Rosen Entertainment Systems DS-VW0710VW User Manual

Installation Guide

NOTICE OF INTENDED INSTALLATION AND USE

THE ROSEN MULTI-MEDIA NAVIGATION SYSTEMS CONTAIN AN INTERNAL VIDEO PLAYER, WHICH IS

NOT INTENDED FOR VIEWING BY THE DRIVER. THE VIDEO PLAYER IS DISABLED WHEN THE VEHICLE

IS IN MOTION THROUGH A CONNECTION TO THE PARKING BRAKE.

THE INSTALLER OF THIS PRODUCT MUST INSURE THE VIDEO DISABLE CONNECTION IS

WORKING PROPERLY PRIOR TO DELIVERY OF THE VEHICLE.

IMPROPER INSTALLATION COULD DISTRACT THE DRIVER OR INTERFERE WITH SAFE OPERATION OF

THE VEHICLE, WHICH COULD RESULT IN SERIOUS INJURY OR DEATH, AND COULD ALSO VIOLATE

STATE AND/OR FEDERAL LAW.

ROSEN ENTERTAINMENT SYSTEMS DISCLAIMS ANY LIABILITY FOR ANY BODILY INJURY OR

PROPERTY DAMAGE THAT MAY RESULT FROM ANY IMPROPER OR UNINTENDED INSTALLATION

AND/OR USE.

CAUTION

STOP

Damage to the vehicle may occur

Do not proceed until process has been completed

CAUTION

Process must be carefully observed in order to reduce

the risk of damage to the accessory or vehicle

CRITICAL

Process must be carefully observed in order to ensure a

quality installation

TOOLS and EQUIPMENT

Specific tools and equipment recommended for this

process

SAFETY RISK

Observe safe practices, this process can be dangerous

and there is a risk of personal injury

TESTING and TROUBLESHOOTING

Content specific testing and troubleshooting points

DS-VW0710 VW Series

Installation Guide VW Series

PREPARING FOR THE INSTALLATION

Before you start, please read these critical steps below

STEP

BEFORE YOU START THE INSTALLATION,

READ THIS GUIDE!

VISIT

Rosen Dealer Central

For the latest Updates, Corrections and Technical Tips

about this product and installation

www.

RosenDealerCentral

.com

CHECK THE BATTERY

Test the battery voltage to make sure it’s fully charged

This only takes seconds and can save hours of

troubleshooting later.

TURN THE VEHICLE

OFF

Keep the Vehicle Off during the installation to avoid setting

various Vehicle Faults

Keep the Vehicle OFF during the

installation

Failure to follow this may cause the AIRBAG FAULT

SENSOR to become enabled. Dealer Service

Departments charge a significant fee to reset the Fault

Sensor.

Page 2

Installation Guide VW Series

REMOVE THE FACTORY RADIO

You will need to remove multiple interior trim components prior to removing the factory radio.

The following steps will help guide you through this process.

STEP

Remove Upper Dash/Vent Trim

Use a thin pry tool to carefully lift the Upper grill. Use

Caution, the plastic is fragile and excess force can break

or damage trim

Remove the Inner Trim / Vent Components

Remove 3 x T-20 Torx screws to release the inner Trim /

Vent components.

Remove the Radio Surround Trim

Remove 2 x T-20 Torx screws to release Radio Surround

Trim

CAUTION

Remove the Radio Mounting Screws

Remove 4 x T-20 Torx screws to release the radio

Remove OEM Radio from Dash and

Unplug Factory Harness

Carefully slide the radio out, and release the main

connector block and antenna connectors

CAUTION

Page 3

Installation Guide VW Series

LOCATING REMOTE COMPONENTS

You will need to mount the GPS and Optional Satellite Radio Antennas on the exterior of the

vehicle. And mount the iPod Interface Connector in the vehicle. The following steps will help guide

you through this process.

Use Caution around SRS Components

It is the installer’s responsibility

equipment in the vehicle is NOT adversely affected by

installation of this system. Ensure that the routing of the

harnesses do NOT obstruct airbags, SRS or other safety

devices.

to ensure that the safety

STEP

Mount the GPS and Sat Radio antenna in a

location on the exterior of the Vehicle

Route the GPS harness away from other power harnesses in the

vehicle.

This will help to ensure optimum performance of the GPS

system.

Install the iPod interface connector in a

location accessible to the end-user

Locate the iPod interface module in an area which can be

serviced in the future.

The iPod cable is intended to be a serviceable item, which plugs

into the iPod/Sat radio Interface Module.

INSTALL THE ROSEN NAVIGATION SYSTEM

You will need to prepare the Rosen Navigation System for installation in the vehicle.

STEP

Remove the DVD Transport Screws

There are 2 x Phillips Transport Screws which protect the DVD

Mechanism during transportation.

Transport Screws must be removed prior to installation.

Page 4
