Rosewill R7329 User Manual

ATX

Computer Case R7329

User Manual

ATX Computer Case R7329

Chapter 1 Product Introduction

Drawing ………………………………….........................……….. 2

Specification……………………………......................…….……. 2

Chapter 2 Installation

Removing and installing side panels..........................................3

Installing the Motherboard.........................................................4

Installing Add-on card ...............................................................4

Installing Drives (CD/DVD ROM, FDD and HDD)........................5

Replacing the Power Device ……………....…........................….5

Replacing/ Installing the Case Fan ……….….............................6

I/O Function Panel Installation Guide …………..........................6

User Manual

1

ATX Computer Case R7329

Chapter 1: Introduction

Mechanical Drawing:

User Manual

Specifications:

Dimensions 200mm(W) x 430mm(H) x 480mm(D)
M/B Type ATX 12” x 9.6” (30.5cm x 24.5 cm); Micro-ATX
Material SECC Metal 0.8cm

5.25” Drive Bay 5 (Exposed)

3.5” Drive Bay 2 (Exposed); 5 (Hidden)
I/O Panel USB2.0 x 2; MIC x 1; SPK x 1
Cooling System One 80mm front fan ( Intake) (optional);

One 80mm rear fan ( Exhaust )
Power Supply Standard ATX PS2, 350W
Expansion slot 7 slots
