Rong Tian Shi Tech Outdoor HD PTZ IP User Manual
Rong Tian Shi Tech Ltd
Outdoor HD PTZ IP Speed Dome Camera
Main feature:
Private mold, 2.5 inch professional design for HD network camera, beautiful and delicate, best for
security
Material: Plastic, IP66 waterproof
6pcs array IR + 4pcs white LED, effective night vision distance is 40-50 meters in dark
environment
H.265 Video compression,5 megapixel (2560x1920), 2 megapixel (1920x1080)
Support for factory dynamic domain name and third-party dynamic domain name resolution
IR-CUT auto switch in day and night, 3.6mm megapixel fixed focus lens
Preset position, cruise, limit scan, home position functions
Horizontal 355° rotation, rotate speed 60° / second, vertical 3° - 90° rotate, speed 30° / second
Will not lose internal data when power off, can manual control IR LED turn on / off
Support 3D DNR, digital WDR, auto white balance, auto electronic shutter, auto electronic gain, real
color reproduction, high resolution image
Support ONVIF protocol
Support FTP server
Support IE ,Google, Firefox browser
Functions: WIFI / Audio / TF Card slot
Free P2P for remote surveillance
Installation method: wall mount
Size: 179 x 171 x 110 mm (included bracket)
China Professional manufacturer of security products and fingerprint door lock
Tel: +86 755-27512212 ; Fax: +86 755-27516873 ; www.ratingsecu.com
Model:
R-QS2510-HH50
5MP
R-QS2510-HJ20
2MP
Camera
Imaging
sensor
1/2.8” COMS SONY IMX335
1/2.7" SC2235H
Chip
Hi3516EV300
T21
Signal system
PAL / NTSC adjustable
Scanning
Mode
Progressive scanning
Illumination
Color :0.2 Lux@F1.2 B/W: 0.02 Lux @ F1.2
Lens
3.6mm megapixel lens (2.7-13.5mm 5X zoom for optional)
Day and night
switch
IR-CUT dual optical filters auto switch in day and night
Electronic
shutter
1/25s~1/10000s; automatic
White balance
Auto / manual
DNR
DNR
SNR
≥50dB(AGC OFF)
Privacy
masking
Support
IR source
6pcs IR + 4pcs white LED
Night vision
distance
40-50 meters
Standard
compression
compression
H.265, H.264
Video bit rate
32 Kbps -- 6144 bps;
Audio
compression
G.726/G.711
Main stream
5MP (2560 x 1920)
4MP (2560 x 1440)
2MP (1920x1080)
Sub stream
800x448
Frame rate
1-25fps (50HZ)
1-25fps (50HZ)
adjustment
Can adjust Saturation, brightness, contrast, sharpness
mirroring
Horizontal mirroring, vertical mirroring
Scene
Auto, indoor, outdoor
Digital enlarge
Can achieve through NVR, P2P HD monitoring management software
Rong Tian Shi Tech Ltd
Technical parameters:
China Professional manufacturer of security products and fingerprint door lock
Tel: +86 755-27512212 ; Fax: +86 755-27516873 ; www.ratingsecu.com
