ROHM KD3003-DF10A Technical data
KD3003-DF10A
Printheads
Compact high speed thick film
thermal printhead (12 dots / mm)
KD3003-DF10A
Using its expertise in LSI technolo gy , R OHM has developed new high density driver ch ips for use in the KD3003-DF10A .
Capable of being employed for bot h thermal and therm al transfer pr inting, with a print speed of 20 0mm/s, the resulti ng
print heads are the fastest in their class. The high -spe ed and hi gh-d en sity prin ti ng answers the needs of ATM, kiosk and
ticket printing devices, which are increasingly being called upon to produce graphical output.
zApplications
Label printers
Ticket printers
T erminal printers
zFeatures
1) The use of a special partial glaze and the latest heating elemen t structure, along w ith new high-de nsity driver chip s that
can accept big current, has allowed ROHM to achieve print speeds of 200mm/s with using thermal history control, the
fastest in its class.
2) One rank resistance value of 1000Ω ± 3% eliminates the inconvenience of rank selection.
3) The required driving voltage of 3.15 to 5.25V allows wide range of power supply voltage setting. This also allows
multiple choice of electronic co mponents fo r printers.
4) 2-inch, 3-inch, 4-inch and 8-inch series are available.
zDimensions (Unit : mm)
91
(4.844)
MAX. 20
2.6±0.1
No.15 No.1
CONNECTOR B CONNECTOR A
(10.2)
5±0.2
81.312 (EFFECTIVE PRINT WITH)
DOT #960 DOT #1
No.15 No.1
81±0.2
2-M3 EFFECTIVE DEPTH 3
φ20.0
5.1±0.1
5.1±0.4
4±0.2
Rev.A 1/4
Printheads
zEquivalent circuit
KD3003-DF10A
VH
GND
VSF
VDD
STB4
STB3
DI2
DO2
TM
TM
CONNECTOR B CONNECTOR A
STB No.
Dot No.
1
2
3
4
193 ∼ 448
449 ∼ 704
705 ∼ 960
DOT #960 DOT #1
L/S
LATCH REGISTER
SHIFT REGISTER SHIFT REGISTER
THERMISTOR
30kΩ B:3950
1 ∼ 192
dots / STB
192
256
DI No.
1
2
256
256
12348 7 56
Dot No.
1 ∼ 448
449 ∼ 960
dots / STB
448
512
VH
GND
STB1
STB2
LAT
CLK
DO1
DI1
Fig.1
Rev.A 2/4
