Roland DS61 Implementation

MIDI Implementation

Model: JUNO-DS61/DS88 Date: Sep 15, 2015 Version: 1.00

1. Data Reception (Sound Source Section)

7

Channel Voice Messages

* Not received in Performance mode when the Receive Switch parameter (PERFORM EDIT:LEVEL/CH:RxSw or PART EDIT:LEVEL/CH:Rx

Switch) is OFF.

7

Note o

Status 2nd byte 3rd byte 8nH kkH vvH 9nH kkH 00H n = MIDI channel number: 0H - FH (ch.1 - 16) kk = note number: 00H - 7FH (0 - 127)

vv = note o velocity: 00H - 7FH (0 - 127)

* Not received when the Tone Env Mode parameter (PATCH EDIT:CTRL:Env Mode or DRUM KIT EDIT:COMMON:Tone Env Mode) is NO-SUS.

7

Note on Status 2nd byte 3rd byte 9nH kkH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) kk = note number: 00H - 7FH (0 - 127) vv = note on velocity: 01H - 7FH (1 - 127)

7

Polyphonic Key Pressure Status 2nd byte 3rd byte AnH kkH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) kk = note number: 00H - 7FH (0 - 127) vv = Polyphonic Key Pressure: 00H - 7FH (0 - 127)

* Not received in Performance mode when the Receive Polyphonic Key Pressure parameter (PERFORM EDIT:MIDI:PA or PART

EDIT:MIDI:PAFT) is OFF.

7

Control Change

* If the corresponding Controller number is selected for the Matrix Control 1-4 Source parameter (PATCH EDIT:MTRX CTRL1-

4:Control 1-4 Source), the corresponding eect will occur.

* If a Controller number that corresponds to the System Control 1-4 Source parameter (SYSTEM:CONTROL:Sys Ctrl 1-4 Source)

is selected, the specied eect will apply if the Matrix Control 1-4 Source parameter (PATCH EDIT:MTRX CTRL1-4:Control

1-4 Source) is set to SYS CTRL1, SYS CTRL2, SYS CTRL3 or SYS CTRL4.

6

Bank Select (Controller number 0, 32) Status 2nd byte 3rd byte BnH 00H mmH BnH 20H llH n = MIDI channel number: 0H - FH (ch.1 - 16) mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)

* Not received in Performance mode when the Receive Bank Select parameter (PERFORM EDIT:MIDI:BS or PART EDIT:MIDI:BS) is

OFF.

The Performances, Patterns, Patches, and Drum Kits corresponding to each Bank Select are as follows.

-----+-----------+-----------+-------------------------+------------000 | | 001 - 128 | GM Patch | 0001 - 0256 : | | | | 063 | | 001 - 128 | GM Patch | 0001 - 0256 085 | 000 | 001 - 128 | User Performance | 001 - 128 | 001 | 001 - 128 | User Pattern | 001 - 128 | 064 | 001 - 064 | Preset Performance | 001 - 064 | 065 | 001 - 032 | Preset Pattern | 001 - 032 086 | 000 | 001 - 008 | User Drum | R501 - R508 | 064 | 001 - 021 | Preset Drum | 0001 - 0021 | 065 | 001 - 009 | DS Drum | 0001 - 0009

1

087 | 000 | 001 - 128 | User Patch | 0501 - 0628 | 001 | 001 - 128 | User Patch | 0629 - 0756 | 064 | 001 - 128 | Preset Patch | 0001 - 0128 | 065 | 001 - 128 | Preset Patch | 0129 - 0256 | : | | : | : | 072 | 001 - 064 | Preset patch | 1025 - 1088 | 073 | 001 - 128 | DS patch | 0001 - 0128 | 074 | 001 - 056 | DS patch | 0129 - 0184 092 | 000 - | 001 - | Expansion Drum | 0001 093 | 000 - | 001 - | Expansion Patch | 0001 120 | | 001 - 057 | GM Drum | 0001 - 0009 121 | 000 - | 001 - 128 | GM Patch | 0001 - 0256

The Expansion Sounds corresponding to each Bank Select are as follows.

-----+-----------+-----------+-------------------------+------------093 | 001 | 001 - 050 | Expansion Patch (EXP04) | 0001 - 0050

-----+-----------+-----------+-------------------------+------------093 | 002 | 001 - 128 | Expansion Patch (EXP06) | 0001 - 0128 092 | 002 | 001 - 012 | Expansion Drum (EXP06) | 0001 - 0012

-----+-----------+-----------+-------------------------+------------093 | 003 | 001 - 128 | Expansion Patch (EXP08) | 0001 - 0128

-----+-----------+-----------+-------------------------+------------093 | 007 | 001 - 128 | Expansion Patch (EXP10) | 0001 - 0128 | : | : | | : | 010 | 001 - 065 | | 0385 - 0449 092 | 007 | 001 - 005 | Expansion Drum (EXP10) | 0001 - 0005

-----+-----------+-----------+-------------------------+------------093 | 011 | 001 - 128 | Expansion Patch (EXP02) | 0001 - 0128 | : | : | | : | 014 | 001 - 022 | | 0385 - 0406

-----+-----------+-----------+-------------------------+------------093 | 015 | 001 - 128 | Expansion Patch (EXP01) | 0001 - 0128 | : | : | | : | 017 | 001 - 105 | | 0257 - 0361 092 | 015 | 001 - 016 | Expansion Drum (EXP01) | 0001 - 0016

-----+-----------+-----------+-------------------------+------------093 | 019 | 001 - 128 | Expansion Patch (EXP03) | 0001 - 0128 | : | : | | : | 022 | 001 - 023 | | 0385 - 0407 092 | 019 | 001 - 010 | Expansion Drum (EXP03) | 0001 - 0010

-----+-----------+-----------+-------------------------+------------093 | 023 | 001 - 100 | Expansion Patch (EXP07) | 0001 - 0100

-----+-----------+-----------+-------------------------+------------093 | 024 | 001 - 042 | Expansion Patch (EXP09) | 0001 - 0042

-----+-----------+-----------+-------------------------+------------093 | 026 | 001 - 050 | Expansion Patch (EXP05) | 0001 - 0050

6

Modulation (Controller number 1) Status 2nd byte 3rd byte BnH 01H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Modulation depth: 00H - 7FH (0 - 127)

* Not received in Performance mode when the Receive Modulation parameter (PERFORM EDIT:MIDI:MD or PART EDIT:MIDI:MOD) is

OFF.

6

Breath type (Controller number 2) Status 2nd byte 3rd byte BnH 02H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

6

Foot type (Controller number 4) Status 2nd byte 3rd byte BnH 04H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

6

Portamento Time (Controller number 5) Status 2nd byte 3rd byte BnH 05H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Portamento Time: 00H - 7FH (0 - 127)

* In Performance mode, the Part Portamento Time parameter (PERFORM EDIT:PITCH:Time or PART EDIT:PITCH:Porta Time) will

change.

2

6

Data Entry (Controller number 6, 38) Status 2nd byte 3rd byte BnH 06H mmH BnH 26H llH n = MIDI channel number: 0H - FH (ch.1 - 16)

mm, ll = the value of the parameter specied by RPN/NRPN

mm = MSB, ll = LSB

6

Volume (Controller number 7) Status 2nd byte 3rd byte BnH 07H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Volume: 00H - 7FH (0 - 127)

* Not received in Performance mode when the Receive Volume parameter (PERFORM EDIT:MIDI:VO or PART EDIT:MIDI:VOL) is OFF.

* In Performance mode, the Part Level parameter (PERFORM EDIT:LEVEL/CH:Level or PART EDIT:LEVEL/CH:Level) will change.

6

Panpot (Controller number 10) Status 2nd byte 3rd byte BnH 0AH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Panpot: 00H - 40H - 7FH (Left - Center - Right)

* Not received in Performance mode when the Receive Pan parameter (PERFORM EDIT:MIDI:PN or PART EDIT:MIDI:PAN) is OFF.

* In Performance mode, the Part Pan parameter (PERFORM EDIT:LEVEL/CH:Pan or PART EDIT:LEVEL/CH:Pan) will change.

6

Expression (Controller number 11) Status 2nd byte 3rd byte BnH 0BH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Expression: 00H - 7FH (0 - 127)

* Not received when the Tone Receive Expression parameter (PATCH EDIT:CTRL:Rx Expression or DRUM KIT EDIT:COMMON:Tone Rx

Expression) is OFF.

* Not received in Performance mode when the Receive Expression parameter (PERFORM EDIT:MIDI:EX or PART EDIT:MIDI:EXP) is OFF.

6

Hold 1 (Controller number 64) Status 2nd byte 3rd byte BnH 40H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON

* Not received when the Tone Receive Hold-1 parameter (PATCH EDIT:CTRL:Rx Hold-1 or DRUM KIT EDIT:COMMON:Tone Rx Hold-1) is

OFF.

* Not received in Performance mode when the Receive Hold-1 parameter (PERFORM EDIT:MIDI:HD or PART EDIT:MIDI:HOLD) is OFF.

* When the Tone Redamper Switch parameter (PATCH EDIT:CTRL:Redamper Sw) is turned ON, 128 discrete steps are recognized for

the value.

6

Portamento (Controller number 65) Status 2nd byte 3rd byte BnH 41H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON

* In Performance mode, the Part Portamento Switch parameter (PERFORM EDIT:PITCH:Porta or PART EDIT:PITCH:Porta Switch) will

change.

6

Sostenuto (Controller number 66) Status 2nd byte 3rd byte BnH 42H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON

6

Soft (Controller number 67) Status 2nd byte 3rd byte BnH 43H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON

6

Legato Foot Switch (Controller number 68) Status 2nd byte 3rd byte BnH 44H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON

* In Performance mode, the Part Legato Switch parameter (PERFORM EDIT:PITCH:Legt or PART EDIT:PITCH:Legato Switch) will

change.

3

6

Hold-2 (Controller number 69) Status 2nd byte 3rd byte BnH 45H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

* A hold movement isn’t done.

6

Resonance (Controller number 71) Status 2nd byte 3rd byte BnH 47H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv= Resonance value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Resonance Oset parameter (PERFORM EDIT:OFFSET:Reso or PART EDIT:OFFSET:Reso Oset) will change.

6

Release Time (Controller number 72) Status 2nd byte 3rd byte BnH 48H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Release Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Release Time Oset parameter (PERFORM EDIT:OFFSET:Release or PART EDIT:OFFSET:Release

Oset) will change.

6

Attack time (Controller number 73) Status 2nd byte 3rd byte BnH 49H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Attack time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Attack Time Oset parameter (PERFORM EDIT:OFFSET:Attack or PART EDIT:OFFSET:Attack Oset)

will change.

6

Cuto (Controller number 74)

Status 2nd byte 3rd byte BnH 4AH vvH n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Cuto value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Cuto Oset parameter (PERFORM EDIT:OFFSET:Cuto or PART EDIT:OFFSET:Cuto Oset) will change.

6

Decay Time (Controller number 75) Status 2nd byte 3rd byte BnH 4BH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Decay Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Decay Time Oset parameter (PERFORM EDIT:OFFSET:Decay or PART EDIT:OFFSET:Decay Oset) will

change.

6

Vibrato Rate (Controller number 76) Status 2nd byte 3rd byte BnH 4CH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Vibrato Rate value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Vibrato Rate parameter (PERFORM EDIT:VIBRATO:Rate or PART EDIT:VIBRATO:Vibrato Rate) will

change.

6

Vibrato Depth (Controller number 77) Status 2nd byte 3rd byte BnH 4DH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Vibrato Depth Value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Vibrato Depth parameter (PERFORM EDIT:VIBRATO:Depth or PART EDIT:VIBRATO:Vibrato Depth)

will change.

6

Vibrato Delay (Controller number 78) Status 2nd byte 3rd byte BnH 4EH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Vibrato Delay value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

* In Performance mode, the Part Vibrato Delay parameter (PERFORM EDIT:VIBRATO:Delay or PART EDIT:VIBRATO:Vibrato Delay)

will change.

4

6

General Purpose Controller 5 (Controller number 80) Status 2nd byte 3rd byte BnH 50H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

* The Tone Level parameter (PATCH EDIT:TVA:Tone Level or SAMPLE EDIT:TVA:Tone Level) of Tone 1 will change.

6

General Purpose Controller 6 (Controller number 81) Status 2nd byte 3rd byte BnH 51H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

* The Tone Level parameter (PATCH EDIT:TVA:Tone Level) of Tone 2 will change.

6

General Purpose Controller 7 (Controller number 82) Status 2nd byte 3rd byte BnH 52H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

* The Tone Level parameter (PATCH EDIT:TVA:Tone Level) of Tone 3 will change.

6

General Purpose Controller 8 (Controller number 83) Status 2nd byte 3rd byte BnH 53H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

* The Tone Level parameter (PATCH EDIT:TVA:Tone Level) of Tone 4 will change.

6

Portamento control (Controller number 84) Status 2nd byte 3rd byte BnH 54H kkH n = MIDI channel number: 0H - FH (ch.1 - 16) kk = source note number: 00H - 7FH (0 - 127)

* A Note-on received immediately after a Portamento Control message will change continuously in pitch, starting from the

pitch of the Source Note Number.

* If a voice is already sounding for a note number identical to the Source Note Number, this voice will continue sounding

(i.e., legato) and will, when the next Note-on is received, smoothly change to the pitch of that Note-on.

* The rate of the pitch change caused by Portamento Control is determined by the Portamento Time value.

6

Eect 1 (Reverb Send Level) (Controller number 91)

Status 2nd byte 3rd byte BnH 5BH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Reverb Send Level: 00H - 7FH (0 - 127)

* In Performance mode, the Part Reverb Send Level parameter (PERFORM EDIT:OUTPUT:Rev or PART EDIT:OUTPUT:Rev Send Level)

will change.

6

Eect 3 (Chorus Send Level) (Controller number 93)

Status 2nd byte 3rd byte BnH 5DH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Chorus Send Level: 00H - 7FH (0 - 127)

* In Performance mode, the Part Chorus Send Level parameter (PERFORM EDIT:OUTPUT:Cho or PART EDIT:OUTPUT:Cho Send Level)

will change.

6

RPN MSB/LSB (Controller number 100, 101) Status 2nd byte 3rd byte BnH 65H mmH BnH 64H llH n = MIDI channel number: 0H - FH (ch.1 - 16)

mm = upper byte (MSB) of parameter number specied by RPN ll = lower byte (LSB) of parameter number specied by RPN

<<< RPN >>> Control Changes include RPN (Registered Parameter Numbers), which are extended.

When using RPNs, rst RPN (Controller numbers 100 and 101; they can be sent in any order) should be sent in order to

select the parameter, then Data Entry (Controller numbers 6 and 38) should be sent to set the value. Once RPN messages are received, Data Entry messages that is received at the same MIDI channel after that are recognized as changing toward the value of the RPN messages. In order not to make any mistakes, transmitting RPN Null is recommended after setting parameters you need.

5

This device receives the following RPNs. RPN Data entry MSB, LSB MSB, LSB Notes 00H, 00H mmH, llH Pitch Bend Sensitivity mm: 00H - 18H (0 - 24 semitones) ll: ignored (processed as 00H)

Up to 2 octave can be specied in semitone steps.

* In Performance mode, the Part Pitch Bend Range parameter (PERFORM EDIT:PITCH:Bend or PART EDIT:PITCH:Bend Range) will

change.

00H, 01H mmH, llH Channel Fine Tuning mm, ll: 20 00H - 40 00H - 60 00H (-4096 x 100 / 8192 - 0 - +4096 x 100 / 8192 cent)

* In Performance mode, the Part Fine Tune parameter (PERFORM EDIT:PITCH:Fine or PART EDIT:PITCH:Fine Tune) will change.

00H, 02H mmH, llH Channel Coarse Tuning mm: 10H - 40H - 70H (-48 - 0 - +48 semitones) ll: ignored (processed as 00H)

* In Performance mode, the Part Coarse Tune parameter (PERFORM EDIT:PITCH:Crs or PART EDIT:PITCH:Coarse Tune) will change.

00H, 05H mmH, llH Modulation Depth Range mm, ll: 00 00H - 00 06H (0 - 16384 x 600 / 16384 cent)

* Not received in Patch mode.

7FH, 7FH ---, --- RPN null

RPN and NRPN will be set as “unspecied.” Once this setting has been made, subsequent Parameter

values that were previously set will not change. mm, ll: ignored

7

Program Change Status 2nd byte CnH ppH n = MIDI channel number: 0H - FH (ch.1 - 16) pp = Program number: 00H - 7FH (prog.1 - prog.128)

* Not received in Performance mode when the Receive Program Change parameter (PERFORM EDIT:MIDI:PC or PART EDIT:MIDI:PC) is

OFF.

7

Channel Pressure Status 2nd byte DnH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Channel Pressure: 00H - 7FH (0 - 127)

* Not received in Performance mode when the Receive Channel Pressure parameter (PERFORM EDIT:MIDI:CA or PART EDIT:MIDI:CAFT)

is OFF.

7

Pitch Bend Change Status 2nd byte 3rd byte EnH llH mmH n = MIDI channel number: 0H - FH (ch.1 - 16) mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

* Not received when the Tone Receive Bender parameter (PATCH EDIT:CTRL:Rx Bender) is OFF.

* Not received in Performance mode when the Receive Bender parameter (PERFORM EDIT:MIDI:PB or PART EDIT:MIDI:BEND) is OFF.

9

Channel Mode Messages

* Not received in Performance mode when the Receive Switch parameter (PERFORM EDIT:LEVEL/CH:RxSw or PART EDIT:LEVEL/CH:Rx

Switch) is OFF.

7

All Sounds O (Controller number 120)

Status 2nd byte 3rd byte BnH 78H 00H n = MIDI channel number: 0H - FH (ch.1 - 16)

* When this message is received, all notes currently sounding on the corresponding channel will be turned o.

7

Reset All Controllers (Controller number 121) Status 2nd byte 3rd byte BnH 79H 00H n = MIDI channel number: 0H - FH (ch.1 - 16)

* When this message is received, the following controllers will be set to their reset values.

Controller Reset value Pitch Bend Change +/-0 (center)

Polyphonic Key Pressure 0 (o)

6

Channel Pressure 0 (o) Modulation 0 (o)

Breath Type 0 (min) Expression 127 (max) However the controller will be at minimum.

Hold 1 0 (o) Sostenuto 0 (o) RPN unset; previously set data will not change NRPN unset; previously set data will not change

7

All Notes O (Controller number 123)

Status 2nd byte 3rd byte BnH 7BH 00H n = MIDI channel number: 0H - FH (ch.1 - 16)

* When All Notes O is received, all notes on the corresponding channel will be turned o. However, if Hold 1 or Sostenuto

is ON, the sound will be continued until these are turned o.

7

OMNI OFF (Controller number 124) Status 2nd byte 3rd byte BnH 7CH 00H n = MIDI channel number: 0H - FH (ch.1 - 16)

* The same processing will be carried out as when All Notes O is received.

7

OMNI ON (Controller number 125) Status 2nd byte 3rd byte BnH 7DH 00H n = MIDI channel number: 0H - FH (ch.1 - 16)

* The same processing will be carried out as when All Notes O is received. OMNI ON will not be turned on.

7

MONO (Controller number 126) Status 2nd byte 3rd byte BnH 7EH mmH n = MIDI channel number: 0H - FH (ch.1 - 16) mm = mono number: 00H - 10H (0 - 16)

* The same processing will be carried out as when All Notes O is received.

* In Performance mode, the Part Mono/Poly parameter (PERFORM EDIT:PITCH:Mono or PART EDIT:PITCH:Mono/Poly) will change.

7

POLY (Controller number 127) Status 2nd byte 3rd byte BnH 7FH 00H n = MIDI channel number: 0H - FH (ch.1 - 16)

* The same processing will be carried out as when All Notes O is received.

* In Performance mode, the Part Mono/Poly parameter (PERFORM EDIT:PITCH:Mono or PART EDIT:PITCH:Mono/Poly) will change.

9

System Realtime Messages

7

Active Sensing Status FEH

* When Active Sensing is received, the unit will begin monitoring the intervals of all further messages. While monitoring,

if the interval between messages exceeds 420 ms, the same processing will be carried out as when All Sounds O, All Notes O and Reset All Controllers are received, and message interval monitoring will be halted.

9

System Exclusive Message Status Data byte Status

F0H iiH, ddH, ......,eeH F7H

F0H: System Exclusive Message status ii = ID number: an ID number (manufacturer ID) to indicate the manufacturer whose Exclusive message this is.

Roland’s manufacturer ID is 41H. ID numbers 7EH and 7FH are extensions of the MIDI standard;

Universal Non-realtime Messages (7EH) and Universal Realtime Messages (7FH). dd,...,ee = data: 00H - 7FH (0 - 127) F7H: EOX (End Of Exclusive)

Of the System Exclusive messages received by this device, the Universal Non-realtime messages and the Universal Realtime

messages and the Data Request (RQ1) messages and the Data Set (DT1) messages will be set automatically.

7

Universal Non-realtime System Exclusive Messages

6

Identity Request Message

Status Data byte Status F0H 7EH, dev, 06H, 01H F7H

Byte Explanation F0H Exclusive status 7EH ID number (Universal Non-realtime Message) dev Device ID (dev: 10H, 7FH) 06H Sub ID#1 (General Information)

01H Sub ID#2 (Identity Request)

F7H EOX (End Of Exclusive)

* When this message is received, Identity Reply message (p. 16) will be transmitted.

6

GM1 System On Status Data byte Status F0H 7EH, 7FH, 09H, 01H F7H

Byte Explanation F0H Exclusive status 7EH ID number (Universal Non-realtime Message) 7FH Device ID (Broadcast) 09H Sub ID#1 (General MIDI Message) 01H Sub ID#2 (General MIDI 1 On) F7H EOX (End Of Exclusive)

* When this messages is received, this instrument will turn to the Performance mode.

6

GM2 System On Status Data byte Status F0H 7EH 7FH 09H 03H F7H

Byte Explanation F0H Exclusive status 7EH ID number (Universal Non-realtime Message) 7FH Device ID (Broadcast) 09H Sub ID#1 (General MIDI Message) 03H Sub ID#2 (General MIDI 2 On) F7H EOX (End Of Exclusive)

* When this messages is received, this instrument will turn to the Performance mode.

6

GM System O

Status Data byte Status F0H 7EH, 7F, 09H, 02H F7H

Byte Explanation F0H Exclusive status 7EH ID number (Universal Non-realtime Message) 7FH Device ID (Broadcast) 09H Sub ID#1 (General MIDI Message)

02H Sub ID#2 (General MIDI O)

F7H EOX (End Of Exclusive)

* When this messages is received, this instrument will return to the Performance mode.

7

Universal Realtime System Exclusive Messages

6

Master Volume Status Data byte Status F0H 7FH, 7FH, 04H, 01H, llH, mmH F7H

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 04H Sub ID#1 (Device Control) 01H Sub ID#2 (Master Volume) llH Master Volume lower byte mmH Master Volume upper byte F7H EOX (End Of Exclusive)

* The lower byte (llH) of Master Volume will be handled as 00H.

* The Master Level parameter (SYSTEM:SOUND:Master Level) will change.

8

6

Master Fine Tuning Status Data byte Status F0H 7FH, 7FH, 04H, 03H, llH, mmH F7H

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 04H Sub ID#1 (Device Control) 03H Sub ID#2 (Master Fine Tuning) llH Master Fine Tuning LSB mmH Master Fine Tuning MSB F7H EOX (End Of Exclusive)

mm, ll: 00 00H - 40 00H - 7F 7FH (-100 - 0 - +99.9 [cents])

* The Master Tune parameter (SYSTEM:SOUND:Master Tune) will change.

6

Master Coarse Tuning Status Data byte Status F0H 7FH, 7FH, 04H, 04H, llH, mmH F7

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 04H Sub ID#1 (Device Control) 04H Sub ID#2 (Master Coarse Tuning) llH Master Coarse Tuning LSB mmH Master Coarse Tuning MSB F7H EOX (End Of Exclusive)

llH: ignored (processed as 00H) mmH: 28H - 40H - 58H (-24 - 0 - +24 [semitones])

* The Master Key Shift parameter (SYSTEM:SOUND:Master Key Shift) will change.

7

Global Parameter Control

* Not received in Patch mode.

6

Reverb Parameters Status Data byte Status F0H 7FH, 7FH, 04H, 05H, 01H, 01H, F7H 01H, 01H, 01H, ppH, vvH

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 04H Sub ID#1 (Device Control) 05H Sub ID#2 (Global Parameter Control) 01H Slot path length 01H Parameter ID width 01H Value width 01H Slot path MSB

01H Slot path LSB (Eect 0101: Reverb)

ppH Parameter to be controlled. vvH Value for the parameter. pp=0 Reverb Type vv=00H Small Room vv=01H Medium Room vv=02H Large Room vv=03H Medium Hall vv=04H Large Hall vv=08H Plate pp=1 Reverb Time vv=00H - 7FH 0 - 127 F7H EOX (End Of Exclusive)

9

6

Chorus Parameters Status Data byte Status F0H 7FH, 7FH, 04H, 05H, 01H, 01H, F7H 01H, 01H, 02H, ppH, vvH

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 04H Sub ID#1 (Device Control) 05H Sub ID#2 (Global Parameter Control) 01H Slot path length 01H Parameter ID width 01H Value width 01H Slot path MSB

02H Slot path LSB (Eect 0102: Chorus)

ppH Parameter to be controlled. vvH Value for the parameter. pp=0 Chorus Type vv=0 Chorus1 vv=1 Chorus2 vv=2 Chorus3 vv=3 Chorus4 vv=4 FB Chorus vv=5 Flanger pp=1 Mod Rate vv=00H - 7FH 0 - 127 pp=2 Mod Depth vv=00H - 7FH 0 - 127 pp=3 Feedback vv=00H - 7FH 0 - 127 pp=4 Send To Reverb vv=00H - 7FH 0 - 127 F7H EOX (End Of Exclusive)

6

Channel Pressure Status Data byte Status F0H 7FH, 7FH, 09H, 01H, 0nH, ppH, rrH F7H

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 09H Sub ID#1 (Controller Destination Setting) 01H Sub ID#2 (Channel Pressure) 0nH MIDI Channel (00 - 0F) ppH Controlled parameter rrH Controlled range pp=0 Pitch Control rr=28H - 58H -24 - +24 [semitones]

pp=1 Filter Cuto Control

rr=00H - 7FH -9600 - +9450 [cents] pp=2 Amplitude Control rr=00H - 7FH 0 - 200% pp=3 LFO Pitch Depth rr=00H - 7FH 0 - 600 [cents] pp=4 LFO Filter Depth rr=00H - 7FH 0 - 2400 [cents] pp=5 LFO Amplitude Depth rr=00H - 7FH 0 - 100% F7H EOX (End Of Exclusive)

10

6

Controller Status Data byte Status F0H 7FH, 7FH, 09H, 03H, 0nH, ccH, ppH, rrH F7H

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 09H Sub ID#1 (Controller Destination Setting) 03H Sub ID#2 (Control Change) 0nH MIDI Channel (00 - 0F) ccH Controller number (01 - 1F, 40 - 5F) ppH Controlled parameter rrH Controlled range pp=0 Pitch Control rr=28H - 58H -24 - +24 [semitones]

pp=1 Filter Cuto Control

rr=00H - 7FH -9600 - +9450 [cents] pp=2 Amplitude Control rr=00H - 7FH 0 - 200% pp=3 LFO Pitch Depth rr=00H - 7FH 0 - 600 [cents] pp=4 LFO Filter Depth rr=00H - 7FH 0 - 2400 [cents] pp=5 LFO Amplitude Depth rr=00H - 7FH 0 - 100% F7H EOX (End Of Exclusive)

6

Scale/Octave Tuning Adjust Status Data byte Status

F0H 7EH, 7FH, 08H, 08H, H, ggH, hhH, ssH... F7

Byte Explanation F0H Exclusive status 7EH ID number (Universal Non-realtime Message) 7FH Device ID (Broadcast) 08H Sub ID#1 (MIDI Tuning Standard) 08H Sub ID#2 (scale/octave tuning 1-byte form)

H Channel/Option byte 1

bits 0 to 1 = channel 15 to 16

bit 2 to 6 = Undened

ggH Channel byte 2 bits 0 to 6 = channel 8 to 14 hhH Channel byte 3 bits 0 to 6 = channel 1 to 7

ssH 12 byte tuning oset of 12 semitones from C to B

00H = -64 [cents]

40H = 0 [cents] (equal temperament)

7FH = +63 [cents] F7H EOX (End Of Exclusive)

6

Key-based Instrument Controllers Status Data byte Status F0H 7FH, 7FH, 0AH, 01H, 0nH, kkH, nnH, vvH F7H

Byte Explanation F0H Exclusive status 7FH ID number (universal realtime message) 7FH Device ID (Broadcast) 0AH Sub ID#1 (Key-Based Instrument Control) 01H Sub ID#2 (Controller) 0nH MIDI Channel (00 - 0FH) kkH Key Number nnH Control Number vvH Value nn=07H Level vv=00H - 7FH 0 - 200% (Relative) nn=0AH Pan vv=00H - 7FH Left - Right (Absolute) nn=5BH Reverb Send vv=00H - 7FH 0 - 127 (Absolute) nn=5D Chorus Send vv=00H - 7FH 0 - 127 (Absolute) : : F7H EOX (End Of Exclusive)

* This parameter aects drum instruments only.

11

7

Data Transmission This instrument can use exclusive messages to exchange many varieties of internal settings with other devices. The model ID of the exclusive messages used by this instrument is 00H 00H 3AH.

6

Data Request 1 (RQ1) This message requests the other device to transmit data. The address and size indicate the type and amount of data that is

requested. When a Data Request message is received, if the device is in a state in which it is able to transmit data, and if the

address and size are appropriate, the requested data is transmitted as a Data Set 1 (DT1) message. If the conditions are

not met, nothing is transmitted.

Status Data byte Status F0H 41H, dev, 00H, 00H, 3AH, 11H, aaH, bbH, F7H ccH, ddH, ssH, ttH, uuH, vvH, sum

Byte Remarks F0H Exclusive status 41H ID number (Roland) dev device ID (dev: 10H, 7FH) 00H model ID #1 (JUNO-DS61/DS88) 00H model ID #2 (JUNO-DS61/DS88) 3AH model ID #3 (JUNO-DS61/DS88)

11H command ID (RQ1)

aaH address MSB bbH address ccH address ddH address LSB ssH size MSB ttH size uuH size vvH size LSB sum checksum F7H EOX (End Of Exclusive)

* The size of data that can be transmitted at one time is xed for each type of data. And data requests must be made with a

xed starting address and size. Refer to the address and size given in “Parameter Address Map” (p. 19).

* For the checksum, refer to p. 64.

6

Data set 1 (DT1) Status Data byte Status F0H 41H, dev, 00H, 00H, 3AH, 12H, aaH, bbH, F7H

ccH, ddH, eeH, ... H, sum

Byte Explanation F0H Exclusive status 41H ID number (Roland) dev Device ID (dev: 10H, 7FH) 00H Model ID #1 (JUNO-DS61/DS88) 00H Model ID #2 (JUNO-DS61/DS88) 3AH Model ID #3 (JUNO-DS61/DS88) 12H Command ID (DT1) aaH Address MSB: upper byte of the starting address of the data to be sent bbH Address: upper middle byte of the starting address of the data to be sent ccH Address: lower middle byte of the starting address of the data to be sent ddH Address LSB: lower byte of the starting address of the data to be sent. eeH Data: the actual data to be sent. Multiple bytes of data are transmitted in order starting from the address. :

H Data

sum Checksum F7H EOX (End Of Exclusive)

* The amount of data that can be transmitted at one time depends on the type of data, and data will be transmitted from the

specied starting address and size. Refer to the address and size given in “Parameter Address Map” (p. 19).

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each packet will be sent at an interval

of about 20 ms.

* Regarding the checksum, please refer to p. 64.

Status Data byte Status F0H 41H, dev, 42H, 12H, aaH, bbH, ccH, F7H ddH, ... eeH, sum

Byte Explanation F0H Exclusive status 41H ID number (Roland) dev Device ID (dev: 10H, 7FH) 42H Model ID (GS) 12H Command ID (DT1) aaH Address MSB: upper byte of the starting address of the transmitted data

12

bbH Address: middle byte of the starting address of the transmitted data ccH Address LSB: lower byte of the starting address of the transmitted data ddH Data: the actual data to be transmitted. Multiple bytes of data are transmitted starting from the address. : eeH Data sum Checksum F7H EOX (End Of Exclusive)

* The amount of data that can be transmitted at one time depends on the type of data, and data will be transmitted from the

specied starting address and size. Refer to the address and size given in “Parameter Address Map” (p. 19).

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each packet will be sent at an interval

of about 20 ms.

* Regarding the checksum, please refer to p. 64.

2. Data Transmission (Sound Source Section)

9

Channel Voice Messages

7

Note o

Status 2nd byte 3rd byte 8nH kkH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) kk = note number: 00H - 7FH (0 - 127)

vv = note o velocity: 00H - 7FH (0 - 127)

7

Note on Status 2nd byte 3rd byte 9nH kkH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) kk = note number: 00H - 7FH (0 - 127) vv = note on velocity: 01H - 7FH (1 - 127)

7

Control Change

* By selecting a controller number that corresponds to the setting of parameters of controllers, the JUNO-DS61/DS88 can

transmit any control change message.

6

Bank Select (Controller number 0, 32) Status 2nd byte 3rd byte BnH 00H mmH BnH 20H llH n = MIDI channel number: 0H - FH (ch.1 - 16) mm, ll = Bank number: 00 00H - 7F 7FH (bank.1 - bank.16384)

* These messages are transmitted when Patch, Drum Kit, Performance, or Pattern is selected.

6

Modulation (Controller number 1) Status 2nd byte 3rd byte BnH 01H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Modulation depth: 00H - 7FH (0 - 127)

6

Breath type (Controller number 2) Status 2nd byte 3rd byte BnH 02H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

6

Portamento Time (Controller number 5) Status 2nd byte 3rd byte BnH 05H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Portamento Time: 00H - 7FH (0 - 127)

6

Data Entry (Controller number 6, 38) Status 2nd byte 3rd byte BnH 06H mmH BnH 26H llH n = MIDI channel number: 0H - FH (ch.1 - 16)

mm, ll = the value of the parameter specied by RPN/NRPN

mm = MSB, ll = LSB

6

Volume (Controller number 7) Status 2nd byte 3rd byte BnH 07H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Volume: 00H - 7FH (0 - 127)

13

6

Panpot (Controller number 10) Status 2nd byte 3rd byte BnH 0AH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Panpot: 00H - 40H - 7FH (Left - Center - Right)

6

Expression (Controller number 11) Status 2nd byte 3rd byte BnH 0BH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Expression: 00H - 7FH (0 - 127)

6

Hold 1 (Controller number 64) Status 2nd byte 3rd byte BnH 40H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127) 0-63 = OFF, 64-127 = ON

* If the Continuous Hold Pedal parameter (SYSTEM:PEDAL:Continuous Hold Pedal) is set to OFF on the JUNO-DS61/DS88, only 00H

(OFF) or 7FH (ON) can be transmitted as the value of the control.

6

Portamento (Controller number 65) Status 2nd byte 3rd byte BnH 41H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127) 0 - 63 = OFF, 64 - 127 = ON

6

Resonance (Controller number 71) Status 2nd byte 3rd byte BnH 47H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv= Resonance value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

6

Release Time (Controller number 72) Status 2nd byte 3rd byte BnH 48H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Release Time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

6

Attack time (Controller number 73) Status 2nd byte 3rd byte BnH 49H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Attack time value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

6

Cuto (Controller number 74)

Status 2nd byte 3rd byte BnH 4AH vvH n = MIDI channel number: 0H - FH (ch.1 - 16)

vv = Cuto value (relative change): 00H - 40H - 7FH (-64 - 0 - +63)

6

General Purpose Controller 5 (Controller number 80) Status 2nd byte 3rd byte BnH 50H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

6

General Purpose Controller 6 (Controller number 81) Status 2nd byte 3rd byte BnH 51H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

6

General Purpose Controller 7 (Controller number 82) Status 2nd byte 3rd byte BnH 52H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

6

General Purpose Controller 8 (Controller number 83) Status 2nd byte 3rd byte BnH 53H vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Control value: 00H - 7FH (0 - 127)

14

6

Portamento control (Controller number 84) Status 2nd byte 3rd byte BnH 54H kkH n = MIDI channel number: 0H - FH (ch.1 - 16) kk = source note number: 00H - 7FH (0 - 127)

7

Program Change Status 2nd byte CnH ppH n = MIDI channel number: 0H - FH (ch.1 - 16) pp = Program number: 00H - 7FH (prog.1 - prog.128)

* These messages are transmitted when Patch, Drum Kit, Performance, or Pattern is selected.

7

Channel Pressure Status 2nd byte DnH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Channel Pressure: 00H - 7FH (0 - 127)

7

Pitch Bend Change Status 2nd byte 3rd byte EnH llH mmH n = MIDI channel number: 0H - FH (ch.1 - 16) mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

9

Channel Mode Messages

6

MONO (Controller number 126) Status 2nd byte 3rd byte BnH 7EH mmH n = MIDI channel number: 0H - FH (ch.1 - 16) mm = mono number: 00H - 10H (0 - 16)

6

POLY (Controller number 127) Status 2nd byte 3rd byte BnH 7FH 00H n = MIDI channel number: 0H - FH (ch.1 - 16)

9

System Realtime Messages

7

Timing Clock Status F8H

* Transmitted when the Sync Mode parameter (DAW CONTROL:DAW:Sync Mode) is set to SLAVE and the Sync Output parameter (DAW

CONTROL:DAW:Sync Output) is set to ON.

7

Continue Status FBH

* Transmitted when the Control Map parameter (DAW CONTROL:DAW:Control Map) is set to USER.

7

Stop Status FCH

* Transmitted when the Control Map parameter (DAW CONTROL:DAW:Control Map) is set to USER.

7

Active Sensing Status FEH

* This message is transmitted at intervals of approximately 250 msec.

15

9

System Exclusive Messages Universal Non-realtime System Exclusive Message and Data Set 1 (DT1) are the only System Exclusive messages transmitted by

the JUNO-DS61/DS88.

7

Universal Non-realtime System Exclusive Message

6

Identity Reply Message (JUNO-DS61/DS88)

Receiving Identity Request Message (p. 8), the JUNO-DS61/DS88 send this message.

Status Data byte Status F0H 7EH, dev, 06H, 02H, 41H, 3AH, 02H, F7H 00H, 00H, 00H, 03H, 00H, 00H

Byte Explanation F0H Exclusive status 7EH ID number (Universal Non-realtime Message) 10H Device ID (dev: 10H) 06H Sub ID#1 (General Information) 02H Sub ID#2 (Identity Reply) 41H ID number (Roland) 3AH 02H Device family code 02H 00H Device family number code 00H 03H 00H 00H Software revision level F7H EOX (End of Exclusive)

7

Data Transmission

6

Data set 1 (DT1) Status Data byte Status F0H 41H, dev, 00H, 00H, 3AH, 12H, aaH, bbH, F7H

ccH, ddH, eeH, ... H, sum

Byte Explanation F0H Exclusive status 41H ID number (Roland) dev Device ID (dev: 10H, 7FH) 00H Model ID #1 (JUNO-DS61/DS88) 00H Model ID #2 (JUNO-DS61/DS88) 3AH Model ID #3 (JUNO-DS61/DS88) 12H Command ID (DT1) aaH Address MSB: upper byte of the starting address of the data to be sent bbH Address: upper middle byte of the starting address of the data to be sent ccH Address: lower middle byte of the starting address of the data to be sent ddH Address LSB: lower byte of the starting address of the data to be sent. eeH Data: the actual data to be sent. Multiple bytes of data are transmitted in order starting from the address. : :

H Data

sum Checksum F7H EOX (End Of Exclusive)

* The amount of data that can be transmitted at one time depends on the type of data, and data will be transmitted from the

specied starting address and size. Refer to the address and size given in “Parameter Address Map” (p. 19).

* Data larger than 256 bytes will be divided into packets of 256 bytes or less, and each packet will be sent at an interval

of about 20 ms.

16

3. Data Reception (Sequencer Section)

3.1 Messages recorded during recording

9

Channel Voice Messages

7

Note o

Status 2nd byte 3rd byte 8nH kkH vvH 9nH kkH 00H n = MIDI channel number: 0H - FH (ch.1 - 16) kk = note number: 00H - 7FH (0 - 127)

vv = note o velocity: 00H - 7FH (0 - 127)

7

Note on Status 2nd byte 3rd byte 9nH kkH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) kk = note number: 00H - 7FH (0 - 127) vv = note on velocity: 01H - 7FH (1 - 127)

7

Control Change Status 2nd byte 3rd byte BnH 01H vvH n = MIDI channel number: 0H - FH (ch.1 - ch.16) kk = Control number: 00H - 78H (0 - 120) vv = value: 00H - 7FH (0 - 127)

* kk = 00H and kk = 20H are not recorded.

7

Channel Aftertouch Status 2nd byte DnH vvH n = MIDI channel number: 0H - FH (ch.1 - 16) vv = Channel Aftertouch: 00H - 7FH (0 - 127)

7

Pitch Bend Change Status 2nd byte 3rd byte EnH llH mmH n = MIDI channel number: 0H - FH (ch.1 - 16) mm, ll = Pitch Bend value: 00 00H - 40 00H - 7F 7FH (-8192 - 0 - +8191)

9

Channel Mode Messages

7

All Sounds O (Controller number 120)

Status 2nd byte 3rd byte BnH 78H 00H n = MIDI channel number: 0H - FH (ch.1 - 16)
