Roland SRX-05 User Manual

このエクスパンション・ボードは新フォーマットを採用してい

Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY” and “IMPORTANT
NOTES” (p. 2; p. 4). These sections provide important information concerning the proper operation of the unit.
Additionally, in order to feel assured that you have gained a good grasp of every feature provided by your new
unit, this manual should be read in its entirety. The manual should be saved and kept on hand as a convenient
reference.

201a

この機器を正しくお使いいただくために、ご使用前に「安全上のご注意」（P.3）と「使用上のご注意」（P.4）をよく
お読みください。また、この機器の優れた機能を十分ご理解いただくためにも、この取扱説明書をよくお読みくださ
い。取扱説明書は必要なときにすぐに見ることができるよう、手元に置いてください。

Thank you, and congratulations on your choice of the SRX-05
“Supreme Dance” Wave Expansion Board.

This expansion board provides a huge variety of tried-and-true
sounds geared for dance music, whether it be Techno, House,
HipHop, Trance, 2-Step, or Drum ’n’ Bass. In addition, it also
includes some of the latest sounds developed by Spectrasonics, the
American company that is known for its range of high-quality CD­ROMs for samplers.

The SRX-05 includes a great number of rhythm sounds, including
133 different snare sounds and 113 kick sounds, along with 82
vintage synth and JP-8000 waveforms like Hit&Stab, SH, JUNO, and
JUPITER, scratch sounds, FX, strings/electric piano chords, phrase
loops, and more.

The Patches and Rhythm Sets include synth bass, synth lead, pads,
and FX patches—all indispensable when creating dance tracks.

Also included are special Rhythm Sets that you can use in a wide
variety of musical genres.

• Patches: 312

(The contents for the Fantom series/XV series/MX-200 and the RD series
with SRX slots/MC-909/VR-760/G-70 are slightly different.)

• Rhythm Sets: 34

(The contents for the Fantom series/XV series/MX-200 and the RD series
with SRX slots/MC-909/VR-760/G-70 are slightly different.)

• Waveforms: 818

* The parameter settings for Patches and Rhythm Sets are optimized for

the Fantom series, XV series, MX-200, RD series with SRX slots,
MC-909, VR-760, and G-70 models, so there are some minor
differences in the sounds each instrument produces.

This expansion board utilizes a new format. Check the
system program version for your instrument, and if a
relevant upgrade is available, upgrade your instrument
using the appropriate system update program on the
included CD-ROM. (See p. 27.)

このたびは、ウェーブ・エクスパンション・ボード SRX-05

「Supreme Dance」をお買い上げいただき、まことにありがとうご

ざいます。
このエクスパンション・ボードは、Techno、House、HipHop、

Trance、2-Step、Drum 'n' Bass など、様々なダンス・ ミュージッ
ク向けの定番音色から、サンプラー用の高品位な CD-ROM を数多
く制作している米国 Spectrasonics 社が開発した最新音色まで、幅
広く網羅しています。

ウェーブフォームは、スネア 133 種類、キック 113 種類をはじめ
とする多数のリズム音色、82 種類の Hit&Stab、SH、JUNO、
JUPITER といったビンテージ・ シンセや JP-8000 シリーズのシン
セ波形、スクラッチ、FX、ストリングス／エレピ・コード、フレー
ズ・ループなどを収録しています。

パッチ／リズム・セットは、ダンス・トラックを製作するのに重宝
するシンセ・ベース、シンセ・リード、パッド、FX、各ジャンルに
幅広く使える特徴あるリズム・セットなどが収録されています。

•

パッチ 312 種類

（Fantom シリーズ /XV シリーズ /MX-200 と SRX 対応の RD シリーズ

/MC-909/VR-760 とで内容が若干異なります。）

•

リズム・セット 34 種類

（Fantom シリーズ /XV シリーズ /MX-200 と SRX 対応の RD シリーズ

/MC-909/VR-760 とで内容が若干異なります。）

ウェーブフォーム 818 種類

•

※ 各パッチ／リズム・セットは Fantom シリーズ、XV シリーズ、

MX-200、SRX 対応の RD シリーズ、MC-909、VR-760 の各
機種ごとに最適なパラメーター設定を行っていますので、それ
ぞれ出音が異なることがあります。

ます。お使いの機種のシステム・プログラム・バージョンをご
確認の上、バージョン・アップ対象の場合は、付属 CD-ROM
に収録のシステム・アップデート・プログラムでバージョン・
アップしてからご使用ください。（P.27 をご覧ください。）

1

USING THE UNIT SAFELY

Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.

Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.

* Material damage refers to damage or

other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.

001

• Before using this unit, make sure to read the
instructions below, and the Owner’s Manual.

..........................................................................................................

002a

• Do not open or perform any internal modifica­tions on the unit.

..........................................................................................................

003

• Do not attempt to repair the unit, or replace parts
within it (except when this manual provides
specific instructions directing you to do so). Refer
all servicing to your retailer, the nearest Roland
Service Center, or an authorized Roland
distributor, as listed on the “Information” page.

..........................................................................................................

004

• Never use or store the unit in places that are:

• Subject to temperature extremes (e.g., direct

sunlight in an enclosed vehicle, near a heating
duct, on top of heat-generating equipment); or
are

• Damp (e.g., baths, washrooms, on wet floors);

or are

• Humid; or are

• Exposed to rain; or are

• Dusty; or are

• Subject to high levels of vibration.

..........................................................................................................

011

• Do not allow any objects (e.g., flammable material,
coins, pins); or liquids of any kind (water, soft
drinks, etc.) to penetrate the unit.

..........................................................................................................

The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.

The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.

The ● symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the power­cord plug must be unplugged from the outlet.

013

• In households with small children, an adult
should provide supervision until the child is
capable of following all the rules essential for the
safe operation of the unit.

..........................................................................................................

014

• Protect the unit from strong impact.

(Do not drop it!)

..........................................................................................................

022c

• Before installing the SRX-05, you must first always
turn off the Fantom series/XV series/MX-200/RD
series with SRX slots/MC-909/VR-760/G-70 and
unplug its power cord.

..........................................................................................................

023

• DO NOT play a CD-ROM disc on a conventional
audio CD player. The resulting sound may be of a
level that could cause permanent hearing loss.
Damage to speakers or other system components
may result.

..........................................................................................................

106

• Never climb on top of, nor place heavy objects on
the unit.

..........................................................................................................

115b

• Install the circuit board only into the specified unit
(Fantom series/XV series/MX-200/RD series with
SRX slots/MC-909/VR-760/G-70). Remove only
the specified screws during the installation.

..........................................................................................................

118a

• Should you remove screws, make sure to put them
in a safe place out of children’s reach, so there is
no chance of them being swallowed accidentally.

..........................................................................................................

* In the interest of product improvement, the specifications and/or contents of this package are subject to change

without prior notice.

2

安全上のご注意

警告

注意

安全上のご注意

火災・感電・傷害を防止するには

注意の意味について警告と

取扱いを誤った場合に、使用者が

警告

注意

死亡または重傷を負う可能性が想
定される内容を表わしています。

取扱いを誤った場合に、使用者が
傷害を負う危険が想定される場合
および物的損害のみの発生が想定
される内容を表わしています。

※物的損害とは、家屋・家財およ

び家畜・ペットにかかわる拡大
損害を表わしています。

以下の指示を必ず守ってください

警告

001

●この機器を使用する前に、以下の指示と取扱説
明書をよく読んでください。

..............................................................................................................

002a

●この機器を分解したり、改造したりしないでく
ださい。

..............................................................................................................

003

●修理／部品の交換などで、取扱説明書に書かれ
ていないことは、絶対にしないでく ださい。必

ずお買い上げ店またはローランド・サー ビスに
相談してください。

..............................................................................................................

004

●次のような場所での使用や保存はしないでくだ
さい。

○ 温度が極端に高い場所（直射日光の当たる場

所、暖房機器の近く、発熱する機器の上など）

○ 水気の近く（風呂場、洗面台、濡れた床など）

や湿度の高い場所
○ 雨に濡れる場所
○ ホコリの多い場所
○ 振動の多い場所

..............................................................................................................

011

●この機器に、異物（燃えやすいもの、硬貨、針
金など）や液体（水、ジュースなど）を絶 対に

入れないでください。

図記号の例

は、注意（危険、警告を含む）を表わしていま
す。
具体的な注意内容は、 の中に描かれています。
左図の場合は、「一般的な注意、警告、危険」を
表わしています。

は、禁止（してはいけないこと）を表わしてい
ます。
具体的な禁止内容は、 の中に描かれています。
左図の場合は、「分解禁止」を表わしています。

●は、強制（必ずすること）を表わしています。

具体的な強制内容は、
左図の場合は、「電源プラグをコンセントから抜
くこと」を表わしています。

013

●お子様のいるご家庭で使用する場合、お子様の
取り扱いやいたずらに注意してくだ さい。必ず

大人のかたが、監視／指導してあげてください。

..............................................................................................................

014

●この機器を落としたり、この機器に強い衝撃を
与えないでください。

..............................................................................................................

022c

● SRX-05 を取り付ける前に、Fantom シリーズ、
XV シリーズ、MX-200、SRX 対応の RD シリー

ズ、MC-909、VR-760 の電源を切って電源プラ
グをコンセントから外してください。

..............................................................................................................

023

● CD-ROM を、一般のオーディオ CD プレーヤー
で再生しないで下さい。大音量によって 耳を痛

めたり、スピーカーを破損する恐れがあります。

106

●この機器の上に乗ったり、機器の上に重いもの
を置かないでください。

..............................................................................................................

115b

● 指定の機器（Fantom シリーズ、XV シリーズ、
MX-200、SRX 対応の RD シリーズ、MC-909、

VR-760）だけに取り付け、取り付け時には指定
されたネジだけを外してください。

..............................................................................................................

118a

●ネジを外した場合は、小さなお子様が誤って飲
み込んだりすることのないようお子様 の手の届

かないところへ保管してください。

●の中に描かれています。

※ 製品の仕様および内容は、改良のため予告なく変更することがあります。

3

IMPORTANT NOTES

When you purchase the SRX-05 expansion board from an authorized
Roland dealer, the included sounds and samples are licensed, not
sold, to you by Roland Corporation, for commercial use in music
production, public performance, broadcast, etc.

You may use any of the included phrases and/or samples in a
commercial or non-commercial recording without paying any
additional license fees. However, you must strictly adhere to the
following crediting guidelines on any music recording that utilize
material from SRX-05.

Reproduction or duplication of this collection or any of the sound
recording contained in the SRX-05, either as they exist on this
expansion board or by any means of reformatting, mixing, filtering,
re-synthesizing, processing or otherwise editing for use in another
product or for re-sale, is strictly prohibited without the express
written consent of Roland. All unauthorized giving, trading,
lending, renting, re-issue, re-distribution or re-sale of the sounds
included in the SRX-05 are expressly prohibited.

In Plain English: Be creative in your application of the SRX-05
sounds, and keep this library for your use only. DO NOT COPY IT.

Roland constantly monitors other Soundware releases to check for
copyright infringements, and will prosecute all piracy and copyright
violations to the fullest extent of the law.

THIS LIBRARY IS GUARANTEED TO BE 100%
COPYRIGHT CLEAN.

291a

In addition to the items listed under “USING THE UNIT
SAFELY” on page 2, please read and observe the following:

Handling CD-ROMs

801

* Avoid touching or scratching the shiny underside (encoded surface) of

the disc. Damaged or dirty CD-ROM discs may not be read properly.
Keep your discs clean using a commercially available CD cleaner.

使用上のご注意

お客様が SRX-05 エクスパンション・ボード（以下、「本製
品」といいます）をローランドの正規販売店からお買い上げ
になった時点で、本製品に含まれる音やサンプルは、ローラ
ンド株式会社から、お客様に対して、音楽制作、公共の場で
の演奏、放送などの商用目的のための使用を許諾したもので
あって、著作権を譲渡したものではありません。

お客様は、いかなる追加料金を支払うこともなく、本製品に
含まれるあらゆるフレーズやサンプルを、商用あるいは非商
用目的の録音に使用できます。ただし、お客様が本製品を使
用して音楽の録音を行う際は、以下のことにご注意ください。

本製品に含まれるいかなる録音物も、そのままの状態であ
れ、いかなる手段によって再構成、ミキシング、フィルター
加工、再合成、加工処理、その他の編集作業をした状態であ
れ、ローランドの書面による許可なく、他の製品に含めたり
再販売するために複製・複写することを禁止します。また、
本製品に含まれるいかなる音も、許可なく贈与、取引、貸
与、賃貸、再発行、再配布、再販売することを禁止します。

従って、本製品の音色は音楽制作の範囲でお使いいただくよ
うお願いします。そして、本製品のライブラリーはお客様ご
自身の個人的使用の目的の範囲でお使いください。本製品の
音色データの複製・複写は禁止します。

ローランドは、著作権侵害がないかどうか、常時他のサウン
ド・ライブラリーの発売を把握しており、著作権侵害に対し
ては法的手段を行使する場合があります。

なお、本製品のライブラリーは第三者の著作権を一切侵害し
ていないことを保証します。

291a

3 ページに記載されている「安全上のご注意」以外に、次の
ことに注意してください。

Handling the Board

901

To avoid the risk of damage to internal components that can
be caused by static electricity, please carefully observe the
following whenever you handle the board.

1

* Before you touch the board, always first grasp a metal object

(such as a water pipe), so you are sure that any static
electricity you might have been carrying has been discharged.

2

* When handling the board, grasp it only by its edges. Avoid

touching any of the electronic components or connectors.

5

* Save the bag in which the board was originally shipped, and

put the board back into it whenever you need to store or
transport it.

901 (F)

Veuillez suivre attentivement les instructions suivantes quand
vous manipulez la carte afin d’éviter tout risque
d’endommagement des pièces internes par l’électricité statique.

1

* Toujours toucher un objet métallique relié à la terre (comme

un tuyau par exemple) avant de manipuler la carte pour vous
décharger de l’électricité statique que vous auriez pu
accumuler.

2

* Lorsque vous manipulez la carte, la tenir par les côtés. Évitez

de toucher aux composants ou aux connecteurs.

5

* Conservez le sachet d’origine dans lequel était la carte lors de l’envoi

et remettez la carte dedans si vous devez la ranger ou la transporter.

修理について

451a

※ お客様がこの機器を分解、改造された場合、以後の性能

について保証できなくなります。また、修理をお断りす
る場合もあります。

453

※ 当社では、この製品の補修用性能部品（製品の機能を維

持するために必要な部品）を、製造打切後 6 年間保有し
ています。この部品保有期間を修理可能の期間とさせて
いただきます。なお、保有期間が経過した後も、故障箇
所によっては修理可能の場合がありますので、お買い上
げ店、または最寄りのローランド・サービスにご相談く
ださい。

CD-ROM の取り扱い

801

※ ディスクの裏面（信号面）に触れたり、傷をつけたりし

ないでください。データの読み出しがうまくいかないこ
とがあります。ディスクの汚れは、市販の CD 専用ク
リーナーでクリーニングしてください。

基板の取り扱い

901

この基板は、静電気により部品が破壊される恐れがありま
す。基板を取り扱うときは、次の点に注意してください。

1

※ 基板を持つときは、あらかじめ何らかの金属に触れて、

体や衣類にたまっている静電気を放電してください。

2

※ 基板を持つときは、基板の縁を持ち、部品やコネクター

の部分に直接手を触れないでください。

5

※ 基板を保管するとき、または輸送するときなどは、購入

時に基板が入っていた袋（導電袋）に入れてください。

4

INSTALLING THE WAVE EXPANSION
BOARD

* Turn off your instrument.

1.

Remove the cover located on the top (or rear) of your
instrument.

2.

Insert the Wave Expansion Board connector into a connector
for an SRX Series slot, while simultaneously inserting the
board holders into the holes in the Wave Expansion Board.

* Do not touch any of the printed circuit pathways or

connection terminals.

* Never use excessive force when installing a circuit board. If it doesn’t

fit properly on the first attempt, remove the board and try again.

3.

Use the supplied Installation Tool to turn the holders in the
LOCK direction, so the board will be fastened in place.

(To remove the Wave Expansion Board, turn the board holders
in the UNLOCK direction, and lift up the board.)

* When circuit board installation is complete, double-check your

work.

4.

Using the screws removed in Step 1, refasten the cover in its
original position.

5.

Check if the Wave Expansion Board is correctly installed.

* If the “EXP” display cannot be selected (doesn’t appear) in the

Waveform Selection Screen (refer to the owner’s manual of the
instrument you use), remove the Wave Expansion Board and
install it properly.

* Éteindre l’instrument.

1.

Retirer le couvercle situé sur le dessus (ou á l’arrière) de
l’instrument.

2.

Inserer le connecteur de la carte dans un des creneaux pour
la serie SRX tout en enfoncant les supports a carte dans les
trous de celle-ci.

* Ne pas toucher aux circuits imprimes ou aux connecteurs.
* Ne jamais forcer lors de l’installation de la carte de circuits

imprimes. Si la carte s’ajuste mal au premier essai, enlevez la
carte et recommencez l’installation.

3.

Utiliser l’outil d’installation fourni pour tourner les clips de
retenue vers la position de blocage (LOCK) de façon á ce que
la carte soit retenue en place.

(Pour retirer la carte d’expansion Wave, tourner les clips de
retenue de la carte vers la position déblocage (UNLOCK) et
retirer la carte en la soulevant.)

* Quand l’installation de la carte de circuits imprimes est

terminee, reverifiez si tout est bien installe.

4.

Remettre la plaque a sa place et la fixer a l’aide des vis
enlevees a l’etape 1.

5.

S’assurer que la carte d’expansion Wave est installée
correctement.

* S’il est impossible de sélectionner l’affichage “EXP” (il

n’apparaît pas) á l’écran de sélection Waveform (se reporter au
guide du propriétaire de l’instrument utilisé), retirer la carte
d’expansion Wave et la réinstaller correctement.

ウェーブ・エクスパンション・ボードの取り
付けかた

※ 使用機器の電源スイッチをオフにしてください。

1.

使用機器の上部、または背面にあるカバーをはずしま
す。

2.

SRX シリーズ用のスロットのコネクターにウェーブ・エ
クスパンション・ボードのコネクターを差し込み、同時

に基板ホルダーをウェーブ・エクスパンション・ボード

の穴にはめ込みます。
※ 回路部やコネクター部には手を触れないでください。
※ 基板を無理に押し込まないでください。装着しにくい場

合、いったん基板を外してやり直してください。

3.

付属の固定用具で基板ホルダーを LOCK 方向に回し、

ウェーブ・エクスパンション・ボードを固定します。

（ウェーブ・エクスパンション・ボードを取り外すには、

基板ホルダーを UNLOCK 方向に回してから取り外しま

す。）
※ 取り付けを終えたら、正しく取り付けられていることを

再度確認してください。

手順 1 で外したネジで、カバーを元通りに取り付けます。

4.

ウェーブ・エクスパンション・ボードの取り付けが正し

5.

く行われたかを確認します。
※ ウェーブフォームの選択画面（使用機器の取扱説明書参

照）でEXPが選べない（表示されない）ときは、も

う一度ウェーブ・エクスパンション・ボードをつけ直し

てください。

Screwdriver

Tournevis

ドライバー

Wave Expansion Board (SRX series)

21 3

Carte d'extension Wave (serie SRX)

ウェーブ・エクスパンション・ボード（SRXシリーズ）

Connector

Connecteur

コネクター

Board holder
Support à carte

基板ホルダー

Position them as shown before you install the board.
Avant l’installation, orienter les supports à carte tel qu’indiqué sur le schéma.

取り付ける前に図のような向きに合わせます

LOCK

Installation tool
Outil d'installation

固定用具

5

Patch List (1)

For Fantom series/XV series/MX-200

(BANK SELECT MSB: 93; LSB: 4 [No.1–128], LSB: 5 [No.129–256], LSB: 6 [No.257–312])

No. Name Voices Category

1 SecretDancer 5 BEAT&GROOVE
2 Mean Streets 4 BEAT&GROOVE
3 E-tronic 4 BEAT&GROOVE
4 License2chil 8 BRIGHT PAD
5 Scratch Menu 1 SOUND FX
6 Hit Specials 2 HIT&STAB
7 Motivation 7 STRINGS
8 Sine Vibrato 1 SOFT LEAD
9 Acid Punch 2 SYNTH BASS
10 E.Gtr Menu 2 EL.GUITAR
11 Brite Flange 2 BRIGHT PAD
12 Dance Vibes 3 TECHNO SYNTH
13 N-Trance 4 PULSATING
14 Phatt 8 BEAT&GROOVE
15 DoubleDown 5 BEAT&GROOVE
16 LoopFX Dark 8 BEAT&GROOVE
17 Yo DJ 5 BEAT&GROOVE
18 HH Piledrivr 3 BEAT&GROOVE
19 Trush Head 2 BEAT&GROOVE
20 Rap 21 6 BEAT&GROOVE
21 Teknobeat 5 BEAT&GROOVE
22 Filter Beat 7 BEAT&GROOVE
23 FashionStyle 4 BEAT&GROOVE
24 Strobobeat 8 BEAT&GROOVE
25 SpaceGroove2 6 BEAT&GROOVE
26 Underground 4 BEAT&GROOVE
27 Extra Drive 4 BEAT&GROOVE
28 NakedPrey 3 BEAT&GROOVE
29 Mod It! 4 BEAT&GROOVE
30 Broken’Roll 2 COMBINATION
31 Drew Groove 4 COMBINATION
32 Beat Menu 2 BEAT&GROOVE
33 Sinewave Bs 1 SYNTH BASS
34 808 Bass 2 SYNTH BASS
35 Low Bass 2 4 SYNTH BASS
36 Low Bass 3 3 SYNTH BASS
37 Low Bass 4 4 SYNTH BASS
38 Hood Bass 2 2 SYNTH BASS
39 Rubber Bs 21 3 SYNTH BASS
40 Cheezee Bass 2 SYNTH BASS
41 Bend Bs /sw 2 SYNTH BASS
42 Saws Bass 4 SYNTH BASS
43 Bass Kadett 3 SYNTH BASS
44 Qube Bass 2 SYNTH BASS
45 LegatoSynBs 3 SYNTH BASS
46 15inch Bass 2 (1) SYNTH BASS
47 MG Filter Bs 2 SYNTH BASS
48 Plk Bass 1 SYNTH BASS
49 Flat SawBass 3 SYNTH BASS
50 SH-101 Bass 2 SYNTH BASS
51 Pulsing Bs 2 SYNTH BASS
52 Arrpy 2 SYNTH BASS

No. Name Voices Category

53 Acid Bass 2 1 SYNTH BASS
54 Euro Bass 21 2 SYNTH BASS
55 DarkEchoBass 8 SYNTH BASS
56 UnisonSwBass 2 SYNTH BASS
57 Dirty Bass 4 SYNTH BASS
58 Comp NzBass 3 SYNTH BASS
59 JunoDistBass 1 SYNTH BASS
60 TB Dist Bs 1 1 SYNTH BASS
61 TB Dist Bs 2 1 SYNTH BASS
62 TB Dist Bs 3 2 SYNTH BASS
63 Human Bass 2 SYNTH BASS
64 Interferenz 2 SYNTH BASS
65 16th SeqBass 4 SYNTH BASS
66 Woofer Blow 1 BASS
67 Guitaron Oct 1 BASS
68 Finger Bass6 1 BASS
69 Noisy P.Bass 3 BASS
70 FeelBass 3 (2) BASS
71 Ethno Bass 3 2 BASS
72 FAT Rave 2 OTHER SYNTH
73 JUNO Rave 2 OTHER SYNTH
74 4 x Saws 4 OTHER SYNTH
75 Euro Saws 3 OTHER SYNTH
76 Super Sawz 4 OTHER SYNTH
77 Step Phaser 6 OTHER SYNTH
78 Vade Retro 2 OTHER SYNTH
79 Pulse Keys 4 OTHER SYNTH
80 P5 Pluck 2 OTHER SYNTH
81 Alpha Waves 4 OTHER SYNTH
82 Andes 5 OTHER SYNTH
83 Northern Pls 3 OTHER SYNTH
84 R&B Pluck 2 2 OTHER SYNTH
85 SynHarpsi 2 OTHER SYNTH
86 Saw Wave HQ 2 OTHER SYNTH
87 Sqr Wave HQ 2 OTHER SYNTH
88 JU2 Wave 1 2 OTHER SYNTH
89 JU2 Wave 2 2 OTHER SYNTH
90 Pulse Wave 1 2 OTHER SYNTH
91 Pulse Wave 2 2 OTHER SYNTH
92 SpectrumWave 2 OTHER SYNTH
93 Pure Sine 2 1 OTHER SYNTH
94 Slippers 4 OTHER SYNTH
95 Climb Maj7th 4 OTHER SYNTH
96 Return2Minor 8 OTHER SYNTH
97 FallingStar 3 OTHER SYNTH
98 Convulsions 2 PULSATING
99 CrazZzeee 4 PULSATING
100 Creative 5 PULSATING
101 Juno Slice 4 PULSATING
102 Epic Slice 4 PULSATING
103 Klang Werk 8 PULSATING
104 Ouverture 6 PULSATING

No. Name Voices Category

105 Tropic Slice 4 PULSATING
106 Strained 4 PULSATING
107 Wicked DJ 2 5 PULSATING
108 Ultra Noise 3 PULSATING
109 JunoArpeggio 4 PULSATING
110 Autoarpeggio 8 PULSATING
111 SeqOctarveEP 4 PULSATING
112 Sync Vox 8 PULSATING
113 Stack Clavi 4 PULSATING
114 Pump up 3 PULSATING
115 Sine Seq 2 PULSATING
116 Seq Saws 4 PULSATING
117 Finale Hit 8 HIT&STAB
118 Big Hit 3 8 HIT&STAB
119 AnswerMe!Hit 4 HIT&STAB
120 LoungeLizard 7 HIT&STAB
121 Disco Stabs 8 HIT&STAB
122 12x12’sDisco 6 HIT&STAB
123 LittleDots 2 HIT&STAB
124 TribalTechno 4 HIT&STAB
125 Minor Bumwah 4 HIT&STAB
126 Bobs Slide 1 HIT&STAB
127 BrassHit 1 1 HIT&STAB
128 BrassHit 2 1 HIT&STAB
129 BrassHit 3 1 HIT&STAB
130 BrassHit 4 2 HIT&STAB
131 BrassHit 5 2 HIT&STAB
132 BrassHit 6 2 HIT&STAB
133 BrassHit 7 1 HIT&STAB
134 SymphHit 1 2 HIT&STAB
135 SymphHit 2 2 HIT&STAB
136 SymphHit 3 2 HIT&STAB
137 OrgTrnsplnt 2 HIT&STAB
138 Organ Hit 3 1 HIT&STAB
139 Organ Hit 4 2 HIT&STAB
140 Chord Hit 1 1 HIT&STAB
141 Chord Hit 2 2 HIT&STAB
142 Chord Hit 3 2 HIT&STAB
143 Chord Hit 4 1 HIT&STAB
144 Crystal Hit 2 HIT&STAB
145 Stamp Hit 2 HIT&STAB
146 ThousandHit 2 HIT&STAB
147 9th Hit 2 HIT&STAB
148 Slap Hit 1 2 HIT&STAB
149 Slap Hit 2 2 HIT&STAB
150 Dust Hit 2 HIT&STAB
151 Dist Hit 1 2 HIT&STAB
152 Dist Hit 2 2 HIT&STAB
153 Wah Hit 1 HIT&STAB
154 Tremble Hit 1 HIT&STAB
155 Dah Hit 2 HIT&STAB
156 Pretty Hit 2 HIT&STAB

When playing patches on the expansion board, we
recommend that you set all the EFFECTS ON/OFF settings
on the Fantom series/XV series to “ON.” If such settings are
set to “OFF,” you may not obtain the intended sound.

* When played by the XV-3080/88, Patches 46 and 70 will have the

number of voices indicated in parentheses.

* Note that the Release Time has been set to a fairly long value for

some of the patches. As a result, if your sound generator has been
set so “Patch Remain” is “ON,” the release portion of a
previously sounding patch may continue to be heard even after
switching to a new patch.

* Refer to the owner’s manual for your instrument for specific

instructions on how to play Patches on the expansion board.

* On the Fantom series/XV series/MX-200, you can not select only

the patches which are designed to be used with the RD series (with
SRX slots)/MC-909/VR-760/G-70.

* Some of the patch names shown in this list may appear differently

on the display of the device being used, but the tones themselves
remain unaffected.

6

エクスパンション・ボードのパッチを発音させるときは、
Fantom シリーズ /XV シリーズの EFFECTS ON/OFF の設
定をすべて ON にして使用することをお勧めいたします。
OFF に設定した場合、意図した音色にならないことがあり
ます。

※ No.46 と 70 のパッチは、XV-3080/88 で発音させるとき

は（ ）内のボイス数になります。
※ パッチの中にはリリース・タイムが長く設定してあるパッ

チもありますので、音源のパッチ・リメインが ＯＮ になっ

ていると音色を切り替えても前のパッチのリリースが残る

場合があります。

※ エクスパンション・ボードのパッチを発音させるときは、使

用機器の取扱説明書にしたがって、実行してください。

※ Fantom シリーズ /XV シリーズ /MX-200 では、RD シ

リーズ（SRX 対応）/MC-909/VR-760 専用のパッチを選

ぶことはできません。
※ 一部のパッチの名前が、本リストと使用機器の画面表示と

で異なる場合がありますが、音色自体に影響はありません。

Patch List (2)

For Fantom series/XV series/MX-200

(BANK SELECT MSB: 93; LSB: 4 [No.1–128], LSB: 5 [No.129–256], LSB: 6 [No.257–312])

No. Name Voices Category

157 Smoky Hit 2 HIT&STAB
158 Fist Hit 1 HIT&STAB
159 Clavy Hit 2 HIT&STAB
160 Tread Hit 1 HIT&STAB
161 Old Org Hit 1 HIT&STAB
162 Cave Hit 2 HIT&STAB
163 Thru Hit 1 HIT&STAB
164 Mull Hit 1 HIT&STAB
165 Electronica 1 HIT&STAB
166 Ripper 2 HIT&STAB
167 Bounce Hit1 2 HIT&STAB
168 Bounce Hit2 1 HIT&STAB
169 Hit OneShots 2 HIT&STAB
170 Brass Stab 5 TECHNO SYNTH
171 Null Zone 4 TECHNO SYNTH
172 Loop Techno 6 TECHNO SYNTH
173 Tribal RaveX 5 TECHNO SYNTH
174 Raverlisious 8 TECHNO SYNTH
175 2FingerRifff 8 TECHNO SYNTH
176 UK Garage 01 2 TECHNO SYNTH
177 UKgarage2002 7 TECHNO SYNTH
178 XV-303 1 TECHNO SYNTH
179 Psy-Tron 2 TECHNO SYNTH
180 House128bpm 7 TECHNO SYNTH
181 NewAcid Line 4 TECHNO SYNTH
182 Raver Saws 3 TECHNO SYNTH
183 Dist Saws 4 TECHNO SYNTH
184 BoosterBips2 2 TECHNO SYNTH
185 Auto 101 3 TECHNO SYNTH
186 BPF Sweep 4 TECHNO SYNTH
187 Elektrico 1 TECHNO SYNTH
188 What The ?? 4 TECHNO SYNTH
189 PlayEuroRiff 6 TECHNO SYNTH
190 MayhemAppegi 4 TECHNO SYNTH
191 AmbientTranz 2 TECHNO SYNTH
192 DanceStrSect 8 TECHNO SYNTH
193 5thIn4th Tri 4 TECHNO SYNTH
194 5th Vox 6 TECHNO SYNTH
195 Kompakt Voic 6 TECHNO SYNTH
196 Resound 2 TECHNO SYNTH
197 StrikeWhstle 1 TECHNO SYNTH
198 Rocket Blast 2 TECHNO SYNTH
199 Future Drain 5 BRIGHT PAD
200 Foilage 5 BRIGHT PAD
201 JP-8000 Pad 2 BRIGHT PAD
202 SynthChord01 3 BRIGHT PAD
203 PWM 4 BRIGHT PAD
204 Introductory 2 BRIGHT PAD
205 Miracle Pad 5 BRIGHT PAD
206 5th Sweep 2 3 BRIGHT PAD
207 Choir Sweep 3 BRIGHT PAD
208 Retro Pad 6 SOFT PAD

No. Name Voices Category

209 Beautiful:-] 6 SOFT PAD
210 Steam Pad 3 SOFT PAD
211 AggressiveLd 4 HARD LEAD
212 I know Juno 3 HARD LEAD
213 Def Lead 21 4 HARD LEAD
214 HiPass 3 HARD LEAD
215 DynaPulseLd 1 HARD LEAD
216 Dist Lead 2 HARD LEAD
217 80’s Memory 1 HARD LEAD
218 OD SyncLead 1 HARD LEAD
219 80’sTechLead 4 HARD LEAD
220 3-SquareLead 3 HARD LEAD
221 PortaSynLead 2 SOFT LEAD
222 Tri Lead 2 SOFT LEAD
223 Corrupt Sine 3 SOFT LEAD
224 Neonlight 2 SOFT LEAD
225 Higher&Highr 5 SOFT LEAD
226 Waspy Solo1 1 SOFT LEAD
227 Waspy Solo2 2 SOFT LEAD
228 Vib Sine 2 SOFT LEAD
229 Legato Saw 2 SOFT LEAD
230 Wet Saw Ld 2 SOFT LEAD
231 Dry BassLead 2 SOFT LEAD
232 PluckLead 1 SOFT LEAD
233 Comp Piano 2 1 AC.PIANO
234 a Tack Piano 4 AC.PIANO
235 Analog Piano 2 AC.PIANO
236 Tri EP 1 EL.PIANO
237 Pulsing EP 2 EL.PIANO
238 Cool EP 2 3 EL.PIANO
239 EP Chd Menu 1 EL.PIANO
240 EP Maj 9th 1 EL.PIANO
241 EP Maj 11th 1 EL.PIANO
242 EP Min 11th 1 EL.PIANO
243 NoisySynthEP 3 EL.PIANO
244 CompClav/Rls 2 KEYBOARDS
245 Comp Clavi 1 KEYBOARDS
246 HarmoOrg/Mod 3 ORGAN
247 ZigZag Organ 1 ORGAN
248 Notre Organ 4 ORGAN
249 SpectrumBell 3 BELL
250 Square Bell1 2 BELL
251 Square Bell2 3 BELL
252 ClnGtr Slide 2 EL.GUITAR
253 Gtr TrmDown 2 EL.GUITAR
254 Waw Chord 1 EL.GUITAR
255 Wha Wha Wha 8 EL.GUITAR
256 Wha De Da 4 EL.GUITAR
257 Fuzz Phaze 3 DIST.GUITAR
258 Ringmod Ting 3 DIST.GUITAR
259 BPF Strings 3 STRINGS
260 LoFiStringz 7 STRINGS

No. Name Voices Category

261 LightStrings 2 STRINGS
262 Flange Str 2 STRINGS
263 4th-LayerStr 6 STRINGS
264 LA Pizz 4 STRINGS
265 DanceClustor 6 STRINGS
266 CaveStrHit 2 STRINGS
267 StrChd Menu 2 STRINGS
268 StrScaleMaj 2 STRINGS
269 StrSpread 2 STRINGS
270 EuroBeat Brs 4 SYNTH BRASS
271 OB Brass 2 2 SYNTH BRASS
272 Funny Brass 2 SYNTH BRASS
273 Saws Brass 3 SYNTH BRASS
274 AnalogMaster 4 SYNTH BRASS
275 OneKeyMajor 8 AC.BRASS
276 Danz Braz 4 AC.BRASS
277 WindFX Menu 1 WIND
278 Flute FX 1 1 WIND
279 Flute FX 2 1 WIND
280 Flute FX 3 1 WIND
281 Sax FX 1 1 WIND
282 Sax FX 2 1 WIND
283 Sax FX 3 1 WIND
284 VINYL VOX 6 VOX
285 PsycheVocals 6 VOX
286 Vox Menu 1 VOX
287 Yeah F 1 VOX
288 Ho F 1 VOX
289 Oh F 1 VOX
290 Wow Yeah F 1 VOX
291 Ring Mod 2 SYNTH FX
292 Hydrolyze 4 SYNTH FX
293 Hydrolyze 2 7 SYNTH FX
294 Danger Zone 5 SYNTH FX
295 Danger Zone2 5 SYNTH FX
296 Horror 4 SYNTH FX
297 Space Scrach 4 SYNTH FX
298 OldSkool FX 4 SYNTH FX
299 Snare Bomb 4 SYNTH FX
300 CymbalMusic 4 SYNTH FX
301 Recollection 2 SYNTH FX
302 Dive Start ! 1 SOUND FX
303 DJ Mayhem 4 SOUND FX
304 TurnOff>Rev 2 SOUND FX
305 Scratch 4 1 SOUND FX
306 Scratch 5 1 SOUND FX
307 Scratch 6 1 SOUND FX
308 Scratch 7 1 SOUND FX
309 Scratch 8 1 SOUND FX
310 Scratch 9 1 SOUND FX
311 Scratch 10 1 SOUND FX
312 Vinyl Nz 1 SOUND FX

For All Instruments

(BANK SELECT MSB: 92; LSB: 4)

No RhythmName

1 PhatTrak Kit
2 Euro Kit
3 Urban Kit
4 Tight Kit
5 BitzOHitzKit
6 Intl.Tek Kit
7 GloblHousKit
8 BreakBts Kit
9 Trip Kit
10 Bright Kit
11 Soulful Kit
12 LiteStep Kit

Rhythm Set List

No RhythmName

13 4onFloorKit
14 Street Kit
15 Machine Kit
16 LoTek Kit
17 Solid Kit
18 TekTrio Kit
19 TekQuartoKit
20 Hit Menu
21 Kick Menu 1
22 Kick Menu 2
23 Snare Menu 1
24 Snare Menu 2

No RhythmName

25 Snare Menu 3
26 RimShot Menu
27 Tom Menu
28 HiHats Menu
29 Clap Menu
30 Cymbal Menu
31 Perc. Menu
32 FX Menu
33 SynPerc.Menu
34 All TR Menu

7

Patch List (3)

For RD series (with SRX slots)/MC-909/VR-760/G-70

(BANK SELECT MSB: 93; LSB: 4 [No.1–128], LSB: 5 [No.129–256], LSB: 6 [No.257–312])

No. Name Voices Category Tempo

1 SecretDancer 5 BEAT&GROOVE 120
2 Mean Streets 4 BEAT&GROOVE 80
3 E-tronic 4 BEAT&GROOVE 120
4 License2chil 8 BRIGHT PAD
5 Scratch Menu 1 SOUND FX
6 Hit Specials 2 HIT&STAB
7 Motivation 7 STRINGS
8 Sine Vibrato 1 SOFT LEAD
9 Acid Punch 2 SYNTH BASS
10 E.Gtr Menu 2 EL.GUITAR
11 Brite Flange 2 BRIGHT PAD
12 Dance Vibes 3 TECHNO SYNTH
13 LikeChordMem 4 PULSATING
14 Phatt 8 BEAT&GROOVE 80
15 DoubleDown 5 BEAT&GROOVE 80
16 LoopFX Dark 8 BEAT&GROOVE
17 Yo DJ 5 BEAT&GROOVE 89
18 HH Piledrivr 3 BEAT&GROOVE
19 Trush Head 2 BEAT&GROOVE 93
20 Rap 21 6 BEAT&GROOVE 96
21 Teknobeat 5 BEAT&GROOVE 120
22 Filter Beat 7 BEAT&GROOVE 120
23 FashionStyle 4 BEAT&GROOVE 120
24 Strobobeat 8 BEAT&GROOVE 135
25 SpaceGroove2 6 BEAT&GROOVE 124
26 Underground 4 BEAT&GROOVE 136
27 Extra Drive 4 BEAT&GROOVE
28 NakedPrey 3 BEAT&GROOVE 160
29 Mod It! 4 BEAT&GROOVE
30 Broken’Roll 2 COMBINATION
31 Drew Groove 4 COMBINATION 120
32 Beat Menu 2 BEAT&GROOVE
33 Sinewave Bs 1 SYNTH BASS
34 808 Bass 2 SYNTH BASS
35 Low Bass 2 4 SYNTH BASS
36 Low Bass 3 3 SYNTH BASS
37 Low Bass 4 4 SYNTH BASS
38 Hood Bass 2 2 SYNTH BASS
39 Rubber Bs 21 3 SYNTH BASS
40 Cheezee Bass 2 SYNTH BASS
41 Bend Bs /sw 2 SYNTH BASS
42 Saws Bass 4 SYNTH BASS
43 Bass Kadett 3 SYNTH BASS
44 Qube Bass 2 SYNTH BASS
45 LegatoSynBs 3 SYNTH BASS
46 15inch Bass 2 SYNTH BASS
47 MG Filter Bs 2 SYNTH BASS
48 Plk Bass 1 SYNTH BASS
49 Flat SawBass 3 SYNTH BASS
50 SH-101 Bass 2 SYNTH BASS
51 Pulsing Bs 2 SYNTH BASS
52 Arrpy 2 SYNTH BASS

Recommended

No. Name Voices Category

53 Acid Bass 2 1 SYNTH BASS
54 Euro Bass 21 2 SYNTH BASS
55 Unison Bass 4 SYNTH BASS
56 UnisonSwBass 2 SYNTH BASS
57 Dirty Bass 4 SYNTH BASS
58 Comp NzBass 3 SYNTH BASS
59 JunoDistBass 1 SYNTH BASS
60 TB Dist Bs 1 1 SYNTH BASS
61 TB Dist Bs 2 1 SYNTH BASS
62 TB Dist Bs 3 2 SYNTH BASS
63 Voxy Bass 3 SYNTH BASS
64 Interferenz 2 SYNTH BASS
65 16th SeqBass 4 SYNTH BASS
66 Woofer Blow 1 BASS
67 Guitaron Oct 1 BASS
68 Finger Bass6 1 BASS
69 Noisy P.Bass 3 BASS
70 FeelBass 3 BASS
71 FilterQ Bass 4 SYNTH BASS
72 FAT Rave 2 OTHER SYNTH
73 JUNO Rave 2 OTHER SYNTH
74 4 x Saws 4 OTHER SYNTH
75 Euro Saws 3 OTHER SYNTH
76 Super Sawz 4 OTHER SYNTH
77 Step Phaser 6 OTHER SYNTH
78 Vade Retro 2 OTHER SYNTH
79 Pulse Keys 4 OTHER SYNTH
80 P5 Pluck 2 OTHER SYNTH
81 Alpha Waves 4 OTHER SYNTH
82 Andes 5 OTHER SYNTH
83 Northern Pls 3 OTHER SYNTH
84 R&B Pluck 2 2 OTHER SYNTH
85 SynHarpsi 2 OTHER SYNTH
86 Saw Wave HQ 2 OTHER SYNTH
87 Sqr Wave HQ 2 OTHER SYNTH
88 JU2 Wave 1 2 OTHER SYNTH
89 JU2 Wave 2 2 OTHER SYNTH
90 Pulse Wave 1 2 OTHER SYNTH
91 Pulse Wave 2 2 OTHER SYNTH
92 SpectrumWave 2 OTHER SYNTH
93 Pure Sine 2 1 OTHER SYNTH
94 Slippers 4 OTHER SYNTH
95 Climb Maj7th 4 OTHER SYNTH
96 Return2Minor 8 OTHER SYNTH
97 FallingStar 3 OTHER SYNTH
98 Convulsions 2 PULSATING
99 CrazZzeee 4 PULSATING
100 Creative 5 PULSATING
101 Sweeping Sin 2 PULSATING
102 Epic Slice 4 PULSATING
103 Klang Werk 8 PULSATING
104 Ouverture 6 PULSATING

No. Name Voices Category

105 Talkativenes 3 PULSATING
106 Strained 4 PULSATING
107 Wicked DJ 2 5 PULSATING
108 Ultra Noise 3 PULSATING
109 JunoArpeggio 4 PULSATING
110 Autoarpeggio 8 PULSATING
111 SeqOctarveEP 4 PULSATING
112 Sync Vox 8 PULSATING
113 Stack Clavi 4 PULSATING
114 Pump up 3 PULSATING
115 Sine Seq 2 PULSATING
116 Seq Saws 4 PULSATING
117 Finale Hit 8 HIT&STAB
118 Big Hit 3 8 HIT&STAB
119 AnswerMe!Hit 4 HIT&STAB
120 LoungeLizard 7 HIT&STAB
121 Disco Stabs 8 HIT&STAB
122 12x12’sDisco 6 HIT&STAB
123 LittleDots 2 HIT&STAB
124 TribalTechno 4 HIT&STAB
125 Minor Bumwah 4 HIT&STAB
126 Bobs Slide 1 HIT&STAB
127 BrassHit 1 1 HIT&STAB
128 BrassHit 2 1 HIT&STAB
129 BrassHit 3 1 HIT&STAB
130 BrassHit 4 2 HIT&STAB
131 BrassHit 5 2 HIT&STAB
132 BrassHit 6 2 HIT&STAB
133 BrassHit 7 1 HIT&STAB
134 SymphHit 1 2 HIT&STAB
135 SymphHit 2 2 HIT&STAB
136 SymphHit 3 2 HIT&STAB
137 OrgTrnsplnt 2 HIT&STAB
138 Organ Hit 3 1 HIT&STAB
139 Organ Hit 4 2 HIT&STAB
140 Chord Hit 1 1 HIT&STAB
141 Chord Hit 2 2 HIT&STAB
142 Chord Hit 3 2 HIT&STAB
143 Chord Hit 4 1 HIT&STAB
144 Crystal Hit 2 HIT&STAB
145 Stamp Hit 2 HIT&STAB
146 ThousandHit 2 HIT&STAB
147 9th Hit 2 HIT&STAB
148 Slap Hit 1 2 HIT&STAB
149 Slap Hit 2 2 HIT&STAB
150 Dust Hit 2 HIT&STAB
151 Dist Hit 1 2 HIT&STAB
152 Dist Hit 2 2 HIT&STAB
153 Wah Hit 1 HIT&STAB
154 Tremble Hit 1 HIT&STAB
155 Dah Hit 2 HIT&STAB
156 Pretty Hit 2 HIT&STAB

* With some tones, tempos may change suddenly or noise may

be produced. This occurs when the tempo is being
synchronized, for example to multi-effects or chorus delay
times. If the noise becomes noticeable, change the delay time
value settings to something other than times corresponding to
beats.

* On the RD series (with SRX slots)/MC-909/VR-760/G-70,

you can not select only the patches which are designed to be
used with the Fantom series/XV series/MX-200.

* Some of the patch names shown in this list may appear

differently on the display of the device being used, but the
tones themselves remain unaffected.

8

※ 音色によっては、テンポを急激に変化させるとノイズが

出る場合があります。これは、マルチエフェクトやコー

ラスのディレイ・タイムなどがテンポに同期している場

合に発生します。ノイズが気になる場合は、ディレイ・

タイムなどの設定を音符以外の値に変更してください。

※ SRX 対応の RD シリーズ /MC-909/VR-760 では、

Fantom シリーズ /XV シリーズ /MX-200 専用のパッチ

を選ぶことはできません。

※ 一部のパッチの名前が、本リストと使用機器の画面表示

とで異なる場合がありますが、音色自体に影響はありま

せん。

Patch List (4)

For RD series (with SRX slots)/MC-909/VR-760/G-70

(BANK SELECT MSB: 93; LSB: 4 [No.1–128], LSB: 5 [No.129–256], LSB: 6 [No.257–312])

No. Name Voices Category

157 Smoky Hit 2 HIT&STAB
158 Fist Hit 1 HIT&STAB
159 Clavy Hit 2 HIT&STAB
160 Tread Hit 1 HIT&STAB
161 Old Org Hit 1 HIT&STAB
162 Cave Hit 2 HIT&STAB
163 Thru Hit 1 HIT&STAB
164 Mull Hit 1 HIT&STAB
165 Electronica 1 HIT&STAB
166 Ripper 2 HIT&STAB
167 Bounce Hit1 2 HIT&STAB
168 Bounce Hit2 1 HIT&STAB
169 Hit OneShots 2 HIT&STAB
170 Brass Stab 5 TECHNO SYNTH
171 Null Zone 4 TECHNO SYNTH
172 Loop Techno 5 TECHNO SYNTH
173 Tribal RaveX 5 TECHNO SYNTH
174 Dream in 3d 5 TECHNO SYNTH
175 Smooth House 4 TECHNO SYNTH
176 UK Garage 01 2 TECHNO SYNTH
177 UKgarage2002 7 TECHNO SYNTH
178 XV-303 1 TECHNO SYNTH
179 Psy-Tron 1 TECHNO SYNTH
180 House Chord2 4 TECHNO SYNTH
181 Velo Techno 2 TECHNO SYNTH
182 Raver Saws 3 TECHNO SYNTH
183 Dist Saws 4 TECHNO SYNTH
184 BoosterBips2 2 TECHNO SYNTH
185 Auto 101 3 TECHNO SYNTH
186 BPF Sweep 4 TECHNO SYNTH
187 Elektrico 1 TECHNO SYNTH
188 What The ?? 4 TECHNO SYNTH
189 PlayEuroRiff 6 TECHNO SYNTH
190 Voovtrigger 5 TECHNO SYNTH
191 AmbientTranz 2 TECHNO SYNTH
192 DanceStrSect 8 TECHNO SYNTH
193 5thIn4th Tri 4 TECHNO SYNTH
194 5th Vox 4 TECHNO SYNTH
195 Grainger 4 TECHNO SYNTH
196 Resound 2 TECHNO SYNTH
197 StrikeWhstle 1 TECHNO SYNTH
198 Rocket Blast 2 TECHNO SYNTH
199 Future Drain 5 BRIGHT PAD
200 Foilage 5 BRIGHT PAD
201 JP-8000 Pad 2 BRIGHT PAD
202 SynthChord01 3 BRIGHT PAD
203 PWM 4 BRIGHT PAD
204 Introductory 2 BRIGHT PAD
205 Miracle Pad 5 BRIGHT PAD
206 5th Sweep 2 3 BRIGHT PAD
207 Choir Sweep 3 BRIGHT PAD
208 Retro Pad 6 SOFT PAD

No. Name Voices Category

209 Twin Sqr Pad 2 SOFT PAD
210 Steam Pad 3 SOFT PAD
211 AggressiveLd 4 HARD LEAD
212 I know Juno 3 HARD LEAD
213 Def Lead 21 4 HARD LEAD
214 HiPass 3 HARD LEAD
215 DynaPulseLd 1 HARD LEAD
216 Dist Lead 2 HARD LEAD
217 Blistering 2 2 HARD LEAD
218 Talking Box2 3 HARD LEAD
219 80’sTechLead 4 HARD LEAD
220 3-SquareLead 3 HARD LEAD
221 PortaSynLead 2 SOFT LEAD
222 Tri Lead 2 SOFT LEAD
223 Corrupt Sine 3 SOFT LEAD
224 Neonlight 2 SOFT LEAD
225 Higher&Highr 5 SOFT LEAD
226 Waspy Solo1 1 SOFT LEAD
227 Waspy Solo2 2 SOFT LEAD
228 Vib Sine 2 SOFT LEAD
229 Legato Saw 2 SOFT LEAD
230 Wet Saw Ld 2 SOFT LEAD
231 Dry BassLead 2 SOFT LEAD
232 PluckLead 1 SOFT LEAD
233 Comp Piano 2 1 AC.PIANO
234 a Tack Piano 3 AC.PIANO
235 Analog Piano 2 AC.PIANO
236 Tri EP 1 EL.PIANO
237 Pulsing EP 2 EL.PIANO
238 Imitate EP 2 7 EL.PIANO
239 EP Chd Menu 1 EL.PIANO
240 EP Maj 9th 1 EL.PIANO
241 EP Maj 11th 1 EL.PIANO
242 EP Min 11th 1 EL.PIANO
243 NoisySynthEP 3 EL.PIANO
244 CompClav/Rls 1 KEYBOARDS
245 Comp Clavi 1 KEYBOARDS
246 HarmoOrg/Mod 3 ORGAN
247 ZigZag Organ 1 ORGAN
248 Notre Organ 4 ORGAN
249 SpectrumBell 3 BELL
250 Square Bell1 2 BELL
251 Square Bell2 3 BELL
252 ClnGtr Slide 2 EL.GUITAR
253 Gtr TrmDown 2 EL.GUITAR
254 Waw Chord 1 EL.GUITAR
255 Wha Wha Wha 8 EL.GUITAR
256 Wha De Da 4 EL.GUITAR
257 Fuzz Phaze 3 DIST.GUITAR
258 Ringmod Ting 3 DIST.GUITAR
259 BPF Strings 3 STRINGS
260 LoFiStringz 7 STRINGS

No. Name Voices Category

261 LightStrings 2 STRINGS
262 Flange Str 2 STRINGS
263 4th-LayerStr 6 STRINGS
264 LA Pizz 2 STRINGS
265 DanceClustor 6 STRINGS
266 CaveStrHit 2 STRINGS
267 StrChd Menu 2 STRINGS
268 StrScaleMaj 2 STRINGS
269 StrSpread 2 STRINGS
270 EuroBeat Brs 4 SYNTH BRASS
271 OB Brass 2 2 SYNTH BRASS
272 Funny Brass 2 SYNTH BRASS
273 Saws Brass 3 SYNTH BRASS
274 AnalogMaster 4 SYNTH BRASS
275 OneKeyMajor 8 AC.BRASS
276 Danz Braz 4 AC.BRASS
277 WindFX Menu 1 WIND
278 Flute FX 1 1 WIND
279 Flute FX 2 1 WIND
280 Flute FX 3 1 WIND
281 Sax FX 1 1 WIND
282 Sax FX 2 1 WIND
283 Sax FX 3 1 WIND
284 VINYL VOX 6 VOX
285 PsycheVocals 6 VOX
286 Vox Menu 1 VOX
287 Yeah F 1 VOX
288 Ho F 1 VOX
289 Oh F 1 VOX
290 Wow Yeah F 1 VOX
291 Evil Sweep 6 SYNTH FX
292 Hydrolyze 4 SYNTH FX
293 Hydrolyze 2 7 SYNTH FX
294 Danger Zone 5 SYNTH FX
295 Danger Zone2 5 SYNTH FX
296 Horror 4 SYNTH FX
297 Space Scrach 4 SYNTH FX
298 Noise Cycle 1 SYNTH FX
299 Snare Bomb 4 SYNTH FX
300 CymbalMusic 4 SYNTH FX
301 Recollection 2 SYNTH FX
302 Dive Start ! 1 SOUND FX
303 DJ Mayhem 4 SOUND FX
304 TurnOff>Rev 2 SOUND FX
305 Scratch 4 1 SOUND FX
306 Scratch 5 1 SOUND FX
307 Scratch 6 1 SOUND FX
308 Scratch 7 1 SOUND FX
309 Scratch 8 1 SOUND FX
310 Scratch 9 1 SOUND FX
311 Scratch 10 1 SOUND FX
312 Vinyl Nz 1 SOUND FX

* With some tones, tempos may change suddenly or noise may

be produced. This occurs when the tempo is being
synchronized, for example to multi-effects or chorus delay
times. If the noise becomes noticeable, change the delay time
value settings to something other than times corresponding to
beats.

* On the RD series (with SRX slots)/MC-909/VR-760/G-70,

you can not select only the patches which are designed to be
used with the Fantom series/XV series/MX-200.

* Some of the patch names shown in this list may appear

differently on the display of the device being used, but the
tones themselves remain unaffected.

※ 音色によっては、テンポを急激に変化させるとノイズが

出る場合があります。これは、マルチエフェクトやコー

ラスのディレイ・タイムなどがテンポに同期している場

合に発生します。ノイズが気になる場合は、ディレイ・

タイムなどの設定を音符以外の値に変更してください。

※ SRX 対応の RD シリーズ /MC-909/VR-760 では、

Fantom シリーズ /XV シリーズ /MX-200 専用のパッチ

を選ぶことはできません。

※ 一部のパッチの名前が、本リストと使用機器の画面表示

とで異なる場合がありますが、音色自体に影響はありま

せん。

9

Rhythm Set Key Assign (1)

For Fantom series/XV series/MX-200

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

1. PhatTrak
Kit

Gan Kick
Vinyl Kick
Dinky SD 3
Gan Kick
Lo-Tek SD
909 DryKick3
808 Dry CHH
Analog Kick2
R&B Kick 2
Deviant RM3
R&B SD 1
GospelClap
Cartn Boing1
Old LTom A2
Timba CHH
Old HTom B2
Jazz ClHH1 f
707 Dry LTom
Jazz OpHH mf
707 Dry MTom
707 Dry HTom
Pop Crash1
707 Dry HTom
PopRideCym 2
MG Nz Cym
707 Dry RD
Long Tamb
Pop SprshCym
Cwbl Hi
Pop Cym Roll
Cwbl Mute
808 Dry Cym4
LTBit CgH
LTBit CgL Hi
LTBit CgL Lo
Cartn Fall
Thumpkin 1
Thumpkin 2
StrChdMn11
Thru Hit 1
MG S Zap 3
Real Cabasa3
808 Dry Mrcs
Cartn Boing1
Cartn Boing2
Scratch 4
Scratch 5
Scratch 6
Scratch 7
Scratch 8
Scratch 13
Vinyl NzLp 2
MG S Zap 1
SH2 S Zap 1
MG NoiseHit
Press Hit
Ho F
Long Triangl
Sonar Hit
LoFi Coo
Dist Slide
Box Hit 2
Spoon Hit
LoFi Pod Hit
Rumble Hit
Fl Press Hit
US SweepD L1
WindChime Up
WindChime Dn
R8 Click
Metronome 1
Dry CHH 2
Dry OHH
909 Dry CHH2
909 Dry OHH2
UltrafunkCH1

2. Euro
Kit

Mellow Kick
L-RiderKick2
Cartn Fall
Layer Kick 1
Blade SD
909 DryKick1
909 Dry OHH1
909 DryKick3
Analog Kick2
Hop RimShot1
Gan SD mb
Lofi Clap3mb
Funk SD1
909 Dry LTom
Lulu CHH
808 Dry LTom
909 Dry CHH2
909 Dry MTom
909 Dry OHH1
808 Dry MTom
909 Dry HTom
909 Dry CR 2
808 Dry HTom
707 Dry RD
MG Nz Cym
909 Dry RD2
707 Dry Tamb
Pop Crash1
707 Dry Cwbl
707 Dry CR
Sonar Hit
808 Dry Cym4
HiConga Opn
HiConga Slap
HiConga Opn
Thmpkn>Slide
Vice Hit 1
Thumpkin
StrSprdMaj
Thru Hit 2
SH2 U Zap 3
Real Cabasa3
808 Dry Mrcs
Cartn Boing1
Cartn Boing2
US SweepU L2
MG SweepDn
US SweepD L2
Bobs Slide
Exhaust Hit
Clavy Hit
Oh F
Wow Yeah F
Whoo! M
BrassHit 22
Electronica
Ho F
Long Triangl
Long Guiro2
Howl Sync
Dist Slide
LoFi Bit 1
Spoon Hit
LoFi Pod Hit
Rumble Hit
US Metal 2
Ring FX 2
WindChime Up
WindChime Dn
R8 Click
Metronome 1
Dry CHH 2
Dry OHH
909 Dry CHH2
909 Dry OHH2
808 Dry CHH

3. Urban
Kit

808 DryKick5
Metal Kick
Snare Ghost
Old Kick
Snapy SD
Analog Kick2
Lo-Fi CHH 1
Layer Kick 6
Plump Kick
Metalic SD
Dinky SD 1
Clap Tail 2
LoBtHf SD2mb
SH2 S Zap 3
Comp CHH 1
SH2 S Zap 4
Lo-Fi CHH 2
SH2 S Zap 2
Lo-Fi OHH
MG S Zap 2
SH2 U Zap 1
Pop Crash1
MG S Zap 3
PopRideCym 1
WindChime Up
PopRideCym 2
Long Tamb
NzCym/AahHit
808 Dry Cwbl
Pop Cym Roll
707 Dry Cwbl
808 Dry Cym3
HiConga Opn
HiConga Slap
HiConga Cls
LoConga Opn
LoBongo Opn
Tmbl Lo Flm
Tmbl Hi Flm
Latin Hit
Cwbl Lo
Cwbl Lo
Real Shaker1
Real Shaker2
LoFi Bit 1
Long Guiro2
Short Guiro2
Nz Pass
MG NoiseHit
US SweepD S2
Swish Rope 3
LoFi Bit 1
US Metal 2
Bobs Slide
LoFi Bit 2
SH2 U Zap 6
909 DryKick1
GoGo SD mb
909 Dry SD1
Metal Atk Lo
Gruntoid SD
Cym Slide
909 Dry CHH1
Vice Hit 1
909 Dry CHH2
WindChime Up
909 Dry OHH1
Gtr & XRacer
RocketBrs
R8 Click
Metronome 1
You’re DJ M
Vinyl NzLp 1
Vinyl NzLp 2
Club SD1
Rocky SD 1

4. Tight
Kit

106 Kick 1
Filter Kick
Basis Rim
Craze Kick 3
Lo-Bit CStk
Layer Kick 1
R&B Crs Stk2
808 DryKick5
Old Kick 1
R&B Crs Stk1
R&B SD 1
Clap Tail 2
Alley SD1 mb
Old LTom B2
Mosaic CHH1S
Old LTom B1
Mosaic CHH1L
Old HTom B3
707 Dry OHH
Old HTom B2
Old HTom B3
Pop Crash2
Old HTom B2
PopRideCym 1
Pop SprshCym
PopRideCym 4
Long Tamb
Pop Cym Roll
808 Dry Cwbl
Pop ChinaCym
Long Guiro2
Light Kick 8
Vinyl Kick
Hop RimShot2
GoGo SD
St. FgSnap
Retro SD6
Cwbl Mute
Dry CHH 2S
Cwbl Lo
Dry CHH 2L
Dry CHH 1
Dry OHH
Real Cabasa3
LTBit CgL
707 Dry RSht
LTBit CgH
Single HClp1
Scratch 8
Scratch 4
Comp CHH 2
Scratch 12
Comp CHH 1
Scratch 7
Comp CHH 3
Vinyl NzLp 1
Blade Beat
808 Dry RSht
Rug Burn
MG SweepDn
Boss Club
X Racer
TrmDwnGtr2
BladeBeatRev
TrmDwnGtr1
BossClub Rev
Bobs Slide
R&Bees Rev
StrikeWhstle
R8 Click
Metronome 1
Flute Fx 3
Flute Fx 1
Flute Fx 2
ClnGtrRif2
ClnGtrRif1

5. BitzOHitz
Kit

PhraseMenu
BladeBt Kick
Basis Rim
R&Bees Kick
Lo-Bit CStk
Clubbin Kick
R&B Crs Stk2
US SweepD S1
BossClubKick
R&B Crs Stk1
Chord Hit 2
Clap Tail 2
Dist Hit 1
Bounce Hit2
Mosaic CHH1S
Chord Hit 2
Mosaic CHH1L
Chord Hit 4
707 Dry OHH
Chord Hit 3
Chord Hit 2
Pop Crash2
Chord Hit 1
PopRideCym 1
Pop SprshCym
Pop CymRollL
Long Tamb
Pop CymRollH
808 Dry Cwbl
Pop ChinaCym
Long Guiro2
Smoky Hit
Wah Hit
Hop RimShot2
Blowout
St. FgSnap
BrassHit 8
Cwbl Mute
Dry CHH 2S
Cwbl Lo
Dry CHH 2L
Dry CHH 1
Dry OHH
Real Cabasa3
Str Fall
707 Dry RSht
StrChdMin9
Single HClp1
Scratch 4
Scratch 5
Comp CHH 2
Scratch 13
Comp CHH 1
Scratch 14
Comp CHH 3
Vinyl NzLp 1
EP Chd&Voice
808 Dry RSht
EP Chd & Gtr
US SweepD L1
WahGtrCt3
WahGtrCt1
TrmDwnGtr2
ClnGtrRif2
TrmDwnGtr1
ClnGtrRif1
Bobs Slide
TrmDwnGtr1
WahGtrRif2
R8 Click
Metronome 1
Sax Fx 1
Sax Fx 2
Sax Fx 3
StrSprd&Bt
StrSprd&Bt R

6. Intl.Tek
Kit

Club Kick
Fat Kick
Lofi Clap3mb
ChickenKick2
Lulu CHH
Blade Kick
707&Long TB
106 Kick 2
Craze Kick 2
Club SD2 mb
Heat SD mb
Clap Tail 2
Hush SD mb
Tmbl HiPaila
Comp CHH 3
909 Dry MTom
808 Cl&OpHH
Layer SD8 mb
808 Dry Cym2
Basis Rim
808 Dry SD2
Crash 1
BigDreds SD
909 Dry RD2
808 Dry Cym1
Pop Crash1
Long Tamb
707 Dry CR
Dist Cowbell
PopRideCym 4
808 Dist CB
HiTune SD
909 Dry SD2
909 Dry Clap
909 Dry Clap
909 Dry Clap
Cartn Fall
Cym Slide
Lo-Bit CHH
Cartn Boing2
Voice Breath
Swish Rope 2
Clavy Hit
Sweep OHH
GummoKickRev
Org Click
Dist Chekele
Howl Sync
Craze Kick 2
JU2SpSub2
OSC Perc 1
US SweepU L1
Rocky SD3 mb
OSC Perc 2
Engine
Chord Hit
ClnGtr Hit
DistSymphHit
DistStrChord
Guitarrn&Sax
Brass Hit 18
Daw Hit
Brass Hit 21
SymphHit&Cym
Oh F
Yeah M
Oh F
Dist Oh F
Metronome 2
R8 Click
Metronome 1
Lo-Fi CHH1
Lo-Fi CHH2
Lo-Fi CHH3
UltrafunkCH1
Jiggle OHH

7. GloblHous
Kit

Dance Kick 8
808 Dry Clap
Filter SD2Hi
Dance Kick 5
Filter SD2Lo
Craze Kick 2
Long Tamb
909 DryKick1
Vinyl Kick
MG Nz Cym
Hush SD mb
707 Dry Clap
Devi RM1mb
909 Dry MTom
909 Dry CHH2
Dinky Kick 3
Snapy HH
GoGo SD mb
707 Dry OHH
Hush SD mb
909 Dry Clap
Crash 1
GospelClap
PopRideCym 4
Pop Crash1
Crash Cymbal
707 Dry Tamb
707 Dry RD
Car Pass
808 Dry Cym1
Org Click
Voice Breath
106 Kick 1
US SweepD L3
909 Dry SD5
Lofi Clap2mb
707 Dry SD1
707 Dry Clap
Lo-Bit CHH
808 Dry Clap
Comp CHH 3
909 Dry Clap
Comp OHH
909 Dry OHH1
HiBongo&OHH
LoConga Opn
Thumpkin
HiConga Opn
Osc&Cabasa
Tramp Hit
Warp Hit 3
Stamp Hit
Bounce Hit4
Hop RimShot3
SymphHit 3
Str Chd Hit
Brass Hit 16
Swanky Kick
Aah Hit
Metal&AahHit
PizzHit&Cym
StrChdMin9Hi
StrChdMin9Lo
Guitarrn&Sax
Yeah M
You’re DJ M
Yeah M
You’re DJ M
Metronome 2
R8 Click
Metronome 1
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

* On the Fantom series/XV series/MX-200, you can not select only the rhythm

sets which are designed to be used with the RD series (with SRX slots)/MC-909/
VR-760/G-70.

* Some of the rhythm tone names shown in this list may appear differently on the

display of the device being used, but the tones themselves remain unaffected.

10

※ Fantom シリーズ /XV シリーズ /MX-200では、RD シリーズ（SRX 対

応）/MC-909/VR-760 専用のリズム・セットを選ぶことはできません。

※ 一部のリズム・トーンの名前が、本リストと使用機器の画面表示とで異

なる場合がありますが、音色自体に影響はありません。

Rhythm Set Key Assign (2)

For Fantom series/XV series/MX-200

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

8. BreakBts
Kit

70s Kick 2
Swanky Kick
Lo-Fi CHH 2
Fuzz Kick
707 Dry SD2
Retro Kick 2
Filter SD3
Metal Kick
Craze Kick 3
Funk SD2
Devi RM1mb
Club SD3
Alley SD1 mb
808 Kick 1
808 Dry OHH1
808 Kick 2
808 Dry OHH3
808 Kick 3
909 Dry OHH2
808 Kick 4
ShredFuzzGtr
909 Dry CR 1
808 Cl&OpHH
909 Dry RD2
Rock CrCym1f
MG SweepDn
OSC Perc 2
Box Hit 2
OSC Perc 2
Pop Cym Roll
Lofi Clap3mb
Short FgSnap
WahHit&Tamb
Chekele 2
Pop Cym Roll
Chekele2
PopRideCym 4
Filter SD2
Layer SD2 mb
Retro SD6
Swish Rope 4
Ring FX 2
WahGtrChord
Clap Tail 2
LoBtHf SD3mb
LoBongo Opn
HiConga Opn
HiBongo Mute
Whoo! M
You’re DJ M
US SweepD S1
US SweepU L1
Cartn Boing1
Long Tamb
9thHit&Kick
Old SD6 mb
Tmbl Hi Roll
Long Tamb
707 Dry Clap
Pop Cym Roll
LTBit CgH
808 Dry Mrcs
WindChime Dn
Craze Kick 3
BS & 808OHH
808 Dry RSht
808 SN
Dance Kick
REV Timp3 pp
R8 Click
Metronome 2
Comp CHH 1
Comp CHH 2
Comp CHH 3
Lo-Tek HH1
Lo-Tek HH4

9. Trip
Kit

LoBit Kick 2
Dance Kick 8
Soul SD mb
Fuzz Kick
707 Dry SD2
Layer Kick 4
Retro SD5
Layer Kick 1
Analog Kick2
Layer SD8 mb
FilterSD5 mb
PFunkSD mb
GoGo SD mb
808 Kick L
Timba CHH
808 Kick H
Lo-Bit OHH
Scratch 15
909 Dry OHH2
Layer Kick 4
Rebo Kick 1
Lofi Clap2mb
LoBtHf SD3mb
Lofi Clap3mb
R&B SD 2
US SweepD L2
808 Dry CHH
Sonar Hit
808 Dry OHH1
Pop Cym Roll
707 Dry OHH
Real Cabasa3
909 Dry CR 2
Pop SprshCym
707 Dry RD
PopRideCym L
PopRideCym H
BrassHit 18
Aah Hit
Scratch 14 S
Metal Atk Lo
Scratch 14 L
WahGtrCt2
Scratch 14 H
Craze Kick 2
LTBit CgR Lo
Lofi Clap3mb
LTBit CgR Hi
Yeah M
TrmDwnGtr2
Hop RimShot1
Cartn Boing2
Cartn Boing1
ClvsLoP Lo
Scratch 9
Retro SD3
707 Dry Tamb
Long Tamb
909 Dry RD3
Pop Crash2
LTBit CgR
Long Triangl
ClvsLoP Hi
707 DryKick1
808 Dry OHH1
SparkleSD mb
808 SN
Dance Kick
REV Timp3 pp
R8 Click
Metronome 2
Mosaic CHH 1
Mosaic CHH 2
Mosaic CHH 3
UltrafunkCH1
UltrafunkOHH

10. Bright
Kit

FunkB Kick
Rebo Kick 2
Rebo SD2
Rebo Kick 1
Attack SD1
Dyna Kick
Dry CHH 1
Alley Kick 1
Layer Kick 3
Hop RimShot1
Filter SD3
Slipper Hit
Club SD1
Old LTom B2
Dry CHH 2
Old LTom B2
Dry CHH 3
Old LTom B2
Dry OHH
Old LTom B2
Old HTom B2
Pop Crash1
Old HTom B2
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Vice Hit 1
US Nz Cym
HiBongo Opn
LoBongo Opn
HiConga Slap
HiConga Opn
LoConga Opn
Tmbl Hi f
Tmbl Lo p
WindChime Dn
Short FgSnap
St. FgSnap
Thumpkin
Chekele 1
Rug Burn
Clubbin
X Racer
Blowout
Altr Hit
LoFi Hole
ThousandHit
Head Knd Clp
Tmbl Hi Rim
Tmbl Hi Roll
Real Shaker1
Real Shaker2
Real Shaker3
MG NoiseHit
Pod Hit
Latin Hit
Scratch 7
Scratch 8
Scratch 9
Scratch 10
Scratch 11
Scratch 12
Scratch 13
Scratch 14
Scratch 15
R8 Click
Metronome 1
Lo-Tek HH2
Lo-Tek HH1
Lo-Tek HH3
Lo-Tek HH4
Miami OHH

11. Soulful
Kit

Vinyl Kick
Soul Kick
R&B SD 1
Abuz Kick
R&B Crs Stk2
Old Kick 2
Lo-Tek HH2
R&B Kick 1
R&B Kick 2
R&B Crs Stk1
Lo-Bit SD 1
Buck Clap
Comp SD1 mb
Old LTom B1
Lulu CHH 1
Old LTom B1
Lulu CHH 2
Old LTom B1
Miami OHH
Old LTom B1
Old HTom B2
Pop Crash1
Old HTom B2
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Scratch 4
Scratch 5
Scratch 6
Scratch 9
Scratch 7
Scratch 8
WindChime Up
WindChime Dn
Short Tri
Long Triangl
Real Cabasa3
St. FgSnap
Crystal Hit
Warp Hit 6
Pod Hit
LoFi Pod Hit
Press Hit
Cartn Fall
LoFi Shaker
Wow Yeah F
Yeah F
Aow F
Oh F
Wah Hit
Organ Hit 2
OrgTrnsplnt
BrassHit 4
BrassHit 2
SymphHit 7
StrChdMn11
StrChdMin9
Str Fall
StrScaleMaj
ClnGtrRif1
ClnGtrRif2
TrmDwnGtr2
WahGtrCt4
R8 Click
Metronome 1
Lo-Tek HH2
Dry CHH 1
Dry CHH 2
Dry CHH 3
Dry OHH

12. LiteStep
Kit

MG Kick 1
808 DryKick5
Deviant RM3
808 DryKick5
Deviant RM1
808 DryKick5
Lo-Tek HH2
Filter Kick
909 DryKick1
Retro SD2 mb
Club SD3
707 Dry Clap
Hop RimShot1
707 Dry LTom
Mosaic CHH L
707 Dry LTom
Mosaic CHH H
707 Dry MTom
Miami OHH
707 Dry MTom
707 Dry HTom
Pop Crash1
707 Dry HTom
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Fall Bass
Lo-Bit CStk
Dinky SD 1
Lofi Clap3mb
LoBtHf SD3mb
Sim5 Tom4S
Noise CHH 1
Sim5 Tom3S
Noise PHH 1
Sim5 Tom2S
Noise OHH 1
Sim5 Tom1S
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
LoBongo Opn
HiBongo Mute
LoBongo Slap
Tmbl Hi f
Tmbl Lo p
Real Cabasa3
Real Shaker3
Organ Hit 1
Drain-O L
Old Org Hit
EP Maj 9th
Flute Fx 2
StrChdMn11
StrChdMin9
Ho F
Crystal Hit
LTBit CgH
Nz Pass
SH2 S Zap 2
SH2 S Zap 2
R8 Click
Metronome 1
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

13. 4onFloor
Kit

Gummo Kick 2
Blade Kick
909 Dry SD3
Light Kick 8
909 Dry SD4
Mellow Kick
Time OHH
L-RiderKick2
909 DryKick1
909 Dry RSht
909 Dry SD2
909 Dry Clap
909 SD&CLP
909 Dry LTom
909 Dry CHH1
909 Dry LTom
909 Dry CHH3
909 Dry MTom
909 Dry OHH2
909 Dry MTom
909 Dry HTom
909 Dry CR 2
909 Dry HTom
PopRideCym 2
Pop Crash2
909 Dry RD2
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Craze Kick 2
Basis Rim
106 SD2
Royal Clap
Retro SD5
Old LTom B2
Chill CHH
Old LTom B2
Chill CHH
Old HTom B2
Miami OHH
Old HTom B2
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
LoBongo Opn
HiBongo Mute
LoBongo Slap
Tmbl Hi f
Tmbl Lo p
Tmbl Hi Flm
Tmbl Lo Flm
Tmbl Hi Roll
Tmbl HiPaila
Latin Hit
BrassHit 10
BrassHit 11
StrChdMn11
StrChdMin9
WahGtrRif1
WahGtrRif2
WahGtrCt3
WahGtrCt2
WahGtrCt1
WahGtrChord
R8 Click
Metronome 1
909 HPF CHH1
909 HPF CHH2
909 HPF CHH3
909 HPF OHH1
909 HPF OHH2

14. Street
Kit

Hybrid Kick3
Vinyl Kick
HipHop SD 1
Layer Kick 4
Lo-Bit SD 1
Layer Kick 1
Lo-Bit CHH
L-RiderKick2
FunkB Kick
Hop RimShot1
Dinky SD 1
Single HClp1
Snapy SD
Retro Tom2
Mosaic CHH 2
Retro Tom2
Mosaic CHH 1
Retro Tom1
Comp OHH
Retro Tom1
Retro Tom1
Pop Crash1
Retro Tom1
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Scratch 4
Scratch 5
Scratch 6
Scratch 7
Scratch 8
Scratch 9
Scratch 10
Scratch 11
Scratch 12
Scratch 13
Scratch 14
Scratch 15
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
LoBongo Opn
HiBongo Mute
LoBongo Slap
Tmbl Hi f
Tmbl Lo p
Real Cabasa3
Real Shaker3
BrassHit 2
BrassHit 15
BrassHit 19
BrassHit 5
Dust Hit L
StrChdMn11
StrChdMin9
SymphHit 7
Sax Fx 1
Com’on M
Whoo! M
You’re DJ M
Vinyl NzLp 1
R8 Click
Metronome 1
Lo-Fi CHH1
Lo-Fi CHH2
Lo-Fi CHH3
UltrafunkCH1
Jiggle OHH

* On the Fantom series/XV series/MX-200, you can not select only the rhythm

sets which are designed to be used with the RD series (with SRX slots)/MC-909/
VR-760/G-70.

* Some of the rhythm tone names shown in this list may appear differently on the

display of the device being used, but the tones themselves remain unaffected.

※ Fantom シリーズ /XV シリーズ /MX-200では、RD シリーズ（SRX 対

応）/MC-909/VR-760 専用のリズム・セットを選ぶことはできません。

※ 一部のリズム・トーンの名前が、本リストと使用機器の画面表示とで異

なる場合がありますが、音色自体に影響はありません。

11

Rhythm Set Key Assign (3)

For Fantom series/XV series/MX-200

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

15. Machine
Kit

106 Kick 1
Craze Kick 1
707 Dry SD2
Alley Kick 1
Noisy SD
909 DryKick3
808 Cl&OpHH
106 Kick 2
909 DryKick1
Hop RimShot2
909 Dry SD2
Clap Tail 2
909 Dry Clap
707 Dry LTom
909 Dry CHH1
707 Dry LTom
909 Dry OHH1
707 Dry MTom
909 Dry OHH2
707 Dry MTom
707 Dry HTom
909 Dry CR 2
707 Dry HTom
909 Dry RD3
MG Nz Cym
Nz SweepTone
Long Tamb
LoFi Moan
LoTek Bit
LoFi Bit 1
LoFi Hole
LoFi Bit 2
Craze Kick 2
808 Dry RSht
808 Dry SD1
808 Dry Clap
808 Dry SD2
808 Dry LTom
808 Dry CHH
808 Dry LTom
808 Cl&OpHH
808 Dry MTom
808 Dry OHH3
808 Dry HTom
OSC Perc 1
US SweepD L3
OSC Perc 1
Ring FX 2
Ring FX 1
MG SweepDn
MG S Zap 3
SH2 S Zap 1
SH2 S Zap 2
SH2 S Zap 3
SH2 S Zap 4
SH2 S Zap 5
Warp Hit 7
Mull Hit
Warp Hit 8
Bounce Hit4
Chord Hit 4
Electric Saw
Dist Slide
Howl Sync
Metal Atk Lo
Metal Atk Hi
Thumpkin
LoFi Coo
Sonar Hit
R8 Click
Metronome 1
Lo-Tek HH2
Lo-Tek HH1
Lo-Tek HH3
Lo-Tek HH4
Jiggle OHH

16. LoTek
Kit

106 Kick 2
Craze Kick 2
LoBtHf SD3mb
Lo-Tek Kick
LoBtHf SD4mb
ChickenKick1
Time OHH
LoBit Kick 1
LoBit Kick 2
Lo-Bit CStk
Lo-Bit SD 2
Clap Tail 2
Lo-Bit SD 1
Retro Tom2
Lo-Bit CHH
Retro Tom2
Lo-Bit CHH
Retro Tom1
Lo-Bit OHH
Retro Tom1
Retro Tom1
909 Dry CR 2
Retro Tom1
PopRideCym 2
Pop Crash2
909 Dry RD2
Long Tamb
Pop Cym Roll
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Hybrid Kick3
Deviant RM3
Filter SD3
Lofi Clap3mb
Dinky SD 1
Old HTom A3
Miami OHH
Old HTom A3
Time OHH
Old HTom A3
UltrafunkOHH
Old HTom A3
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
Tmbl Hi f
Tmbl Lo p
Tmbl Hi Flm
Tmbl Lo Flm
Tmbl Hi Roll
Tmbl HiPaila
Latin Hit
Tramp Hit
Bounce Hit4
Warp Hit 6
Ring FX 2
Ripper
Cave Hit
LoFi Hole
LoFi Coo
LoFi Bit 1
LoFi Bit 2
LoTek Bit
LTBit CgH
LTBit CgL
R8 Click
Metronome 1
Comp CHH 1
Comp CHH 2
Comp CHH 3
Lo-Tek HH1
Lo-Tek HH4

17. Solid
Kit

Metal Kick
Croak Kick 1
Pump SD
Blade Kick
Blade SD
Fuzz Kick
Mosaic CHH 1
Alley Kick 1
Metal Kick
HopRimshot 2
Attack SD1
Clap Tail 2
Attack SD4
808 Dry LTom
Chill CHH
707 Dry LTom
UltrafunkCH1
808 Dry MTom
Jiggle OHH
707 Dry MTom
808 Dry HTom
909 Dry CR 1
707 Dry HTom
909 Dry RD1
MG Nz Cym
US Nz Cym
707 Dry Tamb
Pop SprshCym
707 Dry Cwbl
Pop ChinaCym
808 Dry Cwbl
808 Dry Cym4
Gummo Kick 2
US Metal 2
Metal Atk Lo
US Metal 1
Metal Atk
SH2 U Zap 6
Noise CHH 2
SH2 U Zap 5
Noise PHH 2
SH2 U Zap 4
Noise OHH 2
SH2 U Zap 2
Ring FX 1
Electronica
Howl Sync
Dist Slide
Thumpkin Rev
Cave Hit
Flute Fx 1
Flute Fx 2
Flute Fx 3
Sax Fx 1
Sax Fx 2
Sax Fx 3
BrassHit 5
BrassHit 12
BrassHit 16
BrassHit 20
Tremble Hit
Aah Hit
Exhaust Hit
Blade Beat
R&Bees
Rug Burn
Boss Club
Clubbin
X Racer
R8 Click
Metronome 1
Lo-Tek HH2
Dry CHH 1
Dry CHH 2
Dry CHH 3
Dry OHH

18. TekTrio
Kit

Gummo Kick 1
MG Kick 2
MG S Zap 2
MG Kick 1
MG S Zap 1
Alley Kick 2
Dry OHH
LoBit Kick 1
707 DryKick1
Lo-Bit CStk
Funk SD1
Head Knd Clp
Lo-Bit SD 1
Sim5 Tom4S
Dry CHH 1
Sim5 Tom4F
Dry CHH 1
Sim5 Tom3S
Dry OHH
Sim5 Tom3F
Sim5 Tom2S
Pop Crash1
Sim5 Tom2F
Pop Crash2
Sim5 Tom1S
Sim5 Tom1F
Long Tamb
Pop SprshCym
Res NzPerc S
Pop ChinaCym
Res NzPerc L
Noise Attack
R&B Kick 2
US Nz Cym
Retro SD 1
MG NoiseHit
Retro SD3
Retro Tom2
Lulu CHH
US SweepD S2
Lulu PHH
US SweepD S1
Lo-Bit OHH
US SweepD L2
US SweepD L1
US Metal 2
US SweepU L2
US Metal 1
US SweepU L1
SH2 S Zap 5
SH2 S Zap 1
SH2 S Zap 2
SH2 S Zap 3
SH2 S Zap 4
SH2 U Zap 4
SH2 U Zap 5
808 Dry Clap
808 Dry Mrcs
808 Dry RSht
808 Dry Clvs
808 Dry Cwbl
808 Dry Lcng
808 Dry CHH
808 Dry Mcng
808 Cl&OpHH
808 Dry Hcng
808 Dry OHH3
707 Dry Tamb
707 Dry Cwbl
R8 Click
Metronome 1
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

19. TekQuarto
Kit

808 DryKick2
808 DryKick3
SH2 S Zap 1
MG Kick 2
SH2 S Zap 2
MG Kick 1
808 Cl&OpHH
707 DryKick1
808 DryKick5
808 Dry RSht
808 Dry SD1
Head Knd Clp
SH2 S Zap 3
808 Dry LTom
808 Dry CHH
808 Dry LTom
808 Cl&OpHH
808 Dry MTom
808 Dry OHH3
808 Dry MTom
808 Dry HTom
808 Dry Cym2
808 Dry HTom
808 Dry Cym3
MG Nz Cym
909 Dry RD2
Long Tamb
Pop SprshCym
808 Dry Cwbl
Pop ChinaCym
Long Triangl
808 Dry Cym4
909 DryKick1
909 Dry RSht
Clap Tail 2
909 Dry Clap
Attack SD1
909 Dry LTom
Noise CHH 3
909 Dry LTom
Noise PHH 3
909 Dry MTom
Noise OHH 3
909 Dry HTom
Nz Flang SD
MG S Zap 3
Slipper Hit
Spoon Hit
Metal Atk Lo
Metal Atk Hi
Sonar Hit
Vice Hit 2
Vice Hit 3
Box Hit 2
Cartn Boing1
Cartn Boing2
LTBit CgL
LTBit CgH
LoTek Bit
LoFi Hole
LoFi Bit 1
Thru Hit 1
Thru Hit 2
Electronica
Ho F
Yeah F
Clavy Hit
Ring FX 2
Ring FX 1
R8 Click
Metronome 1
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

20. Hit
Menu

Bobs Slide
BrassHit 18
BrassHit 19
SymphHit 3
Altr Hit
Crystal Hit
Dirty Hit 2
Iron Hit 2
Clavy Hit
Warp Hit 1
Warp Hit 2
Warp Hit 3
Warp Hit 4
Cave Hit
Warp Hit 6
Thru Hit 2
Thru Hit 1
Mull Hit
Warp Hit 7
Warp Hit 8
Electronica
Ripper
Warp Hit 9
Tickle Hit
PercolateHit
Tramp Hit
Bounce Hit1
Bounce Hit2
Warp Hit 5
ParabolaHit
Smoky Hit
Fist Hit
BrassHit 1
BrassHit 2
BrassHit 4
BrassHit 6
BrassHit 8
BrassHit 7
BrassHit 13
BrassHit 23
SymphHit 7
SymphHit 5
OrgTrnsplnt
Organ Hit 2
Chord Hit 3
Chord Hit 4
Exhaust Hit
Scoop Hit
Stamp Hit
9th Hit
Dust Hit
Dist Hit 2
Sweep Hit
Daw Hit
Tread Hit
Bounce Hit3
Bounce Hit4
BrassHit 21
Slap Hit 1
Slap Hit 2
Organ Hit 1
Old Org Hit
BrassHit 10
BrassHit 11
StrSprdMaj
StrSprdMin
StrChdMn11
StrChdMin9
BrassHit 20
BrassHit5
Brass Hit 9
BrassHit 16
ThousandHit
Chord Hit 1
Tremble Hit
SymphHit 1

21. Kick
Menu 1

--

--

--

--

--

--

--

--

R&B Kick 1
Old Kick 1
Old Kick 2
Metal Kick
Old Kick 3
Rebo Kick 1
Abuz Kick
Cool Kick 1
Dyna Kick
Floor Kick
Gan Kick
GoGo Kick
Livn Kick
Old Kick 4
Mellow Kick
Two Kick
Gummo Kick 1
Gummo Kick 2
R&B Kick 2
Alley Kick 2
FunkB Kick
Light Kick 1
Light Kick 2
Light Kick 3
Light Kick 4
Light Kick 6
H-Rider Kick
Layer Kick 1
Layer Kick 2
Layer Kick 3
Layer Kick 4
Retro Kick 1
Retro Kick 2
Pump Kick
Heavy Kick 1
Heavy Kick 2
Heavy Kick 3
Heavy Kick 4
Layer Kick 5
Shake Kick
Rebo Kick 2
Chop Kick
Light Kick 9
Soul Kick
Trip Kick
Vinyl Kick
Club Kick
Dinky Kick 1
Dinky Kick 3
Dinky Kick 4
Slopey Kick1
Junk Kick
Motor Kick
Layer Kick 6
Dance Kick 7
BigDrds Kick
DeeBee Kick

--

--

--

--

--

--

--

--

--

--

--

* On the Fantom series/XV series/MX-200, you can not select

only the rhythm sets which are designed to be used with the
RD series (with SRX slots)/MC-909/VR-760/G-70.

12

※ Fantom シリーズ /XV シリーズ /MX-200 では、RD シ

リーズ（SRX 対応）/MC-909/VR-760 専用のリズム・
セットを選ぶことはできません。

Rhythm Set Key Assign (4)

For Fantom series/XV series/MX-200

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

22. Kick
Menu 2

--

--

--

--

--

--

--

--

LoBit Kick 1
LoBit Kick 2
Narrow Kick
Alley Kick 1
L-RiderKick1
Light Kick 5
Light Kick 7
L-RiderKick2
Light Kick 8
ChickenKick1
Edge Kick
Buck Kick
Ambi Kick
Cbell Kick
Tamb Kick
Cool Kick 2
Seiz Kick
Lo-Tek Kick
Filter Kick
Blade Kick
Dinky Kick 2
Old Kick 5
Hybrid Kick3
707 DryKick1
707 DryKick2
808 DryKick1
808 DryKick2
808 DryKick3
808 DryKick4
808 DryKick5
Analog Kick1
Analog Kick2
909 DryKick3
909 DryKick2
909 DryKick1
Craze Kick 1
Craze Kick 2
106 Kick 1
106 Kick 2
MG Kick 1
MG Kick 2
Fat Kick
Croak Kick 1
Fuzz Kick
ChickenKick2
Craze Kick 3
Craze Kick 4
Plump Kick
Deviant Kick
Dance Kick 5
Dance Kick 6
Dance Kick 8
Slopey Kick2
Swanky Kick
SnugBugaKick
Synth Kick

--

--

--

--

--

--

--

--

--

--

--

--

23. Snare
Menu 1

--

--

--

--

--

--

--

--

HipHop SD 1
R&B SD 1
Lo-Bit SD 1
Basis SD 1
Gruntoid SD
L-Rider SD
Craze SD 1
R&B SD 2
Lo-Bit SD 2
Dinky SD 1
Dinky SD 2
Dinky SD 3
Basis SD 2
Basis SD 3
Retro SD 1
Snapy SD
Rocky SD1
Rocky SD1 mb
Rocky SD2 mb
Rocky SD3 mb
Club SD1
Club SD2 mb
Club SD3
Club SD3 mb
Comp SD1 mb
Comp SD2 mb
Rev SD mb
LoBtHf SD1mb
LoBtHf SD2mb
LoBtHf SD3mb
LoBtHf SD4mb
LoBtHf SD5mb
LoBtHf SD6mb
Light SD1
Light SD1 mb
Light SD2
Light SD2 mb
Alley SD1
Alley SD1 mb
H-Rider SD
Slopey SD
Gan SD mb
MellowSD mb
MGT SD mb
Old SD1 mb

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

24. Snare
Menu 2

--

--

--

--

--

--

--

--

Old SD2 mb
Old SD3 mb
Old SD4 mb
Old SD5 mb
Attack SD1
Retro SD1
Retro SD3
Retro SD4
Retro SD5
Retro SD6
Layer SD1 mb
Attack SD3
Lo-Tek SD
Filter SD3
Filter SD4
Retro SD7
Retro SD8
Funky SD
Layer SD3
Heat SD mb
Cool SD
GoGo SD
Soul SD mb
Layer SD6
Vynil SD mb
Hop RimShot3
Blade SD
Metalic SD
Noisy SD
Pump SD
Basis SD 4
HiTune SD
Thin SD
Thin SD mb
Slim SD
BigDreds SD
PFunkSD mb
GoGo SD mb
Retro SD2 mb
Hybrid SD mb
DeeBee SD
Old SD6 mb
Layer SD2 mb
Filter SD1
Filter SD2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

25. Snare
Menu 3

--

--

--

--

--

--

--

--

Attack SD2
Attack SD4
Layer SD5 mb
Ultra SD 1
Ultra SD 2
Layer SD4 mb
Alley SD2
Alley SD2 mb
Fella SD1 mb
Fella SD2
Fella SD2 mb
Rebo SD1
Rebo SD1 mb
Rebo SD2
Swush SD mb
Chicken SD
Funk SD1
Funk SD2
Dinky SD4 mb
Layer SD7 mb
Layer SD8 mb
Layer SD9 mb
FilterSD5 mb
Junk SD mb
Clappy SD
Cranky SD
Grim SD
Sparkle SD
SparkleSD mb
Hush SD mb
707 Dry SD1
707 Dry SD2
808 Dry SD1
808 Dry SD2
808 Dry SD3
909 Dry SD1
909 Dry SD4
909 Dry SD5
909 Dry SD3
909 Dry SD2
909 SD&CLP
106 SD1
106 SD2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

26. RimShot
Menu

--

--

--

--

--

--

--

--

R&B Crs Stk1
R&B Crs Stk2
Lo-Bit CStk
707 Dry RSht
808 Dry RSht
909 Dry RSht
Basis Rim
Basis Rim mb
Deviant RM1
Devi RM1mb
Deviant RM2
Deviant RM3
Devi RM3mb
Hop RimShot1
Hop RimShot2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

27. Tom
Menu

--

--

--

--

--

--

--

--

Old HTom A1
Old HTom A2
Old HTom A3
Old LTom A1
Old LTom A2
Old HTom B1
Old HTom B2
Old HTom B3
Old LTom B1
Old LTom B2
Retro Tom1
Retro Tom2
Sim5 Tom1S
Sim5 Tom1F
Sim5 Tom2S
Sim5 Tom2F
Sim5 Tom3S
Sim5 Tom3F
Sim5 Tom4S
Sim5 Tom4F
707 Dry HTom
707 Dry MTom
707 Dry LTom
808 Dry HTom
808 Dry MTom
808 Dry LTom
909 Dry HTom
909 Dry MTom
909 Dry LTom

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

28. HiHats
Menu

--

--

--

--

--

--

--

--

Lo-Tek HH1
Lo-Tek HH2
Lo-Tek HH3
Lo-Tek HH4
Lo-Bit CHH
Dry CHH 1
Dry CHH 2
Dry CHH 3
Comp CHH 1
Comp CHH 2
Comp CHH 3
Lo-Fi CHH 1
Lo-Fi CHH 2
Lo-Fi CHH 3
Timba CHH
Chill CHH
Mosaic CHH 1
Mosaic CHH 2
Mosaic CHH 3
UltrafunkCH1
UltrafunkCH2
Miami CHH
Lulu CHH
707 Dry CHH
808 Dry CHH
808 Cl&OpHH
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
Miami OHH
Time OHH
UltrafunkOHH
Jiggle OHH
Lo-Bit OHH
Dry OHH
Comp OHH
Lo-Fi OHH
707 Dry OHH
808 Dry OHH1
808 Dry OHH2
808 Dry OHH3
909 Dry OHH1
909 Dry OHH2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

* On the Fantom series/XV series/MX-200, you can not select

only the rhythm sets which are designed to be used with the
RD series (with SRX slots)/MC-909/VR-760/G-70.

※ Fantom シリーズ /XV シリーズ /MX-200 では、RD シ

リーズ（SRX 対応）/MC-909/VR-760 専用のリズム・
セットを選ぶことはできません。

13

Rhythm Set Key Assign (5)

For Fantom series/XV series/MX-200

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

29. Clap
Menu

--

--

--

--

--

--

--

--

Single HClp1
Single HClp2
Single HClp3
Real Clap
Lofi Clap1mb
Lofi Clap2mb
Lofi Clap3mb
Buck Clap
Head Knd Clp
Royal Clap
Clap Tail 2
GospelClap
707 Dry Clap
808 Dry Clap
909 Dry Clap

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

30. Cymbal
Menu

--

--

--

--

--

--

--

--

Pop Crash1
Pop Crash2
Pop SprshCym
Pop ChinaCym
Pop Cym Roll
707 Dry CR
909 Dry CR 1
909 Dry CR 2
909 Dry CR 3
PopRideCym 1
PopRideCym 2
PopRideCym 3
PopRideCym 4
707 Dry RD
808 Dry Cym1
808 Dry Cym2
808 Dry Cym3
808 Dry Cym4
909 Dry RD1
909 Dry RD2
909 Dry RD3
MG Nz Cym
US Nz Cym

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

31. Perc.
Menu

--

--

--

--

--

--

--

--

WindChime Up
WindChime Dn
Cwbl Lo
Cwbl Hi
Cwbl Mute
707 Dry Cwbl
808 Dry Cwbl
808 Dry Clvs
Clvs Hi
Clvs Lo
HiBongo Opn
HiBongo Mfld
HiBongo 2
HiBongo Slp1
HiBongo Slp2
HiBongo Mute
LoBongo Opn
LoBongo Slap
808 Dry Hcng
808 Dry Mcng
808 Dry Lcng
LTBit CgH
LTBit CgL
HiConga Opn
HiConga Slap
HiConga Cls
LoConga Opn
Tmbl Hi p
Tmbl Hi f
Tmbl Hi Rim
Tmbl Hi Flm
Tmbl Hi Roll
Tmbl HiPaila
Tmbl Lo p
Tmbl Lo Flm
Latin Hit
Chekele 1
Chekele 2
Real Shaker1
Real Shaker2
Real Shaker3
Real Cabasa3
808 Dry Mrcs
Short Guiro2
Long Guiro2
Long Tamb
707 Dry Tamb
Short Tri
Long Triangl
Short FgSnap
St. FgSnap

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

32. FX
Menu

--

--

--

--

--

--

--

--

Electric Saw
Cartn Fall
Cartn Boing1
Cartn Boing2
LoTek Bit
LoFi Hole
LoFi Coo
LoFi Bit 1
LoFi Bit 2
Nz Pass
Thumpkin
Dist Slide
Howl Sync
Slipper Hit
Spoon Hit
Pod Hit
LoFi Shaker
Box Hit 1
Hard Shaker
LoFi Pod Hit
Press Hit
Swish Hit
Rumble Hit
Cym Slide
Knock Hit 1
Knock Hit 2
Swish Rope 1
Swish Rope 2
Swish Rope 3
Swish Rope 4
Metal Atk Lo
Metal Atk
Fl Press Hit
Dump Hit
Vice Hit 1
Vice Hit 2
Vice Hit 3
Box Hit 2
Flute Fx 1
Flute Fx 2
Flute Fx 3
Sax Fx 1
Sax Fx 2
Sax Fx 3
Whoo! M
You’re DJ M
Groove M
Com’on M
Yeah M
Wow Yeah F
Yeah F
Ho F
Aow F
Oh F
Scratch 4
Scratch 5
Scratch 6
Scratch 7
Scratch 8
Scratch 9
Scratch 10
Scratch 11
Scratch 12
Scratch 13
Scratch 14
Scratch 15
Vinyl NzLp 1
Vinyl NzLp 2

33. SynPerc.
Menu

--

--

--

--

--

--

--

--

US Metal 2
US Metal 1
OSC Perc 2
OSC Perc 1
MG NoiseHit
SH2 S Zap 1
SH2 S Zap 2
SH2 S Zap 3
SH2 S Zap 4
SH2 S Zap 5
MG S Zap 1
MG S Zap 2
MG S Zap 3
SH2 U Zap 1
SH2 U Zap 2
SH2 U Zap 3
SH2 U Zap 4
SH2 U Zap 5
SH2 U Zap 6
Ring FX 1
Ring FX 2
US SweepD L1
US SweepD S1
US SweepD L2
US SweepD S2
US SweepD L3
MG SweepDn
US SweepU L1
US SweepU L2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

34. All TR
Menu

--

--

--

--

--

--

--

--

707 DryKick1
707 DryKick2
707 Dry SD1
707 Dry SD2
707 Dry LTom
707 Dry MTom
707 Dry HTom
707 Dry RSht
707 Dry Cwbl
707 Dry Clap
707 Dry Tamb
707 Dry CHH
707 Dry OHH
707 Dry CR
707 Dry RD
808 DryKick1
808 DryKick2
808 DryKick3
808 DryKick4
808 DryKick5
808 Dry SD1
808 Dry SD2
808 Dry SD3
808 Dry LTom
808 Dry MTom
808 Dry HTom
808 Dry Lcng
808 Dry Mcng
808 Dry Hcng
808 Dry RSht
808 Dry Clvs
808 Dry Mrcs
808 Dry Clap
808 Dry Cwbl
808 Dry Cym1
808 Dry Cym2
808 Dry Cym3
808 Dry Cym4
808 Dry CHH
808 Cl&OpHH
808 Dry OHH1
808 Dry OHH2
808 Dry OHH3
909 DryKick3
909 DryKick2
909 DryKick1
909 Dry SD1
909 Dry SD4
909 Dry SD3
909 Dry SD5
909 Dry SD2
909 SD&CLP
909 Dry LTom
909 Dry MTom
909 Dry HTom
909 Dry RSht
909 Dry Clap
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2
909 Dry CR 1
909 Dry CR 2
909 Dry CR 3
909 Dry RD1
909 Dry RD2
909 Dry RD3

* On the Fantom series/XV series/MX-200, you can not select

only the rhythm sets which are designed to be used with the
RD series (with SRX slots)/MC-909/VR-760/G-70.

14

※ Fantom シリーズ /XV シリーズ /MX-200 では、RD シ

リーズ（SRX 対応）/MC-909/VR-760 専用のリズム・
セットを選ぶことはできません。

Rhythm Set Key Assign (6)

For RD series (with SRX slots)/MC-909/VR-760/G-70

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

1. PhatTrak
Kit

Gan Kick
Vinyl Kick
Dinky SD 3
Gan Kick
Lo-Tek SD
909 DryKick3
808 Dry CHH
Analog Kick2
R&B Kick 2
Deviant RM3
R&B SD 1
GospelClap
Cartn Boing1
Old LTom A2
Timba CHH
Old HTom B2
Jazz ClHH1 f
707 Dry LTom
Jazz OpHH mf
707 Dry MTom
707 Dry HTom
Pop Crash1
707 Dry HTom
PopRideCym 2
MG Nz Cym
707 Dry RD
Long Tamb
Pop SprshCym
Cwbl Hi
Pop Cym Roll
Cwbl Mute
808 Dry Cym4
LTBit CgH
LTBit CgL Hi
LTBit CgL Lo
Cartn Fall
Thumpkin 1
Thumpkin 2
StrChdMn11
Thru Hit 1
MG S Zap 3
Real Cabasa3
808 Dry Mrcs
Cartn Boing1
Cartn Boing2
Scratch 4
Scratch 5
Scratch 6
Scratch 7
Scratch 8
Scratch 13
Vinyl NzLp 2
MG S Zap 1
SH2 S Zap 1
MG NoiseHit
Press Hit
Ho F
Long Triangl
Sonar Hit
LoFi Coo
Dist Slide
Box Hit 2
Spoon Hit
LoFi Pod Hit
Rumble Hit
Fl Press Hit
US SweepD L1
WindChime Up
WindChime Dn
SH Click
Metronome
Dry CHH 2
Dry OHH
909 Dry CHH2
909 Dry OHH2
UltrafunkCH1

2. Euro
Kit

Mellow Kick
L-RiderKick2
Cartn Fall
Layer Kick 1
Blade SD
909 DryKick1
909 Dry OHH1
909 DryKick3
Analog Kick2
Hop RimShot1
Gan SD mb
Lofi Clap3mb
Funk SD1
909 Dry LTom
Lulu CHH
808 Dry MTom
909 Dry CHH2
808 Dry LTom
909 Dry OHH1
909 Dry HTom
909 Dry MTom
909 Dry CR 2
808 Dry HTom
707 Dry RD
MG Nz Cym
909 Dry RD2
707 Dry Tamb
Pop Crash1
707 Dry Cwbl
707 Dry CR
Sonar Hit
808 Dry Cym4
HiConga Opn
HiConga Slap
HiConga Opn
Thmpkn>Slide
Vice Hit 1
Thumpkin
StrSprdMaj
Thru Hit 2
SH2 U Zap 3
Real Cabasa3
808 Dry Mrcs
Cartn Boing1
Cartn Boing2
US SweepU L2
MG SweepDn
US SweepD L2
Bobs Slide
Exhaust Hit
Clavy Hit
Oh F
Wow Yeah F
Whoo! M
BrassHit 22
Electronica
Ho F
Long Triangl
Long Guiro2
Howl Sync
Dist Slide
LoFi Bit 1
Spoon Hit
LoFi Pod Hit
Rumble Hit
US Metal 2
Ring FX 2
WindChime Up
WindChime Dn
SH Click
Metronome
Dry CHH 2
Dry OHH
909 Dry CHH2
909 Dry OHH2
808 Dry CHH

3. Urban
Kit

808 DryKick5
Metal Kick
Snare Ghost
Old Kick
Snapy SD
Analog Kick2
Lo-Fi CHH 1
Layer Kick 6
Plump Kick
Metalic SD
Dinky SD 1
Clap Tail 2
LoBtHf SD2mb
SH2 S Zap 3
Comp CHH 1
SH2 S Zap 4
Lo-Fi CHH 2
SH2 S Zap 2
Lo-Fi OHH
MG S Zap 2
SH2 U Zap 1
Pop Crash1
MG S Zap 3
PopRideCym 1
WindChime Up
PopRideCym 2
Long Tamb
NzCym/AahHit
808 Dry Cwbl
Pop Cym Roll
707 Dry Cwbl
808 Dry Cym3
HiConga Opn
HiConga Slap
HiConga Cls
LoConga Opn
LoBongo Opn
Tmbl Lo Flm
Tmbl Hi Flm
Latin Hit
Cwbl Lo
Cwbl Lo
Real Shaker1
Real Shaker2
LoFi Bit 1
Long Guiro2
Short Guiro2
Nz Pass
MG NoiseHit
US SweepD S2
Swish Rope 3
LoFi Bit 1
US Metal 2
Bobs Slide
LoFi Bit 2
SH2 U Zap 6
909 DryKick1
GoGo SD mb
909 Dry SD1
Metal Atk Lo
Gruntoid SD
Cym Slide
909 Dry CHH1
Vice Hit 1
909 Dry CHH2
WindChime Up
909 Dry OHH1
Gtr & XRacer
RocketBrs
SH Click
Metronome
You’re DJ M
Vinyl NzLp 1
Vinyl NzLp 2
Club SD1
Rocky SD 1

4. Tight
Kit

106 Kick 1
Filter Kick
Basis Rim
Craze Kick 3
Lo-Bit CStk
Layer Kick 1
R&B Crs Stk2
808 DryKick5
Old Kick 1
R&B Crs Stk1
R&B SD 1
Clap Tail 2
Alley SD1 mb
Old LTom B2
Mosaic CHH1S
Old LTom B1
Mosaic CHH1L
Old HTom B3
707 Dry OHH
Old HTom B2
Old HTom B3
Pop Crash2
Old HTom B2
PopRideCym 1
Pop SprshCym
PopRideCym 4
Long Tamb
Pop Cym Roll
808 Dry Cwbl
Pop ChinaCym
Long Guiro2
Light Kick 8
Vinyl Kick
Hop RimShot2
GoGo SD
St. FgSnap
Retro SD6
Cwbl Mute
Dry CHH 2S
Cwbl Lo
Dry CHH 2L
Dry CHH 1
Dry OHH
Real Cabasa3
LTBit CgL
707 Dry RSht
LTBit CgH
Single HClp1
Scratch 8
Scratch 4
Comp CHH 2
Scratch 12
Comp CHH 1
Scratch 7
Comp CHH 3
Vinyl NzLp 1
Blade Beat
808 Dry RSht
Rug Burn
MG SweepDn
Boss Club
X Racer
TrmDwnGtr2
BladeBeatRev
TrmDwnGtr1
BossClub Rev
Bobs Slide
R&Bees Rev
StrikeWhstle
SH Click
Metronome
Flute FX 3
Flute FX 1
Flute Fx 2
ClnGtrRif2
ClnGtrRif1

5. BitzOHitz
Kit

PhraseMenu
BladeBt Kick
Basis Rim
R&Bees Kick
Lo-Bit CStk
Clubbin Kick
R&B Crs Stk2
US SweepD S1
BossClubKick
R&B Crs Stk1
Chord Hit 2
Clap Tail 2
Dist Hit 1
Bounce Hit2
Mosaic CHH1S
Chord Hit 2
Mosaic CHH1L
Chord Hit 4
707 Dry OHH
Chord Hit 3
Chord Hit 2
Pop Crash2
Chord Hit 1
PopRideCym 1
Pop SprshCym
Pop CymRollL
Long Tamb
Pop CymRollH
808 Dry Cwbl
Pop ChinaCym
Long Guiro2
Smoky Hit
Wah Hit
Hop RimShot2
Blowout
St. FgSnap
BrassHit 8
Cwbl Mute
Dry CHH 2S
Cwbl Lo
Dry CHH 2L
Dry CHH 1
Dry OHH
Real Cabasa3
Str Fall
707 Dry RSht
StrChdMin9
Single HClp1
Scratch 4
Scratch 5
Comp CHH 2
Scratch 13
Comp CHH 1
Scratch 14
Comp CHH 3
Vinyl NzLp 1
EP Chd&Voice
808 Dry RSht
EP Chd & Gtr
US SweepD L1
WahGtrCt3
WahGtrCt1
TrmDwnGtr2
ClnGtrRif2
TrmDwnGtr1
ClnGtrRif1
Bobs Slide
TrmDwnGtr1
WahGtrRif2
SH Click
Metronome
Sax FX 1
Sax FX 2
Sax Fx 3
StrSprd&Bt
RtrSprd&Bt

6. Intl.Tek
Kit

Club Kick
Fat Kick
Lofi Clap3mb
ChickenKick2
Lulu CHH
Blade Kick
707&Long TB
106 Kick 2
Craze Kick 2
Club SD2 mb
Heat SD mb
Clap Tail 2
Hush SD mb
Tmbl HiPaila
Comp CHH 3
909 Dry MTom
808 Cl&OpHH
Layer SD8 mb
808 Dry Cym2
Basis Rim
808 Dry SD2
Crash 1
BigDreds SD
909 Dry RD2
808 Dry Cym1
Pop Crash1
Long Tamb
707 Dry CR
Dist Cowbell
PopRideCym 4
808 Dist CB
HiTune SD
909 Dry SD2
909 Dry Clap
909 Dry Clap
909 Dry Clap
Cartn Fall
Cym Slide
Lo-Bit CHH
Cartn Boing2
Voice Breath
Swish Rope 2
Clavy Hit
Sweep OHH
GummoKickRev
Org Click
Dist Chekele
Howl Sync
Craze Kick 2
JU2SpSub2
OSC Perc 1
US SweepU L1
Rocky SD3 mb
OSC Perc 2
Engine
Chord Hit
ClnGtr Hit
DistSymphHit
DistStrChord
Guitarrn&Sax
Brass Hit 18
Daw Hit
Brass Hit 21
SymphHit&Cym
Oh F
Yeah M
Oh F
Dist Oh F
MG S Zap 2
SH Click
Metronome
Lo-Fi CHH1
Lo-Fi CHH2
Lo-Fi CHH3
UltrafunkCH1
Jiggle OHH

7. GloblHous
Kit

Dance Kick 8
808 Dry Clap
Filter SD2Hi
Dance Kick 5
Filter SD2Lo
Craze Kick 2
Long Tamb
909 DryKick1
Vinyl Kick
MG Nz Cym
Hush SD mb
707 Dry Clap
Devi RM1mb
909 Dry MTom
909 Dry CHH2
Dinky Kick 3
Snapy SD
GoGo SD mb
707 Dry OHH
Hush SD mb
909 Dry Clap
Crash 1
GospelClap
PopRideCym 4
Pop Crash1
Crash Cymbal
707 Dry Tamb
707 Dry RD
Car Pass
808 Dry Cym1
Org Click
Voice Breath
106 Kick 1
US SweepD L3
909 Dry SD5
Lofi Clap2mb
707 Dry SD1
707 Dry Clap
Lo-Bit CHH
808 Dry Clap
Comp CHH 3
909 Dry Clap
Comp OHH
909 Dry OHH1
HiBongo&OHH
LoConga Opn
Thumpkin
HiConga Opn
Osc&Cabasa
Tramp Hit
Warp Hit 3
Stamp Hit
Bounce Hit4
Hop RimShot3
SymphHit 3
Vox Menu
Brass Hit 16
Swanky Kick
Aah Hit
Metal&AahHit
PizzHit&Cym
StrChdMin9Hi
StrChdMin9Lo
Guitarrn&Sax
Yeah M
You’re DJ M
Yeah M
You’re DJ M
MG S Zap 2
SH Click
Metronome
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

* On the RD series (with SRX slots)/MC-909/VR-760/G-70, you can not select only the

rhythm sets which are designed to be used with the Fantom series/XV series/MX-200.

* On the MC-909, you can use only the rhythm tones for the sixteen keys from

note numbers 35 (B1) through 50 (D3).

* Some of the rhythm tone names shown in this list may appear differently on the

display of the device being used, but the tones themselves remain unaffected.

※

SRX 対応の RD シリーズ /MC-909/VR-760 では、Fantom シリーズ /
XV シリーズ /MX-200 専用のリズム・セットを選ぶことはできません。

※ MC-909 では、Note No. 35（B1）から 50（D3）までの 16 鍵分のリ

ズム・トーンのみ使用できます。

※ 一部のリズム・トーンの名前が、本リストと使用機器の画面表示とで異

なる場合がありますが、音色自体に影響はありません。

15

Rhythm Set Key Assign (7)

For RD series (with SRX slots)/MC-909/VR-760/G-70

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

8. BreakBts
Kit

70s Kick 2
Swanky Kick
Lo-Fi CHH 2
Fuzz Kick
707 Dry SD2
Retro Kick 2
Filter SD3
Metal Kick
Craze Kick 3
Funk SD2
Devi RM1mb
Club SD3
Alley SD1 mb
808 Kick 1
808 Dry OHH1
808 Kick 2
808 Dry OHH3
808 Kick 3
909 Dry OHH2
808 Kick 4
ShredFuzzGtr
909 Dry CR 1
808 Cl&OpHH
909 Dry RD2
Rock CrCym1f
MG SweepDn
OSC Perc 2
Box Hit 2
OSC Perc 2
Pop Cym Roll
Lofi Clap3mb
Short FgSnap
WahHit&Tamb
Chekele 2
Pop Cym Roll
Chekele2
PopRideCym 4
Filter SD2
Layer SD2 mb
Retro SD6
Swish Rope 4
Ring FX 2
WahGtrChord
Clap Tail 2
LoBtHf SD3mb
LoBongo Opn
HiConga Opn
HiBongo Mute
Whoo! M
You’re DJ M
US SweepD S1
US SweepU L1
Cartn Boing1
Long Tamb
9thHit&Kick
Old SD6 mb
Tmbl Hi Roll
Long Tamb
707 Dry Clap
Pop Cym Roll
LTBit CgH
808 Dry Mrcs
WindChime Dn
Craze Kick 3
BS & 808OHH
808 Dry RSht
808 SN
Dance Kick
REV Timp3 pp
SH Click
Metronome
Comp CHH 1
Comp CHH 2
Comp CHH 3
Lo-Tek HH1
Lo-Tek HH4

9. Trip
Kit

LoBit Kick 2
Dance Kick 8
Soul SD mb
Fuzz Kick
707 Dry SD2
Layer Kick 4
Retro SD5
Layer Kick 1
Analog Kick2
Layer SD8 mb
FilterSD5 mb
PFunkSD mb
GoGo SD mb
808 Kick L
Timba CHH
808 Kick H
Lo-Bit OHH
Scratch 15
909 Dry OHH2
Layer Kick 4
Rebo Kick 1
Lofi Clap2mb
LoBtHf SD3mb
Lofi Clap3mb
R&B SD 2
US SweepD L2
808 Dry CHH
Sonar Hit
808 Dry OHH1
Pop Cym Roll
707 Dry OHH
Real Cabasa3
909 Dry CR 2
Pop SprshCym
707 Dry RD
PopRideCym L
PopRideCym H
BrassHit 18
Aah Hit
Scratch 14 S
Metal Atk Lo
Scratch 14 L
WahGtrCt2
Scratch 14 H
Craze Kick 2
LTBit CgR Lo
Lofi Clap3mb
LTBit CgR Hi
Yeah M
TrmDwnGtr2
Hop RimShot1
Cartn Boing2
Cartn Boing1
ClvsLoP Lo
Scratch 9
Retro SD3
707 Dry Tamb
Long Tamb
909 Dry RD3
Pop Crash2
LTBit CgR
Long Triangl
ClvsLoP Hi
707 DryKick1
808 Dry OHH1
SparkleSD mb
808 SN
Dance Kick
REV Timp3 pp
SH Click
Metronome
Mosaic CHH 1
Mosaic CHH 2
Mosaic CHH 3
UltrafunkCH1
UltrafunkOHH

10. Bright
Kit

FunkB Kick
Rebo Kick 2
Rebo SD2
Rebo Kick 1
Attack SD1
Dyna Kick
Dry CHH 1
Alley Kick 1
Layer Kick 3
Hop RimShot1
Filter SD3
Slipper Hit
Club SD1
Old LTom B2
Dry CHH 2
Old LTom B2
Dry CHH 3
Old LTom B2
Dry OHH
Old LTom B2
Old HTom B2
Pop Crash1
Old HTom B2
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Vice Hit 1
US Nz Cym
HiBongo Opn
LoBongo Opn
HiConga Slap
HiConga Opn
LoConga Opn
Tmbl Hi f
Tmbl Lo p
WindChime Dn
Short FgSnap
St. FgSnap
Thumpkin
Chekele 1
Rug Burn
Clubbin
X Racer
Blowout
Altr Hit
LoFi Hole
ThousandHit
Head Knd Clp
Tmbl Hi Rim
Tmbl Hi Roll
Real Shaker1
Real Shaker2
Real Shaker3
MG NoiseHit
Pod Hit
Latin Hit
Scratch 7
Scratch 8
Scratch 9
Scratch 10
Scratch 11
Scratch 12
Scratch 13
Scratch 14
Scratch 15
SH Click
Metronome
Lo-Tek HH2
Lo-Tek HH1
Lo-Tek HH3
Lo-Tek HH4
Miami OHH

11. Soulful
Kit

Vinyl Kick
Soul Kick
R&B SD 1
Abuz Kick
R&B Crs Stk2
Old Kick 2
Lo-Tek HH2
R&B Kick 1
R&B Kick 2
R&B Crs Stk1
Lo-Bit SD 1
Buck Clap
Comp SD1 mb
Old LTom B1
Lulu CHH 1
Old LTom B1
Lulu CHH 2
Old LTom B1
Miami OHH
Old LTom B1
Old HTom B2
Pop Crash1
Old HTom B2
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Scratch 4
Scratch 5
Scratch 6
Scratch 9
Scratch 7
Scratch 8
WindChime Up
WindChime Dn
Short Tri
Long Triangl
Real Cabasa3
St. FgSnap
Crystal Hit
Warp Hit 6
Pod Hit
LoFi Pod Hit
Press Hit
Cartn Fall
LoFi Shaker
Wow Yeah F
Yeah F
Aow F
Oh F
Wah Hit
Organ Hit 2
OrgTrnsplnt
BrassHit 4
BrassHit 2
SymphHit 7
StrChdMn11
StrChdMin9
Str Fall
StrScaleMaj
ClnGtrRif1
ClnGtrRif2
TrmDwnGtr2
WahGtrCt4
SH Click
Metronome
Lo-Tek HH2
Dry CHH 1
Dry CHH 2
Dry CHH 3
Dry OHH

12. LiteStep
Kit

MG Kick 1
808 DryKick5
Deviant RM3
808 DryKick5
Deviant RM1
808 DryKick5
Lo-Tek HH2
Filter Kick
909 DryKick1
Retro SD2 mb
Club SD3
707 Dry Clap
Hop RimShot1
707 Dry LTom
Mosaic CHH L
707 Dry LTom
Mosaic CHH H
707 Dry MTom
Miami OHH
707 Dry MTom
707 Dry HTom
Pop Crash1
707 Dry HTom
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Fall Bass
Lo-Bit CStk
Dinky SD 1
Lofi Clap3mb
LoBtHf SD3mb
Sim5 Tom4S
Noise CHH 1
Sim5 Tom3S
Noise PHH 1
Sim5 Tom2S
Noise OHH 1
Sim5 Tom1S
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
LoBongo Opn
HiBongo Mute
LoBongo Slap
Tmbl Hi f
Tmbl Lo p
Real Cabasa3
Real Shaker3
Organ Hit 1
Drain-O L
Old Org Hit
EP Maj 9th
Flute Fx 2
StrChdMn11
StrChdMin9
Ho F
Crystal Hit
LTBit CgH
Nz Pass
SH2 S Zap 2
SH2 S Zap 2
SH Click
Metronome
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

13. 4onFloor
Kit

Gummo Kick 2
Blade Kick
909 Dry SD3
Light Kick 8
909 Dry SD4
Mellow Kick
Time OHH
L-RiderKick2
909 DryKick1
909 Dry RSht
909 Dry SD2
909 Dry Clap
909 SD&CLP
909 Dry LTom
909 Dry CHH1
909 Dry LTom
909 Dry CHH3
909 Dry MTom
909 Dry OHH2
909 Dry MTom
909 Dry HTom
909 Dry CR 2
909 Dry HTom
PopRideCym 2
Pop Crash2
909 Dry RD2
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Craze Kick 2
Basis Rim
106 SD2
Royal Clap
Retro SD5
Old LTom B2
Chill CHH
Old LTom B2
Chill CHH
Old HTom B2
Miami OHH
Old HTom B2
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
LoBongo Opn
HiBongo Mute
LoBongo Slap
Tmbl Hi f
Tmbl Lo p
Tmbl Hi Flm
Tmbl Lo Flm
Tmbl Hi Roll
Tmbl HiPaila
Latin Hit
BrassHit 10
BrassHit 11
StrChdMn11
StrChdMin9
WahGtrRif1
WahGtrRif2
WahGtrCt3
WahGtrCt2
WahGtrCt1
WahGtrChord
SH Click
Metronome
909 HPF CHH1
909 HPF CHH2
909 HPF CHH3
909 HPF OHH1
909 HPF OHH2

14. Street
Kit

Hybrid Kick3
Vinyl Kick
HipHop SD 1
Layer Kick 4
Lo-Bit SD 1
Layer Kick 1
Lo-Bit CHH
L-RiderKick2
FunkB Kick
Hop RimShot1
Dinky SD 1
Single HClp1
Snapy SD
Retro Tom2
Mosaic CHH 2
Retro Tom2
Mosaic CHH 1
Retro Tom1
Comp OHH
Retro Tom1
Retro Tom1
Pop Crash1
Retro Tom1
PopRideCym 2
Pop Crash2
PopRideCym 1
Long Tamb
Pop SprshCym
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Scratch 4
Scratch 5
Scratch 6
Scratch 7
Scratch 8
Scratch 9
Scratch 10
Scratch 11
Scratch 12
Scratch 13
Scratch 14
Scratch 15
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
LoBongo Opn
HiBongo Mute
LoBongo Slap
Tmbl Hi f
Tmbl Lo p
Real Cabasa3
Real Shaker3
BrassHit 2
BrassHit 15
BrassHit 19
BrassHit 5
Dust Hit L
StrChdMn11
StrChdMin9
SymphHit 7
Sax Fx 1
Com’on M
Whoo! M
You’re DJ M
Vinyl NzLp 1
SH Click
Metronome
Lo-Fi CHH1
Lo-Fi CHH2
Lo-Fi CHH3
UltrafunkCH1
Jiggle OHH

* On the RD series (with SRX slots)/MC-909/VR-760/G-70, you can not select only the

rhythm sets which are designed to be used with the Fantom series/XV series/MX-200.

* On the MC-909, you can use only the rhythm tones for the sixteen keys from

note numbers 35 (B1) through 50 (D3).

* Some of the rhythm tone names shown in this list may appear differently on the

display of the device being used, but the tones themselves remain unaffected.

16

※

SRX 対応の RD シリーズ /MC-909/VR-760 では、Fantom シリーズ /
XV シリーズ /MX-200 専用のリズム・セットを選ぶことはできません。

※ MC-909 では、Note No. 35（B1）から 50（D3）までの 16 鍵分のリ

ズム・トーンのみ使用できます。

※ 一部のリズム・トーンの名前が、本リストと使用機器の画面表示とで異

なる場合がありますが、音色自体に影響はありません。

Rhythm Set Key Assign (8)

For RD series (with SRX slots)/MC-909/VR-760/G-70

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

15. Machine
Kit

106 Kick 1
Craze Kick 1
707 Dry SD2
Alley Kick 1
Noisy SD
909 DryKick3
808 Cl&OpHH
106 Kick 2
909 DryKick1
Hop RimShot2
909 Dry SD2
Clap Tail 2
909 Dry Clap
707 Dry LTom
909 Dry CHH1
707 Dry LTom
909 Dry OHH1
707 Dry MTom
909 Dry OHH2
707 Dry MTom
707 Dry HTom
909 Dry CR 2
707 Dry HTom
909 Dry RD3
MG Nz Cym
Nz SweepTone
Long Tamb
LoFi Moan
LoTek Bit
LoFi Bit 1
LoFi Hole
LoFi Bit 2
Craze Kick 2
808 Dry RSht
808 Dry SD1
808 Dry Clap
808 Dry SD2
808 Dry LTom
808 Dry CHH
808 Dry LTom
808 Cl&OpHH
808 Dry MTom
808 Dry OHH3
808 Dry HTom
OSC Perc 1
US SweepD L3
OSC Perc 1
Ring FX 2
Ring FX 1
MG SweepDn
MG S Zap 3
SH2 S Zap 1
SH2 S Zap 2
SH2 S Zap 3
SH2 S Zap 4
SH2 S Zap 5
Warp Hit 7
Mull Hit
Warp Hit 8
Bounce Hit4
Chord Hit 4
Electric Saw
Dist Slide
Howl Sync
Metal Atk Lo
Metal Atk Hi
Thumpkin
LoFi Coo
Sonar Hit
SH Click
Metronome
Lo-Tek HH2
Lo-Tek HH1
Lo-Tek HH3
Lo-Tek HH4
Jiggle OHH

16. LoTek
Kit

106 Kick 2
Craze Kick 2
LoBtHf SD3mb
Lo-Tek Kick
LoBtHf SD4mb
ChickenKick1
Time OHH
LoBit Kick 1
LoBit Kick 2
Lo-Bit CStk
Lo-Bit SD 2
Clap Tail 2
Lo-Bit SD 1
Retro Tom2
Lo-Bit CHH
Retro Tom2
Lo-Bit CHH
Retro Tom1
Lo-Bit OHH
Retro Tom1
Retro Tom1
909 Dry CR 2
Retro Tom1
PopRideCym 2
Pop Crash2
909 Dry RD2
Long Tamb
Pop Cym Roll
Cwbl Lo
Pop ChinaCym
Cwbl Mute
808 Dry Cym3
Hybrid Kick3
Deviant RM3
Filter SD3
Lofi Clap3mb
Dinky SD 1
Old HTom A3
Miami OHH
Old HTom A3
Time OHH
Old HTom A3
UltrafunkOHH
Old HTom A3
HiConga Opn
LoConga Opn
HiConga Slap
HiConga Cls
HiBongo Opn
Tmbl Hi f
Tmbl Lo p
Tmbl Hi Flm
Tmbl Lo Flm
Tmbl Hi Roll
Tmbl HiPaila
Latin Hit
Tramp Hit
Bounce Hit4
Warp Hit 6
Ring FX 2
Ripper
Cave Hit
LoFi Hole
LoFi Coo
LoFi Bit 1
LoFi Bit 2
LoTek Bit
LTBit CgH
LTBit CgL
SH Click
Metronome
Comp CHH 1
Comp CHH 2
Comp CHH 3
Lo-Tek HH1
Lo-Tek HH4

17. Solid
Kit

Metal Kick
Croak Kick 1
Pump SD
Blade Kick
Blade SD
Fuzz Kick
Mosaic CHH 1
Alley Kick 1
Metal Kick
HopRimshot 2
Attack SD1
Clap Tail 2
Attack SD4
808 Dry LTom
Chill CHH
707 Dry LTom
UltrafunkCH1
808 Dry MTom
Jiggle OHH
707 Dry MTom
808 Dry HTom
909 Dry CR 1
707 Dry HTom
909 Dry RD1
MG Nz Cym
US Nz Cym
707 Dry Tamb
Pop SprshCym
707 Dry Cwbl
Pop ChinaCym
808 Dry Cwbl
808 Dry Cym4
Gummo Kick 2
US Metal 2
Metal Atk Lo
US Metal 1
Metal Atk
SH2 U Zap 6
Noise CHH 2
SH2 U Zap 5
Noise PHH 2
SH2 U Zap 4
Noise OHH 2
SH2 U Zap 2
Ring FX 1
Electronica
Howl Sync
Dist Slide
Thumpkin Rev
Cave Hit
Flute Fx 1
Flute Fx 2
Flute Fx 3
Sax Fx 1
Sax Fx 2
Sax Fx 3
BrassHit 5
BrassHit 12
BrassHit 16
BrassHit 20
Tremble Hit
Aah Hit
Exhaust Hit
Blade Beat
R&Bees
Rug Burn
Boss Club
Clubbin
X Racer
SH Click
Metronome
Lo-Tek HH2
Dry CHH 1
Dry CHH 2
Dry CHH 3
Dry OHH

18. TekTrio
Kit

Gummo Kick 1
MG Kick 2
MG S Zap 2
MG Kick 1
MG S Zap 1
Alley Kick 2
Dry OHH
LoBit Kick 1
707 DryKick1
Lo-Bit CStk
Funk SD1
Head Knd Clp
Lo-Bit SD 1
Sim5 Tom4S
Dry CHH 1
Sim5 Tom4F
Dry CHH 1
Sim5 Tom3S
Dry OHH
Sim5 Tom3F
Sim5 Tom2S
Pop Crash1
Sim5 Tom2F
Pop Crash2
Sim5 Tom1S
Sim5 Tom1F
Long Tamb
Pop SprshCym
Res NzPerc S
Pop ChinaCym
Res NzPerc L
Noise Attack
R&B Kick 2
US Nz Cym
Retro SD 1
MG NoiseHit
Retro SD3
Retro Tom2
Lulu CHH
US SweepD S2
Lulu PHH
US SweepD S1
Lo-Bit OHH
US SweepD L2
US SweepD L1
US Metal 2
US SweepU L2
US Metal 1
US SweepU L1
SH2 S Zap 5
SH2 S Zap 1
SH2 S Zap 2
SH2 S Zap 3
SH2 S Zap 4
SH2 U Zap 4
SH2 U Zap 5
808 Dry Clap
808 Dry Mrcs
808 Dry RSht
808 Dry Clvs
808 Dry Cwbl
808 Dry Lcng
808 Dry CHH
808 Dry Mcng
808 Cl&OpHH
808 Dry Hcng
808 Dry OHH3
707 Dry Tamb
707 Dry Cwbl
SH Click
Metronome
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

19. TekQuarto
Kit

808 DryKick2
808 DryKick3
SH2 S Zap 1
MG Kick 2
SH2 S Zap 2
MG Kick 1
808 Cl&OpHH
707 DryKick1
808 DryKick5
808 Dry RSht
808 Dry SD1
Head Knd Clp
SH2 S Zap 3
808 Dry LTom
808 Dry CHH
808 Dry LTom
808 Cl&OpHH
808 Dry MTom
808 Dry OHH3
808 Dry MTom
808 Dry HTom
808 Dry Cym2
808 Dry HTom
808 Dry Cym3
MG Nz Cym
909 Dry RD2
Long Tamb
Pop SprshCym
808 Dry Cwbl
Pop ChinaCym
Long Triangl
808 Dry Cym4
909 DryKick1
909 Dry RSht
Clap Tail 2
909 Dry Clap
Attack SD1
909 Dry LTom
Noise CHH 3
909 Dry LTom
Noise PHH 3
909 Dry MTom
Noise OHH 3
909 Dry HTom
Nz Flang SD
MG S Zap 3
Slipper Hit
Spoon Hit
Metal Atk Lo
Metal Atk Hi
Sonar Hit
Vice Hit 2
Vice Hit 3
Box Hit 2
Cartn Boing1
Cartn Boing2
LTBit CgL
LTBit CgH
LoTek Bit
LoFi Hole
LoFi Bit 1
Thru Hit 1
Thru Hit 2
Electronica
Ho F
Yeah F
Clavy Hit
Ring FX 2
Ring FX 1
SH Click
Metronome
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2

20. Hit
Menu

Bobs Slide
BrassHit 18
BrassHit 19
SymphHit 3
Altr Hit
Crystal Hit
Dirty Hit 2
Iron Hit 2
Clavy Hit
Warp Hit 1
Warp Hit 2
Warp Hit 3
Warp Hit 4
Cave Hit
Warp Hit 6
Thru Hit 2
Thru Hit 1
Mull Hit
Warp Hit 7
Warp Hit 8
Electronica
Ripper
Warp Hit 9
Tickle Hit
PercolateHit
Tramp Hit
Bounce Hit1
Bounce Hit2
Warp Hit 5
ParabolaHit
Smoky Hit
Fist Hit
BrassHit 1
BrassHit 2
BrassHit 4
BrassHit 6
BrassHit 8
BrassHit 7
BrassHit 13
BrassHit 23
SymphHit 7
SymphHit 5
OrgTrnsplnt
Organ Hit 2
Chord Hit 3
Chord Hit 4
Exhaust Hit
Scoop Hit
Stamp Hit
9th Hit
Dust Hit
Dist Hit 2
Sweep Hit
Daw Hit
Tread Hit
Bounce Hit3
Bounce Hit4
BrassHit 21
Slap Hit 1
Slap Hit 2
Organ Hit 1
Old Org Hit
BrassHit 10
BrassHit 11
StrSprdMaj
StrSprdMin
StrChdMn11
StrChdMin9
BrassHit 20
BrassHit5
Brass Hit 9
BrassHit 16
ThousandHit
Chord Hit 1
Tremble Hit
SymphHit 1

21. Kick
Menu 1

--

--

--

--

--

--

--

--

R&B Kick 1
Old Kick 1
Old Kick 2
Metal Kick
Old Kick 3
Rebo Kick 1
Abuz Kick
Cool Kick 1
Dyna Kick
Floor Kick
Gan Kick
GoGo Kick
Livn Kick
Old Kick 4
Mellow Kick
Two Kick
Gummo Kick 1
Gummo Kick 2
R&B Kick 2
Alley Kick 2
FunkB Kick
Light Kick 1
Light Kick 2
Light Kick 3
Light Kick 4
Light Kick 6
H-Rider Kick
Layer Kick 1
Layer Kick 2
Layer Kick 3
Layer Kick 4
Retro Kick 1
Retro Kick 2
Pump Kick
Heavy Kick 1
Heavy Kick 2
Heavy Kick 3
Heavy Kick 4
Layer Kick 5
Shake Kick
Rebo Kick 2
Chop Kick
Light Kick 9
Soul Kick
Trip Kick
Vinyl Kick
Club Kick
Dinky Kick 1
Dinky Kick 3
Dinky Kick 4
Slopey Kick1
Junk Kick
Motor Kick
Layer Kick 6
Dance Kick 7
BigDrds Kick
DeeBee Kick

--

--

--

--

--

--

--

--

--

--

--

* On the RD series (with SRX slots)/MC-909/VR-760/G-70, you can not select only the

rhythm sets which are designed to be used with the Fantom series/XV series/MX-200.

* On the MC-909, you can use only the rhythm tones for the sixteen keys from

note numbers 35 (B1) through 50 (D3).

※

SRX 対応の RD シリーズ /MC-909/VR-760 では、Fantom シリーズ /
XV シリーズ /MX-200 専用のリズム・セットを選ぶことはできません。

※ MC-909 では、Note No. 35（B1）から 50（D3）までの 16 鍵分のリ

ズム・トーンのみ使用できます。

17

Rhythm Set Key Assign (9)

For RD series (with SRX slots)/MC-909/VR-760/G-70

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

22. Kick
Menu 2

--

--

--

--

--

--

--

--

LoBit Kick 1
LoBit Kick 2
Narrow Kick
Alley Kick 1
L-RiderKick1
Light Kick 5
Light Kick 7
L-RiderKick2
Light Kick 8
ChickenKick1
Edge Kick
Buck Kick
Ambi Kick
Cbell Kick
Tamb Kick
Cool Kick 2
Seiz Kick
Lo-Tek Kick
Filter Kick
Blade Kick
Dinky Kick 2
Old Kick 5
Hybrid Kick3
707 DryKick1
707 DryKick2
808 DryKick1
808 DryKick2
808 DryKick3
808 DryKick4
808 DryKick5
Analog Kick1
Analog Kick2
909 DryKick3
909 DryKick2
909 DryKick1
Craze Kick 1
Craze Kick 2
106 Kick 1
106 Kick 2
MG Kick 1
MG Kick 2
Fat Kick
Croak Kick 1
Fuzz Kick
ChickenKick2
Craze Kick 3
Craze Kick 4
Plump Kick
Deviant Kick
Dance Kick 5
Dance Kick 6
Dance Kick 8
Slopey Kick2
Swanky Kick
SnugBugaKick
Synth Kick

--

--

--

--

--

--

--

--

--

--

--

--

23. Snare
Menu 1

--

--

--

--

--

--

--

--

HipHop SD 1
R&B SD 1
Lo-Bit SD 1
Basis SD 1
Gruntoid SD
L-Rider SD
Craze SD 1
R&B SD 2
Lo-Bit SD 2
Dinky SD 1
Dinky SD 2
Dinky SD 3
Basis SD 2
Basis SD 3
Retro SD 1
Snapy SD
Rocky SD1
Rocky SD1 mb
Rocky SD2 mb
Rocky SD3 mb
Club SD1
Club SD2 mb
Club SD3
Club SD3 mb
Comp SD1 mb
Comp SD2 mb
Rev SD mb
LoBtHf SD1mb
LoBtHf SD2mb
LoBtHf SD3mb
LoBtHf SD4mb
LoBtHf SD5mb
LoBtHf SD6mb
Light SD1
Light SD1 mb
Light SD2
Light SD2 mb
Alley SD1
Alley SD1 mb
H-Rider SD
Slopey SD
Gan SD mb
MellowSD mb
MGT SD mb
Old SD1 mb

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

24. Snare
Menu 2

--

--

--

--

--

--

--

--

Old SD2 mb
Old SD3 mb
Old SD4 mb
Old SD5 mb
Attack SD1
Retro SD1
Retro SD3
Retro SD4
Retro SD5
Retro SD6
Layer SD1 mb
Attack SD3
Lo-Tek SD
Filter SD3
Filter SD4
Retro SD7
Retro SD8
Funky SD
Layer SD3
Heat SD mb
Cool SD
GoGo SD
Soul SD mb
Layer SD6
Vynil SD mb
Hop RimShot3
Blade SD
Metalic SD
Noisy SD
Pump SD
Basis SD 4
HiTune SD
Thin SD
Thin SD mb
Slim SD
BigDreds SD
PFunkSD mb
GoGo SD mb
Retro SD2 mb
Hybrid SD mb
DeeBee SD
Old SD6 mb
Layer SD2 mb
Filter SD1
Filter SD2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

25. Snare
Menu 3

--

--

--

--

--

--

--

--

Attack SD2
Attack SD4
Layer SD5 mb
Ultra SD 1
Ultra SD 2
Layer SD4 mb
Alley SD2
Alley SD2 mb
Fella SD1 mb
Fella SD2
Fella SD2 mb
Rebo SD1
Rebo SD1 mb
Rebo SD2
Swush SD mb
Chicken SD
Funk SD1
Funk SD2
Dinky SD4 mb
Layer SD7 mb
Layer SD8 mb
Layer SD9 mb
FilterSD5 mb
Junk SD mb
Clappy SD
Cranky SD
Grim SD
Sparkle SD
SparkleSD mb
Hush SD mb
707 Dry SD1
707 Dry SD2
808 Dry SD1
808 Dry SD2
808 Dry SD3
909 Dry SD1
909 Dry SD4
909 Dry SD5
909 Dry SD3
909 Dry SD2
909 SD&CLP
106 SD1
106 SD2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

26. RimShot
Menu

--

--

--

--

--

--

--

--

R&B Crs Stk1
R&B Crs Stk2
Lo-Bit CStk
707 Dry RSht
808 Dry RSht
909 Dry RSht
Basis Rim
Basis Rim mb
Deviant RM1
Devi RM1mb
Deviant RM2
Deviant RM3
Devi RM3mb
Hop RimShot1
Hop RimShot2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

27. Tom
Menu

--

--

--

--

--

--

--

--

Old HTom A1
Old HTom A2
Old HTom A3
Old LTom A1
Old LTom A2
Old HTom B1
Old HTom B2
Old HTom B3
Old LTom B1
Old LTom B2
Retro Tom1
Retro Tom2
Sim5 Tom1S
Sim5 Tom1F
Sim5 Tom2S
Sim5 Tom2F
Sim5 Tom3S
Sim5 Tom3F
Sim5 Tom4S
Sim5 Tom4F
707 Dry HTom
707 Dry MTom
707 Dry LTom
808 Dry HTom
808 Dry MTom
808 Dry LTom
909 Dry HTom
909 Dry MTom
909 Dry LTom

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

28. HiHats
Menu

--

--

--

--

--

--

--

--

Lo-Tek HH1
Lo-Tek HH2
Lo-Tek HH3
Lo-Tek HH4
Lo-Bit CHH
Dry CHH 1
Dry CHH 2
Dry CHH 3
Comp CHH 1
Comp CHH 2
Comp CHH 3
Lo-Fi CHH 1
Lo-Fi CHH 2
Lo-Fi CHH 3
Timba CHH
Chill CHH
Mosaic CHH 1
Mosaic CHH 2
Mosaic CHH 3
UltrafunkCH1
UltrafunkCH2
Miami CHH
Lulu CHH
707 Dry CHH
808 Dry CHH
808 Cl&OpHH
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
Miami OHH
Time OHH
UltrafunkOHH
Jiggle OHH
Lo-Bit OHH
Dry OHH
Comp OHH
Lo-Fi OHH
707 Dry OHH
808 Dry OHH1
808 Dry OHH2
808 Dry OHH3
909 Dry OHH1
909 Dry OHH2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

* On the RD series (with SRX slots)/MC-909/VR-760/G-70, you can not select only the

rhythm sets which are designed to be used with the Fantom series/XV series/MX-200.

* On the MC-909, you can use only the rhythm tones for the sixteen keys from

note numbers 35 (B1) through 50 (D3).

18

※

SRX 対応の RD シリーズ /MC-909/VR-760 では、Fantom シリーズ /
XV シリーズ /MX-200 専用のリズム・セットを選ぶことはできません。

※ MC-909 では、Note No. 35（B1）から 50（D3）までの 16 鍵分のリ

ズム・トーンのみ使用できます。

Rhythm Set Key Assign (10)

For RD series (with SRX slots)/MC-909/VR-760/G-70

Note No.

28

29

31

33

35
36

C2

38

40

41

43

45

47

48

C3

50

52

53

55

57

59

60

C4

62

64

65

67

69

71

72

C5

74

76

77

79

81

83

84

C6

86

88

89

91

93

95

96

C7

98

100
101

103

30

32

34

37

39

42

44

46

49

51

54

56

58

61

63

66

68

70

73

75

78

80

82

85

87

90

92

94

97

99

102

29. Clap
Menu

--

--

--

--

--

--

--

--

Single HClp1
Single HClp2
Single HClp3
Real Clap
Lofi Clap1mb
Lofi Clap2mb
Lofi Clap3mb
Buck Clap
Head Knd Clp
Royal Clap
Clap Tail 2
GospelClap
707 Dry Clap
808 Dry Clap
909 Dry Clap

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

30. Cymbal
Menu

--

--

--

--

--

--

--

--

Pop Crash1
Pop Crash2
Pop SprshCym
Pop ChinaCym
Pop Cym Roll
707 Dry CR
909 Dry CR 1
909 Dry CR 2
909 Dry CR 3
PopRideCym 1
PopRideCym 2
PopRideCym 3
PopRideCym 4
707 Dry RD
808 Dry Cym1
808 Dry Cym2
808 Dry Cym3
808 Dry Cym4
909 Dry RD1
909 Dry RD2
909 Dry RD3
MG Nz Cym
US Nz Cym

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

31. Perc.
Menu

--

--

--

--

--

--

--

--

WindChime Up
WindChime Dn
Cwbl Lo
Cwbl Hi
Cwbl Mute
707 Dry Cwbl
808 Dry Cwbl
808 Dry Clvs
Clvs Hi
Clvs Lo
HiBongo Opn
HiBongo Mfld
HiBongo 2
HiBongo Slp1
HiBongo Slp2
HiBongo Mute
LoBongo Opn
LoBongo Slap
808 Dry Hcng
808 Dry Mcng
808 Dry Lcng
LTBit CgH
LTBit CgL
HiConga Opn
HiConga Slap
HiConga Cls
LoConga Opn
Tmbl Hi p
Tmbl Hi f
Tmbl Hi Rim
Tmbl Hi Flm
Tmbl Hi Roll
Tmbl HiPaila
Tmbl Lo p
Tmbl Lo Flm
Latin Hit
Chekele 1
Chekele 2
Real Shaker1
Real Shaker2
Real Shaker3
Real Cabasa3
808 Dry Mrcs
Short Guiro2
Long Guiro2
Long Tamb
707 Dry Tamb
Short Tri
Long Triangl
Short FgSnap
St. FgSnap

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

32. FX
Menu

--

--

--

--

--

--

--

--

Electric Saw
Cartn Fall
Cartn Boing1
Cartn Boing2
LoTek Bit
LoFi Hole
LoFi Coo
LoFi Bit 1
LoFi Bit 2
Nz Pass
Thumpkin
Dist Slide
Howl Sync
Slipper Hit
Spoon Hit
Pod Hit
LoFi Shaker
Box Hit 1
Hard Shaker
LoFi Pod Hit
Press Hit
Swish Hit
Rumble Hit
Cym Slide
Knock Hit 1
Knock Hit 2
Swish Rope 1
Swish Rope 2
Swish Rope 3
Swish Rope 4
Metal Atk Lo
Metal Atk
Fl Press Hit
Dump Hit
Vice Hit 1
Vice Hit 2
Vice Hit 3
Box Hit 2
Flute Fx 1
Flute Fx 2
Flute Fx 3
Sax Fx 1
Sax Fx 2
Sax Fx 3
Whoo! M
You’re DJ M
Groove M
Com’on M
Yeah M
Wow Yeah F
Yeah F
Ho F
Aow F
Oh F
Scratch 4
Scratch 5
Scratch 6
Scratch 7
Scratch 8
Scratch 9
Scratch 10
Scratch 11
Scratch 12
Scratch 13
Scratch 14
Scratch 15
Vinyl NzLp 1
Vinyl NzLp 2

33. SynPerc.
Menu

--

--

--

--

--

--

--

--

US Metal 2
US Metal 1
OSC Perc 2
OSC Perc 1
MG NoiseHit
SH2 S Zap 1
SH2 S Zap 2
SH2 S Zap 3
SH2 S Zap 4
SH2 S Zap 5
MG S Zap 1
MG S Zap 2
MG S Zap 3
SH2 U Zap 1
SH2 U Zap 2
SH2 U Zap 3
SH2 U Zap 4
SH2 U Zap 5
SH2 U Zap 6
Ring FX 1
Ring FX 2
US SweepD L1
US SweepD S1
US SweepD L2
US SweepD S2
US SweepD L3
MG SweepDn
US SweepU L1
US SweepU L2

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

--

34. All TR
Menu

--

--

--

--

--

--

--

--

707 DryKick1
707 DryKick2
707 Dry SD1
707 Dry SD2
707 Dry LTom
707 Dry MTom
707 Dry HTom
707 Dry RSht
707 Dry Cwbl
707 Dry Clap
707 Dry Tamb
707 Dry CHH
707 Dry OHH
707 Dry CR
707 Dry RD
808 DryKick1
808 DryKick2
808 DryKick3
808 DryKick4
808 DryKick5
808 Dry SD1
808 Dry SD2
808 Dry SD3
808 Dry LTom
808 Dry MTom
808 Dry HTom
808 Dry Lcng
808 Dry Mcng
808 Dry Hcng
808 Dry RSht
808 Dry Clvs
808 Dry Mrcs
808 Dry Clap
808 Dry Cwbl
808 Dry Cym1
808 Dry Cym2
808 Dry Cym3
808 Dry Cym4
808 Dry CHH
808 Cl&OpHH
808 Dry OHH1
808 Dry OHH2
808 Dry OHH3
909 DryKick3
909 DryKick2
909 DryKick1
909 Dry SD1
909 Dry SD4
909 Dry SD3
909 Dry SD5
909 Dry SD2
909 SD&CLP
909 Dry LTom
909 Dry MTom
909 Dry HTom
909 Dry RSht
909 Dry Clap
909 Dry CHH1
909 Dry CHH2
909 Dry CHH3
909 Dry OHH1
909 Dry OHH2
909 Dry CR 1
909 Dry CR 2
909 Dry CR 3
909 Dry RD1
909 Dry RD2
909 Dry RD3

* On the RD series (with SRX slots)/MC-909/VR-760/G-70, you can not select only the

rhythm sets which are designed to be used with the Fantom series/XV series/MX-200.

* On the MC-909, you can use only the rhythm tones for the sixteen keys from

note numbers 35 (B1) through 50 (D3).

※

SRX 対応の RD シリーズ /MC-909/VR-760 では、Fantom シリーズ /
XV シリーズ /MX-200 専用のリズム・セットを選ぶことはできません。

※ MC-909 では、Note No. 35（B1）から 50（D3）までの 16 鍵分のリ

ズム・トーンのみ使用できます。

19

Waveform List (1)

No. Name

1 PhraseMenuL * **
2 PhraseMenuR * **
3 080:BladeBtL * #
4 080:BladeBtR * #
5 093:R&Bees #
6 096:RugBurnL * #
7 096:RugBurnR * #
8 120:BossClbL * #
9 120:BossClbR * #
10 120:ClubbinL * #
11 120:ClubbinR * #
12 135:XRacer L * #
13 135:XRacer R * #
14 Drain-O L *
15 Drain-O R *
16 RocketBrs L *
17 RocketBrs R *
18 Resound L *
19 Resound R *
20 StrikeWhstle
21 Blowout L *
22 Blowout R *
23 MGSAW HQ
24 P5SAW HQ
25 106 Saw HQ
26 SH101SAW HQ
27 TB303SAW HQ
28 CustomSawA2
29 JU2SpSaw2
30 JU2SpSaw3
31 JU2SpSaw4
32 OB2 Pat7
33 JPSuperSaw
34 JP8SQU HQ
35 MGSQU HQ
36 P5SQU HQ
37 CustomSquA2
38 TB303SQU HQ
39 106 SubOsc
40 JU2SpSub1
41 JU2SpSub2
42 JP8PLS05 HQ
43 JP8PLS15 HQ
44 JP8PLS20 HQ
45 JP8PLS30 HQ
46 JP8PLS40 HQ
47 JP8PLS45 HQ
48 SyncPlsInv
49 JUNO Pls Bd
50 JUNO Pls Rls

No. Name

51 JP6 DynPLS P
52 JP6 DynPLS N
53 JUNO106 Rave
54 MGTRI HQ
55 JP8TRI HQ
56 Variant Sin
57 ARP SIN
58 CalcSIN2
59 106 Bs56
60 Spct11
61 Sprk vx2
62 Spct2 20
63 MG WhteNz HQ
64 MG PinkNz HQ
65 Spect Noise
66 JD PnoEQ
67 EP Chd Menu **
68 EP Maj 9th
69 EP Maj 11th
70 EP Min 11th
71 FM Clavi mf
72 Old Hous Org
73 FM Prc Organ
74 Fing E.Bs mf
75 Fing E.Bs ff
76 Baby Bass f2
77 Baby Bassff2
78 GuitarrnWarm
79 GuitarrnOct2
80 HouseBass mf
81 HouseBass ff
82 Brs Stab L *
83 Brs Stab R *
84 Brs Fall L *
85 Brs Fall R *
86 WindsFX Menu **
87 Flute Fx 1
88 Flute Fx 2
89 Flute Fx 3
90 Sax Fx 1
91 Sax Fx 2
92 Sax Fx 3
93 Gregorian2 L *
94 Gregorian2 R *
95 Dance Str L *
96 Dance Str R *
97 D50Pizzagogo
98 Str Fall L *
99 Str Fall R *
100 StrScaleMajL *

No. Name

101 StrScaleMajR *
102 StrChd MenuL * **
103 StrChd MenuR * **
104 StrChdMin9L *
105 StrChdMin9R *
106 StrChdMn11L *
107 StrChdMn11R *
108 StrSprdMaj L *
109 StrSprdMaj R *
110 StrSprdMin L *
111 StrSprdMin R *
112 E.Gtr Menu L * **
113 E.Gtr Menu R * **
114 ShredFuzzGtr
115 ClnGtrRif1 L *
116 ClnGtrRif1 R *
117 ClnGtrRif2 L *
118 ClnGtrRif2 R *
119 TrmDwnGtr1 L *
120 TrmDwnGtr1 R *
121 TrmDwnGtr2 L *
122 TrmDwnGtr2 R *
123 WahGtrChord *
124 WahGtrCt1 L *
125 WahGtrCt1 R *
126 WahGtrCt2 L *
127 WahGtrCt2 R *
128 WahGtrCt3 L *
129 WahGtrCt3 R *
130 WahGtrCt4 L *
131 WahGtrCt4 R *
132 WahGtrCt5 L *
133 WahGtrCt5 R *
134 WahGtrCt6 L *
135 WahGtrCt6 R *
136 WahGtrRif1 L *
137 WahGtrRif1 R *
138 WahGtrRif2 L *
139 WahGtrRif2 R *
140 Hit SpecialL * **
141 Hit SpecialR * **
142 Hit OneShotL * **
143 Hit OneShotR * **
144 BrassHit 1
145 BrassHit 2
146 BrassHit 3
147 BrassHit 4
148 BrassHit 5
149 BrassHit 6 L *
150 BrassHit 6 R *

No. Name

151 BrassHit 7 L *
152 BrassHit 7 R *
153 BrassHit 8
154 BrassHit 9 L *
155 BrassHit 9 R *
156 BrassHit 10L *
157 BrassHit 10R *
158 BrassHit 11L *
159 BrassHit 11R *
160 BrassHit 12L *
161 BrassHit 12R *
162 BrassHit 13L *
163 BrassHit 13R *
164 BrassHit 14L *
165 BrassHit 14R *
166 BrassHit 15
167 BrassHit 16L *
168 BrassHit 16R *
169 BrassHit 17L *
170 BrassHit 17R *
171 BrassHit 18
172 BrassHit 19L *
173 BrassHit 19R *
174 BrassHit 20
175 BrassHit 21L *
176 BrassHit 21R *
177 BrassHit 22L *
178 BrassHit 22R *
179 BrassHit 23L *
180 BrassHit 23R *
181 BrassHit 24
182 SymphHit 1 L *
183 SymphHit 1 R *
184 SymphHit 2 L *
185 SymphHit 2 R *
186 SymphHit 3 L *
187 SymphHit 3 R *
188 SymphHit 4 L *
189 SymphHit 4 R *
190 SymphHit 5 L *
191 SymphHit 5 R *
192 SymphHit 6 L *
193 SymphHit 6 R *
194 SymphHit 7 L *
195 SymphHit 7 R *
196 Organ Hit 1
197 OrgTrnsplntL *
198 OrgTrnsplntR *
199 Organ Hit 2L *
200 Organ Hit 2R *

No. Name

201 Chord Hit 1
202 Chord Hit 2L *
203 Chord Hit 2R *
204 Chord Hit 3L *
205 Chord Hit 3R *
206 Chord Hit 4
207 Altr Hit L *
208 Altr Hit R *
209 Crystal HitL *
210 Crystal HitR *
211 Dirty Hit 2
212 Exhaust HitL *
213 Exhaust HitR *
214 Scoop Hit L *
215 Scoop Hit R *
216 Stamp Hit L *
217 Stamp Hit R *
218 ThousandHitL *
219 ThousandHitR *
220 9th Hit L *
221 9th Hit R *
222 Slap Hit 1 L *
223 Slap Hit 1 R *
224 Slap Hit 2 L *
225 Slap Hit 2 R *
226 Slap Hit 3 L *
227 Slap Hit 3 R *
228 Dust Hit L *
229 Dust Hit R *
230 Dist Hit 1 L *
231 Dist Hit 1 R *
232 Dist Hit 2 L *
233 Dist Hit 2 R *
234 Slide Hit L *
235 Slide Hit R *
236 Wah Hit
237 Slide Hit 2L *
238 Slide Hit 2R *
239 Tremble Hit
240 Sweep Hit
241 ParabolaHitL *
242 ParabolaHitR *
243 Daw Hit L *
244 Daw Hit R *
245 Dah Hit L *
246 Dah Hit R *
247 Aah Hit
248 Mixed Hit L *
249 Mixed Hit R *
250 Showy Hit

*: These are stereo waveforms, offered in left-right pairs.
**: These are menu waveforms. Include multiple waveforms assigned to

keys individually.

#: These are phrase loop waveform. The numbers included in the wave

name represent the recommended tempo (B.P.M.). And these waveforms
can be synchronized to a device such as a sequencer.

* Some of the waveform names shown in this list may appear differently on the

display of the device being used, but the tones themselves remain unaffected.

When you create a Patch using the waveforms stored in the
Expansion Board, observe the following points:

* If you make a Patch with a single voice and then later play it in a chord, the

sound may be distorted with certain settings for the Effects and TVA. If this
happens, adjust the level of the Effects and TVA.

20

*：

LとRでペアになるステレオ・ウェーブフォームです。

**： メニュー・ウェーブフォームです。複数のウェーブフォームが、各

キーに割り当てられています。

#： フレーズ・ループのウェーブフォームです。ウェーブ・ネームに付い

ている数字は推奨テンポ（B.P.M.）です。また、これらのウェーブ
フォームはシーケンサーなどとの同期が可能です。

※ 一部のウェーブフォームの名前が、本リストと使用機器の画面表示とで

異なる場合がありますが、音色自体に影響はありません。

このエクスパンション・ボードに収められているウェーブフォーム
を使ってパッチを作るときには、次の点に注意してください。

※ 単音でパッチを作ったとき、エフェクトや TVA の設定状態によって、

その音を和音で演奏すると音が歪む場合があります。このようなとき
は、エフェクトや TVA のレベルを調整してください。

Waveform List (2)

No. Name

251 Pretty Hit L *
252 Pretty Hit R *
253 Smoky Hit L *
254 Smoky Hit R *
255 Fist Hit
256 Iron Hit 2
257 Clavy Hit L *
258 Clavy Hit R *
259 Warp Hit 1L *
260 Warp Hit 1R *
261 Warp Hit 2L *
262 Warp Hit 2R *
263 Warp Hit 3L *
264 Warp Hit 3R *
265 Warp Hit 4
266 Tread Hit
267 Old Org Hit
268 Sand Hit
269 Bounce Hit1
270 Bounce Hit2L *
271 Bounce Hit2R *
272 Bounce Hit3
273 Warp Hit 5L *
274 Warp Hit 5R *
275 Bounce Hit4
276 Scratch Menu **
277 Scratch 4
278 Scratch 5
279 Scratch 6
280 Scratch 7
281 Scratch 8
282 Scratch 9
283 Scratch 10
284 Scratch 11
285 Scratch 12
286 Scratch 13
287 Scratch 14
288 Scratch 15
289 Vinyl NzLp 1
290 Vinyl NzLp 2
291 Vox Menu **
292 Whoo! M
293 You’re DJ M
294 Groove M
295 Com’on M
296 Yeah M
297 Wow Yeah F
298 Yeah F
299 Ho F
300 Aow F

No. Name

301 Oh F
302 R&B Kick 1
303 LoBit Kick 1
304 LoBit Kick 2
305 Old Kick 1
306 Old Kick 2
307 Metal Kick
308 Old Kick 3
309 Rebo Kick 1
310 Abuz Kick
311 Cool Kick 1
312 Dyna Kick
313 Floor Kick
314 Gan Kick
315 GoGo Kick
316 Livn Kick
317 Old Kick 4
318 Mellow Kick
319 Two Kick
320 Gummo Kick 1
321 Gummo Kick 2
322 R&B Kick 2
323 Narrow Kick
324 Alley Kick 1
325 Alley Kick 2
326 FunkB Kick
327 Light Kick 1
328 Light Kick 2
329 Light Kick 3
330 L-RiderKick1
331 Light Kick 4
332 Light Kick 5
333 Light Kick 6
334 H-Rider Kick
335 Light Kick 7
336 L-RiderKick2
337 Light Kick 8
338 ChickenKick1
339 Edge Kick
340 Buck Kick
341 Layer Kick 1
342 Layer Kick 2
343 Layer Kick 3
344 Layer Kick 4
345 Retro Kick 1
346 Ambi Kick
347 Cbell Kick
348 Tamb Kick
349 Retro Kick 2
350 Pump Kick

No. Name

351 Heavy Kick 1
352 Heavy Kick 2
353 Heavy Kick 3
354 Heavy Kick 4
355 Layer Kick 5
356 Shake Kick
357 Rebo Kick 2
358 Chop Kick
359 Cool Kick 2
360 Light Kick 9
361 Seiz Kick
362 Soul Kick
363 Trip Kick
364 Lo-Tek Kick
365 Filter Kick
366 Vinyl Kick
367 Blade Kick
368 Club Kick
369 Dinky Kick 1
370 Dinky Kick 2
371 Dinky Kick 3
372 Dinky Kick 4
373 Old Kick 5
374 Hybrid Kick3
375 Slopey Kick1
376 Junk Kick
377 707 DryKick1
378 707 DryKick2
379 808 DryKick1
380 808 DryKick2
381 808 DryKick3
382 808 DryKick4
383 808 DryKick5
384 Analog Kick1
385 Analog Kick2
386 909 DryKick1
387 909 DryKick2
388 909 DryKick3
389 Craze Kick 1
390 Craze Kick 2
391 106 Kick 1
392 106 Kick 2
393 MG Kick 1
394 MG Kick 2
395 Fat Kick
396 Croak Kick 1
397 Fuzz Kick
398 ChickenKick2
399 Motor Kick
400 Craze Kick 3

No. Name

401 Craze Kick 4
402 Layer Kick 6
403 Plump Kick
404 Deviant Kick
405 Dance Kick 5
406 Dance Kick 6
407 Dance Kick 7
408 Dance Kick 8
409 BigDrds Kick
410 Slopey Kick2
411 Swanky Kick
412 SnugBugaKick
413 Synth Kick
414 DeeBee Kick
415 HipHop SD 1
416 R&B SD 1
417 Lo-Bit SD 1
418 Blade SD
419 Basis SD 1
420 Gruntoid SD
421 L-Rider SD
422 Craze SD 1
423 R&B SD 2
424 Lo-Bit SD 2
425 Metalic SD
426 Noisy SD
427 Pump SD
428 Dinky SD 1
429 Dinky SD 2
430 Dinky SD 3
431 Basis SD 2
432 Basis SD 3
433 Basis SD 4
434 Retro SD 1
435 HiTune SD
436 Snapy SD
437 Thin SD
438 Thin SD mb ***
439 Slim SD
440 Rocky SD1
441 Rocky SD1 mb ***
442 Rocky SD2 mb ***
443 Rocky SD3 mb ***
444 Club SD1
445 Club SD2 mb ***
446 Club SD3
447 Club SD3 mb ***
448 Comp SD1 mb ***
449 Comp SD2 mb ***
450 Rev SD mb ***

No. Name

451 LoBtHf SD1mb ***
452 LoBtHf SD2mb ***
453 LoBtHf SD3mb ***
454 LoBtHf SD4mb ***
455 LoBtHf SD5mb ***
456 LoBtHf SD6mb ***
457 Light SD1
458 Light SD1 mb ***
459 Light SD2
460 Light SD2 mb ***
461 Alley SD1
462 Alley SD1mb ***
463 BigDreds SD
464 H-Rider SD
465 PFunkSD mb ***
466 Slopey SD
467 Gan SD mb ***
468 GoGo SD mb ***
469 MellowSD mb ***
470 Metal SD mb ***
471 Old SD1 mb ***
472 Old SD2 mb ***
473 Old SD3 mb ***
474 Old SD4 mb ***
475 Old SD5 mb ***
476 Attack SD1
477 Retro SD1
478 Retro SD2 mb ***
479 Retro SD3
480 Retro SD4
481 Retro SD5
482 Retro SD6
483 Hybrid SD mb ***
484 DeeBee SD
485 Old SD6 mb ***
486 Layer SD1 mb ***
487 Layer SD2 mb ***
488 Filter SD1
489 Filter SD2
490 Attack SD2
491 Attack SD3
492 Attack SD4
493 Lo-Tek SD
494 Chicken SD
495 Filter SD3
496 Filter SD4
497 Retro SD7
498 Retro SD8
499 Ultra SD 1
500 Ultra SD 2

*: These are stereo waveforms, offered in left-right pairs.
**: These are menu waveforms. Include multiple

waveforms assigned to keys individually.

***: These are waveforms that have been processed so the

midrange is emphasized.

When you create a Patch using the waveforms stored in the
Expansion Board, observe the following points:

* If you make a Patch with a single voice and then later play it in

a chord, the sound may be distorted with certain settings for
the Effects and TVA. If this happens, adjust the level of the
Effects and TVA.

*：

LとRでペアになるステレオ・ウェーブフォームです。

**： メニュー・ウェーブフォームです。複数のウェーブ

フォームが、各キーに割り当てられています。

***：中音域を強調する処理を施したウェーブフォームです。
このエクスパンション・ボードに収められているウェーブ

フォームを使ってパッチを作るときには、次の点に注意して
ください。

※ 単音でパッチを作ったとき、エフェクトや TVA の設定

状態によって、その音を和音で演奏すると音が歪む場合
があります。このようなときは、エフェクトや TVA の
レベルを調整してください。

21

Waveform List (3)

No. Name

501 Funky SD
502 Layer SD3
503 Layer SD4 mb ***
504 Alley SD2
505 Alley SD2 mb ***
506 Fella SD1 mb ***
507 Fella SD2
508 Fella SD2 mb ***
509 Rebo SD1
510 Rebo SD1 mb ***
511 Rebo SD2
512 Swush SD mb ***
513 Heat SD mb ***
514 Layer SD5 mb ***
515 Cool SD
516 GoGo SD
517 Soul SD mb ***
518 Layer SD6
519 Funk SD1
520 Funk SD2
521 Dinky SD4 mb ***
522 Layer SD7 mb ***
523 Layer SD8 mb ***
524 Layer SD9 mb ***
525 Vynil SD mb ***
526 FilterSD5 mb ***
527 Junk SD mb ***
528 707 Dry SD1
529 707 Dry SD2
530 808 Dry SD1
531 808 Dry SD2
532 808 Dry SD3
533 909 Dry SD1
534 909 Dry SD2
535 909 Dry SD3
536 909 Dry SD4
537 909 Dry SD5
538 909 SD&CLP
539 106 SD1
540 106 SD2
541 Clappy SD
542 Cranky SD
543 Grim SD
544 Sparkle SD
545 SparkleSD mb ***
546 Hush SD mb ***
547 R&B Crs Stk1
548 R&B Crs Stk2
549 Lo-Bit CStk
550 707 Dry RSht

No. Name

551 808 Dry RSht
552 909 Dry RSht
553 Basis Rim
554 Basis Rim mb ***
555 Deviant RM1
556 Devi RM1mb ***
557 Deviant RM2
558 Deviant RM3
559 Devi RM3mb ***
560 Hop RimShot1
561 Hop RimShot2
562 Hop RimShot3
563 Old HTom A1
564 Old HTom A2
565 Old HTom A3
566 Old LTom A1
567 Old LTom A2
568 Old HTom B1
569 Old HTom B2
570 Old HTom B3
571 Old LTom B1
572 Old LTom B2
573 Retro Tom1
574 Retro Tom2
575 Sim5 Tom1S
576 Sim5 Tom1F
577 Sim5 Tom2S
578 Sim5 Tom2F
579 Sim5 Tom3S
580 Sim5 Tom3F
581 Sim5 Tom4S
582 Sim5 Tom4F
583 707 Dry HTom
584 707 Dry MTom
585 707 Dry LTom
586 808 Dry HTom
587 808 Dry MTom
588 808 Dry LTom
589 909 Dry HTom
590 909 Dry MTom
591 909 Dry LTom
592 Lo-Tek HH1
593 Lo-Tek HH2
594 Lo-Tek HH3
595 Lo-Tek HH4
596 Lo-Bit CHH
597 Dry CHH 1
598 Dry CHH 2
599 Dry CHH 3
600 Comp CHH 1

No. Name

601 Comp CHH 2
602 Comp CHH 3
603 Lo-Fi CHH 1
604 Lo-Fi CHH 2
605 Lo-Fi CHH 3
606 Timba CHH
607 Chill CHH
608 Mosaic CHH 1
609 Mosaic CHH 2
610 Mosaic CHH 3
611 UltrafunkCH1
612 UltrafunkCH2
613 Miami CHH
614 Lulu CHH
615 707 Dry CHH
616 808 Dry CHH
617 808 Cl&OpHH
618 909 Dry CHH1
619 909 Dry CHH2
620 909 Dry CHH3
621 Miami OHH
622 Time OHH
623 UltrafunkOHH
624 Jiggle OHH
625 Lo-Bit OHH
626 Dry OHH
627 Comp OHH
628 Lo-Fi OHH
629 707 Dry OHH
630 808 Dry OHH1
631 808 Dry OHH2
632 808 Dry OHH3
633 909 Dry OHH1
634 909 Dry OHH2
635 Single HClp1
636 Single HClp2
637 Single HClp3
638 Real Clap L *
639 Real Clap R *
640 Lofi Clap1mb ***
641 Lofi Clap2mb ***
642 Lofi Clap3mb ***
643 Buck Clap
644 Head Knd Clp
645 Royal Clap
646 Clap Tail 2
647 GospelClap L *
648 GospelClap R *
649 707 Dry Clap
650 808 Dry Clap

No. Name

651 909 Dry Clap
652 Pop Crash1
653 Pop Crash2
654 Pop SprshCym
655 Pop ChinaCym
656 Pop Cym Roll
657 707 Dry CR
658 909 Dry CR 1
659 909 Dry CR 2
660 909 Dry CR 3
661 PopRideCym 1
662 PopRideCym 2
663 PopRideCym 3
664 PopRideCym 4
665 707 Dry RD
666 808 Dry Cym1
667 808 Dry Cym2
668 808 Dry Cym3
669 808 Dry Cym4
670 909 Dry RD1
671 909 Dry RD2
672 909 Dry RD3
673 MG Nz Cym
674 US Nz Cym
675 WindChime Up
676 WindChime Dn
677 Cwbl Lo
678 Cwbl Hi
679 Cwbl Mute
680 707 Dry Cwbl
681 808 Dry Cwbl
682 808 Dry Clvs
683 Clvs Hi
684 Clvs Lo
685 HiBongo Opn
686 HiBongo Mfld
687 HiBongo 2
688 HiBongo Slp1
689 HiBongo Slp2
690 HiBongo Mute
691 LoBongo Opn
692 LoBongo Slap
693 808 Dry HCng
694 808 Dry MCng
695 808 Dry LCng
696 LTBit CgH L *
697 LTBit CgH R *
698 LTBit CgL L *
699 LTBit CgL R *
700 HiConga Opn

No. Name

701 HiConga Slap
702 HiConga Cls
703 LoConga Opn
704 Tmbl Hi p
705 Tmbl Hi f
706 Tmbl Hi Rim
707 Tmbl Hi Flm
708 Tmbl Hi Roll
709 Tmbl HiPaila
710 Tmbl Lo p
711 Tmbl Lo Flm
712 Latin Hit
713 Chekele 1
714 Chekele 2
715 Real Shaker1
716 Real Shaker2
717 Real Shaker3
718 Real Cabasa3
719 808 Dry Mrcs
720 Short Guiro2
721 Long Guiro2
722 Long Tamb
723 707 Dry Tamb
724 Long Triangl
725 Short FgSnap
726 St. FgSnap L *
727 St. FgSnap R *
728 Bobs Slide
729 Cave Hit L *
730 Cave Hit R *
731 Warp Hit 6
732 Thru Hit 1
733 Thru Hit 2
734 Mull Hit
735 Warp Hit 7
736 Warp Hit 8
737 Electronica
738 Ripper L *
739 Ripper R *
740 Warp Hit 9
741 Tickle Hit
742 PercolateHit
743 Tramp Hit L *
744 Tramp Hit R *
745 LoFi Moan
746 Sonar Hit
747 Electric Saw
748 Cartn Fall L *
749 Cartn Fall R *
750 Cartn Boing1

*: These are stereo waveforms, offered in left-right pairs.

**: These are menu waveforms. Include multiple

waveforms assigned to keys individually.

***: These are waveforms that have been processed so the

midrange is emphasized.

When you create a Patch using the waveforms stored in the
Expansion Board, observe the following points:

* If you make a Patch with a single voice and then later play it in

a chord, the sound may be distorted with certain settings for
the Effects and TVA. If this happens, adjust the level of the
Effects and TVA.

22

*：

LとRでペアになるステレオ・ウェーブフォームです。

**： メニュー・ウェーブフォームです。複数のウェーブ

フォームが、各キーに割り当てられています。
***：中音域を強調する処理を施したウェーブフォームです。
このエクスパンション・ボードに収められているウェーブ

フォームを使ってパッチを作るときには、次の点に注意して
ください。

※ 単音でパッチを作ったとき、エフェクトや TVA の設定

状態によって、その音を和音で演奏すると音が歪む場合
があります。このようなときは、エフェクトや TVA の

レベルを調整してください。

Waveform List (4)

No. Name

751 Cartn Boing2
752 LoTek Bit L *
753 LoTek Bit R *
754 LoFi Hole
755 LoFi Coo
756 LoFi Bit 1
757 LoFi Bit 2
758 Nz Pass L *
759 Nz Pass R *
760 Thumpkin L *
761 Thumpkin R *
762 Dist Slide L *
763 Dist Slide R *
764 Howl Sync
765 Slipper Hit

No. Name

766 Spoon Hit
767 Pod Hit
768 LoFi Shaker
769 Box Hit 1
770 Hard Shaker
771 LoFi Pod Hit
772 Press Hit
773 Swish Hit
774 Rumble Hit
775 Cym Slide
776 Knock Hit 1
777 Knock Hit 2
778 Swish Rope 1
779 Swish Rope 2
780 Swish Rope 3

No. Name

781 Swish Rope 4
782 Metal Atk Lo
783 Metal Atk Hi
784 Fl Press Hit
785 Dump Hit
786 Vice Hit 1
787 Vice Hit 2
788 Vice Hit 3
789 Box Hit 2
790 US Metal 1
791 US Metal 2
792 MG NoiseHit
793 SH2 S Zap 1
794 SH2 S Zap 2
795 SH2 S Zap 3

*: These are stereo waveforms, offered in left-right pairs.

**: These are menu waveforms. Include multiple

waveforms assigned to keys individually.

***: These are waveforms that have been processed so the

midrange is emphasized.

When you create a Patch using the waveforms stored in the
Expansion Board, observe the following points:

* If you make a Patch with a single voice and then later play it in

a chord, the sound may be distorted with certain settings for
the Effects and TVA. If this happens, adjust the level of the
Effects and TVA.

No. Name

796 SH2 S Zap 4
797 SH2 S Zap 5
798 MG S Zap 1
799 MG S Zap 2
800 MG S Zap 3
801 SH2 U Zap 1
802 SH2 U Zap 2
803 SH2 U Zap 3
804 SH2 U Zap 4
805 SH2 U Zap 5
806 SH2 U Zap 6
807 Ring FX 1
808 Ring FX 2
809 OSC Perc 1
810 OSC Perc 2

*：

LとRでペアになるステレオ・ウェーブフォームです。

No. Name

811 US SweepD L1
812 US SweepD S1
813 US SweepD L2
814 US SweepD S2
815 US SweepD L3
816 MG SweepDn
817 US SweepU L1
818 US SweepU L2

**： メニュー・ウェーブフォームです。複数のウェーブ

フォームが、各キーに割り当てられています。
***：中音域を強調する処理を施したウェーブフォームです。
このエクスパンション・ボードに収められているウェーブ

フォームを使ってパッチを作るときには、次の点に注意して
ください。

※ 単音でパッチを作ったとき、エフェクトや TVA の設定

状態によって、その音を和音で演奏すると音が歪む場合
があります。このようなときは、エフェクトや TVA の
レベルを調整してください。

1:2 PhraseMenu *

Key Wave Name

C4 080:BladeBt
D4 093:R&Bees
E4 096:RugBurn
F4 120:BossClb
G4 120:Clubbin
A4 135:XRacer

67 EP Chd Menu

Key Wave Name

C3 EP Maj 9th
C4 EP Maj 11th
C6 EP Min 11th

86 WindsFX Menu

Key Wave Name

C4 Flute Fx 1
D4 Flute Fx 2
E4 Flute Fx 3
F4 Sax Fx 1
G4 Sax Fx 2
A4 Sax Fx 3

Menu Waveform

102:103 StrChd Menu *

Key Wave Name

C3 StrChdMin9
C4 StrChdMn11
C5 StrSprdMaj
C6 StrSprdMin
C7 StrSprdMaj Reverse

112:113 E.Gtr Menu *

Key Wave Name

C2 ShredFuzzGtr
A4 WahGtrChord
A#4 WahGtrCt5
B4 WahGtrCt6
C5 WahGtrCt4
C#5 WahGtrCt3
D5 WahGtrCt2
D#5 WahGtrCt1
E5 WahGtrRif1
F5 WahGtrRif2
F#5 ClnGtrRif1
G5 ClnGtrRif2
C6 TrmDwnGtr1
C7 TrmDwnGtr2
C8 ShredFuzzGtr Reverse

140:141 Hit Special *

Key Wave Name

C2 Bobs Slide
D2 BrassHit 1
E2 BrassHit 5
F2 BrassHit 6
G2 BrassHit 7
A2 BrassHit 10
B2 BrassHit 11
C3 BrassHit 13
D3 BrassHit 14
E3 BrassHit 18
F3 BrassHit 19
G3 BrassHit 20
A3 SymphHit 1
B3 SymphHit 3
C4 SymphHit 5
D4 SymphHit 7
E4 OrgTrnsplnt
F4 Organ Hit 2
G4 Chord Hit 2
A4 Chord Hit 3
B4 Exhaust Hit
C5 Scoop Hit
D5 ThousandHit
E5 Slap Hit 1
F5 Slap Hit 3
G5 Dist Hit 2

A5 Slide Hit
B5 Wah Hit
C6 ParabolaHit
D6 Dah Hit L
E6 Aah Hit
F6 Ripper
G6 Tickle Hit
A6 Tramp Hit
B6 Bounce Hit2
C7 Chord Hit 1

142:143 Hit OneShot *

Key Wave Name

C4 BrassHit 4
D4 Altr Hit L
E4 Dirty Hit 2
F4 Warp Hit 3
G4 Warp Hit 4
A4 Warp Hit 7
B4 Warp Hit 8
C5 PercolateHit
D5 Bounce Hit1

276 Scratch Menu

Key Wave Name

C4 Scratch 4
D4 Scratch 5
E4 Scratch 6
F4 Scratch 7
G4 Scratch 8
A4 Scratch 9
B4 Scratch 10
C5 Scratch 11
D5 Scratch 12
E5 Scratch 13
F5 Scratch 14
G5 Scratch 15
A5 Vinyl NzLp 1

291 Vox Menu

Key Wave Name

C4 Whoo! M
D4 You’re DJ M
E4 Groove M
F4 Com’on M
G4 Yeah M
A4 Wow Yeah F
B4 Yeah F
C5 Ho F
D5 Aow F
E5 Oh F

*: These use stereo waveforms.

Menu Waveforms provide multiple Waveforms, with each
one assigned to a different key.

*：ステレオ・ウェーブフォームを使用しています。

メニュー・ウェーブフォームは、キーごとに異なるウェーブ
フォームが割り当てられています。

23

B.P.M. Conversion Table/B.P.M.

変換テーブル

By changing the pitch, you can change the B.P.M. (tempo).

The B.P.M. used when sampling the original (Original
B.P.M.) is reproduced by the C4 key when both "c.t." (Coarse
Tune) and "f.t." (Fine Tune) are at "0."

If you want to obtain twice the tempo of the original B.P.M.,
either play the C5 key (key one octave above), or set
"c.t."(Coarse Tune) to +12 and play the C4 key.

For specifics, refer to the separate B.P.M. Conversion Table.

How to Read the Table

B.P.M. Conversion When Creating Patches

The Original B.P.M. is the B.P.M. obtained when the
Waveform is played by the C4 key (when both Coarse and

Fine Tune are at "0"). (Marked with in table.)

For example, to play a B.P.M. 80 Waveform at B.P.M. 93:

dst key / c.t f.t

80 C 4 / 00 00
: : :
93 D#4 / +03 -39

12

Look up the "f.t." (Fine Tune) parameter in the table, and
you will see that the setting for "f.t." should be -39 and that
the D#4 key should be played.

Look up the "c.t." (Coarse Tune) and "f.t." (Fine Tune)
parameters in the table, and you will see that the setting for
"c.t." should be +3, and that for "f.t." should be -39, and that
the C4 key should be played.

So, as you can see from the above example, the settings you
should make change depending on whether you want to
play using the same key or not.

B.P.M. Conversion When Creating Rhythm Sets

Given that the Original Pitch for the Rhythm Set is C4, you
need to set "c.t." (Coarse Tune) for the range C-1 through G9.

To play a Phrase Loop Waveform at the Original B.P.M., set
"c.t." (Coarse Tune) to C4, and "f.t." (Fine Tune) to "0."

To change the B.P.M. for a Phrase Loop Waveform in a
Rhythm Set, look up "key" and "f.t." (Fine Tune) in the table,
and make the necessary settings.

ピッチを変えることにより、B.P.M.（テンポ）を変えること
が可能です。

サンプリング時の B.P.M.（Original B.P.M.）は、キーが C4
でピッチの c.t（コース・チューン）、f.t（ファイン・チュー
ン）が共に 0 のときに再現されます。

もし Original B.P.M. を 2 倍のテンポにしたい場合は、C5
キー（1 オクターブ上のキー）を弾くか、あるいは c.t

（コース・チューン）を +12 にして C4 キーを弾くことにな

ります。
詳しくは別表の B.P.M. 変換テーブルを参照してください。

表の見かた

パッチ作成時の B.P.M. 変換

Original B.P.M. とは、そのウェーブフォームを C4（コース･
チューン、ファイン･チューン共に 0）キーで再生したとき
のB.P.M. です。( 表中の の部分です。)

<例>
Original B.P.M. 80 のウェーブフォームを B.P.M. 93 で再生

したい場合

dst key / c.t f.t

80 C 4 / 00 00
: : :
93 D#4 / +03 -39

1.

2.

（ファイン・チューン）を表で参照の上、c.t=+3、

以上のように、プレイ・キーを C4 キーのままで演奏する
か、プレイ・キーを変更して演奏するかで、設定のしかたが
異なりますので注意してください。

リズム・セット作成時の B.P.M. 変換

リズム・セットでは Original pitch を C4 として、C-1 〜 G9
の範囲で c.t（コース・チューン）を設定します。

フレーズ・ループのウェーブフォームを Original B.P.M. で
再生するには c.t（コース・チューン）= C4、f.t（ファイ
ン・チューン）= 0 に設定します。

リズム・セットでフレーズ・ループのウェーブフォームの
B.P.M. を変更する場合は、B.P.M. 変換テーブルの key と f.t

（ファイン・チューン）の部分を参照して行ってください。

12

ピッチ・パラメーターの f.t（ファイン・チューン）を表
で参照の上、f.t=-39 を設定し、key=D#4 より D#4

キーを弾きます。
ピッチ・パラメーターの c.t（コース・チューン）、f.t

f.t=-39 を設定し、C4 キーを弾きます。

1.

2.

24

B.P.M. Conversion Table (1)

* 96 C 4/ 00 00

Original B.P.M. 80

dst key/c.t f.t

40 C 3/-12 00
41 C 3/-12 +43
42 C#3/-11 -16
43 C#3/-11 +25
44 D 3/-10 -35
45 D 3/-10 +04
46 D 3/-10 +42
47 D#3/-09 -21
48 D#3/-09 +16
49 E 3/-08 -49
50 E 3/-08 -14
51 E 3/-08 +21
52 F 3/-07 -46
53 F 3/-07 -13
54 F 3/-07 +20
55 F#3/-06 -49
56 F#3/-06 -17
57 F#3/-06 +13
58 F#3/-06 +43
59 G 3/-05 -27
60 G 3/-05 +02
61 G 3/-05 +31
62 G#3/-04 -41
63 G#3/-04 -14
64 G#3/-04 +14
65 G#3/-04 +41
66 A 3/-03 -33
67 A 3/-03 -07
68 A 3/-03 +19
69 A 3/-03 +44
70 A#3/-02 -31
71 A#3/-02 -07
72 A#3/-02 +18
73 A#3/-02 +41
74 B 3/-01 -35
75 B 3/-01 -12
76 B 3/-01 +11
77 B 3/-01 +34
78 C 4/ 00 -44
79 C 4/ 00 -22
* 80 C 4/ 00 00
81 C 4/ 00 +22
82 C 4/ 00 +43
83 C#4/+01 -36
84 C#4/+01 -16
85 C#4/+01 +05
86 C#4/+01 +25
87 C#4/+01 +45
88 D 4/+02 -35
89 D 4/+02 -15
90 D 4/+02 +04
91 D 4/+02 +23
92 D 4/+02 +42
93 D#4/+03 -39
94 D#4/+03 -21
95 D#4/+03 -02
96 D#4/+03 +16
97 D#4/+03 +34
98 E 4/+04 -49
99 E 4/+04 -31
100 E 4/+04 -14
101 E 4/+04 +04
102 E 4/+04 +21
103 E 4/+04 +37
104 F 4/+05 -46
105 F 4/+05 -29
106 F 4/+05 -13
107 F 4/+05 +03
108 F 4/+05 +20
109 F 4/+05 +36
110 F#4/+06 -49
111 F#4/+06 -33
112 F#4/+06 -17
113 F#4/+06 -02
114 F#4/+06 +13
115 F#4/+06 +28
116 F#4/+06 +43
117 G 4/+07 -42
118 G 4/+07 -27
119 G 4/+07 -13
120 G 4/+07 +02
121 G 4/+07 +16
122 G 4/+07 +31
123 G 4/+07 +45
124 G#4/+08 -41
125 G#4/+08 -27
126 G#4/+08 -14
127 G#4/+08 00
128 G#4/+08 +14
129 G#4/+08 +27
130 G#4/+08 +41
131 A 4/+09 -46
132 A 4/+09 -33
133 A 4/+09 -20
134 A 4/+09 -07
135 A 4/+09 +06
136 A 4/+09 +19
137 A 4/+09 +31
138 A 4/+09 +44
139 A#4/+10 -44

dst key/c.t f.t

140 A#4/+10 -31
141 A#4/+10 -19
142 A#4/+10 -07
143 A#4/+10 +06
144 A#4/+10 +18
145 A#4/+10 +30
146 A#4/+10 +41
147 B 4/+11 -47
148 B 4/+11 -35
149 B 4/+11 -23
150 B 4/+11 -12
151 B 4/+11 00
152 B 4/+11 +11
153 B 4/+11 +23
154 B 4/+11 +34
155 B 4/+11 +45
156 C 5/+12 -44
157 C 5/+12 -33
158 C 5/+12 -22
159 C 5/+12 -11
160 C 5/+12 00
161 C 5/+12 +11
162 C 5/+12 +22
163 C 5/+12 +32
164 C 5/+12 +43
165 C#5/+13 -47
166 C#5/+13 -36
167 C#5/+13 -26
168 C#5/+13 -16
169 C#5/+13 -05
170 C#5/+13 +05
171 C#5/+13 +15
172 C#5/+13 +25
173 C#5/+13 +35
174 C#5/+13 +45
175 D 5/+14 -45
176 D 5/+14 -35
177 D 5/+14 -25
178 D 5/+14 -15
179 D 5/+14 -06
180 D 5/+14 +04
181 D 5/+14 +14
182 D 5/+14 +23
183 D 5/+14 +33
184 D 5/+14 +42
185 D#5/+15 -49
186 D#5/+15 -39
187 D#5/+15 -30
188 D#5/+15 -21
189 D#5/+15 -12
190 D#5/+15 -02
191 D#5/+15 +07
192 D#5/+15 +16
193 D#5/+15 +25
194 D#5/+15 +34
195 D#5/+15 +42
196 E 5/+16 -49
197 E 5/+16 -40
198 E 5/+16 -31
199 E 5/+16 -22
200 E 5/+16 -14
201 E 5/+16 -05
202 E 5/+16 +04
203 E 5/+16 +12
204 E 5/+16 +21
205 E 5/+16 +29
206 E 5/+16 +37
207 E 5/+16 +46
208 F 5/+17 -46
209 F 5/+17 -37
210 F 5/+17 -29
211 F 5/+17 -21
212 F 5/+17 -13
213 F 5/+17 -05
214 F 5/+17 +03
215 F 5/+17 +12
216 F 5/+17 +20
217 F 5/+17 +28
218 F 5/+17 +36
219 F 5/+17 +43
220 F#5/+18 -49
221 F#5/+18 -41
222 F#5/+18 -33
223 F#5/+18 -25
224 F#5/+18 -17
225 F#5/+18 -10
226 F#5/+18 -02
227 F#5/+18 +06
228 F#5/+18 +13
229 F#5/+18 +21
230 F#5/+18 +28
231 F#5/+18 +36
232 F#5/+18 +43
233 G 5/+19 -49
234 G 5/+19 -42
235 G 5/+19 -34
236 G 5/+19 -27
237 G 5/+19 -20
238 G 5/+19 -13
239 G 5/+19 -05
240 G 5/+19 +02

Original B.P.M. 93

dst key/c.t f.t

40 A 2/-15 +39
41 A#2/-14 -18
42 A#2/-14 +24
43 B 2/-13 -35
44 B 2/-13 +04
45 B 2/-13 +43
46 C 3/-12 -19
47 C 3/-12 +19
48 C#3/-11 -45
49 C#3/-11 -09
50 C#3/-11 +26
51 D 3/-10 -40
52 D 3/-10 -06
53 D 3/-10 +27
54 D#3/-09 -41
55 D#3/-09 -09
56 D#3/-09 +22
57 E 3/-08 -48
58 E 3/-08 -17
59 E 3/-08 +12
60 E 3/-08 +41
61 F 3/-07 -30
62 F 3/-07 -02
63 F 3/-07 +26
64 F#3/-06 -47
65 F#3/-06 -20
66 F#3/-06 +06
67 F#3/-06 +32
68 G 3/-05 -42
69 G 3/-05 -17
70 G 3/-05 +08
71 G 3/-05 +33
72 G#3/-04 -43
73 G#3/-04 -19
74 G#3/-04 +04
75 G#3/-04 +28
76 A 3/-03 -49
77 A 3/-03 -27
78 A 3/-03 -05
79 A 3/-03 +18
80 A 3/-03 +39
81 A#3/-02 -39
82 A#3/-02 -18
83 A#3/-02 +03
84 A#3/-02 +24
85 A#3/-02 +44
86 B 3/-01 -35
87 B 3/-01 -15
88 B 3/-01 +04
89 B 3/-01 +24
90 B 3/-01 +43
91 C 4/ 00 -38
92 C 4/ 00 -19
* 93 C 4/ 00 00
94 C 4/ 00 +19
95 C 4/ 00 +37
96 C#4/+01 -45
97 C#4/+01 -27
98 C#4/+01 -09
99 C#4/+01 +08
100 C#4/+01 +26
101 C#4/+01 +43
102 D 4/+02 -40
103 D 4/+02 -23
104 D 4/+02 -06
105 D 4/+02 +10
106 D 4/+02 +27
107 D 4/+02 +43
108 D#4/+03 -41
109 D#4/+03 -25
110 D#4/+03 -09
111 D#4/+03 +06
112 D#4/+03 +22
113 D#4/+03 +37
114 E 4/+04 -48
115 E 4/+04 -32
116 E 4/+04 -17
117 E 4/+04 -03
118 E 4/+04 +12
119 E 4/+04 +27
120 E 4/+04 +41
121 F 4/+05 -44
122 F 4/+05 -30
123 F 4/+05 -16
124 F 4/+05 -02
125 F 4/+05 +12
126 F 4/+05 +26
127 F 4/+05 +39
128 F#4/+06 -47
129 F#4/+06 -34
130 F#4/+06 -20
131 F#4/+06 -07
132 F#4/+06 +06
133 F#4/+06 +19
134 F#4/+06 +32
135 F#4/+06 +45
136 G 4/+07 -42
137 G 4/+07 -29
138 G 4/+07 -17
139 G 4/+07 -04

dst key/c.t f.t

140 G 4/+07 +08
141 G 4/+07 +20
142 G 4/+07 +33
143 G 4/+07 +45
144 G#4/+08 -43
145 G#4/+08 -31
146 G#4/+08 -19
147 G#4/+08 -07
148 G#4/+08 +04
149 G#4/+08 +16
150 G#4/+08 +28
151 G#4/+08 +39
152 A 4/+09 -49
153 A 4/+09 -38
154 A 4/+09 -27
155 A 4/+09 -16
156 A 4/+09 -05
157 A 4/+09 +07
158 A 4/+09 +18
159 A 4/+09 +28
160 A 4/+09 +39
161 A#4/+10 -50
162 A#4/+10 -39
163 A#4/+10 -29
164 A#4/+10 -18
165 A#4/+10 -07
166 A#4/+10 +03
167 A#4/+10 +13
168 A#4/+10 +24
169 A#4/+10 +34
170 A#4/+10 +44
171 B 4/+11 -46
172 B 4/+11 -35
173 B 4/+11 -25
174 B 4/+11 -15
175 B 4/+11 -06
176 B 4/+11 +04
177 B 4/+11 +14
178 B 4/+11 +24
179 B 4/+11 +34
180 B 4/+11 +43
181 C 5/+12 -47
182 C 5/+12 -38
183 C 5/+12 -28
184 C 5/+12 -19
185 C 5/+12 -09
186 C 5/+12 00
187 C 5/+12 +09
188 C 5/+12 +19
189 C 5/+12 +28
190 C 5/+12 +37
191 C 5/+12 +46
192 C#5/+13 -45
193 C#5/+13 -36
194 C#5/+13 -27
195 C#5/+13 -18
196 C#5/+13 -09
197 C#5/+13 -01
198 C#5/+13 +08
199 C#5/+13 +17
200 C#5/+13 +26
201 C#5/+13 +34
202 C#5/+13 +43
203 D 5/+14 -49
204 D 5/+14 -40
205 D 5/+14 -32
206 D 5/+14 -23
207 D 5/+14 -15
208 D 5/+14 -06
209 D 5/+14 +02
210 D 5/+14 +10
211 D 5/+14 +18
212 D 5/+14 +27
213 D 5/+14 +35
214 D 5/+14 +43
215 D#5/+15 -49
216 D#5/+15 -41
217 D#5/+15 -33
218 D#5/+15 -25
219 D#5/+15 -17
220 D#5/+15 -09
221 D#5/+15 -02
222 D#5/+15 +06
223 D#5/+15 +14
224 D#5/+15 +22
225 D#5/+15 +30
226 D#5/+15 +37
227 D#5/+15 +45
228 E 5/+16 -48
229 E 5/+16 -40
230 E 5/+16 -32
231 E 5/+16 -25
232 E 5/+16 -17
233 E 5/+16 -10
234 E 5/+16 -03
235 E 5/+16 +05
236 E 5/+16 +12
237 E 5/+16 +20
238 E 5/+16 +27
239 E 5/+16 +34
240 E 5/+16 +41

Original B.P.M. 96

dst key/c.t f.t

40 A 2/-15 -16
41 A 2/-15 +27
42 A#2/-14 -31
43 A#2/-14 +10
44 A#2/-14 +49
45 B 2/-13 -12
46 B 2/-13 +26
47 C 3/-12 -36
48 C 3/-12 00
49 C 3/-12 +36
50 C#3/-11 -29
51 C#3/-11 +05
52 C#3/-11 +39
53 D 3/-10 -28
54 D 3/-10 +04
55 D 3/-10 +36
56 D#3/-09 -33
57 D#3/-09 -02
58 D#3/-09 +28
59 E 3/-08 -43
60 E 3/-08 -14
61 E 3/-08 +15
62 E 3/-08 +43
63 F 3/-07 -29
64 F 3/-07 -02
65 F 3/-07 +25
66 F#3/-06 -49
67 F#3/-06 -23
68 F#3/-06 +03
69 F#3/-06 +28
70 G 3/-05 -47
71 G 3/-05 -22
72 G 3/-05 +02
73 G 3/-05 +26
74 G 3/-05 +49
75 G#3/-04 -27
76 G#3/-04 -04
77 G#3/-04 +18
78 G#3/-04 +41
79 A 3/-03 -37
80 A 3/-03 -16
81 A 3/-03 +06
82 A 3/-03 +27
83 A 3/-03 +48
84 A#3/-02 -31
85 A#3/-02 -11
86 A#3/-02 +10
87 A#3/-02 +30
88 A#3/-02 +49
89 B 3/-01 -31
90 B 3/-01 -12
91 B 3/-01 +07
92 B 3/-01 +26
93 B 3/-01 +45
94 C 4/ 00 -36
95 C 4/ 00 -18

97 C 4/ 00 +18
98 C 4/ 00 +36
99 C#4/+01 -47
100 C#4/+01 -29
101 C#4/+01 -12
102 C#4/+01 +05
103 C#4/+01 +22
104 C#4/+01 +39
105 D 4/+02 -45
106 D 4/+02 -28
107 D 4/+02 -12
108 D 4/+02 +04
109 D 4/+02 +20
110 D 4/+02 +36
111 D#4/+03 -49
112 D#4/+03 -33
113 D#4/+03 -18
114 D#4/+03 -02
115 D#4/+03 +13
116 D#4/+03 +28
117 D#4/+03 +42
118 E 4/+04 -43
119 E 4/+04 -28
120 E 4/+04 -14
121 E 4/+04 +01
122 E 4/+04 +15
123 E 4/+04 +29
124 E 4/+04 +43
125 F 4/+05 -43
126 F 4/+05 -29
127 F 4/+05 -16
128 F 4/+05 -02
129 F 4/+05 +12
130 F 4/+05 +25
131 F 4/+05 +38
132 F#4/+06 -49
133 F#4/+06 -36
134 F#4/+06 -23
135 F#4/+06 -10
136 F#4/+06 +03
137 F#4/+06 +16
138 F#4/+06 +28
139 F#4/+06 +41

dst key/c.t f.t

140 G 4/+07 -47
141 G 4/+07 -34
142 G 4/+07 -22
143 G 4/+07 -10
144 G 4/+07 +02
145 G 4/+07 +14
146 G 4/+07 +26
147 G 4/+07 +38
148 G 4/+07 +49
149 G#4/+08 -39
150 G#4/+08 -27
151 G#4/+08 -16
152 G#4/+08 -04
153 G#4/+08 +07
154 G#4/+08 +18
155 G#4/+08 +29
156 G#4/+08 +41
157 A 4/+09 -48
158 A 4/+09 -37
159 A 4/+09 -26
160 A 4/+09 -16
161 A 4/+09 -05
162 A 4/+09 +06
163 A 4/+09 +17
164 A 4/+09 +27
165 A 4/+09 +38
166 A 4/+09 +48
167 A#4/+10 -42
168 A#4/+10 -31
169 A#4/+10 -21
170 A#4/+10 -11
171 A#4/+10 -01
172 A#4/+10 +10
173 A#4/+10 +20
174 A#4/+10 +30
175 A#4/+10 +39
176 A#4/+10 +49
177 B 4/+11 -41
178 B 4/+11 -31
179 B 4/+11 -21
180 B 4/+11 -12
181 B 4/+11 -02
182 B 4/+11 +07
183 B 4/+11 +17
184 B 4/+11 +26
185 B 4/+11 +36
186 B 4/+11 +45
187 C 5/+12 -46
188 C 5/+12 -36
189 C 5/+12 -27
190 C 5/+12 -18
191 C 5/+12 -09
192 C 5/+12 00
193 C 5/+12 +09
194 C 5/+12 +18
195 C 5/+12 +27
196 C 5/+12 +36
197 C 5/+12 +45
198 C#5/+13 -47
199 C#5/+13 -38
200 C#5/+13 -29
201 C#5/+13 -21
202 C#5/+13 -12
203 C#5/+13 -04
204 C#5/+13 +05
205 C#5/+13 +13
206 C#5/+13 +22
207 C#5/+13 +30
208 C#5/+13 +39
209 C#5/+13 +47
210 D 5/+14 -45
211 D 5/+14 -37
212 D 5/+14 -28
213 D 5/+14 -20
214 D 5/+14 -12
215 D 5/+14 -04
216 D 5/+14 +04
217 D 5/+14 +12
218 D 5/+14 +20
219 D 5/+14 +28
220 D 5/+14 +36
221 D 5/+14 +44
222 D#5/+15 -49
223 D#5/+15 -41
224 D#5/+15 -33
225 D#5/+15 -25
226 D#5/+15 -18
227 D#5/+15 -10
228 D#5/+15 -02
229 D#5/+15 +05
230 D#5/+15 +13
231 D#5/+15 +20
232 D#5/+15 +28
233 D#5/+15 +35
234 D#5/+15 +42
235 D#5/+15 +50
236 E 5/+16 -43
237 E 5/+16 -35
238 E 5/+16 -28
239 E 5/+16 -21
240 E 5/+16 -14

25

B.P.M. Conversion Table (2)

Original B.P.M. 120

dst key/c.t f.t

40 F 2/-19 -02
41 F 2/-19 +41
42 F#2/-18 -17
43 F#2/-18 +23
44 G 2/-17 -37
45 G 2/-17 +02
46 G 2/-17 +40
47 G#2/-16 -23
48 G#2/-16 +14
49 G#2/-16 +49
50 A 2/-15 -16
51 A 2/-15 +19
52 A#2/-14 -48
53 A#2/-14 -15
54 A#2/-14 +18
55 A#2/-14 +49
56 B 2/-13 -19
57 B 2/-13 +11
58 B 2/-13 +41
59 C 3/-12 -29
60 C 3/-12 00
61 C 3/-12 +29
62 C#3/-11 -43
63 C#3/-11 -16
64 C#3/-11 +12
65 C#3/-11 +39
66 D 3/-10 -35
67 D 3/-10 -09
68 D 3/-10 +17
69 D 3/-10 +42
70 D#3/-09 -33
71 D#3/-09 -09
72 D#3/-09 +16
73 D#3/-09 +40
74 E 3/-08 -37
75 E 3/-08 -14
76 E 3/-08 +09
77 E 3/-08 +32
78 F 3/-07 -46
79 F 3/-07 -24
80 F 3/-07 -02
81 F 3/-07 +20
82 F 3/-07 +41
83 F#3/-06 -38
84 F#3/-06 -17
85 F#3/-06 +03
86 F#3/-06 +23
87 F#3/-06 +43
88 G 3/-05 -37
89 G 3/-05 -17
90 G 3/-05 +02
91 G 3/-05 +21
92 G 3/-05 +40
93 G#3/-04 -41
94 G#3/-04 -23
95 G#3/-04 -04
96 G#3/-04 +14
97 G#3/-04 +32
98 G#3/-04 +49
99 A 3/-03 -33
100 A 3/-03 -16
101 A 3/-03 +02
102 A 3/-03 +19
103 A 3/-03 +36
104 A#3/-02 -48
105 A#3/-02 -31
106 A#3/-02 -15
107 A#3/-02 +01
108 A#3/-02 +18
109 A#3/-02 +34
110 A#3/-02 +49
111 B 3/-01 -35
112 B 3/-01 -19
113 B 3/-01 -04
114 B 3/-01 +11
115 B 3/-01 +26
116 B 3/-01 +41
117 C 4/ 00 -44
118 C 4/ 00 -29
119 C 4/ 00 -14
*120 C 4/ 00 00
121 C 4/ 00 +14
122 C 4/ 00 +29
123 C 4/ 00 +43
124 C#4/+01 -43
125 C#4/+01 -29
126 C#4/+01 -16
127 C#4/+01 -02
128 C#4/+01 +12
129 C#4/+01 +25
130 C#4/+01 +39
131 D 4/+02 -48
132 D 4/+02 -35
133 D 4/+02 -22
134 D 4/+02 -09
135 D 4/+02 +04
136 D 4/+02 +17
137 D 4/+02 +29
138 D 4/+02 +42
139 D#4/+03 -46

dst key/c.t f.t

140 D#4/+03 -33
141 D#4/+03 -21
142 D#4/+03 -09
143 D#4/+03 +04
144 D#4/+03 +16
145 D#4/+03 +28
146 D#4/+03 +40
147 E 4/+04 -49
148 E 4/+04 -37
149 E 4/+04 -25
150 E 4/+04 -14
151 E 4/+04 -02
152 E 4/+04 +09
153 E 4/+04 +21
154 E 4/+04 +32
155 E 4/+04 +43
156 F 4/+05 -46
157 F 4/+05 -35
158 F 4/+05 -24
159 F 4/+05 -13
160 F 4/+05 -02
161 F 4/+05 +09
162 F 4/+05 +20
163 F 4/+05 +30
164 F 4/+05 +41
165 F#4/+06 -49
166 F#4/+06 -38
167 F#4/+06 -28
168 F#4/+06 -17
169 F#4/+06 -07
170 F#4/+06 +03
171 F#4/+06 +13
172 F#4/+06 +23
173 F#4/+06 +33
174 F#4/+06 +43
175 G 4/+07 -47
176 G 4/+07 -37
177 G 4/+07 -27
178 G 4/+07 -17
179 G 4/+07 -08
180 G 4/+07 +02
181 G 4/+07 +12
182 G 4/+07 +21
183 G 4/+07 +31
184 G 4/+07 +40
185 G 4/+07 +49
186 G#4/+08 -41
187 G#4/+08 -32
188 G#4/+08 -23
189 G#4/+08 -14
190 G#4/+08 -04
191 G#4/+08 +05
192 G#4/+08 +14
193 G#4/+08 +23
194 G#4/+08 +32
195 G#4/+08 +41
196 G#4/+08 +49
197 A 4/+09 -42
198 A 4/+09 -33
199 A 4/+09 -24
200 A 4/+09 -16
201 A 4/+09 -07
202 A 4/+09 +02
203 A 4/+09 +10
204 A 4/+09 +19
205 A 4/+09 +27
206 A 4/+09 +36
207 A 4/+09 +44
208 A#4/+10 -48
209 A#4/+10 -39
210 A#4/+10 -31
211 A#4/+10 -23
212 A#4/+10 -15
213 A#4/+10 -07
214 A#4/+10 +01
215 A#4/+10 +10
216 A#4/+10 +18
217 A#4/+10 +26
218 A#4/+10 +34
219 A#4/+10 +41
220 A#4/+10 +49
221 B 4/+11 -43
222 B 4/+11 -35
223 B 4/+11 -27
224 B 4/+11 -19
225 B 4/+11 -12
226 B 4/+11 -04
227 B 4/+11 +04
228 B 4/+11 +11
229 B 4/+11 +19
230 B 4/+11 +26
231 B 4/+11 +34
232 B 4/+11 +41
233 B 4/+11 +49
234 C 5/+12 -44
235 C 5/+12 -36
236 C 5/+12 -29
237 C 5/+12 -22
238 C 5/+12 -14
239 C 5/+12 -07
240 C 5/+12 00

Original B.P.M. 135

dst key/c.t f.t

40 D#2/-21 -06
41 D#2/-21 +37
42 E 2/-20 -21
43 E 2/-20 +19
44 F 2/-19 -41
45 F 2/-19 -02
46 F 2/-19 +36
47 F#2/-18 -27
48 F#2/-18 +10
49 F#2/-18 +45
50 G 2/-17 -20
51 G 2/-17 +15
52 G 2/-17 +48
53 G#2/-16 -19
54 G#2/-16 +14
55 G#2/-16 +45
56 A 2/-15 -23
57 A 2/-15 +07
58 A 2/-15 +37
59 A#2/-14 -33
60 A#2/-14 -04
61 A#2/-14 +25
62 B 2/-13 -47
63 B 2/-13 -19
64 B 2/-13 +08
65 B 2/-13 +35
66 C 3/-12 -39
67 C 3/-12 -13
68 C 3/-12 +13
69 C 3/-12 +38
70 C#3/-11 -37
71 C#3/-11 -12
72 C#3/-11 +12
73 C#3/-11 +36
74 D 3/-10 -41
75 D 3/-10 -18
76 D 3/-10 +05
77 D 3/-10 +28
78 D#3/-09 -50
79 D#3/-09 -28
80 D#3/-09 -06
81 D#3/-09 +16
82 D#3/-09 +37
83 E 3/-08 -42
84 E 3/-08 -21
85 E 3/-08 -01
86 E 3/-08 +19
87 E 3/-08 +39
88 F 3/-07 -41
89 F 3/-07 -21
90 F 3/-07 -02
91 F 3/-07 +17
92 F 3/-07 +36
93 F#3/-06 -45
94 F#3/-06 -27
95 F#3/-06 -08
96 F#3/-06 +10
97 F#3/-06 +28
98 F#3/-06 +45
99 G 3/-05 -37
100 G 3/-05 -20
101 G 3/-05 -02
102 G 3/-05 +15
103 G 3/-05 +32
104 G 3/-05 +48
105 G#3/-04 -35
106 G#3/-04 -19
107 G#3/-04 -02
108 G#3/-04 +14
109 G#3/-04 +30
110 G#3/-04 +45
111 A 3/-03 -39
112 A 3/-03 -23
113 A 3/-03 -08
114 A 3/-03 +07
115 A 3/-03 +22
116 A 3/-03 +37
117 A#3/-02 -48
118 A#3/-02 -33
119 A#3/-02 -18
120 A#3/-02 -04
121 A#3/-02 +10
122 A#3/-02 +25
123 A#3/-02 +39
124 B 3/-01 -47
125 B 3/-01 -33
126 B 3/-01 -19
127 B 3/-01 -06
128 B 3/-01 +08
129 B 3/-01 +21
130 B 3/-01 +35
131 B 3/-01 +48
132 C 4/ 00 -39
133 C 4/ 00 -26
134 C 4/ 00 -13
*135 C 4/ 00 00
136 C 4/ 00 +13
137 C 4/ 00 +25
138 C 4/ 00 +38
139 C#4/+01 -49

dst key/c.t f.t

140 C#4/+01 -37
141 C#4/+01 -25
142 C#4/+01 -12
143 C#4/+01 00
144 C#4/+01 +12
145 C#4/+01 +24
146 C#4/+01 +36
147 C#4/+01 +47
148 D 4/+02 -41
149 D 4/+02 -29
150 D 4/+02 -18
151 D 4/+02 -06
152 D 4/+02 +05
153 D 4/+02 +17
154 D 4/+02 +28
155 D 4/+02 +39
156 D#4/+03 -50
157 D#4/+03 -39
158 D#4/+03 -28
159 D#4/+03 -17
160 D#4/+03 -06
161 D#4/+03 +05
162 D#4/+03 +16
163 D#4/+03 +26
164 D#4/+03 +37
165 D#4/+03 +47
166 E 4/+04 -42
167 E 4/+04 -32
168 E 4/+04 -21
169 E 4/+04 -11
170 E 4/+04 -01
171 E 4/+04 +09
172 E 4/+04 +19
173 E 4/+04 +29
174 E 4/+04 +39
175 E 4/+04 +49
176 F 4/+05 -41
177 F 4/+05 -31
178 F 4/+05 -21
179 F 4/+05 -12
180 F 4/+05 -02
181 F 4/+05 +08
182 F 4/+05 +17
183 F 4/+05 +27
184 F 4/+05 +36
185 F 4/+05 +45
186 F#4/+06 -45
187 F#4/+06 -36
188 F#4/+06 -27
189 F#4/+06 -17
190 F#4/+06 -08
191 F#4/+06 +01
192 F#4/+06 +10
193 F#4/+06 +19
194 F#4/+06 +28
195 F#4/+06 +37
196 F#4/+06 +45
197 G 4/+07 -46
198 G 4/+07 -37
199 G 4/+07 -28
200 G 4/+07 -20
201 G 4/+07 -11
202 G 4/+07 -02
203 G 4/+07 +06
204 G 4/+07 +15
205 G 4/+07 +23
206 G 4/+07 +32
207 G 4/+07 +40
208 G 4/+07 +48
209 G#4/+08 -43
210 G#4/+08 -35
211 G#4/+08 -27
212 G#4/+08 -19
213 G#4/+08 -11
214 G#4/+08 -02
215 G#4/+08 +06
216 G#4/+08 +14
217 G#4/+08 +22
218 G#4/+08 +30
219 G#4/+08 +38
220 G#4/+08 +45
221 A 4/+09 -47
222 A 4/+09 -39
223 A 4/+09 -31
224 A 4/+09 -23
225 A 4/+09 -16
226 A 4/+09 -08
227 A 4/+09 00
228 A 4/+09 +07
229 A 4/+09 +15
230 A 4/+09 +22
231 A 4/+09 +30
232 A 4/+09 +37
233 A 4/+09 +45
234 A#4/+10 -48
235 A#4/+10 -40
236 A#4/+10 -33
237 A#4/+10 -26
238 A#4/+10 -18
239 A#4/+10 -11
240 A#4/+10 -04

26

About the New Format

Expansion boards SRX-01–04 could only hold a maximum of
128 Patches. In order to make it possible to provide an even
greater variety of sounds, a new format (implemented
originally on the SRX-05) is now being employed. This new
format is capable of handling more than 128 Patches.

If you are using one of the five models listed below, and are
still using an older version of the system, you may need to
upgrade its system to enable it to support the new SRX
format. Check the system program version of your
instrument; if your current version is the same as, or older
than the corresponding one listed below, use the system
update program on the included CD-ROM to upgrade to the
latest version before using the SRX-05.

• Fantom: Update required for versions up to Ver. 1.12

• XV-5080: Update required for versions up to Ver. 1.24

• XV-3080: Update required for versions up to Ver. 1.08

• XV-88: Update required for versions up to Ver. 1.07

• RD-700: Update required for versions up to Ver. 1.04

新フォーマットに関して

エクスパンション・ボード SRX-01 〜 04 は、最大 128
パッチを収録していました。SRX-05 以降は、より多彩な音
色をお客様に供給する為に、128 以上のパッチを扱えるよ
う、新フォーマットを採用しています。

これにより、以下の 5 機種において、現在お使いのバー
ジョンによっては、新フォーマットに対応するためにバー
ジョン・アップしていただく必要があります。システム・プ
ログラム・バージョンをご確認の上、下記のバージョン、も
しくはそれより古いバージョンの場合は、付属 CD-ROM に
収録のシステム・アップデート・プログラムを使用して、製
品をバージョン・アップしてから SRX-05 をお使いくださ
い。

•

Fantom： Ver1.12 まではアップデートが必要

•

XV-5080： Ver1.24 まではアップデートが必要

•

XV-3080： Ver1.08 まではアップデートが必要
XV-88： Ver1.07 まではアップデートが必要

•

RD-700： Ver1.04 まではアップデートが必要

•

* Although the XV-5050 has always been compatible with this

new format, the most recent program version, current as of
January, 2002, is included.

For instructions on checking the system program version for
each instrument, and upgrading the software, refer to the
text files for the relevant instrument included on the CD­ROM.

About the Included CD-ROM

The included CD-ROM features:

• System update programs compatible with new-format
SRX expansion boards (for Fantom, XV-5080, XV-3080,
XV-88, and RD-700)

* For the XV-5050, the system update program is that for the

version that is current as of January, 2002.

• SMF rhythm data exclusively for SRX-05 rhythm kits

• SRX-01–05 demo songs

For more detailed information on each file, refer to
Readme_E.txt on the CD-ROM.

* Take proper care of the included CD-ROM; it will not be

reissued.

* The system programs on the included CD-ROM are the latest

versions, as of January, 2002. For information regarding
newer versions than those on this disk, you should contact the
nearest Roland Service Center.

※ XV-5050 は、当初より新フォーマットに対応していま

すが、2002 年 1 月時点での最新プログラムを収録して
います。

各機種のシステム・プログラム・バージョンの確認方法、お
よびバージョン・アップ方法は、付属 CD-ROM に収録の、
各機種別テキスト・ファイルを参照してください。

付属 CD-ROM について

付属 CD-ROM には

SRX エクスパンション・ボード新フォーマット対応用

•

システム・アップデート・プログラム

（Fantom、XV-5080、XV-3080、XV-88、RD-700）

※ XV-5050 は、2002 年 1 月時点での最新システム・

アップデート・プログラム

•

SRX-05 リズム・キット専用リズム SMF データ

•

SRX-01 〜 05 デモ・ソング

が収録されています。各ファイルの詳しい内容は、CD­ROM 内の ReadmeJ.txt を参照してください。

※付属CD-ROM は再発行しませんので、大切にお使いく

ださい。

※付属CD-ROM に収録の各システム・プログラムは、

2002 年 1 月時点での最新のものです。収録バージョン
より新しいプログラムに関しては、もよりのローラン
ド・サービスにお問い合わせください。

27

ローランド製品保証書 ［持込修理］

ご芳名

お
客
様

取扱販売店名・住所・

保
証
期
間

太枠内に記入または捺印の無い場合は、必ず販売店発行の領収書またはそのお
買い上げ年月日・販売店等を証明するものを保証書に添付願います。記入もし
くは添付の無い場合は無効となりますので、ご注意ください。

型名

〒

ご住所

お買い上げ日

年  月  日より

SRX-05 “Supreme Dance”

本体は一年間

ただし、ソフトウェア、
付属品、消耗部品は除く

様

●

本保証書は、本書記載内容で無料修理をさ
せていただくことをお約束するものです。

●保証期間中に故障が発生した場合は、製
品と本書をご持参ご提示の上、お買上げ
の販売店にご依頼ください。

●ご転居・ご贈答品などの場合で、お買上
げ販売店に修理を依頼することができな
い場合は、ローランドサービスステーシ
ョンにお問い合せください。

●本書は再発行いたしません。所定事項の
記入および内容をよくお読みの上、大切
に保存してください。

本社〒530-0002大阪市北区曽根崎新地1-4-20桜橋IMビル11F
  電話[phone]



保証規定

1. 保証期間内において、取扱説明書・本体貼付ラベルなど
の注意書に従った正常なご使用状態で発生した故障につ
いては、第3項に示す場合を除き、無料修理いたします。

2. 保証期間内に無料修理をお受けになる場合は、お買い上
げの販売店・又は最寄りのローランドサービスステーショ
ンにご依頼のうえ、修理の際に本書をご提示ください。
お客様のご事情により出張修理を依頼された場合、保証
期間中であっても出張料金を申し受けます。

3.保証期間内でも、次の場合には有料修理となります。

（イ）本書のご提示が無い場合。

（ロ）本書にお買上げ年月日・販売店名の記入が無い場

合、または字句を書き換えられた場合。

（ハ）ご使用上の誤り、又は当社の指定者以外の手によ

り修理・改造された場合。

（ニ）本製品に異常がなく、他の部分、他の機器に異常

があり、点検及び改善した場合。

（ホ）お買い上げ後の輸送、移動、落下等による故障や

損傷および使用中に生じたキズ・汚れなどの外観
上の変化。

（ヘ）地震、落雷、風水害、その他の天災地変、火災、

公害、ガス、異常電圧による故障や損傷。

（ト）消耗部品（例：電池など）の取り替えを要する場合、

および消耗部品の摩耗や劣化に起因する故障や損傷。

4. 本製品は日本国内でご使用いただくことを前提に製造・
販売しております。従って本製品の保証は、日本国外で



はお受けできませんので、ご了承ください。

This warranty is valid only in Japan.

修理メモ

※ 本保証書は以上の保証規定により無料修理をお約束する

ものです。従ってこの保証書によってお客様の法律上の
権利を制限するものではありません。

※ 本製品の補修用性能部品（製品の機能を維持するために

必要な部品）の最低保有期間は製造打切後6年です。こ
の部品保有期間を修理可能の期間とさせていただきます。
保有期間経過後も、故障内容によっては修理可能の場合
がありますので、ローランドサービスステーションまで
お問い合わせください。

※ 修理の際、交換した部品を再生、再利用、製品の品質向

上等の目的で回収させていただくことがありますので、
ご協力願います。

Copyright © 2002 ROLAND CORPORATION

All rights reserved. No part of this publication may be reproduced in any form without the written permission of ROLAND
CORPORATION.

©

 2002 ローランド 本書の一部、もしくは全部を無断で複写・転載することを禁じます。 

40455201 ’05-3-3N

28
