IMPORTANT:
PLEASE, READ ALL INSTRUCTIONS
BEFORE ASSEMBLING!
PLEASE, SAVE INSTRUCTIONS FOR
FUTURE USE
ASSEMBLY INSTRUCTIONS
FOR
8510
YOUR
STATIONARY CRIB
THIS CRIB CONFORMS TO APPLICABLE
REGULATIONS PROMULGATED BY THE
CONSUMER PRODUCT SAFETY COMMISION
20 Corporation Row, Edison, NJ 088 7
Phone1(718) 478-5100, Fax (718) 478-5117
www.rominakidsfurniture.com
Europe's Kids Furniture
Furniture
DO NOT THROW THIS INSTRUCTION BOOKLET
NOTE: THE STYLE OF YOUR CRIB,
MATTRESS SUPPORT OR
TODDLER RAIL MAY VARY FROM
WHAT IS PICTURED IN THE
INSTRUCTION SHEET
this picture shows how your crib
should look like after completing assembly
* READ ALL INSTRUCTIONS BEFORE ASSEMBLING
CRIB. KEEP INSTRUCTIONS FOR FUTURE USE.
* NEVER USE PLASTIC SHIPPING BAGS OR OTHER
PLASTIC FILM AS MATTRESS COVERS BECAUSE
THEY CAN CAUSE SUFFOCATION.
* INFANTS CAN SUFFOCATE IN GAPS BETWEEN CRIB
SIDES AND A MATTRESS THAT IS TOO SMALL.
CAUTION:
*WHEN A CHILD'S HEIGHT REACHES 35 INCHES, THE CHILD SHOULD BE PLACED IN AYOUTH
OR REGULAR BED.
*USE OF A VAPORIZER NEAR FURNITURE WILL CAUSE WOOD TO SWELL AND FINISH TO
PEEL.
*DO NOT STORE CRIB IN AREAS WHERE TEMPERATURES AND CONDITIONS ARE EXTREME,
SUCH AS HOTATTICS OR COLD DAMP BASEMENTS. BOTH OF THESE EXTREME CONDITIONS
MAY CAUSE THE WOOD TO CRACK AND GLUE JOINTS TO LOOSEN RESULTING IN
STRUCTURAL FAILURE.
*SHOULD IT BECOME DESIRABLE TO REFINISH THIS CRIB IN LATER YEARS, THE
MANUFACTURER WARNS THAT ANY MATERIAL USED SHOULD BE NON-TOXIC. REGULAR
CLEANING WITH MILD SOAP ON A SOFT CLOTH, FOLLOWED BY A CLEAN DAMP CLOTH, THEN
ADRY CLOTH, WILL PRESERVE THE ORIGINALLUSTER AND BEAUTY OF THIS FINE FINISH.
*THIS CRIB IS NOT EQUIPPED TO HANDLE THE EXCESS WEIGHT OF A CRIB WATER
MATTRESS.
*LIFT SLIGHTLY WHEN MOVING ON CARPETINGTO PREVENT LEGBREAKAGE.
ENSURE A SAFE ENVIRONMENT FOR THE CHILD BY
CHECKING REGULARLY, BEFORE PLACING THE CHILD IN
THE CRIB, THAT EVERY COMPONENT IS PROPERLY AND
SECUERLY IN PLACE.
MAINTENANCE OF YOUR ROMINA CONVERTIBLE CRIB:
DO NOT
ROMINA FURNITURE
NEVER SUBSTITUTE PARTS OR MAKE ALTERATIONS TO
YOUR CRIB!
AFTER YOU FINISH ASSEMBLING YOUR CRIB, BE SURE THAT
ALL BOLTS HAVE BEEN TIGHTENED SECURELY. YOU MUST
CHECK ALL BOLTS PERIODICALLY AND RE-TIGHTEN AS
NECESSARY. PERIODICALLY INSPECT CRIB FOR DAMAGED
HARDWARE, LOOSE JOINTS OR SPLINTERED EDGES.
USE CRIB IF PARTS ARE DAMAGED OR BROKEN!
CONTACT YOUR DEALER OR FOR
ASSISTANCE AND REPLACEMENT PARTS. PLEASE BE SURE
TO HAVE YOUR MODEL CODE WRITTEN DOWN BEFORE YOU
MAKE CONTACT. THE MODEL CODE CAN BE FOUND ON A
WHITE LABEL LOCATED ON THE INSIDE OF YOUR CRIB ON
THE SIDE PANEL.
printed in full size
5
6
7
8
9
3
4
Please locate and confirm that
you have the following parts:
EP. end panel = 2
FS. fixed side = 2
SB. stabilizing bar = 2
MS. mattress support = 1
one bag of hardware with the following:
1. Allen wrench =
2. one storage pouch and two plastic ties
3. Allen bolt (3/4" or 20 mm) = 4
4. Allen bolt (1 31/32" or 50 mm) = 8
5. rounded head bolt (1 3/16" or 30 mm) = 4
6. rounded head bolt (19/32" or 15 mm) = 4
7. "butterfly" type nut = 4
8. bigger “internal star” lock washer = 12
9. smaller “external star” lock washer = 8
1
Required tools:
CAUTION:
Allen wrench (supplied), Phillips
screwdriver (not included), flat screwdriver
Do not use a power screwdriver which
can cause screws to break or strip
(not
included).
Note:
TIGHTEN COMPLETELY
During the assembly process whenever using screws or bolts, check
each by placing the screw / bolt on the upper diagram which is drawn in actual
size. Be sure to use the proper size and shape specified in the instructions.
Be sure to the screws / bolts when you are asked to do this.
Phillips screwdriver (not included)
The item
number of your
product is located on
the inner side of the left
pannel, on a black and white
label. Please, refer to this number in
the event that you need to call ROMINA
FURNITURE or your local distributor.
Note:
Thank
you.
Note: The letters which
identifies a part are the
initials of the respective
part name (such method
is employed to facilitate
parts recognition
between the drawings
and the parts list).
1
7
2
MS
SB
EP
EP
FS
FS
8
9
REQUIRED
T ixedsides and attach them to using all the 8
bigger Allen bolts and 8 washers .
STEP 1
Align the tenons attached at the end of the stabilizing bars with the lower holes existing
on the inner faces of the end panels of the crib. Using all the 4 smaller Allen bolts 4
washers and the suplied Allen wrench attach the stabilizing bars to the end panels
.
Be sure that the metallic inserts faces of the stabilizing bars are facing towards the inside of
the crib (follow the instructions attached to the stabilizing bar). Start the threads by hand to
assure you don't strip the threads.
Do not tighten the bolts completely at this moment, you will be asked to do this later.
the end panels y
Start the threads by hand to assure you don't strip
the threads, then, use the suplied Allen wrench .
U
all the bigger Allen bolts listed above
(see ).
You have a total of Allen bolts, distributed as following:
- bigger bolts in the fixedsides
(SB)
(3),
(8) (1)
(EP)
(EP)
(1)
tighten
completely 8 (4)
FIGURE 1
8
8 (4+8) (FS)
ake the f (S)
(4) (8)
F of our crib
REMINDER
sing the Allen wrench supplied,(1) you must
FIGURE 1
FS
EP
FS
SB
SB
EP
4
3
4
3
4
4
4
4
3
4
4
WARNING:
VERY
IMPORTANT
TO KEEP YOUR BABY
SECURE AND SAFE, AND TO AVOID
POTENTIAL INJURY OR DEATH, IT'S
TO
ALLTHE BOLTSLISTED IN .
TIGHTEN COMPLETELY
8 STEP 1
WARNING!
TIGHTEN COMPLETELY!
WARNING!
TIGHTEN COMPLETELY!
8
8
8
8
8
8
8
8
8
8
8
REQUIRED
LOWEST POSITION
MIDDLE POSITION
HIGHEST POSITION
LOWEST POSITION
MIDDLE POSITION
HIGHEST POSITION
Assemble the mattress support using 4 bigger
round head bolts , 4
STEP 2
(5)
Do not tighten the bolts completely at
this step, you will be asked to do this later.
"butterfly" type nuts , 4
smaller lock washers and a Phillips screwdriver
(not supplied). The lock washer must be attached
to the bolt after the bolt passed through the frame
and the metallic bracket of the mattress support
and before attaching the nut.
There are three positions for the mattress support
(from the highest one for a newborn to the lowest
one for a child that is maximum 35" tall - see
caution note). You must adjust the height of the
mattress support depending of your child height by
inserting all the four bolts in the same position
(see ).
(7)
(9)
FIGURE 2
NOTE: THE STYLEOF YOUR CRIB OR
OF YOUR MATTRESS SUPPORT MAY
VARY FROM WHAT IS PICTURED IN
THE INSTRUCTION SHEET
FIGURE 2
5
7
5
7
5
7
5
7
5
7
9
9
9
9
9
To adjust the vertical position of your mattress support you must remove all the four bolts & nuts
loosen all the four bolts , lower the frame and insert the bolts back into the corresponding holes,
according to the desired height (see ). Then, you must attach the lock washers and the nuts
as described in andtighten all the bolts completely.
ADJUSTING THE HEIGHT OF YOUR MATTRESS SUPPORT
(5+9+7),
(6+9) (5)
FIGURE 2 (9) (7)
STEP 2
ADJUSTED THE HEIGHT OF YOUR MATTRESS
SUPPORT
Your crib is designed in such a manner that, when the mattress support is adjusted to it’s lowest
position, themattress support frame must be placed directly over the stabilizing bars. Before tighten
the bolts, you must slightlypress the mattress supportframe to make sure thisposition is achieved.
WARNING:
IT'S VERY IMPORTANT TO TIGHTEN COMPLETELY ALL THE 8 BOLTS
(5+9+7) & (6+9) AFTER YOU HAVE
.
TO KEEP YOUR BABY SECURE AND SAFE, AND TO AVOID POTENTIAL INJURY OR
DEATH,
5+9+7
6
5+9+7
5+9+7
5+9+7
STEP 3
REMINDER
STEP 4
(Two adults are required to complete this
step)
STEP 1
(FS)
tighten
completely 4 (3+8)
FIGURE 3
(MS)
(6+9)
tighten completely 8
(5+9+7, 6+9)
FIGURE 3
12
4 (3+8) (SB)
4 (6+9)
(SB)
4 (5+9+7)
(MS).
(Two adults are required to complete this
step)
y as resulted after completing and
carefully lace it on the floor with one of the fixedsides
on the ground, taking care not to scratch its finish.
U
all the smaller Allen bolts used to fix
the stabilizing bars (see ).
the mattress support on the stabilizing bars
using all the four smaller rounded head bolts and washers
all the bolts
involved in mattress support fixing using a
Phillips screwdriver (not supplied) (see ).
You have a total of bolts, distributed as following:
- smaller Allen bolts in the stabilizing bars ;
- smaller rounded head bolts in the stabilizing bars
;
- bigger rounded head bolts in the mattress
support
Turn your crib with its feet back on the floor.
A
After completing assembly,
your crib should look like the
one depicted on the first page
of this manual
Take our crib
p
Mount
sing the supplied Allen wrench ,
supplied and a Phillips screwdriver (not supplied).
The lock washer must be attached to the bolt before
inserting the bolt through the metallic bracket of the
mattress support.
Now,
ttach the storage pouch supplied to the mattress support
spring using two plastic ties (also supplied). Store this
instruction booklet in the
storage pouch for future use.
(1) you must
you must
FIGURE 3
3
3
3
3
WARNING:
VERY
IMPORTANT
TO KEEP YOUR BABY
SECURE AND SAFE, AND TO AVOID
POTENTIAL INJURY OR DEATH, IT'S
TO
ALLTHE BOLTS LISTED IN .
TIGHTEN COMPLETELY
12 STEP 3
WARNING!
TIGHTEN COMPLETELY!
REQUIRED
MS
9
8
8
8
8
9
6
9
6
9
6
TODDLER RAIL OPTION OF
YOUR CONVERTIBLE CRIB8510
(THE TODDLER RAIL IS SOLD SEPARATELY)
NOTE: Y
ASSEMBLY INSTRUCTIONS FOR TODDLER RAIL
CAN BE FOUND INSIDE OFTR 8510 PACKAGE.
PLEASE, CONTACT ROMINA FURNITURE OR YOUR
LOCAL DISTRIBUTOR FOR MORE INFORMATION.
OU CAN ATTACH A TODDLER RAIL TO
YOUR CRIB WITH THE PURCHASE OF ROMINA
FURNITURE ITEM ( ODDLER AIL ).TR 8510 T R 8510
NOTE: THE STYLE OF YOUR CRIB, MATTRESS
SUPPORT OR TODDLER RAIL MAY VARY FROM
WHAT IS PICTURED IN THE INSTRUCTION SHEET
GENERAL FURNITURE CARE TIPS
· Wood, like any natural material is likely to present variations of grain and texture which will result in
slight color variations or richness in the finish. These differences make each Romina furniture item as
beautiful and unique as you and your baby are.
· To preserve the initial appearance and functionality of your furniture, it is recommended that all furniture
items be used in accordance withtheir intended design.
· Special water-based finishes are used to make this furniture safe for your baby. These finishes may be
more delicate than those used onadult furniture thus requiring carefulmaintenance.
· Constant rubbing or mechanical interaction with sharp/hard objects such as belt buckles, jeans' zippers
or buttons will likely damage the finish on your furniture. When placing or retrieving items onto the furniture,
always set them down and pick them up, do not “slide” them. Items placed onto the horizontal surfaces
must be moved/rotated to prevent discolorationin the finish.
· Exposure to extreme variations of environmental conditions such as humidity and temperature can
affect the finish quality due to wood sudden expansion or shrinkage. It is recommended that the room
temperature be maintained in between 65 and 75 degrees Fahrenheit and a relative humidity of 35 – 40 %.
Do not place items which aretoo hot or too colddirectly onto the finishedsurfaces!
· Use caution when using a humidifier or vaporizer. Excessive moisture is harmful to the furniture causing
the finish to peel and thewood to warp.
· Wipe up spills promptly. If water or otherliquids stay incontact withthe furniturefor a longperiod oftime,
they can cause the finish to turn white or discolor. Alcohol orsolvent containingsubstances ormaterials will
permanently damage the finish.
· In general, furniture should not be placed in front or too close to air-conditioning outlets, fireplaces,
heaters or humidifiers. Direct sunlight and ultraviolet rays will cause colors to fade, affect the luster and
smoothness of the finish and in most cases may cause hairline cracks in the finish. White finishes will
yellow naturally over time; exposure to direct sunlight will accelerate this natural process. Please note that
all wood essences will darken over time along with the natural aging process which is not considered to be
a quality defect.
· To clean the furniture, use a damp cloth immediately followed by wiping with a dry cloth. Do not allow
water to stay in contact withthe finish as it willdamage the finish.
· If you need to put your furnitureinto storage for any period of time, avoid placing it indamp basements or
hot attics. Air flow around and under the furniture should be allowed. Do not place furniture too close to
walls, do not stack anything onit and do not coverit entirely.
· When using a vinyl changing pad or similar plastic accessories, make sure to use a fabric felt
underneath. Certain plastics have ingredients that can react with and damage the finish. It is
recommended to rotate the changing pad'sposition frequently to avoid finishdiscoloration.
Regular cleaning with mild soapon asoft cloth,followed bya clean damp
cloth, thena dry cloth,will preserve the original lusterand beauty ofthis
fine finish ofyour RominaFurniture product.
Visit
for updates, special offers and more new designs.
www.rominakidsfurniture.com
Team
Thank you for beeing one of our distinguished clients.
Furniture
Loading...
