Rosemount Analytical 3300HT, 3300HTVP Specifications
Product Data Sheet
00813-0100-3300, Rev AA
September 2019
Rosemount™ 3300HT/3300HTVP, 3400HT/
3400HTVP, and 3500P/3500VP
PERpH-X™ High Performance pH/ORP Sensors
A sensor design that is flexible to meet your demanding pH/ORP needs
Rosemount PERpH-X sensors are versatile sensors suited to meet a number of difficult application
requirements. Thse high performance sensors are ideal for use in high temperature and high pressure
processes and feature a wide array of options to solve your pH/ORP measurement needs.
Overview
Extended application flexibility
September 2019
■
Selectable reference electrolytes allow sensors to be used in
a large number of applications.
■
Electrolyte options include:
— High temperature: most suitable for use in highly acidic,
basic, or oxidative solutions and high temperature
applications.
— Bio-film resistant: inhibits the growth of bacteria and
algae.
— Poisoning resistant: most suitable for use in processes
containing sulfides, mercaptans, and cyanides.
— Oil resistant: aimed for use in applications where light
oils and greases can foul a sensor.
— Scaling resistant: targets applications where the
precipitation of calcium magnesium salts like gypsum or
water hardness coat over the electrode.
— Metal resistant: most suitable for use in applications
where chloride in the reference electrode would react
with the process.
Minimal maintenance and lower total cost of ownership
■
A long lasting rebuildable reference junction and electrolyte
extends sensor life and allows sensors to be easily rebuilt
where normally other sensors would have to be replaced.
■
SMART preamplifier allows automatic recognition of pH
sensors by Rosemount™ transmitters: 1066, 1057, 1056,
and 56.
■
pH calibration data is stored, which allows sensors to be
calibrated in advance for "plug and play" installations in the
field.
Versatile mounting options to meet your installation requirements
■
Ryton body sensors feature 1-in. MNPT front and rear facing process threads.
■
Titanium body sensors offered in 21-in. (533,4 mm) and 36-in. (914,4 mm) lengths suitable for use with retraction assemblies.
Contents
Overview........................................................................................................................................................................................... 2
Ordering information........................................................................................................................................................................ 3
Specifications.................................................................................................................................................................................... 8
Dimensional and installation drawings............................................................................................................................................ 10
Accessories......................................................................................................................................................................................25
2 Emerson.com/Rosemount
September 2019
■
Variopol (VP8) cable connection option, for quick cable-to-sensor release, eliminates cable twisting.
Ordering information
Rosemount™ PERpH-X™ High Performance pH/ORP sensors feature various sensor body options.
Figure 1: Rosemount 3500P pH/ORP
Sensor
Table 1: Rosemount 3300HT Ordering Information
Option Description
3300HT pH/ORP sensor - PERpH-X High Performance
Measuring electrode
10 GPHT hemi pH glass, 0-14 pH
12 ORP
O-ring material
30 EPDM O-rings
31 Viton
32 Kalrez
Sensors are available in a chemically resistant Ryton plastic body (Rosemount 3500P/
3500VP) or titanium tube housing (Rosemount 3300HT/3300HTVP/3400HT/
3400HTVP). Emerson constructs Rosemount 3500P/3500VP sensors with front and
rear facing 1-in. MNPT threads for insertion or submersion type installations.
Rosemount 3300HT/3300HTVP/3400HT/3400HTVP sensors must be used with a
process connector allowing for various insertion depths. These titanium body sensors
also have extended sensor length options allowing installation through a ball valve
assembly. Sensors feature a Teflon reference junction and a Pt-100 resistance
temperature device (RTD) for temperature compensation. Rosemount PERpH-X
pH/ORP sensors are available with either an integral cable connection or Variopol
(VP8) connector. Variopol cables sold separately (see Accessories).
®
®
Cable
02 Without preamplifier, 15-ft. (4,6 m) cable
07 Without preamplifier, 4-ft. (1,2 m) cable
08 Without preamplifier, 10-ft. (3 m) cable
Calibration and conformance certificates - optional level
CC Certificate of Calibration (no test data given)
LC Loop Calibration Certificate (sensor and transmitter calibrated together, with test
data)
EC Electronic Calibration Certificate (sensor calibrated against factory instrument, with
test data)
Q1 Certificate of Conformance
Note
The Rosemount 3300HT pH/ORP sensor is housed in a titanium tube with a replaceable reference junction and refilliable reference
electrolyte. The sensor includes a Pt-100 temperature compensator. The sensor is available with a standard 15-ft. (4,6 m) cable.
You can mount the sensor using a process connector, ordered separately. You can also order junction box kits with preamplifiers
separately if the transmitter does not have an integral preamplifier within 15-ft. (4,6 m) of the sensor.
Rosemount PERpH-X 3
Table 2: Rosemount 3300HTVP Ordering Information
Option Description
3300HTVP pH/ORP sensor - PERpH-X High Performance with Variopol connector
Measuring electrode
10 GPHT hemi pH glass, 0-14 pH
12 ORP
O-ring material
30 EPDM
31 Viton
32 Kalrez
Preamplifier option
_ No selection
70 SMART preamplifier (for use with -10 only)
Calibration and conformance certificates - optional level
CC Certificate of Calibration (no test data given)
September 2019
LC Loop Calibration Certificate (sensor and transmitter calibrated together, with test
data)
EC Electronic Calibration Certificate (sensor calibrated against factory instrument, with
test data)
Q1 Certificate of Conformance
Note
The Rosemount 3300HTVP Sensor is available with an integral Variopol (VP 8.0) connector. A mating Variopol connector cable is
required for use with these sensors. SMART preamplifier (-70) is the standard preamplifier option.
Table 3: Rosemount 3400HT Ordering Information
Option Description
3400HT pH/ORP sensor - PERpH-X High Performance Retractable
Measuring electrode
10 GPHT hemi pH glass, 0-14 pH
12 ORP
Sensor length
21 21-in. (533,4 mm) titanium tube
25 36-in. (914,4 mm) titanium tube
O-ring material
30 EPDM
31 Viton
32 Kalrez
Options
61 9.5-in. (241,3 mm) cable without BNC (for preamplifier options)
4 Emerson.com/Rosemount
September 2019
Table 3: Rosemount 3400HT Ordering Information (continued)
Option Description
62 15-ft. (4,6 m) cable without BNC
07 Without preamplifier, 4-ft. (1,2 m) cable
08 Without preamplifier, 10-ft. (3 m) cable
Calibration and conformance certificates - optional level
CC Certificate of Calibration (no test data given)
LC Loop Calibration Certificate (sensor and transmitter calibrated together, with test
data)
EC Electronic Calibration Certificate (sensor calibrated against factory instrument, with
test data)
Q1 Certificate of Conformance
Note
The Rosemount 3400HT High Temperature pH/ORP Retractable Sensor is housed in a titanium tube for use with a ball valve (order
separately). You can mount the sensor with a ball valve or a process connector, both ordered separately.
Table 4: Rosemount 3400HTVP Ordering Information
Option Description
3400HTVP pH/ORP sensor - PERpH-X Retractable/Variopol Connector
Measuring electrode
10 GPHT hemi pH glass, 0-14 pH
12 ORP
Sensor length
21 21-in. (533,4 mm) titanium tube
25 36-in. (914,4 mm) titanium tube
O-ring material
30 EPDM
31 Viton
32 Kalrez
Preamplifier option
_ No selection
70 SMART preamplifier (for use with -10 only)
Calibration and conformance certificates - optional level
CC Certificate of Calibration (no test data given)
LC Loop Calibration Certificate (sensor and transmitter calibrated together, with test
data)
EC Electronic Calibration Certificate (sensor calibrated against factory instrument, with
test data)
Q1 Certificate of Conformance
Rosemount PERpH-X 5
September 2019
Note
The standard Rosemount 3400HTVP is offered with an integral Variopol connector.
Table 5: Rosemount 3500P Ordering Information
Option Description
3500P pH/ORP sensor - PERpH-X Insertion/Submersion
Electrolyte selection
BF Bio-film resistant
HT High temperature
MR Metal resistant
OR Oil resistant
PR Poisoning resistant
SR Scaling resistant
Preamplifier/cable
01 SMART integral preamplifier, 25-ft. (7,6 m) for Rosemount 1056, 1057, 1066, 56,
5081, 6081, and Xmt. (Standard preamp if used with ORP)
02 Without integral preamplifier, 15-ft. (4,6 m) cable
03 SMART preamplifier, 33-ft. (10 m) cable (standard preamp if used with ORP)
04 SMART preamplifier, 50-ft. (15,2 m) cable (standard preamp if used with ORP)
05 SMART preamplifier, 66-ft. (20 m) cable (standard preamp if used with ORP)
06 SMART preamplifier, 100-ft. (30,5 m) cable (standard preamp if used with ORP
07 Without preamplifier, 4-ft. (1,2 m) cable
08 Without preamplifier, 10-ft. (3 m) cable
Measuring electrode type
10 GPHT hemi pH glass, 0-14 pH
12 ORP
Reference type
21 Double junction reference
O-ring material
30 EPDM
31 Viton
32 Kalrez
Calibration and conformance certificates - optional level
CC Certificate of Calibration (no test data given)
LC Loop Calibration Certificate (sensor and transmitter calibrated together, with test
data)
EC Electronic Calibration Certificate (sensor calibrated against factory instrument, with
test data)
Q1 Certificate of Conformance
6 Emerson.com/Rosemount
September 2019
Note
The Rosemount 3500P Sensor is a versatile sensor platform for measuring pH or ORP. The rugged Ryton body and rebuildable
reference electrode with front and rear facing 1-in. MNPT threads allows use in either insertion or submersion applications.
Table 6: Rosemount 3500VP Ordering Information
Option Description
3500P pH/ORP sensor - PERpH-X Insertion/Submersion
Electrolyte selection
BF Bio-film resistant
HT High temperature
MR Metal resistant
OR Oil resistant
PR Poisoning resistant
SR Scaling resistant
Preamplifier/cable
01 SMART integral preamplifier, 25-ft. (7,6 m) for Rosemount 1056, 1057, 1066, 56,
5081, 6081, and Xmt. (Standard preamp if used with ORP)
02 Without integral preamplifier, 15-ft. (4,6 m) cable
Measuring electrode type
10 GPHT hemi pH glass, 0-14 pH
12 ORP
Reference type
21 Double junction reference
O-ring material
30 EPDM
31 Viton
32 Kalrez
Calibration and conformance certificates - optional level
CC Certificate of Calibration (no test data given)
LC Loop Calibration Certificate (sensor and transmitter calibrated together, with test
data)
EC Electronic Calibration Certificate (sensor calibrated against factory instrument, with
test data)
Q1 Certificate of Conformance
Note
The Rosemount 3500VP uses a mating Variopol cable (purchased separately). The sensor is offered with six different gel
electrolytes to match the application.
Rosemount PERpH-X 7
Specifications
Table 7: Percent Linearity over pH Range
pH range HT series
0 to 2 pH 94%
2 to 12 pH 99%
12 to 13 pH 97%
13 to 14 pH 92%
Table 8: Rosemount 3300HT/3300HTVP pH/ORP Sensor Specifications
Measurement range
pH 0 to 14
ORP -1500 to +1500 mV
Operating temperature
Without preamplifier 41 to 311 °F (5 to 155 °C)
September 2019
With preamplifier Up to 212 °F (100 °C)
Storage temperature
14 to 138 °F (-10 to 70 °C)
Maximum process pressure
400 psig (2859 kPa [abs])
CRN rating 200 psig at room temperature
Wetted materials
Titanium, Ryton, Teflon™, glass, and user-specified O-ring matieral (EPDM, Viton®, or Kalrez®)
Reference electrode
Double junction with replaceable process side electrolyte and Teflon junction
Temperature sensor
Pt-100 resistance temperature device (RTD)
Process connections
Must use 1-in. compression process connector (PN 23166-00 or 23166-01)
Cable length
4 to 15 ft. (1,2 to 4,6 m) integral cable (Rosemount 3300HT) or VP8 cable for Rosemount 3300HTVP (sold separately)
Weight/shipping weight
1 lb./2 lb. (0,5 kg/0,9 kg)
Table 9: Rosemount 3400HT/3400HTVP pH/ORP Sensor Specifications
Measurement range
pH 0 to 14
ORP -1500 to +1500 mV
8 Emerson.com/Rosemount
September 2019
Table 9: Rosemount 3400HT/3400HTVP pH/ORP Sensor Specifications (continued)
Operating temperature
Without preamplifier 41 to 311 °F (5 to 155 °C)
With preamplifier Up to 212 °F (100 °C)
Storage temperature
14 to 138 °F (-10 to 70 °C)
Maximum process pressure
400 psig (2859 kPa [abs])
CRN rating 200 psig at room temperature
Maximum pressure at retraction or insertion
21-in. (533,4 mm) length 64 psig (542 kPa [abs])
36-in. (914,4 mm) length 35 psig (343 kPa [abs])
Wetted materials
Titanium, Ryton, Teflon, glass, and user-specified O-ring matieral (EPDM, Viton, or Kalrez)
Reference electrode
Double junction with replaceable process side electrolyte and Teflon junction
Temperature sensor
Pt-100 resistance temperature device (RTD)
Process connections
Must use 1-in. compression process connector (PN 23166-00 or 23166-01). Can be inserted through a ball valve.
Cable length
4 to 15 ft. (1,2 to 4,6 m) integral cable or options 9.5-in. (241,3 mm) for use with sensor head junction box (Rosemount 3400HT)
VP8 cable for Rosemount 3400HTVP (sold separately)
Weight/shipping weight
1 lb./2 lb. (0,5 kg/0,9 kg)
Table 10: Rosemount 3500P/3500VP pH/ORP Sensor Specifications
Measurement range
pH 0 to 14
ORP -1500 to +1500 mV
Temperature range
41 to 248 °F (5 to 120 °C)
Storage temperature
14 to 122 °F (-10 to 50 °C)
Maximum process pressure
100 psig (790 kPa [abs])
CRN rating 40 psig at room temperature
Rosemount PERpH-X 9
Loading...
