Operation Manual
QCL-MAN -CT4000-OEM-Module, Rev D
October 2015
CT4000 OEM
Module
Preface
Published by Emerson Process Management
All possible care has been taken in the preparation of this publication, but Emerson Process Management and
its agents and distributors accept no liability for any inaccuracies that may be found. This manual reflects the
state of the product at the issue date below, but further enhancements, while in service, may mean that the
manual does not reflect your particular system.
Emerson Process Management reserves the right to make changes without notice both to this publication and
the products which it describes.
Revision D, September 2015
© Emerson Process Management 2015
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by
any means electronic, mechanical, photocopying, recording, or otherwise without the express prior written
permission of the copyright holder.
If you require technical assistance with this product that is not covered within this manual, then help can be
requested from Cascade Technical Support
partners.
(qcl.csc@emerson.com)
or Cascade Technologies distribution
A
A
Only for EC countries:
Do not dispose of measuring tools into household waste!
According to the European Guideline 2002/96/EC for Waste Electrical and Electronic Equipment and its
implementation into national right, m easuring tools that are no longer usable must be collected separately
and disposed of in an environmentally correct manner.
Associated Publications
There are currently no associated publications for this manual.
Document Record
The list below gives, for each element of this manual, the latest Revision Number that has been incorporated
and the date of that revision.
Publication Element Revision No.
Front Cover Revision D
Preface Revision D
Document Record (this page) Revision D
Revision Date
September 2015
September 2015
September 2015
Contents Revision D
Safety Precautions Revision D
List of
bbreviations Revision D
Glossary Revision D
Section 1 Introduction Revision D
Section 2 Description Revision D
Section 3 System Specification Revision D
Section 4 Operation Revision D
Section 5 Scheduled Maintenance Revision D
Section 6 Failure Diagnosis
ppendix A Revision D
Appendix B Revision D
Revision D
September 2015
September 2015
September 2015
September 2015
September 2015
September 2015
September 2015
September 2015
September 2015
September 2015
September 2015
September 2015
Safety Precautions
If the equipment is used in a manner not specified by the manufacturer, the protection provided by the
equipment may be impaired.
ELECTRIC SHOCK
The OEM module operates using mains voltage that is dangerous to life. Ensure that the OEM module is
disconnected from the mains supply before removing any outer covers or performing any work inside the
OEM module. This is particularly important when working at heights.
Death, personal injury and/or damage to persons and/or property may result if this is not observed.
Besides the danger from high voltages, the seals against water and dust can be damaged or impaired if the
OEM module is closed or opened incorrectly.
BURNS
Some parts of the OEM Module may be heated to 200 °C. To prevent burns, do not touch any of the hot
parts. Always assume that all parts of an OEM module are hot unless it has been of switched off and allowed
to cool down.
Before touching, handling, fitting, removing, or performing any maintenance on the OEM module, ensure
that it has been switched off and allowed to cool for at least one hour. Before performing any maintenance
on, or in the vicinity of, the analysis cell, allow the OEM module to cool for at least twelve hours, as the
analysis cell is insulated against heat loss.
When handling the OEM module, always use suitable protective gloves.
Personal injury and/or damage to property may result if these safety precautions are not observed. These
precautions are particularly important when working at heights. If a burn is received, seek medical treatment
immediately.
FLAMMA BLE SUBSTANCES
Some parts of the OEM module may reach temperatures of 200 °C and may present an ignition source.
Exercise care when using oil, paint, cleaning rags, and other flammable substances near the OEM module. A
fire may result if this precaution is not observed. Always assume that the interior of an OEM module is hot
unless it has been switched off and allowed to cool down.
LASER
The OEM module contains lasers. Opening up the OEM module and attempting to perform adjustments or
procedures other than those specified in this manual may result in hazardous optical radiation exposure.
μm
Classification
The classification of the system is Class 1. The lasers within the OEM module are Class 1:
The QCL lasers, which are activated when the system is operating, are Class 1. The emitted laser light is
invisible (mid-infrared), and the combined laser powers are sufficiently low at the first accessible aperture that
the unprotected eye will not be damaged. This class is eye safe under all operating conditions.
The characteristics of the lasers contained within the OEM Module are included in Table1.
Table1 Laser characteristics
Parameter QCL laser
Operation mode Pulsed
Lasers per system 1 — 4
Wavelength 4 — 10
Power < 5 mW
Pulse duration < 1 μs
Pulse repetition frequency < 100 kHz
Duty cycle < 5%
Comment
Combined powers of QCL laser at first accessible aperture
< 9.62 mW
Location of laser safety labels on the OEM module are specified in Section 3.4.
Use of controls or adjustments or performance of procedures other than those specified herein may result in
hazardous radiation exposure.
HAZARDOUS SUBSTANCES
The OEM module may contain hazardous substances. Always handle OEM Module assemblies and
components with extreme caution.
Gas handling components within the OEM module may contain particulate matter residue from the sample
gases. Over the life of the OEM module, the concentration of particulate matter may become enriched
within the gas handling components. The particulate matter comprises carbon, ash, soluble organic fraction,
and, depending upon the type of gases that are sampled, may include compounds derived from sulfur, which
are acidic in nature and may cause respiratory problems. When performing repairs and maintenance on the
OEM module:
•
Handle used gas handling components with extreme caution;
•
Avoid direct skin contact with used gas handling components;
•
Smoking, drinking, and eating in the work area are prohibited;
•
Goggles or eye shields are to be worn;
•
A suitable face mask is to be worn to protect against inhalation of particulate matter;
•
Keep food and beverages away from the OEM module;
•
Do not wet fingers, eyes, or any exposed skin;
•
Pack used gas handling components for disposal in sealed packaging and label it Contaminated;
•
Dispose of contaminated items as hazardous material according to the applicable local, national or
international health and safety regulations and pollution regulations.
HEAVY ITEM
Handle the OEM module with caution during unpacking, installation, maintenance and transport to prevent
crushing of hands, feet, or other body parts.
The OEM module weighs 13 kg and should always be lifted with caution. Wear suitable protective gloves and
protective footwear. When preparing the OEM module for transport by air, road, or rail, safeguard the OEM
module against movement or break-away during transport by securely strapping it in place.
EQUIPMENT DAMAGE — PRE-SYSTEM STARTUP CHECKS
Do not power up or try to operate the OEM module unless it is physically secure and all connections to the
OEM module and control PC are in place.
Before beginning the OEM module system start-up process, it is important to ensure that power, sample
handling facilities and any calibration gases that are required are available at the installation site.
y
Abbreviations
The following abbreviations are used in this
Table 2 Abbreviations
Abbreviation Stands for
AC Alternating current
ADC Analog to digital converter
DC Direct current
EMC Electromagnetic compatibility
GB Gigabyte
GHz Gigahertz
Hz Hertz
I.P. Internet protocol
IPxx Ingress protection (the xx are numbers that define the level of protection)
kHz Kilo-hertz
L Liter
L/min Liters per minute
m Meter
mm Millimeter
2
mm
μm Micro-meter
mW Milli-watt
Nm Newton meter
No. Number
OEM Original equipment manufacturer
Para Paragraph
PC Personal computer
ppm Parts per million
ppmC Parts per million carbon
s/n Signal to noise
TEC Thermoelectric controller
UPS Uninterruptable power suppl
USB Universal serial bus
V Volt
W Watt
Square millimeter
manual:
Glossary
The following words, defined in the table below, are used in this manual.
Table 3 Glossary
Word Definition
Danger Signal word used to indicate an imminently hazardous situation, which, if not avoided, will
result in death or injury.
Warning The word warning has two meanings within this manual.
Signal word used to indicate a potentially hazardous situation, which, if not avoided, could
result in death or serious injury. This is the normal usage of the word warning within this
manual.
In the Troubleshooting and Diagnostics section of this manual, some of the on-screen error
messages generated by the OEM module system include the word warning to indicate a
minor fault.
Caution Signal word used to indicate a potentially hazardous situation, which, if not avoided, could
result in minor or moderate injury.
Background A pulse recorded with no absorbing species at the wavelengths of the lasers present in the
cell.
Detection limit Although the gas detection range is given from zero, this is the lowest possible level of gas
that the OEM module can detect.
Fit In the repair procedures, fit means to place an assembly, sub-assembly, or component in its
correct position.
Fitting The technique used to analyze the recorded data to give a concentration.
Laser beam path length The optical distance travelled by the laser through the gas being measured.
Measurement frequency The frequency at which all output gas concentrations are updated.
Measurand A quantity that is being determined by the measurement.
Purge The use of high pressure gas to remove particulates that may have built up on the cell mirror
surfaces.
Replace In the repair procedures, replace means to remove and discard an unserviceable item and
then fit a serviceable replacement item.
Sample flow rate The rate at which sample gas flows through the cell.
Operation Manual Table of Contents
QCL-MAN -CT4000-OEM-Rev D October 2015
Contents
Section 1:Introduction
1.1 Introduction .................................................................................................. 1
1.2 Customer information ................................................................................... 1
1.3 Safety precautions ......................................................................................... 1
1.4 Qualified personnel ....................................................................................... 2
1.5 Software version ............................................................................................ 2
Section 2: Description
2.1 Equipment purpose and role.......................................................................... 3
2.2 System overview ........................................................................................... 4
2.3 Location of OEM module ............................................................................... 6
2.3.1 System installation ........................................................................ 7
2.3.2 Operation ..................................................................................... 7
2.4 OEM module description ............................................................................... 8
2.4.1 OEM module ................................................................................. 9
2.4.2 Control PC ..................................................................................... 9
2.4.3 Sample handling system ................................................................ 9
2.5 Optical description ...................................................................................... 10
Section 3:System specification
3.1 Gas detection .............................................................................................. 13
3.2 Detailed system specification ...................................................................... 13
3.3 Control PC specification ............................................................................... 17
3.4 System labels .............................................................................................. 18
3.5 Compliance approvals ................................................................................. 23
3.6 CE marking .................................................................................................. 23
Section 4: Operation
4.1 Introduction ................................................................................................ 24
4.2 Software installation .................................................................................... 24
4.3 Sensor states ............................................................................................... 25
4.4 Preparation for use ...................................................................................... 25
4.5 Startup procedure ....................................................................................... 25
4.5.1 Standby mode ............................................................................. 26
4.5.2 Work Mode ................................................................................. 27
4.6 System shutdown ........................................................................................ 28
4.7 Restarting gas sensor software following system shutdown ......................... 28
4.8 System preferences ..................................................................................... 29
4.9 Gas sensor software package ....................................................................... 30
4.9.1 Measurements ............................................................................ 31
4.9.2 Log Messages .............................................................................. 32
4.9.3 Viewing data in graphs ................................................................ 33
4.9.4 Viewing the laser pulses plot........................................................ 34
4.10 Gas calibration procedure ............................................................................ 35
4.10.1 Tools required ............................................................................. 36
4.10.2 Schedule ..................................................................................... 36
4.10.3 Zero calibration ........................................................................... 36
4.10.4 Span calibration .......................................................................... 37
4.11 Background division .................................................................................... 38
4.12 X-Shift adjustment ...................................................................................... 38
4.12.1 After X-shift adjustment .............................................................. 40
Table of Contents i
Table of Contents Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
4.13 The laser calibration tool .............................................................................. 40
4.13.1 Required equipment ................................................................... 40
4.13.2 Procedure ................................................................................... 41
Section 5:Scheduled maintenance
5.1 Maintenance ............................................................................................... 46
5.2 Schedule ................................................................................................... 46
5.2.1 Weekly check .............................................................................. 46
5.2.2 Monthly check ............................................................................. 46
5.2.3 Biannual check ............................................................................ 46
5.3 Maintenance activities ................................................................................. 46
5.3.1 Zero calibration ........................................................................... 46
5.3.2 Span calibration .......................................................................... 47
5.3.3 X-shift calibration ........................................................................ 47
5.3.4 Sample cell mirror purge ............................................................. 47
5.3.5 Laser wavelength calibration ....................................................... 47
Section 6:Failure diagnosis
6.1 Introduction ................................................................................................ 48
6.2 Failure diagnosis principles .......................................................................... 48
6.3 Repairable faults .......................................................................................... 48
6.4 Faults only repairable by Emerson Process Management .............................. 49
6.5 Tools and test equipment ............................................................................ 49
6.6 Wiring diagram ........................................................................................... 49
6.7 General troubleshooting and diagnostics information ................................. 55
6.7.1 System messages ........................................................................ 55
6.7.2 Warning or error message significance ........................................ 58
6.7.3 Communication fault messages................................................... 58
6.7.4 Resolution of warning or error messages ..................................... 59
6.8 Simple fault resolution ................................................................................. 59
6.8.1 No gas measurement change ...................................................... 59
6.8.2 Gas temperature low ................................................................... 59
6.8.3 Laser signal level low .................................................................... 60
6.9 Visual examination of the OEM module........................................................ 60
6.9.1 Visual inspection of the CT4000................................................... 60
6.9.2 Removing the lower cover ........................................................... 61
6.9.3 Replacing the lower cover ........................................................... 62
6.9.4 Component identification ........................................................... 63
Appendix A: Model CT4142
A.1 System specification .................................................................................... 66
A.2 Cross-interference performance .................................................................. 67
A.3 Linearity performance ................................................................................. 67
A.4 Performance characteristics ........................................................................ 67
A.5 Operational and physical characteristics ...................................................... 69
Appendix B: Model CT4125
B.1 System specification .................................................................................... 70
B.2 Cross-interference performance .................................................................. 70
B.3 Linearity performance ................................................................................. 70
B.4 Performance characteristics ........................................................................ 71
B.5 Operational and physical characteristics ...................................................... 71
Table of Contents ii
Operation Manual List of Tables
QCL-MAN -CT4000-OEM-Rev D October 2015
List of Tables
Table1 Laser characteristics .................................................................................. iii
Table 2 Abbreviations ............................................................................................. v
Table 3 Glossary .................................................................................................... vi
Table 2-1 Gases ......................................................................................................... 4
Table 2-2 Main items of the CT4000 OEM module ..................................................... 6
Table 3-1 Physical characteristics ............................................................................. 13
Table 3-2 Performance characteristics ..................................................................... 13
Table 3-3 Electrical connector specifications ............................................................ 16
Table 3-4 Environmental characteristics .................................................................. 17
Table 3-5 Control PC minimum specifications .......................................................... 18
Table 3-6 System labels ........................................................................................... 18
Table 6-1 System notice messages .......................................................................... 56
Table 6-2 System warning messages ....................................................................... 57
Table 6-3 System error messages ............................................................................ 58
Table A-1 System Specification ................................................................................ 66
Table A-2 Cross-interference performance ............................................................... 67
Table A-3 Performance characteristics ..................................................................... 68
Table A-4 Operational and physical characteristics ................................................... 69
Table B-1 System specification ................................................................................ 70
Table B-2 Cross-interference performance ............................................................... 70
Table B-3 Performance characteristics ..................................................................... 71
Table B-4 Operational and physical characteristics ................................................... 71
List of Tables iii
List of Figures Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
List of Figures
Figure 2-1 CT4000 OEM module ................................................................................. 3
Figure 2-2 Complete OEM module gas analysis system ............................................... 5
Figure 2-3 Connection points ...................................................................................... 8
Figure 2-4 Optical path - electrical side ..................................................................... 11
Figure 2-5 Optical path - cell side shown with insulation removed ............................. 11
Figure 3-1 OEM module dimensions - top view with fixing centers ............................ 14
Figure 3-2 OEM module dimensions - end on view with connection points ................ 15
Figure 3-3 OEM module dimensions - side view ......................................................... 16
Figure 3-4 Label locations - end panels ...................................................................... 20
Figure 3-5 Label locations - top view ......................................................................... 20
Figure 3-6 Label locations - side panels ..................................................................... 21
Figure 3-7 Labels visible with covers removed ........................................................... 22
Figure 4-1 Initial screen ............................................................................................. 26
Figure 4-2 Standby Mode screen ................................................................................ 27
Figure 4-3 Work Mode screen .................................................................................... 28
Figure 4-4 Shutdown button ..................................................................................... 28
Figure 4-5 Terminal startup ...................................................................................... 29
Figure 4-6 Preferences window ................................................................................. 30
Figure 4-7 Gas sensor software screen ...................................................................... 31
Figure 4-8 Configuration window .............................................................................. 33
Figure 4-9 Laser pulses plot ....................................................................................... 34
Figure 4-10 Background Division plot ......................................................................... 35
Figure 4-11 Background Division plot rescaled ............................................................ 35
Figure 4-12 Zero calibration ........................................................................................ 36
Figure 4-13 Span calibration ....................................................................................... 37
Figure 4-14 X-Shift adjustment ................................................................................... 39
Figure 4-15 The Log window ....................................................................................... 39
Figure 4-16 Laser calibration feature restriction message ............................................ 40
Figure 4-17 Selecting the laser and starting the calibration tool .................................. 41
Figure 4-18 Calibration tool screen ............................................................................. 42
Figure 4-19 Etalon calibration ..................................................................................... 43
Figure 4-20 Final adjustment of calibration ................................................................. 44
Figure 6-1 CT 4000 OEM module wiring diagram ...................................................... 51
Figure 6-2 CT4000 OEM module cable assembly wiring detail ................................... 52
Figure 6-3 CT4000 OEM module cable assembly wiring detail continued .................. 53
Figure 6-4 Removal of the lower cover ...................................................................... 62
Figure 6-5 Components in the electronic section ...................................................... 63
Figure 6-6 Components in laser module side ............................................................. 64
Figure 6-7 Components in PCB side ........................................................................... 65
List of Figures iv
Operation Manual Introduction
QCL-MAN -CT4000-OEM-Rev D October 2015
1 Introduction
1.1 Introduction
The CT4000 OEM module is an electronic sensor that identifies and measures gas
concentrations. The CT4000 is a configurable gas sensor designed to be integrated with
the customer’s sample handling system. The CT4000 is used with GasSensor-3 software,
which may be supplied on a PC with the unit or as
customer owned PC. The software analyses the laser pulses and calculates and displays the
gas concentrations detected.
This operation manual for the OEM module is intended for the person who installs and
maintains the equipment.
1.2 Customer information
This manual contains all the information required to install, operate, and maintain the OEM
module. Please read the manual carefully before you start work on the OEM Module, as it
contains important information that must be followed to guarantee the correct operation
of the system and the safety of personnel. The manual is divided into sections, which
should allow users to rapidly find the information they need.
a software
package to install on a
Emerson Process Management is committed to continuously improving its products and
documentation. Every effort will be made to include any sensor modifications by the
manufacturer in the documentation. However it should be noted that this document
reflects the supplied OEM module as of the revision number and date on the front cover.
Should you require further information, or should particular problems arise that are not
covered within this Operation Manual, then additional help can also be requested from
Cascade Technical Support
partners. Further contact details for Cascade Technologies can be found in the preliminary
material of this manual.
(qcl.csc@emerson.com)
1.3 Safety precautions
Before installing or performing any maintenance on the OEM module, read and understand
the safety precautions given in the preliminary material of this manual.
The OEM module described in this manual has been quality control tested and left the
manufacturer in pristine condition. To achieve the correct and safe operation of the
product, it must be transported, installed, operated, and maintained as described by the
manufacturer.
All lasers used within the Emission Sensor are of class 1. The emitted laser light is invisible
(mid-infrared) and the pulse duration so short that the unprotected eye will not be
damaged. The nature of the laser beam path and beam width further ensures that it
should be impossible to cause any eye damage.
or Cascade Technologies distribution
There is also a visible laser that may be installed in the OEM module for service and
maintenance procedures. It is not installed at the point of shipment or in normal
operation. This visible laser is of class 2. A class 2 laser is safe because the blink reflex will
Introduction 1
Introduction Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
limit the exposure to the beam to no more than 0.25 s. Intentional suppression of the blink
reflex could lead to eye injury. The visible laser will be supplied with the relevant
operational and safety instructions.
1.4 Qualified personnel
This manual provides maintenance personnel with the level of knowledge required to
safely start, operate, switch off, install, maintain, and troubleshoot the OEM Module.
The installation, advanced operation, switching off, service, and troubleshooting of the
OEM module must only be performed by technically qualified personnel in the field of
instrumentation and control who are familiar with this manual and who have been specially
trained on the OEM module. Only qualified and trained persons have the required specific
knowledge to correctly interpret the general safety information, warnings and procedures
given in this manual and apply them to this particular application. Please contact Emerson
Process Management or their distribution partners for further information on training that
is available.
Knowledge of the safety information within this manual and its technically correct
implementation are prerequisites for danger-free operation, installation, and maintenance
of the OEM module.
1.5 Software version
The OEM Module includes software that is used to control the operation of the sensor. This
Manual describes software version 3.9.
Introduction 2
Operation Manual Description
QCL-MAN -CT4000-OEM-Rev D October 2015
2 Description
2.1 Equipment purpose and role
The CT4000 OEM module (Figure 2-1) is a gas sensor system that can be configured to
measure the concentrations of multiple sm all molecules contained in the gas sample that
is supplied to the OEM module via a sample line. The types of molecules that are measured
depend on the system configuration.
Figure 2-1 CT4000 OEM module
Description 3
Description Operation Manual
r
3
October 2015 QCL-MAN -CT4000-OEM-Rev D
The OEM Module is typically configured to detect and measure between one and eight
components, depending on the combination of laser modules. These components may
include, but are not limited to, a selection of the following gases:
Table 2-1 Gases
Name Symbol
Nitric oxide NO
Nitrogen dioxide NO
Carbon monoxide CO
Carbon dioxide CO
Wate
Sulfur dioxide SO
Methane CH
Nitrous oxide N2O
Ammonia NH
The configuration and performance of the OEM Module supplied with this manual can be
found in Appendix A — System Configuration and Performance, located at the end of this
manual.
2
2
H2O
2
4
2.2 System overview
A compete OEM module gas analysis system consists of a gas handling system, the OEM
module, and a control PC as shown in Figure 2-2 below. The gas handling system is
provided by the customer, the OEM module is supplied by Cascade Technologies Ltd, and
the control PC is typically supplied by the customer, but may be supplied by Cascade
Technologies depending on the customer requirement. Figure 2-2 shows the typical
scope of supply.
The OEM module enclosure contains an optical system with up to four lasers, a heated
multi-pass sample cell, a series of optical components that direct the laser beams through
the sample cell, sample and outlet ports that can be connected to a gas handling system,
and control and analysis electronics. The whole system operates from a 12 V DC input and
either a 110 or 240V AC supply, depending on system configuration. The exact
configuration of the OEM Module supplied with this manual can be found in Appendix A System Configuration and Performance.
Gas concentrations are measured using mid-infrared optical absorption spectroscopy. The
light sources are quantum cascade lasers, which are operated to produce wavelength
chirps that cover the absorption lines of the gases. The light from each laser is directed
through the sample cell using a series of optical components. The sample gas is
conditioned and drawn through the cell by external sample handling system. The light
exits the multi-pass cell and is directed to the infrared detector in the OEM Module. The
variation in the intensity of light in the vicinity of the absorption lines is measured, and the
concentration is determined using a comprehensive spectral fitting routine.
Description 4
Operation Manual Description
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 2-2 Complete OEM module gas analysis system
There is no sample conditioning provided within the OEM module; the sample gas must be
brought within the parameters shown in
Table 3-4 before entering the OEM module system. Detailed characteristics of the OEM
module are also given in Section 3.
Description 5
Description Operation Manual
y
AC
AC pow
October 2015 QCL-MAN -CT4000-OEM-Rev D
Table 2-2 Main items of the CT4000 OEM module
Item Name or
Supplied b
Part number Quantity
Notes
Description
1
CT4000 OEM
module
2
Gassensor-3
software package,
version 3.8.X or
higher
3
110 or 240 V
power
cable to OEM
module
4
12 V DC power
cable combined
with digital IO to
OEM module
5
Heated gas sample
line hose
6
Exhaust line hose
(for sample gas)
7
Compressed air
supply
(for purge gas line)
8
Purge gas line hose Customer
9
Gas handling system Customer
10
11
12
Ethernet
from OEM module
to
Control PC Customer or
Power cable to
control
PC
cable
control PC
Emerson Process
Management
Emerson Process
Management
Customer
Customer
Customer
Customer
Customer
Customer
Emerson
Process
Management
Customer
CT4XXX-XXXXX 1
GS-3.8.X
GS-3.9.X
GS-3.10.X
Customer choice 1
Customer choice 1
Customer choice 1
Customer choice 1
Customer choice 1
Customer choice 1
Customer choice 1
Customer choice 1
TBA
Customer choice 1
1
Software
version
included in
Error! Not a
1
Confirmed at
er
specification
included in
Error! Not a valid
Including
cylinders and
vacuum pump
as appropriate
time of order
placement
gas
2.3 Location of OEM module
The OEM module should be mounted in the vicinity of a gas handing system. Emerson
Process Management recommends that:
1. The OEM Module is free from risk of direct liquid spillage and away from any hot
air vent.
1. No more than 25 m of Ethernet cable run from the OEM module to the control PC.
Description 6
Operation Manual Description
QCL-MAN -CT4000-OEM-Rev D October 2015
2.3.1 System installation
The inlet and exhaust sample lines and the DC and AC supply cables can then be connected
to the OEM Module as shown in Figure 2-3 and Figure 2-4.
Electrical Power to operate the OEM Module must be provide by the customer. Two
electrical supplies are required:
1. A +12 V DC supply to operate the control, analysis, and data communication
electronics contained within the OEM module.
2. A 110 V or 240 V AC supply to power the heater that maintains the temperature of
the sample cell at a constant temperature. The temperature set point of the sample
cell is factory set and may be between 50 and 190 ˚C, depending on system
configuration.
Many gases that the OEM Module can measure are highly poisonous even at low
concentrations. Special care should therefore be taken to endure that the exhaust sample
line discharges the sample gas to a location that will not cause inhalation injury to
personnel.
The sample line must be heated all the way to the inlet fitting on the OEM Module to
prevent condensation forming at any point in the sample line. The sample line should be
set to the same temperature as the OEM Module cell. The cell temperature can be found in
the system configuration detailed in Appendix A.
The OEM module can then be connected to the control P.C. via the Ethernet port using a
Cat 5 network cable.
2.3.2 Operation
Once the OEM module and control PC are powered on, the system is ready to use. Detailed
instructions of how to operate the gas sensor software can be found in
Section 4 — Operation.
Description 7
Description Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 2-3 Connection points
1. Gas outlet
2. Gas inlet
3. Ethernet connector
4. DC power in and Digital IO connection point
5. AC power in connection point
2.4 OEM module description
The OEM module system consists of the OEM module, a sample handling system and a
control PC. Figure 2-2 shows a complete OEM module system. Table 2-2 lists all the main
items of the OEM module system.
Description 8
Operation Manual Description
QCL-MAN -CT4000-OEM-Rev D October 2015
2.4.1 OEM module
The system contains between one and four lasers, which are mounted in the lower
electronic tray. The control electronics are also located in this section. Light emitted from
the lasers is directed using a series of optical components from the upper tray into the
sample cell, where it may be partially absorbed by the gas present in the cell. The light that
is transmitted from the cell is detected by a receiver in the upper electronic tray.
The variation in the intensity of the light in the vicinity of the absorption lines is measured,
and as the path length and the absorption characteristics of the gas are known, the
concentration may be determined using the Beer Lambert Law. The gas sensor software
uses a comprehensive spectral fitting routine to match the recorded spectra to a
theoretically generated spectrum, and uses this best fit to calculate the concentrations of
the gases present.
2.4.2 Control PC
The control PC runs the gas sensor software, which controls the OEM module and
calculates the gas concentrations from the data provided by the OEM module. The control
PC displays and can be configured to store the calculated information. The type and size of
the control PC depends on the particular application and regulatory requirements; so it
could be a laptop in a protective housing, a nineteen inch rack mounted system, or a
normal desktop computer. The measured data may also be transmitted from the control
PC to a client. The control PC is usually provided by the customer but may be supplied by
Cascade Technologies with the OEM module on request.
2.4.3 Sample handling system
The sample handling system controls the gas flow through the OEM module. It typically
consists of the parts shown in Figure 2-2. A vacuum pump is used to draw the sample
through the sample cell, and a series of valves control the flow rate and pressure in the
sample cell. The cell pressure should be controlled to the set point given in Table A-3 of
Description 9
Description Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Appendix A. A heated line is recommended on the inlet side to condition the gas up to the
same temperature as the sample cell before it enters the OEM Module. A heated line on the
exhaust may be required to prevent condensates forming in the line.
2.5 Optical description
The laser modules are located in the lower electronic tray of the OEM module. Each laser
module produces a separate light beam, and these beams are combined linearly as the
modules are aligned in the system. The combined beams are closely coupled, parallel, and
coaxial about a virtual line. The laser light beams pass through the baseplate onto an
optical steering assembly which directs the laser beams through the sample cell.
The sample cell contains a set of mirrors to create a path through the sample gas that is
between 2m and 5m through multiple reflections along the length of the cell. The laser
beams exit the cell at the opposite end to where they entered and are directed using a
second optical block on to a receiver.
By measuring and analyzing the light detected by the receiver unit, it is possible to
accurately determine the concentrations of the target molecules within the gas sample
cell.
Description 10
Operation Manual Description
M7
M2
to
DET
M6
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 2-4 Optical path - electrical side
L1
to L4 Collimation lens 1 to 4
and M3 Steering mirrors to upper
BS1
section
BS4 Beam splitters 1 to 4
and M8 Steering mirrors onto detector
ETA
Etalon (optional)
Detector
Figure 2-5 Optical path - cell side shown with insulation removed
M3 Steering mirror into cell W1 and W2 Cell windows
and M5 Internal Cell Mirrors
M4
Steering mirror to lower section
Description 11
Description Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Refer to Figure 2-4 and Figure 2-5. The light beams output from up to four lasers are
collimated by lenses L1 to L4 in Figure 2-4 and combined to a linear beam using four beam
splitters (BS1 to BS4). The combined light beam is directed on to the upper section shown
in Figure 2-5 by a series of mirrors (M1 to M3) where it is directed through a multipath cell
configured to a path length of either 2m or 5m depending on the specification. The sample
cell has two internal mirrors (M4 and M5) and windows (W1 and W2) to create a sealed cell.
The light exiting the cell is directed back to the lower section and onto a receiver (MCT
detector) using two steering mirrors (M6 and M7) and an off-axis parabolic mirror (M8).
There is an optional etalon which may be moved into the beam to allow calibration of the
wavenumber output of the lasers using an interference fringe pattern that it produces.
Section 4.12 describes how the laser calibration is performed using the Gas Sensor
software and the etalon.
Description 12
Operation Manual System Specification
V
x
x
x
w
x
V
v
V
AC
DC
V 2 A
AC
W
W
- -
- Pow
- -
-
r
6 mm Sw
6 mm Sw
Max
QCL-MAN -CT4000-OEM-Rev D October 2015
3 System Specification
3.1 Gas detection
The CT4000 OEM Module is highly configurable in the gases that can be detected and their
range of concentrations. A detailed specification including the gas measurement
capability is therefore included in Appendix A.
3.2 Detailed system specification
Table 3-1 gives the physical characteristics of the OEM Module. Schematic diagrams of the
sensor and mounting points are shown in to Figure 3-1 to Figure 3-3.
Table 3-1 Physical characteristics
OEM module
CT4000 dimensions 498
CT4000 weight
13
alue
218
260
Units Comment
mm Depth
height.
kg
idth
Table 3-2 gives the general characteristics of the OEM Module.
Table 3-2 Performance characteristics
OEM module
Heater supply
Supply Voltage
Peak Power Consumption
Continuous steady-state
AC Power Consumption
Frame and structure material
Housing material
Measurement Technique
Mid IR Source
Laser classification CLASS 1 (Mid
Inlet gas port connector
Exhaust gas port connector
Purge air pressure
oltage 110 or 240
al
12
500
200
-
-
IR)
2
Units
barg
Comment
50-60Hz (specify on order).
Max consumption per sensor.
Once sensor has stabilized and the
sample cell has reached the
temperature set point.
Stainless Steel S304 and Electroless
nickel coated aluminum.
der coated aluminum.
Mid IR
Absorption Spectroscopy.
Quantum Cascade lase
BS EN 60825-1:2007 Safety of laser
products. Equipment classification
and requirements (identical to IEC
60825-1 2007).
agelok type
agelok type
imum purge pressure
System Specification 13
System Specification Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 3-1 OEM module dimensions - top view with fixing centers
System Specification 14
Operation Manual System Specification
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 3-2 OEM module dimensions - end on view with connection points
System Specification 15
System Specification Operation Manual
AC Power
AC power
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 3-3 OEM module dimensions - side view
Table 3-3 gives right angled and straight coupled electrical connector options to connect
to the OEM
module.
Table 3-3 Electrical connector specifications
Connector
12 VDC Supply and
Digital IO
12 VDC Supply and
Digital IO
Supply Hirose*
supply Hirose*
Ethernet Various
Manufacturer
Hirose*
Hirose*
Part number
HR34B-12WPB-10S
HR34B-12WPB-10S(71)
HR34B-12WLPD-4S
HR34B-12WPE-4S
CAT5e
n/a
Description
10 pole male straight
solder bucket cable
connector
10 pole male right
angle solder bucket
cable connector.
4 pole male straight
solder bucket cable
connector
4 pole male right
angle solder bucket
cable connector.
* The Hirose connectors are available from RS Components, part numbers 715-3328 and 715-3356 for the
straight and right angle 12 V DC Supply and Digital IO and 715-3338 and 715-3312 for the straight and
right angle AC Power Supply connectors, correct at the revision date of this Operation Manual.
System Specification 16
Operation Manual System Specification
V
10
%
QCL-MAN -CT4000-OEM-Rev D October 2015
Table 3-4 gives the environmental characteristics of the OEM module.
Table 3-4 Environmental characteristics
Environmental characteristic
CT4000 operating temperature range -20 to +70 deg C Ambient temperature.
Sample gas temperature range +50 to +195 deg C Factory set, specify on order
Sample gas m oisture content
Sample gas particulate density
Sample gas particulate size
CT4000 IP Code
CT4000 Humidity Range
Operating Altitude 0 to 2000
alue
20
5
Mg/m3
10
30
to 95
3.3 Control PC specification
The control PC is supplied by either the customer or Emerson Process Management. There
are a number of PC types available. If a control PC has been supplied by Emerson Process
Management with the OEM module, refer to
Units
%
Maximum
μm
m
Indoor use
Comment
Ingress Protection (IP) to IEC
60529
Relative humidity (Noncondensing)
at 45 deg C.
System Specification 17
System Specification Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Appendix A for the specification. The two most commonly supplied types of control PC
are a rugged laptop and a rack mounted PC that is compatible with a 19 inch rack. The
minimum specifications for a control PC are given in Table 3-5.
Table 3-5 Control PC minimum specifications
Parameter
Processor
RAM memory
Hard disk
Ethernet
Operating system 12.04 LTS Ubuntu
Value
1.8
GHz Intel(R) Atom™ D525
2
8
100
MBit
3.4 System labels
The labels applied to the OEM module are specified in Table 3-6. Figure 3-7 shows the
label locations on the external casing.
Units Comment
GB
GB
SSD
System Specification 18
Operation Manual System Specification
wer
AC power
v
r
w
QCL-MAN -CT4000-OEM-Rev D October 2015
Table 3-6 System labels
Label type
Identification label
Electrical safety label
USA FDA Compliance Label
(for systems shipping to USA)
Caution — Hot label
Example
Location
External end panel
External
External end panel
On
end panel
cell insulation
Warning — isolate electrical
supply
label
Laser
label
supply
adiation
oltage
arning
Lo
external cover
cell
On
insulation and
in the lower
section
containing
electronic PCAs
On baseplate
next to
Laser Modules
System Specification 19
System Specification Operation Manual
3.
October 2015 QCL-MAN -CT4000-OEM-Rev D
Label type
Laser module identification
label
Example
Location
On laser
module
housing
Figure 3-4 Label locations - end panels
1. USA
2. Electrical
FDA Compliance label
safety label
Identification label
Figure 3-5 Label locations - top view
1. Caution — Hot label
System Specification 20
Operation Manual System Specification
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 3-6 Label locations - side panels
1. Warning — Isolate electrical supply
2. AC power supply voltage label
System Specification 21
System Specification Operation Manual
3.
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 3-7 Labels visible with covers removed
Laser module Identification Label
1.
2.
Laser Radiation Warning Label
System Specification 22
AC Power Supply Voltage Label
Operation Manual System Specification
QCL-MAN -CT4000-OEM-Rev D October 2015
3.5 Compliance approvals
This product complies with USA 21 CFR 1040.10. It is also
designed and manufactured under an approved quality
management s ystem to ISO 9001:2008.
3.6 CE marking
Emerson Process Management and the CT4000 OEM Module have
satisfied the requirements for applying the CE marking to the system.
System Specification 23
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
4 Operation
4.1 Introduction
This section describes how to start and perform normal operations using the CT4000 OEM
module. Operation of the OEM Module is controlled through the software display on the
control PC.
It should be noted that the gases shown in the following screenshots may be different from
those shown in your particular OEM module system. They indicate the functionality of the
software, which is the same regardless of the gases being measured.
This manual describes version 3.9 of the control software. The screenshots provided in this
section show the software version as version 3.9.19, indicating that it is sub-version 19 of
software version 3.9.
The OEM module requires a control PC to operate. This is usually provided by the Customer
to the minimum specification given in Table 3-5. The control PC must have the gas sensor
software package installed prior to operation of the OEM module. The gas sensor software
package will be provided by Cascade Technologies with the OEM module. If you do not
have a copy of the software installation package please contact Cascade Technologies or
their distribution partners for assistance. Section 4.2 provides instructions to install the gas
sensor software.
In some cases the control PC is provided by Cascade Technologies with the OEM module. In
this case, the control PC will be supplied ready to use. Please proceed to Section 4.3 for
further instructions on operation of the OEM module.
BURNS
Some parts of the OEM Module are heated to 200 degrees C. To prevent burns do not
touch any of the hot parts. Always assume that all parts of an OEM module are hot unless
it has been switched off and allowed to cool down.
Before touching, handling, fitting, removing, or performing any maintenance on the OEM
module, ensure that it has been switched off and allowed to cool for at least thirty
minutes. Before performing any maintenance on, or in the vicinity of, the analysis cell,
allow the OEM module to cool for at least twelve hours as the analysis cell is insulated
against heat loss.
When handling the OEM module, always use suitable protective gloves.
Personal injury and/or damage to property may result if these safety precautions are not
observed. If a burn is received, seek medical treatment immediately.
4.2 Software installation
The control PC should have the minimum specification given in Table 3-5. The operating
system is Ubuntu, and the software package provided is for installation onto this software
platform. The gas sensor software package is installed as follows:
Operation 24
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
1. Power on the control PC and log in to the Administrator account
2. Copy the software package to the Home folder. The software package will be
named: Cascade_GasSensor.sh or sim ilar.
3. Open a terminal window by going to Applications > Accessories > Terminal.
4. Type the following command into the Terminal window and press enter: sudo
/home/admin/Cascade_GasSensor.sh
The name of the software package and location of the file may vary depending on the PC
set up and application. Please amend the comm and above as appropriate for the
installation.
5. You may be prompted for the Administrator password. Following installation of
the package, the PC automatically restarts. On restart, the gas sensor software
automatically opens.
6. A license file for the software may also be provided with the format Licence.conf.
Copy this file to the following location on the control PC:
/home/user/.Config/CascadeTechnologiesLtd/
7. A configuration file will also be provided with the format CT4XXX-0XXXX.cfg. Copy
this file to the home folder and refer to Section 4.5 to set the preferences so that
the configuration file automatically loads when the gas sensor software is started
(recommended).
The gas sensor software package is now installed and ready to use.
4.3 Sensor states
The OEM module has three operating states: WORK MODE, STANDBY M ODE and OFF.
1. As the OEM module is designed for long term continuous operation, the OEM
module is usually in WORK MODE.
2. When not being used to calculate gas concentrations, it is recommended that the
OEM module is placed in STANDBY M ODE.
3. The OEM module is normally only placed in the OFF state for maintenance.
4. To start measuring gas concentrations using the OEM module system, it is
necessary to perform the start-up procedure described below.
4.4 Preparation for use
The OEM module must be installed and fully commissioned prior to operation.
4.5 Startup procedure
To start measuring gas concentrations using the OEM module perform the following steps:
1. Connect power to the OEM module. The OEM module requires a 12 V DC supply
and either 110 or 240 V AC. The AC voltage requirement is determined by the
Operation 25
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
heater specification. Please refer to the warning labels on the OEM module case at
the power connection points if unclear.
2. Connect the OEM module to the control PC, and power on the control PC.
3. The OEM module does not have a sample handling system. Connect the exhaust
to a source of suction and a suitable gas ventilation system. Connect the Inlet to the
gas supply to be analyzed.
4. The control PC may be configured to automatically load the gas sensor software
and the configuration file for the OEM module it has been supplied with. On
completion of the startup procedure, the screen will look similar to that shown in
Figure 4-1.
Figure 4-1 Initial screen
4.5.1 Standby mode
Once the system is powered on and the control PC has loaded the gas sensor software, the
system should be put into standby mode whilst the gas cell reaches the operational
temperature. The operational temperature may vary from system to system; please refer
to the system configuration.
1. Connect the sensor to the PC by clicking the Connect button.
2. Start the laser thermoelectric coolers by clicking the Start TECs button.
3. Monitor the cell heaters by clicking the Read ADCs button.
4. Following activation of these three buttons, the OEM Module will be in Standby
Mode, shown in Figure 4-2.
Operation 26
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
The OEM module should be left in Standby Mode when not in use. This will maintain the cell
temperature to the set value, and the OEM module will remain ready to use at any time.
Figure 4-2 Standby Mode screen
4.5.2 Work Mode
Once the cell temperature has reached the target temperature, to start analyzing gas
concentrations, the OEM module must be put into Work Mode.
1. Disconnect from the sensor by clicking the Disconnect button.
2. Click the Work button.
The gas concentration will update in the measurements plot, as shown in Figure 4-3.
Operation of the gas sensor software package is described in more detail in Section 4.8.
To return the OEM module to Standby Mode, click the Work button and follow the
procedure given in Section 4.5.1.
The CT4000 system can be left in either Standby or Work mode, as shown in the following
sections, until routine servicing is required. Routine servicing is described in Section 5:
Operation 27
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Scheduled Maintenance.
Figure 4-3 Work Mode screen
4.6 System shutdown
The gas sensor software can be stopped by clicking the Work button shown in
Figure 4-3, then choosing Quit from the File menu.
The PC can then be shut down by clicking the power button at the top right of the menu bar
(see Figure 4-4).
Figure 4-4 Shutdown button
The OEM module can then be shut down by turning off the power supply.
4.7 Restarting gas sensor software following
system shutdown
If the gas sensor software is closed down using the procedure described in Section 4.6, it
may be restarted using the following procedure:
1. Open a terminal window, by selecting Applications > Accessories > Terminal.
2. A terminal window opens. Type GasSensor-3 and press Enter, as shown in
Figure 4-1.
3. The gas sensor software main screen will be displayed as shown in Figure 4-1.
Operation 28
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 4-5 Terminal startup
4.8 System preferences
The OEM module has a number of startup options that can be configured in the
Preferences window, shown in Figure 4-6. The preferences are usually configured to
automatically load the correct configuration file for the instrument and should be set up to
do this:
1. Select Full screen to set the display to cover the entire PC screen.
2. The Auto load radio button should remain checked to automatically load the
configuration file for the OEM module.
3. Select Auto start to automatically set the OEM module to operational mode on
startup of the PC.
4. Select Fix widgets to fix the order of the icons on the top banner.
5. The font size and plot refresh time may also be configured. Note that decreasing
the plot refresh time from 100 ms may slow down the update rate of the OEM
module.
Operation 29
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 4-6 Preferences window
4.9 Gas sensor software package
Figure 4-7 shows the main screen displayed by the gas sensor software package. Each
element in the window is described in the following paragraphs. The various sections of
the gas sensor software main screen can be resized by clicking on their border and
dragging with the mouse. The exact layout of your screen may consequently vary from
that illustrated here.
The gas sensor software may be configured to start automatically when the PC is started,
using the Preferences tab described in Section 4.8. If the gas sensor software does not start
automatically, it can be started from a terminal window following the steps given in
Section 4.7 and put into Work Mode by following the steps in Section 4.5.2. Once in Work
Mode, the display on the control PC will appear as shown in
Figure 4-3.
Operation 30
Operation Manual Operation
v
g
play
g
y
9.
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 4-7 Gas sensor software screen
1. Menu bar 6. Software
2. Tool
3. Dis
4. Measurements
5. Sensor
bar 7. Monitorin
area 8. Lo
displa
measurements column
4.9.1 Measurements
As shown in Figure 4-7, the main screen of the gas sensor software package displays the
gases being measured, the units of measurement, and the measurement readings
obtained from the OEM module. In Figure 4-7, there are five gases being measured; NO,
, CO
NO
2
calibration (compensated) values being shown. There are ten gas concentrations in total.
In each case, the last recorded measurement is displayed.
1. When the gas sensor is switched on, the measurements in the sensor
2. After a few seconds, the initial gas concentrations, and the OEM module system
and H2O on a single path, with both the initial output and zero / span
2, SO2
measurements column (5) will initially appear as dashes ( - ) until the first readings
are taken.
temperatures and pressures will be displayed in the sensor measurements column
(5).
ersion
window
window
Sensor status
10. System messages
Operation 31
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
3. The Pressure reading is the pressure in Torr in the sample cell.
A Torr is a non-SI unit of pressure, defined as 1/760 of standard atmospheric pressure, and
is equal to the fluid-pressure of 1 mm of mercury.
4. The Internal Temperature reading is the temperature in degrees C in those areas of
the sensor that are not heated and not in direct contact with the gas. If the sensor
is functioning correctly, the internal temperature reading should be between 20
degrees C and 65 degrees C.
5. The Gas Temperature reading is the temperature in degrees C of the sampled gas.
If the Sensor is functioning correctly, the gas temperature reading should be the
same as, or close to, the cell temperature reading.
6. The Cell Temperature reading is the temperature in degrees C of the sample cell.
7. The Pressure Temperature gives the temperature of the pressure sensor in
degrees C, and is used to correct the thermal dependency of the pressure sensor.
8. The Concentration readings are the concentrations of each gas, calculated from
the appropriate laser.
9. In the bottom right-hand corner (6) of the screen is the software version number
and the fitting software version numbers.
10. In the bottom left-hand corner (9) of the screen is the sensor status. The
information given consists of: the operating state of the Sensor; the number of
concentration fits the software is performing per second; and the average number
of concentration fits performed since the sensor was started.
If the gas sensor software display does not display measurements as shown in Figure 4-7
or if the most recent (top) icon in the Log window (10) of the screen is not the blue circular
icon shown, then refer to the Troubleshooting and System Diagnostics in Section 0 of this
manual for guidance.
4.9.2 Log Messages
Log messages (10) are displayed at the left of the screen as shown in Figure 4-7.
1. The first panel of the Log window gives the date and time that the message was
generated and defines the message level, that is, the importance of the message,
by means of the icon at the start of the message.
2. At the start of each Log message is a colored icon. The color of the icon indicates
whether the CT4000 system is operating correctly (blue circular icon), there is a
minor fault or indication of a service that cannot be completed due to the current
status (yellow triangular icon), or a major fault (red square icon with a white cross
inside).
3. The second panel of the Log window contains the text of the System Status
message. Figure 4-7 shows Information messages. A list of all system message
levels with their definition can be found in Section 6.7.1, System messages.
Operation 32
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
4.9.3 Viewing data in graphs
The measured gas concentrations can be viewed in a graph. In GasSensor-3, click Windows
in the top menu bar and then select Show measurement plot from the dropdown list that
appears.
The plot is displayed in the central space and can be moved and stretched like a standard
computer window. The Measurements plot is shown in
Figure 4-3. In this case it has been configured to show the compensated gas
measurements.
1. By clicking the Vertical left box, the Concentration axis can be scaled to closely
examine the measurements. Scale gives the vertical scale of the graph in the
measurand units from top to bottom. Position gives the position of the bottom of
the graph in the measurand units. Note that 1 % vol is equivalent to 10,000 ppm.
2. Similarly, the time axis can be rescaled by choosing a different scale from the
dropdown list. The plot will display the last 600 readings, which is typically
between one and ten minutes of data, but may vary depending on the update rate
of the analyzer. These readings can be exported to a .csv format file by clicking the
appropriate gas button to the right of the graph, then clicking the Export button.
Figure 4-8 Configuration window
The gases which are displayed on the measurement plot can be selected by opening the
configuration file. Click on the Configure button in the tool bar to open the file. The
configuration window will appear as shown in Figure 4-8. Scroll down until the
measurements are displayed, indicated by blue >>. Select the gas that is to be added to
the measurement plot. In the Info tab, select the Post Fits plot and check that the name
matches the name that is displayed on the measurements list. Select the Plot checkbox to
add the measurement to the graph. Figure 4-8 shows selecting NO compensated to be
displayed on the plot.
Operation 33
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
4.9.4 Viewing the laser pulses plot
With the sensor running normally, the laser pulses can be viewed by selecting Show pulses
plot from the View menu.
1. The laser pulses should look similar to those shown in Figure 4-9. There may be
any number of pulses between 1 and 4, depending on your system specification.
The flat line at the end of the pulses should be at 0, and the pulse intensity should
be greater than -0.05. If the pulse intensity is less than -0.05, contact Emerson
Process Management for assistance.
Figure 4-9 Laser pulses plot
2. If background division is used, the pulses displayed will be divided by a
background and will look similar to Figure 4-10. Although this may look like a
system error, if the vertical scale is changed, the pulses may be viewed more
clearly as shown in Figure 4-11. The pulses should be centered around 1 and show
the absorptions as decreasing features. The background function is described in
Section 4.10.
Operation 34
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 4-10 Background Division plot
Figure 4-11 Background Division plot rescaled
4.10 Gas calibration procedure
The gas concentrations measured by the OEM module can be calibrated against a known
sample gas by using the following procedures. The OEM Module configuration has to be
preconfigured to allow zero and span calibration procedures to be used. If you are unable
to complete the steps below, contact Emerson Process Management for further
assistance.
Operation 35
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
4.10.1 Tools required
The calibration of the CT4000 requires the following items:
1. Suitable span calibration gases for each gas measured
2. Nitrogen gas of suitable purity for zero calibration gas.
3. Gas bottle pressure regulator.
4. Appropriate plumbing to connect gas bottle to the OEM module.
4.10.2 Schedule
Zero and span calibration should be carried out at the user defined maintenance period. It
is recommended that both zero and span calibration are carried out at the same time.
4.10.3 Zero calibration
The zero gas concentrations measured by the OEM module when no exhaust gas is flowing
through the OEM module can be calibrated against a known sample gas by using the
following procedure:
1. The analyzer must have been running at a stable temperature for at least thirty
minutes prior to following this procedure.
2. Connect the tube from the calibration gas bottle regulator to the inlet gas port on
the front of the CT4000, or through an external gas manifold.
3. Click Gas calibration at the top of the screen.
4. The Gas calibration window shown in Figure 4-12 opens.
Figure 4-12 Zero calibration
5. Flow the zero gas from the cylinder into the analyzer.
Operation 36
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
6. Allow the concentrations to stabilize and wait for two minutes after stabilization.
7. Click the Concentration dropdown list and then click to select the gas you wish to
calibrate.
8. Click Apply.
9. A system message should appear to indicate that the reference concentration has
been successfully applied.
10. Stop the flow of calibration gas from the cylinder.
11. Close the Gas Calibration window by clicking on the cross at the top right hand
side of the window.
12. Repeat steps 1-11 for the remaining gases as required.
4.10.4 Span calibration
The gas concentrations measured by the OEM Module can be calibrated against a known
sample gas by using the following procedure:
1. The analyzer must have been running at a stable temperature for at least thirty
minutes prior to following this procedure.
2. Connect the tube from the calibration gas bottle regulator to the OEM module.
3. Click on Gas calibration at the top of the screen, as shown in the Figure 4-12.
4. The Gas calibration window shown in Figure 4-13 opens.
Figure 4-13 Span calibration
5. Flow the span gas from the cylinder into the analyzer.
6. Allow the concentrations to stabilize and wait for two minutes after stabilization.
Operation 37
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
7. Click the Concentration dropdown list and then click to select the gas you wish to
calibrate. Click the C alibration type dropdown list and select span.
8. Set the appropriate reference concentration using the up and down arrows by
typing in the correct calibration gas value. Then click the Apply button; as shown in
Figure 4-14 below.
9. Clicking Reset changes the selected gas span calibration value back to its default
setting.
10. A system message appears to indicate that the reference concentration has been
successfully applied.
11. Stop the flow of calibration gas from the cylinder.
12. The Gas Calibration window can then be closed by clicking on the cross at the top
right hand side of the window.
13. Repeat steps 1 to 12 for the remaining gases as required.
4.11 Background division
Background division can be used as a method of minimizing the noise on a laser pulse and
enhancing the sensitivity of the instrument. It is recommended that you discuss your
requirements with the Emerson Process Management technical team to determine
whether background division is suitable for a particular application or gas. For example,
background division of a laser that is monitoring water is challenging, as water may be
present in the external light path, and it may be difficult to completely purge residual water
from the system.
Background division can be activated in the following way:
1. While the system is in work mode, supply zero gas to the analyzer and wait for at
least two minutes for any residual gas to purge from the system.
2. Select the Read Background icon from the top banner or from the Tools dropdown
list.
3. After a short period, a message in log will confirm that a background has been
selected for each laser and that normal working mode has resumed.
4. To renew a background, follow steps 1 to 3 above.
5. To cancel a background, click on the cancel background button on the top
banner, or from the Tools dropdown list.
4.12 X-Shift adjustment
In order to maintain the laser wavelengths during long term operation, a periodic
wavelength optimization is required, as described below.
1. With the sensor taking measurements of each gas, allow the gas concentration
readings to come to a steady value.
2. Click the Tools dropdown list and select Configure, or click the Configure icon on
the top banner.
Operation 38
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
3. Click System in the explorer panel and click on the Monitoring tab, as shown in
Figure 4-14.
4. Check the Enable box under the heading Automatic Xshift calibration.
5. Click Apply, Save, and Close.
Figure 4-14 X-Shift adjustment
6. If the Log window is not visible, select Log from the View dropdown list.
7. Note that the position of the Log window may vary depending on your system. If
any of the laser wavelengths require optimization, a series of notices X-Shift: TEC #
temperature offset adjusted to xxxxx appear at ten second intervals in the Log
window. When the optimization is complete, Path
#, Laser
#: X-Shift has come back
into target range appear. In the example below, Laser 2 is back in the target range,
while Laser 1 is still undergoing optimization:
Figure 4-15 The Log window
8. When all necessary adjustments have completed, repeat steps 1 to 3, uncheck the
enable box, and then repeat step 5.
9. Note that it is possible for all, none, or some of the lasers to require adjustment.
Operation 39
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
4.12.1 After X-shift adjustment
Once the X-shift adjustment has been completed, a zero calibration and a span gas
calibration should be performed as described in Section 4.10, if this functionality of the
software is regularly used to maintain the gas concentrations.
4.13 The laser calibration tool
This procedure describes the steps taken to perform the calibration of the lasers within a
sensor using the calibration tool on gas sensor 3.
This procedure may only be carried out if an etalon is installed in the system. This is an
optional component that may be specified on order. Contact Emerson Process
Management if you are unsure of the configuration of your system.
This procedure is for use by Emerson Process Management personnel an d qualified
personnel who have received training on use of the tool only. For further assistance, please
contact Emerson Process Management.
4.13.1 Required equipment
The following equipment is required:
1. A CT4000 OEM module
2. An etalon assembly for the CT4000
3. A control PC with a suitable version of gas sensor-3 software (version 3.8 or higher)
4. Calibration gas of a concentration of between 30 and 100% of range (refer to
Appendix A of this manual for information on the concentration ranges for your
system).
5. Sample handling system or pump.
If there is no etalon assembly installed in the CT4000 you are using, the following window
will be displayed when the laser calibration tool is activated:
Figure 4-16 Laser calibration feature restriction message
Operation 40
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
4.13.2 Procedure
Calibrate each laser as follows:
1. Ensure the sensor is powered on and in Work Mode, and that the unit has been
powered on for sufficient time for the cell to reach a stable operational
temperature for at least one hour.
2. Supply nitrogen or zero air to the OEM module, wait a few seconds and then press
the Configure button.
3. Select the laser you wish to calibrate (NO is shown in the screenshots in this
procedure) from the dropdown list on the left side.
4. On the Calibration tab, go to the Calibration tool section and click the Run button.
Figure 4-17 shows the opening screen.
Figure 4-17 Selecting the laser and starting the calibration tool
5. On pressing the Run button, the screen in the left hand panel of Figure 4-19 Etalon
calibration will appear in a separate window.
Operation 41
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 4-18 Calibration tool screen
6. Ensure that there is no gas (except nitrogen or zero air) flowing to the sensor.
Press the Read button for the Etalon pulse. This enables the etalon in the sensor,
saves the pulse data from the relevant detector, and displays it. If the etalon
fringes do not look well defined, press the Read button a second time.
7. Now supply the target gas for the laser that is under calibration to the OEM
module. Press the Read button for Gas pulse. The right hand panel of Figure 4-19
shows how the etalon and the gas pulses might look for an NO laser.
8. Before moving to the next page, select the window that will be used in the
calibration by dragging the blue and pink lines to the desired position on the
etalon pulse. When moved on the etalon pulse, the lines will automatically move
on the gas pulse. For example, for NO, both absorption lines should be included in
the calibration and so the window selected should accommodate this. Take care
not to leave either line on the edge of the pulse as this may affect the calibration.
The lines have been correctly adjusted in the right hand panel of Figure 4-19.
9. Click Next. The etalon fringes should now be recognized by the software as shown
in the left hand panel of Figure 4-20. Each valley (or trough) should be marked
with a black point. The software defaults to valleys instead of peaks, but either can
be used. If all of the valleys or peaks are not recognized by the software, change
the value in the Window size box in increments of 1 and click Replot. Repeat this
until all fringes are recognized.
Operation 42
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 4-19 Etalon calibration
10. Click the Calibrate button in the middle of the screen. The software should show
the gas pulse; see an example in the right hand panel of Figure 4-20.
11. Click Next for the final adjustment of the calibration. Enter the gas concentration
and click Plot. Two sets of spectra should appear, the actual spectrum (black) and
the simulated spectrum (red), as shown in the left hand panel of Figure 4-20.
Operation 43
Operation Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 4-20 Final adjustment of calibration
12. Click Auto calibrate. The software should try to match the two spectra to each
other. However, the Auto calibrate feature may not match the spectra exactly.
13. For an accurate calibration, the two spectra are as closely matched as possible, so
that they overlap completely. Further adjustment is normally required after the
auto calibration. There are three parameters that may be adjusted:
a. The Gas Input value (the concentration value in ppm) may be altered by
typing in a new value or by using the up and down arrows. This is mainly
useful for matching the heights of the absorption peaks on the spectra.
b. The X-Shift value may be altered by using the slider, typing in a new value,
or using the up and down arrows. This moves the position of the spectrum
in the X-axis.
c. The Adjust etalon feature may be altered by using the slider, typing in a
new value, or using the up and down arrows. This is the fine adjustment of
the wavelength tuning of the laser to achieve a closer fit.
These parameters can be adjusted several times in order to achieve the best fit. Press the
Save positions button after any adjustment of the X-shift or etalon, especially if the up and
down arrows are used for the adjustments, as Save positions activates the change. The
right hand panel of Figure 4-20 shows the final calibration for the NO laser described in this
procedure.
The Fitting Test feature can be used for a preview of the fitting for the laser before the laser
calibration factors are saved. To activate click the Start button next to Fitting Test.
Operation 44
Operation Manual Operation
QCL-MAN -CT4000-OEM-Rev D October 2015
14. Once a satisfactory calibration has been achieved, click Save polynomial, a nd th is
will write the new polynomial values for the fit to the laser module memory. Click
Finish.
15. As a final check, the fitting for the laser should be viewed. First, click Work on
GasSensor-3. Once the sensor has started properly, click View and then Fittings.
Choose the appropriate path and laser to view the fit. The real data and the
simulated data should be closely overlapped.
16. If the fit is satisfactory, the calibration for the laser is complete. Repeat the
procedure for other lasers as appropriate.
Operation 45
Scheduled Maintenance Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
5 Scheduled Maintenance
5.1 Maintenance
This Section describes the scheduled maintenance for the OEM module. Scheduled
maintenance is also sometimes known as planned preventative maintenance.
5.2 Schedule
The following are maintenance activities and their suggested frequency. Variation in
customer sites may require these activities to be performed more or less often than
indicated; however, the time between checks should not be increased by more than 20%.
Details of the actions to be performed are contained in subsequent paragraphs of this
section, or in Section 0 of this manual.
5.2.1 Weekly check
At least once per week, perform the following preventative maintenance action:
Check the zero and span calibration of the OEM module.
5.2.2 Monthly check
At planned m onthly intervals, perform the following preventative maintenance actions:
1. Perform the weekly check detailed in Section 5.2.1.
2. Run an X-Shift calibration.
3. Purge the long path cell mirrors.
5.2.3 Biannual check
At planned biannual intervals, perform the following preventative maintenance actions:
1. Perform the monthly check detailed in Section 5.2.2.
2. Perform a laser wavelength calibration (if supported b y the system configuration).
5.3 Maintenance activities
Maintenance activities are described in this section or referenced to the relevant part of
this manual.
5.3.1 Zero calibration
Refer to Section 4 for instructions on how to perform a zero calibration. This activity is
performed using the GasSensor-3 software.
Scheduled Maintenance 46
Operation Manual Scheduled Maintenance
QCL-MAN -CT4000-OEM-Rev D October 2015
5.3.2 Span calibration
Refer to Section 4 for instructions on how to perform a span calibration. This activity is
performed using the GasSensor-3 software.
5.3.3 X-shift calibration
Refer to Section 4 for instructions on how to perform an X-Shift calibration. This activity is
performed using the GasSensor-3 software.
5.3.4 Sample cell mirror purge
The sample cell mirrors are purged using the inlet port connector on the OEM module, and
either a high pressure dry nitrogen or high pressure dry zero air gas supply. The purge is
intended to remove any particulate matter or dust that has adhered to the mirror surface
while sampling gas.
The sensor should be powered off and allowed to cool for at least twelve hours prior to
.
performing a mirror purge
when cold purge gas is applied to the mirror surface. If the system is purged when the gas
cell is heated, the purge gas should also be heated to the same temperature as the gas cell
prior to entering the OEM module purge port.
This is to allow the system to cool and to prevent thermal shock
To purge the mirrors, connect the purge air gas supply to the inlet port. Disconnect the
exhaust port connection to prevent pressure buildup within the cell. Set the supply
pressure to one bar, and open the purge air supply. Apply the purge gas for two minutes.
Turn off the air supply and disconnect the purge supply.
5.3.5 Laser wavelength calibration
Refer to Section 4 for instructions on how to perform a laser wavelength calibration. This
activity is performed using the GasSensor-3 software. An etalon assembly is required to
perform a laser wavelength calibration, and this is an optional accessory depending on the
system configuration. Contact Cascade Technologies if you are unsure of the suitability of
your system to perform this maintenance activity.
Scheduled Maintenance 47
Failure Diagnosis Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
6 Failure Diagnosis
6.1 Introduction
This section contains the failure diagnosis procedures for the OEM module.
HEAVY ITEM
•
Handle the OEM module with caution during unpacking, installation,
maintenance, and transport to prevent crushing of hands, feet, or other body
parts.
•
The OEM module weighs 13 kg and should be lifted with caution. Wear suitable
protective gloves and protective footwear. When preparing the OEM module for
transport by air, road, or rail, safeguard the OEM module against movement or
break-away during transport by securely strapping it in place.
6.2 Failure diagnosis principles
The failure diagnosis procedures described in this section makes the assumption that any
host equipment is fully functional. Ensure that the host equipment is fully serviceable
before performing failure diagnosis on the OEM module.
Electrical power to operate the OEM module is provided by the host equipment.
All controls and indicators are on the OEM module or control PC unless otherwise
indicated.
Failure diagnosis of the OEM module comprises interpretation of the system messages
displayed on the computer and visual examination.
6.3 Repairable faults
The following items in the cell assembly are repairable by maintenance personnel who
have been trained and are authorized to carry out repairs on the OEM module. In all cases,
the repair is by direct replacement of the faulty item with a known serviceable item:
•
Cell heaters
•
Cell thermistors
•
Cell thermal cut out
•
Pressure sensor
•
The complete cell assembly
Failure Diagnosis 48
Operation Manual Failure Diagnosis
QCL-MAN -CT4000-OEM-Rev D October 2015
The following items in the Laser Module Side are repairable. In all cases the repair is by
direct replacement of the faulty item with a known serviceable item:
•
Detector
•
Etalon assembly
•
All four Laser Modules
•
Digitizer PCA
•
Peripheral PCA
•
Power Distribution PCA
•
Detector TEC PCA
The other items in the OEM module that are repairable are as follows. In all cases the repair
is by direct replacement of the faulty item with a known serviceable item:
•
The control PC (where supplied by Emerson Process Management)
•
Ethernet connector
•
DC voltage connector
•
AC voltage connector
•
12 V ceramic fuse
6.4 Faults only repairable by Emerson Process
Management
If any of the following items in the OEM Module are unserviceable, the complete OEM
Module must be returned to Emerson Process Management for repair:
•
The cell internal mirrors
•
The cell windows
•
The cell insulation and pipework
•
The motherboard PCA
•
Any other component not listed in the repairable parts
6.5 Tools and test equipment
The tools required to perform scheduled maintenance on the OEM Module are standard
. The
hand tools
meter that may be used to perform continuity checks on electrical wiring during an
Inspection.
only test equipment required when repairing the OEM Module is a multi-
6.6 Wiring diagram
To assist with Failure Diagnosis, a layout and wiring diagram for the OEM module is shown
in Figure 6-1. The Cable Assembly configurations are shown in Figure 6-2 and Figure 6-3.
Failure Diagnosis 49
Failure Diagnosis Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
These diagrams may be used to locate the position of a wiring connector should it become
disconnected.
BURNS
Some parts of the OEM module are heated to 200 °C. To prevent burns do not touch any
of the hot parts. Always assume that all parts of an OEM Module are hot unless it has been
switched off and allowed to cool down.
Before touching, handling, fitting, removing, or performing any maintenance on the OEM
module, ensure that it has been switched off and allowed to cool for at least sixty minutes.
Before performing any maintenance on, or in the vicinity of, the analysis cell, allow the
OEM module to cool for at least twelve hours as the analysis cell is insulated against heat
loss.
When handling the OEM module always use suitable protective gloves.
Personal injury and/or damage to property may result if these safety precautions are not
observed. If a burn is received seek medical treatment immediately.
Failure Diagnosis 50
Operation Manual Failure Diagnosis
QCL-MAN -CT4000-OEM-Rev D October 2015
Figure 6-1 CT 4000 OEM module wiring diagram
Failure Diagnosis 51
Failure Diagnosis Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 6-2 CT4000 OEM module cable assembly wiring detail
Failure Diagnosis 52
Operation Manual Failure Diagnosis
QCL-MAN- CT-4000-OEM-Rev D October 2015
Figure 6-3 CT4000 OEM module cable assembly wiring detail continued
Failure Diagnosis 53
Failure Diagnosis Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
FLAMMABLE SUBSTANCES
Some parts of the OEM module may reach temperatures of 200 °C and may present an
ignition source. Exercise care when using oil, paint, cleaning rags, and other flammable
substances near the OEM module. A fire may result if this precaution is not observed.
Always assume that all parts of an OEM module are hot unless it has been switched off and
allowed to cool down.
ELECTRIC SHOCK
The OEM Module operates using mains voltage that is dangerous to life. Ensure that the
OEM Module is disconnected from the mains supply before removing any outer covers or
performing any work inside the OEM Module. This is particularly important when working
at heights.
Death, personal injury, and/or damage to persons and/or property may result if this is not
observed.
Besides the danger from high voltages, the seals against water and dust can be damaged
or impaired if the OEM Module is closed or opened incorrectly.
HAZARDOUS SUBSTANCES
The OEM module may contain hazardous substances. Always handle OEM module
assemblies and components with extreme caution.
Gas handling components within the OEM module will contain particulate matter residue
from the sample gases. Over the life of the OEM module, the concentration of particulate
matter will become enriched within the gas handling components. The particulate matter
comprises carbon, ash, soluble organic fraction, and, depending upon the type of fuel
used, may include compounds derived from sulfur, which are acidic in nature and may
cause respiratory problems. When performing repairs and maintenance on the OEM
Module:
•
Handle used gas handling components with extreme caution.
•
Avoid direct skin contact with used gas handling components.
•
Do not smoke, eat, or drink in the work area.
•
Wear goggles or eye shields.
•
Wear a suitable face mask to protect against inhalation of particulate matter.
•
Keep food and beverages away from the OEM module.
•
Do not wet fingers, eyes, or any exposed skin.
•
Pack used gas handling components for disposal in sealed packaging and label it
Contaminated.
•
Dispose of contaminated items as hazardous material according to the applicable
local, national, or international health and safety regulations and pollution
regulations.
Failure Diagnosis 54
Operation Manual Failure Diagnosis
QCL-MAN- CT-4000-OEM-Rev D October 2015
6.7 General troubleshooting and diagnostics
information
The OEM module is specifically designed to run unattended indefinitely, to automatically
resolve system issues, and to recover from power failures and return to a normal working
state. This troubleshooting guide is intended to assist maintenance personnel, who have
been trained to service the OEM module, when the OEM module has not appeared to be
working normally for a period of more than five minutes. If the procedures given in this
section fail to return the OEM module system to normal operation, notify your service
agent for further assistance.
6.7.1 System messages
Table 6-1, Table 6-2, and Table 6-3 all list system messages that can appear in the System
Messages panel of the Gas Sensor software window and describe the meaning of each
message. The system messages are divided into three types:
• Notices
• Warnings
• Errors
1. A system message that is a Notice is for information only and requires no action by
the user.
2. A system message that is a warning indicates that a minor fault has occurred. The
problem cannot be rectified by the user, but may be automatically rectified by the
OEM module. A suitably qualified and trained engineer is required to rectify faults
that are not automatically rectified.
3. A system message that is an Error indicates that a major fault has occurred. The
problem cannot be rectified by the user or the OEM module. A suitably qualified and
trained engineer is required to rectify the fault.
Failure Diagnosis 55
Failure Diagnosis Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Table 6-1 System notice messages
Message and type Meaning
NOTICE
No action required.
Sensor, communication
recovered;
Communication with the
sensor recovered
Sensor {name},
initialized; Sensor
initialized
Sensor {name},
initialized; {s ystem
firmware}
Laser {number} started
TEC {number} started
TEC {number} stable
Heater Cell started
Laser {Laser N}:
X-Shift
has come back into
target range
The gas sensor software has reconnected via Ethernet
to the exhaust analyzer.
The Sensor with {name} has been successfully initialized.
The computer has successfully initialized the exhaust
analyzer with {name} and {firmware version}.
The laser {identified by its number} has started
and is operating normally.
The thermoelectric controller (TEC) {identified by its
number} has started.
The thermoelectric controller (TEC) {identified by its
number} is operating normally.
The heater in the analysis unit has started and is
operating normally.
The automatic X-Shift adjustment has changed the laser
TEC temperature to within the normal range.
Failure Diagnosis 56
Operation Manual Failure Diagnosis
w
QCL-MAN- CT-4000-OEM-Rev D October 2015
Table 6-2 System warning messages
Message and type Meaning
WARNING
Repairs (if required) can only be
performed by a suitably trained and
qualified engineer.
has not been possible to
GasSensor, log to file error; Error while
logging to file; system error while writing
logs
It
Sensor log file to the computer file
system.
rite a Gas
Laser, TEC warning; TEC {TEC N}
not in
+-5 deg C range of set point
Sensor, Unknown error received; network
system error
SpecFit, fit error; Error returned by the
fitting routine, pulse is flat line
SpecFit, fit error; Error returned by the
fitting routine, tail of pulse is not just noise
SpecFit, fit error; Error returned by the
fitting routine, pulse is too noisy {s/n}
Laser {Laser N}:
X-Shift is {above/below}
warning level
X-Shift: TEC {TEC N}
temperature offset
adjusted to x.xxxxx
Laser {Laser N}:
X-Shift
Concentration=xxxx.xx is {above/below}
below the {maximum/minimum} level
The thermoelectric controller (TEC)
identified as {TEC
N} is outside the
normal acceptable range.
A non-fatal error related to the
Ethernet communications between
the exhaust analyzer and the
computer. Refer to Section 6.7.3:
Communication fault messages.
The laser pulse has no shape and
appears to be just a flat line.
The tail of the laser pulse is not shaped as
expected.
The shape of the pulse contains too
much noise for the fitting routine to
calculate an accurate concentration.
The automatic X-Shift adjustment has
changed the laser TEC temperature to
within the warning range.
The automatic X-Shift adjustment has
changed the laser TEC temperature to
that shown.
The measured gas concentration is
outside the limits that allow the
automatic X-Shift adjustment of
the laser TEC temperature to be
adjusted.
Failure Diagnosis 57
Failure Diagnosis Operation Manual
f
g
October 2015 QCL-MAN -CT4000-OEM-Rev D
Table 6-3 System error messages
Message and Type Meaning
ERROR
Laser, TEC error; TEC {TEC N}
10 deg C range of set point
Sensor, communication
Communication with the sensor lost
Sensor, communication lost;
Communication with the sensor lost
Path {Path N},
{above/below} error level
Laser {Laser N}:
not in +-
ailed;
X-Shift is
Repairs can only be performed by a
suitably trained and qualified engineer.
The thermoelectric controller (TEC)
identified as {TEC
warning acceptable range.
Some communications via Ethernet
between the computer and the
exhaust analyzer have been lost.
Refer to Section 6.7.3:
Communications via Ethernet between
the computer and the exhaust analyzer
have been lost for greater than a set
time-out period. Refer to Section
6.7.3: Communication fault
messa
The automatic X-Shift adjustment has
changed the laser TEC temperature to
above or below the error range.
es.
N} is outside the
6.7.2 Warning or error message significance
A warning or error message that is displayed again and again with new time stamps
indicates that the gas concentrations being measured may be compromised. If the
warning or error message does not reappear with a new time stamp after a period of
several seconds, and there is no message stating “communication lost”, then this indicates
that the problem has been resolved.
6.7.3 Communication fault messages
The one warning and two error messages related to communication failures between the
control PC, the CT4000 OEM module, and an external data logger or reader are usually
caused by:
•
The Ethernet cable being disconnected.
•
Power loss to the Sensor.
•
Power loss to the Ethernet switches (if installed).
If these three communication fault messages are not followed by the recovery notice:
“Sensor, communication recovered; Communication with the sensor recovered”, then
stop the software and shut down the sensor as described above. If the problem persists
when the sensor is restarted, contact Emerson Process Management for assistance.
Failure Diagnosis 58
Operation Manual Failure Diagnosis
QCL-MAN- CT-4000-OEM-Rev D October 2015
6.7.4 Resolution of warning or error messages
For warning or error messages that are not resolved automatically by the CT4000 system,
or if the Gas Sensor software seems to have frozen or is not behaving as described in this
manual, then follow the system shutdown and system startup instructions in Sections
4.6and 4.7 and re-start the whole OEM module. If the same faults reoccur, then follow the
fault resolution procedures given below.
6.8 Simple fault resolution
The faults described below may be investigated and possibly rectified by a suitably trained
and qualified engineer.
6.8.1 No gas measurement change
6.8.1.1 Symptom
Measurements do not change when measurement gas is supplied to the analyzer.
6.8.1.2 Possible cause
There is no flow through the measurement cell. The OEM module does not have an internal
sample handling system, and it is the user’s responsibility to flow gas through the
measurement cell. Check the external pump and gas supply.
6.8.2 Gas temperature low
6.8.2.1 Symptom
The temperature of the sample cell is outside of specification.
6.8.2.2 Possible causes
6. The cell is heating up after startup; wait for the temperature to become stable and
then monitor for at least ten minutes. If temperature is still too low, then consider
the following other possible causes.
7. The AC voltage is disconnected; check that the AC voltage is connected and at the
voltage specified in Appendix A.
8. The cell heaters are faulty; replace cell heaters. This is a specialist maintenance
task; contact Emerson Process Management for parts and assistance.
Failure Diagnosis 59
Failure Diagnosis Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
6.8.3 Laser signal level low
6.8.3.1 Symptom
The size of the laser signal is low; the baseline to peak measurement is less than 0.05V.
6.8.3.2 Possible causes
9. The cell mirrors are contaminated; purge the sample cell mirrors as described in
Section 5.3.4.
10. The sensor optics are misaligned; contact Emerson Process Management for
instruction.
11. The cell window is contaminated; contact Emerson Process Management for
instruction.
6.9 Visual examination of the OEM module
A visual examination of the OEM module is recommended as the next step in failure
diagnosis after interpreting the system messages. The upper and lower sections of the
OEM module should be assessed. The section components are illustrated in Figure
6-5,Figure 6-6, and Figure 6-7, and the inspection process is described below. If any
components are found to be faulty, replacements may be purchased from Emerson
Process Management and will be supplied with instructions for installation. If a
component is found to be faulty and is not a repairable part, please contact Emerson
Process Management for technical support.
ELECTRIC SHOCK
The OEM Module operates using mains voltage that is dangerous to life. Ensure that the
OEM Module is disconnected from the mains supply before removing any outer covers or
performing any work inside the OEM Module. This is particularly important when working
at heights.
Death, personal injury, and/or damage to persons and/or property may result if this is not
observed.
Besides the danger from high voltages, the seals against water and dust can be damaged
or impaired if the OEM module is closed or opened incorrectly.
6.9.1 Visual inspection of the CT4000
1. Visually examine the exterior of the OEM module for signs of damage.
2. Visually examine the upper section of the OEM Module around the cell assembly
for signs of damage. Refer to Figure 6-6 and Figure 6-7.
3. Remove the lower cover from the underside of the OEM module as described in
Section 6.9.2.
Failure Diagnosis 60
Operation Manual Failure Diagnosis
QCL-MAN- CT-4000-OEM-Rev D October 2015
4. Perform a visual inspection of the optical and electrical components in the lower
section of the OEM module. Refer to Figure 6-5, Figure 6-6, and Figure 6-7.
5. Refit the lower cover using the reverse of the removal instructions in Section
6.9.2.
If any components are found to be faulty, and they are some of the repairable parts listed in
Section 6.3, the parts may be replaced using spare parts and service procedures provided
by Emerson Process Management or their distribution partners. If a component is found
to be faulty and is not a repairable part, please contact Emerson Process Management for
technical support.
If any loose connections are found in the lower electronic tray, refer to the layout and
wiring diagrams shown in Figure 6-2, Figure 6-3, and Figure 6-4 to identify the connection
points and repair the connection.
6.9.2 Removing the lower cover
The lower cover on the underside of the CT4000 OEM module must be removed in order to
perform repairs in this section. Refer to Figure 6-4 below and remove the lower cover as
follows:
1. Turn the OEM module upside down so it rests on the upper lips (1.)
2. Remove and retain the six M6 by 6 screws and associated spring and plain washers
(2).
3. Slide the lower cover (3) upwards and remove it from the OEM Module.
4. Examine the lower cover for signs of physical damage.
5. Perform a visual inspection of the CT4000 OEM module electronic and optical
components. The components are identified in Figure 6-5, Figure 6-6, and Figure
6-7.
Failure Diagnosis 61
Failure Diagnosis Operation Manual
3.
x 6 mm
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 6-4 Removal of the lower cover
1. Upper
2. M6
lips on OEM Module
screw with washers
Lower cover
6.9.3 Replacing the lower cover
1. Slide the lower cover (3) downwards onto the OEM module.
2. Use the six M6 by 6 screws and the associated spring and plain washers to reattach
the lower cover.
3. Turn the OEM module right side up.
Failure Diagnosis 62
Operation Manual Failure Diagnosis
xis
4.
QCL-MAN- CT-4000-OEM-Rev D October 2015
6.9.4 Component identification
Figure 6-5 to Figure 6-7 provide schematic diagrams of the CT4000 OEM module and are
shown to aid component identification during a visual inspection. Refer to Section 6.3 for a
list of repairable items in each section of
Figure 6-5 Components in the electronic section
the OEM module.
1. Laser
2. Off-a
module
parabolic mirror
3. Detector module
Etalon assembly (optional)
Failure Diagnosis 63
Failure Diagnosis Operation Manual
y
October 2015 QCL-MAN -CT4000-OEM-Rev D
Figure 6-6 Components in laser module side
5. Peripheral PCA 9. Heater rods (inside cell body)
6. Detector
7. Detector
8. Digitizer PCA (behind
TEC PCA 10. Gas temperature thermistor
module 11. Cell assembl
12.
Thermal cut out
detector)
Failure Diagnosis 64
Operation Manual Failure Diagnosis
A
y
v
AC
v
QCL-MAN- CT-4000-OEM-Rev D October 2015
Figure 6-7 Components in PCB side
.
13. Pressure Sensor
14. Motherboard
15. Power
16. Solid
distribution PCA
state relay PCA
PCA
ssembl
17. Ethernet connector
18. DC
19.
oltage connector
oltage connector
Failure Diagnosis 65
Appendix A: Model CT4142 Operation Manual
October 2015 QCL-MAN -CT4000-OEM-Rev D
Appendix A: Model CT4142
The system configuration and performance characteristics of the model CT4142 are
specified in this appendix.
A.1 System specification
Basic performance characteristics of the OEM module supplied with this manual are given
in Table A-1.
Table A-1 System Specification
Path 1
Attribute Gas Value Units
Range
Detection limit
Zero noise
NO
NO2
SO2
CO2
CO
CH4
H2O
NO
NO2
SO2
CO
CH4
CO2
H2O
NO
<
2,000
500
2,000
15
3,000
3,000
20
5
1
5
5
5
0.1
0.1
5
ppm
ppm
ppm
%
ppm
ppm
%
ppm
ppm
ppm
ppm
ppm
%
%
ppm
NO2 <
CO
<
CH4 <
SO2 <
CO2 <
H2O <
Span noise
Appendix A: Model CT4142 66
NO < 40
NO
2
CO < 60
CH
4
1
5
5
5
0.1
0.1
<10
< 60
ppm
ppm
ppm
ppm
%
%
ppm
ppm
ppm
ppm
Operation Manual Appendix A: Model CT4142
QCL-MAN- CT-4000-OEM-Rev D October 2015
Attribute Gas Value Units
Path 1
24 hour zero drift
SO
2
CO
2
H2O < 0.4
NO < 5
NO
2
CO < 5
CH
4
SO
2
CO
2
H2O < 0.1
< 40
< 0.3
< 1
< 5
< 5
< 0.1
ppm
%
%
ppm
ppm
ppm
ppm
ppm
%
%
A.2 Cross-interference performance
The OEM module supplied with this manual is designed to be immune to the crossinterferent gases listed in Table A-2. The response of the analyzers will be < the detection
limit when the cross-interferent is supplied at the listed concentration.
Table A-2 Cross-interference performance
Gas Concentration Units
Water (H2O)
Nitric oxide (NO)
Nitrogen dioxide (NO2)
Nitrous oxide (N2O)
Methane (CH4)
Carbon monoxide (CO)
Oxygen (O2)
20
2,000
500
100
3,000
3,000
20
%
ppm
ppm
ppm
ppm
ppm
%
A.3 Linearity performance
The linearity performance of the OEM module supplied with this manual is given below.
•
A linear fit to the data set will give a maximum error of < 2 % when analyzed to
MCERTS standards.
•
A linear fit to the data set will give an R2 coefficient of > 0.999.
•
Test data points are 0, 10, 30, 50, 70, 90 and 100% of the range.
A.4 Performance characteristics
Performance characteristics of the OEM Module supplied with this manual are given in
Table A-3.
Appendix A: Model CT4142 67
Appendix A: Model CT4142 Operation Manual
— 70
— 70
October 2015 QCL-MAN -CT4000-OEM-Rev D
Table A-3 Performance characteristics
Attribute Value Units
Cell temperature
Cell pressure 300 ± 50
190
C
Factory set
Torr
Comments
Variation in concentration
reading < 2% of reading per 10
Torr, test range 300 to 350 Torr
Path length
Rise time (T
T
)
90
10
Measurement
to
2
<
>1
5
m
s
With a flow rate of > 5 L/min
Hz
All measurements
frequency
Operational
temperature
-20
degrees C
Variation in concentration
reading < 2% of reading per 10
°C, test range 25 °C to 45 °C.
Storage
temperature
-20
degrees C
Allow system to
acclimatize in noncondensing environment
Warm up time
90
minutes Temperature drift < 2% after 90
minutes
Vibration
resistance
20 —
0.02
100
Hz
G
Variation in concentration
reading < 1% of full scale
Appendix A: Model CT4142 68
Operation Manual Appendix A: Model CT4142
QCL-MAN- CT-4000-OEM-Rev D October 2015
A.5 Operational and physical characteristics
Operational and ph ysical characteristics of the OEM module supplied with this manual are
given in Table A-4.
Table A-4 Operational and physical characteristics
Attribute Value Units Comments
Sensor supply voltage + 12
V
DC
Heater supply voltage
Dimensions 498 x 218 x 260
Weight
Control PC t ype
Control PC dimensions
Control PC weight
240
13
n/a
n/a
n/a
V
AC 50 — 60 Hz
mm
Depth x width x
height
kg
Supplied by
customer
Supplied by
customer
Supplied by
customer
Appendix A: Model CT4142 69
Appendix B: Model CT4125 Operation Manual
%
%
October 2015 QCL-MAN -CT4000-OEM-Rev D
Appendix B: Model CT4125
The system configuration and performance characteristics of the model CT4125 are
specified in this appendix.
B.1 System specification
Table B-1 System specification
Path 1
Attribute Gas
Range SO
Detection limit SO
Zero noise SO
Span noise SO
24 hour zero drift SO
24 hour span drift SO
CO
CO
CO
CO
CO
CO
2
2
2
2
2
2
2
2
2
2
2
2
Value
100
15
3
0.1
< 3
< 0.1
< 2
< 0.3
< 3
< 0.1
< 2
< 0.3
Units
ppm
%
ppm
%
ppm
%
ppm
%
ppm
%
ppm
%
B.2 Cross-interference performance
The OEM module supplied with this manual is designed to be immune to the crossinterferent gases listed in Table B-2. The analyzer’s response will be less than the detection
limit when the cross-interferent is supplied at the listed concentration.
Table B-2 Cross-interference performance
Gas Concentration
Water (H2O) 20
Nitric oxide (NO) 1,000
Nitrogen dioxide
(NO2)
Nitrous oxide (N2O) 100
Methane (CH4) 100
Carbon monoxide
(CO)
200
1,000
Oxygen (O2) 20
Units
ppm
ppm
ppm
ppm
ppm
Comments
B.3 Linearity performance
The linearity performance of the OEM module supplied with this manual is given below.
A linear fit to the dataset gives a maximum error of < 2 % when analyzed to
MCERTS standards.
2
A linear fit to the dataset gives an R
coefficient of >0.999
Test data points are 0, 10, 30, 50, 70, 90, and 100% of the range.
Appendix B: Model CT4125 70
Operation Manual Appendix B: Model CT4125
m
s
Hz
— 70
V
V
Mm
Kg
QCL-MAN- CT-4000-OEM-Rev D October 2015
B.4 Performance characteristics
Performance characteristics of the OEM module suppled with this manual are given in
Table B-3.
Table B-3 Performance characteristics
Attribute Value
Cell temperature 190
Cell pressure 300 ± 50
Path length 5
Rise time (T
Measurement
frequency
Operational
temperature
Storage temperature -2- - 70
Warm-up time 90
Vibration resistance 20 — 100
to T90) < 5
10
> 1
-20
0.02
Units
° C
Torr
° C
° C
Minutes
Hz
G
Comments
Factory set
Variation in
concentration
reading < 2% of
reading per 10 Torr,
test range 300 to
500 Torr
With a flow rate of >
5 L/min
All measurements
Variation in
concentration
reading < 2% of
reading per 10 °C,
test range 25 to 45
°C
Allow system to
acclimatize in noncondensing
environment
Temperature drift <
2% after 90 minutes
Variation in
concentration
reading < 1% of full
scale
B.5 Operational and physical characteristics
Operational and physical characteristics of the OEM module supplied with this manual are
given in Table B-4.
Table B-4 Operational and physical characteristics
Attribute Value
Sensor supply voltage + 12
Heater supply voltage 240
Dimensions 498 x 218 x 260
Weight 13
Control PC type N/A
Control PC dimensions N/A
Control PC weight N/A
Appendix B: Model CT4125 71
Units
Comments
DC
AC 50 — 60 Hz
Depth x width x height
Supplied by customer
Supplied by customer
Supplied by customer
EmersonProcess.com/GasAnalysis
AnalyticExpert.com
youtube.com/user/RosemountAnalytical
twitter.com/Rosemount_News
facebook.com/Rosemount
QCL-MAN-CT4000-OEM-Module
Revision D
2015
HEADQUARTERS
Emerson Process Management
Glendevon House
Castle Business Park,
Stirling FK9 4TZ UK
T +44 (0) 1786 447721
F +44 (0) 1786 475822
qcl.csc@emerson.com
©2015 Emerson Process Management. All rights reserved.
The Emerson logo is a trademark and service mark of Emerson Electric Co. All other marks are
property of their respective owners.
The contents of this publication are presented for information purposes only, and, while effort
has been made to ensure their accuracy, they are not to be construed as warranties or
guarantees, express or implied, regarding the products or services described herein or their use
or applicability. All sales are governed by our terms and conditions, which are available on
request. We reserve the right to modify or improve the designs or specifications of our products
at any time without notice.
Loading...
