ROHS 361R Technical data

Type 361R 105 °C, Miniature, Industrial Grade, Radial Leaded

High-value, High Ripple, Low ESR & ESL

Type 361R capacitors are for industrial applications
from –40

capability and low ESR and ESL. Also available with three
mounting leads. For three leads, change Type designation
from 361R to 366R.

Highlights

• Excellent Ripple Capability

• Low ESR and ESL

• High Value

Specifications

Operating Temperature:

Rated Voltage:

Capacitance:

Leakage Current:

Ripple Current Multipliers:

–40 °C to +105 °C

6.3 to 450 Vdc
7 to 18,000 µF ± 20%
≤0.002 CV µF +25 °C, 6.3 to 160 Vdc
≤0.02 CV µF +25 °C, 200 to 450 Vdc

Ambient Temperature

45 °C 55 °C 65 °C 75 °C 85 °C 95 °C 105 °C

2.00 1.60 1.40 1.25 1.00 0.79 0.5

°C to +105 °C. They deliver excellent ripple

Complies with the EU
Directive 2002/95/EC
requirement restricting
the use of Lead (Pb),
Mercury (Hg), Cadmium
(Cd), Hexavalent chromium
(Cr(VI)), PolyBrominated
Biphenyls (PBB) and
PolyBrominated Diphenyl
Ethers (PBDE).

Outline Drawings

Load Life:

Shelf Life:

Vibration:

50 Hz 60 Hz 120 Hz 360 Hz 1 kHz 5 kHz 10 kHz & up

6.3 & 10 V 0.91 0.93 1.00 1.06 1.08 1.09 1.09

16 to 25 V 0.85 0.88 1.00 1.12 1.18 1.21 1.22

35 V & up 0.77 0.82 1.00 1.21 1.32 1.37 1.38

4,000 h @ +105 °C
∆ Capacitance ±15%
ESR 175% of limit
DCL 100% of limit
1,000 h @ 105 °C
∆ Capacitance ±15%
ESR 150% of limit
DCL 200% of limit
10 to 55 Hz, 0.06” and 10 g, 2 h ea of 3 planes

CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: [phone] • Fax: [phone] • www.cde.com

Type 361R 105 °C, Miniature, Industrial Grade, Radial Leaded

Case Dimensions

Nominal Insulated Insulated S T Lead Diam. Weight

Case D x L D x L Epoxy Seal ± 0.6 ± 0.5 mm AWG g

Code (mm) (mm) (mm) (mm) (mm)

EG 12.5 x 20.0 13.0 x 21.5 13.0 x 23.0 5.0 2.5 0.81 20 3.8

EK 12.5 x 25.0 13.0 x 26.5 13.0 x 29.0 5.0 2.5 0.81 20 4.5

EM 12.5 x 26.5 13.0 x 28.0 13.0 x 29.5 5.0 2.5 0.81 20 4.7

EN 12.5 x 33.5 13.0 x 34.2 13.0 x 36.0 5.0 2.5 0.81 20 5.8

ER 12.5 x 42.5 13.0 x 43.7 13.0 x 45.5 5.0 2.5 0.81 20 7.3

FK 16.0 x 25.0 16.5 x 26.2 16.5 x 27.9 7.5 3.75 0.81 20 7.2

FF 16.0 x 32.0 16.5 x 33.5 16.5 x 36.0 7.5 3.75 0.81 20 9.4

FN 16.0 x 33.5 16.5 x 34.2 16.5 x 36.0 7.5 3.75 0.81 20 9.5

FQ 16.0 x 36.0 16.5 x 37.5 16.5 x 40.0 7.5 3.75 0.81 20 10.6

FV 16.0 x 40.0 16.5 x 41.7 16.5 x 42.4 7.5 3.75 0.81 20 11.9

LQ 18.0 x 36.0 18.5 x 37.5 18.5 x 40.0 7.5 3.75 0.81 20 13.4

LV 18.0 x 40.0 18.5 x 42.0 18.5 x 43.0 7.5 3.75 0.81 20 14.9

HH 22.0 x 22.0 22.5 x 23.5 22.5 x 26.0 10.0 5.0 0.81 20 11.0

HK 22.0 x 25.0 22.5 x 26.2 22.5 x 27.9 10.0 5.0 0.81 20 13.5

HG 22.0 x 30.0 22.5 x 32.5 22.5 x 34.0 10.0 5.0 0.81 20 15.1

L incl. Sleeve & Epoxy Seal - Millimeters

Part Numbering System

361R

Type

361R

or 366R

183

Capacitance

100 = 10 µF
101 = 100 µF
183 = 18000 µF

M

Tolerance

M = ±20%

U = –10 + 75%

Typical Performance Curves

6R3

Voltage

6R3 = 6.3 Vdc

063 = 63 Vdc

LV

Case Code

2

Insulation

0 = None

2 = PVC

E

Epoxy End Seal

(blank) = no epoxy

E = Epoxy

CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: [phone] • Fax: [phone] • www.cde.com

Type 361R 105 °C, Miniature, Industrial Grade, Radial Leaded

Ratings

ESR Max.

Cap.

(µF)

2200 361R222M6R3EG2 0.205 1.130 12.5 x 20 1000 361R102M020EG2 0.200 0.970 12.5 x 20

3300 361R332M6R3EK2 0.140 1.440 12.5 x 25 1500 361R152M020EK2 0.133 1.300 12.5 x 25

3900 361R392M6R3EM2 0.131 1.380 12.5 x 26.5 2200 361R222M020EM2 0.103 1.510 12.5 x 26.5

4700 361R472M6R3EN2 0.098 1.840 12.5 x 33.5 2700 361R272M020EN2 0.084 1.840 12.5 x 33.5

6800 361R682M6R3ER2 0.075 2.160 12.5 x 42.5 3300 361R332M020FK2 0.076 2.000 16 x 25

6800 361R682M6R3FK2 0.084 2.000 16 x 25 3300 361R332M020HH2 0.076 2.320 22 x 22

6800 361R682M6R3HH2 0.091 2.200 22 x 22 3900 361R392M020ER2 0.065 2.320 12.5 x 42.5

8200 361R822M6R3HK2 0.075 2.330 22 x 25 3900 361R392M020HK2 0.065 2.500 22 x 25

10000 361R103M6R3FF2 0.068 2.330 16 x 32 4700 361R472M020FF2 0.060 2.480 16 x 32

10000 361R103M6R3HG2 0.046 3.290 22 x 30 5600 361R562M020FQ2 0.055 2.720 16 x 36

12000 361R123M6R3FQ2 0.062 2.550 16 x 36 6800 361R682M020FV2 0.053 2.900 16 x 40

12000 361R123M6R3FV2 0.058 2.750 16 x 40 6800 361R682M020HG2 0.047 3.330 22 x 30

15000 361R153M6R3HV2 0.044 3.420 22 x 40 8200 361R822M020LQ2 0.047 3.180 18 x 36

15000 361R153M6R3LQ2 0.053 2.990 18 x 36 10000 361R103M020HV2 0.044 3.750 22 x 40

18000 361R183M6R3LV2 0.049 3.240 18 x 40 10000 361R103M020LV2 0.044 3.280 18 x 40

1500 361R152M010EG2 0.210 0.947 12.5 x 20 820 361R821M025EG2 0.280 0.860 12.5 x 20

2200 361R222M010EK2 0.158 1.330 12.5 x 25 1000 361R102M025EK2 0.230 1.080 12.5 x 25

2700 361R272M010EM2 0.144 1.420 12.5 x 26.5 1200 361R122M025EM2 0.190 1.150 12.5 x 26.5

3300 361R332M010EN2 0.115 1.760 12.5 x 33.5 1800 361R182M025EN2 0.128 1.550 12.5 x 33.5

4700 361R472M010ER2 0.083 2.250 12.5 x 42.5 2200 361R222M025FK2 0.121 1.660 16 x 25

4700 361R472M010FK2 0.093 2.000 16 x 25 2200 361R222M025HH2 0.121 1.840 22 x 22

4700 361R472M010HH2 0.094 2.170 22 x 22 2700 361R272M025ER2 0.096 2.000 12.5 x 42.5

5600 361R562M010HK2 0.074 2.540 22 x 25 3300 361R332M025FF2 0.091 2.080 16 x 32

6800 361R682M010FF2 0.073 2.440 16 x 32 3300 361R332M025HK2 0.091 2.230 22 x 25

8200 361R822M010FQ2 0.063 2.950 16 x 36 3900 361R392M025FK2 0.081 2.360 16 x 36

8200 361R822M010HG2 0.052 3.170 22 x 30 4700 361R472M025FV2 0.071 2.560 16 x 40

10000 361R103M010FV2 0.059 3.000 16 x 40 4700 361R472M025HG2 0.071 2.750 22 x 30

12000 361R123M010HV2 0.046 3.390 22 x 40 4700 361R472M025LQ2 0.071 2.710 18 x 36

12000 361R123M010LQ2 0.056 3.050 18 x 36 5600 361R562M025LV2 0.065 2.830 18 x 40

15000 361R153M010LV2 0.051 3.400 18 x 40 6800 361R682M025HV2 0.053 3.610 22 x 40

1000 361R102M016EG2 0.265 0.942 12.5 x 20 680 361R681M035EG2 0.287 0.850 12.5 x 20

1800 361R182M016EK2 0.156 1.350 12.5 x 25 1000 361R102M035EK2 0.199 1.200 12.5 x 25

2200 361R222M016EM2 0.147 1.410 12.5 x 26.5 1200 361R122M035EM2 0.190 1.250 12.5 x 26.5

3300 361R332M016EN2 0.108 1.790 12.5 x 33.5 1500 361R152M035EN2 0.133 1.570 12.5 x 33.5

3300 361R332M016FK2 0.100 1.880 16 x 25 1800 361R182M035FK2 0.133 1.620 16 x 25

3300 361R332M016HH2 0.100 2.080 22 x 22 1800 361R182M035HH2 0.110 1.840 22 x 22

4700 361R472M016ER2 0.084 2.200 12.5 x 42.5 2200 361R222M035ER2 0.106 1.900 12.5 x 42.5

4700 361R472M016FF2 0.077 2.280 16 x 32 2200 361R222M035FF2 0.106 2.000 16 x 32

4700 361R472M016HK2 0.082 2.430 22 x 25 2700 361R272M035FQ2 0.086 2.330 16 x 36

6800 361R682M016FQ2 0.066 2.670 16 x 36 2700 361R272M035HK2 0.086 2.180 22 x 25

6800 361R682M016FV2 0.064 2.700 16 x 40 3300 361R332M035FV2 0.080 2.380 16 x 40

6800 361R682M016HG2 0.014 3.110 22 x 30 3300 361R332M035HG2 0.081 2.570 22 x 30

7800 361R782M016LQ2 0.060 2.800 18 x 36 3300 361R332M035LQ2 0.080 2.400 18 x 36

9000 361R902M016HV2 0.011 3.590 22 x 40 4700 361R472M035HV2 0.064 3.270 22 x 40

10000 361R103M016LV2 0.053 3.000 18 x 40 4700 361R472M035LV2 0.064 2.700 18 x 40

Catalog

Part Number

6.3 Vdc (8 Vdc Surge) 20 Vdc (25 Vdc Surge)

10 Vdc (12.5 Vdc Surge) 25 Vdc (32 Vdc Surge)

16 Vdc (20 Vdc Surge) 35 Vdc (44 Vdc Surge)

120 Hz

25ºC (Ω)

Ripple A

120 Hz

85ºC (A)

Nom Size

D X L
(mm)

Cap.

(µF)

Catalog

Part Number

ESR Max.

120 Hz

25ºC (Ω)

Ripple A

120 Hz

85ºC (A)

Nom Size

D X L
(mm)

CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: [phone] • Fax: [phone] • www.cde.com

Type 361R 105 °C, Miniature, Industrial Grade, Radial Leaded

ESR Max.

Cap.

(µF)

330 361R331M050EG2 0.443 0.760 12.5 x 20 100 361R101M100EG2 1.650 0.355 12.5 x 20

470 361R471M050EK2 0.343 0.960 12.5 x 25 120 361R121M100EK2 1.320 0.450 12.5 x 25

560 361R561M050EM2 0.266 1.050 12.5 x 26.5 150 361R151M100EM2 1.100 0.500 12.5 x 26.5

820 361R821M050EN2 0.180 1.380 12.5 x 33.5 220 361R221M100EN2 0.750 0.666 12.5 x 33.5

820 361R821M050HH2 0.190 1.560 22 x 22 220 361R221M100HH2 0.750 0.760 22 x 22

1000 361R102M050FK2 0.156 1.530 16 x 25 270 361R271M100ER2 0.610 0.750 12.5 x 42.5

1200 361R122M050ER2 0.125 1.810 12.5 x 42.5 270 361R271M100HK2 0.520 0.950 22 x 25

1500 361R152M050FF2 0.101 2.140 16 x 32 330 361R331M100FK2 0.500 0.875 16 x 25

1500 361R152M050HK2 0.106 2.160 22 x 25 390 361R391M100FF2 0.420 1.010 16 x 32

1800 361R182M050FQ2 0.083 2.440 16 x 36 470 361R471M100FQ2 0.350 1.150 16 x 36

1800 361R182M050HG2 0.084 2.490 22 x 30 470 361R471M100FV2 0.350 1.250 16 x 40

2200 361R222M050LQ2 0.081 2.640 18 x 36 470 361R471M100HG2 0.351 1.250 22 x 30

2200 361R222M050FV2 0.081 2.600 16 x 40 560 361R561M100LQ2 0.290 1.370 18 x 36

2700 361R272M050HV2 0.067 3.190 22 x 40 680 361R681M100HV2 0.241 1.690 22 x 40

2700 361R272M050LV2 0.065 3.040 18 x 40 680 361R681M100LV2 0.240 1.570 18 x 40

330 361R331M063EG2 0.450 0.760 12.5 x 20 33 361R330M160EG2 5.000 0.200 12.5 x 20

470 361R471M063EK2 0.318 0.960 12.5 x 25 47 361R470M160EK2 3.500 0.250 12.5 x 25

470 361R471M063EM2 0.318 0.980 12.5 x 26.5 56 361R560M160EM2 2.950 0.280 12.5 x 26.5

560 361R561M063EN2 0.268 1.150 12.5 x 33.5 82 361R820M160EN2 2.000 0.380 12.5 x 33.5

680 361R681M063ER2 0.183 1.540 12.5 x 42.5 100 361R101M160ER2 1.650 0.460 12.5 x 42.5

820 361R821M063FK2 0.220 1.310 16 x 25 100 361R101M160FK2 1.650 0.430 16 x 25

820 361R821M063HH2 0.220 1.420 22 x 22 100 361R101M160HH2 1.650 0.475 22 x 22

1200 361R122M063FF2 0.150 1.700 16 x 32 150 361R151M160FF2 1.100 0.580 16 x 32

1200 361R122M063HK2 0.150 1.810 22 x 25 150 361R151M160HK2 1.100 0.610 22 x 25

1500 361R152M063FQ2 0.125 1.980 16 x 36 180 361R181M160FQ2 0.920 0.665 16 x 36

1500 361R152M063HG2 0.099 2.310 22 x 30 220 361R221M160FV2 0.750 0.770 16 x 40

1800 361R182M063FV2 0.100 2.300 16 x 40 220 361R221M160HG2 0.751 0.840 22 x 30

1800 361R182M063LQ2 0.100 2.580 18 x 36 220 361R221M160LQ2 0.750 0.800 18 x 36

2200 361R222M063HV2 0.072 2.990 22 x 40 270 361R271M160LV2 0.610 0.920 18 x 40

2200 361R222M063LV2 0.083 2.700 18 x 40 330 361R331M160HV2 0.512 0.990 22 x 40

150 361R151M075EG2 1.070 0.450 12.5 x 20 27 361R270M200EG2 5.900 0.175 12.5 x 20

220 361R221M075EK2 0.727 0.580 12.5 x 25 47 361R470M200EK2 3.600 0.250 12.5 x 25

270 361R271M075EM2 0.600 0.650 12.5 x 26.5 56 361R560M200EM2 3.000 0.280 12.5 x 26.5

390 361R391M075EN2 0.410 0.870 12.5 x 33.5 68 361R680M200EN2 2.500 0.340 12.5 x 33.5

470 361R471M075FK2 0.340 1.000 16 x 25 82 361R820M200FK2 2.000 0.390 16 x 25

470 361R471M075HH2 0.340 1.040 22 x 22 82 361R820M200HH2 2.000 0.430 22 x 22

560 361R561M075ER2 0.285 1.160 12.5 x 42.5 100 361R101M200ER2 1.650 0.450 12.5 x 42.5

680 361R681M075FF2 0.235 1.320 16 x 32 120 361R121M200FF2 1.380 0.520 16 x 32

680 361R681M075HK2 0.235 1.310 22 x 25 120 361R121M200HK2 1.380 0.545 22 x 25

820 361R821M075FQ2 0.195 1.520 16 x 36 150 361R151M200FQ2 1.100 0.600 16 x 36

1000 361R102M075FV2 0.160 1.660 16 x 40 180 361R181M200HG2 1.000 0.730 22 x 30

1000 361R102M075HG2 0.161 1.810 22 x 30 220 361R221M200FV2 0.760 0.760 16 x 40

1000 361R102M075LQ2 0.160 1.700 18 x 36 220 361R221M200LQ2 0.760 0.790 18 x 36

1200 361R122M075LV2 0.133 1.900 18 x 40 270 361R271M200HV2 0.781 0.940 22 x 40

1500 361R152M075HV2 0.107 2.530 22 x 40 270 361R271M200LV2 0.620 0.910 18 x 40

Catalog

Part Number

50 Vdc (63 Vdc Surge) 100 Vdc (125 Vdc Surge)

63 Vdc (79 Vdc Surge) 160 Vdc (185 Vdc Surge)

75 Vdc (90 Vdc Surge) 200 Vdc (225 Vdc Surge)

120 Hz

25ºC (Ω)

Ripple A

120 Hz

85ºC (A)

Nom Size

D X L
(mm)

ESR Max.

Cap.

(µF)

Catalog

Part Number

120 Hz

25ºC (Ω)

Ripple A

120 Hz

85ºC (A)

Nom Size

D X L
(mm)

CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: [phone] • Fax: [phone] • www.cde.com

Type 361R 105 °C, Miniature, Industrial Grade, Radial Leaded

ESR Max.

Cap.

(µF)

18 361R180M250EG2 9.200 0.145 12.5 x 20 39 361R390M350FF2 4.250 0.295 16 x 32

27 361R270M250EK2 6.100 0.190 12.5 x 25 47 361R470M350FQ2 3.500 0.340 16 x 36

33 361R330M250EM2 5.000 0.215 12.5 x 26.5 47 361R470M350HK2 3.500 0.340 22 x 25

47 361R470M250EN2 3.500 0.285 12.5 x 33.5 56 361R560M350FV2 2.950 0.385 16 x 40

47 361R470M250FK2 3.500 0.295 16 x 25 56 361R560M350HG2 2.950 0.420 22 x 30

56 361R560M250ER2 2.950 0.345 12.5 x 42.5 68 361R680M350LQ2 2.420 0.445 18 x 36

56 361R560M250HH2 2.950 0.350 22 x 22 82 361R820M350HV2 2.000 0.590 22 x 40

68 361R680M250FF2 2.420 0.390 16 x 32 82 361R820M350LV2 2.000 0.500 18 x 40

82 361R820M250FQ2 2.000 0.450 16 x 36 400 Vdc (450 Vdc Surge)

82 361R820M250HK2 2.000 0.450 22 x 25 8 361R080M400EK2 20.00 0.105 12.5 x 25

100 361R101M250FV2 1.650 0.515 16 x 40 12 361R120M400EM2 13.80 0.125 12.5 x 26.5

120 361R121M250HG2 1.380 0.620 22 x 30 18 361R180M400EN2 9.100 0.175 12.5 x 33.5

120 361R121M250LQ2 1.380 0.585 18 x 36 22 361R220M400FK2 7.500 0.200 16 x 25

150 361R151M250LV2 1.100 0.685 18 x 40 27 361R270M400ER2 6.100 0.235 12.5 x 42.5

180 361R181M250HV2 0.921 0.880 22 x 40 33 361R330M400FF2 5.000 0.275 16 x 32

12 361R120M300EG2 13.80 0.120 12.5 x 20 39 361R390M400FQ2 4.200 0.315 16 x 36

18 361R180M300EK2 9.150 0.155 12.5 x 25 39 361R390M400HK2 4.200 0.315 22 x 25

22 361R220M300EM2 7.500 0.175 12.5 x 26.5 47 361R470M400FV2 3.500 0.355 16 x 40

33 361R330M300EN2 5.000 0.240 12.5 x 33.5 47 361R470M400HG2 3.510 0.390 22 x 30

33 361R330M300FK2 5.000 0.245 16 x 25 56 361R560M400LQ2 2.950 0.400 18 x 36

39 361R390M300HH2 4.250 0.295 22 x 22 68 361R680M400HV2 2.420 0.530 22 x 40

47 361R470M300ER2 3.500 0.315 12.5 x 42.5 68 361R680M400LV2 2.420 0.465 18 x 40

47 361R470M300FF2 3.500 0.325 16 x 32 450 Vdc (500 Vdc Surge)

56 361R560M300FQ2 2.950 0.375 16 x 36 7 361R070M450EK2 20.00 0.100 12.5 x 25

56 361R560M300HK2 2.950 0.375 22 x 25 10 361R100M450EM2 16.50 0.120 12.5 x 26.5

68 361R680M300FV2 2.420 0.430 16 x 40 15 361R150M450EN2 11.00 0.165 12.5 x 33.5

68 361R680M300HG2 2.420 0.480 22 x 30 18 361R180M450FK2 9.100 0.185 16 x 25

82 361R820M300LQ2 2.000 0.485 18 x 36 22 361R220M450ER2 7.500 0.215 12.5 x 42.5

100 361R101M300HV2 1.650 0.650 22 x 40 27 361R270M450FF2 6.100 0.245 16 x 32

100 361R101M300LV2 1.650 0.555 18 x 40 27 361R270M450HH2 6.100 0.245 22 x 22

10 361R100M350EK2 16.50 0.115 12.5 x 25 33 361R330M450HK2 5.000 0.300 22 x 25

15 361R150M350EM2 11.00 0.145 12.5 x 26.5 39 361R390M450FV2 4.200 0.325 16 x 40

22 361R220M350EN2 7.500 0.195 12.5 x 33.5 39 361R390M450HG2 4.200 0.350 22 x 30

27 361R270M350FK2 6.100 0.225 16 x 25 47 361R470M450LQ2 3.500 0.365 18 x 36

33 361R330M350ER2 5.000 0.265 12.5 x 42.5 56 361R560M450LV2 2.950 0.415 18 x 40

Catalog

Part Number

120 Hz

25ºC (Ω)

250 Vdc (300 Vdc Surge) 33 361R330M350HH2 5.000 0.275 22 x 22

300 Vdc (365 Vdc Surge) 33 361R330M400HH2 5.000 0.275 22 x 22

350 Vdc (400 Vdc Surge) 33 361R330M450FQ2 5.000 0.285 16 x 36

Ripple A

120 Hz

85ºC (A)

Nom Size

D X L
(mm)

ESR Max.

Cap.

(µF)

68 361R680M450HV2 2.450 0.530 22 x 40

Catalog

Part Number

120 Hz

25ºC (Ω)

Ripple A

120 Hz

85ºC (A)

Nom Size

D X L
(mm)

CDM Cornell Dubilier • 140 Technology Place • Liberty, SC 29657 • Phone: [phone] • Fax: [phone] • www.cde.com
