Instruction Manual

ETC01076
12/2002

Magnetically Operated Touch Panel

Hints on Operating CAT 100 / BINOS 100 F and
CAT 200 / MLT 2 Gas Analyzers

www.processanalytic.com

ESSENTIAL INSTRUCTIONS

READ THIS PAGE BEFORE PROCEEDING!

Rosemount Analytical designs, manufactures and tests its products to meet many national and
international standards. Because these instruments are sophisticated technical products, you
MUST properly install, use, and maintain them to ensure they continue to operate within their
normal specifications. The following instructions MUST be adhered to and integrated into your
safety program when installing, using and maintaining Fisher-Rosemount products. Failure to
follow the proper instructions may cause any one of the following situations to occur: Loss of life;
personal injury; property damage; damage to this instrument; and warranty invalidation.
Fisher-Rosemount MFG GmbH & Co. OHG must not be liable for any errors in this
documentation. As well any liability for direct and indirect damages which occur in relation to the
delivery or usage of this documentation is refused as far as accepted by law..

· Read all instructions prior to installing, operating, and servicing the product.

· If you do not understand any of the instructions, contact your Fisher­Rosemount representative for clarification.

· Follow all warnings, cautions, and instructions marked on and supplied

with the product.

· Inform and educate your personnel in the proper installation, operation,
and maintenance of the product.

· Install your equipment as specified in the Installation Instructions of the
appropriate Instruction Manual and per applicable local and national
codes. Connect all products to the proper electrical and pressure sources.

· To ensure proper performance, use qualified personnel to install, operate,

update, program, and maintain the product.

· When replacement parts are required, ensure that qualified people use
replacement parts specified by Fisher-Rosemount. Unauthorized parts and
procedures can affect the product’s performance, place the safe operation of
your process at risk, and VOID YOUR WARRANTY. Look-alike substitutions
may result in fire, electrical hazards, or improper operation.

· Ensure that all equipment doors are closed and protective covers are in
place, except when maintenance is being performed by qualified
persons, to prevent electrical shock and personal injury.

The information contained in this document is subject to change without notice.

1. edition 12/2002

Emerson Process Management

Fisher-Rosemount MFG GmbH & Co. OHG

Industriestrasse 1
D-63594 Hasselroth
Germany
T [phone]
F [phone]

http://www.EmersonProcess.com

Instruction Manual

ETC01076
12/2002

1-1 Overview

Magnetically Operated Touch Panel

SECTION 1

Introduction

Analyzers intended either to be used in
hazardous area or for outdoor usage are
provided with a magnetically operated touch
panel. This special version ensures ingress
protection (IP) and resistance against

1-2 Magnetic Touch Panel Elements

Whereas standard front panels are using keys
for operating the analyzer the magnetically
operated touch panel uses contactless
technology instead. This results in a slightly
different design:

mechanical shocks. On account of its design it
requires some special measures to operate
the corresponding analyzer in a safe manner,
so read the following instructions carefully!

Each standard panel key is replaced by a reed
relay located behind the front panel design foil.
(CAT 200, MLT 2 only: The sequence of the 4
keys at the right side has changed due to
ergonomic reasons.)

Fig. 1: CAT 100 / BINOS 100 F version

Fig. 2: CAT 200 / MLT 2 version

1-3 Accessories

To operate the magnetically operated touch
panel a special tool (actuator) is required. The

be provided together with your analyzer. If it is
missing please contact your local sales office.

following picture shows this tool as it should

Fig. 3: Magnetic actuator

Fisher-Rosemount MFG GmbH & Co. OHG A Division of Emerson Process Management 3

Fig. 4: Magnetic actuator,

view at magnets
