Getting Started
This manual describes the following R&S®NGE100B models and options:
●
R&S®NGE102B 2-Channel PSU (5601.3800.02)
●
R&S®NGE103B 3-Channel PSU (5601.3800.03)
●
R&S®NGE-K101 Ethernet Remote Control (5601.2204.03)
●
R&S®NGE-K102 Wireless LAN Remote Control (5601.2210.03)
●
R&S®NGE-K103 Digital Trigger I/O (5601.2227.03)
The contents of this manual correspond to firmware version 1.50 or higher.
The software contained in this product uses several valuable open source software packages. For information, see the "Open Source Acknowledgment" document, which is available for download from the R&S
NGE100B product page at www.rohde-schwarz.com/product/nge100b > "Downloads" > "Firmware".
Rohde & Schwarz would like to thank the open source community for their valuable contribution to embedded computing.
© 2018 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: +49 89 41 29 - 0
Fax: +49 89 41 29 12 164
Email: info@rohde-schwarz.com
Internet: www.rohde-schwarz.com
Subject to change – Data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
5601.1337.02 | Version 05 | R&S®NGE100B
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g.
R&S®NGE100B is indicated as R&S NGE100B.
1
Safety Instructions
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent
electric shock, fire,
●
●
●
●
Keep the "Basic Safety Instructions" and the product documentation
Riesgo de lesiones y daños en el instrumento
El instrumento se debe usar de manera adecuada para p
descargas eléctricas, incendios, lesiones o daños materiales.
●
●
●
especificaciones técnicas pueden contener condiciones adicionales
●
Instrucciones de seguridad
Sicherheitshinweise
Consignes de sécurité
personal injury or instrument damage.
Do not open the instrument casing.
Read and observe the "Basic Sa fety Instructions" delivered as
printed brochure with the instrument.
Read and observe the safety instructions in the following sections.
Note that the data sheet may specify additional operating conditions.
in a safe place and pass them on to the subsequent users.
No abrir la carcasa del instrumento.
Lea y cumpla las "Instrucciones de seguridad elementales"
suministradas con el instrumento como folleto impreso.
Lea y cumpla las instrucciones de seguridad incluidas en las
siguientes secciones. Se debe tener en cuenta que las
para su uso.
Guarde bien las instrucciones de seguridad elementales, así como
la documentación del producto, y entréguelas a usuarios
posteriores.
revenir
1171.1307.42 - 05
2
Gefahr von Verletzungen und Schäden am Gerät
Betreiben Sie das Gerät immer ordnungsgemäß, um elektrischen
Schlag, Brand, Verletzungen von Personen oder Geräteschäden zu
verhindern.
●
●
●
●
Risque de blessures et d'endommagement de l'appareil
L'ap
les électrocutions, incendies, dommages corporels et matériels.
●
●
●
suivantes. Il ne faut pas oublier que la fiche technique peut indiquer
●
Öffnen Sie das Gerätegehäuse nicht.
Lesen und beachten Sie die "Grundlegenden Sicherheitshinweise",
die als gedruckte Broschüre dem Gerät beiliegen.
Lesen und beachten Sie die Sicherheitshinweise in den folgenden
Abschnitten; möglicherweise enthält das Datenblatt weitere
Hinweise zu speziellen Betriebsbedingungen.
Bewahren Sie die "Grundlegenden Sicher h ei t s hi nweise" und die
Produktdokumentation gut auf und geben Sie diese an weitere
Benutzer des Produkts weiter.
pareil doit être utilisé conformément aux prescriptions afin d'éviter
N'ouvrez pas le boîtier de l'appareil.
Lisez et respectez les "consignes de sécurité fondamentales"
fournies avec l’app ar eil sous forme de brochure imprimée.
Lisez et respectez les instructions de sécurité dans les sections
des conditions d’exploitation supplémentaires.
Gardez les consignes de sécurité fondamentales et la
documentation produit dans un lieu sûr et transmettez ces
documents aux autres utilisateurs.
1171.1307.42 - 05
R&S®NGE100B
Contents
Contents
1 Preface....................................................................................5
1.1 Documentation Overview.....................................................................5
1.2 Conventions Used in the Documentation...........................................6
1.2.1 Typographical Conventions.....................................................................6
1.2.2 Conventions for Procedure Descriptions................................................ 7
1.2.3 Notes on Screenshots.............................................................................7
1.2.4 Other Conventions.................................................................................. 7
2 Welcome to R&S NGE100B...................................................8
3 Putting into Operation...........................................................9
3.1 Safety................................................................................................... 10
3.2 Intended Operation............................................................................. 12
3.3 Unpacking and Checking the Instrument......................................... 13
3.4 Setting Up the Instrument.................................................................. 14
3.4.1 Bench Operation................................................................................... 14
3.4.2 Rack Mounting...................................................................................... 15
4 Instrument Tour................................................................... 16
4.1 Overview of Controls..........................................................................16
4.1.1 Front Panel........................................................................................... 16
4.1.2 Rear Panel............................................................................................ 18
4.2 Switching On the Instrument............................................................. 19
5 Trying Out the Instrument...................................................21
5.1 Selecting the Channels...................................................................... 21
5.2 Setting the Output Voltage and Current Limit..................................21
5.3 Activating the Channels Output........................................................ 22
3Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
5.4 Storing/Recalling of Instrument Settings......................................... 22
Contents
6 Maintenance......................................................................... 23
Index..................................................................................... 24
4Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Documentation Overview
Preface
1 Preface
1.1 Documentation Overview
This section provides an overview of the R&S NGE100B user documentation.
You find it on the product page at:
http://www.rohde-schwarz.com/product/nge100b > "Downloads"
Getting started manual
Introduces the R&S NGE100B and describes how to set up and start working with
the product. A printed version is included in the delivery.
User manual
The user manual contains the description of all instrument modes and functions.
It also provides an introduction to remote control, a complete description of the
remote control commands with programming examples, and information on maintenance, instrument interfaces and error messages.
Service manual
The service manual is available for registered users on the global Rohde &
Schwarz information system (GLORIS, https://gloris.rohde-schwarz.com).
Basic safety instructions
Contains safety instructions, operating conditions and further important information. The printed document is included in the delivery.
Brochure
The brochure provides an overview of the R&S NGE100B and shows its specific
characteristics. The technical specifications of the R&S NGE100B are included in
the brochure. It also lists the options and their order numbers as well as optional
accessories.
5Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Preface
Conventions Used in the Documentation
Calibration certificate
The calibration certificates of your device are available online. Visit the R&S
NGE100B product page and select the item to download the calibration certificate. You will be forwarded to a Gloris page.
https://gloris.rohde-schwarz.com/calcert.
Enter the device ID of your R&S NGE100B and download the certificate. You can
find the device ID either in the "Setup" menu or on the label on the rear panel.
Release notes and open source acknowledgment (OSA)
The release notes list new features, improvements and known issues of the current firmware version, and describe the firmware installation.
The open source acknowledgment document provides verbatim license texts of
the used open source software.
See http://www.rohde-schwarz.com/product/nge100b > "Downloads" > "Firm-
ware".
Application notes, application cards, white papers, etc.
These documents contain information about possible applications and background information on various topics, see www.rohde-schwarz.com/appnotes.
1.2 Conventions Used in the Documentation
1.2.1 Typographical Conventions
The following text markers are used throughout this documentation:
Convention Description
"Graphical user interface
elements"
[Keys] Key and knob names are enclosed by square brackets.
File names, commands,
program code
All names of graphical user interface elements on the screen,
such as dialog boxes, menus, options, buttons, and softkeys are
enclosed by quotation marks.
File names, commands, coding samples and screen output are
distinguished by their font.
6Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Preface
Conventions Used in the Documentation
Convention Description
Input Input to be entered by the user is displayed in italics.
Links Links that you can click are displayed in blue font.
"References" References to other parts of the documentation are enclosed by
quotation marks.
1.2.2 Conventions for Procedure Descriptions
When operating the instrument, several alternative methods may be available to
perform the same task. In this case, the procedure using the touchscreen is
described. Any elements that can be activated by touching can also be clicked
using an additionally connected mouse. The alternative procedure using the keys
on the instrument or the on-screen keyboard is only described if it deviates from
the standard operating procedures.
The term "select" may refer to any of the described methods, i.e. using a finger on
the touchscreen, a mouse pointer in the display, or a key on the instrument or on
a keyboard.
1.2.3 Notes on Screenshots
When describing the functions of the product, we use sample screenshots. These
screenshots are meant to illustrate as many as possible of the provided functions
and possible interdependencies between parameters. The shown values may not
represent realistic usage scenarios.
The screenshots usually show a fully equipped product, that is: with all options
installed. Thus, some functions shown in the screenshots may not be available in
your particular product configuration.
1.2.4 Other Conventions
Remote commands may include abbreviations to simplify input. In the description
of such commands, all parts that have to be entered are written in capital letters.
Additional text in lowercase characters is for information only.
7Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Welcome to R&S NGE100B
2 Welcome to R&S NGE100B
The two or three-channels power supply series are based on a classical transformer concept with high efficiency electronic pre-regulators and secondary linear
regulators. This concept allows the instrument to achieve the high output power
within a minimum space, high efficiency and lowest residual ripple.
The R&S NGE100B power supply series feature galvanically isolated, floating
overload and short-circuit proof outputs with adjustable power ratings. The outputs can be connected in series or in parallel, thus making high currents and voltages available.
Multi-purpose protection functions are available for each channel which you can
set separately, such as overcurrent protection (FUSE), overvoltage protection
(OVP), overpower protection (OPP) and overtemperature protection (OTP). If
such a limit is reached, the affected output channel is automatically turned off and
an indicator message (FUSE, OVP, OPP or OTP) is displayed. The overcurrent
protection can be linked to other channel (FuseLink function). In this case, all
linked channels are turned off when the set channel reaches its limit.
The EasyArb function allows channel 1 (Ch 1) to have a freely definable voltage
and current sequences with a timeframe as short as 10 ms. It allows you to vary
the voltage or current limit during a test sequence, for example to simulate different charging conditions of a battery. With EasyRamp function, the R&S NGE100B
provides the operating condition to simulate the continuous rise of the supply voltage within a defined timeframe of 10 ms to 10 s.
Four data lines of the digital I/O interface are mutually independent and can be
used as trigger input or trigger output separately. Various trigger conditions (e.g.
fuse tripped, voltage, current, indicator messages) can be used to turn off, on or
invert the output state when the trigger condition is met.
All R&S NGE100B power supply series are equipped with a color LCD display
(320 x 240 pixels resolution). The R&S NGE100B comes with a USB interface
and optional LAN (LXI) and wireless LAN (WLAN) interface.
For models with WLAN, network connection can also be established wirelessly.
This user manual contains a description of the functionalities that the instrument
provides. The latest version is available for download at the product homepage
(http://www.rohde-schwarz.com/product/nge100b).
8Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Putting into Operation
3 Putting into Operation
This chapter describes the steps to set up the R&S NGE100B for the first time.
Risk of injury and instrument damage
The instrument must be used in an appropriate manner to prevent electric
shock, fire, personal injury, or damage.
●
Do not open the instrument casing
●
Read and observe the "Basic Safety Instructions" delivered as a printed
brochure with the instrument. Note that the basic safety instructions also
contain information on operating conditions that prevent damage to the
instrument
In addition, read and observe the safety instructions in the following sections. Notice that the data sheet may specify additional operating conditions.
Risk of radio interference
This instrument is compliant with Class A of CISPR 32. In a residential environment, this instrument may cause radio interference.
9Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Risk of instrument damage during operation
An unsuitable operating site or test setup can cause damage to the instrument and the connected devices. Ensure the following operating conditions
before you switch on the instrument:
●
The instrument is dry and shows no sign of condensation
●
The instrument is positioned as described in Chapter 3.4.1, "Bench
Operation", on page 14
●
The ambient temperature does not exceed the range specified in the
data sheet
●
Signal levels at the input connectors are all within the specified ranges
●
Signal outputs are correctly connected and not overloaded
Putting into Operation
Safety
EMI impact on measurement results
Electromagnetic interference (EMI) may affect the measurement results.
To suppress the generated EMI:
●
Use suitable shielded cables of high quality, for example, LAN cables
●
Note the EMC classification in the data sheet
● Safety..............................................................................................................10
● Intended Operation......................................................................................... 12
● Unpacking and Checking the Instrument........................................................ 13
● Setting Up the Instrument............................................................................... 14
3.1 Safety
This instrument was built in compliance with DIN EN 61010-1 (VDE 0411 part 1),
safety regulations for electrical instruments, control units and Iaboratory equipment. It has been tested and shipped from the plant in safe condition. It is also in
compliance with the regulations of the European standard EN 61010-1 and the
international standard IEC 61010-1.
To maintain this condition and ensure safe operation, you must observe all
instructions and warnings given in this user manual. Casing, chassis and all mea-
10Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
suring ports are connected to a protective earth conductor. The instrument is
designed in compliance with the regulations of protection class I.
For safety reasons, the instrument may only be operated with authorized safety
sockets. The power cord must be plugged in before signal circuits may be connected.
Never use the product if the power cable is damaged. Check regularly that the
power cables are in perfect condition. Choose suitable protective measures and
installation types to ensure that the power cord cannot be damaged and that no
harm is caused by tripping hazards or from electric shock, for instance.
Risk of electric shock
It is prohibited to disconnect the earthed protective connection inside or outside of the instrument!
Putting into Operation
Safety
If it is assumed that a safe operation is no longer possible, the instrument must be
shut down and secured against any unintended operation.
Safe operation can no longer be assumed as follows:
●
Instrument shows visible damage
●
Instrument includes loose parts
●
Instrument no longer functions properly
– After an extended period of storage under unfavorable conditions (e.g. out-
doors or in damp rooms)
– After rough handling during transport (e.g. packaging that does not meet
the minimum requirements by post office, railway or forwarding agency)
Exceeding the Low Voltage Protection
Use insulated wires and not bare wires for the terminal connection.
For the series connection of all output voltages, it is possible to exceed the
low voltage protection of 42 V. Please note that in this case any contact with
live components is life-threatening. It is assumed that only qualified and
trained personnel service the power supplies and the connected loads.
11Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Prior to switching on the product, it must be ensured that the nominal voltage setting on the product matches the nominal voltage of the AC supply network. If it is
necessary to set a different voltage, the power fuse of the product must be
changed accordingly.
Putting into Operation
Intended Operation
3.2 Intended Operation
The instrument is intended only for use by personnel familiar with the potential
risks of measuring electrical quantities.
For safety reasons, the instrument may only be connected to properly installed
safety socket outlets. Separating the ground is prohibited.
The power plug must be inserted before signal circuits may be connected.
Use only the power cord included in the delivery package. See "Delivery
package" on page 14.
Before each measurement, measuring cables must be inspected for damage and replaced if necessary. Damaged or worn components can damage
the instrument or cause injury.
The product may be operated only under the operating conditions and in the positions specified by the manufacturer, without the product's ventilation being
obstructed. If the manufacturer’s specifications are not observed, this can result
in electric shock, fire and/or serious personal injury, and in some cases, death.
Applicable local or national safety regulations and rules for the prevention of accidents must be observed in all work performed.
The instrument is designed for use in the following sectors: Industrial, residential,
business and commercial areas and small businesses.
The instrument is designed for indoor use only. Before each measurement, you
need to verify at a known source if the instrument functions properly.
To disconnect from the mains, the low-heat device socket on the back panel
has to be unplugged.
12Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Putting into Operation
Unpacking and Checking the Instrument
See Table 3-1 for the general data on the instrument specification. For more infor-
mation, see the instrument product brochure (PN: 5214.8748.12).
Table 3-1: General data on instrument specification
Mains nominal voltage AC 115/230 V (±10 %) 50/60 Hz
Power consumption Maximum input power 180 W
Mains fuses 115 V AC IEC 60127-2/5 T 5 A 250 V
Temperature Operating temperature range 0 °C to + 40 °C
Humidity Non-condensing 5 % to 80 %
Display
Rack mount capability ½ 19 " R&S HZC95 option
Dimensions W x H x D 222 mm x 88 mm x 280 mm
Weight R&S NGE102B 4.9 kg (10.80 lb)
230 V AC IEC 60127-2/5 T 2.5 A 250 V
Storage temperature range - 20 °C to + 70 °C
R&S NGE103B 5.0 kg (11.02 lb)
3.5 " (QVGA)
(8.74 in x 3.46 in x 11.02 in)
3.3 Unpacking and Checking the Instrument
Check the equipment for completeness using the delivery note and package contents list for the various items. Check the instrument for any damage and loose
parts. If there is any damage, immediately contact the carrier who delivered the
instrument.
Packing material
Retain the original packing material. If the instrument needs to be transported or shipped at a later date, you can use the material to protect the control
elements and connectors.
13Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Risk of damage during transportation and shipment
Insufficient protection against mechanical and electrostatic effects during
transportation and shipment can damage the instrument.
●
Always ensure that sufficient mechanical and electrostatic protection are
provided
●
When shipping an instrument, the original packaging should be used. If
you do not have the original packaging, use sufficient padding to prevent the instrument from moving around inside the box. Pack the instrument in antistatic wrap to protect it from electrostatic charging
●
Secure the instrument to prevent any movement and other mechanical
effects during transportation
Putting into Operation
Setting Up the Instrument
Delivery package
The package contents contain the following items:
●
R&S NGE100B power supply preloaded with two 230 V fuses
●
Four power cables
●
Two 115 V fuses (replace the preloaded fuses with these fuses depending on
the mains voltage, see Chapter 4.2, "Switching On the Instrument",
on page 19 for more information)
●
One Getting Started manual
●
One document folder containing safety instructions, calibration certificate, KC
and CE certificate
3.4 Setting Up the Instrument
The R&S NGE100B is designed for benchtop and rackmount.
3.4.1 Bench Operation
On a benchtop, the R&S NGE100B can either lie flat or stand on its feet. As
shown in Figure 3-1, feet on the bottom can be folded out to set the instrument in
an inclined position.
14Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Figure 3-1: Operating positions
Positioning of instrument
The instrument must be positioned in a manner that allows the user to disconnect the unit from the mains at any time and without restrictions.
Putting into Operation
Setting Up the Instrument
3.4.2 Rack Mounting
The instrument can be installed in a 19 " rack-mount using a rack adapter kit.
Ambient temperature
Place the R&S NGE100B in an area where the ambient temperature is
within +0 °C to +40 °C. The R&S NGE100B is fan-cooled and must be
installed with sufficient space on the top to ensure a free flow of air.
Required minimum distance: 1 rack unit (RU).
Figure 3-2: Rack mounting
15Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Instrument Tour
Overview of Controls
4 Instrument Tour
This chapter provides an overview of all the controls available in the R&S
NGE100B models and steps to switch on the instrument for the first time.
● Overview of Controls.......................................................................................16
● Switching On the Instrument...........................................................................19
4.1 Overview of Controls
4.1.1 Front Panel
The front panel of the R&S NGE100B is as shown in Figure 4-1. The function
keys and navigation controls are located at the right side of the display. The various connectors are located below the display and function keys.
Figure 4-1: Front panel of R&S NGE100B
1 = Display
2 = Function keys
3 = Rotary knob and arrow keys
16Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Instrument Tour
Overview of Controls
4 = Output channels (three for NGE103B and two for NGE102B)
5 = USB connector
6 = Power key
Display
The display is a color LCD screen. Depending on the instrument type, up to three
channels are shown on the screen. The respective measurement settings and
functions are displayed in the individual channel section. There is a status bar
above the channels to show whether a certain function is enabled, disabled or
operating in a certain mode.
For a detailed description on-screen layout, see section "Screen Layout" in the
User Manual.
Function keys
Function keys are means of input for manual operation of the instrument functions. When a function key is pressed, all the related keys are also illuminated.
For detailed description on function keys, see section "Function Keys" in the User
Manual.
Rotary knob and arrow keys
Rotary knob and arrow keys are means of navigation and adjustment. When
pressed or rotated, they perform tasks like navigation around the screen, adjustment of parameter values or confirmation of entries.
For detailed description on rotary knob and arrow keys, see section "Navigation
Controls" in the User Manual.
Output channels
Depending on the instrument type, up to three output channels are available for
output of power to the connected load. They are Ch 1, Ch 2 and Ch 3 (0 V to 32
V/0 A to 3 A).
USB connector
The USB connector is a Type-A connector. You can connect a USB flash drive to
this connector to perform a firmware update. See section "Firmware Update" in
the release notes for the update procedure.
17Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Instrument Tour
Overview of Controls
For screenshot and firmware update, USB flash drive file system supports FAT32
only.
Power key
The Power key switches the instrument on and off.
4.1.2 Rear Panel
Figure 4-2 shows the rear panel of the R&S NGE100B with its connectors.
Figure 4-2: Rear panel of R&S NGE100B
7 = AC inlet with fuse holder
8 = Voltage selector
9 = Ethernet (LAN) connector
10 = USB connector
11 = Digital I/O connector
AC inlet with fuse holder
Main supply cord
Do not use detachable mains supply cord with inadequate rating.
18Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Switching On the Instrument
For safety reasons, the instrument can only be operated with authorized safety
sockets.
The power cable must be plugged in before signal circuits can be connected.
Never use the product if the power cable is damaged. See Chapter 4.2, "Switch-
ing On the Instrument", on page 19 for more information.
Voltage selector
The voltage selector selects the mains voltage between 115 V and 230 V.
Ethernet connector
This connector is used for establishing remote control via SCPI or LXI. See section "Ethernet Setup" in the user manual for more information on the connection
setup.
The Ethernet option NGE-K101 must be installed for this function to be available
in the instrument.
Instrument Tour
USB connector
The USB connector is a Type-B connector for remote control operation via USB
TMC or USB VCP.
Digital I/O connector
The Digital I/O connector is a terminal block for external trigger input or output.
Measurement control can be achieved by means of an external input signal or
using an external output signal to trigger other instruments for some measurements.
The Digital Trigger I/O option (NGE-K103) must be installed for this function to be
available in the instrument.
4.2 Switching On the Instrument
Prior to switching on the instrument, check if the value on the voltage selector
corresponds to the mains voltage (115 V or 230 V). Switch it, if necessary, and
change the power fuse of the instrument accordingly.
19Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Switching On the Instrument
To change the power fuse:
1. Peel off the yellow label sticker on the AC inlet.
2. Pull out the fuse holder which is located directly on top of the socket.
3. Remove the preloaded fuses from the fuse holder.
4. Check the caps of both fuses that you want to change to for their ratings.
There should be written either T5A250V for 115 V or T2.5A250V for 230 V.
The fuse size is 5 x 20 mm.
5. Once verified, insert the fuses into each groove of the fuse holder.
6. Return the fuse holder to its position in the panel.
To switch on the instrument:
1. Connect the power cable to the AC inlet and switch on the mains power.
Instrument Tour
2. Press Power key on the front panel.
The instrument performs a system check, boots the operating system, and
starts the R&S NGE100B firmware.
By default, all output channels are off when the instrument is switched on to
prevent connected loads from being damaged unintentionally.
Instrument settings from memory location M1 and auto saved parameters are
loaded during the instrument startup.
For more information on the store/recall instrument settings, see the "Store
and Recall" chapter in the user manual.
To switch off the instrument, press Power key again.
20Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Setting the Output Voltage and Current Limit
Trying Out the Instrument
5 Trying Out the Instrument
This chapter describes some basic functions that you can perform with the R&S
NGE100B.
5.1 Selecting the Channels
To select a channel, press the corresponding channel key. The key illuminates.
5.2 Setting the Output Voltage and Current Limit
To set the output voltage and current limit via Live-Mode:
1. Long press the rotary knob to enter into editing mode.
The channel 1 voltage is highlighted in blue.
2. Move to the desired parameter via the arrow keys.
3. On the desired parameter, rotate the knob to adjust its value.
Alternatively:
1. Press Voltage or Current key on the front panel.
2. Press the desired channel key to activate the respective voltage or current
limit setting for that channel. The value on the respective channel becomes
editable and the digit for adjustment is indicated by a blue cursor.
3. Press the right or left arrow key to move the cursor.
4. Press the up/down arrow key or turn the rotary knob to change the value of
the digit indicated by the cursor. The new value registers immediately.
21Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Storing/Recalling of Instrument Settings
Trying Out the Instrument
5.3 Activating the Channels Output
The output voltages can be switched on or off irregardless of the operating mode
the instrument is in.
To activate the channel output, press Output key on the front panel followed by
the desired channel key or vice versa. The font color of that channel section
changes to green or red depending on the operating mode the instrument is in.
5.4 Storing/Recalling of Instrument Settings
The instrument settings can be stored in the instrument memory by long pressing
Store Recall key and selecting the memory location key (M1 to M5). The previous setting is overwritten.
To retrieve the desired saved settings, press Store Recall key and select the
memory location key (M1 to M5).
22Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Maintenance
6 Maintenance
Before cleaning the instrument, ensure that it has been switched off and power
cable is disconnected.
Clean the outer case of the instrument at regular intervals, using a soft, lint-free
dust cloth.
Instrument damage caused by cleaning agents
Cleaning agents contain substances that may damage the instrument. For
example, cleaning agents that contain a solvent may damage the front
panel labeling, plastic parts, or the display.
Never use cleaning agents such as solvents (thinners, acetone, etc.), acids,
bases, or other substances.
The display may only be cleaned with an appropriate glass cleaner. Rub the display down with a dry, clean and lint-free cloth. Do not allow cleaning fluid to enter
the instrument.
23Getting Started 5601.1337.02 ─ 05
R&S®NGE100B
Index
Index
A
Application cards ....................................... 6
Application notes ....................................... 6
B
Brochure ....................................................5
C
Calibration Certificate ................................ 6
Controls ................................................... 16
Conventions .............................................. 6
D
Data Sheet ................................................ 5
F
Front Panel
Display ................................................ 16
Function keys ......................................16
Output channels ..................................16
Power key ........................................... 16
Rotary knob and arrow keys ............... 16
USB connector ....................................16
S
Safety instructions ..................................... 5
Service manual ..........................................5
Setting Up the Instrument
Bench Operation .................................14
Rack Mounting ....................................14
Switching On the Instrument ................... 19
T
Trying Out the Instrument
Activating the Channels Output .......... 21
Selecting the Channels .......................21
Setting the Output Voltage and Current
Limit .................................................... 21
Storing/Recalling of Instrument Settings
............................................................ 21
U
Unpacking and checking the instrument . 13
User Manual .............................................. 5
W
White papers ............................................. 6
G
Getting Started .......................................... 5
M
Maintenance ............................................23
O
Open Source Acknowledgment .................6
P
Package contents ....................................13
R
Rear Panel
AC inlet with fuse holder ..................... 18
Digital I/O connector ........................... 18
Ethernet connector ............................. 18
USB connector ....................................18
Voltage selector .................................. 18
Release notes ........................................... 6
24Getting Started 5601.1337.02 ─ 05
Loading...
