Rohde&Schwarz R&S®SMA100B Getting Started Getting started
®
R&S
SMA100B
RF Signal Generator
Getting Started
(>CäD2)
1419862002
Version 09
This document describes the R&S®SMA100B, stock no. 1419.8888.02 and its
options.
© 2022 Rohde & Schwarz GmbH & Co. KG
Muehldorfstr. 15, 81671 Muenchen, Germany
Phone: +49 89 41 29 - 0
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1419.8620.02 | Version 09 | R&S®SMA100B
The following abbreviations are used throughout this manual: R&S®SMA100B is abbreviated as
R&S SMAB, Linux® is abbreviated as Linux, R&S®VISA is abbreviated as R&S VISA
R&S®SMA100B
Contents
1 Safety and regulatory information....................................... 7
1.1 Safety instructions................................................................................7
1.2 Labels on R&S SMA100B................................................................... 10
1.3 Warning messages in the documentation........................................10
1.4 Korea certification class A................................................................. 11
2 Documentation overview.................................................... 12
2.1 Getting started manual.......................................................................12
2.2 User manuals and help.......................................................................12
Contents
2.3 Service manual....................................................................................12
2.4 Instrument security procedures........................................................ 13
2.5 Printed safety instructions.................................................................13
2.6 Data sheets and brochures................................................................13
2.7 Release notes and open source acknowledgment (OSA)...............13
2.8 Application notes, application cards, white papers, etc................. 14
3 Key features......................................................................... 15
4 Preparing for use................................................................. 16
4.1 Lifting and carrying............................................................................ 16
4.2 Unpacking and checking....................................................................16
4.3 Choosing the operating site.............................................................. 17
4.4 Setting up the R&S SMA100B............................................................17
4.4.1 Placing the R&S SMA100B on a bench top..........................................17
4.4.2 Mounting the R&S SMA100B in a rack................................................. 19
4.5 Considerations for test setup............................................................ 20
4.6 Connecting to power.......................................................................... 21
3Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
4.7 Connecting to LAN............................................................................. 21
4.8 Connecting USB devices................................................................... 22
4.9 Connecting to RF................................................................................ 23
4.10 Connecting to Ref In/Ref Out.............................................................25
4.11 Switching on or off............................................................................. 26
Contents
5 Instrument tour.................................................................... 28
5.1 Front panel tour.................................................................................. 28
5.1.1 Touchscreen..........................................................................................29
5.1.2 Utility keys.............................................................................................30
5.1.3 On/Standby........................................................................................... 31
5.1.4 Function keys........................................................................................31
5.1.5 Keypad..................................................................................................31
5.1.6 Navigation controls............................................................................... 32
5.1.6.1 Rotary knob...........................................................................................32
5.1.6.2 editing keys........................................................................................... 32
5.1.6.3 Navigation keys.....................................................................................33
5.1.7 Display keys..........................................................................................34
5.1.8 SD card slot.......................................................................................... 34
5.1.9 USB connector......................................................................................34
5.1.10 Sensor...................................................................................................34
5.1.11 RF 50 Ω.................................................................................................35
5.1.12 Pulse signal connectors........................................................................ 36
5.1.13 LF modulation connectors.....................................................................36
5.1.14 Clock synthesizer connectors............................................................... 37
5.2 Rear panel tour....................................................................................37
5.2.1 Connectors............................................................................................38
6 Trying out the instrument................................................... 42
4Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
6.1 Generating an unmodulated carrier.................................................. 42
6.2 Generating an RF frequency sweep signal...................................... 46
6.3 Saving and recalling settings............................................................ 48
Contents
7 Instrument control............................................................... 52
7.1 Possible ways to operate the instrument......................................... 52
7.2 Means of manual interaction............................................................. 53
7.3 Understanding the display information............................................ 53
7.3.1 Status bar..............................................................................................54
7.3.2 Tile diagram.......................................................................................... 54
7.3.3 Taskbar................................................................................................. 55
7.3.4 Additional display characteristics.......................................................... 56
7.4 Accessing the functionality............................................................... 58
7.5 Entering data....................................................................................... 59
7.5.1 Entering numeric parameters................................................................59
7.5.2 Entering alphanumeric parameters.......................................................60
7.5.3 Undo and redo actions..........................................................................60
7.6 Getting information and help.............................................................61
7.7 Remote control....................................................................................63
7.8 Remote operation over VNC.............................................................. 63
8 Contacting customer support............................................ 65
Index..................................................................................... 66
5Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Contents
6Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Safety and regulatory information
Safety instructions
1 Safety and regulatory information
The product documentation helps you use the product safely and efficiently. Follow the instructions provided here and in the following chapters.
Intended use
The product is intended for the development, production and verification of electronic components and devices in industrial, administrative, and laboratory environments. Use the product only for its designated purpose. Observe the operating
conditions and performance limits stated in the data sheet.
Where do I find safety information?
Safety information is part of the product documentation. It warns you of potential
dangers and gives instructions on how to prevent personal injury or damage
caused by dangerous situations. Safety information is provided as follows:
●
In Chapter 1.1, "Safety instructions", on page 7. The same information is
provided in many languages as printed "Safety Instructions". The printed
"Safety Instructions" are delivered with the product.
●
Throughout the documentation, safety instructions are provided when you
need to take care during setup or operation.
1.1 Safety instructions
Products from the Rohde & Schwarz group of companies are manufactured
according to the highest technical standards. To use the products safely, follow
the instructions provided here and in the product documentation. Keep the product documentation nearby and offer it to other users.
Use the product only for its intended use and within its performance limits. Intended use and limits are described in the product documentation such as the data
sheet, manuals and the printed "Safety Instructions". If you are unsure about the
appropriate use, contact Rohde & Schwarz customer service.
Using the product requires specialists or specially trained personnel. These users
also need sound knowledge of at least one of the languages in which the user
interfaces and the product documentation are available.
7Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Never open the casing of the product. Only service personnel authorized by
Rohde & Schwarz are allowed to repair the product. If any part of the product is
damaged or broken, stop using the product. Contact Rohde & Schwarz customer
service at http://www.customersupport.rohde-schwarz.com.
Lifting and carrying the product
The maximum weight of the product is provided in the data sheet. To move the
product safely, you can use lifting or transporting equipment such as lift trucks
and forklifts. Follow the instructions provided by the equipment manufacturer.
Choosing the operating site
Only use the product indoors. The product casing is not waterproof. Water that
enters can electrically connect the casing with live parts, which can lead to electric shock, serious personal injury or death if you touch the casing. If
Rohde & Schwarz provides accessories designed for your product, e.g. a carrying
bag, you can use the product outdoors.
Safety and regulatory information
Safety instructions
Unless otherwise specified, you can operate the product up to an altitude of
2000 m above sea level. The product is suitable for pollution degree 2 environments where nonconductive contamination can occur. For more information on
environmental conditions such as ambient temperature and humidity, see the
data sheet.
Setting up the product
Always place the product on a stable, flat and level surface with the bottom of the
product facing down. If the product is designed for different positions, secure the
product so that it cannot fall over.
If the product has foldable feet, always fold the feet completely in or out to ensure
stability. The feet can collapse if they are not folded out completely or if the product is moved without lifting it. The foldable feet are designed to carry the weight of
the product, but not an extra load.
If stacking is possible, keep in mind that a stack of products can fall over and
cause injury.
If you mount products in a rack, ensure that the rack has sufficient load capacity
and stability. Observe the specifications of the rack manufacturer. Always install
the products from the bottom shelf to the top shelf so that the rack stands
securely. Secure the product so that it cannot fall off the rack.
8Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Connecting to power
The product is an overvoltage category II product. Connect the product to a fixed
installation used to supply energy-consuming equipment such as household
appliances and similar loads. Keep in mind that electrically powered products
have risks, such as electric shock, fire, personal injury or even death.
Take the following measures for your safety:
●
Before switching on the product, ensure that the voltage and frequency indicated on the product match the available power source. If the power adapter
does not adjust automatically, set the correct value and check the rating of the
fuse.
●
Only use the power cable delivered with the product. It complies with countryspecific safety requirements. Only insert the plug into an outlet with protective
conductor terminal.
●
Only use intact cables and route them carefully so that they cannot be damaged. Check the power cables regularly to ensure that they are undamaged.
Also ensure that nobody can trip over loose cables.
Safety and regulatory information
Safety instructions
●
If the product needs an external power supply, use the power supply that is
delivered with the product or that is recommended in the product documentation or a power supply that conforms to the country-specific regulations.
●
Only connect the product to a power source with a fuse protection of maximum 20 A.
●
Ensure that you can disconnect the product from the power source at any
time. Pull the power plug to disconnect the product. The power plug must be
easily accessible. If the product is integrated into a system that does not meet
these requirements, provide an easily accessible circuit breaker at the system
level.
Cleaning the product
Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that
the casing is not waterproof. Do not use liquid cleaning agents.
Meaning of safety labels
Safety labels on the product warn against potential hazards.
9Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Safety and regulatory information
Warning messages in the documentation
Potential hazard
Read the product documentation to avoid personal injury or product damage.
Electrical hazard
Indicates live parts. Risk of electric shock, fire, personal injury or even death.
Hot surface
Do not touch. Risk of skin burns. Risk of fire.
Protective conductor terminal
Connect this terminal to a grounded external conductor or to protective ground. This
connection protects you against electric shock if an electric problem occurs.
1.2 Labels on R&S SMA100B
Labels on the casing inform about:
●
Personal safety, see "Connecting to power" on page 9.
●
Product and environment safety, see Table 1-1.
●
Identification of the product, see the serial number on the rear panel.
Table 1-1: Labels regarding R&S SMA100B and environment safety
Labeling in line with EN 50419 for disposal of electrical and electronic equipment after
the product has come to the end of its service life. For more information, see the product user manual, chapter "Disposal".
1.3 Warning messages in the documentation
A warning message points out a risk or danger that you need to be aware of. The
signal word indicates the severity of the safety hazard and how likely it will occur
if you do not follow the safety precautions.
WARNING
Potentially hazardous situation. Could result in death or serious injury if not avoided.
10Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
CAUTION
Potentially hazardous situation. Could result in minor or moderate injury if not
avoided.
NOTICE
Potential risks of damage. Could result in damage to the supported product or to
other property.
Safety and regulatory information
Korea certification class A
1.4 Korea certification class A
이 기기는 업무용(A급) 전자파 적합기기로서 판매자 또는 사용자는 이 점을 주의하
시기 바라며, 가정외의 지역에서 사용하는 것을 목적으로 합니다.
11Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Documentation overview
Service manual
2 Documentation overview
This section provides an overview of the R&S SMA100B user documentation.
Unless specified otherwise, you find the documents on the R&S SMA100B product page at:
www.rohde-schwarz.com/manual/sma100b
2.1 Getting started manual
Introduces the R&S SMA100B and describes how to set up and start working with
the product. Includes basic operations, typical measurement examples, and general information, e.g. safety instructions, etc. A printed version is delivered with
the instrument.
2.2 User manuals and help
Contains the description of all instrument modes and functions. It also provides
an introduction to remote control, a complete description of the remote control
commands with programming examples, and information on maintenance, instrument interfaces and error messages. Includes the contents of the getting started
manual.
The contents of the user manuals are available as help in the R&S SMA100B.
The help offers quick, context-sensitive access to the complete information.
All user manuals are also available for download or for immediate display on the
Internet.
2.3 Service manual
Describes the performance test for checking compliance with rated specifications,
firmware update, troubleshooting, adjustments, installing options and maintenance.
12Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Release notes and open source acknowledgment (OSA)
The service manual is available for registered users on the global
Rohde & Schwarz information system (GLORIS):
https://gloris.rohde-schwarz.com
Documentation overview
2.4 Instrument security procedures
Deals with security issues when working with the R&S SMA100B in secure areas.
It is available for download on the Internet.
2.5 Printed safety instructions
Provides safety information in many languages. The printed document is delivered with the product.
2.6 Data sheets and brochures
The data sheet contains the technical specifications of the R&S SMA100B. It also
lists the options and their order numbers and optional accessories.
The brochure provides an overview of the instrument and deals with the specific
characteristics.
See www.rohde-schwarz.com/brochure-datasheet/sma100b
2.7 Release notes and open source acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of
the used open source software.
13Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Application notes, application cards, white papers, etc.
See www.rohde-schwarz.com/firmware/sma100b
Documentation overview
2.8 Application notes, application cards, white papers, etc.
These documents deal with special applications or background information on
particular topics.
See www.rohde-schwarz.com/application/sma100b
14Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Key features
3 Key features
The R&S SMA100B is a new high-performance signal generator developed to
meet demanding customer requirements. Offering excellent signal characteristic
and straightforward and intuitive operation, the signal generator makes signal
generation fast and easy.
Outstanding key features of the R&S SMA100B are:
●
Frequency range from 8 kHz to up to 20 GHz (overrange 72 GHz)
●
Excellent signal quality
●
Excellent single sideband (SSB) phase noise
●
Nearly no wideband noise
●
Very high output power
●
Low harmonics
●
Unique pulse train generation
●
High-stability reference oscillator
●
Intuitive operation via touchscreen with the tile diagram as key element
For more information, see data sheet.
15Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Unpacking and checking
Preparing for use
4 Preparing for use
Here, you can find basic information about setting up the product for the first time.
4.1 Lifting and carrying
► WARNING! The R&S SMA100B can be heavy, e.g., if fully equipped. Use a
lifting equipment, see also "Lifting and carrying the product" on page 8.
Use the carrying handles at the side for lifting and carrying the
R&S SMA100B.
The handles at the front are only for pushing and pulling the instrument when
mounting in a rack, see Chapter 4.4.2, "Mounting the R&S SMA100B in a
rack", on page 19.
4.2 Unpacking and checking
1. Unpack the R&S SMA100B carefully.
2. Retain the original packing material. Use it to protect the control elements and
connectors when transporting or shipping the R&S SMA100B later.
See also chapter "Transporting" in the user manual.
3. Using the delivery notes, check the equipment for completeness.
4. Check the equipment for damage.
If the delivery is incomplete or equipment is damaged, contact
Rohde & Schwarz.
16Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Setting up the R&S SMA100B
Preparing for use
4.3 Choosing the operating site
Specific operating conditions ensure proper operation and avoid damage to the
product and connected devices. For information on environmental conditions
such as ambient temperature and humidity, see the data sheet.
See also "Choosing the operating site" on page 8.
Electromagnetic compatibility classes
The electromagnetic compatibility (EMC) class indicates where you can operate
the product. The EMC class of the product is given in the data sheet.
●
Class B equipment is suitable for use in:
– Residential environments
– Environments that are directly connected to a low-voltage supply network
that supplies residential buildings
●
Class A equipment is intended for use in industrial environments. It can cause
radio disturbances in residential environments due to possible conducted and
radiated disturbances. It is therefore not suitable for class B environments.
If class A equipment causes radio disturbances, take appropriate measures to
eliminate them.
4.4 Setting up the R&S SMA100B
See also:
●
"Setting up the product" on page 8
●
"Intended use" on page 7
4.4.1 Placing the R&S SMA100B on a bench top
To place the product on a bench top
1. Place the product on a stable, flat and level surface. Ensure that the surface
can support the weight of the product. For information on the weight, see the
data sheet.
17Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Preparing for use
Setting up the R&S SMA100B
2. CAUTION! Foldable feet can collapse. See "Setting up the product"
on page 8.
Always fold the feet completely in or out. With folded-out feet, do not place
anything on top or underneath the product.
3. WARNING! A stack of products can fall over and cause injury. Never stack
more than three products on top of each other. Instead, mount them in a rack.
Stack as follows:
● If the products have foldable feet, fold them in completely.
● It is best if all products have the same dimensions (width and length). If the
products have different dimensions, stack according to size and place the
smallest product on top.
● Do not exceed the permissible total load placed on the product at the bottom of the stack:
– 50 kg when stacking products of identical dimensions (left figure).
– 25 kg when stacking smaller products on top (middle figure).
Left = Stacked correctly, same dimensions
Middle = Stacked correctly, different dimensions
Right = Stacked incorrectly, too many products
4. NOTICE! Overheating can damage the product.
Prevent overheating as follows:
● Keep a minimum distance of 10 cm between the fan openings of the product and any object in the vicinity.
● Do not place the product next to heat-generating equipment such as radiators or other products.
18Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Setting up the R&S SMA100B
Preparing for use
4.4.2 Mounting the R&S SMA100B in a rack
To prepare the rack
1. Observe the requirements and instructions in "Setting up the product"
on page 8.
2. NOTICE! Insufficient airflow can cause overheating and damage the product.
Design and implement an efficient ventilation concept for the rack.
To mount the R&S SMA100B in a rack
1. Use an adapter kit that fits the dimensions of the R&S SMA100B to prepare
the instrument for rack mounting.
a) Order the rack adapter kit designed for the R&S SMA100B. For the order
number, see data sheet.
b) Mount the adapter kit. Follow the assembly instructions provided with the
adapter kit.
2. WARNING! The R&S SMA100B can be heavy, e.g., if fully equipped. Use a
lifting equipment, see also "Lifting and carrying the product" on page 8.
Lift the R&S SMA100B to shelf height.
3. Grab the handles at the front and push the R&S SMA100B onto the shelf until
the rack brackets fit closely to the rack.
4. Tighten all screws at the rack brackets with a tightening torque of 1.2 Nm to
secure the R&S SMA100B in the rack.
To unmount the R&S SMA100B from a rack
1. Loosen the screws at the rack brackets.
2. WARNING! The R&S SMA100B can be heavy, e.g., if fully equipped. Use a
lifting equipment, see also "Lifting and carrying the product" on page 8.
Bring the lifting equipment to shelf height.
3. Remove the R&S SMA100B from the rack.
4. If placing the R&S SMA100B on a bench top again, unmount the adapter kit
from the R&S SMA100B. Follow the instructions provided with the adapter kit.
19Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
Considerations for test setup
Preparing for use
4.5 Considerations for test setup
Cable selection and electromagnetic interference (EMI)
Electromagnetic interference (EMI) can affect the measurement results.
To suppress electromagnetic radiation during operation:
●
Use high-quality shielded cables, especially for the following connector types:
– BNC
Double-shielded BNC cables.
– SMA
Double-shielded SMA cables.
How to: "To connect to Ref In/Ref Out (reference = 1 GHz)" on page 25
– USB
Double-shielded USB cables.
How to: Chapter 4.8, "Connecting USB devices", on page 22.
See also chapter "Measuring USB cable quality" in the user manual.
– LAN
At least CAT6 STP cables.
How to: Chapter 4.7, "Connecting to LAN", on page 21
●
Always terminate open cable ends.
●
Ensure that connected external devices comply with EMC regulations.
Signal input and output levels
Information on signal levels is provided in the data sheet. Keep the signal levels
within the specified ranges to avoid damage to the R&S SMA100B and connected
devices.
Preventing electrostatic discharge (ESD)
Electrostatic discharge is most likely to occur when you connect or disconnect a
DUT.
► NOTICE! Electrostatic discharge can damage the electronic components of
the product and the device under test (DUT).
Ground yourself to prevent electrostatic discharge damage:
a) Use a wrist strap and cord to connect yourself to ground.
20Getting Started 1419.8620.02 ─ 09
R&S®SMA100B
b) Use a conductive floor mat and heel strap combination.
Preparing for use
Connecting to LAN
4.6 Connecting to power
For safety information, see "Connecting to power" on page 9.
1. Plug the AC power cable into the AC power connector on the rear panel of the
instrument. Only use the AC power cable delivered with the R&S SMA100B.
2. Plug the AC power cable into a power outlet with ground contact.
The required ratings are listed next to the AC power connector and in the data
sheet.
4.7 Connecting to LAN
Network environment
Before connecting the product to a local area network (LAN), consider the following:
●
Install the latest firmware to reduce security risks.
●
For internet or remote access, use secured connections if applicable.
●
Ensure that the network settings comply with the security policies of your company. Contact your local system administrator or IT department before connecting your product to your company LAN.
●
When connected to the LAN, the product may potentially be accessed from
the internet, which may be a security risk. For example, attackers might misuse or damage the product.
To connect to LAN
The connector is located on the rear panel.
► Connect the LAN socket via an RJ-45 cable to the LAN.
By default, the R&S SMA100B is configured to use DHCP (dynamic host configuration protocol) and no static IP address is configured.
21Getting Started 1419.8620.02 ─ 09
