company will not be responsible for any losses incurred.
• This appliance is produced to be used in houses and it is only suitable for cooling / storing foods. It is not suitable for commercial or common use and/or for storing substances except for food. Our company is not responsible for any
losses incurred by inappropriate usage of the appliance.
EN - 9
2 DESCRIPTION OF THE |
The most energy-saving configuration |
|
APPLIANCE |
|
requires drawers, food box and shelves to |
|
|
be positioned in the product, please refer to |
1 |
A |
the above pictures. |
2 |
13 |
|
|
|
|
3 |
|
12 |
|
|
|
|
|
11 |
4 |
|
10 |
5 |
|
|
|
|
|
6 |
|
B |
7 |
|
|
|
|
9 |
8
This presentation is only for information about the parts of the
appliance. Parts may vary according to the appliance model.
A)Refrigerator compartment
B)Freezer compartment
1)Control panel
2)Turbo fan *
3)Refrigerator shelves
4)Crisper cover
5)Crisper
6)Freezer upper flap / Drawer
7)Freezer drawers
8)Ice box tray
9)Freezer glass shelves
10)Bottle shelf
11)Adjustable door shelf * / Door shelf
12)Door shelves
13)Egg holder
*In some models
EN - 10
2.1 Dimensions
* 1770 - 1778 for metal top cover
min40mm
2 min200cm
|
|
mm |
|
570 |
|
- |
|
|
560 |
|
|
545 mm
| <![if ! IE]> <![endif]>max 2100 mm |
<![if ! IE]> <![endif]>mm |
|
|
|
<![if ! IE]> <![endif]>1770 - 1790 |
|
<![if ! IE]> <![endif]>1770 mm |
|
|
|
mm |
|
|
|
540 |
|
|
(recommended) |
|
|
|
min |
560 |
|
|
. |
|
|
|
550 |
|
|
|
|
<![if ! IE]> <![endif]>660,3 mm |
<![endif]>995,5 mm
<![if ! IE]><![endif]>62 mm
<![if ! IE]><![endif]>623,5 mm
EN - 11
3 USING THE APPLIANCE
3.1Information on the Frost Free Technology
The Frost Free refrigerators have a different operating system to static refrigerators.
In normal (static) fridges, the humidity entering the fridge due to opening the
door, and the humidity inherent in the food,
causes frost build-up in
the freezer compartment. To defrost the frost
and ice in the freezer compartment, you are
required to periodically switch off the fridge, place the frozen food
in a separate cooled
container, then remove the ice gathered in the
freezer compartment.
The situation is completely different in Nofrost fridges. A built-in fan
blows dry and cold air evenly throughout the cooler and freezer compartments. The cold air disperses uniformly between the shelves, ensuring all your food is cooled equally, thus preventing humidity and frost build-up.
Therefore, your No-frost fridge allows ease of use, in addition to its huge capacity and stylish appearance.
3.2 Display and Control Panel
1 |
2 |
3 |
4 |
Using the Control Panel
1.Temperature set button
2.Super cooling symbol (Super cooling LED)
3.Alarm symbol (Alarm LED)
4.Adjusted temperature indicator
3.3 Operating your Fridge Freezer
Lighting (If available)
When the product is plugged in for the first time, the interior lights may turn on 1 minute late due to opening tests.
3.3.1 Temperature Set Button
This button allows setting temperature of the fridge. In order to set values for fridge partition, press this button. Use this button also to activate super cooling mode.
3.3.2 Temperature Settings
• It ensures that the temperature settings in the cooling and freezing compartments of your refrigerator are performed automatically. It may be set to any value ranging from MIN to MAX and super cooling mode. As you press
temperature set button from MIN to MAX, the temperature decreases. To save energy in winter months, operate your refrigerator in a lower position.
• Initial temperature setting for refrigerator is at the middle point.
• Every time you press temperature set button, setting temperature will decrease until super cooling symbol and if you keep on pressing the set temperature will be min set temperature again.
EN - 12
3.3.3 Super Cooling Mode
When Would It Be Used?
• To cooling huge quantities of food. • To cooling fast food.
• To cooling food quickly.
• To store seasonal food for a long time.
How To Use?
• If you press temperature set button until super cooling symbol is displayed on the display and you do not press any button within the following 3 seconds, super cooling will blink.
• Super cooling led will light during this mode.
• For optimal appliance performance in maximum cooling capacity, set the
appliance to active Super Cooling mode 5 hours before you put the fresh food into the fridge.
During this mode:
If you press temperature set button, the mode will be cancelled and the setting will be restored from MAX.
Super cooling mode will be automatically cancelled after 5 hours.
3.3.4 Alarm light
In case of a problem within the fridge, the alarm led will release red light.
3.4 Temperature Adjustment Warnings
• It is not recommended that you operate your fridge in environments colder than
10°C in terms of its efficiency.
• Do not start another adjustment while you are already making an adjustment.
• Temperature adjustments should be made according to the frequency of door openings, the quantity of food kept inside the fridge and the ambient temperature in the location of your fridge.
• In order to allow your fridge to reach the operating temperature after being connected to mains, do not open the
doors frequently or place large quantities of food in the fridge. Please note that, depending on the ambient temperature, it may take 24 hours for your fridge to reach the operating temperature.
• A 5 minute delay function is applied to prevent damage to the compressor of your fridge when connecting or disconnecting to mains, or when an energy breakdown occurs. Your fridge will begin to operate normally after 5 minutes.
• Your appliance is designed to operate in the ambient temperature (T/N = 16°C -
43°C) intervals stated in the standards, according to the climate class displayed on the information label. We do not recommend operating your appliance out of the stated temperature limits in terms of cooling effectiveness.
Climate class and meaning:
T (tropical): This refrigerating appliance is intended to be used at ambient temperatures ranging from 16 °C to 43 °C.
ST (subtropical): This refrigerating appliance is intended to be used at ambient temperatures ranging from 16 °C to 38 °C.
N (temperate): This refrigerating appliance is intended to be used at ambient temperatures ranging from 16 °C to 32 °C.
SN (extended temperate): This refrigerating appliance is intended to be used at ambient temperatures ranging from 10 °C to 32 °C.
The Turbo Fan
Do not block the air inlet and outlet openings when storing food, otherwise air circulation provided by the turbo fan will be impaired.
Turbo fan
3.5 Accessories
Visual and text descriptions in the accessories section may vary according to the model of your appliance.
3.5.1 Ice Tray
• Fill the ice tray with water and place in the freezer compartment.
• After the water has completely frozen, you can twist the tray as shown below to remove the ice cubes.
3.5.2 The Freezer Box
The freezer box allows food to be accessed more easily.
Freezer boxes
Freezer flap cover
Removing the freezer box:
• Pull the box out as far as possible • Pull the front of the box up and out
Carry out the opposite of this operation when refitting the sliding compartment.
Always keep hold of the handle of the box while removing it.
3.5.3 The Fresh Dial
Fresh dial
If the crisper is full, the fresh dial located in front of the crisper should be opened. This allows the air in the crisper and the humidity rate to be controlled, to increase the life of food within.
The dial, located behind the shelf, must be opened if any condensation is seen on the glass shelf.
EN - 14
4 FOOD STORAGE
4.1 Refrigerator Compartment
• To reduce humidity and avoid the consequent formation of frost, always store liquids in sealed containers in the refrigerator. Frost tends to concentrate in the coldest parts of the evaporating liquid and, in time, your appliance will require more frequent defrosting.
• Never place warm food in the refrigerator. Warm food should be allowed to cool at room temperature and should be arranged to ensure
adequate air circulation in the refrigerator compartment.
• Make sure no items are in direct contact with the rear wall of the appliance as frost will develop and packaging will stick to it. Do not open the refrigerator door frequently.
• We recommend that meat and clean fish are loosely wrapped and stored on the glass shelf just above the vegetable bin where the air is cooler, as this provides the best storage conditions.
• Store loose fruit and vegetable items in the crisper containers.
• Store loose fruit and vegetables in the crisper.
• Storing fruit and vegetables separately helps prevent ethylene-sensitive vegetables (green leaves, broccoli, carrot, etc.) being affected by ethylenereleaser fruits (banana, peach, apricot, fig etc.).
• Do not put wet vegetables into the refrigerator.
• Storage time for all food products depends on the initial quality of the food and an uninterrupted refrigeration cycle before refrigerator storage.
• To avoid cross-contamination do not store meat products with fruit and vegetables. Water leaking from meat may contaminate other products in the refrigerator. You should package meat
products and clean any leakages on the shelves.
• Do not put food in front of the air flow passage.
• Consume packaged foods before the recommended expiry date.
NOTE: Potatoes, onions and garlic should not be stored in the refrigerator.
• For normal working conditions, it will be sufficient to adjust the temperature setting of your refrigerator to +4 °C.
• The temperature of the fridge compartment should be in the range of 0-8 °C, fresh foods below 0 °C are
iced and rotted, bacterial load increases above 8 °C, and spoils.
• Do not put hot food in the refrigerator immediately, wait for the temperature to pass outside. Hot foods increase the degree of your refrigerator and cause
food poisoning and unnecessary spoiling of the food.
• Meat, fish, etc. should be store in the chiller compartment of the food, and the vegetable compartment is preferred for vegetables. (if available)
• To prevent cross contamination, meat products and fruit vegetables are not stored together.
• Foods should be placed in the refrigerator in closed containers or covered to prevent moisture and odors.
The table below is a quick guide to show you the most efficient way to store the major food groups in your refrigerator compartment.
Food |
Maximum |
How and where to |
|
storage time |
store |
||
|
|||
Vegetables |
1 week |
Vegetable bin |
|
and fruits |
|||
|
|
||
|
|
Wrap in plastic foil, |
|
Meat and |
2 - 3 days |
bags, or in a meat |
|
fish |
container and store |
||
|
|||
|
|
on the glass shelf |
|
Fresh |
3 - 4 days |
On the designated |
|
cheese |
door shelf |
||
|
|||
Butter and |
1 week |
On the designated |
|
margarine |
door shelf |
||
|
EN - 15
Loading...
