Rosemount™ 975 Series
Flame Detectors
Certification Information
00825-0500-4975, Rev AC
June 2021
Page 2
Contents
Page 3

1 Ex approvals

Manufacturer
Rosemount
6021 Innovation Blvd
Shakopee, MN 55379
WARNING
Electrical shock
Keep covers tight while circuits are alive.
WARNING
Attention
Garder le couvercle bien fermé tant que les circuits sont sous tension.
Or the equivalent.
WARNING
Install a shield within 18-in. (457.2 mm) of the enclosure.
WARNING
Attention
Un scellement doit être installé à moins de 18-in. (457.2 mm) du boîtier.
Page 4
Table 1-1: ATEX/IECEx
Classification Standards
Rosemount 975 Legacy Series
II 2 G D
Ex db eb IIC T4 Gb Ex tb IIIC T100 °C Db (Ta -40 °C to +75 °C) IP66/68
Rosemount 975 Series
II 2G D
Ex db eb IIC T4 Gb Ex tb IIIC T110 °C Db (Ta –50 °C to +85 °C) IP66/68
ATEX
EN IEC 60079-0:2018 General Requirements
EN 60079-1:2014 Flameproof Enclosure
EN 60079-7:2015/ A1:2018 Increased Safety
EN 60079-31:2014 Dust Protection by Enclosure
IECEx
EN IEC 60079-0:2018 Ed.7 General Requirements
IEC 60079-1:2014 Ed.7 Flameproof Enclosure
IEC 60079-7:2015 Ed.5 Increased Safety
IEC 60079-31:2013 Ed.2 Dust Protection by Enclosure
Table 1-2: FM/FMC
Rosemount 975 Legacy Series Rosemount 975 Series
Class I, Division 1, Groups B, C, and D, T4A
Class II, III, Division 1, Groups E, F, and G, T4A
Class I, Division 2, Groups A, B, C, and D, T4
Ta = -40 °C to +75 °C Type 6P; IP 66/68 2 m for 45 minutes
Class I, Division 1, Groups B, C, and D, T4A
Class II, III, Division 1, Groups E, F, and G, T4A
Class I, Division 2, Groups A, B, C, and D, T4
Ta = -50 °C to +85 °C Type 6P; IP 66/68 2 m for 45 minutes
Table 1-3: United States and Canadian Standards
United States standards Canadian standards
Class number Date Class number Date
FM Class 3600 2018 CSA C22.2 No. 0.4 2013
FM Class 3615 2018 CSA C22.2 No. 0.5 R2012
FM Class 3616 2011 CSA C22.2 No. 25 R2009
Page 5
Table 1-3: United States and Canadian Standards (continued)
United States standards Canadian standards
Class number Date Class number Date
NEMA® 250 2014 CSA C22.2 No. 30 R2012
ANSI/IEC 60529 2004 CSA C22.2 No. 94 R2011
ANSI/FM Class 3260 2015 CSA C22.2 No. 60529 R2010
N/A N/A ULC/ORD-C386-15 September
2015
Table 1-4: CSA/US
Classification Applicable requirements
Rosemount 975 Legacy Series
Class I, Division 1, Groups B, C, and D, T4A Class II, III, Division 1, Groups E, F, and G, T4A
Class I, Division 2, Groups A, B, C, and D, T4
Ta = -40 °C to +75 °C IP66/68 Type 6P; IP 66/68 2 m for
45 minutes
Rosemount 975 Series
Class I, Division 1, Groups B, C, and D, T4 Class II, III, Division 1, Groups E, F, and G, T4
Class I, Division 2, Groups A, B, C, and D, T4
Ta = -50 °C to +85 °C IP66/68 Type 6P; IP 66/68 2 m for
45 minutes
CSA C22.2 No. 0-20, 11th Edition
CSA C22.2 No.61010-1-12 (R2017), 3rd Edition
CSA C22.2 No. 25-17, 4th Edition
CSA C22.2 No. 30:20, 4th Edition
CSA C22.2 No. 213-17, 3rd Edition
CSA C22.2 No. 94.2-15, 2nd Edition
CSA C22.2 60529 :16, 2nd Edition
UL 61010-1, 3rd Edition UL 121201, 9th Edition UL 50E, 2nd Edition FM Class 3600:2018 FM Class 3611:2018 FM Class 3615:2018 FM Class 3616:2011
Table 1-5: TR CU Markings
Rosemount 975 Legacy Series Rosemount 975 Series
1 Ex db eb IIC T4 GbX Ex tb IIIC T100 °C Db X
(-40 °C ≤ Ta ≤ +75 °C)
1 Ex db eb IIC T4 Gb X Ex tb IIC T110 °C Db X
(-55 °C ≤ Ta ≤ +85 °C)
Page 6

2 EN54-10

The detector classes' sensitivity settings are as follows:
Model Sensitivity settings - Class I
Rosemount 975
Rosemount 975MR 15, 40, 45, 65, 90
Rosemount 975HR
Rosemount 975UF 15, 28
Rosemount 975UR
Page 7

3 DNV

Table 3-1: Approval Standards
Type approval MED B MED D
Complies with: DNV GL rules for classification:
Rosemount 975MR
Rosemount 975HR
Rosemount 975UF
Rosemount 975UR
ships, offshore units, and high speed and light craft
Classes: • IEC
Temperature D
Humidity B
Vibration B
EMC B
Enclosure C
Tests carried out:
• DNVGL-CG-0339.
• EN54-10:2002+A1:2005.
(EU) 2017/306, item number MED/3.51e. SOLAS 74 as amended, Regulation II-2/7 & X/3, 1994 HSC Code 7, 2000 HSC Code 7, FSS Code 9 and IMO MSC.1/Circ. 1242
60092-504 (2001) inc Corr 1: (2011)
• IEC 60533
(1999)
• IEC 60945
(2002)
• EN54-10:
(2002) / A1(2005)
Annex II, Module D in the directive 2014/90/EU and regulation (EU) 2017/306
• 2014/90/EU
• (EU)
2017/306
CAUTION
Equipment damage
This device is not field repairable due to the meticulous alignment and calibration of the sensors and the respective circuits. Modifying or repairing the internal circuits may impair the system's performance and void the Emerson product warranty.
Do not attempt to modify or repair the internal circuits or change their settings.
Page 8

4 Approvals

The flame detector series has been assessed and rated in accordance with several directives that are included in this document.
EN54-10 approval
The Rosemount 975 Flame Detector series is approved per EN54-10 and CPD.
• The detector is approved per EN54-10 by FM.
• This test includes a functional test, environmental test, EMI/EMC test,
and software check.
• For more details see FM Report No. XXXXX.
Marking
The flame detector series is labeled with the CE mark in accordance with the ATEX Directive 2014/34/EU.
Serial number
The flame detector is marked with a serial number and the year of manufacture.
FM fuel test response according to FM 3260
The following fuels: Gasoline, N-heptane, diesel, JP5, kerosene, alcohol 95%, IPA, methanol, methane, LPG, polypropylene, paper, hydrogen, magnesium alloy, gun powder, fireworks, cooking oil, mineral oil (20w50), wood, ethylene glycol, butyl acrylate, vinyl acetate, flammable adhesive (flash point < 140 °F [60 °C]), solvents, oil paint, jet A1, and battery.
Please refer to the technical manual for fuel sensitivities.
