Rolls PA555 Connection Manual

OUT
PA555
MADE IN USA
2
3
4
1
2
3
4
IN 1
15 VDC
Power
Preamplifier
PA555
Preamplifier
What's in the box?
1 - Made in USA PA555 1 - 15V power supply PN PS27s 1 - This owners manual 1 - Love for great audio
PA555 Preamplier
SPECIFICATIONS
Input Impedance: 10K ohms Max Output Gain: 11.1 dB THD: 0.1% S/N Ratio: 103 db, unweighted
Indicator: 1 Power LED Frequency Response: 5 Hz - 198 KHz +/- 3 db Crosstalk: -75 dB Output impedance: 100 Ohms Output Connector: RCA Stereo Input Connectors: 1: 1/8" TRS Stereo jack 3: RCA Stereo jacks
PWR: 15 VDC 500mA Size: 6"w x 2.5"h x 5.4"d Weight: 2 lb.
Salt Lake City, UT 4/19
Connection guide
Thank you for purchasing the PA555. We hope you enjoy using the PA555, and that it makes listening to your music collection rewarding. We sincerely appreciate the opportunity to build a product for you and participate in your love of qual­ity music and sound. We love what we do and we’re happy to help. All Bellari products are hand built in Salt Lake City, Utah by people who care about high quality music.
The PA555 uses one 12AX7 tube running at 150 volts. The input signal is connected directly to the grid of the tube and all of the gain of the PA555 is from the 12AX7 tube. The out­put section is a pair of emitter followers to drive the output. The PA555 has a no feedback circuit or integrated circuits in the audio path, it is all analog.
CONNECTION: 1 - Connect your sources to the PA555's “in” RCA jacks on the back or 1/8" stereo jack on the front. 2 - Connect the supplied PS27s adapter to the jack labeled “15VDC”. Do not use any other adapter, or the unit might be unhappy, and you would need some repair work done. 3 - Connect your amplier to the "OUTPUT" RCA jacks, se­lect the channel you want. 4 - Enjoy your music.
Q: Do di󰀨erent tubes have di󰀨erent gain?
A: Yes, but it is not a big enough di󰀨erence to worry about.
With a 12AX7 the PA555 has 11.1 dB of gain. With a 5751 the PA555 has 10.7 dB of gain. Even though the 12AX7 has a gain factor of 100 and the 5751 (12AXWA) has a gain fac­tor of 70 the slight decrease in max gain will not be notice­able as the PA555 has more gain than most preamps. Even
di󰀨erent brands of tubes will have a slightly di󰀨erent gain, but it is so small you will not hear a di󰀨erence.
Q: Do di󰀨erent tube brands have di󰀨erent specs?
A: Yes, some tubes have better specs than others. The best
tube we tested for specs in the PA555 was a N.O.S. 1960's Mullard long plate made in Great Britain 12AX7. The THD was improved quite a lot in our testing. The crosstalk also im­proved. With most all tubes the frequency response and sig­nal to noise ratio will be about the same. The bad news about the Mullard tube is it is about a $180 tube if purchased from a reputable tube seller. The included 12AX7 is a wonderful sounding tube with very smooth response. Changing tubes can be fun, but by no means necessary. The specs given for the PA555 are with the included 12AX7.
TUBE TEMP: The tube will get up to around 140 degrees fahrenheit, it will be warm to the touch. The top chassis will also get warm from the tube's heat. This will not be an issue as the chassis will only get 20 degrees warmer than room temp. The entire top of the chassis will seem hot after the PA555 has been on for a few hours, this is normal and nothing to be concerned about. Some tubes do run hotter than others. In our testing the hottest tube we have seen was a NOS RCA 5751 made in Canada it ran at 147 degrees, and did make the top of the PA555 very warm to the touch after being on for a few hours. This is normal and is not a cause for concern.
