RackView Keyboard
10707 Stancliff Road
Phone: (281) 933-7673
Houston, Texas 77099
WWW.ROSE.COM
Rack Mountable Keyboard Drawer
INSTALLATION AND OPERATIONS MANUAL
TM
LIMITED WARRANTY………………………………………………………………………
Rose Electronics warrants the CrystalView DVI Quad to be in good working order for one year from the date
of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in good working
order at any time during this one-year warranty period, Rose Electronics will, at its option, repair or replace
the Unit as set forth below. Repair parts and replacement units will be either reconditioned or new. All
replaced parts become the property of Rose Electronics. This limited warranty does not include service to
repair damage to the Unit resulting from accident, disaster, abuse, or unauthorized modification of the Unit,
including static discharge and power surges.
Limited Warranty service may be obtained by delivering this unit during the one-year warranty period to Rose
Electronics or an authorized repair center providing a proof of purchase date. If this Unit is delivered by mail,
you agree to insure the Unit or assume the risk of loss or damage in transit, to prepay shipping charges to
the warranty service location, and to use the original shipping container or its equivalent. You must call for a
return authorization number first. Under no circumstances will a unit be accepted without a return
authorization number. Contact an authorized repair center or Rose Electronics for further information.
ALL EXPRESS AND IMPLIED WARRANTIES FO R THIS PRODUCT INCLUDING THE WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMIT ED IN DURATION TO A
PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE, AND NO WARRANTIES, WHETHER
EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD. SOME STATES DO NOT ALLOW
LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
IF THIS PRODUCT IS NOT IN GOOD WORKING ORDER AS W ARRANT ED ABOVE, YOUR SOLE
REMEDY SHALL BE REPLACEMENT OR REPAIR AS PROVIDED ABOVE. IN NO EVENT WILL ROSE
ELECTRONICS BE LIABLE TO YOU FOR ANY DAMAGES INCLUDING ANY LOST PROFITS, LOST
SAVINGS OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF
OR THE INABILITY TO USE SUCH PRODUCT, EVEN IF RO SE ELECTRONICS OR AN AUTHORIZED
DEALER HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES, OR FOR ANY CLAIM BY
ANY OTHER PARTY.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, SO THE ABOVE MAY NOT APPLY TO
YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER
RIGHTS WHICH MAY VARY FROM STATE TO STATE.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at his own expense.
IBM, AT, and PS/2 are trademarks of International Business Machines Corp. Microsoft and Microsoft
Windows are registered trademarks of Microsoft Corp. Any other trademarks mentioned in this manual are
acknowledged to be the property of the trademark owner.
Copyright Rose Electronics 2012. All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transcribed in any form or any means, electronic or mechanical, including photocopying and
recording, without the prior written permission of Rose Electronics.
Rose Electronics Part # MAN-CRVDVIQ
Printed In the United States of America – 1.3
FCC/IC STATEMENTS, EU DECLARATION OF CONFORMITY
Product: RackView Keyboard
This equipment generates, uses and can radiate radio frequency energy and if not installed and
used properly, that is in strict accordance with the manufacturer’s instructions may cause
interference to radio communication. It has been tested and found to comply with the limits for a
Class A digital device in accordance with the specifications of Part 15 of FCC rules, which are
designed to provide reasonable protection against such interference when the equipment is
operated in a commercial environment. Operation of this equipment in a residential area is likely to
cause interference, in which case the user at his own expense will be required to take whatever
measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance could
void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital
apparatus set out in the Radio Interference Regulation of Industry Canada.
Operation is subject to the following two conditions:
1- This device may not cause harmful interference
2- This device must accept any interference received including interference that may cause
undesired operation.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites
applicables aux appareils numériques de la classe A prescrites dans le Règlement sur le brouillage
radioélectrique publi é par Indus tr i e Ca na da.
CE Statement
The product meets European Standard EMC:
EN-55022:2006 Class A
EN 61000-4-2:2001
EN 61000-4-3:2006
EN 61000-4-4:2004
EN 61000-4-5:2006
INTRODUCTION
Disclaimer
While every precaution has been taken in the preparation of this manual, the manufacturer assumes
no responsibility for errors or omissions. Neither does the manufacturer assume any liability for
damages resulting from the use of the information contained herein. The manufacturer reserves the
right to change the specifications, functions, or circuitry of the product without notice.
The manufacturer cannot accept liability for damages due to misuse of the product or other
circumstances outside the manufacturer’s control. The manufacturer will not be responsible for any
loss, damage, or injury arising directly or indirectly from the use of this product.
Introduction
The RackView is the perfect addition to your server room. It mounts easily at any height in a
standard 19" rack. It slides easily into the rack and out of site when it's not in use. The optional builtin KVM switch capability offers the added convenience of complete access to as many as 1,000
servers or computers. Adding a multi-user KVM switch allows server management to be performed
locally from RackView or remotely from multiple KVM workstations.
Features
₃ Integrated touchpad mouse for PS2 and USB
₃
15”, 17”, or 19” TFT/LCD color monitor with front panel controls
₃
Built-in single or multiple user KVM switch options provides access to as many as 1,000
computers (Separate monitor needed)
₃
Quick and easy rack mounting installation
₃
Front panel conceals unit when it is not in use
₃
Full size keyboard for typing comfort
₃
Easy-glide KVM drawer can be mounted at any height in a standard 19 inch rack
₃
Made in USA
RackView Keyboard Installation and Operation Manual ..1..
Package contents
Dimensions
Depth
Weight
RV1-KTZ
17.8 in / 452 mm
13.2 lbs / 6 Kg
Installation and Operation Manual
₃ RackView Drawer assembly
₃
User manual CD
₃
USB Cable
₃ Rack mounting brackets
₃
Eight screws for bracket/rail fastening
Unpacking
DO NOT DISCARD THE SHIPPING CONTAINER, PACKING MATERIAL OR SHIPPING PLATE.
₃
₃
Tools needed - #2 Phillips head screwdriver
₃
Remove RackView Keyboard from the shipping container by removing the top protective foam and lifting
from the middle of the unit.
Remove other protective foam and covering.
₃
₃
Set the unit on a flat surface and open the monitor far enough to remove the protective foam material, and
then close the monitor.
Remove the shipping plate from the back of the unit’s rail assembly (if applicable).
₃
Do not adjust the front rail brackets.
₃
₃
The rack dimensions must be 19” x 23” to 28”
It is recommended that two people perform the installation.
Part Numbers
RV1-KTZ 1U Keyboard Drawer
Mounted PS/2 and USB
Keyboard + Touchpad mouse
Specifications
Keyboard: Full size tactile keyboard with separate numeric keypad,
Mouse: Touchpad
Connectors: Keyboard: PS/2 or USB
Mouse: PS/2 or USB
..2.. RackView Keyboard
RackView Keyboard Installation
RackView is very easy to install. Simply adjust the rack rail length to the depth of your rack, slide
the unit through the rack and secure the rack mount brackets to the rack rails.
Assembly
1. Tilt the RackView Keyboard assembly enough to fit through the rack opening. Guide it through
the rack until the rear mounting flanges are just past the rear of the rack rails. Make sure the front
mounting flanges remain on the outside of the front rack rails.
2. Level the RackView Keyboard assembly (left to right) and secure the rear mounting flanges (left
and right) to the rear rack rails using the included mounting screws (4 screws).
3. Secure the front mounting flanges (left and right) to the front rack rails using the included
mounting screws (4 screws). Make sure the RackView Keyboard assembly is level (front to
back).
4. Check that the RackView Keyboard assembly will slide in flush with the front rack rails, and open
fully with no binding. See Figure 1 for further reference.
RackView Keyboard Installation and Operation Manual ..3..
Figure 1: Product Dimensions
Installation and Operation Manual
..4.. RackView Keyboard
Maintenance and Repair
This unit does not contain any user-serviceable parts. In the event a Unit needs repair or
maintenance, you must first obtain a Return Authorization (RA) number from Rose
Electronics or an authorized repair center. This Return Authorization number must appear on
the outside of the shipping container.
When returning a Unit, it should be packed in the original container or equivalent, insured and
shipped to:
Rose Electronics
Attn: RA__________
10707 Stancliff Road
Houston, Texas 77099 USA
Technical Support
If you are experiencing problems, or need assistance in setting up, configuring or operating
your Rose Electronics equipment, consult the appropriate sections of this manual. If,
however, you require additional information or assistance, please contact the Rose
Electronics Technical Support Department at:
Phone: (281) 933-7673
E-Mail: TechSupport@rose.com
Web: www.rose.com
Technical Support hours are from: 8:00 am to 6:00 pm CST (USA), Monday through Friday.
Please report any malfunctions in the operation of this Unit or any discrepancies in this
manual to the Rose Electronics Technical Support Department.
Copyright Rose Electronics 2002. All rights reserved.
No part of this manual ma y be reproduced, stored in a retrieval system, or transcribed in any form or any means, electronic or mechanical, including
photocopying and recording, without the prior written permission of Rose Electronics.
Rose Electronics Part # MAN-RV-1.4
Printed In the United States of America – Revision 1.4
RackView Keyboard Installation and Operation Manual ..5..
Safety……………………………………………………………………………………............
Installation and Operatin Manual
The RackView Keyboard has been tested for conformance to safety regulations and
requirements, and has been certified for international use. Like all electronic equipment, the
RackView Keyboard should be used with care. To protect yourself from possible injury and to
minimize the risk of damage to the Unit, read and follow these safety instructions.
Follow all instructions and warnings marked on this Unit.
Except where explained in this manual, do not attempt to service this Unit yourself.
Do not use this Unit near water.
Assure that the placement of this Unit is on a stable surface or rack mounted.
Provide proper ventilation and air circulation.
Keep power cord and connection cables clear of obstructions that might cause damage to
them.
Use only power cords and connection cables designed for this Unit.
Use only a grounded (three-wire) electrical outlet.
Keep objects that might damage this Unit and liquids that may spill, clear from this Unit.
Liquids and foreign objects might come in contact with voltage points that could create a
risk of fire or electrical shock.
Operate this Unit only when the cover is in place.
Do not use liquid or aerosol cleaners to clean this Unit. Always unplug this Unit from its
electrical outlet before cleaning.
Unplug this Unit from the electrical outlet and refer servicing to a qualified service center if
any of the following conditions occur:
The power cord or connection cables are damaged or frayed.
The Unit has been exposed to any liquids.
The Unit does not operate normally when all operating instructions have been followed.
The Unit has been dropped or the case has been damaged.
The Unit exhibits a distinct change in performance, indicating a need for service.
..6.. RackView Keyboard
