Rosemount Analytical
M
ODEL
P
ERCENT OXYGEN
A
NALYZER
I
NSTRUCTION MANUAL
7003M
748223-J
OTICE
N
The information contained in this document is subject to change without notice.
Manual Part Number 748223-J
December 2000
Printed in U.S.A.
Rosemount Analytical Inc.
4125 East La Palma Avenue
Anaheim, California 92807-1802
C
P
REFACE
SAFETY SUMMARY ..........................................................................................P1
SPECIFICATIONS - PERFORMANCE...............................................................P3
SPECIFICATIONS - PHYSICAL.........................................................................P3
SPECIFICATIONS - ELECTRICAL ....................................................................P4
SPECIFICATIONS - SENSORS.........................................................................P5
CUSTOMER SERVICE, TECHNICAL ASSISTANCE AND FIELD SERVICE............P6
RETURNING PARTS TO THE FACTORY.........................................................P6
TRAINING ......................................................................................................P6
DOCUMENTATION............................................................................................P6
ONTENTS
COMPLIANCES .................................................................................................P7
SECTION 1. INTRODUCTION
1.1 OVERVIEW.................................................................................................1
1.2 PRINCIPLE OF MEASUREMENT...............................................................2
1.3 SENSORS...................................................................................................2
1.4 CONDITIONS AFFECTING MEASUREMENT............................................2
1.4.1 Gas Composition ...........................................................................2
1.4.2 Sample and Cal Gas Pressures.....................................................3
1.4.3 Environmental Factors...................................................................3
1.5 FEATURES .................................................................................................3
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
i
ONTENTS
C
SECTION 2. INSTALLATION
2.1 UNPACKING............................................................................................... 5
2.1.1 Storage ..................................................................................... 5
2.2 ANALYZER INSTALLATION....................................................................... 5
2.3 SENSOR INSTALLATION .......................................................................... 5
2.3.1 Analyzer/Sensor Jumper Configuration......................................... 6
2.4 ELECTRICAL CONNECTIONS .................................................................. 7
2.4.1 Sensor Cable................................................................................. 8
2.4.2 Power Connections....................................................................... 9
2.4.3 Current Output Connections.......................................................... 10
2.4.4 Voltage Output Connections ......................................................... 11
2.4.5 Relay Contacts for Alarms or ON/OFF-Controls ........................... 13
SECTION 3. OPERATION
3.1 OVERVIEW ................................................................................................ 15
3.2 KEYPAD OPERATION ............................................................................... 15
3.2.1 Changing Parameters With The Keypad....................................... 16
3.2.2 Single and Double Keystroke........................................................ 17
3.2.3 Display Prompts............................................................................ 18
3.2.4 Error Messages............................................................................. 20
3.2.5 Automatic Return to RUN Mode.................................................... 21
3.2.6 Preventing Unauthorized Access .................................................. 21
3.2.7 Sensor Equilibrium........................................................................21
3.3 START-UP.................................................................................................. 22
3.3.1 Initial Power-Up............................................................................. 22
3.3.2 System Restart.............................................................................. 23
3.3.3 Automatic Restart - Due to Power Failure..................................... 23
3.3.4 Manual Restart.............................................................................. 23
3.4 RUN MODE................................................................................................. 24
3.4.1 Display Oxygen Concentration/Sensor Temperature.................... 24
3.4.2 Acknowledge Alarms..................................................................... 24
3.4.3 Access Other Modes..................................................................... 24
3.5 SETUP MODE ............................................................................................ 25
3.5.1 Security Code................................................................................ 27
3.5.2 Current Output Range - 0-20mA or 4-20mA .............................. 27
3.5.3 Range Endpoint Adjustments........................................................ 27
3.5.4 Zero Offset Adjustment ................................................................. 29
3.6 ALARM MODE VS. ON/OFF-CONTROL MODE........................................30
3.6.1 Relay Configured as Alarm ........................................................... 30
3.6.2 Relay Configured as ON/OFF-Controller....................................... 30
3.6.3 Relay Contacts.............................................................................. 32
ii
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
3.6.4 Fail Safe Operation........................................................................32
3.6.5 Relay Reset Upon Fatal Error........................................................32
3.6.6 Pressure Effects on Alarms ...........................................................32
3.6.7 Setting Alarm and ON/OFF-Controller Relays...............................32
3.6.8 Setting Alarm Setpoints .................................................................32
3.6.9 Setting Alarm ON and OFF Levels ................................................33
SECTION 4. CALIBRATION AND ADJUSTMENTS
4.1 FREQUENCY OF CALIBRATION...............................................................35
4.2 CALIBRATION MODE.................................................................................35
4.2.1 Zero Calibration .............................................................................35
4.2.2 Span Calibration............................................................................36
4.2.3 Pressure Compensation - Correction for Constant Pressure
Differences....................................................................38
4.3 HOLD MODE...............................................................................................39
4.4 DIAGNOSTICS MODE................................................................................42
4.4.1 Raw Sensor Voltage......................................................................42
4.4.2 Test Current Output.......................................................................43
4.4.3 Linearizing Current Output.............................................................43
4.4.4 Test Alarm Relays..........................................................................45
ONTENTS
C
4.5 ADJUSTMENTS AND SETTINGS...............................................................46
S
ECTION
5.1 PRINCIPLES OF OPERATION...................................................................47
5.2 EFFECTS OF SAMPLE CONDITIONS.......................................................47
5.3 CIRCUIT DESCRIPTIONS.......................................................................... 49
S
ECTION
5. T
5.1.1 Electrochemical Theory.................................................................47
5.2.1 Barometric Pressure......................................................................47
5.2.2 Humidity ......................................................................................47
5.2.3 Sample Temperature.....................................................................48
5.2.4 Interfering Gases...........................................................................48
5.3.1 Signal Board..................................................................................49
5.3.2 Power Supply Board......................................................................49
5.3.3 Microprocessor Board....................................................................49
5.3.4 Alarm Circuits.................................................................................50
6. R
HEORY
OUTINE SERVICING AND TROUBLESHOOTING
6.1 ROUTINE SERVICING................................................................................51
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
iii
ONTENTS
C
6.2 TROUBLESHOOTING................................................................................ 51
6.2.1 Symptoms..................................................................................... 51
SECTION 7. REPLACEMENT PARTS
7.1 CIRCUIT BOARD REPLACEMENT POLICY.............................................. 53
7.2 REPLACEMENT PARTS - MODEL 7003M................................................ 53
7.3 REPLACEMENT PARTS - SENSORS ....................................................... 54
7.3.1 Rechargeable Sensors.................................................................. 54
7.3.2 Disposable Sensors ...................................................................... 55
G
ENERAL PRECAUTIONS FOR HANDLING
& S
TORING HIGH PRESSURE CYLINDERS
WARRANTY
F
IELD SERVICE AND REPAIR FACILITIES
FIGURES
2-1. Sensor Ordering Matrix.............................................................................. 6
2-2. Model 7003M Rear Panel Connections..................................................... 7
2-3. Power Jumpers and Fuses........................................................................ 10
2-4. Current Output Connections...................................................................... 12
3-1. Model 7003M Front Panel Controls and Indicators .................................... 15
3-2. Model 7003M Operation Flow Diagram ..................................................... 16
3-3. SETUP Mode Flowchart............................................................................ 26
3-4. Security Access Routine Flowchart............................................................28
3-5. ALARM Mode Flowchart............................................................................ 31
3-6. Action of Alarm Relay ON and OFF Setpoints........................................... 33
4-1. CALIBRATION Mode and PRESSURE COMPENSATION Flowchart....... 37
4-2. HOLD and DIAGNOSTICS Modes Flowchart............................................ 42
iv
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
TABLES
2-1. Sensor Cables............................................................................................8
2-2. Analyzer Cable Connections......................................................................8
3-1. Key Functions.............................................................................................17
3-2. Display Indicators.......................................................................................17
3-3. Security Access Prompts and Responses..................................................18
3-4. Alarm Settings Prompts and Responses....................................................18
3-5. Calibration Prompts and Responses..........................................................18
3-6. System Setup Prompts and Responses.....................................................18
3-7. System Hold and Diagnostics Codes.........................................................19
3-8. Data Displayed in DIAGNOSTICS Mode....................................................19
3-9. Miscellaneous Prompts and Responses....................................................19
3-10. Power ON, Reset Diagnostics Errors (Fatal Errors) .................................20
3-11. RUN Mode Errors (Non-Fatal Errors).......................................................20
3-12. Signal Board Errors..................................................................................20
3-13. Microprocessor Errors That Reset The System .......................................20
3-14. Default Settings at Power-Up...................................................................23
3-15. RUN Mode Key Functions........................................................................24
3-16. SETUP Mode Key Functions...................................................................25
3-17. ALARM Mode Key Functions..................................................................30
3-18. Alarm Relay Contact Positions/Terminal Locations..................................32
4-1. CALIBRATION Mode Key Functions.........................................................35
4-2. Composition of Dry Atmospheric Air...........................................................36
4-3. Composition of Humid Atmospheric Air......................................................36
4-4. Barometric Pressure Effect on Apparent Oxygen Concentration ...............38
4-5. PRESSURE COMPENSATION Mode Key Functions...............................38
4-6. HOLD Mode Key Functions.......................................................................39
4-7. Caret Readings ..........................................................................................40
4-8. DIAGNOSTICS Mode Key Functions........................................................42
ONTENTS
C
D
RAWINGS
652542 Outline and Mounting - Panel Mount
652543 Outline and Mounting - Wall Mount
652544 Outline and Mounting - Pipe Mount
652682 Pictorial Wiring Diagram
652683 Interconnect Diagram
652699 Installation Drawing
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
v
ONTENTS
C
NOTES
vi
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
P
REFACE
S
AFETY SUMMARY
To avoid explosion, loss of life, personal injury and damage to this equipment and
on-site property, all personnel authorized to install, operate and service the Model
7003M Percent Oxygen Analyzer should be thoroughly familiar with and strictly follow
the instructions in this manual. Save these instructions.
DANGER is used to indicate the presence of a hazard which will cause severe
personal injury, death, or substantial property damage if the warning is ignored
WARNING is used to indicate the presence of a hazard which can cause severe
personal injury, death, or substantial property damage if the warning is ignored.
CAUTION is used to indicate the presence of a hazard which will or can cause minor
personal injury or property damage if the warning is ignored.
NOTE is used to indicate installation, operation, or maintenance information which is
important but not hazard-related.
WARNING: ELECTRICAL SHOCK HAZARD
Do not operate without doors and covers secure. Servicing requires access to
live parts which can cause death or serious injury. Refer servicing to qualified
personnel.
For safety and proper performance this instrument must be connected to a
properly grounded three-wire source of power.
Relay contacts wired to separate power sources must be disconnected before
servicing.
This instrument was shipped from the factory set up to operate on either 115
VAC 50/60 Hz, or 230 VAC 50/60 Hz, as specified by sales order. Verification
that this voltage is proper for the installation is the responsibility of the
purchaser. See Section 2.4.2.
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
P1
REFACE
P
WARNING: OXYGEN LEVEL WILL NOT BE MONITORED
The instrument will not return automatically to the RUN mode from HOLD or
DIAGNOSTICS modes. Operator must manually return instrument to RUN mode
to continue monitoring oxygen.
WARNING: ERRONEOUS OXYGEN READINGS
If the pressure compensation function is not applied correctly, erroneous
readings can be displayed. The display using span gas during calibration
should be the same as the reading using the same gas in RUN mode if the
pressure values are correctly entered.
WARNING: PARTS INTEGRITY
Tampering or unauthorized substitution of components may adversely affect
safety of this product. Use only factory documented components for repair
WARNING: HIGH PRESSURE GAS CYLINDERS
If gas cylinders are used for supplying drying or carrier gases, refer to "General
Precautions for Handling and Storing High Pressure Gas Cylinders" in the rear
of this manual.
WARNING: SENSOR NOT INTRINSICALLY SAFE
The oxygen sensors used with this analyzer are not intrinsically safe. Use of
the sensors in or near flammable liquids, gases or vapors or in Class I, Division
1, Hazardous Locations should be carefully evaluated by qualified personnel at
the site and is entirely the responsibility of the user.
P2
The sensor is approved as non-incendive for use in Class I, Division 2 locations.
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
SPECIFICATIONS - PERFORMANCE
ACCURACY
±0.25% oxygen
O
PERATING RANGE
0 to 25% oxygen (endpoints set by user)
L
INEARITY
±0.25% oxygen
(with constant sample temperature after sensor zero offset correction)
Z
ERO STABILITY
±0.25% oxygen/week at 25°C
S
PAN STABILITY
±0.25% oxygen/24 hours at 25°C
N
OISE
±0.25% oxygen
REFACE
P
R
ESPONSE TIME
90% of reading in 20 seconds at 25°C
T
EMPERATURE EFFECTS
32 to 110°F (0 to 44°C):
60 to 90°F (15 to 32°C):
other 30°F (16°C) ranges:
SPECIFICATIONS - PHYSICAL
M
OUNTING
Standard: Panel Mount
Optional: Wall Mount, Pipe Mount
D
IMENSIONS
5.7 x 5.7 x 7.6 inches (14 x 14 x 19 cm) HxWxD
W
EIGHT
Approximately 3.0 pounds (1.36 kg)
E
NCLOSURE
ABS Plastic, Black, NEMA Type 4X, IP65
A
MBIENT HUMIDITY
95% relative humidity, non-condensing (maximum)
±6% reading
±3% reading
+4% reading
A
MBIENT TEMPERATURE
14 to 122°F (-10 to 50°C)
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
P3
REFACE
P
SPECIFICATIONS - PHYSICAL (CONTINUED)
SENSOR CABLE
2 twisted pairs, specified length up to 1000 feet (305 m) maximum
P
OWER CABLE
3 conductor, Type SJT, 18 AWG minimum
C
ONNECTION CONDUIT
Power: 1/2 inch
Sensor: 3/4 inch
SPECIFICATIONS - ELECTRICAL
POWER REQUIREMENTS
115/230 VAC ±10%, 50/60 Hz ±3 Hz
D
ISPLAY
3-1/2 digit liquid crystal (LCD)
S
IGNAL OUTPUT
Isolated 4 to 20 or 0 to 20 mA (selectable)
600 ohms maximum load
A
LARM RELAY CONTACTS
Two Form C Relays
SPDT, resistive load, independently adjustable
Deadband adjustable over full range
A
LARM RELAY CONTACTS RATINGS
General Purpose (Ordinary) Locations:
115 VAC, 3.0 A (resistive), 230 VAC, 1.5 A resistive
Class I, Division 2 Locations:
CSA: 120 VAC, 3.0 A (non-inductive)
240 VAC, 1.5 A (non-inductive).
FM: 28 VDC (resistive) (Ci = 0, Li = 0)
Groups A&B: 150 mA
Group C: 400 mA
Group D: 540 mA
R
ECORDER OUTPUT
Isolated 4 to 20 mA
P4
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
SPECIFICATIONS - SENSORS
TYPES
Rechargeable and Disposable
P
ROCESS CONNECTIONS
Refer to flow chamber (if supplied)
S
AMPLE PRESSURE
0 to 50 psig (0 to 345 kPa)
S
AMPLE TEMPERATURE
32 to 110°F (0 to 44°C)
A
MBIENT TEMPERATURE
32 to 110°F (0 to 44°C)
A
MBIENT HUMIDITY
95% relative humidity, non-condensing (maximum)
REFACE
P
A
LSO REFER TO INSTRUCTIONS SUPPLIED WITH SENSOR
.
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
P5
REFACE
P
CUSTOMER SERVICE, TECHNICAL ASSISTANCE AND FIELD SERVICE
For order administration, replacement Parts, application assistance, on-site or factory
repair, service or maintenance contract information, contact:
Rosemount Analytical Inc.
Process Analytical Division
Customer Service Center
1-800-433-6076
RETURNING PARTS TO THE FACTORY
Before returning parts, contact the Customer Service Center and request a Returned
Materials Authorization (RMA) number. Please have the following information when
you call: Model Number, Serial Number, and Purchase Order Number or Sales Order
Number.
Prior authorization by the factory must be obtained before returned materials will be
accepted. Unauthorized returns will be returned to the sender, freight collect.
When returning any product or component that has been exposed to a toxic, corrosive
or other hazardous material or used in such a hazardous environment, the user must
attach an appropriate Material Safety Data Sheet (M.S.D.S.) or a written certification
that the material has been decontaminated, disinfected and/or detoxified.
Return to:
Rosemount Analytical Inc.
4125 East La Palma Avenue
Anaheim, California 92807-1802
USA
T
RAINING
A comprehensive Factory Training Program of operator and service classes is
available. For a copy of the Current Operator and Service Training Schedule contact
the Technical Services Department at:
Rosemount Analytical Inc.
Phone: 1-714-986-7600
FAX: 1-714-577-8006
D
OCUMENTATION
The following Model 7003M Percent Oxygen Analyzer instruction materials are
available. Contact Customer Service or the local representative to order.
748223 Instruction Manual (this document)
P6
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
COMPLIANCES
The Model 7003M Percent Oxygen Analyzer and Models 4000 and 5000 series
sensors are suitable for use in Class I, Groups A, B, C, and D, Division 2 locations per
North American electrical codes. Factory Mutual Research (FM) approved under J.I.
1T5AO.AX. Canadian Standards Association (CSA) certified under file LR 93812.
REFACE
P
FM
APPROVED
®
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
P7
REFACE
P
NOTES
P8
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
I
NTRODUCTION
1
1.1 OVERVIEW
The Model 7003M Percent Oxygen Analyzer continuously monitors the concentration
of oxygen in a gaseous sample. It consists of a sensor and the analyzer. The sensor
is housed in a chamber assembly and is connected to the analyzer by a shielded
multi-conductor cable.
The Model 7003M Percent Oxygen Analyzer provides direct digital readout, isolated
current output, automatic temperature compensation circuitry, and dual relay contact
closures for alarms or ON/OFF control devices as standard features. The alarm
ranges can be selected independently from the output range, eliminating the need to
readjust alarm setpoints if the range is changed.
The analyzer has six modes of operation:
MODE FUNCTION
RUN (see Section 3.4) Normal monitoring
SETUP (see Section 3.5) Changing parameters
ALARM/CONTROL (see Section 3.6) Set alarms or ON/OFF controllers
CALIBRATION (see Section 4.2) Gas calibration/pressure inputs
HOLD (see Section 4.3) Retain last output value
DIAGNOSTICS (see Section 4.4) Electronics checks
The Model 7003M Percent Oxygen Analyzer is housed in a NEMA 4X (CSA enclosure
4), corrosion resistant housing suitable for panel, pipe or wall mounting.
The analyzer has a microprocessor controlled keyboard for operation. Signals from
the remote oxygen and temperature sensors are processed to compute real time
oxygen concentration corrected for temperature, constant pressure differences and
residual sensor current. The oxygen concentration is compared with user-set alarm
parameters, and also generates an isolated 4 to 20 or 0 to 20mA signal. Data is
stored in a memory circuit that retains the data in case power is removed.
The analyzer is shipped from the factory configured for operation on either 115 VAC
or 230 VAC, 50/60 Hz as specified by the customer when ordered.
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
1
NTRODUCTION
I
1.2 PRINCIPLE OF MEASUREMENT
Measurement is based on the electro-chemical reaction between oxygen and the
sensor cathode which produces a low level electrical current. The sensor signal is
proportional to the partial pressure of oxygen present at the membrane. This signal
and a thermistor signal are received by the analyzer and processed by the electronics
to output a calibrated oxygen signal that is compensated for temperature.
1.3 SENSORS
Rosemount Analytical offers rechargeable and disposable oxygen sensors which can
be used with the Model 7003M. These sensors are supplied in kits: Submersion, inline flow, fast response, and a cell separation kit. Sensors are available constructed
of polypropylene or Ryton. See Section 7.3 Replacement Parts - Sensors, for
additional information.
1.4 CONDITIONS AFFECTING MEASUREMENT
Oxygen measurement is affected by the following:
• Composition of the sampled gas
• Sample and calibration gas pressures
• Environment of sensor, cable and analyzer
Each must be considered when calibrating and operating the analyzer to obtain
accurate measurements.
1.4.1 G
AS COMPOSITION
Any substance in the sample that significantly interferes or "poisons" the sensor
oxygen reading should be removed by a chemical and/or mechanical sample handling
system (see Section 5.2). If ambient air is not used as the span gas, the composition
of calibration gases should also be representative of the sample.
The sample and calibration gases must meet certain specifications (see Specifications
in Preface) to ensure accurate measurement. Physical parameters that affect
measurement include:
• Pressure
• Humidity
• Temperature
• Gas composition
Also refer to Section 5.2 for additional information about how gas conditions affect the
oxygen measurement.
2
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
NTRODUCTION
I
1.4.2 S
AMPLE AND CAL GAS PRESSURES
The sample and calibration gases may be at different pressures as long as the
pressure of each remains constant. Any variation in the pressure of either gas will
result in an incorrect output reading of the same proportion.
Two methods of sample calibration are recommended:
1. Calibrate at the sample pressure, or
2. Calibrated at a different pressure, and enter the two pressure in the analyzer
(Section 4.2.3)
Refer to Section 5.2 for a more detailed discussion of the relationship between gas
pressures and apparent oxygen concentration.
1.4.3 E
NVIRONMENTAL FACTORS
If radio frequency interference (RFI) normally occurs in the operating environment, the
sensor cable should be electrically shielded during installation.
1.5 FEATURES
UPPRESSED RANGES
S
When setting the Model 7003M to a suppressed output range (15 to 25%, etc.), note
that the absolute accuracy, drift, and noise of the oxygen measurement will remain the
same for all ranges (see Specifications in Preface).
ALAR M M
ODE
ALARM Mode is not self-resetting. Operator must press ACK to bring relays back to
their no-alarm state. Used when immediate operator action is required.
Note:
Operator Can Bypass Alarm Relays
When relays are set to ALARM Mode (Section 3.6.1) and an alarm condition has
occurred, pressing the ACK key will turn off the relay switch, whether the
oxygen level is out of range or not. If you do not want an operator to be able to
bypass the relay switches in this way, set the instrument to ON/OFF -CONTROL
Mode.
ON/OFF-C
ONTROLLER MODE
ON/OFF-CONTROLLER Mode is self-resetting. Pressing ACK has no effect on relay
coils. Used when automated action is required.
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
3
NTRODUCTION
I
NOTES
4
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
I
NSTALLATION
2
2.1 UNPACKING
Carefully examine the shipping carton and contents for signs of damage. Immediately
notify the shipping carrier if the carton or contents is damaged. Retain the carton and
packing material until all components associated with the Model 7003M Percent
Oxygen Analyzer are operational.
2.1.1 S
2.2 ANALYZER INSTALLATION
2.3 SENSOR INSTALLATION
TORAGE
The sensors and analyzer unit may be shipped together or separately. The sensors
are shipped assembly and charged, ready for use.
If rechargeable sensors are stored longer than six months, they may need to be
recharged or rejuvenated if performance is marginal. Disposable sensors are not
rechargeable.
Refer to documentation supplied with sensors for more information.
The Model 7003M Percent Oxygen Analyzer is designed to meet NEMA Type 4X
(CSA enclosure 4) requirements, provided that the cutouts in the bottom of the
enclosure are fitted with approved conduit fittings or are properly sealed by the user
with Hoffman plugs (PN A-S050) or equivalent.
The Model 7003M is supplied with the Panel Mounting Kit PN 652527 as standard.
Optional Wall Mount Kit PN 652539 and Pipe Mount Kit PN 652529 are available.
Refer to the Outline and Mounting drawings provided in the rear of this manual.
Note:
Refer to Figure 2-1 Sensor Ordering Matrix, and verify that the sensor to be used
corresponds with the application. If an incorrect sensor is used, calibration may
be impossible or incorrect. If a different type of sensor is to be used, the rocker
switch (SW1) on the Signal Board may have to be changed (see Section 2.3.1).
748223-J Rosemount Analytical Inc. December 2000
Model 7003M Percent Oxygen Analyzer
5
NSTALLATION
I
Install the sensor in an area where temperature is relatively constant, taking care to
avoid changes in exposure to sunlight or due to sudden drafts. A room-temperature
environment is preferable. The flow chamber/sensor kit contains detailed mounting
and sample flow information. Add distilled or deionized water to the sensor to the
maximum level indication on the sensor reservoir. Let sensor stand for approximately
15 minutes and check for leaks around the base of the reservoir, and at the seams
and corners. If a leak is found, contact the factory before proceeding. Drain the
sensor.
4000 Rechargeable Sensor
5000 Disposable Sensor
1 Polypropylene
2 Ryton (rechargeable only)
9 Special (consult factory)
1 Submersion
2 In-Line Flow
3 Fast Response (rechargeable only)
9 Special (consult factory)
Position →
4000 3
1234
1
5
6
Positions 1 through 4 = Sensor Type
Position 5 = Material of Construction (Sensor and Flow Assembly)
Position 6 = Flow Assembly Configuration
Example 400013 is a Rechargeable sensor, constructed of polypropylene,
mounted in a Fast-Response Flow Chamber Assembly.
F
IGURE
2.3.1 A
2-1. S
NALYZER/SENSOR JUMPER CONFIGURATION
ENSOR ORDERING MATRIX
The Model 7003M is configured to match the type of sensor ordered with the analyzer.
If the Signal Board or Sensor is repaired or replaced, verify rocker switch SW 1 on the
Signal Board is properly set.
Rechargeable Sensor: Close positions 1, 4, and 5
Disposable Sensor: Close positions 2, 4, and 6
6
December 2000 Rosemount Analytical Inc. 748223-JModel 7003M Percent Oxygen Analyzer
