1 Welcome to the R&S SMCVB-KV12 option
The R&S SMCVB-KV12 is a waveform library that provides waveform files in accordance with the DRM+ digital standard.
This user manual contains a reference description of the functionality that the waveform library provides. All functions not discussed in this manual are described in the
R&S SMCV100B user manual. The latest version is available at:
www.rohde-schwarz.com/manual/SMCV100B
1.1 Key features
The R&S SMCVB-KV12 features:
●
●
Welcome to the R&S SMCVB-KV12 option
Documentation overview
Numerous waveform files in accordance with DRM+ digital standard
Efficient use with dedicated waveforms
1.2 Installation
You can find detailed installation instructions in the supplement document of the
R&S SMCV100B user manual and in the R&S SMCV100B user manual describing
firmware versions FW 4.90.002.xx and later of the R&S SMCV100B.
1.3 What's new
Compared to the previous version there are editorial changes only.
1.4 Documentation overview
This section provides an overview of the R&S SMCV100B user documentation. Unless
specified otherwise, you find the documents on the R&S SMCV100B product page at:
www.rohde-schwarz.com/manual/smcv100b
1.4.1 Getting started manual
Introduces the R&S SMCV100B and describes how to set up and start working with the
product. Includes basic operations, typical measurement examples, and general information, e.g. safety instructions, etc. A printed version is delivered with the instrument.
5User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
1.4.2 User manuals and help
Separate manuals for the base unit and the software options are provided for download:
●
●
The contents of the user manuals are available as help in the R&S SMCV100B. The
help offers quick, context-sensitive access to the complete information for the base unit
and the software options.
All user manuals are also available for download or for immediate display on the Internet.
Welcome to the R&S SMCVB-KV12 option
Documentation overview
Base unit manual
Contains the description of all instrument modes and functions. It also provides an
introduction to remote control, a complete description of the remote control commands with programming examples, and information on maintenance, instrument
interfaces and error messages. Includes the contents of the getting started manual.
Software option manual
Contains the description of the specific functions of an option. Basic information on
operating the R&S SMCV100B is not included.
1.4.3 Service manual
Describes the performance test for checking compliance with rated specifications, firmware update, troubleshooting, adjustments, installing options and maintenance.
The service manual is available for registered users on the global Rohde & Schwarz
information system (GLORIS):
https://gloris.rohde-schwarz.com
1.4.4 Instrument security procedures
Deals with security issues when working with the R&S SMCV100B in secure areas. It
is available for download on the Internet.
1.4.5 Printed safety instructions
Provides safety information in many languages. The printed document is delivered with
the product.
1.4.6 Data sheets and brochures
The data sheet contains the technical specifications of the R&S SMCV100B. It also
lists the options and their order numbers and optional accessories.
The brochure provides an overview of the instrument and deals with the specific characteristics.
6User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
See www.rohde-schwarz.com/brochure-datasheet/smcv100b
1.4.7 Release notes and open source acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current
firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of the
used open source software.
See www.rohde-schwarz.com/firmware/smcv100b
1.4.8 Application notes, application cards, white papers, etc.
These documents deal with special applications or background information on particular topics.
See www.rohde-schwarz.com/application/smcv100b
Welcome to the R&S SMCVB-KV12 option
Documentation overview
7User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2 Available waveform files
2.1 General settings and features
All files have general features and settings as follows:
●
●
●
●
●
●
●
Available waveform files
Naming conventions
DRM Mode E (DRM+)
Sample rate 192 kHz
Bandwidth 100 kHz
Filter bandwidth 2x 76.8 kHz
File length approx. 500 MB
Play time per file approx. 10 minutes
Included PRPS services have the polynomial G23(x)=x23 + x18 + 1, register contents
are initially all set to binary 1.
2.2 Naming conventions
DRM setting files (chapter 2.3)
The file name consists of:
●
MSC mapping type
●
MSC lower protection level
●
MSC higher protection level
●
SDC protection level
Example: MSC_4QAM_MSC_LPP_0_MSC_HPP_0_SDC_1.wv
This file has the following characteristics:
●
MSC mapping type: 4QAM
●
MSC lower protection level (MSC_LPP): 0
●
MSC higher protection level (MSC_HPP): 0
●
SDC protection level (SDC): 1
DRM service files (chapter 2.3)
The file name consists of:
●
Services
●
Number of services
●
Audio coding of each service
Example: Services_3_HE-AAC_HE-AAC_PRBS.wv
8User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
This file has the following characteristics:
●
●
EN 303 345 DRM testing files (chapter 2.5)
The file name consists of:
●
●
Example: VHF_wanted.wv
In this standard, there are three different frequency bands defined. Only the VHF band
uses robustness mode E. The other frequency bands use robustness mode B and are
excluded from this library. These files are part of the waveform library R&S SMCVBKV11 DRM Waveforms (1434.5370.xx).
Available waveform files
DRM settings
Contains 3 services
Audio coding: service 0: HE-AAC; service 1: HE-AAC; service 2: data PRBS
Frequency band
Wanted/unwanted signal
2.3 DRM settings
2.3.1 4QAM MSC mapping
Describes the files with 4QAM MSC mapping and different protection levels.
2.3.1.1 MSC_4QAM_MSC_LPP_0_MSC_HPP_0_SDC_1.wv
Table 2-1: General settings
Samples 125337600
Peak offset 3.12 dB
Peak/RMS 12.44 dB
Duration 10 minutes 52 seconds
MSC mapping 4QAM
MSC lower protection 0 (highest)
MSC higher protection 0 (highest)
SDC protection 1 (highest)
Service 2 and 3 are not available.
Table 2-2: Services
Service ID 0xAFFE 0xAFFF
Language Japanese Korean
Service 0 Service 1
9User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Service label HE-AAC Data PRBS
Available waveform files
DRM settings
Service content Audio HE-AAC
16.32 kb/s
HPP 43 bytes
24 kHz
Param. stereo + SBR
Program type Varied
Links to AFS1
Service eFM+RDS, 0xD001
Schedule None
Content Equal
Frequency 96.6 MHz
Local Information
Country Germany
Language of audience English
Text
Text headline Text Message Service 0
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
PRBS
20.88 kb/s
Synchronized
Low protected: 226 bytes
High protected: 35 bytes
Text transmit 4 times
2.3.1.2 MSC_4QAM_MSC_LPP_1_MSC_HPP_1_SDC_1.wv
Table 2-3: General settings
Samples 126028800
Peak offset 2.83 dB
Peak/RMS 12.75 dB
Duration 10 minutes 56 seconds
MSC mapping 4QAM
MSC lower protection 1 (high)
MSC higher protection 1 (high)
SDC protection 1 (highest)
Service 2 and 3 are not available.
10User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Table 2-4: Services
Available waveform files
DRM settings
Service ID 0xAFFA 0xAFFF
Language German English
Service label Service 0 xHE Data PRBS
Service content Audio xHE-AAC
Program type Varied
Links to AFS1
Service eFM+RDS, 0xD001 -
Schedule None -
Content Equal -
Frequency 96.6 MHz -
Local Information
Country Germany
Service 0 Service 1
Data PRBS
32.08 kb/s
No HPP
38.4 kHz
Stereo no SBR
17.6 kb/s
Synchronized
Low protected: 220 bytes
High protected: 0 bytes
Language of audience English
Text
Text headline Text Message Service 0
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library DRM
Mode E
Text transmit 4 times
2.3.1.3 MSC_4QAM_MSC_LPP_1_MSC_HPP_1_SDC_0.wv
Table 2-5: General settings
Samples 125107200
Peak offset 3.84 dB
Peak/RMS 12.06 dB
Duration 10 minutes 51 seconds
MSC mapping 4QAM
MSC lower protection 1 (high)
11User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
MSC higher protection 1 (high)
SDC protection 0 (weak)
Service 3 is not available.
Table 2-6: Services
Available waveform files
DRM settings
Service ID 0xAFFE 0xF 0xFF
Language German German German
Service label Audio 0 HE-AAC Audio 1 HE-AAC Audio 2 HE-AAC
Service content Audio HE-AAC
Program type Pop music Other music Science
Links to AFS1
Service eFM+RDS, D001 eFM+RDS 0xD001 eFM (no service ID)
Schedule None None None
Content Equal Equal Equal
Frequency 96.6 MHz 88.9 MHz 88.9 MHz
Local Information
Country Germany Canada Canada
Service 0 Service 1 Service 2
16.32 kb/s
HPP: 43 bytes
24 kHz
Param. stereo + SBR
Audio HE-AAC
16.32 kb/s
HPP: 43 bytes
24 kHz
Param. stereo + SBR
Audio xHE-AAC
16.32 kb/s
HPP 43 bytes
24 kHz
Param. stereo + SBR
Language of audience English Kakota Balinese
Text
Text headline Text Message Service 0 Text Message Service 1 Text Message Service 2
Text content Munich, Germany
Waveform Library
DRM Mode E
Rohde&Schwarz
Text transmit 4 times 6 times 4 times
DRM Mode E
Waveform Library
Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
2.3.1.4 MSC_4QAM_MSC_LPP_2_MSC_HPP_1_SDC_1.wv
Table 2-7: General settings
Samples 125107200
Peak offset 3.76 dB
DRM Mode E
Waveform Library
Rohde & Schwarz
Broadcast and Media
Division
Munich, Germany
12User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Peak/RMS 11.79 dB
Duration 10 minutes 51 seconds
MSC mapping 4QAM
MSC lower protection 2 (medium)
MSC higher protection 1 (high)
SDC protection 1 (highest)
Table 2-8: Services
Available waveform files
DRM settings
Service ID 0xAFFE 0xF 0xFF 0xAFFF
Language German German English Not specified
Service label Audio 0 HE-AAC Audio 1 HE-AAC Audio 2 HE-AAC Data PRBS
Service content Audio HE-AAC
Program type Pop music Other music Science
Links to AFS1
Service eFM+RDS, D001 eFM+RDS 0xD001 eFM (no service
Schedule None None None
Content Equal Equal Different
Frequency 96.6 MHz 88.9 MHz 87.5 MHz
Service 0 Service 1 Service 2 Service 3
16.32 kb/s
HPP: 43 bytes
24 kHz
Param. stereo +
SBR
Audio HE-AAC
16.32 kb/s
HPP: 43 bytes
24 kHz
Param. stereo +
SBR
Audio HE-AAC
16.32 kb/s
HPP: 43 bytes
24 kHz
Param. stereo +
SBR
ID)
Data PRBS
8.48 kb/s
Synchronized
Low protected:
104 bytes
High protected :
2 bytes
Local Information
Country Germany Canada Canada
Language of audience
Text
Text headline Text Message Ser-
English Dakota Balinese
Text Message Ser-
vice 0
vice 1
Text Message Service 2
13User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Text transmit 4 times 6 times 5 times
DRM Mode E
Waveform Library
Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
2.3.1.5 MSC_4QAM_MSC_LPP_2_MSC_HPP_2_SDC_1.wv
Table 2-9: General settings
Samples 125337600
Peak offset 4.73 dB
Peak/RMS 11.75 dB
Duration 10 minutes 52 seconds
MSC mapping 4QAM
MSC lower protection 2 (medium)
MSC higher protection 2 (medium)
DRM Mode E
Waveform Library
Rohde & Schwarz
Broadcast and
Media Division
Munich, Germany
SDC protection 1 (highest)
Table 2-10: Services
Service ID 0xAFFE 0xF 0xFF 0xAFFF
Language German German English Not specified
Service label Audio 0 HE-AAC Audio 1 HE-AAC Audio 2 HE-AAC Not specified
Service content Audio HE-AAC
Program type Music Other music
Links to AFS1
Service eFM+RDS, D001 eFM+RDS, D001 eFM (no service
Schedule None None None
Service 0 Service 1 Service 2 Service 3
16.32 kb/s
HPP 43 bytes
24 kHz
Param. stereo
+SBR
Audio HE-AAC
16.32 kb/s
HPP 43 bytes
24 kHz
Param. stereo
+SBR
Audio HE-AAC
16.32 kb/s
HPP 43 bytes
24 kHz
Param. stereo +
SBR
ID)
Data PRBS
10.64 kb/s
Synchronized
Low protected:
130 bytes
High protected :
3 bytes
Content Equal Equal Equal
Frequency 96.6 MHz 88.9 MHz 88.9 MHz
14User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Local Information
Country Germany Canada Canada
Language of audience
Text
Text headline Message Service 0 Text Message Ser-
Text content Rohde & Schwarz
Text transmit 4 times 6 times 5 times
English Dakota Balinese
vice 1
DRM Mode E
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Waveform Library
Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
2.3.1.6 MSC_4QAM_MSC_LPP_2_MSC_HPP_3_SDC_1.wv
Table 2-11: General settings
Samples 125337600
Text Message Service 2
DRM Mode E
Waveform Library
Rohde & Schwarz
Broadcast and
Media Division
Munich, Germany
Peak offset 2.38 dB
Peak/RMS 12.82 dB
Duration 10 minutes 52 seconds
MSC mapping 4QAM
MSC lower protection 2 (medium)
MSC higher protection 3 (weak)
SDC protection 1 (highest)
Service 3 is not available.
Table 2-12: Services
Service ID 0xAFFE 0x422 0x423
Language German German Not specified
Service label Audio 0 HE-AAC Label audio 1 AAC Data PRBS
Service content Audio HE-AAC
Service 0 Service 1 Service 2
16.32 kb/s
HPP: 43 bytes
24 kHz
Param. stereo no SBR
Audio AAC
32.0 kb/s
HPP 83 bytes
48 kHz
Mono
Data PRBS
13.36 bit/s
Synchronized
Low protected: 163 bytes
High protected: 4 bytes
Program type Pop music Serious classical --
15User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Links to AFS1
Service eFM+RDS, D001 DAB 0x422
Schedule None None
Content Equal Equal
Frequency 96.6 MHz 5A
Local Information
Country Germany Austria
Language of audience English Not specified
Text
Text headline Text Message Service 0 Text Message Service 1
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Text transmit 4 times 6 times
DRM Mode E
Waveform Library
Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
2.3.1.7 MSC_4QAM_MSC_LPP_2_MSC_HPP_3_SDC_0.wv
Table 2-13: General settings
Samples 125337600
Peak offset 3.36 dB
Peak/RMS 12.49 dB
Duration 10 minutes 52 seconds
MSC mapping 4QAM
MSC lower protection 2 (medium)
MSC higher protection 3 (weak)
SDC protection 0 (weak)
Table 2-14: Services
Service ID 0xC1D2 0x467 0x468 0x469
Language Hindi German German German
Service label Audio xHE-AAC Audio xHE-AAC Audio xHE-AAC Data slideshow
Service 0 Service 1 Service 2 Service 3
16User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Service content Audio xHE-AAC
16.32 kb/s
No HHP
32 kHz
Stereo no SBR
Program type Science Varied Other music
Links to AFS1
Service aFM (no Service
ID)
Schedule Schedule 1 Schedule 1 Schedule 1
Content Equal Equal Equal
Frequency 76 MHz 76 MHz 100.0 MHz
Local Information
Country India Pakistan Afghanistan Cameroon
Language of audience
Hindi Urdu Artificial language Not specified
Audio xHE-AAC
14.96 kb/s
No HPP
32 kHz
Stereo no SBR
aFM+PI 0x467 DRM+
Audio xHE-AAC
14.96 kb/s
No HHP
24 kHz
Stereo no SBR
Packed data
10.96 kb/s
Low protected:
155 bytes
High protected:
5 bytes
MOT slideshow
10.96 kb/s
Text
Text headline Text Message Ser-
vice 0
Text content Company
Rohde&Schwarz
Munich, Germany
DRM Mode E
Waveform Library
Text transmit 4 times 11 times
Text Message Ser-
vice 1
Waveform Library
DRM+ ES 201 980
Rohde & Schwarz
Germany, Munich
2.3.1.8 MSC_4QAM_MSC_LPP_3_MSC_HPP_3_SDC_0.wv
Table 2-15: General settings
Samples 125337600
Peak offset 3.09 dB
Peak/RMS 12.60 dB
Duration 10 minutes 52 seconds
MSC mapping 4QAM
Text Message Service 2
PC based DRM
modulator
DRM Mode E
Rohde&Schwarz
GmbH & Co. KG
Germany, Munich
MSC lower protection 3 (weak)
17User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
MSC higher protection 3 (weak)
SDC protection 0 (weak)
Table 2-16: Services
Available waveform files
DRM settings
Service ID 0xC1D2 0x467 0x468 0x469
Language Hindi German German German
Service label Audio0 xHE-AAC Audio1 xHE-AAC Audio2 HE-AAC Data slideshow
Service content Audio xHE-AAC
Program type Science Varied Other music
Links to AFS1
Service aFM (no Service
Schedule Schedule 1 Schedule 1 Schedule 1
Content Different Different Equal
Frequency 76 MHz 76 MHz 100.0 MHz
Service 0 Service 1 Service 2 Service 3
18.08 kb/s
No HHP
32 kHz
Stereo no SBR
ID)
Audio xHE-AAC
22.96 kb/s
No HHP
32 kHz
Stereo no SBR
aFM+PI 0x467 DRM+ 0x486
Audio HE-AAC
16.32 kb/s
HHP: 43 bytes
24 kHz
Parm. Stereo +
SBR
Packed data
17.12 kb/s
Low protected:
209 bytes
High protected:
5 bytes
MOT slideshow
17.12 kb/s
Local Information
Country India Pakistan Afghanistan Cameroon
Language of audience
Text
Text headline Text Message Ser-
Text content Company
Text transmit 4 times 11 times
Hindi Urdu Artificial language Not specified
Text Message Service 0
Rohde&Schwarz
Munich, Germany
DRM Mode E
Waveform Library
vice 1
Waveform Library
DRM+ ES 201 980
Rohde & Schwarz
Germany, Munich
Text Message Service 2
PC based DRM
modulator
DRM Mode E
Rohde&Schwarz
GmbH & Co. KG
Germany, Munich
18User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.3.2 16QAM MSC mapping
Describes the files with 16QAM MSC mapping and different protection levels.
2.3.2.1 MSC_16QAM_MSC_LPP_0_MSC_HPP_0_SDC_1.wv
Table 2-17: General settings
Samples 125337600
Peak offset 4.38 dB
Peak/RMS 11.83 dB
Duration 10 minutes 52 seconds
MSC mapping 16QAM
MSC lower protection 0 (highest)
MSC higher protection 0 (highest)
SDC protection 1 (highest)
Available waveform files
DRM settings
Service 2 and 3 are not available.
Table 2-18: Services
Service ID 0xAFFD 0xAFFF
Language Arabic Bengali
Service label xHE-AAC Data PRBS
Service content Audio xHE-AAC,
Program type News
Links to AFS1
Service 1: eFM+RDS, 0xD001
Schedule 1: None
Content 1: Different
Service 0 Service 1
PRBS
41.44 kb/s
No HPP
48 kHz
Stereo no SBR
2: DAB 0xA
2: Schedule 1
2: Different
57.76 kb/s
Synchronized
Low protected: 629 bytes
High protected: 93 bytes
-
-
-
Frequency 1: 96.6 MHz
2: 5A
Local Information
Country Afghanistan
-
19User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Language of audience Afar
Text
Text headline Text Message Service 0
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Text transmit 4 times
2.3.2.2 MSC_16QAM_MSC_LPP_1_MSC_HPP_1_SDC_1.wv
Table 2-19: General settings
Samples 125337600
Peak offset 3.93 dB
Peak/RMS 12.65 dB
Duration 10 minutes 52 seconds
MSC mapping 16QAM
MSC lower protection 1 (high)
MSC higher protection 1 (high)
SDC protection 1 (highest)
Service 1, 2 and 3 are not available.
Table 2-20: Services
Service ID 0xAFFD
Language Chinese
Service label xHE-AAC
Service content Audio xHE-AAC
Program type Current affairs
Links to AFS1
Service eFM+RDS, 0xD001
Service 0
121.44 kb/s
No HPP
48 kHz
Stereo no SBR
Schedule None
Content Different
20User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Frequency 96.6 MHz
Local Information
Country Åland Islands
Language of audience Abkhazian
Text
Text headline Text Message Service 0
Text content Rohde & Schwarz
Text transmit 4 times
2.3.2.3 MSC_16QAM_MSC_LPP_1_MSC_HPP_1_SDC_0.wv
Available waveform files
DRM settings
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Table 2-21: General settings
Samples 125107200
Peak offset 3.68 dB
Peak/RMS 12.79 dB
Duration 10 minutes 51 seconds
MSC mapping 16QAM
MSC lower protection 1 (high)
MSC higher protection 1 (high)
SDC protection 0 (weak)
Table 2-22: Services
Service ID 0xAFFD 0xF 0xFF 0x45A
Language Dutch Hindi German French
Service label Audio 0 HE-AAC Audio 1 HE-AAC Audio 2 xHE-AAC Audio 3 HE-AAC
Service content Audio HE-AAC
Service 0 Service 1 Service 2 Service 3
16.32 kb/s
HPP: 43 bytes
24 kHz
Param. stereo +
SBR
Audio HE-AAC
HE-AAC 4
1.44 kb/s
No HPP
24 kHz
Mono + SBR
Audio xHE-AAC
14.96 kb/s
No HPP
32 kHz
Stereo no SBR
Audio HE-AAC
48.64 kb/s
HPP 30 bytes
24 kHz
Stereo + SBR
Program type Information Education Science Drama
Links to AFS1
21User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Service eFM+RDS, D001 eFM+RDS 0xD001 eFM (no service
ID)
Schedule None None None Schedule 1
Content Different Different Different Equal
Frequency 96.6 MHz 88.9 MHz 88.9 MHz 98.5 MHz
Local Information
Country Albania American Samoa Andorra Angola
Language of audience
Text
Text headline Text Message Ser-
Text content Munich, Germany
Achinese Acoli Adangme Adyghe; Adygei
Text Message Service 0
Waveform Library
DRM Mode E
Rohde&Schwarz
vice 1
Broadcast and
media Division
Rohde & Schwarz
GmbH & Co. KG
Mühldorfstraße 15
81671 Munich
Germany
Text Message Service 2
DRM Mode E
Waveform Library
Rohde & Schwarz
Broadcast and
Media Division
Munich, Germany
DRM+ 0x45B
Text Message Service 3
Test
МУЯФТхХµюЮЫЩэ
Э¯´±‗¾¶§
Text transmit 4 times 6 times 4 times 10 times
2.3.2.4 MSC_16QAM_MSC_LPP_2_MSC_HPP_1_SDC_1.wv
Table 2-23: General settings
Samples 125337600
Peak offset 2.61 dB
Peak/RMS 12.82 dB
Duration 10 minutes 52 seconds
MSC mapping 16QAM
MSC lower protection 2 (medium)
MSC higher protection 1 (high)
SDC protection 1 (highest)
Table 2-24: Services
Service ID 0xAFFD 0xF 0xFF 0xAFFF
Language Javanese Korean Portuguese Not specified
Service 0 Service 1 Service 2 Service 3
Service label Audio 0 HE-AAC Audio 1 xHE-AAC Audio 2 xHE-AAC Data PRBS
22User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Service content Audio HE-AAC
41.44 kb/s
No HPP
24 kHz
Mono + SBR
Program type Serious classical
music
Links to AFS1
Service eFM+RDS, D001 eFM+RDS 0xD001 eFM (no service
Schedule None None None
Content Different Different Different
Frequency 96.6 MHz 88.9 MHz 87.5 MHz
Local Information
Country Anguilla Antarctica Antigua and Bar-
Language of audience
Afro-Asiatic languages
Audio xHE-AAC
30.96 kb/s
No HPP
38.4 kHz
Stereo no SBR
Rock Music Easy listening
Afrihili Afrikaans
Audio xHE-AAC
22.96 kb/s
No HPP
32 kHz
Stereo no SBR
music
ID)
buda
Data PRBS
53.68 kb/s
Synchronized
Low protected:
671 bytes
High protected:
0 bytes
Text
Text headline Text Message Ser-
vice 0
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Text transmit 4 times 6 times 5 times
Text Message Ser-
vice 1
DRM Mode E
Waveform Library
Rohde & Schwarz
GmbH & Co.
KG Munich, Ger-
many
Text Message Service 2
DRM Mode E
Waveform Library
Rohde & Schwarz
Broadcast and
Media Division
Munich, Germany
2.3.2.5 MSC_16QAM_MSC_LPP_2_MSC_HPP_2_SDC_1.wv
Table 2-25: General settings
Samples 125337600
Peak offset 3.51 dB
Peak/RMS 12.94 dB
Duration 10 minutes 52 seconds
MSC mapping 16QAM
MSC lower protection 2 (medium)
23User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
MSC higher protection 2 (medium)
SDC protection 1 (highest)
Table 2-26: Services
Available waveform files
DRM settings
Service ID 0xAFFD 0xF 0xFF 0xAFFF
Language Russian Korean Portuguese Not specified
Service label Audio 0 xHE-AAC Audio 1 HE-AAC Audio 2 HE-AAC Service 3 PRBS
Service content Audio xHE-AAC
Program type Light classical Other music Science
Links to AFS1
Service eFM+RDS, D001 eFM+RDS, D002 eFM (no service
Schedule None None None
Content Different Different Different
Frequency 96.6 MHz 88.9 MHz 87.5 MHz
Service 0 Service 1 Service 2 Service 3
41.44 kb/s
No HPP
48 kHz
Stereo no SBR
Audio HE-AAC
16.32 kb/s
HPP 43 bytes
24 kHz
Param. stereo
+SBR
Audio ScienceHEAAC
16.32 kb/s
HPP 43 bytes
24 kHz
Param. stereo +
SBR
ID)
Data PRBS
74.8 kb/s
Synchronized
Low protected:
935 bytes
High protected:
0 bytes
Local Information
Country Antigua and Bar-
buda
Language of audience
Text
Text headline Text Message Ser-
Text content Rohde & Schwarz
Text transmit 4 times 6 times 4 times
Ainu Dakota Dargwa
vice 0
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Canada Cabo Verde
Text Message Ser-
vice 1
DRM Mode E
Waveform Library
Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Text Message Service 2
DRM Mode E
Waveform Library
Rohde & Schwarz
Broadcast and
Media Division
Munich, Germany
24User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.3.2.6 MSC_16QAM_MSC_LPP_2_MSC_HPP_3_SDC_1.wv
Table 2-27: General settings
Samples 125337600
Peak offset 3.04 dB
Peak/RMS 12.49 dB
Duration 10 minutes 52 seconds
MSC mapping 16QAM
MSC lower protection 2 (medium)
MSC higher protection 3 (weak)
SDC protection 1 (highest)
Table 2-28: Services
Available waveform files
DRM settings
Service ID 0xAFFD 0x3FE 0x3FF 0x400
Language Russian Spanish Arabic Not specified
Service label Audio 0 xHE-AAC Audio 1 xHE-AAC Audio 2 xHE-AAC Data PRBS
Service content Audio xHE-AAC
Program type Business Pop music Science
Links to AFS1
Service aFM (no service
Schedule None None None
Content Different Equal Equal
Frequency 78.6 MHz 5A 5A
Local Information
Service 0 Service 1 Service 2 Service 3
30.96 kb/s
No HPP
38.4 kHz
Stereo no SBR
ID)
Audio xHE-AAC
30.96 kb/s
No HPP
38.4 kHz
Stereo no SBR
DAB+EEC 0x3FE DAB 0x3FF
Audio xHE-AAC
32.4 bit/s
No HPP
38.4 kHz
Stereo no SBR
Data PRBS
54.72 kb/s
Low protected:
684 bytes
High protected:
0 bytes
Country Cayman Islands Central African
Republic
Language of audience
Text
Text headline Text Message Ser-
Land Dayak languages
vice 0
Caddo Basa
Text Message Ser-
vice 1
Chad
Headline Service 2
25User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Text transmit 4 times 4 times 4 times
DRM Mode E
Waveform Library
Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
DRM+ Library
Waveforms
Rohde & Schwarz
2.3.2.7 MSC_16QAM_MSC_LPP_2_MSC_HPP_3_SDC_0.wv
Table 2-29: General settings
Samples 125337600
Peak offset 3.03 dB
Peak/RMS 12.43 dB
Duration 10 minutes 52 seconds
MSC mapping 16QAM
MSC lower protection 2 (medium)
MSC higher protection 3 (weak)
SDC protection 0 (weak)
Table 2-30: Services
Service ID 0xC1D2 0x467 0x468 0x469
Language Hindi Dutch Chinese Bengali
Service label Audio 0 xHE-AAC Audio 1 xHE-AAC Audio 2 HE-AAC Data slideshow
Service content Audio xHE-AAC
Program type Science Varied Other music
Links to AFS1
Service aFM +PI 0xC1D2 aFM (no service
Schedule None Schedule 2 Schedule 1
Service 0 Service 1 Service 2 Service 3
30.96 kb/s
No HPP
38.4 kHz
Stereo no SBR
Audio xHE-AAC
41.44 kb/s
No HPP
48 kHz
Stereo no SBR
ID)
Audio HE-AAC
29.12 kb/s
No HHP
24 kHz
Param. stereo +
SBR
eFM+ECC 0x468
Packed data
48.16 kb b
Low protected: 557
Bytes
High protected:
45 bytes
Packet size:
258 bytes
MOT slideshow
41.28 kb/s
Content Different Different Different
26User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM settings
Frequency 76 MHz 76 MHz 87.5 MHz
Local Information
Country India Pakistan Afghanistan Cameroon
Language of audience
Text
Text headline Text Message Ser-
Text content Company
Text transmit 4 times 11 times
Hindi Urdu Artificial language Not specified
Text Message Service 0
Rohde&Schwarz
Munich, Germany
DRM Mode E
Waveform Library
vice 1
Waveform Library
DRM+ ES 201 980
Rohde & Schwarz
Germany, Munich
Text Message Service 2
PC based DRM
modulator
DRM Mode E
Rohde&Schwarz
GmbH & Co. KG
Germany, Munich
2.3.2.8 MSC_16QAM_MSC_LPP_3_MSC_HPP_3_SDC_0.wv
Table 2-31: General settings
Samples 125337600
Peak offset 3.37 dB
Peak/RMS 12.76 dB
Duration 10 minutes 52 seconds
MSC mapping 16QAM
MSC lower protection 3 (weak)
MSC higher protection 3 (weak)
SDC protection 0 (weak)
Table 2-32: Services
Service ID 0xC1D2 0x467 0x468 0x469
Language French Arabic Chinese German
Service label Service0 xHE-AAC Service1 HE-AAC Service2 HE-AAC Data slideshow
Service 0 Service 1 Service 2 Service 3
27User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
DRM services
Service content Audio xHE-AAC
41.44 kb/s
No HHP
48 kHz
Stereo no SBR
Program type Science Varied Other music
Links to AFS1
Service aFM (no Service
ID)
Schedule Schedule 1 Schedule 1 Schedule 1
Content Different Different Equal
Frequency 76 MHz 76 MHz 100.0 MHz
Local Information
Country India Pakistan Germany Cameroon
Audio HE-AAC
48.64 kb/s
HHP 30 Bytes
24 kHz
Stereo + SBR
aFM+PI 0x467 DRM+ 0x496
Audio HE-AAC
31.2 kb/s
HHP 78 bytes
24 kHz
Stereo + SBR
Packed data
64.72 kb/s
Low protected:
804 bytes
High protected:
5 bytes
Packet size:
258 bytes
MOT slideshow
61.92 kb/s
Language of audience
Text
Text headline Text Message Ser-
Text content Company
Text transmit 4 times 11 times 11 times
Hindi Urdu Artificial language Not specified
vice 0
Rohde&Schwarz
Munich, Germany
DRM Mode E
Waveform Library
2.4 DRM services
All files of this group have DRM settings as follows:
●
MSC mapping: 16QAM
●
MSC lower protection: 2 (medium)
●
MSC higher protection: 2 (medium)
●
SDC protection: 1 (highest)
Text Message Ser-
vice 1
Waveform Library
DRM+ ES 201 980
Rohde & Schwarz
Germany, Munich
Text Message Service 2
PC based DRM
modulator
DRM Mode E
Rohde&Schwarz
GmbH & Co. KG
Germany, Munich
28User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.4.1 Services_1_aac.wv
Table 2-33: General settings
Samples 125337600
Peak offset 3.11 dB
Peak/RMS 12.26 dB
Duration 10 minutes 52 seconds
Service 1, 2 and 3 are not available.
Table 2-34: Services
Available waveform files
DRM services
Service ID 0xABCD
Language Japanese
Service label Sweep 20 Hz 20 kHz
Service content Audio AAC
Program type Science
Links to AFS1
Service DAB data 0x3ED
Schedule None
Content Different
Frequency 5A
Local Information
Country Åland Islands
Language of audience Acoli
Text
Service 0
149.04 kb/s
HHP: 377 bytes
Text headline Headline Service 0
Text content Test wave sweep sine
20 Hz to 20 kHz
Duration 20 s
Text transmit 4 times
29User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.4.2 Services_2_he-aac_xhe-aac.wv
Table 2-35: General settings
Samples 125337600
Peak offset 3.41 dB
Peak/RMS 12.65 dB
Duration 10 minutes 52 seconds
Service 2 and 3 are not available.
Table 2-36: Services
Available waveform files
DRM services
Service ID 0xBCDE 0xBCDF
Language Portuguese Other Language
Service label Audio0 HE-AAC Audio 1 xHE-AAC
Service content Audio HE-AAC
Program type Science Rock music
Links to AFS1
Service eFM+EEC, BCDE
Schedule None
Content Equal
Frequency 87.5 MHz
Local Information
Country Yemen Western Sahara
Service 0 Service 1
Audio xHE-AAC
121.44 kb/s
HPP: 307 bytes
48 kHz
Stereo no SBR
27.6 kb/s
No HPP
38.4 kHz
Stereo no SBR
Language of audience Zande languages Zenaga
Text
Text headline Headline Service 0 Headline Service 1
Text content Mozart
121.44 kbit/s
HE-AAC
48 kHz
Stereo, no SBR
Text transmit 4 times 4 times
Schadstoff Rock
xHE-AAC
28.24 kbit/s
Stereo
30User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.4.3 Services_2_he-aac_aac.wv
Table 2-37: General settings
Samples 125337600
Peak offset 4.10 dB
Peak/RMS 12.42 dB
Duration 10 minutes 52 seconds
Service 2 and 3 are not available.
Table 2-38: Services
Available waveform files
DRM services
Service ID 0xCEEE 0x3FB
Language Russian Korean
Service label Audio 0 HE-AAC Audio AAC
Service content Audio HE-AAC
Program type Light classical Other music
Links to AFS1
Service aFM+Pi, 0xCEEE eFM+RDS, 0x3FB
Schedule Schedule 1 None
Content Different Equal
Frequency 76 MHz 87.5 MHz
Local Information
Country Vietnam Venezuela
Service 0 Service 1
Audio AAC
61.84 kb/s
HPP 157 bytes
48 kHz
Stereo no SBR
87.2 kb/s
HPP 227 bytes
Mono
Language of audience Yupik languages Yoruba
Text
Text headline Text Message Service 0 Sweep 20 Hz 20 kHz
Text content Rohde & Schwarz
GmbH & Co. KG
Munich, Germany
Waveform Library
DRM Mode E
Text transmit 4 times 4 times
Sine sweep
20 Hz to 20 kHz
Duration 20 s
AAC
87.2 kbit/s
HPP = 227 bytes
31User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.4.4 Services_3_he-aac_aac_prbs.wv
Samples 125337600
Peak offset 3.22 dB
Peak/RMS 12.42 dB
Duration 10 minutes 52 seconds
Service 3 is not available.
Table 2-39: Services
Available waveform files
DRM services
Service ID 0x3F1 0x3EA 0x3EB
Language Korean Javanese German
Service label Audio HE-AAC Audio AAC Data PRBS
Service content Audio HE-AAC
Program type Other music Science
Links to AFS1
Service aFM (no service ID) DAB+EEC 0x3EA
Schedule None None
Content Different Equal
Frequency 76 MHz 5A
Local Information
Country Vanuata Uzbekistan
Service 0 Service 1 Service 2
74.48 kb/s
HPP 188 bytes
24 kHz
Stereo + SBR
Audio HE-AAC
37.28 kb/s
HPP 93 bytes
Mono
PRBS
Synchronized
37.28 kb/s
HPP 0 bytes
Language of audience Yiddish Yapese
Text
Text headline Headline Service 0 Headline Service 1
Text content Mozart
HE-AAC
74.48 kbit/s
HPP 188 bytes
24 kHz stereo
Text transmit 4 times 4 times
Sweep audio
20 Hz to 20 kHz
20 seconds
Audio AAC
37.28 kbit/s
HPP 28 bytes
32User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.4.5 Services_3_he-aac_he-aac_prbs.wv
Table 2-40: General Settings
Samples 125337600
Peak offset 2.96 dB
Peak/RMS 12.89 dB
Duration 10 minutes 52 seconds
Service 3 is not available.
Table 2-41: Services
Available waveform files
DRM services
Service ID 0xC111 0x3EA 0x3EB
Language Arabic Javanese Other Language
Service label Audio Sweep HE Audio 1 Rock Data PRBS
Service content Audio HE-AAC
Program type Science Varied
Links to AFS1
Service aFM (no Service ID) eFM (no service ID)
Schedule None None
Content Different Equal
Frequency 76 MHz 87.5 MHz
Local Information
Country Uruguay Tuvalu
Service 0 Service 1 Service 2
61.84 kb/s
HPP 157 bytes
48 kHz
Stereo no SBR
Audio HE-AAC
43.6 kb/s
HPP 113 bytes
24 kHz
Stereo + SBR
Data PRBS
Synchronized
43.6 kb/s
No HHP
Language of audience Yao Xhosa
Text
Text headline Headline Text 0 Headline Service 1
Text content Coding HE-AAC
61.84 kbit/s
HPP 187 bytes
48 kHz
Stereo, no SBR
Text transmit 4 times 8 times
Mozart
HE-AAC
43.6 kbit/s
HPP 113 bytes
24 kHz stereo SBR
33User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
2.4.6 Services_4_xhe-aac_xhe-aac_xhe-aac_xhe-aac.wv
Table 2-42: General settings
Samples 125337600
Peak offset 3.77 dB
Peak/RMS 13.11 dB
Duration 10 minutes 52 seconds
Table 2-43: Services
Available waveform files
DRM services
Service ID 0xA001 0xA002 0xA003 A004
Language Other language Dutch French Hindi
Service label Audio0 xHE-AAC Audio1 xHE-AAC Audio2 xHE-AAC Audio3 xHE-AAC
Service content Audio xHE-AAC
Program type Other music Rock Music Serious classical Varied
Links to AFS1
Service aFM (no service
Schedule None None None None
Content Different Equal Equal Equal
Frequency 76 MHz 6.95 MHz 6.75 MHz 76 MHz
Local Information
Country Turkey Tunisia Trinidad and
Service 0 Service 1 Service 2 Service 3
30.96 kb/s
No HPP
38.4 kHz
Stereo no SBR
ID)
Audio xHE-AAC
27.92 kb/s
No HPP
38.4 kHz
Stereo no SBR
AM+AMSS AM (no service ID) aFM+PI 0xA004
Audio xHE-AAC
41.44 kb/s
No HPP
48 kHz
Stereo no SBR
Tobago
Audio xHE-AAC
27.92 kb/s
No HPP
38.4 kHz
Stereo no SBR
Tonga
Language of audience
Text
Text headline Headline Service 0 Headline Service 1 Headline Service 2
Walloon Sorbian languages Welsh Washo
34User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Available waveform files
EN 303 345 DRM testing
Text content Martin Luther King
(speech)
Coding xHE-AAC
30.96 kbit/s
No HHP
38.4 kHz
Stereo, no SBR
Text transmit 4 times 4 times 4 times 4 times
Schadstoff Rock
Coding xHE-AAC
27.92 kbit/s
No HPP
38.4 kHz
Stereo no SBR
2.5 EN 303 345 DRM testing
The files in this folder are for DRM testing according to EN 303 345-5 v0.0.5. Table 1 in
this standard defines the required parameters.
The proposed test cases are defined for three different frequency bands:
●
LFMF
●
HF
●
VHF
For each frequency band, two signals are required:
●
Wanted signal (1 kHz sine)
●
Unwanted signal (2 kHz sine)
Mozart
Coding xHE-AAC
41.44 kbit/s
No HPP
48 kHz
Stereo no SBR
Schadstoff Rock
Coding xHE-AAC
27.92 kbit/s
No HPP
32.8 kHz
Stereo no SBR
The LFMF band and the HF band use robustness mode B. The VHF band uses robustness mode E.
This waveform library (R&S SMCVB-KV12) contains only DRM test signals that use
robustness mode E. They are described in Chapter 2.5.1, "VHF_wanted.wv",
on page 35 and Chapter 2.5.2, "VHF_unwanted.wv", on page 36.
DRM test signals using robustness mode B are part of the waveform library
R&S SMCVB-KV11 DRM Waveforms (1434.5370.xx).
2.5.1 VHF_wanted.wv
Table 2-44: General settings
Samples 53683200
Peak offset 0 dB
Peak/RMS 12.11 dB
Duration 6 minutes 59 seconds
Table 2-45: Services
Service ID 0x1001
Service 0
35User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Language English
Service label "Sine 1 kHz"
Program type Other Music
Country United Kingdom
Language of audience English
Table 2-46: Audio Parameters
Parameter Service 0
Audio Signal 1 kHz tone, -3 dBFs
Audio Coding AAC
Audio Mode Mono
SBR Disabled
Sampling rate 48 kHz
Bit rate 149040 bps
Available waveform files
EN 303 345 DRM testing
2.5.2 VHF_unwanted.wv
Table 2-47: General settings
Samples 53683200
Peak offset 0 dB
Peak/RMS 12.11 dB
Duration 6 minutes 59 seconds
Table 2-48: Services
Service ID 0x1001
Language English
Service label "Sine 2 kHz"
Program type Other Music
Country United Kingdom
Language of audience English
Table 2-49: Audio Parameters
Service 0
Parameter Service 0
Audio Signal 2 kHz tone, -3 dBFs
Audio Coding AAC
Audio Mode Mono
36User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
SBR Disabled
Sampling rate 48 kHz
Bit rate 149040 bps
Available waveform files
EN 303 345 DRM testing
37User Manual 1179.2777.02 ─ 02
R&S®SMCVB-KV12
Index
A
Application cards ................................................................. 7
Application notes ................................................................. 7
B
Brochures ............................................................................ 6
D
Data sheets ......................................................................... 6
Documentation overview ..................................................... 5
G
Getting started ..................................................................... 5
H
Help ..................................................................................... 6
Index
I
Installation ........................................................................... 5
Instrument help ................................................................... 6
Instrument security procedures ........................................... 6
K
Key features ........................................................................ 5
O
Open source acknowledgment (OSA) ................................. 7
R
Release notes ..................................................................... 7
S
Safety instructions ............................................................... 6
Security procedures ............................................................ 6
Service manual ................................................................... 6
U
User manual ........................................................................ 6
W
Waveform files .....................................................................8
Welcome ............................................................................. 5
What's new .......................................................................... 5
White papers ....................................................................... 7
38User Manual 1179.2777.02 ─ 02
Loading...
