INTRODUCTION
The Phoenix, Net Safety’s latest flame detection product, is a triple spectrum
IR fire detector designed to respond to infrared radiation emitted by a wide
range of hydrocarbon based fires.
The three IR sensors allow the Phoenix to extend detector range, reduce the
number of detectors required, produce substantially fewer false alarms and
draw less power than many other products on the market.
The Phoenix is suitable for indoor and outdoor applications and has been
tested and proven reliable in extreme environmental conditions including
heavy rain.
LOCATE DETECTOR
When positioning fire detectors, consider such factors as distance from the
fire, type of fuel and temperature, as well as any environmental factors which
may influence the detector’s response to radiation.
Typical applications
automotive-manufacturing and paint spray booths
aircraft hangars (commercial and military)
offshore platforms, refineries, pipelines and production ships
printing industry facilities
oil, gas and petrochemical refineries/production/storage/off
loading/shipping
various production, processing and storage facilities
munitions handling
warehouses (flammable liquids/toxic gases) and tank farms
(floating/non-floating)
power generation pumps, generators and unmanned stations
Potential Fire Sources
The following are examples of some potential fire sources:
Potential Inhibitors
A potential inhibitor is anything located between the detector and a potential
fire source which could prevent the Phoenix from detecting a fire or reduces
its sensitivity to fire. Possible inhibitors include but are not limited to the
following:
Solid objects such as machinery, glass or plexiglass between the detector
and potential fire source
Excess water, fog, rain, dirt or dust on the detector’s window or heavy
smoke between the detector and potential fire source
Immune
The Phoenix exhibits excellent immunity to many conditions/activities
including but not limited to the following:
hot body radiation
sunlight (direct/reflected)
arc welding radiation
lightning
artificial lighting
water surface flicker
water/rain on the lens
MAN-0072 Rev 05 IR3S-XX-X 5
January 16, 2013
Net Safety Monitoring Inc
Response Testing
Fuel
Size
Distance
(ft/m)
Average Response
Time (Seconds)
n-Heptane
1' x 1'
100/30.5
1.74
Methane
36" Plume
110/33.5
4.4
Methanol
1' x 1'
105/32
9.8
Ethanol
1' x 1'
90/27.4
1.6
Field of View Testing
Fuel
Size
Horizontal
Degrees
Vertical
Degrees
n-Heptane
1' x 1'
100 (+50, -50)
100 (+50, -50)
Methane
36"
Plume
90 (+45, -45)
90 (+45, -45)
Methanol
1' x 1'
90 (+45, -45)
90 (+45, -45)
Ethanol
1' x 1'
90 (+45, -45)
90 (+45, -45)
Distance and Field of View
Distance (ft/m)
Horizontal Degrees
Vertical Degrees
200/61
70(+35,-35)
70(+35,-35)
Sensitivity
The practical application distance is directly related to the intensity of the IR
radiation source.
Table 1: Summary of Distances(FM Performance Tested)
NOTE: The response time is based on zero time delay and maximum
sensitivity.
Field of View (As per FM and NFPA definition)
The area in front of a flame detector, where a standardized flame can be
detected and which is specified by distance and angle off the central axis, is
the Field of View. The referenced flame is moved to 50% of the maximum
on-axis detection distance and then moved off-axis horizontally and
vertically to the limit of detection. These off-axis angle limits specify Field
of View.
Table 2: Field of View Testing (FM Performance Tested)
NOTE: Data based on Maximum Sensitivity Setting.
Sensitivity Setting Considerations
For practical planning purposes, the “Low” sensitivity setting results
in a reduction of sensitivity of approximately 30%. Net Safety has
determined through flame testing that the difference in sensitivity will
vary between approximately 23% and 35%, using the “Low”
sensitivity setting as compared to the “High” sensitivity setting,
depending on the fuel type, environmental conditions and the
individual detector. See ‘System Sensitivity’ and Table 8 when
determining settings.
Table 3: Distance and Field of View
Note: The data in table above is not FM Performance verified.
Installation Considerations
The following should be considered when mounting the Phoenix.
Point detector toward where the flame is expected.
Ensure an unobstructed view of the area to be monitored.
Employ more than one detector to ensure the hazard is fully covered.
Mount the detector a few feet (about 1 metre) below the ceiling so it
can respond before being blocked by smoke accumulation at the
ceiling.
If dense smoke is likely to accumulate prior to flame (as in an
electrical fire), supplement IR detector(s) with other protection such
as Net Safety Monitoring Airborne Particle Monitor.
The detector should be accessible for cleaning.
MAN-0072 Rev 05 IR3S-XX-X 6
January 16, 2013
Net Safety Monitoring Inc
Tilt detector downward a minimum of 10 to 20° to reduce dirt and
dust accumulation which could obscure the detector’s viewing
window.
Securely mount detector so as to minimize vibration.
Detector sensitivity may be reduced by heavy fog, rain /or ice on the
lens.
Consider shortening the time delay settings when dense smoke is
expected to accumulate before or during a fire (refer to "System
Sensitivity").
Reduce sensitivity setting if false alarms, related to surrounding
activities, occur (refer to "System Sensitivity").
If a detector is located close to an intense flickering IR source, the
detector’s sensitivity may be affected.
When installed near or on water (such as an off shore platform), be
sure to take into account the low horizon level when tilting detector
downward.
For protection against induced power disturbances, it is required to
install detector wires in a braided flexible conduit, grounded and less
than 5 feet to the junction box.
UNPACK
Figure 1: Detector and Swivel Mount
Carefully remove all components from the packaging. Check components
against the enclosed packing list and inspect all components for obvious
damage such as broken or loose parts.
If you find any components missing or damaged, notify the representative or
Net Safety Monitoring immediately.
MAN-0072 Rev 05 IR3S-XX-X 7
January 16, 2013
Net Safety Monitoring Inc
Figure 2: Dimensional Drawing
FIELD INSTALLATION
WARNING:
• Wiring codes and regulations may vary. Compliance with
regulations is the responsibility of the installer. Wiring must
comply with applicable regulations relating to the installation of
electrical equipment in a hazardous area. If in doubt, consult a
qualified official before wiring the system.
• This equipment is only suitable for ATEX Category 2 (Zone 1)
locations.
• Equipment must be installed in compliance with EN 60079-14.
• The permanently connected cable need appropiate protection of
the free end of the cable. Use an ATEX certified Junction Box
• Do not open the housing and expose the electronics in a
classified area (Do not open when an explosive atmosphere may
be present)
• The area must be de-classified prior to opening housing.
• The parts of the bushing outside the flameproof enclosure have
to be protected from mechanical impact by means of Ex
components(e.g.Enclosure, Thread adapters, Conduit)
MAN-0072 Rev 05 IR3S-XX-X 8
January 16, 2013
Wiring
For protection against induced power disturbances, it is required to install
detector pig tail lead wires in a braided flexible conduit less than 5 feet in
length to the termination box. From the termination box to the power supply
the recommended detector cable is four conductor (or greater), shielded 18
AWG rated 300 V for distances up to 150 feet. When cable is installed in
conduit, the conduit must not be used to support wiring to other electrical
equipment. Detectors can be located over 150 feet and up to 2000 feet if 16
AWG shielded conductor is used. The maximum distance between the
detector and the power supply is limited by the resistance of the connecting
wiring, which is a function of the gauge of the wire being used. Refer to
Net Safety Monitoring Inc
“Appendix B, Resistance Table (Ohms)". The unterminated wires must be
terminated in a suitable certified ATEX enclosure or fitting.
Grounding
An external ground is required. The flame detector must also be connected to
an ATEX certified junction Box to ensure adherence to safety conditions. If
the junction box is non-metallic, the external ground must be provided by
some other means.
Sealing
Water-proof and explosion-proof conduit seals are always recommended to
prevent the accumulation of moisture within the junction box. Seals should
be located as close to the device as possible and not more than 18 inches
(46 cm) away. Explosion-proof installations may require an additional seal
where conduit enters a non-hazardous area. When pouring a seal, use a fibre
dam to ensure proper formation of the seal. Seals should never be poured at
temperatures below freezing.
The jacket and shielding of the cable should be stripped back to permit the
seal to form around the individual wires. This will prevent air, gas and water
leakage through the inside of the shield and into the enclosure.
It is recommended that explosion-proof drains and conduit breathers be used.
Changes in temperature and barometric pressure can cause 'breathing' which
allows moist air to enter the conduit. Joints are seldom enough to prevent this
'breathing'.
CONNECTING
The Phoenix can be either an Analog, Analog/Digital, Relay or Digital
model. Refer to the following tables for specifics regarding connections for
the various models. A termination junction box can be also be supplied by
Net Safety if required.
WARNING: Prior to wiring, ensure power is disconnected. Improper
wiring can cause damage to the detector.
Non-Isolated and Isolated Power Configuration (IR3S-A or
IR3S-AD only)
For current source using Non-Isolated configuration, the jumper must remain
in the default INT position. The jumper is placed in the EXT position for
current sink using Non-isolated configuration.
If a separate power supply is used (Isolated configuration) to isolate current
output, the jumper must be placed in the EXT position for source and sink.
See Figure 3 and Figure 4.
MAN-0072 Rev 05 IR3S-XX-X 9
January 16, 2013
Net Safety Monitoring Inc
INT
EXT
Figure 3: Current Output Jumper Placement
Figure 4: Current Source and Sink
Note the INT and EXT Jumper position for each configuration.
MAN-0072 Rev 05 IR3S-XX-X 10
January 16, 2013
Net Safety Monitoring Inc
FLAME DETECTOR WIRE CODING
Wire
Colour
Function
Green
Earth Ground (GND)
Red
Vdc (+)
Black
Com (-)
Purple
Isolated Power (+) (ISO)
Yellow
4-20mA Signal Output
FLAME DETECTOR WIRE CODING
Wire
Colour
Function
Green
Earth Ground (GND)
Red
Vdc (+)
Black
Com (-)
Orange
Alarm Relay
Orange
Alarm Relay
Violet
Fault Relay
Violet
Fault Relay
WARNING: If terminations are being done in a Net Safety Multi-Purpose Junction Box, refer to MAN-0081 for specific terminal designations.
Note: When using a Analog unit (IR3S-A) with the Analog/Relay Junction Box (JB-IR3SAR-A/S), the external magnet can be used to reset the
junction box latched alarm . See MAN-0081 for instructions.
WARNING: Analog units use the purple wire (Terminal Marked ISO) to isolate the current output when using a separate power supply.
Also see Figure 3 – Current Output Jumper Placement (for IR3S-A or IR3S-AD only).
Table 4: Wire Colour Coding — IR3S-A-X (ANALOG)
Table 5: Wire Colour Coding — IR3S-R-X (RELAY)
MAN-0072 Rev 05 IR3S-XX-X 11
January 16, 2013
Net Safety Monitoring Inc
FLAME DETECTOR WIRE CODING
Wire
Colour
Function
Green
Earth Ground (GND)
Red
Vdc (+)
Black
Com (-)
Blue
A (Communication)
Brown
B (Communication)
Purple
Isolated Power (+) (ISO)
Yellow
4-20mA Signal Output
FLAME DETECTOR WIRE CODING
Wire
Colour
Function
Green
Earth Ground (GND)
Red
Vdc (+)
Black
Com (-)
Blue
A (Communication)
Brown
B (Communication)
NOTE: Up to 254 Modbus units can be included in the chain. An End of Line Resistor (120-150 Ohms) MUST be included between the A and B
Terminals in the last junction box.
Table 6: Wire Colour Coding—IR3S-AD-X (ANALOG / DIGITAL)
Table 7: Wire Colour Coding — IR3S-D-X (DIGITAL)
MAN-0072 Rev 05 IR3S-XX-X 12
January 16, 2013
Net Safety Monitoring Inc
DETECTOR SETUP
SYSTEM SENSITIVITY
Important Fire Sensitivity Considerations
The desired fire performance standard is to always respond quickly to a real
fire and never respond to a false alarm condition. The best performance is
obtained through user adjustments to meet the specific application
conditions.
Some applications such as the interior of a storage warehouse may have very
little infrared or thermal activity and therefore allow the use of full sensitivity
and low time delay settings.
Applications exposed to intense sunlight reflected from metallic surfaces or
water, hot process bodies, exhaust pipes and flare stacks, may require custom
combinations of sensitivity and time delay settings.
It is recommended that initial settings be low sensitivity and 5 second time
delay. If false alarms occur, change the time delay to 10 seconds. If false
alarms continue, consult the factory for other recommendations, such as
Field of View restrictor.
If there are no false alarms after a trial period at the above settings and it is
important to alarm on very small or distant fires, then change sensitivity
setting to high. If there are still no false alarms and an alarm response to
short term transient fire conditions is required, reduce time delay to 3
seconds.
A time delay of zero can only be considered in very controlled applications
where instantaneous response is necessary and if there is a tolerance for
possible false alarms.
Time Delay Settings of 3, 5 and 10 seconds
The time delay setting defines the length of time that a fire signal must be
continuously present for the detector to output a fire alarm. After the fire has
persisted for the set delay time, the alarm output will occur within 5 seconds.
This secondary delay of up to 5 seconds is not user adjustable.
Sensitivity Setting
The adjustable Sensitivity setting is used to optimize the Phoenix for a
particular application.
When selecting Low or High Sensitivity, consider the following:
- Size of potential fire
- Distance between possible fire and detector
- Type of flammable substance to be detected
- Environmental factors
Response time can vary depending on the intensity and type of fire.
See Table 8 for Time Delay and Sensitivity settings.
DIP Switch Access
DIP Switches are used to define various functional settings and are located
on the internal electronics module of the Phoenix. Simply slide a DIP Switch
to the ON or OFF position (as marked in Figure 5). Also refer to Table 8 for
DIP Switch positioning instructions.
WARNING: Do not open the fire head in a classified area. The area
must be de-classified prior to opening the fire head. ATEX approved
products have a locking collar that requires a 2 mm hex key to open. When
open, keep water away from electronics.
WARNING: Do not touch internal components other than the DIP
Switches (refer to Appendix A, Electrostatic Sensitive Device (ESD).
MAN-0072 Rev 05 IR3S-XX-X 13
January 16, 2013
Net Safety Monitoring Inc
DIP Switch #1
Time Delay
Sensitivity settings
Position 1
Position 2
Position 3
Sensitivity
0 Seconds
ON
ON
ON
High
3 Seconds
ON
OFF
OFF
Low (default)
5 Seconds(default)
OFF
ON
10 Seconds
OFF
OFF
DIP Switch #2
DIP
Setting
Relay Coil Status
Alarm
Position 2
OFF
Normally Energized
Fire
ON
Normally De-energized (factory default)
Relay
The Relay Phoenix uses two sets of DIP Switches.
DIP Switch #1 is used for defining Sensitivity and Time Delay.
DIP Switch #2 is used for defining the Relay setting; it is only available for
relay models and only position 2 is used. See Tables 8 and 9.
Analog
The analog (no relays) Phoenix uses only DIP Switch #1 to define Sensitivity
and Time Delay settings. Refer to Table 8 for dip switch positioning
instructions.
Figure 5: DIP Switch Location
Table 8: Sensitivity and Time Delay Settings (DIP Switch #1)
Note: Default settings are 5 second Time Delay and Low Sensitivity.
RELAY SETTINGS ( IR3S-R ONLY)
Coil Status Setting
The Fire relay can be set to Normally Energized or Normally De-energized
using DIP Switch #2, Position 2. Refer to Table 9.
NOTE: The Fault relay is fixed as Energized and both relays are fixed as
Non-Latching.
Table 9: Relay Setting (Dip Switch #2)
Note: The above figure is a general representation of the IR3S selectable DIP
Switch positions.
MAN-0072 Rev 05 IR3S-XX-X 14
January 16, 2013
Relay Contact Setting
The Fire and Fault relay contacts can be selected as Normally Open or
Normally Closed using Jumpers. Simply position the Jumper over two of the
pins to define the Normally Open/Closed Fire or Fault relay contacts (refer to
Figure 6 and Table 10 for settings).
Net Safety Monitoring Inc
Jumper Position
Function
Pin 1 & 2
Normally closed (NC)
Pin 2 & 3
Normally Open (NO) (factory default)
Relay State
Unpowered
Powered
Alarm
(FIRE)
Energized/NO
OPEN
CLOSED
OPEN
Energized/NC
CLOSED
OPEN
CLOSED
De-energized/NO
OPEN
OPEN
CLOSED
De-energized/NC
CLOSED
CLOSED
OPEN
Relay State
Unpowered
Powered
Alarm
(FAULT)
Energized/NO
OPEN
CLOSED
OPEN
Energized/NC
CLOSED
OPEN
CLOSED
Converter
Detector
A
Blue wire
B
Brown wire
Gnd
Black wire
A+
Red wire
shown in Normally Open position
shown in Normally Open position
Figure 6: Normally Open or Normally Closed Jumpers.
Note each jumper default position based on the IR3S orientation above.
Table 10: Relays Contact
Table 11: Fire Alarm Relay States
Table 12: Fault Alarm Relay States
MODBUS RTU ( IR3S-D & AD)
Install Phoenix PC Set Up Software
In order to program various settings required for the Modbus RTU protocol,
user-interface software is required.
The software is available for download at:
http://www.net-safety.com/resources/nsm_phoenix_setup.zip
1. Go to the web address given above. Save the file on your desktop,
and then extract the file.
2. Double click on Setup.exe and run the Phoenix set up software to
install it; the Setup Wizard will guide the user in completing the
install. A shortcut will then be placed on the desktop.
WARNING: An RS-232 to RS-485 converter is required to
communicate with the detector and perform Modbus set up. An external
power supply (12 V or 24 V depending on the converter used) is required to
power up the detector during Modbus set up.
Table 13: Wiring for Modbus Detector Set Up
MAN-0072 Rev 05 IR3S-XX-X 15
January 16, 2013
Net Safety Monitoring Inc
Baud rate 4800bps
Baud rate 9600bps
Baud rate 14.4kbps
Baud rate 19.2kbps (default)
Baud rate 28.8kbps
Baud rate 38.4kbps
Baud rate 57.6kbps
DIP Switch #1
Modbus RTU Setting
Position 4
ON
Confirm address set up once power recycled
OFF
Reset Node Address (default is Address 1)
Note: On the Analog /Digital model (AD), ignore the yellow and purple
wires for set up.
Table 14: Available Baud Rates
Note: Baud rate 2400 is not available at this time.
Modbus Set Up
A node address must be assigned and a baud rate specified for each Phoenix
in the chain, one at a time. The baud rate is set using the Phoenix Set Up
software; the address is also set using this software and a DIP Switch must be
used to confirm the address assignment.
The Modbus Phoenix uses DIP Switch #1, Position 4 to confirm the address
assignment for each detector (refer to Table 15 for detailed information).
Table 15: Digital Modbus RTU Setting (DIP Switch #1, Position 4)
1. Ensure Position 4 of DIP Switch #1, is set to OFF.
2. Connect a Phoenix using a RS-232 to RS-485 Converter.
3. Start the Phoenix Modbus Set Up program.
4. Set up the computer communication by selecting a Port and Baud Rate
under the PC Settings at the bottom of the screen.
5. Click on the Connect button at the bottom of the screen (the button will
then change to "Connected").
6. Click on the Get Current Settings button (if necessary, make a note of
existing settings).
7. The message OK should appear under Modbus Communication Status.
8. Under Phoenix Settings enter the new Node Address for the detector.
9. Select the Baud Rate for the detector (refer to Table 14).
10. Click on the Update button under the Phoenix Settings.
11. The message OK should appear under Modbus Communication Status.
12. Close Phoenix Modbus Set UP software (close connection).
13. Turn off power to the detector.
14. Move Position 4 of DIP Switch #1, to the ON position (this will
confirm the address set up).
15. Turn on power to the detector and repeat for all detectors in the chain.
Note: Each time a change is made to the RTU setting (DIP #1, Position 4),
power to the detector must be cycled.
TIP: Make a note of the newly assigned Node Address for each unit.
MAN-0072 Rev 05 IR3S-XX-X 16
January 16, 2013
Net Safety Monitoring Inc
Figure 7: Phoenix Modbus Set Up
Get Current Setting
Click to display the current Modbus set up of the connected Phoenix.
Modbus Set Up Failure/Reset
If the Modbus Set Up fails or the connected Phoenix is not recognized (the
message Failed will appear under Modbus Communication Status when the
Connect button is pressed), the connected detector needs to be reset.
DETECTOR FUNCTIONALITY
Figure 8: Detector Viewing Window
START UP PROCEDURE
1. Turn off power to the unit.
2. Move DIP Switch #1, Position 4 to OFF.
3. Turn on power to the unit.
4. The connected device(detector) returns to default Node Address 1.
5. Repeat the Modbus Set Up process.
Once powered up, the Phoenix begins a start up routine. The three Blue
LEDs are Solid, and the Green LED Flashes. After approximately 30 seconds
the Blue LEDs will turn off and the Green LED will turn solid, indicating
normal operation. During start up, the current output is 3.0 mA for
approximately 30 seconds at which time the unit begins normal operation and
current output increases to 4.0 mA.
MAN-0072 Rev 05 IR3S-XX-X 17
January 16, 2013
Net Safety Monitoring Inc
Condition
Current Output
No Power Fault
0 mA
VI Test Failure - VI Testing (Warning)
2.0 mA
Start delay/Start up
3.0 mA
Normal Operation
4.0 mA
Warning – Infrared Activity
16 mA
Fire Alarm
20 mA
LED
Status
IR Sensor LEDs
Colour Condition LEDs
Blue 1
LED
Blue 2
LED
Blue 3
LED
Green
LED
(Power)
Red
LED
(Alarm)
Yellow
LED
(Fault)
Power
up >30
second
start
delay
Solid
Solid
Solid
Flashing
off
off
Normal
operation
off
off
off
Solid
off
off
VI Test
failure
Flashing
Flashing
Flashing
Solid
off
Flashing
VI Test
OK
off
off
off
Solid
off
off
Warning-
Infrared
Activity
Flashing
Flashing
Flashing
Solid
off
off
Fire
Alarm
Solid
Solid
Solid
Solid
Solid
off
MONITOR
The Detector’s status can be determined by monitoring the current output and
the IR Sensor LEDs or Coloured Condition LEDs. Refer to Tables 16 and 17.
Condition Status—Current Output
The following table defines the current output status for the Phoenix during
various detector conditions.
Table 16: Current Output Status
Condition Status—LEDs
There are six (6) LEDs used to indicate the status and condition of the
detector.
Table 17: Status LEDs
MAN-0072 Rev 05 IR3S-XX-X 18
January 16, 2013
Net Safety Monitoring Inc
RTUfire_powerup
0x0001
0000 0000 0000 0001B
Power up delay
RTUfire_vi_fault
0x0002
0000 0000 0000 0010B
Failed self test
RTUfire_normal
0x0004
0000 0000 0000 0100B
Fire heads normal
operation
RTUfire_fault
0x0008
0000 0000 0000 1000B
Fire heads fault
RTUfire_warning
0x0040
0000 0000 0100 0000B
Infrared activity
RTUfire_alarm
0x0080
0000 0000 1000 0000B
Fire Alarm
Table 18: RTU Status (Register 40001) Read Only
Automatic Digital Zoom (ADZ)
If a fire is located at an extreme distance, the infrared characteristics may not
be at levels needed for accurate detection. If the sensor data acquired is
weak, the Automatic Digital Zoom (ADZ) will increase the gain of the sensor
amplifiers until the sensors can measure the infrared characteristics of the
fire. The three detection wavelengths have been specifically selected to
ensure the greatest degree of fire recognition with the least amount of false
fire detection.
MAN-0072 Rev 05 IR3S-XX-X 19
January 16, 2013
Net Safety Monitoring Inc
TESTING
Automatic Visual Integrity (VI) Test
To evaluate the cleanliness of the lens and verify the function of the detection
circuits, the Phoenix performs an automatic Visual Integrity (VI) test every 3
minutes.
If accumulation of material on the surface of the lens reaches a factory
calibrated preset level, which could substantially reduce flame detection
sensitivity, the Phoenix will transmit a VI fault signal indicating that the
cause of the fault should be investigated and, if necessary, the window
cleaned. Refer to Table 19 for fault types and possible solutions.
Note: Unusual heavy oil accumulations may not be easily detected by the
internal VI Test, but are easily identified by an observer during regular
inspections.
MAINTAIN
Monitoring the VI fault signal is only part of the necessary routine to ensure
the safe operating condition of the detector. If conditions exist, whereby
foreign materials could accumulate on the detector’s lens, maintenance
routines should include regular visual inspection of the detector and cleaning
when necessary, by qualified personnel.
Clean The Window/Lens
WARNING: Always bypass Alarm Output and disconnect external
response equipment when performing cleaning and maintenance tasks.
When cleaning the window/lens, use the cloth and the cleaning solution
provided with the detector. Use only the cleaning solution provided, as some
cleaners may leave a residue or film that blocks IR radiation.
O-ring
The rubber o-ring on the detector housing is used to ensure the detector is
watertight. The housing should be opened periodically and the o-ring
inspected for breaks, cracks or dryness. To test the o-ring, remove it from the
detector housing and stretch it slightly. If cracks are visible, the o-ring should
be replaced. If it feels dry to the touch, a thin coating of lubricant should be
applied (such as polyalphaolefin grease). When re-installing the o-ring, be
sure that it is properly seated in the groove on the housing.
The o-ring must be properly installed and in good condition to prevent water
from entering the detector and causing failure. The life expectancy of rubber
o- rings varies depending on the type and amount of contaminants present in
the area. The person who maintains the system must rely on experience and
common sense to determine how frequent the rings should be inspected. A
coating of lubricant should also be applied to the enclosure threads before
reassembling the detector to help prevent moisture from entering.
MAN-0072 Rev 05 IR3S-XX-X 20
January 16, 2013
Net Safety Monitoring Inc
Current O/P
Green
Yellow
Red
Blue 1
Blue 2
Blue 3
Possible Problem
Possible Solution
0 mA
Off
Off
Off
Off
Off
Off
Faulty power supply/ wiring
or failure of electronic
component(s).
Check wiring, check power supply. Consult factory
0 mA
On
Off
Off
Off
Off
Off
Shorted signal output/ faulty
wiring or failure of electronic
component(s).
Check current loop wiring. Verify that the unit is
IR3S-A or IR3S-AD. Consult factory.
2.0 mA
Solid
Flashing
Off
Flashing
Flashing
Flashing
VI (visual integrity) fault;
dirty lens, obstruction, failed
IR source or sensor.
Clean Lens (use Net Safety Monitoring Lens
cleaner only) Check IR source bulbs; they should
be on every 3 minutes to indicate a VI test.
Simulate a fire test to verify sensors are operational.
Phoenix Modbus Set Up Software Error Messages
Wr Failed
Wrong COM port or Baud
rate selected for
System/Detector
communication
DIP Switch improperly set
Change the COM port or Baud rate
(refer to " Modbus Set Up " )
Ensure DIP #1, Position 4 is set to OFF
(refer to " Modbus Set Up”)
Failed
Wrong COM port or Baud
rate selected for Computer
Change the COM port or Baud rate
(refer to “ Modbus Set Up Failure/Reset”)
TROUBLE SHOOT
The occurrence of a fault condition may be due to various factors. In order to determine the possible cause of the problem, keep accurate records of these
occurrences including time, date, weather conditions, activities in area, etc. See the table below for possible solutions.
Table 19: Possible Problems and Solutions
MAN-0072 Rev 05 IR3S-XX-X 21
January 16, 2013
Net Safety Monitoring Inc
HOW TO RETURN EQUIPMENT
A Material Return Authorization number is required in order to return
equipment. Please contact Net Safety Monitoring at (403) 219-0688 before
returning equipment or consult our Service Department to possibly avoid
returning equipment.
If you are required to return equipment, include the following information:
1. A Material Return Authorization number (provided over the phone to
you by Net Safety).
2. A detailed description of the problem. The more specific you are
regarding the problem, the quicker our Service department can determine
and correct the problem.
3. A company name, contact name and telephone number.
4. A Purchase Order, from your company, authorizing repairs or request for
quote.
5. Ship all equipment, prepaid to:
Net Safety Monitoring Inc
2721 Hopewell Place NE
Calgary, Alberta, Canada
T1Y 7J7
6. Mark all packages: RETURN for REPAIR
Waybills, for shipments from outside Canada, must state:
Equipment being returned for repair
All charges to be billed to the sender
Also, please ensure a duplicate copy of the packing slip is enclosed inside the
box indicating item 1-4 along with the courier and account number for
returning the goods.
All Equipment must be Shipped prepaid. Collect shipments will not be
accepted.
Pack items to protect them from damage and use anti-static bags or
aluminum- backed cardboard as protection from electrostatic discharge.
MAN-0072 Rev 05 IR3S-XX-X 22
January 16, 2013
Net Safety Monitoring Inc
Appendix A:
ELECTROSTATIC SENSITIVE DEVICE (ESD)
Electrostatic discharge (ESD) is the transfer, between bodies, of an
electrostatic charge caused by direct contact or induced by an electrostatic
field.
The most common cause of ESD is physical contact. Touching an object can
cause a discharge of electrostatic energy—ESD! If the charge is sufficient
and occurs near electronic components, it can damage or destroy those
components.
In some cases, damage is instantaneous and an immediate malfunction
occurs. However, symptoms are not always immediate—performance may
be marginal or seemingly normal for an indefinite period of time, followed
by a sudden failure.
To eliminate potential ESD damage, review the following guidelines:
Handle boards by metal shields—taking care not to touch electronic
components
Wear grounded wrist or foot straps, or ESD shoes or heel grounders to
dissipate unwanted static energy
Prior to handling boards, dispel any charge in your body or equipment
Ensure components are transported and stored in static safe packaging
When returning boards, carefully package in the original carton and static
protective wrapping
In general, exercise accepted and proven precautions normally observed
when handling electrostatic sensitive devices.
A warning label is placed on the packaging, identifying product using
electrostatic sensitive semiconductor devices.
Ensure ALL personnel are educated and trained in ESD Control
Procedures
MAN-0072 Rev 05 IR3S-XX-X 23
January 16, 2013
Net Safety Monitoring Inc.
Appendix B:RESISTANCE TABLE (OHMS)
MAN-0072 Rev 05 IR3S-XX-X 24
January 16, 2013
Net Safety Monitoring Inc
Models:
IR3S-A (Analog)
I3RS-R (Relay)
IR3S-AD (Analog/Digital)
Operating Voltage
10 to 32 VDC measured at the detector
Power Consumption
(@ 24Vdc)
Nominal 30mA/ 0.72W
Maximum 64mA/ 1.44W
De-Energized: Nominal 39mA/0.96W. Maximum 73mA/ 1.68W
Energized: Nominal- 51mA, =1.20w). Maximum- 86mA, 2.16W
Nominal 30mA/ 0.72W
Maximum 64mA/ 1.44W
Power Consumption
(@ 12Vdc)
Nominal 45mA/ 0.60W
Maximum 113mA/ 1.32W
De-Energized: Nominal- 66mA/0.84W. Maximum- 138mA/ 1.68W
Energized: Nominal- 93mA, =1.08w)
Maximum- 165mA, 2.04W
Nominal 45mA/ 0.60W
Maximum 113mA/ 1.32W
In Rush Current
(at 24Vdc)
Up to 2.6 A for 2.ms (varies with power supply)
Output
0 to 20 mA – Into a max loop
impedance of 800Ohms @
32Vdc or 150Ohms @ 11.0Vdc.
Non-Isolated loop supply
Normally open/Normally closed contacts rated for 5A @ 30Vdc/125Vac.
Selectable energized/ de-energized Fire relay. Fault relay fixed as energized and
both Fire & Fault relays fixed as non-latching
0 to 20 mA – Into a max loop
impedance of 800Ohms @ 32Vdc or
150Ohms @ 11.0Vdc. Non-Isolated
loop supply.
RS-485 RTU Modbus protocol.
Field of View
FM Performance tested: 100° horizontal / 100° vertical @ 50% of the on-axis detection distance for N-Heptane. See Table 2 for more information.
70° horizontal / 70° vertical at a distance of 200ft. ( Not FM Performance tested) See Table 3.
Spectral Range
The IR3S fire detector measures at three distinct Infrared Wavelengths
Time Delay
DIP switch selectable 0, 3, 5, 10 seconds,
Sensitivity Settings
Two (2) adjustable setting via DIP switch (High/Low)
Temperature/ RH
FM Certified (-40°C to +75°C / -40°F to 167°F). Operational (-50°C to +75°C / -58°F to 167°F). 0 – 95% RH non condensing
Metallurgy & IP/Nema
Ratings
Aluminum or SS316 (factory sealed housing). IP66 and NEMA 4X
Weight (with swivel)
2.1Kg /4.5lbs (SS316 Option @ 3.4Kg/ 7.5lbs)
Approvals
Performance certified to: Class3260, ANSI/NEMA 250, and IEC60529.
0575 II2G, EEx d II B+H2 T5
Appendix C:SPECIFICATION
NOTE: Performance certified by FM with maximum sensitivity setting and zero second time delay.
MAN-0072 Rev 05 IR3S-XX-X 25
January 16, 2013
Net Safety Monitoring Inc
False Alarm Immunity
False Alarm Source
Distance
(ft/m)
Modulated
Unmodulated
Sunlight direct
--------
No Alarm
No Alarm
Sunlight indirect
--------
No Alarm
No Alarm
Arc Welder
10/3.0
No Alarm
No Alarm
1500 Watt heater
10/3.0
No Alarm
No Alarm
40 Watt Fluorescent Lights
10/3.0
No Alarm
No Alarm
500 Watt Halogen Light
10/3.0
No Alarm
No Alarm
250 Watt Incandescent Light
10/3.0
No Alarm
No Alarm
250 Watt Sodium Vapor Lamp
10/3.0
No Alarm
No Alarm
70 Watt Sodium Vapor Lamp
10/3.0
No Alarm
No Alarm
250 Watt Metal Halide Lamp
10/3.0
No Alarm
No Alarm
Response Testing w/ Un-modulated False Alarm Stimuli Present
False Alarm Source
False Alarm Source Distance (ft/m)
Fire Source
Fire Source Distance (ft/m)
Sunlight direct
---------------
16" Propane Plume
25/7.62
Sunlight indirect
---------------
16" Propane Plume
25/7.62
Arc Welding
10/3.0
16" Propane Plume
25/7.62
1500 Watt heater
10/3.0
16" Propane Plume
25/7.62
40 Watt Fluorescent Lights
10/3.0
16" Propane Plume
25/7.62
500 Watt Halogen Light
10/3.0
16" Propane Plume
25/7.62
250 Watt Incandescent Light
10/3.0
16" Propane Plume
25/7.62
250 Watt Sodium Vapor Lamp
10/3.0
16" Propane Plume
25/7.62
70 Watt Sodium Vapor Lamp
10/3.0
16" Propane Plume
25/7.62
250 Watt Metal Halide Lamp
10/3.0
16" Propane Plume
25/7.62
Appendix D:IR3S DATA
MAN-0072 Rev 05 IR3S-XX-X 26
January 16, 2013
Net Safety Monitoring Inc
Response Testing w/ Modulated False Alarm Stimuli Present
Fire Alarm Source
Distance
(ft/m)
Fire Source
Fire Source Distance (ft/m)
Sunlight direct
---------------
16" Propane Plume
25/7.62
Sunlight indirect
---------------
16" Propane Plume
25/7.62
Arc Welding
10/3.0
16" Propane Plume
25/7.62
1500 Watt heater
10/3.0
16" Propane Plume
25/7.62
40 Watt Fluorescent
Lights
10/3.0
16" Propane Plume
25/7.62
500 Watt Halogen Light
10/3.0
16" Propane Plume
25/7.62
250 Watt Incandescent
Light
10/3.0
16" Propane Plume
25/7.62
250 Watt Sodium Vapor
Lamp
10/3.0
16" Propane Plume
25/7.62
70 Watt Sodium Vapor
Lamp
10/3.0
16" Propane Plume
25/7.62
250 Watt Metal Halide
Lamp
10/3.0
16" Propane Plume
25/7.62
MAN-0072 Rev 05 IR3S-XX-X 27
January 16, 2013
Net Safety Monitoring Inc.
2721 Hopewell Place NE, Calgary, AB Canada T1Y 7J7
1-866-FIREGAS (347-3427) | ph. (403) 219-0688 | fx. (403) 219-0694
http://www.net-safety.com | Email: nsmsales@net-safety.com
PRODUCT SERVICES CONTACT INFORMATION
Telephone [ 8am - 5pm MDT ]: (403) 769-6074 | (403) 717-8219
Fax: (403) 219-0694 Email: productservices@net-safety.com
http://www.net-safety.com/service/product_services.html
Loading...
