Roland DS-1 User Manual

Owner's Manual

DCAC

AC & BATTERY

POWERED

FET

1

Thank you, and congratulations on your choice of BOSS DS-1 Distortion.
Before using this unit, carefully read the sections entitled: “USING THE UNIT SAFELY”

and “IMPORTANT NOTES” (separate sheet). These sections provide important information
concerning the proper operation of the unit. Additionally, in order to feel assured that you
have gained a good grasp of every feature provided by your new unit, this manual should
be read in its entirety. The manual should be saved and kept on hand as a convenient
reference.

Copyright © 1994 BOSS Corporation
All right reserved. No part of this publication may be reproduced in any form without the
permission of BOSS Corporation.

2

FEATURES

The DS-1 is an effect unit that generates both distortion and sustain effects.
By rotating the knobs you can create all kinds of sounds, from warm, soft sustain to hard,

powerful distortion.
The DS-1 can be powered by a battery or an optional AC adaptor.

3

PANEL DESCRIPTIONS

1
2

3

4

5

4

1. AC Adaptor Jack

Accepts connection of an AC Adaptor (op­tionally available BOSS PSA-Series). By
using an AC Adaptor, you can play without
being concerned about how much battery
power you have left.

* You may find that it is a good idea to keep a

battery installed in the unit even while using

6

an adaptor. That way your playing won't be
disrupted even if the adaptor is accidentally
disconnected.

* If you are going to use an AC adaptor, be sure

to use the specified unit (BOSS PSA-Series).
Use of any other adaptor may result in dam­age, malfunction or electric shock.
Also, if you are not going to be using it for an
extended period of time, disconnect the AC
adaptor from the AC outlet.

2. CHECK Indicator

This indicator shows whether an effect is
ON/OFF, and also doubles as the Battery
Check indicator.
The indicator lights when an effect is ON.
If this indicator goes dim or no longer lights
while an effect is ON, the battery is near
exhaustion and should be replaced imme­diately.

* The CHECK indicator shows whether the effect

is being applied or not. It does not indicate
whether the power to the device is on or not.

3. OUTPUT Jack

The output jacks are used to connect the
unit to amplifiers or other devices.

4. Pedal Switch

This switch turns the effects ON/OFF.

5. Thumbscrew

This thumbscrew is loosened to open the
pedal, allowing battery replacement. For
instructions on how to replace the battery,
please refer to “Changing the Battery.”

6. INPUT Jack

This jack accepts input signals (coming
from a guitar, some other electric or elec­tronic musical instrument, or another ef­fects unit).

* The INPUT jack also serves as the power

switch. Power is turned on whenever a plug is
inserted into the INPUT jack, and is turned off
when the plug is disconnected. When not
using the unit, you should disconnect any
cord connected to the INPUT jack.

5
