Rose CrystalView DVI Multi User Manual

CrystalView DVI Multi

IN S TAL LATION AND

MANUAL

OPERATIONS

10707 Stancliff Road Phone: [phone]
Houston, Texas 77099 WWW.ROSE.COM

LIMITED WARRANTY

Rose Electronics warrants the CrystalView Multi to be in good working order for one year from the
date of purchase from Rose Electronics or an authorized dealer. Should this product fail to be in
good working order at any time during this one-year warranty period, Rose Electronics will, at its
option, repair or replace the Unit as set forth below. Repair parts and replacement units will be
either reconditioned or new. All replaced parts become the property of Rose Electronics. This
limited warranty does not include service to repair damage to the Unit resulting from accident,
disaster, abuse, or unauthorized modification of the Unit, includin g s tatic dis charge and power
surges.

Limited Warranty service may be obtained by delivering this unit during the one-year warranty
period to Rose Electronics or an authorized repair center providing a proof of purchase date. If this
Unit is delivered by mail, you agree to insure the Unit or assume the risk of loss or damage in
transit, to prepay shipping charges to the warranty service location, and t o use the origi nal shippi ng
container or its equivalent. You must call for a return authorization number first. Under no
circumstances will a unit be accepted without a return authorization number. Contact an authorized
repair center or Rose Electronics for further information.

ALL EXPRESS AND IMPLIED WARRANTIES FOR THIS PRODUCT INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR P URPOS E, ARE
LIMITED IN DURATION TO A PERIOD OF ONE YEAR FROM THE DATE OF PURCHASE, AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY
LASTS, SO THE ABOVE LIMITATIO N MAY NOT APPLY TO YOU.

IF THIS PRODUCT IS NOT IN GOOD WORKING ORDER AS WARRANTED ABOVE, YOUR
SOLE REMEDY SHALL BE REPLACEMENT OR REPAIR AS PROVIDED ABOVE. IN NO EVENT
WILL ROSE ELECTRONICS BE LIA BLE T O YOU FOR ANY DAMAGES INCLUDING ANY LOST
PROFITS, LOST SAVINGS OR OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES
ARISING OUT OF THE USE OF OR THE INABILITY TO USE SUCH PRODUCT, EVEN IF ROSE
ELECTRONICS OR AN AUTHORIZED DEALER HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES, OR FOR ANY CLAIM BY ANY OTHER PARTY.

SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR CONSUMER PRODUCTS, SO THE ABOVE MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY
ALSO HAVE OTHER RIGHTS WHICH MAY VARY FROM STATE TO STATE.

NOTE: This equipment has been test ed and found t o c omply with the limits fo r a C lass B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipmen t in a residen tial area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.

IBM, AT, and PS/2 are tr ademarks of Internatio nal Business Machines Corp. Microsoft a n d
Microsoft Windows are registered trademarks of Microsof t Corp. Any other trad emarks mentioned
in this manual are acknowledged to be the property of the trademark ow ner.

Copyright  Rose Electronics 2010. All rights reserved.
No part of this manual may be reproduced, stored in a retrieval system, or transcribed in any form or any
means, electronic or mechanical, including photocopying and recording, without the prior written
permission of Rose Electronics.

Rose Electronics Part # MAN-CRVDVIMUL
Printed In the United States of America – Revision

TABLE of CONTENTS

Contents Page #

System Introduction ..................................................................................... 1

Features ................................................................................................... 2

Package Contents ................................................................................... 2

Additional Items needed .......................................................................... 2

Rose Electronics web site ........................................................................ 2

Product Registration ................................................................................ 2

Models ......................................................................................................... 3

Product Installation ...................................................................................... 4

EDID Learning procedure ........................................................................ 4

Maintenance and Repair ............................................................................. 6

Technical Support ....................................................................................... 6

Safety .......................................................................................................... 7

Safety and EMC Regulatory Statements .................................................... 8

Figures Page #

Figure 1. Typical connections ...................................................................... 5

Appendices Page #

Appendix A – General Specifications .......................................................... 9

Appendix B – Part Numbers ........................................................................ 9

INTRODUCTION

Disclaimer

While every precaution has been taken in the preparation of this manual,
the manufacturer assumes no responsibility for errors or omissions.
Neither does the manufacturer assume any liability for damages resulting
from the use of the information contained herein. The manufacturer
reserves the right to change the specifications, functions, or circuitry of the
product without notice.

The manufacturer cannot accept liability for damages due to misuse of the
product or other circumstances outside the manufacturer’s control. The
manufacturer will not be responsible for any loss, damage, or injury arising
directly or indirectly from the use of this product.

System Introduction

The CrystalView DVI Multi from Rose Electronics is the perfect addition to
your video distribution system. Whether you are enhancing an existin g
system or designing a new video distribution system, the CrystalView DVI
Multi can easily integrate into your system and provide perfect DVI video
quality to all connected displays. If you need to extend a single video to a
remote monitor, the CrystalView DVI Multi single model works perfectly for
the task. If you have multiple monitors that you need to display
information to, the x2, x4, and x8 models can handle the job. With all
models, you can view locally what is being distr ibuted to the remote
monitors.
The remote displays can be extended up to 220 feet away from the
controlling computer. This is ideal for many applications where the
controlling computer needs to be remotely located in a secure area away
from the DVI displays, especially in a retail environment.

All models offer a local DVI connection for viewing on a locally connected
DVI monitor.

CrystalView DVI Multi Installation and Operations Manual 1
