Roland Corporation FP-3 Owner's Manual

Page 1

Owner’s Manual

Thank you, and congratulations on your choice of the Roland Digital Piano FP-3.

Main Features

Stylish, Light, Compact Design

The refined design fits in anywhere; and since it is so lightweight and compact, it’s easy to take the instrument with you wherever you go.

Authentic Piano Performances

High-quality concert grand piano tones, along with the Progressive Hammer Action keyboard, which gives more realistic piano touch by providing a heavier feel in the low end and a lighter feel in the upper notes, let you enjoy truly authentic piano performances.

Before using this unit, carefully read the sections entitled:

UNIT SAFELY” and “IMPORTANT NOTES” (p. 2; p. 4)

provide important information concerning the proper operation of the unit. Additionally, in order to feel assured that you have gained a good grasp of every feature provided by your new unit, Owner’s manual should be read in its entirety. The manual should be saved and kept on hand as a convenient reference.

“USING THE

. These sections

Wide Variety of Tones For Use in Many Musical Genres

In addition to piano tones, the FP-3 offers 40 different onboard tones, which can be used for almost every conceivable style of music. You can also play Drum Sets with the instrument.

“Session Partner” Lets You Enjoy Playing with a Session-Like Feel

Enjoy true session-like feel while performing along with a “Rhythm” section built upon realistic drum and bass sounds. You can have the “Rhythm” chord progression advance automatically, or you can specify the chords to be played with your left hand.

Numerous Internal Songs

The FP-3 features four internal demo songs, along with a further fifty internal piano songs.

Experience a Variety of Performances with Dual and Split Functions

Layer two of the FP-3’s many internal tones, play with different tones assigned to the left and right sections of the keyboard, and enjoy many other possibilities in working with Performances.

Keyboard Touch Can Be Set to Match Finger Strength

You can change the keyboard touch so it better suits the finger strength of the person playing the keyboard.

Easy Recording Functions

You can easily record your own performances using simple button operations.

Two Headphone Jacks Provided

The FP-3 comes equipped with two headphone jacks, allowing two people to use headphones simultaneously. This is a convenient feature for use in lessons, or when playing pieces for four hands.

Includes Line In/Out Jacks

By connecting external audio equipment to the FP-3’s Line Out jacks you can play sounds from the FP-3 through your audio setup, and with a CD player or other such device connected to the Line In jacks, you can then play internal sounds along with FP-3 Performances.

any form without the written permission of ROLAND CORPORATION.

Page 2

For the U.K.

IMPORTANT: THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.

As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug, proceed as follows: The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK. The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED. Under no circumstances must either of the above wires be connected to the earth terminal of a three pin plug.

USING THE UNIT SAFELY

BLUE: BROWN:

NEUTRAL LIVE

Used for instructions intended to alert the user to the risk of death or severe injury should the unit be used improperly.

Used for instructions intended to alert the user to the risk of injury or material damage should the unit be used improperly.

* Material damage refers to damage or

other adverse effects caused with respect to the home and all its furnishings, as well to domestic animals or pets.

The symbol alerts the user to important instructions or warnings.The specific meaning of the symbol is determined by the design contained within the triangle. In the case of the symbol at left, it is used for general cautions, warnings, or alerts to danger.

The symbol alerts the user to items that must never be carried out (are forbidden). The specific thing that must not be done is indicated by the design contained within the circle. In the case of the symbol at left, it means that the unit must never be disassembled.

The ● symbol alerts the user to things that must be

carried out. The specific thing that must be done is indicated by the design contained within the circle. In the case of the symbol at left, it means that the powercord plug must be unplugged from the outlet.

001

• Before using this unit, make sure to read the instructions below, and the Owner’s Manual.

..........................................................................................................

002c

• Do not open (or modify in any way) the unit or its AC adaptor.

..........................................................................................................

003

• Do not attempt to repair the unit, or replace parts within it (except when this manual provides specific instructions directing you to do so). Refer all servicing to your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page.

..........................................................................................................

004

• Never use or store the unit in places that are:

• Subject to temperature extremes (e.g., direct

sunlight in an enclosed vehicle, near a heating duct, on top of heat-generating equipment); or are

• Damp (e.g., baths, washrooms, on wet floors);

or are

• Humid; or are

• Exposed to rain; or are

• Dusty; or are

• Subject to high levels of vibration.

..........................................................................................................

005

• This unit should be used only with a rack or stand that is recommended by Roland.

..........................................................................................................

006

• When using the unit with a rack or stand recommended by Roland, the rack or stand must be carefully placed so it is level and sure to remain stable. If not using a rack or stand, you still need to make sure that any location you choose for placing the unit provides a level surface that will properly support the unit, and keep it from wobbling.

..........................................................................................................

008c

• Be sure to use only the AC adaptor supplied with the unit. Also, make sure the line voltage at the installation matches the input voltage specified on the AC adaptor’s body. Other AC adaptors may use a different polarity, or be designed for a different voltage, so their use could result in damage, malfunction, or electric shock.

..........................................................................................................

009

• Do not excessively twist or bend the power cord, nor place heavy objects on it. Doing so can damage the cord, producing severed elements and short circuits. Damaged cords are fire and shock hazards!

..........................................................................................................

Page 3

010

• This unit, either alone or in combination with an amplifier and headphones or speakers, may be capable of producing sound levels that could cause permanent hearing loss. Do not operate for a long period of time at a high volume level, or at a level that is uncomfortable. If you experience any hearing loss or ringing in the ears, you should immediately stop using the unit, and consult an audiologist.

..........................................................................................................

011

• Do not allow any objects (e.g., flammable material, coins, pins); or liquids of any kind (water, soft drinks, etc.) to penetrate the unit.

..........................................................................................................

012b

• Immediately turn the power off, remove the AC adaptor from the outlet, and request servicing by your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page when:

• The AC adaptor, the power-supply cord, or the

plug has been damaged; or

• Objects have fallen into, or liquid has been

spilled onto the unit; or

• The unit has been exposed to rain (or otherwise

has become wet); or

• The unit does not appear to operate normally or

exhibits a marked change in performance.

..........................................................................................................

013

• In households with small children, an adult should provide supervision until the child is capable of following all the rules essential for the safe operation of the unit.

..........................................................................................................

014

• Protect the unit from strong impact.

(Do not drop it!)

..........................................................................................................

015

• Do not force the unit’s power-supply cord to share an outlet with an unreasonable number of other devices. Be especially careful when using extension cords—the total power used by all devices you have connected to the extension cord’s outlet must never exceed the power rating (watts/amperes) for the extension cord. Excessive loads can cause the insulation on the cord to heat up and eventually melt through.

..........................................................................................................

016

• Before using the unit in a foreign country, consult with your retailer, the nearest Roland Service Center, or an authorized Roland distributor, as listed on the “Information” page.

..........................................................................................................

101b

• The unit and the AC adaptor should be located so their location or position does not interfere with their proper ventilation.

..........................................................................................................

102c

• Always grasp only the plug on the AC adaptor cord when plugging into, or unplugging from, an outlet or this unit.

..........................................................................................................

103b

• Whenever the unit is to remain unused for an extended period of time, disconnect the AC adaptor.

..........................................................................................................

104

• Try to prevent cords and cables from becoming entangled. Also, all cords and cables should be placed so they are out of the reach of children.

..........................................................................................................

106

• Never climb on top of, nor place heavy objects on the unit.

..........................................................................................................

107c

• Never handle the AC adaptor or its plugs with wet hands when plugging into, or unplugging from, an outlet or this unit.

..........................................................................................................

108b

• Before moving the unit, disconnect the AC adaptor and all cords coming from external devices.

..........................................................................................................

109b

• Before cleaning the unit, turn off the power and unplug the AC adaptor from the outlet (p. 8 ).

..........................................................................................................

110b

• Whenever you suspect the possibility of lightning in your area, disconnect the AC adaptor from the outlet.

..........................................................................................................

118

• Should you remove the screws fastening the music stand or stand, make sure to put them in a safe place out of children’s reach, so there is no chance of them being swallowed accidentally.

..........................................................................................................

Page 4

IMPORTANT NOTES

In addition to the items listed under “USING THE UNIT SAFELY” on page 2 and 3, please read and observe the following:

Power Supply

301

• Do not use this unit on the same power circuit with any device that will generate line noise (such as an electric motor or variable lighting system).

302

• The AC adaptor will begin to generate heat after long hours of consecutive use. This is normal, and is not a cause for concern.

307

• Before connecting this unit to other devices, turn off the power to all units. This will help prevent malfunctions and/or damage to speakers or other devices.

Placement

351

• Using the unit near power amplifiers (or other equipment containing large power transformers) may induce hum. To alleviate the problem, change the orientation of this unit; or move it farther away from the source of interference.

352

• This device may interfere with radio and television reception. Do not use this device in the vicinity of such receivers.

354a

• Do not expose the unit to direct sunlight, place it near devices that radiate heat, leave it inside an enclosed vehicle, or otherwise subject it to temperature extremes. Excessive heat can deform or discolor the unit.

355

• To avoid possible breakdown, do not use the unit in a wet area, such as an area exposed to rain or other moisture.

358

• Do not allow objects to remain on top of the keyboard. This can be the cause of malfunction, such as keys ceasing to produce sound.

• Do not leave this instrument standing on end for more than approximately two weeks. Doing so can adversely impact the keyboard’s functionality.

359

• Do not paste stickers, decals, or the like to this instrument. Peeling such matter off the instrument may damage the exterior finish.

Additional Precautions

553

• Use a reasonable amount of care when using the unit’s buttons, sliders, or other controls; and when using its jacks and connectors. Rough handling can lead to malfunctions.

554

• Never strike or apply strong pressure to the display.

556

• When connecting / disconnecting all cables, grasp the connector itself—never pull on the cable. This way you will avoid causing shorts, or damage to the cable’s internal elements.

558a

• To avoid disturbing your neighbors, try to keep the unit’s volume at reasonable levels. You may prefer to use headphones, so you do not need to be concerned about those around you (especially when it is late at night).

559a

• When you need to transport the unit, package it in the box (including padding) that it came in, if possible. Otherwise, you will need to use equivalent packaging materials.

561

• Use only the specified expression pedal (EV-5; sold separately). By connecting any other expression pedals, you risk causing malfunction and/or damage to the unit.

562

• Use a cable from Roland to make the connection. If using some other make of connection cable, please note the following precautions.

• Some connection cables contain resistors. Do not use cables that incorporate resistors for connecting to this unit. The use of such cables can cause the sound level to be extremely low, or impossible to hear. For information on cable specifications, contact the manufacturer of the cable.

Stand (FPS-10A: sold separately)

Cautions When Handling the Speaker Stand

• To prevent accidents caused by falling speakers, do not use the speaker stands included with the stand FPS-10A in combination with any other instrument or product.

• Be sure to use the provided velcro tape to keep the speakers fixed to where they are set on the speaker stands.

Maintenance

401a

• For everyday cleaning wipe the unit with a soft, dry cloth or one that has been slightly dampened with water. To remove stubborn dirt, use a cloth impregnated with a mild, non-abrasive detergent. Afterwards, be sure to wipe the unit thoroughly with a soft, dry cloth.

402

• Never use benzine, thinners, alcohol or solvents of any kind, to avoid the possibility of discoloration and/or deformation.

• Setting the speakers sideways to increase power may cause the velcro tape to separate, making it easier for the speakers to fall; exercise due caution.

• Please use Roland speakers that meet the following requirements: <Weight: 10 kg or less; Dimensions: 210 (W) x 280 (D) x 330 (H) mm or less> When installed in combination with speakers other than one described above, Roland no assurance as to the stability thereof. Before attempting such use, be sure to check carefully to ensure that stable installation continued stability during use are possible.

• Merely screwing in the speaker stand attachment screws as is without the proper preparation may result in damage to the unit. Be absolutely sure to attach the speaker stand attachment screws to the speaker stands.

Page 5

USING THE UNIT SAFELY...............................................2

IMPORTANT NOTES .........................................................4

Contents.................................................................................5

Panel Descriptions ...............................................................6

Before You Play ...................................8

Making Connections............................................................8

Installing the Music Stand ..................................................9

Connecting Pedals..............................................................10

Turning the Power On and Off........................................10

Adjusting the Sound’s Volume and Brilliance...............11

Connecting Headphones...................................................11

Chapter 1 Playing the Keyboard......... 12

Listening to Internal Songs...............................................12

Playing Back All Songs Continuously

(All Song Play)..............................................................12

Listening to Each Part Separately.............................. 13

Performing with a Variety of Sounds .............................14

Selecting a Rhythm ............................................................28

Changing Rhythms As You Perform........................28

Changing a Rhythm’s Tempo...........................................29

Selecting a Rhythm’s Chord Progression.......................30

Performing With the Chord Progression Specified

in the Left Hand (Rhythm Split Play)..............................31

Changing the Volume Balance Between the Keyboard

and the Rhythm..................................................................32

Chapter 3 Recording a Performance ... 33

Recording a Performance..................................................33

Recording a Performance Using Rhythms...............34

Recording a Performance Using Rhythms

(in Split Play) ................................................................35

Recording Selected Track buttons.............................36

Erasing Recorded Performances......................................37

Correspondence Between Recorded Performance and Track

Buttons .................................................................................. 37

Chapter 4 Other Functions ..................38

Performing With Two Layered Tones (Dual Play) .......15

Performing With Different Tones in the Left and

Right Sides of the Keyboard (Split Play) ........................16

Changing Tones ...........................................................17

Changing the Keyboard’s Split Point .......................17

Changing the Volume Balance for Dual Play and

Split Play..............................................................................18

Changing the Keyboard’s Touch.....................................19

Adding Breadth to the Sound (Chorus Effect)...............20

Adding a Spinning Sound to Organ Tones

(Rotary Effect)...............................................................20

Changing the Depth of Chorus Effect.......................20

Adding Reverberation to Sounds (The Reverb Effect).21

Changing the Depth of Reverb Effect....................... 21

Transposing the Key of the Keyboard (Key Transpose) 22

Using the Metronome........................................................ 23

Changing the Tempo...................................................23

Changing the Beat of Metronome .............................24

Changing the Volume.................................................24

Changing the Damper Pedal’s Resonance......................38

Changing How the Pedals Work.....................................38

Changing How the Pedal Effects Are Applied..............39

Changing the Pitch of the Lower Tone in Octave Steps

(Octave Shift) ......................................................................39

Tuning to Other Instruments’ Pitches (Master Tuning).40

Adjusting the Tuning.........................................................40

Changing the Beat Pattern................................................41

Connecting MIDI Devices.................................................42

Appendices ........................................45

Troubleshooting .................................................................45

Error Messages/Other Messages.....................................47

Tone List..............................................................................48

Rhythm List.........................................................................49

Chord Progression Pattern List........................................50

Chord Fingering List .........................................................52

Internal Song List...............................................................54

Chapter 2 Playing Along with Rhythms25

What is Session Partner?................................................... 25

Performing Along With Rhythms ...................................26

Performing Along With Drum Sounds ....................26

Performing With Chord Parts....................................26

About the lighting of the [Drum] and [Chord] button

indicators .............................................................................. 27

Easy Operation List............................................................56

MIDI Implementation........................................................57

Main Specifications............................................................58

Index.....................................................................................59

Page 6

Panel Descriptions

Front Panel

1 2 3 5 6 7 9 11 12 134 8 10

[Volume] Knob

Adjusts the overall volume level (p. 11).

[Brilliance] Knob

Adjusts the tone brightness (p. 11).

[Split] Button

Allows you to play different tones in the left and right sides of the keyboard (p. 16) and specify Rhythm chords with the left hand (p. 31).

Tone Buttons

They are used to choose the kinds of sounds (Tone Groups) played by the keyboard (p. 14).

Display

Displays information such as the song number, Rhythm number, tempo, beat, and parameter settings values.

[-]/[+] Buttons

These two buttons are used to modify the values of a variety of settings. Pressing both the [-] and [+] buttons simultaneously returns the setting of a particular item or function to its default value. Additionally, with certain settings, the indicators of these buttons may change color when the settings are changed.

[Tempo/Rhythm] Button

Press this to change the tempo or Rhythm (p. 23, p. 28)

Rhythm Button

Switches each Rhythm on or off. Use these two buttons to determine whether a Rhythm is to be played in each individual part.

[Drums] Button

Turns the Rhythm Drum part on and off (p. 26). Press this button when you want to stop both the Drum and Chord parts.

[Chord] Button

Turns the Rhythm Drum part and Chord part on and off. You can also turn only the Chord part off (p. 26).

[ (Metronome)] Button

Turns the internal metronome on and off (p. 23).

Recorder Buttons

Used for playing back and recording performances. Such operations employ the following two buttons.

[Play] Button

Starts and stops playback of internal songs and recorded performances (p. 12).

Used for starting recording of performances (p. 33). Can also be used to force-stop Rhythms (p. 26).

[Rec] button

Puts the unit in the state whereby it is ready for recording performances (p. 33).

[Chorus] Button

You can use this to add three-dimensional breadth and “fatness” to sounds (p. 20).

[Reverb] Button

You can use this to add the characteristic reverberation of a concert hall to what you play (p. 21).

[Song] Button

For selecting internal songs (p. 12). By holding down this button and pressing the [Reverb]

button, you can change the keyboard’s touch sensitivity (p.

19). In addition, you can hold down this button while pressing

other specified buttons to make various different settings (p. 38 to p. 44).

Page 7

Rear Panel

Damper Soft

Pedal Line In

1 2 3 4 5 6 7

Out In

MIDI

RL (Mono

Stereo

Panel Descriptions

)

RL (Mono

Stereo

Line Out

)

Power

Off

DC In 9V

Pedal Jacks

Accepts connection of the supplied pedal , or other suitable pedals (p. 10).

MIDI Connectors

You can connect external MIDI devices to the FP-3 and exchange performance data among them (p. 42).

Line In Jacks

Provide input of the audio signals. Used for connecting audio equipment and other such devices (p. 8).

Line Out Jacks

Provide output of the audio signals. Also used for connecting audio equipment and other such devices (p. 8).

These allow you to play sounds from the FP-3 through other audio devices.

[Power] Switch

This switch turns the unit on/off (p. 10).

DC In Jack

Connect the supplied AC adaptor here (p. 8).

Cord Hook

Use this to fix in place the cord from the supplied AC adaptor (p. 8).

Page 8

Before You Play

Making Connections

The FP-3 does not contain an amp or speakers. To hear sound, either connect an amplifier and speakers, or use stereo headphones.

* MIDI cable and stereo headphones are not included. Consult your Roland dealer if

you need to purchase accessories such as these.

fig.00-01

Damper Soft

Pedal Line In

Out In

MIDI

MIDI devices (p. 42)

Pedal switch (DP-2, DP-6, etc.)

RL (Mono

Stereo

NOTE

To prevent malfunction and/or damage to speakers or other devices, always turn down the volume, and turn off the power on all devices before making any connections.

)

RL (Mono

Stereo

Line Out

)

Power

Off

DC In 9V

AC adaptor

Roland

Expression pedal (EV-5)

Pedal switch (DP-2, DP-6, etc.)

CD player, audio devices

Speaker with built-in amp, keyboard amp, etc.

1. Before you begin making connections, confirm the

following.

Is the volume level of the FP-3 or connected amp turned all the way down? Is the power to the FP-3 or connected amp turned off?

AC cable

Stereo set, etc

Power outlet

Page 9

2. Connect the supplied AC adaptor to the FP-3, and then plug

its other end into a power outlet.

To prevent the inadvertent disruption of power to your unit (should the plug be pulled out accidentally), and to avoid applying undue stress to the DC In jack, anchor the power cord using the cord hook, as shown in the illustration.

fig.00-02

Rear panel

Off

Power

DC In 9V

3. Connect the amp or audio gear to the Line Out jacks as

Before You Play

shown in the diagram.

In order to take full advantage of the FP-3’s sound we recommend that you play it in stereo.

When using the system in mono, connect to the Line Out L (Mono) jack.

→If you are using headphones, refer to “Connecting Headphones” (p. 11).

For instructions on connecting to the Pedal jacks, refer to “Connecting Pedals” (p. 10).

→ →For instructions on connecting to the MIDI connectors, refer to “Connecting MIDI

Devices” (p. 42).

Installing the Music Stand

fig.00-03

1. Using the supplied screws, fasten the music stand to the

back of the FP-3 as illustrated.

Be sure to use the supplied screws for attaching the music stand. Turn the screws clockwise to tighten them. When attaching the music stand, support it firmly with one hand to make sure

that you do not drop it. Be careful, so you do not get your fingers pinched.

2. To remove the music stand, support it with one hand while

loosening the screws.

NOTE

Do not apply excessive force to the installed music stand.

Page 10

Before You Play

Connecting Pedals

1. Connect the pedal included with the FP-3 to one

of the Pedal jacks.

When connected to the Damper jack, the pedal can be used as a damper pedal.

When connected to Soft, the pedal can be used as a soft pedal.

* Unplugging a pedal cord from the unit while the power is on

may cause the pedal’s effect to be applied without stopping. The power of the FP-3 must be turned off before inserting or removing a pedal cord.

Damper Pedal

Use this pedal to sustain the sound. While the pedal is depressed, long lingering reverberations continue to be added to the sound after you release from the keys.

When you depress the damper pedal on an acoustic piano, the sound from the strings that were struck resonates with other strings, adding rich reverberations and broadness to the sound. You can adjust this resonance (sympathetic resonance) when the damper pedal is depressed.

* The amount of the resonance obtained with the Damper pedal

can be changed. For more information and instructions, please refer to “Changing the Damper Pedal’s Resonance” (p. 38).

Soft Pedal

This pedal is used to make the sound softer.

Turning the Power On and Off

Once the connections have been completed, turn on or off power to your various devices in the order specified. By turning on devices in the wrong order, you risk causing malfunction and/or damage to speakers and other devices.

■ Turning On the Power

1. Before you switch on the power, turn the volume

down all the way by rotating the [Volume] knob.

fig.00-05

Also completely turn down the volume of any connected audio device and other equipment.

2. Press the [Power] switch on the back of the unit.

After a few seconds, the unit becomes operable and playing the keyboard produces sound.

fig.00-06

Rear panel

Lower position

Off

Power

DC In 9V

Playing with the soft pedal depressed produces a sound that is not as strong as when otherwise played with the equivalent strength. This is the same function as the left pedal of an acoustic piano.

* When connected to the Soft Pedal jack, the pedal may also be

used as a sostenuto pedal or expression pedal. For more information and instructions, please refer to “Changing How the Pedals Work” (p. 38).

* By obtaining a second pedal, you can then use two pedals

simultaneously. If you wish to purchase the optional pedal (DP-2/DP-6), please contact the dealer where you purchased the FP-3.

* This unit is equipped with a protection circuit. A brief interval

(a few seconds) after power up is required before the unit will operate normally.

3. Turn on the power of the connected external

equipment.

4. Adjust the volume of the connected external

device.

5. Adjust the FP-3’s volume to obtain the proper

volume level.

Page 11

Before You Play

■ Turning Off the Power

1. Before switching the power off, turn the volume

all the way down by rotating the [Volume] knob.

Also completely turn down the volume of any connected audio device and other equipment.

2. Turn off the power to the connected external

equipment.

3. Press the [Power] switch on the back of the unit.

The power is switched off.

fig.00-07

Rear panel

Upper position

Off

Power

DC In 9V

OFF

Adjusting the Sound’s Volume and Brilliance

fig.00-08

Connecting Headphones

Connecting headphones allows you to enjoy playing anytime, even at night, without concern.

fig.00-09

1. Plug the headphones into the Phones jack at the

front, on the left side of the piano.

Use the [Volume] knob on the FP-3 to adjust the volume of the headphones.

* Make sure to use stereo headphones.

Some Notes on Using Headphones

• To prevent damage to the cord, handle the headphones only by the headset or the plug.

• The headphones may be damaged if the volume is too high when they are plugged in. Lower the volume on the FP-3 before plugging in the headphones.

• To prevent possible auditory damage, loss of hearing, or damage to the headphones, the headphones should not be used at an excessively high volume. Use the headphones at a moderate volume level.

1. Use the [Volume] knob to adjust the overall

volume level.

Rotating the knob clockwise increases the volume; counterclockwise rotation decreases it.

2. Use the [Brilliance] knob to adjust the overall

sound quality.

Rotating the knob clockwise makes the tone brighter; rotating it counterclockwise makes the sound more subdued.

Page 12

Chapter 1 Playing the Keyboard

Listening to Internal Songs

Now, try listening to internal songs The FP-3 comes with fifty four internal songs.

fig.01-01

1. Press the [Song] button, getting its indicator to light.

The following appears in the display.

fig.01-02

2. Press the [-] or [+] button to select the song.

3. Press the [Play] button.

The song will begin playing back. The selected song is played to the end, and then playback stops.

4. To stop playback, press the [Play] button once more.

The next time you press the [Play] button, the song that was stopped is played from the beginning.

For more on internal song names, refer to “Internal Song List” (p. 54).

12 3, 4

bout the Display of

the Internal Songs

USr (User)—Stores recorded Performances (for more on recording →p. 33). When “d.” is added— Indicates one of the demo songs that make use of the FP-3’s various internal tones. When “P.” is added— Indicates one of the piano songs

NOTE

■

Playing Back All Songs Continuously (All Song Play)

Listening to all of internal songs repeatedly played back in succession is known as “All Song Play.”

fig.01-06

You cannot play the internal song and Rhythm (p. 26) at the same time.

1. Hold down the [Song] button and press the [Play] button.

Songs play back continuously. When playback of the last song is reached, playback continues by returning to the first song and playing that again.

2. To stop playback, press the [Play] button.

All Song Play is exited when the performance is stopped. The next time you press the [Play] button, the song that was stopped is played from the beginning.

When you change the volume balance between the keyboard and the Rhythm, the volume

alance between the keyboard and the internal song may change. Refer to “Changing the Volume Balance Between the Keyboard and the Rhythm”

Page 13

When the following appears in the display

If there is any performance data stored in the FP-3’s memory, the following appears in the display.

fig.01-03

Flashes in green Flashes in red Flashes in green

Until you erase the performance data, you cannot play back an internal song.

To erase the performance data and play back the internal song, press the [Rec] button.

If you don’t want to erase the song, press the [Play] or [Song] button.

■ Listening to Each Part Separately

With the internal songs, you can select the performance part that is to be played back.

Chapter 1 Playing the Keyboard

With Piano songs 1 to 50, you can also practice each hand separately while playing along with the song.

1. Select the song to be played back.

2. Hold down the [Play] button and press the button, either

[Chord (1)] or [ (2)], for the part that is not to be played back.

The indicator on the selected button goes out. The performance data is assigned to the Track buttons as shown below.

fig.01-05

Left-hand

Part

Right-hand

Part

3. Press the [Play] button.

The song will begin playing back. The sound for the performance part selected in Step 2 is not played. Temporarily preventing the sounds of a specified part from playing is called

“muting.”

4. Hold down the [Play] button and press the button selected in

Step 2.

The sound of the muted part is then played.

Page 14

Chapter 1 Playing the Keyboard

Performing with a Variety of Sounds

The FP-3 features 40 different internal sounds, allowing you to enjoy performing with sounds suitable for many different types of music.

These onboard sounds are called “Tones.” The Tones are divided into six different groups, each of which is assigned to a different Tone button.

The Tone “Grand Piano 1” is selected when the instrument’s power is turned on.

fig.01-07

1, 3 2

For more on Tones, refer to “Tone List” (p. 48)

1. Press one of the Tone buttons to choose a Tone Group.

You’ll hear the Tone assigned to Tone number 1 in the selected Tone Group. Try fingering the keyboard.

The Tone number appears in the display.

fig.01-08

When you press the Tone button, the [-] and [+] buttons light in orange.

2. Press the [-] or [+] button to select a Tone from the Tone

Group.

The indicator for the selected Tone button flashes, showing that the tone has been selected.

3. Finger the keyboard or press the flashing Tone button.

The Tone button’s indicator lights up, and you can check the sound. The Tone you’ve selected is heard when you finger the keyboard.

The next time you choose this Tone button, the tone you’ve selected here is played.

Page 15

Chapter 1 Playing the Keyboard

Performing With Two Layered Tones (Dual Play)

You can play two different sounds from a single key at the same time. This method of performance is called “Dual Play.”

Example: Try Layering Piano and String Tones

fig.01-09

1. Press the [Piano] button and the [Strings/Pad] button at the

same time.

The indicators for both buttons light. Try fingering the keyboard. Both the piano and string sounds play. Pressing two Tone buttons at the same time in this manner activates Dual Play. In Dual Play, the Tone for the left button you press is called the “Upper

Tone,” and the Tone for the right button is called the “Lower Tone.” The Tone button’s indicator lights in orange for the Upper Tone, and in red

for the Lower Tone.

fig.01-10

Orange

Upper Tone

Here, the piano tone is the Upper Tone and the strings tone is the Lower Tone.

Red

Lower Tone

You can change the pitch of the Lower Tone an octave at a time. Refer to “Changing the Pitch of the Lower Tone in Octave Steps (Octave Shift)” (p. 39).

You can vary the volumelevel balance of the two tones. Take a look at “Changing the Volume Balance for Dual Play and Split Play” (p. 18).

2. To exit Dual Play, press either Tone button.

Now, only the tone of the button you just pressed is sounded.

Switching the Upper Tone and Lower Tone

When in Dual Play, you can together press both of the Tone buttons for the two currently selected tones a second time to assign the tone of the left button to the Lower Tone, and the tone of the right button to the Upper Tone.

You can easily switch between two tones, which is useful for times such as when you have things set so the pedal’s effect is not applied to the Lower Tone (see “MEMO”).

Although when you press the pedal while in Dual Play, the effect is applied to

oth tones, you can set the FP-3 so that the effect is not applied to the Lower Tone. Refer to “Changing How the Pedal Effects Are Applied” (p. 39).

Page 16

Chapter 1 Playing the Keyboard

Performing With Different Tones in the Left and Right Sides of the Keyboard (Split Play)

Performing with the keyboard divided at a certain key into a left side and a right side is called “Split Play,” and the point at which the keyboard is divided is called the “split point.”

In Split Play, you can have a different tone sound in the left and right sides. Furthermore, when you use the Rhythm in performances, you can specify

chords with the keys in the left-hand part (for more detailed instructions, refer to “Performing With the Chord Progression Specified in the Left Hand (Rhythm Split Play)” (p. 31)).

When the instrument is turned on, the split point is set to “F 3.” The split point key is included in the left side.

While in Split Play, a sound played in the right side is called an “Upper Tone,” and the sound played in the left side is called a “Lower Tone.”

Example: Let’s try split play with the piano tones.

fig.01-11

12, 3

1. Press the [Piano] button.

Now, the piano tone is selected.

2. Press the [Split] button, getting its indicator to light.

The keyboard is divided into upper and lower sections.

fig.01-12

F 3 (Split Point)

Lower Tone Upper Tone

The right-hand section of the keyboard plays piano tone, and the left-hand section plays Acoustic Bass+Cymbal tone. You can play a tone for the right side (the Upper Tone) before splitting the keyboard. The Tone button’s indicator lights in orange for the Upper Tone, and in red for the Lower Tone.

3. To exit Split Play, press the [Split] button once more.

The [Split] button’s indicator light goes out and the upper tone becomes the tone for the entire keyboard.

When you switch from Dual Play (p. 15) to Split Play, the Upper Tone used in Dual Play is selected as the Upper Tone for Split Play.

You can vary the volumelevel balance of the two tones. Take a look at “Changing the Volume Balance for Dual Play and Split Play” (p. 18).

Page 17

■ Changing Tones

fig.01-13

Chapter 1 Playing the Keyboard

1. Hold down the [Split] button and press the Tone button for

the tone you want to change, whether the Upper or Lower Tone.

The indicators for the [-] and [+] buttons light in the same color as the indicator of the selected tone button.

When orange, it indicates that the Upper Tone can be changed; when red, it is the Lower Tone that is being changed.

2. Use the Tone buttons and the [-] and [+] buttons to select the

Tones.

For more on selecting tones, refer to “Performing with a Variety of Sounds” (p. 14).

■ Changing the Keyboard’s Split Point

You can change the location where the keyboard is divided (the split point) within the range of B1 through B6.

When the tone of the same Tone button is selected for

oth the Upper and Lower Tones, you can determine which of the Tones is being changed by the color of the indicators for the [-] and [+]

uttons.

You can change the pitch of the Lower Tone an octave at a time. Refer to “Changing the Pitch of the Lower Tone in Octave Steps (Octave Shift)” (p. 39).

This is set to “F 3” when the instrument is turned on. This setting remains in effect until you turn off the power.

fig.01-14

F 3

B1 B6

1. Hold down the [Split] button and press a key set as the split

point.

The key you pressed becomes the split point, and belongs to the left-hand section of the keyboard.

The name of the key acting as the split point is indicated in the display, as shown below.

Display

C d_ d E_

Letter

C D D E

name

Display

E F F G

Letter

E F F G

name

Display

A_ A b_ b

Letter

A A B B

name

While the [Split] button is held down, the key being used as the split point appears in the display.

With the [Split] button held down, you can change the value, even by pressing the [-] or [+] button.

Additionally, by holding down the [

Split

] button and pressing the [-] or [+]

button one time, you can display the currently selected value. When you release the [Split] button, you return to the previous screen.

By holding down the [Split]

utton and pressing both the [-] and [+] buttons simultaneously, the setting returns to its original value.

Page 18

Chapter 1 Playing the Keyboard

Changing the Volume Balance for Dual Play and Split Play

You can change the volume balance of the Upper and Lower Tones in Dual Play (p. 15) and Split Play (p. 16).

When the instrument is turned on, this is set to “5–5” (“Lower Tone volume”–“Upper Tone volume”).

fig.01-15

2 3

1. Hold down the [Song] button and press the [Split] button.

The indicators for the [Song] and [Split] buttons flash in red.

fig.01-16

Lower Tone volume

(The Tone button’s indicator light is red)

Upper Tone volume (The Tone button’s indicator light is Orange)

2. Press the [-] or [+] buttons to adjust the volume balance.

To restore the normal default volume balance, press the [-] and [+] buttons simultaneously.

3. Press the [Song] button.

The indicators return to their previous state.

Page 19

Changing the Keyboard’s Touch

You can change the touch sensitivity, or response of the keys. When the instrument is turned on, this is set to “Normal.”

fig.01-17

Chapter 1 Playing the Keyboard

2 3

1. Hold down the [Song] button and press the [Reverb] button.

The indicators for the [Song] and [Reverb] buttons flash in red.

fig.01-18

2. Press the [-] or [+] buttons to select the touch.

Indicate Description

OFF

(Fixed)

1 (Light)

2 (Normal)

The sound plays at one set volume, regardless of the force used to play the keys.

A light keyboard touch is selected. You can achieve fortissimo (ff) play with a less forceful touch than usual, so the keyboard feels lighter. This setting makes it easy to play, even for children.

This sets the standard keyboard touch. You can play with the most natural touch. This is the closest to the touch of an acoustic piano.

Here, a heavy keyboard touch is selected. You have to ﬁnger the keyboard more forcefully than usual in order to

3 (Heavy)

play fortissimo (ff), so the keyboard touch feels heavier. Dynamic ﬁngering adds even more feeling to what you play.

3. Press the [Song] button.

The indicators return to their previous state.

Page 20

Chapter 1 Playing the Keyboard

Adding Breadth to the Sound (Chorus Effect)

You can apply a chorus effect to the notes you play on the keyboard. By adding the chorus effect, you can give the sound greater dimension, with more fatness and breadth.

The settings of the chorus effect are memorized independently for each sound, and remain in effect until you turn off the power.

fig.01-19

1. Press the [Chorus] button, getting its indicator to light.

1, 2

Try fingering the keyboard. The chorus effect is applied to the currently selected tone.

2. The remove the chorus effect, press the [Chorus] button once

more, extinguishing the indicator.

■ Adding a Spinning Sound to Organ Tones (Rotary Effect)

Some organ tones selected with the [Organ] button feature a rotary effect. When one of these tones is selected, you can use the [Chorus] button to change the speed of the rotary effect.

What the rotary effect does is to add a “spinning” effect similar to the sound of an organ using a rotating speaker.

Press the [Organ] button and select the organ tone. Each time pressing the [Chorus] button, switch the speed of

the rotary effect between rapid and slow rotation.

When a tone that has the Rotary effect added is selected, the [Chorus] button’s indicator flashes in red or green.

When the [Chorus] button’s indicator flashes in red, a more rapid rotary effect is applied.

Some tones initially have chorus applied. Selecting such a tone makes the [Chorus] button’s indicator light up automatically.

For more information on Tones applied the Rotary effect, see “Tone List” (p. 48).

When the [Chorus] button’s indicator flashes in green, a slower rotary effect is applied.

■ Changing the Depth of Chorus Effect

You can select from ten levels of depth for the chorus effect.

Hold down the [Chorus] button and press the [-] or [+] button.

The [Chorus] button’s indicator flashes in red. The depth for the chorus effect being applied to the currently selected tone

appears in the display.

NOTE

You cannot change the levels of depth for the rotary effect.

Page 21

Chapter 1 Playing the Keyboard

fig.01-20

2. Press the [-] or [+] button to change the depth of effect.

3. Press the [Chorus] button once more.

The button’s indicator returns to its previous state. The next time you choose the same tone, the chorus effect with the depth

you’ve selected here is applied.

Adding Reverberation to Sounds (The Reverb Effect)

You can apply a reverb effect to the notes you play on the keyboard. With the reverb effect, you obtain a pleasant reverberation, making it sound as if you were performing in a concert hall or similar space.

fig.01-21

1. Press the [Reverb] button, getting its indicator to light.

Try fingering the keyboard. The reverb effect is applied to the entire tone.

2. The eliminate the Reverb effect, press the [Reverb] button

once more, extinguishing the indicator.

■ Changing the Depth of Reverb Effect

You can select from ten levels of depth for the reverb effect.

1. Hold down the [Reverb] button and press the [-] or [+]

button.

The [Reverb] button’s indicator flashes in red. The selected depth for the reverb effect appears in the display.

fig.01-22

1, 2

NOTE

You cannot make separate reverb effect depth settings for each individual tone. The effect is applied at the same depth to all tones.

2. Press the [-] or [+] button to change the depth of the effect.

3. Press the [Reverb] button once more.

The indicator returns to its previous state.

Page 22

Chapter 1 Playing the Keyboard

Transposing the Key of the Keyboard (Key Transpose)

You can transpose the key of a performance without having to shift the position of your fingers on the keyboard. This feature is called “Key Transpose.”

This lets you take a song in a difficult key with lots of sharps ( ) and flats () and play it in a key with fingering that’s easier for you. This is handy

when playing accompaniment to a song, to match what you play to the pitch of the singer’s voice.

fig.01-23

Press the corresponding key

1. Hold down the [Song] button and press the key

corresponding to the tonic of the desired key.

The Key Transpose settings value continues to appear in the display while the [Song] button is held down.

With the [Song] button held down, you can change the value, even by pressing the [-] or [+] button.

Additionally, by holding down the [Song] button and pressing the [-] or [+] button one time, you can display the currently selected Key Transpose value.

The available range is -6–0–5.

fig.01-24

When you release the [Song] button, you return to the previous screen.

2. To return to the original key, hold down the [Song] button

1, 2

By holding down the [Song]

utton and pressing both the [-] and [+] buttons simultaneously, the setting returns to its original value.

and press the C key (the tonic of C Major).

Example: Playing a Song in the Key of E Major After Transposition to C Major

Hold down the [Song] button and press the E key (since E is the tonic). Counting from C as a reference point, one moves up four keys, including the

black keys, to reach E, thus “4” appears in the display.

fig.01-25

Page 23

Chapter 1 Playing the Keyboard

Using the Metronome

Here’s how you can make use of the metronome.

fig.02-01

1. Press the [ (Metronome)] button to have the metronome

sound.

The [Tempo/Rhythm] button’s indicator flashes in red and green in time with the beat selected at that time. The indicator lights in red on the downbeats, and in green on weak beats.

1, 2

The tempo appears in the display.

fig.02-02

2. To stop the metronome, press the [ (Metronome)] button

again.

■ Changing the Tempo

1. Press the [Tempo/Rhythm] button, so you have the tempo

displayed.

Pressing the [Tempo/Rhythm] button alternately displays the tempo and the currently selected Rhythm number (indicated by an initial “r”).

When the tempo is displayed, the [-] and [+] buttons light in red.

2. Press the [-] or [+] button to adjust the tempo.

About Rhythm, refer to “Chapter 2 Playing Along with Rhythms” (p. 25).

Page 24

Chapter 1 Playing the Keyboard

■ Changing the Beat of Metronome

1. While holding down the [Tempo/Rhythm] button, press the

[-] or [+] button.

The [Tempo/Rhythm] button’s indicator flashes in red. The currently selected beat is displayed.

fig.02-03

2. Press the [-] or [+] button to select the beat.

You can select from the following beats.

Display Beat Display Beat

2.2 2/2 6.4 6/4

0.4 Weak beats only 7.4 7/4

2.4 2/4 3.8 3/8

3.4 3/4 6.8 6/8

4.4 4/4 9.8 9/8

NOTE

You cannot change the metronome beat while a song or Rhythm is being played.

5.4 5/4 12.8 12/8

3. Press the [Tempo/Rhythm] button.

The button’s indicator returns to its previous state.

■ Changing the Volume

The volume of the metronome can be adjusted, with ten volume levels available.

This is set to “5” when the instrument is turned on.

1. While holding down the [ (Metronome)] button, press the

[-] or [+] button.

The [ (Metronome)] button’s indicator flashes in red. The currently selected metronome volume is displayed.

fig.02-04

2. Press the [-] or [+] button to adjust the volume.

3. Press the [ (Metronome)] button.

The button’s indicator returns to its previous state.

Page 25

Chapter 2 Playing Along with Rhythms

What is Session Partner?

“Session Partner” Lets You Enjoy Playing with a Session-Like Feel

“Session Partner” is a function that lets you select the On/Off status of the two Rhythm buttons along with the “Rhythm,” making it easy to add accompaniment.

You can play intros, endings, and fill-ins (short phrases inserted at transition points in the song) by pressing buttons as you play the keyboard.

Additionally, you can also have chord changes be made automatically as you play the Rhythm, giving you piano performances with a session-like feel—like having a whole band backing you.

What You Can Do With “Session Partner”

“Session Partner” lets you mainly do the following things.

• Play along to a Rhythm’s Drum Part in place of the metronome sound (p. 26)

• Play piano with a session-like feel along with Rhythms while the chord progression continues automatically (p. 26)

• Play the piano to provide your own accompaniment as you specify chords with the left hand (the left part of the keyboard) (p. 31)

• Record Rhythms along with specified chords, then use the entire keyboard to perform along with this prerecorded accompaniment (p. 35)

By changing the chords and Rhythms, even while playing the same melody, you can easily enjoy creating all kinds of new arrangements.

We encourage you to enjoy the variety of performance options open to you by using the “Session Partner” feature.

What are the FP-3’s “Rhythms?”

The FP-3 features internal “Rhythms” complementing Jazz, Rock, and other various musical genres.

“Rhythms,” which combine rhythmic patterns, bass patterns, and other elements found in different musical styles, form the foundation of performance accompaniment in the “Session Partner” function.

Additionally, each Rhythm is composed of a “Drum Part” and a “Chord Part.”

Drum Parts consist of drum sounds. Chord Parts are Parts in which chords are played, with the bass sound forming the foundation, but also using other instrumental sounds. You can play each of these Parts by pressing the [Drums] and [Chord] buttons.

Page 26

Chapter 2 Playing Along with Rhythms

Performing Along With Rhythms

fig.02-05

■ Performing Along With Drum Sounds

Now, try performing as the sound of the Rhythm’s Drum Part plays. Since a wide variety of musical genres is provided, be sure to use a Rhythm

that best suits the song you are performing. Please refer to “Selecting a Rhythm” (p. 28).

1. Press the [Drums] button.

The [Drums] button’s indicator lights up, and the intro begins to play.

2. When you press the [Drums] button once more, the ending is

played, and the Rhythm stops.

The [Drums] button’s indicator goes out.

■ Performing With Chord Parts

In addition to the Drum Parts, you can also perform with “Chord Parts” that use bass and other sounds.

The chord progression is automatic, so feel free to play the melody any way you like.

Furthermore, you can also stop the Chord Part during the performance and have only the Drum Part continue playing.

1. Press the [Chord] button.

The indicators for the [Chord] and [Drums] buttons light up, and the intro begins to play.

NOTE

You cannot play the internal song and Rhythm at the same time.

For more information on the different Rhythm types, refer to the “Rhythm List” (p. 49).

To Immediately Stop a Rhythm

You can press the [Play]

utton to stop a Rhythm immediately. Additionally, when the [Drums] button indicator is lit in red, if you then press the [Drums]

utton once more, you can immediately stop the intro or ending, even when while these are being played.

2. Press the [Chord] button, extinguishing the indicator.

The Chord Part sound stops, and only the Drum Part continues playing.

You can change the chord progression patterns. Refer to the “Chord Progression Pattern List” (p. 50).

3. Press the [Chord] button again, getting the button’s indicator

to light.

The Chord Part sound starts playing again.

4. When you press the [Drums] button once more, the ending is

played, and the Rhythm stops.

The lights for the [Chord] button and the [Drums] button go out.

You can also specify the chords to be played in a Rhythm. For details, refer to “Performing With the Chord Progression Specified in the Left Hand (Rhythm Split Play)” (p. 31).

Page 27

Chapter 2 Playing Along with Rhythms

Playing Only the Bass Sound of the Chord Part

A Rhythm’s Chord Part not only contains its fundamental bass sound, but may also include the sound of instruments other than the bass. However, you can have just the bass sound of such Chord Parts play.

You can also change the settings while the Rhythm is being played. This setting is effective for all Rhythms until the FP-3’s power is turned off.

1. Hold down the [Song] button and press the [Chord] button.

The indicators for the [Song] and [Chord] buttons flash in red.

fig.02-07

2. Press the [-] or [+] button to select the setting.

Indication Description

On All of the Chord Part’s sounds are played.

OFF Only the Chord Part’s bass sound is played.

3. Press the [Song] button.

The indicators return to their previous state.

About the lighting of the [Drums] and [Chord] button indicators

The indicators of the [Drums] and [Chord] buttons indicate the status of the Rhythm performance, as shown below.

Indicator Performance

Dark

Lit in red

Performance is stopped

Intro/Fill-In/Ending is being played

Lit in green

Rhythm is being performed

Page 28

Chapter 2 Playing Along with Rhythms

Selecting a Rhythm

Now, try changing the Rhythm being performed.

fig.02-09

2 1 4 3

1. Press the [Tempo/Rhythm] button so that the Rhythm

number appears in the display.

Rhythm numbers are indicated by an “r” before the number. When a Rhythm is displayed, the [-] and [+] buttons light in green.

fig.02-10

2. Press the [-] or [+] button to select the Rhythm.

3. Press the [Chord] or [Drums] button.

The button’s indicator lights up, and the intro of the selected Rhythm begins to play.

4. To stop the performance, press the [Drums] button.

An Ending is played, then the Rhythm stops. The indicator for the [Chord] or [Drums] button goes out.

■ Changing Rhythms As You Perform

If you change Rhythms while a Rhythm is being played, the selected Rhythm begins after the fill-in is played. The indicator for the [Chord] button or [Drums] button lights in red while the fill-in is played.

What’s a “Fill In”?

A short improvisational phrase inserted at the bar line is called a “Fill In.” The phrase best suited to the selected Rhythm is played.

NOTE

You cannot change Rhythms while the intro or ending is being played.

Page 29

Chapter 2 Playing Along with Rhythms

Changing a Rhythm’s Tempo

You can change the tempo of the selected Rhythm. Furthermore, you can change the tempo as the Rhythm is being played.

fig.02-08

2 1

1. Press the [Tempo/Rhythm] button to have the tempo

displayed.

Pressing the [Tempo/Rhythm] button alternately displays the tempo and the currently selected Rhythm number (indicated by an initial “r”).

When the tempo is displayed, the [-] and [+] buttons light in red.

2. Press the [+] and [-] buttons to adjust the tempo.

The tempo can be changed within the range from 20 ~ 250. When the [Chord] button or [Drums] button is pressed, the Rhythm is

played at the selected tempo. Pressing both the [-] and [+] buttons simultaneously returns the tempo to

96.

Page 30

Chapter 2 Playing Along with Rhythms

Selecting a Rhythm’s Chord Progression

When playing the Chord Part while performing, the chord progression is automatic. You can change the chord progression pattern if you want.

These settings cannot be memorized independently for each Rhythm.

1. Hold down the [Chord] button and press the [-] or [+] button.

The [Chord] button’s indicator flashes in red. The currently selected chord progression pattern number and the root of the

beginning chord are displayed. The performance stops when the Rhythm is played.

fig.02-11

Chord progression pattern number The root of the beginning chord

2. Press the [-] or [+] button to change the chord progression

pattern.

3. Press the key corresponding to the root note of the first

For more information on chord progression patterns, refer to the “Chord Progression Pattern List” (p. 50).

The root is indicated in the display as shown below.

Display

C C d E_

Letter

C C D E

name

Display

E F F G

Letter

E F F G

name

Display

A_ A b_ b

Letter

A A B B

name

chord.

The chord progression that follows is changed to match the specified chord.

fig.02-12

CDEEFFGAAB

4. Press the [Chord] button once more.

The button’s indicator returns to its previous state.

You can specify chords yourself in Split Play. For details, refer to “Performing With the Chord Progression Specified in the Left Hand

(Rhythm Split Play)” (p. 31).

Page 31

Chapter 2 Playing Along with Rhythms

Performing With the Chord Progression Specified in the Left Hand (Rhythm Split Play)

Performing with the keyboard divided at a certain key into a left side and a right side is called “Split Play.” When using the Rhythm while Split Play is in effect, you can specify the

chords with the keys in the left part of the keyboard.

fig.02-13

1, 5 4 2

1. Press the [Split] button, getting its indicator to light.

2. Press the [Chord] button, getting its indicator to light.

The indicators for the [Chord] and [Drums] buttons flash, and the FP-3 is put into standby mode. When the [Split] button is pressed while a performance is in progress, the Rhythm stops.

3. The chord is specified with a key in the left part of the

keyboard, and the Rhythm begins.

fig.02-14

F 3 (Split point)

NOTE

When specifying the chords in the left part of the keyboard, Dual Play (p. 15) is disabled in the right part.

The point at which the keyboard is divided is called the “split point”; you can also change this split point. For more information, take a look at “Changing the Keyboard’s Split Point” (p. 17).

The range specified a chord

You can specify chords

Specify the chord in the left part of the keyboard, and perform the melody in the right side. It is not necessary to continue holding down the keys for chords in the left side. Even after you release the key, the same chord continues until the next chord is played. When specifying chords, sounds from the left side of the keyboard are not played.

simply with your finger, even without playing the keys for all the chords’ constituent notes. For more information about chord fingering, refer to the “Chord Fingering List” (p. 52).

4. To stop the Rhythm, press the [Drums] button.

After the ending is done, the performance stops. The indicators for the [Chord] and [Drums] buttons then start flashing, and the FP-3 is put into standby mode.

5. To exit Split Play, press the [Split] button, extinguishing the

indicator.

While in Split Play, when the [Chord] button is off, and only the Drum part is

eing played, you can perform in the left side of the keyboard using the Lower Tone (p. 16).

Page 32

Chapter 2 Playing Along with Rhythms

Changing the Volume Balance Between the Keyboard and the Rhythm

When using Rhythms in a performance, you can change the balance between the Rhythm volume and the volume of the performance played on the keyboard.

When the power is turned on, the volume balance is set to “5–5” (“Keyboard volume” – “Rhythm volume”).

fig.02-15

When you change the volume balance between the keyboard and the Rhythm, the volume

alance between the keyboard and the internal song may change.

2 3

1. Hold down the [Song] button and press the [Drums] button.

The [Song] and [Drums] buttons’ indicator flashes in red. The selected volume balance appears in the display.

fig.02-16

Keyboard volume Rhythm volume

2. Press the [-] or [+] button to adjust the volume balance.

To restore the normal default volume balance, press the [-] and [+] buttons simultaneously.

3. Press the [Song] button.

The buttons’ indicator return to their previous state.

Page 33

Chapter 3 Recording a Performance

You can easily record your performances. You can play back a performance you have recorded to check what and how you played, and play melodies on the keyboard along with prerecorded accompaniment using the Rhythm.

Notes Regarding Recording

• Only one song can be recorded. With second or later recordings, the previously recorded song is erased as the new material is recorded. When recording a new performance, it is probably a good idea to erase the previously recorded performance first (p. 37).

• Recorded performances are erased when the power is turned off.

To Record Without Erasing the Previously Recorded Performance...

2nd Pass

1st Pass

Recording a Performance

This records only what you play on the keyboard, without using the Rhythm.

fig.03-01

1. Press the [Song] button, getting its indicator to light.

The song number appears in the display.

2. Press the [-] button to display the “USr.”

3. Select the Tone to be played.

4. If necessary, sound the metronome.

While listening the metronome, select the tempo and beat of the song (p. 23).

The first Perform-

ance is preserved

6, 8

NOTE

When you record additional material without erasing the previously recorded sounds, the song is recorded at the initially recorded tempo.

5. Press the [Rec] button.

The [Rec] button’s indicator lights, the [Play] button’s indicator begins flashing, and the FP-3 is put into recording standby.

6. Press the [Play] button or play a key on the keyboard to

During the count-in, the count measure is indicated in the display as “-2” then “-1.”

begin recording.

Press the [Play] button, and after two measures of count sound, recording begins. Recording will begin when you start playing the keyboard, even if you do not press the [Play] button. In this case, a count is not sounded.

bout “USr” in the

Display

When recording is stopped,

7. Press the [Rec] button or the [Play] button to stop recording.

The indicators for the [Rec] and [Play] buttons are extinguished, and recording stops.

Listening to the Recorded Performance

8. Press the [Play] button.

Press the [Play] button again, and playback stops.

the “ ” indication

changes to “ ” in the display. The “.” in the display indicates that there is Performance material already recorded.

Page 34

Chapter 3 Recording a Performance

■ Recording a Performance Using Rhythms

You can also easily record session performances to the internal Rhythms and chord progressions.

fig.03-02

1. Select the Tone or Rhythm to be played.

Also set the Rhythm tempo to one that is easier to play (p. 29).

2. Press the [Rec] button.

NOTE

When you record additional material without erasing the previously recorded sounds, the song is recorded at the initially recorded tempo.

54 3

For more on selecting tone and Rhythm, refer to p. 14 and p. 28.

The [Rec] button’s indicator lights up, the [Play] button’s indicator flashes, and the FP-3 is put into recording standby.

3. Press the [Chord] button or the [Drums] button to begin

recording.

The Rhythm starts to play, while simultaneously recording begins.

4. Press the [Drums] button to stop recording.

The ending is played, and the performance and recording stop. When you press the [Rec] button or the [Play] button, recording stops

without the ending being played.

Listening to the Recorded Performance

5. Press the [Play] button.

Press the [Play] button again to stop playback.

For more information on the different Rhythm and Chord progression pattern, refer to the “Rhythm List” (p. 49) and “Chord Progression Pattern List” (p. 50).

NOTE

A Rhythm cannot be started while recording is in progress.

Page 35

Chapter 3 Recording a Performance

■ Recording a Performance Using Rhythms

(in Split Play)

Specify the chord progression yourself to record session performances with even greater freedom.

By prerecording only the Rhythm (accompaniment) using your preferred chord progressions, you can then use the entire keyboard in session

performances as you play along with the playback of this recording.

fig.03-06

NOTE

When you record additional material without erasing the previously recorded sounds, the song is recorded at the initially recorded tempo.

3 46 7

1. Select the Tone or Rhythm to be played.

Also set the Rhythm tempo to one that is easier to play (p. 29).

2. Press the [Rec] button.

The [Rec] button’s indicator lights up, the [Play] button’s indicator flashes, and the FP-3 is put into recording standby.

3. Press the [Split] button, getting its indicator to light.

The keyboard is set to Split Play.

4. Press the [Chord] button.

The indicators for the [Chord] and [Drums] buttons flash, and the FP-3 is put into standby mode.

5. Specify a chord by playing it on the left-hand keyboard

section.

The Rhythm’s intro starts to play, and at the same time, recording begins.

Record the accompaniment while specifying the chords in the left part of the keyboard.

6. Press the [Drums] button to stop recording.

The ending is played, and then the Rhythm and recording stop. When you press the [Rec] button or the [Play] button, recording stops

without the ending being played.

Listening to the Recorded Performance

7. Press the [Play] button.

Press the [Play] button again to stop playback.

Page 36

Chapter 3 Recording a Performance

■ Recording Selected Track buttons

FP-3’s Recorder has three Track buttons. When you press the [Rec] button, all Track buttons are set to be recorded, but by selecting Track buttons that are not to be recorded, you can then record only on the specific Track buttons you want. For example, you can record each hand’s performance to different Track buttons, or record over only certain Track buttons in a previously recorded performance. Only sounds from Drum set tones and Rhythm sounds can be recorded to

the [Drums (R)] button.

fig.03-03

NOTE

When you record additional material without erasing the previously recorded sounds, the song is recorded at the initially recorded tempo.

While holding down the [Rec] button, and turn off the indicator light for the Track button, whether the [Drums (R)],

[Chord (1)], or [ (2)] button, for any track not to be recorded.

The [Rec] button’s indicator lights up, the [Play] button’s indicator flashes, and the FP-3 is put into recording standby. With the FP-3 in standby, go on to record the performance according to the procedures as described in “Recording a Performance” (p. 33), “Recording a Performance Using Rhythms” (p. 34) or “Recording a Performance Using Rhythms (in Split Play)” (p. 35), starting from Step 3.

The performance is recorded only to the Track buttons whose indicator was lit.

Recording along with internal songs

You can also record your own performance as you play along with the internal piano songs. When recording to specific Track buttons, the sounds on the selected Track buttons are not played. For example, you can record what you are playing

with your right hand as you listen to the left-hand part.

1. With the [Song], [-] and [+] buttons select the song.

2. Hold down the [Rec] button and light the indicator for the

track button of the track you intend to play yourself.

The [Rec] button’s indicator lights up, the [Play] button’s indicator flashes, and the FP-3 is put into recording standby.

bout the Lighting of

Track Button Indicators

hen the [Rec] Button

Is Pressed

Dark

Lit in orange

Lit in red

Correspondence Between Internal Piano Song Track Buttons and Performance

[1] button: left-hand Part [2] button: right-hand Part No performance data is assigned to the [R] button.

NOTE

Not Recording

Recording

Data Recorded

Recording

No Data Recorded

3. Press the [Play] button to start recording.

The material at the Track button whose indicator was lit in Step 2 is not played.

4. Press the [Rec] or [Play] button to stop recording.

When recording along with an internal song, you will not be able to obtain playback at a modified tempo.

Page 37

Erasing Recorded Performances

You can erase recorded performances.

fig.03-04

Chapter 3 Recording a Performance

1. Hold down the [Song] button and press the [Rec] button.

A confirmation message appears in the display.

fig.03-05

Flashes in green Flashes in red Flashes in green

2. Press the [Rec] button.

The recorded performance is erased. If you do not want to erase the performance, press the [Play] or [Song]

button.

Correspondence Between Recorded Performance and Track Buttons

A recorded performance will be assigned to the Track buttons as follows.

Track button Performance recorded

[R]

[1] • Lower Tone in Dual play or Split play (p. 15, p. 16)

[2]

* You can also record to the [1] button regular keyboard performances in which

only the [1] button is specified.

• Rhythm (Drums Part, Chord Part) (p. 25)

• A performance of drum set tones

• The performance of the entire keyboard (except drum set tones)

• Upper Tone in Dual play or Split play (p. 15, p. 16)

Page 38

Chapter 4 Other Functions

Changing the Damper Pedal’s Resonance

On an acoustic piano, depressing the damper pedal makes the notes you play resonate with other strings, adding rich reverberations and fatness to the sound. The damper pedal on the FP-3 recreates this resonance (Sympathetic Resonance) when depressed.

You can select from ten levels of depth for the resonant sound (resonance level).

This is set to “5” when the instrument is turned on.

* This setting is effective only with tones 1, 2 and 5 for the

[Piano] button. You cannot make this setting with other tones.

1. Hold down the [Reverb] and [Chorus] buttons

and press the [-] or [+] button.

The indicators for the [Reverb] and [Chorus] buttons flash in red.

The resonance for the currently selected tone appears in the display.

fig.04-01

fig.04-02

Flashes in redFlashes in red

2. Press the [-] or [+] button to select the pedal

function.

Indication Description

1 (Soft Pedal) Sets function to soft pedal. Setting made

when the instrument is turned on.

2 (Sostenuto Pedal)

3 (Expression Pedal)

When the pedal is pressed, only the sounds of the keys being pressed are sustained. Connect the supplied pedal or a separately available pedal.

Allows control of the volume. You can also change the volume with the [Volume] knob, but by using this pedal you can change the volume level without taking your hands off the keyboard. Connect a separately available expression pedal (EV-5).

Flash in red

2. Press the [-] or [+] button to select the resonance

level.

3. Press the [Reverb] or [Chorus] button.

The indicators return to their previous state.

Changing How the Pedals Work

Although a pedal connected to the Pedal [Soft] jack normally functions as a soft pedal (p. 10), it can also be set to function as a sostenuto pedal or expression pedal.

For use as a sostenuto pedal, connect the supplied pedal or a separately available pedal. For use as an expression pedal, connect the separately available expression pedal (EV-5).

When the instrument is turned on, this is set to function as a soft pedal.

4 (Start/Stop) You can control the start/stop of

Rhythms by pressing the pedal, instead of pressing the buttons. If you press the pedal when the Rhythm is stopped, the Rhythm begins from the intro (the same result as the [Chord] button being pressed). If you press the pedal when the Rhythm is playing, the ending is played and the Rhythm stops (the same result as the [Drums] button being pressed). You cannot start only the Drum Part, or stop only the Chord Part by pressing the pedal. (See p. 26.)

3. Press the [Song] button.

The indicators return to their previous state.

* Use only the specified expression pedal (EV-5; sold separately).

By connecting any other expression pedal, you risk causing malfunction and/or damage to the unit.

* Be sure to switch off the power to the unit before attempting to

disconnect or connect a pedal cord.

1. Hold down the [Song] button and press the

[E.Piano] button.

The indicators for the [Song] and [E.Piano] buttons flash in red.

Page 39

Chapter 4 Other Functions

Changing How the Pedal Effects Are Applied

When the pedal is pressed in Dual Play (p. 15) or Split Play (p. 16), the pedal’s effect is applied to both the Upper Tone and the Lower Tone, but you can change the settings for the tone to which the effect is applied.

When the instrument is turned on, the setting determining how the effects are applied is the same for both the Upper Tone and the Lower Tone (“1” in the table below).

1. Hold down the [Song] button and press the

[Organ] button.

The indicators for the [Song] and [Organ] buttons flash in red.

fig.04-03

Flashes in redFlashes in red

Changing the Pitch of the Lower Tone in Octave Steps (Octave Shift)

You can change the pitch of the Lower Tone in Dual Play (p. 15) and Split Play (p. 16) an octave at a time.

Altering the pitch in one-octave units in this way is called “Octave Shift.”

For example, you can raise the pitch of the Lower Tone to the same pitch of the Upper Tone in Split Play.

The range of available pitch change spans from two octaves higher to two octaves lower.

This setting remains in effect until you turn off the power.

1. Hold down the [Song] button and press the

[Piano] button.

The indicators for the [Song] and [Piano] buttons flash in red.

fig.04-04

2. Press the [-] or [+] button to select how the pedal

effects are to be applied.

Indica-

tion

1 All enabled

* Right pedal—connect to the [Damper] jack * Left pedal—connect to the [Soft] jack

Description Lower

Tone

❍❍Right Pedal ❍❍Left Pedal

Applied only to the Upper Tone

Left pedal enabled for Lower T one only

x ❍ Right Pedal

x ❍ Left Pedal

❍❍Right Pedal

❍ x Left Pedal

Upper

Tone

Pedal

3. Press the [Song] button.

The indicators return to their previous state.

Flashes in redFlashes in red

2. Press the [-] or [+] button to select the pitch.

The pitch is lowered one octave each time the [-] button is pressed, while each press of the [+] button raises the pitch by one octave.

To return to the original pitch, press the [-] and [+] buttons simultaneously.

3. Press the [Song] button.

The indicators return to their previous state.

Page 40

Chapter 4 Other Functions

Tuning to Other Instruments’ Pitches (Master Tuning)

When playing ensemble with other instruments and in other such instances, you can match the standard pitch to another instrument.

The standard pitch generally refers to the pitch of the note that’s played when you finger the middle A key. For a cleaner ensemble sound while performing with one or more other instruments, ensure that each instrument’s basic pitch is in tune with that of the other instruments. This tuning of all the instruments to a standard pitch is called “master tuning.”

You can set the standard pitch anywhere in a range of 415.3 Hz to 466.2 Hz.

When the instrument is turned on, the standard pitch is set to “440.0 Hz.”

This setting remains in effect until you turn off the power.

1. Hold down the [Song] button and press the

[Voice/Winds] button.

The indicators for the [Song] and [Voice/Winds] buttons flash in red.

fig.04-05

Flashes in redFlashes in red

The last three digits of the current standard pitch setting appear in the display.

2. Press the [-] or [+] button to change the standard

pitch.

The pitch is lowered 0.1 Hz each time the [-] button is pressed. When the button is held down, the pitch drops continuously.

The pitch is raised 0.1 Hz each time the [+] button is pressed. When the button is held down, the pitch rises continuously.

To return to the original pitch, press the [-] and [+] buttons simultaneously.

3. Press the [Song] button.

The indicators return to their previous state.

Adjusting the Tuning

You can play classical music such as baroque pieces using their original tuning.

Most modern songs are composed and played with the assumption that equal temperament (the most common tuning in use today) will be used, but when classical music was composed, there were a wide variety of other tuning systems in existence. Playing a composition with its original tuning lets you enjoy the sonorities of the chords that the composer originally intended.

1. Hold down the [Song] button and press the

[Chorus] button.

The indicators for the [Song] and [Chorus] buttons flash in red.

fig.04-06

Flashes in redFlashes in red

Temperament Tonic

2. Press the [-] or [+] button to change the

temperament, and press the key corresponding to the keynote.

You can choose from among the seven tunings described below.

Temperament Qualities

1 Equal In this tuning, each octave is

divided into twelve equal steps. Every interval produces about the same amount of slight dissonance. This setting is in effect when you turn on the power.

2 Pythagorean This tuning, devised by the philos-

opher Pythagoras, eliminates dissonance in fourths and ﬁfths. Dissonance is produced by thirdinterval chords, but melodies are euphonious.

3 Just Major This tuning eliminates ambiguities

in the ﬁfths and thirds. It is unsuited to playing melodies and cannot be transposed, but is capable of beautiful sonorities.

Page 41

Chapter 4 Other Functions

Temperament Qualities

4 Just Minor The Just tunings differ from major

and minor keys. You can get the same effect with the minor scale as with the major scale.

5 Mean Tone This scale makes some compro-

mises in just intonation, enabling transposition to other keys.

6 Werckmeister This temperament combines the

Mean Tone and Pythagorean tunings. Performances are possible in all keys (ﬁrst technique, III).

7 Kirnberger This is an improvement of the

Mean Tone and Just tunings that provides a high degree of freedom of modulation. Performances are possible in all keys (III).

The display is as follows:

fig.Chart3

Display

Letter name

C d_ d E_ E F F G A_ A b_ b C D D E E F F G A A B B

When playing with tuning other than equal temperament, you need to specify the keynote for tuning the song to be performed (that is, the note that corresponds to C for a major key or to A for a minor key).

Changing the Beat Pattern

The metronome usually sounds one beat per quarter note, but you can change the beat pattern to sound, for example, one beat for every dotted quarter note.

1. Hold down the [Song] button and press the

[ (Metronome)] button.

The indicators for the [Song] and [ (Metronome)] buttons flash in red.

fig.04-07

Flashes in redFlashes in red

2. Press the [-] or [+] button to change the beat

division.

Indication Description

—

(Normal)

A1 The metronome plays with a backbeat added

A2 Counting is with triplets for each beat. A3 The added sounds are shufﬂed.

2. ( )

The metronome sounds in the ordinary way.

to each beat.

Counting starts at the beginning of the measure, in intervals of dotted half-note upbeats.

If you choose an equal temperament, there’s no need to select a keynote.

3. Press the [Song] button.

The indicators buttons return to their original state.

* When performing in ensemble with other instruments, be

aware that depending on the key, there may be some shifting of the pitch. Tune the FP-3 to the fundamental pitch of the other instruments.

2 ( )

4. ( )

4 ( )

8. ( )

8 ( )

16 ( )

Counting starts at the beginning of the measure, in intervals of half-note upbeats.

Counting starts at the beginning of the measure, in intervals of dotted quarter-note upbeats.

Counting starts at the beginning of the measure, in intervals of quarter-note upbeats.

Counting starts at the beginning of the measure, in intervals of dotted eighth-note upbeats.

Counting starts at the beginning of the measure, in intervals of eighth-note upbeats.

Counting starts at the beginning of the measure, in intervals of sixteenth-note upbeats.

3. Press the [Song] button.

The indicators return to their previous state.

→ If you select “A1” with a triplet rhythm (6/8, 9/8, 12/8), the

additional sound is played in the same way as “A2.”

→ Refer to “Using the Metronome” (p. 23).

Page 42

Chapter 4 Other Functions

Connecting MIDI Devices

About MIDI

MIDI stands for “Musical Instrument Digital Interface,” and is a worldwide standard for the exchange of performance data (MIDI messages) and other information among electronic instruments and computers. The FP-3 features a MIDI connector and a computer connector to allow performance information to be exchanged with external devices. Connecting the keyboard to other devices with these connectors provides you with an even greater variety of ways to use your keyboard.

*A separate publication titled “MIDI Implementation” is also

available. It provides complete details concerning the way MIDI has been implemented on this unit. If you should require this publication (such as when you intend to carry out bytelevel programming), please contact the nearest Roland Service Center or authorized Roland distributor.

■ Connectors

fig.04-08

■ How to Enjoy MIDI

Recording Data of Performances Played on the FP-3 to a Sequencer* and Automatically Playing Recorded Performance Data on the FP-3

Connection example: Connecting to a sequencer (the Roland MT series, etc.)

fig.04-09.e

Sequencer

* The MT-80s has no MIDI

InOut

MIDI

Out connector.

)

RL (Mono

Stereo

FP-3

RL (Mono

Stereo

Line Out

)

MIDI

Damper Soft

Out In

Pedal Line In

→ When connecting a sequencer, we recommend using it with

the settings described below.

• Local Control off (p. 43)

• MIDI Out Mode 1 (p. 44) When the instrument is turned on, MIDI Out Mode is set to “1.”

Out In

MIDI

MIDI Out Connector

Sends data about what is being played on the keyboard and other performance data. Connect to the MIDI in connector on the external MIDI device.

MIDI In connector

Receives messages sent from external MIDI devices. Connect to the MIDI Out connector on the external MIDI device.

■ Making the Connections

* To prevent malfunction and/or damage to speakers or other

devices, always turn down the volume, and turn off the power on all devices before making any connections.

1. Turn the volume all the way down on the FP-3

and on the device you’re about to connect.

2. Turn off the power to the FP-3 and to the device

being connected.

3. Connect a MIDI cable (sold separately) between

the MIDI connectors on each device.

4. Switch on the power to the FP-3 and the

connected device.

5. Adjust the volume level on the FP-3 and the

connected device.

6. You should also set the MIDI settings as needed.

Make the settings for the MIDI send and receive channels (p. 43) and for Local On/Off (p. 43).

Performing on the FP-3 Using Sounds from Another Sound Module*

Connection Example: Connecting to a MIDI Sound Module

fig.04-10.e

Sound Module

MIDI OUTTHRU IN

FP-3

)

Damper Soft

→

When connecting to a MIDI sound module, we recommend

Out In

Pedal Line In

MIDI

RL (Mono

Stereo

RL (Mono

Stereo

Line Out

)

using the system with MIDI Out Mode set to “2” (p. 44). When the instrument is turned on, MIDI Out Mode is set to “1.”

What is a Sequencer?

A sequencer is a device that records the stream of MIDI messages that is sent out by an instrument. These messages convey all the details of what has occurred while the instrument is played; including the timing of notes, their sound, the force used to play them, and for how long. Afterwards, you can send the recorded MIDI information back to the instrument, and it will play automatically.

What is a MIDI Sound Module?

Inside a synthesizer or electronic piano is the section that actually produces sound, known as the sound module. A MIDI sound module produces sounds as the result of MIDI messages sent to it by other devices.

Page 43

Chapter 4 Other Functions

■ MIDI Settings

MIDI Send Channel Settings

MIDI features sixteen MIDI channels, numbered 1–16. Simply connecting a cable is not enough for communication to take place. The connected devices must be set to use the same MIDI channels. Otherwise, no sound will be produced, and no sounds can be selected. Select the transmission channel (1–16) of the FP-3. When the instrument is turned on, this is set to Channel “1.” The FP-3 receives messages on all channels, 1–16.

* When the keyboard is split into left and right sides, the

transmission channel for messages from the left-hand side is fixed at “3.”

* When a Drum Set Tone is assigned to the keyboard, the

transmission channel is fixed at “10.”

1. Hold down the [Song] button and press the

[Guitar/Bass] button.

The indicators for the [Song] and [Guitar/Bass] buttons flash in red.

fig.04-11

Local Control ON: The keyboard and the internal sound generator are in a linked state.

fig.04-13.e

Sound is emitted

Sound Generator

Local On

Local Control OFF: The keyboard and the internal sound generator are in an unlinked state. No sound will be produced by the keyboard when it is played.

fig.04-14.e

No sound produced

Sound Generator

Local Off

Flashes in redFlashes in red

2. Press the [-] or [+] button to select the

transmission channel.

3. Press the [Song] button.

The indicators return to their previous state.

Switching Local Control On and Off

When connecting a MIDI sequencer, set Local Control to “Off.” When the instrument is turned on, this is set to “On.” As illustrated, information describing what has been played

on the keyboard is passed to the internal sound generator over two different routes, (1) and (2). As a result, you hear overlapping or intermittent sounds. To prevent this from happening, route (1) must be severed, by setting the unit to what is known as “Local Off.”

fig.04-12.e

Local On

(1)

Sequencer

MIDI

Sound

Generator

MIDI

MIDI OUT

OUT

MIDI

Memory

* When connecting a unit in the Roland MT series, you don’t

need to switch off Local Control. MT units transmit Local Off messages when their power is switched on. If you first switch on the FP-3, then the MT-series device, Local Control is automatically switched off on the FP-3.

1. Hold down the [Song] button and press the

[Tempo/Rhythm] button.

The indicators for the [Song] and [Tempo/Rhythm] buttons flash in red.

fig.04-15

Flashes in redFlashes in red

2. Press the [-] or [+] button to switch Local Control

on and off.

3. Press the [Song] button.

The indicators return to their previous state.

Each note played is sounded twice

Thru function On

(2)

Page 44

Chapter 4 Other Functions

Setting the MIDI Out Mode

By setting the MIDI Out Mode, you can select to have a more suitable (to the external MIDI device) selection of MIDI data be output from the MIDI Out connector when you make tone changes on the FP-3.

Three settings for the MIDI Out Mode are available. “MIDI Out Mode 1” is the power-up default setting.

MIDI

Out

Mode

1 MIDI

Out Mode 1

This setting is suitable for the connection of sequencers. The MIDI information shown below is output from the MIDI Out connector when you make a tone change on the FP-3. When recording something on a sequencer , this mode should assure that when you play back the performance on the FP-3, you will hear the same tones used when the performance was recorded.

• Program Change

• Reverb or chorus effect on/off

• Reverb or chorus effect depth

• Sympathetic resonance depth

Descriptions

3. Press the [Song] button.

The indicators return to their previous state.

2 MIDI

Out Mode 2

3 MIDI

Out Mode 3

This setting is suited for connecting to a sound module. The MIDI information on tone and effect is not output from the MIDI Out connector when you make a tone change on the FP-3.

You can transmit performance data recorded with the FP-3. Additionally, the MIDI messages that are output have the same content as those in MIDI Out Mode 1.

1. Hold down the [Song] button and press the

[Strings/Pad] button.

The indicators for the [Song] and [Strings/Pad] buttons flash in red.

fig.04-17

Flashes in redFlashes in red

2. Press the [-] or [+] button to select the MIDI Out

Mode.

Page 45

Troubleshooting

If you think there’s a problem, read this first.

Case Cause/What to do

No Power Is the power cord properly connected? (p. 8)

No Sound

No Sound (With a MIDI Device Connected)

No Sound, Even When Key is Pressed

The Volume of the Keyboard is Too Low

No Sound From the Left Side

Two Sounds are Produced When the Keyboard is Played

Not All Sounds Are Played

The Keyboard or Song Register or Pitch is Off

Rhythm Does Not Sound

Is the volume level of the FP-3 (p. 11) or connected device turned all the way down?

Is the power to all devices turned on? (p. 10)

Is the MIDI cable connected and plugged in correctly? (p. 42)

Does the MIDI channel match the connected instrument? (p. 43)

Is Local Off selected? When Local Control is set to OFF, no sound is produced by playing the keyboard. Set Local Control to “ON” (p. 43).

Is the volume balance for the keyboard turned all the way down? (p. 32)

Is the [Split] button’s indicator on? (p. 31) No sound from the left side is produced if the [Split] button’s indicator is on while the Chord part is playing.

Is the FP-3 in Dual Play? (p. 15)

When the FP-3 is connected to an external sequencer, set it to the Local OFF mode (p.

43). Alternatively, set SOFT THRU on the sequencer to “OFF.”

The FP-3 has a maximum polyphony of 64 voices. When playing together with a song or Rhythm along with heavy use of the damper pedal, the performance data may exceed the number of available voices, and as a result, some notes or sounds played on the keyboard may not sound.

Have you set Transpose? (p. 22)

Are the settings for the Temperament (p. 40) correct?

Is the setting for Master Tuning correct? (p. 40)

Is the volume balance for the Rhythm turned all the way down? (p. 32)

Case Cause/What to do

Is the [Song] button indicator lit in green? (p. 12) Songs cannot be played back when the [Song] button’s indicator is on. Press the [Song] but-

Song Doesn’t Play Back

The Volume of Internal Song is Too Low

Only the Sound of a Particular Instrument in a Song Does Not Play

Cannot Select Tone or Rhythm

Cannot Record

Tempo of Recorded Song or Metronome is Off

ton, getting its indicator to light.

Does “dEL” appear in the display? (p. 13) The internal songs cannot be played back while recorded performance data remains in the FP-3’s memory . Try playing back the song after deleting the performance data.

Is the volume balance for the Rhythm (and internal song) turned all the way down? (p. 32)

Is Track Mute on? (p. 13) If the button’s light is out when you hold down the [Play] button, the music on that track is not heard. Press the track button so the light is illuminated.

Is the [Song] button indicator ﬂashing in red? When the [Song] button indicator ﬂashes in red it means that setting of functions is in progress. Press the [Song] button once more, then select the tone or Rhythm.

Have you selected which of the T rack Buttons to be recorded? (p. 36)

When you select for recording an internal song that features tempo changes, the tempos of Performances recorded on other tracks are altered along with these changes. In addition, the Metronome tempo is also changed the same way.

When you record additional material without erasing the previously recorded sounds, the song is recorded at the initially recorded tempo. (

Performances that have been recorded are

Recorded Performance is Erased

erased when the power for the FP-3 is turned off or when a song is selected. Once erased, Performances cannot be recovered.

p. 37)

Chords Not Recognized in the Left Side When Playing Rhythms

Is the [Split] button’s indicator off (p. 31) When the [Split] button’s indicator is off while the Chord part is playing, the chord progression then proceeds automatically.

Page 46

Troubleshooting

Case Cause/What to do

Is the pedal connected correctly? Connect the pedal securely to the Pedal jack (p. 10).

Pedal Has No Effect, or Effect “Sticks”

Reverb Remains Even After Reverb is Lifted

Sound Suddenly Changes at Key in Upper Octaves

Unplugging a pedal cord from the unit while the power is on may cause the pedal’s effect to be applied nonstop. Be sure to switch off the power to the unit before attempting to disconnect or connect a pedal cord (p. 10).

As the FP-3 piano sounds faithfully reproduce the depth and reverberation of actual acoustic pianos, reverberation may still be audible even after the reverb effect is removed from sounds.

With the acoustic piano settings, sounds in the upper 1 1/2-octave range are extended to the end regardless of the damper pedal actions. The tone is also different in this range. Roland’s pianos faithfully reproduce the sonic qualities of acoustic pianos. Furthermore, you can use the instrument’s Key Transpose setting to change that range over which the damper pedal has no effect.

Case Cause/What to do

When listening through speakers: Playing at loud volumes may cause instruments near the FP-3 to resonate. Resonation can also occur with ﬂuorescent light tubes, glass doors, and other objects. In particular, this problem occurs more easily when the bass component is increased, and when the sound is played at higher volumes. Use the

Low End Sounds Are Strange/Have a Rattling Sound

The Volume Lev el of the Instrument Connected to Line In Jack is Too Low.

following measures to suppress such resonance.

- Place speakers so they are 10–15 cm from walls and other surfaces.

- Reduce the volume.

- Move the speakers away from any resonating objects. When listening through headphones: The cause lies somewhere else. Consult your Roland dealer or nearest Roland Service Center.

Could you be using a connection cable that contains a resistor? Use a connection cable that does not contain a resistor.

High-Pitched Whine is Produced

When listening through headphones: Certain piano tones that feature vibrant, sparking sounds contain a large high-frequency component, which may make it appear that a metallic reverberation has been applied. This faithfully reproduces the characteristics of acoustic pianos, and does not indicate any malfunction. Since this reverberation becomes particularly audible when supplemented by heavy reverb, you may be able to diminish the problem by reducing the amount of reverb applied to the sound. When listening through speakers: Here, a different cause (such as resonance produced by the FP-3) would be suspect. Consult your Roland dealer or nearest Roland Service Center.

Page 47

Error Messages/Other Messages

Display Meaning

USr User. Stores recorded Performances. (p. 12, p. 33)

Usr.

d. Demo song number. (p. 12, p. 36) P. Piano song number. (p. 12, p. 36) r. Rhythm number. (p. 28)

dEL

E.32

E.40

E.41

E.51

The “.” in the display indicates that there is Performance material already recorded. (p. 12, p. 33)

This appears when you attempt to delete a recorded song (p. 37). Additionally, this appears after recording a song when you try to select another song (p. 13).

The amount of performance information is too large, and further recording is not possible.

Too much MIDI data was sent from the external MIDI instrument at one time, and the unit could not process the data. Reduce the amount of MIDI data being sent to the FP-3.

A problem such as a loose MIDI cable or computer cable occurred. Make sure the MIDI cables and computer cables are correctly hooked up.

A system error has occurred. Try performing the procedure over again. Should this message continue to appear even after repeated attempts, please consult the nearest Roland Service Center.

* Error messages are indicated by an “E.” before the number

When the Error message appears, the [-] and [+] button indicators flashes in red. Press the [-] or [+] button, and you can cancel the error message.

Page 48

Tone List

→ “Performing with a Variety of Sounds” (p. 14)

Piano

1 Grand Piano 1* 2 Grand Piano 2* 3 Rock Piano 4 Honky-tonk 5 Upright Piano* 6 Harpsichord

* indicates a tone with sympathetic resonance (p. 38).

E.Piano

1 Stage Rhodes 2 Dyno Rhodes 3 E.Piano 4 Suitcase 5 Wurly 6 Clavi 7 Vibraphone 8 Vibra Bell

Organ

1 Jazz Organ* 2 Rock Organ 3 Full Organ* 4 Lower Organ* 5 Church Organ 6 Nason Flute 8’

* indicates a tone with rotary effect (p. 20).

Guitar/Bass

1 Acoustic Guitar 2 Jazz Guitar 3 Acoustic Bass 4 Acoustic Bass + Cymbal 5 Fingered Bass 6 Thum Voice

Strings/Pad

1 Slow Strings 2 Strings 3 Warm JP Strings 4 Holy Voice 5 Sugar Key 6 Harp

Voice/Winds

1 Jazz Scat 2 Rich Choir 3 Dreamy Choir 4 Alto Sax 5 Flute 6 Trumpet 7 Pop Drum Set 8 Vox Drum Set

Pop Drum Set Vox Drum Set

21 23 24 26 28 29 31 33 35 36 38 40 41 43 45 47 48 50 52 53 55 57 59 60 62 64 65 67 69 71 72 74 76 77 79 81 83 84 86 88 89 91 93 95 96 98

100 101

103

105

R&B Snare

Rock Snare Rock Snare Pop Snare m Pop Snare Ghost

Pop Snare m

Finger Snap 707 Claps Hand Clap [EXC7]

Hand Clap2 [EXC7] Hand Clap

Pop Pedal HH [EXC1] Hand Clap

Pop Snare Ghost Pop Kick Pop Kick Pop Side Stick

Pop Sanre s

Pop Snare Ghost Pop Snare s Pop Low Tom f

Pop CHH 1 [EXC1] Pop Low Tom

Pop CHH 2 [EXC1] Pop Mid Tom f

Pop OHH [EXC1] Pop Mid Tom Pop High Tom f Pop Crash Cymbal 1

Pop High Tom

Pop Ride Cymbal 1 Pop Chinees Cymbal Pop Ride Bell

Tambourine 2 Splash Cymbal

Cha Cha Cowbell Pop Crash Cymbal 2

Vibra-slap 2 Pop Ride Cymbal 2 High Bongo 2 Low Bongo 2

Mute Conga

High Conga 2 Low Conga 2 High Timbale 2

Low Timbale 2 High Agogo

Low Agogo Shaker 3

Shaker 4 Short Hi Whistle [EXC2] Long Low Whistle [EXC2] Short Guiro [EXC3]

Long Guiro [EXC3]

Claves High Wood Block Low Wood Block

Mute Cuica [EXC4] Open Cuica [EXC4]

Mute Triangle [EXC5] Open Triangle [EXC5]

Shaker Jingle Bell Bar Chime Castanets

Mute Surdo [EXC6]

Open Surdo [EXC6]

----Falamenco Hi-Timbale

Falamenco Lo-Timbale Falamenco Tmbl Flam

Shekere 1 Shekere 2

Low Bongo Mute

-----

----- Falamenco HC Falamenco HC

102

Bongo Cowbell

-----

104

Bongo Cowbell

-----

* ---: No sound. * [EXC]: will not sound simultaneously with other percussion instruments of the same number.

R&B Snare Rock Snare Rock Snare Pop Snare m Pop Snare Ghost Pop Snare m Finger Snap 707 Claps Hand Clap [EXC7] Hand Clap2 [EXC7] Hand Clap Pop Pedal HH Hand Clap Vox Dut Vox Dom Vox Tuush Vox Hehho Vox Doyear Vox Thu! Vox That Vox Aahhh Vox Tu Vox Dooh Vox Ptu Vox Down Vox Pa Vox Bom Vox Toear Vox Aahhu Vox Toya Vox Thu Vox Cheey Vox Cymm Vox Tub Vox Pruru Vox Tut Vox Tyun Vox Tdum Vox Afahhhh High Bongo 2 Low Bongo 2 Mute Conga High Conga 2 Low Conga 2 High Timbale 2 Low Timbale 2 High Agogo Low Agogo Shaker 3 Shaker 4 Short Hi Whistle [EXC2] Long Low Whistle [EXC2] Short Guiro [EXC3] Long Guiro [EXC3] Claves High Wood Block Low Wood Block Mute Cuica [EXC4] Open Cuica [EXC4] Mute Triangle [EXC5] Open Triangle [EXC5] Shaker Jingle Bell Bar Chime Castanets Mute Surdo [EXC6] Open Surdo [EXC6]

----Falamenco Hi-Timbale Falamenco Lo-Timbale Falamenco Tmbl Flam Shekere 1 Shekere 2 Low Bongo Mute

-----

----- Falamenco HC Falamenco HC Bongo Cowbell

----- Bongo Cowbell

-----

Page 49

Rhythm List

→ “Selecting a Rhythm” (p. 28)

No. Genre Name

Recommended

Beat

Tempo

r01 Pop Cutting Guitar 1 90 ~ 120 4/4

r02 Pop Cutting Guitar 2 90 ~ 120 4/4

r03 Pop EP Pop 1 80 ~ 110 4/4

r04 Pop EP Pop 2 80 ~ 110 4/4

r05 Pop Acoustic Pop 1 80 ~ 110 4/4

r06 Pop Acoustic Pop 2 80 ~ 110 4/4

r07 Pop Piano Pop 1 85 ~ 115 4/4

r08 Pop Piano Pop 2 85 ~ 115 4/4

r09 Latin Bossa Nova 1 110 ~ 140 4/4

r10 Latin Bossa Nova 2 110 ~ 140 4/4

r11 Ballad Ballad 1 70 ~ 100 4/4

r12 Ballad Ballad 2 70 ~ 100 4/4

No. Genre Name

Recommended

Beat

Tempo

r31 Pop Funk Pop 1 90 ~ 120 4/4

r32 Pop Funk Pop 2 90 ~ 120 4/4

r33 Pop Funk Pop 3 90 ~ 120 4/4

r34 Pop Funk Pop 4 90 ~ 120 4/4

r35 Pop Hip Hop 1 80 ~ 110 4/4

r36 Pop Hip Hop 2 80 ~ 110 4/4

r37 Pop Easy Pop 1 100 ~ 130 4/4

r38 Pop Easy Pop 2 100 ~ 130 4/4

r39 Pop Cutting Guitar 3 90 ~ 120 4/4

r40 Pop Cutting Guitar 4 90 ~ 120 4/4

r41 Pop Fusion 1 85 ~ 115 4/4

r42 Pop Fusion 2 85 ~ 115 4/4

r13 Jazz Scat Swing 1 100 ~ 130 4/4

r14 Jazz Scat Swing 2 100 ~ 130 4/4

r15 Pop Country Pop 1 85 ~ 115 4/4

r16 Pop Country Pop 2 85 ~ 115 4/4

r17 Pop EP Pop 3 80 ~ 110 4/4

r18 Pop EP Pop 4 80 ~ 110 4/4

r19 Shufﬂe Shufﬂe 1 110 ~ 140 4/4

r20 Shufﬂe Shufﬂe 2 110 ~ 140 4/4

r21 Shufﬂe Shufﬂe 3 130 ~ 160 4/4

r22 Shufﬂe Shufﬂe 4 130 ~ 160 4/4

r23 Jazz Jazz 1 110 ~ 140 4/4

r24 Jazz Jazz 2 110 ~ 140 4/4

r25 Jazz Jazz 3 100 ~ 130 4/4

r26 Jazz Jazz 4 100 ~ 130 4/4

r43 Pop Contemporary 1 85 ~ 115 4/4

r44 Pop Contemporary 2 85 ~ 115 4/4

r45 Ballad Piano Ballad 1 50 ~ 80 4/4

r46 Ballad Piano Ballad 2 50 ~ 80 4/4

r47 Ballad Piano Ballad 3 75 ~ 105 4/4

r48 Ballad Piano Ballad 4 75 ~ 105 4/4

r49 Waltz Jazz Waltz 1 90 ~ 120 3/4

r50 Waltz Jazz Waltz 2 90 ~ 120 3/4

r51 Waltz Piano Waltz 1 85 ~ 115 3/4

r52 Waltz Piano Waltz 2 85 ~ 115 3/4

r53 Rock Gospel Shout 1 125 ~ 155 4/4

r54 Rock Gospel Shout 2 125 ~ 155 4/4

r55 Blues Boogie 1 145 ~ 175 4/4

r56 Blues Boogie 2 145 ~ 175 4/4

r27 Latin Beguine 1 90 ~ 120 4/4

r28 Latin Beguine 2 90 ~ 120 4/4

r29 Latin Mambo 1 90 ~ 120 4/4

r30 Latin Mambo 2 90 ~ 120 4/4

r57 Blues Blues 1 60 ~ 90 4/4

r58 Blues Blues 2 60 ~ 90 4/4

r59 Rock Rock 1 110 ~ 140 4/4

r60 Rock Rock 2 110 ~ 140 4/4

Page 50

Chord Progression Pattern List

→ “Selecting a Rhythm’s Chord Progression” (p. 30)

Recommended Rhythm Genre: All

Pattern 1

Recommended Rhythm Genre: All

Pattern 2

Recommended Rhythm Genre: Jazz

Pattern 3

Recommended Rhythm Genre: Pop, Ballad

C Am Dm7 G7

I VIm IIm7 V7

Am G F E7

Im VII VI V7

CM7 Am7 Dm7 G7

I M7 VIm7 IIm7 V7

Dm7 G7 CM7 Am7

IIm7 V7 I M7 VIm7

Pattern 4

Dm7 G7 CM7 A7

IIm7 V7 I M7 VI7

Recommended Rhythm Genre: Pop

C Bm7 Em7 Am

I VIIm7 IIIm7 VIm

Pattern 5

FGCsus4 C

IV V I sus4 I

Recommended Rhythm Genre: Ballad, Jazz

Dm7 G7 CM7 FM7

IVm7 VII7 III M7 VIM7

Pattern 6

Bm7 5 E7 Am7 A7

IIm7 5 V7 I m7 I 7

Page 51

Recommended Rhythm Genre: Blues, Rock, Pop

C7 F7 C7

I 7 IV7 I 7

Chord Progression Pattern List

Pattern 7

IV7 I 7

G7 F7 C7 G7

F7 C7

V7 IV7 I 7 V7

Recommended Rhythm Genre: Jazz

CM7 Cdim

I M7 I dim

Dm9 CM7

IIm9 I M7

Pattern 8

CM7 Cdim

I M7 I dim

Dm9 G7 CM7

IIm9 V7 I M7

G7 Dm9

V7 IIm9

Recommended Rhythm Genre: Latin, Pop

C Am7

I VIm7

Pattern 9

Dm7 G7sus4

IIm7 V7sus4

Page 52

Chord Fingering List

● symbol: indicates the constituent notes of chords. ★ symbol: Chords shown with an “★” can be played by pressing just the key marked with the “★”.

→ “Performing With the Chord Progression Specified in the Left Hand (Rhythm Split Play)” (p. 31)

CC#DE EF

CM7 C#M7 DM7 E M7 EM7 FM7

C7 C#7 D7 E 7 E7 F7

Cm C#m Dm E m Em Fm

Cm7 C#m7 Dm7 E m7 Em7 Fm7

Cdim C#dim Ddim E dim Edim Fdim

Cm7 ( 5 )

Caug C#aug Daug E aug Eaug Faug

Csus4 C#sus4 Dsus4 E sus4 Esus4 Fsus4

C7sus4 C#7sus4 D7sus4 E 7sus4 E7sus4 F7sus4

C6 C#6 D6 E 6 E6

Dm7 ( 5 ) Em7 ( 5 )

Fm7 ( 5 )E m7 ( 5 )C#m7 ( 5 )

Cm6 Dm6 Em6

C#m6 E m6

Fm6

Page 53

Chord Fingering List

F# G A A B B

F#M7 GM7 A M7 AM7 B M7 BM7

F#7 G7 A 7 A7 B 7 B7

F#m Gm A m Am B m Bm

F#m7 Gm7 A m7 Am7 B m7 Bm7

F#dim Gdim A dim Adim B dim Bdim

Gm7 ( 5 ) Am7 ( 5 ) Bm7 ( 5 )

F#aug Gaug A aug Aaug B aug Baug

F#sus4 Gsus4 A sus4 Asus4 B sus4 Bsus4

F#7sus4 G7sus4 A 7sus4 A7sus4 B 7sus4 B7sus4

F#6

A6A 6 B6

B m7 ( 5 )A m7 ( 5 )F#m7 ( 5 )

B 6

F#m6

Gm6

B m6Am6A m6

Bm6

Page 54

Internal Song List

→ “Listening to Internal Songs” (p. 12)

Song

Song Title Composer Copyright

No.

d. 1 Jobs For The Boys J. Maul © 2000 John Maul d. 2 Howz It Feel? S. Wilkie © 2000 Scott Wilkie (ASCAP) d. 3 Bop on the Rock J. Maul © 1992 Roland Corporation d. 4 Yesterday’s Dream J. Maul © 1992 Roland Corporation P. 1 Arabesque No. 1 in E-Major C. Debussy © 1994 Roland Corporation P. 2 Gymnopedie No. 1 E. Satie © 1997 Roland Corporation P. 3 Golliwog’s Cakewalk C. Debussy © 1996 Roland Corporation P. 4 Je Te Veux E. Satie © 1997 Roland Corporation P. 5 “Clair de lune” from “Suite Bergamasque” C. Debussy © 1990 Roland Corporation P. 6 “Passepied” from “Suite Bergamasque” C. Debussy © 1998 Roland Corporation P. 7 Nocturne No. 2 in E-ﬂat Major, Op. 9-2 F. Chopin © 1993 Roland Corporation P. 8 “Troika Drive: November” from “The Seasons,” Op. 37 P. Tchaikovsky © 1996 Roland Corporation P. 9 Polonaise No. 6 in A-ﬂat Major “Héroïque,” Op. 53 (Excerpt) F. Chopin © 1994 Roland Corporation P.10 Piano Sonata No. 14 in C-sharp Minor, “Moonlight” 1st Movement L. v. Beethoven © 1998 Roland Corporation P.11 Rhapsody No. 2, Op. 79 J. Brahms © 1998 Roland Corporation P.12 Nocturne No. 5 in F-sharp Major, Op. 15-2 F. Chopin © 1990 Roland Corporation P.13 Mazurka No.5 in B-ﬂat Major, Op. 7-1 F. Chopin © 1995 Roland Corporation P.14 “Doctor Gradus Ad Parnassum” from Suite “Children’s Corner” C. Debussy © 1995 Roland Corporation P.15 Turkish March, Op.113 L. v. Beethoven © 1996 Roland Corporation P.16 Etude Op. 25-1 in A-ﬂat Major “The Shepherd Boy” F. Chopin © 1995 Roland Corporation P.17 Etude No. 5 in G-ﬂat Major “Black Keys,” Op. 10-5 F. Chopin © 1990 Roland Corporation P. 18 Fantasie-Impromptu Op.66 F. Chopin © 1994 Roland Corporation P.19 Valse No. 1 in E-ﬂat Major, Op. 18 “Grand Valse Brillante” F. Chopin © 1998 Roland Corporation P.20 Valse No. 6 in D-ﬂat Major, Op. 64-1 “Petit Chien” F. Chopin © 1990 Roland Corporation P.21 Valse No. 2 in A-ﬂat Major, Op.34-1 “Valse Brillante” F. Chopin © 1994 Roland Corporation P.22 Valse No. 7 in C-sharp Minor, Op. 64-2 F. Chopin © 1996 Roland Corporation P.23 Rondo Brillante “Aufforderung Zum Tanz” in D-ﬂat Major, Op. 65 C. M. v. Weber © 1994 Roland Corporation

P.25

P.27

Menuet in G Major, BWV. Anh. 114 from “Notebook Of Anna Magdalena Bach”

12 Variationen Über Ein Französisches Lied “Ah, Vuos Dirai-Je, Maman,” K. 265

A. Dvorák

P.28

Turkisch March (Piano Sonate No. 11 in A Major, 3rd Movement “Alla Turca”)

Page 55

Internal Song List

Song

Song Title Composer Copyright

No.

P.31 Spinnerlied Op. 14-4 A. Ellmenreich © 1994 Roland Corporation P.32 “Berceuse” from “Dolly,” Op. 56 G. Fauré © 1995 Roland Corporation P.33 3-Romances Sans Paroles No. 3, Op. 17 G. Fauré © 1996 Roland Corporation P.34 “Gavotte” from Opera “Rosine” F. Gossec © 1996 Roland Corporation P.35 “Arietta” from “Lyric Pieces, Volume 1” Op. 12-1 E. Grieg © 1996 Roland Corporation P.36 Invention No. 4 in D Minor, BWV. 775 J. S. Bach © 1998 Roland Corporation P.37 Invention No. 13 in A-Minor J. S. Bach © 1997 Roland Corporation P.38 Invention Three-Part (Sinfonia) No. 12 in A Major, BWV. 798 J. S. Bach © 1998 Roland Corporation P.39 1st Mov. from Sonatina Op. 20 No. 1 in C-Major F. Kuhlau © 1996 Roland Corporation P.40 No. 14 “La Styrienne” from “25 Easy Studies” Op. 100 F. Burgmuller © 1992 Roland Corporation P.41 Harmonious Blacksmith G. Handel © 1996 Roland Corporation P.42 La Cinquantaine G. P. Marie © 1996 Roland Corporation P.43 Blumenlied G. Lange © 1996 Roland Corporation P.44 On Wings Of Song F. Mendelssohn © 1996 Roland Corporation P.45 “Frühlingslied” from “Lieder Ohne Worte Heft 5,” Op. 62-6 F. Mendelssohn © 1996 Roland Corporation P.46 Moment musicaux No. 3, Op. 94-3 F. Schubert © 1994 Roland Corporation P.47 Military March No. 1, Op. 51-1 F. Schubert © 1998 Roland Corporation P.48 “Fröhlicher Landmann” from “Album Für Die Jugend” Op. 68 R. Schumann © 1996 Roland Corporation

P.49

“Grande Ritournelle” from “La Belle Excentrique (Fantaisie Serieuse)”

a violation of applicable laws.

* No data for the internal songs that is played will be output from MIDI OUT connector.

■ Profile

John Maul Scott Wilkie

John Maul is a musician, composer and arranger having graduated from the Royal Academy of Music in London. John’s work encompasses studio recordings and live performances including work with top UK Jazz artists. His writing credits include commercial music for BBC radio and television, as well as scoring jazz and classical works. Having been a product specialist for Roland U.K., John is now actively involved in music software composing/programming for both Roland Japan and various music publishers. Quite recently his “Musical Picture Book,” a volume of original piano music encompassing all standards of musical ability, which included the piano and orchestral accompaniment data in SMF format, was published and printed.

Scott Wilkie is a contemporary jazz recording artist, based in southern California. He has several recordings available on NaradaJazz Records, and he tours frequently with his own band. He also appears worldwide as an artist for Roland. You can ﬁnd him online at www.scottwilkie.com.

Page 56

Easy Operation List

4 5 6 7

9 10 11 12 13 14 15

2 3 4 5

No. You want to Buttons Page

Hold down the [Song] button and press the [●] button.

Volume balance between the Lower and Upper

Tone Octave Shift

Pedal works

How the pedal effects are applied

MIDI send channel settings

MIDI OutMode

[Song] + [Split] p. 18

[Song] + [Piano] p. 39

[Song] + [E.Piano] p. 38

[Song] + [Organ] p. 39

[Song] + [Guitar/Bass] p. 43

[Song] + [Strings/Pad] p. 44

Master Tuning

Local Control

Volume balance between the keyboard and

Rhythm Playing only the bass sound of the Chord Part

Metronome beat pattern

All Song Play

Erasing the recorded performance

Selecting a temperament

Specifying the keynote Key Touch

[Song] + [Voice/Winds] p. 40

[Song] + [Tempo/Rhythm] p. 43

[Song] + [Drums] p. 32

[Song] + [Chord] p. 27

[Song] + [Metronome] p. 41

[Song] + [Play] p. 12

[Song] + [Rec] p. 37

[Song] + [Chorus] + key

[Song] + [Reverb] p. 19

Hold down the [ ] button and press the [-] or [+] button.

Beat of metronome

Metronome volume

Selecting a chord progression pattern

Specifying the root of the beginning chord

[Tempo/Rhythm] + [-] [+] p. 24

[Metronome] + [-] [+] p. 24

[Chord] + [-] [+] + key

p. 40

p. 30

Depth of the Chorus effect

Depth of the Reverb effect

Damper pedal’s resonance level

[Chorus] + [-] [+] p. 20

[Reverb] + [-] [+] p. 21

[Reverb] + [Chorus] + [-] [+] p. 38

Hold down the [Split] or [Song] button and press the key.

Split Point Key Transpose

[Split] + key p. 17 [Song] + key p. 22

Page 57

MIDI Implementati on

DIGITAL PIANO Model FP-3

Basic Channel

Mode

Note Number :

Velocity

After Touch

Pitch Bend

Control Change

Function...

Default Changed

Default Messages Altered

True Voice

Note ON Note OFF

Key’s Ch’s

0, 32

10 11 64 66 67 91 93

MIDI Implementation Chart

Transmitted Recognized Remarks

1 1

Mode 3 x

**************

15–113

**************

O x 8n v=64

x x

x O

x O O O O O O

–16

*3 *3

1–16 1–16

Mode 3 Mode 3, 4(M=1)

0–127 0–127

O x

O O

O O O O O O O (Reverb) O (Chorus)

*1 *1

*1 *1 *1 *1 *1 *1 *1 *1 *1

Date : Oct. 1, 2000

Version : 1.00

* 2

Bank select Volume Panpot Expression Hold 1 Sostenuto Soft Effect1 depth Effect3 depth

Prog Change

: True Number

System Exclusive

System Common

System Real Time

Aux Message

: Song Pos : Song Sel : Tune

: Clock : Commands

: All sound off :

Reset all controllers : Local Control : All Notes OFF : Active Sense : Reset

Notes

Mode 1 : OMNI ON, POLY Mode 3 : OMNI OFF, POLY

O 0–37, 63

**************

O x

x x

O x

x x x x O x

O 0–37, 63

O x

x x

O (120, 126, 127) O O O (123–125) O x

Program number 1–38, 64

* 1 O x is selectable by SysEx. * 2 Recognized as M=1 even if M=1. * 3 Not transmitted when MIDI Out Mode (p. 44) is set to “2.”

Mode 2 : OMNI ON, MONO Mode 4 : OMNI OFF, MONO

O : Yes X : No

Page 58

Main Specifications

88 keys (Progressive Hammer Action Keyboard)

Touch Sensitivity

Light/Normal/Heavy/Fixed

Keyboard Mode

Whole Dual Split (adjustable split point)

Max.Polyphony

64 voices

Tones

6 groups 40 variations (including 2 drum sets)

Effects

Reverb (10 levels) Chorus (10 levels) Sympathetic Resonance (10 levels, for some Pianos only) Rotary (for some Organs only)

Transpose

-6 to +5 (semitone steps)

Temperament

7 types, selectable tonic

Master Tuning

415.3 Hz to 466.2 Hz (0.1 Hz Step)

Display

7-segment, 3-digit LED

Connectors

Line Out jacks (L/Mono, R) Line In jacks (L/Mono, R) Phones jack x 2 (Stereo Mini) MIDI connectors (In/Out) Pedal jacks (Damper, Soft/Sostenuto/Expression)

Power Supply

DC 9 V

Power Consumption

1,000 mA

Dimensions

1,291 (W) x 302 (D) x 124(H) mm 50-7/8(W) x 11-15/16 (D) x 4-15/16(H) inch

Weights

18.5 kg / 40 lbs 13 oz

Accessories

Owner’s manual AC adaptor AC cord Music Stand/2 Screws for the music stand Audio cables Pedal Cover

Rhythms

60 Rhythms

Chord Progression

Automatic or input with keyboard

Metronome

Beat: 2/2,0/4,2/4,3/4,4/4,5/4, 6/4,7/4,3/8,6/8,9/8,12/8 Volume: 10 levels Pattern: 11 patterns

Tracks

3 tracks

Song

1 song

Note Storage

Approx. 30,000 notes

Tempo

Quarter note = 20 to 250

Resolution

120 ticks per quarter note

* In the interest of product improvement, the specifications and/

or appearance of this unit are subject to change without prior notice.

Page 59

Index

AC adaptor ....................................................................... 9

All Song Play .................................................................. 12

Beat .................................................................................. 24

Brilliance ......................................................................... 11

Chord .............................................................................. 52

Chord Fingering List ..................................................... 52

Chord Part ................................................................ 25, 26

Bass ............................................................................ 27

Chord progression

Automatic ................................................................. 26

Selecting pattern ...................................................... 30

Specifying the chords .............................................. 31

Chord Progression Pattern List ................................... 50

Chorus Effect ................................................................. 20

Changing the depth ................................................. 20

Connection ....................................................................... 8

Damper ........................................................................... 10

Damper Pedal .......................................................8, 10, 38

Display ............................................................................ 47

Drum Part ................................................................. 25, 26

Dual Play ........................................................................ 15

Easy Operation List ....................................................... 56

Erasing ............................................................................ 37

Expression pedal ....................................................... 8, 38

Line Out ............................................................................ 9

Local Control .................................................................. 43

Lower Tone .............................................................. 15, 16

Master Tuning ................................................................ 40

Messages ......................................................................... 47

Metronome ..................................................................... 23

Beat Pattern ............................................................... 41

Volume ...................................................................... 24

MIDI ................................................................................ 42

MIDI Device ................................................................... 42

MIDI In/Out .................................................................. 42

MIDI Out Mode ............................................................. 44

MIDI Send Channel ....................................................... 43

MIDI Sound Module ..................................................... 42

Music Stand ...................................................................... 9

Muting ............................................................................. 13

Octave Shift .................................................................... 39

Operation List ................................................................ 56

Pedal .................................................................... 10, 38, 39

Phones ............................................................................. 11

Pitch ................................................................................. 40

Playback

All Songs ................................................................... 12

Each part separately ................................................ 13

Internal song ............................................................. 12

Power .............................................................................. 10

Fill In ............................................................................... 28

Headphones ................................................................... 11

Including pedal .............................................................. 10

Internal Song .................................................................. 12

Recording....................................................................36

Internal Song List .......................................................... 54

Key Transpose ............................................................... 22

Keyboard’s Touch (Key Touch) .................................. 19

Recording ....................................................................... 33

Along with internal songs ...................................... 36

Performance using Rhythms .................................. 34

Performance using Rhythms in Split Play ........... 35

Selected Tracks ......................................................... 36

Resonance ....................................................................... 38

Reverb Effect .................................................................. 21

Changing the depth ................................................. 21

Rhythm ............................................................... 25, 26, 28

Rhythm List .................................................................... 49

Rotary Effect ................................................................... 20

Page 60

Index

Sequencer ....................................................................... 42

Session Partner .............................................................. 25

Soft ................................................................................... 10

Soft Pedal .............................................................. 8, 10, 38

Sostenuto pedal ............................................................. 38

Split Play ......................................................................... 16

Rhythm ...................................................................... 31

Split Point ....................................................................... 17

Standard pitch ............................................................... 40

Sympathetic Resonance .......................................... 10, 38

Temperament ................................................................. 40

Tempo ....................................................................... 23, 29

Tone ................................................................................. 14

Tone group ..................................................................... 14

Tone List ......................................................................... 48

Track Button

Recording ............................................................ 36, 37

Track button ................................................................... 13

Transpose ....................................................................... 22

Troubleshooting ............................................................ 45

Tuning ............................................................................. 40

Upper Tone .............................................................. 15, 16

Volume ............................................................................ 11

Metronome ............................................................... 24

Volume Balance

Keyboard and Rhythm ........................................... 32

Lower Tone and Upper Tone ................................. 18

Page 61

MEMO

Page 62

Information

When you need repair service, call your nearest Roland Service Center or authorized Roland distributor in your country as shown below.

AFRICA

EGYPT

Al Fanny Trading Office

9, EBN Hagar A1 Askalany Street, ARD E1 Golf, Heliopolis, Cairo 11341, EGYPT TEL: 20-2-417-1828

REUNION

Maison FO - YAM Marcel

25 Rue Jules Hermann, Chaudron - BP79 97 491 Ste Clotilde Cedex, REUNION ISLAND TEL: (0262) 218-429

SOUTH AFRICA

That Other Music Shop (PTY) Ltd.

11 Melle St., Braamfontein, Johannesbourg, SOUTH AFRICA

P.O.Box 32918, Braamfontein 2017 Johannesbourg, SOUTH AFRICA TEL: (011) 403 4105

Paul Bothner (PTY) Ltd.

17 Werdmuller Centre, Main Road, Claremont 7708 SOUTH AFRICA

P.O.BOX 23032, Claremont 7735, SOUTH AFRICA TEL: (021) 674 4030

ASIA

CHINA

Beijing Xinghai Musical Instruments Co., Ltd.

6 Huangmuchang Chao Yang District, Beijing, CHINA TEL: (010) 6774 7491

Shanghai Xingtong Acoustics Equipment CO.,Ltd.

5F. No.1500 Pingliang Road New East Club Plaza, Shanghai, CHINA TEL: (021) 5580-0800

HONG KONG

Tom Lee Music Co., Ltd. Service Division

22-32 Pun Shan Street, Tsuen Wan, New Territories, HONG KONG TEL: 2415 0911

INDIA

Rivera Digitec (India) Pvt. Ltd.

409, Nirman Kendra Mahalaxmi Flats Compound Off. Dr. Edwin Moses Road, Mumbai-400011, INDIA TEL: (022) 498 3079

INDONESIA

PT Citra IntiRama

J1. Cideng Timur No. 15J-150 Jakarta Pusat INDONESIA TEL: (021) 6324170

KOREA

Cosmos Corporation

1461-9, Seocho-Dong, Seocho Ku, Seoul, KOREA TEL: (02) 3486-8855

MALAYSIA

BENTLEY MUSIC SDN BHD

140 & 142, Jalan Bukit Bintang 55100 Kuala Lumpur,MALAYSIA TEL: (03) 2144-3333

PHILIPPINES

G.A. Yupangco & Co. Inc.

339 Gil J. Puyat Avenue Makati, Metro Manila 1200, PHILIPPINES TEL: (02) 899 9801

SINGAPORE

Swee Lee Company

150 Sims Drive, SINGAPORE 387381 TEL: 846-3676

CRISTOFORI MUSIC PTE LTD

Blk 3014, Bedok Industrial Park E, #02-2148, SINGAPORE 489980 TEL: 243 9555

TAIWAN

ROLAND TAIWAN ENTERPRISE CO., LTD.

Room 5, 9fl. No. 112 Chung Shan N.Road Sec.2, Taipei, TAIWAN, R.O.C. TEL: (02) 2561 3339

THAILAND

Theera Music Co. , Ltd.

330 Verng NakornKasem, Soi 2, Bangkok 10100, THAILAND TEL: (02) 2248821

VIETNAM

Saigon Music

138 Tran Quang Khai St., District 1 Ho Chi Minh City VIETNAM TEL: (08) 844-4068

AUSTRALIA/ NEW ZEALAND

AUSTRALIA

Roland Corporation Australia Pty., Ltd.

38 Campbell Avenue Dee Why West. NSW 2099 AUSTRALIA TEL: (02) 9982 8266

NEW ZEALAND

Roland Corporation Ltd.

32 Shaddock Street, Mount Eden, Auckland, NEW ZEALAND TEL: (09) 3098 715

CENTRAL/LATIN AMERICA

ARGENTINA

Instrumentos Musicales S.A.

Av.Santa Fe 2055 (1123) Buenos Aires ARGENTINA TEL: (011) 4508-2700

BRAZIL

Roland Brasil Ltda

Rua San Jose, 780 Sala B Parque Industrial San Jose Cotia - Sao Paulo - SP, BRAZIL TEL: (011) 4615 5666

COSTA RICA

JUAN Bansbach Instrumentos Musicales

Ave.1. Calle 11, Apartado 10237, San Jose, COSTA RICA TEL: 258-0211

CHILE

Comercial Fancy S.A.

Rut.: 96.919.420-1 Nataniel Cox #739, 4th Floor Santiago - Centro, CHILE TEL: (02) 688-9540

EL SALVADOR

OMNI MUSIC

75 Avenida Norte y Final Alameda Juan Pablo , Edificio No.4010 San Salvador, EL SALVADOR TEL: 262-0788

MEXICO

Casa Veerkamp, s.a. de c.v.

Av. Toluca No. 323, Col. Olivar de los Padres 01780 Mexico D.F. MEXICO TEL: 668-0480

PANAMA

SUPRO MUNDIAL, S.A.

Boulevard Andrews, Albrook, Panama City, REP. DE PANAMA TEL: 315-0101

PARAGUAY

Distribuidora De Instrumentos Musicales

J.E. Olear y ESQ. Manduvira Asuncion PARAGUAY TEL: (021) 492-124

PERU

VIDEO Broadcast S.A.

Portinari 199 (ESQ. HALS), San Borja, Lima 41, REP. OF PERU TEL: (01) 4758226

URUGUAY

Todo Musica S.A.

Francisco Acuna de Figueroa 1771 C.P.: 11.800 Montevideo, URUGUAY TEL: (02) 924-2335

VENEZUELA

Musicland Digital C.A.

Av. Francisco de Miranda, Centro Parque de Cristal, Nivel C2 Local 20 Caracas VENEZUELA TEL: (212) 285-8586

EUROPE

AUSTRIA

Roland Austria GES.M.B.H.

Siemensstrasse 4, P.O. Box 74, A-6063 RUM, AUSTRIA TEL: (0512) 26 44 260

BELGIUM/HOLLAND/ LUXEMBOURG

Roland Benelux N. V.

Houtstraat 3, B-2260, Oevel (Westerlo) BELGIUM TEL: (014) 575811

DENMARK

Roland Scandinavia A/S

Nordhavnsvej 7, Postbox 880, DK-2100 Copenhagen DENMARK TEL: (039)16 6200

FRANCE

Roland France SA

4, Rue Paul Henri SPAAK, Parc de l'Esplanade, F 77 462 St. Thibault, Lagny Cedex FRANCE TEL: 01 600 73 500

FINLAND

Roland Scandinavia As, Filial Finland

Lauttasaarentie 54 B Fin-00201 Helsinki, FINLAND TEL: (9) 682 4020

GERMANY

Roland Elektronische Musikinstrumente HmbH.

Oststrasse 96, 22844 Norderstedt, GERMANY TEL: (040) 52 60090

GREECE

STOLLAS S.A. Music Sound Light

155, New National Road Patras 26442, GREECE TEL: (061) 43-5400

HUNGARY

Intermusica Ltd.

Warehouse Area ‘DEPO’ Pf.83 H-2046 Torokbalint, HUNGARY TEL: (23) 511011

IRELAND

Roland Ireland

Audio House, Belmont Court, Donnybrook, Dublin 4. Republic of IRELAND TEL: (01) 2603501

ITALY

Roland Italy S. p. A.

Viale delle Industrie 8, 20020 Arese, Milano, ITALY TEL: (02) 937-78300

NORWAY

Roland Scandinavia Avd. Kontor Norge

Lilleakerveien 2 Postboks 95 Lilleaker N-0216 Oslo NORWAY TEL: 273 0074

POLAND

P. P. H. Brzostowicz

UL. Gibraltarska 4. PL-03664 Warszawa POLAND TEL: (022) 679 44 19

PORTUGAL

Tecnologias Musica e Audio, Roland Portugal, S.A.

Cais Das Pedras, 8/9-1 Dto 4050-465 PORTO PORTUGAL TEL: (022) 608 00 60

ROMANIA

FBS LINES

Piata Libertatii 1, RO-4200 Gheorghehi TEL: (095) 169-5043

RUSSIA

MuTek

3-Bogatyrskaya Str. 1.k.l 107 564 Moscow, RUSSIA TEL: (095) 169 5043

SPAIN

Roland Electronics de España, S. A.

Calle Bolivia 239, 08020 Barcelona, SPAIN TEL: (93) 308 1000

SWEDEN

Roland Scandinavia A/S SWEDISH SALES OFFICE

Danvik Center 28, 2 tr. S-131 30 Nacka SWEDEN TEL: (08) 702 0020

SWITZERLAND

Roland (Switzerland) AG Musitronic AG

Gerberstrasse 5, Postfach, CH-4410 Liestal, SWITZERLAND TEL: (061) 927-8383

UKRAINE

TIC-TAC

Mira Str. 19/108 P.O. Box 180 295400 Munkachevo, UKRAINE TEL: (03131) 414-40

UNITED KINGDOM

Roland (U.K.) Ltd.

Atlantic Close, Swansea Enterprise Park, SWANSEA SA7 9FJ, UNITED KINGDOM TEL: (01792) 700139

MIDDLE EAST

BAHRAIN

Moon Stores

No.16, Bab Al Bahrain Avenue, P.O.Box 247, Manama 304, State of BAHRAIN TEL: 211 005

CYPRUS

Radex Sound Equipment Ltd.

17, Diagorou Street, Nicosia, CYPRUS TEL: (02) 66-9426

IRAN

MOCO, INC.

No.41 Nike St., Dr.Shariyati Ave., Roberoye Cerahe Mirdamad Tehran, IRAN TEL: (021) 285-4169

ISRAEL

Halilit P. Greenspoon & Sons Ltd.

8 Retzif Ha'aliya Hashnya St. Tel-Aviv-Yafo ISRAEL TEL: (03) 6823666

JORDAN

AMMAN Trading Agency

245 Prince Mohammad St., Amman 1118, JORDAN TEL: (06) 464-1200

KUWAIT

Easa Husain Al-Yousifi

Abdullah Salem Street, Safat, KUWAIT TEL: 243-6399

LEBANON

A. Chahine & Fils

Gerge Zeidan St., Chahine Bldg., Achrafieh, P.O.Box: 16-5857 Beirut, LEBANON TEL: (01) 20-1441

QATAR

Al Emadi Co. (Badie Studio & Stores)

P.O. Box 62, Doha, QATAR TEL: 4423-554

SAUDI ARABIA

aDawliah Universal Electronics APL

Corniche Road, Aldossary Bldg., 1st Floor, Alkhobar, SAUDI ARABIA

P.O.Box 2154, Alkhobar 31952 SAUDI ARABIA TEL: (03) 898 2081

SYRIA

Technical Light & Sound Center

Bldg. No. 47, Khaled Ebn Al Walid St. Damascus, SYRIA TEL: (011) 221-1230

TURKEY

Barkat muzik aletleri ithalat ve ihracat Ltd Sti

Siraselviler Caddesi Siraselviler Pasaji No:74/20 Taksim - Istanbul, TURKEY TEL: (0212) 2499324

U.A.E.

Zak Electronics & Musical Instruments Co. L.L.C.

Zabeel Road, Al Sherooq Bldg., No. 14, Grand Floor, Dubai, U.A.E. TEL: (04) 3360715

NORTH AMERICA

CANADA

Roland Canada Music Ltd. (Head Office)

5480 Parkwood Way Richmond B. C., V6V 2M4 CANADA TEL: (0604) 270 6626

Roland Canada Music Ltd. (Toronto Office)

Unit 2, 109 Woodbine Downs Blvd, Etobicoke, ON M9W 6Y1 CANADA TEL: (0416) 213 9707

U. S. A.

Roland Corporation U.S.

5100 S. Eastern Avenue Los Angeles, CA 90040-2938, U. S. A. TEL: (323) 890 3700

As of January 1, 2002 (Roland)

Page 63

For EU Countries

This product complies with the requirements of European Directive 89/336/EEC.

For the USA

FEDERAL COMMUNICATIONS COMMISSION

RADIO FREQUENCY INTERFERENCE STATEMENT
