OWNER’S MANUAL
Amplifier
HF
Amplifier
LF
Thank you for purchasing the Roland Bi-Amp Monitor DS-8/7/5.
201b
Before using this unit, carefully read the sections entitled: “IMPORTANT SAFETY
INSTRUCTIONS” (p. 2), “USING THE UNIT SAFELY” (p. 3, 4), and “IMPORTANT
NOTES” (p. 5). These sections provide important information concerning the proper
operation of the unit. Additionally, in order to feel assured that you have gained a
good grasp of every feature provided by your new unit, Owner’s manual should be
read in its entirety. The manual should be saved and kept on hand as a convenient
reference.
Main Features
●
In Pursuit of High Sound Quality
The DS-8/7/5 powered monitor uses a two-way, bi-
amplifier design to achieve high sound quality.
The LF driver and dome HF driver use separate amps
sections for LF and HF, ensuring optimal sound quality.
In particular, the DS-8/7 feature completely discrete DC
power amps for the highest possible quality.
●
Analog Input
In addition to an XLR connector, which provides for
balanced input, a 1/4" TRS phone jack accommodating either balanced or unbalanced input
is also provided. This assures broad-ranging connectivity.
●
Digital Input
The digital inputs (coaxial and optical) support 24-bit digital audio data at sampling rates up
to 192 kHz. AES/EBU professional audio format digital input is also provided.
Digitally input signals are reproduced faithfully through 24-bit D/A conversion, thus
preventing noise or a drop in sound quality.
You can use the monitors with a wide variety of equipment and applications through
selective use of the analog and digital settings.
●
Magnetically Shielded Low- and High-Frequency Drivers
This allows you to use the speakers next to CRT displays.
202
Copyright © 2004 ROLAND CORPORATION
All rights reserved. No part of this publication may be reproduced in any form without the
written permission of ROLAND CORPORATION.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
ATTENTION: RISQUE DE CHOC ELECTRIQUE NE PAS OUVRIR
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the product.
INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS.
IMPORTANT SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING - When using electric products, basic precautions should always be followed, including the following:
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with a dry cloth.
7. Do not block any of the ventilation openings. Install in
accordance with the manufacturers instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
WARNING:
IMPORTANT:
As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying
the terminals in your plug, proceed as follows:
The wire which is coloured GREEN-AND-YELLOW must be connected to the terminal in the plug which is marked by the
letter E or by the safety earth symbol or coloured GREEN or GREEN-AND-YELLOW.
The wire which is coloured BLUE must be connected to the terminal which is marked with the letter N or coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with the letter L or coloured RED.
THIS APPARATUS MUST BE EARTHED
THE WIRES IN THIS MAINS LEAD ARE COLOURED IN ACCORDANCE WITH THE FOLLOWING CODE.
GREEN-AND-YELLOW: EARTH, BLUE: NEUTRAL, BROWN: LIVE
For the U.K.
10. Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified
by the manufacturer.
12. Unplug this apparatus during lightning storms or when
unused for long periods of time.
13. Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus,
the apparatus has been exposed to rain or moisture, does
not operate normally, or has been dropped.
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture.
2
USING THE UNIT SAFELY
Used for instructions intended to alert
the user to the risk of death or severe
injury should the unit be used
improperly.
Used for instructions intended to alert
the user to the risk of injury or material
damage should the unit be used
improperly.
* Material damage refers to damage or
other adverse effects caused with
respect to the home and all its
furnishings, as well to domestic
animals or pets.
001
• Before using this unit, make sure
to read the instructions below,
and the Owner’s Manual.
.......................................................................
001-50
• Connect mains plug of this
model to a mains socket outlet
with a protective earthing
connection.
.......................................................................
002a
• Do not open or perform any
internal modifications on the
unit.
.......................................................................
003
• Do not attempt to repair the unit,
or replace parts within it (except
when this manual provides
specific instructions directing
you to do so). Refer all servicing
to your retailer, the nearest
Roland Service Center, or an
authorized Roland distributor, as listed
on the “Information” page.
.......................................................................
004
• Never use or store the unit in
places that are:
• Subject to temperature
extremes (e.g., direct sunlight
in an enclosed vehicle, near a
heating duct, on top of heatgenerating equipment); or are
• Damp (e.g., baths, washrooms, on wet
floors); or are
• Humid; or are
• Exposed to rain; or are
• Dusty; or are
• Subject to high levels of vibration.
.......................................................................
007
• Make sure you always have the
unit placed so it is level and sure
to remain stable. Never place it
on stands that could wobble, or on
inclined surfaces.
.......................................................................
The symbol alerts the user to important instructions
or warnings.The specific meaning of the symbol is
determined by the design contained within the
triangle. In the case of the symbol at left, it is used for
general cautions, warnings, or alerts to danger.
The symbol alerts the user to items that must never
be carried out (are forbidden). The specific thing that
must not be done is indicated by the design contained
within the circle. In the case of the symbol at left, it
means that the unit must never be disassembled.
The ● symbol alerts the user to things that must be
carried out. The specific thing that must be done is
indicated by the design contained within the circle. In
the case of the symbol at left, it means that the powercord plug must be unplugged from the outlet.
008a
• The unit should be connected to
a power supply only of the type
described in the operating
instructions, or as marked on the rear side
of unit.
......................................................................
008e
• Use only the attached powersupply cord. Also, the supplied
power cord must not be used
with any other device.
......................................................................
009
• Do not excessively twist or bend
the power cord, nor place heavy
objects on it. Doing so can
damage the cord, producing
severed elements and short
circuits. Damaged cords are fire and
shock hazards!
......................................................................
010
• This unit, either alone or in
combination with an amplifier
and headphones or speakers,
may be capable of producing
sound levels that could cause
permanent hearing loss. Do not
operate for a long period of time
at a high volume level, or at a
level that is uncomfortable. If
you experience any hearing loss
or ringing in the ears, you should
immediately stop using the unit, and
consult an audiologist.
......................................................................
011
• Do not allow any objects (e.g.,
flammable material, coins, pins);
or liquids of any kind (water, soft
drinks, etc.) to penetrate the unit.
......................................................................
013
• In households with small
children, an adult should
provide supervision until the
child is capable of following all
the rules essential for the safe operation
of the unit.
......................................................................
012a
• Immediately turn the power off,
remove the power cord from the
outlet, and request servicing by
your retailer, the nearest Roland
Service Center, or an authorized
Roland distributor, as listed on the “Information” page when:
• The power-supply cord, or the plug
has been damaged; or
• If smoke or unusual odor occurs
• Objects have fallen into, or liquid has
been spilled onto the unit; or
• The unit has been exposed to rain (or
otherwise has become wet); or
• The unit does not appear to operate
normally or exhibits a marked change
in performance.
.......................................................................
014
• Protect the unit from strong
impact.
(Do not drop it!)
.......................................................................
015
• Do not force the unit’s powersupply cord to share an outlet
with an unreasonable number of
other devices. Be especially
careful when using extension
cords—the total power used by
all devices you have connected to
the extension cord’s outlet must
never exceed the power rating
(watts/amperes) for the
extension cord. Excessive loads can cause
the insulation on the cord to heat up and
eventually melt through.
.......................................................................
016
• Before using the unit in a foreign
country, consult with your
retailer, the nearest Roland
Service Center, or an authorized
Roland distributor, as listed on the “Information” page.
.......................................................................
3
026
• Do not put anything that
contains water (e.g., flower
vases) on this unit. Also, avoid
the use of insecticides, perfumes,
alcohol, nail polish, spray cans,
etc., near the unit. Swiftly wipe
away any liquid that spills on the unit
using a dry, soft cloth.
.......................................................................
101a
• The unit should be located so
that its location or position does
not interfere with its proper
ventilation.
.......................................................................
102b
• Always grasp only the plug on
the power-supply cord when
plugging into, or unplugging
from, an outlet or this unit.
.......................................................................
103a
• At regular intervals, you should
unplug the power plug and clean
it by using a dry cloth to wipe all
dust and other accumulations
away from its prongs. Also,
disconnect the power plug from
the power outlet whenever the
unit is to remain unused for an
extended period of time. Any
accumulation of dust between the power
plug and the power outlet can result in
poor insulation and lead to fire.
.......................................................................
104
• Try to prevent cords and cables
from becoming entangled. Also,
all cords and cables should be
placed so they are out of the reach of
children.
......................................................................
106
• Never climb on top of, nor place
heavy objects on the unit.
......................................................................
1107b
• Never handle the power cord or
its plugs with wet hands when
plugging into, or unplugging
from, an outlet or this unit.
......................................................................
108a
• Before moving the unit,
disconnect the power plug from
the outlet, and pull out all cords
from external devices.
......................................................................
109a
• Before cleaning the unit, turn off
the power and unplug the power
cord from the outlet (p. 5).
......................................................................
110a
• Whenever you suspect the possibility of lightning in your area,
pull the plug on the power cord
out of the outlet.
......................................................................
119
• The top of the unit may become
hot, so take care to avoid burns.
......................................................................
For EU Countries
This product complies with the requirements of European Directives EMC 89/336/EEC and LVD 73/23/EEC.
For the USA
FEDERAL COMMUNICATIONS COMMISSION
RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
– Reorient or relocate the receiving antenna.
– Increase the separation between the equipment and receiver.
– Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
– Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
Unauthorized changes or modification to this system can void the users authority to operate this equipment.
This equipment requires shielded interface cables in order to meet FCC class B Limit.
For Canada
NOTICE
This Class B digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations.
4
AVIS
Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada.
IMPORTANT NOTES
291b
In addition to the items listed under “IMPORTANT
SAFETY INSTRUCTIONS” and “USING THE UNIT
SAFELY” on pages 2 ~ 4, please read and observe the
following:
Power Supply
301
• Do not connect this unit to same electrical outlet that is being
used by an electrical appliance that is controlled by an inverter
(such as a refrigerator, washing machine, microwave oven, or air
conditioner), or that contains a motor. Depending on the way in
which the electrical appliance is used, power supply noise may
cause this unit to malfunction or may produce audible noise. If it
is not practical to use a separate electrical outlet, connect a power
supply noise filter between this unit and the electrical outlet.
307
• Before connecting this unit to other devices, turn off the power to
all units. This will help prevent malfunctions and/or damage to
speakers or other devices.
308
• Although the LCD and LEDs are switched off when the POWER
switch is switched off, this does not mean that the unit has been
completely disconnected from the source of power. If you need to
turn off the power completely, first turn off the POWER switch,
then unplug the power cord from the power outlet. For this
reason, the outlet into which you choose to connect the power
cord’s plug should be one that is within easy reach and readily
accessible.
Placement
351
• Using the unit near power amplifiers (or other equipment
containing large power transformers) may induce hum. To
alleviate the problem, change the orientation of this unit; or move
it farther away from the source of interference.
352a
• This device may interfere with radio and television reception. Do
not use this device in the vicinity of such receivers.
352b
• Noise may be produced if wireless communications devices, such
as cell phones, are operated in the vicinity of this unit. Such noise
could occur when receiving or initiating a call, or while
conversing. Should you experience such problems, you should
relocate such wireless devices so they are at a greater distance
from this unit, or switch them off.
354b
• Do not expose the unit to direct sunlight, place it near devices
that radiate heat, leave it inside an enclosed vehicle, or otherwise
subject it to temperature extremes. Also, do not allow lighting
devices that normally are used while their light source is very
close to the unit (such as a piano light), or powerful spotlights to
shine upon the same area of the unit for extended periods of time.
Excessive heat can deform or discolor the unit.
355b
• When moved from one location to another where the temperature and/or humidity is very different, water droplets (condensation) may form inside the unit. Damage or malfunction may
result if you attempt to use the unit in this condition. Therefore,
before using the unit, you must allow it to stand for several
hours, until the condensation has completely evaporated.
356
• Do not allow rubber, vinyl, or similar materials to remain on the
unit for long periods of time. Such objects can discolor or
otherwise harmfully affect the finish.
359
• Do not paste stickers, decals, or the like to this instrument.
Peeling such matter off the instrument may damage the exterior
finish.
Maintenance
401a
• For everyday cleaning wipe the unit with a soft, dry cloth or one
that has been slightly dampened with water. To remove stubborn
dirt, use a cloth impregnated with a mild, non-abrasive detergent.
Afterwards, be sure to wipe the unit thoroughly with a soft, dry
cloth.
402
• Never use benzine, thinners, alcohol or solvents of any kind, to
avoid the possibility of discoloration and/or deformation.
Additional Precautions
553
• Use a reasonable amount of care when using the unit’s buttons,
sliders, or other controls; and when using its jacks and
connectors. Rough handling can lead to malfunctions.
556
• When connecting / disconnecting all cables, grasp the connector
itself—never pull on the cable. This way you will avoid causing
shorts, or damage to the cable’s internal elements.
557
• A small amount of heat will radiate from the unit during normal
operation.
558b
• To avoid disturbing your neighbors, try to keep the unit’s volume
at reasonable levels (especially when it is late at night).
559a
• When you need to transport the unit, package it in the box
(including padding) that it came in, if possible. Otherwise, you
will need to use equivalent packaging materials.
562
• Use a cable from Roland to make the connection. If using some
other make of connection cable, please note the following precautions.
• Some connection cables contain resistors. Do not use cables
that incorporate resistors for connecting to this unit. The use
of such cables can cause the sound level to be extremely low,
or impossible to hear. For information on cable specifications,
contact the manufacturer of the cable.
add
• Avoid inserting fingers into
the bass reflex ducts when
transporting or handling
the unit. Otherwise, you
risk getting your fingers
stuck.
5
Panel Descriptions
Front
fig.
Power Switch
This switch turns the power on/off.
If you need turn off the
power supply completely,
first turn off the POWER
switch, then unplug the
power cord from the power
outlet. Refer to Power
Supply (p. 5).
HF Driver
* Do not touch
the diaphragm.
LF Driver
* Do not touch
the speaker cone.
Bass-reflex Ducts
These are conduits for rich, bass-range reproduction.
Rear
Digital In Indicator
This lights
connected digital device.
Connect the digital-signal output device, set the
"Input Select switch" to DIGITAL INPUT, and set
the "Digital Input select switch" according to the
connector to which the device is attached (Coaxial,
Optical or XLR (AES/EBU)).
* When the connected digital-signal output device
is not powered up, the Digital In indicator does not
light up.
up when output is received from a
Power Indicator
Lights when power is on.
Before turning the power on or off, you must lower
the volume of this unit and your connected device etc.
This unit is equipped with a protection circuit. A brief
interval (a few seconds) after power up is required
before the unit will operate normally.
fig.
Power cord
1 Digital Input
Coaxial Input Connector (Digital Input)
This is the digital input connector for coaxial cable.
It cannot be used for input of analog audio signals (no sound
5
6
7
4
3
2
8
1
is produced).
Optical Input Connector (Digital Input)
This is the digital input connector for optic-fiber cable. Use
commercially available optical cable for audio equipment to
make the connection.
XLR Input Connector (Digital Input)
This is a digital input for AES/EBU professional format
digital audio.
It cannot be used for input of analog audio signals (no sound
is produced).
6
Panel Descriptions
Digital Input Select Switch
This switch selects AES/EBU, Optical or Coaxial. Select the
connector used for the input signal.
Assign Switch
This switch selects the stereo position of the digital signal.
It selects Right, L+R, or Left when using two DS-8/7/5
monitors for stereo sound (with digital signals).
Choose the setting appropriate for your setup.
With the DS-8/7/5, there is no difference between L and R.
When using the digital input connectors of two DS-8/7/5
monitors for stereo sound, the digital signal can be input to
either L or R.
2 Thru (Digital Out) Connector
When connecting multiple DS-8/7/5 monitors with digital
signals, this connector is used for output to the second DS-8/7/
5.
Refer to
Connection Examples
(p. 8).
5 Level Control
This adjusts the input level. Turning the control clockwise
increases the sound from the speakers.
6 HF Trim Control
This adjusts the sound quality of the treble range
It adjusts the output level of the HF driver.
(+/-3 dB above the crossover frequency)
7 LF Trim Control
This adjusts the sound quality of the bass range
(80 Hz, +/-3 dB).
The LF Trim and HF Trim controls on the DS-8/7/5 are
designed to correct the sound quality of the sonic field. Use
these to make fine adjustments to match the usage conditions.
8 AC Inlet
Connect the included Power cord here. Plug it firmly in, so
that the cable does not accidentally become disconnected.
3 Analog Input
XLR/TRS Phone Input Connector (Analog Input)
This is for connecting XLR or TRS phone plugs.
fig.
XLR type
Phone type
(Unbalanced)
Both balanced and unbalanced connections are possible.
922b
This instrument is equipped with balanced (XLR/TRS) type
input jacks. Wiring diagrams for these jacks are shown
below. Make connections after first checking the wiring
diagrams of other equipment you intend to connect.
fig.
1:GND
2:HOT
3:COLD
phone type
(Balanced)
HOT(TIP)
TRS
GND(SLEEVE)
COLD(RING)
4 Input Select Switch
Used to select Digital Input or Analog Input.
Select the connector used for the input signal.
7
Connection Examples
Mixer,etc.
Example for
Using Analog Input Connectors
Example for
Using Digital Input Connectors
CD Player, DVD Player,
MD Player, etc
VS-2480DVD/CD, VS-2400CD, VS-2000CD,etc
Recording Equipment,etc.
Select
DIGITAL OUT
DIGITAL IN
(COAXIAL, OPTICAL, AES/EBU)
THRU
(DIGITAL OUT)
DIGITAL IN
(COAXIAL)
Using Two DS-8/7/5 Monitors for Stereo Sound
fig.
Tips about high sound quality playback
• Please pay careful attention to the placement location. In order to take full advantage of the low-frequency
playback capabilities of this device, we recommend that you place it on a hard and strong base.
• When using digital in connections, turn down the LEVEL knob of this device and raise the output level of the
connected device. This will take advantage of the full number of bits in the digital signal, improving the audio
quality.
8
Important Notes on Placement
Connection Examples
• During setup and transport, be careful not to damage the
vibrating portions (the speaker cone and diaphragm).
• Be sure to place the monitor so that the slits on the top to
radiate the heat is not obstructed. Also, make sure the
monitor does not touch any curtains or other fabrics.
• This unit performs cooling when the monitor is placed as
shown below. Do not place the monitor on its side or
upside down.
fig.
Heated Air
• When this unit is in operation, the top side will become
hot. Take care not to touch it.
• Do not put anything on the unit.
• During operation, this unit must be placed at a distance
of no less than 20 cm (7-7/8 inches) from any walls.
fig.
(7-7/8 inches)
no less
than 20cm
(7-7/8 inches)
no less
than 20cm
(7-7/8 inches)
* Please also refer to “Placement” in
no less
than 20cm
IMPORTANT NOTES
no less than 20cm
(7-7/8 inches)
5).
(p.
Precautions When Connecting and Turning on the Power
921
• To prevent malfunction and/or damage to speakers or
other devices, always turn down the volume, and turn
off the power on all devices before making any
connections.
941
• Once the connections have been completed, turn on
power to your various devices in the order specified. By
turning on devices in the wrong order, you risk causing
malfunction and/or damage to speakers and other
devices. (When turning the power off, reverse this
procedure.)
1.
Turn on the power on the devices connected to the
DS-8/7/5.
2.
Turn off the power on the DS-8/7/5.
942
• This unit is equipped with a protection circuit. A brief
interval (a few seconds) after power up is required
before the unit will operate normally.
926a
• When connection cables with resistors are used, the
volume level of equipment connected to the inputs
(Analog Input) may be low. If this happens, use
connection cables that do not contain resistors, such as
those from the Roland PCS series.
9
Reference
Troubleshooting
If there is no sound or if the unit does not operate as you expect, please check the following points first. If this does not resolve the
problem, contact the nearest Roland service center or authorized Roland distributor.
There’s No Sound
• Make sure the Input Level control has not been turned
fully counterclockwise.
• Make sure the Input Select switch has been set to the
connector where the input signal is connected (Digital
Input or Analog Input).
• Make sure the Digital Input select switch has been set to
the connector where the input signal is connected (AES/
EBU, Optical or Coaxial).
• Input a digital signal to the Digital Input connector. No
sound is produced when an analog signal is input.
926
Dimensions
fig.
A
The volume level of the instrument
connected to ANALOG INPUT is too
low
• Could you be using a connection cable that contains a
resistor? Use a connection cable that does not contain a
resistor.
During Digital Signal Input, the Stereo
Image Is Reversed or Sounds
Unnatural, or Output Doesn’t Sound
Like Stereo
• Check the setting of the Assign switch (Right, L+R, or
Left). The DS-8/7/5 uses an identical construction for
the left and right monitors, and makes no distinction
between left and right. During digital signal input, set
the Assign switch L or R as appropriate for your setup.
C
B
D
F
* Not include the power cord.
DS-8
254 mm (10 inches)
A
406 mm (16 inches)
B
317.5 mm (12-1/2 inches) 262 mm (10-3/8 inches) 228.6 mm (9 inches)
C
7.5 mm (5/16 inches)
D
42 mm (1-11/16 inches)
E
367 mm (14-1/2 inches)
F
209 mm (8-1/4 inches) 184 mm (7-1/4 inches)
336 mm (13-1/4 inches) 295 mm (11-5/8 inches)
7.5 mm (5/16 inches) 7 mm (5/16 inches)
37 mm (1-1/2 inches) 32 mm (1-5/16 inches)
306.5 mm (12-1/8 inches) 267.6 mm (10-9/16 inches)
DS-7 DS-5
E
10
Frequency Response
15
6040 80 200 300 500 700 1K 2K 4K 8K6K3K 24K
0
-15
-30
30
(dB)
Response
(Hz)
LF: max
flat
LF: min
HF: max
flatflat
HF: min
15
6040 80 200 300 500 700 1K 2K 4K 8K6K3K 24K
0
-15
-30
30
(dB)
Response
(Hz)
LF: max
flat
LF: min
HF: max
flatflat
HF: min
15
6040 80 200 300 500 700 1K 2K 4K 8K6K3K 24K
0
-15
-30
30
(dB)
Response
(Hz)
Frequency
LF: max
flat
LF: min
HF: max
flatflat
HF: min
DS-8
DS-7
Reference
DS-5
11
Specifications
DS-7 DS-5
130 mm (5-1/4”) Polypropylene
cone type, magnetically shielded
19 mm (3/4”) Soft dome type,
magnetically shielded
System
Enclosure
Cabinet
LF Driver
HF Driver
Frequency Response
Crossover Frequency
LF Amplifier Power
HF Amplifier Power
Analog In
Input Sensitivity
Input Impedance
Digital In Format
Sample Rate
Word Length
DA Converter
DS-8
2-Way Bi-Amplified Monitor
Bass-reflex type
3/4” MDF (Baffle: 1” MDF)
200 mm (8”) Polypropylene cone
type, magnetically shielded
25 mm (1”) Soft dome type,
magnetically shielded
58 Hz to 24 kHz (+/-3 dB)
2.3 kHz (active fourth order)
80 W
40 W
5/8” MDF (Baffle: 3/4” MDF) 1/2” MDF (Baffle: 5/8” MDF)
160 mm (6-1/2”) Polypropylene
cone type, magnetically shielded
19 mm (3/4”) Soft dome type,
magnetically shielded
68 Hz to 23 kHz (+/-3 dB) 78 Hz to 23 kHz (+/-3 dB)
2.7 kHz (active fourth order) 3.3 kHz (active fourth order)
40 W 30 W
20 W 15 W
0 dBu (0.775 Vrms)
20 k ohms (Balanced/Unbalanced)
Conformity with AES/EBU and IEC60958
32 kHz to 192 kHz (automatically) (de-emphasis: OFF)
24 bit
24 bit
LEVEL Knob, LF TRIM Knob, HF TRIM Knob
INPUT SELECT SW (Analog In/Digital In)
Controls
ASSIGN SW (Right/L+R/Left)
DIGITAL INPUT SELECT SW (AES/EBU / Optical / Coaxial)
POWER SW
Indicators
POWER, DIGITAL IN
ANALOG INPUT (XLR, 1/4 inch TRS phone type)
Connectors
DIGITAL INPUT (XLR, Optical, Coaxial)
DIGITAL THRU OUT (Coaxial)
Power Supply
Power Consumption
Dimensions
Weight
Accessories
962a
AC 117 V, AC 220 V, AC 230 V, AC 240 V (50/60 Hz)
125 W
254 (W) x 367 (D) x 406 (H) mm
10 (W) x 14-1/2 (D) x 16 (H) inches
17.2 kg / 37 lbs 15 oz
75 W 55 W
209 (W) x 306.5 (D) x 336 (H) mm
8-1/4 (W) x 12-1/8 (D) x 13-1/4 (H)
inches
9.7 kg / 21 lbs 7 oz 7.2 kg / 15 lbs 14 oz
Owner’s Manual, Power Cord
184 (W) x 267.6 (D) x 295 (H) mm
7-1/4 (W) x 10-9/16(D) x 11-5/8 (H)
inches
* In the interest of product improvement, the specifications and/or appearance of this unit are subject to change without prior notice.
UK
DE
FR
IT
ES
PT
NL
DK
For EU Countries
SE
FI
HU
PL
CZ
SK
EE
LT
LV
SI
NO
GR
C5100021 4YG
Loading...
