R&S
RT-Z2T
Probe Interface Adapter
Manual
(=J[á2)
1326438302
Version 03
This manual describes the R&S RT-Z2T probe interface adapter (1338.0007.02).
© 2022 Rohde & Schwarz GmbH & Co. KG
Muehldorfstr. 15, 81671 Muenchen, Germany
Phone: +49 89 41 29 - 0
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
TEKTRONIX, TEK, and TEKPROBE are registered trademarks of Tektronix, Inc.
Trade names are trademarks of the owners.
1326.4383.02 | Version 03 | R&S®RT-Z2T
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.
R&S®RT-Z2T is indicated as R&S RT-Z2T.
R&S®RT-Z2T
Product Description
Usage Information
1 Product Description
The R&S RT-Z2T probe interface adapter is a product designed to connect a series of active Tektronix oscilloscope probes with TekProbe BNCTM level II interface
to every R&S oscilloscope that is equipped with the Rohde & Schwarz probe
interface.
The adapter provides power to operate the probe. The R&S oscilloscope is adjusted to the correct settings by selecting the probe from a list of predefined probes
in the probe menu of the oscilloscope.
1.1 Supported Tektronix Probes
The following probes are supported by the R&S RT-Z2T adapter:
●
Single-ended probes: P6205, P6243, P6245, P6241, P6249
●
Current probes: TCP202
●
Differential probes: P6246, P6247, P6248, P6250, P6251
●
High-voltage differential probes: P5205, P5210
●
Electro-optical probes: P6701B, P6703B, P6711, P6713
1.2 Usage Information
The R&S RT-Z2T probe adapter is an add-on probe adapter, indented to be used
at laboratory or test and measurement areas. These areas are used for analysis,
testing and servicing and where equipment is operated by trained personnel.
3Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Risk of injury
Use the accessory carefully to prevent electric shock, personal injury, or
damage. Read and observe the "Basic Safety Instructions" that are delivered as a printed brochure.
Also, read and observe the safety instructions of the oscilloscope the
accessory is connected to.
Device Description
1.3 Deliveries
The R&S RT-Z2T delivery package contains the following items:
●
R&S RT-Z2T probe interface adapter
●
Manual
●
"Basic Safety Instructions" brochure
1.4 Inspecting the Contents
●
Inspect the package for damage.
Keep a damaged package and the cushioning material until the contents have
been checked for completeness and the device has been tested.
If the packaging material shows any signs of stress, notify the carrier and your
Rohde & Schwarz service center. Keep the package and cushioning material
for inspection.
●
Inspect the product.
If there is any damage or defect, or if the R&S RT-Z2T does not operate properly, notify your Rohde & Schwarz service center.
2 Device Description
The R&S probe interface of the R&S RT-Z2T probe interface adapter is attached
to a Rohde & Schwarz oscilloscope.
4Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Figure 2-1: R&S probe interface of the R&S RT-Z2T
1 = Release knob
2 = Rohde & Schwarz probe interface with 7 mm (276 mil) coaxial connector and 6 pogo pins
Device Description
Risk of interface damage
Connect the adapter only to a base unit that has a Rohde & Schwarz probe
interface. Do not connect the adapter to a commercially available BNC
jack, as this connection can damage the interface irreparably. From the outside, the 7 mm coaxial connector of the R&S probe interface looks like a
standard BNC connector. However, it is constructed differently and has a
significantly higher frequency limit.
The Tektronix active probe is connected to the adapter’s TekProbe BNCTM level II
interface. This interface also provides the power for the probe.
5Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Putting into Operation
Figure 2-2: TekProbe BNCTM level II interface of the R&S RT-Z2T
3 Putting into Operation
The R&S RT-Z2T has been designed to withstand a moderate amount of physical
and electrical stress. Treat the adapter with care.
Risk of adapter and instrument damage due to excess power
Voltages above the specified limits of the R&S RT-Z2T probe interface
adapter or the connected R&S oscilloscope can damage the adapter or the
oscilloscope. Do not exceed the lesser of the maximum input voltages
specified for the adapter or the oscilloscope.
If the oscilloscope is set to 50 Ω, input coupling, the maximum input voltage
is usually determined by the oscilloscope. If the oscilloscope is set to 1 MΩ
input coupling, the maximum input voltage is usually determined by the
adapter.
6Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Wrist strap with cord
Ground connection
of operational site
Heel strap
Floor mat
Putting into Operation
Connecting the Adapter to an R&S Oscilloscope
Damage caused by electrostatic discharge
To avoid damage of electronic components, protect the operational site
against electrostatic discharge (ESD).
Wrist strap with cord
Building ground
Floor mat
Heel strap
Ground connection
of operational site
To protect the operational site, use one or both of the following measures:
●
Wrist strap with cord to ground connection
●
Conductive floor mat and heel strap combination
3.1 Connecting the Adapter to an R&S Oscilloscope
The R&S RT-Z2T has been designed for use with R&S oscilloscopes that feature
an R&S probe interface.
A user manual is delivered with the adapter, which describes the usage of the
adapter in detail.
7Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Connecting the Tektronix Probe to the Adapter
► Connect the adapter (1) to the Rohde & Schwarz probe interface of the base
unit (2). The adapter snaps in when connected properly to the port.
► To disconnect, press the release button (3). Pull the adapter away from the
front panel of the base unit.
Putting into Operation
3.2 Connecting the Tektronix Probe to the Adapter
To connect a Tektronix probe to the probe interface of the R&S RT-Z2T adapter:
1. Turn the lever of the probe to the left side in the open position.
2. Connect the BNC connector of the probe to the BNC socket of the R&S RT-
Z2T adapter.
3. Lock the probe by pushing the lever to the right into the closed position.
4. Adjust the oscilloscope settings by choosing the correct predefined probe or
by entering the values for external attenuation, input coupling and display unit
manually.
For a description of the usage of a Tektronix probe, refer to its user manual.
8Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Maintenance and Service
Contacting customer support
4 Maintenance and Service
4.1 Service Strategy
Like all Rohde & Schwarz products, Rohde & Schwarz probes and adapters are
of high quality and require only minimum service and repair. However, if service
or calibration is needed, contact your Rohde & Schwarz service center. Return a
defective product to the Rohde & Schwarz service center for diagnosis and
exchange.
You can return the R&S RT-Z2T probe interface adapter for calibration. The service personnel carry out the required tests.
4.2 Contacting customer support
Technical support – where and when you need it
For quick, expert help with any Rohde & Schwarz product, contact our customer
support center. A team of highly qualified engineers provides support and works
with you to find a solution to your query on any aspect of the operation, programming or applications of Rohde & Schwarz products.
Contact information
Contact our customer support center at www.rohde-schwarz.com/support, or fol-
low this QR code:
Figure 4-1: QR code to the Rohde & Schwarz support page
9Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Maintenance and Service
Cleaning
4.3 Returning for servicing
Use the original packaging to return your R&S RT-Z2T to your Rohde & Schwarzservice center. A list of all service centers is available on:
www.services.rohde-schwarz.com
If you cannot use the original packaging, consider the following:
1. Use a sufficiently sized box.
2. Protect the product from damage and moisture (e.g. with bubble wrap).
3. Use some kind of protective material (e.g. crumpled newspaper) to stabilize
the product inside the box.
4. Seal the box with tape.
5. Address the package to your nearest Rohde & Schwarz service center.
4.4 Cleaning
1. Discharge any static electricity at your hands before cleaning the facing surfaces of the sensor head.
Thus, you ensure that no high voltage caused by static electricity is applied to
the product. Application of a high voltage can damage the internal Hall elements or circuitry. You can attract static electricity to your hands by touching a
nearby metal object.
2. Clean the outside of the product using a soft cloth moistened with either distilled water or isopropyl alcohol. Keep in mind that the casing is not waterproof.
Note: Do not use cleaning agents. Solvents (thinners, acetone), acids and
bases can damage the labeling or plastic parts.
3. Dry the product completely before using it.
10Manual 1326.4383.02 ─ 03
R&S®RT-Z2T
Maintenance and Service
Disposal
4.5 Disposal
Rohde & Schwarz is committed to making careful, ecologically sound use of natural resources and minimizing the environmental footprint of our products. Help us
by disposing of waste in a way that causes minimum environmental impact.
Disposing electrical and electronic equipment
A product that is labeled as follows cannot be disposed of in normal household
waste after it has come to the end of its service life. Even disposal via the municipal collection points for waste electrical and electronic equipment is not permitted.
Figure 4-2: Labeling in line with EU directive WEEE
Rohde & Schwarz has developed a disposal concept for the eco-friendly disposal
or recycling of waste material. As a manufacturer, Rohde & Schwarz completely
fulfills its obligation to take back and dispose of electrical and electronic waste.
Contact your local service representative to dispose of the product.
11Manual 1326.4383.02 ─ 03
