1. Technical Description

The ML T 3 analyzer for suppressed ranges in the gas purity application is part of the NGA 2000
MLT family . The MLT 3 is enclosed in a 19 " housing with thermostat control (55 °C). The physical
part (photometer bench, sensors etc.) is separated from the electronic part
(see also Fig.1-3)
The ML T 3 gas analyzer for N2O, CO2 or PO2 gas purity can measure in two measuring modes:

1. absolute range: 0 - 100 % CO2/ N2O / PO2 (paramagnetic oxygen)

2. suppressed range: 95 or 98 - 100 % CO2 / N2O / PO

Suppressed ranges, like 95 or 98-100 % CO2, N2O or PO2 , are strongly influenced by pressure,
temperature, flow and ambient CO2 and water vapor. Special means are necessary to keep these
factors as constant as possible to reduce their influence on the measurement.
An internal pressure regulator, capillary , pressure, temperature and flow sensor are provided to
control flow and allow compensation for temperature and barometric pressure variations.
A special calibration procedure is necessary to achieve the requested suppressed range (see
chapter 4). Purge of the optical bench with constant CO2 and H2O is requested (0.1-0.2 l/min).
The installation of the complete analytical equipment (MLT 3 gas analyzer, sample handling
system and calibration gases [zero and span gas] ) should be in an air conditioned room or at least
in a well ventilated room to fulfill the permissible ambient temperatures (20 to 30 °C).

2

1.1 Front View

The front panel of the analyzer is the operating front panel (see Fig. 1-1).
Measured values and the entire operating procedure are displayed on a LC display. The
operation and programming of the instrument is performed by using the four cursor keys, the
ENTER key and the five soft keys (see separate ML T Software Manual).
The MLT 3 front panel for gas purity measurements is identical with the standard MLT 3 front panel.
The internal mounting is described later under "Internal Construction" (see Fig. 1-3, 1-4).

F 3F 1 F 2 F 4 F 5

NGA 2000

www.EmersonProcess.com

Fig. 1-1: MLT 3 (1/1 19" housing), front view

1 - 1

Addendum ML T 3 Gas Purity

1.2 Rear View

Network connection (RJ 45 socket)

Instruction Manual

90002929_ML T 3

12/2007

IN

Ch 1

OUT

IN

Ch 2

OUT

optional PCB [SIO/DIO e.g.]

Input 230/120 V ac (UPS 01 T)

Gas connections

Fig. 1-2a: MLT 3 (standard version), Rear view

See Figures 1-2a and 1-2b for differences between the "standard ML T 3" and the "MLT 3 for
gas purity measurement". The "ML T 3 for gas purity measurement" is equipped with a

solenoid valve block for the supply of sample, zero and span gas, which is controlled by the
analyzer. The control is done with the relay outputs of I/O Board "SIO" via an external
connection cable "SIO => Solenoid V alve Block" (pin assignments see Fig. 21-4 in the
standard ML T manual).The gas connections are shown in Fig. 1-2b and are marked specific
to the application. The outlet of the valve block is connected to the gas inlet of the ML T 3.

Sub.-min. D, 9 pole

(to Solenoid Valve Block)

NETWORK

DIGITAL I/O

Sub.-min. D, 9 pole

(connection to PCB “SIO”)

!

Inlet Pressure:
min. 20 psig
max. 25 psig

Span gas

Out (Outlet)

230/120 V

50/60 Hz

max. 240 VA

Sample gas

Purge Gas Connections

(Purge Gas Inlet & Outlet)

Purge IN

IN (Inlet)

ANALOG I/O SERIAL I/O

Zero gas

OUT (Outlet)

Purge OUT

PCB "SIO" Sample Gas Connections

Input 230/120 V ac (PS UPS 01 T) Solenoid Valve Block

(Gas Inlet & Outlet)

Fig. 1-2b: MLT 3 (gas purity measurement), Rear view

1 - 2

www.EmersonProcess.com

Instruction Manual

90002929_ML T 3
12/2007

Addendum ML T 3 Gas Purity

1.3 Internal Construction

The photometer assembly and physical parts is located on the left side (front view) while the
electronic part with interconnection board and PCBs is located on the right.

Gas connections

(Gas inlet via valve

block, gas outlet,

Purge inlet/outlet, 1/4")

Pressure

Sensor

Flow

Sensor

Heating

Unit

Solenoid valve block

(zero, span & sample gas inlet, 1/8 ")

Power Supply

(UPS 01 T)

Card cage
(electronic

boards)

Pressure
regulator

www.EmersonProcess.com

Photometer bench

(MLT 3, suppressed range)

Fig. 1-3: MLT 3 (gas purity measurement), Top view

Fan

Operating Front Panel

(MLT 3 analyzer)

1 - 3
