DROP-IN CERAMIC SINK
Model :
Item Number starting with 2003 XX, 2004XX
Tools Required
MATERIALS INCLUDED
1 Vitreous China Drop In Sink
Step 1:
Position countertop opening to ensure clearance
between the lavatory, faucet, and backsplash.
Cut counter top opening and cut-out base on the
cut-out template provided. Set sink and seal with
silicone or caulking
See Figure 1.
NOTE:
DO NOT USE any adhesives with silicone. Silicone will bond to
the decorative finish and cause permanent damage. Check the
Ronbow website for the individual sink cutout template.
Figure 1.
countertop
Step 2:
Step 3:
Step 4:
Place a generous portion of plumbers’ putty
under drain cap and insert whole drain body
inside the bowl and through the countertop.
NOTE: There may be a small beveled rubber
washer packaged with your drain, please discard
this and use plumbers’ putty instead)
See Figure 2.
From under the drain, insert the thickrubber
washer and screw on and tighten the metal nut.
Remove excess plumbers’ putty
See Figure 3.
Attach p-trap to tailpiece.
Figure 2.
Figure 3.
Overflow hole
Drain
Drain Nut
Tailpiece
Drain Cap
Thick rubber
washer
Metal Nut
Tailpiece
Thick rubber
washer
P-trap
1
170620ronbow.comINSTALLATION SHEET
DROP-IN CERAMIC SINK
Model :
Item Number starting with 2003 XX, 2004XX
PRODUCT CARE AND MAINTENANCE
The fine furniture finish of your new vanity, mirror or other bathroom accessories are designed to
protect against normal home use. With proper care, your product will provide years of use and beauty
in your home.
General Care Tips
• Test cleaning product on small, discrete area prior to applying to entire surface.
• Wipe surfaces frequently with dry, soft, non-abrasive and lint-free towel.
• Do not allow liquids and moisture to accumulate on the surface of products.
• For warranty information, please visit our website at www.ronbow.com or contact the Customer Service
Department at (510) 713-1188.
Ceramic Sinks
• If a spill occurs, clean and dry the surface immediately as liquid can soak through the surface and cause
greater damage.
• Do not place in direct sunlight. Exposure to sunlight may affect the appearance of your vanity, and the
finish will eventually crack.
• Keep away from direct sources of extreme temperatures as heat, cold or moisture from humidity.
Color changes, or blemishes in the wood can occur if recommended care of is not met. Try to avoid
these extremes.
• Most wood surfaces can be cleaned, or dusted, with any commercial wood cleaning product. For general
cleaning, use a non-abrasive, or lint-free cloth while dusting along the wood grain to preserve the
wood’s chacteristics.
Recommended Products
• Bar Keeper’s Friend
• Household Vinegar
• Propietary Bathroom Cleaning Products
DISCLAIMERS:
amounts of cleansers. Because of these many dierent conditions, Ronbow cannot guarantee that the above
eectively clean your product.
Eectiveness of cleaning your Ronbow products is dependent on various factors that include: water temperature, concentration and/or
Product Care & Maintenance methods will
2
