ROHM RPM973-H11 Technical data

RPM973-H11

z

z

z

z

z

Photo Link Module

Ultra-compact, Ultra-thin Side View FIR-comp atible IrDA
Module with Built-in Remote Control Transmission Function

RPM973-H1 1

Outline

The RPM973-H11 is a high performance IrDA module that
integrates an infrared remote control transmission function and
a high-speed (4Mbps) FIR-co mpatible IrDA module into
the world’s smallest



package, resulting in substantial space savings.

!

Applications

All types of data communication, including, image data
and music transmission data in mobile phones,
digital still cameras, and printers

Features

1) Equipped with a remote control function

2) World’s smallest



package (6.8x2.44x1.5mm)

3) 4Mbps FIR-compatible (faster speeds possible with Ir Simple)

Dimensions (Unit : mm)

6.8

3.4

0.16

2.38 2.16

LED

0.95
P0.95 6=5.7

1.1

6.4

R0.83

1.5

0.68

2.09

PD

0.37 0.1

R0.9

0.1

2.18

2.44

0.4

7pin1pin

Absolute maximum ratings (T a = 25qC)

Parameter Symbol Limits Unit
Supply voltage Vcc / VLEDA / VIO 6.5
Input voltage
Operation temperature
Storage temperature

∗1) This applies to all pins basis ground pin (7pin).

 Jan.07 ROHM study

Vin(3,4,5pin)

Topr
Tstg

−0.3 to VIO+0.3

∗1

−25 to +85

−40 to +100

V
V

°C
°C

1/2

RPM973-H11

z

Photo Link Module

Electrical Optical characteristics (Ta = 25qC)

Recommended operating conditions

Parameter

Supply voltage

Electrical Optical Characteristics(Unless otherwise noted, Vcc=3V, VLEDVCC=3V, VIO=3V, Ta=25°C)

Consumption Current2(FIR Mode)
Consumption Current3(at PWDOWN)
LED anode current
Receiver latency time
Peak wavelength
Intensity
Half-angle
Minimum irradiance in augular2
Input half-angle

Symbol

VLEDA

Parameter

Vcc

VIO

Min.

2.4

2.7

1.7

Typ.

3.0

3.0

3.0

Max.

3.6

5.5

Vcc

Unit

V
V
V

At no input light

At no input light
