Instruction Manual
90002496
04/2008
Instruction Manual
Platform
for NGA 2000 CLD, FID, HFID, MLT
and WCLD Analyzer Modules
1/1 19“, 3 HU Housing
rd
3
Edition 04/2008
www.EmersonProcess.com
Platform for CLD, FID, HFID, ML T AND WCLD Instruction Manual
90002496
04/2008
ESSENTIAL INSTRUCTIONS
READ THIS P AGE BEFORE PROCEEDING!
Emerson Process Management (Rosemount Analytical) designs, manufactures and test s
its products to meet many national and international standards. Because these instruments
are sophisticated technical products, you MUST properly install, use, and maintain
them to ensure they continue to operate within their normal specifications. The following
instructions MUST be adhered to and integrated into your safety program when installing,
using and maintaining Emerson Process Management (Rosemount Analytical) products.
Failure to follow the proper instructions may cause any one of the following situations to
occur: Loss of life; personal injury; property damage; damage to this instrument; and warranty
invalidation.
• Read all instructions prior to installing, operating, and servicing the product.
• If you do not understand any of the instructions, contact your Emerson Process
Management (Rosemount Analytical) representative for clarification.
• Follow all warnings, cautions, and instructions marked on and supplied with the product.
• Inform and educate your personnel in the proper installation, operation, and
maintenance of the product.
• Install your equipment as specified in the Installation Instructions of the appropriate
Instruction Manual and per applicable local and national codes. Connect all products
to the proper electrical and pressure sources.
• T o ensure proper performance, use qualified personnel to install, operate, update, program,
and maintain the product.
• When replacement parts are required, ensure that qualified people use replacement parts
specified by Emerson Process Management (Rosemount Analytical). Unauthorized parts
and procedures can affect the product’s performance, place the safe operation of your
process at risk, and VOID YOUR W ARRANTY. Look-alike substitutions may result in fire,
electrical hazards, or improper operation.
• Ensure that all equipment doors are closed and protective covers are in place, except
when maintenance is being performed by qualified persons, to prevent electrical
shock and personal injury.
The information contained in this document is subject to change without notice. Misprints
reserved.
1st Edition 06/1995 2
nd
Edition 03/1999
3rd Edition 04/2008
© 2008 by Emerson Process Management
Emerson Process Management
GmbH & Co. OHG
Industriestrasse 1
D-63594 Hasselroth
Germany
T +49 (0) 6055 884-0
F +49 (0) 6055 884-209
Internet: www.EmersonProcess.com
Rosemount Analytical
SAFETY SUMMARY S - 1
General S - 2
Gases and Gas Conditioning (Sample Handling of analyzer modules) S - 3
Supply Voltage S - 4
Instrument specific notes for the user S - 5
Additional notes for service / maintenance S - 6
Electrostatic Discharge S - 7
CONTENTS
Table of Contents
INTRODUCTION E - 1
Platform E - 1
EMC-Housing E - 1
DESCRIPTION
1. Technical Description 1 - 1
1.1 Front Panel 1 - 3
1.2 Rear Panel 1 - 4
1.3 Internal Layout 1 - 5
1.3.1 Interconnection Board ICB 01 1 - 7
1.3.2 Power Supply Unit 1 - 9
1.3.3 Line - Fan - Module (LFM 01) 1- 10
Ventilation 1 - 11
1.3.4 Controller Board ACU 02 1 - 12
1.3.5 Network Module LEM 01 1 - 13
2.
- (open)
4.
90002496(2) [NGA-Platform e] 30.03.99
i
CONTENTS
OPERATION
5. Preparation 5 - 1
5.1 Installation Site 5 - 1
5.2 External Modules 5 - 2
5.3 Installation of an Analyzer Module into the Platform 5 - 3
5.4 Installation of PCBs / Rear Mounting Modules 5 - 4
5.4.1 Rear Mounting Modules 5 - 4
5.4.2 Internal Slots (with 5 A power supply only) 5 - 4
6. Switching On 6 - 1
6.1 24 Vdc - Operation 6 - 2
Rosemount Analytical
6.2 230 / 115 Vac - Operation 6 - 2
7. Switching Off 7 - 1
8.
- (open)
10.
11. TROUBLESHOOTING 11 - 1
11.1 Instrument has no Function (LCD display is dark) 11 - 1
11.2 No Measurement Screen 11 - 2
11.3 Line - Fan - Module (LFM 01) 11 - 3
11.4 Power Supply Unit 11 - 3
11.5 Fuses 11 - 4
11.5.1 AC - Fuses 11 - 4
11.5.2 DC - Fuses 11 - 4
12.
- (open)
14.
ii
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
MAINTENANCE
15. Opening the Housing 15 - 1
15.1 Front Panel 15 - 1
15.2 Housing Cover 15 - 2
16. (open)
17. Removal / Replacement of Components 17 - 1
17.1 Removal of Analyzer Module 17 - 1
17.2 Removal / Replacement of PCBs / Rear Mounting Modules 17 - 2
17.2.1 Rear Mounting Modules 17 - 2
CONTENTS
17.2.2 Internal Slots 17 - 2
17.3 Removal / Replacement of Front Panel 17 - 3
17.4 Replacement of EPROM / Buffer Battery on the ACU 02 17 - 4
17.4.1 Removal of ACU 02 17 - 4
17.4.2 Replacement of EPROM 17 - 5
17.4.3 Replacement of Buffer Battery 17 - 6
17.4.4 Installation of ACU 02 17 - 6
18. (open)
19. Cleaning of Housing Outside 19 - 1
90002496(2) [NGA-Platform e] 30.03.99
iii
CONTENTS
20. TECHNICAL DATA 20 - 1
20.1 Platform 20 - 1
20.1.1 Housing 20 - 1
20.1.2 Environments 20 - 1
20.2 Line - Fan - Module (LFM 01) 20 - 4
20.2.1 Electrical Safety 20 - 4
20.3 Internal Power Supply Unit 20 - 5
20.3.1 5 A Power Supply 20 - 5
20.3.2 10 A Power Supply 20 - 5
Rosemount Analytical
SUPPLEMENT
21. Pin Assignments 21 - 1
21.1 24 Vdc Input (LFM 01) 21 - 1
21.2 230/115 Vac Input (LFM 01) 21 - 1
21.3 24 Vdc Output to analyzer module (internal) 21 - 1
INDEX R - 1
List of Figures R - 5
iv
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
SAFETY SUMMARY
Safety Summary
Outside and/or inside platform or at operation manual resp. different symbols gives you a hint to
special sources of danger.
Source of danger !
See Operation Manual!
GENERAL
Electrostatic Discharge (ESD) !
Explosives !
Hot components !
T oxic !
Risk to health !
Platform specific notes for the user !
In operation manual we will give partly additional informations to these symbols.
Strictly follow these instructions please !
90002496(2) [NGA-Platform e] 30.03.99
S - 1
SAFETY SUMMARY
GENERAL
Rosemount Analytical
1. General
◆ The following gener al safety precautions must be observed during all phases of operation,
service and repair of this instrument !
Failure to comply with these precautions or with specific w arnings elsewhere in this manual
violates safety standards of design, manufacture and intended use of this instrument !
Failure to comply with these precautions may lead to personal injury and damage to this
instrument !
◆ Fisher-Rosemount GmbH & Co. does not take responsibility (liability) for the customer´s
failure to comply with these requirements !
◆ Do not attempt internal service or adjustment unless other person, capable of rendering first
aid and resuscitation, is present !
◆ Because of the danger of introducing additional hazards, do not perform any unauthorized
modification to the instrument !
Return the instrument to a Fisher-Rosemount Sales and Service office for service or repair
to ensure that safety features are maintained !
◆ Instruments which appear damaged or defective should be made inoperativ e and secured
against unintended operation until they can be repaired by qualified service personnel.
S - 2
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
SAFETY SUMMARY
GENERAL / GASES AND GAS CONDITIONING (SAMPLE HANDLING)
Operating personnel must not remove instrument covers !
Component replacement and internal adjustments must be made by qualified
service personnel only !
Read all operation manuals before attempting to operate with the instrument !
Be sure to observe the additional notes, safety precautions and warnings given
in the individual operation manuals (e. g. platform, analyzer modules and
I/O-modules) !
Do not operate the instrument in the presence of flammable gases or explosive
atmosphere without supplementary protective measures !
At photometer or heated components there could be exist hot components !
2. Gases and Gas Conditioning (Sample Handling of analyzer modules)
Be sure to observe the safety regulations for the respective gases
(sample gas and test gases / span gases) and the gas bottles !
Inflammable or explosiv e gas mixtures must not be purged into the instrument
without supplementary protective measures !
To avoid a danger to the operators by e xplosive, toxic or unhealthy gas
components, first purge the gas lines with ambient air or nitrogen (N2) before
cleaning or exchange parts of the gas paths.
90002496(2) [NGA-Platform e] 30.03.99
S - 3
SAFETY SUMMARY
SUPPLY VOLTAGE
3. Supply Voltage
The socket outlet shall be installed near the equipment and shall be easily
accessible to disconnect the device from the socket outlet.
Verify whether the line voltage stated on the instrument (LFM 01) or power supply
agrees with that of your mains line!
Be sure to observe the safety precautions and warnings given by
manufacturer of pow er supply !
Rosemount Analytical
◆ NGA 2000 platform is a Safety Class 1 instrument
The platform is provided with a protective earth terminal.
T o prevent shoc k hazard, the instrument chassis and cabinet must be connected
to an electrical ground. The instrument must be connected to the AC pow er
supply mains through a three-conductor power cable, with the third wire firmly
connected to an electrical ground (safety ground) at the power outlet.
If the instrument is to be energized via an external power supply , that goes for the
power supply too .
Any interruption of the protective (grounding) conductor or disconnection of the
protective earth terminal will cause a potential shock hazard that could result in
personal injury. Deliberate disconnection is inadmissible / prohibited !
Verify that the position of input voltage switch of the 10 A power supply agrees
with that of your mains line (Fig. 20-3 and 1-4) !
Verify correct polarity for 24 V dc - operation !
S - 4
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
4. Instrument specific notes for the user
The installation site for the instrument has to be dry and remain above freezing
point at all times.
The instrument must be exposed neither to direct sunlight nor to strong sources
of heat. Be sure to observe the permissible ambient temperature !
For outdoor sites, we recommend to install the instrument in a protective cabinet.
At least, the instrument has to be protected against rain (e.g., shelter).
Free flo w of air into and out of the platform (ventilation slits) must not be hindered
by nearby objects or w alls !
SAFETY SUMMARY
INSTRUMENT SPECIFIC NOTES FOR USER
Use only from our factory optional delivered cables or equiv alent shielded cables
to be in agreement with the CE - conformity.
The customer has to guarantee, that the shield is be connected bothsided.
Shield and connectors housing have to be connected conductiv e.
Sub.-min.-D-plugs/soc kets have to be scre w ed to the analyzer.
By using of optional delivering terminal strip adapters the analyzer is not be in
agreement with the CE - conformity . In this case CE - conf ormity is to be declared
by customer as “manufacturer of system”.
90002496(2) [NGA-Platform e] 30.03.99
S - 5
SAFETY SUMMARY
ADDITIONAL NOTES FOR SERVICE / MAINTENANCE
5. Additional notes for service / maintenance
Operating personnel must not remove instrument covers !
Component replacement and internal adjustments must be made by qualified
service personnel only !
Always disconnect power, discharge circuits and remove external voltage
sources before troub leshooting, repair or replacement of any component !
Any work inside the instrument without switching off the power must be
performed by a specialist, who is familiar with the related danger, only !
Rosemount Analytical
In case of exchanging fuses the customer has to be certain that fuses of specified
type and rated current are used. It is prohibited to use repaired fuses or def ective
fuse holders or to short-circuit fuse carriers (fire hazard).
At component replacement or installation the RF shielding contacts must not be
bended !
S - 6
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
ELECTROSTATIC DISCHARGE
SAFETY SUMMARY
5.1 Electrostatic Discharge
The electronic parts of the analyzer can be irreparably damaged if exposed to electrostatic
discharge (ESD).
The instrument is ESD protected when the covers have been secured and safety precautions
observed. When the housing is open, the internal components are not ESD protected anymore.
Although the electronic parts are reasonable safe to handle, you should be a ware of the following
considerations:
Best ESD example is when you w alked across a carpet and then touched an electrical grounded
metal doorknob. The tiny spark which has jumped is the result of electrostatic discharge (ESD).
You prevent ESD by doing the following:
Remove the charge from your body before opening the housing and maintain during work with
opened housing, that no electrostatic charge can be built up.
Ideally you are opening the housing and working at an ESD - protecting workstation.
Here you can wear a wrist trap.
However, if you do not have such a workstation, be sure to do the following procedure exactly:
Discharge the electric charge from your body. Do this by touching a device that is grounded
electrically (any device that has a three - prong plug is grounded electrically when it is plugged into
a power receptacle).
This should be done several times during the operation with opened housing (especially after
leaving the service site because the movement on a low conducting floors or in the air might cause
additional ESDs).
90002496(2) [NGA-Platform e] 30.03.99
S - 7
SAFETY SUMMARY
Rosemount Analytical
S - 8
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
INTRODUCTION
Introduction
This operation manual informs you about the platform, which is used for accommodating
analyzers or analysis modules of the NGA 2000 series (19", 3 HU, IP 20-housing).
Platform
This housing, together with the operator interface and the built-in controller board ACU 02,
represents the platform for analyzers of the NGA 2000 series.
EMC-Housing
Should the housing be used as an EMC-assembly carrier for non-EMC analysis modules, please
be aware that the installation differs from the description given in this manual. The following
changes must be taken into consideration:
1. The 19" operator interf ace (chapter 1.1) will be substituted by two 1/2 19" blind front panels .
Each blind front panel can be dismounted separately by remo ving the respective screws
(6 for each panel).
2. The controller board ACU 02 (chapter 1.3.4) will be replaced by a bulkhead plate.
3. Only rear-panel modules using network can be built-in in this housing.
Modules which need the ICB-bus can not be connected, because the A CU 02 board is not
installed.
4. The operation of built-in analyzer module and any additional rear-panel modules must be
carried out via a "true-type" platform or a superior analyzer.
90002496(2) [NGA-Platform e] xx.03.99
E - 1
INTRODUCTION
Rosemount Analytical
E - 2
90002496(2) [NGA-Platform e] xx.03.99
Rosemount Analytical
TECHNICAL DESCRIPTION
1. Technical Description
The basis for analyzers of the NGA 2000 series is a 19", 3 HU housing of IP 20 protection class.
The instrument can be delivered as table top or rac k mountable unit.
The platform contains all components necessary for operating the analyzer and can be used as
a "stand alone" analysis instrument when combined with an analyzer module and an Input/Output
(I/O) module, or it can be configured as a system when equipped with sev eral analyzer and I/O
modules.
The conceptional design is depicted in the block diagram below (Fig. 1-1).
90002496(2) [NGA-Platform e] 30.03.99
Fig. 1-1: Block diagram platform design (external)
1 - 1
TECHNICAL DESCRIPTION
Rosemount Analytical
NGA standard housing contains:
◆ the front panel (84 DU, see chapter 1.1)
◆ the interconnection board ICB 01 (see chapter 1.3.1)
◆ the line-fan module LFM 01 (12 DU, see chapter 1.3.3), the power supply (see chapter 1.3.2)
and the controller board ACU 02 (see chapter 1.3.4)
◆ the network module LEM 01 for connecting the platform with external analyzer modules
(see chapter 1.3.5)
◆ 5 free slots (PCBs, 5 DU) on the rear panel, which can be assigned optionally with
“Input / Output Modules” (I/O's)
e.g. programmable I/O's: one SIO and up to 4 DIO boards
◆ 4 internal free slots (Euro cards) which can be assigned optionally (for 5 A power supply only)
AC DC
Platform
Analyzer Module
Analyzer Module
Analyzer Module
1 - 2
Network Cable
Fig. 1-1a: Analyzer system via platform (schematic diagram)
Network Cable
24VDC Cable
Power supply
24VDC Cable
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
TECHNICAL DESCRIPTION
FRONT PANEL
1.1 Front Panel
The 1/1-19" front panel (84 DU) accommodates the LCD display , accompanying front panel circuit
board AFP 01 and the keys necessary for operating the instrument (see Fig. 1-2).
For assembling and disassembling the analyz er module and for maintenance and repair, the front
panel can be swivelled out after releasing the six fastening screws, while the instrument may
remain in operation.
Footing
(table-top housing only)
Fastening screws
front panel
LCD display
F 3F 1 F 2 F 4 F 5
Softkeys
(Function depends on menu)
Cursor keys
NGA 2000
ENTER key
Mounting
(with rack mount-
able housing only)
90002496(2) [NGA-Platform e] 30.03.99
Fig. 1-2: Housing, Front View
(Front panel)
1 - 3
TECHNICAL DESCRIPTION
REAR PANEL
Rosemount Analytical
1.2 Rear Panel
The rear panel (84 DU) accommodates (see Fig. 1-3):
◆ the line-fan module LFM 01 (12 DU, see chapter 1.3.3)
◆ the network module LEM 01 for connecting the platform with external analyzer modules
(see chapter 1.3.5)
◆ 5 free slots (PCBs, 5 DU) on the rear panel, which can be assigned optionally with
“Input / Output Modules” (I/O's)
e.g. programmable I/O's: one SIO and up to 4 DIO boards
◆ the gas fittings and optional electrical connections of analyzer modules (see separately
operation manual)
Analyzer module
(optionally built-in)
Footing
Line - Fan - Module
LFM 01 (12 DU)
5 free slots for optional
rear-panel modules
(PCB's, 5 DU)
Network Module
LEM 01 (5 DU)
(table-top housing only)
Mounting (at the front)
(with rack mountable
housing only)
1 - 4
Fig. 1-3: Housing, Rear View
90002496(2) [NGA-Platform e] 30.03.99
Rosemount Analytical
TECHNICAL DESCRIPTION
INTERNAL LAYOUT
1.3 Internal Layout
The interior of the housing is divided into two 42 DU wide halves.
When looking from the front side, on the right there is the electronics with interconnection board
and printed circuit board (PCB of Euro standard format).
On the left side, there is spare room for locating an analyzer module.
Network Module
LEM 01 (5 DU)
Interconnection Board
ICB 01
Analysis module
(optionally built-in)
5 free slots for optional I/O's
(PCBs, 5 DU)
Line- Fan - Module
LFM 01 (12 DU)
5 A
Power Supply
(for MLT, TFID
analyzer modules)
Mounting
rack mountable housing
(option)
90002496(2) [NGA-Platform e] 30.03.99
4 optional internal PCBs
Retention pin of analysis module
(dependent on analysis module version)
Carrying handles
Fig. 1-4a: Internal view of housing (with 5 A power supply)
Controller Board
ACU 02
hinge
front panel
Front panel with LCD display
and AFP 01 - PCB
1 - 5
TECHNICAL DESCRIPTION
INTERNAL LAYOUT
Rosemount Analytical
Network Module
LEM 01 (5 DU)
Interconnection Board
ICB 01
Analyzer module
(optionally built-in)
5 free slots for optional I/O's
(PCBs, 5 DU)
Line- Fan - Module
LFM 01 (12 DU)
10 A
Power Supply
(for CLD, WCLD,
HFID, McFid
analyzer modules)
1 - 6
Controller Board ACU 02
Front panel with LCD display
Carrying handles
Fig. 1-4b: Internal view of housing (with 10 A power supply)
24 Vdc
to
analyzer module
Fan
hinge
front panel
and AFP 01 - PCB
90002496(2) [NGA-Platform e] 30.03.99
