ASSEMBLY INSTRUCTIONS
BEFORE ASSEMBLY
Description
Dimension
: ROUND TABLE WITH 2 DROP LEAVES
: Ф42”x29”1/2.H
Cube Size : 44”x26.7”x3.1” NW: 28.6 LBS
(TOP) GW: 31 LBS
Cube Size : 25.5”x9”x6” NW: 12.1 LBS
(PEDESTAL) GW: 14 LBS
Thank you for purchasing this quality product. This product has been designed for easy assembly and constructed for durability. Please take the time to read
and follow the assembly instructions carefully.
- 1 -
Be sure to check all packing material carefully for small parts which may have come loose inside the carton during shipment. Please separate, identify, and
PART LIST
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
A
Top
1 B Leg
4
C
Pedestal
1
D
Mounting
plate
1
HARDWARE LIST
NO
Description
Qty
Sketch
NO
Description
Qty
Sketch
1
Large flat
washer
(Bag 2)
(8.5x19mm)
4
2
Large lock
washer
(Bag 2)
(8.5x11mm)
4
3
Hexagon nut
(bag 2)
(M8x13mm)
4
4
Wrench
(Bag 2)
(M13mm)
1
5
Small flat
washer
(bag 2)
(6.5x13mm)
4
6
Small lock
washer
(Bag 2)
(6.5x9mm)
12
7
Bolt
(Bag 2)
(M6x48mm)
12
8
Medium flat
washer
(Bag 2)
(6.5x16mm)
8
9
Allen key
(Bag 2)
(M4)
1
10
Screw
M3.5x20
(Bag 1)
4
11
Plastic
(Bag 1)
2
STEP1
Hardware Bag 1
Hardware Bag 2
count all parts and metal hardware. Compare with part list to be sure all parts are present.
If hardware is missing or you have difficulty assembling this product, please call for us.
IMPORTANT NOTE:
- Place all wooden parts on a clean and smooth surface such as a rug or carpet to avoid the parts from being scratched.
- Remove all wrapping material, including staples & packing straps before you start to assemble.
- DO NOT tighten all screws and bolts until completely assembled.
- Keep all hardware parts out of reach of children.
When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have the following parts:
When unpacking, please be careful not to discard any parts with the packaging. Before continuing, please make sure you have all of the
following hardware:
Attach legs (B) to the pedestal (C) with washers (1), (2) and nuts (3). Tighten with wrench (4).
- 2 -
x4
C
B
1
2
3
4
STEP 2
Put the Mounting plate (D) on top of the pedestal, and attach with bolts (7), washers (5), (6). Tighten with Allen
6
5
7
9
D
x4
STEP 3
Remove
Hardware bag 1
key (9).
Please remove Hardware Bag 1 as shown below.
- 3 -
STEP 4
Attach plastic(11) to the top (A). use the screw driver to tighten the screws (10) as shown below.
STEP 5
6
8
7
9
A
x8
A
X4
10
11
Carefully place the frame (from Step 2) on bottom side of the table top (A), with bolts (7), washers (8), (6).
Tighten with Allen key (9).
- 4 -
