Roland VB-99 Implementation

V-BASS SYSTEM Date : Nov. 11. 2008
Model VB-99 MIDI Implementation Version : 1.00

1.RECOGNIZED RECEIVE DATA (Main Section)

--------------------------------------------------------------------------------------

■CHANNEL VOICE MESSAGE

Received when the "MIDI CH" setting for "SYSTEM/MIDI/CH" matches the number of the
MIDI channel on which they arrive. Also, when "OMNI MODE" for "SYSTEM/MIDI/CH" is
set to "ON," all MIDI channel numbers are received, regardless of the MIDI receive
channel number.

* Channel Voice messages are received on "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING,"
so change the MIDI route as required.

●Control Change

○Bank Select

Status 2nd byte 3rd byte

---------- --------- --------­BnH 00H mmH

n = MIDI channel number : 0H - FH (ch.1 - ch.16)
mm = Bank number :00H - 7FH ( 0 - 3)

* For values of 03H or lower, the “SYSTEM / MIDI / RX PC MAP” will be switched
according to the value. For values of 04H or higher, the received data will be
ignored.

* After start-up, the VB-99 will operate with bank number 00H until it receives a bank
select.

○Control Change Number #1～#31、#64～#95

Status 2nd byte 3rd byte

---------- --------- --------­BnH ccH vvH

n = MIDI channel number : 0H - FH (ch.1 - ch.16)
cc = Controller Number :01H - 1FH ( 1 - 31)
:40H - 5FH ( 64 - 95)
vv = Value: :00H - 7FH ( 0 - 127)

* By specifying this as a Source for “CONTROL ASSIGN 1-16” you can use
these messages to control a Target.

●Program Change

Status 2nd byte

---------- --------­CnH ppH

n = MIDI channel number : 0H - FH (ch.1 - ch.16)
pp = Program Number: :00H - 7FH (No.1 - No.128)

* Patches will be selected according to the program number that is received.
* Patches are changed as shown below in correspondence with the bank number and
program number received when "RX PC MAP" for "SYSTEM" is set to "FIX."

BANK PROG BANK PROG BANK PROG BANK PROG
MSB CHG VB-99 MSB CHG VB-99 MSB CHG VB-99 MSB CHG VB-99

---- ---- ----- ---- ---- ----- ---- ---- ----- ---- ---- ----­ 0 1 = #001 1 1 = #101 2 1 = #201 3 1 = #301
0 2 = #002 1 2 = #102 2 2 = #202 3 2 = #302
: : : :
: : : :
0 99 = #099 1 99 = #199 2 99 = #299 3 99 = #399
0 100 = #100 1 100 = #200 2 100 = #300 3 100 = #400
0 101 = #101 1 101 = #201 2 101 = #301
0 102 = #102 1 102 = #202 2 102 = #302
: : :
0 126 = #126 1 126 = #226 2 126 = #326
0 127 = #127 1 127 = #227 2 127 = #327

* When "RX PC MAP" for "SYSTEM" is set to "PROG," patches change in accord with
the patch settings made for "SYSTEM/MIDI/RX PC MAP."

Model VB-99 MIDI Implementation 　Version : 1.00

■SYSTEM REALTIME MESSAGE

●Timing Clock

Status

---------­F8H

* This is detected when "SYNC CLOCK" for "SYSTEM" is set to "AUTO(USB)," "AUTO(MIDI),"
or "AUTO(RRC2)," and "BPM" for "NAME/KEY/BPM" is updated accordingly.

●Active Sensing

Status

---------­FEH

* When an Active Sensing message is received, the interval of all subsequent messages
will begin to be monitored. If an interval greater than 400 msec. between messages,
the display will indicate “MIDI OFFLINE!”

■SYSTEM EXCLUSIVE MESSAGE

Status Data Byte Status

---------- --------------------------------- ---------­F0H iiH, ddH, ... eeH F7H

Byte Explanation

------ ---­F0H Exclusive status
iiH Manufacturer ID
ddH Data
: :
eeH Data
F7H EOX (End of Exclusive)

●Universal Non-realtime System Exclusive Messages

○Identity Request Message

Status Data Byte Status

---------- --------------------------------- ---------­F0H 7EH, dev, 06H, 01H F7H

Byte Explanation

------ ---­F0H Exclusive status
7EH ID number (Universal Non-realtime Message)

page1

Dev Device ID
06H Sub ID#1 (General Information)
01H Sub ID#2 (Identity Request)
F7H EOX (End of Exclusive)

* This is always received, regardless of the setting for the unit's device ID.
* When this message is received, Identity Reply message will be transmitted.

●ONE WAY COMMUNICATION (Model ID = 00H 00H 1DH - VB-99)

○Request Data 1 RQ1(11H)

Status Data Byte Status

---------- --------------------------------- ---------­F0H 41H, dev, 00H, 00H, 1DH, 11H, aaH, F7H
bbH, ccH, ddH, ssH, ttH, uuH, vvH,
sum

Byte Explanation

------ ---­F0H Exclusive status
41H Manufacturer ID (Roland)
Dev Device ID (Dev=00H-1FH, 7FH)
00H Model ID #1 (VB-99)
00H Model ID #2 (VB-99)
1DH Model ID #3 (VB-99)
11H Command ID (RQ1)
aaH Address MSB
bbH Address
ccH Address
ddH Address LSB
ssH Size MSB
ttH Size
uuH Size
vvH Size LSB
sum Checksum
F7H EOX (End of Exclusive)

* Only a device ID of 7FH or message matching the VB-99's device ID is received.
* The setting range for the device ID is 1 through 32. The factory default setting is 1.

○Data Set 1 DT1(12H)

Status Data Byte Status

---------- --------------------------------- ---------­F0H 41H, dev, 00H, 00H, 1DH, 12H, aaH, F7H
bbH, ccH, ddH, eeH, ... ffH, sum

Byte Explanation

------ ---­F0H Exclusive status
41H Manufacturer ID (Roland)
Dev Device ID (Dev=00H-1FH, 7FH)
00H Model ID #1 (VB-99)
00H Model ID #2 (VB-99)
1DH Model ID #3 (VB-99)
12H Command ID (DT1)
aaH Address MSB
bbH Address
ccH Address
ddH Address LSB
eeH Data
: :
ffH Data
sum Checksum
F7H EOX (End of Exclusive)

* Only a device ID of 7FH or message matching the VB-99's device ID is received.
* The setting range for the device ID is 1 through 32. The factory default setting is 1.

●ONE WAY COMMUNICATION (Model ID = 00H 00H 20H - Foot Controller)

○Data Set 1 DT1(12H)

Status Data Byte Status

---------- --------------------------------- ---------­F0H 41H, dev, 00H, 00H, 20H, 12H, F7H
aaH, bbH, ccH, ... ddH, sum

Byte Explanation

------ ---­F0H Exclusive status
41H Manufacturer ID (Roland)
Dev Device ID
00H Model ID #1 (Foot Controller)
00H Model ID #2 (Foot Controller)
20H Model ID #3 (Foot Controller)
12H Command ID (DT1)
aaH Address MSB
bbH Address LSB
ccH Data
: :
ddH Data
sum Checksum
F7H EOX (End of Exclusive)

* This is always received, regardless of the setting for the unit's device ID.

Model VB-99 MIDI Implementation 　Version : 1.00

2.TRANSMITTED DATA (Main Section)

--------------------------------------------------------------------------------------

■CHANNEL VOICE MESSAGE

For the MIDI transmit channel number for Channel Voice messages, set "MIDI CH"for "SYSTEM/MIDI/CH."

* Channel Voice messages are transmitted from "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING,"
so change the MIDI route as required.

●Control Change

○Bank Select

Status 2nd byte 3rd byte

---------- --------- --------­BnH 00H mmH
BnH 20H llH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
mm = Bank number (MSB) :00H - 7FH ( 0 - 127)
ll = Bank number (LSB) :00H - 7FH ( 0 - 127)

* If you set up a system parameter “ MIDI / PC OUT” for “ON,” program change
information is transmitted when switching patch.

○Control Change Number #1～#31、#33～#95

Status 2nd byte 3rd byte

---------- --------- --------­page2

BnH ccH vvH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
cc = Controller Number :01H - 1FH ( 1 - 31)
:40H - 5FH ( 64 - 95)
vv = Value: :00H - 7FH ( 0 - 127)

--------------------------------------------------------------------------------------

* If you set up a control change number at a system parameter “MIDI / TX CC”control
change information is transmitted when operating each controllers.

●Program Change

Status 2nd byte

---------- ---------

CnH ppH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
pp = Program Number :00H - 7FH (No.1 - No.128)

* If you set up a system parameter “ MIDI / PC OUT” for “ON,” program change
* The program numbers transmitted when "TX PC MAP" for "SYSTEM" is set to "FIX"
are as shown below.

BANK PROG BANK PROG BANK PROG BANK PROG
VB-99 MSB LSB CHG VB-99 MSB LSB CHG VB-99 MSB LSB CHG VB-99 MSB LSB CHG

----- --- --- --- ----- --- --- --- ----- --- --- --- ----- --- --- ---

#001 = 0 0 1 #101 = 1 0 1 #201 = 2 0 1 #301 = 3 0 1
#002 = 0 0 2 #102 = 1 0 2 #202 = 2 0 2 #302 = 3 0 2
: : : :
: : : :
#099 = 0 0 99 #199 = 1 0 99 #299 = 2 0 99 #399 = 3 0 99
#100 = 0 0 100 #200 = 1 0 100 #300 = 2 0 100 #400 = 3 0 100

* When "TX PC MAP" for "SYSTEM" is set to "PROG," the value of the setting for
"NAME/KEY/BPM/TX PC" is transmitted.

■SYSTEM REALTIME MESSAGE

●Start

Status

----------

FAH

* This is transmitted at the time of controller operation when "MIDI START/STOP"
is set for a controller other than "GK VOL," "EXP PEDAL," "FC-300 EXP1," or
"FC-300 EXP2" for "SYSTEM/CONTROL ASSIGN."
* Start messages are transmitted from "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING," so
change the MIDI route as required.

Model VB-99 MIDI Implementation 　Version : 1.00

●Stop

Status

----------

FCH

* This is transmitted at the time of controller operation when "MIDI START/STOP"
is set for a controller other than "GK VOL," "EXP PEDAL," "FC-300 EXP1," or
"FC-300 EXP2" for "SYSTEM/CONTROL ASSIGN."
* Stop messages are transmitted from "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING," so
change the MIDI route as required.

●Active Sensing

Status

----------

FEH

* This is transmitted at intervals of approximately 200 msec.

■SYSTEM EXCLUSIVE MESSAGE

Status Data Byte Status

---------- --------------------------------- ----------

F0H iiH, ddH, ... eeH F7H

Byte Explanation

------ ----

F0H Exclusive status
iiH Manufacturer ID
ddH Data
: :
eeH Data
F7H EOX (End of Exclusive)

●Universal System Exclusive Message

○Identity Reply Message

* Receiving Identity Request Message, the VB-99 send this message.

Status Data Byte Status

---------- --------------------------------- ----------

F0H 7EH, dev, 06H, 02H, 41H, 71H, 01H F7H
00H, 00H, 00H, 00H, 00H, 00H

Byte Explanation

------ ----

F0H Exclusive status
7EH ID number (Universal Non-realtime Message)
Dev Device ID (Dev=00H-1FH)
06H Sub ID#1 (General Information)
02H Sub ID#2 (Identity Request)
41H ID number (Roland)
1DH 02H Device family code
00H 00H Device family number code
00H 01H 00H 00H Software revision level
F7H EOX (End of Exclusive)

○MIDI Machine Control Command STOP (MCS)

Status Data Byte Status

---------- --------------------------------- ----------

F0H 7FH, Dev, 06H, 01H F7H

Byte Explanation

------ ----

F0H Exclusive status
7FH Universal System Exclusive Realtime Header
Dev Device ID (7FH)
06H MMC command message
01H STOP (MCS)
F7H EOX (End of Exclusive)

* This is transmitted at the time of controller operation when "MMC PLAY/STOP"
is set for a controller other than "GK VOL," "EXP PEDAL," "FC-300 EXP1," or

page3

"FC-300 EXP2" for "SYSTEM/CONTROL ASSIGN."

○MIDI Machine Control Command DEFERRED PLAY (MCS)

Status Data Byte Status

---------- --------------------------------- ----------

F0H 7FH, Dev, 06H, 03H F7H

Byte Explanation

------ ----

F0H Exclusive status
7FH Universal System Exclusive Realtime Header
Dev Device ID (7FH)
06H MMC command message
03H DEFERRED PLAY (MCS)
F7H EOX (End of Exclusive)

* This is transmitted at the time of controller operation when "MMC PLAY/STOP"
is set for a controller other than "GK VOL," "EXP PEDAL," "FC-300 EXP1," or
"FC-300 EXP2" for "SYSTEM/CONTROL ASSIGN."

●ONE WAY COMMUNICATION (Model ID = 00H 00H 1DH - VB-99)

○Data Set 1 DT1(12H)

Status Data Byte Status

---------- --------------------------------- ----------

F0H 41H, dev, 00H, 00H, 1DH, 12H, aaH, F7H
bbH, ccH, ddH, eeH, ... ffH, sum

Byte Explanation

------ ----

F0H Exclusive status
41H Manufacturer ID (Roland)
Dev Device ID (Dev=00H-1FH)
00H Model ID #1 (VB-99)
00H Model ID #2 (VB-99)
1DH Model ID #3 (VB-99)
12H Command ID (DT1)
aaH Address MSB
bbH Address
ccH Address
ddH Address LSB
eeH Data
: :
ffH Data
sum Checksum
F7H EOX (End of Exclusive)

* The setting range for the device ID is 1 through 32. The factory default setting is 1.

●ONE WAY COMMUNICATION (Model ID = 00H 00H 20H - Foot Controller)

○Data Set 1 DT1(12H)

Status Data Byte Status

---------- --------------------------------- ----------

F0H 41H, dev, 00H, 00H, 20H, 12H, F7H
aaH, bbH, ccH, ... ddH, sum

Byte Explanation

------ ----

F0H Exclusive status
41H Manufacturer ID (Roland)
Dev Device ID (Dev=7FH)
00H Model ID #1 (Foot Controller)
00H Model ID #2 (Foot Controller)
20H Model ID #3 (Foot Controller)
12H Command ID (DT1)
aaH Address MSB
bbH Address LSB
ccH Data
: :
ddH Data
sum Checksum
F7H EOX (End of Exclusive)

Model VB-99 MIDI Implementation 　Version : 1.00

3.TRANSMITTED DATA (BASS TO MIDI Section)

--------------------------------------------------------------------------------------

Shown below are the messages transmitted when "BASS TO MIDI" is set to "ON."

■CHANNEL VOICE MESSAGE

For the MIDI transmit channel number, make the setting for "BASIC CH" under
"BASS TO MIDI/SYSTEM."
Also, for each respective setting of "MODE" for "BASS TO MIDI/PATCH," this is
transmitted on the channels shown below.

For "MONO": 6 channels, starting with the basic channel
For "POLY": Basic channel only

* Channel Voice messages are transmitted from "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING,"
so change the MIDI route as required.

●Note off

Status 2nd byte 3rd byte

---------- --------- ---------

9nH kkH 00H

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
kk = Note number :00H - 7FH ( 0 - 127)

●Note on

Status 2nd byte 3rd byte

---------- --------- ---------

9nH kkH vvH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
kk = Note number :00H - 7FH ( 0 - 127)
vv = Note on velocity :01H - 7FH ( 1 - 127)

●Control Change

○Bank Select

Status 2nd byte 3rd byte

---------- --------- ---------

BnH 00H mmH
BnH 20H llH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
mm = Bank number (MSB) :00H - 7FH ( 0 - 127)
ll = Bank number (LSB) :00H - 7FH ( 0 - 127)

* This is transmitted when changing "BANK MSB/LSB" for "BASS TO MIDI/PATCH/PC"

page4

when switching to a patch for which "BANK MSB/LSB" and "PC" for "BASS TO MIDI/PATCH/PC"
are not set to "OFF."

○Control Change Number #1～#31、#33～#95

Status 2nd byte 3rd byte

---------- --------- ---------

BnH ccH vvH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
cc = Controller Number :01H - 1FH ( 1 - 31)
:40H - 5FH ( 64 - 95)
vv = Value :00H - 7FH ( 0 - 127)

--------------------------------------------------------------------------------------

* A Control Change message is transmitted at the time of "SRC" controller operation
when "CC" for "BASS TO MIDI/PATCH CC" is set to a value other than "OFF."

○Data Entry (Controller number 6, 38)

Status 2nd byte 3rd byte

---------- --------- ---------

BnH 06H mmH
BnH 26H llH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
mm,ll = the value of the parameter specified by RPN
mm = MSB, ll = LSB

○RPN MSB/LSB (Controller number 100, 101)

Status 2nd byte 3rd byte

---------- --------- ---------

BnH 65H mmH
BnH 64H llH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
mm = upper byte (MSB) of parameter number specified by RPN
ll = lower byte (LSB) of parameter number specified by RPN

<<< RPN >>>
Control Changes include RPN (Registered Parameter Numbers), which are extended.
This device transmits followings RPNs.

RPN Data entry
MSB, LSB MSB, LSB Notes

---------- --------- ---------

00H, 00H 0CH, 00H Pitch Bend Sensitivity
Always transmits 0CH 00H (12 semitones).

* This is transmitted when switching patches when "BASS TO MIDI"
is set to "ON."

7FH, 7FH ---, --- RPN null
This places the receiving device in a state in which RPN is not set.

●Program Change

Status 2nd byte

---------- ---------

CnH ppH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
pp = Program number :00H - 7FH (No.1 - No.128)

* This is transmitted when changing "PC" for "BASS TO MIDI/PATCH/PC"
when switching to a patch for which "PC" for "BASS TO MIDI/PATCH/PC"
are not set to "OFF."

●Pitch Bend Change

Status 2nd byte 3rd byte

---------- --------- ---------

EnH llH mmH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
mm,ll = Pitch Bend value : 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

Model VB-99 MIDI Implementation 　Version : 1.00

■System Realtime Message

●Active Sensing

Status

----------

FEH

* This is constantly transmitted at an interval of approximately 200 ms, regardless
of the "ON/OFF" setting of "BASS TO MIDI."

4.TRANSMITTED DATA (V-LINK Section)

--------------------------------------------------------------------------------------

Shown below are the messages transmitted when "V-LINK" is set to "ON."

■CHANNEL VOICE MESSAGE

For the MIDI transmit channel number, make the setting for "MIDI A CH," "MIDI B CH,"
or "MIDI C CH," under "V-LINK / SYSTEM / MIDI CH."

* Channel Voice messages are transmitted from "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING,"
so change the MIDI route as required.

●Note off

Status 2nd byte 3rd byte

---------- --------- ---------

9nH kkH 00H

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
kk = Note number :00H - 7FH ( 0 - 127)

* This is transmitted when "V-LINK/STRING CH" is set to a value other than "OFF."
* This is transmitted to the MIDI channel numbers set with "V-LINK/STRING CH" for
each bass string.

●Note on

Status 2nd byte 3rd byte

---------- --------- ---------

9nH kkH vvH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
kk = Note number :00H - 7FH ( 0 - 127)
vv = Note on velocity :01H - 7FH ( 1 - 127)

* This is transmitted when "V-LINK/STRING CH" is set to a value other than "OFF."
* This is transmitted to the MIDI channel numbers set with "V-LINK/STRING CH" for

page5

each bass string.

●Control Change

○Bank Select

Status 2nd byte 3rd byte

---------- --------- ---------

BnH 00H mmH
BnH 20H 00H

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
mm = Bank number (MSB) :00H - 1FH ( 0 - 31)
ll = Bank number (LSB) :00H ( 0 )

* This is transmitted when changing "PALETTE" for "V-LINK / PATCH / CLIP"
when switching to a patch for which "PALETTE" for "V-LINK / PATCH / CLIP"
are not set to "OFF."

○Control Change Number #1, #3, #8, #10, #11, #64-#65, #71-#74, #81, #83,
#85-#86, #91-#94

Status 2nd byte 3rd byte

---------- --------- ---------

BnH ccH vvH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
cc = Controller Number :01H ( 1 )
:03H ( 3 )
:08H ( 8 )
:0AH ( 10 )
:0BH ( 11 )
:40H - 41H ( 64 - 65)
:47H - 4AH ( 71 - 74)
:51H ( 81 )
:53H ( 83 )
:55H - 56H ( 85 - 86)
:5BH - 5EH ( 91 - 94)
vv = Value :00H - 7FH ( 0 - 127)

* A Control Change message is transmitted at the time of "SOURCE" controller operation
when "SOURCE" for "V-LINK / PATCH / ASSIGN" is set to a value other than "OFF."
* The MIDI transmit channel number differs for each controller number.
For more information, refer to the "V-LINK Function Correspondence Chart"
in the VB-99 Owner's Manual.

●Program Change

Status 2nd byte

---------- ---------

CnH ppH

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)
pp = Program number :00H - 1FH (No.1 - No.32)

* This is transmitted when changing "CLIP" for "V-LINK / PATCH / CLIP"
when switching to a patch for which "CLIP" for "V-LINK / PATCH / CLIP"
are not set to "OFF."

■Channel Mode Messages

* Channel Mode messages are transmitted from "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING,"
so change the MIDI route as required.

●Reset All Controllers (Controller number 121)

Status 2nd byte 3rd byte

---------- --------- ---------

BnH 79H 00H

n = MIDI Channel Number : 0H - FH (ch.1 - ch.16)

※'V-LINK / SYSTEM / MIDI CH'の'MIDI A CH'、'MIDI B CH'、'MIDI C CH'の設定変更時、
'V-LINK'をOFF'に設定時に送信します。
* This is transmitted when changing the "OFF" setting for "V-LINK" when changing
the "MIDI A CH," "MIDI B CH," or "MIDI C CH" setting for "V-LINK/SYSTEM/MIDI CH."

■System Realtime Message

●Active Sensing

Status

----------

FEH

* This is constantly transmitted at an interval of approximately 200 ms, regardless
of the "ON/OFF" setting of "V-LINK."

■SYSTEM EXCLUSIVE MESSAGE

Status Data Byte Status

---------- --------------------------------- ----------

F0H iiH, ddH, ... eeH F7H

Byte Explanation

------ ----

F0H Exclusive status
iiH Manufacturer ID
ddH Data
: :
eeH Data
F7H EOX (End of Exclusive)

* System exclusive messages for V-LINK section are transmitted from "VB-99 MAIN" for "SYSTEM/MIDI/ROUTING,"
so change the MIDI route as required.

●ONE WAY COMMUNICATION (Model ID = 00H 51H - V-LINK)

○Data Set 1 DT1(12H)

Status Data Byte Status

---------- --------------------------------- ----------

F0H 41H, dev, 00H, 51H, 12H, aaH, bbH, F7H
ccH, ddH, eeH, ... ffH, sum

Byte Explanation

------ ----

F0H Exclusive status
41H Manufacturer ID (Roland)
Dev Device ID (Dev=7FH)
00H Model ID #1 (V-LINK)
51H Model ID #2 (V-LINK)
12H Command ID (DT1)
aaH Address MSB
bbH Address
ccH Address
ddH Address LSB
eeH Data
: :
ffH Data

page6

Model VB-99 MIDI Implementation 　Version : 1.00

sum Checksum
F7H EOX (End of Exclusive)

* This is transmitted when changing the "ON/OFF" setting for "V-LINK" when changing
the "MIDI A CH," "MIDI B CH," or "MIDI C CH" setting for "V-LINK/SYSTEM/MIDI CH."

5.PARAMETER ADDRESS MAP (Model ID = 00 00 1D - VB-99)

--------------------------------------------------------------------------------------

The address and size are displayed under 7-bit hexadecimal notation.

Address MSB LSB
Binary 0aaa aaaa 0bbb bbbb 0ccc cccc 0ddd dddd
7-bit Hexadecimal AA BB CC DD

Size MSB LSB
Binary 0sss ssss 0ttt tttt 0uuu uuuu 0vvv vvvv
7-bit Hexadecimal SS TT UU VV

Address Block Map

----------------------------------------------------------------------------------------------

Address Block Sub Block Note

00 00 00 00 +------------------------------------------+
| SYSTEM | * Refer to Table 'SYSTEM'
+------------------------------------------+
00 01 00 00 +------------------------------------------+
| MIDI | * Refer to Table 'MIDI'
+------------------------------------------+
10 00 00 00 +-------------------+ +--------------------+
| GLOBAL | | #1 | * Refer to Table 'GLOBAL'
| | +--------------------+
10 00 01 00 | | +--------------------+
| | | #2 |
| | +--------------------+
: | | :
: | | :
10 00 09 00 | | +--------------------+
| | | #10 |
+-------------------+ +--------------------+
20 00 00 00 +-------------------+ +--------------------+
| GK SETTING | | #1 | * Refer to Table 'GK SETTING'
| | +--------------------+
20 00 01 00 | | +--------------------+
| | | #2 |
| | +--------------------+
: | | :
: | | :
20 00 09 00 | | +--------------------+
| | | #10 |
+-------------------+ +--------------------+
30 00 00 00 +------------------------------------------+
| FAVORITE | * Refer to Table 'FAVORITE'
+------------------------------------------+
3C 00 00 00 +------------------------------------------+
| FAVORITE NAME | * Refer to Table 'FAVORITE NAME'
+------------------------------------------+
40 00 00 00 +-------------------+ +--------------------+
| USER Patch | | #001 | * Refer to Table 'PATCH'
| | +--------------------+
40 01 00 00 | | +--------------------+
| | | #002 |
| | +--------------------+
: | | :
: | | :
40 7F 00 00 | | +--------------------+
| | | #128 |
| | +--------------------+
41 00 00 00 | | +--------------------+
| | | #129 |
| | +--------------------+
: | | :
: | | :
41 46 00 00 | | +--------------------+
| | | #199 |
| | +--------------------+
41 47 00 00 | | +--------------------+
| | | #200 |
+-------------------+ +--------------------+
50 00 00 00 +-------------------+ +--------------------+
| PRESET Patch | | #201 | * Refer to Table 'PATCH'
| | +--------------------+ (Read only)
50 01 00 00 | | +--------------------+
| | | #202 |
| | +--------------------+
: | | :
: | | :
50 7F 00 00 | | +--------------------+
| | | #328 |
| | +--------------------+
51 00 00 00 | | +--------------------+
| | | #329 |
| | +--------------------+
: | | :
: | | :
51 46 00 00 | | +--------------------+
| | | #399 |
| | +--------------------+
51 47 00 00 | | +--------------------+
| | | #400 |
+-------------------+ +--------------------+
60 00 00 00 +------------------------------------------+
| TEMPORARY PATCH | * Refer to Table 'PATCH'
+------------------------------------------+
70 00 00 00 +------------------------------------------+
| SYSTEM (TEMPORARY) | * Refer to Table 'SYSTEM(TEMPORARY)'
+------------------------------------------+
71 00 00 00 +------------------------------------------+
| COMMAND | * Refer to Table 'COMMAND'
+------------------------------------------+

----------------------------------------------------------------------------------------------

* Although system exclusive message can be received at any time, be sure to appropriately describe the value for one
parameter in one packet [F0...F7].
* Do not use an address appended with “#” as the first address.
* Parameters for which Size is 2 or higher should not be separated; make sure these are sent in the same packet.
* Parameters with Size of 2 or higher transmitted from the specified addresses in sequence, from MSB to LSB.

Model VB-99 MIDI Implementation 　Version : 1.00

Table 'SYSTEM'

------------------------------------------------------------------------------------------------------------------------

Address(H) Size(H) Data(H) Parameter Description

------------------------------------------------------------------------------------------------------------------------

00 00 00 00 00 00 00 01 00 - 31 CONTRAST 1 - 50
00 00 01 01 00 00 00 02 00 00 - 00 10 CONTROL ASSIGN / GK VOL * Refer to Table 'SYSTEM CONTROL VOL'

page7

00 00 01 08 00 00 00 02 00 00 - 00 0A CONTROL ASSIGN / GK S1,S2 * Refer to Table 'SYSTEM CONTROL S1,S2'
00 00 01 0F 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / CTL1 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 16 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / CTL2 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 1D 00 00 00 02 00 00 - 00 10 CONTROL ASSIGN / EXP PEDAL * Refer to Table 'SYSTEM CONTROL VOL'
00 00 01 24 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / CTL3 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 2B 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / CTL4 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 32 00 00 00 02 00 00 - 00 10 CONTROL ASSIGN / FC-300 EXP1 * Refer to Table 'SYSTEM CONTROL VOL'
00 00 01 39 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / FC-300 EXP1 SW * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 40 00 00 00 02 00 00 - 00 10 CONTROL ASSIGN / FC-300 EXP2 * Refer to Table 'SYSTEM CONTROL VOL'
00 00 01 47 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / FC-300 EXP2 SW * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 4E 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / FC-300 CTL1 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 55 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / FC-300 CTL2 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 5C 00 00 00 02 00 00 - 00 1C CONTROL ASSIGN / FC-300 EXP3/CTL3 * Refer to Table 'SYSTEM CONTROL ENC/CTL'
00 00 01 63 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / FC-300 CTL4 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 6A 00 00 00 02 00 00 - 00 1C CONTROL ASSIGN / FC-300 EXP4/CTL5 * Refer to Table 'SYSTEM CONTROL ENC/CTL'
00 00 01 71 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / FC-300 CTL6 * Refer to Table 'SYSTEM CONTROL SW'
00 00 01 78 00 00 00 02 00 00 - 00 1C CONTROL ASSIGN / FC-300 EXP5/CTL7 * Refer to Table 'SYSTEM CONTROL ENC/CTL'
00 00 01 7F 00 00 00 02 00 00 - 00 0D CONTROL ASSIGN / FC-300 CTL8 * Refer to Table 'SYSTEM CONTROL SW'
00 00 02 05 00 00 00 01 00 - 01 DIRECT EDIT 00 : SYSTEM
01 : PATCH
00 00 02 06 00 00 00 02 00 00 - 7F 7F TARGET PARAMETER * Refer to Table 'CONTROL ASSIGN TARGET'
00 00 02 08 00 00 00 02 00 00 - 7F 7F TARGET PARAMETER * Refer to Table 'CONTROL ASSIGN TARGET'
00 00 02 0A 00 00 00 02 00 00 - 7F 7F TARGET PARAMETER * Refer to Table 'CONTROL ASSIGN TARGET'
00 00 02 0C 00 00 00 02 00 00 - 7F 7F TARGET PARAMETER * Refer to Table 'CONTROL ASSIGN TARGET'
00 00 02 0E 00 00 00 02 00 00 - 7F 7F TARGET PARAMETER * Refer to Table 'CONTROL ASSIGN TARGET'
00 00 02 10 00 00 00 02 00 00 - 7F 7F TARGET PARAMETER * Refer to Table 'CONTROL ASSIGN TARGET'
00 00 10 00 00 00 00 01 00 - 03 DISPLAY MODE 00 : Standard
01 : Full Name
02 : Chain
03 : Level Meter
00 00 10 02 00 00 00 01 00 - 09 GK SETTING / SETTING 1 - 10
00 00 10 03 00 00 00 01 00 - 01 GK SETTING / SET MODE 00 : SYSTEM
01 : PATCH
00 00 10 04 00 00 00 01 00 - 09 GLOBAL / SETTING 1 - 10
00 00 10 05 00 00 00 01 00 - 02 GK SETTING / GK CONNCT 00 : AUTO
01 : OFF
02 : ON
00 00 10 06 00 00 00 01 00 - 0A TUNER / PITCH 435Hz - 445Hz
00 00 10 07 00 00 00 01 00 - 01 ASSIGN HOLD 00 : OFF
01 : ON
00 00 10 08 00 00 00 02 00 00 - 03 0F DIR.PATCH 1 1 - 400
00 00 10 0A 00 00 00 02 00 00 - 03 0F DIR.PATCH 2 1 - 400
00 00 10 0C 00 00 00 02 00 00 - 03 0F DIR.PATCH 3 1 - 400
00 00 10 0E 00 00 00 02 00 00 - 03 0F DIR.PATCH 4 1 - 400
00 00 10 10 00 00 00 02 00 00 - 03 0F DIR.PATCH 5 1 - 400
00 00 10 12 00 00 00 01 00 - 01 TUNER / MUTE 00 : OFF
01 : ON
00 00 10 13 00 00 00 01 00 - 64 USB / IN LEVEL 00 : 0
01 : 2
: :
64 : 200
00 00 10 14 00 00 00 01 00 - 06 USB / USB IN 00 : OFF
01 : COSM BASS A
02 : COSM BASS B
03 : NORMAL PU
04 : MAIN OUT
05 : SUB OUT
06 : MAIN & SUB
00 00 10 15 00 00 00 01 00 - 64 USB / OUT LEVEL 00 : 0
01 : 2
: :
64 : 200
00 00 10 16 00 00 00 01 00 - 08 USB / USB OUT 00 : COSM BASS A
01 : COSM BASS B
02 : NORMAL PU
03 : CH A
04 : CH B
05 : MIXER (DRY)
06 : MIXER
07 : MAIN OUT
08 : SUB OUT
00 00 10 17 00 00 00 01 00 - 64 OUTPUT / D OUT LEVEL 00 : 0
01 : 2
: :
64 : 200
00 00 10 18 00 00 00 01 00 - 08 OUTPUT / D OUT 00 : COSM BASS A
01 : COSM BASS B
02 : NORMAL PU
03 : CH A
04 : CH B
05 : MIXER (DRY)
06 : MIXER
07 : MAIN OUT
08 : SUB OUT
00 00 10 19 00 00 00 01 00 - 01 OUTPUT / OUTPUT MODE 00 : SYSTEM
01 : PATCH
00 00 10 1A 00 00 00 01 00 - 01 USB / DRIVER MODE 00 : STNDRD
01 : ADVANC
00 00 10 1B 00 00 00 01 00 - 01 USB / MON CMD 00 : DISABL
01 : ENABLE
00 00 10 1C 00 00 00 01 00 - 01 FC-300 / SYS EX MODE 00 : OFF
01 : ON
00 00 10 1D 00 00 00 01 00 - 01 FC-300 / BANK CHANGE 00 : IMMEDIATE
01 : WAIT NUM
00 00 10 1E 00 00 00 01 00 - 0F V-LINK / MIDI A CH 1ch - 16ch
00 00 10 1F 00 00 00 01 00 - 0F V-LINK / MIDI B CH 1ch - 16ch
00 00 10 20 00 00 00 01 00 - 0F V-LINK / MIDI C CH 1ch - 16ch
00 00 10 22 00 00 00 01 00 - 04 OUTPUT / MAIN OUT 00 : CH A
01 : CH B
02 : MIXER (DRY)
03 : MIXER
04 : BASS DIRECT
00 00 10 23 00 00 00 01 00 - 04 OUTPUT / SUB OUT 00 : CH A
01 : CH B
02 : MIXER (DRY)
03 : MIXER
04 : BASS DIRECT
00 00 10 24 00 00 00 02 00 00 - 01 52 SYSTEM BPM 40 - 250
00 00 10 26 00 00 00 01 00 - 01 BPM MODE 00 : SYSTEM
01 : PATCH
00 00 20 00 00 00 00 01 00 - 01 FC-300 / QUICK TUNER 00 : OFF
01 : ON
00 00 20 01 00 00 00 01 00 - 01 D BEAM DISAB 00 : OFF
01 : ON
00 00 20 06 00 00 00 02 00 00 - 03 0F PATCH EXTENT / FROM 1 - 400
00 00 20 08 00 00 00 02 00 00 - 03 0F PATCH EXTENT / TO 1 - 400
00 00 20 10 00 00 00 01 00 - 64 OUTPUT / MAIN LEVEL 00 : 0
01 : 2
: :
64 : 200
00 00 20 11 00 00 00 01 00 - 64 OUTPUT / SUB LEVEL 00 : 0
01 : 2
: :
64 : 200
00 00 30 00 00 00 00 08 - - - CATEGORY PRESET 1 NAME "E.BASS " * Refer to Table 'NAME' (Read only)
00 00 30 08 00 00 00 08 - - - CATEGORY PRESET 2 NAME "AC BASS " * Refer to Table 'NAME' (Read only)
00 00 30 10 00 00 00 08 - - - CATEGORY PRESET 3 NAME "SYNTH " * Refer to Table 'NAME' (Read only)
00 00 30 18 00 00 00 08 - - - CATEGORY PRESET 4 NAME "E.GUITAR" * Refer to Table 'NAME' (Read only)
00 00 30 20 00 00 00 08 - - - CATEGORY PRESET 5 NAME "EFFECTS " * Refer to Table 'NAME' (Read only)
00 00 30 28 00 00 00 08 - - - CATEGORY PRESET 6 NAME "OTHERS " * Refer to Table 'NAME' (Read only)

page8

Model VB-99 MIDI Implementation 　Version : 1.00

00 00 32 00 00 00 00 01 20 - 7D CATEGORY USER 1 NAME 1 * Refer to Table 'NAME'
00 00 32 01# 00 00 00 01 20 - 7D CATEGORY USER 1 NAME 2
: : : :
00 00 32 07# 00 00 00 01 20 - 7D CATEGORY USER 1 NAME 8
00 00 32 08 00 00 00 01 20 - 7D CATEGORY USER 2 NAME 1 * Refer to Table 'NAME'
00 00 32 09# 00 00 00 01 20 - 7D CATEGORY USER 2 NAME 2
: : : :
00 00 32 0F# 00 00 00 01 20 - 7D CATEGORY USER 2 NAME 8
00 00 32 10 00 00 00 01 20 - 7D CATEGORY USER 3 NAME 1 * Refer to Table 'NAME'
00 00 32 11# 00 00 00 01 20 - 7D CATEGORY USER 3 NAME 2
: : : :
00 00 32 17# 00 00 00 01 20 - 7D CATEGORY USER 3 NAME 8
00 00 32 18 00 00 00 01 20 - 7D CATEGORY USER 4 NAME 1 * Refer to Table 'NAME'
00 00 32 19# 00 00 00 01 20 - 7D CATEGORY USER 4 NAME 2
: : : :
00 00 32 1F# 00 00 00 01 20 - 7D CATEGORY USER 4 NAME 8
00 00 32 20 00 00 00 01 20 - 7D CATEGORY USER 5 NAME 1 * Refer to Table 'NAME'
00 00 32 21# 00 00 00 01 20 - 7D CATEGORY USER 5 NAME 2
: : : :
00 00 32 27# 00 00 00 01 20 - 7D CATEGORY USER 5 NAME 8
00 00 32 28 00 00 00 01 20 - 7D CATEGORY USER 6 NAME 1 * Refer to Table 'NAME'
00 00 32 29# 00 00 00 01 20 - 7D CATEGORY USER 6 NAME 2
: : : :
00 00 32 2F# 00 00 00 01 20 - 7D CATEGORY USER 6 NAME 8
00 00 32 30 00 00 00 01 20 - 7D CATEGORY USER 7 NAME 1 * Refer to Table 'NAME'
00 00 32 31# 00 00 00 01 20 - 7D CATEGORY USER 7 NAME 2
: : : :
00 00 32 37# 00 00 00 01 20 - 7D CATEGORY USER 7 NAME 8
00 00 32 38 00 00 00 01 20 - 7D CATEGORY USER 8 NAME 1 * Refer to Table 'NAME'
00 00 32 39# 00 00 00 01 20 - 7D CATEGORY USER 8 NAME 2
: : : :
00 00 32 3F# 00 00 00 01 20 - 7D CATEGORY USER 8 NAME 8
00 00 32 40 00 00 00 01 20 - 7D CATEGORY USER 9 NAME 1 * Refer to Table 'NAME'
00 00 32 41# 00 00 00 01 20 - 7D CATEGORY USER 9 NAME 2
: : : :
00 00 32 47# 00 00 00 01 20 - 7D CATEGORY USER 9 NAME 8
00 00 32 48 00 00 00 01 20 - 7D CATEGORY USER 10 NAME 1 * Refer to Table 'NAME'
00 00 32 49# 00 00 00 01 20 - 7D CATEGORY USER 10 NAME 2
: : : :
00 00 32 4F# 00 00 00 01 20 - 7D CATEGORY USER 10 NAME 8

------------------------------------------------------------------------------------------------------------------------

Table 'MIDI'

------------------------------------------------------------------------------------------------------------------------

Address(H) Size(H) Data(H) Parameter Description

------------------------------------------------------------------------------------------------------------------------

00 01 00 00 00 00 00 01 00 - 0F MIDI CH 1ch - 16ch
00 01 00 01 00 00 00 01 00 - 01 OMNI MODE 00 : OFF
01 : ON
00 01 00 02 00 00 00 01 00 - 01 PC OUT 00 : OFF
01 : ON
00 01 00 03 00 00 00 01 00 - 01 TX PC MAP 00 : FIX
01 : PROG
00 01 00 04 00 00 00 01 00 - 01 RX PC MAP 00 : FIX
01 : PROG
00 01 00 05 00 00 00 01 00 - 01 ROUTING MIDI IN -> 00 : OFF
01 : MAIN
00 01 00 06 00 00 00 01 00 - 01 ROUTING RRC2 -> 00 : OFF
01 : MAIN
00 01 00 07 00 00 00 01 00 - 02 ROUTING MIDI OUT <- 00 : OFF
01 : MAIN
02 : USB
00 01 00 08 00 00 00 01 00 - 02 ROUTING RRC2 <- 00 : OFF
01 : MAIN
02 : USB
00 01 00 09 00 00 00 01 00 - 02 ROUTING MIDI OUT (THRU) <- 00 : OFF
01 : MIDI
02 : RRC2
00 01 00 0A 00 00 00 01 00 - 01 ROUTING RRC2 (THRU) <- 00 : OFF
01 : MIDI
00 01 00 0B 00 00 00 01 00 - 03 ROUTING USB <- 00 : OFF
01 : MAIN
02 : MIDI
03 : RRC2
00 01 00 0C 00 00 00 01 00 - 01 ROUTING USB -> 00 : OFF
01 : MAIN
00 01 00 0F 00 00 00 01 00 - 03 SYNC CLOCK 00 : INTER-NAL
01 : AUTO (USB)
02 : AUTO (MIDI)
03 : AUTO (RRC2)
00 01 00 10 00 00 00 01 00 - 01 BASS TO MIDI / BASS TO MIDI SW 00 : OFF
01 : ON
00 01 00 11 00 00 00 01 00 - 0D BASS TO MIDI / HOLD CTL 00 : GK S1
01 : GK S2
02 : CTL1
03 : CTL2
04 : CTL3
05 : CTL4
06 : FC-300 CTL1
07 : FC-300 CTL2
08 : FC-300 CTL3
09 : FC-300 CTL4
0A : FC-300 CTL5
0B : FC-300 CTL6
0C : FC-300 CTL7
0D : FC-300 CTL8
00 01 00 12 00 00 00 01 00 - 01 BASS TO MIDI / BEND THIN 00 : OFF
01 : ON
00 01 00 14 00 00 00 01 00 - 0A BASS TO MIDI / BASIC CH 1ch - 11ch
00 01 00 15 00 00 00 01 00 - 01 BASS TO MIDI / PC MASK 00 : OFF
01 : ON
00 01 00 17 00 00 00 01 00 - 3F TX CC / GK VOL 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 18 00 00 00 01 00 - 3F TX CC / GK S1 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 19 00 00 00 01 00 - 3F TX CC / GK S2 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 1A 00 00 00 01 00 - 3F TX CC / CTL1 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 1B 00 00 00 01 00 - 3F TX CC / CTL2 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 1C 00 00 00 01 00 - 3F TX CC / EXP PEDAL 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 1D 00 00 00 01 00 - 3F TX CC / CTL3 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 1E 00 00 00 01 00 - 3F TX CC / CTL4 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 1F 00 00 00 01 00 - 3F TX CC / D BEAM H 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95

page9

Model VB-99 MIDI Implementation 　Version : 1.00

00 01 00 20 00 00 00 01 00 - 3F TX CC / D BEAM V 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 21 00 00 00 01 00 - 3F TX CC / RIBBON ACT 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 22 00 00 00 01 00 - 3F TX CC / RIBBON POS 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 23 00 00 00 01 00 - 3F TX CC / FC-300 EXP1 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 24 00 00 00 01 00 - 3F TX CC / FC-300 EXP SW1 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 25 00 00 00 01 00 - 3F TX CC / FC-300 EXP2 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 26 00 00 00 01 00 - 3F TX CC / FC-300 EXP SW2 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 27 00 00 00 01 00 - 3F TX CC / FC-300 CTL1 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 28 00 00 00 01 00 - 3F TX CC / FC-300 CTL2 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 29 00 00 00 01 00 - 3F TX CC / FC-300 EXP3/CTL3 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 2A 00 00 00 01 00 - 3F TX CC / FC-300 CTL4 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 2B 00 00 00 01 00 - 3F TX CC / FC-300 EXP4/CTL5 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 2C 00 00 00 01 00 - 3F TX CC / FC-300 CTL6 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 2D 00 00 00 01 00 - 3F TX CC / FC-300 EXP5/CTL7 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 00 2E 00 00 00 01 00 - 3F TX CC / FC-300 CTL8 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
00 01 10 00 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:0 PC: 1 1 - 400
00 01 10 02 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:0 PC: 2 1 - 400
: : : :
00 01 11 7E 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:0 PC:128 1 - 400
00 01 12 00 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:1 PC: 1 1 - 400
00 01 12 02 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:1 PC: 2 1 - 400
: : : :
00 01 13 7E 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:1 PC:128 1 - 400
00 01 14 00 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:2 PC: 1 1 - 400
00 01 14 02 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:2 PC: 2 1 - 400
: : : :
00 01 15 7E 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:2 PC:128 1 - 400
00 01 16 00 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:3 PC: 1 1 - 400
00 01 16 02 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:3 PC: 2 1 - 400
: : : :
00 01 17 7E 00 00 00 02 00 00 - 03 0F RX PC MAP / BANK:3 PC:128 1 - 400

------------------------------------------------------------------------------------------------------------------------

Model VB-99 MIDI Implementation 　Version : 1.00

Table 'GLOBAL'

------------------------------------------------------------------------------------------------------------------------

Address(H) Size(H) Data(H) Parameter Description

------------------------------------------------------------------------------------------------------------------------

10 00 ** 00 00 00 00 01 20 - 7D GLOBAL NAME 1 * Refer to Table 'NAME'
10 00 ** 01# 00 00 00 01 20 - 7D GLOBAL NAME 2
: : : :
10 00 ** 07# 00 00 00 01 20 - 7D GLOBAL NAME 8
10 00 ** 10 00 00 00 01 00 - 28 NS -20dB - +20dB
10 00 ** 11 00 00 00 01 00 - 64 REVERB 00 : 0%
01 : 2%
: :
64 : 200%
10 00 ** 12 00 00 00 01 00 - 02 MAIN OUTPUT SELECT 00 : AMP W/TWEETER
01 : AMP NO TWEETR
02 : LINE / PHONES
10 00 ** 13 00 00 00 01 00 - 01 EQ(MAIN) / MAIN EQ SW 00 : OFF
01 : ON
10 00 ** 14 00 00 00 01 00 - 18 EQ(MAIN) / LOW GAIN -12dB - +12dB
10 00 ** 15 00 00 00 01 00 - 1B EQ(MAIN) / LOW MID FREQ * Refer to Table 'EQ MID FREQ'
10 00 ** 16 00 00 00 01 00 - 05 EQ(MAIN) / LOW MID Q * Refer to Table 'EQ Q'
10 00 ** 17 00 00 00 01 00 - 18 EQ(MAIN) / LOW MID GAIN -12dB - +12dB
10 00 ** 18 00 00 00 01 00 - 1B EQ(MAIN) / HIGH MID FREQ * Refer to Table 'EQ MID FREQ'
10 00 ** 19 00 00 00 01 00 - 05 EQ(MAIN) / HIGH MID Q * Refer to Table 'EQ Q'
10 00 ** 1A 00 00 00 01 00 - 18 EQ(MAIN) / HIGH MID GAIN -12dB - +12dB
10 00 ** 1B 00 00 00 01 00 - 18 EQ(MAIN) / HIGH GAIN -12dB - +12dB
10 00 ** 1C 00 00 00 01 00 - 18 EQ(MAIN) / TOTAL GAIN -12dB - +12dB
10 00 ** 1D 00 00 00 01 00 - 01 EQ(SUB) / SUB EQ SW 00 : OFF
01 : ON
10 00 ** 1E 00 00 00 01 00 - 18 EQ(SUB) / LOW GAIN -12dB - +12dB
10 00 ** 1F 00 00 00 01 00 - 1B EQ(SUB) / LOW MID FREQ * Refer to Table 'EQ MID FREQ'
10 00 ** 20 00 00 00 01 00 - 05 EQ(SUB) / LOW MID Q * Refer to Table 'EQ Q'
10 00 ** 21 00 00 00 01 00 - 18 EQ(SUB) / LOW MID GAIN -12dB - +12dB
10 00 ** 22 00 00 00 01 00 - 1B EQ(SUB) / HIGH MID FREQ * Refer to Table 'EQ MID FREQ'
10 00 ** 23 00 00 00 01 00 - 05 EQ(SUB) / HIGH MID Q * Refer to Table 'EQ Q'
10 00 ** 24 00 00 00 01 00 - 18 EQ(SUB) / HIGH MID GAIN -12dB - +12dB
10 00 ** 25 00 00 00 01 00 - 18 EQ(SUB) / HIGH GAIN -12dB - +12dB
10 00 ** 26 00 00 00 01 00 - 18 EQ(SUB) / TOTAL GAIN -12dB - +12dB
10 00 ** 27 00 00 00 01 00 - 64 SUBOUT LEVEL 00 : 0%
01 : 2%
: :
64 : 200%

------------------------------------------------------------------------------------------------------------------------

Table 'GK SETTING'

------------------------------------------------------------------------------------------------------------------------

Address(H) Size(H) Data(H) Parameter Description

------------------------------------------------------------------------------------------------------------------------

20 00 ** 00 00 00 00 01 20 - 7D GK SETTING NAME 1 * Refer to Table 'NAME'
20 00 ** 01# 00 00 00 01 20 - 7D GK SETTING NAME 2
: : : :
20 00 ** 07# 00 00 00 01 20 - 7D GK SETTING NAME 8
20 00 ** 0E 00 00 00 01 00 - 14 PIEZO TONE LOW -10 - +10
20 00 ** 0F 00 00 00 01 00 - 14 PIEZO TONE HIGH -10 - +10
20 00 ** 10 00 00 00 01 00 - 04 GK PU TYPE 00 : GK-3B
01 : GK-2B
02 : PIEZO
03 : PIEZO G
04 : PIEZO R
20 00 ** 11 00 00 00 01 00 - 01 GK PU DIRECTION 00 : NORMAL
01 : REVRSE
20 00 ** 12 00 00 00 02 05 46 - 07 30 BASS SCALE 05 46 - 07 2C : 710mm - 940mm
07 2D : SHORT

page10

07 2E : MEDIUM
07 2F : LONG JB/PB
07 30 : EXTRA LONG
20 00 ** 14 00 00 00 01 00 - 01 GK PU PHASE 00 : NORMAL
01 : INVERS
20 00 ** 15 00 00 00 01 00 - 01 S1/S2 POS 00 : NORMAL
01 : REVRSE
20 00 ** 16 00 00 00 01 00 - 64 PICKUP <--> BRIDGE HiC 00 : 0.0mm
01 : 0.5mm
: :
64 : 50.0mm
20 00 ** 17 00 00 00 01 00 - 64 PICKUP <--> BRIDGE 1st 00 : 0.0mm
01 : 0.5mm
: :
64 : 50.0mm
20 00 ** 18 00 00 00 01 00 - 64 PICKUP <--> BRIDGE 2nd 00 : 0.0mm
01 : 0.5mm
: :
64 : 50.0mm
20 00 ** 19 00 00 00 01 00 - 64 PICKUP <--> BRIDGE 3rd 00 : 0.0mm
01 : 0.5mm
: :
64 : 50.0mm
20 00 ** 1A 00 00 00 01 00 - 64 PICKUP <--> BRIDGE 4th 00 : 0.0mm
01 : 0.5mm
: :
64 : 50.0mm
20 00 ** 1B 00 00 00 01 00 - 64 PICKUP <--> BRIDGE LowB 00 : 0.0mm
01 : 0.5mm
: :
64 : 50.0mm
20 00 ** 1C 00 00 00 01 00 - 64 SENS HiC 0 - 100
20 00 ** 1D 00 00 00 01 00 - 64 SENS 1st 0 - 100
20 00 ** 1E 00 00 00 01 00 - 64 SENS 2nd 0 - 100
20 00 ** 1F 00 00 00 01 00 - 64 SENS 3rd 0 - 100
20 00 ** 20 00 00 00 01 00 - 64 SENS 4th 0 - 100
20 00 ** 21 00 00 00 01 00 - 64 SENS LowB 0 - 100
20 00 ** 22 00 00 00 01 00 - 07 GK PU POS 00 : 4STR-1
01 : 4STR-2
02 : 4STR-3
03 : 5STR Lo1
04 : 5STR Lo2
05 : 5STR Hi1
06 : 5STR Hi2
07 : 6STR

------------------------------------------------------------------------------------------------------------------------

Model VB-99 MIDI Implementation 　Version : 1.00

Table 'SYSTEM(TEMPORARY)'

------------------------------------------------------------------------------------------------------------------------

Address(H) Size(H) Data(H) Parameter Description

------------------------------------------------------------------------------------------------------------------------

70 00 00 00 00 00 00 01 00 - 03 RUNNING MODE 00 : PLAY
01 : TUNER / MULTI MODE
02 : TUNER / SINGLE MODE
03 : GK SETTING / SENS
70 00 01 00 00 00 00 01 00 - 01 EDITOR COMUNICATION MODE 00 : OFF
01 : ON
70 00 02 00 00 00 00 01 - - - TUNER MULTI MODE / STR 1 NOTE * Refer to Table 'TUNER NOTE' (Read only)
70 00 02 01 00 00 00 01 - - - TUNER MULTI MODE / STR 1 CENT * Refer to Table 'TUNER CENT' (Read only)
70 00 02 02 00 00 00 01 - - - TUNER MULTI MODE / STR 2 NOTE * Refer to Table 'TUNER NOTE' (Read only)
70 00 02 03 00 00 00 01 - - - TUNER MULTI MODE / STR 2 CENT * Refer to Table 'TUNER CENT' (Read only)
70 00 02 04 00 00 00 01 - - - TUNER MULTI MODE / STR 3 NOTE * Refer to Table 'TUNER NOTE' (Read only)
70 00 02 05 00 00 00 01 - - - TUNER MULTI MODE / STR 3 CENT * Refer to Table 'TUNER CENT' (Read only)
70 00 02 06 00 00 00 01 - - - TUNER MULTI MODE / STR 4 NOTE * Refer to Table 'TUNER NOTE' (Read only)
70 00 02 07 00 00 00 01 - - - TUNER MULTI MODE / STR 4 CENT * Refer to Table 'TUNER CENT' (Read only)
70 00 02 08 00 00 00 01 - - - TUNER MULTI MODE / STR 5 NOTE * Refer to Table 'TUNER NOTE' (Read only)
70 00 02 09 00 00 00 01 - - - TUNER MULTI MODE / STR 5 CENT * Refer to Table 'TUNER CENT' (Read only)
70 00 02 0a 00 00 00 01 - - - TUNER MULTI MODE / STR 6 NOTE * Refer to Table 'TUNER NOTE' (Read only)
70 00 02 0b 00 00 00 01 - - - TUNER MULTI MODE / STR 6 CENT * Refer to Table 'TUNER CENT' (Read only)
70 00 03 00 00 00 00 01 - - - GK LEVEL MONITOR 1st 0 - 31 (Read only)
70 00 03 01 00 00 00 01 - - - GK LEVEL MONITOR 2nd 0 - 31 (Read only)
70 00 03 02 00 00 00 01 - - - GK LEVEL MONITOR 3rd 0 - 31 (Read only)
70 00 03 03 00 00 00 01 - - - GK LEVEL MONITOR 4th 0 - 31 (Read only)
70 00 03 04 00 00 00 01 - - - GK LEVEL MONITOR 5th 0 - 31 (Read only)
70 00 03 05 00 00 00 01 - - - GK LEVEL MONITOR 6th 0 - 31 (Read only)
70 00 03 10 00 00 00 01 - - - GK PEAK MONITOR 1st 0 - 31 (Read only)
70 00 03 11 00 00 00 01 - - - GK PEAK MONITOR 2nd 0 - 31 (Read only)
70 00 03 12 00 00 00 01 - - - GK PEAK MONITOR 3rd 0 - 31 (Read only)
70 00 03 13 00 00 00 01 - - - GK PEAK MONITOR 4th 0 - 31 (Read only)
70 00 03 14 00 00 00 01 - - - GK PEAK MONITOR 5th 0 - 31 (Read only)
70 00 03 15 00 00 00 01 - - - GK PEAK MONITOR 6th 0 - 31 (Read only)
70 00 04 00 00 00 00 01 - - - TUNER SINGLE MODE / STRING NUMBER 00 : No Signal
01 - 06 : 1 - 6
(Read only)
70 00 05 00 00 00 00 01 - - - TUNER SINGLE MODE / NOTE * Refer to Table 'TUNER NOTE' (Read only)
70 00 05 01 00 00 00 01 - - - TUNER SINGLE MODE / CENT * Refer to Table 'TUNER CENT' (Read only)
70 00 06 00 00 00 00 01 00 - 64 [A]COSM BASS / PITCH BEND 0 - 100
70 00 06 01 00 00 00 01 00 - 64 [B]COSM BASS / PITCH BEND 0 - 100
70 00 06 12 00 00 00 01 00 - 01 [A]COSM BASS / OSC SYNTH HOLD 00 : OFF
01 : ON
70 00 06 13 00 00 00 01 00 - 01 [B]COSM BASS / OSC SYNTH HOLD 00 : OFF
01 : ON
70 00 07 00 00 00 00 01 00 - 01 USB / DIRECT MON 00 : OFF
01 : ON

------------------------------------------------------------------------------------------------------------------------

Address Block Map ( PATCH )

--------------------------------------------------------------------------------

Address Block Sub Block Note
** ** 00 00 +----------------------------------------+
| PATCH COMMON |
+----------------------------------------+
** ** 01 00 +----------------------------------------+
| CONTROL ASSIGN |
+----------------------------------------+
** ** 0D 00 +----------------------------------------+
| V-LINK |
+----------------------------------------+
** ** 0D 1E +----------------------------------------+
| D BEAM |
+----------------------------------------+
** ** 0D 35 +----------------------------------------+
| RIBBON |
+----------------------------------------+
** ** 20 00 +----------------------------------------+
| MIXER |
+----------------------------------------+
** ** 30 00 +----------------------------------------+
| COSM BASS |
+----------------------------------------+
** ** 40 00 +----------------------------------------+
| POLY FX |
+----------------------------------------+
** ** 50 00 +----------------------------------------+
| CHAIN, COSM AMP, FX |
+----------------------------------------+

page11

** ** 70 00 +----------------------------------------+

Model VB-99 MIDI Implementation 　Version : 1.00

| CONTROL ASSIGN 1-16 |
+----------------------------------------+
** ** 73 70 +----------------------------------------+
| INPUT SENS |
+----------------------------------------+
** ** 7C 00 +----------------------------------------+
| FAVORITE SELECT |
+----------------------------------------+

Table 'PATCH'

------------------------------------------------------------------------------------------------------------------------

Address(H) Size(H) Data(H) Parameter Description

------------------------------------------------------------------------------------------------------------------------

[ PATCH COMMON ]
** ** 00 00 00 00 00 01 20 - 7D PATCH NAME 1 * Refer to Table 'NAME'
** ** 00 01# 00 00 00 01 20 - 7D PATCH NAME 2
: : : :
** ** 00 0F# 00 00 00 01 20 - 7D PATCH NAME 16
: : : :
** ** 00 10 00 00 00 01 00 - 0F CATEGORY 00 - 09 : USER 1 - USER 10
0A : E.BASS
0B : AC BASS
0C : SYNTH
0D : E.GUITAR
0E : EFFECTS
0F : OTHERS
** ** 00 11 00 00 00 01 00 - 09 GK SETTING 1 - 10
** ** 00 12 00 00 00 02 00 00 - 01 00 TX PC / BANK MSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 14 00 00 00 01 00 - 7F TX PC / PC 1 - 128
** ** 00 15 00 00 00 02 00 00 - 01 52 BPM 40 - 250
** ** 00 17 00 00 00 01 00 - 0B KEY 00 : C Am
01 : Db Bbm
02 : D Bm
03 : Eb Cm
04 : E C#m
05 : F Dm
06 : F# D#m
07 : G Em
08 : Ab Fm
09 : A F#m
0A : Bb Gm
0B : B G#m
** ** 00 18 00 00 00 02 00 00 - 7F 7F DIRECT EDIT F1 * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 00 1A 00 00 00 02 00 00 - 7F 7F DIRECT EDIT F2 * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 00 1C 00 00 00 02 00 00 - 7F 7F DIRECT EDIT F3 * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 00 1E 00 00 00 02 00 00 - 7F 7F DIRECT EDIT F4 * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 00 20 00 00 00 02 00 00 - 7F 7F DIRECT EDIT F5 * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 00 22 00 00 00 02 00 00 - 7F 7F DIRECT EDIT F6 * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 00 24 00 00 00 01 00 - 01 FC AMP CTL1 00 : OFF
01 : ON
** ** 00 25 00 00 00 01 00 - 01 FC AMP CTL2 00 : OFF
01 : ON
** ** 00 26 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING HiC BANK MSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 28 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING HiC BANK LSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 2A 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING HiC PC 00 00 : OFF
00 01 - 01 00 : 1 - 128
** ** 00 2C 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 1st BANK MSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 2E 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 1st BANK LSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 30 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 1st PC 00 00 : OFF
00 01 - 01 00 : 1 - 128
** ** 00 32 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 2nd BANK MSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 34 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 2nd BANK LSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 36 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 2nd PC 00 00 : OFF
00 01 - 01 00 : 1 - 128
** ** 00 38 00 00 00 01 00 - 01 BASS TO MIDI / MODE 00 : MONO
01 : POLY
** ** 00 39 00 00 00 01 00 - 05 BASS TO MIDI / PLAY FEEL 00 : FEEL1
01 : FEEL2
02 : FEEL3
03 : FEEL4
04 : NO DYNA
05 : STRUM
** ** 00 3A 00 00 00 01 00 - 03 BASS TO MIDI / CHROMATIC 00 : OFF
01 : TYPE1
02 : TYPE2
03 : TYPE3
** ** 00 3B 00 00 00 01 00 - 02 BASS TO MIDI / HOLD TYPE 00 : HOLD1
01 : HOLD2
02 : HOLD3
** ** 00 3C 00 00 00 01 00 - 17 BASS TO MIDI / CC / 1 SRC * Refer to Table 'BASS TO MIDI CC SRC'
** ** 00 3D 00 00 00 01 00 - 3F BASS TO MIDI / CC / 1 CC 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
** ** 00 3E 00 00 00 01 00 - 17 BASS TO MIDI / CC / 2 SRC * Refer to Table 'BASS TO MIDI CC SRC'
** ** 00 3F 00 00 00 01 00 - 3F BASS TO MIDI / CC / 2 CC 00 : OFF
01 - 1F : CC #1 - CC #31
20 - 3F : CC #64 - CC #95
** ** 00 40 00 00 00 02 00 00 - 01 00 TX PC / BANK LSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 42 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 3rd BANK MSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 44 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 3rd BANK LSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 46 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 3rd PC 00 00 : OFF
00 01 - 01 00 : 1 - 128
** ** 00 48 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 4th BANK MSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 4A 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 4th BANK LSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 4C 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING 4th PC 00 00 : OFF
00 01 - 01 00 : 1 - 128
** ** 00 4E 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING LowB BANK MSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 50 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING LowB BANK LSB 00 00 : OFF
00 01 - 01 00 : 0 - 127
** ** 00 52 00 00 00 02 00 00 - 01 00 BASS TO MIDI / STRING LowB PC 00 00 : OFF
00 01 - 01 00 : 1 - 128
** ** 00 54 00 00 00 01 00 - 01 PRM_BASS_DIRECT 00 : OFF
01 : ON

[ CONTROL ASSIGN GK VOL ]
** ** 01 00 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 01 01 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 03 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 01 05 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 01 08 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 01 09 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127

page12

** ** 01 0A 00 00 00 01 00 - 01 (2) SW 00 : OFF

Model VB-99 MIDI Implementation 　Version : 1.00

01 : ON
** ** 01 0B 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 0D 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 01 0F 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 01 12 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 01 13 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN GK S1,S2 ]
** ** 01 14 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 01 15 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 17 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 01 19 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 01 1B 00 00 00 01 00 - 03 (1) MODE 00 : S1:DEC S2:INC
01 : S1:INC S2:DEC
02 : S1:MIN S2:MAX
03 : S1:MAX S2:MIN
** ** 01 1E 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 01 1F 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 21 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 01 23 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 01 25 00 00 00 01 00 - 03 (2) MODE 00 : S1:DEC S2:INC
01 : S1:INC S2:DEC
02 : S1:MIN S2:MAX
03 : S1:MAX S2:MIN

[ CONTROL ASSIGN CONTROL1 ]
** ** 01 28 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 01 29 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 2B 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 01 2D 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 01 2F 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 01 32 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 01 33 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 35 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 01 37 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 01 39 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN CONTROL2 ]
** ** 01 3C 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 01 3D 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 3F 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 01 41 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 01 43 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 01 46 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 01 47 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 49 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 01 4B 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 01 4D 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN EXP PEDAL ]
** ** 01 50 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 01 51 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 53 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 01 55 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 01 58 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 01 59 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 01 5A 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 01 5B 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 5D 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 01 5F 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 01 62 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 01 63 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN CTL3 ]
** ** 01 64 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 01 65 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 67 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 01 69 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 01 6B 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 01 6E 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 01 6F 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 71 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 01 73 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 01 75 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN CTL4 ]
** ** 01 78 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 01 79 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 01 7B 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 01 7D 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 01 7F 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 02 02 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 02 03 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 02 05 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 02 07 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 02 09 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN D BEAM V ]
** ** 03 00 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 03 01 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 03 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 03 05 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 03 07 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 03 08 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 03 09 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 03 0A 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 03 0B 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 0D 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 03 0F 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET

page13

** ** 03 11 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT

Model VB-99 MIDI Implementation 　Version : 1.00

01 : LATCH
** ** 03 12 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 03 13 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN D BEAM H ]
** ** 03 14 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 03 15 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 17 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 03 19 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 03 1C 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 03 1D 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 03 1E 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 03 1F 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 21 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 03 23 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 03 26 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 03 27 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN RIBBON ACT ]
** ** 03 28 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 03 29 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 2B 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 03 2D 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 03 2F 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 03 32 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 03 33 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 35 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 03 37 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 03 39 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN RIBBON POS ]
** ** 03 3C 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 03 3D 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 3F 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 03 41 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 03 44 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 03 45 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 03 46 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 03 47 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 03 49 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 03 4B 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 03 4E 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 03 4F 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN FC-300 EXP1 ]
** ** 05 00 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 05 01 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 03 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 05 05 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 05 08 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 05 09 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 05 0A 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 05 0B 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 0D 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 05 0F 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 05 12 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 05 13 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN FC-300 EXP SW1 ]
** ** 05 14 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 05 15 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 17 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 05 19 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 05 1B 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 05 1E 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 05 1F 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 21 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 05 23 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 05 25 00 00 00 01 00 - 01 SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN FC-300 EXP2 ]
** ** 05 28 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 05 29 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 2B 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 05 2D 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 05 30 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 05 31 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 05 32 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 05 33 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 35 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 05 37 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 05 3A 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 05 3B 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN FC-300 EXP SW2 ]
** ** 05 3C 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 05 3D 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 3F 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 05 41 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 05 43 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 05 46 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 05 47 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 05 49 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 05 4B 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 05 4D 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN FC-300 CTL1 ]
** ** 06 00 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 06 01 00 00 00 02 00 00 - 7F 7F TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 03 00 00 00 02 00 00 - 7F 7F MIN * Depend on TARGET

page14

** ** 06 05 00 00 00 02 00 00 - 7F 7F MAX * Depend on TARGET

Model VB-99 MIDI Implementation 　Version : 1.00

** ** 06 07 00 00 00 01 00 - 01 SW MODE 00 : MOMENT
01 : LATCH
** ** 06 0A 00 00 00 01 00 - 01 SW 00 : OFF
01 : ON
** ** 06 0B 00 00 00 02 00 00 - 7F 7F TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 0D 00 00 00 02 00 00 - 7F 7F MIN * Depend on TARGET
** ** 06 0F 00 00 00 02 00 00 - 7F 7F MAX * Depend on TARGET
** ** 06 11 00 00 00 01 00 - 01 SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN FC-300 CTL2 ]
** ** 06 14 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 06 15 00 00 00 02 00 00 - 7F 7F TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 17 00 00 00 02 00 00 - 7F 7F MIN * Depend on TARGET
** ** 06 19 00 00 00 02 00 00 - 7F 7F MAX * Depend on TARGET
** ** 06 1B 00 00 00 01 00 - 01 SW MODE 00 : MOMENT
01 : LATCH
** ** 06 1E 00 00 00 01 00 - 01 SW 00 : OFF
01 : ON
** ** 06 1F 00 00 00 02 00 00 - 7F 7F TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 21 00 00 00 02 00 00 - 7F 7F MIN * Depend on TARGET
** ** 06 23 00 00 00 02 00 00 - 7F 7F MAX * Depend on TARGET
** ** 06 25 00 00 00 01 00 - 01 SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN FC-300 E3/C3 ]
** ** 06 28 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 06 29 00 00 00 02 00 00 - 7F 7F TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 2B 00 00 00 02 00 00 - 7F 7F MIN * Depend on TARGET
** ** 06 2D 00 00 00 02 00 00 - 7F 7F MAX * Depend on TARGET
** ** 06 2F 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 06 30 00 00 00 01 00 - 7E RANGE LOW 0 - 126
** ** 06 31 00 00 00 01 01 - 7F RANGE HIGH 1 - 127
** ** 06 32 00 00 00 01 00 - 01 SW 00 : OFF
01 : ON
** ** 06 33 00 00 00 02 00 00 - 7F 7F TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 35 00 00 00 02 00 00 - 7F 7F MIN * Depend on TARGET
** ** 06 37 00 00 00 02 00 00 - 7F 7F MAX * Depend on TARGET
** ** 06 39 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH
** ** 06 3A 00 00 00 01 00 - 7E RANGE LOW 0 - 126
** ** 06 3B 00 00 00 01 01 - 7F RANGE HIGH 1 - 127

[ CONTROL ASSIGN FC-300 CTL4 ]
** ** 06 3C 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 06 3D 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 3F 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 06 41 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 06 43 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 06 46 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 06 47 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 49 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 06 4B 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 06 4D 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN FC-300 E4/C5 ]
** ** 06 50 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 06 51 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 53 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 06 55 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 06 57 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 06 58 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 06 59 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 06 5A 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 06 5B 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 5D 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 06 5F 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 06 61 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH
** ** 06 62 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 06 63 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN FC-300 CTL6 ]
** ** 06 64 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 06 65 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 67 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 06 69 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 06 6B 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 06 6E 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 06 6F 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 71 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 06 73 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 06 75 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ CONTROL ASSIGN FC-300 E5/C7 ]
** ** 06 78 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 06 79 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 06 7B 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET
** ** 06 7D 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 06 7F 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 07 00 00 00 00 01 00 - 7E (1) RANGE LOW 0 - 126
** ** 07 01 00 00 00 01 01 - 7F (1) RANGE HIGH 1 - 127
** ** 07 02 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 07 03 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 07 05 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 07 07 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 07 09 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH
** ** 07 0A 00 00 00 01 00 - 7E (2) RANGE LOW 0 - 126
** ** 07 0B 00 00 00 01 01 - 7F (2) RANGE HIGH 1 - 127

[ CONTROL ASSIGN FC-300 CTL8 ]
** ** 07 0C 00 00 00 01 00 - 01 (1) SW 00 : OFF
01 : ON
** ** 07 0D 00 00 00 02 00 00 - 7F 7F (1) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'

page15

** ** 07 0F 00 00 00 02 00 00 - 7F 7F (1) MIN * Depend on TARGET

Model VB-99 MIDI Implementation 　Version : 1.00

** ** 07 11 00 00 00 02 00 00 - 7F 7F (1) MAX * Depend on TARGET
** ** 07 13 00 00 00 01 00 - 01 (1) SW MODE 00 : MOMENT
01 : LATCH
** ** 07 16 00 00 00 01 00 - 01 (2) SW 00 : OFF
01 : ON
** ** 07 17 00 00 00 02 00 00 - 7F 7F (2) TARGET * Refer to Table 'CONTROL ASSIGN TARGET'
** ** 07 19 00 00 00 02 00 00 - 7F 7F (2) MIN * Depend on TARGET
** ** 07 1B 00 00 00 02 00 00 - 7F 7F (2) MAX * Depend on TARGET
** ** 07 1D 00 00 00 01 00 - 01 (2) SW MODE 00 : MOMENT
01 : LATCH

[ V-LINK COMMON ]
** ** 0D 00 00 00 00 01 00 - 20 V-LINK / A ch PALETTE 00 : OFF
01 - 20 : 1 - 32
** ** 0D 01 00 00 00 01 00 - 20 V-LINK / A ch CLIP 00 : OFF
01 - 20 : 1 - 32
** ** 0D 02 00 00 00 01 00 - 20 V-LINK / B ch PALETTE 00 : OFF
01 - 20 : 1 - 32
** ** 0D 03 00 00 00 01 00 - 20 V-LINK / B ch CLIP 00 : OFF
01 - 20 : 1 - 32
** ** 0D 04 00 00 00 01 00 - 03 V-LINK / STRING CH HiC 00 : OFF
01 : A CH
02 : B CH
03 : C CH
** ** 0D 05 00 00 00 01 00 - 03 V-LINK / STRING CH 1st 00 : OFF
01 : A CH
02 : B CH
03 : C CH
** ** 0D 06 00 00 00 01 00 - 03 V-LINK / STRING CH 2nd 00 : OFF
01 : A CH
02 : B CH
03 : C CH
** ** 0D 07 00 00 00 01 00 - 03 V-LINK / STRING CH 3rd 00 : OFF
01 : A CH
02 : B CH
03 : C CH
** ** 0D 08 00 00 00 01 00 - 03 V-LINK / STRING CH 4th 00 : OFF
01 : A CH
02 : B CH
03 : C CH
** ** 0D 09 00 00 00 01 00 - 03 V-LINK / STRING CH LowB 00 : OFF
01 : A CH
02 : B CH
03 : C CH

[ V-LINK ASSIGN1 ]
** ** 0D 0A 00 00 00 01 00 - 1B SOURCE * Refer to Table 'V-LINK ASSIGN SOURCE'
** ** 0D 0B 00 00 00 01 00 - 21 TARGET * Refer to Table 'V-LINK ASSIGN TARGET'
** ** 0D 0C 00 00 00 01 00 - 7F MIN 0 - 127
** ** 0D 0D 00 00 00 01 00 - 7F MAX 0 - 127
** ** 0D 0E 00 00 00 01 00 - 64 WAVE PEDAL RATE 0 - 100
** ** 0D 0F 00 00 00 01 00 - 02 WAVE PEDAL FORM 00 : SAW
01 : TRI
02 : SIN
** ** 0D 10 00 00 00 02 00 00 - 00 17 INTERNAL PEDAL TRIGGR * Refer to Table 'INTERNAL PEDAL TRIGGER'
** ** 0D 12 00 00 00 01 00 - 64 INTERNAL PEDAL TIME 0 - 100
** ** 0D 13 00 00 00 01 00 - 02 INTERNAL PEDAL CURVE 00 : LINEAR
01 : SLOW RISE
02 : FAST RISE

[ V-LINK ASSIGN2 ]
** ** 0D 14 00 00 00 01 00 - 1B SOURCE * Refer to Table 'V-LINK ASSIGN SOURCE'
** ** 0D 15 00 00 00 01 00 - 21 TARGET * Refer to Table 'V-LINK ASSIGN TARGET'
** ** 0D 16 00 00 00 01 00 - 7F MIN 0 - 127
** ** 0D 17 00 00 00 01 00 - 7F MAX 0 - 127
** ** 0D 18 00 00 00 01 00 - 64 WAVE PEDAL RATE 0 - 100
** ** 0D 19 00 00 00 01 00 - 02 WAVE PEDAL FORM 00 : SAW
01 : TRI
02 : SIN
** ** 0D 1A 00 00 00 02 00 00 - 00 17 INTERNAL PEDAL TRIGGR * Refer to Table 'INTERNAL PEDAL TRIGGER'
** ** 0D 1C 00 00 00 01 00 - 64 INTERNAL PEDAL TIME 0 - 100
** ** 0D 1D 00 00 00 01 00 - 02 INTERNAL PEDAL CURVE 00 : LINEAR
01 : SLOW RISE
02 : FAST RISE

[ D BEAM ]
** ** 0D 1E 00 00 00 01 00 - 03 SELECT 00 : OFF
01 : PITCH
02 : FILTER
03 : ASSIGN
** ** 0D 1F 00 00 00 01 00 - 01 PITCH TYPE 00 : T-ARM
01 : FREEZE
** ** 0D 20 00 00 00 01 00 - 02 T-ARM CH 00 : A
01 : B
02 : A+B
** ** 0D 21 00 00 00 01 00 - 03 T-ARM TYPE 00 : S-TYPE
01 : B-TYPE
02 : F-TYPE
03 : TRANS
** ** 0D 22 00 00 00 01 00 - 64 T-ARM DOWN MIN -50 - +50
** ** 0D 23 00 00 00 01 00 - 64 T-ARM DOWN MAX -50 - +50
** ** 0D 24 00 00 00 01 00 - 30 T-ARM (TRANS) DOWN MIN -24 - +24
** ** 0D 25 00 00 00 01 00 - 30 T-ARM (TRANS) DOWN MAX -24 - +24
** ** 0D 26 00 00 00 01 00 - 02 FREEZE CH 00 : A
01 : B
02 : A+B
** ** 0D 27 00 00 00 01 00 - 64 FREEZE A ATTACK 0 - 100
** ** 0D 28 00 00 00 01 00 - 64 FREEZE A REL 0 - 100
** ** 0D 29 00 00 00 01 00 - 64 FREEZE A LEVEL 0 - 100
** ** 0D 2A 00 00 00 01 00 - 64 FREEZE A DIRECT 0 - 100
** ** 0D 2B 00 00 00 01 00 - 64 FREEZE B ATTACK 0 - 100
** ** 0D 2C 00 00 00 01 00 - 64 FREEZE B REL 0 - 100
** ** 0D 2D 00 00 00 01 00 - 64 FREEZE B LEVEL 0 - 100
** ** 0D 2E 00 00 00 01 00 - 64 FREEZE B DIRECT 0 - 100
** ** 0D 2F 00 00 00 01 00 - 02 FILTER CH 00 : A
01 : B
02 : A+B
** ** 0D 30 00 00 00 01 00 - 02 FILTER TYPE 00 : LPF
01 : BPF
02 : HPF
** ** 0D 31 00 00 00 01 00 - 64 FILTER FREQ MIN 0 - 100
** ** 0D 32 00 00 00 01 00 - 64 FILTER FREQ MAX 0 - 100
** ** 0D 33 00 00 00 01 00 - 64 FILTER RESO 0 - 100
** ** 0D 34 00 00 00 01 00 - 64 FILTER LEVEL 0 - 100

[ RIBBON ]
** ** 0D 35 00 00 00 01 00 - 03 SELECT 00 : OFF
01 : PITCH
02 : FILTER
03 : ASSIGN
** ** 0D 36 00 00 00 01 00 - 02 T-ARM CH 00 : A
01 : B
02 : A+B
** ** 0D 37 00 00 00 01 00 - 03 T-ARM TYPE 00 : S-TYPE

page16

01 : B-TYPE
02 : F-TYPE
03 : TRANS
** ** 0D 38 00 00 00 01 00 - 64 T-ARM DOWN MIN -50 - +50
** ** 0D 39 00 00 00 01 00 - 64 T-ARM DOWN MAX -50 - +50
** ** 0D 3A 00 00 00 01 00 - 30 T-ARM (TRANS) DOWN MIN -24 - +24
** ** 0D 3B 00 00 00 01 00 - 30 T-ARM (TRANS) DOWN MAX -24 - +24
** ** 0D 3C 00 00 00 01 00 - 02 FILTER CH 00 : A
01 : B
02 : A+B
** ** 0D 3D 00 00 00 01 00 - 02 FILTER TYPE 00 : LPF
01 : BPF
02 : HPF
** ** 0D 3E 00 00 00 01 00 - 64 FILTER FREQ MIN 0 - 100
** ** 0D 3F 00 00 00 01 00 - 64 FILTER FREQ MAX 0 - 100
** ** 0D 40 00 00 00 01 00 - 64 FILTER RESO 0 - 100
** ** 0D 41 00 00 00 01 00 - 64 FILTER LEVEL 0 - 100

[ MIXER ]
** ** 20 00 00 00 00 01 00 - 64 V-BASS LEVEL 00 : 0
01 : 2
: :
64 : 200
** ** 20 01 00 00 00 01 00 - 64 MAIN LEVEL 00 : 0
01 : 2
: :
64 : 200
** ** 20 02 00 00 00 01 00 - 64 SUB LEVEL 00 : 0
01 : 2
: :
64 : 200
** ** 20 03 00 00 00 01 00 - 64 D OUT LEVEL 00 : 0
01 : 2
: :
64 : 200
** ** 20 04 00 00 00 01 00 - 04 MAIN OUT 00 : CH A
01 : CH B
02 : MIXER (DRY)
03 : MIXER
04 : BASS DIRECT
** ** 20 05 00 00 00 01 00 - 04 SUB OUT 00 : CH A
01 : CH B
02 : MIXER (DRY)
03 : MIXER
04 : BASS DIRECT
** ** 20 06 00 00 00 01 00 - 08 D OUT 00 : COSM BASS A
01 : COSM BASS B
02 : NORMAL PU
03 : CH A
04 : CH B
05 : MIXER (DRY)
06 : MIXER
07 : MAIN OUT
08 : SUB OUT
** ** 20 07 00 00 00 01 00 - 01 DYNAMIC / DYNA SW 00 : OFF
01 : ON
** ** 20 08 00 00 00 01 00 - 02 DYNAMIC / TYPE 00 : DYNA A
01 : DYNA B
02 : DYNA BAL
** ** 20 09 00 00 00 01 00 - 63 DYNAMIC / LOWER RNG 0 - 99
** ** 20 0A 00 00 00 01 01 - 64 DYNAMIC / UPPER RNG 1 - 100
** ** 20 0B 00 00 00 01 00 - 64 DYNAMIC / RELEASE 0 - 100
** ** 20 0C 00 00 00 01 00 - 64 DYNAMIC / LOWER LEV A 0 - 100
** ** 20 0D 00 00 00 01 00 - 64 DYNAMIC / UPPER LEV A 0 - 100
** ** 20 0E 00 00 00 01 00 - 64 DYNAMIC / LOWER LEV B 0 - 100
** ** 20 0F 00 00 00 01 00 - 64 DYNAMIC / UPPER LEV B 0 - 100
** ** 20 10 00 00 00 01 00 - 64 DYNAMIC / LOWER BAL A100:0B - A0:100B
** ** 20 11 00 00 00 01 00 - 64 DYNAMIC / UPPER BAL A100:0B - A0:100B
** ** 20 13 00 00 00 01 00 - 64 A/B BAL A100:0B - A0:100B
** ** 20 14 00 00 00 01 00 - 64 MIX A / PAN 100:0 - 0:100
** ** 20 15 00 00 00 01 00 - 64 MIX A / LEVEL 0 - 100
** ** 20 16 00 00 00 01 00 - 64 MIX A / REVERB A SEND 0 - 100
** ** 20 17 00 00 00 01 00 - 64 MIX A / DELAY A SEND 0 - 100
** ** 20 18 00 00 00 01 00 - 32 MIX A / CH DELAY 0ms - 50ms
** ** 20 19 00 00 00 01 00 - 01 MIX A / MIX SW 00 : OFF
01 : ON
** ** 20 1A 00 00 00 01 00 - 64 MIX B / PAN 100:0 - 0:100
** ** 20 1B 00 00 00 01 00 - 64 MIX B / LEVEL 0 - 100
** ** 20 1C 00 00 00 01 00 - 64 MIX B / REVERB B SEND 0 - 100
** ** 20 1D 00 00 00 01 00 - 64 MIX B / DELAY B SEND 0 - 100
** ** 20 1E 00 00 00 01 00 - 32 MIX B / CH DELAY 0ms - 50ms
** ** 20 1F 00 00 00 01 00 - 01 MIX B / MIX SW 00 : OFF
01 : ON
** ** 20 20 00 00 00 01 00 - 01 REVERB / REVERB SW 00 : OFF
01 : ON
** ** 20 21 00 00 00 01 00 - 04 REVERB / TYPE 00 : AMB
01 : ROOM
02 : HALL1
03 : HALL2
04 : PLATE
** ** 20 22 00 00 00 01 00 - 63 REVERB / TIME 0.1s - 10.0s
** ** 20 23 00 00 00 01 00 - 64 REVERB / PRE DELAY 0ms - 100ms
** ** 20 24 00 00 00 01 00 - 0A REVERB / LOW CUT * Refer to Table 'LOW CUT'
** ** 20 25 00 00 00 01 00 - 09 REVERB / HIGH CUT * Refer to Table 'HIGH CUT'
** ** 20 26 00 00 00 01 00 - 0A REVERB / DENS 0 - 10
** ** 20 27 00 00 00 01 00 - 64 REVERB / LEVEL 0 - 100
** ** 20 28 00 00 00 01 00 - 01 DELAY / DELAY SW 00 : OFF
01 : ON
** ** 20 29 00 00 00 02 00 01 - 0E 15 DELAY / TIME 00 01 - 0E 08 : 1ms - 1800ms
0E 09 - 0E 15 : * Refer to Table 'BPM NOTE(2)'
** ** 20 2B 00 00 00 01 00 - 64 DELAY / FEEDBACK 0 - 100
** ** 20 2C 00 00 00 01 00 - 09 DELAY / HIGH CUT * Refer to Table 'HIGH CUT'
** ** 20 2D 00 00 00 01 00 - 78 DELAY / LEVEL 0 - 120
** ** 20 2F 00 00 00 01 00 - 01 TOTAL EQ / EQ SW 00 : OFF
01 : ON
** ** 20 30 00 00 00 01 00 - 18 TOTAL EQ / LOW GAIN -12dB - +12dB
** ** 20 31 00 00 00 01 00 - 1B TOTAL EQ / LOW MID FREQ * Refer to Table 'EQ MID FREQ'
** ** 20 32 00 00 00 01 00 - 05 TOTAL EQ / LOW MID Q * Refer to Table 'EQ Q'
** ** 20 33 00 00 00 01 00 - 18 TOTAL EQ / LOW MID GAIN -12dB - +12dB
** ** 20 34 00 00 00 01 00 - 1B TOTAL EQ / HIGH MID FREQ * Refer to Table 'EQ MID FREQ'
** ** 20 35 00 00 00 01 00 - 05 TOTAL EQ / HIGH MID Q * Refer to Table 'EQ Q'
** ** 20 36 00 00 00 01 00 - 18 TOTAL EQ / HIGH MID GAIN -12dB - +12dB
** ** 20 37 00 00 00 01 00 - 18 TOTAL EQ / HIGH GAIN -12dB - +12dB
** ** 20 38 00 00 00 01 00 - 18 TOTAL EQ / TOTAL GAIN -12dB - +12dB

Model VB-99 MIDI Implementation 　Version : 1.00

[ [A] COSM BASS ]
** ** 30 00 00 00 00 01 00 - 02 COSM BASS SW 00 : OFF
01 : ON
02 : NORMAL PU
** ** 30 01 00 00 00 01 00 - 03 MODLNG TYPE 00 : E.GTR
01 : AC BASS
02 : E.BASS
03 : SYNTH
** ** 30 02 00 00 00 01 00 - 01 EQ / EQ SW 00 : OFF
01 : ON
** ** 30 03 00 00 00 01 00 - 18 EQ / LOW GAIN -12dB - +12dB
** ** 30 04 00 00 00 01 00 - 1B EQ / LOW MID FREQ * Refer to Table 'EQ MID FREQ'
** ** 30 05 00 00 00 01 00 - 05 EQ / LOW MID Q * Refer to Table 'EQ Q'

page17

** ** 30 06 00 00 00 01 00 - 18 EQ / LOW MID GAIN -12dB - +12dB
** ** 30 07 00 00 00 01 00 - 1B EQ / HIGH MID FREQ * Refer to Table 'EQ MID FREQ'
** ** 30 08 00 00 00 01 00 - 05 EQ / HIGH MID Q * Refer to Table 'EQ Q'
** ** 30 09 00 00 00 01 00 - 18 EQ / HIGH MID GAIN -12dB - +12dB
** ** 30 0A 00 00 00 01 00 - 18 EQ / HIGH GAIN -12dB - +12dB
** ** 30 0B 00 00 00 01 00 - 18 EQ / TOTAL GAIN -12dB - +12dB
** ** 30 0C 00 00 00 01 00 - 64 MIX / STRING PAN HiC 100:0 - 0:100
** ** 30 0D 00 00 00 01 00 - 64 MIX / STRING PAN 1st 100:0 - 0:100
** ** 30 0E 00 00 00 01 00 - 64 MIX / STRING PAN 2nd 100:0 - 0:100
** ** 30 0F 00 00 00 01 00 - 64 MIX / STRING PAN 3rd 100:0 - 0:100
** ** 30 10 00 00 00 01 00 - 64 MIX / STRING PAN 4th 100:0 - 0:100
** ** 30 11 00 00 00 01 00 - 64 MIX / STRING PAN LowB 100:0 - 0:100
** ** 30 12 00 00 00 01 00 - 64 MIX / STRING LEVEL HiC 0 - 100
** ** 30 13 00 00 00 01 00 - 64 MIX / STRING LEVEL 1st 0 - 100
** ** 30 14 00 00 00 01 00 - 64 MIX / STRING LEVEL 2nd 0 - 100
** ** 30 15 00 00 00 01 00 - 64 MIX / STRING LEVEL 3rd 0 - 100
** ** 30 16 00 00 00 01 00 - 64 MIX / STRING LEVEL 4th 0 - 100
** ** 30 17 00 00 00 01 00 - 64 MIX / STRING LEVEL LowB 0 - 100
** ** 30 18 00 00 00 01 00 - 64 MIX LEVEL COSM BASS 0 - 100
** ** 30 1A 00 00 00 01 00 - 64 MIX LEVEL NORMAL PU 0 - 100
** ** 30 1B 00 00 00 01 00 - 64 NORMAL LEVEL (COSM BASS SW = NORMAL PU) 0 - 100
** ** 30 1C 00 00 00 01 00 - 09 E.BASS / E.BASS TYPE 00 : VINT JB
01 : JB
02 : VINT PB
03 : PB
04 : M-MAN
05 : RICK
06 : T-BIRD
07 : ACTIVE
08 : VIOLIN
09 : VARI
** ** 30 1D 00 00 00 01 00 - 64 E.BASS / (MASTER) VOL 0 - 100
** ** 30 1E 00 00 00 01 00 - 64 E.BASS / REAR VOL 0 - 100
** ** 30 1F 00 00 00 01 00 - 64 E.BASS / FRONT VOL 0 - 100
** ** 30 20 00 00 00 01 00 - 64 E.BASS / BAL R100:0F - R0:100F
** ** 30 21 00 00 00 01 00 - 64 E.BASS / TONE 0 - 100
** ** 30 22 00 00 00 01 00 - 64 E.BASS / REAE TONE 0 - 100
** ** 30 23 00 00 00 01 00 - 64 E.BASS / FRONT TONE 0 - 100
** ** 30 24 00 00 00 01 00 - 02 E.BASS / PU SELECT 00 : REAR
01 : R+F
02 : FRONT
** ** 30 25 00 00 00 01 00 - 64 E.BASS / TREBLE 0-100 0 - 100
** ** 30 26 00 00 00 01 00 - 64 E.BASS / BASS 0-100 0 - 100
** ** 30 27 00 00 00 01 00 - 64 E.BASS / TREBLE +/-50 -50 - +50
** ** 30 29 00 00 00 01 00 - 64 E.BASS / BASS +/-50 -50 - +50
** ** 30 2A 00 00 00 01 00 - 01 E.BASS / TREBLE ON 00 : OFF
01 : ON
** ** 30 2B 00 00 00 01 00 - 01 E.BASS / BASS ON 00 : OFF
01 : ON
** ** 30 2C 00 00 00 01 00 - 01 E.BASS / RHYTHM/SOLO 00 : RHYTHM
01 : SOLO
** ** 30 2D 00 00 00 01 00 - 03 E.BASS VARI / CTL TYPE 00 : 2V2T
01 : 2V1T
02 : BAL
03 : 2BAND
** ** 30 2E 00 00 00 01 00 - 64 E.BASS VARI / TONE -50 - +50
** ** 30 2F 00 00 00 01 00 - 64 E.BASS VARI / REAR TONE -50 - +50
** ** 30 30 00 00 00 01 00 - 64 E.BASS VARI / FRONT TONE -50 - +50
** ** 30 33 00 00 00 01 00 - 02 E.BASS VARI / REAR PU TYPE 00 : SINGLE
01 : DOUBLE
02 : PIEZO
** ** 30 34 00 00 00 01 00 - 59 E.BASS VARI / REAR PU POS 00 : 5mm
01 : 10mm
: :
59 : 450mm
** ** 30 35 00 00 00 01 00 - 01 E.BASS VARI / REAR PU PHASE 00 : IN
01 : OUT
** ** 30 36 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET HiC 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 38 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 1st 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 3A 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 2nd 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 3C 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 3rd 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 3E 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 4th 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 40 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET LowB 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 42 00 00 00 01 00 - 02 E.BASS VARI / FRONT PU TYPE 00 : SINGLE
01 : DOUBLE
02 : PIEZO
** ** 30 43 00 00 00 01 00 - 59 E.BASS VARI / FRONT PU POS 00 : 5mm
01 : 10mm
: :
59 : 450mm
** ** 30 44 00 00 00 01 00 - 01 E.BASS VARI / FRONT PU PHASE 00 : IN
01 : OUT
** ** 30 45 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET HiC 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 47 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 1st 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 49 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 2nd 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 4B 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 3rd 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 4D 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 4th 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 4F 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET LowB 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 30 51 00 00 00 01 00 - 64 AC BASS / LEVEL 0 - 100
** ** 30 52 00 00 00 01 00 - 64 AC BASS / BODY 0 - 100
** ** 30 53 00 00 00 01 00 - 64 AC BASS / SIZE -50 - +50
** ** 30 54 00 00 00 01 00 - 64 AC BASS / RESO 0 - 100
** ** 30 55 00 00 00 01 00 - 64 AC BASS / ATTACK 0 - 100
** ** 30 56 00 00 00 01 00 - 64 AC BASS / BOTTOM 0 - 100

page18

Model VB-99 MIDI Implementation 　Version : 1.00

** ** 30 57 00 00 00 01 00 - 64 AC BASS / BUZZ SENS 0 - 100
** ** 30 5D 00 00 00 01 00 - 64 AC BASS / DECAY 0 - 100
** ** 30 5E 00 00 00 01 00 - 01 E.GTR / E.GTR TYPE 00 : ST
01 : LP
** ** 30 5F 00 00 00 01 00 - 02 E.GTR / PU SEL (3POS) 00 : REAR
01 : R+F
02 : FRONT
** ** 30 60 00 00 00 01 00 - 04 E.GTR / PU SEL (5POS) 00 : REAR
01 : R+C
02 : CENTER
03 : C+F
04 : FRONT
** ** 30 61 00 00 00 01 00 - 64 E.GTR / VOL 0 - 100
** ** 30 62 00 00 00 01 00 - 64 E.GTR / TONE 0 - 100
** ** 30 63 00 00 00 01 00 - 01 PITCH / PITCH SHIFT SW 00 : OFF
01 : ON
** ** 30 64 00 00 00 01 00 - 01 PITCH / SHIFT MODE 00 : SHIFT
01 : HARMO
** ** 30 65 00 00 00 01 00 - 30 PITCH / SHIFT HiC * Refer to Table 'COSM BASS / PITCH SHIFT HiC'
** ** 30 66 00 00 00 01 00 - 30 PITCH / SHIFT 1st * Refer to Table 'COSM BASS / PITCH SHIFT 1st'
** ** 30 67 00 00 00 01 00 - 30 PITCH / SHIFT 2nd * Refer to Table 'COSM BASS / PITCH SHIFT 2nd'
** ** 30 68 00 00 00 01 00 - 30 PITCH / SHIFT 3rd * Refer to Table 'COSM BASS / PITCH SHIFT 3rd'
** ** 30 69 00 00 00 01 00 - 30 PITCH / SHIFT 4th * Refer to Table 'COSM BASS / PITCH SHIFT 4th'
** ** 30 6A 00 00 00 01 00 - 30 PITCH / SHIFT LowB * Refer to Table 'COSM BASS / PITCH SHIFT LowB'
** ** 30 6B 00 00 00 01 00 - 64 PITCH / FINE HiC -50 - +50
** ** 30 6C 00 00 00 01 00 - 64 PITCH / FINE 1st -50 - +50
** ** 30 6D 00 00 00 01 00 - 64 PITCH / FINE 2nd -50 - +50
** ** 30 6E 00 00 00 01 00 - 64 PITCH / FINE 3rd -50 - +50
** ** 30 6F 00 00 00 01 00 - 64 PITCH / FINE 4th -50 - +50
** ** 30 70 00 00 00 01 00 - 64 PITCH / FINE LowB -50 - +50
** ** 30 71 00 00 00 01 00 - 1D PITCH / HARMO * Refer to Table 'HARMONY'
** ** 30 72 00 00 00 01 00 - 30 PITCH / USER HARMONY I -24 - +24
** ** 30 73 00 00 00 01 00 - 30 PITCH / USER HARMONY IIb -24 - +24
** ** 30 74 00 00 00 01 00 - 30 PITCH / USER HARMONY II -24 - +24
** ** 30 75 00 00 00 01 00 - 30 PITCH / USER HARMONY IIIb -24 - +24
** ** 30 76 00 00 00 01 00 - 30 PITCH / USER HARMONY III -24 - +24
** ** 30 77 00 00 00 01 00 - 30 PITCH / USER HARMONY IV -24 - +24
** ** 30 78 00 00 00 01 00 - 30 PITCH / USER HARMONY IV# -24 - +24
** ** 30 79 00 00 00 01 00 - 30 PITCH / USER HARMONY V -24 - +24
** ** 30 7A 00 00 00 01 00 - 30 PITCH / USER HARMONY VIb -24 - +24
** ** 30 7B 00 00 00 01 00 - 30 PITCH / USER HARMONY VI -24 - +24
** ** 30 7C 00 00 00 01 00 - 30 PITCH / USER HARMONY VIIb -24 - +24
** ** 30 7D 00 00 00 01 00 - 30 PITCH / USER HARMONY VII -24 - +24
** ** 30 7E 00 00 00 01 00 - 30 PITCH / BEND SHIFT HiC -24 - +24
** ** 30 7F 00 00 00 01 00 - 30 PITCH / BEND SHIFT 1st -24 - +24
** ** 31 00 00 00 00 01 00 - 30 PITCH / BEND SHIFT 2nd -24 - +24
** ** 31 01 00 00 00 01 00 - 30 PITCH / BEND SHIFT 3rd -24 - +24
** ** 31 02 00 00 00 01 00 - 30 PITCH / BEND SHIFT 4th -24 - +24
** ** 31 03 00 00 00 01 00 - 30 PITCH / BEND SHIFT LowB -24 - +24
** ** 31 04 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL HiC 0 - 100
** ** 31 05 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 1st 0 - 100
** ** 31 06 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 2nd 0 - 100
** ** 31 07 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 3rd 0 - 100
** ** 31 08 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 4th 0 - 100
** ** 31 09 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL LowB 0 - 100
** ** 31 0A 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL HiC 0 - 100
** ** 31 0B 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 1st 0 - 100
** ** 31 0C 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 2nd 0 - 100
** ** 31 0D 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 3rd 0 - 100
** ** 31 0E 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 4th 0 - 100
** ** 31 0F 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL LowB 0 - 100
** ** 31 10 00 00 00 01 00 - 64 PITCH / DELAY HiC 0ms - 100ms
** ** 31 11 00 00 00 01 00 - 64 PITCH / DELAY 1st 0ms - 100ms
** ** 31 12 00 00 00 01 00 - 64 PITCH / DELAY 2nd 0ms - 100ms
** ** 31 13 00 00 00 01 00 - 64 PITCH / DELAY 3rd 0ms - 100ms
** ** 31 14 00 00 00 01 00 - 64 PITCH / DELAY 4th 0ms - 100ms
** ** 31 15 00 00 00 01 00 - 64 PITCH / DELAY LowB 0ms - 100ms
** ** 34 00 00 00 00 01 00 - 0B SYNTH TYPE * Refer to Table 'SYNTH TYPE'
** ** 34 01 00 00 00 01 00 - 64 SYNTH MASTER VOL 0 - 100
** ** 34 02 00 00 00 01 00 - 02 ANALOG GR / MODE 00 : VCO
01 : V+D
02 : DIST
** ** 34 04 00 00 00 01 00 - 01 ANALOG GR / COMP 00 : OFF
01 : ON
** ** 34 05 00 00 00 01 00 - 64 ANALOG GR / CUTOFF FREQ 0 - 100
** ** 34 06 00 00 00 01 00 - 64 ANALOG GR / RESO 0 - 100
** ** 34 07 00 00 00 01 00 - 02 ANALOG GR / ENV MOD SW 00 : OFF
01 : ON
02 : INV
** ** 34 08 00 00 00 01 00 - 64 ANALOG GR / ENV MOD ATTACK 0 - 100
** ** 34 09 00 00 00 01 00 - 64 ANALOG GR / ENV MOD SENS 0 - 100
** ** 34 0A 00 00 00 01 00 - 01 ANALOG GR / DUET 00 : OFF
01 : ON
** ** 34 0B 00 00 00 01 00 - 18 ANALOG GR / PITCH A PITCH -12 - +12
** ** 34 0C 00 00 00 01 00 - 64 ANALOG GR / PITCH A FINE -50 - +50
** ** 34 0D 00 00 00 01 00 - 02 ANALOG GR / PITCH SW 00 : A
01 : OFF
02 : B
** ** 34 0E 00 00 00 01 00 - 18 ANALOG GR / PITCH B PITCH -12 - +12
** ** 34 0F 00 00 00 01 00 - 64 ANALOG GR / PITCH B FINE -50 - +50
** ** 34 10 00 00 00 01 00 - 01 ANALOG GR / SWEEP SW 00 : OFF
01 : ON
** ** 34 11 00 00 00 01 00 - 64 ANALOG GR / SWEEP RISE 0 - 100
** ** 34 12 00 00 00 01 00 - 64 ANALOG GR / SWEEP FALL 0 - 100
** ** 34 13 00 00 00 01 00 - 01 ANALOG GR / VIBRATO SW 00 : OFF
01 : ON
** ** 34 14 00 00 00 01 00 - 64 ANALOG GR / VIBRATO RATE 0 - 100
** ** 34 15 00 00 00 01 00 - 64 ANALOG GR / VIBRATO DEPTH 0 - 100
** ** 34 1C 00 00 00 01 00 - 64 BOWED / FILTER CUTOFF 0 - 100
** ** 34 1D 00 00 00 01 00 - 64 BOWED / FILTER RESO 0 - 100
** ** 34 1E 00 00 00 01 00 - 64 BOWED / TOUCH SENS 0 - 100
** ** 34 1F 00 00 00 01 00 - 64 BOWED / SUSTAIN 0 - 100
** ** 34 20 00 00 00 01 00 - 64 BOWED / POWER BEND 0 - 100
** ** 34 21 00 00 00 01 00 - 64 BOWED / POWER BEND Q 0 - 100
** ** 34 28 00 00 00 01 00 - 64 FILTER / FILTER CUTOFF 0 - 100
** ** 34 29 00 00 00 01 00 - 64 FILTER / FILTER RESO 0 - 100
** ** 34 2A 00 00 00 01 00 - 64 FILTER / TOUCH SENS 0 - 100
** ** 34 2B 00 00 00 01 00 - 64 FILTER / FILTER DECAY 0 - 100
** ** 34 2C 00 00 00 01 00 - 64 FILTER / COLOR 0 - 100
** ** 34 2D 00 00 00 01 00 - 64 PIPE / FILTER CUTOFF 0 - 100
** ** 34 2E 00 00 00 01 00 - 64 PIPE / FILTER RESO 0 - 100
** ** 34 2F 00 00 00 01 00 - 64 PIPE / TOUCH SENS 0 - 100
** ** 34 30 00 00 00 01 00 - 64 PIPE / POWER BEND 0 - 100
** ** 34 31 00 00 00 01 00 - 64 PIPE / POWER BEND Q 0 - 100
** ** 34 32 00 00 00 01 00 - 64 PIPE / SUSTAIN 0 - 100
** ** 34 3E 00 00 00 01 00 - 64 CRYSTAL / ATTACK LENGTH 0 - 100
** ** 34 3F 00 00 00 01 00 - 64 CRYSTAL / MOD TUNE 0 - 100
** ** 34 40 00 00 00 01 00 - 64 CRYSTAL / MOD DEPTH 0 - 100
** ** 34 41 00 00 00 01 00 - 64 CRYSTAL / ATTACK LEVEL 0 - 100
** ** 34 42 00 00 00 01 00 - 64 CRYSTAL / BODY LEVEL 0 - 100
** ** 34 43 00 00 00 01 00 - 64 CRYSTAL / SUSTAIN 0 - 100
** ** 34 44 00 00 00 01 00 - 64 ORGAN / FEET 16 0 - 100
** ** 34 45 00 00 00 01 00 - 64 ORGAN / FEET 8 0 - 100
** ** 34 46 00 00 00 01 00 - 64 ORGAN / FEET 4 0 - 100
** ** 34 47 00 00 00 01 00 - 64 ORGAN / SUSTAIN 0 - 100
** ** 34 48 00 00 00 01 00 - 64 BRASS / FILTER CUTOFF 0 - 100
** ** 34 49 00 00 00 01 00 - 64 BRASS / FILTER RESO 0 - 100
** ** 34 4A 00 00 00 01 00 - 64 BRASS / TOUCH SENS 0 - 100
** ** 34 4B 00 00 00 01 00 - 64 BRASS / SUSTAIN 0 - 100
** ** 34 4C 00 00 00 01 00 - 01 WAVE / WAVE SHAPE 00 : SAW

page19

Model VB-99 MIDI Implementation 　Version : 1.00

01 : SQUARE
** ** 34 4D 00 00 00 01 00 - 64 WAVE / WAVE SENS 0 - 100
** ** 34 4E 00 00 00 01 00 - 64 WAVE / WAVE ATTACK 0 - 100
** ** 34 4F 00 00 00 01 00 - 64 WAVE / WAVE DECAY 0 - 100
** ** 34 51 00 00 00 01 00 - 64 WAVE / CUTOFF 0 - 100
** ** 34 52 00 00 00 01 00 - 64 WAVE / RESO 0 - 100
** ** 34 53 00 00 00 01 00 - 01 WAVE / FILTER TYPE 00 : -12dB
01 : -24dB
** ** 34 54 00 00 00 01 00 - 64 WAVE / FILTER ATTACK 0 - 100
** ** 34 55 00 00 00 01 00 - 64 WAVE / FILTER DECAY 0 - 100
** ** 34 56 00 00 00 01 00 - 64 WAVE / FILTER DEPTH -50 - +50
** ** 34 57 00 00 00 01 00 - 01 NS / SW 00 : OFF
01 : ON
** ** 34 58 00 00 00 01 00 - 64 NS / THRSH 0 - 100
** ** 34 59 00 00 00 01 00 - 64 NS / REL 0 - 100
** ** 34 5A 00 00 00 01 00 - 64 OSC / SHAPE SQ=0 SW=100 - SQ=100 SW=0
** ** 34 5B 00 00 00 01 00 - 64 OSC / SENS 0 - 100
** ** 34 5D 00 00 00 01 00 - 64 OSC / PWM WIDTH 0 - 100
** ** 34 5E 00 00 00 01 00 - 64 OSC / PWM RATE 0 - 100
** ** 34 5F 00 00 00 01 00 - 64 OSC / PWM DEPTH 0 - 100
** ** 34 60 00 00 00 01 00 - 01 OSC / ENV FOLLOW 00 : OFF
01 : ON
** ** 34 61 00 00 00 01 00 - 64 OSC / CUTOFF 0 - 100
** ** 34 62 00 00 00 01 00 - 64 OSC / RESO 0 - 100
** ** 34 63 00 00 00 01 00 - 01 OSC / FILTER TYPE 00 : -12dB
01 : -24dB
** ** 34 64 00 00 00 01 00 - 64 OSC / FILTER ATTACK 0 - 100
** ** 34 65 00 00 00 01 00 - 64 OSC / FILTER DECAY 0 - 100
** ** 34 66 00 00 00 01 00 - 64 OSC / FILTER DEPTH -50 - +50
** ** 34 67 00 00 00 01 00 - 02 OSC / SUB OSC 00 : OFF
01 : DETUNE
02 : -1OCT
** ** 34 68 00 00 00 01 00 - 64 OSC / SUB DETUNE -50 - +50
** ** 34 69 00 00 00 01 00 - 64 OSC / SUB LEVEL 0 - 100

[ [B] COSM BASS ]
** ** 38 00 00 00 00 01 00 - 02 COSM BASS SW 00 : OFF
01 : ON
02 : NORMAL PU
** ** 38 01 00 00 00 01 00 - 03 MODLNG TYPE 00 : E.GTR
01 : AC BASS
02 : E.BASS
03 : SYNTH
** ** 38 02 00 00 00 01 00 - 01 EQ / EQ SW 00 : OFF
01 : ON
** ** 38 03 00 00 00 01 00 - 18 EQ / LOW GAIN -12dB - +12dB
** ** 38 04 00 00 00 01 00 - 1B EQ / LOW MID FREQ * Refer to Table 'EQ MID FREQ'
** ** 38 05 00 00 00 01 00 - 05 EQ / LOW MID Q * Refer to Table 'EQ Q'
** ** 38 06 00 00 00 01 00 - 18 EQ / LOW MID GAIN -12dB - +12dB
** ** 38 07 00 00 00 01 00 - 1B EQ / HIGH MID FREQ * Refer to Table 'EQ MID FREQ'
** ** 38 08 00 00 00 01 00 - 05 EQ / HIGH MID Q * Refer to Table 'EQ Q'
** ** 38 09 00 00 00 01 00 - 18 EQ / HIGH MID GAIN -12dB - +12dB
** ** 38 0A 00 00 00 01 00 - 18 EQ / HIGH GAIN -12dB - +12dB
** ** 38 0B 00 00 00 01 00 - 18 EQ / TOTAL GAIN -12dB - +12dB
** ** 38 0C 00 00 00 01 00 - 64 MIX / STRING PAN HiC 100:0 - 0:100
** ** 38 0D 00 00 00 01 00 - 64 MIX / STRING PAN 1st 100:0 - 0:100
** ** 38 0E 00 00 00 01 00 - 64 MIX / STRING PAN 2nd 100:0 - 0:100
** ** 38 0F 00 00 00 01 00 - 64 MIX / STRING PAN 3rd 100:0 - 0:100
** ** 38 10 00 00 00 01 00 - 64 MIX / STRING PAN 4th 100:0 - 0:100
** ** 38 11 00 00 00 01 00 - 64 MIX / STRING PAN LowB 100:0 - 0:100
** ** 38 12 00 00 00 01 00 - 64 MIX / STRING LEVEL HiC 0 - 100
** ** 38 13 00 00 00 01 00 - 64 MIX / STRING LEVEL 1st 0 - 100
** ** 38 14 00 00 00 01 00 - 64 MIX / STRING LEVEL 2nd 0 - 100
** ** 38 15 00 00 00 01 00 - 64 MIX / STRING LEVEL 3rd 0 - 100
** ** 38 16 00 00 00 01 00 - 64 MIX / STRING LEVEL 4th 0 - 100
** ** 38 17 00 00 00 01 00 - 64 MIX / STRING LEVEL LowB 0 - 100
** ** 38 18 00 00 00 01 00 - 64 MIX LEVEL COSM BASS 0 - 100
** ** 38 1A 00 00 00 01 00 - 64 MIX LEVEL NORMAL PU 0 - 100
** ** 38 1B 00 00 00 01 00 - 64 NORMAL LEVEL (COSM BASS SW = NORMAL PU) 0 - 100
** ** 38 1C 00 00 00 01 00 - 09 E.BASS / E.BASS TYPE 00 : VINT JB
01 : JB
02 : VINT PB
03 : PB
04 : M-MAN
05 : RICK
06 : T-BIRD
07 : ACTIVE
08 : VIOLIN
09 : VARI
** ** 38 1D 00 00 00 01 00 - 64 E.BASS / (MASTER) VOL 0 - 100
** ** 38 1E 00 00 00 01 00 - 64 E.BASS / REAR VOL 0 - 100
** ** 38 1F 00 00 00 01 00 - 64 E.BASS / FRONT VOL 0 - 100
** ** 38 20 00 00 00 01 00 - 64 E.BASS / BAL R100:0F - R0:100F
** ** 38 21 00 00 00 01 00 - 64 E.BASS / TONE 0 - 100
** ** 38 22 00 00 00 01 00 - 64 E.BASS / REAE TONE 0 - 100
** ** 38 23 00 00 00 01 00 - 64 E.BASS / FRONT TONE 0 - 100
** ** 38 24 00 00 00 01 00 - 02 E.BASS / PU SELECT 00 : REAR
01 : R+F
02 : FRONT
** ** 38 25 00 00 00 01 00 - 64 E.BASS / TREBLE 0-100 0 - 100
** ** 38 26 00 00 00 01 00 - 64 E.BASS / BASS 0-100 0 - 100
** ** 38 27 00 00 00 01 00 - 64 E.BASS / TREBLE +/-50 -50 - +50
** ** 38 29 00 00 00 01 00 - 64 E.BASS / BASS +/-50 -50 - +50
** ** 38 2A 00 00 00 01 00 - 01 E.BASS / TREBLE ON 00 : OFF
01 : ON
** ** 38 2B 00 00 00 01 00 - 01 E.BASS / BASS ON 00 : OFF
01 : ON
** ** 38 2C 00 00 00 01 00 - 01 E.BASS / RHYTHM/SOLO 00 : RHYTHM
01 : SOLO
** ** 38 2D 00 00 00 01 00 - 03 E.BASS VARI / CTL TYPE 00 : 2V2T
01 : 2V1T
02 : BAL
03 : 2BAND
** ** 38 2E 00 00 00 01 00 - 64 E.BASS VARI / TONE -50 - +50
** ** 38 2F 00 00 00 01 00 - 64 E.BASS VARI / REAR TONE -50 - +50
** ** 38 30 00 00 00 01 00 - 64 E.BASS VARI / FRONT TONE -50 - +50
** ** 38 33 00 00 00 01 00 - 02 E.BASS VARI / REAR PU TYPE 00 : SINGLE
01 : DOUBLE
02 : PIEZO
** ** 38 34 00 00 00 01 00 - 59 E.BASS VARI / REAR PU POS 00 : 5mm
01 : 10mm
: :
59 : 450mm
** ** 38 35 00 00 00 01 00 - 01 E.BASS VARI / REAR PU PHASE 00 : IN
01 : OUT
** ** 38 36 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET HiC 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 38 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 1st 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 3A 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 2nd 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 3C 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 3rd 00 00 : -445mm
00 01 : -440mm

page20

Model VB-99 MIDI Implementation 　Version : 1.00

: :
01 32 : +445mm
** ** 38 3E 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET 4th 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 40 00 00 00 02 00 00 - 01 32 E.BASS VARI / REAR PU OFFSET LowB 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 42 00 00 00 01 00 - 02 E.BASS VARI / FRONT PU TYPE 00 : SINGLE
01 : DOUBLE
02 : PIEZO
** ** 38 43 00 00 00 01 00 - 59 E.BASS VARI / FRONT PU POS 00 : 5mm
01 : 10mm
: :
59 : 450mm
** ** 38 44 00 00 00 01 00 - 01 E.BASS VARI / FRONT PU PHASE 00 : IN
01 : OUT
** ** 38 45 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET HiC 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 47 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 1st 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 49 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 2nd 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 4B 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 3rd 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 4D 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET 4th 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 4F 00 00 00 02 00 00 - 01 32 E.BASS VARI / FRONT PU OFFSET LowB 00 00 : -445mm
00 01 : -440mm
: :
01 32 : +445mm
** ** 38 51 00 00 00 01 00 - 64 AC BASS / LEVEL 0 - 100
** ** 38 52 00 00 00 01 00 - 64 AC BASS / BODY 0 - 100
** ** 38 53 00 00 00 01 00 - 64 AC BASS / SIZE -50 - +50
** ** 38 54 00 00 00 01 00 - 64 AC BASS / RESO 0 - 100
** ** 38 55 00 00 00 01 00 - 64 AC BASS / ATTACK 0 - 100
** ** 38 56 00 00 00 01 00 - 64 AC BASS / BOTTOM 0 - 100
** ** 38 57 00 00 00 01 00 - 64 AC BASS / BUZZ SENS 0 - 100
** ** 38 5D 00 00 00 01 00 - 64 AC BASS / DECAY 0 - 100
** ** 38 5E 00 00 00 01 00 - 01 E.GTR / E.GTR TYPE 00 : ST
01 : LP
** ** 38 5F 00 00 00 01 00 - 02 E.GTR / PU SEL (3POS) 00 : REAR
01 : R+F
02 : FRONT
** ** 38 60 00 00 00 01 00 - 04 E.GTR / PU SEL (5POS) 00 : REAR
01 : R+C
02 : CENTER
03 : C+F
04 : FRONT
** ** 38 61 00 00 00 01 00 - 64 E.GTR / VOL 0 - 100
** ** 38 62 00 00 00 01 00 - 64 E.GTR / TONE 0 - 100
** ** 38 63 00 00 00 01 00 - 01 PITCH / PITCH SHIFT SW 00 : OFF
01 : ON
** ** 38 64 00 00 00 01 00 - 01 PITCH / SHIFT MODE 00 : SHIFT
01 : HARMO
** ** 38 65 00 00 00 01 00 - 30 PITCH / SHIFT HiC * Refer to Table 'COSM BASS / PITCH SHIFT HiC'
** ** 38 66 00 00 00 01 00 - 30 PITCH / SHIFT 1st * Refer to Table 'COSM BASS / PITCH SHIFT 1st'
** ** 38 67 00 00 00 01 00 - 30 PITCH / SHIFT 2nd * Refer to Table 'COSM BASS / PITCH SHIFT 2nd'
** ** 38 68 00 00 00 01 00 - 30 PITCH / SHIFT 3rd * Refer to Table 'COSM BASS / PITCH SHIFT 3rd'
** ** 38 69 00 00 00 01 00 - 30 PITCH / SHIFT 4th * Refer to Table 'COSM BASS / PITCH SHIFT 4th'
** ** 38 6A 00 00 00 01 00 - 30 PITCH / SHIFT LowB * Refer to Table 'COSM BASS / PITCH SHIFT LowB'
** ** 38 6B 00 00 00 01 00 - 64 PITCH / FINE HiC -50 - +50
** ** 38 6C 00 00 00 01 00 - 64 PITCH / FINE 1st -50 - +50
** ** 38 6D 00 00 00 01 00 - 64 PITCH / FINE 2nd -50 - +50
** ** 38 6E 00 00 00 01 00 - 64 PITCH / FINE 3rd -50 - +50
** ** 38 6F 00 00 00 01 00 - 64 PITCH / FINE 4th -50 - +50
** ** 38 70 00 00 00 01 00 - 64 PITCH / FINE LowB -50 - +50
** ** 38 71 00 00 00 01 00 - 1D PITCH / HARMO * Refer to Table 'HARMONY'
** ** 38 72 00 00 00 01 00 - 30 PITCH / USER HARMONY I -24 - +24
** ** 38 73 00 00 00 01 00 - 30 PITCH / USER HARMONY IIb -24 - +24
** ** 38 74 00 00 00 01 00 - 30 PITCH / USER HARMONY II -24 - +24
** ** 38 75 00 00 00 01 00 - 30 PITCH / USER HARMONY IIIb -24 - +24
** ** 38 76 00 00 00 01 00 - 30 PITCH / USER HARMONY III -24 - +24
** ** 38 77 00 00 00 01 00 - 30 PITCH / USER HARMONY IV -24 - +24
** ** 38 78 00 00 00 01 00 - 30 PITCH / USER HARMONY IV# -24 - +24
** ** 38 79 00 00 00 01 00 - 30 PITCH / USER HARMONY V -24 - +24
** ** 38 7A 00 00 00 01 00 - 30 PITCH / USER HARMONY VIb -24 - +24
** ** 38 7B 00 00 00 01 00 - 30 PITCH / USER HARMONY VI -24 - +24
** ** 38 7C 00 00 00 01 00 - 30 PITCH / USER HARMONY VIIb -24 - +24
** ** 38 7D 00 00 00 01 00 - 30 PITCH / USER HARMONY VII -24 - +24
** ** 38 7E 00 00 00 01 00 - 30 PITCH / BEND SHIFT HiC -24 - +24
** ** 38 7F 00 00 00 01 00 - 30 PITCH / BEND SHIFT 1st -24 - +24
** ** 39 00 00 00 00 01 00 - 30 PITCH / BEND SHIFT 2nd -24 - +24
** ** 39 01 00 00 00 01 00 - 30 PITCH / BEND SHIFT 3rd -24 - +24
** ** 39 02 00 00 00 01 00 - 30 PITCH / BEND SHIFT 4th -24 - +24
** ** 39 03 00 00 00 01 00 - 30 PITCH / BEND SHIFT LowB -24 - +24
** ** 39 04 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL HiC 0 - 100
** ** 39 05 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 1st 0 - 100
** ** 39 06 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 2nd 0 - 100
** ** 39 07 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 3rd 0 - 100
** ** 39 08 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL 4th 0 - 100
** ** 39 09 00 00 00 01 00 - 64 PITCH / EFFECT LEVEL LowB 0 - 100
** ** 39 0A 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL HiC 0 - 100
** ** 39 0B 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 1st 0 - 100
** ** 39 0C 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 2nd 0 - 100
** ** 39 0D 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 3rd 0 - 100
** ** 39 0E 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL 4th 0 - 100
** ** 39 0F 00 00 00 01 00 - 64 PITCH / DIRECT LEVEL LowB 0 - 100
** ** 39 10 00 00 00 01 00 - 64 PITCH / DELAY HiC 0ms - 100ms
** ** 39 11 00 00 00 01 00 - 64 PITCH / DELAY 1st 0ms - 100ms
** ** 39 12 00 00 00 01 00 - 64 PITCH / DELAY 2nd 0ms - 100ms
** ** 39 13 00 00 00 01 00 - 64 PITCH / DELAY 3rd 0ms - 100ms
** ** 39 14 00 00 00 01 00 - 64 PITCH / DELAY 4th 0ms - 100ms
** ** 39 15 00 00 00 01 00 - 64 PITCH / DELAY LowB 0ms - 100ms
** ** 3C 00 00 00 00 01 00 - 0B SYNTH TYPE * Refer to Table 'SYNTH TYPE'
** ** 3C 01 00 00 00 01 00 - 64 SYNTH MASTER VOL 0 - 100
** ** 3C 02 00 00 00 01 00 - 02 ANALOG GR / MODE 00 : VCO
01 : V+D
02 : DIST
** ** 3C 04 00 00 00 01 00 - 01 ANALOG GR / COMP 00 : OFF
01 : ON
** ** 3C 05 00 00 00 01 00 - 64 ANALOG GR / CUTOFF FREQ 0 - 100
** ** 3C 06 00 00 00 01 00 - 64 ANALOG GR / RESO 0 - 100
** ** 3C 07 00 00 00 01 00 - 02 ANALOG GR / ENV MOD SW 00 : OFF
01 : ON
02 : INV
** ** 3C 08 00 00 00 01 00 - 64 ANALOG GR / ENV MOD ATTACK 0 - 100
** ** 3C 09 00 00 00 01 00 - 64 ANALOG GR / ENV MOD SENS 0 - 100

page21

Model VB-99 MIDI Implementation 　Version : 1.00

** ** 3C 0A 00 00 00 01 00 - 01 ANALOG GR / DUET 00 : OFF
01 : ON
** ** 3C 0B 00 00 00 01 00 - 18 ANALOG GR / PITCH A PITCH -12 - +12
** ** 3C 0C 00 00 00 01 00 - 64 ANALOG GR / PITCH A FINE -50 - +50
** ** 3C 0D 00 00 00 01 00 - 02 ANALOG GR / PITCH SW 00 : A
01 : OFF
02 : B
** ** 3C 0E 00 00 00 01 00 - 18 ANALOG GR / PITCH B PITCH -12 - +12
** ** 3C 0F 00 00 00 01 00 - 64 ANALOG GR / PITCH B FINE -50 - +50
** ** 3C 10 00 00 00 01 00 - 01 ANALOG GR / SWEEP SW 00 : OFF
01 : ON
** ** 3C 11 00 00 00 01 00 - 64 ANALOG GR / SWEEP RISE 0 - 100
** ** 3C 12 00 00 00 01 00 - 64 ANALOG GR / SWEEP FALL 0 - 100
** ** 3C 13 00 00 00 01 00 - 01 ANALOG GR / VIBRATO SW 00 : OFF
01 : ON
** ** 3C 14 00 00 00 01 00 - 64 ANALOG GR / VIBRATO RATE 0 - 100
** ** 3C 15 00 00 00 01 00 - 64 ANALOG GR / VIBRATO DEPTH 0 - 100
** ** 3C 1C 00 00 00 01 00 - 64 BOWED / FILTER CUTOFF 0 - 100
** ** 3C 1D 00 00 00 01 00 - 64 BOWED / FILTER RESO 0 - 100
** ** 3C 1E 00 00 00 01 00 - 64 BOWED / TOUCH SENS 0 - 100
** ** 3C 1F 00 00 00 01 00 - 64 BOWED / SUSTAIN 0 - 100
** ** 3C 20 00 00 00 01 00 - 64 BOWED / POWER BEND 0 - 100
** ** 3C 21 00 00 00 01 00 - 64 BOWED / POWER BEND Q 0 - 100
** ** 3C 28 00 00 00 01 00 - 64 FILTER / FILTER CUTOFF 0 - 100
** ** 3C 29 00 00 00 01 00 - 64 FILTER / FILTER RESO 0 - 100
** ** 3C 2A 00 00 00 01 00 - 64 FILTER / TOUCH SENS 0 - 100
** ** 3C 2B 00 00 00 01 00 - 64 FILTER / FILTER DECAY 0 - 100
** ** 3C 2C 00 00 00 01 00 - 64 FILTER / COLOR 0 - 100
** ** 3C 2D 00 00 00 01 00 - 64 PIPE / FILTER CUTOFF 0 - 100
** ** 3C 2E 00 00 00 01 00 - 64 PIPE / FILTER RESO 0 - 100
** ** 3C 2F 00 00 00 01 00 - 64 PIPE / TOUCH SENS 0 - 100
** ** 3C 30 00 00 00 01 00 - 64 PIPE / POWER BEND 0 - 100
** ** 3C 31 00 00 00 01 00 - 64 PIPE / POWER BEND Q 0 - 100
** ** 3C 32 00 00 00 01 00 - 64 PIPE / SUSTAIN 0 - 100
** ** 3C 3E 00 00 00 01 00 - 64 CRYSTAL / ATTACK LENGTH 0 - 100
** ** 3C 3F 00 00 00 01 00 - 64 CRYSTAL / MOD TUNE 0 - 100
** ** 3C 40 00 00 00 01 00 - 64 CRYSTAL / MOD DEPTH 0 - 100
** ** 3C 41 00 00 00 01 00 - 64 CRYSTAL / ATTACK LEVEL 0 - 100
** ** 3C 42 00 00 00 01 00 - 64 CRYSTAL / BODY LEVEL 0 - 100
** ** 3C 43 00 00 00 01 00 - 64 CRYSTAL / SUSTAIN 0 - 100
** ** 3C 44 00 00 00 01 00 - 64 ORGAN / FEET 16 0 - 100
** ** 3C 45 00 00 00 01 00 - 64 ORGAN / FEET 8 0 - 100
** ** 3C 46 00 00 00 01 00 - 64 ORGAN / FEET 4 0 - 100
** ** 3C 47 00 00 00 01 00 - 64 ORGAN / SUSTAIN 0 - 100
** ** 3C 48 00 00 00 01 00 - 64 BRASS / FILTER CUTOFF 0 - 100
** ** 3C 49 00 00 00 01 00 - 64 BRASS / FILTER RESO 0 - 100
** ** 3C 4A 00 00 00 01 00 - 64 BRASS / TOUCH SENS 0 - 100
** ** 3C 4B 00 00 00 01 00 - 64 BRASS / SUSTAIN 0 - 100
** ** 3C 4C 00 00 00 01 00 - 01 WAVE / WAVE SHAPE 00 : SAW
01 : SQUARE
** ** 3C 4D 00 00 00 01 00 - 64 WAVE / WAVE SENS 0 - 100
** ** 3C 4E 00 00 00 01 00 - 64 WAVE / WAVE ATTACK 0 - 100
** ** 3C 4F 00 00 00 01 00 - 64 WAVE / WAVE DECAY 0 - 100
** ** 3C 51 00 00 00 01 00 - 64 WAVE / CUTOFF 0 - 100
** ** 3C 52 00 00 00 01 00 - 64 WAVE / RESO 0 - 100
** ** 3C 53 00 00 00 01 00 - 01 WAVE / FILTER TYPE 00 : -12dB
01 : -24dB
** ** 3C 54 00 00 00 01 00 - 64 WAVE / FILTER ATTACK 0 - 100
** ** 3C 55 00 00 00 01 00 - 64 WAVE / FILTER DECAY 0 - 100
** ** 3C 56 00 00 00 01 00 - 64 WAVE / FILTER DEPTH -50 - +50
** ** 3C 57 00 00 00 01 00 - 01 NS / SW 00 : OFF
01 : ON
** ** 3C 58 00 00 00 01 00 - 64 NS / THRSH 0 - 100
** ** 3C 59 00 00 00 01 00 - 64 NS / REL 0 - 100
** ** 3C 5A 00 00 00 01 00 - 64 OSC / SHAPE SQ=0 SW=100 - SQ=100 SW=0
** ** 3C 5B 00 00 00 01 00 - 64 OSC / SENS 0 - 100
** ** 3C 5D 00 00 00 01 00 - 64 OSC / PWM WIDTH 0 - 100
** ** 3C 5E 00 00 00 01 00 - 64 OSC / PWM RATE 0 - 100
** ** 3C 5F 00 00 00 01 00 - 64 OSC / PWM DEPTH 0 - 100
** ** 3C 60 00 00 00 01 00 - 01 OSC / ENV FOLLOW 00 : OFF
01 : ON
** ** 3C 61 00 00 00 01 00 - 64 OSC / CUTOFF 0 - 100
** ** 3C 62 00 00 00 01 00 - 64 OSC / RESO 0 - 100
** ** 3C 63 00 00 00 01 00 - 01 OSC / FILTER TYPE 00 : -12dB
01 : -24dB
** ** 3C 64 00 00 00 01 00 - 64 OSC / FILTER ATTACK 0 - 100
** ** 3C 65 00 00 00 01 00 - 64 OSC / FILTER DECAY 0 - 100
** ** 3C 66 00 00 00 01 00 - 64 OSC / FILTER DEPTH -50 - +50
** ** 3C 67 00 00 00 01 00 - 02 OSC / SUB OSC 00 : OFF
01 : DETUNE
02 : -1OCT
** ** 3C 68 00 00 00 01 00 - 64 OSC / SUB DETUNE -50 - +50
** ** 3C 69 00 00 00 01 00 - 64 OSC / SUB LEVEL 0 - 100

Model VB-99 MIDI Implementation 　Version : 1.00

[ POLY FX ]
** ** 40 00 00 00 00 01 00 - 01 POLYFX CH 00 : CH A
01 : CH B
** ** 40 01 00 00 00 01 00 - 01 POLYFX SW 00 : OFF
01 : ON
** ** 40 02 00 00 00 01 00 - 08 TYPE 00 : POLY COMP
01 : POLY DEFRET
02 : POLY DIST
03 : POLY EQ
04 : POLY LIMITR
05 : POLY OCTAVE
06 : POLY RING
07 : POLY SG
08 : STRING MODLNG
** ** 40 03 00 00 00 01 00 - 64 POLY COMP / SUSTAIN HiC 0 - 100
** ** 40 04 00 00 00 01 00 - 64 POLY COMP / SUSTAIN 1st 0 - 100
** ** 40 05 00 00 00 01 00 - 64 POLY COMP / SUSTAIN 2nd 0 - 100
** ** 40 06 00 00 00 01 00 - 64 POLY COMP / SUSTAIN 3rd 0 - 100
** ** 40 07 00 00 00 01 00 - 64 POLY COMP / SUSTAIN 4th 0 - 100
** ** 40 08 00 00 00 01 00 - 64 POLY COMP / SUSTAIN LowB 0 - 100
** ** 40 09 00 00 00 01 00 - 64 POLY COMP / ATTACK HiC 0 - 100
** ** 40 0A 00 00 00 01 00 - 64 POLY COMP / ATTACK 1st 0 - 100
** ** 40 0B 00 00 00 01 00 - 64 POLY COMP / ATTACK 2nd 0 - 100
** ** 40 0C 00 00 00 01 00 - 64 POLY COMP / ATTACK 3rd 0 - 100
** ** 40 0D 00 00 00 01 00 - 64 POLY COMP / ATTACK 4th 0 - 100
** ** 40 0E 00 00 00 01 00 - 64 POLY COMP / ATTACK LowB 0 - 100
** ** 40 0F 00 00 00 01 00 - 64 POLY COMP / TONE HiC -50 - +50
** ** 40 10 00 00 00 01 00 - 64 POLY COMP / TONE 1st -50 - +50
** ** 40 11 00 00 00 01 00 - 64 POLY COMP / TONE 2nd -50 - +50
** ** 40 12 00 00 00 01 00 - 64 POLY COMP / TONE 3rd -50 - +50
** ** 40 13 00 00 00 01 00 - 64 POLY COMP / TONE 4th -50 - +50
** ** 40 14 00 00 00 01 00 - 64 POLY COMP / TONE LowB -50 - +50
** ** 40 15 00 00 00 01 00 - 64 POLY COMP / LEVEL HiC 0 - 100
** ** 40 16 00 00 00 01 00 - 64 POLY COMP / LEVEL 1st 0 - 100
** ** 40 17 00 00 00 01 00 - 64 POLY COMP / LEVEL 2nd 0 - 100
** ** 40 18 00 00 00 01 00 - 64 POLY COMP / LEVEL 3rd 0 - 100
** ** 40 19 00 00 00 01 00 - 64 POLY COMP / LEVEL 4th 0 - 100
** ** 40 1A 00 00 00 01 00 - 64 POLY COMP / LEVEL LowB 0 - 100
** ** 40 1B 00 00 00 01 00 - 64 POLY LIMITER / ATTACK HiC 0 - 100
** ** 40 1C 00 00 00 01 00 - 64 POLY LIMITER / ATTACK 1st 0 - 100
** ** 40 1D 00 00 00 01 00 - 64 POLY LIMITER / ATTACK 2nd 0 - 100
** ** 40 1E 00 00 00 01 00 - 64 POLY LIMITER / ATTACK 3rd 0 - 100
** ** 40 1F 00 00 00 01 00 - 64 POLY LIMITER / ATTACK 4th 0 - 100
** ** 40 20 00 00 00 01 00 - 64 POLY LIMITER / ATTACK LowB 0 - 100
** ** 40 21 00 00 00 01 00 - 64 POLY LIMITER / THRESHOLD HiC 0 - 100

page22

** ** 40 22 00 00 00 01 00 - 64 POLY LIMITER / THRESHOLD 1st 0 - 100
** ** 40 23 00 00 00 01 00 - 64 POLY LIMITER / THRESHOLD 2nd 0 - 100
** ** 40 24 00 00 00 01 00 - 64 POLY LIMITER / THRESHOLD 3rd 0 - 100
** ** 40 25 00 00 00 01 00 - 64 POLY LIMITER / THRESHOLD 4th 0 - 100
** ** 40 26 00 00 00 01 00 - 64 POLY LIMITER / THRESHOLD LowB 0 - 100
** ** 40 27 00 00 00 01 00 - 11 POLY LIMITER / RATIO HiC * Refer to Table 'LIMITR RATIO'
** ** 40 28 00 00 00 01 00 - 11 POLY LIMITER / RATIO 1st * Refer to Table 'LIMITR RATIO'
** ** 40 29 00 00 00 01 00 - 11 POLY LIMITER / RATIO 2nd * Refer to Table 'LIMITR RATIO'
** ** 40 2A 00 00 00 01 00 - 11 POLY LIMITER / RATIO 3rd * Refer to Table 'LIMITR RATIO'
** ** 40 2B 00 00 00 01 00 - 11 POLY LIMITER / RATIO 4th * Refer to Table 'LIMITR RATIO'
** ** 40 2C 00 00 00 01 00 - 11 POLY LIMITER / RATIO LowB * Refer to Table 'LIMITR RATIO'
** ** 40 2D 00 00 00 01 00 - 64 POLY LIMITER / RELEASE HiC 0 - 100
** ** 40 2E 00 00 00 01 00 - 64 POLY LIMITER / RELEASE 1st 0 - 100
** ** 40 2F 00 00 00 01 00 - 64 POLY LIMITER / RELEASE 2nd 0 - 100
** ** 40 30 00 00 00 01 00 - 64 POLY LIMITER / RELEASE 3rd 0 - 100
** ** 40 31 00 00 00 01 00 - 64 POLY LIMITER / RELEASE 4th 0 - 100
** ** 40 32 00 00 00 01 00 - 64 POLY LIMITER / RELEASE LowB 0 - 100
** ** 40 33 00 00 00 01 00 - 64 POLY LIMITER / TONE HiC -50 - +50
** ** 40 34 00 00 00 01 00 - 64 POLY LIMITER / TONE 1st -50 - +50
** ** 40 35 00 00 00 01 00 - 64 POLY LIMITER / TONE 2nd -50 - +50
** ** 40 36 00 00 00 01 00 - 64 POLY LIMITER / TONE 3rd -50 - +50
** ** 40 37 00 00 00 01 00 - 64 POLY LIMITER / TONE 4th -50 - +50
** ** 40 38 00 00 00 01 00 - 64 POLY LIMITER / TONE LowB -50 - +50
** ** 40 39 00 00 00 01 00 - 64 POLY LIMITER / LEVEL HiC 0 - 100
** ** 40 3A 00 00 00 01 00 - 64 POLY LIMITER / LEVEL 1st 0 - 100
** ** 40 3B 00 00 00 01 00 - 64 POLY LIMITER / LEVEL 2nd 0 - 100
** ** 40 3C 00 00 00 01 00 - 64 POLY LIMITER / LEVEL 3rd 0 - 100
** ** 40 3D 00 00 00 01 00 - 64 POLY LIMITER / LEVEL 4th 0 - 100
** ** 40 3E 00 00 00 01 00 - 64 POLY LIMITER / LEVEL LowB 0 - 100
** ** 40 3F 00 00 00 01 00 - 64 POLY DEFRETTER / SENS 0 - 100
** ** 40 40 00 00 00 01 00 - 64 POLY DEFRETTER / COLOR 0 - 100
** ** 40 41 00 00 00 01 00 - 64 POLY DEFRETTER / TONE 0 - 100
** ** 40 42 00 00 00 01 00 - 64 POLY DEFRETTER / LEVEL 0 - 100
** ** 40 44 00 00 00 01 00 - 03 POLY DIST / MODE 00 : OD1
01 : OD2
02 : DS1
03 : DS2
** ** 40 45 00 00 00 01 00 - 64 POLY DIST / DRIVE 0 - 100
** ** 40 46 00 00 00 01 00 - 64 POLY DIST / TONE -50 - +50
** ** 40 47 00 00 00 01 00 - 64 POLY DIST / EFFECT LEVEL 0 - 100
** ** 40 48 00 00 00 01 00 - 64 POLY DIST / DIRECT LEVEL 0 - 100
** ** 40 49 00 00 00 01 00 - 64 POLY DIST / DRIVE BAL -50 - +50
** ** 40 4A 00 00 00 01 00 - 64 POLY DIST / POLY BAL 0 - 100
** ** 40 4B 00 00 00 01 00 - 28 POLY EQ / LOW GAIN HiC -20dB - +20dB
** ** 40 4C 00 00 00 01 00 - 28 POLY EQ / LOW GAIN 1st -20dB - +20dB
** ** 40 4D 00 00 00 01 00 - 28 POLY EQ / LOW GAIN 2nd -20dB - +20dB
** ** 40 4E 00 00 00 01 00 - 28 POLY EQ / LOW GAIN 3rd -20dB - +20dB
** ** 40 4F 00 00 00 01 00 - 28 POLY EQ / LOW GAIN 4th -20dB - +20dB
** ** 40 50 00 00 00 01 00 - 28 POLY EQ / LOW GAIN LowB -20dB - +20dB
** ** 40 51 00 00 00 01 00 - 1B POLY EQ / LOW MID FREQ HiC * Refer to Table 'EQ MID FREQ'
** ** 40 52 00 00 00 01 00 - 1B POLY EQ / LOW MID FREQ 1st * Refer to Table 'EQ MID FREQ'
** ** 40 53 00 00 00 01 00 - 1B POLY EQ / LOW MID FREQ 2nd * Refer to Table 'EQ MID FREQ'
** ** 40 54 00 00 00 01 00 - 1B POLY EQ / LOW MID FREQ 3rd * Refer to Table 'EQ MID FREQ'
** ** 40 55 00 00 00 01 00 - 1B POLY EQ / LOW MID FREQ 4th * Refer to Table 'EQ MID FREQ'
** ** 40 56 00 00 00 01 00 - 1B POLY EQ / LOW MID FREQ LowB * Refer to Table 'EQ MID FREQ'
** ** 40 57 00 00 00 01 00 - 05 POLY EQ / LOW MID Q HiC * Refer to Table 'EQ Q'
** ** 40 58 00 00 00 01 00 - 05 POLY EQ / LOW MID Q 1st * Refer to Table 'EQ Q'
** ** 40 59 00 00 00 01 00 - 05 POLY EQ / LOW MID Q 2nd * Refer to Table 'EQ Q'
** ** 40 5A 00 00 00 01 00 - 05 POLY EQ / LOW MID Q 3rd * Refer to Table 'EQ Q'
** ** 40 5B 00 00 00 01 00 - 05 POLY EQ / LOW MID Q 4th * Refer to Table 'EQ Q'
** ** 40 5C 00 00 00 01 00 - 05 POLY EQ / LOW MID Q LowB * Refer to Table 'EQ Q'
** ** 40 5D 00 00 00 01 00 - 28 POLY EQ / LOW MID GAIN HiC -20dB - +20dB
** ** 40 5E 00 00 00 01 00 - 28 POLY EQ / LOW MID GAIN 1st -20dB - +20dB
** ** 40 5F 00 00 00 01 00 - 28 POLY EQ / LOW MID GAIN 2nd -20dB - +20dB
** ** 40 60 00 00 00 01 00 - 28 POLY EQ / LOW MID GAIN 3rd -20dB - +20dB
** ** 40 61 00 00 00 01 00 - 28 POLY EQ / LOW MID GAIN 4th -20dB - +20dB
** ** 40 62 00 00 00 01 00 - 28 POLY EQ / LOW MID GAIN LowB -20dB - +20dB
** ** 40 63 00 00 00 01 00 - 1B POLY EQ / HIGH MID FREQ HiC * Refer to Table 'EQ MID FREQ'
** ** 40 64 00 00 00 01 00 - 1B POLY EQ / HIGH MID FREQ 1st * Refer to Table 'EQ MID FREQ'
** ** 40 65 00 00 00 01 00 - 1B POLY EQ / HIGH MID FREQ 2nd * Refer to Table 'EQ MID FREQ'
** ** 40 66 00 00 00 01 00 - 1B POLY EQ / HIGH MID FREQ 3rd * Refer to Table 'EQ MID FREQ'
** ** 40 67 00 00 00 01 00 - 1B POLY EQ / HIGH MID FREQ 4th * Refer to Table 'EQ MID FREQ'
** ** 40 68 00 00 00 01 00 - 1B POLY EQ / HIGH MID FREQ LowB * Refer to Table 'EQ MID FREQ'
** ** 40 69 00 00 00 01 00 - 05 POLY EQ / HIGH MID Q HiC * Refer to Table 'EQ Q'
** ** 40 6A 00 00 00 01 00 - 05 POLY EQ / HIGH MID Q 1st * Refer to Table 'EQ Q'
** ** 40 6B 00 00 00 01 00 - 05 POLY EQ / HIGH MID Q 2nd * Refer to Table 'EQ Q'
** ** 40 6C 00 00 00 01 00 - 05 POLY EQ / HIGH MID Q 3rd * Refer to Table 'EQ Q'
** ** 40 6D 00 00 00 01 00 - 05 POLY EQ / HIGH MID Q 4th * Refer to Table 'EQ Q'
** ** 40 6E 00 00 00 01 00 - 05 POLY EQ / HIGH MID Q LowB * Refer to Table 'EQ Q'
** ** 40 6F 00 00 00 01 00 - 28 POLY EQ / HIGH MID GAIN HiC -20dB - +20dB
** ** 40 70 00 00 00 01 00 - 28 POLY EQ / HIGH MID GAIN 1st -20dB - +20dB
** ** 40 71 00 00 00 01 00 - 28 POLY EQ / HIGH MID GAIN 2nd -20dB - +20dB
** ** 40 72 00 00 00 01 00 - 28 POLY EQ / HIGH MID GAIN 3rd -20dB - +20dB
** ** 40 73 00 00 00 01 00 - 28 POLY EQ / HIGH MID GAIN 4th -20dB - +20dB
** ** 40 74 00 00 00 01 00 - 28 POLY EQ / HIGH MID GAIN LowB -20dB - +20dB
** ** 40 75 00 00 00 01 00 - 28 POLY EQ / HIGH GAIN HiC -20dB - +20dB
** ** 40 76 00 00 00 01 00 - 28 POLY EQ / HIGH GAIN 1st -20dB - +20dB
** ** 40 77 00 00 00 01 00 - 28 POLY EQ / HIGH GAIN 2nd -20dB - +20dB
** ** 40 78 00 00 00 01 00 - 28 POLY EQ / HIGH GAIN 3rd -20dB - +20dB
** ** 40 79 00 00 00 01 00 - 28 POLY EQ / HIGH GAIN 4th -20dB - +20dB
** ** 40 7A 00 00 00 01 00 - 28 POLY EQ / HIGH GAIN LowB -20dB - +20dB
** ** 40 7B 00 00 00 01 00 - 28 POLY EQ / TOTAL GAIN HiC -20dB - +20dB
** ** 40 7C 00 00 00 01 00 - 28 POLY EQ / TOTAL GAIN 1st -20dB - +20dB
** ** 40 7D 00 00 00 01 00 - 28 POLY EQ / TOTAL GAIN 2nd -20dB - +20dB
** ** 40 7E 00 00 00 01 00 - 28 POLY EQ / TOTAL GAIN 3rd -20dB - +20dB
** ** 40 7F 00 00 00 01 00 - 28 POLY EQ / TOTAL GAIN 4th -20dB - +20dB
** ** 41 00 00 00 00 01 00 - 28 POLY EQ / TOTAL GAIN LowB -20dB - +20dB
** ** 41 01 00 00 00 01 00 - 64 POLY OCTAVE / -1 OCTAVE LEVEL HiC 0 - 100
** ** 41 02 00 00 00 01 00 - 64 POLY OCTAVE / -1 OCTAVE LEVEL 1st 0 - 100
** ** 41 03 00 00 00 01 00 - 64 POLY OCTAVE / -1 OCTAVE LEVEL 2nd 0 - 100
** ** 41 04 00 00 00 01 00 - 64 POLY OCTAVE / -1 OCTAVE LEVEL 3rd 0 - 100
** ** 41 05 00 00 00 01 00 - 64 POLY OCTAVE / -1 OCTAVE LEVEL 4th 0 - 100
** ** 41 06 00 00 00 01 00 - 64 POLY OCTAVE / -1 OCTAVE LEVEL LowB 0 - 100
** ** 41 07 00 00 00 01 00 - 64 POLY OCTAVE / -2 OCTAVE LEVEL HiC 0 - 100
** ** 41 08 00 00 00 01 00 - 64 POLY OCTAVE / -2 OCTAVE LEVEL 1st 0 - 100
** ** 41 09 00 00 00 01 00 - 64 POLY OCTAVE / -2 OCTAVE LEVEL 2nd 0 - 100
** ** 41 0A 00 00 00 01 00 - 64 POLY OCTAVE / -2 OCTAVE LEVEL 3rd 0 - 100
** ** 41 0B 00 00 00 01 00 - 64 POLY OCTAVE / -2 OCTAVE LEVEL 4th 0 - 100
** ** 41 0C 00 00 00 01 00 - 64 POLY OCTAVE / -2 OCTAVE LEVEL LowB 0 - 100
** ** 41 0D 00 00 00 01 00 - 64 POLY OCTAVE / DIRECT LEVEL HiC 0 - 100
** ** 41 0E 00 00 00 01 00 - 64 POLY OCTAVE / DIRECT LEVEL 1st 0 - 100
** ** 41 0F 00 00 00 01 00 - 64 POLY OCTAVE / DIRECT LEVEL 2nd 0 - 100
** ** 41 10 00 00 00 01 00 - 64 POLY OCTAVE / DIRECT LEVEL 3rd 0 - 100
** ** 41 11 00 00 00 01 00 - 64 POLY OCTAVE / DIRECT LEVEL 4th 0 - 100
** ** 41 12 00 00 00 01 00 - 64 POLY OCTAVE / DIRECT LEVEL LowB 0 - 100
** ** 41 13 00 00 00 01 00 - 01 POLY RING MOD / MDOE 00 : NORMAL
01 : INTELLIGENT
** ** 41 14 00 00 00 01 00 - 64 POLY RING MOD / FREQ 0 - 100
** ** 41 15 00 00 00 01 00 - 64 POLY RING MOD / DIST DRIVE 0 - 100
** ** 41 16 00 00 00 01 00 - 64 POLY RING MOD / DIST TONE -50 - +50
** ** 41 17 00 00 00 01 00 - 64 POLY RING MOD / DIST LEVEL 0 - 100
** ** 41 18 00 00 00 01 00 - 64 POLY RING MOD / EFFECT LEVEL HiC 0 - 100
** ** 41 19 00 00 00 01 00 - 64 POLY RING MOD / EFFECT LEVEL 1st 0 - 100
** ** 41 1A 00 00 00 01 00 - 64 POLY RING MOD / EFFECT LEVEL 2nd 0 - 100
** ** 41 1B 00 00 00 01 00 - 64 POLY RING MOD / EFFECT LEVEL 3rd 0 - 100
** ** 41 1C 00 00 00 01 00 - 64 POLY RING MOD / EFFECT LEVEL 4th 0 - 100
** ** 41 1D 00 00 00 01 00 - 64 POLY RING MOD / EFFECT LEVEL LowB 0 - 100
** ** 41 1E 00 00 00 01 00 - 64 POLY RING MOD / DIRECT LEVEL HiC 0 - 100
** ** 41 1F 00 00 00 01 00 - 64 POLY RING MOD / DIRECT LEVEL 1st 0 - 100
** ** 41 20 00 00 00 01 00 - 64 POLY RING MOD / DIRECT LEVEL 2nd 0 - 100

page23

Model VB-99 MIDI Implementation 　Version : 1.00

** ** 41 21 00 00 00 01 00 - 64 POLY RING MOD / DIRECT LEVEL 3rd 0 - 100
** ** 41 22 00 00 00 01 00 - 64 POLY RING MOD / DIRECT LEVEL 4th 0 - 100
** ** 41 23 00 00 00 01 00 - 64 POLY RING MOD / DIRECT LEVEL LowB 0 - 100
** ** 41 24 00 00 00 01 00 - 64 POLY SG / RISE TIME 0 - 100
** ** 41 25 00 00 00 01 00 - 64 POLY SG / SENS 0 - 100
** ** 41 26 00 00 00 01 00 - 02 POLY STRING MODELING / TYPE HiC 00 : OFF
01 : FLAT WOUND
02 : BLACK NYLON
** ** 41 27 00 00 00 01 00 - 02 POLY STRING MODELING / TYPE 1st 00 : OFF
01 : FLAT WOUND
02 : BLACK NYLON
** ** 41 28 00 00 00 01 00 - 02 POLY STRING MODELING / TYPE 2nd 00 : OFF
01 : FLAT WOUND
02 : BLACK NYLON
** ** 41 29 00 00 00 01 00 - 02 POLY STRING MODELING / TYPE 3rd 00 : OFF
01 : FLAT WOUND
02 : BLACK NYLON
** ** 41 2A 00 00 00 01 00 - 02 POLY STRING MODELING / TYPE 4th 00 : OFF
01 : FLAT WOUND
02 : BLACK NYLON
** ** 41 2B 00 00 00 01 00 - 02 POLY STRING MODELING / TYPE LowB 00 : OFF
01 : FLAT WOUND
02 : BLACK NYLON
** ** 41 2C 00 00 00 01 00 - 64 POLY STRING MODELING / LEVEL HiC 0 - 100
** ** 41 2D 00 00 00 01 00 - 64 POLY STRING MODELING / LEVEL 1st 0 - 100
** ** 41 2E 00 00 00 01 00 - 64 POLY STRING MODELING / LEVEL 2nd 0 - 100
** ** 41 2F 00 00 00 01 00 - 64 POLY STRING MODELING / LEVEL 3rd 0 - 100
** ** 41 30 00 00 00 01 00 - 64 POLY STRING MODELING / LEVEL 4th 0 - 100
** ** 41 31 00 00 00 01 00 - 64 POLY STRING MODELING / LEVEL LowB 0 - 100

[ [A] CHAIN ]
** ** 50 00 00 00 00 01 00 - 0B CHAIN 1 * Refer to Table 'CHAIN'
** ** 50 01# 00 00 00 01 00 - 0B CHAIN 2
: : : :
** ** 50 0B# 00 00 00 01 00 - 0B CHAIN 12

[ [A] COSM AMP ]
** ** 50 0D 00 00 00 01 00 - 01 COSM AMP SW 00 : OFF
01 : ON
** ** 50 0E 00 00 00 01 00 - 0B GTR AMP / PREAMP TYPE * Refer to Table 'COSM AMP'
** ** 50 0F 00 00 00 01 00 - 78 GTR AMP / GAIN 0 - 120
** ** 50 10 00 00 00 01 00 - 64 GTR AMP / BASS 0 - 100
** ** 50 11 00 00 00 01 00 - 64 GTR AMP / MIDDLE 0 - 100
** ** 50 12 00 00 00 01 00 - 64 GTR AMP / TREBLE 0 - 100
** ** 50 13 00 00 00 01 00 - 64 GTR AMP / PRESENCE 0 - 100
** ** 50 14 00 00 00 01 00 - 64 GTR AMP / LEVEL 0 - 100
** ** 50 15 00 00 00 01 00 - 01 GTR AMP / BRIGHT 00 : OFF
01 : ON
** ** 50 16 00 00 00 01 00 - 02 GTR AMP / GAIN SW 00 : LOW
01 : MIDDLE
02 : HIGH
** ** 50 17 00 00 00 01 00 - 01 GTR AMP / SOLO SW 00 : OFF
01 : ON
** ** 50 18 00 00 00 01 00 - 64 GTR AMP / SOLO LEVEL 0 - 100
** ** 50 19 00 00 00 01 00 - 08 GTR AMP / SPEAKER SP TYPE 00 : OFF
01 : ORIG
02 : 1x8"
03 : 1x10"
04 : 1x12"
05 : 2x12"
06 : 4x10"
07 : 4x12"
08 : 8x12"
** ** 50 1A 00 00 00 01 00 - 04 GTR AMP / SPEAKER MIC TYPE 00 : DYN57
01 : DYN421
02 : CND451
03 : CND87
04 : FLAT
** ** 50 1B 00 00 00 01 00 - 01 GTR AMP / SPEAKER MIC DIS 00 : OffMIC
01 : On MIC
** ** 50 1C 00 00 00 01 00 - 0A GTR AMP / SPEAKER MIC POS 00 : CENTER
01 - 0A : 1cm - 10cm
** ** 50 1D 00 00 00 01 00 - 64 GTR AMP / SPEAKER LEVEL 0 - 100
** ** 50 1E 00 00 00 01 00 - 64 GTR AMP / SPEAKER DIRECT MIX 0 - 100
** ** 50 1F 00 00 00 01 00 - 64 GTR AMP / SPEAKER BOTTOM 0 - 100
** ** 50 20 00 00 00 01 00 - 64 BASS AMP / GAIN 0 - 100
** ** 50 21 00 00 00 01 00 - 64 BASS AMP / BASS 0 - 100
** ** 50 22 00 00 00 01 00 - 64 BASS AMP / MIDDLE 0 - 100
** ** 50 23 00 00 00 01 00 - 64 BASS AMP / TREBLE 0 - 100
** ** 50 24 00 00 00 01 00 - 64 BASS AMP / LEVEL 0 - 100
** ** 50 25 00 00 00 01 00 - 01 BASS AMP / BRIGHT 00 : OFF
01 : ON
** ** 50 26 00 00 00 01 00 - 02 BASS AMP / MIDDLE FREQ 00 : 220Hz
01 : 800Hz
02 : 3.0kHz
** ** 50 27 00 00 00 01 00 - 02 BASS AMP / ULTRA LOW (CONCRT 810) 00 : ­ 01 : 0
02 : +
** ** 50 28 00 00 00 01 00 - 01 BASS AMP / ULTRA HIGH (CONCRT 810) 00 : OFF
01 : ON
** ** 50 29 00 00 00 01 00 - 01 BASS AMP / RESPONSE (FIP TOP) 00 : BASS
01 : FLAT
** ** 50 2A 00 00 00 01 00 - 01 BASS AMP / DEEP (B MAN) 00 : OFF
01 : ON
** ** 50 2B 00 00 00 01 00 - 02 BASS AMP / PRESHAPE (T.E.) 00 : OFF
01 : 1
02 : 2
** ** 50 2C 00 00 00 01 00 - 64 BASS AMP / ENHANCER (SESSION) 0 - 100
** ** 50 2D 00 00 00 01 00 - 06 BASS AMP / SPEAKER SP TYPE 00 : OFF
01 : ORIG
02 : 1x15"
03 : 1x18"
04 : 2x15"
05 : 4x10"
06 : 8x10"
** ** 50 2E 00 00 00 01 00 - 0A BASS AMP / SPEAKER MIC POS 00 : CENTER
01 - 0A : 1cm - 10cm
** ** 50 2F 00 00 00 01 00 - 64 BASS AMP / SPEAKER LEVEL 0 - 100
** ** 50 30 00 00 00 01 00 - 64 BASS AMP / SPEAKER DIRECT MIX 0 - 100
** ** 50 31 00 00 00 01 00 - 64 BASS AMP / PRESENCE 0 - 100
** ** 50 32 00 00 00 01 00 - 64 BASS AMP / SPEAKER BOTTOM 0 - 100

Model VB-99 MIDI Implementation 　Version : 1.00

[ [A] FX OD/DS ]
** ** 50 33 00 00 00 01 00 - 01 OD/DS SW 00 : OFF
01 : ON
** ** 50 34 00 00 00 01 00 - 0B TYPE * Refer to Table 'FX OD/DS TYPE'
** ** 50 35 00 00 00 01 00 - 64 DRIVE 0 - 100
** ** 50 36 00 00 00 01 00 - 64 BOTTOM 0 - 100
** ** 50 37 00 00 00 01 00 - 64 TONE -50 - +50
** ** 50 38 00 00 00 01 00 - 64 LEVEL 0 - 100
** ** 50 39 00 00 00 01 00 - 64 DIRECT MIX 0 - 100

[ [A] FX NS ]
** ** 50 40 00 00 00 01 00 - 01 NS SW 00 : OFF
01 : ON
** ** 50 41 00 00 00 01 00 - 64 THRSH 0 - 100

page24
