■V-1200HD Multi-format Video Switcher
Video
Processing
Input Connectors
Output Connectors
Formats
Effects
(4:2:2 Processing)
Effects
(4:4:4 Processing)
Still Image
Multiviewer
Audio
Processing
Input Connectors
4: 4: 4 (Y/Pb/Pr / RGB), 10-bit /
4: 2: 2 (Y/Pb/Pr), 10-bit
3G/HD-SDI: BNC type x 10 *Conforms to SMPTE 424M (SMPTE 425M-AB), 292M
HDMI: type A x 2 (HDMI INPUT 1-2) * HDCP Not supported
HDMI: type A x 2 (HDMI INPUT 3-4) * HDCP Supported., Multi-format Supported.
3G/HD-SDI: BNC type x 6 *Conforms to SMPTE 424M (SMPTE 425M-AB), 292M
HDMI: type A x 2 (HDMI OUTPUT 1-2) * HDCP Supported
HDMI: type A x 2 (HDMI OUTPUT MULTI-VIEW 1 * HDCP Not required, 1080/60p)
(HDMI OUTPUT MULTI-VIEW 2 * HDCP Required, 1080/60p)
SDI: 1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p
*Conforms to SMPTE 274M
HDMI: 480/59.94i, 576/50i, 480/59.94p, 576/50p, 720/59.94p, 720/50p, 1080/59.94i, 1080/50i,
1080/59.94p, 1080/50p,1024x768/60 (*1), 1280x720/60 (*1), 1280x800/60 (*1),
1366x768/60 (*1), 1280x1024/60 (*1), 1400x1050/60 (*1),1600x1200/60, 1920x1080/60,
1920x1200/60RB
* Conforms to CEA-861-E, VESA DMT Version 1.0 Revision 11
* The output format of HDMI1,2 is always the same.
* Frame rate is 59.94(NTSC) or 50(PAL)
* MULTI-VIEW 1,2 output is 1080/60p always.
(*1)Output refresh rate is 75 Hz when frame rate is set to 50Hz.
M/E: 1 M/E, 1.5 M/E, 2 M/E (9 patterns)
Transition: Mix, NAM (*2), FAM (*2), Cut, Wipe
Composition (Keyer): 4 (PinP, Luminance Key, Chroma Key, External Key supported)
AUX: 2
Others: Output Fade, Output Freeze, Output Capture, Composition Edit, SDI Output Patchbay
*These effects depend on M/E type.
(*2)PGM/PST only
M/E: 1 M/E, Matrix, Scaler
Input: 4 (4:2:2 Processing outputs x 2, HDMI INPUT 3, HDMI INPUT 4)
Transition: Mix, Cut
Composition(Keyer):1(PinP, Luminance Key)
Others: HDCP Supported, Output Fade, Output Cropping, Signal Generator
These effects depends on M/E type.
Still Image Inputs: 2, Internal Memory: 16, Maximum 1920x1080 pixels
Format: Windows Bitmap File (.bmp ) 24 bit per pixel, uncompressed, Portable Network
Graphic File (.png) * Alpha channel Supported.
MULTI-VIEW 1 (4:2:2 Processing): 16/10 screens, Label, Tally *
MULTI-VIEW 2 (4:4:4 Processing): 4/10 screens, Label, Tally, OSD Setup Menu
* HDCP Required
Sampling Rate : 24 bits/48 kHz
3G/HD-SDI: BNC type x 4 (Ch7-10), HDMI: type A x 4, AUDIO IN (XLR) L (1/2)/R (3/4)
*Analog Audio or AES/EBU
■V-1200HDR Control Surface
Display
Video input
Others
Power Supply
7 inch 800 x 480 Graphic color LCD (touch screen) x 2
HDMI (type A) x 2 *1920x1080/60p, 59.94p, 59.94i, 50p, 50i *HDCP Supported
USB: Type A x 1 * USB Memory
LAN: RJ45 100Base-TX (Connect to V-1200HD)
PHONES jack: Stereo 1/4-inch phone type×1(80mW+80mW, 32ohms)
Internal speaker
AC Adaptor, DC 9V to 16V(XLR-4-32 type) *Can not be used at the same time.
HDCP Not required
Output Connectors
Input Level and
Impedance
Output Level and
Impedance
Formats
Effects
Others
Expansion Slot
Reference
External Connectors
Memory
User Function Button
Remote Camera
Control
Remore Controler
Power Supply
Power Consumption
Operation Temperature
Dimensions
Weight
Accessories
*0dBu=0.775Vrms
*This product is a Class A digital device under FCC part 15.
*In the interest of product improvement, the specifications and/or appearance of this unit are subject to change
without prior notice.
Power Consumption
Operation Temperature
Dimensions
Weight
Accessories
3G/HD-SDI: BNC type x 4 (Ch1--4), HDMI: type A x 4, AUDIO OUT (XLR) L (1/2)/R (3/4)
*Analog Audio or AES/EBU
AUDIO IN: +4dBu (Maximum: +22dBu, 15k ohms)
AUDIO OUT: +4dBu (Maximum: +22dBu, 600 ohms)
SDI: Linear PCM, 24bits, 48kHz, 16ch * Conforms to SMPTE 299M
HDMI: Linear PCM, 24bits, 48kHz, 2ch
AES/EBU: Linear PCM, 24bits, 48kHz, 4ch
Patchbay: 92 inputs x 92 outputs
Delay: 16ch
Mixer: 16ch, channel Effects: 3-Band EQ, Delay Master Effects: Mastering, 3-Band EQ, Reverb
Slot:2
*The video a maximum of 2 inputs 2 outputs and the audio a maximum of 16 inputs 16
outputs can treat in 2 slots sum total.
Input: BNC type×1
*Black Burst(Sync to frames), Bi-level, Tri-level
Output/Through: BNC type×1
*Black Burst(Sync to frames)
RS-232: DB-9 type (Male) x 1 *for Remote Control
RS-422: DB-9 type (Female) x 1 *for VISCA Control
TALLY/GPIO: DB-25 type (Female) x 1 (Input: 8, Output/Tally: 16)
LAN: RJ45 100BASE-TX (Connect to V-1200HDR or Computer (V-1200HD RCS))
USB: A type x 2 (USB Memory)
8 * Last Memory Function
32 * 16 buttons x 2 banks
Connector: RS-422 DB-9 type (Female) x 1 Protocol: VISCA
V-1200HDR Control Surface * Option
V-1200HD RCS *Windows7 SP1, OS X 10.9 or later
AC 117V, AC 220V, AC 230V, AC240V(50/60Hz)
DC 24V(XLR-4-32 type)
*Redundant Power Supply
90 W/0.8 A (117V), 90 W/0.5 A (220V, 230V, 240V), 90 W/3.75 A (DC 24V)
*When expansion slot is void.
+0 to +40 degrees Celsius +32 to +104 degrees Fahrenheit
482(W)×357(D)×133(H)mm 19(W)×14-1/16(D)×5-1/4(H)inches *EIA-3U rack mount size
9.0 kg 19 Ibs 14 oz
Power Cord, Rubber Feet(4), Owner's Manual
36W
+0 to +40 degrees Celsius +32 to +104 degrees Fahrenheit
520(W)×237(D)×111(H)mm 20-1/2(W)×9-3/8(D)×4-3/8(H)inches *Protruding parts not included.
4.3 kg 9 Ibs 8 oz
AC Adaptor, Power Cord, Owner's Manual
Hybrid Engine 2 M/E Switcher and Processor
for Broadcast and Live Event
■Dimensions
V-1200HD V-1200HDR
430
482
357
344
133
328
520
514
106
99
Unit : mm
5
237
proav.roland.com
All specifications and appearances are subject to change without notice.
Company names and product names appearing in this document are registered
trademarks or trademarks of their respective owners. Roland is either registered
trademark or trademark of Roland Corporation in the United States and/or other
countries. It is forbidden by law to make an audio recording, video recording,
copy or revision of a third party‘s copyrighted work (musical work, video work,
broadcast, live performance, or other work), whether in whole or in part, and
distribute, sell, lease, perform, or broadcast it without the permission of the
copyright owner. Do not use this product for purposes that could infringe on a
copyright held by a third party. We assume no responsibility whatsoever with
regard to any infringements of third-party copyrights arising through your use of
this product.
Printed in Japan. Sept. 2016 RAM-20060 BLY-PD
Flexible M/E
A comprehensive and flexible multi-format video switcher giving
you complete control of video sources, key layers and mixing
engine configurations. The V-1200HD introduces a unique flexible
hybrid engine with 4:2:2 broadcast switcher and 4:4:4 live event
switcher. In addition to powerful video capabilities, the V-1200HD
also has a built-in 16-channel audio mixer.
The 4:2:2 engine's variety of M/E modes allows
for more creative freedom.
2 M/E Mode
This provides a standard two M/E operation style. Two keyers
can be used with each M/E. Keyer priority can also be assigned
and changed. Not only is re-entry of the video source from M/E
1 to M/E 2 possible, but so is reverse re-entry from M/E 2 to M/E
1. This means you can switch the two M/Es and output them
from a single PGM output. The two M/Es can also be output
independently allowing for applications such as simultaneous
transmission of captions in two different languages.
1.5 M/E Mode
This is the highest-performance operation style, capable of
using PGM/PST rows as the final stage in addition to M/E 1. All
four keyers can be used in M/E 1. You can freely change the
priority of each keyer, and even copy keyers. This mode enables
complex mixing operations such as switching a video source
with four compositions to another single video source.
M/E 1
M/E 1
PGM1
M/E 2
PGM2
PGM/PST
10 SDI and 4 HDMI inputs, and 6 SDI and 2 HDMI outputs
•
4:2:2/4:4:4 hybrid engine
•
The 4:2:2 process functions as a 2 M/E switcher that is able
•
to switch 2 M/E, 1.5 M/E, and 1 M/E.
The 4:4:4 process functions as a multi-format processor that
•
supports live presentation, split-screen, and matrix output.
Up to 92 Inputs/Outputs 16-channel audio mixer
•
Control of up to 7 remote cameras
•
Optional control surface with a T-fader and dual displays
•
All switcher functions can be operated from a computer
•
using remote control software, V-1200HD RCS
Input/output expandable via expansion slots
•
Innovative hybrid processing from Roland
In addition to a 4:2:2 video process widely used
for video signals, 4:4:4 signals that are the
standard output for computers are handled by
a separate processing engine 4:2:2 signals can be
upsampled to 4:4:4 signals.
INPUT OUTPUT
SDI×10
HDMI×2
HDMI×2
4:2:2
PROCESS
4:4:4
PROCESS
SDI×6
HDMI×2
1 M/E Mode
This is a simple operation style using one M/E with four keyers. In
addition to using PGM/PST rows on the main line, you can use two
AUX buses. In this mode, the V-1200HD can be used as a video
distributor or routing switcher making it the ideal primary switcher
for a number of broadcast and live performance applications. In
cases when you want to use three or more AUXes, using the
composition buses lets you achieve up to six additional outputs.
4:4:4 Multi-Format Processor
There are two scalers between the 4:2:2 engine and the
4:4:4 engine, and two scalers between HDMI IN 3 and 4
and the 4:4:4 engine. These enable switching, self key
composition, and matrix output. Signals input from HDMI
IN 3 and 4 can be sent to both 4:2:2 process and 4:4:4
process, which means if you choose the latter, you will get
clearer computer images. With the scalers you can also
display a single picture across two screens.
SDI
HDMI
HDMI IN 3, 4
4:2:2
PROCESS
Scaler×2
Scaler×2
4:4:4
PROCESS
M/E 1
+
SDI
HDMI
SDI Recorder
Dot by Dot
LED Display
Split
LED Display
PGM
AUX1
AUX2
1 2
Processing
An innovative and flexible system designed to easily realize your full creative potential.
Video Structure Support for a Wide Range of Resolutions Audio Structure
HDMI inputs 3 and 4 and both HDMI outputs are
equipped with scalers that support SD through HD,
including data resolutions such as 1366x768 and
1920x1200.This makes it possible to input common data
resolutions sent from computers without external
converters and transmit signals from the V-1200HD that
Supported resolutions for the 4:4:4 process
Supported resolutions for the 4:2:2 process
are matched to the native resolution of the destination
display.
At this screen, you can make video-related settings such as selecting the M/E mode for the
4:2:2 process or changing the connection destinations for HDMI IN 3 and 4. If you want to
output HDMI signals with crystal image on large-sized LED and projector displays, you can
specify the 4:4:4 process as the connection destination for HDMI IN 3 and 4 here.
M/E and AUX
Three M/E modes, 1 M/E, 1.5 M/E and 2 M/E, for the 4:2:2 process are provided to meet
the needs of your video production. Each M/E mode has multiple patterns of
composition and AUX combinations. Usable composition effects include Self Key
(Luminance Key and Chroma Key), External Key and PinP. In cases when you need extra
AUXes, you can make settings at the PATCHBAY 1 screen to use unassigned
composition buses as AUXes.
* Two keyers are used when External Key is selected.
Root Menu
All functions and setting changes are
accessible from the root menu. This
instantly calls up the required operation
screen from among the large number of
parameters. These operations can be
performed not only via the dedicated
* Tablet control available from
Windows compatible tablets.
V-1200HDR Control Surface, but also by
using the free remote control software,
V-1200HD RCS, on a connected
computer. You can use the software for
off-line system configurations and
training operatiors.
Input and output of up to 92 channels of audio embedded in SDI and HDMI signals is
possible. Full 16-channel support is provided for SDI audio. A 16-channel audio mixer
equipped with EQ, reverb, and delay is also built-in. Powerful patchbay functionality
lets you select 16 sources to be assigned to the audio mixer and also accomplish central
control of source feeds as a hub not just for video, but for audio as well.
Still Memory
Up to 16 still-images in BMP or PNG format can be stored in the internal memory.
The unit supports resolutions up to 1920x1080, and also supports alpha channel for
images in PNG format.
Assignable Cross-points
Keyers
Multi-view
Multi-view is indispensable for single-point monitoring of
multiple video feeds. The V-1200HD provides two
multi-view outputs, MULTI-VIEW 1 for the 4:2:2 process
and MULTI-VIEW 2 for the 4:4:4 process. You can assign
Multi-view Out for the 4:4:4 Process
Features for changing priority and for copying and pasting settings are built into the four
channels of composition (keyers). You can instantly access preset settings through store
and recall operations using four memory banks. The number of keyers available in each
M/E differs according to the format selected as the 4:2:2 process format.
3 4
Multi-view Out for the 4:2:2 Process
video sources for the multi-view screen. Three layout
patterns are available for the 4:2:2 process.
Primary inputs are freely assignable to any cross-point location. Quick input changes can be
accommodated easily because the source labels follow simultaneously.
Operation
A dedicated V-1200HDR controller provides fast and accurate operation. Dual touch monitors provide quick and easy operation.
All the functionality required for operation of a high-end switcher, in an efficient compact size.
Dual Touch Monitors
These dual touch monitors let you
display different GUIs on the left and
right. Incoming video signals from the
HDMI connectors on the rear panel
can also be displayed.
V-1200HD menus shown on the left and
•
right displays
The V-1200HD's multi-view output shown on
•
the right display
Cross-point Display
Primary video inputs are freely
assignable to any cross-point location.
The name of the source appears at the
bottom of the display, reducing
operation errors.
Phones Jack
This monitors the HDMI audio input into
the console.
Value Knob
The large value knob and exit/enter buttons
allow you to adjust value settings instantly.
Audio Master Volume
This adjusts the volume level of
mixed audio.
Positioner
The positioner used for adjusting X, Y and
Z parameters provides flexible control of
the remote cameras.
V-1200HD
Layout Buttons
These save screens displayed on the monitors
as presets and recall one when needed.
M/E Transition Selection
Although the control surface is designed in
the style of one M/E, you can use these two
buttons to switch between the two M/Es.
T-fader
The large T-fader provides precise manual
operation for switching.
AUX Bus Buttons
These select video sources output to
the AUX buses or video channels used
for composition. They also access to
assigned user presets.
Cross-point Buttons
This broad range of cross-point
switches affords a commanding view
of 16 sources at one time.
Redundant Power
In addition to an AC adapter, the unit
can be powered by a 12V battery.
Connecting both at the same time
provides redundant power.
Transition Block
Transition buttons provide accurate, full
control of operations for the next take.
Examples of Wipe Patterns
•
Along with standard MIX, NAM and FAM
transitions are also built in. With NAM,
mixing proceeds from the picture's
brightest areas, and during the FAM
transition, the luminance level of both Bus
A and Bus B maintain at a certain level.
Ordinary MIX transition
Video A Video AVideo B Video B
FAM and NAM transitions
Setup Example
Ethernet
HUB
V-1200HD V-1200HDR
Wireless
LAN device
LAN Port
An Ethernet cable connects the V-1200HDR to the main unit.
Using an Ethernet hub lets you connect up to two controllers,
V-1200HDR units or computers on which the dedicated remote
control sofware V-1200HD RCS is installed, to the V-1200HD.
* Use a Cat 5e or higher cable for connection.
HDMI Input
You can input video to the dual monitors. If you
connect the main unit's multi-view outputs to the
V-1200HDR's HDMI inputs, the multi-view content
will display on the V-1200HDR's built-in screens.
* HDCP supported
Delegation Block
These change the selection targets for
the AUX bus buttons.
5 6
ApplicationHardware
Multi-format support for a diverse range of inputs and outputs.
Two expansion slots are provided for even more compatibility.
TALLY/GPIO Connector
This connects to a video monitor capable of
tally input or a tally light system to
illuminate the tally lamps.You can also use
it to transmit and receive control signals
between the unit and an external device.
LAN Port
An Ethernet cable connects the
console and the main-unit
processors. Using an Ethernet hub
lets you connect up to two
controllers, V-1200HDR units or
computers on which the dedicated
remote control sofware V-1200HD
RCS is installed, to the V-1200HD.
USB Port
Along with importing still images for storage in
internal memory, this is used for saving and
loading settings for the V-1200HD as well as for
updating the firmware.
SDI Input
The ten SDI inputs support 3G and
HD. All inputs are equipped with color
correction.
* SDI IN 7 through 10 each supports
16 channels of embedded audio input.
XLR Audio Input/Output
Either two analog channels or four
AES/EBU channels are selectable for the
XLR audio input/output connectors.
(Input and output share a common
format.)
SDI Output
The six SDI outputs support 3G and
HD. Each output is individually
switchable to PGM, FTB, and still
image.
* SDI OUT 1 through 4 can each embed
16-channel audio.
Multi-view Output 2
Video in the 4:4:4 processor can be
monitored via MULTI-VIEW 2.
* Using an HDCP-compatible display for
monitoring is recommended.
LED Status IndicatorsMenu Buttons
These monitor the status of the
connection between the main unit and
the control surface, the cooling fan and
the power supply.
4:2:2 HDMI Input
Dedicated HDMI inputs for 4:2:2
process with color space selection and
color correction.
*
HDCP is not supported.
* HDMI IN 1 and 2 each support the upper
two channels of embedded audio input.
Multi-view Output 1
Video in the 4:2:2 process can be
monitored via MULTI-VIEW 1.
An ordinary computer display can be
used for monitoring.
* HDMI IN 1 and 2 each supports the upper
two channels of embedded audio input.
The flexible workflow and functionality supports a wide variety
of live production applications.
Broadcast Studios
A wide variety of video effects are ideal
for all kinds of broadcast studios.
Composition with freely selectable priority can be accomplished
using the four scaler-equipped keyers. The system also features
high-end Chroma Key, as well as the External Key essential for
title compositing. In addition to PGM and PVW output, two
AUX buses are usable for output (when in the 1M/E mode).
Live-performance Production
Multiple M/E choices allow for a diverse range of
video production applications in one switcher.
The V-1200HD is ideal as a main switcher for concert recording and
for a live feed. Through a variety of multi-view functions, even a
large number of sources can be checked at a glance. The M/E
configuration can be varied as desired to meet the needs of the
production. Control up to seven remote cameras ensures creative
productions even with limited camera operators.
Events and Conferences
Equipped with HDMI input and output with
multi-format support. Freely mix computer and
video sources and output to a wide range
of displays and devices.
Along with ten 3G/HD-SDI inputs, the V-1200HD features four HDMI
inputs. Six 3G/HD-SDI and two HDMI outputs are also provided.
Among these, two HDMI inputs and outputs offer multi-format support.
Computer sources with varying resolutions and frame rates are supported
without a need for video converters. The signal is passed directly to the
4:4:4 process, so it can be output, unchanged, at the same high resolution.
Classrooms and Event Halls
Supporting a rich range of control
as a video/audio hub.
Remote Connectors
The RS-422 connector allows you
to connect and control VISCAcompatible cameras. The RS-232
connector is used for remote
control from an external device.
* "VISCA" is a trademark of Sony
Corporation.
Redundant Power
The V-1200HD accommodates both AC and
DC 24V power sources. Connectingboth
establishes a redundant power supply.
Reference
Black burst, 2-value, and 3-value
input are supported. In addition
to loop-through, installing a
generator for output is also
supported.
Expansion Slots
The unit's functionality can be extended through
two expansion slots. These make it possible to add
input and output.
HDMI Output
These output the mixed video by
the 4:4:4 process.
4:4:4 HDMI Input
These can be used for both 4:2:2
process and 4:4:4 process. The 4:4:4
process supports HDCP.
* HDMI IN 3 and 4 each supports the upper
two channels of embedded audio input.
* 4:2:2 process doesn't support HDCP.
7 8
The full-featured routing functionality enables conversion and
distribution of a high number of video sources in a variety of
formats. The V-1200HD can also achieve remote operation as a
video/audio source hub from a variety of control terminals and
programs. In addition to just simple video switching, the system also
offers functions available only on production switchers, such as
distributing PinP video to various locations.
*1. When HDCP is on, the input signal can only be output to the XLR analog outputs and the HDMI outputs that are connected to H
*3: When the audio selector switch is set to AES/EBU, 2 channels each of AES/EBU input and output are possible. When the switch
Options
A diverse selection of option cards for video and audio system expansion.
SDI Expansion Interface
XI-SDI
●
Equipped with two input and two output SDI
connectors.
●
Two scalers are built in.
●
Connect to 4:2:2 engine
DVI Expansion Interface
XI-DVI
●
Equipped with two DVI-I connectors for switchable
bidirectional input/output, with support for analog
RGB, DVI-D, and HDMI signals.
●
Two scalers are built in.
●
Connect to 4:2:2 engine
*Analog RGB is supported input only.
Block Diagram
SDI 2
SDI 3
SDI 1
OUTPUT
2
6 IN
PATCHBAY
B1B2B3B4B5
SDI 4
6 OUT
SDI 5
SDI 6
FREEZE
(One bus only)
EXPANSION
SLOT A
2 IN
OUTPUT
EXPANSION
B6
EXPANSION
SLOT B
4 OUT
PATCHBAY
6 IN x 2 OUT
to STILL MEMORY
*1
HDMI
MULTI-VIEW 1
1
MULTI-VIEW
from INPUT
HDMI 1
FTB
HDMI 2
FTB
HDMI
MULTI-VIEW 2
2
MULTI-VIEW
from INPUT
REF OUT /
REF THRU
SDI 1
SDI 2
OUTPUT
16ch
16ch
SDI 3
16ch
SDI 4
16ch
OUTPUT
HDMI 1
2ch
MAIN L
SIG/PEAK
MAIN
LEVEL
HDMI 2
2ch
MAIN R
MASTERING
PEQ
MULTI-VIEW1
MULTI-VIEW2
2ch
AUX1
SIG/PEAK
AUX1
LEVEL
XLR 1/2 *3
2ch
SIG/PEAK
AUX2
LEVEL
AUX2
XLR 3/4 *3
2ch
SIG/PEAK
EXPANSION
SLOT A
EXPANSION
16ch
16ch
16ch
SOLO L
SOLO R
SLOT B
DCP compliant devices.
is set to ANALOG, 1 channel each of input and output are possible.
VC-1 Series Video Converters
Converters enabling input/output expansion and format conversion however you like.
These provide support for upgrading systems to achieve low heat generation and lossless conversion.
Scan Converter HDMI to SDI
VC-1-SC
Conversion of digital signals of
SDI and HDMI and analog
signals of RGB, component and
composite to SDI or HDMI
VC-1-DL
Bi-directional conversion of video
and audio signals from HDMI to
SDI or SDI to HDMI with Frame
Sync and Delay
VC-1-HS
Conversion of video and
audio signals from HDMI
input to SDI output
SDI to HDMIFS Delay
VC-1-SH
Conversion of video and
audio signals from SDI input
to HDMI output
POST PROCESS
RE
PATCHBAY
*1
RE-ENTRY
422 PROCESS
XPT
RE
FTB
FTB
FTB
B1
B2B3B4B5B6
1
16 IN
8 OUT
AUX
2M/E, 1.5M/E, 1M/E
2M/E SWITCHER
16 IN
8 OUT
CAPTURE
FTB
FTB
168
CHROMA KEY
EXTERNAL KEY
LUMINANCE KEY
COMPOSITION
PinP
FS
FTB
S1
10ch
S2
WIPE
TRANSITION
MIX, FAM, NAM
(1080p x 8)
444 PROCESS
PROCESSOR
MULTI-FORMAT
STILL 2
STILL 1
XPT
SCALER
FS
MIX / CUT
CROPPING
LUMINANCE KEY
to MULTI-VIEW 1
SIGNAL GENERATOR
to MULTI-VIEW 2
PGM, PVW, XPT1-1 - XPT2-4
SOLO R
SOLO L
AUX 2
AUX 1
REVERB
MAIN R
MAIN L
PAN
MUTE
DELAY
AUDIO
FOLLOW
LEVEL
from VIDEO STRUCTURE
PEQ
SIG/PEAK
INPUT
1–16
INPUT
MIXER
16ch
REVERB
REVERB
SEND
AUX1
LEVEL
REVERB
AUX1
SEND
MUTE
PRE/POST
AUX2
MUTE
AUX2
PRE/POST
SEND
PAN
SOLO
*2. When analog is selected, the XLR connectors are mono only.
DELAY
16ch 16ch
SCALER
SCALER
SIGNAL GENERATOR
HDMI 3
HDMI 4
SYNC GENERATOR
REF IN
PATCHBAY PATCHBAY
16ch
16ch 92ch
SDI 8
SDI 7
INPUT
Audio Block
16ch
SDI 9
16ch
SDI 10
2ch
2ch
XLR 3/4 *3
16ch
16ch
16ch
SLOT A
EXPANSION
EXPANSION
SLOT B
2ch
2ch 2ch
2ch
2ch
HDMI 2 *2
HDMI 1 *2
HDMI 4 *2
HDMI 3 *2
XLR 1/2 *3
SDI 1
SDI 2
SDI 3
INPUT
Video Block
SDI 4
SDI 5
SDI 6
SDI 7
SDI 8
SDI 9
SDI 10
HDMI 1
HDMI 2
4 IN x 2 OUT
EXPANSION
INPUT PATCHBAY
SLOT A
EXPANSION
EXPANSION
SLOT B
STILL
MEMORY
USB
MEMORY
16 SLOTS
from
CAPTURE
9 10
Loading...
