RoHS MS-101 User Manual

WIFI SMART SWITCH

Model: MS-101

Parameter

Power Supply: 90V~250V AC
Max. Current: 2200W/10A
Wi-Fi Standard: 2.4 GHz b/g/n
Material: ABS V0

Size: 88＊38＊22mm

Check list before using
the device

Your smart phone or tablet has connected
to a 2.4G WiFi with internet.
You have the correct WiFi PWD.
Your smart phone or tablet must have
access to APP Store, Google Play.

Your router is MAC-open.

Download Smart Life APP

Please scanthe QR code or download

Smart Life on App Store or Google Play.

User Guide

Start with “Smart Life”App.

Register an Smart Life Smart
account.

IF you have Smart Life account,just
log in.

Power up.

ON/OFF operating principle:
The connected appliances work/stop
through live wire power on/off.

4.1 Appliance wiring instruction.

4.2 Celling lamp wiring instruction.

4.3 Light wiring instruction.

＊Note: The WiFi Switch must be powered
up by N and L wires.

Press and hold the button for about
7 seconds until the WiFi green LED
blinks fast.

Enter the App, tap “+”in the upper
right of the page to enter network
connection page.

There are two network connection
methods (Normal mode and AP
mode). Normal mode is default.
Users could tap the upper right
corner to switch the connection
method to AP mode.

Please make sure the device’s
indicator light rapidly flashes (2
times per second),tap to go on to
the next step.

If indicator light is not rapidly
flashing,tap “how to set indicator
light as rapid flashes” to view
operation processes.

Input your WiFi password.

Name your device.

The device is online.

TROUBLESHOOTING

Q: How to set indicator light as rapid
flashing?

Power on device.

Hold the reset button for 5s.

Confirm indicator light is now rapidly
flashing.

Q: How to set indicator light as slow
flashing?

Power on device.
Hold the reset button for 5s.
Confirmin indicator light is now rapidly

flashing.

4

Hold reset button for 8s until indicator

light is slowly flashing.

The new ad ded devi ce needs 1min to
conne ct to WiFi and t he Intern et if it stays
offline for a lo ng time, plea se judge t he
proble m by the WiFi LE D status.

WiFi LED qu ickly blin ks one time eve ry
second;

WiFi Sw itch faile d to conne ct to your
WiFi:

Maybe you h ave entere d wrong WiF i

password.

WiFi Switc h is too far away fr om your
WiFi ple ase take it clo ser.

Make sure yo ur router is M AC-ope n.
If still fail ed,try to op en a mobile hot a pot

and add a gain.

Set your Echo speaker by
Alexa APP

1. If you have finish ed to install S mart Lif e
then open A mazon Ale xa App; sign in
your Alexa a ccount an d enter pas sword.

2. Click the menu on the lef t corner-clic k
“S ettings”; choose “Se t up a ne w device”

(choose a device,li ke Echo) Note: When the
bel ow page appear s, long press the sm all

dot on you r Echo device until the light tur ns
to yello w. Then click Continu e on App.

Note: at this m oment, th e mobile pho ne
can not op en a variet y of WPN soft ware.

3.Choos e your own WiF i and wait for a
few minute s. After an in troduct ion video.
click nex t step, it will ent er Home pag e
automati cally.
Now the Ech o has conn ected to Wi- Fi
succe ssfully.

Enable Smart Life Skill in
Alexa APP

Choose “Skills” in the options bar, and then
search “Smart Life” in the input box.

Select Smart Life in the search results,and
then click “Enable Skill”.

Then input the user name and password
of Smart Life APP that you had previously
registered.

Control the Light Switch by
Voice

After th e above ope ration is suc cessf ul,
you can co ntrol the Lig ht Switch v ia Echo.

1. Discover Devices

Firstl y, you need to say to th e Echo:
Echo (or Alex a), discover my de vices.
Echo will st art to find th e device wh ich
is adde d in Smart Li fe APP. It will take
about 20 s econds , then Echo wi ll tell
you the re sult.
You can also cli ck “Discob er devic es”
in Alexa AP P, then it will show th e
device s that have be en found
successfully.

2. Control Device by Voice

Notr:The name of the device must be
consistent with be addition of Smart
Life APP.

You can also group the Light Switch
and give instructions to control them
together.

Note:

Echo is one of the wake-up names, which
can be any of the three names (Settings):
Alexa,Echo,Amazon.

3. Support Skill List

You can control the device by
instructions like these:

Alexa (or Echo), turn on the Light Switch

Alexa (or Echo), turn off the Light Switch

Google Assistant - Activate
Smart Life in Google Home App

Preparation

● Have downloaded the Google
Home App-compatible with

Android (4.2 or higher) or IOS
(8.0 or higher) smartphones or

tablet.

● Have registered your Google
Account.

● Have paired Light Switch with
Smart Life App and named it

with a recognizable name.

● Have finished setting up
Google Home.

Open G oogle Home App; tap
“ ”on the upp er left corne r;
select “More S etting s” to enter
the nex t inter face.

Choose “Services” in the opptions bar
and select “Smart Life”to enter the next
interface.

Tap “Link Account”, then sign in your
Smart Life Account.

Tap “Link Now”, after your Smart Life
account has linked to Google Assistant,
the smart devices will automatically

appear.

Command the Device through
Your Voice

After the above operation is
successful, you can control the
device via Google Home.
Firstly, you need to say “OK Google,
talk to Smart Life” to wake up the
Smart Life. Then you can control the
device by instructions like these:

Turn on the Light Switch
Turn off the Light Switch

Note

After Smart Life has been wakened up, you
can say “Cancel” or “Stop” to exit Smart Life
or say “Nothing” when you hear “What can
I do for you.” Then you can say “OK Google,
talk to Smart Life” to start voice contronl.

IFTTT-Setup and Usage

Get Started: How to connect the product
to IFTTT?

Visit the IFTTT official website on your PC
and sign in with your IFTTT account.

Note: You can also use IFTTT app and
follow similar steps to connect your
device to the IFTTT. In this FAQ we take
the website setting method for example.

Search for “Smart Life”, and then click
“Smart Life” service.

Click “Connect”, then log in your Smart Life
ID and tap “Link Now”. (The Smart Life ID
is the same with that of Smart Life APP).

After successfully connecting your IFTTT
account to your Smart Life ID. You are
ready to enjoy the IFTTT service of the
product now.

Instructions:2 methods to use IFTTT
with the products.

Method 1
On Smart Life service page, choose an
existing Applet you need,turn it on and
then finish the configuration.

Method 2

Create a new Applet on your own.

Click “My Applet” on the top and then click
“New Applet” on the right top corner of the
webpage to create a new Applet.

Create a Trigger

Tap “this” to choose a Trigger. You can
search for “Weather Underground” to
choose a Trigger.

We select “Sunset” as the Trigger.

Create an Action

Tap “that” to choose an Action. You
can search for “Smart Life”to choose
a Smart Life Action.

We select “Turn on ”of the Light
Switch as the Action in this case.

New Applet “If sunset, then turn on Light
Switch”has created as a result.

Note:

The Smart Life service can only work when
creating an action. You can’t use
“Smart Life”as a trigger.
