R5505 DVD/CD/MP3 Player w/ TV Tuner
R5506 DVD/CD/MP3 Player
Owner's Manual and Installation Guide
R
R
.mp3
T
Warning!
Table of Contents
THE R5505/R5506 DVD/CD/MP3 PLA YERS ARE DESIGNED TO
ENABLE VIEWING OF DVD OR CD-VIDEO RECORDINGS ONL Y
FOR REAR-SEA T OCCUPANTS.
MOBILE VIDEO PRODUCTS ARE NOT INTENDED FOR VIEWING BY THE DRIVER WHILE THE VEHICLE IS IN MOTION.
SUCH USE MA Y DISTRACT THE DRIVER OR INTERFERE WITH
THE DRIVER’S SAFE OPERATION OF THE VEHICLE, AND
THUS RESUL T IN SERIOUS INJURY OR DEA TH. SUCH USE
MA Y ALSO VIOLATE STA TE LAW.
ROSEN ENTERTAINMENT SYSTEMS DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR PROPERTY DAMAGE THA T
MA Y RESUL T FROM ANY IMPROPER OR UNINTENDED USE.
About Installation
Installation of mobile audio and video components requires
experience with a variety of mechanical and electrical procedures. Even though this manual provides general installation
and operation instructions for your new, it does not show the
exact installation methods for your particular system or
vehicle.
If you do not have the required knowledge and experience to
successfully complete the installation, we strongly recommend
consulting an authorized Rosen/necvox dealer about professional installation options.
Introduction ...................................................................... 2
Care and Maintenance ..................................................... 3
Discs P layed b y this u nit ................................................... 4
Using the DVD player ........................................................ 5
The Remote Control .......................................................... 7
DVD/VCD/CD-Audio Playback .......................................... 8
Watching Broadcast Television (R5505 only)................. 10
MP3 Playback on CD-R discs.......................................... 11
Installation and Wiring.................................................... 1 2
Setup ............................................................................... 16
Troubleshooting .............................................................. 16
INTRODUCTION
The R5505 and R5506 are full-featured disc players, supporting DVD, CD-Video, CD-Audio, and MP3 playback, and are
designed specifically for the mobile environment. They are
intended for use with other Rosen/necvox products and
Rosen/necvox video monitors, and can also be integrated
with many other products as part of a complete mobile video
solution. With a digital audio output, they can also support
use of optional digital audio processors. These DVD players
incorporate many different video output settings to allow the
best possible viewing experience, regardless of what type of
video monitor you may be using.
Note:
• The R5505 and R5506 are designed to be components in a full
audio/video system. If you have any questions about compatible
components, such as monitors, FM modulators, or other audio/
video products, contact your authorized Rosen/necvox dealer.
Accessories Supplied
• Infrared (IR) remote control
• External IR Receiver for optional applications
• Power-supply harness and RCA audio and video cables
• Assorted mounting hardware
• This Owner’s Manual / Installation Guide
The R5505 and R5506 play DVD discs in PAL or NTSC
formats (NTSC is the standard North American video format),
CD-Audio discs, and CD-recordable discs with MP3 files. For
more details on disc types supported, please see “Discs
Played by the Unit”
The remote control (included) provides access to the full set
of standard DVD functions, such as subtitle control, digital
freeze-frame viewing, viewing from multiple camera angles,
selection of various language audio soundtracks, and digital
playback at fast or slow speeds.
4 R5505
About the Registered Marks
This product incorporates copyright protection technology that
is protected by method claims of certain U.S. patents and
other intellectual property rights owned by Macrovision
Corporation and other rights owners. Use of this copyright
protection technology must be authorized by Macrovision
Corporation, and is intended for home and other limited
viewing uses only unless otherwise authorized by Macrovision
Corporation. Reverse engineering or disassembly is prohibited.
Manufactured under license from Dolby Laboratories. Dolby
and the double-D symbol are trademarks of Dolby Laboratories.
FCC Approval
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to consult the
dealer or an experienced radio/TV technician for help.
CARE AND MAINTENANCE
Handling Discs
Always handle a disc by its edges. Never touch the surface of
the disc directly. To remove inadvertent fingerprints and dust,
use a soft cloth and wipe in a straight line from the center of
the disc to the outside edge. Never use liquid or aerosol
cleaners, anti-static spray, or thinner to clean the disc surface.
Do not place discs in the following places: direct sunlight; dirty,
dusty and damp areas; near car heaters; on the seats or
dashboard. Avoid using adhesive labels on discs.
Liquids and the DVD player
Keep all liquids, including beverages and cleaning liquids,
away from the DVD player. Liquids inside the player can
damage the electronics, and result in electrical shock or fire.
If the unit or the remote control should become wet, turn off all
power and contact an authorized Rosen/necvox dealer to
have the system inspected.
Servicing the DVD player
This unit uses a precision mechanism. In the event that
trouble arises, never open the case, disassemble the unit, or
lubricate the rotating parts.
R5505 5
Do not attempt to open the unit or the remote control. The
internal parts are not serviceable by the user. Opening any of
the components will void the warranty . THIS IS A CLASS I
LASER PRODUCT , USING A LASER WHICH COULD CAUSE
HAZARDOUS RADIATION EXPOSURE IF IMPROPERL Y
DISASSEMBLED. All service should be performed by authorized Rosen service centers or other qualified service
personnel.
CAUTION!
Changes or modifications to this product not
approved by the manufacturer will void the
warranty and will violate FCC approval.
Temperature and Moisture
DISCS PLA YED BY THE UNIT
Discs Compatible with the R5505 and R5506
DVD, Video CD (VCD), CD/CD-R, and MP3 discs are compatible with the unit. The identifying logo and description of each
disc type is given below.
DVD 12 cm disc/8 cm disc
(single-sided disc only)
If the player is used while the interior of the vehicle is very
cold, condensation may form on the disc or on the internal
optical pickup system and prevent proper playing of the disc. If
you suspect that condensation is an issue, eject the disc and
inspect the playing surface. If necessary, remove the condensation with a clean soft cloth as described above. If you still
experience problems with playback, you will need to wait for
approximately one hour to allow the DVD player to warm up,
and for the condensation to evaporate. If playback issues
continue, please see your authorized Rosen/necvox dealer.
6 R5505
Video CD 12 cm disc/8 cm disc
CD/CD-R, MP3 12 cm disc/8 cm disc
DVD Regions
This digital media player is designed and manufactured to
respond to the Region Management Information that is
recorded on a DVD disc. If the Region number described on
the DVD disc does not correspond to the Region number of
ACC or engine
ON position
this player (Region 1), this player will not be able to play the
DVD disc. Some DVD discs are manufactured to operate in
“all” zones, and those discs are compatible with this DVD
player.
Region Icons:
ALL
1
1
4
6
Discs Incompatible with the R5505 and R5506
The following disc types are incompatible:
• DVD-ROM
• DVD-R/DVD-RW/DVD-RAM
• Photo CD
• CD-ROM (Excluding most CD-Recordable discs using MP3
or CD-A formats)
• CD-Audio manufactured with certain copy protection
methods
• Any DVD with a Region number other than “1” and “ALL”
USING THE DVD PLA YER
In order to operate the player, the vehicle ignition key switch
must be in the ACC or engine ON position.
WARNING!
To prevent the battery from going dead,
operate this unit with the engine
running, if possible.
R5505 7
DVD
icon
Play/
Pause
icon
DTS
surround
icon
Angle
mark
icon
MP3
icon
Numeric display
Repeat
status
icons
Disc
status
indicator
Dolby
surround
indicator
VCD
icon
Playback
Control
indicator
Front-Panel Controls
1
7
1 Disc loading drawer
2 Front-panel display
3 [POWER] button
4 [PLAY/P AUSE] button
8 R5505
5 [STOP] button
6 [OPEN/CLOSE] button
7 A/V auxiliary inputs
2
The [POWER] button turns the DVD player on and off. The
[POWER] button on the remote can also turn on the unit.
3
The [OPEN/CLOSE] button operates the disc loading drawer.
For information on using the rest of the front-panel controls,
please see the sections describing disc playback.
4
The front-panel display provides basic information about the
status of the DVD player. Please note that essential informa-
5
tion about using the unit will be displayed on the video screen
connected to the unit, and initial setup of the DVD player
cannot be completed without an operating video monitor
6
providing this on-screen display of menus and settings.
Whenever the term “on-screen display” is used, it refers to the
video monitor display, not the front panel display.
THE REMOTE CONTROL
Power
Source -
DVD/TV/EXT
Scan
Surround
Zoom
Next /Previous -
Audio
SKIP
Menu
Title Menu
Navigation
keys
Slow
Stop
Open/Close
A-B
Display
Angle
Volume
Subtitle
Mute
Setup
Equalizer
Enter/Play
Fast
Pause/Step
Numeric
keypad
Using the Remote Control
Aim the remote control towards the IR receiver on the front
panel. The remote control can operate at a 30-degree angle
from the front of the unit.
If you try to perform an action that is not permitted at the
moment, the DVD playerdisplays the following symbol on the
screen:
This is typically displayed if a key is pressed during disc
loading or ejecting, during the introduction section of a disc,
or if you attempt to access certain sections of the Setup menu
while the disc is in Play, Pause, or “pre-stop” mode. Also, this
symbol will be displayed whenever the loaded DVD disc
disallows the attempted action.
R5505 9
DVD/VCD/CD-AUDIO PLA YBACK
Inserting a DVD/VCD/CD
1 Turn the vehicle’s ignition key to the ACC or ON position.
ACC or engine
ON position
2 Press either the [POWER] button on the front panel or the
[POWER] button on the remote control.
Disc Playback
DVD playback will often begin automatically when the disc is
inserted. With some DVD discs, you will need to press
[ENTER/PLAY] to begin playback.
CD-Audio discs will begin playback automatically.
CDs with MP3 files may require you to navigate the file
structure menu. For more information, see “MP3 Playback.”
Stopping Playback
3 Press the [OPEN/CLOSE] button. Remove any disc already
in the tray, and gently place a disc in the tray label-side up.
4 Press [OPEN/CLOSE] or [PLAY].
10 R5505
There are two ways to stop playback:
• Pressing [STOP] once will stop playback, and the DVD
player will store the location last played on the disc.
Playback can be resumed at the same point on the disc by
pressing [PLAY].
• Pressing [STOP] twice will stop playback and clear the
R5505 ’s memory of the last point played on the disc.
Pressing [PLAY] at this point will cause the DVD player to
begin playback from the beginning of the disc.
Selecting a Track or Chapter
Repeat Mode
Moving to the Next Track or Chapter
Press the [SKIP forward] button during playback. The next
track or chapter will be selected.
Moving to the Previous Track or Chapter
Press the [SKIP back] button during playback. The first time
this button is pressed, playback of the current track or chapter
will restart from the beginning. Pressing this button again will
cause the previous track or chapter to be played.
Fast Searching During Playback
Press [ ] and [ ] during playback to rapidly search for a
particular section of a DVD or CD. Each time a fast-search
button is pressed, the speed of the fast search changes as
follows:
Standard Speed – 2X Standard Speed – 4X – 6X – 8X – Back
to Standard Speed.
Pausing Playback
Press [PLAY/PAUSE] - disc playback will pause, and the
frame being displayed will remain on the screen. Press
[PLAY/PAUSE] again to return to normal playback.
Press the [REPEAT] button to select from the following repeat
modes:
Repeat 1 - Repeat - Repeat Off.
With DVD playback, pressing the [REPEAT] button once
causes the current chapter to be replayed. Pressing it twice
enables the DVD disc to be continuously replayed.
With CD playback, pressing the [REPEAT] button once
causes the current track to be replayed. Pressing it twice
enables the disc to be continuously replayed.
Viewing Angles
The Angle Mark appears on the front-panel display and on the
on-screen display during scenes that offer multiple viewing
angles. (Not all DVD discs support this function.) Use the
[ANGLE] button to select from the various angles available. To
conceal the Angle Mark, please see the “Setup” section.
R5505 11
Parental Control
YES
W ATCHING BROADCAST TELEVISION
Parental Control allows authorized users to select an upper
limit to film ratings that can be played. If a DVD is inserted that
exceeds that rating, the following screen appears:
The parental setting of this
player prohibits play.
Would you like this disc to play?
YES
NO
INPUT PASSWD:
The parental setting of this
player prohibits play.
Would you like this disc to play?
YES
NO
In order for the film to play, the viewer must select “Yes,” and
then the four-digit numeric “password” must be entered.
The factory default password is 3308. The password can be
changed—see section “Setup.” The film ratings allowed are
also selected in the “Setup” section.
Notes:
• To change the film rating setting, the password must be used.
• The DVD player determines the correct film ratings to use based
on the country selected in the “Locale” setting —see section
“Setup.”
• Not all DVD titles support this feature.
Using the TV Tuner in the R5505
The R5505 has a built-in TV tuner. With an optional antenna
(not included), broadcast television can be received and
viewed on the monitor connected to the R5505.
Use the [DVD/TV/EXT] button to select TV. Use the [ ] and
[ ] buttons to change channels.
Use the [REP/SCAN] button to scan the stored stations.
Use the [A-B/SAV/ERS] button to store stations, and to erase
stations which have been stored.
Note:
• Television reception is greatly influenced by terrain, atmospheric
conditions, and the location of the receiver. When viewing
broadcast television in a moving vehicle, various types of
interference are often experienced. This is inherent in the nature
of analog broadcast television (and why cable was invented!).
12 R5505
MP3 PLA YBACK ON CD-R DISCS
T 0
(AR
TIST NAME) 1
- - SMAR
T NA
VI - -
(AR
TIST NAME) 3
(AR
TIST NAME) 2
MP3 Disc Recording and File Extensions
Always add a file extension “ .MP3” or “.mp3” to an MP3 file
by using single-byte letters. If you add a different file extension, or forget to add the file extension “ .MP3” or “.mp3,” the
file cannot be played. In addition, if you use upper case and
lower case letters (capital and small letters) mixed together
for file extensions, normal play may not be possible.
Notes:
• Theis player cannot play back a disc recorded on a CD-RW unit.
• Some CDs recorded in CD-R mode may not be usable.
• Files without MP3 data will not play .
MP3 Playback
When a disc with MP3 files is inserted, the SMART NAVI
screen will appear. Each folder and file will be shown (the
order may be slightly different than that on your PC). Navigate
the files and folders using the navigation arrow keys, and
select a file or folder to be played by using the [ENTER] button.
To move to the next file or the previous file, use the [SKIP]
buttons.
- - SMAR
ROOT
ARTIST NAME - SONG TITLE
T NA
VI - -
ROOOOT 0
MP3
(AR
TIST NAME) 1
MP3
(AR
TIST NAME) 2
MP3
(AR
TIST NAME) 3
Three repeat modes are available for MP3 use:
• NO REPEAT
• REP – ONE repeats the current file
• FOLDER REP repeats the current folder
To conceal the SMART NAVI screen, see “Setup.”
Supported MP3 File Formats
• ISO9660, level 1 and level 2 (the most common type of MP3
format)
• Joliet (a version of ISO9660 that supports longer filenames)
• Romeo (a format used by some CD-creating software)
R5505 13
Installation and Wiring
1. Before Starting
Read these instructions and the following precautions
carefully.
WARNING!
Be sure to disconnect the battery (-)
terminal before starting. This is to
prevent short circuits during installation.
Precautions
• This unit is exclusively for cars with a negative ground, 12V
power supply.
• Do not open the case. There are no user-serviceable parts inside.
If you drop anything into the unit during installation, consult your
dealer or an authorized Rosen service center.
• Use a soft, dry cloth to clean the case. Never use a rough cloth,
thinner, benzene, alcohol, or other solvent. For tough dirt, apply a
small amount of cold or warm water to a soft cloth and gently
wipe.
2. Package Contents
• Disc player unit
• IR Remote control
• 4-pin Power Supply harness
• RCA Audio Cable
• Additional IR Receiver (with cable)
• Installation Brackets and Assorted Hardware
• Owner’s Manual / Installation Guide
• Warranty Card
3. Installation Requirements
1 Use the enclosed screws for installation. Using other
screws can cause damage and void the warranty.
Chassis Chassis
Damage
Max. 8 mm (M5 screw)
14 R5505
4. Installing the DVD player
Mounting the
Always use great care when attaching
anything to a vehicle! Visually inspect all
sides of any potential screw location, to
insure no damage will occur. If you have
questions about this process, see your
authorized Rosen dealer.
Do not overtighten the screws on uneven
surfaces! This can cause damage to the
unit. If an even mounting surface cannot be found, fabricate a flat panel,
mount the unit to it, and mount that
panel to the vehicle
First, temporarily remove the Phillips side screws from the
unit as shown.
DVD player
WARNING!
CAUTION!
Next, use these screws to attach the mounting brackets to the
unit. Depending on the installation location, you will orient
them either up or down.
Finally, attach the mounting brackets to the mounting surface
in a safe and secure fashion.
R5505 15
Wiring the DVD player
Read the following precautions before wiring your system.
• Disconnect the negative battery terminal before making
any wiring connections.
• Be particularly careful where you route wires. Keep them
away from the engine, exhaust system, etc. Heat may
damage wires.
• If the fuse should blow, make sure all connections are
correct and no wires are damaged before replacing the
fuse. Always use fuses that are the same amperage value
as the original. When replacing a fuse, never let the battery
side touch any metal part or any other wire.
Power Harness Connections
Wire Color Codes
Note: Connect
using proper fusing
with 3A fuses.
Yellow
+12V Constant power
Red
+12V Accessory
Black
- Ground
Not all Rosen and Rosen/necvox products
use identically-wired four-pin power
harnesses! ONLY use the four-pin power
harness supplied with this unit! Use of any
other four-pin harness may cause failure
NOT covered by the manufacturer’s
warranty!
16 R5505
WARNING!
Wire side of Power Connector
Red
+12V Accessory
Yellow
+12V
Constant
Power
Black
- Ground
Rear Panel Connections
Four-pin
three-wire
power
harness
connector
External
IR sensor
input
Video output
(yellow)
Left and right
audio output
(white = left,
red = right)
Coaxial digital
output
TV
antenna
input
(R5505
only)
R5505 17
SETUP
TYPICAL SETUP AND CONFIGURATION
The DVD player is very flexible. For more advanced setting
options, please see the “Setup Options List” at the end of this
section.
The unit is shipped with the following configuration:
• Standard 4:3 aspect ratio format output
• Automatic NTSC/PAL output switching
• Analog stereo audio, digital audio output off
• All language options set to English
• Parental control off, and default password of 3308.
Changing Settings
The following sections explain how to customize various
features of the DVD player.
To change settings:
1 Press [SETUP].
2 Use the [
3 Press the [ENTER] button to confirm your selection.
If you try to perform an action that is not permitted (such as
accessing the Preferences menu while a disc is playing), the
on-screen display will use the following symbol:
] and [ ] buttons to highlight a selection.
SETUP MENU -- MAIN PAGE
GENERAL SETUP
SPEAKER SETUP
AUDIO SETUP
PREFERENCES
EXIT SETUP
18 R5505
Changing the Aspect Ratio Mode
To change the aspect ratio mode, select GENERAL, and then
select TV DISPLAY. For widescreen (16:9) monitors, select
WIDE. For standard monitors and letterbox viewing (black
bars on the top and bottom of the screen, but the entire image
preserved), select NORMAL/LB. For standard 4:3 monitors
and a full-screen image, but with the edges variably cropped
to fit (“pan-and-scan” mode), select NORMAL/PS.
- - GENERAL PAGE - -
TV DISPLAY
OP MODE
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
NORMAL/PS
NORMAL/LB
WIDE
Changing the Video Output Mode
To change the video output mode, select PREFERENCES,
and then select TV TYPE. The default is MULTI. If you experience problems playing a PAL disc on your NTSC monitors,
select NTSC. If you are using European-spec PAL monitors
exclusively , select PAL.
- - PREFERENCES PAGE - -
TV TYPE
SUBTITLE
AUDIO
SUBTITLE
DISC MENU
LOCALE
PARENTAL
MULTI
NTSC
PA L
MAIN PAGE
Note:
• The default “MULTI” will automatically output NTSC video from
NTSC discs, and PAL video from PAL discs. Many video monitors
can automatically handle either type of video signal. NTSC is the
North American standard, and the only type of disc many North
American users will encounter.
R5505 19
Concealing the “Angle Mark”
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANG
MAIN PAGE
OFFOFF
- - GENERAL PAGE - -
ON
CAPTIONSCAPTIONS
SCR SAVER
ANGLE MARK
ON
To display or conceal the “angle mark,” which appears during
scenes that support the multiple-viewing-angle feature, select
GENERAL and ANGLE MARK.
- - GENERAL PAGE - -
TV DISPLAY
PIC MODE
20 R5505
ANGLE MARK
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
ON
OFF
Activating Captions and Subtitles
To enable or disable captions or subtitles, select GENERAL
and CAPTIONS.
Note:
• If CAPTIONS is set to OFF , the [SUBTITLE] button will be defeated
from working. If SUBTITLE OFF is selected under Preferences –
Audio, then the [SUBTITLE] button can still enable subtitles during
playback, as long as CAPTIONS is set to ON.
Activating the Digital Output
To turn on the digital output, select AUDIO and AUDIO OUT.
Note:
• Only enable the digital output when a digital audio processor is
in use, since enabling it disables the analog audio output on the
red and white RCA jacks. Note that some digital audio processors will require you to select an LPCM output frequency.
-- AUDIO SETUP --
AUDIO OUT
OP MODE
DUAL MONO
DYNAMIC
PRO LOGIC
LPCM OUT
MAIN PAGE
ANALOG
SPDIF/RAW
SPDIF/PCM
Selecting an LPCM Output Frequency
To select an LPCM output frequency (when a digital audio
processor is in use), select AUDIO and LPCM OUTPUT.
-- AUDIO SETUP --
AUDIO OUT
OP MODE
DUAL MONO
DYNAMIC
PRO LOGIC
LPCM OUT
MAIN PAGE
LPCM 48K
LPCM 96K
R5505 21
Deactivating the “Smart Nav” On-Screen Menu Display
TV DISPLAY
PIC MODE
ANGLE MARK
OSD LANGOSD LANG
MAIN PAGE
- - GENERAL PAGE - -
ENGLISHENGLISH
CHINESE
CAPTIONS
SCR SAVER
To play MP3 discs without the “Smart Nav” on-screen menu
display, select PREFERENCES, then SMART NAV.
- - PREFERENCES PAGE - -
AUDIO
SUBTITLE
DISC MENU
LOCALE
PARENTAL
22 R5505
PASSWORD
SMART NAV
DEFAULTS
MAIN PAGE
NO MENU
WITH MENU
Changing Language Settings
Several language settings can be customized on the R5505.
Notes:
• Not all language settings are supported by all discs.
• The languages supported by the DVD player vary by individual
option setting.
T o change the on-screen display language, select GENERAL and OSD LANG.
T o change the soundtrack language, select PREFERENCES
SMAR
MAIN P
GERMAN
DISC MENU
ENGLISH
and AUDIO.
T o change the disc menu language, select PREFERENCES
and DISC MENU.
- - PREFERENCES PAGE - -
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
AUDIO
SUBTITLE
DISC MENU
LOCALE
PARENTAL
PASSWORD
SMART NAV
DEFAULTS
MAIN PAGE
To change the subtitle or caption language, select PREFERENCES and SUBTITLE.
- - PREFERENCES PAGE - -
AUDIO
SUBTITLE
DISC MENU
LOCALE
PARENTAL
PASSWORD
SMAR
T NAV
DEFAULTS
MAIN P
AGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
GERMAN
ITALIAN
- - PREFERENCES PAGE - -
AUDI O
SUBTITLE
DISC MENU
LOCALE
PARENTAL
PASSWORD
SMART NAV
DEFAULTS
MAIN PAGE
ENGLISH
FRENCH
SPANISH
CHINESE
JAPANESE
GERMAN
ITALIAN
R5505 23
Setup Options List
The factory default options are given in bold type.
GENERAL PAGE
TV DISPLA Y: NORMAL/PS, NORMAL/LB, WIDE.
PIC MODE: AUTO, HI-RES, N-FLICKER
ANGLE MARK: ON, OFF
OSD LANG: ENGLISH, CHINESE
CAPTIONS: ON, OFF
SCRN SA VER: OFF, ON
SPEAKER SETUP
DOWNMIX: LT/RT, STEREO
AUDIO SETUP
AUDIO OUTPUT : ANALOG, SPDIF/RAW , SPDIF/PCM
OP MODE: LINE OUT, RF REMOD
DUAL MONO: STEREO, L-MONO, R-MONO, MIX-MONO
DYNAMIC: OFF to FULL (eight steps)
PRO LOGIC: OFF, ON, AUT O
24 R5505
(AUDIO SETUP CONTINUED)
LPCM OUTPUT : LPCM 48K, LPCM 96K
PREFERENCES PAGE
TV TYPE: MULTI, NTSC, P AL
AUDIO: ENGLISH, FRENCH, SPANISH, CHINESE,
JAPANESE
SUBTITLE: ENGLISH, FRENCH, SPANISH, CHINESE,
JAP ANESE, OFF
DISC MENU: ENGLISH, FRENCH, SPANISH, CHINESE,
JAPANESE
LOCALE: CHINA, FRANCE, HONG KONG , JAP AN,
TAIWAN, GBR, USA
PARENTAL: OFF
PASSWORD: 3308
SMART NAV: ON, OFF
DEFAULTS: RESTORE FACTORY SETTINGS
TROUBLESHOOTING
SPECIFICA TIONS
“Tinny” sound or low-level sound.
Check the Volume setting.
Check the “Downmix” setting in the SETUP menus and
ensure that it is set to “Stereo,” not “LT/RT.”
No sound
Check the Mute function on the remote control.
Is the Analog audio output turned off? Check the Setup Menu
under Audio, Audio Out. Using the Digital output defeats the
Analog audio output.
Picture distorts, “rolls”, appears black and white.
Check that the TV Type setting is correct for the monitors
being used. PAL video often “rolls” on NTSC monitors.
With a widescreen 16:9 monitor, I have black bars on the
top and bottom of my screen.
Change the TV Display mode to “Wide.”
Supply voltage: 12V DC Nominal, 1 1-16V operating voltage*
Temperature: 0
o
to 50o Celsius*
Current consumption: Less than 2A
Video:
T elevision System: NTSC/P AL
Aspect ratio: 4:3, 16:9
TV encoder resolution: 10-bit DA converter
Video Signal level: 1V peak-to-peak
Discs played:
DVD video discs—
5“ (12 cm) single-sided, single and double-layer
3“ (8 cm) single-sided, single and double-layer
Compact discs (CD-DA, VIDEO-CD, CD-R)—
5“ (12 cm) disc
3“ (8 cm) disc
Audio output level: 2V RMS @1kHz
Audio signal output characteristics:
Frequency response: 48khz sampling : 4Hz~22khz
96khz sampling : 4Hz~44khz
* Note: Use of the R5505 or R5506 beyond the safe operating ranges
listed can cause temporary or permanent damage to the unit, and such
damage may not covered by the manufacturer’s warranty.
R5505 25
26 R5505
www.rosenentertainment.com
866-GO ROSEN
Please read this entire document carefully
before operating or installing this unit.
Loading...
