Fantom-G MIDI Implementation

❍

1. Receive Data (Sound Source Section)

■

Channel Voice Messages

* Not received when the Receive Switch parameter is OFF.

●

Note off

Status

8nH kkH vvH

9nH kkH 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

kk = note number: 00H - 7FH (0 - 127)

vv = note off velocity: 00H - 7FH (0 - 127)

* Not received when the Tone Env Mode parameter is NO-SUS.

●

Note on

Status

9nH kkH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

kk = note number: 00H - 7FH (0 - 127)

vv = note on velocity: 01H - 7FH (1 - 127)

●

Polyphonic Key Pressure

Status

AnH kkH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

kk = note number: 00H - 7FH (0 - 127)

vv = Polyphonic Key Pressure: 00H - 7FH (0 - 127)

* Not received when the Receive Poly Key Pressure parameter is OFF.

●

Control Change

* If the corresponding Controller number is selected for the Patch Matrix Control Source

1–4 parameter (Patch Mtrx Ctrl1–4), the corresponding effect will occur.

* If a Controller number that corresponds to the System Control Source 1–4 parameter is

selected, the specified effect will apply if Patch Matrix Control Source 1–4 parameter is

set to SYS-CTRL1, SYS-CTRL2, SYS-CTRL3 or SYS-CTRL4.

❍

Bank Select (Controller number 0, 32)

Status 2nd byte 3rd byte

BnH 00H mmH

BnH 20H llH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)

* Not received when the Receive Bank Select is OFF.

* The Live sets, Studio sets, Patches, Sample sets and Rhythm sets corresponding to each

Bank Select are as follows.

* The ARX series corresponding to each Bank Select are to see the ARX series owner’s

manual.

-----+-----------+-----------+----------------------+---------- 000 | | 001 - 128 | GM Patch | 001 - 256 : | | | | 063 | | 001 - 128 | GM Patch | 001 - 256 084 | 000 | 001 - 128 | User Live Set | 001 - 128 | 001 | 001 - 128 | User Live Set | 129 - 256 | 002 | 001 - 128 | User Live Set | 257 - 384 | 003 | 001 - 128 | User Live Set | 385 - 512 | 064 | 001 - 128 | Preset Live Set | 001 - 128 | : | | : | 085 | 000 | 001 - 128 | User Studio Set | 001 - 128 | 064 | 001 - 008 | Preset Studio Set | 001 - 008 086 | 000 | 001 - 064 | User Rhythm | 001 - 064 | 064 | 001 - 064 | Preset Rhythm | 001 - 064 087 | 000 | 001 - 128 | User Patch | 001 - 128 | 001 | 001 - 128 | User Patch | 129 - 256 | 002 | 001 - 128 | User Patch | 257 - 384 | 003 | 001 - 128 | User Patch | 385 - 512 | 064 | 001 - 128 | Preset Patch A | 001 - 128 | 065 | 001 - 128 | Preset Patch B | 001 - 128 | : | | : | 120 | | 001 - 057 | GM Rhythm | 001 - 009 121 | 000 - | 001 - 128 | GM Patch | 001 - 256

2nd byte 3rd byte

Modulation (Controller number 1)

Status

BnH 01H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Modulation depth: 00H - 7FH (0 - 127)

* Not received when the Receive Modulation parameter is OFF.

❍

Status

BnH 40H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON

* Not received when Tone Receive Hold-1 parameter is OFF.

* Not received when Receive Hold-1 parameter is OFF.

* When the Tone Redamper Switch parameter is turned ON, 128 discrete steps are

recognized for the value.

❍

Portamento (Controller number 65)

Status

BnH 41H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON

* The Part Portamento Switch parameter will change.

❍

Sostenuto (Controller number 66)

Status 2nd byte 3rd byte

BnH 42H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON

2nd byte 3rd byte

1

Fantom-G MIDI Implementation

❍

Status

this voice will continue sounding (i.e., legato) and will, when the next Note-on is

received, smoothly change to the pitch of that Note-on.

* The rate of the pitch change caused by Portamento Control is determined by the

Portamento Time value.

❍

Effect 1 (Reverb Send Level) (Controller number 91)

Status 2nd byte 3rd byte

BnH 5BH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Reverb Send Level: 00H - 7FH (0 - 127)

* The Part Reverb Send Level parameter will change.

❍

Effect 3 (Chorus Send Level) (Controller number 93)

Status

BnH 5DH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Chorus Send Level: 00H - 7FH (0 - 127)

* The Part Chorus Send Level parameter will change.

❍

RPN MSB/LSB (Controller number 100, 101)

Status

BnH 65H mmH BnH 64H llH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm = upper byte (MSB) of parameter number specified by RPN

ll = lower byte (LSB) of parameter number specified by RPN

2nd byte 3rd byte

❍

Vibrato Delay (Controller number 78)

Status

BnH 4EH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Vibrato Delay value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* The Part Vibrato Delay parameter will change.

2nd byte 3rd byte

2

Fantom-G MIDI Implementation

<<< RPN >>>

Control Changes include RPN (Registered Parameter Numbers), which are extended.

When using RPNs, first RPN (Controller numbers 100 and 101; they can be sent in any order)

should be sent in order to select the parameter, then

Data Entry (Controller numbers 6 and 38) should be sent to set the value. Once RPN

messages are received, Data Entry messages that is received at the same MIDI channel after

that are recognized as changing toward the value of the RPN messages. In order not to make

any mistakes, transmitting RPN Null is recommended after setting parameters you need.

This device receives the following RPNs.

RPN Data entry

MSB, LSB MSB, LSB Notes

00H, 00H mmH, llH Pitch Bend Sensitivity

* The Part Bend Range parameter will change.

00H, 01H mmH, llH Channel Fine Tuning

* The Part Fine Tune parameter will change.

00H, 02H mmH, llH Channel Coarse Tuning

* The Part Coarse Tune parameter will change.

00H, 05H mmH, llH Modulation Depth Range

7FH, 7FH ---, --- RPN null

❍

General Controller

Status 2nd byte 3rd byte

BnH kkH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

kk = Controller number: 00H - 77H (0 - 31, 33 - 95)

vv = Modulation depth: 00H - 7FH (0 - 127)

●

Program Change

Status 2nd byte

CnH ppH

n = MIDI channel number: 0H - FH (ch.1 - 16)

pp = Program number: 00H - 7FH (prog.1 - prog.128)

* Not received when the Receive Program Change parameter is OFF.

●

Channel Pressure

Status

DnH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Channel Pressure: 00H - 7FH (0 - 127)

* Not received when the Receive Channel Pressure parameter is OFF.

●

Pitch Bend Change

Status

EnH llH mmH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

* Not received when the Tone Receive Bender parameter is OFF.

* Not received when the Receive Pitch Bend parameter is OFF.

2nd byte

2nd byte 3rd byte

mm: 00H - 18H (0 - 24 semitones)

ll: ignored (processed as 00H)

Up to 2 octave can be specified in semitone steps.

mm, ll: 20 00H - 40 00H - 60 00H

(-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)

mm: 10H - 40H - 70H (-48 - 0 - +48 semitones)

ll: ignored (processed as 00H)

mm, ll: 00 00H - 06 00H

(0 - 16384*600 / 16384 cent)

RPN and NRPN will be set as “unspecified.”

Once this setting has been made, subsequent

Parameter values that were previously set will

not change.

mm, ll: ignored

■

Channel Mode Messages

* Not received when the Receive Switch parameter is OFF.

●

All Sounds Off (Controller number 120)

Status 2nd byte 3rd byte

BnH 78H 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

* When this message is received, all notes currently sounding on the corresponding

channel will be turned off.

●

Reset All Controllers (Controller number 121)

Status 2nd byte 3rd byte

BnH 79H 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

* When this message is received, the following controllers will be set to their reset values.

Controller Reset value

Pitch Bend Change +/-0 (center)

Polyphonic Key Pressure 0 (off)

Channel Pressure 0 (off)

Modulation 0 (off)

Breath Type 0 (min)

Expression 127 (max)

Hold 1 0 (off)

Sostenuto 0 (off)

Soft 0 (off)

Hold 2 0 (off)

RPN unset; previously set data will not change

NRPN unset; previously set data will not change

●

All Notes Off (Controller number 123)

Status 2nd byte 3rd byte

BnH 7BH 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

* When All Notes Off is received, all notes on the corresponding channel will be turned

off. However, if Hold 1 or Sostenuto is ON, the sound will be continued until these are

turned off.

●

OMNI OFF (Controller number 124)

Status 2nd byte 3rd byte

BnH 7CH 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

* The same processing will be carried out as when All Notes Off is received.

●

OMNI ON (Controller number 125)

Status 2nd byte 3rd byte

BnH 7DH 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

* The same processing will be carried out as when All Notes Off is received. OMNI ON

will not be turned on.

●

MONO (Controller number 126)

Status 2nd byte 3rd byte

BnH 7EH mmH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm = mono number: 00H - 10H (0 - 16)

* The same processing will be carried out as when All Notes Off is received.

* The Part Mono/Poly parameter will change.

●

POLY (Controller number 127)

Status

BnH 7FH 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

2nd byte 3rd byte

However the controller will be at minimum.

* The same processing will be carried out as when All Notes Off is received.

* The Part Mono/Poly parameter will change.

3

Fantom-G MIDI Implementation

■

System Realtime Message

●

Timing Clock

Status

F8H

Received when Sync Mode parameter is set to MIDI.

●

Active Sensing

Status

FEH

* When Active Sensing is received, the unit will begin monitoring the intervals of all

further messages. While monitoring, if the interval between messages exceeds 420 ms,

the same processing will be carried out as when All Sounds Off, All Notes Off and Reset

All Controllers are received, and message interval monitoring will be halted.

■

System Exclusive Message

Status

F0H iiH, ddH, ......,eeH F7H

F0H: System Exclusive Message status

ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer whose

dd,...,ee = data: 00H - 7FH (0 - 127)

F7H: EOX (End Of Exclusive)

Of the System Exclusive messages received by this device, the Universal Non-realtime

messages and the Universal Realtime messages and the Data Request (RQ1) messages and

the Data Set (DT1) messages will be set automatically.

●

Universal Non-realtime System Exclusive Messages

❍

Identity Request Message

Status

F0H 7EH, dev, 06H, 01H F7H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

dev Device ID (dev: 10H - 1FH, 7FH)

06H Sub ID#1 (General Information)

01H Sub ID#2 (Identity Request)

F7H EOX (End Of Exclusive)

* When this message is received, Identity Reply message (P.9) will be transmitted.

❍

GM1 System On

Status Data byte Status

F0H 7EH, 7FH, 09H, 01H F7H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

7FH Device ID (Broadcast)

09H Sub ID#1 (General MIDI Message)

01H Sub ID#2 (General MIDI 1 On)

F7H EOX (End Of Exclusive)

* When this messages is received, this instrument will turn to the Studio mode.

* Not received when the Receive GM System On parameter is OFF.

Data byte Status

Exclusive message this is. Roland’s manufacturer ID is 41H.

ID numbers 7EH and 7FH are extensions of the MIDI standard;

Universal Non-realtime Messages (7EH) and Universal Realtime

Messages (7FH).

Data byte Status

❍

GM2 System On

Status Data byte Status

F0H 7EH 7FH 09H 03H F7H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

7FH Device ID (Broadcast)

09H Sub ID#1 (General MIDI Message)

03H Sub ID#2 (General MIDI 2 On)

F7H EOX (End Of Exclusive)

* When this messages is received, this instrument will turn to the Studio mode.

* Not received when the Receive GM2 System On parameter is OFF.

❍

GM System Off

Status

F0H 7EH, 7F, 09H, 02H F7H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

7FH Device ID (Broadcast)

09H Sub ID#1 (General MIDI Message)

02H Sub ID#2 (General MIDI Off)

F7H EOX (End Of Exclusive)

* When this messages is received, this instrument will return to the Studio mode.

●

Universal Realtime System Exclusive Messages

❍

Master Volume

Status

F0H 7FH, 7FH, 04H, 01H, llH, mmH F7H

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

04H Sub ID#1 (Device Control)

01H Sub ID#2 (Master Volume)

llH Master Volume lower byte

mmH Master Volume upper byte

F7H EOX (End Of Exclusive)

* The lower byte (llH) of Master Volume will be handled as 00H.

* The Master Level parameter will change.

❍

Master Fine Tuning

Status Data byte Status

F0H 7FH, 7FH, 04H, 03H, llH, mmH F7H

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

04H Sub ID#1 (Device Control)

03H Sub ID#2 (Master Fine Tuning)

llH Master Fine Tuning LSB

mmH Master Fine Tuning MSB

F7H EOX (End Of Exclusive)

mm, ll: 00 00H - 40 00H - 7F 7FH (-100 - 0 - +99.9 [cents])

* The Master Tune parameter will change.

Data byte Status

4

Fantom-G MIDI Implementation

❍

Master Coarse Tuning

Status Data byte Status

F0H 7FH, 7FH, 04H, 04H, llH, mmH F7

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

04H Sub ID#1 (Device Control)

04H Sub ID#2 (Master Coarse Tuning)

llH Master Coarse Tuning LSB

mmH Master Coarse Tuning MSB

F7H EOX (End Of Exclusive)

llH: ignored (processed as 00H)

mmH: 28H - 40H - 58H (-24 - 0 - +24 [semitones])

* The Master Key Shift parameter will change.

●

Global Parameter Control

* Not received in Patch mode.

❍

Reverb Parameters

Status

F0H 7FH, 7FH, 04H, 05H, 01H, 01H, F7H

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

04H Sub ID#1 (Device Control)

05H Sub ID#2 (Global Parameter Control)

01H Slot path length

01H Parameter ID width

01H Value width

01H Slot path MSB

01H Slot path LSB (Effect 0101: Reverb)

ppH Parameter to be controlled.

vvH Value for the parameter.

F7H EOX (End Of Exclusive)

❍

Chorus Parameters

Status

F0H 7FH, 7FH, 04H, 05H, 01H, 01H, F7H

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

04H Sub ID#1 (Device Control)

05H Sub ID#2 (Global Parameter Control)

01H Slot path length

01H Parameter ID width

01H Value width

01H Slot path MSB

02H Slot path LSB (Effect 0102: Chorus)

ppH Parameter to be controlled.

Data byte Status

01H, 01H, 01H, ppH, vvH

pp=0 Reverb Type

vv = 00H Small Room

vv = 01H Medium Room

vv = 02H Large Room

vv = 03H Medium Hall

vv = 04H Large Hall

vv = 08H Plate

pp=1 Reverb Time

vv = 00H - 7FH 0 - 127

Data byte Status

01H, 01H, 02H, ppH, vvH

vvH Value for the parameter.

F7H EOX (End Of Exclusive)

❍

Channel Pressure

Status Data byte Status

F0H 7FH, 7FH, 09H, 01H, 0nH, ppH, rrH F7H

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

09H Sub ID#1 (Controller Destination Setting)

01H Sub ID#2 (Channel Pressure)

0nH MIDI Channel (00 - 0F)

ppH Controlled parameter

rrH Controlled range

F7H EOX (End Of Exclusive)

❍

Controller

Status

F0H 7FH, 7FH, 09H, 03H, 0nH, ccH, ppH, rrH F7H

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

09H Sub ID#1 (Controller Destination Setting)

03H Sub ID#2 (Control Change)

0nH MIDI Channel (00 - 0F)

ccH Controller number (01 - 1F, 40 - 5F)

ppH Controlled parameter

rrH Controlled range

F7H EOX (End Of Exclusive)

pp=0 Chorus Type

vv=0 Chorus1

vv=1 Chorus2

vv=2 Chorus3

vv=3 Chorus4

vv=4 FB Chorus

vv=5 Flanger

pp=1 Mod Rate

vv= 00H - 7FH 0 - 127

pp=2 Mod Depth

vv = 00H - 7FH 0 - 127

pp=3 Feedback

vv = 00H - 7FH 0 - 127

pp=4 Send To Reverb

vv = 00H - 7FH 0 - 127

pp=0 Pitch Control

rr = 28H - 58H -24 - +24 [semitones]

pp=1 Filter Cutoff Control

rr = 00H - 7FH -9600 - +9450 [cents]

pp=2 Amplitude Control

rr = 00H - 7FH 0 - 200%

pp=3 LFO Pitch Depth

rr = 00H - 7FH 0 - 600 [cents]

pp=4 LFO Filter Depth

rr = 00H - 7FH 0 - 2400 [cents]

pp=5 LFO Amplitude Depth

rr = 00H - 7FH 0 - 100%

Data byte Status

pp=0 Pitch Control

rr = 28H - 58H -24 - +24 [semitones]

pp=1 Filter Cutoff Control

rr = 00H - 7FH -9600 - +9450 [cents]

pp=2 Amplitude Control

rr = 00H - 7FH 0 - 200%

pp=3 LFO Pitch Depth

rr = 00H - 7FH 0 - 600 [cents]

pp=4 LFO Filter Depth

rr = 00H - 7FH 0 - 2400 [cents]

pp=5 LFO Amplitude Depth

rr = 00H - 7FH 0 - 100%

5

Fantom-G MIDI Implementation

❍

Scale/Octave Tuning Adjust

Status Data byte Status

F0H 7EH, 7FH, 08H, 08H, ffH, ggH, hhH, ssH... F7

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

7FH Device ID (Broadcast)

08H Sub ID#1 (MIDI Tuning Standard)

08H Sub ID#2 (scale/octave tuning 1-byte form)

ffH Channel/Option byte 1

ggH Channel byte 2

hhH Channel byte 3

ssH 12 byte tuning offset of 12 semitones from C to B

F7H EOX (End Of Exclusive)

❍

Key-based Instrument Controllers

Status

F0H 7FH, 7FH, 0AH, 01H, 0nH, kkH, nnH, vvH F7H

Byte Explanation

F0H Exclusive status

7FH ID number (universal realtime message)

7FH Device ID (Broadcast)

0AH Sub ID#1 (Key-Based Instrument Control)

01H Sub ID#2 (Controller)

0nH MIDI Channel (00 - 0FH)

kkH Key Number

nnH Control Number

vvH Value

::

F7 EOX (End Of Exclusive)

* This parameter affects drum instruments only.

●

Data Transmission

This instrument can use exclusive messages to exchange many varieties of internal settings

with other devices.

The model ID of the exclusive messages used by this instrument is 00H 27H.

❍

Data Request 1 RQ1

This message requests the other device to transmit data. The address and size indicate the

type and amount of data that is requested.

When a Data Request message is received, if the device is in a state in which it is able to

transmit data, and if the address and size are appropriate, the requested data is transmitted

as a Data Set 1 (DT1) message. If the conditions are not met, nothing is transmitted.

Status data byte status

F0H

Byte Remarks

F0H Exclusive status

41H ID number (Roland)

dev device ID (dev: 10H - 1FH, 7FH)

00H model ID #1 (Fantom-G6/G7/G8)

00H model ID #2 (Fantom-G6/G7/G8)

27H model ID #3 (Fantom-G6/G7/G8)

11H command ID (RQ1)

aaH address MSB

bbH address

bits 0 to 1 = channel 15 to 16

bit 2 to 6 = Undefined

bits 0 to 6 = channel 8 to 14

bits 0 to 6 = channel 1 to 7

00H = -64 [cents]

40H = 0 [cents] (equal temperament)

7FH = +63 [cents]

Data byte Status

nn=07H Level

vv = 00H - 7FH 0 - 200% (Relative)

nn=0AH Pan

vv = 00H - 7FH Left - Right (Absolute)

nn=5BH Reverb Send

vv = 00H - 7FH 0 - 127 (Absolute)

nn=5D Chorus Send

vv = 00H - 7FH 0 - 127 (Absolute)

41H, dev, 00H, 27H, 11H, aaH, bbH, ccH,

ddH, ssH, ttH, uuH, vvH, sum

F7H

ccH address

ddH address LSB

ssH size MSB

ttH size

uuH size

vvH size LSB

sum checksum

F7H EOX (End Of Exclusive)

* The size of data that can be transmitted at one time is fixed for each type of data. And

data requests must be made with a fixed starting address and size. Refer to the address

and size given in

* For the checksum, refer to P.45.

* Not received when the Receive Exclusive parameter is OFF.

❍

Data set 1 (DT1)

Status Data byte Status

F0H 41H, dev, 00H, 27H, 12H, aaH, bbH, F7H

Byte Explanation

F0H Exclusive status

41H ID number (Roland)

dev Device ID (dev: 00H - 1FH, 7FH)

00H model ID #1 (Fantom-G6/G7/G8)

00H model ID #2 (Fantom-G6/G7/G8)

27H model ID #3 (Fantom-G6/G7/G8)

12H Command ID (DT1)

aaH Address MSB: upper byte of the starting address of the data to be

bbH Address: upper middle byte of the starting address of the data

ccH Address: lower middle byte of the starting address of the data

ddH Address LSB: lower byte of the starting address of the data to be

eeH Data: the actual data to be sent. Multiple bytes of data are

: :

ffH Data

sum Checksum

F7H EOX (End Of Exclusive)

* The amount of data that can be transmitted at one time depends on the type of data, and

data will be transmitted from the specified starting address and size. Refer to the address

and size given in

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each

packet will be sent at an interval of about 20 ms.

* Regarding the checksum, please refer to P.45.

* Not received when the Receive Exclusive parameter is OFF.

❍

Data set 1 (DT1)

Status

F0H 41H, dev, 42H, 12H, aaH, bbH, ccH, F7H

Byte Explanation

F0H Exclusive status

41H ID number (Roland)

dev Device ID (dev: 10H - 1FH, 7FH)

42H Model ID (GS)

12H Command ID (DT1)

aaH Address MSB: upper byte of the starting address of the transmitted

bbH Address: middle byte of the starting address of the transmitted

ccH Address LSB: lower byte of the starting address of the transmitted

ddH Data: the actual data to be transmitted. Multiple bytes of

: :

eeH Data

sum Checksum

F7H EOX (End Of Exclusive)

Parameter Address Map

ccH, ddH, eeH, ... ffH, sum

Parameter Address Map

Data byte Status

ddH, ... eeH, sum

(P.14).

sent

to be sent

sent.

transmitted in order starting from the address.

(P.14).

data

data are transmitted starting from the address.

6

Fantom-G MIDI Implementation

* The amount of data that can be transmitted at one time depends on the type of data, and

data will be transmitted from the specified starting address and size. Refer to the address

and size given in

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each

packet will be sent at an interval of about 20 ms.

* Regarding the checksum, please refer to P.45.

* Not received when the Receive Exclusive parameter is OFF.

Parameter Address Map

(P.14).

2. Data Transmission

kk = note number: 00H - 7FH (0 - 127)

vv =

Polyphonic Key Pressure:

●

Control Change

* By selecting a controller number that corresponds to the setting of parameters of

controllers (knob, slider and so on), the Fantom-G can transmit any control change

message.

00H - 7FH (0 - 127)

❍

Bank Select (Controller number 0, 32)

Status

BnH 00H mmH

BnH 20H llH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)

* These messages are transmitted when Patch, Rhythm Set, Sample Set, Live Set or Studio

Set is selected. But not transmitted when Transmit Program Change or Transmit Bank

Select parameter is OFF.

* These messages are not transmitted when External Bank Select MSB or External PC

Number parameter is OFF.

* Although with the Fantom-G you can select the Bank Select messages to be transmitted,

be sure to refer to the Program Change Map on “Sound List” for the Bank Select

messages transmitted when the Fantom-G is select a Patch, Rhythm Set, Sample Set, Live

Set or Studio Set.

* The Bank Select Numbers corresponding to ARX series should be referred to the ARX

series owner’s manual.

❍

Modulation (Controller number 1)

Status 2nd byte 3rd byte

BnH 01H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Modulation depth: 00H - 7FH (0 - 127)

❍

Portamento Time (Controller number 5)

Status

BnH 05H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Portamento Time: 00H - 7FH (0 - 127)

❍

Data Entry (Controller number 6, 38)

Status

BnH 06H mmH

BnH 26H llH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm, ll = the value of the parameter specified by RPN/NRPN

mm = MSB, ll = LSB

2nd byte 3rd byte

❍

Volume (Controller number 7)

Status

BnH 07H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Volume: 00H - 7FH (0 - 127)

2nd byte 3rd byte

7

Fantom-G MIDI Implementation

❍

Panpot (Controller number 10)

Status 2nd byte 3rd byte

BnH 0AH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Panpot: 00H - 40H - 7FH (Left - Center - Right),

❍

Expression (Controller number 11)

Status

BnH 0BH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Expression: 00H - 7FH (0 - 127)

❍

Hold 1 (Controller number 64)

Status

BnH 40H vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON

2nd byte 3rd byte

❍

Vibrato Rate (Controller number 76)

Status 2nd byte 3rd byte

BnH 4CH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Vibrato Rate value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

❍

Vibrato Depth (Controller number 77)

Status

BnH 4DH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Vibrato Depth Value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

❍

Vibrato Delay (Controller number 78)

Status

BnH 4EH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

Status

Status

BnH kkH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

kk = Controller number: 00H - 77H (0 - 31, 33 - 95)

vv = Modulation depth:00H - 7FH (0 - 127)

2nd byte 3rd byte

❍

Decay Time (Controller number 75)

Status

BnH 4BH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Decay Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

2nd byte 3rd byte

8

Fantom-G MIDI Implementation

●

Program Change

Status

CnH ppH

n = MIDI channel number: 0H - FH (ch.1 - 16)

pp = Program number: 00H - 7FH (prog.1 - prog.128)

* These messages are transmitted when Patch, Rhythm Set, Sample Set, Live Set or Studio

Set is selected. But not transmitted when Transmit Program Change parameter is OFF.

* These messages are not transmitted when External PC Num parameter is OFF.

●

Channel Pressure

Status

DnH vvH

n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Channel Pressure: 00H - 7FH (0 - 127)

●

Pitch Bend Change

Status

EnH llH mmH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

■

Channel Mode Messages

●

MONO (Controller number 126)

Status

BnH 7EH mmH

n = MIDI channel number: 0H - FH (ch.1 - 16)

mm = mono number: 00H - 10H (0 - 16)

●

POLY (Controller number 127)

Status 2nd byte 3rd byte

BnH 7FH 00H

n = MIDI channel number: 0H - FH (ch.1 - 16)

2nd byte

2nd byte 3rd byte

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

dev Device ID (dev: 10H - 1FH)

06H Sub ID#1 (General Information)

02H Sub ID#2 (Identity Reply)

41H ID number (Roland)

27H 02H Device family code

00H 00H Device family number code

00H 03H 00H 00H Software revision level

F7H EOX (End of Exclusive)

❍

Identity Reply Message (Fantom-G7)

Receiving Identity Request Message, the Fantom-G7 send this message.

Status Data byte Status

F0H 7EH, dev, 06H, 02H, 41H, 27H, 02H, F7H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

dev Device ID (dev: 10H - 1FH)

06H Sub ID#1 (General Information)

02H Sub ID#2 (Identity Reply)

41H ID number (Roland)

27H 02H Device family code

00H 00H Device family number code

01H 03H 00H 00H Software revision level

F7H EOX (End of Exclusive)

❍

Identity Reply Message (Fantom-G8)

Receiving Identity Request Message, the Fantom-G8 send this message.

Status Data byte Status

F0H 7EH, dev, 06H, 02H, 41H, 27H, 02H, F7H

00H, 00H, 01H, 03H, 00H, 00H

00H, 00H, 02H, 03H, 00H, 00H

■

System Realtime Messages

●

Active Sensing

Status

FEH

* This message is transmitted at intervals of approximately 250 msec.

* This message is not sent when Transmit Active Sensing parameter is OFF.

■

System Exclusive Messages

Status

F0H iiH, ddH, ......,eeH F7H

F0H: System Exclusive Message status

ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer whose

dd,...,ee = data: 00H - 7FH (0 - 127)

F7H: EOX (End Of Exclusive)

Universal Non-realtime System Exclusive Message” and Data Set 1 (DT1) are the only

System Exclusive messages transmitted by the Fantom-G.

●

Universal Non-realtime System Exclusive Message

❍

Identity Reply Message (Fantom-G6)

Receiving Identity Request Message, the Fantom-G6 send this message.

Status Data byte Status

F0H 7EH, dev, 06H, 02H, 41H, 27H, 02H, F7H

Data byte Status

Exclusive message this is. Roland’s manufacturer ID is 41H.

ID numbers 7EH and 7FH are extensions of the MIDI standard;

Universal Non-realtime Messages (7EH) and Universal Realtime

Messages (7FH).

00H, 00H, 00H, 03H, 00H, 00H

Byte Explanation

F0H Exclusive status

7EH ID number (Universal Non-realtime Message)

dev Device ID (dev: 10H - 1FH)

06H Sub ID#1 (General Information)

02H Sub ID#2 (Identity Reply)

41H ID number (Roland)

27H 02H Device family code

00H 00H Device family number code

02H 00H 00H 00H Software revision level

F7H EOX (End of Exclusive)

9

Fantom-G MIDI Implementation

●

Data Transmission

❍

Data set 1 DT1

Status Data byte Status

F0H 41H, dev, 00H, 27H, 12H, aaH, bbH, F7H

Byte Explanation

F0H Exclusive status

41H ID number (Roland)

dev Device ID (dev: 00H - 1FH, 7FH)

00H model ID #1 (Fantom-G6/G7/G8)

00H model ID #2 (Fantom-G6/G7/G8)

27H model ID #3 (Fantom-G6/G7/G8)

12H Command ID (DT1)

aaH Address MSB: upper byte of the starting address of the data to be

bbH Address: upper middle byte of the starting address of the data

ccH Address: lower middle byte of the starting address of the data

ddH Address LSB: lower byte of the starting address of the data to be

eeH Data: the actual data to be sent. Multiple bytes of data are

: :

ffH Data

sum Checksum

F7H EOX (End Of Exclusive)

* The amount of data that can be transmitted at one time depends on the type of data, and

data will be transmitted from the specified starting address and size. Refer to the address

and size given in

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each

packet will be sent at an interval of about 20 ms.

ccH, ddH, eeH, ... ffH, sum

sent

to be sent

sent.

transmitted in order starting from the address.

Parameter Address Map

(P.14).

3. Data reception (Sequencer Section)

3.1 Messages recorded during recording

■

Channel Voice Messages

●

Note Off

Status

8nH kkH vvH

9nH kkH 00H

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

kk=note number: 00H - 7FH (0 - 127)

vv=note off velocity: 00H - 7FH (0 - 127)

* Not received when the Note parameter (Recording Select window) is OFF.

●

Note on

Status

9nH kkH vvH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

kk=note number: 00H - 7FH (0 - 127)

vv=note on velocity: 01H - 7FH (1 - 127)

* Not received when the Note parameter (Recording Select window) is OFF.

●

Polyphonic Aftertouch

Status

AnH kkH vvH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

kk=note number: 00H - 7FH (0 - 127)

vv=Polyphonic Aftertouch: 00H - 7FH (0 - 127)

* Not received when the Poly Afertouch parameter (Recording Select window) is OFF.

●

Control Change

Status

BnH kkH vvH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

kk=Control number: 00H - 78H (0 - 120)

vv=value: 00H - 7FH (0 - 127)

2nd byte 3rd byte

* Not received when the Control Change parameter (Recording Select window) is OFF.

●

Program Change

Status

CnH ppH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

pp=Program number: 00H - 7FH (prog.1 - prog.128)

* Not received when the Program Change parameter (Recording Select window) is OFF.

●

Channel Aftertouch

Status

DnH vvH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

vv=Channel Aftertouch: 00H - 7FH (0 - 127)

* Not received when the Channel Aftertouch parameter (Recording Select window) is

OFF.

●

Pitch Bend Change

Status

EnH llH mmH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

mm, ll=Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

* Not received when the Pitch Bend parameter (Recording Select window) is OFF.

2nd byte

2nd byte 3rd byte

10

BnH 7CH 00H

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

* The same processing will be done as when an All Note Off message is received.

●

Omni On (Controller number 125)

Status 2nd byte 3rd byte

BnH 7DH 00H

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

* The same processing will be done as when an All Note Off message is received.

Fantom-G MIDI Implementation

■

System Exclusive Messages

Status Data byte Status

F0H iiH, ddH, ......, eeH F7H

F0H: System Exclusive message status

ii=ID number: This is the ID number (manufacturer ID) that specifies the

dd,..., ee = data: 00H - 7FH (0 - 127)

F7H: EOX (End of System Exclusive)

* Not received when the System Exclusive parameter (Recording Select window) is OFF.

* MIDI Machine Control and MIDI Time code is not recorded. (Refer to “3.3 Messages

acknowledged for synchronization”)

manufacturer whose exclusive message this is. Roland’s manufacturer

ID is 41H. ID numbers 7EH and 7FH are defined in an expansion of

the MIDI standard as Universal Non-real-time messages (7EH) and

Universal Realtime Messages (7FH).

●

Mono (Controller number 126)

Status

BnH 7EH mmH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

mm=mono number: 00H - 10H (0 - 16)

* The same processing will be done as when an All Note Off message is received.

●

Poly (Controller number 127)

Status 2nd byte 3rd byte

BnH 7FH 00H

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

* The same processing will be done as when an All Note Off message is received.

2nd byte 3rd byte

11

Fantom-G MIDI Implementation

3.2 Messages not recorded during recording

■

Channel mode messages

●

Local On/Off (Controller number 122)

Status

BnH 7AH vvH

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

vv=Value: 00H, 7FH (Local Off, Local On)

●

All notes off (Controller number 123)

Status

BnH 7BH 00H

n=MIDI channel number: 0H - FH (ch.1 - ch.16)

* When an All Note Off message is received, all notes of the corresponding channel that

are on will be sent Note Off’s, and the resulting Note Off messages will be recorded.

3.3 Messages acknowledged for synchronization

■

System Common messages

●

Tune Request

Status

F6H

●

MIDI Time Code Quarter Frame Messages

MIDI Time Code Quarter Frame Messages can be transmitted while the sequencer is

running (Playing or Recording) if the Sync Mode parameter (System/Sync/Tempo) is

MASTER and MTC Sync Output parameter (System/Sync/Tempo) is ON. The transmitted

time counts are summed to MTC Offset Time parameter (System/Sync/Tempo) as the song

top is “00:00:00:00.”

The sequencer synchronizes with the time counts which are summed to MTC Offset Time

parameter (System/Sync/Tempo) as the song top is “00:00:00:00” if the Sync Mode

parameter (System/Sync/Tempo) is SLAVE(MTC).

2nd byte 3rd byte

■

System Realtime Messages

●

Status

FCH

* Received when Sync Mode parameter (System/Sync/Tempo) is set to SLAVE-MIDI or

REMOTE.

Status Second

F1H mmH (= 0nnndddd)

nnn = Message type :

0 = Frame count LS nibble

1 = Frame count MS nibble

2 = Seconds count LS nibble

3 = Seconds count MS nibble

4 = Minutes count LS nibble

5 = Minutes count MS nibble

6 = Hours count LS nibble

7 = Hours count MS nibble

dddd = 4 bit nibble data : h - FH (0 - 15)

Bit Field is assigned as follows.

Frame Count xxxyyyyy

xxx Reserved (000)

yyyyy Frame No.(0-29)

Seconds Count xxyyyyyy

Minutes Count xxyyyyyy

Hours Count xyyzzzzz

●

Song Position Pointer

Status

F2H mmH llH

mm, ll=value: 00 00H - 7F 7FH (0 - 16383)

xx Reserved (00)

yyyyyy Seconds (0-59)

xx Reserved (00)

yyyyyy Minutes (0-59)

x Reserved (0)

yy Time Code type

0 = 24 Frames / Sec

1 = 25 Frames / Sec

2 = 30 Frames / Sec (Drop Frame)

3 = 30 Frames / Sec (Non Drop Frame

zzzzz Hours (0-23)

2nd byte 3rd byte

12

■

System Exclusive Message

●

MIDI Machine Control (MMC)

* Received when the MMC Mode parameter (System/Sync/Tempo) is SLAVE.

❍

STOP (MCS)

Status Data byte Status

F0H 7FH, dev, 06H, 01H F7H

Fantom-G MIDI Implementation

4. Data transmission (Sequencer Section)

4.1 Messages transmitted during playing

Recorded messages are transmitted during playback.

4.2 Soft Through

Messages (except System Common and System Realtime Messages) that are received are

then sent out when Soft Through parameter (System/MIDI) is switched to ON.

Byte Remarks

F0H Exclusive status

7FH Universal System Exclusive Realtime Header

7FH Device ID

06H MMC command message

01H STOP (MCS)

F7H EOX (End of Exclusive)

❍

DEFERRED PLAY (MCS)

Status Data byte Status

F0H 7FH, dev, 06H, 03H F7H

Byte Remarks

F0H Exclusive status

7FH Universal System Exclusive Realtime Header

7FH Device ID

06H MMC command message

03H DEFERRED PLAY (MCS)

F7H EOX (End of Exclusive)

❍

LOCATE (MCP)

❍

Format2—LOCATE [TARGET]

Status Data byte Status

F0H 7FH, dev, 06H, 44H, 06H, 01H, F7H

Byte Remarks

F0H Exclusive status

7FH Universal System Exclusive Realtime Header

7FH Device ID

06H MMC command message

44H LOCATE (MCP)

06H Byte count

01H “TARGET” sub-Command

hrH Standard Time Specification with subframes

mnH

scH

frH

ffH

F7H EOX (End of Exclusive)

hrH, mnH, scH, frH, ffH

4.3 Messages that are generated and transmitted

4.3.1 Messages Appearing When Synchronizing with Other Devices

■

System Common Messages

* Sent when Sync Output parameter (System/Sync/Tempo) is set to ON.

●

Song Position Pointer

Status

F2H mmH llH

mm, ll=value: 00 00H - 7F 7FH (0 - 16383)

■

Status

F1H mmH (= 0nnndddd)

* Sent when Sync Mode parameter (System/Sync/Tempo) is set to MASTER and MTC

Sync Output parameter (System/Sync/Tempo) is set to ON. Furthermore, sending a

Quarter Frame Message with “00h00m00s00f00” at the beginning of the song adds the

MTC Offset Time parameter (System/Sync/Tempo).

2nd byte 3rd byte

2nd byte

13

Fantom-G MIDI Implementation

■

System Exclusive Message

●

MIDI Time code

❍

Full Message

Full Messages are used, which encode the complete time into a single message.

This message transmitted when the song position moves.

Status Data Byte Status

F0H, 7FH xxH, 01H, 01H, hrH, mnH, scH, frH F7H

F0H, 7FH : Realtime Universal System Exclusive Header

xxH : 7F (Device ID)

01H : sub-ID #1 (MIDI Time code)

01H : sub-ID #2 (Full Message)

hrH : hours and type: 0 yy zzzzz

yy type:

zzzzz : Hours (00 - 23)

mnH : Minutes (00 - 59)

scH : Seconds (00 - 59)

frH : Frames (00 - 29)

F7H : EOX (End of Exclusive)

●

* Not received when the MMC Mode parameter (System/Sync/Tempo) is Master.

❍

STOP (MCS)

Status

F0H 7FH, dev, 06H, 01H F7H

Byte Remarks

F0H Exclusive status

7FH Universal System Exclusive Realtime Header

7FH Device ID

06H MMC command message

01H STOP (MCS)

F7H EOX (End of Exclusive)

❍

DEFFERRED PLAY (MCS)

Status Data byte Status

F0H 7FH, dev, 06H, 03H F7H

Byte Remarks

F0H Exclusive status

7FH Universal System Exclusive Realtime Header

7FH Device ID

06H MMC command message

03H DEFERRED PLAY (MCS)

F7H EOX (End of Exclusive)

❍

LOCATE (MCP)

❍

Format2—LOCATE [TARGET]

Status Data byte Status

F0H 7FH, dev, 06H, 44H, 06H, 01H, hrH, mnH, scH, frH, ffH F7H

Byte Remarks

F0H Exclusive status

7FH Universal System Exclusive Realtime Header

7FH Device ID

06H MMC command message

44H LOCATE (MCP)

06H Byte count

01H “TARGET” sub-Command

hrH Standard Time Specification with subframes

mnH

scH

frH

ffH

F7H EOX (End of Exclusive)

00 = 24 Flame/sec

01 = 25 Flame/sec

10 = 30 Flame/sec

11 = 30 Flame/sec

MIDI Machine Control (MMC)

Data byte Status

5. Parameter Address Map

* Transmission of “#” marked address is divided to some packets. For example, ABH in

hexadecimal notation will be divided to 0AH and 0BH, and is sent/received in this order.

System Insert MFX

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | MFX Type (0 - 78) | | 00 01 | 0aaa aaaa | MFX Dry Send Level (0 - 127) | | 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) | | 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) | | 00 04 | 0000 00aa | MFX Output Assign (0 - 1) | | | | A, B | |-------------+-----------+----------------------------------------------------| | 00 05 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 06 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 07 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 08 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 09 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0A | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 0B | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0C | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 0D | 000a aaaa | MFX Control Assign 1 (0 - 16) | | | | OFF, 1 - 16 | | 00 0E | 000a aaaa | MFX Control Assign 2 (0 - 16) | | | | OFF, 1 - 16 | | 00 0F | 000a aaaa | MFX Control Assign 3 (0 - 16) | | | | OFF, 1 - 16 | | 00 10 | 000a aaaa | MFX Control Assign 4 (0 - 16) | | | | OFF, 1 - 16 | |# 00 11 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 1 (12768 - 52768) | | | | -20000 - +20000 | |# 00 15 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 19 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 4 (12768 - 52768) | | | | -20000 - +20000 | |# 00 21 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 5 (12768 - 52768) | | | | -20000 - +20000 | |# 00 25 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 6 (12768 - 52768) | | | | -20000 - +20000 | |# 00 29 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 7 (12768 - 52768) | | | | -20000 - +20000 | |# 00 2D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 8 (12768 - 52768) | | | | -20000 - +20000 | |# 00 31 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 9 (12768 - 52768) | | | | -20000 - +20000 | |# 00 35 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 10 (12768 - 52768) | | | | -20000 - +20000 | |# 00 39 | 0000 aaaa | | | | 0000 bbbb | |

15

Fantom-G MIDI Implementation

| | 0000 cccc | | | | 0000 dddd | MFX Parameter 11 (12768 - 52768) | | | | -20000 - +20000 | |# 00 3D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 12 (12768 - 52768) | | | | -20000 - +20000 | |# 00 41 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 13 (12768 - 52768) | | | | -20000 - +20000 | |# 00 45 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 14 (12768 - 52768) | | | | -20000 - +20000 | |# 00 49 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 15 (12768 - 52768) | | | | -20000 - +20000 | |# 00 4D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 16 (12768 - 52768) | | | | -20000 - +20000 | |# 00 51 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 17 (12768 - 52768) | | | | -20000 - +20000 | |# 00 55 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 18 (12768 - 52768) | | | | -20000 - +20000 | |# 00 59 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 19 (12768 - 52768) | | | | -20000 - +20000 | |# 00 5D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 20 (12768 - 52768) | | | | -20000 - +20000 | |# 00 61 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 21 (12768 - 52768) | | | | -20000 - +20000 | |# 00 65 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 22 (12768 - 52768) | | | | -20000 - +20000 | |# 00 69 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 23 (12768 - 52768) | | | | -20000 - +20000 | |# 00 6D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 24 (12768 - 52768) | | | | -20000 - +20000 | |# 00 71 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 25 (12768 - 52768) | | | | -20000 - +20000 | |# 00 75 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 26 (12768 - 52768) | | | | -20000 - +20000 | |# 00 79 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 27 (12768 - 52768) | | | | -20000 - +20000 | |# 00 7D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 28 (12768 - 52768) | | | | -20000 - +20000 | |# 01 01 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 29 (12768 - 52768) | | | | -20000 - +20000 | |# 01 05 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 30 (12768 - 52768) | | | | -20000 - +20000 | |# 01 09 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 31 (12768 - 52768) | | | | -20000 - +20000 | |# 01 0D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 32 (12768 - 52768) | | | | -20000 - +20000 | |-------------+----------------------------------------------------------------| | 00 00 01 11 | Total Size | +------------------------------------------------------------------------------+

❍

System Mastering

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 01 | 0aaa aaaa | Low band Attack time (0 - 100) | | 00 02 | 0aaa aaaa | Low band Release time (0 - 100) | | 00 03 | 00aa aaaa | Low band Threshold (0 - 36) | | | | -36, -35, -34, -33, -32, -31, | | | | -30, -29, -28, -27, -26, -25, | | | | -24, -23, -22, -21, -20, -19, | | | | -18, -17, -16, -15, -14, -13, | | | | -12, -11, -10, -9, -8, -7, | | | | -6, -5, -4, -3, -2, -1, 0 [dB] | | 00 04 | 0000 aaaa | Low band Ratio (0 - 13) | | | | 1:1.0, 1:1.1, 1:1.2, 1:1.4, | | | | 1:1.6, 1:1.8, 1:2.0, 1:2.5, | | | | 1:3.2, 1:4.0, 1:5.6, 1:8.0, | | | | 1:16, 1:INF | | 00 05 | 000a aaaa | Low band Level (0 - 24) | | | | 0, 1, 2, 3, 4, 5, 6, 7, 8, | | | | 9, 10, 11, 12, 13, 14, 15, | | | | 16, 17, 18, 19, 20, 21, 22, |

| | | 23, 24 [dB] | | 00 06 | 0aaa aaaa | Mid band Attack time (0 - 100) | | 00 07 | 0aaa aaaa | Mid band Release time (0 - 100) | | 00 08 | 00aa aaaa | Mid band Threshold (0 - 36) | | | | -36, -35, -34, -33, -32, -31, | | | | -30, -29, -28, -27, -26, -25, | | | | -24, -23, -22, -21, -20, -19, | | | | -18, -17, -16, -15, -14, -13, | | | | -12, -11, -10, -9, -8, -7, | | | | -6, -5, -4, -3, -2, -1, 0 [dB] | | 00 09 | 0000 aaaa | Mid band Ratio (0 - 13) | | | | 1:1.0, 1:1.1, 1:1.2, 1:1.4, | | | | 1:1.6, 1:1.8, 1:2.0, 1:2.5, | | | | 1:3.2, 1:4.0, 1:5.6, 1:8.0, | | | | 1:16, 1:INF | | 00 0A | 000a aaaa | Mid band Level (0 - 24) | | | | 0, 1, 2, 3, 4, 5, 6, 7, 8, | | | | 9, 10, 11, 12, 13, 14, 15, | | | | 16, 17, 18, 19, 20, 21, 22, | | | | 23, 24 [dB] | | 00 0B | 0aaa aaaa | High band Attack time (0 - 100) | | 00 0C | 0aaa aaaa | High band Release time (0 - 100) | | 00 0D | 00aa aaaa | High band Threshold (0 - 36) | | | | -36, -35, -34, -33, -32, -31, | | | | -30, -29, -28, -27, -26, -25, | | | | -24, -23, -22, -21, -20, -19, | | | | -18, -17, -16, -15, -14, -13, | | | | -12, -11, -10, -9, -8, -7, | | | | -6, -5, -4, -3, -2, -1, 0 [dB] | | 00 0E | 0000 aaaa | High band Ratio (0 - 13) | | | | 1:1.0, 1:1.1, 1:1.2, 1:1.4, | | | | 1:1.6, 1:1.8, 1:2.0, 1:2.5, | | | | 1:3.2, 1:4.0, 1:5.6, 1:8.0, | | | | 1:16, 1:INF | | 00 0F | 000a aaaa | High band Level (0 - 24) | | | | 0, 1, 2, 3, 4, 5, 6, 7, 8, | | | | 9, 10, 11, 12, 13, 14, 15, | | | | 16, 17, 18, 19, 20, 21, 22, | | | | 23, 24 [dB] | | 00 10 | 0000 0aaa | Split Freq Low (0 - 6) | | | | 200, 250, 315, 400, 500, | | | | 630, 800 [Hz] | | 00 11 | 0000 0aaa | Split Freq High (0 - 6) | | | | 2000, 2500, 3150, 4000, 5000, | | | | 6300, 8000 [Hz] | |-------------+----------------------------------------------------------------| | 00 00 00 12 | Total Size | +------------------------------------------------------------------------------+

❍

System Input FX

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | External Dry Send Level (0 - 127) | | 00 01 | 0aaa aaaa | External Chorus Send Level (0 - 127) | | 00 02 | 0aaa aaaa | External Reverb Send Level (0 - 127) | | 00 03 | 0000 aaaa | External Output Destination Select (0 - 2) | | | | INT, EXP1, EXP2 | | 00 04 | 0000 aaaa | External Output Assign (0 - 2) | | | | A, B, MFX | | 00 05 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | | 00 06 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 07 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+-----------+----------------------------------------------------| | 00 08 | 0000 aaaa | Input Effect Type (1 - 6) | |-------------+-----------+----------------------------------------------------| |# 00 09 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 1 (12768 - 52768) | | | | -20000 - +20000 | |# 00 0D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 11 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 15 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 4 (12768 - 52768) | | | | -20000 - +20000 | |# 00 19 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 5 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 6 (12768 - 52768) | | | | -20000 - +20000 | |# 00 21 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 7 (12768 - 52768) | | | | -20000 - +20000 | |# 00 25 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 8 (12768 - 52768) | | | | -20000 - +20000 | |# 00 29 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 9 (12768 - 52768) | | | | -20000 - +20000 | |# 00 2D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 10 (12768 - 52768) | | | | -20000 - +20000 | |# 00 31 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 11 (12768 - 52768) | | | | -20000 - +20000 | |# 00 35 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 12 (12768 - 52768) | | | | -20000 - +20000 | |# 00 39 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 13 (12768 - 52768) | | | | -20000 - +20000 | |# 00 3D | 0000 aaaa | | | | 0000 bbbb | |

16

Fantom-G MIDI Implementation

| | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 14 (12768 - 52768) | | | | -20000 - +20000 | |# 00 41 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 15 (12768 - 52768) | | | | -20000 - +20000 | |# 00 45 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 16 (12768 - 52768) | | | | -20000 - +20000 | |# 00 49 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 17 (12768 - 52768) | | | | -20000 - +20000 | |# 00 4D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 18 (12768 - 52768) | | | | -20000 - +20000 | |# 00 51 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 19 (12768 - 52768) | | | | -20000 - +20000 | |# 00 55 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Input Effect Parameter 20 (12768 - 52768) | | | | -20000 - +20000 | |-------------+----------------------------------------------------------------| | 00 00 00 59 | Total Size | +------------------------------------------------------------------------------+

❍

System Controller

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 000a | Transmit Program Change (0 - 1) | | | | OFF, ON | | 00 01 | 0000 000a | Transmit Bank Select (0 - 1) | | | | OFF, ON | | 00 02 | 0aaa aaaa | Keyboard Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 03 | 0000 00aa | Keyboard Sens (0 - 2) | | | | LIGHT, MEDIUM, HEAVY | | 00 04 | 0aaa aaaa | Aftertouch Sens (0 - 100) | |-------------+-----------+----------------------------------------------------| | 00 05 | 0000 0aaa | Hold Pedal Polarity (0 - 1) | | | | STANDARD, REVERSE | | 00 06 | 0000 000a | Continuous Hold Pedal (0 - 1) | | | | OFF, ON | |-------------+-----------+----------------------------------------------------| | 00 07 | 0aaa aaaa | Control Pedal 1 Assign (0 - 107) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND-UP, BEND-DOWN, | | | | START/STOP, TAP-TEMPO, | | | | PROG-UP, PROG-DOWN, | | | | USER-GRP-UP, USER-GRP-DOWN, | | | | FAV-UP, FAV-DOWN, PANEL_SW | | 00 08 | 0aaa aaaa | Control Pedal 1 Panel Switch Assign (0 - 11) | | | | OCT-UP, OCT-DW, ARP-SW, CHD-SW, | | | | INC, DEC, SHIFT, ENTER, EXIT, | | | | SKIPBACK, ROLL, HOLD | | 00 09 | 0000 0aaa | Control Pedal 1 Polarity (0 - 1) | | | | STANDARD, REVERSE | | 00 0A | 0aaa aaaa | Control Pedal 2 Assign (0 - 107) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND-UP, BEND-DOWN, | | | | START/STOP, TAP-TEMPO, | | | | PROG-UP, PROG-DOWN, | | | | USER-GRP-UP, USER-GRP-DOWN, | | | | FAV-UP, FAV-DOWN, PANEL_SW | | 00 0B | 0aaa aaaa | Control Pedal 2 Panel Switch Assign (0 - 11) | | | | OCT-UP, OCT-DW, ARP-SW, CHD-SW, | | | | INC, DEC, SHIFT, ENTER, EXIT, | | | | SKIPBACK, ROLL, HOLD | | 00 0C | 0000 0aaa | Control Pedal 2 Polarity (0 - 1) | | | | STANDARD, REVERSE | |-------------+-----------+----------------------------------------------------| | 00 0D | 0000 aaaa | Beam Sens (1 - 10) | | 00 0E | 0aaa aaaa | Beam Switch (0 - 3) | | | | OFF, PAD-TRIG, SOLO-SYN, ASGN | | 00 0F | 0aaa aaaa | Beam Assign (0 - 102) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND-UP, BEND-DOWN, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 10 | 0aaa aaaa | Beam Range Lower (0 - 127) | | 00 11 | 0aaa aaaa | Beam Range Upper (0 - 127) | | 00 12 | 0000 aaaa | Beam Trigger Pad (0 - 15) | | | | 1 - 15 | | 00 13 | 0aaa aaaa | Beam Trigger Velo (1 - 127) | | 00 14 | 0aaa aaaa | Beam Trigger Mode (0 - 1) | | | | MOMENTARY, LATCH | |-------------+-----------+----------------------------------------------------| | 00 15 | 0aaa aaaa | Knob 1 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 16 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 17 | 0aaa aaaa | Knob 2 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 18 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 19 | 0aaa aaaa | Knob 3 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 1A | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 1B | 0aaa aaaa | Knob 4 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 1C | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 1D | 0aaa aaaa | Slider 1 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, |

| | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 1E | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 1F | 0aaa aaaa | Slider 2 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 20 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 21 | 0aaa aaaa | Slider 3 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 22 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 23 | 0aaa aaaa | Slider 4 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 24 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 25 | 0aaa aaaa | Slider 5 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 26 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 27 | 0aaa aaaa | Slider 6 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 28 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 29 | 0aaa aaaa | Slider 7 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 2A | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 2B | 0aaa aaaa | Slider 8 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 2C | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 2D | 0aaa aaaa | Switch S1 Assign (0 - 106) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, MONO/POLY, PFX-SW, | | | | MFX1-SW, MFX2-SW, | | | | CHO-SW, REV-SW, MASTERING-SW, | | | | MASTER-KEY-UP, MASTER-KEY-DW, | | | | SCALE-TUNE-SW | | 00 2E | 0000 000a | Switch S1 Assign Mode (0 - 1) | | | | MOMENTARY, LATCH | | 00 2F | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | | | 00 30 | 0aaa aaaa | Switch S2 Assign (0 - 106) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, MONO/POLY, PFX-SW, | | | | MFX1-SW, MFX2-SW, | | | | CHO-SW, REV-SW, MASTERING-SW, | | | | MASTER-KEY-UP, MASTER-KEY-DW, | | | | SCALE-TUNE-SW | | 00 31 | 0000 000a | Switch S2 Assign Mode (0 - 1) | | | | MOMENTARY, LATCH | | 00 32 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | | |-------------+-----------+----------------------------------------------------| | 00 33 | 0aaa aaaa | Pad Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 34 | 0000 00aa | Pad Sens (0 - 2) | | | | LIGHT, MEDIUM, HEAVY | | 00 35 | 0aaa aaaa | Pad Aftertouch Sens (0 - 100) | | 00 36 | 0aaa aaaa | Pad Mode (0 - 15) | | | | SAMPLE, RHYTHM, CHORD, ARP-SET, | | | | RPS, RHY-PTN, TONE-SW, TRK-MUTE, | | | | BOOKMARK, TX-SW, EFX-SW, | | | | PFX-SW, PART-SEL, PART-MUTE, | | | | USER-GRP, FAVORITE | | 00 37 | 0000 aaaa | Pad Roll Resolution (0 - 7) | |-------------+-----------+----------------------------------------------------| | 00 38 | 0000 000a | Pad Assign Source (0 - 1) | | | | TEMP, SYS | | 00 39 | 0000 000a | D Beam Assign Source (0 - 1) | | | | TEMP, SYS | | 00 3A | 0000 000a | S1/S2 Assign Source (0 - 1) | | | | TEMP, SYS | | 00 3B | 0000 aaaa | Knob Slider Mode (0 - 1) | | | | DIRECT, CATCH | | 00 3C | 0aaa aaaa | Magi Control Switch (0 - 1) | | | | OFF, ON | | 00 3D | 0aaa aaaa | Knob Assign Source (0 - 1) | | | | TEMP, SYS | | 00 3E | 0aaa aaaa | Knob Assign Select (0 - 1) | | | | FIX, SCREEN | | 00 3F | 0aaa aaaa | Slider Assign Source (0 - 1) | | | | TEMP, SYS | | 00 40 | 0aaa aaaa | Slider Assign Select (0 - 1) | | | | FIX, SCREEN | |-------------+----------------------------------------------------------------| | 00 00 00 41 | Total Size | +------------------------------------------------------------------------------+

❍

Live Set Common

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Live Set Name 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 01 | 0aaa aaaa | Live Set Name 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 02 | 0aaa aaaa | Live Set Name 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 03 | 0aaa aaaa | Live Set Name 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 04 | 0aaa aaaa | Live Set Name 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 05 | 0aaa aaaa | Live Set Name 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 06 | 0aaa aaaa | Live Set Name 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 07 | 0aaa aaaa | Live Set Name 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 08 | 0aaa aaaa | Live Set Name 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 09 | 0aaa aaaa | Live Set Name 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0A | 0aaa aaaa | Live Set Name 11 (32 - 127) |

17

Fantom-G MIDI Implementation

| | | 32 - 127 [ASCII] | | 00 0B | 0aaa aaaa | Live Set Name 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0C | 0aaa aaaa | Live Set Name 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0D | 0aaa aaaa | Live Set Name 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0E | 0aaa aaaa | Live Set Name 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0F | 0aaa aaaa | Live Set Name 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 10 | 0aaa aaaa | Live Set Memo 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 11 | 0aaa aaaa | Live Set Memo 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 12 | 0aaa aaaa | Live Set Memo 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 13 | 0aaa aaaa | Live Set Memo 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 14 | 0aaa aaaa | Live Set Memo 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 15 | 0aaa aaaa | Live Set Memo 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 16 | 0aaa aaaa | Live Set Memo 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 17 | 0aaa aaaa | Live Set Memo 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 18 | 0aaa aaaa | Live Set Memo 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 19 | 0aaa aaaa | Live Set Memo 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1A | 0aaa aaaa | Live Set Memo 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1B | 0aaa aaaa | Live Set Memo 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1C | 0aaa aaaa | Live Set Memo 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1D | 0aaa aaaa | Live Set Memo 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1E | 0aaa aaaa | Live Set Memo 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1F | 0aaa aaaa | Live Set Memo 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 20 | 0aaa aaaa | Live Set Memo 17 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 21 | 0aaa aaaa | Live Set Memo 18 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 22 | 0aaa aaaa | Live Set Memo 19 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 23 | 0aaa aaaa | Live Set Memo 20 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 24 | 0aaa aaaa | Live Set Memo 21 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 25 | 0aaa aaaa | Live Set Memo 22 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 26 | 0aaa aaaa | Live Set Memo 23 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 27 | 0aaa aaaa | Live Set Memo 24 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 28 | 0aaa aaaa | Live Set Memo 25 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 29 | 0aaa aaaa | Live Set Memo 26 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2A | 0aaa aaaa | Live Set Memo 27 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2B | 0aaa aaaa | Live Set Memo 28 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2C | 0aaa aaaa | Live Set Memo 29 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2D | 0aaa aaaa | Live Set Memo 30 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2E | 0aaa aaaa | Live Set Memo 31 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2F | 0aaa aaaa | Live Set Memo 32 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 30 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 31 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 32 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 33 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 34 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 35 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 36 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 37 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 39 | 00aa aaaa | (reserve) <*> (0 - 16) | | | | | | 00 3A | 000a aaaa | (reserve) <*> (0 - 16) | | | | | | 00 3B | 000a aaaa | (reserve) <*> (0 - 16) | | | | | |-------------+-----------+----------------------------------------------------| | 00 3C | 0aaa aaaa | Voice Reserve 1 (0 - 64) | | | | 0 - 63, FULL | | 00 3D | 0aaa aaaa | Voice Reserve 2 (0 - 64) | | | | 0 - 63, FULL | | 00 3E | 0aaa aaaa | Voice Reserve 3 (0 - 64) | | | | 0 - 63, FULL | | 00 3F | 0aaa aaaa | Voice Reserve 4 (0 - 64) | | | | 0 - 63, FULL | | 00 40 | 0aaa aaaa | Voice Reserve 5 (0 - 64) | | | | 0 - 63, FULL | | 00 41 | 0aaa aaaa | Voice Reserve 6 (0 - 64) | | | | 0 - 63, FULL | | 00 42 | 0aaa aaaa | Voice Reserve 7 (0 - 64) | | | | 0 - 63, FULL | | 00 43 | 0aaa aaaa | Voice Reserve 8 (0 - 64) | | | | 0 - 63, FULL | | 00 44 | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | | 00 45 | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | | 00 46 | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | | 00 47 | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | | 00 48 | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | | 00 49 | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | | 00 4A | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | | 00 4B | 0aaa aaaa | (reserve) <*> (0 - 64) | | | | | |-------------+-----------+----------------------------------------------------| | 00 4C | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 4D | 0000 000a | (reserve) <*> (0 - 1) | | | | |

| 00 4E | 0000 000a | Live Set Chorus Switch (0 - 1) | | | | OFF, ON | | 00 4F | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 50 | 0000 000a | Live Set Reverb Switch (0 - 1) | | | | OFF, ON | | 00 51 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 52 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 53 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+-----------+----------------------------------------------------| | 00 54 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 55 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 56 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 57 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+----------------------------------------------------------------| | 00 00 00 58 | Total Size | +------------------------------------------------------------------------------+

❍

Live Set Common Chorus

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 aaaa | Chorus Type (0 - 3) | | 00 01 | 0aaa aaaa | Chorus Level (0 - 127) | | 00 02 | 0000 000a | Chorus Output Assign (0 - 1) | | | | A, B | | 00 03 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 04 | 0000 00aa | Chorus Output Select (0 - 2) | | | | MAIN, REV, MAIN+REV | |-------------+-----------+----------------------------------------------------| |# 00 05 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 1 (12768 - 52768) | | | | -20000 - +20000 | |# 00 09 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 0D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 11 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 4 (12768 - 52768) | | | | -20000 - +20000 | |# 00 15 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 5 (12768 - 52768) | | | | -20000 - +20000 | |# 00 19 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 6 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 7 (12768 - 52768) | | | | -20000 - +20000 | |# 00 21 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 8 (12768 - 52768) | | | | -20000 - +20000 | |# 00 25 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 9 (12768 - 52768) | | | | -20000 - +20000 | |# 00 29 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 10 (12768 - 52768) | | | | -20000 - +20000 | |# 00 2D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 11 (12768 - 52768) | | | | -20000 - +20000 | |# 00 31 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 12 (12768 - 52768) | | | | -20000 - +20000 | |# 00 35 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 13 (12768 - 52768) | | | | -20000 - +20000 | |# 00 39 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 14 (12768 - 52768) | | | | -20000 - +20000 | |# 00 3D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 15 (12768 - 52768) | | | | -20000 - +20000 | |# 00 41 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 16 (12768 - 52768) | | | | -20000 - +20000 | |# 00 45 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 17 (12768 - 52768) | | | | -20000 - +20000 | |# 00 49 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 18 (12768 - 52768) | | | | -20000 - +20000 | |# 00 4D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 19 (12768 - 52768) | | | | -20000 - +20000 | |# 00 51 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | |

18

20

Fantom-G MIDI Implementation

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Beam Switch (0 - 3) | | | | OFF, PAD-TRIG, SOLO-SYN, ASGN | | 00 01 | 0aaa aaaa | Beam Assign (0 - 102) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND-UP, BEND-DOWN, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 02 | 0aaa aaaa | Beam Range Lower (0 - 127) | | 00 03 | 0aaa aaaa | Beam Range Upper (0 - 127) | | 00 04 | 0000 aaaa | Beam Trigger Pad (0 - 15) | | | | 1 - 15 | | 00 05 | 0aaa aaaa | Beam Trigger Velo (1 - 127) | | 00 06 | 0aaa aaaa | Beam Trigger Mode (0 - 1) | | | | MOMENTARY, LATCH | |-------------+-----------+----------------------------------------------------| | 00 07 | 0aaa aaaa | Knob 1 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 08 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 09 | 0aaa aaaa | Knob 2 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 0A | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 0B | 0aaa aaaa | Knob 3 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 0C | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 0D | 0aaa aaaa | Knob 4 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 0E | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 0F | 0aaa aaaa | Slider 1 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 10 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 11 | 0aaa aaaa | Slider 2 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 12 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 13 | 0aaa aaaa | Slider 3 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 14 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 15 | 0aaa aaaa | Slider 4 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 16 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 17 | 0aaa aaaa | Slider 5 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 18 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 19 | 0aaa aaaa | Slider 6 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 1A | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 1B | 0aaa aaaa | Slider 7 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 1C | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 1D | 0aaa aaaa | Slider 8 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 1E | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 1F | 0aaa aaaa | Switch S1 Assign (0 - 106) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, MONO/POLY, PFX-SW, | | | | MFX-SW, RESERV, | | | | CHO-SW, REV-SW, MASTERING-SW, | | | | MASTER-KEY-UP, MASTER-KEY-DW, | | | | SCALE-TUNE-SW | | 00 20 | 0000 000a | Switch S1 Assign Mode (0 - 1) | | | | MOMENTARY, LATCH | | 00 21 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | | | 00 22 | 0aaa aaaa | Switch S2 Assign (0 - 106) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, MONO/POLY, PFX-SW, | | | | MFX-SW, RESERV, | | | | CHO-SW, REV-SW, MASTERING-SW, | | | | MASTER-KEY-UP, MASTER-KEY-DW, | | | | SCALE-TUNE-SW | | 00 23 | 0000 000a | Switch S2 Assign Mode (0 - 1) | | | | MOMENTARY, LATCH | | 00 24 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | | |-------------+-----------+----------------------------------------------------| | 00 25 | 0000 000a | Arpeggio Switch (0 - 1) | | | | OFF, ON | | 00 26 | 0000 000a | Arpeggio Hold (0 - 1) | | | | OFF, ON | | 00 27 | 0aaa aaaa | Arpeggio Number (0 - 127) | | 00 28 | 0000 aaaa | Arpeggio Part Group (0 - 3) |

| | | INT, EXP1, EXP2, EXT | | 00 29 | 0000 aaaa | Arpeggio Part Number (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 2A | 0000 000a | Chord Switch (0 - 1) | | | | OFF, ON | | 00 2B | 0aaa aaaa | Chord Number (0 - 127) | | 00 2C | 0000 000a | Rolled Chord (0 - 1) | | | | OFF, ON | | 00 2D | 0aaa aaaa | Rolled Chord Type (0 - 4) | | | | UP, DOWN, ALTERNATE, | | | | L-DOWN, U-UP | |-------------+-----------+----------------------------------------------------| | 00 2E | 0000 000a | Pad Internal Switch (0 - 1) | | | | OFF, ON | | 00 2F | 0000 000a | Pad External Switch (0 - 1) | | | | OFF, ON | | 00 30 | 0000 00aa | Pad Internal Group (0 - 2) | | | | INT, EXP1, EXP2 | | 00 31 | 0000 aaaa | Pad Internal Part (0 - 15) | | | | 1 - 16 | | 00 32 | 000a aaaa | Pad Transmit Channel (0 - 15) | | | | 1 - 16 | | 00 33 | 000a aaaa | Sample Pad Part (0 - 7) | | | | 1 - 8 | |-------------+-----------+----------------------------------------------------| | 00 34 | 0aaa aaaa | Pad 1 Note Number (0 - 127) | | | | C-1 - G9 | | 00 35 | 0aaa aaaa | Pad 1 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 36 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 37 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 39 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 3A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 3B | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 3C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 3D | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 3E | 0aaa aaaa | Pad 2 Note Number (0 - 127) | | | | C-1 - G9 | | 00 3F | 0aaa aaaa | Pad 2 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 40 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 41 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 42 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 43 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 44 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 45 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 46 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 47 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 48 | 0aaa aaaa | Pad 3 Note Number (0 - 127) | | | | C-1 - G9 | | 00 49 | 0aaa aaaa | Pad 3 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 4A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 4B | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 4C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 4D | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 4E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 4F | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 50 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 51 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 52 | 0aaa aaaa | Pad 4 Note Number (0 - 127) | | | | C-1 - G9 | | 00 53 | 0aaa aaaa | Pad 4 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 54 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 55 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 56 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 57 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 58 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 59 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 5A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 5B | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 5C | 0aaa aaaa | Pad 5 Note Number (0 - 127) | | | | C-1 - G9 | | 00 5D | 0aaa aaaa | Pad 5 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 5E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 5F | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 60 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 61 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 62 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 63 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 64 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 65 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 66 | 0aaa aaaa | Pad 6 Note Number (0 - 127) | | | | C-1 - G9 | | 00 67 | 0aaa aaaa | Pad 6 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 68 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 69 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 6A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 6B | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | |

21

Fantom-G MIDI Implementation

| 01 31 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 32 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 33 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 34 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 35 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 36 | 0aaa aaaa | Pad 14 Note Number (0 - 127) | | | | C-1 - G9 | | 01 37 | 0aaa aaaa | Pad 14 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 01 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 39 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 3A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 3B | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 3C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 3D | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 3E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 3F | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 40 | 0aaa aaaa | Pad 15 Note Number (0 - 127) | | | | C-1 - G9 | | 01 41 | 0aaa aaaa | Pad 15 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 01 42 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 43 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 44 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 45 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 46 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 47 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 48 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 49 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4A | 0aaa aaaa | Pad 16 Note Number (0 - 127) | | | | C-1 - G9 | | 01 4B | 0aaa aaaa | Pad 16 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 01 4C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4D | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4F | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 50 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 51 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 52 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 53 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 01 54 | 0aaa aaaa | (reserve) <*> (0 - 1) | | | | | | 01 55 | 0aaa aaaa | Pad Mode (0 - 15) | | | | SAMPLE, RHYTHM, CHORD, ARP-SET, | | | | RPS, RHY-PTN, TONE-SW, TRK-MUTE, | | | | BOOKMARK, TX-SW, EFX-SW, | | | | PFX-SW, PART-SEL, PART-MUTE, | | | | USER-GRP, FAVORITE | | 01 56 | 0000 aaaa | (reserve) <*> (0 - 7) | | | | | |-------------+----------------------------------------------------------------| | 00 00 01 57 | Total Size | +------------------------------------------------------------------------------+

❍

Studio Set Common

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Studio Set Name 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 01 | 0aaa aaaa | Studio Set Name 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 02 | 0aaa aaaa | Studio Set Name 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 03 | 0aaa aaaa | Studio Set Name 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 04 | 0aaa aaaa | Studio Set Name 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 05 | 0aaa aaaa | Studio Set Name 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 06 | 0aaa aaaa | Studio Set Name 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 07 | 0aaa aaaa | Studio Set Name 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 08 | 0aaa aaaa | Studio Set Name 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 09 | 0aaa aaaa | Studio Set Name 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0A | 0aaa aaaa | Studio Set Name 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0B | 0aaa aaaa | Studio Set Name 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0C | 0aaa aaaa | Studio Set Name 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0D | 0aaa aaaa | Studio Set Name 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0E | 0aaa aaaa | Studio Set Name 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0F | 0aaa aaaa | Studio Set Name 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 10 | 0aaa aaaa | Studio Set Memo 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 11 | 0aaa aaaa | Studio Set Memo 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 12 | 0aaa aaaa | Studio Set Memo 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 13 | 0aaa aaaa | Studio Set Memo 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 14 | 0aaa aaaa | Studio Set Memo 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 15 | 0aaa aaaa | Studio Set Memo 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 16 | 0aaa aaaa | Studio Set Memo 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 17 | 0aaa aaaa | Studio Set Memo 8 (32 - 127) |

22

Fantom-G MIDI Implementation

| | | 32 - 127 [ASCII] | | 00 18 | 0aaa aaaa | Studio Set Memo 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 19 | 0aaa aaaa | Studio Set Memo 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1A | 0aaa aaaa | Studio Set Memo 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1B | 0aaa aaaa | Studio Set Memo 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1C | 0aaa aaaa | Studio Set Memo 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1D | 0aaa aaaa | Studio Set Memo 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1E | 0aaa aaaa | Studio Set Memo 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1F | 0aaa aaaa | Studio Set Memo 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 20 | 0aaa aaaa | Studio Set Memo 17 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 21 | 0aaa aaaa | Studio Set Memo 18 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 22 | 0aaa aaaa | Studio Set Memo 19 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 23 | 0aaa aaaa | Studio Set Memo 20 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 24 | 0aaa aaaa | Studio Set Memo 21 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 25 | 0aaa aaaa | Studio Set Memo 22 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 26 | 0aaa aaaa | Studio Set Memo 23 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 27 | 0aaa aaaa | Studio Set Memo 24 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 28 | 0aaa aaaa | Studio Set Memo 25 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 29 | 0aaa aaaa | Studio Set Memo 26 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2A | 0aaa aaaa | Studio Set Memo 27 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2B | 0aaa aaaa | Studio Set Memo 28 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2C | 0aaa aaaa | Studio Set Memo 29 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2D | 0aaa aaaa | Studio Set Memo 30 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2E | 0aaa aaaa | Studio Set Memo 31 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2F | 0aaa aaaa | Studio Set Memo 32 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 30 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 31 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 32 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 33 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 34 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 35 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 36 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 37 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 39 | 00aa aaaa | (reserve) <*> (0 - 16) | | | | | | 00 3A | 000a aaaa | (reserve) <*> (0 - 16) | | | | | | 00 3B | 000a aaaa | (reserve) <*> (0 - 16) | | | | | |-------------+-----------+----------------------------------------------------| | 00 3C | 0aaa aaaa | Voice Reserve 1 (0 - 64) | | | | 0 - 63, FULL | | 00 3D | 0aaa aaaa | Voice Reserve 2 (0 - 64) | | | | 0 - 63, FULL | | 00 3E | 0aaa aaaa | Voice Reserve 3 (0 - 64) | | | | 0 - 63, FULL | | 00 3F | 0aaa aaaa | Voice Reserve 4 (0 - 64) | | | | 0 - 63, FULL | | 00 40 | 0aaa aaaa | Voice Reserve 5 (0 - 64) | | | | 0 - 63, FULL | | 00 41 | 0aaa aaaa | Voice Reserve 6 (0 - 64) | | | | 0 - 63, FULL | | 00 42 | 0aaa aaaa | Voice Reserve 7 (0 - 64) | | | | 0 - 63, FULL | | 00 43 | 0aaa aaaa | Voice Reserve 8 (0 - 64) | | | | 0 - 63, FULL | | 00 44 | 0aaa aaaa | Voice Reserve 9 (0 - 64) | | | | 0 - 63, FULL | | 00 45 | 0aaa aaaa | Voice Reserve 10 (0 - 64) | | | | 0 - 63, FULL | | 00 46 | 0aaa aaaa | Voice Reserve 11 (0 - 64) | | | | 0 - 63, FULL | | 00 47 | 0aaa aaaa | Voice Reserve 12 (0 - 64) | | | | 0 - 63, FULL | | 00 48 | 0aaa aaaa | Voice Reserve 13 (0 - 64) | | | | 0 - 63, FULL | | 00 49 | 0aaa aaaa | Voice Reserve 14 (0 - 64) | | | | 0 - 63, FULL | | 00 4A | 0aaa aaaa | Voice Reserve 15 (0 - 64) | | | | 0 - 63, FULL | | 00 4B | 0aaa aaaa | Voice Reserve 16 (0 - 64) | | | | 0 - 63, FULL | |-------------+-----------+----------------------------------------------------| | 00 4C | 0000 000a | Studio Set Insert MFX1 Switch (0 - 1) | | | | OFF, ON | | 00 4D | 0000 000a | Studio Set Insert MFX2 Switch (0 - 1) | | | | OFF, ON | | 00 4E | 0000 000a | Studio Set Chorus Switch (0 - 1) | | | | OFF, ON | | 00 4F | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 50 | 0000 000a | Studio Set Reverb Switch (0 - 1) | | | | OFF, ON | | 00 51 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 52 | 0000 000a | Studio Set Mastering Switch (0 - 1) | | | | OFF, ON | | 00 53 | 0000 000a | Studio Set Input FX Switch (0 - 1) | | | | OFF, ON | |-------------+-----------+----------------------------------------------------| | 00 54 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 55 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 56 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 57 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+----------------------------------------------------------------| | 00 00 00 58 | Total Size | +------------------------------------------------------------------------------+

❍

Studio Set Common Insert MFX

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | MFX Type (0 - 78) | | 00 01 | 0aaa aaaa | MFX Dry Send Level (0 - 127) | | 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) | | 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) | | 00 04 | 0000 00aa | MFX Output Assign (0 - 1) | | | | A, B | |-------------+-----------+----------------------------------------------------| | 00 05 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 06 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 07 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 08 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 09 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0A | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 0B | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0C | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 0D | 000a aaaa | MFX Control Assign 1 (0 - 16) | | | | OFF, 1 - 16 | | 00 0E | 000a aaaa | MFX Control Assign 2 (0 - 16) | | | | OFF, 1 - 16 | | 00 0F | 000a aaaa | MFX Control Assign 3 (0 - 16) | | | | OFF, 1 - 16 | | 00 10 | 000a aaaa | MFX Control Assign 4 (0 - 16) | | | | OFF, 1 - 16 | |# 00 11 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 1 (12768 - 52768) | | | | -20000 - +20000 | |# 00 15 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 19 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 4 (12768 - 52768) | | | | -20000 - +20000 | |# 00 21 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 5 (12768 - 52768) | | | | -20000 - +20000 | |# 00 25 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 6 (12768 - 52768) | | | | -20000 - +20000 | |# 00 29 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 7 (12768 - 52768) | | | | -20000 - +20000 | |# 00 2D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 8 (12768 - 52768) | | | | -20000 - +20000 | |# 00 31 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 9 (12768 - 52768) | | | | -20000 - +20000 | |# 00 35 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 10 (12768 - 52768) | | | | -20000 - +20000 | |# 00 39 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 11 (12768 - 52768) | | | | -20000 - +20000 | |# 00 3D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 12 (12768 - 52768) | | | | -20000 - +20000 | |# 00 41 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 13 (12768 - 52768) | | | | -20000 - +20000 | |# 00 45 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 14 (12768 - 52768) | | | | -20000 - +20000 | |# 00 49 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 15 (12768 - 52768) | | | | -20000 - +20000 | |# 00 4D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 16 (12768 - 52768) | | | | -20000 - +20000 | |# 00 51 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 17 (12768 - 52768) | | | | -20000 - +20000 | |# 00 55 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 18 (12768 - 52768) | | | | -20000 - +20000 | |# 00 59 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 19 (12768 - 52768) | | | | -20000 - +20000 | |# 00 5D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 20 (12768 - 52768) | | | | -20000 - +20000 |

23

Fantom-G MIDI Implementation

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 000a | Receive Program Change (0 - 1) | | | | OFF, ON | | 00 01 | 0000 000a | Receive Bank Select (0 - 1) | | | | OFF, ON | | 00 02 | 0000 000a | Receive Bender (0 - 1) | | | | OFF, ON | | 00 03 | 0000 000a | Receive Polyphonic Key Pressure (0 - 1) | | | | OFF, ON | | 00 04 | 0000 000a | Receive Channel Pressure (0 - 1) | | | | OFF, ON | | 00 05 | 0000 000a | Receive Modulation (0 - 1) | | | | OFF, ON | | 00 06 | 0000 000a | Receive Volume (0 - 1) | | | | OFF, ON | | 00 07 | 0000 000a | Receive Pan (0 - 1) | | | | OFF, ON | | 00 08 | 0000 000a | Receive Expression (0 - 1) | | | | OFF, ON | | 00 09 | 0000 000a | Receive Hold-1 (0 - 1) | | | | OFF, ON | |-------------+-----------+----------------------------------------------------| | 00 0A | 0000 000a | Phase Lock (0 - 1) | | | | OFF, ON | | 00 0B | 0000 0aaa | Velocity Curve Type (0 - 4) | | | | OFF, 1 - 4 | |-------------+----------------------------------------------------------------| | 00 00 00 0C | Total Size | +------------------------------------------------------------------------------+

❍

Studio Set Part

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 aaaa | Receive Channel (0 - 15) | | | | 1 - 16 | | 00 01 | 0000 000a | Receive Switch (0 - 1) | | | | OFF, ON | |-------------+-----------+----------------------------------------------------| | 00 02 | 0aaa aaaa | Patch Bank Select MSB (CC# 0) (0 - 127) | | 00 03 | 0aaa aaaa | Patch Bank Select LSB (CC# 32) (0 - 127) | | 00 04 | 0aaa aaaa | Patch Program Number (PC) (0 - 127) | |-------------+-----------+----------------------------------------------------| | 00 05 | 0aaa aaaa | Part Level (CC# 7) (0 - 127) | | 00 06 | 0aaa aaaa | Part Pan (CC# 10) (0 - 127) | | | | L64 - 63R |

25

Fantom-G MIDI Implementation

| 00 07 | 0aaa aaaa | Part Coarse Tune (RPN# 2) (16 - 112) | | | | -48 - +48 | | 00 08 | 0aaa aaaa | Part Fine Tune (RPN# 1) (14 - 114) | | | | -50 - +50 | | 00 09 | 0000 00aa | Part Mono/Poly (MONO ON/POLY ON) (0 - 2) | | | | MONO, POLY, PATCH | | 00 0A | 0000 00aa | Part Legato Switch (CC# 68) (0 - 2) | | | | OFF, ON, PATCH | | 00 0B | 000a aaaa | Part Pitch Bend Range (RPN# 0) (0 - 25) | | | | 0 - 24, PATCH | | 00 0C | 0000 00aa | Part Portamento Switch (CC# 65) (0 - 2) | | | | OFF, ON, PATCH | |# 00 0D | 0000 aaaa | | | | 0000 bbbb | Part Portamento Time (CC# 5) (0 - 128) | | | | 0 - 127, PATCH | | 00 0F | 0aaa aaaa | Part Cutoff Offset (CC# 74) (0 - 127) | | | | -64 - +63 | | 00 10 | 0aaa aaaa | Part Resonance Offset (CC# 71) (0 - 127) | | | | -64 - +63 | | 00 11 | 0aaa aaaa | Part Attack Time Offset (CC# 73) (0 - 127) | | | | -64 - +63 | | 00 12 | 0aaa aaaa | Part Decay Time Offset (CC# 75) (0 - 127) | | | | -64 - +63 | | 00 13 | 0aaa aaaa | Part Release Time Offset (CC# 72) (0 - 127) | | | | -64 - +63 | | 00 14 | 0aaa aaaa | Part Vibrato Rate (CC# 76) (0 - 127) | | | | -64 - +63 | | 00 15 | 0aaa aaaa | Part Vibrato Depth (CC# 77) (0 - 127) | | | | -64 - +63 | | 00 16 | 0aaa aaaa | Part Vibrato Delay (CC# 78) (0 - 127) | | | | -64 - +63 | |-------------+-----------+----------------------------------------------------| | 00 17 | 0000 0aaa | Part Octave Shift (61 - 67) | | | | -3 - +3 | | 00 18 | 0aaa aaaa | Part Velocity Sens Offset (1 - 127) | | | | -63 - +63 | | 00 19 | 0aaa aaaa | Keyboard Range Lower (0 - 127) | | | | C-1 - UPPER | | 00 1A | 0aaa aaaa | Keyboard Range Upper (0 - 127) | | | | LOWER - G9 | | 00 1B | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1D | 0000 000a | Mute Switch (0 - 1) | | | | OFF, MUTE | |-------------+-----------+----------------------------------------------------| | 00 1E | 0aaa aaaa | Part Output Level (0 - 127) | | 00 1F | 0aaa aaaa | Part Chorus Send Level (CC# 93) (0 - 127) | | 00 20 | 0aaa aaaa | Part Reverb Send Level (CC# 91) (0 - 127) | | 00 21 | 0000 aaaa | Part Output Assign (0 - 6) | | | | A, B, 1, 2, 3, 4, MFX | | 00 22 | 0000 00aa | Part MFX Select (0 - 1) | | | | MFX1, MFX2 | | 00 23 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | | 00 24 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | |-------------+-----------+----------------------------------------------------| | 00 25 | 0aaa aaaa | Part Scale Tune for C (0 - 127) | | | | -64 - +63 | | 00 26 | 0aaa aaaa | Part Scale Tune for C# (0 - 127) | | | | -64 - +63 | | 00 27 | 0aaa aaaa | Part Scale Tune for D (0 - 127) | | | | -64 - +63 | | 00 28 | 0aaa aaaa | Part Scale Tune for D# (0 - 127) | | | | -64 - +63 | | 00 29 | 0aaa aaaa | Part Scale Tune for E (0 - 127) | | | | -64 - +63 | | 00 2A | 0aaa aaaa | Part Scale Tune for F (0 - 127) | | | | -64 - +63 | | 00 2B | 0aaa aaaa | Part Scale Tune for F# (0 - 127) | | | | -64 - +63 | | 00 2C | 0aaa aaaa | Part Scale Tune for G (0 - 127) | | | | -64 - +63 | | 00 2D | 0aaa aaaa | Part Scale Tune for G# (0 - 127) | | | | -64 - +63 | | 00 2E | 0aaa aaaa | Part Scale Tune for A (0 - 127) | | | | -64 - +63 | | 00 2F | 0aaa aaaa | Part Scale Tune for A# (0 - 127) | | | | -64 - +63 | | 00 30 | 0aaa aaaa | Part Scale Tune for B (0 - 127) | | | | -64 - +63 | |-------------+-----------+----------------------------------------------------| | 00 31 | 0000 000a | Keyboard Switch (0 - 1) | | | | OFF, ON | | 00 32 | 0000 000a | Control Bender (0 - 1) | | | | OFF, ON | | 00 33 | 0000 000a | Control Aftertouch (0 - 1) | | | | OFF, ON | | 00 34 | 0000 000a | Control Modulation (0 - 1) | | | | OFF, ON | | 00 35 | 0000 000a | Control Hold Pedal (0 - 1) | | | | OFF, ON | | 00 36 | 0000 000a | Control Pedal 1 (0 - 1) | | | | OFF, ON | | 00 37 | 0000 000a | Control Pedal 2 (0 - 1) | | | | OFF, ON | | 00 38 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 39 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 3A | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 3B | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 3C | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 3D | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 3E | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 3F | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 40 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 41 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 42 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 43 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 44 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 45 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 46 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+-----------+----------------------------------------------------| | 00 47 | 0aaa aaaa | Velocity Range Lower (1 - 127) | | | | 1 - UPPER | | 00 48 | 0aaa aaaa | Velocity Range Upper (1 - 127) | | | | LOWER - 127 | | 00 49 | 0aaa aaaa | Part Transpose Value (59 - 70) | | | | -5 - +6 | |-------------+----------------------------------------------------------------| | 00 00 00 4A | Total Size | +------------------------------------------------------------------------------+

❍

Studio Set Exp Common

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Level (0 - 127) | | 00 01 | 0aaa aaaa | Pan (0 - 127) | | | | L64 - 63R | |-------------+-----------+----------------------------------------------------| | 00 02 | 0aaa aaaa | Output Level (0 - 127) | | 00 03 | 0aaa aaaa | Chorus Send Level (0 - 127) | | 00 04 | 0aaa aaaa | Reverb Send Level (0 - 127) | | 00 05 | 0000 aaaa | Output Assign (0 - 6) | | | | A, B, 1, 2, 3, 4, MFX | | 00 06 | 0000 00aa | MFX Select (0 - 1) | | | | MFX1, MFX2 | | 00 07 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | | 00 08 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | |-------------+----------------------------------------------------------------| | 00 00 00 09 | Total Size | +------------------------------------------------------------------------------+

❍

Studio Set Exp Part

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 aaaa | Receive Channel (0 - 15) | | | | 1 - 16 | | 00 01 | 0000 000a | Receive Switch (0 - 1) | | | | OFF, ON | |-------------+-----------+----------------------------------------------------| | 00 02 | 0aaa aaaa | Patch Bank Select MSB (CC# 0) (0 - 127) | | 00 03 | 0aaa aaaa | Patch Bank Select LSB (CC# 32) (0 - 127) | | 00 04 | 0aaa aaaa | Patch Program Number (PC) (0 - 127) | |-------------+-----------+----------------------------------------------------| | 00 05 | 0aaa aaaa | Part Level (CC# 7) (0 - 127) | | 00 06 | 0aaa aaaa | Part Pan (CC# 10) (0 - 127) | | | | L64 - 63R | | 00 07 | 0aaa aaaa | Part Coarse Tune (RPN# 2) (16 - 112) | | | | -48 - +48 | | 00 08 | 0aaa aaaa | Part Fine Tune (RPN# 1) (14 - 114) | | | | -50 - +50 | | 00 09 | 000a aaaa | Part Pitch Bend Range (RPN# 0) (0 - 25) | | | | 0 - 24, PATCH | |-------------+-----------+----------------------------------------------------| | 00 0A | 0000 0aaa | Part Octave Shift (61 - 67) | | | | -3 - +3 | | 00 0B | 0aaa aaaa | Keyboard Range Lower (0 - 127) | | | | C-1 - UPPER | | 00 0C | 0aaa aaaa | Keyboard Range Upper (0 - 127) | | | | LOWER - G9 | | 00 0D | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 0E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 0F | 0000 000a | Mute Switch (0 - 1) | | | | OFF, MUTE | |-------------+-----------+----------------------------------------------------| | 00 10 | 0aaa aaaa | Part Output Level (0 - 127) | | 00 11 | 0aaa aaaa | Part Effect1 Send Level (CC# 93) (0 - 127) | | 00 12 | 0aaa aaaa | Part Effect2 Send Level (CC# 91) (0 - 127) | | 00 13 | 0000 aaaa | Part Output Assign (0 - 1) | | | | EXP, DRY | | 00 14 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | | 00 15 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | | 00 16 | 0000 00aa | (reserve) <*> (0 - 1) | | | | | |-------------+-----------+----------------------------------------------------| | 00 17 | 0aaa aaaa | Part Scale Tune for C (0 - 127) | | | | -64 - +63 | | 00 18 | 0aaa aaaa | Part Scale Tune for C# (0 - 127) | | | | -64 - +63 | | 00 19 | 0aaa aaaa | Part Scale Tune for D (0 - 127) | | | | -64 - +63 | | 00 1A | 0aaa aaaa | Part Scale Tune for D# (0 - 127) | | | | -64 - +63 | | 00 1B | 0aaa aaaa | Part Scale Tune for E (0 - 127) | | | | -64 - +63 | | 00 1C | 0aaa aaaa | Part Scale Tune for F (0 - 127) | | | | -64 - +63 | | 00 1D | 0aaa aaaa | Part Scale Tune for F# (0 - 127) | | | | -64 - +63 | | 00 1E | 0aaa aaaa | Part Scale Tune for G (0 - 127) | | | | -64 - +63 | | 00 1F | 0aaa aaaa | Part Scale Tune for G# (0 - 127) | | | | -64 - +63 | | 00 20 | 0aaa aaaa | Part Scale Tune for A (0 - 127) | | | | -64 - +63 | | 00 21 | 0aaa aaaa | Part Scale Tune for A# (0 - 127) | | | | -64 - +63 | | 00 22 | 0aaa aaaa | Part Scale Tune for B (0 - 127) | | | | -64 - +63 | |-------------+-----------+----------------------------------------------------| | 00 23 | 0000 000a | Keyboard Switch (0 - 1) | | | | OFF, ON | | 00 24 | 0000 000a | Control Bender (0 - 1) | | | | OFF, ON | | 00 25 | 0000 000a | Control Aftertouch (0 - 1) | | | | OFF, ON | | 00 26 | 0000 000a | Control Modulation (0 - 1) | | | | OFF, ON | | 00 27 | 0000 000a | Control Hold Pedal (0 - 1) | | | | OFF, ON | | 00 28 | 0000 000a | Control Pedal 1 (0 - 1) | | | | OFF, ON | | 00 29 | 0000 000a | Control Pedal 2 (0 - 1) | | | | OFF, ON | | 00 2A | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 2B | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 2C | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 2D | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 2E | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 2F | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 30 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 31 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 32 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 33 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 34 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 35 | 0000 000a | (reserve) <*> (0 - 1) |

26

Fantom-G MIDI Implementation

| | | | | 00 36 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 37 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 38 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+-----------+----------------------------------------------------| | 00 39 | 0aaa aaaa | Velocity Range Lower (1 - 127) | | | | 1 - UPPER | | 00 3A | 0aaa aaaa | Velocity Range Upper (1 - 127) | | | | LOWER - 127 | | 00 3B | 0aaa aaaa | Part Transpose Value (59 - 70) | | | | -5 - +6 | |-------------+----------------------------------------------------------------| | 00 00 00 3C | Total Size | +------------------------------------------------------------------------------+

❍

Studio Set Ext Part

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| |# 00 00 | 0000 aaaa | | | | 0000 bbbb | External Bank Select MSB (CC# 0) (0 - 128) | | | | 0 - 127, NO-SEND | | 00 02 | 0aaa aaaa | External Bank Select LSB (CC# 32) (0 - 127) | |# 00 03 | 0000 aaaa | | | | 0000 bbbb | External Program Number (PC) (0 - 128) | | | | 0 - 127, NO-SEND | |# 00 05 | 0000 aaaa | | | | 0000 bbbb | External Level (CC# 7) (0 - 128) | | | | 0 - 127, NO-SEND | |# 00 07 | 0000 aaaa | | | | 0000 bbbb | External Pan (CC# 10) (0 - 128) | | | | L64 - 63R, NO-SEND | |-------------+-----------+----------------------------------------------------| | 00 09 | 0aaa aaaa | Keyboard Range Lower (0 - 127) | | | | C-1 - UPPER | | 00 0A | 0aaa aaaa | Keyboard Range Upper (0 - 127) | | | | LOWER - G9 | |-------------+-----------+----------------------------------------------------| | 00 0B | 0000 000a | Keyboard Switch (0 - 1) | | | | OFF, ON | | 00 0C | 0000 000a | Control Bender (0 - 1) | | | | OFF, ON | | 00 0D | 0000 000a | Control Aftertouch (0 - 1) | | | | OFF, ON | | 00 0E | 0000 000a | Control Modulation (0 - 1) | | | | OFF, ON | | 00 0F | 0000 000a | Control Hold Pedal (0 - 1) | | | | OFF, ON | | 00 10 | 0000 000a | Control Pedal 1 (0 - 1) | | | | OFF, ON | | 00 11 | 0000 000a | Control Pedal 2 (0 - 1) | | | | OFF, ON | | 00 12 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 13 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 14 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 15 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 16 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 17 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 18 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 19 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 1A | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 1B | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 1C | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 1D | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 1E | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 1F | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 20 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+-----------+----------------------------------------------------| | 00 21 | 0aaa aaaa | Velocity Range Lower (1 - 127) | | | | 1 - UPPER | | 00 22 | 0aaa aaaa | Velocity Range Upper (1 - 127) | | | | LOWER - 127 | | 00 23 | 0000 0aaa | Part Octave Shift (61 - 67) | | | | -3 - +3 | | 00 24 | 0000 aaaa | Part Transpose Value (59 - 70) | | | | -5 - +6 | |-------------+----------------------------------------------------------------| | 00 00 00 25 | Total Size | +------------------------------------------------------------------------------+

❍

Studio Set Controller

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Beam Switch (0 - 3) | | | | OFF, PAD-TRIG, SOLO-SYN, ASGN | | 00 01 | 0aaa aaaa | Beam Assign (0 - 102) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND-UP, BEND-DOWN, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 02 | 0aaa aaaa | Beam Range Lower (0 - 127) | | 00 03 | 0aaa aaaa | Beam Range Upper (0 - 127) | | 00 04 | 0000 aaaa | Beam Trigger Pad (0 - 15) | | | | 1 - 15 | | 00 05 | 0aaa aaaa | Beam Trigger Velo (1 - 127) | | 00 06 | 0aaa aaaa | Beam Trigger Mode (0 - 1) | | | | MOMENTARY, LATCH | |-------------+-----------+----------------------------------------------------| | 00 07 | 0aaa aaaa | Knob 1 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 08 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 09 | 0aaa aaaa | Knob 2 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 0A | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 0B | 0aaa aaaa | Knob 3 Assign (0 - 103) |

| | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 0C | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 0D | 0aaa aaaa | Knob 4 Assign (0 - 103) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN, | | | | MASTER-LEVEL, DIGITAL-IN-LEVEL | | 00 0E | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 0F | 0aaa aaaa | Slider 1 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 10 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 11 | 0aaa aaaa | Slider 2 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 12 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 13 | 0aaa aaaa | Slider 3 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 14 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 15 | 0aaa aaaa | Slider 4 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 16 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 17 | 0aaa aaaa | Slider 5 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 18 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 19 | 0aaa aaaa | Slider 6 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 1A | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 1B | 0aaa aaaa | Slider 7 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 1C | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | | 00 1D | 0aaa aaaa | Slider 8 Assign (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, BEND, | | | | ARP-ACCENT, ARP-SHUFFLE, | | | | ARP-OCT-UP, ARP-OCT-DOWN | | 00 1E | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 1F | 0aaa aaaa | Switch S1 Assign (0 - 106) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, MONO/POLY, PFX-SW, | | | | MFX1-SW, MFX2-SW, | | | | CHO-SW, REV-SW, MASTERING-SW, | | | | MASTER-KEY-UP, MASTER-KEY-DW, | | | | SCALE-TUNE-SW | | 00 20 | 0000 000a | Switch S1 Assign Mode (0 - 1) | | | | MOMENTARY, LATCH | | 00 21 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | | | 00 22 | 0aaa aaaa | Switch S2 Assign (0 - 106) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | AFT, MONO/POLY, PFX-SW, | | | | MFX1-SW, MFX2-SW, | | | | CHO-SW, REV-SW, MASTERING-SW, | | | | MASTER-KEY-UP, MASTER-KEY-DW, | | | | SCALE-TUNE-SW | | 00 23 | 0000 000a | Switch S2 Assign Mode (0 - 1) | | | | MOMENTARY, LATCH | | 00 24 | 0aaa aaaa | (reserve) <*> (0 - 15) | | | | | |-------------+-----------+----------------------------------------------------| | 00 25 | 0000 000a | Arpeggio Swich (0 - 1) | | | | OFF, ON | | 00 26 | 0000 000a | Arpeggio Hold (0 - 1) | | | | OFF, ON | | 00 27 | 0aaa aaaa | Arpeggio Number (0 - 127) | | 00 28 | 0000 aaaa | Arpeggio Part Group (0 - 3) | | | | INT, EXP1, EXP2, EXT | | 00 29 | 0000 aaaa | Arpeggio Part Number (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 2A | 0000 000a | Chord Switch (0 - 1) | | | | OFF, ON | | 00 2B | 0aaa aaaa | Chord Number (0 - 127) | | 00 2C | 0000 000a | Rolled Chord (0 - 1) | | | | OFF, ON | | 00 2D | 0aaa aaaa | Rolled Chord Type (0 - 4) | | | | UP, DOWN, ALTERNATE, | | | | L-DOWN, U-UP | |-------------+-----------+----------------------------------------------------| | 00 2E | 0000 000a | Pad Internal Switch (0 - 1) | | | | OFF, ON | | 00 2F | 0000 000a | Pad External Switch (0 - 1) | | | | OFF, ON | | 00 30 | 0000 00aa | Pad Internal Group (0 - 2) | | | | INT, EXP1, EXP2 | | 00 31 | 0000 aaaa | Pad Internal Part (0 - 15) | | | | 1 - 16 | | 00 32 | 000a aaaa | Pad Transmit Channel (0 - 15) | | | | 1 - 16 | | 00 33 | 000a aaaa | Sample Pad Part (0 - 15) | | | | 1 - 16 | |-------------+-----------+----------------------------------------------------| | 00 34 | 0aaa aaaa | Pad 1 Note Number (0 - 127) | | | | C-1 - G9 | | 00 35 | 0aaa aaaa | Pad 1 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 36 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 37 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | |

27

Fantom-G MIDI Implementation

28

Fantom-G MIDI Implementation

| 01 43 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 44 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 45 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 46 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 47 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 48 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 49 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4A | 0aaa aaaa | Pad 16 Note Number (0 - 127) | | | | C-1 - G9 | | 01 4B | 0aaa aaaa | Pad 16 Velocity (0 - 127) | | | | REAL, 1 - 127 | | 01 4C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4D | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 4F | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 50 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 51 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 52 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 01 53 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 01 54 | 0aaa aaaa | (reserve) <*> (0 - 1) | | | | | | 01 55 | 0aaa aaaa | Pad Mode (0 - 15) | | | | SAMPLE, RHYTHM, CHORD, ARP-SET, | | | | RPS, RHY-PTN, TONE-SW, TRK-MUTE, | | | | BOOKMARK, TX-SW, EFX-SW, | | | | PFX-SW, PART-SEL, PART-MUTE, | | | | USER-GRP, FAVORITE | | 01 56 | 0000 aaaa | (reserve) <*> (0 - 7) | | | | | |-------------+----------------------------------------------------------------| | 00 00 01 57 | Total Size | +------------------------------------------------------------------------------+

❍

Arpeggio

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Arpeggio Name 1 (32 - 127) | | | | | | 00 01 | 0aaa aaaa | Arpeggio Name 2 (32 - 127) | | | | | | 00 02 | 0aaa aaaa | Arpeggio Name 3 (32 - 127) | | | | | | 00 03 | 0aaa aaaa | Arpeggio Name 4 (32 - 127) | | | | | | 00 04 | 0aaa aaaa | Arpeggio Name 5 (32 - 127) | | | | | | 00 05 | 0aaa aaaa | Arpeggio Name 6 (32 - 127) | | | | | | 00 06 | 0aaa aaaa | Arpeggio Name 7 (32 - 127) | | | | | | 00 07 | 0aaa aaaa | Arpeggio Name 8 (32 - 127) | | | | | | 00 08 | 0aaa aaaa | Arpeggio Name 9 (32 - 127) | | | | | | 00 09 | 0aaa aaaa | Arpeggio Name 10 (32 - 127) | | | | | | 00 0A | 0aaa aaaa | Arpeggio Name 11 (32 - 127) | | | | | | 00 0B | 0aaa aaaa | Arpeggio Name 12 (32 - 127) | | | | | | 00 0C | 0aaa aaaa | Arpeggio Name 13 (32 - 127) | | | | | | 00 0D | 0aaa aaaa | Arpeggio Name 14 (32 - 127) | | | | | | 00 0E | 0aaa aaaa | Arpeggio Name 15 (32 - 127) | | | | | | 00 0F | 0aaa aaaa | Arpeggio Name 16 (32 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 10 | 0aaa aaaa | Style (0 - 127) | | | | 1 - 128 | | 00 11 | 0aaa aaaa | Variation (0 - 127) | | | | 1 - 128 | | 00 12 | 0aaa aaaa | Motif (0 - 9) | | | | UP, DOWN, UP&DOWN, RANDOM, | | | | NOTE-ORDER, GLISSANDO, CHORD, | | | | AUTO1, AUTO2, PHRASE | | 00 13 | 0aaa aaaa | Accent Rate (0 - 100) | | 00 14 | 0aaa aaaa | Shuffle Rate (0 - 100) | | 00 15 | 0000 000a | Shuffle Resolution (0 - 1) | | | | 16TH, 8TH | | 00 16 | 0aaa aaaa | Keyboard Velocity (0 - 127) | | | | REAL, 1 - 127 | | 00 17 | 0000 0aaa | Octave Range (61 - 67) | | | | -3 - +3 | | 00 18 | 0000 000a | Key Trigger (0 - 1) | | | | OFF, ON | |-------------+----------------------------------------------------------------| | 00 00 00 19 | Total Size | +------------------------------------------------------------------------------+

❍

Chord Memory

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 000a | Chord Note1 (0 - 1) | | | | OFF, ON | | 00 01 | 0000 000a | Chord Note2 (0 - 1) | | | | OFF, ON | | 00 02 | 0000 000a | Chord Note3 (0 - 1) | | | | OFF, ON | | 00 03 | 0000 000a | Chord Note4 (0 - 1) | | | | OFF, ON | | 00 04 | 0000 000a | Chord Note5 (0 - 1) | | | | OFF, ON | | 00 05 | 0000 000a | Chord Note6 (0 - 1) | | | | OFF, ON | | 00 06 | 0000 000a | Chord Note7 (0 - 1) | | | | OFF, ON | | 00 07 | 0000 000a | Chord Note8 (0 - 1) | | | | OFF, ON | | 00 08 | 0000 000a | Chord Note9 (0 - 1) | | | | OFF, ON | | 00 09 | 0000 000a | Chord Note10 (0 - 1) | | | | OFF, ON | | 00 0A | 0000 000a | Chord Note11 (0 - 1) | | | | OFF, ON |

| 00 0B | 0000 000a | Chord Note12 (0 - 1) | | | | OFF, ON | | 00 0C | 0000 000a | Chord Note13 (0 - 1) | | | | OFF, ON | | 00 0D | 0000 000a | Chord Note14 (0 - 1) | | | | OFF, ON | | 00 0E | 0000 000a | Chord Note15 (0 - 1) | | | | OFF, ON | | 00 0F | 0000 000a | Chord Note16 (0 - 1) | | | | OFF, ON | | 00 10 | 0000 000a | Chord Note17 (0 - 1) | | | | OFF, ON | | 00 11 | 0000 000a | Chord Note18 (0 - 1) | | | | OFF, ON | | 00 12 | 0000 000a | Chord Note19 (0 - 1) | | | | OFF, ON | | 00 13 | 0000 000a | Chord Note20 (0 - 1) | | | | OFF, ON | | 00 14 | 0000 000a | Chord Note21 (0 - 1) | | | | OFF, ON | | 00 15 | 0000 000a | Chord Note22 (0 - 1) | | | | OFF, ON | | 00 16 | 0000 000a | Chord Note23 (0 - 1) | | | | OFF, ON | | 00 17 | 0000 000a | Chord Note24 (0 - 1) | | | | OFF, ON | | 00 18 | 0000 000a | Chord Note25 (0 - 1) | | | | OFF, ON | | 00 19 | 0000 000a | Chord Note26 (0 - 1) | | | | OFF, ON | | 00 1A | 0000 000a | Chord Note27 (0 - 1) | | | | OFF, ON | | 00 1B | 0000 000a | Chord Note28 (0 - 1) | | | | OFF, ON | | 00 1C | 0000 000a | Chord Note29 (0 - 1) | | | | OFF, ON | | 00 1D | 0000 000a | Chord Note30 (0 - 1) | | | | OFF, ON | | 00 1E | 0000 000a | Chord Note31 (0 - 1) | | | | OFF, ON | | 00 1F | 0000 000a | Chord Note32 (0 - 1) | | | | OFF, ON | | 00 20 | 0000 000a | Chord Note33 (0 - 1) | | | | OFF, ON | | 00 21 | 0000 000a | Chord Note34 (0 - 1) | | | | OFF, ON | | 00 22 | 0000 000a | Chord Note35 (0 - 1) | | | | OFF, ON | | 00 23 | 0000 000a | Chord Note36 (0 - 1) | | | | OFF, ON | | 00 24 | 0000 000a | Chord Note37 (0 - 1) | | | | OFF, ON | | 00 25 | 0000 000a | Chord Note38 (0 - 1) | | | | OFF, ON | | 00 26 | 0000 000a | Chord Note39 (0 - 1) | | | | OFF, ON | | 00 27 | 0000 000a | Chord Note40 (0 - 1) | | | | OFF, ON | | 00 28 | 0000 000a | Chord Note41 (0 - 1) | | | | OFF, ON | | 00 29 | 0000 000a | Chord Note42 (0 - 1) | | | | OFF, ON | | 00 2A | 0000 000a | Chord Note43 (0 - 1) | | | | OFF, ON | | 00 2B | 0000 000a | Chord Note44 (0 - 1) | | | | OFF, ON | | 00 2C | 0000 000a | Chord Note45 (0 - 1) | | | | OFF, ON | | 00 2D | 0000 000a | Chord Note46 (0 - 1) | | | | OFF, ON | | 00 2E | 0000 000a | Chord Note47 (0 - 1) | | | | OFF, ON | | 00 2F | 0000 000a | Chord Note48 (0 - 1) | | | | OFF, ON | | 00 30 | 0000 000a | Chord Note49 (0 - 1) | | | | OFF, ON | | 00 31 | 0000 000a | Chord Note50 (0 - 1) | | | | OFF, ON | | 00 32 | 0000 000a | Chord Note51 (0 - 1) | | | | OFF, ON | | 00 33 | 0000 000a | Chord Note52 (0 - 1) | | | | OFF, ON | | 00 34 | 0000 000a | Chord Note53 (0 - 1) | | | | OFF, ON | | 00 35 | 0000 000a | Chord Note54 (0 - 1) | | | | OFF, ON | | 00 36 | 0000 000a | Chord Note55 (0 - 1) | | | | OFF, ON | | 00 37 | 0000 000a | Chord Note56 (0 - 1) | | | | OFF, ON | | 00 38 | 0000 000a | Chord Note57 (0 - 1) | | | | OFF, ON | | 00 39 | 0000 000a | Chord Note58 (0 - 1) | | | | OFF, ON | | 00 3A | 0000 000a | Chord Note59 (0 - 1) | | | | OFF, ON | | 00 3B | 0000 000a | Chord Note60 (0 - 1) | | | | OFF, ON | | 00 3C | 0000 000a | Chord Note61 (0 - 1) | | | | OFF, ON | | 00 3D | 0000 000a | Chord Note62 (0 - 1) | | | | OFF, ON | | 00 3E | 0000 000a | Chord Note63 (0 - 1) | | | | OFF, ON | | 00 3F | 0000 000a | Chord Note64 (0 - 1) | | | | OFF, ON | | 00 40 | 0000 000a | Chord Note65 (0 - 1) | | | | OFF, ON | | 00 41 | 0000 000a | Chord Note66 (0 - 1) | | | | OFF, ON | | 00 42 | 0000 000a | Chord Note67 (0 - 1) | | | | OFF, ON | | 00 43 | 0000 000a | Chord Note68 (0 - 1) | | | | OFF, ON | | 00 44 | 0000 000a | Chord Note69 (0 - 1) | | | | OFF, ON | | 00 45 | 0000 000a | Chord Note70 (0 - 1) | | | | OFF, ON | | 00 46 | 0000 000a | Chord Note71 (0 - 1) | | | | OFF, ON | | 00 47 | 0000 000a | Chord Note72 (0 - 1) | | | | OFF, ON | | 00 48 | 0000 000a | Chord Note73 (0 - 1) | | | | OFF, ON | | 00 49 | 0000 000a | Chord Note74 (0 - 1) | | | | OFF, ON | | 00 4A | 0000 000a | Chord Note75 (0 - 1) | | | | OFF, ON | | 00 4B | 0000 000a | Chord Note76 (0 - 1) | | | | OFF, ON | | 00 4C | 0000 000a | Chord Note77 (0 - 1) | | | | OFF, ON | | 00 4D | 0000 000a | Chord Note78 (0 - 1) | | | | OFF, ON | | 00 4E | 0000 000a | Chord Note79 (0 - 1) | | | | OFF, ON | | 00 4F | 0000 000a | Chord Note80 (0 - 1) | | | | OFF, ON |

29

Fantom-G MIDI Implementation

| 00 50 | 0000 000a | Chord Note81 (0 - 1) | | | | OFF, ON | | 00 51 | 0000 000a | Chord Note82 (0 - 1) | | | | OFF, ON | | 00 52 | 0000 000a | Chord Note83 (0 - 1) | | | | OFF, ON | | 00 53 | 0000 000a | Chord Note84 (0 - 1) | | | | OFF, ON | | 00 54 | 0000 000a | Chord Note85 (0 - 1) | | | | OFF, ON | | 00 55 | 0000 000a | Chord Note86 (0 - 1) | | | | OFF, ON | | 00 56 | 0000 000a | Chord Note87 (0 - 1) | | | | OFF, ON | | 00 57 | 0000 000a | Chord Note88 (0 - 1) | | | | OFF, ON | | 00 58 | 0000 000a | Chord Note89 (0 - 1) | | | | OFF, ON | | 00 59 | 0000 000a | Chord Note90 (0 - 1) | | | | OFF, ON | | 00 5A | 0000 000a | Chord Note91 (0 - 1) | | | | OFF, ON | | 00 5B | 0000 000a | Chord Note92 (0 - 1) | | | | OFF, ON | | 00 5C | 0000 000a | Chord Note93 (0 - 1) | | | | OFF, ON | | 00 5D | 0000 000a | Chord Note94 (0 - 1) | | | | OFF, ON | | 00 5E | 0000 000a | Chord Note95 (0 - 1) | | | | OFF, ON | | 00 5F | 0000 000a | Chord Note96 (0 - 1) | | | | OFF, ON | | 00 60 | 0000 000a | Chord Note97 (0 - 1) | | | | OFF, ON | | 00 61 | 0000 000a | Chord Note98 (0 - 1) | | | | OFF, ON | | 00 62 | 0000 000a | Chord Note99 (0 - 1) | | | | OFF, ON | | 00 63 | 0000 000a | Chord Note100 (0 - 1) | | | | OFF, ON | | 00 64 | 0000 000a | Chord Note101 (0 - 1) | | | | OFF, ON | | 00 65 | 0000 000a | Chord Note102 (0 - 1) | | | | OFF, ON | | 00 66 | 0000 000a | Chord Note103 (0 - 1) | | | | OFF, ON | | 00 67 | 0000 000a | Chord Note104 (0 - 1) | | | | OFF, ON | | 00 68 | 0000 000a | Chord Note105 (0 - 1) | | | | OFF, ON | | 00 69 | 0000 000a | Chord Note106 (0 - 1) | | | | OFF, ON | | 00 6A | 0000 000a | Chord Note107 (0 - 1) | | | | OFF, ON | | 00 6B | 0000 000a | Chord Note108 (0 - 1) | | | | OFF, ON | | 00 6C | 0000 000a | Chord Note109 (0 - 1) | | | | OFF, ON | | 00 6D | 0000 000a | Chord Note110 (0 - 1) | | | | OFF, ON | | 00 6E | 0000 000a | Chord Note111 (0 - 1) | | | | OFF, ON | | 00 6F | 0000 000a | Chord Note112 (0 - 1) | | | | OFF, ON | | 00 70 | 0000 000a | Chord Note113 (0 - 1) | | | | OFF, ON | | 00 71 | 0000 000a | Chord Note114 (0 - 1) | | | | OFF, ON | | 00 72 | 0000 000a | Chord Note115 (0 - 1) | | | | OFF, ON | | 00 73 | 0000 000a | Chord Note116 (0 - 1) | | | | OFF, ON | | 00 74 | 0000 000a | Chord Note117 (0 - 1) | | | | OFF, ON | | 00 75 | 0000 000a | Chord Note118 (0 - 1) | | | | OFF, ON | | 00 76 | 0000 000a | Chord Note119 (0 - 1) | | | | OFF, ON | | 00 77 | 0000 000a | Chord Note120 (0 - 1) | | | | OFF, ON | | 00 78 | 0000 000a | Chord Note121 (0 - 1) | | | | OFF, ON | | 00 79 | 0000 000a | Chord Note122 (0 - 1) | | | | OFF, ON | | 00 7A | 0000 000a | Chord Note123 (0 - 1) | | | | OFF, ON | | 00 7B | 0000 000a | Chord Note124 (0 - 1) | | | | OFF, ON | | 00 7C | 0000 000a | Chord Note125 (0 - 1) | | | | OFF, ON | | 00 7D | 0000 000a | Chord Note126 (0 - 1) | | | | OFF, ON | | 00 7E | 0000 000a | Chord Note127 (0 - 1) | | | | OFF, ON | | 00 7F | 0000 000a | Chord Note128 (0 - 1) | | | | OFF, ON | |-------------+-----------+----------------------------------------------------| | 01 00 | 0aaa aaaa | Chord Memory Name 1 (32 - 127) | | | | | | 01 01 | 0aaa aaaa | Chord Memory Name 2 (32 - 127) | | | | | | 01 02 | 0aaa aaaa | Chord Memory Name 3 (32 - 127) | | | | | | 01 03 | 0aaa aaaa | Chord Memory Name 4 (32 - 127) | | | | | | 01 04 | 0aaa aaaa | Chord Memory Name 5 (32 - 127) | | | | | | 01 05 | 0aaa aaaa | Chord Memory Name 6 (32 - 127) | | | | | | 01 06 | 0aaa aaaa | Chord Memory Name 7 (32 - 127) | | | | | | 01 07 | 0aaa aaaa | Chord Memory Name 8 (32 - 127) | | | | | | 01 08 | 0aaa aaaa | Chord Memory Name 9 (32 - 127) | | | | | | 01 09 | 0aaa aaaa | Chord Memory Name 10 (32 - 127) | | | | | | 01 0A | 0aaa aaaa | Chord Memory Name 11 (32 - 127) | | | | | | 01 0B | 0aaa aaaa | Chord Memory Name 12 (32 - 127) | | | | | | 01 0C | 0aaa aaaa | Chord Memory Name 13 (32 - 127) | | | | | | 01 0D | 0aaa aaaa | Chord Memory Name 14 (32 - 127) | | | | | | 01 0E | 0aaa aaaa | Chord Memory Name 15 (32 - 127) | | | | | | 01 0F | 0aaa aaaa | Chord Memory Name 16 (32 - 127) | | | | | |-------------+----------------------------------------------------------------| | 00 00 01 10 | Total Size | +------------------------------------------------------------------------------+

❍

Arpeggio Set

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Arpeggio Set Name 1 (32 - 127) | | | | | | 00 01 | 0aaa aaaa | Arpeggio Set Name 2 (32 - 127) | | | | | | 00 02 | 0aaa aaaa | Arpeggio Set Name 3 (32 - 127) | | | | | | 00 03 | 0aaa aaaa | Arpeggio Set Name 4 (32 - 127) | | | | | | 00 04 | 0aaa aaaa | Arpeggio Set Name 5 (32 - 127) | | | | | | 00 05 | 0aaa aaaa | Arpeggio Set Name 6 (32 - 127) | | | | | | 00 06 | 0aaa aaaa | Arpeggio Set Name 7 (32 - 127) | | | | | | 00 07 | 0aaa aaaa | Arpeggio Set Name 8 (32 - 127) | | | | | | 00 08 | 0aaa aaaa | Arpeggio Set Name 9 (32 - 127) | | | | | | 00 09 | 0aaa aaaa | Arpeggio Set Name 10 (32 - 127) | | | | | | 00 0A | 0aaa aaaa | Arpeggio Set Name 11 (32 - 127) | | | | | | 00 0B | 0aaa aaaa | Arpeggio Set Name 12 (32 - 127) | | | | | | 00 0C | 0aaa aaaa | Arpeggio Set Name 13 (32 - 127) | | | | | | 00 0D | 0aaa aaaa | Arpeggio Set Name 14 (32 - 127) | | | | | | 00 0E | 0aaa aaaa | Arpeggio Set Name 15 (32 - 127) | | | | | | 00 0F | 0aaa aaaa | Arpeggio Set Name 16 (32 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 10 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 11 | 0aaa aaaa | Pad 1 Arpeggio Number (0 - 127) | | 00 12 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 13 | 0aaa aaaa | Pad 2 Arpeggio Number (0 - 127) | | 00 14 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 15 | 0aaa aaaa | Pad 3 Arpeggio Number (0 - 127) | | 00 16 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 17 | 0aaa aaaa | Pad 4 Arpeggio Number (0 - 127) | | 00 18 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 19 | 0aaa aaaa | Pad 5 Arpeggio Number (0 - 127) | | 00 1A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1B | 0aaa aaaa | Pad 6 Arpeggio Number (0 - 127) | | 00 1C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1D | 0aaa aaaa | Pad 7 Arpeggio Number (0 - 127) | | 00 1E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1F | 0aaa aaaa | Pad 8 Arpeggio Number (0 - 127) | | 00 20 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 21 | 0aaa aaaa | Pad 9 Arpeggio Number (0 - 127) | | 00 22 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 23 | 0aaa aaaa | Pad 10 Arpeggio Number (0 - 127) | | 00 24 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 25 | 0aaa aaaa | Pad 11 Arpeggio Number (0 - 127) | | 00 26 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 27 | 0aaa aaaa | Pad 12 Arpeggio Number (0 - 127) | | 00 28 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 29 | 0aaa aaaa | Pad 13 Arpeggio Number (0 - 127) | | 00 2A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 2B | 0aaa aaaa | Pad 14 Arpeggio Number (0 - 127) | | 00 2C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 2D | 0aaa aaaa | Pad 15 Arpeggio Number (0 - 127) | | 00 2E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 2F | 0aaa aaaa | Pad 16 Arpeggio Number (0 - 127) | |-------------+----------------------------------------------------------------| | 00 00 00 30 | Total Size | +------------------------------------------------------------------------------+

❍

Chord Set

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Chord Set Name 1 (32 - 127) | | | | | | 00 01 | 0aaa aaaa | Chord Set Name 2 (32 - 127) | | | | | | 00 02 | 0aaa aaaa | Chord Set Name 3 (32 - 127) | | | | | | 00 03 | 0aaa aaaa | Chord Set Name 4 (32 - 127) | | | | | | 00 04 | 0aaa aaaa | Chord Set Name 5 (32 - 127) | | | | | | 00 05 | 0aaa aaaa | Chord Set Name 6 (32 - 127) | | | | | | 00 06 | 0aaa aaaa | Chord Set Name 7 (32 - 127) | | | | | | 00 07 | 0aaa aaaa | Chord Set Name 8 (32 - 127) | | | | | | 00 08 | 0aaa aaaa | Chord Set Name 9 (32 - 127) | | | | | | 00 09 | 0aaa aaaa | Chord Set Name 10 (32 - 127) | | | | | | 00 0A | 0aaa aaaa | Chord Set Name 11 (32 - 127) | | | | | | 00 0B | 0aaa aaaa | Chord Set Name 12 (32 - 127) | | | | | | 00 0C | 0aaa aaaa | Chord Set Name 13 (32 - 127) | | | | | | 00 0D | 0aaa aaaa | Chord Set Name 14 (32 - 127) | | | | | | 00 0E | 0aaa aaaa | Chord Set Name 15 (32 - 127) | | | | | | 00 0F | 0aaa aaaa | Chord Set Name 16 (32 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 10 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 11 | 0aaa aaaa | Pad 1 Chord Number (0 - 127) | | 00 12 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 13 | 0aaa aaaa | Pad 2 Chord Number (0 - 127) | | 00 14 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | |

30

Fantom-G MIDI Implementation

| 00 15 | 0aaa aaaa | Pad 3 Chord Number (0 - 127) | | 00 16 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 17 | 0aaa aaaa | Pad 4 Chord Number (0 - 127) | | 00 18 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 19 | 0aaa aaaa | Pad 5 Chord Number (0 - 127) | | 00 1A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1B | 0aaa aaaa | Pad 6 Chord Number (0 - 127) | | 00 1C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1D | 0aaa aaaa | Pad 7 Chord Number (0 - 127) | | 00 1E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1F | 0aaa aaaa | Pad 8 Chord Number (0 - 127) | | 00 20 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 21 | 0aaa aaaa | Pad 9 Chord Number (0 - 127) | | 00 22 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 23 | 0aaa aaaa | Pad 10 Chord Number (0 - 127) | | 00 24 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 25 | 0aaa aaaa | Pad 11 Chord Number (0 - 127) | | 00 26 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 27 | 0aaa aaaa | Pad 12 Chord Number (0 - 127) | | 00 28 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 29 | 0aaa aaaa | Pad 13 Chord Number (0 - 127) | | 00 2A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 2B | 0aaa aaaa | Pad 14 Chord Number (0 - 127) | | 00 2C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 2D | 0aaa aaaa | Pad 15 Chord Number (0 - 127) | | 00 2E | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 2F | 0aaa aaaa | Pad 16 Chord Number (0 - 127) | |-------------+----------------------------------------------------------------| | 00 00 00 30 | Total Size | +------------------------------------------------------------------------------+

❍

Patch Common

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 01 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 02 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 03 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 04 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 05 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 06 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 07 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 08 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 09 | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 0A | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 0B | 0aaa aaaa | (reserve) <*> (32 - 127) | | | | | | 00 0C | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 0D | 0000 000a | (reserve) <*> | |-------------+-----------+----------------------------------------------------| | 00 0E | 0aaa aaaa | Patch Level (0 - 127) | | 00 0F | 0aaa aaaa | Patch Pan (0 - 127) | | | | L64 - 63R | | 00 10 | 0000 000a | Patch Priority (0 - 1) | | | | LAST, LOUDEST | | 00 11 | 0aaa aaaa | Patch Coarse Tune (16 - 112) | | | | -48 - +48 | | 00 12 | 0aaa aaaa | Patch Fine Tune (14 - 114) | | | | -50 - +50 | | 00 13 | 0000 0aaa | Octave Shift (61 - 67) | | | | -3 - +3 | | 00 14 | 0000 00aa | Stretch Tune Depth (0 - 3) | | | | OFF, 1 - 3 | | 00 15 | 0aaa aaaa | Analog Feel (0 - 127) | | 00 16 | 0000 000a | Mono/Poly (0 - 1) | | | | MONO, POLY | | 00 17 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 18 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 19 | 0000 000a | Portamento Switch (0 - 1) | | | | OFF, ON | | 00 1A | 0000 000a | Portamento Mode (0 - 1) | | | | NORMAL, LEGATO | | 00 1B | 0000 000a | Portamento Type (0 - 1) | | | | RATE, TIME | | 00 1C | 0000 000a | Portamento Start (0 - 1) | | | | PITCH, NOTE | | 00 1D | 0aaa aaaa | Portamento Time (0 - 127) | | 00 1E | 0000 000a | (reserve) <*> | |# 00 1F | 0000 aaaa | (reserve) <*> | | | 0000 bbbb | (reserve) <*> | | 00 21 | 0000 000a | (reserve) <*> | |-------------+-----------+----------------------------------------------------| | 00 22 | 0aaa aaaa | Cutoff Offset (1 - 127) | | | | -63 - +63 | | 00 23 | 0aaa aaaa | Resonance Offset (1 - 127) | | | | -63 - +63 | | 00 24 | 0aaa aaaa | Attack Time Offset (1 - 127) | | | | -63 - +63 | | 00 25 | 0aaa aaaa | Release Time Offset (1 - 127) | | | | -63 - +63 | | 00 26 | 0aaa aaaa | Velocity Sens Offset (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 00 27 | 0000 aaaa | (reserve) <*> (0 - 13) | | | | | |-------------+-----------+----------------------------------------------------| | 00 28 | 0000 000a | TMT Control Switch (0 - 1) | | | | OFF, ON | | 00 29 | 00aa aaaa | Pitch Bend Range Up (0 - 48) | | 00 2A | 00aa aaaa | Pitch Bend Range Down (0 - 48) | |-------------+-----------+----------------------------------------------------| | 00 2B | 0aaa aaaa | Matrix Control 1 Source (0 - 109) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4, VELOCITY, | | | | KEYFOLLOW, TEMPO, LFO1, LFO2, | | | | PIT-ENV, TVF-ENV, TVA-ENV | | 00 2C | 00aa aaaa | Matrix Control 1 Destination 1 (0 - 33) |

| | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 2D | 0aaa aaaa | Matrix Control 1 Sens 1 (1 - 127) | | | | -63 - +63 | | 00 2E | 00aa aaaa | Matrix Control 1 Destination 2 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 2F | 0aaa aaaa | Matrix Control 1 Sens 2 (1 - 127) | | | | -63 - +63 | | 00 30 | 00aa aaaa | Matrix Control 1 Destination 3 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 31 | 0aaa aaaa | Matrix Control 1 Sens 3 (1 - 127) | | | | -63 - +63 | | 00 32 | 00aa aaaa | Matrix Control 1 Destination 4 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 33 | 0aaa aaaa | Matrix Control 1 Sens 4 (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 00 34 | 0aaa aaaa | Matrix Control 2 Source (0 - 109) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4, VELOCITY, | | | | KEYFOLLOW, TEMPO, LFO1, LFO2, | | | | PIT-ENV, TVF-ENV, TVA-ENV | | 00 35 | 00aa aaaa | Matrix Control 2 Destination 1 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 36 | 0aaa aaaa | Matrix Control 2 Sens 1 (1 - 127) | | | | -63 - +63 | | 00 37 | 00aa aaaa | Matrix Control 2 Destination 2 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 38 | 0aaa aaaa | Matrix Control 2 Sens 2 (1 - 127) | | | | -63 - +63 | | 00 39 | 00aa aaaa | Matrix Control 2 Destination 3 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 3A | 0aaa aaaa | Matrix Control 2 Sens 3 (1 - 127) | | | | -63 - +63 | | 00 3B | 00aa aaaa | Matrix Control 2 Destination 4 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 3C | 0aaa aaaa | Matrix Control 2 Sens 4 (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 00 3D | 0aaa aaaa | Matrix Control 3 Source (0 - 109) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4, VELOCITY, | | | | KEYFOLLOW, TEMPO, LFO1, LFO2, | | | | PIT-ENV, TVF-ENV, TVA-ENV | | 00 3E | 00aa aaaa | Matrix Control 3 Destination 1 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 3F | 0aaa aaaa | Matrix Control 3 Sens 1 (1 - 127) | | | | -63 - +63 | | 00 40 | 00aa aaaa | Matrix Control 3 Destination 2 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 41 | 0aaa aaaa | Matrix Control 3 Sens 2 (1 - 127) | | | | -63 - +63 | | 00 42 | 00aa aaaa | Matrix Control 3 Destination 3 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, |

31

Fantom-G MIDI Implementation

| | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 43 | 0aaa aaaa | Matrix Control 3 Sens 3 (1 - 127) | | | | -63 - +63 | | 00 44 | 00aa aaaa | Matrix Control 3 Destination 4 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 45 | 0aaa aaaa | Matrix Control 3 Sens 4 (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 00 46 | 0aaa aaaa | Matrix Control 4 Source (0 - 109) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4, VELOCITY, | | | | KEYFOLLOW, TEMPO, LFO1, LFO2, | | | | PIT-ENV, TVF-ENV, TVA-ENV | | 00 47 | 00aa aaaa | Matrix Control 4 Destination 1 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 48 | 0aaa aaaa | Matrix Control 4 Sens 1 (1 - 127) | | | | -63 - +63 | | 00 49 | 00aa aaaa | Matrix Control 4 Destination 2 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 4A | 0aaa aaaa | Matrix Control 4 Sens 2 (1 - 127) | | | | -63 - +63 | | 00 4B | 00aa aaaa | Matrix Control 4 Destination 3 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 4C | 0aaa aaaa | Matrix Control 4 Sens 3 (1 - 127) | | | | -63 - +63 | | 00 4D | 00aa aaaa | Matrix Control 4 Destination 4 (0 - 33) | | | | OFF, PCH, CUT, RES, LEV, PAN, | | | | DRY, CHO, REV, PIT-LFO1, | | | | PIT-LFO2, TVF-LFO1, TVF-LFO2, | | | | TVA-LFO1, TVA-LFO2, PAN-LFO1, | | | | PAN-LFO2, LFO1-RATE, LFO2-RATE, | | | | PIT-ATK, PIT-DCY, PIT-REL, | | | | TVF-ATK, TVF-DCY, TVF-REL, | | | | TVA-ATK, TVA-DCY, TVA-REL, | | | | TMT, FXM, PFX1, PFX2, PFX3, PFX4 | | 00 4E | 0aaa aaaa | Matrix Control 4 Sens 4 (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 00 4F | 0000 000a | Part Modulation Switch (0 - 1) | | | | OFF, ON | |-------------+----------------------------------------------------------------| | 00 00 00 50 | Total Size | +------------------------------------------------------------------------------+

❍

Patch Common MFX

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | MFX Type (0 - 76) | | 00 01 | 0aaa aaaa | MFX Dry Send Level (0 - 127) | | 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) | | 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) | | 00 04 | 0000 00aa | (reserve) <*> (0 - 3) | | | | | |-------------+-----------+----------------------------------------------------| | 00 05 | 0aaa aaaa | MFX Control 1 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 06 | 0aaa aaaa | MFX Control 1 Sens (1 - 127) | | | | -63 - +63 | | 00 07 | 0aaa aaaa | MFX Control 2 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 08 | 0aaa aaaa | MFX Control 2 Sens (1 - 127) | | | | -63 - +63 | | 00 09 | 0aaa aaaa | MFX Control 3 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 0A | 0aaa aaaa | MFX Control 3 Sens (1 - 127) | | | | -63 - +63 | | 00 0B | 0aaa aaaa | MFX Control 4 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 0C | 0aaa aaaa | MFX Control 4 Sens (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 00 0D | 000a aaaa | MFX Control Assign 1 (0 - 16) | | | | OFF, 1 - 16 | | 00 0E | 000a aaaa | MFX Control Assign 2 (0 - 16) | | | | OFF, 1 - 16 | | 00 0F | 000a aaaa | MFX Control Assign 3 (0 - 16) | | | | OFF, 1 - 16 | | 00 10 | 000a aaaa | MFX Control Assign 4 (0 - 16) | | | | OFF, 1 - 16 | |# 00 11 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 1 (12768 - 52768) | | | | -20000 - +20000 | |# 00 15 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 19 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | |

32

Fantom-G MIDI Implementation

| | | CHS, VSIN, STEP | |# 00 7C | 0000 aaaa | | | | 0000 bbbb | LFO2 Rate (0 - 149) | | | | 0 - 127, MUSICAL-NOTES | | 00 7E | 0000 0aaa | LFO2 Offset (0 - 4) | | | | -100, -50, 0, +50, +100 | | 00 7F | 0aaa aaaa | LFO2 Rate Detune (0 - 127) | | 01 00 | 0aaa aaaa | LFO2 Delay Time (0 - 127) | | 01 01 | 000a aaaa | LFO2 Delay Time Keyfollow (54 - 74) | | | | -100 - +100 | | 01 02 | 0000 00aa | LFO2 Fade Mode (0 - 3) | | | | ON-IN, ON-OUT, OFF-IN, OFF-OUT | | 01 03 | 0aaa aaaa | LFO2 Fade Time (0 - 127) | | 01 04 | 0000 000a | LFO2 Key Trigger (0 - 1) | | | | OFF, ON | | 01 05 | 0aaa aaaa | LFO2 Pitch Depth (1 - 127) | | | | -63 - +63 | | 01 06 | 0aaa aaaa | LFO2 TVF Depth (1 - 127) | | | | -63 - +63 | | 01 07 | 0aaa aaaa | LFO2 TVA Depth (1 - 127) | | | | -63 - +63 | | 01 08 | 0aaa aaaa | LFO2 Pan Depth (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 01 09 | 0000 aaaa | (reserve) <*> (0 - 1) | | | | | | 01 0A | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 0B | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 0C | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 0D | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 0E | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 0F | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 10 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 11 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 12 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 13 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 14 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 15 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 16 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 17 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 18 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | | 01 19 | 0aaa aaaa | (reserve) <*> (28 - 100) | | | | | |-------------+----------------------------------------------------------------| | 00 00 01 1A | Total Size | +------------------------------------------------------------------------------+

❍

Patch Controller

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | (reserve) <*> (0 - 3) | | | | | | 00 01 | 0aaa aaaa | (reserve) <*> (0 - 102) | | | | | | 00 02 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 03 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 04 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | | 00 05 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | | 00 06 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | | 00 07 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | |-------------+-----------+----------------------------------------------------| | 00 08 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 09 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0A | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0B | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0C | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0D | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0E | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0F | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | |-------------+-----------+----------------------------------------------------| | 00 10 | 0aaa aaaa | (reserve) <*> (0 - 106) | | | | | | 00 11 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 12 | 0aaa aaaa | (reserve) <*> (0 - 106) | | | | | | 00 13 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+----------------------------------------------------------------| | 00 00 00 14 | Total Size | +------------------------------------------------------------------------------+

❍

Patch Common 2

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Patch Name 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 01 | 0aaa aaaa | Patch Name 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 02 | 0aaa aaaa | Patch Name 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 03 | 0aaa aaaa | Patch Name 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 04 | 0aaa aaaa | Patch Name 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 05 | 0aaa aaaa | Patch Name 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 06 | 0aaa aaaa | Patch Name 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 07 | 0aaa aaaa | Patch Name 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 08 | 0aaa aaaa | Patch Name 9 (32 - 127) |

| | | 32 - 127 [ASCII] | | 00 09 | 0aaa aaaa | Patch Name 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0A | 0aaa aaaa | Patch Name 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0B | 0aaa aaaa | Patch Name 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0C | 0aaa aaaa | Patch Name 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0D | 0aaa aaaa | Patch Name 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0E | 0aaa aaaa | Patch Name 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0F | 0aaa aaaa | Patch Name 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 10 | 0aaa aaaa | Patch Memo 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 11 | 0aaa aaaa | Patch Memo 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 12 | 0aaa aaaa | Patch Memo 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 13 | 0aaa aaaa | Patch Memo 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 14 | 0aaa aaaa | Patch Memo 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 15 | 0aaa aaaa | Patch Memo 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 16 | 0aaa aaaa | Patch Memo 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 17 | 0aaa aaaa | Patch Memo 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 18 | 0aaa aaaa | Patch Memo 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 19 | 0aaa aaaa | Patch Memo 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1A | 0aaa aaaa | Patch Memo 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1B | 0aaa aaaa | Patch Memo 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1C | 0aaa aaaa | Patch Memo 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1D | 0aaa aaaa | Patch Memo 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1E | 0aaa aaaa | Patch Memo 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1F | 0aaa aaaa | Patch Memo 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 20 | 0aaa aaaa | Patch Memo 17 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 21 | 0aaa aaaa | Patch Memo 18 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 22 | 0aaa aaaa | Patch Memo 19 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 23 | 0aaa aaaa | Patch Memo 20 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 24 | 0aaa aaaa | Patch Memo 21 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 25 | 0aaa aaaa | Patch Memo 22 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 26 | 0aaa aaaa | Patch Memo 23 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 27 | 0aaa aaaa | Patch Memo 24 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 28 | 0aaa aaaa | Patch Memo 25 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 29 | 0aaa aaaa | Patch Memo 26 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2A | 0aaa aaaa | Patch Memo 27 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2B | 0aaa aaaa | Patch Memo 28 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2C | 0aaa aaaa | Patch Memo 29 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2D | 0aaa aaaa | Patch Memo 30 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2E | 0aaa aaaa | Patch Memo 31 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2F | 0aaa aaaa | Patch Memo 32 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 30 | 0aaa aaaa | Patch Category (0 - 127) | | 00 31 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 32 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 33 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 34 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 35 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 36 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 37 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 39 | 0000 00aa | Legato Switch (0 - 3) | | | | OFF, LEGATO, SUSTAIN, | | | | LEGATO+SUSTAIN | | 00 3A | 0000 00aa | Legato Retrigger (0 - 2) | | | | OFF, ON, AUTO | | 00 3B | 0000 000a | Hold Bend (0 - 1) | | | | OFF, ON | | 00 3C | 0aaa aaaa | Bend Mode (0 - 4) | | | | NORMAL, TOUCH, CATCH, LAST, | | | | CATCH+LAST | | 00 3D | 0aaa aaaa | Bend Mode Control (0 - 95) | | | | OFF, CC01 - CC31, CC33 - CC95 | | 00 3E | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 3F | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 40 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 00 41 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 42 | 0000 000a | Patch MFX Switch (0 - 1) | | | | OFF, ON | | 00 43 | 0000 000a | Chorus Switch (0 - 1) | | | | OFF, ON | | 00 44 | 0000 000a | Reverb Switch (0 - 1) | | | | OFF, ON | |-------------+----------------------------------------------------------------| | 00 00 00 45 | Total Size | +------------------------------------------------------------------------------+

❍

Patch Tone 2

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Tone Output Assign (0 - 1) | | | | PFX, DRY | |-------------+-----------+----------------------------------------------------| | 00 01 | 0000 000a | (reserve) <*> (0 - 1) |

35

Fantom-G MIDI Implementation

| | | | |-------------+-----------+----------------------------------------------------| | 00 02 | 0aaa aaaa | LFO End Step (0 - 6) | | | | 1, 2, 4, 8, 16, 32, 64 | | 00 03 | 0aaa aaaa | LFO Step1 Data (28 - 100) | | | | -36 - +36 | | 00 04 | 0000 000a | LFO Step1 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 05 | 0aaa aaaa | LFO Step2 Data (28 - 100) | | | | -36 - +36 | | 00 06 | 0000 000a | LFO Step2 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 07 | 0aaa aaaa | LFO Step3 Data (28 - 100) | | | | -36 - +36 | | 00 08 | 0000 000a | LFO Step3 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 09 | 0aaa aaaa | LFO Step4 Data (28 - 100) | | | | -36 - +36 | | 00 0A | 0000 000a | LFO Step4 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 0B | 0aaa aaaa | LFO Step5 Data (28 - 100) | | | | -36 - +36 | | 00 0C | 0000 000a | LFO Step5 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 0D | 0aaa aaaa | LFO Step6 Data (28 - 100) | | | | -36 - +36 | | 00 0E | 0000 000a | LFO Step6 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 0F | 0aaa aaaa | LFO Step7 Data (28 - 100) | | | | -36 - +36 | | 00 10 | 0000 000a | LFO Step7 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 11 | 0aaa aaaa | LFO Step8 Data (28 - 100) | | | | -36 - +36 | | 00 12 | 0000 000a | LFO Step8 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 13 | 0aaa aaaa | LFO Step9 Data (28 - 100) | | | | -36 - +36 | | 00 14 | 0000 000a | LFO Step9 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 15 | 0aaa aaaa | LFO Step10 Data (28 - 100) | | | | -36 - +36 | | 00 16 | 0000 000a | LFO Step10 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 17 | 0aaa aaaa | LFO Step11 Data (28 - 100) | | | | -36 - +36 | | 00 18 | 0000 000a | LFO Step11 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 19 | 0aaa aaaa | LFO Step12 Data (28 - 100) | | | | -36 - +36 | | 00 1A | 0000 000a | LFO Step12 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 1B | 0aaa aaaa | LFO Step13 Data (28 - 100) | | | | -36 - +36 | | 00 1C | 0000 000a | LFO Step13 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 1D | 0aaa aaaa | LFO Step14 Data (28 - 100) | | | | -36 - +36 | | 00 1E | 0000 000a | LFO Step14 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 1F | 0aaa aaaa | LFO Step15 Data (28 - 100) | | | | -36 - +36 | | 00 20 | 0000 000a | LFO Step15 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 21 | 0aaa aaaa | LFO Step16 Data (28 - 100) | | | | -36 - +36 | | 00 22 | 0000 000a | LFO Step16 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 23 | 0aaa aaaa | LFO Step17 Data (28 - 100) | | | | -36 - +36 | | 00 24 | 0000 000a | LFO Step17 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 25 | 0aaa aaaa | LFO Step18 Data (28 - 100) | | | | -36 - +36 | | 00 26 | 0000 000a | LFO Step18 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 27 | 0aaa aaaa | LFO Step19 Data (28 - 100) | | | | -36 - +36 | | 00 28 | 0000 000a | LFO Step19 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 29 | 0aaa aaaa | LFO Step20 Data (28 - 100) | | | | -36 - +36 | | 00 2A | 0000 000a | LFO Step20 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 2B | 0aaa aaaa | LFO Step21 Data (28 - 100) | | | | -36 - +36 | | 00 2C | 0000 000a | LFO Step21 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 2D | 0aaa aaaa | LFO Step22 Data (28 - 100) | | | | -36 - +36 | | 00 2E | 0000 000a | LFO Step22 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 2F | 0aaa aaaa | LFO Step23 Data (28 - 100) | | | | -36 - +36 | | 00 30 | 0000 000a | LFO Step23 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 31 | 0aaa aaaa | LFO Step24 Data (28 - 100) | | | | -36 - +36 | | 00 32 | 0000 000a | LFO Step24 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 33 | 0aaa aaaa | LFO Step25 Data (28 - 100) | | | | -36 - +36 | | 00 34 | 0000 000a | LFO Step25 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 35 | 0aaa aaaa | LFO Step26 Data (28 - 100) | | | | -36 - +36 | | 00 36 | 0000 000a | LFO Step26 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 37 | 0aaa aaaa | LFO Step27 Data (28 - 100) | | | | -36 - +36 | | 00 38 | 0000 000a | LFO Step27 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 39 | 0aaa aaaa | LFO Step28 Data (28 - 100) | | | | -36 - +36 | | 00 3A | 0000 000a | LFO Step28 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 3B | 0aaa aaaa | LFO Step29 Data (28 - 100) | | | | -36 - +36 | | 00 3C | 0000 000a | LFO Step29 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 3D | 0aaa aaaa | LFO Step30 Data (28 - 100) | | | | -36 - +36 | | 00 3E | 0000 000a | LFO Step30 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 3F | 0aaa aaaa | LFO Step31 Data (28 - 100) | | | | -36 - +36 | | 00 40 | 0000 000a | LFO Step31 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 41 | 0aaa aaaa | LFO Step32 Data (28 - 100) | | | | -36 - +36 | | 00 42 | 0000 000a | LFO Step32 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 43 | 0aaa aaaa | LFO Step33 Data (28 - 100) | | | | -36 - +36 | | 00 44 | 0000 000a | LFO Step33 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 45 | 0aaa aaaa | LFO Step34 Data (28 - 100) | | | | -36 - +36 |

| 00 46 | 0000 000a | LFO Step34 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 47 | 0aaa aaaa | LFO Step35 Data (28 - 100) | | | | -36 - +36 | | 00 48 | 0000 000a | LFO Step35 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 49 | 0aaa aaaa | LFO Step36 Data (28 - 100) | | | | -36 - +36 | | 00 4A | 0000 000a | LFO Step36 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 4B | 0aaa aaaa | LFO Step37 Data (28 - 100) | | | | -36 - +36 | | 00 4C | 0000 000a | LFO Step37 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 4D | 0aaa aaaa | LFO Step38 Data (28 - 100) | | | | -36 - +36 | | 00 4E | 0000 000a | LFO Step38 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 4F | 0aaa aaaa | LFO Step39 Data (28 - 100) | | | | -36 - +36 | | 00 50 | 0000 000a | LFO Step39 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 51 | 0aaa aaaa | LFO Step40 Data (28 - 100) | | | | -36 - +36 | | 00 52 | 0000 000a | LFO Step40 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 53 | 0aaa aaaa | LFO Step41 Data (28 - 100) | | | | -36 - +36 | | 00 54 | 0000 000a | LFO Step41 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 55 | 0aaa aaaa | LFO Step42 Data (28 - 100) | | | | -36 - +36 | | 00 56 | 0000 000a | LFO Step42 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 57 | 0aaa aaaa | LFO Step43 Data (28 - 100) | | | | -36 - +36 | | 00 58 | 0000 000a | LFO Step43 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 59 | 0aaa aaaa | LFO Step44 Data (28 - 100) | | | | -36 - +36 | | 00 5A | 0000 000a | LFO Step44 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 5B | 0aaa aaaa | LFO Step45 Data (28 - 100) | | | | -36 - +36 | | 00 5C | 0000 000a | LFO Step45 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 5D | 0aaa aaaa | LFO Step46 Data (28 - 100) | | | | -36 - +36 | | 00 5E | 0000 000a | LFO Step46 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 5F | 0aaa aaaa | LFO Step47 Data (28 - 100) | | | | -36 - +36 | | 00 60 | 0000 000a | LFO Step47 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 61 | 0aaa aaaa | LFO Step48 Data (28 - 100) | | | | -36 - +36 | | 00 62 | 0000 000a | LFO Step48 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 63 | 0aaa aaaa | LFO Step49 Data (28 - 100) | | | | -36 - +36 | | 00 64 | 0000 000a | LFO Step49 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 65 | 0aaa aaaa | LFO Step50 Data (28 - 100) | | | | -36 - +36 | | 00 66 | 0000 000a | LFO Step50 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 67 | 0aaa aaaa | LFO Step51 Data (28 - 100) | | | | -36 - +36 | | 00 68 | 0000 000a | LFO Step51 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 69 | 0aaa aaaa | LFO Step52 Data (28 - 100) | | | | -36 - +36 | | 00 6A | 0000 000a | LFO Step52 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 6B | 0aaa aaaa | LFO Step53 Data (28 - 100) | | | | -36 - +36 | | 00 6C | 0000 000a | LFO Step53 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 6D | 0aaa aaaa | LFO Step54 Data (28 - 100) | | | | -36 - +36 | | 00 6E | 0000 000a | LFO Step54 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 6F | 0aaa aaaa | LFO Step55 Data (28 - 100) | | | | -36 - +36 | | 00 70 | 0000 000a | LFO Step55 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 71 | 0aaa aaaa | LFO Step56 Data (28 - 100) | | | | -36 - +36 | | 00 72 | 0000 000a | LFO Step56 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 73 | 0aaa aaaa | LFO Step57 Data (28 - 100) | | | | -36 - +36 | | 00 74 | 0000 000a | LFO Step57 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 75 | 0aaa aaaa | LFO Step58 Data (28 - 100) | | | | -36 - +36 | | 00 76 | 0000 000a | LFO Step58 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 77 | 0aaa aaaa | LFO Step59 Data (28 - 100) | | | | -36 - +36 | | 00 78 | 0000 000a | LFO Step59 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 79 | 0aaa aaaa | LFO Step60 Data (28 - 100) | | | | -36 - +36 | | 00 7A | 0000 000a | LFO Step60 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 7B | 0aaa aaaa | LFO Step61 Data (28 - 100) | | | | -36 - +36 | | 00 7C | 0000 000a | LFO Step61 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 7D | 0aaa aaaa | LFO Step62 Data (28 - 100) | | | | -36 - +36 | | 00 7E | 0000 000a | LFO Step62 Type (0 - 1) | | | | TYPE1, TYPE2 | | 00 7F | 0aaa aaaa | LFO Step63 Data (28 - 100) | | | | -36 - +36 | | 01 00 | 0000 000a | LFO Step63 Type (0 - 1) | | | | TYPE1, TYPE2 | | 01 01 | 0aaa aaaa | LFO Step64 Data (28 - 100) | | | | -36 - +36 | | 01 02 | 0000 000a | LFO Step64 Type (0 - 1) | | | | TYPE1, TYPE2 | |-------------+-----------+----------------------------------------------------| | 01 03 | 0aaa aaaa | (reserve) <*> (0 - 63) | | | | | | 01 04 | 0aaa aaaa | (reserve) <*> (0 - 63) | | | | | | 01 05 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | | 01 06 | 0aaa aaaa | (reserve) <*> (0 - 63) | | | | | | 01 07 | 0aaa aaaa | (reserve) <*> (0 - 63) | | | | | | 01 08 | 0aaa aaaa | (reserve) <*> (1 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 01 09 | 0000 0aaa | (reserve) <*> (0 - 6) | | | | |

36

Rhythm Tone

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Tone Name 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 01 | 0aaa aaaa | Tone Name 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 02 | 0aaa aaaa | Tone Name 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 03 | 0aaa aaaa | Tone Name 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 04 | 0aaa aaaa | Tone Name 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 05 | 0aaa aaaa | Tone Name 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 06 | 0aaa aaaa | Tone Name 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 07 | 0aaa aaaa | Tone Name 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 08 | 0aaa aaaa | Tone Name 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 09 | 0aaa aaaa | Tone Name 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0A | 0aaa aaaa | Tone Name 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0B | 0aaa aaaa | Tone Name 12 (32 - 127) | | | | 32 - 127 [ASCII] | |-------------+-----------+----------------------------------------------------| | 00 0C | 0000 000a | Assign Type (0 - 1) | | | | MULTI, SINGLE | | 00 0D | 000a aaaa | Mute Group (0 - 31) | | | | OFF, 1 - 31 | |-------------+-----------+----------------------------------------------------| | 00 0E | 0aaa aaaa | Tone Level (0 - 127) | | 00 0F | 0aaa aaaa | Tone Coarse Tune (0 - 127) | | | | C-1 - G9 | | 00 10 | 0aaa aaaa | Tone Fine Tune (14 - 114) | | | | -50 - +50 | | 00 11 | 000a aaaa | Tone Random Pitch Depth (0 - 30) | | | | 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, | | | | 10, 20, 30, 40, 50, 60, 70, 80, | | | | 90, 100, 200, 300, 400, 500, | | | | 600, 700, 800, 900, 1000, 1100, | | | | 1200 | | 00 12 | 0aaa aaaa | Tone Pan (0 - 127) | | | | L64 - 63R | | 00 13 | 00aa aaaa | Tone Random Pan Depth (0 - 63) | | 00 14 | 0aaa aaaa | Tone Alternate Pan Depth (1 - 127) | | | | L63 - 63R | | 00 15 | 0000 000a | Tone Env Mode (0 - 1) |

38

Fantom-G MIDI Implementation

| | | NO-SUS, SUSTAIN | |-------------+-----------+----------------------------------------------------| | 00 16 | 0aaa aaaa | Tone Dry Send Level (0 - 127) | | 00 17 | 0aaa aaaa | Tone Chorus Send Level (0 - 127) | | 00 18 | 0aaa aaaa | Tone Reverb Send Level (0 - 127) | | 00 19 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1A | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 1B | 0000 aaaa | (reserve) <*> (0 - 12) | | | | | |-------------+-----------+----------------------------------------------------| | 00 1C | 00aa aaaa | Tone Pitch Bend Range (0 - 48) | | 00 1D | 0000 000a | Tone Receive Expression (0 - 1) | | | | OFF, ON | | 00 1E | 0000 000a | Tone Receive Hold-1 (0 - 1) | | | | OFF, ON | | 00 1F | 0000 000a | Tone Receive Pan Mode (0 - 1) | | | | CONTINUOUS, KEY-ON | |-------------+-----------+----------------------------------------------------| | 00 20 | 0000 00aa | WMT Velocity Control (0 - 2) | | | | OFF, ON, RANDOM | |-------------+-----------+----------------------------------------------------| | 00 21 | 0000 000a | WMT1 Wave Switch (0 - 1) | | | | OFF, ON | | 00 22 | 0000 00aa | WMT1 Wave Group Type (0 - 3) | | | | INT, ---, SAMPLE, --- | |# 00 23 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT1 Wave Group ID (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 27 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT1 Wave Number L (Mono) (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 2B | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT1 Wave Number R (0 - 16384) | | | | OFF, 1 - 16384 | | 00 2F | 0000 00aa | WMT1 Wave Gain (0 - 3) | | | | -6, 0, +6, +12 [dB] | | 00 30 | 0000 000a | WMT1 Wave FXM Switch (0 - 1) | | | | OFF, ON | | 00 31 | 0000 00aa | WMT1 Wave FXM Color (0 - 3) | | | | 1 - 4 | | 00 32 | 000a aaaa | WMT1 Wave FXM Depth (0 - 16) | | 00 33 | 0000 000a | WMT1 Wave Tempo Sync (0 - 1) | | | | OFF, ON | | 00 34 | 0aaa aaaa | WMT1 Wave Coarse Tune (16 - 112) | | | | -48 - +48 | | 00 35 | 0aaa aaaa | WMT1 Wave Fine Tune (14 - 114) | | | | -50 - +50 | | 00 36 | 0aaa aaaa | WMT1 Wave Pan (0 - 127) | | | | L64 - 63R | | 00 37 | 0000 000a | WMT1 Wave Random Pan Switch (0 - 1) | | | | OFF, ON | | 00 38 | 0000 00aa | WMT1 Wave Alternate Pan Switch (0 - 2) | | | | OFF, ON, REVERSE | | 00 39 | 0aaa aaaa | WMT1 Wave Level (0 - 127) | | 00 3A | 0aaa aaaa | WMT1 Velocity Range Lower (1 - 127) | | | | 1 - UPPER | | 00 3B | 0aaa aaaa | WMT1 Velocity Range Upper (1 - 127) | | | | LOWER - 127 | | 00 3C | 0aaa aaaa | WMT1 Velocity Fade Width Lower (0 - 127) | | 00 3D | 0aaa aaaa | WMT1 Velocity Fade Width Upper (0 - 127) | | 00 3E | 0000 000a | WMT2 Wave Switch (0 - 1) | | | | OFF, ON | | 00 3F | 0000 00aa | WMT2 Wave Group Type (0 - 3) | | | | INT, ---, SAMPLE, --- | |# 00 40 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT2 Wave Group ID (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 44 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT2 Wave Number L (Mono) (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 48 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT2 Wave Number R (0 - 16384) | | | | OFF, 1 - 16384 | | 00 4C | 0000 00aa | WMT2 Wave Gain (0 - 3) | | | | -6, 0, +6, +12 [dB] | | 00 4D | 0000 000a | WMT2 Wave FXM Switch (0 - 1) | | | | OFF, ON | | 00 4E | 0000 00aa | WMT2 Wave FXM Color (0 - 3) | | | | 1 - 4 | | 00 4F | 000a aaaa | WMT2 Wave FXM Depth (0 - 16) | | 00 50 | 0000 000a | WMT2 Wave Tempo Sync (0 - 1) | | | | OFF, ON | | 00 51 | 0aaa aaaa | WMT2 Wave Coarse Tune (16 - 112) | | | | -48 - +48 | | 00 52 | 0aaa aaaa | WMT2 Wave Fine Tune (14 - 114) | | | | -50 - +50 | | 00 53 | 0aaa aaaa | WMT2 Wave Pan (0 - 127) | | | | L64 - 63R | | 00 54 | 0000 000a | WMT2 Wave Random Pan Switch (0 - 1) | | | | OFF, ON | | 00 55 | 0000 00aa | WMT2 Wave Alternate Pan Switch (0 - 2) | | | | OFF, ON, REVERSE | | 00 56 | 0aaa aaaa | WMT2 Wave Level (0 - 127) | | 00 57 | 0aaa aaaa | WMT2 Velocity Range Lower (1 - 127) | | | | 1 - UPPER | | 00 58 | 0aaa aaaa | WMT2 Velocity Range Upper (1 - 127) | | | | LOWER - 127 | | 00 59 | 0aaa aaaa | WMT2 Velocity Fade Width Lower (0 - 127) | | 00 5A | 0aaa aaaa | WMT2 Velocity Fade Width Upper (0 - 127) | | 00 5B | 0000 000a | WMT3 Wave Switch (0 - 1) | | | | OFF, ON | | 00 5C | 0000 00aa | WMT3 Wave Group Type (0 - 3) | | | | INT, ---, SAMPLE, --- | |# 00 5D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT3 Wave Group ID (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 61 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT3 Wave Number L (Mono) (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 65 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT3 Wave Number R (0 - 16384) | | | | OFF, 1 - 16384 | | 00 69 | 0000 00aa | WMT3 Wave Gain (0 - 3) | | | | -6, 0, +6, +12 [dB] | | 00 6A | 0000 000a | WMT3 Wave FXM Switch (0 - 1) | | | | OFF, ON | | 00 6B | 0000 00aa | WMT3 Wave FXM Color (0 - 3) | | | | 1 - 4 |

| 00 6C | 000a aaaa | WMT3 Wave FXM Depth (0 - 16) | | 00 6D | 0000 000a | WMT3 Wave Tempo Sync (0 - 1) | | | | OFF, ON | | 00 6E | 0aaa aaaa | WMT3 Wave Coarse Tune (16 - 112) | | | | -48 - +48 | | 00 6F | 0aaa aaaa | WMT3 Wave Fine Tune (14 - 114) | | | | -50 - +50 | | 00 70 | 0aaa aaaa | WMT3 Wave Pan (0 - 127) | | | | L64 - 63R | | 00 71 | 0000 000a | WMT3 Wave Random Pan Switch (0 - 1) | | | | OFF, ON | | 00 72 | 0000 00aa | WMT3 Wave Alternate Pan Switch (0 - 2) | | | | OFF, ON, REVERSE | | 00 73 | 0aaa aaaa | WMT3 Wave Level (0 - 127) | | 00 74 | 0aaa aaaa | WMT3 Velocity Range Lower (1 - 127) | | | | 1 - UPPER | | 00 75 | 0aaa aaaa | WMT3 Velocity Range Upper (1 - 127) | | | | LOWER - 127 | | 00 76 | 0aaa aaaa | WMT3 Velocity Fade Width Lower (0 - 127) | | 00 77 | 0aaa aaaa | WMT3 Velocity Fade Width Upper (0 - 127) | | 00 78 | 0000 000a | WMT4 Wave Switch (0 - 1) | | | | OFF, ON | | 00 79 | 0000 00aa | WMT4 Wave Group Type (0 - 3) | | | | INT, ---, SAMPLE, --- | |# 00 7A | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT4 Wave Group ID (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 7E | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT4 Wave Number L (Mono) (0 - 16384) | | | | OFF, 1 - 16384 | |# 01 02 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | WMT4 Wave Number R (0 - 16384) | | | | OFF, 1 - 16384 | | 01 06 | 0000 00aa | WMT4 Wave Gain (0 - 3) | | | | -6, 0, +6, +12 [dB] | | 01 07 | 0000 000a | WMT4 Wave FXM Switch (0 - 1) | | | | OFF, ON | | 01 08 | 0000 00aa | WMT4 Wave FXM Color (0 - 3) | | | | 1 - 4 | | 01 09 | 000a aaaa | WMT4 Wave FXM Depth (0 - 16) | | 01 0A | 0000 000a | WMT4 Wave Tempo Sync (0 - 1) | | | | OFF, ON | | 01 0B | 0aaa aaaa | WMT4 Wave Coarse Tune (16 - 112) | | | | -48 - +48 | | 01 0C | 0aaa aaaa | WMT4 Wave Fine Tune (14 - 114) | | | | -50 - +50 | | 01 0D | 0aaa aaaa | WMT4 Wave Pan (0 - 127) | | | | L64 - 63R | | 01 0E | 0000 000a | WMT4 Wave Random Pan Switch (0 - 1) | | | | OFF, ON | | 01 0F | 0000 00aa | WMT4 Wave Alternate Pan Switch (0 - 2) | | | | OFF, ON, REVERSE | | 01 10 | 0aaa aaaa | WMT4 Wave Level (0 - 127) | | 01 11 | 0aaa aaaa | WMT4 Velocity Range Lower (1 - 127) | | | | 1 - UPPER | | 01 12 | 0aaa aaaa | WMT4 Velocity Range Upper (1 - 127) | | | | LOWER - 127 | | 01 13 | 0aaa aaaa | WMT4 Velocity Fade Width Lower (0 - 127) | | 01 14 | 0aaa aaaa | WMT4 Velocity Fade Width Upper (0 - 127) | |-------------+-----------+----------------------------------------------------| | 01 15 | 000a aaaa | Pitch Env Depth (52 - 76) | | | | -12 - +12 | | 01 16 | 0aaa aaaa | Pitch Env Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 17 | 0aaa aaaa | Pitch Env Time 1 Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 18 | 0aaa aaaa | Pitch Env Time 4 Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 19 | 0aaa aaaa | Pitch Env Time 1 (0 - 127) | | 01 1A | 0aaa aaaa | Pitch Env Time 2 (0 - 127) | | 01 1B | 0aaa aaaa | Pitch Env Time 3 (0 - 127) | | 01 1C | 0aaa aaaa | Pitch Env Time 4 (0 - 127) | | 01 1D | 0aaa aaaa | Pitch Env Level 0 (1 - 127) | | | | -63 - +63 | | 01 1E | 0aaa aaaa | Pitch Env Level 1 (1 - 127) | | | | -63 - +63 | | 01 1F | 0aaa aaaa | Pitch Env Level 2 (1 - 127) | | | | -63 - +63 | | 01 20 | 0aaa aaaa | Pitch Env Level 3 (1 - 127) | | | | -63 - +63 | | 01 21 | 0aaa aaaa | Pitch Env Level 4 (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 01 22 | 0000 0aaa | TVF Filter Type (0 - 6) | | | | OFF, LPF, BPF, HPF, PKG, LPF2, | | | | LPF3 | | 01 23 | 0aaa aaaa | TVF Cutoff Frequency (0 - 127) | | 01 24 | 0000 0aaa | TVF Cutoff Velocity Curve (0 - 7) | | | | FIXED, 1 - 7 | | 01 25 | 0aaa aaaa | TVF Cutoff Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 26 | 0aaa aaaa | TVF Resonance (0 - 127) | | 01 27 | 0aaa aaaa | TVF Resonance Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 28 | 0aaa aaaa | TVF Env Depth (1 - 127) | | | | -63 - +63 | | 01 29 | 0000 0aaa | TVF Env Velocity Curve Type (0 - 7) | | | | FIXED, 1 - 7 | | 01 2A | 0aaa aaaa | TVF Env Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 2B | 0aaa aaaa | TVF Env Time 1 Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 2C | 0aaa aaaa | TVF Env Time 4 Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 2D | 0aaa aaaa | TVF Env Time 1 (0 - 127) | | 01 2E | 0aaa aaaa | TVF Env Time 2 (0 - 127) | | 01 2F | 0aaa aaaa | TVF Env Time 3 (0 - 127) | | 01 30 | 0aaa aaaa | TVF Env Time 4 (0 - 127) | | 01 31 | 0aaa aaaa | TVF Env Level 0 (0 - 127) | | 01 32 | 0aaa aaaa | TVF Env Level 1 (0 - 127) | | 01 33 | 0aaa aaaa | TVF Env Level 2 (0 - 127) | | 01 34 | 0aaa aaaa | TVF Env Level 3 (0 - 127) | | 01 35 | 0aaa aaaa | TVF Env Level 4 (0 - 127) | |-------------+-----------+----------------------------------------------------| | 01 36 | 0000 0aaa | TVA Level Velocity Curve (0 - 7) | | | | FIXED, 1 - 7 | | 01 37 | 0aaa aaaa | TVA Level Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 38 | 0aaa aaaa | TVA Env Time 1 Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 39 | 0aaa aaaa | TVA Env Time 4 Velocity Sens (1 - 127) | | | | -63 - +63 | | 01 3A | 0aaa aaaa | TVA Env Time 1 (0 - 127) | | 01 3B | 0aaa aaaa | TVA Env Time 2 (0 - 127) | | 01 3C | 0aaa aaaa | TVA Env Time 3 (0 - 127) | | 01 3D | 0aaa aaaa | TVA Env Time 4 (0 - 127) | | 01 3E | 0aaa aaaa | TVA Env Level 1 (0 - 127) | | 01 3F | 0aaa aaaa | TVA Env Level 2 (0 - 127) | | 01 40 | 0aaa aaaa | TVA Env Level 3 (0 - 127) | |-------------+-----------+----------------------------------------------------| | 01 41 | 0000 000a | One Shot Mode (0 - 1) | | | | OFF, ON |

39

Fantom-G MIDI Implementation

| 01 42 | 0aaa aaaa | Relative Level (0 - 127) | | | | -64 - +63 | |-------------+----------------------------------------------------------------| | 00 00 01 43 | Total Size | +------------------------------------------------------------------------------+

❍

Rhythm Controller

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | (reserve) <*> (0 - 3) | | | | | | 00 01 | 0aaa aaaa | (reserve) <*> (0 - 102) | | | | | | 00 02 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 03 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 04 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | | 00 05 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | | 00 06 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | | 00 07 | 0aaa aaaa | (reserve) <*> (0 - 103) | | | | | |-------------+-----------+----------------------------------------------------| | 00 08 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 09 | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0A | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0B | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0C | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0D | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0E | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | | 00 0F | 0aaa aaaa | (reserve) <*> (0 - 101) | | | | | |-------------+-----------+----------------------------------------------------| | 00 10 | 0aaa aaaa | (reserve) <*> (0 - 106) | | | | | | 00 11 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 12 | 0aaa aaaa | (reserve) <*> (0 - 106) | | | | | | 00 13 | 0000 000a | (reserve) <*> (0 - 1) | | | | | |-------------+----------------------------------------------------------------| | 00 00 00 14 | Total Size | +------------------------------------------------------------------------------+

❍

Rhythm Common 2

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Rhythm Name 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 01 | 0aaa aaaa | Rhythm Name 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 02 | 0aaa aaaa | Rhythm Name 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 03 | 0aaa aaaa | Rhythm Name 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 04 | 0aaa aaaa | Rhythm Name 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 05 | 0aaa aaaa | Rhythm Name 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 06 | 0aaa aaaa | Rhythm Name 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 07 | 0aaa aaaa | Rhythm Name 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 08 | 0aaa aaaa | Rhythm Name 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 09 | 0aaa aaaa | Rhythm Name 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0A | 0aaa aaaa | Rhythm Name 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0B | 0aaa aaaa | Rhythm Name 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0C | 0aaa aaaa | Rhythm Name 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0D | 0aaa aaaa | Rhythm Name 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0E | 0aaa aaaa | Rhythm Name 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0F | 0aaa aaaa | Rhythm Name 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 10 | 0aaa aaaa | Rhythm Memo 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 11 | 0aaa aaaa | Rhythm Memo 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 12 | 0aaa aaaa | Rhythm Memo 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 13 | 0aaa aaaa | Rhythm Memo 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 14 | 0aaa aaaa | Rhythm Memo 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 15 | 0aaa aaaa | Rhythm Memo 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 16 | 0aaa aaaa | Rhythm Memo 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 17 | 0aaa aaaa | Rhythm Memo 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 18 | 0aaa aaaa | Rhythm Memo 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 19 | 0aaa aaaa | Rhythm Memo 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1A | 0aaa aaaa | Rhythm Memo 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1B | 0aaa aaaa | Rhythm Memo 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1C | 0aaa aaaa | Rhythm Memo 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1D | 0aaa aaaa | Rhythm Memo 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1E | 0aaa aaaa | Rhythm Memo 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1F | 0aaa aaaa | Rhythm Memo 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 20 | 0aaa aaaa | Rhythm Memo 17 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 21 | 0aaa aaaa | Rhythm Memo 18 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 22 | 0aaa aaaa | Rhythm Memo 19 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 23 | 0aaa aaaa | Rhythm Memo 20 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 24 | 0aaa aaaa | Rhythm Memo 21 (32 - 127) |

| | | 32 - 127 [ASCII] | | 00 25 | 0aaa aaaa | Rhythm Memo 22 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 26 | 0aaa aaaa | Rhythm Memo 23 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 27 | 0aaa aaaa | Rhythm Memo 24 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 28 | 0aaa aaaa | Rhythm Memo 25 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 29 | 0aaa aaaa | Rhythm Memo 26 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2A | 0aaa aaaa | Rhythm Memo 27 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2B | 0aaa aaaa | Rhythm Memo 28 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2C | 0aaa aaaa | Rhythm Memo 29 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2D | 0aaa aaaa | Rhythm Memo 30 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2E | 0aaa aaaa | Rhythm Memo 31 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2F | 0aaa aaaa | Rhythm Memo 32 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 30 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 31 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 32 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 33 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 34 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 35 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 36 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 37 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 39 | 0000 000a | Rhythm MFX Switch (0 - 1) | | | | OFF, ON | | 00 3A | 0000 000a | Chorus Switch (0 - 1) | | | | OFF, ON | | 00 3B | 0000 000a | Reverb Switch (0 - 1) | | | | OFF, ON | |-------------+----------------------------------------------------------------| | 00 00 00 3C | Total Size | +------------------------------------------------------------------------------+

❍

Rhythm Tone 2

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Tone Output Assign (0 - 1) | | | | PFX, DRY | |-------------+-----------+----------------------------------------------------| | 00 01 | 0000 0aaa | (reserve) <*> (0 - 6) | | | | | | 00 02 | 0000 aaaa | (reserve) <*> (58 - 70) | | | | | | 00 03 | 0000 aaaa | (reserve) <*> (0 - 15) | | | | | | 00 04 | 0000 aaaa | (reserve) <*> (58 - 70) | | | | | | 00 05 | 0000 00aa | (reserve) <*> (0 - 3) | | | | | | 00 06 | 0000 aaaa | (reserve) <*> (0 - 9) | | | | | | 00 07 | 0000 aaaa | (reserve) <*> (58 - 70) | | | | | |-------------+----------------------------------------------------------------| | 00 00 00 08 | Total Size | +------------------------------------------------------------------------------+

❍

Sample Set Common

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Sample Set Name 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 01 | 0aaa aaaa | Sample Set Name 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 02 | 0aaa aaaa | Sample Set Name 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 03 | 0aaa aaaa | Sample Set Name 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 04 | 0aaa aaaa | Sample Set Name 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 05 | 0aaa aaaa | Sample Set Name 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 06 | 0aaa aaaa | Sample Set Name 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 07 | 0aaa aaaa | Sample Set Name 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 08 | 0aaa aaaa | Sample Set Name 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 09 | 0aaa aaaa | Sample Set Name 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0A | 0aaa aaaa | Sample Set Name 11 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0B | 0aaa aaaa | Sample Set Name 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0C | 0aaa aaaa | Sample Set Name 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0D | 0aaa aaaa | Sample Set Name 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0E | 0aaa aaaa | Sample Set Name 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 0F | 0aaa aaaa | Sample Set Name 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 10 | 0aaa aaaa | Sample Set Memo 1 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 11 | 0aaa aaaa | Sample Set Memo 2 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 12 | 0aaa aaaa | Sample Set Memo 3 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 13 | 0aaa aaaa | Sample Set Memo 4 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 14 | 0aaa aaaa | Sample Set Memo 5 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 15 | 0aaa aaaa | Sample Set Memo 6 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 16 | 0aaa aaaa | Sample Set Memo 7 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 17 | 0aaa aaaa | Sample Set Memo 8 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 18 | 0aaa aaaa | Sample Set Memo 9 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 19 | 0aaa aaaa | Sample Set Memo 10 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1A | 0aaa aaaa | Sample Set Memo 11 (32 - 127) |

40

Fantom-G MIDI Implementation

| | | 32 - 127 [ASCII] | | 00 1B | 0aaa aaaa | Sample Set Memo 12 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1C | 0aaa aaaa | Sample Set Memo 13 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1D | 0aaa aaaa | Sample Set Memo 14 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1E | 0aaa aaaa | Sample Set Memo 15 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 1F | 0aaa aaaa | Sample Set Memo 16 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 20 | 0aaa aaaa | Sample Set Memo 17 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 21 | 0aaa aaaa | Sample Set Memo 18 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 22 | 0aaa aaaa | Sample Set Memo 19 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 23 | 0aaa aaaa | Sample Set Memo 20 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 24 | 0aaa aaaa | Sample Set Memo 21 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 25 | 0aaa aaaa | Sample Set Memo 22 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 26 | 0aaa aaaa | Sample Set Memo 23 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 27 | 0aaa aaaa | Sample Set Memo 24 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 28 | 0aaa aaaa | Sample Set Memo 25 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 29 | 0aaa aaaa | Sample Set Memo 26 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2A | 0aaa aaaa | Sample Set Memo 27 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2B | 0aaa aaaa | Sample Set Memo 28 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2C | 0aaa aaaa | Sample Set Memo 29 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2D | 0aaa aaaa | Sample Set Memo 30 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2E | 0aaa aaaa | Sample Set Memo 31 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 2F | 0aaa aaaa | Sample Set Memo 32 (32 - 127) | | | | 32 - 127 [ASCII] | | 00 30 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 31 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 32 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 33 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 34 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 35 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 36 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 37 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | | 00 38 | 0aaa aaaa | (reserve) <*> (0 - 127) | | | | | |-------------+-----------+----------------------------------------------------| | 00 39 | 0aaa aaaa | Sample Set Level (0 - 127) | |-------------+-----------+----------------------------------------------------| | 00 3A | 0000 000a | Sample Set MFX Switch (0 - 1) | | | | OFF, ON | | 00 3B | 0000 000a | Chorus Switch (0 - 1) | | | | OFF, ON | | 00 3C | 0000 000a | Reverb Switch (0 - 1) | | | | OFF, ON | |-------------+----------------------------------------------------------------| | 00 00 00 3D | Total Size | +------------------------------------------------------------------------------+

❍

Sample Set Common MFX

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | MFX Type (0 - 76) | | 00 01 | 0aaa aaaa | MFX Dry Send Level (0 - 127) | | 00 02 | 0aaa aaaa | MFX Chorus Send Level (0 - 127) | | 00 03 | 0aaa aaaa | MFX Reverb Send Level (0 - 127) | | 00 04 | 0000 00aa | (reserve) <*> (0 - 3) | | | | | |-------------+-----------+----------------------------------------------------| | 00 05 | 0aaa aaaa | MFX Control 1 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 06 | 0aaa aaaa | MFX Control 1 Sens (1 - 127) | | | | -63 - +63 | | 00 07 | 0aaa aaaa | MFX Control 2 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 08 | 0aaa aaaa | MFX Control 2 Sens (1 - 127) | | | | -63 - +63 | | 00 09 | 0aaa aaaa | MFX Control 3 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 0A | 0aaa aaaa | MFX Control 3 Sens (1 - 127) | | | | -63 - +63 | | 00 0B | 0aaa aaaa | MFX Control 4 Source (0 - 101) | | | | OFF, CC01 - CC31, CC33 - CC95, | | | | BEND, AFT, SYS1 - SYS4 | | 00 0C | 0aaa aaaa | MFX Control 4 Sens (1 - 127) | | | | -63 - +63 | |-------------+-----------+----------------------------------------------------| | 00 0D | 000a aaaa | MFX Control Assign 1 (0 - 16) | | | | OFF, 1 - 16 | | 00 0E | 000a aaaa | MFX Control Assign 2 (0 - 16) | | | | OFF, 1 - 16 | | 00 0F | 000a aaaa | MFX Control Assign 3 (0 - 16) | | | | OFF, 1 - 16 | | 00 10 | 000a aaaa | MFX Control Assign 4 (0 - 16) | | | | OFF, 1 - 16 | |# 00 11 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 1 (12768 - 52768) | | | | -20000 - +20000 | |# 00 15 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 19 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | MFX Parameter 4 (12768 - 52768) | | | | -20000 - +20000 | |# 00 21 | 0000 aaaa | | | | 0000 bbbb | |

41

Fantom-G MIDI Implementation

|-------------+----------------------------------------------------------------| | 00 00 01 11 | Total Size | +------------------------------------------------------------------------------+

❍

Sample Set Common Chorus

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 aaaa | Chorus Type (0 - 3) | | 00 01 | 0aaa aaaa | Chorus Level (0 - 127) | | 00 02 | 0000 000a | Chorus Output Assign (0 - 1) | | | | A, B | | 00 03 | 0000 000a | (reserve) <*> (0 - 1) | | | | | | 00 04 | 0000 00aa | Chorus Output Select (0 - 2) | | | | MAIN, REV, MAIN+REV | |-------------+-----------+----------------------------------------------------| |# 00 05 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 1 (12768 - 52768) | | | | -20000 - +20000 | |# 00 09 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 0D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 11 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 4 (12768 - 52768) | | | | -20000 - +20000 | |# 00 15 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 5 (12768 - 52768) | | | | -20000 - +20000 | |# 00 19 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 6 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 7 (12768 - 52768) | | | | -20000 - +20000 | |# 00 21 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 8 (12768 - 52768) | | | | -20000 - +20000 | |# 00 25 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 9 (12768 - 52768) | | | | -20000 - +20000 | |# 00 29 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 10 (12768 - 52768) | | | | -20000 - +20000 | |# 00 2D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 11 (12768 - 52768) | | | | -20000 - +20000 | |# 00 31 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 12 (12768 - 52768) | | | | -20000 - +20000 | |# 00 35 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 13 (12768 - 52768) | | | | -20000 - +20000 | |# 00 39 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 14 (12768 - 52768) | | | | -20000 - +20000 | |# 00 3D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 15 (12768 - 52768) | | | | -20000 - +20000 | |# 00 41 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 16 (12768 - 52768) | | | | -20000 - +20000 | |# 00 45 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 17 (12768 - 52768) | | | | -20000 - +20000 | |# 00 49 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 18 (12768 - 52768) | | | | -20000 - +20000 | |# 00 4D | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 19 (12768 - 52768) | | | | -20000 - +20000 | |# 00 51 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Chorus Parameter 20 (12768 - 52768) | | | | -20000 - +20000 | |-------------+----------------------------------------------------------------| | 00 00 00 55 | Total Size | +------------------------------------------------------------------------------+

❍

Sample Set Common Reverb

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0aaa aaaa | Reverb Type (0 - 10) | | 00 01 | 0aaa aaaa | Reverb Level (0 - 127) | | 00 02 | 0000 00aa | Reverb Output Assign (0 - 1) | | | | A, B | |-------------+-----------+----------------------------------------------------| |# 00 03 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 1 (12768 - 52768) |

| | | -20000 - +20000 | |# 00 07 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 2 (12768 - 52768) | | | | -20000 - +20000 | |# 00 0B | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 3 (12768 - 52768) | | | | -20000 - +20000 | |# 00 0F | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 4 (12768 - 52768) | | | | -20000 - +20000 | |# 00 13 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 5 (12768 - 52768) | | | | -20000 - +20000 | |# 00 17 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 6 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1B | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 7 (12768 - 52768) | | | | -20000 - +20000 | |# 00 1F | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 8 (12768 - 52768) | | | | -20000 - +20000 | |# 00 23 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 9 (12768 - 52768) | | | | -20000 - +20000 | |# 00 27 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 10 (12768 - 52768) | | | | -20000 - +20000 | |# 00 2B | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 11 (12768 - 52768) | | | | -20000 - +20000 | |# 00 2F | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 12 (12768 - 52768) | | | | -20000 - +20000 | |# 00 33 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 13 (12768 - 52768) | | | | -20000 - +20000 | |# 00 37 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 14 (12768 - 52768) | | | | -20000 - +20000 | |# 00 3B | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 15 (12768 - 52768) | | | | -20000 - +20000 | |# 00 3F | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 16 (12768 - 52768) | | | | -20000 - +20000 | |# 00 43 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 17 (12768 - 52768) | | | | -20000 - +20000 | |# 00 47 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 18 (12768 - 52768) | | | | -20000 - +20000 | |# 00 4B | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 19 (12768 - 52768) | | | | -20000 - +20000 | |# 00 4F | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Reverb Parameter 20 (12768 - 52768) | | | | -20000 - +20000 | |-------------+----------------------------------------------------------------| | 00 00 00 53 | Total Size | +------------------------------------------------------------------------------+

❍

Sample Set Tone

+------------------------------------------------------------------------------+ | Offset | | | Address | Description | |-------------+----------------------------------------------------------------| | 00 00 | 0000 000a | Direction (0 - 1) | | | | FWD, REV | | 00 01 | 0000 00aa | Trigger Mode (0 - 1) | | | | GATE, DRUM | | 00 02 | 000a aaaa | Mute Group (0 - 16) | | | | OFF, 1 - 16 | |-------------+-----------+----------------------------------------------------| |# 00 03 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Wave Group ID (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 07 | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Wave Number L (Mono) (0 - 16384) | | | | OFF, 1 - 16384 | |# 00 0B | 0000 aaaa | | | | 0000 bbbb | | | | 0000 cccc | | | | 0000 dddd | Wave Number R (0 - 16384) | | | | OFF, 1 - 16384 | | 00 0F | 0000 00aa | Wave Gain (0 - 3) | | | | -6, 0, +6, +12 [dB] | | 00 10 | 0000 000a | Tempo Sync (0 - 1) | | | | OFF, ON | |-------------+-----------+----------------------------------------------------| | 00 11 | 0aaa aaaa | Tone Level (0 - 127) | | 00 12 | 0aaa aaaa | Tone Coarse Tune (16 - 112) | | | | -48 - +48 | | 00 13 | 0aaa aaaa | Tone Fine Tune (14 - 114) | | | | -50 - +50 |

42

| 00 14 | 0aaa aaaa | Tone Pan (0 - 127) | | | | L64 - 63R | |-------------+-----------+----------------------------------------------------| | 00 15 | 0aaa aaaa | Tone Output Level (0 - 127) | | 00 16 | 0aaa aaaa | Tone Chorus Send Level (0 - 127) | | 00 17 | 0aaa aaaa | Tone Reverb Send Level (0 - 127) | | 00 18 | 0aaa aaaa | Tone Output Assign (0 - 1) | | | | PFX, DRY | |-------------+-----------+----------------------------------------------------| | 00 19 | 0aaa aaaa | Level Velocity Sens (1 - 127) | | | | -63 - +63 | |-------------+----------------------------------------------------------------| | 00 00 00 1A | Total Size | +------------------------------------------------------------------------------+ m: Map number (0 = MAP1, 1 = MAP2) rr: drum part note number (00H-7FH)

Fantom-G MIDI Implementation

43

Fantom-G MIDI Implementation

6. Supplementary Material

■

Examples of Actual MIDI Messages

■

Decimal and Hexadecimal Table

(An “H” is appended to the end of numbers in hexadecimal notation.)

In MIDI documentation, data values and addresses/sizes of Exclusive messages, etc. are

expressed as hexadecimal values for each 7 bits.

The following table shows how these correspond to decimal numbers.

+——————+——————++——————+——————++——————+——————++——————+——————+ | D | H || D | H || D | H || D | H | +——————+——————++——————+——————++——————+——————++——————+——————+ | 0 | 00H || 32 | 20H || 64 | 40H || 96 | 60H | | 1 | 01H || 33 | 21H || 65 | 41H || 97 | 61H | | 2 | 02H || 34 | 22H || 66 | 42H || 98 | 62H | | 3 | 03H || 35 | 23H || 67 | 43H || 99 | 63H | | 4 | 04H || 36 | 24H || 68 | 44H || 100 | 64H | | 5 | 05H || 37 | 25H || 69 | 45H || 101 | 65H | | 6 | 06H || 38 | 26H || 70 | 46H || 102 | 66H | | 7 | 07H || 39 | 27H || 71 | 47H || 103 | 67H | | 8 | 08H || 40 | 28H || 72 | 48H || 104 | 68H | | 9 | 09H || 41 | 29H || 73 | 49H || 105 | 69H | | 10 | 0AH || 42 | 2AH || 74 | 4AH || 106 | 6AH | | 11 | 0BH || 43 | 2BH || 75 | 4BH || 107 | 6BH | | 12 | 0CH || 44 | 2CH || 76 | 4CH || 108 | 6CH | | 13 | 0DH || 45 | 2DH || 77 | 4DH || 109 | 6DH | | 14 | 0EH || 46 | 2EH || 78 | 4EH || 110 | 6EH | | 15 | 0FH || 47 | 2FH || 79 | 4FH || 111 | 6FH | | 16 | 10H || 48 | 30H || 80 | 50H || 112 | 70H | | 17 | 11H || 49 | 31H || 81 | 51H || 113 | 71H | | 18 | 12H || 50 | 32H || 82 | 52H || 114 | 72H | | 19 | 13H || 51 | 33H || 83 | 53H || 115 | 73H | | 20 | 14H || 52 | 34H || 84 | 54H || 116 | 74H | | 21 | 15H || 53 | 35H || 85 | 55H || 117 | 75H | | 22 | 16H || 54 | 36H || 86 | 56H || 118 | 76H | | 23 | 17H || 55 | 37H || 87 | 57H || 119 | 77H | | 24 | 18H || 56 | 38H || 88 | 58H || 120 | 78H | | 25 | 19H || 57 | 39H || 89 | 59H || 121 | 79H | | 26 | 1AH || 58 | 3AH || 90 | 5AH || 122 | 7AH | | 27 | 1BH || 59 | 3BH || 91 | 5BH || 123 | 7BH | | 28 | 1CH || 60 | 3CH || 92 | 5CH || 124 | 7CH | | 29 | 1DH || 61 | 3DH || 93 | 5DH || 125 | 7DH | | 30 | 1EH || 62 | 3EH || 94 | 5EH || 126 | 7EH | | 31 | 1FH || 63 | 3FH || 95 | 5FH || 127 | 7FH | +——————+——————++——————+——————++——————+——————++——————+——————+

D: decimal

H: hexadecimal

* Decimal values such as MIDI channel, bank select, and program change are listed as one

greater than the values given in the above table.

* A 7-bit byte can express data in the range of 128 steps. For data where greater precision

is required, we must use two or more bytes. For example, two hexadecimal numbers aa

bbH expressing two 7-bit bytes would indicate a value of aa x 128+bb.

* In the case of values which have a +/- sign, 00H = -64, 40H = +/-0, and 7FH = +63, so

that the decimal expression would be 64 less than the value given in the above chart. In

the case of two types, 00 00H = -8192, 40 00H = +/-0, and 7F 7FH = +8191. For example, if

aa bbH were expressed as decimal, this would be aa bbH - 40 00H = aa x 128+bb - 64 x

128.

* Data marked “Use nibbled data” is expressed in hexadecimal in 4-bit units. A value

expressed as a 2-byte nibble 0a 0bH has the value of a x 16+b.

<Example1> What is the decimal expression of 5AH?

From the preceding table, 5AH = 90

<Example2> What is the decimal expression of the value 12 34H given as

hexadecimal for each 7 bits?

From the preceding table, since 12H = 18 and 34H = 52

18 x 128+52 = 2356

<Example3> What is the decimal expression of the nibbled value 0A 03

09 0D?

From the preceding table, since 0AH = 10, 03H = 3, 09H = 9, 0DH = 13

((10 x 16+3) x 16+9) x 16+13 = 41885

<Example1> 92 3E 5F

9n is the Note-on status, and n is the MIDI channel number. Since 2H = 2, 3EH = 62, and

5FH = 95, this is a Note-on message with MIDI CH = 3, note number 62 (note name is D4),

and velocity 95.

<Example2> CE 49

CnH is the Program Change status, and n is the MIDI channel number. Since EH = 14 and

49H = 73, this is a Program Change message with MIDI CH = 15, program number 74.

<Example3> EA 00 28

EnH is the Pitch Bend Change status, and n is the MIDI channel number. The 2nd byte (00H

= 0) is the LSB and the 3rd byte (28H = 40) is the MSB, but Pitch Bend Value is a signed

number in which 40 00H (= 64 x 12+80 = 8192) is 0, so this Pitch Bend Value is

28 00H - 40 00H = 40 x 12+80 - (64 x 12+80) = 5120 - 8192 = -3072

If the Pitch Bend Sensitivity is set to 2 semitones, -8192 (00 00H) will cause the pitch to

change -200 cents, so in this case -200 x (-3072) é÷ (-8192) = -75 cents of Pitch Bend is being

applied to MIDI channel 11.

<Example4> B3 64 00 65 00 06 0C 26 00 64 7F 65 7F

BnH is the Control Change status, and n is the MIDI channel number. For Control Changes,

the 2nd byte is the control number, and the 3rd byte is the value. In a case in which two or

more messages consecutive messages have the same status, MIDI has a provision called

“running status” which allows the status byte of the second and following messages to be

omitted. Thus, the above messages have the following meaning.

B3 64 00 MIDI ch.4, lower byte of RPN parameter number: 00H

(B3) 65 00 (MIDI ch.4) upper byte of RPN parameter number: 00H

(B3) 06 0C (MIDI ch.4) upper byte of parameter value: 0CH

(B3) 26 00 (MIDI ch.4) lower byte of parameter value: 00H

(B3) 64 7F (MIDI ch.4) lower byte of RPN parameter number: 7FH

(B3) 65 7F (MIDI ch.4) upper byte of RPN parameter number: 7FH

In other words, the above messages specify a value of 0C 00H for RPN parameter number

00 00H on MIDI channel 4, and then set the RPN parameter number to 7F 7FH.

RPN parameter number 00 00H is Pitch Bend Sensitivity, and the MSB of the value indicates

semitone units, so a value of 0CH = 12 sets the maximum pitch bend range to +/-12

semitones (1 octave). (The LSB of Pitch Bend Sensitivity is ignored, but the LSB should be

transmitted anyway (with a value of 0) so that operation will be correct on any device.)

Once the parameter number has been specified for RPN or NRPN, all Data Entry messages

transmitted on that same channel will be valid, so after the desired value has been

transmitted, it is a good idea to set the parameter number to 7F 7FH to prevent accidents.

This is the reason for the (B3) 64 7F (B3) 65 7F at the end.

It is not desirable for performance data (such as Standard MIDI File data) to contain many

events with running status as given in <Example 4>. This is because if playback is halted

during the song and then rewound or fast-forwarded, the sequencer may not be able to

transmit the correct status, and the sound generator will then misinterpret the data. Take

care to give each event its own status.

It is also necessary that the RPN or NRPN parameter number setting and the value setting

be done in the proper order. On some sequencers, events occurring in the same (or

consecutive) clock may be transmitted in an order different than the order in which they

were received. For this reason it is a good idea to slightly skew the time of each event (about

1 tick for TPQN = 96, and about 5 ticks for TPQN = 480).

* TPQN: Ticks Per Quarter Note

<Example4> What is the nibbled expression of the decimal value 1258?

16 ) 1258 16 ) 78 ...10 16 ) 4 ...14 0 ... 4

Since from the preceding table, 0 = 00H, 4 = 04H, 14 = 0EH, 10 = 0AH, the result is: 00 04 0E

0AH.

44

■

Example of an Exclusive Message and Calculating a Checksum

Roland Exclusive messages (RQ1, DT1) are transmitted with a checksum at the end (before

F7) to make sure that the message was correctly received. The value of the checksum is

determined by the address and data (or size) of the transmitted Exclusive message.

●

How to calculate the checksum

(hexadecimal numbers are indicated by “H”)

The checksum is a value derived by adding the address, size, and checksum itself and

inverting the lower 7 bits.

Here’s an example of how the checksum is calculated. We will assume that in the Exclusive

message we are transmitting, the address is aabbccddH and the data or size is eeffH.

aa + bb + cc + dd + ee + ff = sum

sum ÷ 128 = quotient ... remainder

128 - remainder = checksum

Fantom-G MIDI Implementation

■

The Scale Tune Feature (address: 40 1x 40)

The scale tune feature allows you to finely adjust the individual pitch of the notes from C

through B. Though the settings are made while working with one octave, the fine

adjustments will affect all octaves. By making the appropriate Scale Tune settings, you can

obtain a complete variety of tuning methods other than equal temperament. As examples,

three possible types of scale setting are explained below.

* The scale tune value received by the part 1 is used in Patch mode and Piano mode.

❍

Equal Temperament

This method of tuning divides the octave into 12 equal parts. It is currently the most widely

used form of tuning, especially in occidental music. On the Fantom, the default settings for

the Scale Tune feature produce equal temperament.

❍

Just Temperament (Tonic of C)

The principal triads resound much more beautifully than with equal temperament, but this

benefit can only be obtained in one key. If transposed, the chords tend to become

ambiguous. The example given involves settings for a key in which C is the keynote.

<Example> Setting CHORUS TYPE of LIVE SET to DELAY (DT1)

According to the

10 00 00 00H, the offset address of CHORUS at Live Set COMMON is 06 00H, and the

address of CHORUS TYPE is 00 00H. Therefore the address of CHORUS TYPE of

PERFORMANCE COMMON is;

10 00 00 00H 06 00H +) 00 00H 10 00 06 00H

DELAY has the value of 02H.

So the system exclusive message should be sent is;

F0 41 10 00 0027 12 10 00 06 00 02 ?? F7

(1) (2) (3) (4) (5) address data checksum (6)

(1) Exclusive Status (2) ID (Roland) (3) Device ID (17)

(4) Model ID (Fantom-G6/G7/G8) (5) Command ID (DT1) (6) End of Exclusive

Then calculate the checksum.

10H + 00H + 06H + 00H + 02H = 16 + 0 + 6 + 0 + 2 = 24 (sum)

24 (sum) ÷ 128 = 0 (quotient) ... 24 (remainder)

checksum = 128 - 24 (remainder) = 104 = 68H

This means that F0 41 10 00 27 12 10 00 06 00 02 68 F7 is the message should be sent.

Parameter Address Map

(P.14), the start address of Temporary Live Set is

❍

Arabian Scale

By altering the setting for Scale Tune, you can obtain a variety of other tunings suited for

ethnic music. For example, the settings introduced below will set the unit to use the Arabian

Scale.

Example Settings

Note name

C0 0 -6

C# 0 -8 +45

D 0 +4 -2

Eb 0 +16 -12

E 0 -14 -51

F 0 -2 -8

F# 0 -10 +43

G 0 +2 -4

G# 0 +14 +47

A 0 -16 0

Bb 0 +14 -10

B 0 -12 -49

The values in the table are given in cents. Convert these values to hexadecimal, and transmit

them as Exclusive data.

For example, to set the tune (C-B) of the Part 1 Arabian Scale, send the following data:

F0 41 10 42 12 40 11 40 3A 6D 3E 34 0D 38 6B 3C 6F 40 36 0F 76 F7

■

ASCII Code Table

Patch Name and Live Set Name, etc., of MIDI data are described the ASCII

code in the table below.

+——————+——————+——————++——————+——————+——————++——————+——————+——————+ | D | H | Char || D | H | Char || D | H | Char | +——————+——————+——————++——————+——————+——————++——————+——————+——————+ | 32 | 20H | SP || 64 | 40H | @ || 96 | 60H | ` | | 33 | 21H | ! || 65 | 41H | A || 97 | 61H | a | | 34 | 22H | " || 66 | 42H | B || 98 | 62H | b | | 35 | 23H | # || 67 | 43H | C || 99 | 63H | c | | 36 | 24H | $ || 68 | 44H | D || 100 | 64H | d | | 37 | 25H | % || 69 | 45H | E || 101 | 65H | e | | 38 | 26H | & || 70 | 46H | F || 102 | 66H | f | | 39 | 27H | ` || 71 | 47H | G || 103 | 67H | g | | 40 | 28H | ( || 72 | 48H | H || 104 | 68H | h | | 41 | 29H | ) || 73 | 49H | I || 105 | 69H | i | | 42 | 2AH | * || 74 | 4AH | J || 106 | 6AH | j | | 43 | 2BH | + || 75 | 4BH | K || 107 | 6BH | k | | 44 | 2CH | , || 76 | 4CH | L || 108 | 6CH | l | | 45 | 2DH | — || 77 | 4DH | M || 109 | 6DH | m | | 46 | 2EH | . || 78 | 4EH | N || 110 | 6EH | n | | 47 | 2FH | / || 79 | 4FH | O || 111 | 6FH | o | | 48 | 30H | 0 || 80 | 50H | P || 112 | 70H | p | | 49 | 31H | 1 || 81 | 51H | Q || 113 | 71H | q | | 50 | 32H | 2 || 82 | 52H | R || 114 | 72H | r | | 51 | 33H | 3 || 83 | 53H | S || 115 | 73H | s | | 52 | 34H | 4 || 84 | 54H | T || 116 | 74H | t | | 53 | 35H | 5 || 85 | 55H | U || 117 | 75H | u | | 54 | 36H | 6 || 86 | 56H | V || 118 | 76H | v | | 55 | 37H | 7 || 87 | 57H | W || 119 | 77H | w | | 56 | 38H | 8 || 88 | 58H | X || 120 | 78H | x | | 57 | 39H | 9 || 89 | 59H | Y || 121 | 79H | y | | 58 | 3AH | : || 90 | 5AH | Z || 122 | 7AH | z | | 59 | 3BH | ; || 91 | 5BH | [ || 123 | 7BH | { | | 60 | 3CH | < || 92 | 5CH | \ || 124 | 7CH | | | | 61 | 3DH | = || 93 | 5DH | ] || 125 | 7DH | } | | 62 | 3EH | > || 94 | 5EH | ^ ||——————+——————+——————+ | 63 | 3FH | ? || 95 | 5FH | _ | +——————+——————+——————++——————+——————+——————+

D: decimal

H: hexadecimal

Equal Temperament Just Temperament (Key-tone C) Arabian Scale

* “SP” is space.

45

(Sound Generator Section) Model Fantom-G6/G7/G8

MIDI Implementation Chart

Date : Feb. 1, 2008

Version : 1.00

Basic Channel

Mode

Note Number :

Velocity

After Touch

Pitch Bend

Control Change

Function...

Default Changed

Default Messages Altered

True Voice

Note On Note Off

Key’s Channel’s

1–31, 33–95

0, 32

6, 38

96, 97

98, 99 100, 101 102–119

1 5

7 10 11 64 65 66 67 68 71 72 73 74 75 76 77 78 80 81 82 83 84 91 93

Transmitted Recognized

1–16 1–16

Mode 3 Mono, Poly

**************

0–127

**************

O O

O

O O O O O O O O O O O O O O O O O O O O O O O O O O O O X X X X

*1

1–16 1–16

Mode 3 Mode 3, 4 (M = 1)

0–127 0–127

O O

O *1 O *1

O *1

O O O O O O O O O O O O O O O O O O O O O (Tone 1 Level) O (Tone 2 Level) O (Tone 3 Level) O (Tone 4 Level) O O (Reverb) O (Chorus) O X X O X

Remarks

* 2

*1 *1

*1 *1 *1 *1

Bank select Modulation Portamento time Data entry Volume Panpot Expression Hold 1 Portamento Sostenuto Soft Legato foot switch Resonance Release time Attack time Cutoff Decay time Vibrato rate Vibrato depth Vibrato delay General purpose controller 5 General purpose controller 6 General purpose controller 7 General purpose controller 8 Portamento control General purpose effects 1 General purpose effects 3 General purpose controller Increment, Decrement NRPN LSB, MSB RPN LSB, MSB Undefined

Program Change

: True Number

System Exclusive

System Common

System Real Time

Aux Messages

: Song Position : Song Select : Tune Request

: Clock : Commands

: All Sound Off : Reset All Controllers : Local On/Off : All Notes Off : Active Sensing : System Reset

Notes

Mode 1 : OMNI ON, POLY Mode 3 : OMNI OFF, POLY

O *1

**************

O

X X X

X X

X X X X O *1 X

O *1 0–127

O *1

X X X

X X

O O X O (123–127) O X

* 1 O X is selectable. * 2 Recognized as M=1 even if M≠1.

Mode 2 : OMNI ON, MONO Mode 4 : OMNI OFF, MONO

Program No. 1–128

O : Yes X : No

(Sequencer Section)

Date : Feb. 1, 2008

Model Fantom-G6/G7/G8

Function...

Basic Channel

Mode

Note Number :

Velocity

After Touch

Pitch Bend

Default Changed

Default Messages Altered

True Voice

Note On Note Off

Key's Channel's

0–119

MIDI Implementation Chart

Transmitted Recognized

All channel X

X X

**************

0–127

**************

O O

O

All channel 1–16

X X

0–127 0–127

O O

O *1 O *1

O *1

O

*1

Version : 1.00

Remarks

There is no specific basic channel.

Control Change

Program Change

: True Number

System Exclusive

: Quarter Frames

System Common

: Song Position : Song Select : Tune Request

System Real Time

Aux Messages

: Clock : Commands

: All Sound Off : Reset All Controllers : Local On/Off : All Notes Off : Active Sensing : System Reset

Notes

Mode 1 : OMNI ON, POLY Mode 3 : OMNI OFF, POLY

O

**************

O

O *1 O *1 X O

O *1 O *1

O O X *2 O *3 O X

*1 O X is selectable. *2 Not stored/transmitted when received, but can be created and transmitted using Microscope. *3 Mode Messages (123–127) are recorded and transmitted, after all currently sounding notes are turned off. The All Note Message itself is not recorded or transmitted. However, it can be created in Microscope and transmitted.

Mode 2 : OMNI ON, MONO Mode 4 : OMNI OFF, MONO

O *1 0–127

O *1

O *2 O *1 X O

O *1 O *1

O O X O (123–127) *3 O X

O : Yes X : No

1PDFFantom-G

Roland Corporation Fantom-G7, Fantom-G8, Fantom-G6 User's Manual

Specifications and Main Features

Frequently Asked Questions

User Manual

1. Receive Data (Sound Source Section)

Channel Voice Messages

Note off

Note on

Polyphonic Key Pressure

Control Change

Bank Select (Controller number 0, 32)

Modulation (Controller number 1)

Portamento Time (Controller number 5)

Data Entry (Controller number 6, 38)

Volume (Controller number 7)

Panpot (Controller number 10)

Expression (Controller number 11)

Hold 1 (Controller number 64)

Portamento (Controller number 65)

Sostenuto (Controller number 66)

Soft (Controller number 67)

Legato Foot Switch (Controller number 68)

Resonance (Controller number 71)

Release Time (Controller number 72)

Attack time (Controller number 73)

Cutoff (Controller number 74)

Decay Time (Controller number 75)

Vibrato Rate (Controller number 76)

Vibrato Depth (Controller number 77)

General Purpose Controller 5 (Controller number 80)

General Purpose Controller 6 (Controller number 81)

General Purpose Controller 7 (Controller number 82)

General Purpose Controller 8 (Controller number 83)

Portamento control (Controller number 84)

Effect 1 (Reverb Send Level) (Controller number 91)

Effect 3 (Chorus Send Level) (Controller number 93)

RPN MSB/LSB (Controller number 100, 101)

Vibrato Delay (Controller number 78)

General Controller

Program Change

Channel Pressure

Pitch Bend Change

Channel Mode Messages

All Sounds Off (Controller number 120)

Reset All Controllers (Controller number 121)

All Notes Off (Controller number 123)

OMNI OFF (Controller number 124)

OMNI ON (Controller number 125)

MONO (Controller number 126)

POLY (Controller number 127)

System Realtime Message

Timing Clock

Active Sensing

System Exclusive Message

Universal Non-realtime System Exclusive Messages

Identity Request Message

GM1 System On

GM2 System On

GM System Off

Universal Realtime System Exclusive Messages

Master Volume

Master Fine Tuning

Master Coarse Tuning

Global Parameter Control

Reverb Parameters

Chorus Parameters

Channel Pressure

Controller

Scale/Octave Tuning Adjust

Key-based Instrument Controllers

Data Transmission

Data Request 1 RQ1

Data set 1 (DT1)

Data set 1 (DT1)

2. Data Transmission

Channel Voice Messages

Note off

Note on

Polyphonic Key Pressure

Control Change
