ROHM BU94603KV Technical data

A

USB Audio Decoder ICs

MP3+SD Memory Card

BU94603KV

Description

BU94603KV is AAC+WMA+MP3 decoder IC which contains USB host and SD card I/F, audio DAC, system controller, regulator for internal CORE power supply.

Features

1) USB2.0 Full Speed host I/F function contained.

2) SD card I/F function contained.

2

C I/F function contained.

3) I

4) FAT analysis function contained.

5) MP3 decode function contained. (available for MPEG1, 2 and 2.5, Layer 1, 2 and 3)

6) WMA decode function contained. (available for WMA9 standard and not available for DRM)

7) AAC decode function contained. (available for MPEG4 AAC-LC and not available for DRM)

8) Sample Rate Converter contained.

9) System Controller contained.

10) LED Controller contained.

11) KEY matrix Controller contained.

12) Stand Alone mode contained.

13) External processor can control. (Slave mode)

14) Audio DAC contained.

15) Sound Effect function contained.

16) Digital Audio Out(I

17) File Name, Folder Name Sorting.

18) ID3TAG and WMATAG and AACTAG Analysis.

19) Reading a specified file data is possible from USB memory.

20) LUN is selectable.

21) Regulator for internal CORE power supply contained.

22) VQFP64pin(0.5mm pitch)

Applications

Audio products, etc.

2

S, S/PDIF) function contained.

No.12080EAT02

www.rohm.com

1/55

2012.04 - Rev.

BU94603KV

A

Absolute maximum ratings (Ta = 25℃)

Parameter Symbol Limits Unit Comment

Supply voltage(Analog, I/O) VDD1MAX

Input voltage VIN Storage temperature range TSTG Operating temperature range TOPR Power dissipation *1 PD 750 mW

*1：In the case of use at Ta=25℃ or more, 7.5mW should be reduced per 1℃. Radiation resistance design is not arranged.

Operating conditions (Ta = 25℃)

Parameter Symbol Limits Unit Comment

Supply voltage(Analog, I/O) VDD1

-0.3～4.5

-0.3 ～ VDD1 + 0.3

-55～125 ℃

-40～85 ℃

3.0～3.6 V DVDDIO,VDD_PLL,

V DVDDIO, VDD_PLL,

V

Technical Note

DAVDD, AVDDC

www.rohm.com

2/55

2012.04 - Rev.

BU94603KV

A

Technical Note

I.Electrical characteristics （Unless specified, Ta=25℃、VDD1=3.3V, DVSS=AVSSC=VSS_PLL=DAVSS=0V, XIN_PLL=16.9344MHz）

Parameter Symbol

MIN. TYP. MAX.

Limits

Unit Condition

<Total > Circuit current (VDD1 USB1) IDD1USB1

- 65 80

mA *1 When USB memory is

played. Circuit current (VDD1 SD1) IDD1SD1 - 35 50 mA *1 When SD card is played. <Digital block> H-Level input voltage VIH VDD1*0.7 － VDD1 V *3 L-Level input voltage H-Level output voltage1 L-Level output voltage1 H-Level output voltage2 L-Level output voltage2 H-Level output voltage3 L-Level output voltage3 H-Level output voltage4 L-Level output voltage4

VIL DVSS － VDD1*0.3 V *3

VOH1 VDD1-0.4 － VDD1 V IOH=-1.6mA, *4

VOL1 0 － 0.4 V IOL=1.6mA. *4

VOH2 VDD1-0.4 － VDD1 V IOH=-3.6mA, *5

VOL2 0 － 0.4 V IOL=3.6mA, *5

VOH3 VDD1-0.4 － VDD1 V IOH=-0.6mA, *6

VOL3 0 － 0.4 V IOL=0.6mA, *6

VOH4 VDD1-1.0 － VDD1 V IOH=-0.6mA, *7

VOL4 0 － 1.0 V IOL=0.6mA, *7

<USB-HOST > H-Level input voltage VIHUSB VDD1*0.6 － VDD1 V *8 L-Level input voltage

VILUSB AVSSC － VDD1*0.3 V *8

Output impedance(H) ZOH 22.0 45.0 60.0  *8 Output impedance(L) ZOL 22.0 45.0 60.0  *8 H-Level output voltage VOHUSB VDD1-0.5 － VDD1 V *8 L-Level output voltage

VOLUSB 0 － 0.3 V *8 Rise/Fall time Tr/Tf － 11 － ns *8, Output capacity 50pF Voltage of crossing point VCRS － VDD1/2 － V *8, Output capacity 50pF Range of differential input VDIFF 0.8 － 2.5 V *8 Differential input sensitivity VSENS 0.2 －－ V *8 Pull-down resistance RPD 14.25 15.0 24.8 k *8 <Audio DAC> Distortion rate THD － 0.02 － % 1kHz, 0dB, sine, *9 Dynamic range DR － 88 － dB 1kHz, -60dB, sine, *9 S/N ratio S/N － 96 － dB *9 Max output level VSMAX － 0.92 － Vrms 1kHz, 0dB, sine, *9

*1 3.3V system I/O, Analog Power supply(VDD1), 1kHz, 0dB, sine-wave playing *3 1-7, 9-17, 19-20, 25-26, 28-30, 40, 49-52, 56, 58-61, 63 pin *4 8, 10-11, 14-16, 48-55 pin *5 13 pin *6 21-23, 26 pin *7 41 pin *8 33, 34 pin *9 44, 46 pin

www.rohm.com

3/55

2012.04 - Rev.

BU94603KV

A

Ⅱ.Block diagram

LED_ERROR/TEST9

LED_PLAY/TEST10

LED_PSD/TEST11

LED_PUSB/TEST12

LED_ACCESS/LRCK

LED_RANDOM/BCK

LED_REPEAT/DATA

TEST13

DVDD_M1

TEST14

TEST15

TEST16

TEST17

DVDDIO

/SPDIF

DVSS

TMODE

AMUTE

49

50

51

52

53

54

55

56

57

LDACO

DAVDD

VCDACO

Audio DAC

Sound Effecter

RDACO

AAC / WMA /

LDO

58

59

60

61

SEL_MP3

System

Controller

SEL_VOL

SEL_DOUT

62

63

64

1 2 3 4 5 6 7 8 9 10111213141516

RESETX

SEL_SLAVE

VSS_PLL

DAVSS

43 42 41 4047 46 45 4448

MP3

Decoder

SEL_APLAY

SEL_UTPKT

XOUT_PLL

XIN_PLL

TEST_PLL

39 38 37 36 35 34 33

VDD_PLL

VOREFI

PLL

Controller

File system

SD I/F

Controller

I2C I/F

Controller

TEST1

TEST2

BUSY

MCHNG

KEY_ROW1/

KEY_ROW2/

KEY_ROW3/SCL

Block diagram

REXTI

USB

FAT

KEY_ROW4/SDA

USB PHY

KEY_COL1/A0

AVSSC

Technical Note

USB_DM

USB_DP

AVDDC

32

31

ATEST1

30

TEST8

TEST7

29

28

TEST6

27

DVDD_M2

26

TEST5/CLKOUT12

25

TEST4

DVSS

24

SD_CS

23

22

SD_DI

21

SD_CLK

SD_DO

20

SD_CON

19

DVDDIO

18

17

TEST3

SEL_SMAN

KEY_COL3/

KEY_COL2/A1

www.rohm.com

4/55

2012.04 - Rev.

BU94603KV

A

y

)

g

)

y

)

y

Ⅲ.Description of Terminals

STAND ALONE MODE(MODE1) SLAVE MODE(MODE2,MODE3)

Signal Name

No.

1 RESETX A I PU

2 SEL_SLAVE B I PU(*1) H: STAND ALONE, L:SLAVE ←

3 SEL_MP3 B I PU(*1)

4 SEL_DOUT B I PU(*1)

5 SEL_VOL B I PU(*1)

6 SEL_APLAY B I PU(*1)

7 SEL_UTPKT B I PU(*1)

8 TEST1 - O PU OPEN (for TEST) ←

9 TEST2 - I PU

10 KEY_ROW1 B I PU KEY Input ROW1 MCHNG O - Music change Output

11 KEY_ROW2 B I PU KEY Input ROW2 BUSY O -

12 KEY_ROW3 B I PU KEY Input ROW3 SCL I - I2C I/F Clock Input

13 KEY_ROW4 B I PU KEY Input ROW4 SDA I/O -

14 KEY_COL1 B O - KEY Input COLUMN1 A0 I -

15 KEY_COL2 B O - KEY Input COLUMN2 A1 I -

16 KEY_COL3 B O - KEY Input COLUMN3 SEL_SMAN I PU(*1) H: MODE2, L: MODE3

17 TEST3 B I PU

18 DVDDIO - - -

19 SD_CON B I - SD I/F (*2) ← 20 SD_DO B I - SD I/F (*2) ← 21 SD_CLK B O - SD I/F ← 22 SD_DI B O - SD I/F ← 23 SD_CS B O - SD I/F ← 24 DVSS - - - Connect to GND ←

25 TEST4 - I PU

26 TEST5 - I PU

27 DVDD_M2 - - - Connect to 57PIN ←

28 TEST6 - I -

29 TEST7 - I -

30 TEST8 - I -

31 ATEST1 - O - OPEN (for TEST) ←

32 AVDDC - - -

33 USB_DM C I/O - USB DATA- ← 34 USB_DP C I/O - USB DATA+ ← 35 AVSSC - - - Connect to GND ←

36 REXTI D O -

37 VOREFI - O - OPEN (for TEST) ←

38 VDD_PLL - - -

39 TEST_PLL - I - OPEN (for TEST) ← 40 XIN_PLL E I - X'tal Input 16.9344MHz ← 41 XOUT_PLL E O - Connect to X'tal 16.9344MHz ←

I/O Cir

I/O

Pull-Up/

Down

Function Signal Name I/O

H: Release RESET, L: RESET

H: PLAY MP3 ONLY, L: PLAY MP1,MP2 and MP3

H: ANALOG DAC Output, L: Digital Output

H: Volume control valid, L: Volume control invalid

H: Auto Play OFF , L: Auto Pla

H: Normal Operation L: USB Test Packet Output

Pull-up to 3.3V system power supply (for TEST

Connect to 3.3V System Power Suppl

Pull-up to 3.3V system power supply (for TEST Pull-up to 3.3V system power supply (for TEST

Pull-up to 3.3V system power supply (for TEST

Connect to 3.3V System Power Suppl

Connect Bias Resistor to GND

Connect to 3.3V System Power Suppl

CLKOUT12(*3)

Pull-Up/

Down

←

I/O

PU(*3) 12MHz CLK Output.

(*3)

←

Technical Note

Function

Command Operation Busy Fla

I2C I/F Data Input/Output I2C I/F Slave Address Set0 I2C I/F Slave Address Set1

www.rohm.com

5/55

2012.04 - Rev.

BU94603KV

A

y

(

)

y

)

r

)

y

42 VSS_PLL - - - Connect to GND ← 43 DAVSS - - - Connect to GND ← 44 RDACO F O - Audio DAC Line Output Rch ←

45 VCDACO F O -

Audio DAC Reference Voltage Output

46 LDACO F O - Audio DAC Line Output Lch ←

47 DAVDD - - -

48 AMUTE G O -

Connect to 3.3V System Power Suppl

Audio Mute Output

H:Mute Cancel, L:Mute

49 LED_ERROR B O - Error LED Output TEST9 I PU

50 LED_PLAY B O - Play LED Output TEST10 I PU

51 LED_PSD B O - Play SD Card LED Output TEST11 I PU

52 LED_PUSB B O - Play USB LED Output TEST12 I PU

53(*3) LED_ACCESS B O - Memory Access LED Output

LRCK

/SPDIF(*4)

54(*3) LED_RANDOM B O - Random Play LED Output BCK(*4)

55(*3) LED_REPEAT B O - Repeat Play LED Output DATA(*4)

56 TEST13 - I PU

57 DVDD_M1 - - -

Pull-up to 3.3V system power supply (for TEST

Connect to Bypass Condense

I/O

(*4)

I/O

(*4)

I/O

(*4)

58 TEST14 F I - Connect to GND ←

59 TEST15 - I -

60 TEST16 - I -

61 TEST17 - I -

Pull-up to 3.3V system power supply (for TEST

62 DVSS - - - Connect to GND ← 63 TMODE H I - Connect to GND ←

64 DVDDIO - - -

Connect to 3.3V System Power Suppl

*1 When L is input, Pull-UP turns OFF. *2 When SD I/F is disused, pull-up to 3.3V system power supply. *3 Enabled/Disabled can be selected using commands. This pin becomes output and pull-up is OFF, only when 12MHz clock output is enable. *4 In STAND ALONE MODE (MODE1), When ANALOG DAC output is selected (SEL_DOUT=H), LED output is enabled. When the Digital output is selected (SEL_DOUT=L), the I2S format audio output is enabled.

In SLAVE MODE (MODE2, MODE3),

When the ANALOG DAC output is selected (SEL_DOUT=H), these pins are TEST terminals.

When the Digital output is selected (SEL_DOUT=L), you can select I2S format audio output or digital audio

interface output (SPDIF).

See Chapter Ⅴ.4 for further information.

Technical Note

←

Pull-up to 3.3V system power suppl Pull-up to 3.3V system power suppl Pull-up to 3.3V system power suppl Pull-up to 3.3V system power suppl

PU(*4)

PU(*4) I2S Output Bit Clock

PU(*4) I2S Output LR DATA

I2S Output LR Clock / SPDIF Output

←

www.rohm.com

6/55

2012.04 - Rev.

BU94603KV

A

Ⅳ. Terminal equivalent circuit diagram

A B C D

DVDDIO

Technical Note

D P

D M

AVDDC

XIN

VDD_PLL

VSS_PLL

15KΩ

AVSSCAVSSC

AVSSC

DVSSIO

15KΩ

E F G H

VDD_PLL

XOUT

VSS_PLL

DAVDD

DAVSS

DVDDIO

DVSSIO

DVDDIO

DVSSIO

I/O terminal equivalent circuit diagram

www.rohm.com

7/55

2012.04 - Rev.

BU94603KV

A

X

V. I/O Signal Specifications

V.1 Clock and reset

Clock

Signal name I/O Function Remarks

XIN_PLL I

XOUT_PLL O

Reset

Signal name I/O Function Remarks

RESETX I System reset input terminal

To disable a reset signal, continue L input for more than 5 us after all of the supply voltage reach the specified value and clock input from the oscillation I/O terminal becomes stable. (See Figure V.1.)

Power supply

XIN_PLL

RESETX

’tal (16.9344 MHz) connection

input terminal

’tal (16.9344 MHz) connection

terminal

Oscillation stabilization

standby time

Technical Note

clk

f

Clock frequency

Reset L interval

V.2 SEL_SLAVE

MODE1/MODE2, 3 selection input signal

Signal name I/O Function Remarks

SEL_SLAVE I Selects MODE1 or MODE2, 3. H: MODE1, L: MODE2, 3

V.3 SEL_MP3

Signal name I/O Function Remarks

SEL_MP3 I MPEG Audio Layer selection

tRSTX

Figure V.1 Reset Timing

Specification

Item Symbol

f

CLK

t

RSTX

min typ max

16.9302 16.9344 16.9386 MHz

5 - - us

Unit Remarks

SEL_SLAVE selects MODE1 (STAND ALONE MODE) or MODE 2/3 (SLAVE MODE). By selecting SEL_SLAVE, SLAVE mode terminal setting shown in Table II.2 is enabled. SEL_SLAVE is set only at power ON. Note that change of selection after power ON is ignored.

MPEG Audio Layer 1, 2, 3 play selection signal

H: Can play MP3 only. L: Can play MP1, MP2 and MP3.

SEL_MP3 allows you to select the layer of the MPEG audio to be played. When enabling all the files having mp1, mp2 or mp3 as the file extension to be played, enter L. When enabling mp3 only, enter H. SEL_MP3 is set only at power ON. Note that change of election after power ON is ignored.

www.rohm.com

8/55

2012.04 - Rev.

BU94603KV

A

F

p

V.4 SEL_DOUT

Audio output selection signal

Signal name I/O Function Remarks

SEL_DOUT I Audio output selection H: Line output, L: I2S 3 lines serial output/SPDIF

This SEL_DOUT selects audio output signal. Table V4.1 “Audio output” shows the audio outputs for each MODE. Also table V4.2 ”I2S_fs” shows the I2S output formats for each MODE. For command, see Chapter VI. "TEST terminal" needs to be pull-up to 3.3V power supply.

Technical Note

TableV.4.1 Audio output

Pin No.

44 Line Out Rch O OF 46 Line Out Lch O OF 53 LED_ACCESS O OF 54 LED_RANDOM O OF 55 LED_REPEAT O OF

SEL_DOUT=H SEL_DOUT=L SEL_DOUT=H

function I/O PU function I/O PU function I/O PU function I/O PU function I/O PU

SEL_DOUT is set only at power ON. Note that change of selection after power ON is ignored.

V.5 SEL_VOL

Sound volume operation selection signal

Signal name I/O Function Remarks

SEL_VOL I Sound volume operation

SEL_VOL selects whether sound volume operation is to be enabled or disabled. Sound volume operation is enabled when SEL_VOL=H. Initial value of audio output is -24.1dB at power ON. Sound volume operation is disabled when SEL_VOL=L. Audio output is fixed to 0dB. Figure V.5 shows the relationship between audio output and sound volume step. SEL_VOL is set only at power ON. Note that change of selection after power ON is ignored.

MODE1 MODE2,3

SEL_DOUT=L

I2S SPDIF　ON

HiZ O OFFLine Out Rch O OFF HiZ O OFF HiZ O OFF HiZ O OFFLine Out Lch O OFF HiZ O OFF HiZ O OFF

I2S LR CLOCK O OFFTEST terminal I ON I2S LR CLOCK O OFF SPDIF O OFF

I2S BIT CLOCK O OFFTEST terminal I ON I2S BIT CLOCK O OFF TEST terminal I OFF

I2S LRDATA O OFFTEST terminal I ON I2S LRDATA O OFF TEST terminal I OFF

*PU・・・Pull-Up

Table V.4.2 I2S_fs

MODE1 32fs

MODE2/3 Can select 32fs, 48fs, 64fs by command.

H: Sound volume operation enabled, L: Sound volume operation disabled

0

-10

-20

-30

-40

-50

 -

Audio output (dB)

-60

Initial value: -24.1 dB (when SEL_VOL=H)

02468101214161820222426283032

Volume ste

Figure V.5 Volume Step Function

www.rohm.com

9/55

2012.04 - Rev.

BU94603KV

A

V.6 SEL_APLAY

Auto play selection signal at power ON/device recognition

Signal name I/O Function Remarks

SEL_APLAY I

SEL_APLAY selects whether the audio data in the memory is to be automatically played when a memory device (USB memory or SD card) is inserted at power ON or when the system recognizes the memory device inserted. SEL_APLAY can be selected only in MODE1. Since selection of SEL_APLAY is ignored in MODE2/3, select it from Pull-up. When MODE2/3 is selected, audio data is halted after the system recognizes a device.

V.7 SEL_UTPKT

USB test packet

Signal name I/O Function Remarks

SEL_UTPKT I USB test packet send H: Disabled, L: USB test packet send

A test packet signal is output from USB_DP terminal or USB_DM terminal when L is set to SEL_UTPKT at power ON. Once enabled, SEL_UTPK keeps that state regardless of operation modes and sends out a test packet. A test packet signal is continuously output until power turns OFF. Use SEL_UTPKT when evaluating the USB terminal. In other cases, use it from Pull-up.

V.8 Audio output

Audio output

Signal name I/O Function Remarks

LDACO O Lch audio line output -

RDACO O Rch audio line output -

These signals are decoded MP3 music audio data line outputs. They turn ON when the line output is selected by SEL_DOUT terminal.

V.9 MUTE control output

Audio MUTE

Signal name I/O Function Remarks

AMUTE O Audio mute control terminal H: At audio output, L: At mute

This is a control terminal to mute audio output at power ON or FF/FB (silence). This terminal outputs H at audio output and L at mute. Figure Ⅴ.9 shows the operation waveform.

Auto play selection signal at device recognition

Technical Note

H: Stop after recognizing device, H: Play after recognizing device

Figure V.9 Waveform at Audio Mute

www.rohm.com

10/55

2012.04 - Rev.

BU94603KV

A

V.10 KEY input format

3x4 matrix command input

Signal name I/O Function Remarks

KEY_ROW1 I

KEY_ROW2 I -

KEY_ROW3 I -

KEY_ROW4 I -

KEY_COL1 O -

KEY_COL2 O -

KEY_COL3 O -

Configure a circuit for the matrix signals terminals for KEY commands as shown in the applied circuit diagram V.10. The operation corresponding to the key pressed over the circuit is performed. Details of each operation are explained in Chapter VI.2.

Technical Note

-

KEY matrix I/O signal

REPEAT RANDOM CHG_DEV+10

VOL+ FOL- FOL+VOL-

V.11 I2C interface format

I2C serial interface

Signal name I/O Function Remarks

SCL I I2C interface clock input -

SDA I/O I2C interface data I/O -

A0 I Slave address selection terminal Slave address [0] bit setting terminal

A1 I Slave address selection terminal Slave address [1] bit setting terminal

This is an I2C serial interface terminal. By inputting L to SEL_SLAVE terminal, the interface terminal becomes enabled. The terminal supports slave I2C operation.

V.11.1 I2C protocol

When I2C bus is in IDLE, SDA and SCL are set to H by the external Pull-up resistance. When starting communications, the master sets SDA to L while SCL is set to H (Start condition). When ending communications, the master sets SDA to H while SCL is set to H (Stop condition). During transfer, SDA is changed only when SCL is set to L. Figure V.11.1 shows Start condition, Stop condition of I2C.

KEY_

ROW1

KEY_

ROW2

PLAY/

PAUSE

STOP

KEY_

ROW3

KEY_

ROW4

FFFB

KEY_

COL1

Figure V.10 KEY Matrix Applied Circuit Diagram

KEY_

COL2

KEY_

COL3

SCL

SDA

12

MSB

Start condition

8

LSB ACK

9 1

9

ACK

Stop condition

Figure V.11.1 I2C start, stop condition

www.rohm.com

11/55

2012.04 - Rev.

BU94603KV

A

V.11.2 Slave address

An I2C bus slave address corresponds to the 7-bit addressing mode. As shown in Table V.11.2, you can select the slave address using input of A0 terminal and A1 terminal. Figure V.11.2 shows the slave address transfer format.

S A6 A5 A4 A3 A2 A1 A0 R/W ACK

Start

condition

R / W = Read / Write Pulse

ACK = Acknowledge

Slave Address

Figure V.11.2 Slave Address Transfer Format

Table V.11.2 Settable Slave Addresses

sent by

slave

Technical Note

MSB

A6

A5 A4 A3 A2

A1

terminal

LSB

A0 terminal

1 0 0 0 0 0 0 1 0 0 0 0 0 1 1 0 0 0 0 1 0 1 0 0 0 0 1 1

V.11.3 Write protocol from master

To send a master command using an I2C bus, follow the transfer protocol shown in Figure V.11.3. For details on each command, see Chapter VI.

S Slave Address A Data(8bit)R/W A Data(8bit) A Data(8bit) PA/A

"0"(write)

From Master to Slave

From Slave to Master

A = Acknowledge(SDA low) A = No Acknowledge(SDA high) S = Start Condition P = Stop condition

Figure V.11.3 Command send protocol

V.11.4 Read protocol to master

To send reception data using an I2C bus from the slave to the master, follow the transfer protocol shown in Figure V.11.4.1. First, transfer the status read command (step1). Then, input SCL clock of required bytes in step 2 to read the status. When the device is BUSY at reception of device status or memory data, the I2C bus may possibly be occupied by the device during BUSY. This LSI transfers the bus to the master so as not to generate such bus occupation. However, as a BUSY state still exists inside of the system, appropriate data may not be transferred during BUSY. Therefore, the first byte of transfer data (Step2) is used to judge the transfer data is enabled/disabled. When specifying addresses from the master to the slave and the first byte of the transfer data immediately after data transfer is required is 0x00, transfer data from the slave is enabled. If the first byte is 0xFF, it shows the BUSY state. Therefore, the transfer data should be disabled. If this happens, retry command transfer at Step 1 to read out the status. Figure V.11.4.2 shows the relationship between the transfer data and BUSY. * For further information on BUSY, see Chapter V.17.

www.rohm.com

12/55

2012.04 - Rev.

BU94603KV

A

I2C

Step1

S Slave Address A Data(8bit)R/W A Data(8bit) PA/A

Step2

S Slave Address A Data(8bit)R/W A Data(8bit) PA/A

From Master to Slave

From Slave to Master

"0"(write)

"1"(read)

A = Acknowledge(SDA low) A = No Acknowledge(SDA high) S = Start Condition P = Stop condition

Figure V.11.4.1 Status Reception Protocol

Step1 command S Slave Address A 0xFF A Data(8bit) PA/AData(8bit) AR

Technical Note

Data(8bit) A

BUSY

Step1 command S Slave Address A 0x00 A Data(8bit) PA/AData(8bit) AR

Dummy byte for Busy

Figure V.11.4.2 Relationship between Transfer Data and BUSY

V.11.5 I2C Bus line electrical specification and timing

SDA and SCL bus-line characteristic (Unless specified, Ta=25℃, Vcc=3.3V)

Parameter Code Min. Max. Unit

1 SDA, SCL H input voltage VIH VDD*0.7 VDD V

2 SDA, SCL L input voltage VIL DVSS VDD*0.3 V

3 SDA H output voltage VOH VDD-0.4 VDD V

4 SDA L output voltage VOL 0 0.4 V

5 SCL clock frequency fSCL 0 400 kHz

Bus-free-time between "Stop" condition and

6

"Start" condition

Hold time for "Start" condition

7

After this, the first clock pulse is generated.

tBUF 1.3 － us

tHD;STA 0.6 － us

8 LOW status hold-time of SCL clock tLOW 1.3 － us

9 HIGH status hold-time of SCL clock tHIGH 0.6 － us

10 Data-hold-time tHD;DAT 0＊－ us

11 Date-setup-time tSU;DAT 100 － ns

12 Rising time of SDA and SCL signal tR 20+0.1*Cb 300 ns

13 Fall time of SDA and SCL signal tF 20+0.1*Cb 300 ns

14 Setup time of "Stop" condition tSU;STO 0.6 － us

15 Capacitive load of each bus-line Cb － 400 pF

The above-mentioned numerical values are all the values corresponding to V *To exceed an undefined area on falling edged of SCL, transmission device should internally offer the hold-time of 300ns or more for SDA signal (V signal). Because the "Repeated Start" condition to send "Start" condition without sending "Stop" condition doesn't correspond, after sending "Start" condition, always send "Stop" condition. Neither terminal SCL nor terminal SDA correspond to 5V tolerant.

IH min

and V

IL max

level.

IH min

of SCL

www.rohm.com

13/55

2012.04 - Rev.

BU94603KV

A

SDA

t

BUF

SCL

t

LOW

t

R

t

HD;STA

SP

t

HD;DAT

t

HIGH

Figure V.11.5 Timing chart

V.12 I2S format

I2S serial audio interface

Signal name I/O Function Remarks

LRCK O I2S Bit clock output (fs=44.1kHz) -

BCK O I2S Bit clock output -

DATA O I2S data output -

This is a serial audio interface terminal. By inputting L to SEL_DOUT terminal, the interface terminal becomes enabled. When selecting the I2S serial audio output, the output format varies depending on MODE. *See Chapter Ⅴ.4. MODE2 allows you to select 32fs, 48fs or 64fs. *See Chapter V.4. Figures V.12.1. V12.2 and V.12.3 show the I2S format to be output.

t

F

t

SU;DAT

t

SU;STO

Technical Note

P

LRCK

BCK(32fs)

DATA

Left Channel

0 15 14 13 12 11 10 9 8 7 6 5 4 3 2 11 0

Right Channel

15

Figure V.12.1 I2S Output Timing (32fs)

LRCK Left Channel Right Channel

BCK(48fs)

DATA

15 14 12 11 10 9 8 7 6 5 4 3 2 1 0 15 1413

Figure V.12.2 I2S Output Timing (48fs)

LRCK

BCK(64fs)

DATA

13 1215 14 11 8 710 9 6 3 25 4 1 0 13 1215 14

Left Channel Right Channel

Figure V.12.3 I2S Output Timing (64fs)

www.rohm.com

14/55

2012.04 - Rev.

BU94603KV

A

V.13 SPDIF format

Signal name I/O Function Remarks

SPDIF O Digital audio output -

SPDIF output becomes enabled by setting SEL_DOUT terminal to L and setting this condition using the I2C command. *See Chapter V.4. Figure V.13 shows the digital audio signal output format.

Source code

Synchronous preamble

Source code(4-31)

SPDIF output

Digital audio interface

034 1112 2728293031

Synchronous

preamble

Synchronous

preamble

all 0 Audio data(16bit)

(B pattern)

(M pattern)

(W pattern)

0 0 0 0 0 0 0 0 1 0 1 1 0 1

LSB MSB

Figure V.13 SPDIF Output Format

Technical Note

V U C P

A sub-frame of SPDIF is composed of synchronous preamble, 16-bit audio data, V bit (validity flag), U bit (user data), C bit (channel status) and P bit (parity bit). Output rate is fixed to 1X speed. SPDIF outputs synchronous preamble (source code 0-3) as it is and others (source code 4-31) as bi-phase output. It outputs L while the operation is stopped. Synchronous preamble and C bit use 32 frames (4.4ms) as one cycle. Table V.13.1 and Table V.13.2 show these formats. V bit is fixed to L. U bit uses 98 frames (13.3ms) as one cycle.

Table V.13.1 Synchronous Preamble Pattern

L0 R0 L1 R1 L2 R2 L3 R3 L4 R4 L5 R5

0 B W M W M W M W M W M W

1 M W M W M W M W M W M W

: : : : : : : : : : : : :

31 M W M W M W M W M W M W

Table V.13.2 C Bit Format

L0 R0 L1 R1 L2 R2 L3 R3 L4 R4 L5 R5

0 0 0 0 0 0 0

1 0 0 1 0 0 0

2 0 0 0 0 0 0

3 0 0 1 0 0 1 0 0

4 0 0 0 0 0 0

5 0 0 0 0 0 0

: : : : : : :

31 0 0 0 0 0 0

www.rohm.com

15/55

2012.04 - Rev.

BU94603KV

A

P bit is set to 1 if the number of “1s” of source codes 4-30 is odd, and set to 0 if the number is even. Therefore, the number of source codes which turn to 1 for one data must be an odd value, SPDIF ends with L output and preamble output always starts in the same direction.

V.14 USB I/F

USB I/O I/F

Signal name I/O Function Remarks

USB_DP I/O USB D+I/O terminal -

USB_DM I/O USB D-I/O terminal -

REXTI O

Differential signals of USB_DP and USB_DM enable communications with USB devices. REXTI terminals become bias resistance connection terminals of the USB-PHY block.

V.15 SD I/F

SPI interface for SD memory card I/F

Signal name I/O Function Remarks

SD_CS O SPI chip select -

SD_CLK O SPI clock -

SD_DI O SPI data input -

SD_DO I SPI data output -

SD_CON I

Since SD memory card slot requires detecting insertion of SD memory card, use of slot equipped with SD memory card detecting terminal and connection to SD_CON terminal are required.

V.16 MCHNG

Playing sound tune number detection output

Signal name I/O Function Remarks

MCHNG O

This signal outputs change of file to be played during playing MP3 file in the memory device. MCHNG correctly outputs "H" during MP3 decode sequence, outputs "L" during "STOP" status.

V.17 BUSY

BUSY state detection output

Signal name I/O Function Remarks

BUSY O

This signal outputs to indicate that this LSI is in BUSY. BUSY signal analyzes commands from the master and outputs H until the operation is executed. This LSI ignores command input during BUSY. However, only the ABORT and STOP commands can be accepted even during BUSY, which can be executed. *See Chapter V.11.

Technical Note

Table V.13.3 U Bit Format

L0 R0 L1 R1 L2 R2 L3 R3 L4 R4 L5 R5

0 0 0 0 0 0 0 0 0 0 0 0 0

1 0 0 0 0 0 0 0 0 0 0 0 0

2 1 0 0 0 0 0 0 0 0 0 0 0

3 1 0 0 0 0 0 0 0 0 0 0 0

: : : : : : : : : : : : :

97 1 0 0 0 0 0 0 0 0 0 0 0

USB bias resistance connection terminal

SD card connect detection terminal

These I/F enable communication with SD memory cards through SD memory card slots.

SD_CON terminal is pulled up within the device and detects SD memory card connection by L input.

Music tune number change detection output signal

BUSY state detection output signal

Connect resistance of 12k  1% to GND.

H: Not detecting SD card connection. L: Detecting SD card connection.

H: Playing, L: Tune completed/stopped

H: Busy, L: Not Busy

www.rohm.com

16/55

2012.04 - Rev.

BU94603KV

A

VI. Function/Operation Explanation

VI.1 File detection

VI.1.1 Function

· This function supports FAT16 and FAT32 file systems. (It does not support NTFS and FAT12.)

· The maximum number of playable files per folder

The number of files described above contains files other than AAC/WMA/MP3 and folders. If those nonAAC/WMA/MP3 files and folders exit within the folder and exceed the maximum number, all the AAC/WMA/MP3 files may not be played.

· Files less than 100 can be sorted by UNICODE in the FAT order within the folder. Files over 100 are sorted in the FAT order. Also, the folders can be sorted in the same manner and those over 100 are sorted in the FAT order.

· The searchable folder hierarchy is of 8 layers containing the root folder. Figure VI.1.1 shows an example of memory layers.

Memory

Technical Note

Table VI.1.1 Maximum Number of Playable Files

Root folder Sub folder

FAT16 512 65534 FAT32 65536 65534

USB

Folder

File File

File

File File

Playable layers

FolderFolder

Folder

Folder Folder

Folder

Folder Folder

Folder File File File File File

Folder File File File

Folder

File

File File File File

File File

Unplayable layers

File

Figure VI.1.1 Example of Memory Layers

www.rohm.com

17/55

2012.04 - Rev.

BU94603KV

A

VI.1.2 Playable file

VI.1.3 Playing sequence

VI.1.4 Folder/file sort

2-a) When character-code that appears first is ≧0x80 ,It’s treated as the first byte of two byte character. Byte

Technical Note

The playable file extensions are *.M4A, *.3GP and *.MP4 for AAC files, *.WMA and *.ASF for WMA files, *.MP3, *.MP2 and *.MP1 for MP3 files. (Upper case letters and lower case letters are not distinguished.) Note that the file operation differs in the following cases: (1) SEL_MP3: See SEL_MP3 for details. (2) Attribute: A AAC/WMA/MP3 file whose attribute is masked can be played. A file with system attributes

cannot be played.

(3) Data destroyed file: When the data section of AAC/WMA/MP3 file is destroyed, the music data of the file

can be played as much as possible rather than disabling to play the entire file. The section which cannot be played is muted. However, AMUTE terminal remains the H output level. When the header section of

WMA and AAC file is destroyed, it plays next. (4) File name: A file name and its size do not depend on playing. (5) Extension: When file data is configured in the non-AAC format and its file extension is *.M4A, *.3GP and

*.MP4 the state is play next. When file data is configured in the non-WMA format and its file extension is

*.WMA, or *.ASF, the state is play next. When file data is configured in the non-MP3 format and its file

extension is *.MP3, *.MP2 or *.MP1, the state is silent playing basically. If playable data can be read, only a

part of the file can be played. The information on time required to output serial status also becomes

uncertain. Then, partial output is done but the correct time information is not output. (6) File size: When file size is “0”, the file do not recognize at AAC/WMA/MP3 files. (7) This LSI corresponds to the AAC file encoded by iTunes. The versions of iTunes checked operation are 4.*,

5.*, 6.*, and 7.0 to 7.5. The AAC file encoded with other software may cause fault, such as being in the

middle of reproduction and skipping to next. (8) When the extension of WMA file is *.ASF, this LSI corresponds to the ASF file of only an audio stream.

The playing sequence of AAC/WMA/MP3 files is determined based on the following rules. See Figure VI.1.3. (1) Folders are sorted in the order written in FAT (in the order of FAT), and files 1 to 100 are sorted in the order

of UNICODE. (*See Chapter VI. 1.4.) Files over 100 are sorted in the order of FAT. Folders over 100

are sorted in the same manner.

AAC/WMA/MP3 files are sorted by AAC/WMA/MP3 following SEL_MP3. Folders are sorted including null

folders and those in which AAC/WMA/MP3 files are not written. Within each folder, AAC/WMA/MP3 files

over 100 and folders over 100 are played in the order written to the FAT directory entry.

Since how to write to the directory entry depends on the OS (Operating System) processing to write to the

memory, you cannot understand the file playing sequence. (2) When AAC/WMA/MP3 file exists in the root folder (the highest layer), the AAC/WMA/MP3 file is played first. (3) When all the AAC/WMA/MP3 files in the root folder have been played, those in the folder under the root

folder, if any, are played. (4) When a folder is layered under that, AAC/WMA/MP3 files in the folder are played. When not, the master

searches any other folders at the same layer and plays the one, if any. (5) After playing all the files, the master returns to the root folder as described in (2) and start playing with the

first sorted file.

Folders and files are sorted in the following sequence using this LSI. (1) Obtain up to 100 files and 100 folders in the order written to FAT. (2) Compare the obtained folder/file names up to 14 characters (including filename extensions) and sort them

in the ascending order.* (3) When the same strings are generated, follow the order written to FAT. When the same strings are

generated and the extension is different, MP3 file is first, WMA file is second, and AAC file is last. (4) For 101 or more folders and files, follow the order written to FAT.

*The processing of the file name and the folder name is shown in the following.

1)When the LFN(long file name) entry exists, folder/filename is processed as one character in two bytes.

2)When the LFN entry doesn't exist, the SFN(short file name) entry is processed as follows.

data afterwards is treated as the second byte of two byte character-code, and treated by two bytes as one

character.

2-b) When the case that doesn't apply to 2-a) ,that is, the character-code appears first is installed within

the range of 0x00-0x7F(US-ASCII) One byte is treated as one character. '0x00' is added and enhanced to Unicode.

Please confirm the specification of the FAT filesystem about details of LFN and SFN.

www.rohm.com

18/55

2012.04 - Rev.

ROHM BU94603KV Technical data

Specifications and Main Features

Frequently Asked Questions

User Manual
