ROMET 4E Electric Vehicle Instruction Manual

ROMET 4E Electric Vehicle Instruction Manual

ROMET 4E Electric Vehicle Instruction Manual

Foreword

◆

Great thanks for using Romet product.

◆

Please read this Instruction Manual carefully before driving your new car. Without knowing the features of the Electric Vehicle, please do not use it.

◆

If you intend to resell your car, please ensure this Instruction Manual attached to the car, because it is an important component of this car.

◆

It is prohibited to refit your car due to the consequential influences on the entire car, especially on safety and durability and the refit may even violate the national

laws and regulations. The warranty excludes the faults or performance degradation resulted from refitting.

◆

There are many models with different configurations to be selected when purchasing the Romet products. This Manual describes all models and configurations of

similar series to this product. Herewith, this Manual may include the potential configurations for the other models while they may not be installed in this product.

◆

The nonstop improvement of the car structure, configuration and part performances ensures safety and high quality of Romet products. Although due care has been

taken to make this publication as complete and accurate as possible, it can still be subject to alteration. ROMET MOTORS reserves the right of changes without any

notices, and special attention is required for the fact that any data, illustrations or descriptions in this Manual are prohibited to be regarded as evidence for indemnity

claim. If any questions to be consulted, we are always at your service.

ROMET 4E Electric Vehicle Instruction Manual

Contents

I. Main Technical Parameters 1

II. General Indicating Diagram and Instrument Cluster of Entire Car 5

III. Operation Procedures for New Car 9

IV. Instrument Cluster Appearance 14

V. Seat and Door 24

VI. On/Off Operations of Front & Rear Engine Bonnet 29

VII. Charging 32

VIII. Motor Controller 34

IX. Notes 36

X. Basic Maintenance and Parts Replacement 39

XI. Emergency 43

XII. Cleaning and Self-maintenance 49

ROMET 4E Electric Vehicle Instruction Manual

Key Notes

I. Important notes for this Manual

The symbols used in this Manual represent as follows：

This symbol represents a special device or a kit or attachment for the other purposes, while it may not be installed in this product;

This symbol represents the end of a note;

This symbol represents the following information is used for optimum use of this product.

This symbol represents warning note. For your safety and security and prevention of damages on the car, you must read the relevant warning notes.

This symbol represents “No…”, “it is prohibited to do…”or “it should be prevented that…” as you see this safety label shown on the left.

ROMET 4E Electric Vehicle Instruction Manual

1

I. Main Technical Parameters

SPECIFICATIONS

OVER-ALL DEMENSIONS (L*W*H) ㎜ 3090 × 1420 × 1480

WHEELBASE ㎜ 2170

TRACK FRONT/REAR ㎜ 1215/1235

MIN GROUND CLEARANCE（FULL LODED）

㎜ 130

MIN TURNING RADIUS ㎜ 4440

APPROACHING ANGEL deg 30

DESCENT ANGEL deg 42

CURB WEIGHT Kg 820

LOADING CAPACITY Kg 300

MAX SPEED Km/h 65

PASSENGER PERSON 4

MAX CLIMBING CAPACITY % 20

MAX.ACCELERATING NOISE db

≦

80

STEERING TYPE WHEEL

BARKE TYPE FRONT/REAR DISC /DRUM

HAND BRAKE HAND MECHANIC

TYRE 145/70-R12

TYRE PRESSURE Kpa 250-280（SUMMER）280-300（WINTER)

RANGE KM 200

(40KM/H STEADY DRIVING,WIND SPEED BELOW LEVEL 4)

ROMET 4E Electric Vehicle Instruction Manual

2

Power assembly

1. Type of drive: rear axle drive

2. AC motor parameter as follows:

Model No. YJM-XYQ-5-4 Power 5 kw

Voltage 72V Quota 60 min

Current 104A Speed 3000r/m

Excitation

AC asynchronous

Insulation Class F

Protection class Ip20

3. Battery pack parameters

Model No. 4-DM-150 Rated voltage 8VAC

Capacity

150AH

3HR 180AH

200AH

Total voltage 72V Quantity (R6) 9 pieces

Connection type 9 batteries in series

ROMET 4E Electric Vehicle Instruction Manual

3

4. The arrangement of the battery pack in the car body is as follows:

5. Batteries are supplied in the front compartment tray while 4 in the rear compartment.

6. The model no. of AC motor controller: G8035, voltage 72V and in series

Model No. SEVCON G8035 Voltage 72V

7. Electric switch accelerator:

0-72V Hall accelerator with 0-5V output voltage

8. The technical parameters of auto hi-frequency intelligent battery charger are as follows:

Input voltage range AC90V-AC265V Output current 25A

Output voltage frequency 45Hz-65Hz Power factor

≧0.99

Output voltage 72VAC Full-load efficiency

≧90%

Waterproof class Ip46 Anti-vibration class SAEJ1378

Ambient temperature -20~50

ROMET 4E Electric Vehicle Instruction Manual

4

II. General Indicating Diagram and Instrument Cluster of Entire

1 Rear combination light 16 Rear view mirror

2 Rear window 17 Rear wheel

3 Front seat 18 Exterior door handle

4 Antenna

19

Door ourer handle

5 Sun roof

20

Hook hole

6 Windscreen

7 Wiper

8 Washing nozzle

9 Front engine bonnet

10 Front combination light

11 Label position

12 License plate position

13 Front wheel

14 Front window

15 Light for lateral turn signal

ROMET 4E Electric Vehicle Instruction Manual

5

1 Right ventilation adjustment knob (for decoration)

2 Right loudspeaker

3 Inner rear-view mirror and reading light

4 Radio

5 Windscreen wiper and washing switch

6 Combination instrument

7 Left loudspeaker

8 Left ventilation adjustment knob (for decoration)

9 Front light combination switch and turn signal light

switch

10 Steering wheel

11 Ash tray

12 Interior and exterior cycling switch (for decoration)

13 Right sundries box

14 Left sundries box

ROMET 4E Electric Vehicle Instruction Manual

6

1 Preparing switch

2 Preparing switch

3 Emergency warning flasher switch

4 Heater switch

5 Ignition switch

6 Parking lever

7 Assistant instrument cluster

8 Shifting lever

9 Power socket

10 High vs low speed switch

11 power button

ROMET 4E Electric Vehicle Instruction Manual

7

III. Operation Procedures for New Car

1. Notes before using the new car

For a new car, large friction force occurs among running components as car traveling. As running-in of the

components, the friction force will gradually reduce. The following notes are proposed for traveling under 3000km

and with the use of these notes, better operational capacity and economy will be gained after the car running-in.

(1) The traveling speed shall not exceed 40km/h.

(2) It is prohibited to driving the car with over-speed and overload.

(3) The transmission oil must be replaced after traveling 2,000 km.

(4) Emergency braking shall be avoided especially during the first 300Km traveling except for emergency

conditions.

2. Actuation switch: there are three positions for the key in the hole:

Lock (locking position)

The key can be extracted from or inserted into the lock cylinder, and if the key cannot rotate in the cylinder, please

try to slowly revolve from left to right.

When the car is traveling, the key cannot be rotated to the “LOCK” position, or the steering wheel will be locked

and accidents may be resulted from this condition.

Three rotation positions of the key

ACC (accessory position)

When the ignition switch is at "ACC" position, only the assistant power supply for radio etc will be controlled. At

that time, even the motor is closed; the user can enjoy the radio.

ON (starting position)

When the key is at this position, the turn control, radio and motor are all switched on, and the users can enjoy radio

and open the hazard signal switch.

The features not controlled by the key, such as headlight, horn, interior lights and width indicator can be directly used without key. Inspect whether the

ROMET 4E Electric Vehicle Instruction Manual

8

voltmeter and electricity meter are ample or not.

The key shall not be left in the car with no one or only kids.

3. Start-up operation of Electric Vehicle

The Electric Vehicles can be divided into two pursuant to high and low speeds: one is Electric

Vehicle with low-gear transmission; the other is Electric Vehicle with high-low gear

transmission (option).

As the key is at the start-up position, open the master switch and inspect the road condition in

front and manual braking condition, the user can drive the car only after confirmation for the

above.

① There are three positions for Electric Vehicles with low-gear transmission: Neutral, drive and reverse positions. The control lever is between the two front seats

and the operation procedures are as follows:

(1) When the lever is vertical at the medium position, (2) The leveler is pushed forward to the drive (3) The lever is pushed backward to “R” position.

ROMET 4E Electric Vehicle Instruction Manual

9

it is neutral position. At this time, even slowly

engaging the accelerator, this car cannot travel.

position, and the car will travel after engaging the

accelerator under proper conditions.

And this gear can realize reversing the car (the

reversing red indicator will light up).

Operation procedures of the Electric Vehicle:

For the Electric Vehicles with low-gear transmission, the start-up procedures are as follows: 1. rotate the key to the start-up position; 2.

push the control lever to the forward position; and 3. slowly engage the accelerator pedal. Then you can drive the car.

For the Electric Vehicles with high-low gear transmission, the start-up procedures are as follows: 1. rotate the key to the start-up position;

2. press the forward button of the power switch; 3. push the control lever to the low-gear position; and 4. slowly engage the accelerator

pedal. Then you can drive the car.

① No shifting during engaging the accelerator pedal! Slowly engaging the accelerator pedal during start-up can extend the traveling mileage!
② If the front wheel can not rotate during acceleration, the user shall not drive the car, while the possible reason is that the wheel has been immersed in the

deep sandpit or muddy ground, or it may be blocked by something hard. At this time, if the car is forced to travel, the differential may be damaged. Likewise,

when the car is traveling uphill, the braking shall not only depend on braking pedal to prevent reversing, or the transmission case may be damaged. At that time,

the car shall be stopped on the slope with parking brake!

4. Parking brake

For parking braking, lift the manual braking handle (1) with your right hand to brake the car. The user shall first

slightly pull the handle up and use the thumb to press the locking button (2) on the handle top in order to release

the braking handle. Put down the handle (3) and the parking will be released.

If the parking brake is not fully engaged, it is very dangerous to leave the car behind, and your car may

voluntarily move due to environmental factors. If the engine is still running, then the car may suddenly

travel resulting in personal injuries. Thus, you shall ensure your car cannot move and inspect the parking

brake is fully engaged.

ROMET 4E Electric Vehicle Instruction Manual

10

Do not shift into high gear or low gear during accelerating. The transmission will be damaged unless you move your foot away from the accelerator pedal before

change gear.

Forwarding and reversing of the car are subject to the switch of “forward” and “reverse”. Move your foot away from the accelerator pedal during switching forward

gear and reverse gear! Otherwise an accident will take place. Be careful!

1. Do not shift into reverse gear as the car is forwarding, the reverse gear is available only when the car is under the condition of shutting down.

2. The car can be forwarding, only when switched on, and the operating arm is shifted into low gear.

3. The ranges of the car can be reduced as a result of using top gear. Suggest using low gear, or the ranges of the car may be shortened.

ROMET 4E Electric Vehicle Instruction Manual

11

III. Instrument Cluster Appearance

1. Speedometer and odometer

The speedometer shows the speed in km/h, while the odometer shows the traveled mileage of

the car in km.

The LED odometer is installed in the car, with the upper line of mileage and the lower line of

traveled distance.

If you want to calculate the traveled distance of certain mileage, first press the reset button

under the odometer and the traveled distance will be metered.

2. Symbols and explanations

Designation Left turn Right turn High-beam

light

Low-beam

light

Charging

indicator

Symbols

Color Green Green Blue Green Red/green

yellow

Designation T

raveling ready

indicator

Motor overheat

alarming

indicator

Position light

Symbols

Color Green Red Green

ROMET 4E Electric Vehicle Instruction Manual

12

LEFT/RIGHT TURN INDICATOR The turn signal indicator is a green signal light installed on the instrument cluster; the blinking represents the turn

signal light is working. If the blinking frequency is too high or no blinking, please repair the light; if no illumination as the turn switch is open, please repair

fuse, lamp and flash relay. When the danger alarming switch is engaged, the two turn signal lights shall flash simultaneously.

HEADLIGHT INDICATOR The illumination of the high-beam indicator represents the headlight is at the high-beam work state.

LOW-BEAM INDICATOR The illumination of the low-beam indicator represents the headlight is at the low-beam work state.

CHARGING INDICATOR Yellow illumination represents the battery capacity above 80%; green blinking represents charging state, while green stop

represents the battery capacity of 100%; red illumination represents the battery capacity lower than 80%; in addition, when this indicator is flashing, it

means insufficient capacity and asking for charging.

TRAVELING READY INDICATOR It represents turning off the light under the traveling conditions.

MOTOR OVERHEAT ALARMING INDICATOR As this indicator lights up, please park the car in a safe location and restart the car only after the

indicator goes off.

POSITION INDICATOR As illumination of the position light, the position indicator will light up.

The optimum time for charging is when the electricity meter represents 55% capacity, while please immediately charge the car as blinking of the relevant

indicator and 40% capacity. Please keep the battery surface clean to extend the life of the batteries.

ROMET 4E Electric Vehicle Instruction Manual

13

Voltmeter

Scale 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
Value 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52

Permissible

tolerance

(v)

±

1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1% ±1%

Ampere meter

Scale (from
left to right)

1 2 3 4

5 (alarming

point)

Percentage 100% 85% 70% 55% 40%

1. When the value in the voltameter is above 85%, this car can be traveling on the road;
when the voltameter is blinking and the value reaches 40%, please charge the car nearby
at once, or the battery life may be negatively affected.

2. When the ignition switch is just turned on, the car doesn’t travel and both meters show
close states.

Ampere meter

scale 8 12 14 16

Volt value (A) 100 200 300 400

Permissible

tolerance

±1 ±2 ±3 ±4

Odometer:

1. ODO represents the total mileage and it is shown with the value simultaneously. Even
keep pressing the reset button, the total mileage will not change!

2. TRIP represents subtotal mileage,
When TRIP is shown with A simultaneously, the lower line shows subtotal 1; and keep
pressing the reset button, the subtotal mileage will be reset!
When TRIP is shown with B simultaneously, the lower line shows subtotal 2; and keep
pressing the reset button, the subtotal mileage will be reset!

3. The LCD red lines, symbols and letters are always indicated.
The speed indication range: 0-80 km/h

ROMET 4E Electric Vehicle Instruction Manual

14

This condition means turning off all

lights.

This condition is to turn on the lights. This condition is to turn on the

headlight, switching between

high-beam and low-beam of the

headlight.

This condition is to turn on the

parking light.

The control lever as shown in the

figure represents the turn lights.

The control lever as shown in the

figure represents the wiper stop.

The control lever as shown in the

figure represents the low-speed swing

of the wiper.

The control lever as shown in the

figure represents the high-speed swing

of the wiper.

ROMET 4E Electric Vehicle Instruction Manual

15

Vertically swing the control lever in the left-right direction as shown in above figures

can realize:

1. Turn off the current headlight; and when the left lever is pushed upward, the

temporary high-beam will light up (giving the overtaking signal). As the signal pole is

released, the signal will stop. The switching between high-beam and low-beam is

shown in the figure.

2. When the right control lever is pushed to "ON" position, the wiper will run; when

“OFF” position, the wiper will stop and automatically reset.

De-frost and de-fog device

Due to the low temperature in winter, there may be fog or frost on the

windshield. De-frost & de-fog switch can be engaged and fog & frost will

dissipate as the temperature is rising. This device applies the electric heating

technology, so the frequent use is improper due to the consequential effects

on the mileage to be traveled.

ROMET 4E Electric Vehicle Instruction Manual

16

Alarming flasher switch

If this switch is turned on, all the turning signal lights will blink and light up; press this switch to turn off

all lights.

When parking the car in the place of potential accidents, if necessary, the alarming flasher must light up to

warn other drivers!

If any button on the instrument cluster can not rebound after pressing, please repair it in the nearby

after-sales service branch!

Cleaning of the ash tray

1. Firstly turn down 1 (as shown in the

figure) and press 2 downward, and

then you can extract the ash tray!

2. Take the baffle out. 3. Throw out the waste. 4. Insert the baffle in the sundries box,

and then insert the tray back into the

sundries slot.

Fire prevention instructions

a) Never take the ash tray as rubbish bin.

b) Fully snuff out the cigarette before close the ash tray.

ROMET 4E Electric Vehicle Instruction Manual

17

Steering wheel

When you want to change the angle of
the steering wheel, clench the steering
wheel and turn it to the angle needed.

Rearview mirror

To adjust the rearview mirror just for viewing the sides
of the car in the exterior rearview mirror.

Interior reading light

The interior reading light is installed above the front
windshield. It is integrated with the interior mirror.
Thus, poke the top button as shown in the figure
during using.

Horn

There is a horn button on the cover of the
steering wheel. And the horn will run
when engaging the button.

Do not adjust the rearview mirror during
traveling, or the accidents may happen.

Radio (typical)

1. Power switch: Volume control knob is engaged to regulate the volume regulated from low to high. Turn
to left to shut off the power as a rattling sound is heard, while turn to right to open the power supply as an
audible rattling sound is heard.

2. Waveband switch: It is used to switch between FM/AM.

3. Stereo switch: It is used to open or close the stereophonic device during listening to the FM broadcast.

4. Audio input insertion hole: It is used to play the music through connection with external MP3 audio
devices.

5. Tuning knob: to rotate this knob for listening to the broadcast.

6. Tone control knob: It is used to adjust the treble & bass tones for the best reception.

7. Balancing knob: To rotate it and select left/right channels.

8. Radio indicator: It will illuminate in reception of radio.

9. Frequency indicator: The user can select the broadcast according to the pointer-indicated frequency
during radio reception.

ROMET 4E Electric Vehicle Instruction Manual

18

Automotive radio / MP3 player

1.Power switch/tone mode button

Shortly press the power switch to start up; another press to shut down; long press the button to switch among the
following five tone modes: BAS/TRE/BAL/DSP OFF/VOL. Use this button with volume button to regulate the tone
mode.

2. Display screen

It shows the radio reception frequency and the information for current playing.

3. SD/MMC card receptacle

Insert SD/MMC card and automatically play the music in relevant formats.

4. AUX-IN port

Used for external audio signal input.

5. Volume button

Under the reception or playing conditions, shortly press to adjust the volume while the highest sound level is 32 and the lowest is 0.

6. Tuning/selecting button

Under radio reception, long press >> or << button to manually search for the broadcasting stations; under playing condition, shortly press >> or << button to
respectively select songs upward or downward; long press >> or << to respectively implement the function of +10 or -10 for the songs.

7. CLK button

Shortly press CLK button and the host will show the time; long press this button, and the host will enter the regulation condition of the perpetual calendar. When the
yearly symbol is blinking on the screen, press the CLK button and the volume button simultaneously to adjust the calendar year. After setting of the year, repeat short
pressing the CLK button to select the month, date, 24-hour mode, clock and minute in the calendar and adjust the relevant item. When the symbol for adjusting each
option is blinking on the display screen, press CLK and the volume button at the same time to adjust. Long press CLK to log off the perpetual calendar and clock
adjustment state after setting completion.

8. BAND button

Under radio reception, shortly press BAND to switch the functions of FM waveband, while the cycling switching sequence is as follows: F1-F2-F3. When manually
locking the radio, long press BAND to keep the broadcasting stations gained from manually searching.

9. MODE button

Shortly press MODE to switch the functions for the mode. With connection between host and USB flash disk & SD/MMC cards, shortly press MODE to switch USB
flash disk, SD/MMC card and radio and AUX-IN in sequence; with connection between host and USB flash disk or SD/MMC card, shortly press MODE and the host
will automatically ignore the unused mode; if no devices connected to the host, shortly pressing MODE is invalid. During radio reception, long pressing MODE is
the function of automatically locking the station.

10. MUTE button

Shortly press MUTE to initiate the silent function, and shortly press again to remove the silent function; long press this button to activate loudness function, while
long press again to remove the loudness function.

11. U-port

Insert USB flash disk and the device will automatically play the songs in relevant formats.

ROMET 4E Electric Vehicle Instruction Manual

19

Main electric switch

The Main electric switch is in the storage box, to the bottom, of the passenger seat. Please cut off the power source when checking the electric vehicle electric

appliances or short circuit suddenly happens. When the main electric switch trips, and no malfunction is found after the emergency maintenance, please wait for 3—5

minutes, then the electric vehicle can operate after linking power again.

ROMET 4E Electric Vehicle Instruction Manual

20

V. Seat and Door

1. Seat

Adjust the driver’s seat manually. Try to move the seat with your own body to make sure that the seat is fixed in place.

The back seat adjusting handle is on one side of the

seat as shown in the picture.

Lift the back seat adjusting handle and adjust the

back seat to a satisfactory position through your own

back.

Lift the adjusting handle and press down on the back

seat, the back seat will kick back and can be adjusted

to a comfortable position.

The seat adjusting handle is in the front of the seat as

shown in the picture.

The seat is adjusted to the furthest position as shown

in the picture.

The seat is adjusted to the closest position as shown

in the picture.

If you adjust the driver’s seat manually during driving, the car may run out of control. You may be impelled to depress the accelerator pedal out of panic due to

Handle

ROMET 4E Electric Vehicle Instruction Manual

21

the sudden move of the seat. Thus, do adjust the driver’s seat only when the car is out of driving.

2. Safety belt (optional)

If you run into car accident without wearing the safety belt, you may get serious hurt. You may run into some part of the car, or be kicked back, or get serious

hurt, or even die in the similar car accident. You won’t get hurt if wearing a safety belt. Wear the safety belt all the time in driving and make sure that your passengers

also fasten their safety belts.

(1) How does the safety belt function?

When you are in any moving object, you will move forward at the same speed with the object. When the object stops suddenly, you won’t stop immediately until

running into some object. You may run into the front windshield, instrument panel or safety belt. If you bump into the belt, you will slow down at the same speed

with the object. You will travel a longer distance in a longer time before stop. The effort born by your strongest bones will protect your other body parts from

collision. That is the significance of the safety belt.

a. Close the door.

b. Adjust the seat to make your upper body sit up straight.

c. Take the safety belt buckle and pull up the belt around you body. Keep the belt in a flat position without twist. The belt may get locked if pulled too fast. In this

case, unlock the belt by slowly pulling the belt back. Then pull up the belt around you body at a slightly slower speed.

ROMET 4E Electric Vehicle Instruction Manual

22

d. Push the buckle into the retaining ring until a “clatter” is heard. Pull the buckle to make sure that the belt is fixed in place. The release button shall be in such a

convenient position where you can pull the buckle out at any time.

e. Pull down the belt at the end of the buckle and pull up the shoulder belt to strain the crouch belt. The belt shall be fastened as low as possible, clung to your hip and

pulled to your thigh. Your pelvis would bear the effort in case of car collision and your body would not be likely to slip to under the crouch belt. If you slip to under

the crouch belt, you won’t get hurt due to the belt’s effort on you belly. The shoulder belt shall run across the shoulder before running across the chest. And the body

part is the best part to bear the binding force of the belt. The belt would be locked if pulled in emergent brake, collision or out of the fast shrinking device.

Pinch the red release button on the buckle lock device to unlock the belt. The belt shall be kept away from the polish, grease and chemicals and the battery acid in

particular. The belt can be washed with water and soft soap. The belt shall not be twisted or the belt will be abraded. If the belt is abraded or damaged, replace it.

Even if the damage is not obvious after serious abrasion, the whole assembly shall be replaced.

If the belt were fastened in a too loose position, you may get serious hurt. And you may get more serious injury due to too much forward move in the collision.

The shoulder belt shall cling to your body and please wear the belt correctly for your safety.

3.

Rear seat

More space can be got by folding forward the rear seat: pull up the lock button

and pull and fold forward the rear seat.

Sun visor

The sun visor can protect eyes from harsh sunlight.

ROMET 4E Electric Vehicle Instruction Manual

23

Front and rear door glass

1. Front door glass

The front door glass can be lifted manually. Turn the lifter handle in

clockwise and the glass will rise; or vice versa.

2. Rear door glass

The rear door glass is only of open/close type which cannot be lifted and

only the ventilation seam can be opened.

3. Dead lock

The inside of the four doors are equipped with manual dead locks

(cylindrical lift button). Press down the button when the door is closed and

the door will be dead locked and the door will be opened by lifting up the

button.

(4) Roof window

1. You must press down the button 1 on the left and right at the same time to
make the button get away from the locating slot before doing other corresponding

operations. Don’t force it!

2. You must clean up the dust on the roof window glass and the seal strip when closing

the window after long-time opening to prevent water leakage.

4. Roof window

The roof window can be kept in three states: fully-closed, forward-opened, and backward-opened.

Fully-closed: make sure that the front and rear fastener close properly. Don’t buckle up falsely, without looseness, or it will damage the window.

Forward-opened: pull back and up the front buckle. It is in a strong ventilation state which is only for fast refreshment of inside air.

Backward-opened: buckle up the front buckles, then open and lock up the rear buckle. It is in a weak ventilation state for slow refreshment of inside air.

The front and rear buckles shall not be opened at the same time or the roof window will be damaged. Don’t open the roof window immediately after the rain. You can

open the window five minutes later when the water between the glass pane and the frame has disappeared.

Dead lock

ROMET 4E Electric Vehicle Instruction Manual

24

VI. On/Off Operations of Front & Rear Engine Bonnet

1. The buckle of the front engine bonnet is on the bottom

left of the steering wheel.

2. Gently pull up the buckle of the front bonnet

with your hand. It will be open with a hut.

3. The spring hook inside the front bonnet is still

hanging on the body. Press the bottom of the spring

hook with your index finger and the front bonnet will

pop out.

Close the engine bonnet

1. Put the strut bar of the engine bonnet back to the

place and hold the engine bonnet with your hand.

2. Put down the engine bonnet and press it slowly.

Make sure that the engine bonnet is fully

closed before driving, or it may pop out suddenly

and block the driver’s sight.

If you notice that the engine bonnet were not

fully closed during driving, please pull over

ROMET 4E Electric Vehicle Instruction Manual

25

4. It is the front engine bonnet and must be lifted up with

both hands to detach the support bracket.

5. Insert the end of the carriage into the socket of

the support bracket as shown in the picture.

immediately and close the engine bonnet.

Back door latch

Turn the key to the right to open the back door.

Press the outside buckle of the back door towards the inside of the door to close

the back door.

When no key is used in dead locking, make sure that you have not left key in the

car. Pay attention to the surrounding environment before opening so as to avoid

accidents. Don’t leave children in the car alone, or it will be difficult for rescue in

case of accidents.

ROMET 4E Electric Vehicle Instruction Manual

26

VII. Charging

The charging machine is under the tail lamp. Open the covering of the charging port. Open the cover of the charging machine.

1. When you need charging, insert the plug

into the plug base and then connect the power plug

to the 220V power.

2. Cut off the 220V AC and then detach the charging

plug after charging.

Don’t charge outside when it rains so as to

avoid accidents.

You must close the motor before charging.

High-voltage electrical equipment is forbidden. Read

the matched instructions carefully before charging

and check and clean the charging plug and plug base

to ensure that they function well.

Align the positioning convex points of the plug with

the concave points of the charging holder to insert

into the charging plug.

The charging wire power plug is connected to a 16A

220V plug base.

ROMET 4E Electric Vehicle Instruction Manual

27

VIII. Motor and Controller

1. Motor

(1) A part of the motor heat is transmitted through the motor case. So keep the motor case clean.
(2) The motor must cool down naturally if it is too hot.

2. Controller

(1) The cooling device of the controller is aluminum plate. So keep clean.
(2) Don’t touch the battery fluid and any other corrosive liquid.

3. Battery

(1) It is normal for the battery to be hot during charging. The battery will cool down naturally after the
charging stops or the car stops.
(2) There will be “warm frost” in north China in winter. Keep dry during charging and the “white smoke” is

normal when it heats.

4. Charging machine

1. Overheat protection: when the internal temperature is over 75℃, the charging current will reduce automatically; when the temperature is over 85℃, the charging
machine will shut down for protection and will automatically restore charging when the temperature drops.

2. Short-circuit protection: when accident short circuit happens in the output of the charging machine, the charging machine will automatically shut down the output.
It will restore the charging 10 seconds after the removal of the faults.

3. Reverse-battery protection: when the battery is connected reversely, the charging machine will cut off the connection between the internal circuit and the battery.
And there will be no charging and no damage.

The charging machine is equipped with three-hole socket and is applicable for the plug base with ground cable. If the battery doesn’t function well or is
damaged, please pull out the power plug and the port of the charging machine immediately and contact with the local dealer. Don’t disassemble the machine. The
casual removal of the machine cover may lead to electric shock or other injuries. The machine is equipped with external radiating fin. The radiating area must be kept
clean to avoid unsmooth heat radiation which will influence the charging effect. Don’t cool down the machine with cold water when the machine heats.

Keep the space more than 10 cm around the radiator empty to ensure the air is smooth during charging. Don’t put the radiator upside down, or the internal

ROMET 4E Electric Vehicle Instruction Manual

28

temperature will be too high which will influence the charging process. The air ventilation must be smooth. Don’t cover anything to avoid temperature rise and
damage of the internal components. Don’t charge the bad battery or non-chargeable battery.

Don’t wash the motor and controller directly with hydraulic monitor.

IX. Notes

For you safety

The car is for urban citizens. It is of wide internal space, comfortable driving and enjoys fast and sudden turns as ordinary cars. If you find it hard to start, shut off
regularly or there is abnormal knocking in the driving motor during acceleration, contact with the local dealer for repair and maintenance immediately.

Before start

1. Check whether the vehicle is in the charging position or not. If yes, cut off the power and detach the charging wire and put away.

2. Check the surrounding environment before entering into the car, such as snow, puddle, space and barriers.

3. Adjust the position and height of the seat and the height of headrest.

4. Adjust the rear mirror inside and outside the car.

5. Lock all the doors.

6. Wear the safety belt.

Safety check before driving

A safety check had better be performed before driving. The several-minute check will improve the driving safety and promote the fun of driving.
Please pay attention to the following items:

Car outside

Tire: check whether the tires function well. Carefully check whether there is cut, damage or abrasion.
Wheel nuts: ensure that no nut is loose or lost.
Leakage: check whether there is leakage of liquids like oil or anti-freezing fluid.
Lighting: ensure that headlamps, lamplets, cornering lamps and interior lamps function well.

Car interior

1. The battery surface shall be kept clean. You can use wet towel to clean up the surface dust.

ROMET 4E Electric Vehicle Instruction Manual

29

2. Please go to the authorized sales service store to replace the wiring harness of the controller if there is abrasion.

3. If the car will be parked for a long time, charge and release for a time every week and it will increase the battery life.

4. Have a frequent check of the battery and check whether the installation bolt is loose or not. If yes, screw it up immediately.

During driving:

1) Try to avoid fast turn or sudden brake if possible to avoid out-of-control and roll-over.

2) Overload shall be avoided for it will influence the control of the car, especially when it is climbing on the slope, the motor’s load will increase and the current also
increase which will influence the service life of motor and controller.

3) Extreme crosswind will lead to the driving instability of the car. Cut the speed to reduce the effect.

4) Don’t try to get onto the steep slope by drifting. It will lead to skid or roll-over once it is out of control.

5) Try your best to climb up or down slopes straightly. In case that the motor is out of service, don’t turn the steering wheel; you can apply the reverse gear and step
on the brake, then try to retreat to a safe place slowly.

6) When the road is in a bad situation or is covered with gravels, cut the speed to get through. The speed cutting will avoid roll-over or skipping stones

Equipped with power battery

The car is equipped with road lead-acid battery special for electrical car. The monomer battery specifications are 8V, 135Ah; 8V, 150Ah; 6V, 180Ah. Different Ah
requires different configurations.
When the battery needs replacing, ask the professional maintainer to replace with the same-type battery which has similar power to ensure the compatibility. The
specific maintenance refers to the Maintenance Manual.

Be sure to check whether the battery pile is loose or not. If yes, fasten it immediately. Or it may cause car burning accident.

Car modification:

Car modification will influence the handling, safety or durability of the car or even violate the law.
The damage and problems caused by modification is not warranted by the after-sales service. Besides, modification may also cause out-of-control, car accident or
serious damage of the car body.

Installation & use of the electrical equipment

If you want to install electromagnetic equipment like two-way radio communication devices, mobile phones and computers which will produce strong
electromagnetic wave in the car, you shall consult the dealer because the electromagnetic wave produced by the above equipment may cause bad interference to the
related electrical system.
Warning: Don’t install any other electrical equipment with load of more than the rated load or replace the original design, or it will cause danger. If there is any smell
like burning, please stop the car and inform the nearest dealer for the check of the car. The safe connection of battery’s positive and negative poles will improve the
miles of continuous travel and may reduce the damage to the battery and the entire car. Therefore, check the battery’s positive and negative poles regularly (every 3
months) and tighten the torque (20N.m).

Battery

As for the use, refer to the Battery Instruction.

ROMET 4E Electric Vehicle Instruction Manual

30

X. Basic Maintenance & Parts Replacement

1. Personal maintenance

If you repair your car without knowing much about the car, your car may be damaged. Make sure that you have adequate knowledge and experience to
replace the parts or use tools correctly before trying to do any maintenance by yourself. Make sure that you are using the right nuts, bolts and other
fasteners. Misuse of fasteners may lead to the breakage or looseness of parts and you got hurt as a result.

2. Check and replacement of the transmission oil

The transmission oil check had better be performed together with the engine check. The transmission oil should be replaced a time every 2,000 kilometers. The steps
are as follows:

1. Remove the plastic refueling screw at the transmission top with wrench

2. Remove the drainage bolt at the transmission bottom counterclockwise with applicable wrench or shifting wrench,

3. Pour the oil into the container and tighten the bolt clockwise after all the oil is drained.

1. Too much or too little transmission oil will damage the transmission. Too much oil will cause overflow while too little oil will accelerate the undue

abrasion of gears. Therefore, regular check is needed and every two months a check is recommended.

2. The transmission oil should be of the right type and misuse is forbidden. The misuse will damage the transmission gears. The right type shall be 85W-90.

3. Refill the oil regularly to keep the oil at a normal level.

3. Brake

The brake fluid container is in the front chamber and near the coolant container. The level of brake fluid in the container shall not be

lower than the position as shown in the picture, or add brake fluid. The brake fluid level drops for two reasons. One is that the oil level

drops to the acceptable position due to the normal abrasion of the brake frictional plate. The oil level will restore after the replacement

of frictional plate. The other is that the brake fluid leaks. In this case, you should get the braking system repaired because the leakage

means that the brake won’t function normally sooner or later or even cause car accidents without braking system.

The wrong type of brake fluid may cause serious damage to the braking system parts. For example: several drops of mineral oil will seriously damage

the parking system part and you will have to replace the part as a result. Don’t use wrong brake fluid. If the brake fluid splashes, clean it up immediately.

4. Battery

If your car is equipped with maintenance-free battery, use as the same type of battery as the original one at the time of replacement.

Brake master cylinder

ROMET 4E Electric Vehicle Instruction Manual

31

5. Replacement of bulbs

(1) Headlamp bulb replacement steps:

a. Open the front chamber cover

b. Loose the compressed spring of the lamp bulb covering cap and take off the cap

c. Loose the fixed snap ring on the lamp

d. Pull out of the bulb directly from the lamp door and replace with the same-type

bulb

e. Tighten the bulb and fix the snap ring, then install the sealed cap of the bulb

f. Pull the front fog lamp directly and replace it. The fog lamp is at the bottom part of

the lamp

(2) Replacement of the tail lamp bulb:

a. Open the back door and remove the corresponding interior trim inside the tail lamp

carefully

b. Remove the tail shield with plum screw driver

6. Basic hand tools include the following items:

1. Dual-duty screwdriver

2. Lifting jack (0.75t)

3. Jack handle

4. 13-15 wrench

5. 8-10 wrench

6. Wheel wrench

7. Warning triangle

8. Ignition wrench

9. Trailer hook

ROMET 4E Electric Vehicle Instruction Manual

32

7. Replacement of windshield wiper blade

a. Cut off the ignition switch when the wiper is in the most outside position where will be easier for the removal or replacement of the blade.
b. Pull away the wiper from windshield
c. Push up the release clip at the joint of the blade and the wiper arm and then pull down the blade component towards the glass. You can remove the blade
component from the wiper arm.
d. Push the new blade close to the wiper arm until a sound of “clatter” is heard, which means the release clip is positioned.

8. Tire without gas

1) If you need to stop the car on the road in this case, try to pull the car away to the right side (or left side) of the road and avoid stop on the pavement.

2) Tighten the hand brake and put the warning triangle in a suitable position at the back of the car (day or night).
Note: Warning triangle is kept together with the basic tools.

3) In case of tire burst
In case of replacing the tires due to the burst, first you must follow the safety precautions: open the hazard warning flasher. Don’t stop on the main roads and make
sure that the car is parked on a flat road which won’t damage the car. Pull the parking brake and place the manual transmission to a reverse position.

9. Vehicle identification number (VIN)
The identification number is in the position as shown in the picture.

10. Name plate

ROMET 4E Electric Vehicle Instruction Manual

33

The name plate is in the place as shown in the picture.

11. Emergency

1. tire burst

When the tire-changing is needed because of puncturing first of all, we need to follow the safety cautions: turn on the hazard warning flashlight. Pull the car over the

non-vital communication line, or over the level area where will not cause any damage to you and your car. Raise the parking brake, and shift the manual transmission

into reverse gear.

Turn off the engine.

It is dangerous to replace your tire on slope or uneven road.

Block the wheel.

When the car is out of gas, you need to pick up several blocks near the car, and place them against the back wheels so as not to occur any unexpected incidents.

ROMET 4E Electric Vehicle Instruction Manual

34

2. The use of jack

(1) Place the jack under the strong point of the vehicle, and hook one end of the screw rod with the hook at front-end handle, then one hand on the jack handle, the

other cranking, ultimately the jack will raise gradually.

Place the jack on the solid and level ground as far as possible. Counterclockwise screw each nut of the vehicle one or two circles (screw diagonally). Lift the vehicle

carefully till the tire off the ground completely. Detach the nuts of the vehicle, and then remove the tire.

When only use jack to support the vehicle, do not lie under the vehicle, you should use vehicle support table. When the vehicle is supported, do not start or operate

the engine, and the passengers is not allowed to stay in the vehicle.

(2) Remove the tires

Unscrew the wheel nut by wheel nut wrench, and do not remove the wheel nut for now. Select one strong point to place the jack and then lift the vehicle till the tires

ROMET 4E Electric Vehicle Instruction Manual

35

off the ground slightly, remove the wheel nut by nut wrench or hand, and then remove the tire.

(4) Fit tires

Fit four nuts by hand; tighten them till the wheels no longer looseness, put down the wheel slowly, and then alternatively tighten the wheel nuts. The tightening
torque is 110±5N. m, do not use foot or pipe to impose additional strength on the wheel wrench, which will make the nut to be too tight.

(5) Upon finishing changing the tire, screw the nuts by torque wrench, in addition, recheck and screw them after driving more than 1000 kilometers. This preventive

action is necessary, which can guarantee the fastness of the wheels. Screw the nuts alternatively and evenly. Do not use oil or lubricating grease on nuts.

Inappropriately tightening the nuts will cause the wheels fall during driving, and the ultimately the vehicle may be out of control.

3. Haul vehicle

(1) Hauling premise

Hauling must be in accordance with the relevant local regulatory.

Romet motors suggest you haul your car by the maintenance personnel; incorrectly hauling will increase the risk of accidents.

(2) Hauling cautions

Use proper facilities so as to prevent any damage to the vehicle while hauling. The transmission and steering mechanism must be able to function properly. Use

applicable haulage chain. During hauling, release the handbrake and shift into neutral gear, turn ignition key to the position of “ACC”.
（3）Hauling position

(4) Traction load

a. The weight of the tractor must be more than that of the trailed vehicle. The traction must be less than the weight of the hauling vehicle.

ROMET 4E Electric Vehicle Instruction Manual

36

b. Do not add extra vehicles to haul one vehicle. The traction of hauling vehicle include the traction of the trailed vehicle, the total traction is larger than the weight of

the trailed vehicle, the pot hole or wallow will put drag on the hauling, therefore, the traction load increased. The traction load must be minimized.
c. During hauling the vehicle by towing hook, keep the angle of traction less then 15°. If the angle is too large, it may damage the vehicle, even cause the vehicle
turns 180°.

d. During pulling the vehicle out of sandpile, snow or mud, the mooring rope must be pulled out straightly in front of the vehicle, but the mooring rope and the hook

can not be formed a side angle.

(5) Hauling speed

If in the process of hauling a vehicle which is sunk into a pit or wallow, keep a safe distance from the hauling cable or drag rod. Once the hauling cable is broken,

great danger will happen.

When haul separately excited motor assembled vehicle, the hauling speed must be less than 30 kilometers per hour.

(6) Tractors hauling

（1）incorrect way of hauling

The vehicle can not be hauled as the graphical way of using sling (type A), using sling will damage the front bumper and the front structure.

(2) correct way of hauling

a. If the vehicle equipped with automatic clutch must be towed over 50 kilometers, then during the transporting, all tires must be off the ground (type B or C), or the

back wheels off the ground (type E), showed in the picture.

b. If the engine or the differential is broken, then during the transporting, all tires must be off the ground (type B or C), showed in the picture.

ROMET 4E Electric Vehicle Instruction Manual

37

c. Hauling as the front wheels off the ground (type D), move the shift (manual transmission) into the “N” (neutral gear). Loosen the hand lever parking brake.

D. Hauling as the back wheels off the ground (type E), turn the ignition switch into “ACC”, fix the steering wheel in the middle. Do not turn the ignition switch into

“LOCK”. It is dangerous to haul when the steering wheel is in the state of lock up. Do not haul the car from behind (reverse haul) if the 4 tires are all on the ground,

because this will serious damage the engine or differential and in the end cause economic loss.

(3) Check and replace fuse

In the cab, right in front of the passenger seat to the bottom, there is one fuse boxer, and various types of fuse are in it. Unplug the fuse to check if it is in good

condition, as clearly shown in the picture on the right.

ROMET 4E Electric Vehicle Instruction Manual

38

If the headlamps or other electrical equipment parts do not work, it is necessary to check the fuse. If the fuse has been burnt out, then replacing is required, there are

two spare fuse in the fuse boxer. Shut down the ignition switch and the parts that do not work, unplug the faulty fuse to check.

If the fuse has been burst out, the new fuse needs to be installed at original location. It can only be installed the fuse which has the same amperage as specified on

the box cover of the original fuse. If there is no equivalent fuse, adopt the fuse with lower amperage, but need to replace a proper fuse as soon as possible, then put

the original fuse back the original clip. It had better buy one set of spare fuse for emergency. If the brand new fuse is burst out immediately, then there is a potential

problem in the electric system. You need to go to Romet motors special service station to conduct maintenance.

Do not use fuse higher than amperes, or any other substance to replace the fuse, otherwise serious damage will result and have a potential risk of breaking out of

fire.

ROMET 4E Electric Vehicle Instruction Manual

39

12. Cleaning and Self-maintenance

（1） Washing fluid pot

Glass washer is used to promote the visibility of visual fields. Check the fluid level through the liquid storage pot.

The composition of the air window washing fluid: clean water, hardness is less than 205g/1000kg at normal
temperature. Low temperature (﹣18℃±3℃)：by 50% methanol aqueous solution. Do not drive without cleanout

fluid.

(2) Brake fluid filler neck

Check if the fluid level in the oil cup is between the high-water mark (MAX) and the low-water mark (MIN). When need to add liquid, only the synthetic brake fluid

DOT4 can be used.

The brake fluid can absorb water. Therefore, if the vehicle is often run in the high humidity area, the frequency of changing the brake fluid is more often than in

usual.

The brake fluid is harm to people and corrosive, if accidental contact, clean relevant part immediately with flushing large amounts of water and neutral soap. If

swallowed, seek medical care immediately.

2. Maintain the light

A. Introductions

Switch the light switch to check if all the lights can function well. If the lights are not lighted, it is often caused by fuse burn-out or bulb ineffective. First of all,

check the fuse; if the fuse is not burn-out, then check the bulb. Checking and replacing the fuse can refer to the relevant content of the “check and replace the fuse”. If

both the fuse and the bulb are in good condition, please drive your vehicle to the Romet motors special service station to conduct maintenance. Check the

maintenance of instrumentation, indicator light/ warning lamp, start the engine to check the function of all instrumentation, indicator light/ warning lamp. If any

problems occur, please drive to the Romet motors special service station to conduct maintenance.

(1) front combined lamps distance light/ dipped headlight………….60W/55W, white

(2) front combined lamps front position lamp……………………….5W, white

ROMET 4E Electric Vehicle Instruction Manual

40

(3) front combined lamps steering lamp……………………………...21W, amber

(4) side steering lamp 5 W、 amber
(5) rear combined lamps brake light/position lamp 21W/5W、white
(6) rear combined lamps steering lamp 21W、amber
(7) rear combined lamps right reserving lamp 21W、white
(8) license plate light 5W、white
B、General Rules
(1) Make sure the lights is turned off before the replacement of bulbs, and check that the corresponding contact parts are not oxidized；

(2) Replace the burned-out bulbs with new bulbs which have the same type and the same power with original ones.

(3) Check the direction after replacing the bulbs of headlamps to ensure safety.

(4) The interior side of headlamps will be covered with a layer of thin mist: this is not an abnormal phenomenon, but very normal under moisture conditions and

in low temperature. The light of headlamps will immediately disappear when they are lit. When water drops appear on the inside of headlamps, which indicates the

entering of water, ask Romet motors special service station for immediate help.

ROMET 4E Electric Vehicle Instruction Manual

41

(5) Do not use your hand or wear dirty gloves to hold bulbs. The greasy on your hands will affect the next replacement of each bulb. If the surface of bulb glass

is stained, alcohol, ethylene etc. is necessary to clean. Remount after it completely dries.

3. Cleaning

Use a dust collector or a soft brush to clean the interior ornament parts, plastic parts and the dust on seats frequently. Use a clean and soft cloth dipped with some

alkalescent soap to scrub the surface of vinyl-plastics and leathers, and then dry it with a soft and dry cloth. Read Manufacturer’s Instruction before using any

fiber protective agents, some of which contain chemical agents that will stain or fade the seats.

4. Anti-corrosion measures

(1) Most common causes of vehicle corrosion are:

a. Wet fouling, dust or other things left on platelike or cavernous parts, or other parts of the vehicle.

b. Damages of coatings or their protective coverings done by sandstones hitting or minor accident.

(2) Environmental factors that affects the corrosion rate:

a. Damp

The sand, fouling and moisture accumulated on the lower part of the vehicle will accelerate the corrosion. Under the vehicle floor where accumulates ice and

snow is hard to dry.

b. Relative humidity

The corrosion will speed up under the following conditions: regions of high relative humidity; regions where the temperature is above freezing point; regions

affected by air pollutions; regions where crusted with road salt;

c. Temperature

The elevation of temperature will accelerate the corrosion of parts suffering insufficient ventilation.

d. Air pollution

Industrial pollution, the excessive salt in air and overabundance of road salt in coast areas will speed up the corrosion process of the coatings.

(3). Protect the vehicle from corrosion:

Regularly scrub the vehicle, wax it in order to keep it clean; timely check that the coatings have no any minute damage and if have, repair as soon as possible;

keep drain holes located at the bottom of doors and the rear apron unimpeded against accumulating water; Check the lower part of the body and the inner side of the

trunk; if any sand, fouling or salt exist, wash them out as soon as possible; do not apply water tube to wash out the dust, sands or other things inside the passenger car,

ROMET 4E Electric Vehicle Instruction Manual

42

and use a vacuum dust collector or a brush instead.

It is not allowed to contact the electronic components with water or other liquids.

5、Self-maintenance

Daily and periodic maintenance is a must to maintain good mechanical properties of the car, the emissions performance and engine performance. The user should

carry out the provisions of the specialized maintenance and general maintenance. As the owner, you are the only one who can guarantee the normal maintenance of

your car. You are one of the most critical maintenance aspects.
General maintenance including those items should be checked before normal daily driving，if you want to guarantee your vehicle for continuous normal operation,

this is a basic requirement. Daily use of the vehicle, general maintenance should be conducted regularly, if you notice any abnormal sound, vibration or odor, check

the reasons or rapidly call in the special service station to check. In addition, if you think your vehicle needs repair, please notify Romet motors special service station

Unless there are special provisions, the maintenance of items listed as follows should be timely carried out.

(1)Tire

Use pressure gauge to check tire pressure regularly in the maintenance station. Adjust to the required pressure when necessary.

(2)Wheel nuts

When check the tires, make sure that no wheel nuts is loose. In the initial 1000KM’s driving, regularly check the wheel nuts and tighten if necessary.

(3)Wheels adjusting and balancing

When traveling on a straight and flat road, if the vehicle always deviates to one side, or you are aware of the uneven or unusual wear of tires, it would be

necessary to locate the wheel. When traveling at normal speed, if the steering wheel or seat vibrates, it is necessary to execute the wheel balancing.

(4)Windshield wiper blade

As it is not working properly, check for cracks or wear.

(5)Doors and front hatches

Check if the operations of all doors, front hatches, trunk lid and rear doors are normal, and ensure that all locks are solid. When necessary, lubricate hooks

and hinges. When the first hook is released, make sure the second hook is keeping the engine cover from being loosened. Driving in areas with road salt or other

corrosive materials, frequently check the status of lubrication.

ROMET 4E Electric Vehicle Instruction Manual

43

(6) Lamps

Check the front combined lamps, rear combined lamps, fog lamps, and other lamps work normally and are securely installed, and check headlamp light beam is

aimed. The maintenance mentioned here should be conducted regularly, such as during regular maintenance and vehicle washing and so on.

(7)Warning lights and buzzers

Make sure all warning lights and buzzers work properly.

(8)Wiper and washer

Check wiper and washer are working properly and no scraping abrasions are observed.

(9)Windshield defroster

When using the heater, check the blow air from the defrost outlet is normal and adequate.

(10)Steering wheel

Check if there is any change of the vehicle steering condition, such as free travel is too long, hard for steering or too noisy.

(11)Seat

Check the controlling of seat position, such as seat regulator and tilt devices of the backrests, to ensure smooth operation, and every seat should be firmly locked.

Check that the headrest moves up and down smoothly and if can be safely fixed in all of the lock (such as equipment) positions.

(12)Gas pedal

Make sure the pedal works steady, and check that free travel is normal

(13)Brake

Check whether the vehicle has the problem of braking deviation; if brake linings are excessively worn.

(14)Brake pedal

Check that the pedal works normal and steady and that its free travel is normal, and make sure there should be reserve travel when the pedal is completely

pressed down. Make sure there is some distance between the floor mat and the pedal.

(15)Parking brake

Check that the stroke of parking brake lever is normal, and make sure that the vehicle can be safely parked on steep slopes when only using the parking brake.

ROMET 4E Electric Vehicle Instruction Manual

44

(16) Lower parts of car body

The lower parts of the car body are often exposed to such things like corrosive materials and sands used to deice the road. Therefore, it is very important to

remove these things from the lower car body and otherwise these things will be accumulated on the floor bottom, frame, oil tube and discharge system. At the end of

winter, wash the places accumulated with slurry and dust.

(17) Liquid leaking

Shortly after parking the car, check whether fuels, engine oil or other liquid is leaking or not. If there is clear evident of leaking or smell of gasoline, check out

the causes and immediately adjust to normal condition.
