Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Table of Contents
SECTION 1 Overview of the HIU-MODBUS Implementation
SECTION 2 Modbus Functions and Data Format
SECTION 3 Modbus Hardware Implementation
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Modbus Implementation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
User-assignable Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Integer Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Integer Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Character Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
Coded Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Packed Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Floating-Point Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Floating-point Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
The Two 16-bit Registers Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-3
Status Bits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Exception Responses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Data Out Of Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
Loopback Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-4
MCAP Signal Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Modbus Host Signal Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
SECTION 4
Modbus
Configuration
SECTION 5
Integer Register
Assignments
User-assignable Registers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
System Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Process Variables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-2
Process Variable Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
PV Alarm Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
User Assignment For Integer Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Installation Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-12
i
SECTION 6 Floating-point Register Assignments
Two 16-bit Registers Format . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Reserved Registers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Process Variables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
PV Alarm Variables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
Zero and Full Scale Variables for Integer Modbus . . . . . . . . . . . . . . . . . . . . . . . 6-2
Correction Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Strapping Table Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Installation Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-8
SECTION 7 Status Bit Assignments
Alarms Status - Internal State 7-1
Alarm Status Enables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-1
Alarm Output Control/State . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
System Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
HIU Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-2
HIU Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
Local Display Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-3
HART Write Protect Selections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Modbus Write Protect Selections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-5
Product Transfer Status Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
Product Transfer Status Alarm Enables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-6
NMI Approved Display Enables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-7
ii
SECTION
1 Overview of the
HIU-Modbus Implementation
INTRODUCTION
This Protocol Guide explains the operation of the Rosemount Protocol per Modicon B (1985) implemented in the Model 3201 Hydrostatic Interface Unit (HIU). This Protocol Guide supplements the Model 3201 Hydrostatic Interface Unit (HIU) Product Manual. For detailed instructions on operating the HIU, consult the HIU Product Manual, MAN 4640.
®
implementation of the Modbus™
®
document PI-MBUS-300 Rev
MODBUS IMPLEMENTATION
A Rosemount implementation of the Modbus protocol provides a standard form of digital communications for the Hydrostatic Tank Gauging (HTG) application. An effort has been made to parallel the PLC implementation to the greatest extent possible, so that the HIU communicates with existing Modbus hosts.
Check compatibility carefully to ensure that the
HIU is properly configured for the data format
expected by the Host. Exceptions made because of the unique requirements of the HTG application have been noted. However, this is no guarantee that the interpretation made here will be the same as that followed by the Modbus host.
A Rosemount implementation of the Modbus protocol provides for the passing of measured and calculated variables, configuration information, and diagnostics in data registers. Data is sent in these registers as floating-point values, integer values, numeric codes relating to configuration lists, status summary words (packed bits), or individual status flags (single bits).
The Modbus Communication and Power (MCAP) output from the HIU is transmitted to the Model 3402 Application Interface Module (AIM) where it is converted to a standard RS-485 or RS-232 Modbus signal.
Table 1-1 lists the Modbus functions implemented in the HIU:.
TABLE 1-1. Modbus Functions Implemented in the HIU.
Function
Code
01 Read Bits Read output status (logic coils) 02 Read Bits Read input status (discrete inputs) 03 Read Integer, Code, Status word, Floating Point Read output registers(holding registers) 04 Read Integer, Code, Status word, Floating Point Read input registers 05 Write Bits Force single coil 06 Write Integer, Code, Status word, Floating Point Presetsingle register 08 N/A Repeat of loopbackmessage Loopback test 15 Write Bits Force multiple coils 16 Write Integer, Code, Status word, Floating Point Presetmultiple registers 17 Read Code Return Slave ID
Exception: Because the HIU does not distinguish between inputs and outputs, function codes 01 and 02 as they apply to bits, and function codes 03 and 04 as they applytonumeric values refertothe same data registers.For example, eitherfunctioncode 03 or function code04can be used to readthe integer form of the true mass variable at data address 0053.
Function Information Type Modbus Nomenclature
1-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
1-2
SECTION
2 Modbus Functions
and Data Format
INTRODUCTION
The Modbus data in the HIU is arranged in integer registers, floating-point registers, and status bits. The assignments for these registers are found in Sections 5, 6, and 7.
Function codes 03, 04, 06, and 16 are used with integer registers and floating point registers.
Function codes 01, 02, 05, and 15 are used with status bits.
Both integer and floating-point registers have space reserved to reorder the registers for maximum communication throughput.
A complete description of all the preceding commands, except floating point, can be found in Modicon Modbus Protocol Reference Guide (document number PI-MBUS-300 Rev B).
NOTE
When reading or writing data to the HIU and using commands 03, 04, or 16, the maximum allowable registers to read and write to with a single command is 125 (as defined by Gould Modicon).
User-assignable Registers
The data written or returned in the first fifty integer or twenty five floating-point registers can be assigned by the user. This provides a means of arranging non-consecutive register information in a sequential order so that it can efficiently be accessed with a multiple-register read or write command. Registers 0 through 49 in the integer map contain the assigned data for either integer or floating-point registers. Integer registers 200 through 249 contain the register assignments for the integer and floating-point map. The registers containing data assignments are codes representing the register number of the associated data. In addition to the configuration of the data register assignments via Modbus, the register assignments may be configured via a HART-based communicator.
Integer Registers
Modbus Message Glossary
This table defines terminology used in the communication examples.
Address: user-assigned address of the slave device. Function Code: the function the slave is to perform. Start Reg.HO: high-orderdata addressbyte ofthe firstregisterto read
or write. Start Reg. LO:low-orderdata address byteofthe first register to read or write. #ofReg.HO:high-order byte of the number of registers to read or write.
#ofReg.LO:low-order byte of the first register to read or write. Byte Count: number of data bytes. Data MSB: data register's most significant byte. Data LSB: data register's least significant byte. Status Bit HO: high-order data address byte of the first bit to read or
write. Status Bit LO: low-order data address byte of the first bit to read or write. Error Check: message checksum LRC (Longitudinal Redundancy Check) in ASCII mode, or CRC (Cyclical Redundancy Check) in RTU mode.
Integer registers are the most commonly used type of Modbus data and are supported by most Modbus hosts. In the HIU Implementation, the Modbus registers are arranged in one of the following four formats:
1. Integer Data - a scaled number from 0 to the maximum Modbus integer
2. Character Data - 2 ASCII characters per 16 bit register (ex. date, password)
3. Coded Data - Multiple choice configuration data chosen from a coded list
4. Packed Bits - Register form of 16 pac ked single bits
The integer, character, and coded data registers contain all of the information needed to configure and read process data. Any Integer register may be read with function code 03 or function code 04. These same registers may be written one at a time with function code 06 or multiple registers can be written with function code 16.
2-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
The HIU rejects the entire message if an attempt is made to write a register with data that is out-of­bounds or not considered to be of legal value. Out-of­bounds data includes coded data values outside of the values listed in each coded data table, integer values larger than the maximum Modbus integer and reserved registers with values other than zero. This rejection scheme has been chosen to add security by helping to prevent the accidental writing of data to incorrect registers.
Integer Data
The integer data is a whole number between 0 and the maximum Modbus integer (inclusive). The maximum Modbus integer is a user-configurable variable that is a whole number between 0 and 65,535 (inclusive). The integer data must also be scaled for each data type by entering the desired units, a zero point, and a full scale point. For the integer value to be correctly interpreted, these scaling factors must match the format expected by the host system. Scaling of the integer parameters is accomplished through floating-point registers or by using a HART-based interface. Table 2-1 shows an example of integer data written to the HIU.
The following communication example shows the request for one register starting at register 56 (0038 Hex).
For this example, assume: Zero = 1 meter
Full Scale = 15 meters
TABLE 2-1. Integer Data.
Host Request
Address
HIU Request
Address
Integer: Hexadecimal Representation: 4124 Decimal Equivalent: 16,676
1 In all communicationexamples, the error checkvalue is dependent on
Function
Code
01 03 00 38 00 01 XX
Function
01 03 02 41 24 XX
the mode of transmission.
Code
Start
Reg HO
Count
Byte
Start
Reg LO
#ofRegHO#ofRegLOError
Data MSB
Data LSB
Check
1
Error
Check
1
If a variable goes out-of-bounds (outside the zero or full scale points), a value equal to the maximum Modbus integer +1 is returned. When writing to any register that contains a variable that is a dynamic output from the HIU, the value will be written over on the next system update.
Character Data
Character data, such as dates or passwords, are returned in registers in ASCII data format. Each Modbus register represents two ASCII characters. Table 2-2 shows an example of character data written to the HIU.
TABLE 2-2. Integer Data.
Maximum Modbus Integer = 65,534
The data returned for data address 56 is 16,676 (4124 Hex). This value must be scaled using the following formula to give it meaning.
Data Full Scale Zero()´
Result
---------------------------------------------------------------- -
Max MODBUS Integer
16 676, 15 1()´
Result
------------------------------------------- -
65 534,
Zero+=
1+=
Result 4.56 meters=
Host Request
Address
(HIU Request Continued)
HIU Response
Address
Character Data
Hexadecimal Representation 54 65 73 74 ASCII Character T E S T
Function
Code
01 10 00 6B 00 02 04
DataHODataLODataHODataLOError
54 65 73 74 XX
Function
Code
01 10 00 6B 00 02 04
Start
Reg HO
Start
Reg HO
Start
Reg LO
Start
Reg LO
#ofRegHO#ofReg
LO
Check
#ofRegHO#ofReg
LO
Byte
Count
Error
Check
2-2
Modbus Functions and Data Format
Coded Data
Coded Data represents a table look-up value. Data written to these registers must be a valid table entry or the entire message is rejected. Table 2-3 shows an example coded data at data address 88 (0058 Hex) representing pressure units. The value 11 (000B Hex) returned from the HIU corresponds to KPa in the pressure unit look-up table.
TABLE 2-3. Coded Data.
Host Request
Address
HIU Response
Address
Coded Data
Hexadecimal Representation: 000B (decimal 11) Pressure Units Table Representation: kPA
Function
Code
01 03 00 58 00 01 XX
Function
Code
01 03 02 00 0B XX
Start
Reg HO
Byte
Count
Start
Reg LO
Data MSB
#ofRegHO#ofReg
Data LSB
LO
Error
Check
Error
Check
Packed Bits
Packed bits represent 16 individual status bits packed into one register. The status bits have been packed this way for systems that prefer handling only register information. These bits may also be read or written individually using a bit command. The bits within the packed registers are grouped by data or function type. T able 2-4 shows an example of packed bits with alarm status information at data address 76 (004C Hex) returned by the HIU.
TABLE 2-4. Packed Bits.
Host Request
Address
HIU Response
Address
Packed Bit Data
Binary Representation (bits 16-0): 0000 0000 0001 0010 Bit #1 is on indicating Lo Alarm
Bit #4 is on indicating an Unathorized Mass Movement
Function
Code
01 03 00 4C 00 01 XX
Function
Code
01 03 02 00 12 XX
Start
Reg HO
Byte
Count
Start
Reg LO
Data MSB
#ofRegHO#ofReg
LO
Data LSB
Error
Check
Error
Check
FLOATING-POINT REGISTERS
Although not specifically addressed by the Modbus protocol specification, floating-point numbers have been implemented per IEEE 754. Floating point numbers reduce the complexity required in scaling integer values and provide a means to transmit numbers used by the HIU that are not easily scaled, such as the K0 through K4 configuration parameters.
Floating-point Data
The HIU is capable of a two 16-bit registers format. An example and description follow.
NOTE
Although this type of data does not require scaling, it is important that the measurement unit selected in the HIU be the same as that expected by the host. In addition, where possible, data is available in both integer and floating-point formats.
The Two 16-bit Registers Format
Function code 03 or 04 are used to read floating­point registers in this format. Function codes 06 or 16 are used to write floating-point registers in this format. An example of reading a floating-point register from the HIU is shown in Table 2-5.
TABLE 2-5. Reading a Two 16-bit Floating-point Register.
Host Request
Address
HIU Response
Address
01 03 04 42 C8 00 00 XX
Floating Point
Hexadecimal Representation: Decimal Equivalent: 100.00
Function
Code
01 03 01 60 00 02 XX
Function
Code
Start RegHOStart
Byte
Count
Reg LO
Data MSB
42C8000
Floating-point registers that are defined as reserved have 0 as their only legal value. A write command to a reserved floating-point register with a value other than zero will be rejected.
Section 6 lists floating-point register assignments using the two 16-bit registers format.
#of
#of
Reg
Reg LO
HO
Data Data Data
LSB
Error
Check
Error
Check
Status bits that are defined as reserved have 0 as their only legal value. A write command that contains a packed bit register with reserved bit of value 1 will be rejected.
2-3
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
STATUS BITS
In the HIU Implementation, status bits contain alarms, commands, and status information. The state of a Modbus status bit is defined as either ON (true) or OFF (false). The ON state is represented by a 1. The status bits may be read with function code 1 or 2. They may be written one at a time with function code 5 or multiple bits may be written with function code 15. Status bits that are defined as reserved have zero as their only legal value. When writing bits, the entire write message will be rejected if reserved bits are not written with a value of zero. This rejection scheme has been chosen to add security by helping to prevent the accidental writing of data to incorrect bits. An example of a read message for bits 2 through 6 as returned by the HIU is shown in Table 2-6.
TABLE 2-6. Status Bits.
Host Request
Address
HIU Response
Address
Status Bit Data
Binary Representation (bits): 1 0010 Bit #2: HI Alarm OFF
Bit #3: HI Alarm ON Bit #4: Unauthorized Mass Movement Alarm OFF Bit #5: Standard Density Alarm OFF Bit #6: Critical Zone Alarm ON
Function
01 02 00 02 00 04 XX
Function
01 02 01 12 XX
Start BitHOStart BitLO#ofBitHO#ofBit
Code
Code
Byte
Count
Data Error
Check
LO
Error
Check
DATA OUT OF RANGE
When integer data calculated by the HIU is outside the zero, and full scale points or is out of range, the value of the maximum Modbus integer + 1 is returned. The data out of range convention does not apply to the status bits, packed status bits, character data, and coded data.
LOOPBACK TEST
Per the Modbus specification, function code 8 initiates a loopback test. The purpose of this test is to check the communication system. It does not affect the operation of the HIU. The HIU supports only diagnostic code 00. This is a request to return query data. Upon receiving a loopback message containing this code, the HIU will echo the message sent by the master . The entire message returned will be identical to the message transmitted by the master, field-per-field. An example of a loopback message is shown in Table 2-8.
TABLE 2-8. Loopback Message.
Host Request
Address
Host Response
Address
Function
Code
01 08 00 00 F3 26 XX
Function
Code
01 08 00 00 F3 26 XX
CodeHOCode
LO
CodeHOCode
LO
Data Data
Data Data
Error
Check
Error
Check
EXCEPTION RESPONSES
The exception responses returned by the HIU are
listed in Table 2-7.
TABLE 2-7. Exception Responses.
Exception Response Reason
01 02
03
Messages that are received with a parity error, checksum error or message format error will be ignored. In addition, the HIU will reject any write message that is sent containing a data register or bit defined as reserved if it does not have a value of 0. An entire block will be rejected if this convention is not followed for every reserved register or bit within the block.
2-4
Illegal Function Illegal Data Address
Illegal Data Value
Message is not allowed Data address (bit or register) requested is not defined Data value being written is out of range
SECTION
3 Modbus
Hardware Implementation
The Model 3201 HIU communicates and is powered using the same pair of wires. The protocol is Manchester-encoded Modbus (MCAP), whic h is then converted to standard RS-485/232 Modbus via the Model 3402 Application Interface Module (AIM).
The recommended wiring configurations are as follows:
MCAP Signal Wiring
one twisted shielded pair, 18 AWG. Wiring
distance is approximately 5,000 feet with 14 HIUs
or SAMs in any combination with 2 HART devices
connected to the HIU. For specific details on
grounding and wiring connections, see the product
manual for the Model 3201 HIU, MAN 4640.
Modbus Host Signal Wiring
Modbus RS-485, one or two twisted shielded pair, 18 AWG. Wiring distance is approximately 5,000 feet. Modbus RS-232, standard serial communication with RJ45 type connector and 25­or 9-pin connector. Wiring distance is approximately 50 feet. For specific details on grounding and wiring connections, see the product manual for the Model 3402 AIM, MAN 4641.
3-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
3-2
SECTION
4
Modbus Configuration
The Model 3201 HIU needs to be configured to establish communications. The HART-based communicator allows the user to set the HIU Modbus port to match the Modbus host and Model 3402 AIM.
HIUs are addressed to provide a unique identifier for the host. The HIU address is configurable through a HART-based communicator. This address may range from 1 to 247 and must be unique. Each HIU only responds when a query has been sent to its unique address by the host device.
In addition to the choice of transmission mode and associated configuration parameters, the HIU must be configured for a transmission speed or baud rate. Allowable MCAP baud rate values for the Model 3201 HIU include: 38400 or 9600. These parameters can also be configured using the HART-based Communicator connected directly to the HIU. A summary of the configuration information required by the HIU in order to implement Modbus is given in Table 4-1.
TABLE 4-1. Modbus Configuration Summary.
Configuration Item Valid Entries
Modbus Address 1 to 247 Yes Yes Baud Rate 38400, 9600 Yes Yes Maximum Integer
Size Integer Scaling
Factors Unit Selection Coded List Yes Yes
Whole Number 0-65,534
Floating Point # Yes Yes
Modbus
Configurable
Yes Yes
HART-based
Communicator
4-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
4-2
SECTION
5
Integer Register Assignments
Data Read Read/ Data
DOnlyWrite
User-assignable Registers
Data Address Read Only Read/Write Data Type
Integer Register 0 0000 30001 40001 Any Integer Register 1 0001 30002 40002 Any Integer Register 2 0002 30003 40003 Any Integer Register 3 0003 30004 40004 Any Integer Register 4 0004 30005 40005 Any Integer Register 5 0005 30006 40006 Any Integer Register 6 0006 30007 40007 Any Integer Register 7 0007 30008 40008 Any Integer Register 8 0008 30009 40009 Any Integer Register 9 0009 30010 40010 Any Integer Register 10 0010 30011 40011 Any Integer Register 11 0011 30012 40012 Any Integer Register 12 0012 30013 40013 Any Integer Register 13 0013 30014 40014 Any Integer Register 14 0014 30015 40015 Any Integer Register 15 0015 30016 40016 Any Integer Register 16 0016 30017 40017 Any Integer Register 17 0017 30018 40018 Any Integer Register 18 0018 30019 40019 Any Integer Register 19 0019 30020 40020 Any Integer Register 20 0020 30021 40021 Any Integer Register 21 0021 30022 40022 Any Integer Register 22 0022 30023 40023 Any Integer Register 23 0023 30024 40024 Any Integer Register 24 0024 30025 40025 Any Integer Register 25 0025 30026 40026 Code Integer Register 26 0026 30027 40027 Code Integer Register 27 0027 30028 40028 Code Integer Register 28 0028 30029 40029 Code Integer Register 29 0029 30030 40030 Code Integer Register 30 0030 30031 40031 Code Integer Register 31 0031 30032 40032 Code Integer Register 32 0032 30033 40033 Code Integer Register 33 0033 30034 40034 Code Integer Register 34 0034 30035 40035 Code Integer Register 35 0035 30036 40036 Code Integer Register 36 0036 30037 40037 Code
5-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
User-assignable Registers (Continued)
Data Address Read Only Read/Write Data Type
Integer Register 37 0037 30038 40038 Code Integer Register 38 0038 30039 40039 Code Integer Register 39 0039 30040 40040 Code Integer Register 40 0040 30041 40041 Code Integer Register 41 0041 30042 40042 Code Integer Register 42 0042 30043 40043 Code Integer Register 43 0043 30044 40044 Code Integer Register 44 0044 30045 40045 Code Integer Register 45 0045 30046 40046 Code Integer Register 46 0046 30047 40047 Code Integer Register 47 0047 30048 40048 Code Integer Register 48 0048 30049 40049 Code Integer Register 49 0049 30050 40050 Code
System Resolution
Data Address Read Only Read/Write Data Type
Maximum Modbus Integer Size 0050 30051 40051 Integer
Process Variables
Data Address Read Only Read/Write Data Type
Effective Mass 0051 30052 40052 Integer True Mass 0052 30053 40053 Integer Measured Density 0053 30054 40054 Integer Standard Density (variable) 0054 30055 40055 Integer Flow Rate 0055 30056 40056 Integer Product Level 0056 30057 40057 Integer Water Bottom Level(variable) 0057 30058 40058 Integer Product Volume 0058 30059 40059 Integer Standard Product Volume 0059 30060 40060 Integer Water Bottom Volume 0060 30061 40061 Integer Ullage Volume 0061 30062 40062 Integer Product Temperature (variable) 0062 30063 40063 Integer Ambient Temperature 0063 30064 40064 Integer T
B
T
M
T
T
VaporMass 0067 30068 40068 Integer VaporDensity 0068 30069 40069 Integer Roof Mass (variable) 0069 30070 40070 Integer P
T
P
B
P
M
AvailableProduct 0073 30074 40074 Integer
0064 30065 40065 Integer 0065 30066 40066 Integer 0066 30067 40067 Integer
0070 30071 40071 Integer 0071 30072 40072 Integer 0072 30073 40073 Integer
5-2
Integer Register Assignments
Process Variables (Continued)
Data Address Read Only Read/Write Data Type
Product Status Alarm Enables 0074 30075 40075 Bit 0-Not Enough Ullage for Transfer Alarm
1-Not Enough Product for Transfer Alarm 2-High Flow Rate Alarm 3-Low Flow Rate Alarm 4-Transfer Complete Alarm 5-Transfer Near Completion (Warning) Alarm 6-Tank Fill Directional Alarm 7-Tank Empty Directional Alarm 8-Reserved 9-Reserved 10-Reserved 11-Reserved 12-Reserved 13-Reserved 14-Reserved 15-Reserved
Product Status Alarms 0075 30076 40076 Bits 0-Not Enough Ullage for Transfer Alarm
1-Not Enough Product for Transfer Alarm 2-High Flow Rate Alarm 3-Low Flow Rate Alarm 4-Transfer Complete Alarm 5-Transfer Near Completion (Warning) Alarm 6-Tank FIll Directional Alarm 7-Tank Empty Directional Alarm 8-Reserved 9-Reserved 10-Reserved 11-Reserved 12-Reserved 13-Reserved 14-Water Bottom Levelin Manual 15-Standard Density in Manual
Alarm Status - Internal State 0076 30077 40077 Bits Bit #0 Low Critical Level Alarm
Bit #1 Low Advisory Level Alarm Bit #2 High Advisory Level Alarm Bit #3 High Critical Level Alarm Bit #4 Unauthorized Mass Movement Alarm Bit #5 Standard Density Alarm Bit #6 Critical Zone Alarm Bit #7 Low Temperature Alarm Bit #8 High Temperature Alarm Bit #9 Hardware Input 1 Alarm Bit #10 Reserved Bit #11 Reserved Bit #12 Reserved Bit #13 Low PTAlarm Bit #14 High PTAlarm Bit #15 Unauthorized Mass Movement Alarm Enabled
5-3
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Process Variables (Continued)
Data Address Read Only Read/Write Data Type
Alarm Status Enables 0077 30078 40078 Bits Bit #0 Low Critical Level Alarm Enabled
Bit #1 Low Advisory Level Alarm Enabled Bit #2 High Advisory Level Alarm Enabled Bit #3 High Critical Level Alarm Enabled Bit #4 Unauthorized Mass Movement Alarm Enabled Bit #5 Standard Density Alarm Enabled Bit #6 Critical Zone Alarm Enabled Bit #7 Low Temperature Alarm Enabled Bit #8 High Temperature Alarm Enabled Bit #9 Reserved Bit #10 Reserved Bit #11 Reserved Bit #12 Hardware Input 1 Alarm Enable Bit #13 Low PTAlarm Enable Bit #14 High PTAlarm Enable Bit #15 Reserved
Alarm Output Control/State 0078 30079 40079 Bits Bit #0 MCAP Write Protect Switch
Bit #1 HART Write Protect Switch Bit #2 Alarm Fail Hi/Lo Switch Bit #3 Switch Input State Bit #4 Reserved Bit #5 Reserved Bit #6 Reserved Bit #7 Reserved Bit #8 Reserved Bit #9 Reserved Bit #10 Reserved Bit #11 Reserved Bit #12 Reserved Bit #13 Reserved Bit #14 Reserved Bit #15 Reserved
System Diagnostics 0079 30080 40080 Bits Bit #0 Top Transmitter Failure
Bit #1 Top Transmitter Communication Failure Bit #2 Middle Transmitter Failure Bit #3 Middle Transmitter Communication Failure Bit #4 Bottom Transmitter Failure Bit #5 Bottom Transmitter Communication Failure Bit #6 Bad Product Temperature Bit #7 RTD Out of Range Bit #8 Water Bottom Device Failure Bit #9 Water Bottom Device Communication Failure Bit #10 PB£ P Bit #11 PB£ P Bit #12 PM£ P Bit #13 PB£ P Bit #14 PM£ P Bit #15 Reserved
M T
T
T
T
5-4
Integer Register Assignments
Process Variables (Continued)
Data Address Read Only Read/Write Data Type
HIU Status 0080 30081 40081 Bits Bit #0 Reserved
Bit #1 Reserved Bit #2 Not Calculating Density Bit #3 Level Out of Strapping PointRange Bit #4 RTD Not Immersed Bit #5 Not Calculating Bit #6 Constant Data Incomplete or Incorrect Bit #7 Calculation Error (Overflow,divideby0.) Bit #8 Reserved Bit #9 Microprocessor Board Failure Bit #10 Surface Mount Analog Board Failure Bit #11 Reserved Bit #12 Reserved Bit #13 Reserved Bit #14 Reserved Bit #15 Reserved
HIU Commands 0081 30082 40082 Bits Bit #0 Reserved
Bit #1 Reserved Bit #2 Reset HIU Bit #3 Reserved Bit #4 Tank Inactive Bit #5 Reserved Bit #6 Level in Manual Bit #7 Temperature in Manual Bit #8 Reserved Bit #9 Reserved Bit #10 Reserved Bit #11 Reserved Bit #12 Reserved Bit #13 Reserved Bit #14 Test HART Carrier Bit #15 Fixed Current Mode
Process Variable Units
Data Address Read Only Read/Write Data Type
Mass Units 0082 30083 40083 Code 0metricton
1kg 2lb 3longton 4 short ton
Density Units 0083 30084 40084 Code
3
0 kg/m
3
1lb/ft 2 lb/gal 3 specific gravity 4 °API 5 °Brix 6 °Baumé heavy 7 °Baumé light 8 °Brix
5-5
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Process Variable Units (Continued)
Data Address Read Only Read/Write Data Type
Standard Density Units 0084 30085 40085 Code
3
0 kg/m
3
1lb/ft 2 lb/gal 3 specific gravity 4 °API 5 °Brix 6 °Baumé heavy 7 °Baumé light 8 °Brix
VolumeUnits 0085 30086 40086 Code
3
0m 1 liters 2 U.S. gal 3 Imperial gal 4bbl
3
5ft Level Units 0086 30087 40087 Code 0 meters
1 feet (decimal) 2 feet (fractional)
Temperature Units 0087 30088 40088 Code 0 °C
1 °F Pressure Units 0088 30089 40089 Code 0inH2Oat68°F
1inHgat0°C 2ftH2Oat68°F 3 mmH2Oat68°F 4 mmHg at 0 °C 5 psi 6 bar 7 mbar
2
8g/cm
2
9 kg/cm 10 Pa 11 kPa 12 Torr at 0 °C 13 Atmospheres
Maximum Fill Height 0089 30090 40090 Integer Tank Capacity 0090 30091 40091 Integer
PV Alarm Variables
Data Address Read Only Read/Write Data Type
Mass Setpoint 0091 30092 40092 Integer Mass Deviation 0092 30093 40093 Integer Mass Deadband 0093 30094 40094 Integer Standard Density Setpoint 0094 30095 40095 Integer Standard Density Deviation 0095 30096 40096 Integer Standard Density Deadband 0096 30097 40097 Integer Low Critical Level Alarm Setpoint 0097 30098 40098 Integer Low Advisory Level Alarm Setpoint 0098 30099 40099 Integer High Advisory Level Alarm Setpoint 0099 30100 40100 Integer High Critical Level Alarm Setpoint 0100 30101 40101 Integer Low Temperature Alarm Setpoint 0101 30102 40102 Integer
5-6
Integer Register Assignments
PV Alarm Variables (Continued)
Data Address Read Only Read/Write Data Type
High Temperature Alarm Setpoint 0102 30103 40103 Integer Temperature Deadband 0103 30104 40104 Integer Solid Temperature Setpoint 0104 30105 40105 Integer Low PTSetpoint 0105 30106 40106 Integer High PTSetpoint 0106 30107 40107 Integer
Installation Information
Data Address Read Only Read/Write Data Type
HIU Tag 0107 30108 40108 Character HIU Tag 0108 30109 40109 Character HIU Tag 0109 30110 40110 Character HIU Tag 0110 30111 40111 Character HIU Tag 0111 30112 40112 Character HIU Tag 0112 30113 40113 Character HIU Tag 0113 30114 40114 Character HIU Tag 0114 30115 40115 Character HIU Serial Number 0115 30116 40116 Character HIU Serial Number 0116 30117 40117 Character HIU Serial Number 0117 30118 40118 Character HIU Serial Number 0118 30119 40119 Character HIU Serial Number 0119 30120 40120 Character HIU Serial Number 0120 30121 40121 Character HIU Serial Number 0121 30122 40122 Character HIU Serial Number 0122 30123 40123 Character HIU Manufacturing Date 0123 30124 40124 Character HIU Manufacturing Date 0124 30125 40125 Character HIU Manufacturing Date 0125 30126 40126 Character Date 0126 30127 40127 Date 0127 30128 40128 Date 0128 30129 40129 Reserved 0129 30130 40130 Reserved 0130 30131 40131 Reserved 0131 30132 40132
5-7
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
Reserved 0132 30133 40133 Local Display Selection #1 0133 30134 40134 Bits Bit #0 Level DisplayEnable
Bit #1 True Mass Display Enable Bit #2 Effective Mass DisplayEnable Bit #3 Standard VolumeDisplay Enable Bit #4 Measured Volume DisplayEnable Bit #5 Standard Density Display Enable Bit #6 Measured Density Display Enable Bit #7 Product Temperature Display Enable Bit #8 Error Display Enable Bit #9 Test All Display Enable Bit #10 Test Blank Display Enable Bit #11 Transfer Time Bit #12 Flow Rate Display Enable Bit #13 Standard Temperature Display Enable Bit #14 PBDisplay Enable Bit #15 PMDisplay Enable
PTType 0134 30135 40135 Code 0-None
1-Reserved 2-Smart Standard 3-Smart Monitor
PMType 0135 30136 40136 Code 0-None
1-Installed PBType 0136 30137 40137 Code Temperature Device Type 0137 30138 40138 Code 0-None
1-Copper RTD 2-Platinum RTD 3-ASU 4-PBTemperature 5-Smart
Water Bottom Type 0138 30139 40139 Code 0-None
1-Capacitance Probe 2-Pressure Transmitter
Roof Type 0139 30140 40140 Code 0-None
1-Fixed 2-Floating-VolumeDeductedfromStrapTable 3-Floating-VolumeNotDeductedfrom Strap Table
Calculation Method for Standard Density 0140 30141 40141 Code 0-None
1-API Constants (K0,K1) 2-Polynomial (K0, K1, K2, K3, K4)
Latitude, degrees 0141 30142 40142 Integer Latitude, minutes 0142 30143 40143 Integer Latitude, seconds 0143 30144 40144 Integer H
B
H
BM
Height of RTD 0146 30147 40147 Integer
0144 30145 40145 Integer 0145 30146 40146 Integer
5-8
Integer Register Assignments
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
Height of Outlet 0147 30148 40148 Integer Calculation Method for Volume 0148 30149 40149 Code 0-Strapping Table
1-Upright Cylinder 2-Horizontal Cylinder 3-Upright Bullet 4-Horizontal Bullet 5-Sphere
Pin Height 0149 30150 40150 Integer Critical Zone Above Pin 0150 30151 40151 Integer Standard Density (constant) 0151 30152 40152 Integer Standard Density Reference Temperature 0152 30153 40153 Integer Water Bottom Level(constant) 0153 30154 40154 Integer Roof Mass (constant) 0154 30155 40155 Integer Pressure Deadband 0155 30156 40156 Integer Product Temperature (constant) 0156 30157 40157 Integer Reserved 0157 30158 40158 Reserved 0158 30159 40159 Reserved 0159 30160 40160 Reserved 0160 30161 40161 Reserved 0161 30162 40162 Reserved 0162 30163 40163 Reserved 0163 30164 40164 Reserved 0164 30165 40165 Reserved 0165 30166 40166 Reserved 0166 30167 40167 Reserved 0167 30168 40168 Reserved 0168 30169 40169 Reserved 0169 30170 40170 Reserved 0170 30171 40171 Reserved 0171 30172 40172 Reserved 0172 30173 40173 Reserved 0173 30174 40174 Reserved 0174 30175 40175 Reserved 0175 30176 40176 Reserved 0176 30177 40177 Reserved 0177 30178 40178 Reserved 0178 30179 40179 Reserved 0179 30180 40180 Reserved 0180 30181 40181 Reserved 0181 30182 40182 Product Name 0182 30183 40183 Character Product Name 0183 30184 40184 Character Product Name 0184 30185 40185 Character Product Name 0185 30186 40186 Character Product Name 0186 30187 40187 Character Product Name 0187 30188 40188 Character Product Name 0188 30189 40189 Character
5-9
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
Product Name 0189 30190 40190 Character Level Switch Type 0190 30191 40191 Code 0-None
1-Calculate on Open 2-Calculate on Close 3-Calculate on Both 4-Monitor
H
BS
No. of Strapping Points 0191 30192 40192 Integer Software Version 0191 30192 40192 Character Software Version 0191 30192 40192 Character Software Version 0191 30192 40192 Character Software Version 0191 30192 40192 Character Local Display Selection #2 0191 30192 40192 Bits Bit #0 Vapor True Mass Display Enable
Bit #1 Vapor Density DisplayEnable Bit #2 Amount Transferred Display Enable Bit #3 Amount Remaining Display Enable Bit #4 Elapsed Time Display Enable Bit #5 Reserved Bit #6 Reserved Bit #7 Reserved Bit #8 Reserved Bit #9 Reserved Bit #10 Reserved Bit #11 Reserved Bit #12 Reserved Bit #13 Reserved Bit #14 Reserved Bit #15 Reserved
VolumeCalculationMethod 0198 30199 40199 Code Local Display Selection #3 0199 30200 40200 Bits Bit #0 PTDisplay Enable
Bit #1 Special 1 Display Enable Bit #2 Special 2 Display Enable Bit #3 Special 3 Display Enable Bit #4 Special 4 Display Enable Bit #5 Special 5 Display Enable Bit #6 Roof Mass Display Enable Bit #7 Tank Capacity Display Enable Bit #8 Ullage Display Enable Bit #9 Water Bottom Volume Display Enable Bit #10 Water Bottom LevelDisplay Enable Bit #11 AvailableProduct DisplayEnable Bit #12 Tank Alarm Display Enable Bit #13 Status Alarm Display Enable Bit #14 Diagnostic Alarm Display Enable Bit #15 Liquid True Mass Display Enable
0191 30192 40192 Integer
User Assignment For Integer Registers
Data Address Read Only Read/Write Data Type
Assign User Register 0 0200 30201 40201 Integer Assign User Register 1 0201 30202 40202 Integer Assign User Register 2 0202 30203 40203 Integer Assign User Register 3 0203 30204 40204 Integer Assign User Register 4 0204 30205 40205 Integer Assign User Register 5 0205 30206 40206 Integer
5-10
Integer Register Assignments
User Assignment For Integer Registers (Continued)
Data Address Read Only Read/Write Data Type
Assign User Register 6 0206 30207 40207 Integer Assign User Register 7 0207 30208 40208 Integer Assign User Register 8 0208 30209 40209 Integer Assign User Register 9 0209 30210 40210 Integer Assign User Register 10 0210 30211 40211 Integer Assign User Register 11 0211 30212 40212 Integer Assign User Register 12 0212 30213 40213 Integer Assign User Register 13 0213 30214 40214 Integer Assign User Register 14 0214 30215 40215 Integer Assign User Register 15 0215 30216 40216 Integer Assign User Register 16 0216 30217 40217 Integer Assign User Register 17 0217 30218 40218 Integer Assign User Register 18 0218 30219 40219 Integer Assign User Register 19 0219 30220 40220 Integer Assign User Register 20 0220 30221 40221 Integer Assign User Register 21 0221 30222 40222 Integer Assign User Register 22 0222 30223 40223 Integer Assign User Register 23 0223 30224 40224 Integer Assign User Register 24 0224 30225 40225 Integer Assign User Register 25 0225 30226 40226 Integer Assign User Register 26 0226 30227 40227 Integer Assign User Register 27 0227 30228 40228 Integer Assign User Register 28 0228 30229 40229 Integer Assign User Register 29 0229 30230 40230 Integer Assign User Register 30 0230 30231 40231 Integer Assign User Register 31 0231 30232 40232 Integer Assign User Register 32 0232 30233 40233 Integer Assign User Register 33 0233 30234 40234 Integer Assign User Register 34 0234 30235 40235 Integer Assign User Register 35 0235 30236 40236 Integer Assign User Register 36 0236 30237 40237 Integer Assign User Register 37 0237 30238 40238 Integer Assign User Register 38 0238 30239 40239 Integer Assign User Register 39 0239 30240 40240 Integer Assign User Register 40 0240 30241 40241 Integer Assign User Register 41 0241 30242 40242 Integer Assign User Register 42 0242 30243 40243 Integer Assign User Register 43 0243 30244 40244 Integer Assign User Register 44 0244 30245 40245 Integer Assign User Register 45 0245 30246 40246 Integer Assign User Register 46 0246 30247 40247 Integer Assign User Register 47 0247 30248 40248 Integer Assign User Register 48 0248 30249 40249 Integer Assign User Register 49 0249 30250 40250 Integer
5-11
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
Tank Material 0250 30251 40251 Code 0-Carbon Steel (.0000117)
1-304 SST (.0000173) 2-316 SST (.0000160) 3-Monel (.0000140) 4-Aluminum (.0000234) 5-Nickel (.0000133) 6-User Defined
Loop Counts 0251 30252 40252 Integer VariableAssignment 0252 30253 40253 Integer Pressure Threshold 0253 30254 40254 Integer Constant P Local Display Selection #4 0255 30256 40256 Bits 0-NMI Approved True Mass Display Enable
1-NMI Approved EffectiveMassDisplay Enable 2-NMI Approved Standard Volume Display Enable 3-NMI Approved Gross Volume Display Enable 4-NMI Approved Standard Density Display Enable 5-NMI Approved Standard Measured Display Enable 6-NMI Approved Vapor Density Display Enable 7-Reserved 8-Reserved 9-Reserved 10-Reserved 11-Reserved 12-Reserved 13-Reserved 14- Reserved 15- Reserved
Reserved 0256 30257 40257 Reserved 0257 30258 40258 Reserved 0258 30259 40259 Reserved 0259 30260 40260 HART Write Protection 0260 30261 40261 Bits 0-Write Protect V Constants
1-Write Protect K Constants and Density Method 2-Write Protect Product Temperature 3-Write Protect Standard Density 4-Write Protect Standard Reference Temperature 5-Write Protect Water Bottom Level 6-Write Protect Level Alarms 7-Write Protect Density Alarms 8-Write Protect Mass Alarms 9-Write Protect PTAlarms 10-Write Protect Display Selects 11-Reserved 12-Reserved 13-Reserved 14-Reserved 15-Reserved
T
0254 30255 40255 Integer
5-12
Integer Register Assignments
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
MCAP Write Protection 0261 30262 40262 0-Write Protect V Constants
1-Write Protect K Constants and Density Method 2-Write Protect Product Temperature 3-Write Protect Standard Density 4-Write Protect Standard Reference Temperature 5-Write Protect Water Bottom Level 6-Write Protect Level Alarms 7-Write Protect Density Alarms 8-Write Protect Mass Alarms 9-Write Protect PTAlarms 10-Write Protect Display Selects 11-Reserved 12-Reserved 13-Reserved 14-Reserved 15-Reserved
Reserved 0262 30263 40263 Reserved 0263 30264 40264 Reserved 0264 30265 40265 Reserved 0265 30266 40266 Reserved 0266 30267 40267 Reserved 0267 30268 40268 Reserved 0268 30269 40269 Transfer Method 0269 30270 40270 0-Mass
1-Gross Volume 2-Standard Volume 3-Level
5-13
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
Flow Unit Select 0270 30271 40271 40271 0-kg/sec
1-kg/min 2-kg/hour 3-kg/day 4-MTon/sec 5-MTon/min 6-MTon/hour 7-MTon/day 8-lb/sec 9-lb/min 10-lb/hour 11-lb/day 12-STon/sec 13-STon/min 14-STon/hour 15-STon/day 16-LTon/sec 17-LTon/min 18-LTon/hour 19-LTon/day 20-m3/sec 21-m3/min 22-m3/hour 23-m3/day 24-ltr/sec 25-ltr/min 26-ltr/hour 27-ltr/day 28-gal/sec 29-gal/min 30-gal/hour 31-gal/day 32-Igal/sec 33-Igal/min 34-Igal/hour 35-Igal/day 36-bbl/sec 37-bbl/min 38-bbl/hour 39-bbl/day 40-ft3/sec 41-ft3/min 42-ft3/hour 43-ft3/day 44-m/sec 45-m/min 46-m/hour 47-m/day 48-in/sec 49-in/min 50-in/hour 51-in/day 52-ft/sec 53-ft/min 54-ft/hour 55-ft/day
5-14
Integer Register Assignments
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
Transfer Unit Select 0271 30272 40272 Code 0-m
1-ft 2-ft
3
3-m 4-liter 5-usgal 6-igal 7-bbls
3
8-ft 9-mTon 10-kg 11-lbs 12-LTon 13-STon
Time Unit Select 0272 30273 40273 Code 0-Seconds
1-Minutes 2-Hours 3-Days
Flow Calculation Period 0273 30274 40274 Integer Transfer Warning Time 0274 30275 40275 Integer Transfer Setpoint 0275 30276 40276 Integer Transfer Setpoint Delta 0276 30277 40277 Integer Amount Remaining 0277 30278 40278 Integer Amount Transferred 0278 30279 40279 Integer Elapsed Time 0279 30280 40280 Integer Transfer Completion Time 0280 30281 40281 Integer Low Flow Setpoint 0281 30282 40282 Integer High Flow Setpoint 0282 30283 40283 Integer Flow Deadband 0283 30284 40284 Integer Mass Capacity 0284 30285 40285 Integer Reserved 0285 30286 40286 Reserved 0286 30287 40287 Reserved 0287 30288 40288 Reserved 0288 30289 40289 Reserved 0289 30290 40290 Baud Rate 0290 30291 40291 Code 0-9600 bps
1-19200 bps 2-38400 bps
Modbus Address 0291 30292 40292 Integer Reserved 0292 30293 40293 Reference Counts 0293 30294 40294 Integer HART Try Counter 0294 30295 40295 Integer HART Error Counter 0295 30296 40296 Integer HART Zero Command 0296 30297 40297 Integer HART Zero Acknowledge 0297 30298 40298 Integer
5-15
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Installation Information (Continued)
Data Address Read Only Read/Write Data Type
HART Device Poll 0298 30299 40299 Bits 0-Slave 1
1-Slave 2 2-Slave 3 3-Slave 4 4-Slave 5 5-Slave 6 6-Slave 7 7-Reserved 8-Reserved 9-Reserved 10-Reserved 11-Reserved 12-Reserved 13-Reserved 14-Reserved 15-Reserved
Reserved 0299 30300 40300
5-16
SECTION
6 Floating-point
Register Assignments
TWO 16-BIT REGISTERS FORMAT
Reserved Registers
Data Address Read Only Read/Write Data Type
Reserved 0300 30301 40301 Reserved 0302 30303 40303 Reserved 0304 30305 40305 Reserved 0306 30307 40307 Reserved 0308 30309 40309 Reserved 0310 30311 40311 Reserved 0312 30313 40313 Reserved 0314 30315 40315 Reserved 0316 30317 40317 Reserved 0318 30319 40319 Reserved 0320 30321 40321 Reserved 0322 30323 40323 Reserved 0324 30325 40325 Reserved 0326 30327 40327 Reserved 0328 30329 40329 Reserved 0330 30331 40331 Reserved 0332 30333 40333 Reserved 0334 30335 40335 Reserved 0336 30337 40337 Reserved 0338 30339 40339 Reserved 0340 30341 40341 Reserved 0342 30343 30343 Reserved 0344 30345 40345 Reserved 0346 30347 40347 Reserved 0348 30349 40349
Process Variables
Data Address Read Only Read/Write Data Type
Effective Mass 0350 30351 40351 Float True Mass 0352 30353 40353 Float Measured Density 0354 30355 40355 Float Standard Density (variable) 0356 30357 40357 Float Reserved 0358 30359 40359 Product Level 0360 30361 40361 Float Water Bottom Level(variable) 0362 30363 40363 Float Product Volume 0364 30365 40365 Float Standard Product Volume 0366 30367 40367 Float
6-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Process Variables (Continued)
Data Address Read Only Read/Write Data Type
Water Bottom Volume 0368 30369 40369 Float Ullage Volume 0370 30371 40371 Float Product Temperature (variable) 0372 30373 40373 Float Ambient Temperature 0374 30375 40375 Float T
B
T
M
T
T
Time to Complete 0382 30383 40383 Float Flow Rate 0384 30385 40385 Float Roof Mass (variable) 0386 30387 40387 Float P
T
P
B
P
M
AvailableProduct 0394 30395 40395 Float VaporMass 0396 30397 40397 Float VaporDensity 0398 30399 40399 Float RTD Resistance 0400 30401 40401 Float Reserved 0402 30403 40403
0376 30377 40377 Float 0378 30379 40379 Float 0380 30381 40381 Float
0388 30389 40389 Float 0390 30391 40391 Float 0392 30393 40393 Float
PV Alarm Variables
Data Address Read Only Read/Write Data Type
Mass Setpoint 0404 30405 40405 Float Mass Deviation 0406 30407 40407 Float Mass Deadband 0408 30409 40409 Float Standard Density Setpoint 0410 30411 40411 Float Standard Density Deviation 0412 30413 40413 Float Standard Density Deadband 0414 30415 40415 Float Low Critical Level Alarm Setpoint 0416 30417 40417 Float Low Advisory Level Alarm Setpoint 0418 30419 40419 Float High Advisory Level Alarm Setpoint 0420 30421 40421 Float High Critical Level Alarm Setpoint 0422 30423 40423 Float Level Deadband 0424 30425 40425 Float Low Temperature Alarm Setpoint 0426 30427 40427 Float High Temperature Alarm Setpoint 0428 30429 40429 Float Temperature Deadband 0430 30431 40431 Float Solid Temperature Setpoint 0432 30433 40433 Float Transfer Setpoint 0434 30435 40435 Float
Zero and Full Scale Variables for Integer Modbus
Data Address Read Only Read/Write Data Type
Mass Zero Scaling 0436 30437 40437 Float Mass Full Scale Scaling 0438 30439 40439 Float Density Zero Scaling 0440 30441 40441 Float Density Full Scale Scaling 0442 30443 40443 Float Standard Density Zero Scaling 0444 30445 40445 Float Standard Density Full Scale Scaling 0446 30447 40447 Float
6-2
Floating-point Register Assignments
Zero and Full Scale Variables for Integer Modbus (Continued)
Data Address Read Only Read/Write Data Type
VolumeZeroScaling 0448 30449 40449 Float VolumeFullScaleScaling 0450 30451 40451 Float Temperature Zero Scaling 0452 30453 40453 Float Temperature Full Scale Scaling 0454 30455 40455 Float Level Zero Scaling 0456 30457 40457 Float Level Full Scale Scaling 0458 30459 40459 Float Pressure Zero Scaling 0460 30461 40461 Float Pressure Full Scale Scaling 0462 30463 40463 Float Flow Zero Scaling 0464 30465 40465 Float Flow Full Scale Scaling 0466 30467 40467 Float Transfer Setpoint Zero Scaling 0468 30469 40469 Float Transfer Setpoint Full Scale Scaling 0470 30471 40471 Float
Correction Information
Data Address Read Only Read/Write Data Type
K00 Density Correction Coefficient 0472 30473 40473 Float K01 Density Correction Coefficient 0474 30475 40475 Float K02 Density Correction Coefficient 0476 30477 40477 Float K03 Density Correction Coefficient 0478 30479 40479 Float K04 Density Correction Coefficient 0480 30481 40481 Float V00 Density Correction Coefficient 0482 30483 40483 Float V01 Density Correction Coefficient 0484 30485 40485 Float V02 Density Correction Coefficient 0486 30487 40487 Float V03 Density Correction Coefficient 0488 30489 40489 Float V04 Density Correction Coefficient 0490 30491 40491 Float Reserved 0492 30493 40493 Reserved 0494 30495 40495 Pressure Threshold 0496 30497 40497 Float Capacity 0498 30499 40499 Float Local Elevation 0500 30501 40501 Float Standard Density (constant) 0502 30503 40503 Float Standard Density Reference Temperature 0504 30505 40505 Float Water Bottom Level(constant) 0506 30507 40507 Float Roof Mass (constant) 0508 30509 40509 Float PT(constant) 0510 30511 40511 Float Product Temperature (constant) 0512 30513 40513 Float Installation Temperature 0514 30515 40515 Float Strapping Temperature 0516 30517 40517 Float Strapping Density 0518 30519 40519 Float H
B
H
BM
Height of RTD 0524 30525 40525 Float Height of Outlet 0526 30527 40527 Float H
BT
Pin Height 0530 30531 40531 Float Critical Zone Above Pin 0532 30533 40533 Float Thermal Expansion Coefficient 0534 30535 40535 Float
0520 30521 40521 Float 0522 30523 40523 Float
0528 30529 40529 Float
6-3
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Strapping Table Values
Data Address Read Only Read/Write Data Type
Strapping Level #1 0536 30537 40537 Float Strapping Volume#1 0538 30539 40539 Float Strapping Level #2 0540 30541 40541 Float Strapping Volume#2 0542 30543 40543 Float Strapping Level #3 0544 30545 40545 Float Strapping Volume#3 0546 30547 40547 Float Strapping Level #4 0548 30549 40549 Float Strapping Volume#4 0550 30551 40551 Float Strapping Level #5 0552 30553 40553 Float Strapping Volume#5 0554 30555 40555 Float Strapping Level #6 0556 30557 40557 Float Strapping Volume#6 0558 30559 40559 Float Strapping Level #7 0560 30561 40561 Float Strapping Volume#7 0562 30563 40563 Float Strapping Level #8 0564 30565 40565 Float Strapping Volume#8 0566 30567 40567 Float Strapping Level #9 0568 30569 40569 Float Strapping Volume#9 0570 30571 40571 Float Strapping Level #10 0572 30573 40573 Float Strapping Volume#10 0574 30575 40575 Float Strapping Level #11 0576 30577 40577 Float Strapping Volume#11 0578 30579 40579 Float Strapping Level #12 0580 30581 40581 Float Strapping Volume#12 0582 30583 40583 Float Strapping Level #13 0584 30585 40585 Float Strapping Volume#13 0586 30587 40587 Float Strapping Level #14 0588 30589 40589 Float Strapping Volume#14 0590 30591 40591 Float Strapping Level #15 0592 30593 40593 Float Strapping Volume#15 0594 30595 40595 Float Strapping Level #16 0596 30597 40597 Float Strapping Volume#16 0598 30599 40599 Float Strapping Level #17 0600 30601 40601 Float Strapping Volume#17 0602 30603 40603 Float Strapping Level #18 0604 30605 40605 Float Strapping Volume#18 0606 30607 40607 Float Strapping Level #19 0608 30609 40609 Float Strapping Volume#19 0610 30611 40611 Float Strapping Level #20 0612 30613 40613 Float Strapping Volume#20 0614 30615 40615 Float Strapping Level #21 0616 30617 40617 Float Strapping Volume#21 0618 30619 40619 Float Strapping Level #22 0620 30621 40621 Float Strapping Volume#22 0622 30623 40623 Float Strapping Level #23 0624 30625 40625 Float Strapping Volume#23 0626 30627 40627 Float Strapping Level #24 0628 30629 40629 Float
6-4
Floating-point Register Assignments
Strapping Table Values (Continued)
Data Address Read Only Read/Write Data Type
Strapping Volume#24 0630 30631 40631 Float Strapping Level #25 0632 30633 40633 Float Strapping Volume#25 0634 30635 40635 Float Strapping Level #26 0636 30637 40637 Float Strapping Volume#26 0638 30639 40639 Float Strapping Level #27 0640 30641 40641 Float Strapping Volume#27 0642 30643 40643 Float Strapping Level #28 0644 30645 40645 Float Strapping Volume#28 0646 30647 40647 Float Strapping Level #29 0648 30649 40649 Float Strapping Volume#29 0650 30651 40651 Float Strapping Level #30 0652 30653 40653 Float Strapping Volume#30 0654 30655 40655 Float Strapping Level #31 0656 30657 40657 Float Strapping Volume#31 0658 30659 40659 Float Strapping Level #32 0660 30661 40661 Float Strapping Volume#32 0662 30663 40663 Float Strapping Level #33 0664 30665 40665 Float Strapping Volume#33 0666 30667 40667 Float Strapping Level #34 0668 30669 40669 Float Strapping Volume#34 0670 30671 40671 Float Strapping Level #35 0672 30673 40673 Float Strapping Volume#35 0674 30675 40675 Float Strapping Level #36 0676 30677 40677 Float Strapping Volume#36 0678 30679 40679 Float Strapping Level #37 0680 30681 40681 Float Strapping Volume#37 0682 30683 40683 Float Strapping Level #38 0684 30685 40685 Float Strapping Volume#38 0686 30687 40687 Float Strapping Level #39 0688 30689 40689 Float Strapping Volume#39 0690 30691 40691 Float Strapping Level #40 0692 30693 40693 Float Strapping Volume#40 0694 30695 40695 Float Strapping Level #41 0696 30697 40697 Float Strapping Volume#41 0698 30699 40699 Float Strapping Level #42 0700 30701 40701 Float Strapping Volume#42 0702 30703 40703 Float Strapping Level #43 0704 30705 40705 Float Strapping Volume#43 0706 30707 40707 Float Strapping Level #44 0708 30709 40709 Float Strapping Volume#44 0710 30711 40711 Float Strapping Level #45 0712 30713 40713 Float Strapping Volume#45 0714 30715 40715 Float Strapping Level #46 0716 30717 40717 Float Strapping Volume#46 0718 30719 40719 Float Strapping Level #47 0720 30721 40721 Float Strapping Volume#47 0722 30723 40723 Float
6-5
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Strapping Table Values (Continued)
Data Address Read Only Read/Write Data Type
Strapping Level #48 0724 30725 40725 Float Strapping Volume#48 0726 30727 40727 Float Strapping Level #49 0728 30729 40729 Float Strapping Volume#49 0730 30731 40731 Float Strapping Level #50 0732 30733 40733 Float Strapping Volume#50 0734 30735 40735 Float Strapping Level #51 0736 30737 40737 Float Strapping Volume#51 0738 30739 40739 Float Strapping Level #52 0740 30741 40741 Float Strapping Volume#52 0742 30743 40743 Float Strapping Level #53 0744 30745 40745 Float Strapping Volume#53 0746 30747 40747 Float Strapping Level #54 0748 30749 40749 Float Strapping Volume#54 0750 30751 40751 Float Strapping Level #55 0752 30753 40753 Float Strapping Volume#55 0754 30755 40755 Float Strapping Level #56 0756 30757 40757 Float Strapping Volume#56 0758 30759 40759 Float Strapping Level #57 0760 30761 40761 Float Strapping Volume#57 0762 30763 40763 Float Strapping Level #58 0764 30765 40765 Float Strapping Volume#58 0766 30767 40767 Float Strapping Level #59 0768 30769 40769 Float Strapping Volume#59 0770 30771 40771 Float Strapping Level #60 0772 30773 40773 Float Strapping Volume#60 0774 30775 40775 Float Strapping Level #61 0776 30777 40777 Float Strapping Volume#61 0778 30779 40779 Float Strapping Level #62 0780 30781 40781 Float Strapping Volume#62 0782 30783 40783 Float Strapping Level #63 0784 30785 40785 Float Strapping Volume#63 0786 30787 40787 Float Strapping Level #64 0788 30789 40789 Float Strapping Volume#64 0790 30791 40791 Float Strapping Level #65 0792 30793 40793 Float Strapping Volume#65 0794 30795 40795 Float Strapping Level #66 0796 30797 40797 Float Strapping Volume#66 0798 30799 40799 Float Strapping Level #67 0800 30801 40801 Float Strapping Volume#67 0802 30803 40803 Float Strapping Level #68 0804 30805 40805 Float Strapping Volume#68 0806 30807 40807 Float Strapping Level #69 0808 30809 40809 Float Strapping Volume#69 0810 30811 40811 Float Strapping Level #70 0812 30813 40813 Float Strapping Volume#70 0814 30815 40815 Float Strapping Level #71 0816 30817 40817 Float
6-6
Floating-point Register Assignments
Strapping Table Values (Continued)
Data Address Read Only Read/Write Data Type
Strapping Volume#71 0818 30819 40819 Float Strapping Level #72 0820 30821 40821 Float Strapping Volume#72 0822 30823 40823 Float Strapping Level #73 0824 30825 40825 Float Strapping Volume#73 0826 30827 40827 Float Strapping Level #74 0828 30829 40829 Float Strapping Volume#74 0830 30831 40831 Float Strapping Level #75 0832 30833 40833 Float Strapping Volume#75 0834 30835 40835 Float Strapping Level #76 0836 30837 40837 Float Strapping Volume#76 0838 30839 40839 Float Strapping Level #77 0840 30841 40841 Float Strapping Volume#77 0842 30843 40843 Float Strapping Level #78 0844 30845 40845 Float Strapping Volume#78 0846 30847 40847 Float Strapping Level #79 0848 30849 40849 Float Strapping Volume#79 0850 30851 40851 Float Strapping Level #80 0852 30853 40853 Float Strapping Volume#80 0854 30855 40855 Float Strapping Level #81 0856 30857 40857 Float Strapping Volume#81 0858 30859 40859 Float Strapping Level #82 0860 30861 40861 Float Strapping Volume#82 0862 30863 40863 Float Strapping Level #83 0864 30865 40865 Float Strapping Volume#83 0866 30867 40867 Float Strapping Level #84 0868 30869 40869 Float Strapping Volume#84 0870 30871 40871 Float Strapping Level #85 0872 30873 40873 Float Strapping Volume#85 0874 30875 40875 Float Strapping Level #86 0876 30877 40877 Float Strapping Volume#86 0878 30879 40879 Float Strapping Level #87 0880 30881 40881 Float Strapping Volume#87 0882 30883 40883 Float Strapping Level #88 0884 30885 40885 Float Strapping Volume#88 0886 30887 40887 Float Strapping Level #89 0888 30889 40889 Float Strapping Volume#89 0890 30891 40891 Float Strapping Level #90 0892 30893 40893 Float Strapping Volume#90 0894 30895 40895 Float Strapping Level #91 0896 30897 40897 Float Strapping Volume#91 0898 30899 40899 Float Strapping Level #92 0900 30901 40901 Float Strapping Volume#92 0902 30903 40903 Float Strapping Level #93 0904 30905 40905 Float Strapping Volume#93 0906 30907 40907 Float Strapping Level #94 0908 30909 40909 Float Strapping Volume#94 0910 30911 40911 Float
6-7
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Strapping Table Values (Continued)
Data Address Read Only Read/Write Data Type
Strapping Level #95 0912 30913 40913 Float Strapping Volume#95 0914 30915 40915 Float Strapping Level #96 0916 30917 40917 Float Strapping Volume#96 0918 30919 40919 Float Strapping Level #97 0920 30921 40921 Float Strapping Volume#97 0922 30923 40923 Float Strapping Level #98 0924 30925 40925 Float Strapping Volume#98 0926 30927 40927 Float Strapping Level #99 0928 30929 40929 Float Strapping Volume#99 0930 30931 40931 Float Strapping Level #100 0932 30933 40933 Float Strapping Volume#100 0934 30935 40935 Float
Installation Information
Data Address Read Only Read/Write Data Type
H
BS
Reserved 0938 30939 40939 Reserved 0940 30941 40941 Tank Diameter 0942 30943 40943 Float Tank Height 0944 30945 40945 Float Lower Range V alue 0946 30947 40947 Float Upper Range Value 0948 30949 40949 Float Low PTSetpoint 0950 30951 40951 Float High PTSetpoint 0952 30953 40953 Float Pressure Deadband 0954 30955 40955 Float Maximum Fill Height 0956 30957 40957 Float Pressure Hysteresis 0958 30959 40959 Float Time Zero 0960 30961 40961 Float Time Full Scale 0962 30963 40963 Float Flow Calculation Period 0964 30965 40965 Float Transfer Warning Time 0966 30967 40967 Float Elapsed Time 0968 30969 40969 Float Amount Remaining 0970 30971 40971 Float Amount Transferred 0972 30973 40973 Float Transfer Setpoint Delta 0974 30975 40975 Float Low Flow Setpoint 0976 30977 40977 Float High Flow Setpoint 0978 30979 40979 Float Flow Deadband 0980 30981 40981 Float Special 1 0982 30983 40983 Float Special 2 0984 30985 40985 Float Special 3 0986 30987 40987 Float Special 4 0988 30989 40989 Float Special 5 0990 30991 40991 Float HWB 0992 30993 40993 Float Mass Capacity 0994 30995 40995 Float Reserved 0996 30997 40997 Reserved 0998 30999 40999
0936 30937 40937 Float
6-8
SECTION
7 Status Bit Assignments
Alarms Status - Internal State
Data Address Read Only Read/Write Data Type
Low Critical Level Alarm 0000 10001 00001 Bit Low Advisory Level Alarm 0001 10002 00002 Bit High Advisory Level Alarm 0002 10003 00003 Bit High Critical Level Alarm 0003 10004 00004 Bit Unauthorized Mass Movement Alarm 0004 10005 00005 Bit Standard Density Alarm 0005 10006 00006 Bit Critical Zone Alarm 0006 10007 00007 Bit Low Temperature Alarm 0007 10008 00008 Bit High Temperature Alarm 0008 10009 00009 Bit Hardware Input 1 Alarm 0009 10010 00010 Bit Reserved 0010 10011 00011 Reserved 0011 10012 00012 Reserved 0012 10013 00013 Low PTAlarm 0013 10014 00014 Bit High PTAlarm 0014 10015 00015 Bit Mass Alarm Enable 0015 10016 00016 Bit
Alarm Status Enables
Data Address Read Only Read/Write Data Type
Low Critical Level Alarm Enabled 0016 10017 00017 Bit Low Advisory Level Alarm Enabled 0017 10018 00018 Bit High Advisory Level Alarm Enabled 0018 10019 00019 Bit High Critical Level Alarm Enabled 0019 10020 00020 Bit Unauthorized Mass Movement Alarm Enabled 0020 10021 00021 Bit Standard Density Alarm Enabled 0021 10022 00022 Bit Critical Zone Alarm Enabled 0022 10023 00023 Bit Low Temperature Alarm Enabled 0023 10024 00024 Bit High Temperature Alarm Enabled 0024 10025 00025 Bit Reserved 0025 10026 00026 Reserved 0026 10027 00027 Reserved 0027 10028 00028 Hardware Input 1 Alarm Enabled 0028 10029 00029 Bit Low PTAlarm Enable 0029 10030 00030 Bit High PTAlarm Enable 0030 10031 00031 Bit Reserved 0031 10032 00032
7-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Alarm Output Control/State
Data Address Read Only Read/Write Data Type
MCAP Write Protect Switch 0032 10033 00033 Bit HART Write Protect Switch 0033 10034 00034 Bit Switch Input State 0034 10035 00035 Bit Reserved 0035 10036 00036 Reserved 0036 10037 00037 Reserved 0037 10038 00038 Reserved 0038 10039 00039 Reserved 0039 10040 00040 Reserved 0040 10041 00041 Reserved 0041 10042 00042 Reserved 0042 10043 00043 Reserved 0043 10044 00044 Reserved 0044 10045 00045 Reserved 0045 10046 00046 Reserved 0046 10047 00047 Reserved 0047 10048 00048
System Diagnostics
Data Address Read Only Read/Write Data Type
Top Transmitter Failure 0048 10049 00049 Bit Top Transmitter Communication Failure 0049 10050 00050 Bit Middle Transmitter Failure 0050 10051 00051 Bit Middle Transmitter Communication Failure 0051 10052 00052 Bit Bottom Transmitter Failure 0052 10053 00053 Bit Bottom Transmitter Communication Failure 0053 10054 00054 Bit Bad Product Temperature 0054 10055 00055 Bit RTD Out of Range 0055 10056 00056 Bit Water Bottom Device Failure 0056 10057 00057 Bit Water Bottom Device CommunicationFailure 0057 10058 00058 Bit
£ P
P
B
PB£ P PM£ P PB£ P P
£ P
M
M
T
T
T
T
0058 10059 00059 Bit 0059 10060 00060 Bit 0060 10061 00061 Bit 0061 10062 00062 Bit 0062 10063 00063 Bit
Reserved 0063 10064 00064
HIU Status
Data Address Read Only Read/Write Data Type
Reserved 0064 10065 00065 Reserved 0065 10066 00066 Not Calculating Density 0066 10067 00067 Bit Level Out of Strapping Point Range 0067 10068 00068 Bit RTD Not Immersed 0068 10069 00069 Bit Not Calculating 0069 10070 00070 Bit Constant Data Incomplete / Incorrect 0070 10071 00071 Bit Calculation Error (Overflow,divide by 0.) 0071 10072 00072 Bit Reserved 0072 10073 00073
7-2
Status Bit Assignments
HIU Status (Continued)
Data Address Read Only Read/Write Data Type
Microprocessor Board Failure 0073 10074 00074 Bit Surface Mount Analog Board Failure 0074 10075 00075 Bit Reserved 0075 10076 00076 Reserved 0076 10077 00077 Reserved 0077 10078 00078 Reserved 0078 10079 00079 Reserved 0079 10080 00080
HIU Commands
Data Address Read Only Read/Write Data Type
Reserved 0080 10081 00081 Reserved 0081 10082 00082 Reset HIU 0082 10083 00083 Bit Reserved 0083 10084 00084 Tank Inactive 0084 10085 00085 Bit Reserved 0085 10086 00086 Level in Manual 0086 10087 00087 Bit Temperature in Manual 0087 10088 00088 Bit Reserved 0088 10089 00089 Reserved 0089 10090 00090 Reserved 0090 10091 00091 Reserved 0091 10092 00092 Reserved 0092 10093 00093 Reserved 0093 10094 00094 Test HART Carrier 0094 10095 00095 Bit Fixed Current Mode 0095 10096 00096 Bit
Local Display Selection
Data Address Read Only Read/Write Data Type
Display Level 0096 10097 00097 Bit Display True Mass 0097 10098 00098 Bit Display EffectiveMass 0098 10099 00099 Bit Display Standard Volume 0099 10100 00100 Bit Display Measured Volume 0100 10101 00101 Bit Display Standard Density 0101 10102 00102 Bit Display Measured Density 0102 10103 00103 Bit Display Product Temperature 0103 10104 00104 Bit Reserved 0104 10105 00105 Display Test All 0105 10106 00106 Bit Display Test Blank 0106 10107 00107 Bit Display Transfer Time 0107 10108 00108 Bit Display Flow Rate 0108 10109 00109 Bit Display Standard Reference Temperature 0109 10110 00110 Bit Display P Display P Display P Display Special 1 0113 10114 00114 Bit
B
M
T
0110 10111 00111 Bit 0111 10112 00112 Bit 0112 10113 00113 Bit
7-3
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Local Display Selection (Continued)
Data Address Read Only Read/Write Data Type
Display Special 2 0114 10115 00115 Bit Display Special 3 0115 10116 00116 Bit Display Special 4 0116 10117 00117 Bit Display Special 5 0117 10118 00118 Bit Display Roof Mass 0118 10119 00119 Bit Display Tank Capacity 0119 10120 00120 Bit Display Ullage 0120 10121 00121 Bit Display Water Bottom Volume 0121 10122 00122 Bit Display Water Bottom Level 0122 10123 00123 Bit Display Available Product 0123 10124 00124 Bit Display Tank Alarm 0124 10125 00125 Bit Display Status Alarm 0125 10126 00126 Bit Display Diagnostic Alarm 0126 10127 00127 Bit Display Liquid True Mass 0127 10128 00128 Bit Display Vapor True Mass 0128 10129 00129 Bit Display Vapor Density 0129 10130 00130 Bit Display Amount Transferred 0130 10131 00131 Bit Display Amount Remaining 0131 10132 00132 Bit Display Elapsed Time 0132 10133 00133 Bit Reserved 0133 10134 00134 Reserved 0134 10135 00135 Reserved 0135 10136 00136 Reserved 0136 10137 00137 Reserved 0137 10138 00138 Reserved 0138 10139 00139 Reserved 0139 10140 00140 Reserved 0140 10141 00141 Reserved 0141 10142 00142 Reserved 0142 10143 00143 Reserved 0143 10144 00144 Reserved 0144 10145 00145 Reserved 0145 10146 00146 Reserved 0146 10147 00147 Reserved 0147 10148 00148 Reserved 0148 10149 00149 Reserved 0149 10150 00150 Reserved 0150 10151 00151 Reserved 0151 10152 00152 Reserved 0152 10153 00153 Reserved 0153 10154 00154 Reserved 0154 10155 00155 Reserved 0155 10156 00156 Reserved 0156 10157 00157 Reserved 0157 10158 00158 Test HART Carrier 0158 10159 00159 Bit Fixed Current Mode 0159 10160 00160 Bit Poll Slave1 0160 10161 00161 Bit Poll Slave2 0161 10162 00162 Bit
7-4
Status Bit Assignments
Local Display Selection (Continued)
Data Address Read Only Read/Write Data Type
Poll Slave3 0162 10163 00163 Bit Poll Slave4 0163 10164 00164 Bit Poll Slave5 0164 10165 00165 Bit Poll Slave6 0165 10166 00166 Bit Reserved 0166 10167 00167 Reserved 0167 10168 00168 Reserved 0168 10169 00169 Reserved 0169 10170 00170 Reserved 0170 10171 00171 Reserved 0171 10172 00172 Reserved 0172 10173 00173 Reserved 0173 10174 00174 Reserved 0174 10175 00175 Reserved 0175 10176 00176
HART Write Protect Selections
Data Address Read Only Read/Write Data Type
V Constants 0176 10176 00177 Bit K Constants 0177 10178 00178 Bit Product Temperature 0178 10179 00179 Bit Standard Density 0179 10180 00180 Bit Standard Temperature 0180 10181 00181 Bit Water Bottom Level 0181 10182 00182 Bit Level Alarms 0182 10183 00183 Bit Density Alarms 0183 10184 00184 Bit Mass Alarms 0184 10185 00185 Bit PT(Ullage Pressure) Alarms 0185 10186 00186 Bit Display Select 0186 10187 00187 Bit Reserved 0187 10188 00188 Reserved 0188 10189 00189 Reserved 0189 10190 00190 Reserved 0190 10191 00191 Reserved 0191 10192 00192
Modbus Write Protect Selections
Data Address Read Only Read/Write Data Type
V Constants 0192 10193 00193 Bit K Constants 0193 10194 00194 Bit Product Temperature 0194 10195 00195 Bit Standard Density 0195 10196 00196 Bit Standard Temperature 0196 10197 00197 Bit Water Bottom Level 0197 10198 00198 Bit Level Alarms 0198 10199 00199 Bit Density Alarms 0199 10200 00200 Bit Mass Alarms 0200 10201 00201 Bit PT(Ullage Pressure) Alarms 0201 10202 00202 Bit Display Select 0202 10203 00203 Bit
7-5
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
Modbus Write Protect Selections (Continued)
Data Address Read Only Read/Write Data Type
Reserved 0203 10204 00204 Reserved 0204 10205 00205 Reserved 0205 10206 00206 Reserved 0206 10207 00207 Reserved 0207 10208 00208
Product Transfer Status Alarms
Data Address Read Only Read/Write Data Type
Not Enough Ullage for Transfer Alarm 0208 10209 00209 Bit Not Enough Product in Transfer Alarm 0209 10210 00210 Bit High Flow Rate Alarm 0210 10211 00211 Bit Low Flow Rate Alarm 0211 10212 00212 Bit Transfer Complete Alarm 0212 10213 00213 Bit Transfer Near Completion (Warning) Alarm 0213 10214 00214 Bit Tank Fill Directional Alarm 0214 10215 00215 Bit Tank Empty Directional Alarm 0215 10216 00216 Bit Reserved 0216 10217 00217 Reserved 0217 10218 00218 Reserved 0218 10219 00219 Reserved 0219 10220 00220 Reserved 0220 10221 00221 Reserved 0221 10222 00222 Water Bottom LevelinManual 0222 10223 00223 Bit Standard Density in Manual 0223 10224 00224 Bit
Product Transfer Status Alarm Enables
Data Address Read Only Read/Write Data Type
Not Enough Ullage for Transfer Alarm Enables 0224 10225 00225 Bit Not Enough Product in Transfer Alarm Enables 0225 10226 00226 Bit High Flow Rate Alarm Enables 0226 10227 00227 Bit Low Flow Rate Alarm Enables 0227 10228 00228 Bit Transfer Complete Alarm Enables 0228 10229 00229 Bit Transfer Near Completion (Warning) Alarm Enables 0229 10230 00230 Bit Tank Fill Directional Alarm Enables 0230 10231 00231 Bit Tank Empty Directional Alarm Enables 0231 10232 00232 Bit Reserved 0232 10233 00233 Reserved 0233 10234 00234 Reserved 0234 10235 00235 Reserved 0235 10236 00236 Reserved 0236 10237 00237 Reserved 0237 10238 00238 Reserved 0238 10239 00239 Reserved 0239 10240 00240
7-6
Status Bit Assignments
NMI Approved Display Enables
Data Address Read Only Read/Write Data Type
Display NMI Approved True Mass 0240 10241 00241 Bit Display NMI Approved Effective Mass 0241 10242 00242 Bit Display NMI Approved Standard Volume 0242 10243 00243 Bit Display NMI Approved Gross Volume 0243 10244 00244 Bit Display NMI Approved Standard Density 0244 10245 00245 Bit Display NMI Approved Measured Density 0245 10246 00246 Bit Display NMI Approved Vapor Density 0246 10247 00247 Bit Reserved 0247 10248 00248 Reserved 0248 10249 00249 Reserved 0249 10250 00250 Reserved 0250 10251 00251 Reserved 0251 10252 00252 Reserved 0252 10253 00253 Reserved 0253 10254 00254 Reserved 0254 10255 00255 Reserved 0255 10256 00256
7-7
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
7-8
INDEX
A
Alarm Output Control/State 7-2 Alarm Status Enables 7-1 Alarms Status - Internal State 7-1
C
Character Data 2-2 Coded Data 2-3 Correction Information 6-3
D
Data Out of Range 2-4
E
Exception Responses 2-4
F
Floating-point Data 2-3
Two 16-bit Registers Format 2-3
Floating-point Register Assignments
(two 16-bit) 6-1
Correction Information 6-3 Process Variables 6-1 PV Alarm Variables 6-2 Strapping Table Values 6-4 Zero and Full Scale Variables for
Integer Modbus 6-2
Floating-point Registers 2-3
H
Hardware Implementation 3-1 HART
Write Protect Selections 7-5 HIU Commands 7-3 HIU Status 7-2
I
Installation Information 5-7 Integer Data 2-1, 2-2 Integer Register Assignments 5-1
Installation Information 5-7
Process Variable Units 5-5
Process Variables 5-2
PV Alarm Variables 5-6
System Resolution 5-2
User Assignment for Integer
Registers 5-10
User-assignable Registers 5-1
L
Local Display Selection 7-3 Loopback Test 2-4
M
Modbus
Communication and Power
(MCAP) 1-1 Hardware Implementation 3-1 Hosts 1-1 Implementation 1-1 Write Protect Selections 7-5
Modbus Configuration 4-1
HART-based Communicator 4-1
Modbus Functions and Data Format
Character Data 2-2 Coded Data 2-3 Data Out of Range 2-4 Exception Responses 2-4 Floating-point Data 2-3 Floating-point Registers 2-3 Integer Data 2-2 Integer Registers 2-1 Loopback Test 2-4 Packed Bits 2-3 Status Bits 2-4 Two 16-bit Registers Format 2-3
N
NMI Appproved Display 7-7
P
Packed Bits 2-3 Process Variable Units 5-5 Process Variables 5-2, 6-1 Product Transfer Status Alarm
Enables 7-6 Product Transfer Status Alarms 7-6 PV Alarm Variables 5-6, 6-2
S
Status Bit Assignments
Alarm Output Control/State 7-2 Alarm Status Enables 7-1 Alarms Status - Internal
State 7-1
HART Write Protect
Selections 7-5 HIU Commands 7-3 HIU Status 7-2 Local Display Selection 7-3 Modbus Write Protect
Selections 7-5 NMI Approved Display
Enables 7-7 Product Transfer Status Alarm
Enables 7-6 Product Transfer Status
Alarms 7-6 System Diagnostics 7-2
Status Bits 2-4 Strapping Table Values 6-4 System Resolution 5-2
T
Two 16-bit Registers Format 2-3
U
User Assignment for Floating-point
Registers 5-10
User-assignable Registers 2-1, 5-1
W
Write Protect Selections 5-12, 5-13,
7-5
Z
Zero and Full Scale Variables for
Integer Modbus 6-2
I-1
Rosemount Model 3201 Hydrostatic Interface Unit Modbus Protocol
I-2
Rosemount Inc.
8200 Market Boulevard Chanhassen, MN 55317 USA Tel 1-800-999-9307 Fax (952) 949-7001 © 1997 Rosemount, Inc.
T
N
I
E
D
R
P
IN
U.
A.
S.
http://www.rosemount.com
¢00809-0300-4640u¤
00809-0300-4640 Rev. AA
Loading...
