Page 1
INDEX
CHAPTER 1- SUMMARY OF USER’S COMMANDS ....................................... 3
CHAPTER 2 – ABOUT THE KEYPAD .............................................................. 5
RP208KCL (LCD KEYPAD) ........................ 5
KEYS AND LED INDICATORS .............................. 5
CHAPTER 3 – SYSTEM FUNCTION AND OPERATION ................................. 9
3.1 DEPRESS KEYS AUDIBLE ........................... 9
3.2 DOOR CHIME .................................. 9
3.3 THE NUMERIC KEYS AND CHARACTER RELATIVE FORM ............... 9
3.4 DIGIT KEYS AND FUNCTIONS KEYS ..................... 10
3.5 MODIFYING/ SETTING AND DELETING CODE ............. 10
3.6 SET DATE AND TIME ............................. 14
3.7 SET FOLLOW-ME NUMBERS ......................... 14
3.8 ARM AND ARM SOUND ............................ 14
3.9 DISARM AND DISARM SOUND ......................... 15
3.10 DURESS CODE DISARM .............................. 16
3.11 STOP SIREN/BELL AND STOP DIALING A NUMBER ................. 16
3.12 BYPASS AND UN-BYPASS ZONE(S) ........................ 16
3.13 EXIT A ERROR OPERATION ......................... 18
3.14 KEYPAD ALARM ................................. 18
3.15 ENTRY DELAY AND EXIT DELAY .................... 18
3.16 TROUBLE AND DISPLAY ........................ 18
3.17 ZONES CHARACTERS ........................... 19
3.18 SYSTEM PARTITION AND CONTROL .................... 19
CHAPTER 4 SYSTEM INSTALL EXPLAIN .................................................... 22
4.1 PREPARATION BEFORE INSTALLATION ................ 22
4.2 FQA OF INSTALLATION AND SOLUTION ................ 22
4.3 MAIN BROAD LAYOUT AND PORT FUNCTION DESCRIPTION ： ..... 23
4.5 CONNECT THE TELEPHONE LINE ...................... 24
4.6 CONNECT THE STANDBY BATTERY ...................... 26
`RP248CN User’s and Installer’s Manual
Page 2
4.7CONNECT TRANSFORMER ........................... 26
4.8 CONNECT SIREN/BELL ......................... 26
4.9 CONNECT DETECTOR(S) ........................... 26
4.10 CONNECT VOICE MODULE ........................ 26
CHAPTER 5 - FUNCTION AND TECHNICAL DATA ...................................... 28
5.1 FEATURES OF RP248KCL ....................... 28
5.2 FEATURES OF RP248MB AND EXPANSION MODULES ........ 29
5.3 TECHNICAL DATA ................................ 34
CHAPTER 6 PROGRAMMING DIRECTION .................................................. 36
6.1 PROGRAMMABLE ITEMS ............................ 36
6.2 RESTORE FACTORY DEFAULTS ................... 36
6.3 PROGRAM EXPLAIN .............................. 36
6.4 CHECK LOCATION DATA ............................ 37
6.5 ENTRY/EXIT PROGRAM STATUS .................. 37
6.5.4 Programmable Utility Output
................................................................................................................ 43
6.6 COMMUNICATION PROTOCOLS .......................... 50
6.7 RP248CN CONTROL PANEL CONTACT ID REPORTING CODES . . . 51
ROISCOK’S WARRANT ................................................................................. 53
`RP248CN User’s and Installer’s Manual
Page 3
CHAPTER 1- SUMMARY of USER’S COMMANDS
The Summary of User’s Commands offers installers and users a quick and convenient way to
operate control panel. All can be done under the status of disarm and so it doesn’t need to entry
programming statue. For detailed information, please go chapter 2 and chapter 3.
No Function Procedure
1 Quick arm [ARM] 2 Arm by code [ARM]+[master code] 3 Arm Stay zones [STAY] 4 Arm Stay zones by code [STAY]+[master code] 5 System disarm [user code]+[#] 6 Duress disarm [duress code]+[#] 7 Free from siren [user code]+[#]
Bypass zone [*]+[1] [1]+[user code]+[zone number]
9 Un-bypass zone [*]+[1] [2]+[user code]+[zone number] 10 Utility output [*]+[2][1] 11 Set follow-me phone No. [*]+[2][7]+[ user code]+[ phone No.] 12 Display trouble [*]+[3][1] 13 Display triggered record [*]+[3][2] 14 Display unready zone [*]+[3][3] 15 Display zone status [*]+[3][4] 16 Display memory [*]+[3][5] 17 Test keypad [*]+[4][1] 18 Test Stand-by battery [*]+[4][2] 19 Off door chime [*]+[4][3] 20 On door chime [*]+[4][4] 21 Off partition door chime [*]+[4][5] 22 On partition door chime [*]+[4][6] 23 Off buzzer [*]+[4][7] 24 On buzzer [*]+[4][8] 25 Delete memory [*]+[4][9] 26 Set/change users code [*]+[5] 27 Set time [*]+[6]+[1] 28 Set date [*]+[6]+[2] 29 Next Auto arm time [*]+[6]+[3] 30 Next Auto disarm time [*]+[6]+[4] 31 Auto arm [*]+[6]+[5] 32 Auto disarm [*]+[6]+[6] 33 Auto stay arm [*]+[6]+[7] 34 keypad panic alarm [1]+[2] at least 2 seconds 35 keypad fire alarm [4]+[5] at least 2 seconds 36 keypad special emergency [7]+[8] at least 2 seconds 37 Escape [ESC]
RP248CN User’s and Installer’s Manual Page 3
Page 4
Trouble List
LCD Display Trouble
MAIN：LOW BATT Battery Power low MAIN：AC TROUBLE AC lost MAIN：BELL LOOP Siren trouble FLASE CODE P=1 Code error KITCHEN：FIR Fire Loop in trouble
KP=03 COMM TRBL The bus in trouble, such as No.3 keypad is in trouble
SYSTEM CLCOK Clock not set
PS= 1 LOW BAT Power Module Battery low. Such as No.1 power Expansion
Module is in trouble
PS=1 AC TRBL Power Module in AC Trouble. Such as No.1 power Expansion
Module is in trouble
PS=1 BELL TRBL Power Module Siren in Trouble. Such as No.1 power
Expansion Module is in trouble
PS=1 AUX TRBL Power Module Stand-by Power is low. Such as No.1 power
Expansion Module is in trouble
PHONE LINE Phone line in trouble
FIRE DOOR：DAY Day time zone in trouble.
RP248CN User’s and Installer’s Manual Page 4
Page 5
CHAPTER 2 – ABOUT THE KEYPAD
RP208KCL (LCD Keypad)
The control panel RP248CN supports LCD Keypad. Each main board can work with 16 LCD
Keypads at most.
The keypads display system status by its LED indicators and LCD display. Through its keys, can
arm and disarm the system, bypass intrusion zones, report emergencies, stop the siren, stop
calling follow-me number, checking the trouble, program the system etc.
Fig.1 Layout of the RP208KCL
Keys Instruction
1：Power LED
2：LCD Display
3：Arm LED
4：Disarm LED
5：Bypass LED
6：Fire LED
7：Tamper LED
8：Digit and Function key-press
9：Arm key-press
10：Buzzer
11：Stay Arm key-press
Keys and LED indicators
The Keys functions:
For Arming, Disarming, Panic Alarm, Programming system etc.
1.
Entry user’s function mode.
2.
Key [ARM] is for quick arming and code arming. When arm by [ARM], the system will be fully
3.
armed.
RP248CN User’s and Installer’s Manual Page 5
Page 6
Key [STAY] is for quick stay arming and code stay arming. Any zone or zones can be set as
4.
interior zone(s) or external zone(s). When arming by [STAY], the external zone(s) will be
armed while leaves the interior zone(s) disarmed.
Under the disarmed status, depress [*] to entry user’s function mode for setting code, clock,
5.
on/off the buzzer and so on. For detail, go to CHAPTER 1- SUMMARY of USER’S
COMMANDS
1. Power LED
On--the system AC power supply is in normal and the stand-by battery is in good condition.
Off—no AC power supply and stand-by battery is in power lack.
Fast flicker—system in trouble.
Slow flicker—system is in users function.
2. LCD Display
The LCD Display on RP248KCL indicates the system status, including zones triggered,
armed/disarmed system, system trouble, time and other programmed information.
Normally the LCD Display indicates partition No., clock, date and weekday as following:
PARTITION 1
10.18 JAN 10 THU
3. ARM LED
On-- system is armed.
Off-- system is disarmed or under the programming status.
Flicker-- The system is under the delay period status.
4. READY LED
The Ready LED indicates whether the system is under ready or not, and also whether system can
be armed or not.
On-- The system is ready to be armed now.
Off-- The system is not ready to be armed now.
Flicker-- The system is ready for arming, and at the same time some especial zone(s) with entry
/exit delay is triggered.
RP248CN User’s and Installer’s Manual Page 6
Page 7
5. BYPASS LED
When BYPASS LED on, one or more zone(s) has/have been bypassed or under stay statue.
6. FIRE LED
The LED flicker rapidly when fired.
7. TEMPER LED
When the detector(s), the keypad or the Expansion Module is /are tempered or destroyed, a
Tamper Code report will be sent and the LED will be flicker.
8. Digit Keys
When programming, key in 0-9 digits.
Under the status of users function, quick go to the menu.
9. System Arming [ARM]
When depress [ARM] key, all the zones are armed. The LED Display delay time.
Under the user functional status, the key [ARM] is used to set data. For example, when setting the
clock, [ARM] can be used to choice the month, weekday and partition.
10. Keypad Buzzer
The buzzer is used for indicating the entry/exit delay, alarm, door chime and so on.
Stay Home Arming [STAY]
11.
the LCD display the delay time.
clock, [STAY] is used to choice month, weekday and partition.
12. Function Key [*]
When depress [STAY] key, the interior zones will not be armed. During stay arming,
Under user function, the [STAY] key is used to set data. For example, when setting the
Depress [*] Key into the function set ting status.
Back t o the anterior menu or return to the normal status.
RP248CN User’s and Installer’s Manual Page 7
Page 8
13. Confirm Key [#]
The Key [#] used for confirm and save input data.
Moving Key [←][→]
14.
Key [←] is used to choice the anterior command, or moving the cursor to left.
Key [→] is used to choice the next command, or moving the cursor to right.
15. Panic Alarm Key [1]＋[2]
Depress [1]+[2] at least 2 seconds, the system will send a panic alarm message to CMS or
following-me numbers.
16. Fire Alarm Key [4]＋[5]
Depress [4]+[5] at least 2 seconds, the system will send a fire alarm message to CMS or following-
me numbers.
17. Special Emergency Key[7]＋[8]
Depress [7]+[8] at least 2 seconds, the system will send a special emergency message to CMS or
following-me numbers.
RP248CN User’s and Installer’s Manual Page 8
Page 9
CHAPTER 3 – SYSTEM FUNCTION AND OPERATION
3.1 Depress Keys Audible
When depress any keys, keypad will emit a brief deep.
After any successful operation the keypad will emit a long beep to confirm. And after error
operation, the keypad will emit three brief beep warn.
When arming, the keypad(s) will beep until the end of the exit delay time.
When trigger an armed zone, the keypad will beep until end the entry delay time. The
system must be disarmed, if not, it will be triggered.
If zone(s) programmed as door chime function, when triggered the zone(s), keypad will emit
three short beeps.
When use keypad for panic alarm, fire alarm and special emergency, there will be a brief
beep.
When triggered alarm, keypad will emit a beep for confirming.
It will not change the setting for siren/bell after change the buzzer setting on the keypad.
3.2 Door Chime
Each keypad can emit a continuous brief sound, called as DOOR CHIME. If you set the door
chime function, the keypad will emit a door chime sound when the door or window is opened. Turn
on/off the door chime by operation [*]+[4]+[master]+[5] or [6].
3.3 The numeric keys and character relative form
Keys
1 A B C D E F G H I J K L M
2 N O P Q R S T U V W X Y Z
3 ! “ & ‘ : - ? . / ( ) [ ]
4 a b c d e f g h i j k l m
5 n o p q r s t u v w x y z
6
7
8
9
0
RP248CN User’s and Installer’s Manual Page 9
Page 10
Program as the following:
The Key [←] and [→] are used move the cursor to the left or to the right.
1.
Key in the character as the above form, such as depress [1] twice to entry the “A” and depress
2.
[2] four times to entry the “P”.
After entry one character, move the cursor to entry other one by Key [←][→].
3.
4. After program, depress [#] to confirm, or depress [*] to cancel.
3.4 Digit Keys and Functions Keys
The Keys can support the following functions:
Entry digit(s) for arming, disarming, panic alarm, programming system etc.
1.
Entry user’s function mode.
2.
Key [ARM] is for quick arming and code Arming.
3.
Key [STAY] is for quick stay arming and code stay arming. Each zone can be set as interior
4.
zone or external zone. When use [STAY] for arming, the external zone is armed while leaves
the interior zone disarmed.
Under the disarmed status, depress [*] to entry user’s function mode. Reference to CHAPTER
5.
1- SUMMARY of USER’S COMMANDS
3.5 Modifying/ Setting and Deleting Code
The Master Code of RP248CN could be set as four or six digit code. The default master code is 1-
2-3-4. Unless your alarm company has already changed it to suit your preference, it’s best to
modify this code to one which is unique and personalized. RP248CN can set a great deal of
codes, one is master code and others are users’ code. The system code can be set under the
disarm status.
Functions of the Master Code:
Change the master code
Distribute, delete and change the system user’s code.
Access to all zones.
RP248CN User’s and Installer’s Manual Page 10
Page 11
Bypass zone(s).
Operation and testing.
Setting the follow-me numbers
Turn on the buzzer.
Turn off the buzzer.
Check the system.
Display memory.
Display troubles.
Setting the system clock time and date.
Setting auto arm time and auto disarm time.
Function of the Users code:
Arm or disarm the system.
Bypass zone(s).
Access one or more zones.
Check the system.
Setting the Users Codes
Through the LCD keypad to set codes, according to the following steps:
RP248CN User’s and Installer’s Manual Page 11
Page 12
Depress [*][5] into access function Mode, then depress [*] to find the menu ” ACCESS CODE
1.
” by [←][→], depress [#] to confirm and into the menu.
Key in the master code (default: 1234 ), then depress [#] to confirm.
2.
To choice a menu by [←][→].
3.
Changing the master codes when display “00 1234 GRANG”.
a)
Changing the User No.1 code when display “01 0 USER”.
b)
…
c)
Key in a new code and confirm by depress [#]. Finish the change when LCD display
4.
“ACCEPTED”
Depress [*] to back to anterior menu Back t o the menu or
5.
Depress [*] twice, the system will return to the normal status. Then the power LED is on, LCD
6.
display partition, clock, date, etc..
RP248CN User’s and Installer’s Manual Page 12
Page 13
Modifying/Setting the master Code
step Operation
1 In disarm status, depress[*][5][#] to entry into function status
2 Input 4 digit master code then depress [#] to confirm, such as [1][2][3][4][#]
3 Input new 4 digit code then depress [#] to confirm, such as [5][6][7][8][#] 4 If successful, the keypad will emit a confirming tone “Beep：”. The selected User
Code is now in effect.
5 Exit by depress [*][*]
6 If operate incorrectly, depress [*] to back to the step 2
Modifying/Setting User’s Codes
Step Operation
1 In disarm status, depress [*][5] to entry into function status
2 Entry Master Code: such as [5][6][7][8]
3 Modify/set user 1 code, depress [1] or
Modify/set user 2 code, depress [2] or
…
The other user codes can be modify/set in the same way.
4 Entry the new user code:
For example, [3][3][5][5]
5 If successful, the keypad will emit a confirming tone “Beep：”.
Deleting User’s Codes
At times, it may be desirable to completely delete a user code. Note that it is impossible to delete
the master code (although it can be changed).
Step Operation
1 In disarm status, depress [*][5] to entry into user function status
2 Entry the master code: [5 ][ 6][7 ][8 ] 3 To delete the user code 1, depress [1]
To delete the user code 2, depress [2]
To delete the user code 3, depress [3]
…
The other user s can be deleted in the same way.
4 Entry the [#] to delete this User Code
5 If successful, the keypad will emit a short confirming beep.
RP248CN User’s and Installer’s Manual Page 13
Page 14
3.6 Set date and time
Set date: [*]+[6]+[1]+[MASTER CODE]+[MM][DD][YY]
Month, Date and Year should be two digits.
Set time: [*]+[6]+[2]+[MASTER CODE]+[HH][MM]
Use a 24-Hour format. Hour and Minute should be two digits.
For example, if you want to entry 16:28, August 18, 2006, operate as:
[*]+[6]+[1]+[MASTER CODE]+[08][18][06]
[*]+[6]+[2]+[MASTER CODE]+[16] [28]
3.7 Set follow-me numbers
(Refer to the section 6.5.6 of chapter 6 for detail operation)
When alarm, RP248CN control panel can report the alarm events (burglar alarm, fire alarm, rob
alarm, emergency alarm) to one or several follow-me number(s) which has been set, and
distinguish different alarm events with different sound.
RP248CN has menu function for convenient operation. In normal status, depress [*][2][7][master
code][#] can entry into setting follow-me number and modify status. Up to 8 of follow-me numbers
can be set in the system. Depress [←][→] to move cursor left and right.
When setting follow-me number(s), should select the partition number first and then input
telephone number(s), and depress [#] to confirm.
3.8 Arm and arm sound
Quick arm
Any partition of RP248CN can be programmed or distinguished as stay zone or exterior zone.
Key [ARM] for quick arm all zones/partitions of the system. Please leave away from all the
partitions during the delay time.
Key [STAY] for quick stay arm all of the exterior partitions/zones, and stay zones would not be
triggered. Please leave away from all the stay zones immediately.
RP248CN User’s and Installer’s Manual Page 14
Page 15
Steps Description
1 Check the disarm LED indicator. If on, the system can be armed; if off, system
2 Quick arm:
can’t be armed, check whether every partition is ready or there is any trouble.
Quick arm: depress [ARM]Quick stay arm: depress [STAY]
3 If operate incorrectly, the keypad will emit three short beeps, try it again please 4 When arming, the keypad will beep until the end of exit delay time. Please leave
Arm with code
Your RP248CN offers two methods of arming, quick arm and code arm. It is defaulted is quick arm.
If user requires code arm, be sure to program the system as code arm in advance. When
RP248CN is set as code arm, it cannot support [ARM] and [STAY] for quick arming. Instead, it
should be operated as [ARM] + [Master Code], or [STAY] + [Master Code] to arm or stay arm.
Arm sound
If selected, Bell Squawk on Arming will produce a brief confirmation "chirp" from the system's
external sounder(s) once the system is armed and the Exit Delay expires. To cancel it, refers 6.5.2
in Chapter 6.
3.9 Disarm and disarm sound
Disarm system
RP248CN can set couples of codes (4 digits or 6 digits), one of them is master code, and the
others are user code. In arming status, any correct code can disarm the system.
before end of exit delay. Defaulted exit delay time is 30s.
Step
s
1 When enter an armed zone, the keypad will beep to remind the system exit delay
begins. The defaulted delay time is 30 seconds.
2 disarm
Description
Before end of entry delay, please input a code and [#] to disarm, or else the
system will alarm
If code is wrong, the keypad will emit three short beeps. Then depress [*] and
3 Check keypad LCD display status:
input code again.
“XXXXXX DISARMED”-- no alarm when armed;“XXXX：ALARM/ NOV 01,07 18:15 →”-- alarmed and the alarm time.
4 Key [←][→] use to check other alarmed events
RP248CN User’s and Installer’s Manual Page 15
Page 16
On/Off Audible Kiss-off
It is defaulted that RP248CN will give a long beep to remind disarm successfully. To on/off the
buzzer, press [*] + [4] + [master code] + [7] or [8].
3.10 Duress code disarm
If you are ever coerced to disarm your system, you can comply with the intruder’s wishes while
sending a silent, duress alarm, to the Central Station. To do so, you must use a special Duress
Code.
Which when used, will disarm the system in the regular manner, while simultaneously transmitting
a silent alarm to the central station. All 10 codes (including one Master Code and 9 User Codes)
can activate the Duress disarming by adding 1 to The last digit of your user codes. The Duress
Code and the User code share the first 3 digits. Example:
User code =1-2-3-4; duress code is 1-2-3-5
User code =5-6-7-8; duress code is 5-6-7-9
User code= 7-8-9-0; duress code is 7-8-9-1
Note: Under no circumstances must the Duress Code be used haphazardly or without reason.
Central Stations, along with Police Departments, treat Duress Codes very seriously and take
immediate action.
3.11 Stop siren/bell and stop dialing a number
If outside premises, open an entry door; the keypad(s) will beep indicating that the Entry Delay
period has begun. The entry delay is defaulted as 30 seconds.
Silencing an alarm in progress
Observe the keypad. If any of the following conditions is evident, an alarm has occurred:
The ARM LED is flashing
Z1,Z2,Z3… are displayed on the LCD
It's best to enter the premises only after police or a security company has investigated and you feel
confident that the burglar is no longer on your premises.
3.12 Bypass and un-bypass zone(s)
Check the zone status
RP248CN User’s and Installer’s Manual Page 16
Page 17
In normal, input [*][3][4] and user/master code and depress [#] to confirm. LCD will display as
follows, the character of second line means zone number, zone description and zone status:
ZONE STATUS：0：01
01) FRONT DOOR：G →
For armed system: G-means zone is in good arm status, B-means zone is in bypass status;
For disarmed system: R-means zone is in ready status, B-means zone is in bypass status, N-
means zone is in unready status
Key [←] [→] are used to check each zone status. Depress [*] or wait few seconds, the system will
auto return to normal status.
Bypass zone(s)
In normal, input a correct user code and depress [→]. If quick bypass is allowed, depress [→] to
bypass this zone directly. LCD displaying as follows:
BYPASS ZONE： (CL)
01) FRONT DOOR N →
The first line means the zone status, second line means whether the zone is bypassed or not. Use
key [→] to choice other zone(s), use key [←] to exchange [Y] and [N], and depress [#] to confirm.
For disarmed system: CL-means zone(s) is closed, OP-means zone(s) is triggered, AL- means
zone(s) armed.
：
For armed system: AR- means zone(s) is armed, CL-means zone(s) is not triggered but bypassed,
OP- means zone(s) is triggered but bypassed, AL- means zone(s) armed.
Cancel bypass
Choose a zone number, use [STAY] exchange ”Y” to “N”, and depress [#]
Bypass reset
Under user function status (USER FUNCTION), use key [←][→] to choose (2)BYPASS RSET, and
depress [#] to confirm. Input a correct user/master code and [#] (It is unnecessary to input code, if
quick arm is allowed). LCD will display as follows, depress [#] to confirm bypass reset:
BYPASS RESET
RP248CN User’s and Installer’s Manual Page 17
Page 18
HIT [#] TO CONFIRM
Exit user function status
Depress [*] twice to exit user function state. Then the Power LCD will be lit on, which means it is in
normal status now.
3.13 Exit a error operation
When operate incorrectly, depress [*] to cancel and then operate again.
3.14 Keypad alarm
RP208CN Keypad (RP208KCL) provides 3 groups emergency keys, which can be pushed at
anytime, and the police, fire department, or medical assistance is required. Emergency Alarm is
defaulted as silence alarm.
Press 1 and 2 simultaneously, and for at least two seconds, will activate a Panic Alarm.
Press 4 and 5 simultaneously, and for at least two seconds, will activate a Fire Alarm.
Press 7 and 8 simultaneously, and for at least two seconds, will activate a Medical
Emergency.
3.15 Entry delay and exit delay
The security system must incorporate in and from the premises without causing inadvertent
alarms. A delay period was chosen during your system’s installation to provide suitable time to
allow for your entry and exit. Entry/Exit Delays can be set by programming, and it’s defaulted as 30
seconds. To change the delay time, refer to 6.5.3 of Chapter 6.
3.16 Trouble and display
When the keypad sends out three short beep regularly, indicating that the system exists some
troubles. When get rid of the troubles, the system will restore to normal status and stop beeping.
Troubles include Battery Low, AC power, No Clock, No Communication, No Siren etc. Press [*]
+[3] to search on the LCD.. Depress [←][→] to check the last or the next event.
The troubles displayed as follows:
LCD Display Trouble
MAIN：LOW BATT Battery Power low
RP248CN User’s and Installer’s Manual Page 18
Page 19
MAIN：AC TROUBLE AC lost MAIN：BELL LOOP Siren trouble FLASE CODE P=1 Code error KITCHEN：FIR Fire Loop in trouble
KP=03 COMM TRBL The bus in trouble, such as No.3 keypad is in trouble
SYSTEM CLCOK Clock not set
PS= 1 LOW BAT Power Module Battery low. Such as No.1 power Expansion
Module is in trouble
PS=1 AC TRBL Power Module in AC Trouble. Such as No.1 power Expansion
Module is in trouble
PS=1 BELL TRBL Power Module Siren in Trouble. Such as No.1 power
Expansion Module is in trouble
PS=1 AUX TRBL Power Module Stand-by Power is low. Such as No.1 power
Expansion Module is in trouble
PHONE LINE Phone line in trouble
FIRE DOOR：DAY Day time zone in trouble.
3.17 Zones characters
Every zone of RP248CN can be appoint its character, such as delay zone, instant zone,
emergency zone, firm zone, tamper zone, remote zone, utility output zone and so on. 24 hours
character will be always armed, no matter the system armed or not. As long as it is triggered, it will
be alarm. Such as emergency zone, tamper zone, emergency button, fire zone and so on.
Delay zone: which has character of entry delay or/and exit delay. Exit delay is the period from the
time depress [ARM]/[STAY] to the system armed. Entry delay is the max time from entry to disarm
the system. Beyond delay time, will occur the system alarm.
Instant zone: system alarm as soon as the zone triggered.
Emergency zone＋ be used to connect emergency button, 24-hours armed.
Fire zone＋be used to connect smoke and gas detectors, 24- hours armed.
Tamper zone: be used to connect detector’s tamper connector, 24- hours armed.
Remote zone: be used to connect remote control receiver zone, 24- hours armed.
3.18 System Partition and Control
RP248CN has 8 zones which can be operated separately.
Keypad and partition
Keypad can be appointed to any one or more partitions. Each partition can be set individual user
RP248CN User’s and Installer’s Manual Page 19
Page 20
code. Master code can be use through any one of the keypads.
Public zone
This zone can divide to one or more partitions at the same time, disarm or/and arm public zone:
1. Disarm public zone: any partition is disarmed, public zone will be disarmed;
2. Arm public zone: all of the partitions are armed, public zone will be armed.
Arm partitioned system
When quick arm system, the partition will be armed by the appointed keypad. When arm the
system through the master code, should select the partition to be armed by key [→][←] as follows:
Input master code through keypad;
1.
Depress [ARM];
2.
Select the partition to be armed by [→][←];
3.
Depress [ARM] or [STAY]. If there is exit delay, the partition will entry into exit delay
4.
countdown;
Repeat steps 1-4 to arm other partitions
5.
Disarm partitioned system
User with multi-admin right code can disarm several partitions at the same time, steps is as
follows:
Input the user code;
1.
Depress [#];
2.
Select the partition(s) to be disarmed by [→][←] ;
3.
Depress [#] to confirm;
4.
Repeat steps 1-4 to disarm other partitions
5.
Disarm partitions system
Own multi admin right user code can disarm several partitions at the same time, detail steps
is as follows:
1. input a valid user code;
2. press [#];
use [→][←] to select the partitions which need to be disarmed;
3.
RP248CN User’s and Installer’s Manual Page 20
Loading...
Buy Points How it Works FAQ Contact Us Questions and Suggestions Privacy Policy Cookie Policy Terms of Use
