Rose displays ANOGOTCHA SQUARE WITH MULTICLIPS User Manual

AnoGotcha™

Parts

OneUp Instruction Sheet

AnoGotcha Shell

12AG400SQ

Instructions for Hanging

Step 1

Insert T-Top Gotcha Holder into AnoGotcha Shell. Fig. 1

Step 2

Squeeze sides of MultiClip together. Fig. 2

Step 3

Align the bottom rail of the MultiClip with the top channel of the aluminum holder. Slide MultiClip into rail. Fig. 3

Step 4

Push end caps into place. Fig. 4

Step 5

Snap the AnoGotcha Holder open and insert poster (top and bottom). Insert graphic completely into holder until edge of graphic meets top of holder. To close, snap the AnoGotcha Holder shut. Fig. 5 Note: It is easier to open and close the Gotcha by starting at one end and working your way down the holder. With large or curling graphics, it may be easier to insert graphic at one end and slide into holder from one end to another

T-Top Gotcha

12GT100

Figure 1

MultiClip

1UP-0101

Figure 3

End Caps

06-5545

Figure 2

Figure 4

Step 6

Suspend poster. Fig. 6

Important note:

Please save and reuse the AnoGotcha Holder, End Caps and MultiClips for future projects.

AnoGotcha™ is a trademark and Gotcha® is a registered trademark of Rose Displays, Ltd. Neither the manufacturer nor any sales agent may be held liable for injury, loss or damage resulting from the use of these products. Part #02INSAnoGotchaSQMC

Incept-7.31.02

Figure 5

Figure 6

35 Congress Street, Salem, MA 01970

Tel# 1- 800 631-9707 Fax# 1-800-560-2890
